P-Dock System®

P-Dock® System

• Smallest Footprint
• Easy Operation
• Accurate Adjustment
• Pre Lock operation
• Fastest setup to various Tester base
• Easiest Z-stack adjustment
• Available for all Tester configuration
• Compatible to all OEM docking.

The P-Dock® system is a highly precise and

functional docking mechanism to be docked
with wafer probers and handlers.
The winning system for future benchmarks!

Turbodynamics Technology has invented the first pneumatic

docking solution with height adjustment and various indexing
positions of the P-Dock --- modules!
Technical data
Dimensions Diameter 112mm x31,5mm Through its modulated design it is possible to integrate this
Weight 0,65 kg per module platform to different footprint pattern of existing platforms.
Required media compressed air With the height adjustment integration it is guaranteed to get
Docking travel 7,5mm fastest setups with this docking system.
Docking force 200 – 2000 N per module
The system itself guarantees best repeatability and yield
Tester performance for your integrations.
Advantest T2000; T5575; T5371; T6673
Credence Kalos; duo; Quartet; D10; D40; Specification
Sapphire S; Shapphire DPI; The P-Dock® system gives the customer the highest
ASL-3000 flexibility to all tester to handler and/or tester to wafer prober
Eagle Test ETS-200; ETS-300; ETS-364; integration. Can be mounted on tester, prober or handler
ETS-600 side.
LTX Fusion CX; Fusion LX;
Fusion MX; The system can be delivered with a Z-axis adjustment of
Nextest Magnum; Maverick 20mm – 50 mm with an accuracy of 0,1mm (resolution of
Teradyne J750; Catalyst; Microflex; Flex; 0,01mm).
Ultraflex; Tiger
Verigy 83000 and 93000 series

Handlers
• Pick and Place handlers
• Gravity Feed handlers
• Strip / Map handlers.
