Computer Interface Trainer (MDA-Win8086)

PROJECT REPORT
ON
Computer Interface Trainer (MDA-Win8086)
SUBMITTED BY
SUPERVISED BY
ROLL NO: 10015406 Md. Morshedul Arefin

REG. NO: 0667 Associate Professor
SESSION: 2009-10 Computer Science and
Engineering
University Of Rajshahi
Department Of Computer Science and Engineering

PROJECT REPORT
ON
Computer Interface Trainer

(MDA-Win8086)
Submitted in partial fulfillment of the requirements for the award of the degree
BACHELOR OF SCIENCE
IN
COMPUTER SCIENCE & ENGINEERING
UNIVERSITY OF RAJSHAHI
Submitted by
Exam Roll : 10015406
Reg No
: 0667
Session
: 2009-10
SUPERVISED BY:
Md. Morshedul Arefin
Associate Professor
Computer Science and
Engineering
Certificate
This is certify the report entitled Computer Interface Trainer (MDA-win8086)

Submitted by (Roll: 10015406, 09085413, and 08245406)
Under my supervision in his own work and has been submitted elsewhere for the award of
B.Sc (Honours) degree to the best of my knowledge and belief.
Signature:
Md. Morshedul Arefin
Associate Professor
Computer Science and Engineering
ACKNOWLEDGEMENT
We con sid er our self ex ception all y fo rtunate that we had indulgent
g u i d e s , l e a r n e d philosophers and caring friends to successfully steer us through
one of the most interesting period of our academic career. Today when our endeavor
has reached its friction, we look back in mute gratitude to one and all without
whose help we are sure this reality would have been a dream.
This work has been possible through the direct and indirect coo p e r a t i o n o f v a r i o u s people of CSE-RU towards whom we wish to express our gratitude.
We are extremely thankful to CSE-RU faculties who provided us challenging opportunity
to work on this project.
Special thanks to Md. Morshedul Arefin (Associate Professor, Computer Science and
Engineering, University Of Rajshahi) under whom we completed this project. He provided us
with all the possible help and advice. Without his guidance this project would have not
reached its completion in such a successful manner.
W e a r e a l s o t h a n k f u l t o a l l m y f r i e n d s for their valuable suggestions.
Abstract
A micro-processor incorporates the functions of a central processing unit (CPU) on a single
integrated circuit.
The first microprocessors used a word size of only 4 bits, so that the transistors of its logic
circuits would fit onto a single part. One or more microprocessors typically serve as the
processing elements of a computer system, embedded system, or handheld device.
From the humble beginning as the drivers for calculators, the continued increase in processing
capacity has led to the dominance of microprocessors over every other form of computer; every
system from the largest mainframes to the smallest handheld computers now uses a
microprocessor at its core.
To learn the different features of microprocessor multiple kits are provided. These trainers are
manufactured using Bare Board Tested Glass Epoxy SMOBC PCBs and the ICs are mounted on
sockets.
Exhaustive Manuals with ample of sample programs are provided with the system. Each trainer
is supplied with built-in power supply.
In computer science, an interface is the point of interaction with software, or computer hardware,
or with peripheral devices such as a computer monitor or a keyboard.
Some computer interfaces such as a touchscreen can send and receive data, while others such as
a mouse, microphone or joystick can only send data.
Index
Acknowledgement
No.
Topics
Page
Chapter[1]: Introduction to MDA 8086 Training Kit
1.1
Introduction
1.2
MDA-8086 Features
Chapter[2]: System configuration

2.1
MDA-Win8086 System configuration
2.2
MDA-8086 Specification
2.3
MDA-8086 Key Functions
2.4
MDA-Win8086 Address Map
2.5
Basic Operations
2.6
Serial Monitor
2.7
How to connect MDA Win8086 to PC
Chapter[3]: About MDA-WinIDE8086

3.1
Steps to execute MDA-WinIDE8086
10
3.2
Execute
13
Chapter[4]: Trainer possible experiment list
4.1
List
14
Chapter[5]: List of completed Experiment

5.1
7-Segment Display
15
5.2
LCD Message Display
21
5.3
LCD- Scroll the message center to right
26
5.4
LCD- Scroll a message right to left
28
5.5
Matrix Scroll top to bottom
30
5.6
Matrix Scroll left to right
34
5.7
Matrix - Display A
36
5.8
Matrix Scroll A left to right
38
5.9
Matrix Scroll A top to bottom
41
5.10
LED display
44
Chapter[6]: What we have Implement
6.1
Matrix Scroll bottom to top
47
6.2
Matrix Scroll right to left
49
6.3
Matrix - Display R
51
6.4
Scroll 'R' from left to center
53
6.5
Scroll 'R' from center to left
57
Chapter[7]: Appendix
7.1
MDA-8086 Memory Circuit
61
7.2
MDA-8086 Connector (CON10) CIRCUIT
62
7.3
8086 Instruction Set Summary
63
7.4
MDA-8086 schematic
64
References & Conclusion
Chapter: One
Introduction to MDA 8086 Training Kit
(1.1) Introduction
MDA-8086 has high performance 64K-byte monitor program. It is designed for
easy function.
After power is on, the monitor begins to work. In addition to all the key function
the monitor has a memory checking routine.
Figure: 16Bit MDA-8086

Processor Board
Page | 1
(1.2) MDA-8086 Features

1. Program debugging function by PC.
2. Software : TURBO-C 2.0 or later, Support Startup Code
3. Program download and trace function
4. Display the register contents
5. Memory contents modification and dump function
6. Various Command function
7. Included stepper motor interface circuit
8. DOT MATRIX unit
9. LCD display unit
10. D/A and A/D converter experiment
11. Sound experiment with Speaker
12. Interrupt experiments
13. Thermistor Sensor
14. Bar LED unit
15. Keyboard experiment
16. External interface connector
17. Display the current BUS status on LED
18. +5V, +12V, -12V S.M.P.S(Free Voltage) Power.
Page | 2
Chapter: Two
System configuration
(2.1) MDA-Win8086 System configuration
FIGURE 1. MDA-Win8086 SYSTEM CONFIGURATION

Page | 3
The function of IC's at Figure 1.

CPU(Central processing unit) :
Using Intel 8086, Using 14.7456.
ROM(Read Only Memory) :
It has program to control user's key input.
LCD display, user's program.
64K Byte, it has data communication program.
Range of ROM Address is F0000H~FFFFFH.
SRAM(Static Random Access Memory) :
Input user's program & data.
Address of memory is 00000H~0FFFFH, totally 64K Byte.
DISPLAY :
Text LCD Module, 16(Characters)2(Lines)
KEYBOARD :
It is used to input machine language.
There are 16 hexadecimal keys and 8 function keys.
SPEAKER :
Sound test.
RS-232C :
Serial communication with IBM compatible PC.
DOT MATRIX LED :
To understand & test the dot matrix structure and principle of display.
It is interfaced to 8255A (PPI).
A/D CONVERTER :
ADC0804 to convert the analog signal to digital signal.
D/A CONVERTER :
DAC0800 (8-bits D/A converter) to convert the digital signal to the analog signal
To control the level meter.
STEPPING MOTOR INTERFACE :
Stepping motor driver circuit is designed.
POWER :
AC 110~220V,
DC +5V 3A, +12V 1A, -12V 0.5A SMPS.
Page | 4
(2.2) MDA-8086 Specification

CPU
Main RAM
Monitor ROM
Display Unit
I/O Port
Serial Port
System Clock
Clock Generator
Interrupt Controller
Timer Controller
Level Meter
Dot Matrix
Software
Key Board
System BUS indicator
Extended Connector
Stepper motor interface
A/D, D/A Converter
Power
Board size
Wood Case
Weight
Page | 5
8086
64KB(62256 x 2)
64KB(27256 x 2)
LCD (16 X 2 Line)
8255A
14.7456MHz
14.7456MHz
8254 (Clock Generator)
8259
8253
HG101A
8 X 8 (2 color)
8086 Assembler
Support C-Language example code
MDA-WinIDE8086 Integration Development
Program
16 Hexadecimal and 10 function keys
LED X 12
System BUS : 62 pins
External interface : 20 pins
Driver T.R X 4
ADC : ADC0804
DAC : DAC0800
- Input : AC 85 ~ 264V
- Output : DC +5V(2A), +12V(1A), 12V(500mA)
310 x 265
100(H) x 300(D) x 430(W)
4.5
(2.3) MDA-8086 Key Functions

MDA-Win8086 has high performance 64K-byte monitor program. It is designed for easy
function. After power is on, the monitor program begins to work. In addition to all the key
function the monitor has a memory checking routine. The following is a simple description of the
key functions.
Figure2: Simple description of the key functions.
(2.4) MDA-Win8086 Address Map

Memory map
ADDRESS
MEMORY
DESCRIPTION
00000H ~ 0FFFFH
RAM
PROGRAM & DATA MEMORY
F0000H ~
FFFFFH
ROM
MONITOR ROM
10000H ~ EFFFFH
Page | 6
USER'S RANGE
I/O address map

ADDRESS
I/O PORT
DESCRIPTION
00H ~ 07H
LCD &
KEYBOARD
LCD Display
00H : INSTRUCTION REGISTER
02H : STATUS REGISTER
04H : DATA REGISTER
KEYBOARD
01H : KEYBOARD REGISTER (Only
read)
01H : KEYBOARD FLAG (Only write)
10H ~ 17H
8259/SPEAKER
8259(Interrupt controller)
10H : COMMAND REGISTER
12H : DATA REGISTER
SPEAKER -> 11H : SPEAKER
08H ~ 0FH
8251 / 8253
8251(Using to data communication)

08H : DATA REGISTER
0AH : INSTRUCTION / STATUS
REGISTER
8253(TIMER/COUNTER)
09H : TIMER 0 REGISTER
0BH : TIMER 1 REGISTER
0DH : TIMER 2 REGISTER
0FH : CONTROL REGISTER
18H ~ 1FH
8255A-CS1/
8255A-CS2
8255A-CS1(DOT & ADC

INTERFACE)
18H : A PORT DATA REGISTER
1AH : B PORT DATA REGISTER
1CH : C PORT CONTROL REGISTER
8255-CS2(LED & STEPPING
MOTOR)
19H : A PORT DATA REGISTER
1BH : B PORT DATA REGISTER
1DH : C PORT CONTROL REGISTER
1FH : CONTROL REGISTER
20H ~ 2FH
I/O EXTEND CONNECTOR
30H ~ FFH
USER'S RANGE
Page | 7
(2.5) Basic Operations
On a power-up, following message will be displayed on a LCD.
Figure: 3
RES
Figure: 4
System Reset Key
Whenever RES is pressed, the display becomes one of this two figures.
To select the Machine Code and Serial monitor mode with P1 switch.
Machine Code
Serial monitor
Serial Monitor is the basic monitor program to do data communicate between MDA-8086
and computer.
Page | 8
(2.6) Serial Monitor

Serial monitor is the basic monitor program to do data communicate between MDAWin8086 and your computer.
To select the Machine Code and Serial monitor mode with P1 switch.
Machine Code
Serial monitor
Serial Monitor is the basic monitor program to do data communicate between MDA-8086
and computer.
(2.7) How to connect MDA Win8086 to PC
Connect the MDA-Win8086 Kit to a spare serial port on your PC.
:5
Page | 9
:6
Chapter: Three
About MDA-WinIDE8086
(3.1) Steps to execute MDA-WinIDE8086
STEP1: Click the Start button in the task bar, then click All Programs and MIDAS ENG.
Then click the "MDA_WinIDE8086" program icon, and the "MDA-WinIDE8086" window will
be displayed.
STEP2: Open a source file from the File-Open menu.
Page | 10
STEP3:
In the Files of types, select a source type from the drop-down list, as an assemble file
Select "Led.ASM" file.
Click "Open" button.
STEP4: Start assembling your target application with the "Assemble and Link" button.
STEP5: If there is no error, following window will be displayed.
Page | 11
STEP6: If you click "Yes" button, your source program will be download from PC into the
target.
STEP7: If you click "Run" button, the program will be executed.
STEP8: LED will be shifted.
Page | 12
(3.2) Execute
Run
Click
button or select "Run" from the Run menu.
We can also type 'G' and "Enter" key on Terminal window.
The Run command in the work menu starts execution of the program. The
Program will be executed until it is stopped by pressing RESET KEY.
Trace
Click
button or select "Trace" from the Run menu.
We can also type 'T' and "Enter" key on Terminal window.
The Trace command in the work menu executes one instruction.
Page | 13
Chapter: Four
Trainer possible experiment list
(4.1) List
LED Display Experiment
FND Display Experiment
DAC Experiment
Bar LED Display Experiment
ADC Experiment
PIT&INT Experiment
8253 Interface Experiment
Sound Experiment
8X8 DOT Matrix Display Experiment
Text LCD Display Experiment
Keyboard Interface Experiment
Page | 14
Chapter: Five
List of completed Experiment
(5.1) 7-Segment Display
A seven-segment display (SSD), or seven-segment indicator, is a form of electronic
display device for displaying decimal numerals.
Seven-segment displays are widely used in digital clocks, electronic meters, and other
electronic devices for displaying numerical information.
Composed of seven elements.
Individually on or off, they can be combined to produce simplified representations of the
numerals.
Objective
To get familiar with the seven segment display and its interfacing with 8086
microprocessor using 8255A.
Equipment
PC having Intel microprocessor, MDA-8086 kit.
Introduction
Seven segment is a display which may be either common anode or common cathode.
Which is ON either on 1 or zero but here we use the format ON on zero.
Page | 15
Interfacing of 8255A with 8086:
Page | 16
Algorithm: Digit drive pattern.

Digit drive pattern of a seven segment LED display is simply the different logic
combinations of its terminals a to h in order to display different digits and characters.
The common digit drive patterns (0 to 9) of a seven segment display are shown in the
table below.
Digit
0
1
2
3
4
5
6
7
8
9
Page | 17
a
1
0
1
1
0
1
1
1
1
1
b
1
1
1
1
1
0
0
1
1
1
c
1
1
0
1
1
1
1
1
1
1
d
1
0
1
1
0
1
1
0
1
1
e
1
0
1
0
0
0
1
0
1
0
f
1
0
0
0
1
1
1
0
1
1
g
0
0
1
1
1
1
1
0
1
1
Flow Chart: 7-segment display

Start MPU
Set x <- 0
Write: pins
<- x
Delay
Increment x by 1
X=10?
Page | 18
C Code for 7-segment LED display

#include"mde8086.h"
int data[11] = { 0xc0, 0xf9, 0xa4, 0xb0, 0x99, 0x92, 0x82, 0xf8, 0x80, 0x90, 0x00 };
void wait(long del)
{
while( del-- );
}
void main(void)
{
int *data1;
/* 8255 -1 Initialization */
outportb( PPI1_CR, 0x80 );
outportb( PPI1_B, 0xf0 );
outportb( PPI1_C, 0x00 );
//main loop
do {
data1 = data;
while( *data1 != 0x00 )
{
outportb( PPI1_A, *data1 );
wait(30000);
data1++;
}
}while(1);
}
Page | 19
Explanation
In common-anode 7-Segment LED, logic 0 is required to turn on a segment.
0xc0, =11000000B
0xf9,=11111001B
=00111111(inverse)
=00000110(inverse)
0xa4,=10100100B
0xb0, =10110000B
0x99,=10011001B
=01011011(inverse)
=01001111(inverse)
=01100110(inverse)
0x92,=10010010B
0x82,=10000010B
0xf8, =11111000B
=01101101(inverse)
=01111101(inverse)
=00000111(inverse)
0x80,=10000000B
0x90, =10010000B
=01111111(inverse)
=01101111(inverse)
Page | 20
(5.2) LCD Message Display

Objective
To get familiar with LCD its pin configuration, internal architecture and its interface
with PPI 8255A.
Equipment
LCD
16 CHARACTERS 2 LINE MODULES
1) PHYSICAL DATA
Module size
80.0W 36.0H 9.30D mm
Min. view area
65.6W 13.8D mm
Character construction
5 7 dots
Character size
2.85W 3.8H mm
Character Pitch
3.65 mm
Dot size
0.55W 0.5H mm
Page | 21
2) Pin Connections
INSTRUCTIONS
Page | 22
LCD INTERFACE
The interface of LCD with PPI 8255A is shown in the figure.
Page | 23
Flow Chart: LCD message displays
Page | 24
C Code for LCD message display

#define _LCD
#include
"mde8086.h"
void string( char *str )
{
while( *str )
{
LCD_putch( *str );
str ++;
wait( 10000 );
/* Delay One character */
}
}
void main( void )
{
LCD_init; /* LCD Initial */
string( "Serial monitor !" );
LCD_LN21;
string( "MDA-Win8086 Kit!" );
do {
LCD_DISPOFF;
wait( 20000 );
LCD_DISPON;
wait( 20000 );
} while(1);
}
Page | 25
(5.3) LCD- Scroll the message center to right

Flow Chart
Page | 26
C Code
#define _LCD
#include
"mde8086.h
void main( void )
{
int i;
LCD_init;
do {
LCD_ALLCLR;
LCD_puts( "Serial monitor !" );
LCD_LN21;
LCD_puts( "MDA-Win8086 Kit!" );
for( i = 0; i < 16; i ++ )
{
wait( 15000 );
LCD_RShift;
/* Right shift */
}
} while(1);
}
Page | 27
(5.4). LCD- Scroll a message right to left

Flow Chart
Page | 28
C Code
#define _LCD
#include "mde8086.h"
/* To the LCD Output String ( Delay One Character ) */
void string( char *str )
{
while( *str ) {
LCD_putch( *str );
str ++;
wait( 10000 );
}
}
void main( void )
{
LCD_init;
LCD_Iout( 0x07 )
/* Entry mode define*/
do
{
LCD_Iout( 0x90 ) /* Character Output Position */
string( "MDA-Win8086 Training Kit" );
} while(1);
}
Page | 29
DOT MATRIX LED

(5.5). Matrix Scroll top to bottom
Objective
To get familiar with dot matrix LEDs and their connections.
Equipment
Introduction
The KMD D1288C is 1.26 inch height 3mm diameter and 8 8 dot matrix LED
displays. The KMD D1288C are dual emitting color type of red, green chips are
contained in a dot with milky and white lens color.
Internal Circuit Diagram
Page | 30
DOT-MATRIX LED interface
Page | 31
Flow Chart
Page | 32
C Code
#include
"mde8086.h"
void wait(long del)

{
while( del-- );
}
void main(void)
{
int dot,i;
/* 8255 Initialization */
outportb( PPI2_A, 0xff );
outportb( PPI2_C, 0xff );
do{
dot = 0x7f;
for( i = 0; i != 8; i++ )
{
outportb( PPI2_B, dot );
dot >>= 1;
dot = ( dot | 0x80 );
wait(30000);
}
}while(1);
}
Page | 33
(5.6). Matrix Scroll left to right

Flow Chart
Page | 34
C Code
#include "mde8086.h"
void wait(long del)
{
while( del-- );
}
void main(void)
{
int dot,i;
/* 8255 Initial */
outportb( PPI2_A, 0x00 );
outportb( PPI2_B, 0x00 );
do{
dot = 0x01;
for( i = 0; i != 8; i++ ){
outportb( PPI2_C, dot );
dot <<= 1;
wait(30000);
}
}while(1);
}
Page | 35
(5.7). Matrix - Display A

Flow Chart
Page | 36
C Code
#include
"mde8086.h"
/* Output Font 'A' */

int font[8] = { 0xff, 0xc0, 0xb7, 0x77,
0x77, 0xb7, 0xc0, 0xff };
void wait(long del)
{
while( del-- );
}
void main(void)
{
int *data;
int common, i;
do{
data = font;
common = 0x01;
for( i = 0; i != 8; i++ )
{
outportb( PPI2_C, common );
outportb( PPI2_B, *data );
wait(120);
data++;
common = common << 1;
}
}while(1);
}
Page | 37
(5.8). Matrix Scroll A left to right

Flow Chart
Page | 38
C Code
#include
"mde8086.h"

int font1[8] = { 0xff, 0xff, 0xff, 0xff,
0xff, 0xff, 0xff, 0xff };
int
font2[8] = { 0xc0, 0xff, 0xff, 0xff,

int
font3[8] = { 0xb7, 0xc0, 0xff, 0xff,

int
font4[8] = { 0x77, 0xb7, 0xc0, 0xff,

int
font5[8] = { 0x77, 0x77, 0xb7, 0xc0,

int
font6[8] = { 0xb7, 0x77, 0x77, 0xb7,

0xc0, 0xff, 0xff, 0xff };
int
font7[8] = { 0xc0, 0xb7, 0x77, 0x77,

0xb7, 0xc0, 0xff, 0xff };
int
font8[8] = { 0xff, 0xc0, 0xb7, 0x77,

0x77, 0xb7, 0xc0, 0xff };
void wait(long del)

{
while( del-- );
}
void display( int *data1 )
{
int *data;
int common, i, k;
for( k = 0; k != 20; k++ ){
common = 0x01;
data = data1;
Page | 39
for( i = 0; i != 8; i++ ) {
wait(120);
data++;
}
}
}
void main(void)
{
do{
display(font1);
display(font2);
display(font3);
display(font4);
display(font5);
display(font6);
display(font7);
display(font8);
display(font8);
display(font8);
} while(1);
}
Page | 40
(5.9). Matrix Scroll A top to bottom

Flow Chart
Page | 41
C Code
#include
"mde8086.h"

int font1[8] = { 0xFf, 0x7f, 0xff, 0xff,
0xff, 0xff, 0x7f, 0xff };
int
font2[8] = { 0xff, 0x3f, 0xff, 0xff,

int
font3[8] = { 0xff, 0x1f, 0xff, 0xff,

int
font4[8] = { 0xff, 0x0f, 0x7f, 0x7f,

0x7f, 0x7f, 0x0f, 0xff };
int
font5[8] = { 0xff, 0x07, 0xbf, 0xbf,

0xbf, 0xbf, 0x07, 0xff };
int
font6[8] = { 0xff, 0x03, 0xdf, 0xdf,

0xdf, 0xdf, 0x03, 0xff };
int
font7[8] = { 0xff, 0x81, 0x6f, 0xef,

0xef, 0x6f, 0x81, 0xff };
int
font8[8] = { 0xff, 0xc0, 0xb7, 0x77,

0x77, 0xb7, 0xc0, 0xff };
void wait(long del)

{
while( del-- );
}
{
int *data;
int common, i, k;
for( k = 0; k != 20; k++ ){
common = 0x01;
data = data1;
for( i = 0; i != 8; i++ ) {
Page | 42

wait(120);
data++;
}
}
void main(void)
{
do{
display(font1);
display(font2);
display(font3);
display(font4);
display(font5);
display(font6);
display(font7);
display(font8);
display(font8);
display(font8);
}while(1);
}
Page | 43
8255A INTERFACE (LED)

(5.10). LED display
Objective
Glow of LEDS on the MDA-8086 kit using port B of PPI 8255.
Equipment
Introduction
8255 is a programmable peripheral interface. It is compatible to Intel and other
microprocessors. It has 3 I/O ports named as port A, B, C and has 24 pins for I/O that
are programmable in group of 12 pins, has groups that operate in three distinct modes
of operation.
Interfacing of 8255A with 8086
Page | 44
Flow Chart
Page | 45
C Code
#include
"mde8086.h"
void wait( long del )

{
while( del-- );
}
void main( void )
{
unsigned char led;
outportb( PPI1_B, 0xff );
outportb( PPI1_C, 0X20 );
led = 0xf1;
do {
outportb( PPI1_B, led );
led = led << 1;
if( led & 0x10 )
led = 0xf1;
wait( 10000 );
} while( 1);
}
Page | 46
Chapter: Six
What we have Implement
(6.1). Matrix Scroll bottom to top
Flow Chart
Page | 47
C Code
#include
"mde8086.h"
void wait(long del)

{
while( del-- );
}
void main(void)
{
int dot,i;
/* 8255 Initialization */
outportb( PPI2_C, 0xff );
do{
dot = 0xfe;
for( i = 0; i != 8; i++ )
{
outportb( PPI2_B, dot );
dot <<= 1;
dot = ( dot | 0x01 );
wait(30000);
}
}
}while(1);
Page | 48
(6.2). Matrix Scroll right to left

Flow Chart
Page | 49
C Code
#include
"mde8086.h"
void wait(long del)

{
while( del-- );
}
void main(void)
{
int dot,i;
/* 8255 Initial */
outportb( PPI2_A, 0x00 );
outportb( PPI2_B, 0x00 );
do{
dot = 0x80;
for( i = 0; i != 8; i++ )
{
outportb( PPI2_C, dot );
dot >>= 1;
wait(30000);
}
}while(1);
}
Page | 50
(6.3). Matrix - Display R

Flow Chart
Page | 51
C Code
#include
"mde8086.h"
/* Output Font 'R' */

int font[8] = { 0xff, 0x80, 0x77, 0x77,
0x73, 0xb5, 0xce, 0xff };
void wait(long del)
{
while( del-- );
}
void main(void)
{
int *data;
int common, i;
do{
data = font;
common = 0x01;
for( i = 0; i != 8; i++ ) {
wait(120);
data++;
}
}while(1);
}
Page | 52
(6.4). Scroll 'R' from left to center

Flow Chart
Page | 53
C Code
#include
"mde8086.h"

int
font1[8] = { 0xff, 0xff, 0xff, 0xff,

int
font2[8] = { 0xce, 0xff, 0xff, 0xff,

int
font3[8] = { 0xb5, 0xce, 0xff, 0xff,

int
font4[8] = { 0x73, 0xb5, 0xce, 0xff,

int
font5[8] = { 0x77, 0x73, 0xb5, 0xce,

int
font6[8] = { 0x77, 0x77, 0x73, 0xb5,

0xce, 0xff, 0xff, 0xff };
int
font7[8] = { 0x80, 0x77, 0x77, 0x73,
Page | 54
0xb5, 0xce, 0xff, 0xff };
int
font8[8] = { 0xff, 0x80, 0x77, 0x77,

0x73, 0xb5, 0xce, 0xff };
void wait(long del)

{
while( del-- );
}

{
int
*data;
int
common, i, k;
for( k = 0; k != 20; k++ ){

common = 0x01;
data = data1;
for( i = 0; i != 8; i++ ) {

wait(120);
data++;
Page | 55
}
}
}
void main(void)
{

do{
display(font1);
display(font2);
display(font3);
display(font4);
display(font5);
display(font6);
display(font7);
display(font8);
display(font8);
display(font8);
} while(1);
}
Page | 56
(5). Scroll 'R' from center to left

Flow Chart
Page | 57
C Code
#include
"mde8086.h"

int
font8[8] = { 0xff, 0xff, 0xff, 0xff,

int
font7[8] = { 0xce, 0xff, 0xff, 0xff,

int
font6[8] = { 0xb5, 0xce, 0xff, 0xff,

int
font5[8] = { 0x73, 0xb5, 0xce, 0xff,

int
font4[8] = { 0x77, 0x73, 0xb5, 0xce,

int
font3[8] = { 0x77, 0x77, 0x73, 0xb5,

0xce, 0xff, 0xff, 0xff };
int
font2[8] = { 0x80, 0x77, 0x77, 0x73,
Page | 58
0xb5, 0xce, 0xff, 0xff };
int
font1[8] = { 0xff, 0x80, 0x77, 0x77,

0x73, 0xb5, 0xce, 0xff };
void wait(long del)

{
while( del-- );
}

{
int
*data;
int
common, i, k;
for( k = 0; k != 20; k++ ){

common = 0x01;
data = data1;
for( i = 0; i != 8; i++ ) {

wait(120);
data++;
Page | 59
}
}
}
void main(void)
{

do{
display(font1);
display(font2);
display(font3);
display(font4);
display(font5);
display(font6);
display(font7);
display(font8);
display(font8);
display(font8);
} while(1);
}
Page | 60
Chapter: Seven
Appendix
(7.1) MDA-8086 Memory Circuit
Page | 61
(7.2) MDA-8086 Connector (CON10) CIRCUIT
3. 8086 Pin configuration.
Page | 62
(7.3) 8086 Instruction Set Summary

8086 REGISTER MODEL
Page | 63
(7.4) MDA-8086 schematic
Page | 64
Page | 65
Page | 66
Page | 67
Page | 68
Page | 69
References
Microprocessor Architecture, Programming, and Application with the 8085
-Ramesh Gaonkar
Microprocessor and Interfacing
-D.V Hall
Microcomputer Systems: 8086/8088 Family
-Y. Liu and G.A Gibson
The 8088 and 8086 Microprocessors: Programming, Interfacing, Software, Hardware, and
Applications
- Walter A. Triebel
www.wikipedia.org
www.google.com
www.midaseng.com
Page | 70

Computer Interface Trainer (MDA-Win8086) - Project

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Computer Interface Trainer (MDA-Win8086) - Project

Uploaded by

Copyright:

Available Formats

PROJECT REPORT

ROLL NO: 10015406 Md. Morshedul Arefin

Department Of Computer Science and Engineering

Computer Interface Trainer

This is certify the report entitled Computer Interface Trainer (MDA-win8086)

Chapter[2]: System configuration

MDA-Win8086 System configuration

MDA-8086 Key Functions

MDA-Win8086 Address Map

How to connect MDA Win8086 to PC

Chapter[3]: About MDA-WinIDE8086

Steps to execute MDA-WinIDE8086

Chapter[5]: List of completed Experiment

LCD Message Display

LCD- Scroll the message center to right

LCD- Scroll a message right to left

Matrix Scroll top to bottom

Matrix Scroll left to right

Matrix Scroll A left to right

Matrix Scroll A top to bottom

Matrix Scroll bottom to top

Matrix Scroll right to left

Scroll 'R' from left to center

Scroll 'R' from center to left

MDA-8086 Memory Circuit

MDA-8086 Connector (CON10) CIRCUIT

8086 Instruction Set Summary

References & Conclusion

Figure: 16Bit MDA-8086

(1.2) MDA-8086 Features

FIGURE 1. MDA-Win8086 SYSTEM CONFIGURATION

The function of IC's at Figure 1.

(2.2) MDA-8086 Specification

(2.3) MDA-8086 Key Functions

Figure2: Simple description of the key functions.

(2.4) MDA-Win8086 Address Map

PROGRAM & DATA MEMORY

I/O address map

8251(Using to data communication)

8255A-CS1(DOT & ADC

I/O EXTEND CONNECTOR

(2.5) Basic Operations

On a power-up, following message will be displayed on a LCD.

System Reset Key

(2.6) Serial Monitor

(2.7) How to connect MDA Win8086 to PC

Connect the MDA-Win8086 Kit to a spare serial port on your PC.

STEP2: Open a source file from the File-Open menu.

STEP5: If there is no error, following window will be displayed.

STEP7: If you click "Run" button, the program will be executed.

STEP8: LED will be shifted.

Interfacing of 8255A with 8086:

Algorithm: Digit drive pattern.

Flow Chart: 7-segment display

C Code for 7-segment LED display

(5.2) LCD Message Display

80.0W 36.0H 9.30D mm

Min. view area

Flow Chart: LCD message displays

C Code for LCD message display

(5.3) LCD- Scroll the message center to right

(5.4). LCD- Scroll a message right to left
