Figma 101

A quick, practical guide on getting

By Marc Andrew

1
If you're a Developer stepping into the world of UI Design and looking for the right

tool to help you create beautiful, functional UIs you really can’t go wrong with

Figma.

It’s browser-based (Windows and Linux users rejoice!) Free! Highly intuitive to use.

Oh and did I mention it was Free?

With this Free Guide I wanted to show you how to gain a better understanding of

this powerful design tool, and get you up to speed on some of its core features.

And as I’ve always said, there’s no better way of learning a new Design Tool than

just diving in and building something. So guess what? That’s what we’ll be doing

together very shortly where I'll be showing you how to create a simple Mobile App

Screen inside of Figma.

Exciting times lie ahead...

2
But I’ve never used a Design Tool be-
fore!
If you've never picked up a Design Tool of any kind, the first time can feel a little

overwhelming. You want to start creating great UIs, but the problem is you don't

know how to actually use the damn tool yet!

Well hopefully the following Guide will help you out, and make you realise what an

intuitive, user-friendly and powerful tool Figma really is.

Let’s get to it...

3
Checking out the Figma interface.

The great thing about the Figma interface is its clean, and intuitive interface.

I’ve used pretty much every design tool there is, and over time a lot of them have

start to feel a little bloated; interface-wise. Figma keeps it tight, and lean and it’s a

joy to use on a daily basis.

Let me give you a super-quick overview of the Figma UI...

Toolbar

4
The Toolbar in Figma contains a variety of tools to help you on your projects, and

what appears in the toolbar will depend on what you've selected on the Canvas.

Here's a little list of Tools you’ll find yourself using the most...

- Move (V)

- Scale (K)

- Frame (A or F)

- Rectangle (R)

- Line (L)

- Arrow (Shift + L)

- Ellipse (O)

- Place Image (Shift + Ctrl + K or Shift + Cmd + K)

- Pen (P)

- Text (T)

- Hand (Press and hold SPACE)

5
Layers Panel

On the left of the screen is where you'll find the Layers Panel.

This gives you easy access to the Layers, Assets and Pages used inside of your cur-

rent Figma file.

Any Frames, Groups or Objects that you add to the Canvas will be visible in the

Layers Panel.

6
Assets Panel

Inside of the Assets Panel is where you’ll have easy access to all of your Compon-

ents.

Components are reusable design elements such as Buttons or Icons, as well as

more complex UI elements such as Menus or Modals.

To speed up your workflow you can quickly select a Component in the Assets Panel

and drag it onto the Canvas to create an Instance.

7
Canvas

The Canvas.

This is where your designs are presented.

Erm. Yeah. Simple as that really.

Moving on...

8
Properties Panel

On the right of the screen is the Properties Panel which allows you to view and ad-

just the properties of any element you currently have selected, as well as access

your current files Prototype settings and view the Code of any selected element.

9
Design Tab

The Design Tab allows you to easily view, add, remove or change the properties of

elements within your design.

The Layer that you currently have selected will determine what settings are avail-

able to you in the Design Tab.

10
Prototype Tab

The Prototype Tab give you access to all of the Prototyping functionality that

Figma has to offer, and enables you to apply Transitions between your Frames,

bringing your static designs to life.

11
Code Tab

The Code Tab in the Properties Panel allows you to see how to present elements of

your design in code, with the following formats available to you...

- CSS

- iOS

- Android

Now on to the good stuff...

12
Designing a Mobile App Screen.

Please Note: Before we dive into this part of the Guide, make sure you download

the required design elements needed to follow along with the tutorial here.

(There’s also the completed file in there for you to reference).

If you've not already, visit https://www.figma.com and Sign Up for a Free account.

13
You can also download the Windows or Mac App from here - https://www.figma.-

com/downloads

With Figma open, create a new document by clicking the on Plus (+) icon at the top

right of the tool.

From the screen that appears, select the iPhone 11 Pro / X option, and click Create

File.

14
 

Then click on the file name in the Toolbar and rename it to ‘Mobile App Screen’.

15
 

16
Post Thumbnail.

Select the Rectangle Tool (R) and draw out a shape around 375px wide by 406px

tall and position it at the top of the Frame. You can also double-check it’s posi-

tioned correctly by checking that it’s set to 0 on the X and Y axis in the Properties

Panel.

17
 

Still in the Properties Panel, click the Independent Corners icon and choose 30 for

the bottom left, and bottom right corner radiuses of the rectangle.

18
 

Now let’s place an image inside of our shape using the aptly titled, and super-help-

ful Place Image function.

So using the shortcut Shift + Ctrl + K or Shift + Cmd + K, choose building.jpg

from the Images folder and then click on the shape to insert the image directly into

it.

19
 

Let's add a gradient overlay to our image to add a little contrast between itself and

the elements that we’ll be placing over it shortly.

From the Fill panel, click the Plus (+) icon to add a new Fill. Make sure the Linear

option is selected.

20
Click on the Fill colour, and then from the fly-out menu insert the following Hex (#)

value: 5D45F9 for the top colour, and 267DEB for the bottom colour. Make sure

both values are set at 50% opacity.

Finally, let’s add a subtle drop shadow to our thumbnail image and add a little

depth to our design.

From the Effects panel click the Plus (+) icon, choose Drop Shadow from the select

menu, and then adjust the following Effect Settings…

- X-0

- Y-4

- Blur - 4

- Color - #303030

21
 - Opacity - 20%

Navigation Bar.

For the Navigation Bar we’re going to insert a couple of Icons. One for navigating

back to the previous screen, and the other for bookmarking the article.

With your Icons folder open simply drag & drop the following icons, one at a time,

onto your Frame…

- arrowback

- bookmark

22
 

With both icons selected, go to the Selection Colors panel, and change the Hex

value to White (FFFFFF).

Holding the Alt key to measure the distance between elements in your design, po-

sition each icon 32px from the left, and right edges of the Frame.

And then with both icons selected, go to the Properties panel and choose Align

Vertical Centers (Alt + V).

23
 

With both icons still selected use Ctrl + G or Cmd + G to Group them, and Ctrl + R

or Cmd + R to Rename. This just keeps things a little more tidy, and organised in

the Layers Panel.

Always rename, and group as you go. It saves a whole lot of time and prevents you

from coming to the end of a design and being faced with a Layers Panel of Rect-

angle 1, Rectangle 2 etc… Not cool!

Finally. Holding Alt, position this new Group 56px from the top of main Frame.

24
 

Notification.

As you can see we added a filled version of the Bookmark icon for the Navigation

Bar as though the user had just bookmarked the post.

Let's add a simple Notification that could be shown to the user when that Book-

mark icon is tapped on. Just a subtle visual cue to show that the action (tapping of

the icon) has been recognised, and completed.

25
Using the Rectangle Tool (R) draw out a shape around 131px x 33px, and then

round the Corners to 24.

From the Fill panel, give it a Hex value of 303030 and reduce its opacity to 60%.

Onto the Effects panel. Let’s give this lil’ Notification a subtle Background Blur to

add both visual interest, and a little more contrast between the image, and the text

that we’ll soon place inside of it.

In the Effects panel click the Plus (+) icon, and from the select menu choose Back-

ground Blur.

26
 

Click on the Effect Settings icon and change the Blur Strength to 6.

Time for some Text, and to tweak some more properties don’t you think?

Using the Text Tool (T), add a new text element and type the word ‘Bookmarked’.

Then from the Text Properties Panel, apply the following...

- Font - Lato

- Weight - Regular

- Size - 14

- Text Align - Center

- Align - Middle

- Fill - #FFFFFF

27
 

With both the Text, and Shape layer selected, use the Alignment options at the top

of the Properties Panel to align the elements both Horizontally and Vertically to one

another.

Use Ctrl + G or Cmd + G to group them and Ctrl + R or Cmd + R to rename.

Then finally use Ctrl + Click or Cmd + Click to select the Notification group, and

Image, and use the Alignment options to align the Notification both horizontally

and vertically inside of the image.

28
 

Avatar + Social Icons.

Let’s get our Avatar, Author Name and Social Share Icons into place shall we?

Select the Ellipse Tool (O) and draw out a shape 48 x 48px. You can also hold

Shift to constrain proportions as you do.

29
 

Using the shortcut Shift + Ctrl + K or Shift + Cmd + K to use the Place Image tool,

select avatar.jpg from the Images folder and place it inside of the shape.

With the shape selected, hop over to the Properties Panel and add the following...

30
Stroke -

- Color - #FFFFFF

- Width - 2

- Position - Inside

Drop Shadow -

- X-0

- Y-2

- Blur - 4

- Color - #303030

- Opacity - 25%

31
Let’s go ahead and drop in a few more Text layers for both the Author Name, and

the date the article was posted…

Using the Text Tool (T) create 2 new Text layers, edit the text accordingly, and then

for the Author Name apply the following properties…

- Font - Lato

- Weight - Bold

- Size - 16

- Text Align - Left

- Fill - #212121

…and for the Date Posted use the following…

- Font - Open Sans

- Weight - Regular

- Size - 12

- Text Align - Left

32
 - Fill - #7D7D7D

Using the trusty Alt shortcut, space the text layers to one another giving them a

little breathing room.

Then use the Alignment tools so they’re both Aligned Left to one another, and then

finally Group (Ctrl + G or Cmd + G) them.

Align this new Group 16px from the right of the Avatar, and then with the new

Group and Avatar selected, press Alt + V to align them vertically to one another.

33
 

Let’s drop in a couple of social share icons…

Like before, simply drag & drop the Instagram and Twitter icons, one at a time, onto

your design, and using a combination of the Alignment tools, and Alt shortcut,

align them vertically to one another (Alt + V), and space them 16px apart.

Group (Ctrl + G or Cmd + G) the icons, and rename (Ctrl + R or Cmd + R).

With your Social Icons Group, Text Layers Group, and Avatar all selected, use Alt +

V to align them vertically to one another.

34
 

Group (Ctrl + G or Cmd + G) all of those elements together, and then position this

new Group 32px from the left, and right edge of the Frame, and 32px from the

bottom of the Image.

35
Title + Content.

Let’s add a lil’ Title and snippet of Content to fill out our design some more…

Using the Text Tool (T), create a simple Title, and then from the Properties Panel ap-

ply the following...

- Font - Lato

- Weight - Bold

- Size - 21

- Line Height - 32

- Text Align - Left

- Align - Top

36
 - Fill - #212121

Then, using the Text Tool (T) once more, create a paragraph of content to appear

below the Title with the following properties...

- Font - Open Sans

- Weight - Regular

- Size - 16

- Line Height - 28

- Text Align - Left

- Align - Top

- Fill - #7D7D7D

37
 

We’ve set the colour of this block of text to be a dark grey (#7D7D7D) so it con-

trasts nicely against the Title, adds a little bit of visual interest, but it’s still accessible

against the White background for users with poor vision.

Hold the Alt key and hover between the 2 Layers to view the distance between

them, and space them 8px apart.

38
Don’t forget to Group (Ctrl + G or Cmd + G) and Rename (Ctrl + R or Cmd + R),

and then space this new group 32px from the left edge of the Frame, and 32px

from the bottom of the Avatar group.

39
Comment Form.

Ok. Let’s wrap things up here, and add a little Comment Form/Field to our design.

Calling upon the Rectangle Tool (R) once more, draw out a shape around 263 x

40px, give it a Corner Radius of 24, and a Fill of #E4E4E4.

Insert a Text layer (T), tweak the wording (ie; Add Comment…), and then add the

following properties…

- Font - Lato

40
 - Weight - Regular

- Size - 16

- Text Align - Left

- Align - Middle

- Fill - #707070

With both the shape, and text layer selected, align them vertically to one another

(Alt + V), and then group (Ctrl + G or Cmd + G) them, and rename (Ctrl + R or

Cmd + R).

Drag & drop the arrowcircleright icon onto your design, and then using the Scale

tool (K), resize it proportionally to 40 x 40px so it shares the same height dimen-

sions as the field we just created.

41
 

Position the icon 8px from the right of the Comment Field, and then with both the

field group and icon selected, align them vertically to one another (Alt + V).

42
Finally. Group the 2 elements (Comment Field, and Icon). And position this new

group 32px from the bottom of the text content, and from the left and right edges

of the Frame.

And that folks is a wrap for our lil’ Mobile App Screen.

43
Hopefully with this short overview of Figma you’ll now feel a little more comfortable

with this powerful, and increasingly popular Design Tool.

I’ve said many times before, just jump in there and start designing, and then design

some more. It’s really the best way to learn a new tool, and improve your design

skills at the same time.

If you have any questions, please get in touch - hello@marcandrew.me

Many thanks

Marc Andrew

https://marcandrew.me

https://twitter.com/@mrcndrw

44
