TECHNICAL DATA SHEET & DRAWING FOR CHAIN LINK FENCE SYSTEMTOTINDIASI2205/2024 TECHNICAL DATA SHEET FOR CHAIN LINK FENCE SYSTEM CHAIN LINK MESH GALVANIZED STEEL GREEN PVC COATED CHAIN LINK MESH MANUFACTURED FROM 3.55 WIRE, TENSILE STRENGTH 28-32 TONS PER SQ. INCH (T'S) THE MESH SIZE 50 x 50 MM, HEIGHT OF THE FENCE FABRIC 1.6MTR. LINE WIRE: ‘4 ROWS OF GALVANIZED STEEL PVC COATED WIRE MADE OUT OF 3.58/4,75NM DIA, TENSILE STRENGTH 2832 TONS PER SQ. INCH (T.S.) STRAINED BETWEEN STRAINER POSTS. ‘STIRRUP WIRE: GALVANIZED STEEL PVC COATED WIRE MADE OUT OF 2.5078 55MM DIA, TENSILE STRENGTH 28-32 TONS PER SQ. INCH (T.S.)) TO SECURE LINE WIRE WITH ALL FENCING POSTS ED TIE WIRE: GALVANIZED STEEL PVC COATED WIRE MADE OUT OF 1.8/2 6NM DIA TENSILE STRENGTH 28 — 32 TONS PER SQ. INCH (T.S.) TO SECURE FENCE TO LINE WIRE, AT EVERY 300MM CENTERS, INTERMEDIATEILINE POSTS: MADE OUT OF CHS 60.3MM DIA x 29NM THICK. TOTAL LENGTH 26MTR. (L7MTR ABOVE FOUNDATION +0.9MTR BURIED INTO THE FOUNDATION) AT EVERY 2.0NTRS CENTERS. ‘STRAINING/PULL POSTS: MADE OUT OF CHS 76.1MM DIA x 4.5MM THICK. TOTAL LENGTH 2.6MTR. (1 7MTR ABOVE FOUNDATION +0.9MTR BURIED INTO THE FOUNDATION)) AT EVERY 50.0MTRS CENTERS, CORNER AND END POST: ‘COMES AT CORNER AREA, CHANGE IN DIRECTION LOCATIONS AND END OF FENCING, CONSTRUCTION OF THIS IS ALSO LIKE ABOVE SAID STRAINER POST. BRACING POSTS: MADE OUT OF CHS 60.3NM DIA x 2. 9NIM THICK, 2 NOS PROVIDED WITH EACH PULL POST AND 1 NOS WITH START & END POST. ‘ACCESSORIES: SHORT WINDERS MADE OUT OF WILD STEEL FLAT BAR 25x3MM TO SECURE LINE WIRES, STRETCHER BARS AND BRACING WITH PULL POST TIGHTENED BY S.S BOLTS & NUTS, A PVC CAP IS FITTED ON TOP OF EACH POST. STRETCHER BAR: MADE OUT OF 25x5MM THICK STEEL FLAT BARS, TOTAL LENGTH 1.60MTR WEAVED THROUGH END MESH ‘AND SECURED TO THE POST AFTER STRETCHING THE FABRIC AT STRAINER POSTS. FINISHING: ‘ALL POSTS AND BRACING ARE HOT DIP GALVANIZED AFTER FABRICATION AND PVC COATED TO 300 MICRONS IN GREEN COLOUR (RAL: 6005). EMM DIA‘TOTINDIAJ2205/2024 TECHNICAL DATA SHEET FOR DOUBLE LEAF SWING GATE (5.0METER WIDE x 1.7MTR HEIGHT) TYPE: DOUBLE LEAF SWING GATE ‘SIZE: BOMTR WIDE x 1.7MTR HEIGHT GATE FRAME: MADE OUT OF CHS 60.3MM DIA x 3. 9MM THICK PIPE. GATE FRAME BRACING: MADE OUT OF CHS 48 3MM DIA x 3.7MM THICK PIPE WITH 10MM DIA TRUSS ROD. GATE POST BRACING: MADE OUT OF CHS 60.3MM DIA x 2.9MM THICK PIPE INFILL: GALVANIZED STEEL PVC COATED CHAIN LINK FENCE FABRIC 3.55/4.76NIM DIA, MESH SIZE 50x50MM FIXED TO GATE FRAME BY USING 25x5MM FLAT BAR, ARRANGED WITH BOLTS & NuTS. GATE POST: MADE OUT OF CHS 168.5MM DIA x 7.1MM THICK PIPE. TOTAL HEIGHT 2.7MTR (1.7MTR ABOVE GROUND +1.0MTR BURIED INTO THE GROUND) FINISHING: ‘ALL GATES FRAME, BRACING AND POSTS ARE HOT DIP GALVANIZED AFTER FABRICATION AND PVC COATED TO 300 MICRON IN GREEN COLOUR (RAL 6008).
