TRUCK-MOUNTED CRANES

ARTICULATED CRANES WITH ULTIMATE PRECISION AND

LIFTING CAPACITY
HC 153

[Link]
 TRUCK MOUNTED CRANES HC 153

TOP SOLUTIONS

1 TPP
RAISE YOUR GAME • Top protection painting - Top quality cataphoresis
treatment and paint process on all crane components

HYVA PERFORMANCE
ensures higher value retention and durability.
• Bolts and nuts protected by Geomet® treatment: 890%
more resistance against corrosion.
1 Top quality protection for harsh environment

2 2 EES
• Extra Extension Speed - The market is always
demanding more speed along with the highest possible
safety. EES is the answer. Through the use of a specially
designed counterbalance valve, this system increases the
extension speed without affecting the crane’s safety.
Save time, precise work, increase efficiency

3 LAS
• Liftrod Articulating System - Joins forged double
linkages on the column and second boom. Its design raises
3 the mechanical advantage of the articulation to provide
consistent force through all working angles.
3 Precision and versatility for all working positions

4 DLD
• Dynamic Load Diagram - After the stabilization,
operator can select the load to be lifted.
Display shows the permitted crane outreach based on
the stability and the load selected.
Crane lifting capacity always under control in all
stabilizer positions

4 5 5 MT
• Magic Touch System - Allows the driver to open the crane
from transport position to working position and back by
6 pushing a single lever on the radio transmitter (or a button
on the display).
Crane Automatic folding/unfolding

6 SDS
• Smooth Descent System - Uses a special counterbalance
valve to reduce boom oscillation, the result for the user is
incredible precision in unloading operations.
Control and precision of the movement

2 3
 TRUCK MOUNTED CRANES HC 153

TECHNICAL SOLUTIONS TO RAISE SMART AND USER-FRIENDLY CONTROLS

RELIABILITY AND SAFETY Control station distinguished by operator comfort and user-friendly
interface derived from dedicated ergonomic and user preference studies

7” color display
Simple and quick access
to all the functions and
Safety first: 425° Slewing Electronics in information
always stable Angle mind: guaranteed
in all conditions
Vertical stabilizers levers
Safe and fast.
Excellent supervision
of stabilizing operation

• More than 40 stabilizer

configurations to ensure safe
• The widest slewing
angle for medium sized
• All electrical components have
IP69K enclosures which offer OUR INNOVATIONS ARE CHANGING THE GAME
positioning of the truck in all cranes. complete protection against Solutions that are the result of smart engineering
ground conditions. • Top efficiency and easy to use. water jet and dust penetration
• Assisted tiltable stabilizers are the providing higher durability and
smart solution. Equipped with less down time. DLD DYNAMIC LOAD DIAGRAM
a gas spring, they provide effortless
movement.
This system, a first on truck-mounted articulated cranes, optimises
stabilization, makes crane operation safer and more efficient and allows
the driver to verify in advance the crane lifting capacity based on truck
Safety Performance Efficiency stability.
A graphic display shows the outreach available for the load selected and
the actual boom slewing position.

MT MAGIC TOUCH

This easy-to-use function improves driver attention, promotes safety, saves

time and increases productivity.
Once the truck is stabilized, a graphic display allows the driver to

H3XL H4XL automatically unfold the crane to a working position and fold the crane
from any position to transport position.
With a 3” TFT display and ergonomic keyboard, A 7” colour display with integrated keyboard gives
the crane operator can select optimum functional the operator a higher level of awareness of the crane
parameters. The system controls the stability with operation and allows selection of the best parameters
2-step beam outreach monitoring and continuous for effective use.
slewing control. The system detects the exact position of the beams
and proportionally calculates the stability.
Wide range Radio selection (Standard)

Hetronic NOT CE Hetronic CE Scanreco Hetronic CE Graphic distributor

Basic

4 5
 TRUCK MOUNTED CRANES HC 153

A TEAM OF SKILLED AND TECHNICAL INFORMATION HC153

CARING SPECIALISTS Dimensions (mm)
Easy installation and smart calibration cranes, A

combined with a high level of service, make Hyva the

E2 E3 E4 E5 E6 E3J2 E4J2
best partner for your business - all over the world
A 2450 2450 2450 2450 2450 2450 2450

EXTRA FUNCTION
B 2330 2330 2330 2330 2330 2450 2500
C 1374 1374 1374 1374 1374 1374 1374

B
D 682 682 682 682 682 682 682
E 160 160 160 160 160 160 160
F 2445 2445 2445 2445 2445 2445 2445
G 4200 4200 4200 4200 4200 4200 4200
H 5400 5400 5400 5400 5400 5400 5400

D
E I 6600 6600 6600 6600 6600 6600 6600
20°
L 825 825 825 895 895 940 940

C
M 930 930 930 975 975 - -

F
L
G
M
H
EXTRA FUNCTION
I

Load diagrams Standard features

E2 Designed in accordance with EN12999
kg 13940* 3010 2060 1570 1160 870 655 Design class: HC1-HD5
m 1,00 4,63 6,58 8,53 10,91 12,96 15,11
- Multifunctional radio remote control
E3 - Sauer Danfoss PVG32
kg 13520* 2870 1940 1455 1160 870 655 485 - Load limit device
m 1,00 4,71 6,66 8,61 10,66 12,96 15,11 17,26
- P-LCS Proportional Lift Control System
E4 - Flanged valves
kg 13150* 2740 1825 1345 1050 870 655 485 395 - Oil tank
m 1,00 4,80 6,75 8,70 10,75 12,80 15,11 17,26 19,36
- Manually extendable stabilizers
E5 - Internal stabilizer pipes
kg 12760* 2615 1720 1245 955 775 655 485 395 - Fixed stabilizer cylinders
m 1,00 4,88 6,83 8,78 10,83 12,88 15,03 17,26 19,36
- Swivel stabilizer foot
E6 - Centralized greasing system
kg 12420* 2505 1625 1155 865 685 565 485 395 - EES Extra Extension Speed
m 1,00 4,96 6,91 8,86 10,91 12,96 15,11 17,26 19,36
- SDS Smooth Descent System
E3J2 - LAS Liftrod Articulating System
kg 615 560 500 350
- H3XL Crane control system (CE)
m 13,35 14,75 16,22 17,80

E4J2
kg 420 380 340 200
m 15,50 16,85 18,35 19,89
*) Theoretical lifting capacity

Recommended truck

ONE CRANE, MANY APPLICATIONS

M.T.T. ton 12 - G.V.W. ton 12

Thanks to the extensive range of accessories and attachments

Technical specifications - EN12999 - HC1-HD5
E2
E3 E4 E5 E6 E3J2 E4J2
Lifting Moment tm 13,9 13,5 13,2 12,8 12,4 9,3 9,5
Slewing Angle ° 425 425 425 425 425 425 425
Building Construction Energy Environment Gardening Working pressure bar 325 325 325 325 325 325 325
Oil tank capacity l 130 130 130 130 130 130 130
Max Oil flow l/min 60 60 60 60 60 60 60
Max lifting height m 12,2 14,4 16,5 18,8 21,0 19,8 22,0
Standard crane weight kg 1820 1935 2040 2140 2230 2275 2395
