Understanding CUCM Traces: End to End

Ayodeji Okanlawon
VIP Alumni

12-08-2015 01:45 PM - edited 03-12-2019 10:20 AM

• 1.1 Introduction
• 2.1 Collecting CUCM logs
• 2.2 CUCM Nodes To Download Logs From
• 3.1 Analysing Logs
• 3.1.1 The Anatomy Of A Trace File
• 3.1.2 References
• 3.1.3 Dive In
• 3.1.5 Task 2: Open Up The Traces In notepad++
• 4.1 Summary

1.1 Introduction
In this document, I will attempt to share one or two things about understanding how
to read and interpret CUCM traces. CUCM is a very complex call control system and
sometimes it is hard to troubleshoot issues without looking at logs. These logs can be
daunting if you don’t know what to look for or how to interpret what you are looking
for. In this document I will be sharing a few tips that have really helped me to
understand this product a little better.

This document is not protocol specific although we will be looking at a sip centric call
flow. There are several protocol specific documentations that have been written and
you should refer to them. I will post links to some of these excellent documents later
on

My aim here is to look at a call end to end and dealing with each protocol that are
involved in the call flow

2.1 Collecting CUCM logs

The first place to start is obviously collecting CUCM logs, hence we need to know how
to collect them. As simple as it sounds, knowing how to collect CUCM logs and which
servers in your cluster to collect the logs from could save you lots of time in
troubleshooting.

So how do we collect these logs. CUCM logs can be collected either via RTMT or the OS
CLI. RTMT is the easiest and most efficient so I thats the one we will focus on.

2.1.1 RTMT

RTMT is the tool we use in downloading logs from CUCM. There are certain settings
that may be needed on the CUCM itself before you can collect meaningful traces.
Please refer to the link below to see what you need to ensure your CUCM servers are
correctly configured. Collecting CUCM logs is mostly the same in most CUCM version
however there are some variations depending on which CUCM version you are using .

• CUCM 8.6.2

https://supportforums.cisco.com/document/126666/collecting-CUCM-traces-CUCM-862-
tac-sr

• CUCM 9.1 and Above:

The link above does apply but there is an additional useful feature here. The little icon
by the save button (set to default) will automatically configure your trace settings for
you and in most cases these settings will be sufficient. The image below shows the set
default icon

Figure 1.1
 • CUCM 10.5 and above:

There is an additional step to configuring your traces in this version. You will need to
tick the tickbox (Trace ON) as shown in the image below

Figure 1.2
2.2 CUCM Nodes To Download Logs From
Knowing which server is your cluster to collect the logs from is usually the most
challenging part of this whole task. In a cluster with multiple CUCM servers, it is
imperative to know which CUCM servers were involved in the particular call you are
interested in. Depending on how your CUCM is configured and the type of call you are
troubleshooting, there may be several servers involved in a single call

• Local Device Node:

The best place to start collecting your logs is the server your phone/device you are
troubleshooting is registered to.

The CUCM server that a device is registered to, will always have at least some of the
logs involved in the call. You must always start here. It is possible that a SDL signal is
sent to another CUCM server in the cluster for further call processing, but you will
always see that from the server the device is registered to. We shall be demonstrating
this in detail further down in this document.

Let us look at an example of a call flow and use this to know which node we need for
logs

In this example, I am troubleshooting a call between two phones registered to two different CUCM
clusters. In this scenario, there are different CUCM involved in this call and we will need to collect
CUCM logs from each and every one of them
 • So we will start from the CUCM the phone is registered to. Once we do this, we will be
able to see which CUCM node on the remote cluster has been selected as the destination
for the sip traffic.
• We then need to collect CUCM logs from that server too.
• It is possible that the node where the phone is registered to is not the node that processed
the sip traffic, hence we will need to collect logs from the node the phone is registered to

The call flow above assumed that we are using run on all active CUCM node feature on
the originating CUCM cluster hence the CUCM node the originating ip phone is
registered to is also the node that processed the sip traffic. However in scenarios
where this is not the case, it is possible that a different CUCM node will processed the
sip traffic and send out the sip invite to the destination node.
At this point I want to quickly touch on the feature "Run on all active cucm node"
and the role it plays in collecting CUCM logs.

2.2.1 Run on all active CM node

One of the many benefits of using this feature is that it aids in troubleshooting. This is
because when this feature is in use, the calling local feature is triggered hence the
node the originating ip phone is registered to is the node that will process th e sip
traffic. This therefore eliminates the need for SDL signalling across the CUCM cluster,
thereby reducing the number of nodes involved in a call, hence reducing the places
where we need to collect CUCM logs. The call flow illustrates what happens when this
feature is not enabled

Figure 1.3

From this call flow, we do not have run on all active CUCM node on both the sip trunk
and Route list. The node the IP hone is registered is also different from the node that
the RL is regsitered to, hence the node that will process the sip traffic will be different
from the node the calling ip phone is registered to. Therefore there is going to be SDL
signal to the CUCM node the RL (for the sip trunk) is registered to. The implication of
this is that we will need to collect CUCM logs from all CUCM involved here increasing
the complexity of the task we face.

If you are interested in knowing more about this feature, I wrote a separate document
on this. Please refer to it here.

https://supportforums.cisco.com/blog/12088366/sip-trunks-and-run-all-active-cm-nodes

As you can see, it’s no small task troubleshooting CUCM related issues. Before we even
begin to look into the trace we need to know the CUCM nodes involved in the call,
which in itself is an art (one that I love very much)
3.1 Analysing Logs
Now that we have our logs, the next crucial set of tasks involves dissecting these logs.
Yes it doesn’t get any easier I am afraid . :)

Tools

The first question I ask myself when analysing logs is, what tool do I use to review
this?

• Translator X (http://translatorx.org/)
• Notepad++
• Wingrep

Two of my favourite’s tools are listed above. The question is “when do I use which”.
The answer to this is it all depends on what I am looking at.

TranslatorX is very efficient when I have a large trace files I need to look at. It’s such a
powerful tool and I can look at multiple trace files in a single view. It also comes into
play when I want to see the sip ladder for a call flow when considering a sip trace. It
gives you an overview of how that call is routed and can be very useful when you want
to quickly identify where something is gone wrong.

Notepad++ is your go to guy, when you need to dissect in detail, when I need to look
at each line of a trace, when I need to look a little closer and a little intimately :)

Most often, I use both tools together. You must get your hands on both and catapult
yourself into another realm of knowledge, passion and ecstasy with CUCM traces :)

3.1.1 The Anatomy Of A Trace File

Now that we have our logs and are armed to go to war with the best of tools, it’s time
to dissect and to perform an anatomy of our trace file

To analyse CUCM logs there are basic things and elements/parameters we need to
know. I will start from the simplest to the more complex.

Call Details.

• Calling number
• Called number
• Time of Call

The most important piece of information you need is identifying that you have the right
logs and this is done by ensuring the call details are present in those logs. I have a
practice of verifying any log I send to TAC is the right log by looking in to ensure my
call details are present. There is nothing so painful as taking your time, gathering logs
and then you get a response back (after 2hrs, 3 hrs, 4hrs), however long it takes the
TAC engineer or the person reviewing the log saying that they can’t find the call in the
log. So the first rule of thumb is ensure your call details are present in the logs

Call Identifier (CI)

In a CUCM log there could be thousands of calls and hence lots of trace files. Therefore
we need to find a way to identify each call. CUCM does this by assigning a unique CI
(call identifier) to each leg of a call. CUCM allocates a unique CI for every
instance/process that it invokes. Eg when a transcoder is needed, CUCM will allocate a
CI for that. When an ANN is needed, CUCM allocates a CI for that. With the CI you can
then trace the transaction for that process.
Within your CUCM logs, you also have each protocol such as SIP, H323, SCCP using
their unique call-ids. Listed below are some of the unique identifiers that some of the
processes on CUCM uses

• CUCM “CI”
• SIP: Call-ID
• H225: “GUID”
• H245: "TtPid"
• Device Registration: "TCP Handle" (Unique identifier for device registered to
CUCM)

Digit Analysis (DA)

Digit analysis is a powerful process on CUCM that has several connotations. Here are
some based on my experience. There may be more

• It happens only on the node that processes the call

• It is used by CUCM to match the calling and called entity
• It tell us the pattern type (Enterprise pattern or Translation pattern)
• It is used by CUCM to know where to route the call

It is a practice of mine to look for digit analysis once I have identified my call. This
would help me to know if I am on the right server that processed the call and where
the call was sent to.
I don’t like talking too much as you must have observed. :) So let all the fun begin.
Let’s get cracking. Let’s put all this together by analysing a trace file..
For this analysis, here is the call flow that we will be using.

false

It is a very complex call flow. This will help us to see all the aspects I have mentioned
in this document. We will only consider CUCM logs and not the expressway logs.

IP details

These are the Ip details int he trace file.

expwcA 192.105.10.5
JabberA 192.168.0.7 (Registered with CUCMUK—192.105.10.11)
CUCMUK 192.105.10.11
CUCMUS1 192.105.12.13
CUCMUS2 192.105.12.174
expwcB 192.105.12.135
JabberB Registered to CUCM 192.105.12.174)

Call details:
Calling number: 72403225
called number: 87555650
Time of call: 12:24-GMT (7:24 EST—where called endpoint is registered to)

Now let’s download the logs:

• The first place to start will be the 192.105.10.11 node. This is where our Jabber
client is registered to.

• Sip trunk destination node

Next question is which node the call will be sent to on the remote cluster, because we
need to collect the logs from that node as well. The answer to this is that, since this is
a sip call, we can look at the outbound INVITE (translatorX can quickly tell us this).
Once we identify the node the INVITE request was sent to, we can then go to that
node and download the logs.
In this call, the INVITE was sent to multiple nodes (there were about eight servers)
configured on the destination sip trunk. But because run on all active cucm node
wasn’t checked on the sip trunk only the node on the cucm group of the trunk
accepted the call. That node is 192.105.12.13

• Called party node (192.105.12.174)

Here are the three log files.

SDL004_100_000315.txt
SDL010_100_000915.txt
SDL022_100_000756.txt

A quick word about the actual CUCM trace files. It is good to know what the file
naming actually means.
From CUCM 9.1 and above, both SDI files and SDL files are combined in a single trace
file now referred to as SDL_CUCMNODECTIID_PROCESSNAME_FILESEQUECENUMBER

So this file “SDL004_100_000315.txt “ is broken down as follows:

004= CTI ID of 4 (CUCM node ID)
100= CUCM process ID
000315 = file number on that CUCM server
With this you can quickly match Node IDs to server names by looking at the SDL trace
files
To know that your CTI ID or node ID is you can simply go to system>Cisco Unified CM

Figure 1.4

3.1.2 References
I mentioned earlier that this document is not looking in detail at protocols such as SIP,
H323, MGCP or SCCP. However we will be using the knowledge of these protocols in
analysing these traces. It is imperative that you familiar yourself with them and here
are some of the excellent links to understanding CUCM traces from the perspective of
some of these protocols

1. Understanding SIP traces

a. https://supportforums.cisco.com/document/113271/understanding -sip-traces

2. Tracking H.323 Calls in CUCM SDI Traces

a. https://supportforums.cisco.com/document/44911/tracking-h323-calls-cucm-sdi-
traces#Locate_the_problem_call

3. How to read CUCM traces - A Basic Call Signalling Protocol Reference Guide
a. https://supportforums.cisco.com/document/12387851/how-read-cucm-traces-
basic-call-signalling-protocol-reference-guide

3.1.3 Dive In
Now then, we will attempt to look at these traces task by task. This is to help you to
formulate a practical approach to troubleshooting. So here goes.

3.1.4 Task 1: Open Up All The Traces In TranslatorX

You can use built in filters in translatorX to filter through the call based on your
call details.
The sip ladder below shows the call flow for this particular call. One of the many
benefits on translatorX is the quick overview it gives. As you can see we can quickly
identify certain issues even without drilling into the trace files.

Figure 1.5

3.1.5 Task 2: Open Up The Traces In notepad++

Now that we have an overview, its time to open up the traces and see what’s going on
in detail

3.1.5.1 Inbound Invite

+++ This node (192.105.10.11) received INVITE from 192.168.10.5 (expwcA) +++

71463168.003 |12:24:11.967 |AppInfo |SIPTcp - wait_SdlReadRsp: Incoming SIP TCP message from 192.105.10.5 on port 25057 index
[3209965,NET]
INVITE sip:87555650@192.105.10.11;user=phone SIP/2.0
Via: SIP/2.0/TCP 192.105.10.5:5060;egress-zone=CEtcp101054011;branch=z9hG4bK0eaf0237eaaffecea193409900fe09a162780;proxy -
call-id=dc7814d2-4204-4d4b-b738-3819d23a213f;rport
Via: SIP/2.0/TLS 192.105.10.5:5073;branch=z9hG4bKe121c1f328d1abaa38fafd2c9374daa84183;x -cisco-local-
service=nettle;received=192.105.10.5;rport=34815;ingress-zone=DefaultZone
Via: SIP/2.0/TLS 192.105.10.5:5061;egress-
zone=DefaultZone;branch=z9hG4bK62be10dc342a46137249a40f67264bbf62779.c7f78fcb7f0f7be0456ab31b3c665219;proxy -call-
id=b1f2edca -168b-4636-a479-3c61a15636c4;received=192.105.10.5;rport=25015
Via: SIP/2.0/TLS 10.106.3.84:7001;egress-
zone=ExpweTraversal;branch=z9hG4bK5e974241584e1cd038ddd27724b21cf094883.ee2c868e6dc530b149461a661a30df3e;proxy -call-
id=a8ffb6ac-d968-4253-b007-ccc10ddd9191;received=10.106.3.84;rport=7001;ingress-zone=ExpwcTraversal
Via: SIP/2.0/TLS 192.168.0.7:38056;branch=z9hG4bK6b59edc9;received=86.29.4.226;rport=38056;ingress -zone=CollaborationEdgeZone
Call-ID: 73f64906-ee92000c-0954f6c3-4fcae256@192.168.0.7

+++ Next CUCM sends a 100 trying +++

71463172.001 |12:24:11.968 |AppInfo |SIPTcp - wait_SdlSPISignal: Outgoing SIP TCP message to 192.105.10.5 on port 25057 index
2145
[3209966,NET]
SIP/2.0 100 Trying
Via: SIP/2.0/TCP 192.105.10.5:5060;egress-
zone=CEtcp101054011;branch=z9hG4bK0eaf0237eaaffecea193409900fe09a162780;proxy -call-id=dc7814d2-4204-4d4b-b738-
3819d23a213f;rport,SIP/2.0/TLS 192.105.10.5:5073;branch=z9hG4bKe121c1f328d1abaa38fafd2c9374daa84183;x -cisco-local-
service=nettle;received=192.105.10.5;rport=34815;ingress-zone=DefaultZone,SIP/2.0/TLS 192.105.10.5:5061;egress-
zone=DefaultZone;branch=z9hG4bK62be10dc342a46137249a40f67264bbf62779.c7f78fcb7f0f7be0456ab31b3c665219;proxy -call-
id=b1f2edca -168b-4636-a479-3c61a15636c4;received=192.105.10.5;rport=25015,SIP/2.0/TLS 10.106.3.84:7001;egress -
zone=ExpweTraversal;branch=z9hG4bK5e974241584e1cd038ddd27724b21cf094883.ee2c868e6dc530b149461a661a30df3e;proxy -
call-id=a8ffb6ac-d968-4253-b007-ccc10ddd9191;received=10.106.3.84;rport=7001;ingress-zone=ExpwcTraversal,SIP/2.0/TLS
192.168.0.7:38056;branch=z9hG4bK6b59edc9;received=86.29.4.226;rport=38056;ingress -zone=CollaborationEdgeZone
From: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=73f64906ee9200341e7558b1 -346a1ebf
To: <sip:87555650@192.105.10.11>
Date: Fri, 20 Nov 2015 12:24:11 GMT
Call-ID: 73f64906-ee92000c-0954f6c3-4fcae256@192.168.0.7
CSeq: 101 INVITE
Allow-Events: presence
Content-Length: 0

3.1.5.2 Digit Analysis

+++ Next CUCM does a Digit Analysis. This process begins with a DaReq (DA request)
+++

71463201.000 |12:24:11.972 |SdlSig |DaReq |wait |Da(22,100,204,1)

|Cdcc (22,100,212,233043) |22,100,13,149006883. 780^192.105.10.5^BOTMHANNAN |[R:N-H:0,N:0,L:0,V:0,Z:0,D:0]

CI=383048635
Fqdn=ti=1nd=02070043225pi=0si1 Cgpn=tn=0npi=0ti=1nd=72403225pi=1si0
DialedNum=tn=0npi=1ti=1nd=87555650User=87555650Host=192.105.10.11Port=5060P assWord=Madder=Transport=4m
DisplayName=RawUrl=sip:87555650@192.105.10.11;us er=phonepi=0si1 requestID=0 DigitAnalysisComplexity=0
CallingUser= IgnoreIntercept=0
71463201.001 |12:24:11.972 |AppInf o |Digit Analysis: star_DaReq:
daReq.partitionSearchSpace(2728b956-43d7-d756-f a63-e8601b9d2245:ca002184-f 2d1-e36d-c5d2-dcf a8292eb37),
f ilteredPartitionSearchSpaceString(PT_UKNP_PREMIUM_B LOCKED:Internal_P T:ABUK556_TX _P T:SYS_OnNet _P T:
SYS_Video_PT:SYS_E164_XLAT_GEO_P T:SYS_G711_PSTN_P T), partitionSearchSpaceString
(PT_UKNP_PREMIUM_BLOCKED:
Internal_PT:ABUK556_TX_P T:SYS_OnNet_P T:SYS_Video_PT:SYS_E164_X LA T_GEO_P T:SYS_G711_PS TN_P T)
71463201.002 |12:24:11.972 |AppInf o |Digit Analysis: Host Address=192.105.10.11 MATCHES this node's IPv4 address.
71463201.003 |12:24:11.972 |AppInf o |Digit Analysis: star_DaReq: Matching SIP URL, Numeric User, user=87555650

+++ Next we get a DA results +++

71463201.010 |12:24:11.972 |AppInf o |DbMobility: getMatchedRemDest can't f ind remdest 87555650 in map
71463201.011 |12:24:11.972 |AppInf o |Digit analysis: match(pi="2", f qcn="02070043225", cn="72403225",plv="5",
pss="PT_UKNP_PREMIUM_BLOCKED:Internal_P T:ABUK556_TX_P T:SYS_OnNet_P T:SYS_Video_PT

:SYS_E164_XLAT_GEO_PT:SYS_G711_PS TN_P T",

TodFilteredPss="PT_UKNP_PREMIUM_BLOCKED:Internal_P T:ABUK556_TX _P T:SYS_OnNet _P T:SYS_Video_PT:
SYS_E164_XLAT_GEO_PT:SYS_G711_PS TN_P T", dd="87555650",dac="0")
71463201.012 |12:24:11.973 |AppInf o |Digit analysis: analysis results
71463201.013 |12:24:11.973 |AppInf o ||Pretransf ormCallingPartyNumber=72403225
|CallingPartyNumber=72403225
|DialingPartition=SYS_Video_PT
|DialingPattern=87555650
|FullyQualif iedCalledPartyNumber=87555650
|DialingPatternRegularExpression=(87555650)
--
--

|CallableEndPointName=[efb8b5fc-adb1-e22c-cec8-cd53215d60f6]

--
71463202.000 |12:24:11.973
|SdlSig |DmPidReq |initialized |DeviceManager(22,100,199,1)
|Da(22,100,204,1) |22,100,13,149006883.780^192.105.10.5^B OTMHA NNAN |[T:N-H:0,N:0,L:0,V:0,Z:0,D:0]
Cepn=ef b8b5f c-adb1-e22c-cec8-cd53215d60f 6 Id=2650870944
71463202.001 |12:24:11.973 |AppInf o |SMDMSharedData::f indAliasRegInf o - AliasName = ef b8b5f c-adb1-e22c-cec8-
cd53215d60f 6 not in AliasInf o hashmap
71463202.002 |12:24:11.973 |AppInf o |DeviceManager::star_DmPidReq - RequestedName=ef b8b5f c-adb1-e22c-cec8-
cd53215d60f 6

LookupName=efb8b5fc-adb1-e22c-cec8-cd53215d60f6
71463202.003 |12:24:11.973 |AppInf o |SMDMSharedData:: findLocalDevice - Name=SYS_US1_Cluster_RL
Key=ef b8b5f c-adb1-e22c-cec8-cd53215d60f 6 isActvie=1 Pid=(22,82,58) f ound
71463203.000 |12:24:11.973 |SdlSig |DmPidRes |wait |Da(22,100,204,1)
|DeviceManager(22,100,199,1) |22,100,13,149006883.780^192.105.10.5^BOTMHA NNA N |[R:N-
H:0,N:0,L:0,V:0,Z:0,D:0]
Cepn=ef b8b5f c-adb1-e22c-cec8-cd53215d60f 6 Id=2650870944 ccmType=3 Pid=22,100,82,58,
71463203.001 |12:24:11.973 |AppInf o |Digit analysis: wait_DmPidRes- Partition=[f 183a6a8-0588-ac9e-544a-
51eaf 097eb94]
Pattern=[87555650] Where=[],cmDeviceType=[AccessDevice], OutsideDialtone =[0], DeviceOverride=[0],
PID=RouteListControl(22,100,82,58) ,
CI=[383048635] ,Sender=Cdcc(22,100,212,233043)
71463204.000 |12:24:11.973
|SdlSig |DaRes |setup_da |Cdcc(22,100,212,233043)
|Da(22,100,204,1) |22,100,13,149006883.780^192.105.10.5^BOTMHANNAN |[R:N-H:0,N:0,L:0,V:0,Z:0,D:0]
CI=383048635

There are three important things I also look for in the DA results

• Called Endpoint (This we can find in the "CallableEndPointName"): The value

here is in reference to the database so that the device manager will find the
match. The device manager will use the process ID responsible for the device to
find it.
• Local device/Remote Device that the call is sent to: This could be a RL/ICT
Trunk/Phone. This we find under the process "DmPidReq"

• The CI for this leg of the call: We did discuss the CI earlier. So here I find mine.
There are multiple ways to find the CI for each call. Under DA results we find
our CI from "DmPidRes"
Typically CUCM uses a process called CCCiReq and a CCCiRes to allocate the CI
 for a call. So in the DA result CUCM just allocates the CI that has already being
created for the call to the DA results. For me I find it easier to locate my CI
using the DA results.
For this call here is the CCCiReq and CCCiRes ( in here you will see the CI
allocated)

+++ CCCiReq +++

71463079.000 |12:24:11.748
|SdlSig |CcCiReq |wait |Cc(22,100,213,1) |LineControl(22,100,167,45507) |22,100,13,1
49006883.778^192.105.10.5^BOTMHANNAN |[R:N-H:0,N:0,L:0,V:0,Z:0,D:0] handle=0 handle2=0pi=0si1

+++ CCCiRes +++

71463080.000 |12:24:11.748
|SdlSig |CcCiRes |restart0 |LineControl(22,100,167,45507) |Cc(22,100,213,1) |22,100,13,
149006883.778^192.105.10.5^BOTMHANNAN |[R:H-H:0,N:0,L:0,V:0,Z:0,D:0] CI=383048635 CI.branch=0 ci=383048635
callIns=0 handle=0 handle2=0

+++ So in our DA results trace here is the line that showed which device this call was
extended to +++

71463202.003 |12:24:11.973 |AppInfo |SMDMSharedData::findLocalDevice - Name=SYS_US1_Cluster_RL Key=efb8b5fc-adb1-

e22c-cec8-cd53215d60f6 isActvie=1 Pid=(22,82,58) found

+++ And here we see our CI +++

71463203.001 |12:24:11.973 |AppInfo |Digit analysis: wait_DmPidRes- Partition=[f183a6a8-0588-ac9e-544a-51eaf097eb94]

Pattern=[87555650] Where=[],cmDeviceType=[AccessDevice], OutsideDialtone =[0], DeviceOverride=[0],
PID=RouteListControl(22,100,82,58),CI=[383048635],Sender=Cdcc(22,100,212,233043)

3.1.5.3 Outbound Leg

Next we need to begin to look at the outbound leg of the call. CUCM has identified the
RL in this case to send the call to. One of the most important thing to identify here is
the CI for the outbounbd leg of the call. Again there are many ways to find the
outbound CI, but I usually use the process called “LBMIF” This is seen in the line
below. Note that this process associates the inbound CI to the new

+++ Outbound leg CI +++

71463209.001 |12:24:11.973 |AppInfo | LBMIF: CI: 383048635 ASSOC 383048636

3.1.5.4 Route List Control Process

+++ Next CUCM sends a setup request to the RouteListContorl Process +++

71463214.000 |12:24:11.973
|SdlSig |CcSetupReq |idle |RouteListControl(22,100,82,58) |Cdcc(22,100,212,2330
43) |22,100,13,149006883.780^192.105.10.5^BOTMHANNAN |[R:N-H:0,N:2,L:0,V:0,Z:0,D:0] CI=383048636

71463214.001 |12:24:11.973 |AppInfo |RouteListControl::idle_CcSetupReq - RouteList(SYS_US1_Cluster_RL), numberSetup=0

numberMember=1 vmEnabled=0

+++ Here we see the RL name that CUCM is extending the call to and the CUCM nodes
in the RL CUCM group. +++

71463215.003 |12:24:11.974 |AppInfo |RouteList - RouteListName=''SYS_US1_Cluster_RL'' CallableEndPointName=''efb8b5fc-adb1-

e22c-cec8-cd53215d60f6'' routeListEnabled=''1''
71463215.004 |12:24:11.974 |AppInfo |TDCLdb.hpp - CallManagerGroup - serverCount = 2
71463215.005 |12:24:11.974 |AppInfo |TDCLdb.hpp - CallManagerGroup - nodeId = 32
71463215.006 |12:24:11.974 |AppInfo |TDCLdb.hpp - CallManagerGroup - nodeId = 28
71463215.007 |12:24:11.974 |AppInfo |RouteList - RouteGroup count=''1''

+++ Next CUCM sends a setup request to the gateway in the Route List—Observe
that the CI is that of our outbound leg +++

71463218.000 |12:24:11.974 |SdlSig |CcSetupReq |null0 |RouteListCdrc(22,100,83,95826) |RouteListControl(22,100,82,58)

|22,100,13,149006883.780^192.105.10.5^BOTMHANNAN
71463218.001 |12:24:11.974 |AppInfo |RouteListCdrc::null0_CcSetupReq check vipr call mViprReroute=0 mViprAlreadyAttempt=0
CI=383048636 BRANCH=0

3.1.5.5 Gateway Selection

+++ Next CUCM does a DmPidReq to locate the device to extend the call to in the
Route List +++

71463219.000 |12:24:11.974
|SdlSig |DmPidReq |initialized |DeviceManager(22,100,199,1) |RouteListCdrc(22,10
0,83,95826) |22,100,13,149006883.780^192.105.10.5^BOTMHANNAN |[T:N-H:0,N:0,L:0,V:0,Z:0,D:0] Cepn=2576684a -c903-
cb8c-aa46-4218b05d684a Id=0
71463219.001 |12:24:11.974 |AppInfo |SMDMSharedData::findAliasRegInfo - AliasName = 2576684a-c903-cb8c-aa46-4218b05d684a
not in AliasInfo hashmap
71463219.002 |12:24:11.974 |AppInfo |DeviceManager::star_DmPidReq - RequestedName=2576684a-c903-cb8c-aa46-4218b05d684a
LookupName=2576684a -c903-cb8c-aa46-4218b05d684a
71463219.003 |12:24:11.974 |AppInfo |SMDMSharedData::findLocalDevice - Name=SYS_US_Cluster1 Key=2576684a -c903-cb8c-
aa46-4218b05d684a isActvie=1 Pid=(22,74,97) found
+++ Next we get a DmPidRes and we see that the call is successfully extended to the
device SYS_US_Cluster1 +++

71463220.000 |12:24:11.974
|SdlSig |DmPidRes |select_facility |RouteListCdrc(22,100,83,95826) |DeviceManager(22,100,199,1) |2
2,100,13,149006883.780^192.105.10.5^BOTMHANNAN
--
71463220.004 |12:24:11.974 |AppInfo |RouteListCdrc::distributeCall ccSetupReq CI=383048636 BRANCH=0
71463220.005 |12:24:11.974 |AppInfo |RouteListCdrc::executeRouteAction:
EXTEND_CALL_TO_CURRENT_MEMBER – Success

--

71463221.009 |12:24:11.975 |AppInfo |CcmCcmdbSIPNormalizeHelper::getSipDeviceScriptPkidGivenDeviceName: This is a regular

SIPTrunk. deviceName - (SYS_US_Cluster1)

+++ Next CUCM sends a setup request to the SIP trunk. In my cluster we have
multiple CUCM nodes in the sip trunk and we can see all the possible nodes here +++

71463239.000 |12:24:11.976
|SdlSig |SIPSetupReq |wait |SIPHandler(22,100,72,1) |SIPCdpc(22,100,75,5088
1) |22,100,13,149006883.780^192.105.10.5^BOTMHANNAN |[T:N-H:0,N:0,L:0,V:0,Z:0,D:0] SignalInfo= SIPInviteNoSdp
CcbId=1243347 --TransType=2 --TransSecurity=0 PeerAddr=192.105.12.12:5060 addrList: |ipAddrType=0 (0)192.105.12.12:5060
(1)192.105.12.173:5060 (2)192.105.12.171:5060 (3)192.105.12.11:5060 (4)192.105.12.14:5060 (5)192.105.12.174:5060
(6)192.105.12.172:5060 (7)192.105.12.13:5060| rtp IP:Port=0 isDtmCall=0 rel1xxConfig=0

+++ Next cucm randomly chooses a node to extend the INVITE to +++

71463239.017 |12:24:11.977 |AppInfo |//SIP/Stack/Info/0x9e9e1d08/act_idle_continue_call_setup:

71463239.018 |12:24:11.977 |AppInfo |//SIP/Stack/Info/0x0/sipSPIProcessTargetInfoDestList: Processing target destination list
71463239.019 |12:24:11.977 |AppInfo |//SIP/Stack/Info/0x0/sipSPITargetInfoChooseInitialDestinatio: numDests=8; Randomly
chosen dest is 4, 192.105.12.14

3.1.5.6 Outbound Invite

+++ Next CUCM sends INVITE out to the chosen node , CUCM appends the outbound
CI to the end of the From header+++

71463256.001 |12:24:11.977 |AppInfo |//SIP/SIPUdp/wait_SdlSPISignal: Outgoing SIP UDP message to 192.105.12.14:[5060]:

[3209967,NET]
INVITE sip:87555650@192.105.12.14:5060 SIP/2.0
Via: SIP/2.0/UDP 192.105.10.11:5060;branch=z9hG4bK114b5154976ba4
From: "Mike Hannan" <sip:72403225@192.105.10.11>; tag=1243347~ffa80926-5fac-4dd6-b405-
2dbbc56ae9a2-383048636
To: <sip:87555650@192.105.12.14>
Date: Fri, 20 Nov 2015 12:24:11 GMT
Call-ID: 99436d00-64f110eb-1018c6-b28690a@192.105.10.11
Supported: timer,resource-priority,replaces
Min-SE: 1800
User-Agent: Cisco-CUCM9.1

+++ Next we get a trying +++

71463269.001 |12:24:12.056 |AppInfo |//SIP/SIPUdp/wait_UdpDataInd: Incoming SIP UDP message size 382 from
192.105.12.14:[5060]:
[3209968,NET]
SIP/2.0 100 Trying
Via: SIP/2.0/UDP 192.105.10.11:5060;branch=z9hG4bK114b5154976ba4
From: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=1243347~ffa80926 -5fac-4dd6-b405-2dbbc56ae9a2-383048636
To: <sip:87555650@192.105.12.14>
Date: Fri, 20 Nov 2015 12:24:12 GMT
Call-ID: 99436d00-64f110eb-1018c6-b28690a@192.105.10.11
CSeq: 101 INVITE
Allow-Events: presence
Content-Length: 0

+++ Next we get a 503 service unavailable +++

71463273.001 |12:24:12.057 |AppInfo |//SIP/SIPUdp/wait_UdpDataInd: Incoming SIP UDP message size 533 from
192.105.12.14:[5060]:
[3209969,NET]
SIP/2.0 503 Service Unavailable
Via: SIP/2.0/UDP 192.105.10.11:5060;branch=z9hG4bK114b5154976ba4
From: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=1243347~ffa80926 -5fac-4dd6-b405-2dbbc56ae9a2-383048636
To: <sip:87555650@192.105.12.14>;tag=931256970
Date: Fri, 20 Nov 2015 12:24:12 GMT
Call-ID: 99436d00-64f110eb-1018c6-b28690a@192.105.10.11
CSeq: 101 INVITE
Allow-Events: presence
Warning: 399 GDN1US-BILRC-1CMS04 "Unable to find a device handler for the request received on
port 5060 from 192.105.10.11"
Content-Length: 0

Here see that the node this call was extended to is not configured in the CUCM group
assigned to the device pool of the sip trunk and since the run on all active cm node
wasn’t checked on the trunk, that node rejected the call

+++ CUCM then proceeds to send INVITE to another node in the remote cluster +++

71463304.019 |12:24:12.247 |AppInfo |//SIP/Stack/Info/0x9e9e1d08/sipSPISendInvite: Associated container=0x9e92d738 to Invite

71463304.020 |12:24:12.247 |AppInfo |//SIP/Stack/Transport/0x9e9e1d08/sipSPISendInvite: Sending Invite to the transport
layer
71463304.021 |12:24:12.247 |AppInfo |//SIP/Stack/Transport/0x9e9e1d08/sipSPITransportSendMessage: msg=0x107f2a10,
addr=192.105.12.13, port=5060, sentBy_port=0, is_req=1, transp

71463307.001 |12:24:12.247 |AppInfo |//SIP/SIPUdp/wait_SdlSPISignal: Outgoing SIP UDP message to 192.105.12.13:[5060]:

[3209979,NET]
INVITE sip:87555650@192.105.12.13:5060 SIP/2.0
Via: SIP/2.0/UDP 192.105.10.11:5060;branch=z9hG4bK114b54480f60aa
From: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=1243347~ffa80926 -5fac-4dd6-b405-2dbbc56ae9a2-383048636
To: <sip:87555650@192.105.12.13>
Date: Fri, 20 Nov 2015 12:24:12 GMT
Call-ID: 99436d00-64f110eb-1018c6-b28690a@192.105.10.11

+++ Next we get a 100 trying +++

71463317.001 |12:24:12.326 |AppInfo |//SIP/SIPUdp/wait_UdpDataInd: Incoming SIP UDP message size 382 from
192.105.12.13:[5060]:
[3209980,NET]
SIP/2.0 100 Trying
Via: SIP/2.0/UDP 192.105.10.11:5060;branch=z9hG4bK114b54480f60aa
From: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=1243347~ffa80926 -5fac-4dd6-b405-2dbbc56ae9a2-383048636
To: <sip:87555650@192.105.12.13>
Date: Fri, 20 Nov 2015 12:24:12 GMT
Call-ID: 99436d00-64f110eb-1018c6-b28690a@192.105.10.11
CSeq: 104 INVITE
Allow-Events: presence
Content-Length: 0

3.1.5.7 Inbound Invite On Remote Cluster

Now we need to go to the remote node that the call has been extended to see what’s
happening there. A quick way to find the call in log file on that node is to use the SIP
call-ID from the originating node (Call-ID: 99436d00-64f110eb-1018c6-
b28690a@192.105.10.11)

+++ Inbound INVITE +++

80988202.001 |07:24:12.286 |AppInfo |//SIP/SIPUdp/wait_UdpDataInd: Incoming SIP UDP message size 1116 from
192.105.10.11:[5060]:
[8404018,NET]
INVITE sip:87555650@192.105.12.13:5060 SIP/2.0
Via: SIP/2.0/UDP 192.105.10.11:5060;branch=z9hG4bK114b54480f60aa
From: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=1243347~ffa80926 -5fac-4dd6-b405-2dbbc56ae9a2-383048636
To: <sip:87555650@192.105.12.13>
Date: Fri, 20 Nov 2015 12:24:12 GMT
Call-ID: 99436d00-64f110eb-1018c6-b28690a@192.105.10.11

+++ Next this CUCM node sends a trying and we can correlate this to the trying we
received earlier +++

80988206.001 |07:24:12.287 |AppInfo |//SIP/SIPUdp/wait_SdlSPISignal: Outgoing SIP UDP message to 192.105.10.11:[5060]:

[8404019,NET]
SIP/2.0 100 Trying
Via: SIP/2.0/UDP 192.105.10.11:5060;branch=z9hG4bK114b54480f60aa
From: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=1243347~ffa80926 -5fac-4dd6-b405-2dbbc56ae9a2-383048636
To: <sip:87555650@192.105.12.13>
Date: Fri, 20 Nov 2015 12:24:12 GMT
Call-ID: 99436d00-64f110eb-1018c6-b28690a@192.105.10.11
CSeq: 104 INVITE
Allow-Events: presence
Content-Length: 0
+++ Next this CUCM node does a DA and allocates a CI for this leg of the call +++

    

 () 
() ⊥⊥ − 
= == ====== ======
=====
=== = = 
= =
      (−−−
−)
−−
−−
      =     
           =
−−
      −    
     (= = ==
=
 =
 ==)

+++ Next we get DA results +++

80988231.007 |07:24:12.290 |AppInfo |Digit analysis: analysis results

80988231.008 |07:24:12.290 |AppInfo ||PretransformCallingPartyNumber=72403225
|CallingPartyNumber=72403225
|DialingPartition=Internal_PT
|DialingPattern=87555650
|FullyQualifiedCalledPartyNumber=16317555650
|DialingPatternRegularExpression=(87555650)
|DialingWhere=
|PatternType=Enterprise

--

|CallableEndPointName=[5b4fa37c-2bd1-8712-a000-412f20426ab0]

+++ Next CUCM does a DmPidReq to locate the device to send the call to +++

80988232.000 |07:24:12.290
|SdlSig |DmPidReq |initialized |DeviceManager(4,100,199,1) |Da(4,100,204,1)
|4,100,238,1.371806^192.105.10.11^* |[T:N-H:0,N:0,L:0,V:0,Z:0,D:0] Cepn=5b4fa37c-2bd1-8712-a000-412f20426ab0
Id=2806496856
----
80988232.002 |07:24:12.290 |AppInfo |DeviceManager::star_DmPidReq - RequestedName=5b4fa37c-2bd1-8712-a000-412f20426ab0
LookupName=5b4fa37c-2bd1-8712-a000-412f20426ab0
80988232.003 |07:24:12.290 |AppInfo |SMDMSharedData::findRemoteDeviceAny - Key=5b4fa37c-2bd1-8712-a000-412f20426ab0
found in RemoteDeviceInfo hashmap - PID(s)=1 Name=87555650:958454d4-0190-b885-adc6-dcebcaef3d7a isActive=1
isDualMode=0 Protocol=LINE Pid=(10,167,52412)
+++ Next we get a DmPidRes and we can also see the CI for this leg of the call here
+++

80988233.000 |07:24:12.290
|SdlSig |DmPidRes |wait |Da(4,100,204,1) |DeviceManager(4,100,199,1) |4,100,238,1
.371806^192.105.10.11^*
80988233.001 |07:24:12.290 |AppInfo |Digit analysis: wait_DmPidRes- Partition=[958454d4-0190-b885-adc6-dcebcaef3d7a]
Pattern=[87555650] Where=[],cmDeviceType=[UserDevice], OutsideDialtone =[0], DeviceOverride=[0],
PID=LineControl(10,100,167,52412),CI=[74628313] ,Sender=Cdcc(4,100,212,455461)
80988234.000 |07:24:12.290
|SdlSig |DaRes |setup_da |Cdcc(4,100,212,455461) |Da(4,100,204,1) |4,100,238,1.3
71806^192.105.10.11^* |[R:N-H:0,N:0,L:0,V:0,Z:0,D:0] CI=74628313

3.1.5.8 DA Local Device And Remote Device

In DA, CUCM determines if the device its extending the call to is a local device or a
remote device. If the device is registered with the CUCM node that is processing the
call, then the device is deemed a local device .If the device is remote to the CUCM
node that is processing the call, then the device is deemed as a remote device.

So in the previous trace file we saw for the node 192.105.10.11 we have these entries
in our DmPidReq:

+++ AppInfo |SMDMSharedData::findLocalDevice +++

71463202.002 |12:24:11.973 |AppInfo |DeviceManager::star_DmPidReq - RequestedName=efb8b5fc-adb1-e22c-cec8-cd53215d60f6

LookupName=efb8b5fc-adb1-e22c-cec8-cd53215d60f6
71463202.003 |12:24:11.973 |AppInfo |SMDMSharedData::findLocalDevice - Name=SYS_US1_Cluster_RL Key=efb8b5fc-adb1-
e22c-cec8-cd53215d60f6 isActvie=1 Pid=(22,82,58) found

We can see the line “findLocalDevice” this tells us that this RL is registered to this node

In this trace below file we see the “findRemoteDeviceAny” this tells us that the device
is not registered to this node

+++ AppInfo |SMDMSharedData::findRemoteDeviceAny +++

80988232.002 |07:24:12.290 |AppInfo |DeviceManager::star_DmPidReq - RequestedName=5b4fa37c-2bd1-8712-a000-412f20426ab0

LookupName=5b4fa37c-2bd1-8712-a000-412f20426ab0
80988232.003 |07:24:12.290 |AppInfo |SMDMSharedData:: findRemoteDeviceAny - Key=5b4fa37c-2bd1-8712-a000-
412f20426ab0 found in RemoteDeviceInfo hashmap - PID(s)=1 Name=87555650:958454d4-0190-b885-adc6-dcebcaef3d7a isActive=1
isDualMode=0 Protocol=LINE Pid=(10,167,52412)

From the trace above there are key things to know:

• Pid=Process ID responsible for this device. The format of the PID= Process
name (Node_id, Process Type, process instance)
 • Pid=(10,167,52412):
o 10= Node_Id where the device isregistered to
o 167=Process type which in this case is LineControl
• Once we see this we know that this node will need to send a SDL signal to
CUCM node 10 (192.105.12.174)
• Protocol=LINE: The protocol identifies what this device is. Here it is a DN.
• PID(s)=1 Name=87555650:958454d4-0190-b885-adc6-dcebcaef3d7a: This
tells us the DN and the pkid for the partition of the DN.We can use the following
SQL query to find the partition.

run sql select name from routepartition where pkid = ”958454d4-0190-b885-adc6-

dcebcaef3d7a”

3.1.5.9 SDL Signal To CUCM Node Where Jabber Is registered

Next CUCM needs to allocate a CI for the outbound leg of the call and extend the call
to the node where the device is registered

+++ Here we see CUCM associate the inboud CI to the outbound CI +++

80988255.000 |07:24:12.291
|SdlSig |CACAssociateReq |connecting |LBMInterface(4,100,169,1) |ReservationMgr(4,100,103,1) |
4,100,238,1.371806^192.105.10.11^* |[T:N-H:0,N:0,L:0,V:0,Z:0,D:0] CI= 74628313 aCI=74628313 bCI=74628314 isASerCI=F
isBSerCI=F sendResp=F mcNodeId=0
80988256.000 |07:24:12.291
|SdlSig |PolicyAndCACAssociateRes |wait |Cc(4,100,213,1) |ReservationMgr(4,100,103,1) |4,1
00,238,1.371806^192.105.10.11^* |[R:N-H:0,N:0,L:0,V:0,Z:0,D:0] CI= 74628313 aCI=74628313 bCI=74628314 isASerCI=F
isBSerCI=F sendResp=F mcNodeId=0
80988255.001 |07:24:12.291 |AppInfo |LBMIF: CI: 74628313 ASSOC 74628314
80988255.002 |07:24:12.291 |AppInfo |LBMIF: CI: 74628314 ASSOC' 74628313

+++ Next CUCM sends an outbound SDL setup request to the node +++

80988259.000 |07:24:12.291 | SdlSig-O |CcSetupReq |NA

RemoteSignal |LineControl(10,100,167,52412) |Cdcc(4,100,212,455461) |4,100,238,1.371806^192.105.10.1
1^* |[R:N-H:0,N:1,L:0,V:0,Z:0,D:0] CI=74628314

key things to note in this trace file

• SdlSig-O:This indicate the SDL operation. Indicates if the Signal Is Local to the
Server (SdlSig),Inbound from Another Node in the Cluster (SdlSig-I), or Out to
Another Node in the Cluster (SdlSig-O). In our case we see that is is outbound
to another node
• CcSetupReq: This indicates the SDL signal name that is being sent from the
source process to the destination process

• RemoteSignal |LineControl(10,100,167,52412): This indicates a

remote signal sent to the CUCM process on node 10. (10,100,167,52412)
(10=node10, 100=CUCM process, 167=LineControl (process type))

• Cdcc(4,100,212,455461): This shows where the SDL request originates from.

Its from node 4 (this node) and it is Cdcc process of the cucm sending it.

3.1.5.10 Inbound SDL Signal To The CUCM NODE10

Now we need to go to the node 10 and see what happens to this request
The quickest way to find this call on node10 is to use the CI=74628314

+++ CUCM node10 receives the inbound SDL setup request +++

50128650.000 |07:24:12.301 |SdlSig-I

|CcSetupReq |restart0 |LineControl(10,100,167,52412) |Cdcc(4,100,212,455461) |4,100,238,1.37
1806^192.105.10.11^* |[R:N-H:0,N:0,L:0,V:0,Z:0,D:0] CI=74628314

+++ Next CUCM node10 processes the requests. The trace file below shows the
relevant information needed to process this. The sip RepUri, Aor etc +++

50128666.008 |07:24:12.324 |AppInfo |SIPCdpc(1863930) - getDefSetup: ReqURI is present: sip:5b4fa37c-2bd1-8712-a000-

412f20426ab0@192.105.12.135:5060;transport=tcp;orig-hostport=62.191.28.104:50183
--
|07:24:12.324 |AppInfo |SIPCdpc(1863930) - checkAorInToHeader: Using To header AoR sip:87555650@192.105.12.174
50128666.013 |07:24:12.324 |AppInfo |SIPCdpc(1863930) - CcPtyNumIdEq: Comparing @, dn: 87555650, ti: DN with @, dn:
87555650, ti: DN, result: true
50128666.014 |07:24:12.324 |AppInfo |SIPCdpc(1863930) - CcPtyNumIdEq: Comparing @, dn: 87555650, ti: DN with @, dn:
87555650, ti: DN, result: true

+++ Next CUCM sends a setup request to the SIPHandler process on this node +++

50128668.000 |07:24:12.324
|SdlSig |SIPSetupReq |wait | SIPHandler(10,100,72,1) | SIPCdpc(10,100,75,18639
30) |4,100,238,1.371806^192.105.10.11^* |[T:N-H:0,N:0,L:0,V:0,Z:0,D:0] SignalInfo= SIPInviteNoSdp CcbId=5745657 --
TransType=1 --TransSecurity=0 PeerAddr=192.105.12.135:5060 addrList: || rtp IP:Port=0 isDtmCall=0 rel1xxConfig=0

+++ Next we get a SIPProceedInd (call proceeding) which indicates that the
SIPHandler process has accepted the request and processing it +++

0128668.022 |07:24:12.324 |AppInfo |//SIP/Stack/Transport/0x0/sipSPIUpdateResponseInfo: Dialog Transaction Address

192.105.12.135,Port 5060, Transport 2, SentBy Port 5060
50128671.000 |07:24:12.324
|SdlSig |SIPProceedInd |wait | SIPStationD(10,100,66,854) |SIPHandler(10,100,72,1) |
4,100,238,1.371806^192.105.10.11^* |[R:N-H:0,N:0,L:0,V:0,Z:0,D:0] CcbId= 5745657 --TransType=1 --TransSecurity=0
PeerAddr = 192.105.12.135:5060

+++ Next CUCM sends a callproceeding via SDL to the requesting node (node 4) +++
50128676.000 |07:24:12.324 | SdlSig-O |CcProceedInd |NA
RemoteSignal | Cc(4,100,213,1) |LineCdpc(10,100,168,332054) |4,100,238,1.371806^192.105.10.11^* |[
R:N-H:0,N:0,L:0,V:0,Z:0,D:0] CI=74628314

3.1.5.11 CUCM Node10 Call Progress

+++ Next CUCM proceeds to send the outbound INVITE to expressway-C +++

50128668.027 |07:24:12.324 |AppInfo |//SIP/Stack/Transport/0xa4b3b598/sipSPISendInvite: Sending Invite to the transport layer

50128668.028 |07:24:12.324 |AppInfo |//SIP/Stack/Transport/0xa4b3b598/sipSPITransportSendMessage: msg=0xa496da60,
addr=192.105.12.135, port=5060, sentBy_port=0, is_req=1, transp
--
--
50128677.001 |07:24:12.324 |AppInfo |SIPTcp - wait_SdlSPISignal: Outgoing SIP TCP message to 192.105.12.135 on port 5060 index
12281
[29778977,NET]
INVITE sip:5b4fa37c-2bd1-8712-a000-412f20426ab0@192.105.12.135:5060;transport=tcp;orig-hostport=62.191.28.104:50183
SIP/2.0
Via: SIP/2.0/TCP 192.105.12.174:5060;branch=z9hG4bK5eb17b335aa8e7
From: "Mike Hannan" <sip:72403225@192.105.12.174>;tag=5745657~52c1d180 -11c8-49c2-8c0b-dea47e22e0b7-74628314
To: <sip:87555650@192.105.12.174>
Date: Fri, 20 Nov 2015 12:24:12 GMT
Call-ID: 99dc0380-64f110ec-28a88e-ae2a690a@192.105.12.174
Supported: timer,resource-priority,replaces
Min-SE: 1800
User-Agent: Cisco-CUCM9.1

+++ Next we get a 100 trying from EXPRESSWAY-C +++

50128680.002 |07:24:12.330 |AppInfo |SIPTcp - wait_SdlReadRsp: Incoming SIP TCP message from 192.105.12.135 on port 5060
index 12281 with 407 bytes:
[29778978,NET]
SIP/2.0 100 Trying
Via: SIP/2.0/TCP 192.105.12.174:5060;branch=z9hG4bK5eb17b335aa8e7;received=192.105.12.174;ingress -zone=CEtcp1010542174
Call-ID: 99dc0380-64f110ec-28a88e-ae2a690a@192.105.12.174

+++ Next we get a 180 ringing +++

50128694.002 |07:24:12.539 |AppInfo |SIPTcp - wait_SdlReadRsp: Incoming SIP TCP message from 192.105.12.135 on port 5060
index 12281 with 822 bytes:
[29778982,NET]
SIP/2.0 180 Ringing
Via: SIP/2.0/TCP 192.105.12.174:5060;branch=z9hG4bK5eb17b335aa8e7;received=192.105.12.174;ingress -zone=CEtcp1010542174
Call-ID: 99dc0380-64f110ec-28a88e-ae2a690a@192.105.12.174
CSeq: 101 INVITE

+++ Next CUCM sends the alert to node4 via SDL +++

50128709.000 |07:24:12.540 | SdlSig-O |CcAlertInd |NA

RemoteSignal |Cc(4,100,213,1) |LineCdpc(10,100,168,332054) |10,100,13,73940.14^192.105.12.135^* |[R:
N-H:0,N:1,L:0,V:0,Z:0,D:0] CI=74628314
3.1.5.12 CUCM Node4 Call Progress

+++ On CUCM node 4 we receive the inboud SDL alert +++

80988280.000 |07:24:12.550 | SdlSig-I

|CcAlertInd |wait |Cc(4,100,213,1) |LineCdpc(10,100,168,332054) |10,100,13,73940
.14^192.105.12.135^* |[R:N-H:0,N:0,L:0,V:0,Z:0,D:0] CI=74628314

+++Next CUCM node4 sends a 180 ringing to the remote cluster +++

80988289.001 |07:24:12.551 |AppInfo |//SIP/SIPUdp/wait_SdlSPISignal: Outgoing SIP UDP message to 192.105.10.11:[5060]:

[8404020,NET]
SIP/2.0 180 Ringing
Via: SIP/2.0/UDP 192.105.10.11:5060;branch=z9hG4bK114b54480f60aa
From: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=1243347~ffa80926 -5fac-4dd6-b405-2dbbc56ae9a2-383048636
To: <sip:87555650@192.105.12.13>;tag=3227903~52c1d180 -11c8-49c2-8c0b-dea47e22e0b7-74628313
Date: Fri, 20 Nov 2015 12:24:12 GMT
Call-ID: 99436d00-64f110eb-1018c6-b28690a@192.105.10.11

3.1.5.13 CUCMUK Node22 Call Progress

+++ Back on the remote UK cluster we see the call progress message arriving +++

71463385.001 |12:24:12.591 |AppInfo |//SIP/SIPUdp/wait_UdpDataInd: Incoming SIP UDP message size 913 from
192.105.12.13:[5060]:
[3209981,NET]
SIP/2.0 180 Ringing
Via: SIP/2.0/UDP 192.105.10.11:5060;branch=z9hG4bK114b54480f60aa
From: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=1243347~ffa80926 -5fac-4dd6-b405-2dbbc56ae9a2-383048636
To: <sip:87555650@192.105.12.13>;tag=3227903~52c1d180 -11c8-49c2-8c0b-dea47e22e0b7-74628313
Date: Fri, 20 Nov 2015 12:24:12 GMT
Call-ID: 99436d00-64f110eb-1018c6-b28690a@192.105.10.11

+++ Next CUCM node22 sends the ringing out to UK-expressway-C +++

71463410.001 |12:24:12.593 |AppInfo |SIPTcp - wait_SdlSPISignal: Outgoing SIP TCP message to 192.105.10.5 on port 25057 index
2145
[3209982,NET]
SIP/2.0 180 Ringing
Via: SIP/2.0/TCP 192.105.10.5:5060;egress-
zone=CEtcp101054011;branch=z9hG4bK0eaf0237eaaffecea193409900fe09a162780;proxy -call-id=dc7814d2-4204-4d4b-b738-
3819d23a213f;rport,SIP/2.0/TLS 192.105.10.5:5073;branch=z9hG4bKe121c1f328d1abaa38fafd2c9374daa84183;x -cisco-local-
service=nettle;received=192.105.10.5;rport=34815;ingress-zone=DefaultZone,SIP/2.0/TLS 192.105.10.5:5061;egress-
zone=DefaultZone;branch=z9hG4bK62be10dc342a46137249a40f67264bbf62779.c7f78fcb7f0f7be0456ab31b3c665219;proxy -call-
id=b1f2edca -168b-4636-a479-3c61a15636c4;received=192.105.10.5;rport=25015,SIP/2.0/TLS 10.106.3.84:7001;egress -
zone=ExpweTraversal;branch=z9hG4bK5e974241584e1cd038ddd27724b21cf094883.ee2c868e6dc530b149461a661a30df3e;proxy -
call-id=a8ffb6ac-d968-4253-b007-ccc10ddd9191;received=10.106.3.84;rport=7001;ingress-zone=ExpwcTraversal,SIP/2.0/TLS
192.168.0.7:38056;branch=z9hG4bK6b59edc9;received=86.29.4.226;rport=38056;ingress -zone=CollaborationEdgeZone
From: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=73f64906ee9200341e7558b1 -346a1ebf
To: <sip:87555650@192.105.10.11>;tag=1243346~ffa80926 -5fac-4dd6-b405-2dbbc56ae9a2-383048635
Date: Fri, 20 Nov 2015 12:24:11 GMT
Call-ID: 73f64906-ee92000c-0954f6c3-4fcae256@192.168.0.7
3.1.5.14 CUCM Node10 Call Progress

+++ CUCM node10 receives a 200 Ok from expressway-C > NB I have omitted the
SDP +++

50128752.002 |07:24:15.516 |AppInfo |SIPTcp - wait_SdlReadRsp: Incoming SIP TCP message from 192.105.12.135 on port 5060
index 12281 with 2685 bytes:
[29778988,NET]
SIP/2.0 200 OK
Via: SIP/2.0/TCP 192.105.12.174:5060;branch=z9hG4bK5eb17b335aa8e7;received=192.105.12.174;ingress -zone=CEtcp1010542174
Call-ID: 99dc0380-64f110ec-28a88e-ae2a690a@192.105.12.174
CSeq: 101 INVITE

+++ next CUCM computes SDP and sends SDP offer via SDL to node4 +++

50128773.000 |07:24:15.582 | SdlSig-O |SDPOfferInd |NA

RemoteSignal |SIPInterface(4,100,69,85035) |SIPCdpc(10,100,75,1863930) |10,100,13,73940.15^192.105.12.135^*
|[R:N-H:0,N:3,L:0,V:0,Z:0,D:0] nAudio=1 stackIdx=1 audioCapCount=7 Caps[6(20),40(0),41(0),4(20),2(20),11(20),12(20)]
port=54890 IP= ipAddrType=0 ipv4=192.105.12.135 SDPMode=0 mediaAttr=0x0 SP=F RTP=T SRTP=F idle=F
QoS=FenabledMask=0rtcbFbCount=0LatentCaps=null ~nVideo=2 stackIdx=2 videoCapCount=2, [103 pt=96 h235=0],[103 pt=97
h235=0] port=54892 ipAddrType=0 ipv4=192.105.12.135

3.1.5.15 CUCM Node4 Call Progress

+++ Back on CUCM node 4 we receive the SDP offer via SDL +++

80988381.000 |07:24:15.592 | SdlSig-I

|SDPOfferInd |waitSDPResponse |SIPInterface(4,100,69,85035) |SIPCdpc(10,100,75,1863930) |10
,100,13,73940.15^192.105.12.135^* |[R:N-H:0,N:0,L:0,V:0,Z:0,D:0] nAudio=1 stackIdx=1 audioCapCount=7
Caps[6(20),40(0),41(0),4(20),2(20),11(20),12(20)] port=54890 IP= ipAddrType=0 ipv4=192.105.12.135

+++ Next CUCM node4 computes its SDP offer and sends a 200 OK to CUCM node 22
(remote node) +++

80988412.001 |07:24:15.593 |AppInfo |//SIP/SIPUdp/wait_SdlSPISignal: Outgoing SIP UDP message to 192.105.10.11:[5060]:

[8404021,NET]
SIP/2.0 200 OK
Via: SIP/2.0/UDP 192.105.10.11:5060;branch=z9hG4bK114b54480f60aa
From: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=1243347~ffa80926 -5fac-4dd6-b405-2dbbc56ae9a2-383048636
To: <sip:87555650@192.105.12.13>;tag=3227903~52c1d180 -11c8-49c2-8c0b-dea47e22e0b7-74628313
Date: Fri, 20 Nov 2015 12:24:12 GMT
Call-ID: 99436d00-64f110eb-1018c6-b28690a@192.105.10.11

3.1.5.16 CUCMUK Node22 Call Progress

Now we should receive the 200 OK sent by CUCM node4, but we never did
The next event we see on this node is a BYE sent from node4

71471172.001 |12:24:35.206 |AppInfo |//SIP/SIPUdp/wait_UdpDataInd: Incoming SIP UDP message size 506 from
192.105.12.13:[5060]:
[3209999,NET]
BYE sip:72403225@192.105.10.11:5060 SIP/2.0
Via: SIP/2.0/UDP 192.105.12.13:5060;branch=z9hG4bK193885132d5402
From: <sip:87555650@192.105.12.13>;tag=3227903~52c1d180 -11c8-49c2-8c0b-dea47e22e0b7-74628313
To: "Mike Hannan" <sip:72403225@192.105.10.11>;tag=1243347~ffa80926 -5fac-4dd6-b405-2dbbc56ae9a2-383048636
Date: Fri, 20 Nov 2015 12:24:12 GMT
Call-ID: 99436d00-64f110eb-1018c6-b28690a@192.105.10.11
User-Agent: Cisco-CUCM9.1
Max-Forwards: 70
CSeq: 101 BYE
Reason: Q.850;cause=86
Content-Length: 0

For this particular issue there was a network related problem causing 200 OK sent via
UDP to be dropped.

4.1 Summary
Congratulations if you stayed with me till the end of this and endure all of my rantings.
This was a monster of a trace. But it did help us to analyse in detail many of the
moving parts within a CUCM process.
It’s no easy task troubleshooting complex issues within a CUCM . Having the right
tools, knowing where to look and what to look for will go a long way in separating the
men from the boys and ccie(s) from CCIE(S) :)

I do hope this has been useful. Please feel free to ask questions and dont forget to rate
if you absolutely love it!
