WI-XML Página 1 de 13
Crafter Current Flow Diagram No. 2 / 1
Edition 12.2007
Basic equipment
● Fog lights
● Luggage compartment light
from March 2006
Notes:
For information concerning
Position of relays and fuses
Multi-pin connections
Control units and relays
Earth connections
→ List of Fitting Locations!
For information concerning
Fault Finding Programs
→ guided fault finding
WI-XML Página 2 de 13
Crafter Current Flow Diagram No. 2 / 2
Battery, second battery, starter, alternator, battery isolation relay,
terminal 50 voltage supply relay, fuses
A - Battery
A1 - Second battery
B - Starter
C - Alternator
C1 - Voltage regulator
J7 - Battery isolation relay, under driver seat
J519 - Onboard supply control unit
J623 - Engine control unit
J682 - Terminal 50 voltage supply relay
S190 - Terminal 30 voltage supply fuse, in alternator wire
SC23 - Fuse 23 on fuse holder C
TV32 - Jump start connection
T2 - 2-pin connector
T8 - 8-connector, black, in left engine compartment
T8a - 8-connector, black, in left engine compartment
T94 - 94-pin connector
- Earth strap, battery - body
1
- Earth strap, second battery - body
5
ws = white
sw = black - Earth point, under driver seat
34
ro = red
br = brown
gn = green - Connection (61), in dash panel wiring harness
A17
bl = blue
gr = grey
li = purple - Positive connection (30), in engine compartment wiring
D50
ge = yellow harness
or = orange
rs = pink * - only models with second battery
WI-XML Página 3 de 13
Crafter Current Flow Diagram No. 2 / 3
Terminal 15 relief relay, engine component current supply relay,
fuses (SA, SB, SC, SD)
J179 - Automatic glow period control unit
J293 - Radiator fan control unit
J519 - Onboard supply control unit
J623 - Engine control unit
J757 - Engine component current supply relay
SA1 - Fuse 1 on fuse holder A
SA2 - Fuse 2 on fuse holder A
SA3 - Fuse 3 on fuse holder A
SA4 - Fuse 4 on fuse holder A
SA5 - Fuse 5 on fuse holder A
SA7 - Fuse 7 on fuse holder A
SB2 - Fuse 2 on fuse holder B
SB12 - Fuse 12 on fuse holder B
SB16 - Fuse 16 on fuse holder B
SC16 - Fuse 16 on fuse holder C
SD2 - Fuse 2 on fuse holder D
SD21 - Fuse 21 on fuse holder D
T1e - Single connector, black, on left A-pillar
ws = white
sw = black T14a - 14-pin connector
ro = red T94 - 94-pin connector
br = brown Z35 - Auxiliary heater element
gn = green
bl = blue - Screw connection (30), on fuse holder on battery
507
gr = grey
li = purple
ge = yellow - Positive connection (30a), in dash panel wiring harness
A1
or = orange
rs = pink
- Positive connection (30), in dash panel wiring harness
A32
- Positive connection 4 (30), in dash panel wiring harness
A98
WI-XML Página 4 de 13
Crafter Current Flow Diagram No. 2 / 4
Steering column electronics control unit, turn signal switch,
headlight dipper/flasher switch, intermittent wiper switch
E2 - Turn signal switch
E4 - Headlight dipper/flasher switch
E22 - Intermittent wiper switch
E34 - Rear wiper switch
E44 - Washer pump switch (automatic wash/wipe and headlight
washer system)
J519 - Onboard supply control unit
J527 - Steering column electronics control unit
T6b - 6-pin connector
* - only models with ESP
ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = purple
ge = yellow
or = orange
rs = pink
WI-XML Página 5 de 13
Crafter Current Flow Diagram No. 2 / 5
Steering column electronics control unit, driver side airbag
igniter, horn plate, steering angle sender
F138 - Airbag coil connector and return spring with slip ring
G85 - Steering angle sender
H - Horn plate
J234 - Airbag control unit
J519 - Onboard supply control unit
J527 - Steering column electronics control unit
N95 - Driver side airbag igniter
T2h - 2-pin connector
T7a - 7-pin connector
T14 - 14-pin connector
T96 - 96-pin connector
- Earth point, lower part of right A-pillar
43
* - only models with ESP
** - only models without electronic stability program
ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = purple
ge = yellow
or = orange
rs = pink
WI-XML Página 6 de 13
Crafter Current Flow Diagram No. 2 / 6
Steering column electronics control unit, electronic steering
column lock control unit, electronic ignition lock, steering column
lock control element, ignition key withdrawal lock solenoid
D1 - Immobilizer reading unit
D9 - Electronic ignition lock
J519 - Onboard supply control unit
J527 - Steering column electronics control unit
J623 - Engine control unit
J764 - Electronic steering column lock control unit
N360 - Steering column lock control element
N376 - Ignition key withdrawal lock solenoid
SC2 - Fuse 2 on fuse holder C
T2fa - 2-pin connector
T2fb - 2-pin connector
T2fe - 2-pin connector
T3e - 3-pin connector
T4d - 4-pin connector
T5a - 5-pin connector
T8e - 8-pin connector
T8d - 8-pin connector
T14 - 14-pin connector
T94 - 94-pin connector
ws = white TV26 - Bus system 1 wiring junction, on right A-pillar
sw = black
ro = red - Earth point, lower part of right A-pillar
43
br = brown
gn = green
bl = blue - Earth point, right A-pillar
638
gr = grey
li = purple
ge = yellow - Positive connection 2 (30), in dash panel wiring harness
A52
or = orange
rs = pink
* - only models with ESP
** - only models without electronic stability program
WI-XML Página 7 de 13
Crafter Current Flow Diagram No. 2 / 7
Immobilizer reading unit, electronic ignition lock, distribution
frame 2 for bus systems
D1 - Immobilizer reading unit
D9 - Electronic ignition lock
J519 - Onboard supply control unit
N376 - Ignition key withdrawal lock solenoid
SC3 - Fuse 3 on fuse holder C
T2eb - 2-pin connector, X30/25.2
T2ec - 2-pin connector, X30/25.3
T2ed - 2-pin connector, X30/25.4
T2ef - 2-pin connector, X30/25.6
T8c - 8-pin connector
T8d - 8-pin connector
TV27 - Bus system 2 wiring junction, on right A-pillar
- Earth point, lower part of right A-pillar
43
* - Aerial, placed under dash panel
ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = purple
ge = yellow
or = orange
rs = pink
WI-XML Página 8 de 13
Crafter Current Flow Diagram No. 2 / 8
Light switch
E1 - Light switch
E7 - Fog light switch
E18 - Rear fog light switch
L9 - Light switch illumination bulb
J519 - Onboard supply control unit
T8f - 8-pin connector
- Positive connection (15a), in dash panel wiring harness
A20
- Positive connection 3 (30), in dash panel wiring harness
A57
- Connection 1 (58d), in main wiring harness
B340
ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = purple
ge = yellow
or = orange
rs = pink
WI-XML Página 9 de 13
Crafter Current Flow Diagram No. 2 / 9
Headlight range control regulator, left headlight
E102 - Headlight range control regulator
J519 - Onboard supply control unit
L54 - Headlight range control regulator illumination bulb
L125 - Left main beam bulb
M1 - Left side light bulb
M5 - Front left turn signal bulb
M29 - Left dipped beam bulb
T10a - 10-pin connector
T10b - 10-pin connector
T28 - 28-pin connector, black, lower part of right A-pillar
- Earth point, lower part of right A-pillar
43
- Earth point, on left headlight
655
- Positive connection 2 (15a), in dash panel wiring harness
A38
- Connection (HRC), in main wiring harness
B455
ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = purple
ge = yellow
or = orange
rs = pink
WI-XML Página 10 de 13
Crafter Current Flow Diagram No. 2 / 10
Left headlight, right headlight
J519 - Onboard supply control unit
L126 - Right main beam bulb
M3 - Right side light bulb
M7 - Front right turn signal bulb
M31 - Right dipped beam bulb
T10b - 10-pin connector
T10c - 10-pin connector
V48 - Left headlight range control motor
V49 - Right headlight range control motor
- Earth connection (HRC), in dash panel wiring harness
288
- Earth point, on left headlight
655
- Positive connection 2 (15a), in dash panel wiring harness
A38
- Connection (HRC), in main wiring harness
B455
ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = purple
ge = yellow
or = orange
rs = pink
WI-XML Página 11 de 13
Crafter Current Flow Diagram No. 2 / 11
Fog light, exterior mirror turn signal
J519 - Onboard supply control unit
J386 - Driver door control unit
L22 - Left fog light bulb
L23 - Right fog light bulb
L131 - Driver side exterior mirror turn signal bulb
T4e - 4-pin connector
T4f - 4-pin connector, black, in left A-pillar
T6c - 6-connector, black, in left exterior mirror
T10c - 10-pin connector
T20 - 20-pin connector
- Earth point, on left headlight
655
- Earth point, on right headlight
656
ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = purple
ge = yellow
or = orange
rs = pink
WI-XML Página 12 de 13
Crafter Current Flow Diagram No. 2 / 12
Left tail light, number plate lights, turn signal in right exterior
mirror
J519 - Onboard supply control unit
L20 - Rear fog light bulb
L132 - Front passenger side exterior mirror turn signal bulb
M4 - Left tail light bulb
M6 - Rear left turn signal bulb
M9 - Left brake light bulb
M16 - Left reversing light bulb
T4m - 4-pin connector, white, in left D-pillar
T6d - 6-pin connector, black, on right exterior mirror
T6e - 6-pin connector
T10g - 10-pin connector, white, in right A-pillar
X - Number plate light
- Earth point, left A-pillar
639
- Earth point, left D-pillar
653
- Connection (RL), in dash panel wiring harness
A87
ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = purple
ge = yellow
or = orange
rs = pink
WI-XML Página 13 de 13
Crafter Current Flow Diagram No. 2 / 13
Right tail light, high level brake light, side marker bulbs
J519 - Onboard supply control unit
L20 - Rear fog light bulb
M2 - Right tail light bulb
M8 - Rear right turn signal bulb
M10 - Right brake light bulb
M17 - Right reversing light bulb
M25 - High level brake light bulb
M33 - Front left side marker bulb
M39 - Centre left side marker bulb
ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = purple
ge = yellow
or = orange
rs = pink
