Subject Code
5EC09 R15
VNR VIGNANA JYOTHI INSTITUTE OF ENGINEERING AND TECHNOLOGY
(AUTONOMOUS)
[Link]. III Year II Semester Supplementary Examinations, August 2021
MICRO PROCESSORS AND MICRO CONTROLLERS
(Common to ECE, EEE and EIE)
Time: 3 hours Max. Marks: 60
Answer any FIVE questions.
All Questions carry EQUAL marks.
5X12=60
***
a) a) Indicate the flag register of 8086 Microprocessor.
b) Using suitable examples, brief the arithmetic instructions of 8086.
b) Outline the block diagram of 8255 PPI and brief each block.
c) Define an Interrupt and summarize the 8259 architectures with diagram.
d) Conceptualize and draw the pin configuration of 8051 microcontroller.
e) a) Present the registers TMOD and TCON.
b) Highlight the internal memory organization of 8051 microcontroller.
f) Represent the program to interface LCD with 8051 microcontroller to print a string WORLD.
g) Draw and explain the architecture of 8086 microprocessor.
h) Illustrate the register organization of ARM processor.
***
Subject Code
5EC72 R15
VNR VIGNANA JYOTHI INSTITUTE OF ENGINEERING AND TECHNOLOGY
(AUTONOMOUS)
[Link]. III Year II Semester Supplementary Examinations, August 2021
INTRODUCTION TO MICROPROCESSORS AND CONTROLLERS
(Open Elective)
Time: 3 hours Max. Marks:
60
Answer any FIVE questions
All Questions carry EQUAL marks
5X12=60
***
1. Perform the following binary-arithmetic operations:
(a) 11.10 + 10.11 + 111.00 + 110.11 + 001.01 = ?
(b) 111.00 - 011.11 = ?
(c) 011.11 - 111.00 = ?
(d) 111.001 х 1001.1 = ?
(e) 101011.1 + 1101.11 = ?
2. Draw the functional block diagram of 8085 microprocessor and explain its flag registers
3. Interface the 8255 Programmable Peripheral Interface to 8086 and explain its key features?
4. Explain special function registers in 8051
5. Explain the operating modes of 8051 serial ports?
6. Explain the features and bus organization of 8085 with neat diagram?
7. Draw the functional block diagram of 8051 microcontroller and explain
8. Write an 8051 microcontroller program for real line clock display
***
Subject Code
18PC1EC09 R18
VNR VIGNANA JYOTHI INSTITUTE OF ENGINEERING AND TECHNOLOGY
(AUTONOMOUS)
[Link]. III Year II Semester Regular Examinations, August 2021
MICROPROCESSORS AND MICROCONTROLLERS
(Common to EEE and EIE)
Time: 3 hours
Max. Marks: 60
Answer any FIVE questions.
All Questions carry EQUAL marks.
5X12=60
***
1. 1. Explain any three addressing modes of 8086 processor with suitable examples. 6M CO-1
2. Explain the Register organization of 8086 processor? 6M BL-2
3. 1. Draw the timing diagram for memory write cycle in maximum mode operation 8M CO-1
of 8086 Processor. CO-2
2. What is MACRO? What are the differences between a MACRO & subroutine? 4M BL-4
3. 1. Draw the 8251 USART architecture. 6M CO-3
2. Explain the operation of each block in 8051 USART. 6M BL-2
3. 1. Interfacing of a two 4X4 PROM and two 8X4 RAM with 8086 CPU, draw the 8M CO-3
memory map and interfacing diagram for it. RAM and ROM addresses are CO-1
continuous and end at FFFFFh. BL-4
2. Explain different maskable and non-maskable interrupts of 8086 4M
microprocessor.
3. i. Discuss briefly the various registers in 8051 microcontroller. 6M CO-1
ii. Give the alternative functions for the port pins of port3? 6M BL-2
4. Describe the different modes of operation of timers/counters in 8051 with its 12M CO-2
associated register. BL-3
5. iii. Draw the functional block diagram of 8086 microprocessor and explain. 8M CO-1
iv. Explain any four branch instructions of 8086. 4M CO-2
BL-2
6. v. Explain the interrupt structure of 8051 microcontroller. 6M CO-1
vi. Explain the interrupt cycle of 8086 microprocessor. 6M BL-2
***
Subject Code
18OE1EC02 R18
VNR VIGNANA JYOTHI INSTITUTE OF ENGINEERING AND TECHNOLOGY
(AUTONOMOUS)
[Link]. III Year II Semester Regular Examinations, August 2021
INTRODUCTION TO MICROCONTROLLERS AND INTERFACING
(Open Elective)
Time: 3 hours
Max. Marks: 60
Answer any FIVE questions.
All Questions carry EQUAL marks.
5X12=60
***
1. 1. Draw and explain the basic block diagram of inside the computer. 6M CO-1
2. Convert the following numbers 6M BL-3
1. (378)10= ( )2 ii. (45F)16 = ( )2
2. 1. Explain the various purposes of embedded systems with illustrative examples 6M CO-1
2. Describe the characteristics of Embedded systems. 6M BL-2
BL-3
3. Write and explain the architecture of 8051 Microcontroller and explain the PSW, 12M CO-1
Memory organization. BL-2
4. 1. Write a program to toggle bits of P1 port continuously with 50ms delay. 6M CO-3
2. Give the bit size and data range details for the widely used C datatypes of 6M BL-3
8051.
3. 1. Write 8051 C program to get a byte of data from P1, wait 112second and 6M CO-3
then send it to P2. BL-3
2. Write 8051 C program to monitor bit P1.5, if it is high send 55H to P1 6M
otherwise FDH to P2.
3. 1. Explain in detail about the difference between 8051 Microcontroller 6M CO-1
programming and Arduino board programing. BL-3
2. Write a short note interfacing of 7 segment display with Arduino. 6M
3. 1. Write difference between embedded system and general computing system 6M CO-1
and explain the components of Embedded system. BL-2
2. Discuss the pin diagram of 8051 Microcontroller 6M
3. Write a short note on 12M CO-2
1. Timers and Counters CO-4
2. Design Challenges in Embedded systems BL-2
3. Features of Arduino
***
Subject Code
13ECE009 R13
VNR VIGNAN JYOTHI INSTITUTE OF ENGINEERING AND TECHNOLOGY
(AUTONOMOUS)
[Link]. III Year II Semester Regular Examinations, May, 2016
MICROPROCESSORS AND MICROCONTROLLERS
(Common to EEE, ECE and EIE)
Time: 3 Hours Max. Marks: 70M
PART-A is compulsory
PART-B Answer any FOUR
PART-A (Compulsory) 30 marks
1. Answer in one sentence 5×1=5M
a) Write the special functions of AX register of 8086.
b) List the handshaking signal used in mode 1 of 8255.
c) Distinguish between maskable and non-maskable interrupt?
d) Give an example of immediate addressing mode of 8051.
e) What is the clock frequency of 8051?
2. Answer the following very briefly 5×2=10M
a) What is the function of instruction queue in 8086?
b) Calculate the no. of address and data lines required to access 64K×8
bits of memory
c) Calculate the ISR address for TYPE 3 interrupt.
d) Distinguish between Microprocessor and Microcontroller.
e) Draw the stepper motor interfacing setup using 8051.
3. Answer the following briefly 5×3=15M
a) Write the advantages of memory segmentation.
b) Give the CWR format for I/O mode of 8255.
c) Write short notes on RS-232 standard
d) Explain internal RAM organization of 8051
e) Give the programming model of ARM
PART-B (Answer any FOUR)
Answer any four questions 4×10=40M
4. Explain the various addressing modes supported by 8086 processor with
suitable examples.
5. Interface DAC to 8086 using 8255 and write an ALP to generate a
symmetrical square waveform of 2ms time period.
6. With a neat sketch, explain the architecture of 8251.
7. Explain MODE 1 timer operation of 8051 with help of special function
registers
8. Interface 2×16 LCD and write an ALP to display “All the Best” on first
line.
9. Explain the pipelining concept of ARM Processor
