Annotation
Annotation
Annotation is the critical or explanatory data on a map or image. Usually, annotation works like an overlay of extra graphics to highlight and label important regions or features. Annotation can be drawn in a Viewer or Map Composer window. Some types of annotation are specifically designed for map compositions. ERDAS IMAGINEs annotation includes rectangles, ellipses (including circles), arcs, polygons and polylines, text, grid lines, tick marks, and symbols. In addition, the Map Composer supports scale bars and legends.
Elements
Annotation is made up of single elements. An element can be a rectangle, ellipse, polyline, symbol, etc. Some annotation elements are incorrect if the pixel aspect ratio of the underlying raster image is not equal to 1 (i.e., non-square pixels).
Annotation Layers
An annotation layer is a set of annotation elements that is drawn in a Viewer or Map Composer and stored together in a file. An annotation layer, like a raster or vector layer, can be arranged in a window with the Arrange Layers dialog.
How Annotation is Stored

Viewer Annotation that is created in a Viewer window is stored in a separate file from the other data in the Viewer. These annotation files are called overlay files (.ovr extension). In the Viewer, you can view annotation with the File Selector dialog. Map Composer Map annotation that is created in a Map Composer window is also stored in an .ovr file, which is named after the map composition. For example, the annotation for a map file called MyFirstMap.map would be MyFirstMap.map.ovr. In a Map Frame When annotation in a Viewer is referenced in a Map Composer map frame, that annotation is not saved with the map composition, but remains in its original .ovr file. Since the data are referenced from the original file and not copied, any changes you make to the original .ovr file will appear in the map composition. Likewise, any changes you make to annotation in the map frame will show up in the original .ovr file.
Annotation
Creating New Annotation

To create a new annotation layer, follow these steps:
It is not necessary to have data opened to create an annotation layer, but a georeferenced
raster or vector layer is required if the annotation is to be georeferenced. Annotation created over a non-georeferenced layer will be created in the same units as the underlying layer. To see if the layer you are using as a backdrop is georeferenced, use the Image Info or Vector Info Utilities. 1. Before creating new annotation, select Annotation | Styles... from the Viewer menu bar to use the Annotation Styles dialog. Select the colors and other attributes for your annotation elements, especially if you are creating annotation without a raster layer underneath. Otherwise, the annotation may not be visible, because the default styles are black. You can change the background color of the Viewer to make annotation more visible using the Background Color dialog which is opened by selecting View | Background Color... from the Viewer menu bar. 2. After setting up the Annotation styles, select File | New | Annotation Layer... on the Viewer menu bar. 3. The File Selector dialog is opened, allowing you to enter an output annotation file name (extension .ovr). 4. Click OK after entering the file name. 5. Use the following dialogs to draw and edit annotation:
o Annotation Tools to draw the annotation elements. o Annotation menu commands to arrange, align, group, set properties, reshape, cut, copy,
and paste.
o Symbol Chooser to select, place, create, and edit symbols and symbol libraries. o Other Chooser dialogs to set colors, line style and width, text fonts, and other text
features. After you have selected an annotation tool, you can press the space bar before or while you are drawing to bring up an editor for that element type. These editors enable you to enter precise position and sizing information. Georeferenced Annotation To georeference annotation, the annotation must be created over a georeferenced raster or vector layer. The coordinate system that is used for storing the annotation coordinates depends on the coordinate system used when the annotation layer was created. 2
Annotation If annotation is created with no data underneath, then screen coordinates (pixels) are used.
Like any other georeferenced data, georeferenced annotation data should be displayed in a Viewer alone, or with data that is similarly georeferenced.
Editing Existing Annotation

In a map frame, any changes that you make to annotation and save to the file will also be made in the original annotation .ovr file. In a Viewer or map frame, the annotation layer must be the top layer of data in order to be editable. If necessary, bring the annotation layer to be edited to the top using the Arrange Layers dialog. If you are editing annotation without a raster layer underneath, the annotation may not be visible, because the default styles are black. Left-hold Annotation | Styles... from the Viewer menu bar to use the Annotation Styles dialog to select a different color or change the background color of the Viewer. Selecting Elements To edit existing annotation, you will need to select the element(s) that you want to edit. An element must be selected to be positioned, sized, or rotated. When an element is selected, a bounding box appears around it. The bounding box shows the farthest extent of the element. The bounding box also has grab handles that you can use to size the element in a variety of ways. Use any of the following methods to select one or more elements.
o Use the
tool on the Annotation Tools palette, and then click on an element (or in the interior of a filled element) to select that element. tool, and shift-click on elements to add to a selection. (Shift-click works as a
o Use the
toggle.)
Elements in an underlying (not the top) layer cannot be shift-selected, except when you click inside an existing selection box.
o Use the
tool on the Annotation Tools palette, and then left-hold and drag to delineate a rectangular area. Any element whose bounding box is surrounded by the marquee will be selected.
Annotation To deselect one or all selected elements:
o Shift-click on a selected element. (Shift-click works as a toggle.) o Use the arrow and click outside any element to deselect all elements.
Properties Dialog Each type of element has a Properties dialog, in which you can specify size, position, and other attributes that are specific to that element type. These dialogs include: Arc Properties Ellipse Properties Group Properties Legend Properties Polygon/Polyline Properties Rectangle Properties Scale Bar Properties Symbol Properties Text Properties To open a Properties dialog, do any of the following:
o Select the element and then click Element Properties... from the Annotation menu on the
viewer.
o Double-click on an element that is selected. The element on which you double-click must be
the only element selected.
o In the Viewer category of the Preference Editor category, click the Automatically Display
Properties option to make the properties dialog open whenever an element is selected. Positioning Elements To move an element, you can do any of the following.
o Select one or more elements, and then left-hold on the element and drag it to the new
location. If more than one element is selected, all selected elements will move.
o Open the Properties dialog for the element, and enter explicit coordinates.
Annotation
o Select one or more elements, and then select Utility | Selector Properties... from the Viewer
menu bar to open the Rotbox Editor dialog. Enter explicit coordinates in this dialog. If more than one element is selected, all the selected elements will move. Sizing Elements To change the size of an element, do any of the following.
o Select one element, and then left-hold on a side grab handle to change its proportions.
(Applies to all elements except text.) The center line remains stationary.
o Select one element, and then left-hold on a corner grab handle to change its size and
proportions in both directions (X and Y) in an unconstrained manner. The center point remains stationary.
o Select one element, and then shift-left-hold on any grab handle to change its size with its
current proportions. The center point remains stationary.
o Open the Properties dialog for the element, and enter an explicit size. o Select one or more elements, and then select Utility | Selector Properties... from the Viewer
menu bar to open the Rotbox Editor dialog. Enter the width and height of the box in this dialog. If more than one element is selected, all the selected elements will be resized. Rotating Elements To rotate an element around its center point, do any of the following.
o Select one element, and then middle-hold anywhere on the object and drag to the desired
rotation. You can drag out from the center, beyond the bounding box, for finer control over the rotation. Also, you may middle-hold on the center point of the object, and drag it to a new location before rotating, in order to rotate about a different pivot point.
o Open the Properties dialog for the element and enter an explicit angle of rotation. o Select one or more elements, and then select Utility | Selector Properties... from the Viewer
menu bar to open the Rotbox Editor dialog. Enter the angle of rotation in this dialog. If more than one element is selected, all the selected elements will be rotated.
Annotation Units
If annotation is georeferenced, then you can specify the size, position, and other element properties in either map or paper units. Your selection not only affects the numbers that you use, but the way that your elements may be displayed in a Viewer, Map Composer, or on paper when printed.
Annotation Map Units
If you use map units in any property or style for annotation that is not georeferenced, then
file coordinates are used instead of map units. When you use map units, your annotation size is related to the geographical coordinates. Therefore, if you change the zoom ratio in a Viewer, the annotation will zoom accordingly. In a Map Composer map frame, the map units are preserved within the map frame. If you move the map frame, annotation that is positioned or sized by map units will move and resize relative to the map frame. Paper Units When paper units (points, inches, centimeters, etc.) are used, the element is sized in real-world units for the Viewer or paper. If you have annotation whose position and size is specified in paper units, the following will happen if you change the zoom ratio or move the annotation:
o in a Viewer, the annotation will keep its size and position relative to the Viewer, and will not
be tied to the data.
o in the Map Composer, which represents a sheet of paper, the annotation will zoom in relation
to the sheet of paper. Annotation inside a map frame will move and resize relative to the window, not to the map frame When printed on paper, the position and size will also be relative to the sheet of paper. Therefore, in a Map Composer, the annotation will remain stationary relative to the window as you move the map frame.
Annotation
Symbols
A symbol is a pre-drawn element that is stored in a symbol library. These are commonly used map symbols such as north arrows, school, church, picnic area, landmark, and many others. To select a symbol from the symbol library, place it, and size it, follow these steps. 1. Use the Symbol Chooser dialog to select a symbol. 2. After choosing the symbol to use, place the symbol in an annotation layer with the tool on the Annotation Tools palette. Click in the Viewer or Map Composer at the desired location, and the symbol will appear. 3. You may change this symbol later if needed by selecting the symbol and then selecting a different symbol name from the Symbol Chooser dialog.
Styles do not apply to symbols. Be aware that resizing a symbol to make it very small may
shift the data in the underlying raster layer. Symbol Editor You can also create your own symbols and symbol libraries by editing those that are delivered with ERDAS IMAGINE or by generating new ones with the Symbol Editor.
Groups
Separate elements can be put into a group of elements. A group can be selected and treated as a single element. Properties and commands can be applied to a group. A group can also include other groups. To create a group from a set of elements, select multiple elements and select Group from the Annotation menu on the Viewer menu bar. These elements remain as a group until they are ungrouped by selecting Ungroup from the Annotation menu on the Viewer menu bar.
Annotation
Cut, Copy, and Paste

Cut, Copy, and Paste are buttons in the Annotation menu. To cut (delete) or copy one or more elements, select the element(s) and Click the Cut or Copy button. If you use Cut, the element(s) will disappear from the Viewer or Map Composer window. When you Cut or Copy an element, it is saved in a temporary buffer until another element is cut or copied. Only one element or selected set of elements is stored in the buffer at a time. That is, only one Copy or Cut operation is saved. If you perform one Cut followed immediately by another cut, the product of the first Cut operation is lost. You can retrieve the contents of the buffer by using Paste. When you paste an element (or a set), it is opened at the same position as the original from which it was cut or copied, according to the units and coordinates that were specified for the original element.
If you copy an element within the same Viewer or Map Composer, the copy will overlap the
original exactly so that you cannot see it. Select the copy and move it to the desired location.
Annotation
Styles
Styles for annotation include:
o Fill styles, used for polygons, ellipses, and rectangles, o Line styles, used for polylines and unfilled polygons, rectangles, arcs, and ellipses, and o Text styles, used for text elements.
Styles are specified with the Annotation Styles dialog.
Styles do not apply to symbols.

Lines and Outlined Elements Polylines have a line style. Line styles can also be used on rectangles, ellipses, and polygons when they are outlined. A line style is described by:
o texture, which is the dot or dash pattern of the line, o whether it a double or single line, consisting of one or two colors, o the color(s), and o width.
These attributes are specified with the Line Style Chooser dialog. When an element is outlined, the width of the line style is added to the thickness or width of the element. The center of the outline is positioned on the edge of the element, so that half of the width is in the interior of the element, and half of the width is on the exterior.
Text is not outlined with a line style, but with a solid line specified by the Use Outline color in
the Fill Style Chooser dialog. The width of the text outline, however, is specified as the width of the line style. Filled Elements Rectangles, ellipses, polygons, and text are filled elements. You can specify a fill style for these elements, consisting of:
o the option to fill the element and a fill color, and
Annotation
o the option to outline the element and the outlines line style or color. (Text is outlined with
one color only, not with a line style.) These attributes are specified with the Fill Style Chooser dialog. Text Styles A text style is described by:
o the font used, o the size of the text, o the option for italics, o the option to underline the text and the underline color (which is the same as the fill color), o the option for a shadow and the shadow color, and o the fill style (including the option to outline).
These attributes are specified with the Text Style Chooser dialog. Text Size ERDAS IMAGINE uses the typographic definition of point size for text size (whether or not the text size units are points). Although it depends on the definition of the font, in general, text size is the measure of distance from the top of the highest ascender to the bottom of the lowest descender. This distance is used as the inter-baseline distance. The characters of different fonts displayed or printed at the same text size may appear very different in size; however, at the same text size the distance between the baselines of multiple lines of text in a paragraph will be the same.
This is 18 point text.

Other Fonts
This is also 18 point text.
ERDAS IMAGINE includes several international fonts and a graphical keyboard to make using those fonts easier. This keyboard also allows you to use special characters, such as , , , etc. See the Keyboard On-Line Help for more information. On some UNIX machines you can also type in special characters using the compose key on your keyboard. See the Compose Key document for details.
10
Annotation
Text Following a Polyline

You can create text that follows a polyline to more easily label streams, contours, or other nonlinear elements. Follow the steps below: 1. Create a text string. 2. Click on the text string to select it. 3. Select the Reshape command from the Annotation menu. A polyline is opened under the text. 4. Move the polyline vertices and/or segments and add vertices (middle-click) to create the desired shape. (Shift-middle-click to delete vertices.) The text will follow the shape of the polyline. You can also select Element Properties... from the Annotation menu to open the Text Properties dialog to further define the polyline. The Vertical Align options do not apply, but the Horizontal Align options allow you to align the text string with the right, left, or center of the polyline. Right align
Left align
Center align
To move or resize the entire line, select it and move/resize the bounding box. Once text is created to follow a polyline, any new text added to that string will also follow that polyline, as in the example below. New text added will follow the direction indicated by the arrow. Text
Using the Arc Tool

You can draw arcs as annotation by selecting the tool from the tool palette.
Left-hold and drag the arc tool in the Viewer to create an arc.
11
Annotation Reshaping the Arc To reshape the arc, select it and then select Reshape from the Annotation menu. The arc Reshape control handles will display, similar to the following example:
Changes end point
Changes height of arc Left-hold to rotate entire arc
Changes width of arc Center of arc Click here to move entire arc Changes start point There are two types of reshape controls for arcs: handles with circles and handles with squares. You control these handles by clicking on the circle or square that appears at the end of the handle and dragging in the direction you want to reshape the arc.
o Handles with circles control the start and end point of the arc. These handles can be any
length while reshaping the arc. The length does not affect the reshaping.
o Handles with squares control the width and height of the arc. The length of the handle
directly corresponds to the width and height the arc.
o The width and height control handles (with the square end) can also be used to rotate the
entire arc. Middle-hold on either of these squares and drag to rotate the arc.
o Left-hold and drag the square handle that represents the center of the arc to move the entire
arc to a new location.
o You can also press the space bar while reshaping an arc to bring up the Ellipse Editor dialog
in which you can enter precise sizing and position information. This is a tool you will understand easily with a little experimentation.
12
Annotation Remember that when creating a circle or circular arc by pressing the shift key while drawing, the mouse button should be released before the shift key.
13
Compose Key Characters

UNIX Only You can use the Compose key (Sun systems) on your keyboard in combination with other keys to create special characters, such as , , , etc. These characters can be used in many ERDAS IMAGINE applications in which you enter text, such as annotation for map compositions. Use the table below for instructions on creating these special characters. For example, to make , press Compose-n-~ in succession without any intervening space. The Compose key does not have to be held while making the special character. You must preceed each two-character sequence in the table below with the Compose key. The table consists of the special character on the left with the sequence of characters required to produce it. Char. Compose Key Sequence
If your keyboard does not have a Compose key, or if you are using a platform other than Sun,
consult your system manuals for the correct keys to use to create these special characters.
These characters may look slightly different on your system, due to the font you are using,
size, etc.
A non-breaking space is generated with the sequence: Compose space space.
14
A a A a A a A a A a A a A a C c C c C c d D E e E e E e E e
^ ^ ~ ~ " " * * E e , , / / O o ^ ^ " "
I i I i I i I i L l N n O o O o O o O o O o O o O o P p P p
^ ^ " " ~ ~ ^ ^ " " ~ ~ / / X x | | ! !
Y y
R r S s s T t U u U u U u U u x Y y y Y y | -
O o O o s H h ^ ^ " " x " | A a : | , O o

1 2 3
1 /4 1 /2 3 /4
/ ^ ^ ^ ^ ^ ^ + 1 1 3 < > ! ? " \ ,
u * . 1 2 3 4 2 4 < > ! ? " \ ,
15
Annotation Tools
Annotation Tools
The Annotation Tools palette lets you create annotation in a Viewer or Map Composer window. The first ten tools on the Annotation Tools palette are available for annotation only. You can use the Grid/Tic tool in a Viewer and a map composition, and you can use the Region Growing tool only in a Viewer. To enter specific position and size parameters, you can press the space bar while drawing many annotation objects and a dialog is opened allowing you to enter precise coordinates and size information. To use the Annotation Tools palette, select Annotation | Tools... from the Viewer menu bar or Map Composer menu bar or click the the top layer in the Viewer. icon on the Viewer tool bar if the annotation layer is
Click on this arrow tool to select annotation elements for moving, sizing, or rotating.
Use this marquee tool to select multiple elements contained in within the area drawn by the tool. To draw a perfect square, use shift-left-hold when drawing.
To draw a rectangle, click the icon, and then drag in the window from the upper left to the lower right corner of the desired rectangle. To draw a perfect square, use shift-left-hold when drawing.
To draw an ellipse, click the icon, and then drag in the window from the center of the desired ellipse to any corner. To draw a perfect circle, use shift-left-hold when drawing.
To draw a polygon, click the icon and then click in the window to add each vertex. Double-click or middle-click to close the polygon, depending on how your preference is set.
To draw a polyline, click the icon and then click in the window to add each vertex. Double-click or middle-click to end the polyline, depending on how your preference is set.
To draw an elliptical arc, click the icon, then drag in the Viewer to draw the arc.
16
Annotation Tools
To place a symbol, click the icon and then click in the window to designate the center point of the symbol. Use the Symbol Chooser dialog to select a symbol. The last symbol selected is the default symbol.
To enter text, click the icon and then click in the Viewer to designate the lower left corner of the beginning of the text string. The Annotation Text dialog is opened, allowing you to enter the text.
In the image underlying the annotation layer, select a single pixel from which a polygonal area grows based on the parameters set in the Region Growing Properties dialog.
Use this tool in a Map Composer window only. To draw a map frame, click the icon, then click in the Map Composer window to anchor one corner of the map frame, and drag from the upper left to the lower right corner of the desired map frame. To draw a perfect square, use shift-left-hold when drawing. The Map Frame Data Source dialog is opened. If the map frame is to be lled with data from a Viewer, click on Viewer, and then follow the Create Frame Instructions that appear. After a Viewer has been selected, the Map Frame dialog is opened.
Use this tool in a Map Composer window only. To select a map frame, click this icon, and click in the map frame.
Use this tool to create grids/ticks in a map composition or in a Viewer. To add grid lines or tick marks, click the icon and then click in the map frame or Viewer for which you want to make grids/ticks. The Set Grid/Tick Info dialog is opened.
Use this tool in a Map Composer window only.
17
Annotation Tools To add scale bars to your map composition, click the icon, and then drag in the Map Composer to draw a bounding box to contain the scalebar(s). Follow the Scalebar Instructions that appear. After clicking in the map frame you want to use, the Scale Bar Properties dialog is opened.
Use this tool in a Map Composer window only. To create a legend for your map composition, click the icon, and then click in the Map Composer where you want the upper left corner of the legend to appear. Follow the Legend Instructions that appear. After clicking in the map frame that you want to use, the Legend Properties dialog is opened.
Click to see this On-Line Help document.
Indicates that the current tool is locked and will remain active until you select another tool.
Click to lock the current tool.
Close Click to close this dialog. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
For step-by-step instructions on using these tools to create a map composition, see the
ERDAS IMAGINE Tour Guides. Cartography is discussed in the ERDAS Field Guide.
18
Annotation Tools (Large Format)

The Annotation Tools palette lets you create annotation in a Viewer or Map Composer window. The top ten tools on the Annotation Tools palette are available for annotation only. You can use the Grid/Tic tool in a Viewer and a map composition, and you can use the Region Growing tool only in a Viewer. To enter specific position and size parameters, you can press the space bar while drawing many annotation objects and a dialog is opened allowing you to enter precise coordinates and size information. To use the Annotation Tools palette, select Annotation | Tools... from the Viewer menu bar or Map Composer menu bar or click the the top layer in the Viewer. icon on the Viewer tool bar if the annotation layer is
Use this marquee tool to select multiple elements contained in within the area drawn by the tool. To draw a perfect square, use shift-left-hold when drawing.
To draw an ellipse, click the icon, and then drag in the window from the center of the desired ellipse to the lower right corner. To draw a perfect circle, use shift-left-hold when drawing.
19
To place a symbol, click the icon and then click in the window to designate the center point of the symbol. Use the Symbol Chooser dialog to select a symbol. The last symbol selected is the default symbol.
To enter text, click the icon and then click in the Viewer to designate the lower left corner of the beginning of the text string. The Annotation Text dialog is opened, allowing you to enter the text.
In the image underlying the annotation layer, select a single pixel from which a polygonal area grows based on the parameters set in the Region Growing Properties dialog.
Use this tool in a Map Composer window only. To draw a map frame, click the icon, then click in the Map Composer window to anchor one corner of the map frame, and drag from the upper left to the lower right corner of the desired map frame. To draw a perfect square, use shift-left-hold when drawing. The Map Frame Data Source dialog is opened. If the map frame is to be lled with data from a Viewer, click on Viewer, and then follow the Create Frame Instructions that appear. After a Viewer has been selected, the Map Frame dialog is opened.
20
Use this tool in a Map Composer window only. To add scale bars to your map composition, click the icon, and then drag in the Map Composer to draw a bounding box to contain the scalebar(s). Follow the Scalebar Instructions that appear. After clicking in the map frame you want to use, the Scale Bar Properties dialog is opened.
Use this tool in a Map Composer window only. To create a legend for your map composition, click the icon, and then click in the Map Composer where you want the upper left corner of the legend to appear. Follow the Legend Instructions that appear. After clicking in the map frame that you want to use, the Legend Properties dialog is opened.
Keep Tool Click this checkbox to lock the currently selected tool for repeated use. Click
again to unlock.
Close Click to close this dialog. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual. 21
22
Annotation Tools and Commands

The Annotation Tools palette lets you create annotation in a Viewer or Map Composer window. The top ten tools on the Annotation Tools palette are available for annotation only. You can use the Grid/Tick tool in a Viewer and a map composition, and you can use the Region Grow tool only in a Viewer. To enter specific position and size parameters, you can press the space bar while drawing many annotation objects and a dialog is opened allowing you to enter precise coordinates and size information. To use the Annotation Tools palette, select Annotation | Tools... from the Viewer menu bar or Map Composer menu bar or click the the top layer in the Viewer. icon on the Viewer tool bar if the annotation layer is
Use this marquee tool to select multiple elements. To draw a perfect square, use shiftleft-hold when drawing.
23
To place a symbol, click the icon and then click in the window to designate the center point of the symbol. Use the Symbol Chooser dialog to select a symbol.
To enter text, click the icon and then click in the window to designate the lower left corner of the beginning of the text string. The Annotation Text dialog is opened, allowing you to enter the text.
Select a single pixel from which a polygonal area grows based on the parameters set in the Region Growing Properties dialog.
Use this tool in a Map Composer window only. To draw a map frame, click the icon, and then drag in the window from the upper left to the lower right corner of the desired map frame. To draw a perfect square, use shift-left-hold when drawing. The Frame Source dialog is opened. Then follow the Create Frame Instructions that appear. The Map Frame dialog is opened.
Use this tool in a Map Composer window only. To add scale bars to your map composition, click the icon, and then drag in the Map Composer to draw a bounding box to contain the scalebar(s).
24
Annotation Tools and Commands Follow the Scalebar Instructions that appear. Then, the Scale Bar Properties dialog is opened.
Use this tool in a Map Composer window only. To create a legend for your map composition, click the icon, and then click in the Map Composer where you want the upper left corner of the legend to appear. Follow the Legend Instructions that appear. Then, the Legend Properties dialog is opened.
Click to undo the last edit. Select multiple times to undo a series of edits (back to the last saved version of this annotation layer).
Click to delete the selected element(s). A copy is kept in a copy/paste buffer.
Click to make a copy of the selected element(s) to a copy/paste buffer.
Click to paste the element(s) from the copy/paste buffer.
Click to reshape a selected polygon, polyline, arc, or AOI. This option also lets you create or reshape the invisible polyline that text may follow:
o left-hold to move a vertex of the polygon, polyline or text polyline; o middle-click to add a vertex to the polygon, polyline or text polyline; o shift-middle-click to add or remove a vertex from the polygon, polyline or text
polyline;
o left-hold on any side of a polygon or segment of a polyline or text polyline to

move it without rotating. To quit reshape mode, click outside the element or select another element. If you are reshaping an arc, you can press the space bar for more reshaping options. The Ellipse Editor dialog is opened.
25
Click to combine the selected elements into a group element.
Click to break a group element into single elements.
Click to open the Properties dialog for the selected element:
o Text o Ellipse o Arc o Rectangle o Polygon/Polyline o Symbol o Map frame o Group

Click to move the selected element(s) in front of all others in the drawing order.
Click to move the selected element(s) forward by one rank in the drawing order.
Click to move the selected element(s) behind all others in the drawing order.
Click to move the selected element(s) back by one rank in the drawing order.
Click to align the selected elements. The Align dialog is opened.
Click to automatically point the selected element(s) to the north.
26
Annotation Tools and Commands If the selected elements are part of a normal annotation layer, the layer must be registered to a map projection. If the selected elements are part of the annotation layer of a map composition, you will be asked to select the frame to which to align the elements. The data in the frame you select must be registered to a map projection.
Click to evenly distribute the centers of selected elements vertically between the top element and the bottom element.
Click to evenly distribute the centers of selected elements horizontally between the right element and the left element.
Click to ip selected annotation vertically.
Click to ip selected annotation horizontally.
Click open the Annotation Styles dialog.
Click to open the Annotation Attributes dialog.
Click to open the Region Growing Properties dialog.
Click to add the currently selected Vector or AOI to the top annotation layer in the current viewer.
Click to create a new digitizing tablet conguration. The Tablet Setup dialog is opened.
Click to use an existing tablet conguration. The Map Setup dialog is opened along with the Tablet Status dialog.
27
click to lock the current tool.
Close click to close this dialog.

For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
ERDAS IMAGINE Tour Guides. Cartography is discussed in the ERDAS Field Guide
28
Annotation Tools and Commands (Large Format)

The Annotation Tools palette lets you create annotation in a Viewer or Map Composer window. The top ten tools on the Annotation Tools palette are available for annotation only. You can use the Grid/Tick tool in a Viewer and a map composition, and you can use the Region Grow tool only in a Viewer. To enter specific position and size parameters, you can press the space bar while drawing many annotation objects and a dialog is opened allowing you to enter precise coordinates and size information. To use the Annotation Tools palette, select Annotation | Tools... from the Viewer menu bar or Map Composer menu bar or click the the top layer in the Viewer. icon on the Viewer tool bar if the annotation layer is
Use this marquee tool to select multiple elements. To draw a perfect square, use shift-left-hold when drawing.
29
To place a symbol, click the icon and then click in the window to designate the center point of the symbol. Use the Symbol Chooser dialog to select a symbol.
To enter text, click the icon and then click in the window to designate the lower left corner of the beginning of the text string. The Annotation Text dialog is opened, allowing you to enter the text.
Select a single pixel from which a polygonal area grows based on the parameters set in the Region Growing Properties dialog.
Use this tool in a Map Composer window only. To draw a map frame, click the icon, and then drag in the window from the upper left to the lower right corner of the desired map frame. To draw a perfect square, use shift-left-hold when drawing. The Frame Source dialog is opened. Then follow the Create Frame Instructions that appear. The Map Frame dialog is opened.
30
Use this tool in a Map Composer window only. To add scale bars to your map composition, click the icon, and then drag in the Map Composer to draw a bounding box to contain the scalebar(s). Follow the Scalebar Instructions that appear. Then, the Scale Bar Properties dialog is opened.
Use this tool in a Map Composer window only. To create a legend for your map composition, click the icon, and then click in the Map Composer where you want the upper left corner of the legend to appear. Follow the Legend Instructions that appear. Then, the Legend Properties dialog is opened.
Click to undo the last edit. Select multiple times to undo a series of edits (back to the last saved version of this annotation layer).
Click to delete the selected element(s). A copy is kept in a copy/paste buffer.
Click to make a copy of the selected element(s) to a copy/paste buffer.
31
Click to paste the element(s) from the copy/paste buffer.
Click to reshape a selected polygon, polyline, arc, or AOI. This option also lets you create or reshape the invisible polyline that text may follow:
o left-hold to move a vertex of the polygon, polyline or text polyline; o middle-click to add a vertex to the polygon, polyline or text polyline; o shift-middle-click to add or remove a vertex from the polygon, polyline or text
polyline;
o left-hold on any side of a polygon or segment of a polyline or text polyline to

move it without rotating. To quit reshape mode, click outside the element or select another element.
Click to combine the selected elements into a group element.
Click to break a group element into single elements.
32
Click to open the Properties dialog for the selected element:
o Text o Ellipse o Arc o Rectangle o Polygon/Polyline o Symbol o Map frame o Group
Click to move the selected element(s) in front of all others in the drawing order.
Click to move the selected element(s) forward by one rank in the drawing order.
Click to move the selected element(s) behind all others in the drawing order.
Send Selected Annotation Backward One
Click to align the selected elements. The Align dialog is opened.
Align Selected Annotation Toward North
33
Click to automatically point the selected element(s) to the north. If the selected elements are part of a normal annotation layer, the layer must be registered to a map projection. If the selected elements are part of the annotation layer of a map composition, you will be asked to select the frame to which to align the elements. The data in the frame you select must be registered to a map projection.
Click to evenly distribute the centers of selected elements horizontally between the right element and the left element.
Click to ip selected annotation vertically.
Click to ip selected annotation horizontally.
Click open the Annotation Styles dialog.
Click to open the Annotation Attributes dialog.
Click to open the Region Growing Properties dialog.
Click to add the currently selected Vector or AOI to the top annotation layer in the current viewer.
34
Click to create a new digitizing tablet conguration. The Tablet Setup dialog is opened.
Click to use an existing tablet conguration. The Map Setup dialog is opened along with the Tablet Status dialog.
click to lock the current tool.
Close click to close this dialog.

Interface manual.
35
Annotation Text
Annotation Text
This dialog lets you enter text to be placed in the Viewer or Map Composer as annotation. To use this dialog, click on the icon on the Annotation Tools palette.
Then click in the Viewer or Map Composer where you want the text to appear. When text has a shadow and is outlined, the outline will always be one pixel wide.
Enter Text String: Click in the text eld and type in the text as you want it to appear in the Viewer or map composition.
You can also use foreign fonts and special characters, such as , , , etc., using the Keyboard option below, or using the Compose key on some UNIX machines (see the Compose Key document for details).
Cut Click to cut the selected text string. Copy Click to copy to selected text string to the buffer. Paste Click to paste the buffer contents into the text string at the cursor position. Keyboard... Click to use a graphical keyboard to use foreign fonts or to enter special
characters. The Keyboard dialog is opened.
ASCII File... Click to import text from an existing ASCII le. The File Selector dialog is
opened.
OK Click to use the text entered and close this dialog. Cancel Click to close this dialog without making any changes. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
36
Annotation Commands
Annotation Commands
These Annotation Commands let you control the placement of annotation elements in the Viewer or Map Composer. This dialog cannot be reached using the IMAGINE user interface. It can only be accessed through EML application functions commands. These commands are also found in the Annotation menu on the Viewer, and in the Annotation Tools and Commands palette.
You can also is opened these commands as icons in the annotation tool palette. This option
is set in the viewer category of the Preference Editor.
Properties ... Left-click to open the Properties dialog for the selected element: o Text o Ellipse o Arc o Rectangle o Polygon/Polyline o Symbol o Map frame o Group Bring to Front Left-click to move the selected element(s) in front of all others in the
drawing order.
Bring Forward Left-click to move the selected element(s) forward by one rank in the
drawing order.
Send to Back Left-click to move the selected element(s) behind all others in the drawing
order.
Send Backward Left-click to move the selected element(s) back by one rank in the
drawing order.
Group Left-click to combine the selected elements into a group element. Ungroup Left-click to break a group element into single elements.
37
Annotation Commands
Align ... Left-click to align the selected elements. The Align dialog is opened. Align North Left-click to automatically point the selected element(s) to the north.
If the selected elements are part of a normal annotation layer, the layer must be registered to a map projection. If the selected elements are part of the annotation layer of a map composition, you will be asked to select the frame to which to align the elements. The data in the frame you select must be registered to a map projection.
Distribute Vert Left-click to evenly distribute the centers of selected elements vertically
between the top element and the bottom element.
Distribute Horiz Left-click to evenly distribute the centers of selected elements

horizontally between the right element and the left element.
Reshape Left-click to reshape a selected polygon, polyline, arc, or AOI. This option also
lets you create or reshape the invisible polyline that text may follow: left-hold to move a vertex of the polygon, polyline or text polyline; middle-click to add a vertex to the polygon, polyline or text polyline; shift-middle-click to add or remove a vertex from the polygon, polyline or text polyline; left-hold on any side of a polygon or segment of a polyline or text polyline to move it without rotating. To quit reshape mode, left-click outside the element or select another element. To enter precise size and positioning coordinates when reshaping an arc, press the space bar after left-clicking Reshape to bring up the Ellipse Editor dialog.
Cut Left-click to delete the selected element(s). A copy is kept in the copy/paste buffer. Copy Left-click to make a copy of the selected element(s) in the copy/paste buffer. Paste Left-click to paste the contents of the copy/paste buffer to the same location. Select
the copied element and move it to the desired location.
Undo Left-click to undo the last edit. Select multiple times to undo a series of edits (back
to the last saved version of this annotation layer).
Close Left-click to close this dialog.
38
Annotation Commands
Help Left-click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
For more information about creating and using annotation, see the Annotation section at the
beginning of this manual.
39
Keyboard
Keyboard
This dialog is opened when you left-click Keyboard from the Annotation Text or Text Properties dialogs. It enables you to easily use foreign fonts (Arabic, Hebrew, Thai, etc.) and characters that are not part of the standard ASCII set that is normally used. On some UNIX machines these are characters that can be created using the Compose Key. You can enter regular text by typing on the keyboard then add these special characters by leftclicking the appropriate key on the graphical keyboard in this dialog. If you are using any of the foreign fonts, text entered by left-clicking on the graphical keyboard will be entered in the direction that it is read (e.g., right to left for Hebrew and Arabic). Text typed on the keyboard will be entered left to right. The string in the text area will also appear in the selected font for easier editing.
(Text Area) Text typed in from the keyboard or entered using the graphical keyboard is
opened here. If you have typed text in the Annotation Text dialog box before left-clicking the Keyboard option or if you are editing a string from the Text Properties dialog, then that text is opened here. The text in this area is opened in the standard font used in the ERDAS IMAGINE interface, regardless of the font selected. The only exceptions to this are the foreign fonts.
Cut Left-click to cut the selected text from the text string. Copy Left-click to copy the selected text string to the buffer. Paste Left-click to paste the buffer contents into the text string at the cursor position. (Graphical Keyboard) Left-click on the appropriate key to enter that character at the
cursor position in the text area above. The characters on the graphical keyboard will appear in the font that you have selected for the string. Use the arrows on either side of the space bar to move the cursor in the text string. The following keys perform specic actions. Shift Click to view additional characters including capital letters. Click to view characters in the high range of the ASCII character set. Click Shift, then HIANSI for the highest range of the ASCII character set.
HIANSI
Shift-HIANSI
BS Click the BS (backspace) key to move the cursor in the text area back one space to delete one character.
40
Keyboard ENTER Click for a carriage return.
Del These keys are not used. Tab CTRL Alt
OK Click to accept this text string, close this dialog box, and copy the text to the dialog from
which the Keyboard was initiated.
Cancel Click to close the Keyboard dialog without changing the text string. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
41
Map Frame
Map Frame
This dialog lets you set up the scale, map area, and frame area for a map frame in the Map Composer window. This dialog is opened after you draw a new map frame with the Tools palette. icon on the Annotation
You can also open this dialog by double-clicking inside the selected map frame or by selecting Element Properties from the Annotation menu.
When using the Map Frame Properties dialog to edit an existing map frame, do not replace
map frame contents with another image that is referenced to a different projection system. These dimensions can also be set using the frame area box and the map area box.
Name: Enter the name of the map frame. Change Map and Frame Area (Maintain Scale) Select to hold constant the scale
of the data in the map frame while changing map area and frame area.
Change Scale and Frame Area (Maintain Map Area) Select to hold constant the
map area of the data in the map frame while changing scale and frame area.
Change Scale and Map Area (Maintain Frame Area) Select to hold constant the frame area of the data in the map frame while changing map area and scale. Scale 1: Set the scale for the map frame with this number eld. Map Area Width: Set the width (in map units) of the map area box in the Viewer.
Height: Set the height (in map units) of the map area box in the Viewer.
Frame Width: Set the width (in paper units) of the frame area box in the map
composition. Height: Set the height (in paper units) of the frame area box in the map composition.
Map Angle: Enter the angle to rotate the selected portion of the source image. (You can change your image area later if you are not happy with it.) Use Entire Source Set the map area to the union of the areas of all images displayed
in the Viewer.
42
Map Frame
Upper Left Map Coordinates: Enter the X and Y coordinates in map units for the
upper left corner of the map area box. X: Enter the X-Coordinate of the Upper Left Corner of the Map Area Y: Enter the Y-Coordinate of the Upper Left Corner of the Map Area
Upper Left Frame Coordinates: Enter the X and Y coordinates in paper units for the
upper left corner of the frame area box. X: Enter the X-Coordinate of the Upper Left Corner of the Frame Area Y: Enter the Y-Coordinate of the Upper Left Corner of the Frame Area
OK Click to create a map frame with the options selected and close this dialog. Cancel Click to close this dialog. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
For step-by-step instructions on creating a map composition, see the ERDAS IMAGINE Tour
Guides. Cartography is discussed in the ERDAS Field Guide.
43
Set Grid/Tick Info
Set Grid/Tick Info

This dialog lets you place a neat line, grid lines, and tick marks around a map frame in a map composition or over an image in the Viewer. To use this dialog, click on the Annotation Tools palette. icon on the
Then click in the map frame or Viewer where you want grid/ticks to appear. If placing grid/ticks over data in a Viewer, you must have an annotation layer on top in which to put the grid/ticks. The line style for the grid/ticks, and the text style used to label grid/ticks are specified with the Annotation Styles dialog and should be set in advance. If placing grid/ticks on a map frame, these elements are configured around the existing map frame. However, they are not a part of the map frame, and will not move or resize with the map frame. Always add these elements after the map frame position and dimensions are set. If placing grid/ticks over data in a Viewer, these elements are configured around the maximum bounding area of all data displayed in the Viewer. Once created, they will not move or resize with the data. If you want the grid/ticks to strictly cover a certain data set, create the grid/ticks before placing data in the Viewer which extends outside of that data set. Also, once you place grid/ticks in an annotation layer, the extent of that layer will grow to include the grid/ticks. If you want to redo the grid/ticks, delete any existing ones and save the layer (this will reset the extent of the layer) or close the layer without saving it and re-open it, then try again. You can redo or apply while this dialog is open without the new grid/ticks affecting the data area.
Name: Enter a name for this grid/tick element. Description: Enter a brief description of this grid/tick element. Geographic Ticks Turn on this check box if the map data have been georeferenced and
you want to use geographic ticks. The check box will be enabled if the data are not georeferenced. If the data on which the grid/ticks are being placed are rotated, you must use non-geographic ticks.
Neat line Turn on this check box if you want to make a neat line border around the map
frame. Enter the width of the neat line in the number eld. Margin Enter the margin between the image and the neatline in the units selected. Select the units to use for the setting the size of the margin and the tick
(units popup) lengths. Points
The margin and ticks will be measured in points. The margin and ticks will be measured in centimeters
Centimeters
44
Set Grid/Tick Info Inches The margin and ticks will be measured in inches. This is the default.
The following options are valid only when you are using Geographic Ticks.
Map Units: Select the units for the grid/ticks. You can select only the options that are appropriate for your map data. The options that appear will depend on the data you are using.
Meters Feet Other The map units are in meters.
The map units are in feet. The map units are in other units. The map units are decimal degrees.
Decimal Degrees Deg Min Sec
The map units are in degrees, minutes, and seconds.
Set Destination Projection... Click to specify the projection to use for the grids/ticks.
Use this option to create grids/ticks in a projection other than the projection to which the data are registered. For example, if your map frame contains State Plane data, but you want to show grids and ticks in UTM coordinates, you would use this option. The Projection Chooser dialog is opened. The currently selected projection is the one used by the data in the map frame or the last one selected.
Horizontal Axis Use this tab to specify grid/tick size and spacing for the horizontal axis
(top/bottom of the map frame). Length Outside: Enter the length of the tick marks outside the map frame or neat line.
Length Inside: Enter the length of the tick marks inside the map frame or neat line. This option is not available when Use Full Grid is selected for the horizontal axis. Length Intersect: Enter the length of grid lines at each grid intersection. This option is not available when Use Full Grid is selected for the horizontal axis. Starting at: Enter the X map coordinate at which to begin grid/ticks. The default is the X map coordinate of the left side of the map frame, rounded up to the next even value of the magnitude of the Spacing: below. Spacing: Enter the spacing between grid/ticks in map units. Copy the information for the horizontal axis to the vertical axis.
Copy to Vertical
Use Full Grid Turn on this check box to create solid vertical grid lines between the horizontal axes. 45
Set Grid/Tick Info Number of lines Shows the number of ticks or grid lines that will appear along this axis, based on Starting at: and Spacing: above. (Horizontal Labels Table) This CellArray contains the labels for each tick. The defaults are the X map coordinates. These can be edited and formatted using the CellArray functions.
Vertical Axis Use this tab to specify grid/tick size and spacing for the vertical axis (left/
right sides of the map frame). Length Outside: Enter the length of the tick marks outside the map frame or neat line.
Length Inside: Enter the length of the tick marks inside the map frame or neat line. This option is not available when Use Full Grid is selected for the vertical axis. Length Intersect: Enter the length of grid lines at each grid intersection. This option is not available when Use Full Grid is selected for the vertical axis. Starting at: Enter the Y map coordinate at which to begin grid/ticks. The default is the Y map coordinate of the bottom of the map frame, rounded up to the next even value of the magnitude of the Spacing: below. Spacing: Enter the spacing between grid/ticks in map units. Copy the information for the vertical axis to the horizontal axis.
Copy to Horizontal Use Full Grid vertical axes.
Turn on this check box to create solid horizontal grid lines between the
Number of lines Shows the number of ticks or grid lines that will appear along this axis, based on Starting at: and Spacing: above. (Vertical Labels Table) This CellArray contains the labels for each tick. The defaults are the Y map coordinates. These can be edited and formatted using the CellArray functions.
The following options are valid only when you are using non-Geographic Ticks.
Number of Tick Levels: Enter the number of tick levels to use. Current Tick Level: Enter the current tick level. The length and other information
entered below will pertain to this level only.
Horizontal Axis Use this tab to specify grid/tick size and spacing for the horizontal axis
(top/bottom of the map frame).
46
Set Grid/Tick Info Length Outside: Enter the length of the tick marks outside the map frame or neat line.
Length Inside: Enter the length of the tick marks inside the map frame or neat line. This option is not available when Use Full Grid is selected for the horizontal axis. Length Intersect: Enter the length of grid lines at each grid intersection. This option is not available when Use Full Grid is selected for the horizontal axis. Divisions: Enter the number of divisions between tick marks at this level.
A division is the space between adjacent tick marks. This number of divisions refers to the total number of divisions on the map frame axis between ticks of the next lower level. Label Divisions Select this radio button if you want to label the divisions. Labels will appear between tick marks. Label Ticks Select this radio button if you want to label the ticks. Labels appear at each tick mark. (Horizontal Labels Table) Use this CellArray to enter the labels for ticks or divisions. The defaults depend on your choice for Label Sequence, below. Label Sequence: Num. Alpha Other Make a selection to initialize the labels in the table, above.
Labels default to 1, 2, 3, etc. Labels default to A, B, C, etc. Leave labels blank or create labels that are not based on letters or numbers. Copy the information for the horizontal axis to the vertical axis.
Copy to Vertical
Use Full Grid Turn on this check box to create solid vertical grid lines between the horizontal axes.
Vertical Axis Use this tab to specify grid/tick size and spacing for the vertical axis (left/
right sides of the map frame). Length Outside: Enter the length of the tick marks outside the map frame or neat line.
Length Inside: Enter the length of the tick marks inside the map frame or neat line. This option is not available when Use Full Grid is selected for the vertical axis. Length Intersect: Enter the length of grid lines at each grid intersection. This option is not available when Use Full Grid is selected for the vertical axis. Divisions: Enter the number of divisions between tick marks at this level.
47
Set Grid/Tick Info A division is the space between adjacent tick marks. This number of divisions refers to the total number of divisions on the map frame axis between ticks of the next lower level. Label Divisions Select this radio button if you want to label the divisions. Labels will appear between tick marks. Label Ticks Select this radio button if you want to label the ticks. Labels appear at each tick mark.
(Vertical Labels Table) Use this CellArray to enter the labels for ticks or divisions. The
defaults depend upon your choice for Label Sequence, below. Label Sequence: Num. Alpha Other Make a selection to initialize the labels in the table, above.
Labels default to 1, 2, 3, etc. Labels default to A, B, C, etc. Leave labels blank or create labels that are not based on letters or numbers. Copy the information for the vertical axis to the horizontal axis.
Copy to Horizontal Use Full Grid vertical axes.
Turn on this check box to create solid horizontal grid lines between the
The following buttons are always available.
Apply Click to create grids/ticks with the options selected. This dialog will remain open so
that you can change the properties as desired. To change the last set of grids/ticks created while this dialog has been open, click the Redo button, not the Apply button. Clicking Apply will always create a new set of grids/ticks on top of the existing grids/ticks. This may be desirable if you want to show grids/ticks in two different projection systems.
Redo Click to modify the last set of grids/ticks created while this dialog has been open after
changing the parameters above. As long as this dialog is open, you can modify the properties of the last set of grids/ticks created.
Close Click to close this dialog.

After clicking Close, you cannot change the properties of this element. You must delete it and create a new one in order to change it.
Help Click to see this On-Line Help document.
48
Set Grid/Tick Info
Interface manual.
For a step-by-step example of how this dialog can be used, see the Map Composer section
of the ERDAS IMAGINE Tour Guides manual.
49
Arc Properties
Arc Properties
This dialog allows you to set the properties of a selected elliptical arc. It is opened when you select Element Properties from the Annotation menu or when you double-click on the selected arc or when you click on the icon on the Annotation tools palette. If more than one element is selected, a Properties dialog is opened for each element.
You can also have the Properties dialog automatically appear when an element is selected
by setting a preference in the Viewer category of the Preference Editor.
Name: Enter a name for the arc or edit the existing name. Description: Enter a description. Center Coordinates: The X,Y center coordinates of the ellipse that forms the arc are reported. Enter new values to position the arc.
X: The X-Coordinate of the Center of the Arc Y: The Y-Coordinate of the Center of the Arc Type: Choose a method for expressing the center coordinates of the ellipse from the following options. Map The center coordinates are expressed in map units.
If your annotation is not georeferenced, then the Units: popup list will be shaded, and file coordinates will be used. Paper Units: The center coordinates are expressed in paper units.
Select the units for the center coordinates from this popup list. Arc coordinates will be measured in meters.
Meters Feet Inches
Arc coordinates will be measured in feet. Arc coordinates will be measured in inches. Arc coordinates will be measured in centimeters.
Centimeters Points
Arc coordinates will be measured in points. Arc coordinates will be measured in device pixels.
Device Pixels Other
Arc coordinates will be measured in other units.
50
Arc Properties Degrees Arc coordinates will be measured in degrees.
Axes: This group lets you specify the long and short axes of the ellipse that forms the arc.
Semi-major Axis: below. Semi-minor Axis: below. Set the length of the long axis in the units that you select at Type: Set the length of the short axis in the units that you select at Type:
Type: Choose a method for expressing the lengths of the axes from the following options. Map The lengths are expressed in map units.
If your annotation is not georeferenced, then the Units: popup list will be shaded, and file coordinates will be used. Paper Units: The lengths are expressed in paper units.
Select the units of the lengths of the axes from this popup list. Ellipse axes will be measured in meters.
Meters Feet Inches
Ellipse axes will be measured in feet. Ellipse axes will be measured in inches. Ellipse axes will be measured in centimeters.
Centimeters Points
Ellipse axes will be measured in points. Ellipse axes will be measured in device pixels.
Device Pixels Other
Ellipse axes will be measured in other units. Ellipse axes will be measured in degrees.
Degrees
Orientation: Enter the amount of rotation for the ellipse that forms the arc in the units chosen below. The element is rotated around the center. At 0.00 rotation, the semi-major axis is horizontal.
The direction of a positive rotation angle is dependent upon the value of your Positive Rotation Direction preference in the User Interface & Session Preference Editor category. Units: Choose Radians or Degrees for the Angle units from this popup list.
51
Arc Properties
Start Angle: Enter the angle from which to start the arc. This angle is measured from the
right semi-major axis. The direction of a positive rotation angle is dependent upon the value of your Positive Rotation Direction preference in the User Interface & Session Preference Editor category.
End Angle: Enter the angle from which to end the arc. This is also measured from the
right semi-major axis. The direction of a positive rotation angle is dependent upon the value of your Positive Rotation Direction preference in the User Interface & Session Preference Editor category.
Arc that is opened
end angle start angle
semi-major axis
Perimeter/Area: Reports information about the selected arc. The units and the unit type
are those that were selected in the Axes group. Perimeter: The perimeter is an approximate measure of the boundary of the arc.
Area: The area is an approximate measure of the area formed by connecting the ends of the arcs to the center of the ellipse that forms the arc. This is shown only for lled arcs.
Apply Click to apply the properties to the selected arc. Close Click to close this dialog. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
52
Ellipse Properties
Ellipse Properties
This dialog lets you change the position, size, or rotation of a selected ellipse. To open this dialog, select an ellipse and select Element Properties from the Annotation menu, or doubleclick on an ellipse that is selected. It is also opened when you click on the icon on the Annotation tools palette. If more than one element is selected, a Properties dialog is opened for each element.
Name: Enter a name for the ellipse in this text eld. A default name is provided. Description: Enter a brief description of the ellipse. Center Coordinates: Use this group to specify the position of the center of the ellipse.
Use the number elds below to enter or change the X and Y coordinates of the center of the ellipse. X: The X-Coordinate of the Center of the Ellipse Y: The Y-Coordinate of the Center of the Ellipse Type: Choose a method for expressing the center coordinates of the ellipse from the following options. Map The center coordinates are expressed in map units.
Select the units for the center coordinates from this popup list. Ellipse coordinates will be measured in meters.
Meters Feet Inches
Ellipse coordinates will be measured in feet. Ellipse coordinates will be measured in inches. Ellipse coordinates will be measured in centimeters.
Centimeters Points
Ellipse coordinates will be measured in points. Ellipse coordinates will be measured in device pixels.
Device Pixels
53
Ellipse Properties Other Ellipse coordinates will be measured in other units. Ellipse coordinates will be measured in degrees.
Degrees
Axes: This group lets you specify the long and short axes of the ellipse.
Semi-major Axis: below. Semi-minor Axis: below. Set the length of the long axis in the units that you select at Type: Set the length of the short axis in the units that you select at Type:
Type: Choose a method for expressing the lengths of the axes from the following options. Map The lengths are expressed in map units.
If your annotation is not georeferenced, then the Units: popup list will be shaded, and file coordinates will be used. Paper Units: The lengths are expressed in paper units.
Select the units of the lengths of the axes from this popup list. Ellipse axes will be measured in meters.
Meters Feet Inches
Ellipse axes will be measured in feet. Ellipse axes will be measured in inches. Ellipse axes will be measured in centimeters.
Centimeters Points
Ellipse axes will be measured in points. Ellipse axes will be measured in device pixels.
Device Pixels Other
Ellipse axes will be measured in other units. Ellipse axes will be measured in degrees.
Degrees
Angle: Enter the amount of rotation for the ellipse in the units chosen below. The element
is rotated around the center. At 0.00 rotation, the semi-major axis is horizontal. The direction of a positive rotation angle is dependent upon the value of your Positive Rotation Direction preference in the User Interface & Session Preference Editor category. Units: Choose Radians or Degrees for the Angle units from this popup list.
54
Ellipse Properties
Perimeter/Area: This group shows you the perimeter and the area of the selected
ellipse. The units and the unit type are those that were selected in the Axes group. Perimeter: Area: The perimeter is an approximate measure of the boundary of the ellipse.
The area is a measure of the area of the ellipse.
Apply Click to apply these properties to the selected ellipse. Close Click to close this dialog. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
55
Group Properties
Group Properties
This dialog lets you enter and save information about a group of elements. To open this dialog, select a group and select Element Properties from the Annotation menu, or double-click on a group that is selected. It is also opened when you click on the the Annotation tools palette. by setting a preference in the Viewer category of the Preference Editor. icon on
You can also have the Properties dialog automatically appear when an element is selected Name: Enter a name for the group in this text eld. Description: Enter a brief description of the group in this text eld. Apply Click to apply the specied properties to the selected group. Close Click to close this dialog. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
56
Legend Properties
Legend Properties
This dialog lets you create a legend for a map frame. To use this dialog, click on the on the Annotation Tools palette. icon
Then click in the Map Composer window where you want the legend to be drawn, and follow the Legend Instructions that are displayed. You can create legends only for map frames containing categorical data displayed in pseudo color, or continuous data displayed in gray scale. The text style used to label a legend is specified with the Annotation Styles dialog, and should be set in advance. NOTE: A legend is configured based on an existing map frame. However, it is not a part of the map frame it is simply annotation. A legend will not be updated if the map data or colors change. Also, changing the color of a legend patch will not affect the color of the map data. Always add a legend after the map frame data and colors are set.
Basic
Name: Enter a name for this legend. Enter a brief description for this legend.
Description: Layer:
Shows the layer being used for the legend.
Legend Layout Use this CellArray to select the classes to be used for the legend entries. If attributes are available, this CellArray shows the class number (le value) and an attribute. If a Class_Names attribute exists, it will be used. Otherwise, the rst attribute in the le is used. Select all or no classes (le values) to use all classes, or use the selection options of the table to select some of the classes. Editing this CellArray affects only the legend, not the attributes. Add Descriptor: Use this scrolling list to select attribute (descriptor) elds to add to the legend. Each selection adds a column to the Legend Layout table. Custom adds a blank column to the table for you to enter your own data. It does not affect the attributes. Histogram Delete Last Click this button to delete the last attribute added to the Legend Layout table.
57
Legend Properties
Title
Title: Enter the title of the legend. The default is Legend.
Underline Title Turn on this check box to underline the legend title. The underline will appear in the currently selected line style. Title/Underline Gap: underline. Enter the distance between the bottom of the title and the
Title/Legend Gap: Enter the distance between the bottom of the title (including the underline) and the legend. Title Alignment: Select Left-Justied, Centered, or Right-Justied for the alignment of the title relative to the legend. Left-Justied Centered Right-Justied
Columns Use this tab to dene the column layout for the legend.
Use Multiple Columns columns. Entries per Column: Turn on this check box to place legend entries in multiple Enter the number of entries to place in each column. Enter the horizontal space between each column. Enter the vertical space between each entry. Enter the vertical distance between the attribute heading
Gap Between Columns: Gap Between Entries:
Heading/First Entry Gap: and the rst entry.
Text Gap: Enter the space between attributes. If there are multiple attributes displayed for each entry and Vertically Stack Descriptor Text below is not turned on, this is the horizontal distance between attributes for the entry. If there are multiple attributes displayed for each entry and Vertically Stack Descriptor Text below is turned on, this is the vertical distance between attributes for the entry. Vertically Stack Descriptor Text Turn on this check box to place attributes in a vertical column rather than in rows.
Color Patches Use this group to enter properties for the color legend patches.
58
Legend Properties Place Patch Left of Text Turn on this check box to place the patch to the left of attribute text. Place Patch Right of Text attribute text. Turn on this check box to place the patch to the right of
Outline Color/Fill Patch Turn on this check box to outline the legend color/ll patches with the currently selected line style. Outline Symbol/Line/Text Patch Turn on this check box to outline the legend symbol/ line/text patches with the currently selected line style. Patch Width: Patch Height: Patch/Text Gap: Enter the width of the patch. Enter the height of the patch. Enter the distance between the patch and the attribute text.
Patch/Text Alignment: Select Top-Justied, Centered, or Bottom-Justied from this popup list for the alignment of the patch relative to the text. Top-Justied Centered Bottom-Justied
Legend Units: Select Points, Centimeters, or Inches from this popup list as the units for
the legend. The units you select will be used for all of the options above. Points Centimeters Inches
Apply Click to create a legend with the options selected. This dialog will remain open so
that you can change the properties as desired. To change the last legend created while this dialog has been open, click the Redo button, not the Apply button. Clicking Apply will always create a new legend on top of the existing legend.
Redo Click to modify an existing legend created while this dialog has been open after
changing the parameters above. As long as this dialog is open, you can modify the properties of the last legend created.
59
Legend Properties
Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
For step-by-step instructions on creating a map composition, see ERDAS IMAGINE Tour
60
Polygon/Polyline Properties
Polygon/Polyline Properties
This dialog allows you to change the shape or size of a selected polygon/polyline. To open this dialog, select a polygon/polyline and select Element Properties from the Annotation menu, or double-click on an polygon/polyline that is selected. It is also opened when you click on the icon on the Annotation tools palette. If more than one element is selected, a Properties dialog is opened for each element.
Name: Enter a name for the polygon/polyline in this text eld. A default name is provided.
Description: Enter a brief description of the polygon/polyline.
(Polygon/Polyline CellArray) This CellArray lists the X and Y coordinates for the
points in the polygon/polyline. Enter new coordinates into the number elds to change the location of a point. Add/delete points to change the shape of the polygon or polyline.
Type: Choose a method for expressing the X and Y coordinates of the polygon/polyline
from the following options: Map The coordinates are expressed in map units.
If your annotation is not georeferenced, then the Units: popup list will be shaded, and file coordinates will be used. Paper The coordinates are expressed in paper units.
Units: Select the units for the X and Y coordinates of the polygon/polyline from this popup
list. Meters Feet Inches Polygon/polyline coordinates will be measured in meters.
Polygon/polyline coordinates will be measured in feet. Polygon/polyline coordinates will be measured in inches. Polygon/polyline coordinates will be measured in centimeters.
Centimeters Points
Polygon/polyline coordinates will be measured in points. Polygon/polyline coordinates will be measured in device pixels.
Device Pixels Other
Polygon/polyline coordinates will be measured in other units.
61
Polygon/Polyline Properties Degrees Polygon/polyline coordinates will be measured in degrees.
Perimeter/Area: This group shows the perimeter and the area of the selected polygon/
polyline. The units and unit type are those that were selected above. Perimeter: polyline. The perimeter is an approximate measure of the boundary of the polygon/
Area: The area is an approximate measure of the area of the polygon. Area is not shown for a polyline.
Apply Click to apply these properties to the selected polygon/polyline. Close Click to close this dialog. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
62
Rectangle Properties
This dialog lets you change the position, size, units, or rotation of a selected rectangle. To open this dialog, select a rectangle and select Element Properties from the Annotation menu, or double-click on a rectangle that is selected. It is also opened when you click on the icon on the Annotation tools palette. If more than one element is selected, a Properties dialog is opened for each element.
Name: Enter a name for the rectangle in this text eld. A default name is provided. Description: Enter a brief description of the rectangle. Rectangle Info: Use this group to set the size, center coordinates, angle, and units for
the rectangle. Width: Height: Type: Map Use this number eld to enter or change the width of the rectangle. Use this number eld to enter or change the height of the rectangle. Choose a method for expressing the width and height from the following options. The width and height are expressed in map units.
If your annotation is not georeferenced, then the Units: popup list will be shaded, and file coordinates will be used. Paper Units: The width and height are expressed in paper units.
Select the units for the width and height from this popup list. Rectangle coordinates will be measured in meters.
Meters Feet Inches
Rectangle coordinates will be measured in feet. Rectangle coordinates will be measured in inches. Rectangle coordinates will be measured in centimeters.
Centimeters Points
Rectangle coordinates will be measured in points. Rectangle coordinates will be measured in device pixels.
Device Pixels Other
Rectangle coordinates will be measured in other units.
63
Rectangle Properties Degrees Rectangle coordinates will be measured in degrees.
Center X: Use these number fields to change the X and Y coordinates of the center of the rectangle. Center Y: The Y-Coordinate of the Center of the Rectangle Type: Choose a method for expressing the position of the center of the rectangle from the following options. Map The center coordinates are expressed in map units.
Select the units for the center coordinates from this popup list. Rectangle coordinates will be measured in meters.
Meters Feet Inches
Rectangle coordinates will be measured in feet. Rectangle coordinates will be measured in inches. Rectangle coordinates will be measured in centimeters.
Centimeters Points
Rectangle coordinates will be measured in points. Rectangle coordinates will be measured in device pixels.
Device Pixels Other
Rectangle coordinates will be measured in other units. Rectangle coordinates will be measured in degrees.
Degrees
Angle: Enter the amount of rotation for the rectangle in the units chosen below. The
element is rotated around the center. At 0.00 rotation, the width is horizontal. The direction of a positive rotation angle is dependent upon the value of your Positive Rotation Direction preference in the User Interface & Session Preference Editor category. Units: Choose Radians or Degrees for the Angle units from this popup list.
Perimeter: The perimeter is the measure of the boundary of the rectangle in the units
selected for width and height.
Area: The area is the measure of the area of the rectangle in the units selected for width and height.
64
Apply Click to apply these properties to the selected rectangle. Close Click to close this dialog. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
65
Scale Bar Properties
Scale Bar Properties

Use this dialog to put a scale bar on your map composition. This dialog is opened when you click on the icon on the Annotation Tools palette.
Hold and drag within the Map Composer window to draw a rectangle at the desired location of the scale bar. Follow the Scale Bar Instructions that appear. The text style used in the scale bar is specified with the Text Style Chooser dialog, and should be set in advance. A scale bar is configured for an existing map frame. However, it is not a part of the map frame, and will not rescale with the map frame. Always add a scale bar after the map frame scale is set.
Name: Enter a name for this scale bar. Description: Enter a brief description of this scale bar. Title: Enter any title to be printed with the scale bar. Representative Fraction Turn on this check box to include the map scale, expressed
as a ratio (e.g., 1:10000). This is additional text below the scale bar(s).
Alignment: Select the alignment to use for multiple scale bars.

Zero Left Right Center Align the zero points of the scale bars. Align the left sides of the scale bars Align the right sides of the scale bars. Align the centers of the scale bars.
Units: Select one or more map units for which to make the scale bar(s). One scale bar will
be created for each check box that is on. Kilometers Meters Miles Click to create a scale bar that shows distance in kilometers.
Click to create a scale bar that shows distance in meters. Click to create a scale bar that shows distance in miles. Click to create a scale bar that shows distance in nautical miles.
Nautical Miles Feet
Click to create a scale bar that shows distance in feet.
66
Scale Bar Properties Yards Click to create a scale bar that shows distance in yards.
Maximum Length: Enter the maximum length of each scale bar.

This length does not include the accompanying text, and it does not account for the total length of multiple scale bars as a group. The length shown is the length of the outline you drew when positioning the scale bar(s). (units) Click the popup list button to select the units to use for the length measurement. Length units are points. Length units are centimeters.
Points
Centimeters Inches
Length units are inches.
Apply Click to create the scale bar(s) with the options selected. This dialog will remain
open so that you can change the properties as desired. To change an the last set of scale bar(s) created while this dialog has been open, click the Redo button, not the Apply button. Clicking Apply will always create a new scale bar(s) on top of the existing scale bar(s).
Redo Click to modify the scale bar(s) after changing the parameters above. As long as this
dialog is open, you can modify the properties of the last scale bar (or set of scale bars) you created while this dialog has been open.

After clicking Close, you cannot change the properties of this element. You must delete it and create a new one in order to change it.
Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
For step-by-step instructions on creating a map composition, see ERDAS IMAGINE Tour
67
Symbol Properties
Symbol Properties
Use this dialog to change the position, size, or rotation of a selected symbol element. To open this dialog, select a symbol element and select Element Properties from the Annotation menu, or double-click on a symbol element that is selected. It is also opened when you click on the icon on the Annotation tools palette. If more than one element is selected, a Properties dialog is opened for each element.
Name: Enter a name for the symbol in this text eld. A default name is provided. Description: Enter a brief description of the symbol. Center X: Enter or change the X coordinate of the center of the symbol element. Center Y: Enter or change the Y-coordinate of the center of the symbol element.
Type: Choose a method for expressing the position of the center of the symbol from the following options. Map The center coordinates are expressed in map units.
Select the units for the center coordinates from this popup list. Symbol coordinates will be measured in meters.
Meters Feet Inches
Symbol coordinates will be measured in feet. Symbol coordinates will be measured in inches. Symbol coordinates will be measured in centimeters.
Centimeters Points
Symbol coordinates will be measured in points. Symbol coordinates will be measured in device pixels.
Device Pixels Other
Symbol coordinates will be measured in other units. Symbol coordinates will be measured in degrees.
Degrees
68
Symbol Properties
Angle: Enter the amount of rotation for the symbol in the units chosen below. The element
is rotated around the center. At 0.00 rotation, the width is horizontal. The direction of a positive rotation angle is dependent upon the value of your Positive Rotation Direction preference in the User Interface & Session Preference Editor category. Units: Choose Radians or Degrees for the Angle units from his popup list.
Size: Use this group to enter the size of the symbol.

The aspect ratio of the symbol will default to that of the original symbol as it is stored in the symbol library. Type: Choose a method for expressing the size from the following options. Map The size is expressed in map units.
If your annotation is not georeferenced, then the Units: popup list will be shaded, and file coordinates will be used. Paper Units: The size is expressed in paper units.
Select the units of the symbol size from this popup list. Symbol size will be measured in meters.
Meters Feet Inches
Symbol size will be measured in feet. Symbol size will be measured in inches. Symbol size will be measured in centimeters.
Centimeters Points
Symbol size will be measured in points. Symbol size will be measured in device pixels.
Device Pixels Other
Symbol size will be measured in other units. Symbol size will be measured in degrees.
Degrees
Apply Click to apply these properties to the selected symbol. Close Click to close this dialog. Help Click to see this On-Line Help document.
69
Symbol Properties
Interface manual.
70
Text Properties
Text Properties
This dialog lets you view or change the text, position, or alignment of a selected text element. To open this dialog, select a text element and select Element Properties from the Annotation menu, or double-click on a text element that is selected. It is also opened when you click on the icon on the Annotation tools palette. If more than one element is selected, a Properties dialog is opened for each element.
by setting the Automatically Display Properties preference in the Viewer category of the Preference Editor.
Name: Enter a name for the text element in this text eld. A default name is provided. Description: Enter a brief description of the text element. Text: Enter or edit the text.
Cut Copy Paste Click to cut the selected text string. Click to copy to selected text string to the buffer. Click to paste the buffer contents into the text string at the cursor position.
Keyboard... Click to use a graphical keyboard to enter special characters and to enter foreign fonts more easily. The Keyboard dialog is opened.
Position: Use this group to enter the position of an anchor point for the text element. The
relationship between the anchor point and the element is specied under Alignment: below. Type: Choose a method for expressing the position of the text anchor from the following options. Map The anchor coordinates are expressed in map units.
If your annotation is not georeferenced, then the Units: popup list is disabled, and file coordinates are used. Paper Units: The anchor coordinates are expressed in paper units.
Select the units for the anchor coordinates from this popup list. The position coordinates are in meters.
Meters Feet
The position coordinates are in feet.
71
Text Properties Inches The position coordinates are in inches. The position coordinates are in centimeters.
Centimeters Points
The position coordinates are in points. The position coordinates are in device pixels.
Device Pixels Other
The position coordinates are in other units. The position coordinates are in degrees.
Degrees
X: Enter or change the X coordinate of the anchor using the units specied at Units below. If the text follows a polyline, these number parts become a CellArray like in the Polygon/Polyline Properties dialog and the angle and angle units disappear. Y: Enter or change the Y coordinate of the anchor using the units specied at Units below. If the text follows a polyline, these number parts become a CellArray like in the Polygon/Polyline Properties dialog and the angle and angle units disappear. Angle: Enter the amount of rotation for the text element in the units chosen below. The element is rotated around the anchor. The direction of a positive rotation angle is dependent upon the value of the Positive Rotation Direction preference in the User Interface & Session category of the Preference Editor. Units: Left-hold this popup list to select the units used for the angle measurement. The angle is measured in radians. The angle is measured in degrees.
Radians Degrees Size: Type: Map
Use this group to enter the size of the text element. Choose a method for expressing the size of the text from the following options. The size is expressed in map units.
If your annotation is not georeferenced, then the Units: popup list will be shaded, and file coordinates will be used. Paper Units: The size is expressed in paper units.
Select the units of the text size from this popup list. The text size is expressed in meters.
Meters Feet
The text size is expressed in feet.
72
Text Properties Inches The text size is expressed in inches. The text size is expressed in centimeters.
Centimeters Points
The text size is expressed in points. The text size is expressed in device pixels.
Device Pixels Other
The text size is expressed in other units. The text size is expressed in degrees.
Degrees
Alignment: Use this group to specify how the text aligns relative to its anchor, as specied under Position: above.
Vertical: Top Use these radio buttons to set the vertical alignment. The anchor is at the top of the element. The anchor is at the top-bottom center of the element. The anchor is at the bottom of the element. Use these radio buttons to set the horizontal alignment.
Center Bottom Horizontal: Left
The anchor is at the left side of the element. The anchor is at the left-right center of the element. The anchor is at the right side of the element.
Center Right
Apply click to apply these properties to the selected element. Close Click to close this dialog. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
73
Point Properties
Point Properties
This dialog enables you to change the position of a point in an AOI (area of interest) layer by entering specific coordinates. This dialog is opened when you double-click on a selected point or when you select AOI | Element Properties... from the Viewer menu bar.
Name: The name of the point is reported. Edit as desired. Description: Write or edit a short description of the point. CellArray The coordinates of the point are displayed in a CellArray. You may edit these
coordinates as desired to change the position of the point.
Type: Click on this popup list to select the type of coordinates to display. AOI elements will
always be displayed in map units. Map Paper Map coordinates will be used. Paper coordinates will be used.
Units: Click on this popup list to specify the units used for the coordinates. Apply Click to apply these properties to the selected point. Close Click to close this dialog. Help click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
74
Align
Align
This dialog enables you to easily line up selected elements vertically and horizontally in relation to the first element selected. This dialog is opened when you click Alignment... in the File Selector dialog.
Top / Bottom These options are for aligning the top and bottom sides of selected
elements. As is Tops Click this check box to leave the alignment as it is opened. Click this check box to line up the top sides of selected elements.
Top / Bottom Centers Click this check box to line up the centers of the top and bottom sides of selected elements. Bottoms Click this check box to line up the bottom sides of selected elements.
Left / Right These options are for aligning the left and right sides of selected elements.
As is Click this check box to leave the left and right alignment as it is opened. Click this check box to line up the left sides of selected elements.
Left Sides
Left / Right Centers Click this check box to line up the centers of the left and right sides of selected elements. Right Sides Click this check box to line up the right sides of selected elements.
OK Click to use the options selected and close this dialog. Cancel Click to close this dialog without making any changes. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
75
Flip Options
Flip Options
This dialog acts as a warning to indicate that some selected elements, such as text and symbols, do not support flipping. You are given the option of how to treat these elements.
Nothing Click to ignore the elements that do not support ipping. Flip the origin Click to ip the origin only. Flip the origin and rotate the element Click to ip the origin and rotate the elements
that do not support ipping.
OK Click to ip the elements as specied. Cancel Click to cancel all ipping. Help Click to view the On-Line Help for this dialog.
76
Annotation Styles
Annotation Styles
This dialog lets you specify styles for lines, filled elements, and text. This dialog is opened by selecting Annotation | Styles... from the Viewer or Map Composer Viewer menu bar or by clicking the icon on the Annotation Tools palette.
Line Style Hold to view/set the line style. The menu options for setting the line style are
displayed in a popup list. Select the Other... option to open the Line Style Chooser dialog.
Fill Style Hold to view/set the ll style. The menu options for setting the ll style are
displayed in a popup list. Select the Other... option to open the Fill Style Chooser dialog.
Text Style Hold to view/set the text style. The menu options for setting the text style are
displayed in a popup list. Select the Other... option to open the Text Style Chooser dialog.
Symbol Style: Hold to view/set the symbol style. The menu options for setting the symbol style are displayed in a popup list. Select the Other... option to open the Symbol Chooser dialog. Close Click to close this dialog. Help Click to see this On-Line Help document.
77
Save Layer As ...
Save Layer As ...

This dialog enables you to save the top layer displayed in a Viewer or Map Composer to a new file. To use this dialog, select File | Save | Top Layer As... in the Viewer or Map Composer menu bar. This dialog is also opened when you select Save Layer As... from the right-button menu of a layer bar in the Arrange Layers dialog.
Save as: Use this lename part to enter a name for the new le. The .ovr extension is
added automatically.
OK Click to save the annotation layer and close this dialog. Cancel Click to cancel this process and close this dialog. Help Click to see this On-Line Help document. For information on using the ERDAS IMAGINE graphical interface, see the on-line IMAGINE
Interface manual.
78
AnnotationInfo
AnnotationInfo
This dialog enables you to view information about an annotation file (.ovr) and edit the map information and projection information.
This information should be modified with caution, because ERDAS IMAGINE programs use
this information for data input. If it is incorrect, there will be errors in the output data for these programs. Changes are not automatically applied. You must save the file to apply changes. Select Tools | Annotation Information... in the ERDAS IMAGINE icon panel or Utility | Layer Info... in the Viewer menu bar to access this dialog.
File Click to access the File options menu that allows you to open annotation layers, print
the information, save annotation layers, and close this dialog. Open ... New ... Click to open a le. The File Selector dialog is opened. Click to create a new AnnotationInfo dialog. Click to set up print parameters. The Print Options dialog is opened.
Print Options ...
Print Click to print using the printing options set in the Print Options dialog. The Print dialog is opened. Save Click to save the current annotation layer. This option is disabled if you do not have write permissions to the le. Save As Click to save the current annotation layer to another le. The File Selector dialog is opened. Close Close all Click to quit this AnnotationInfo dialog. Click to quit all AnnotationInfo dialogs.
Edit Click to access the Edit options menu in order to modify le information. These options
are disabled if you do not have write permissions to the le. Add/Change Mapinfo ... Click to modify map information. The Change Map Info dialog is opened. Delete Mapinfo Click to delete map information.
Add/Change Projection ... Click to modify the map projection information. The Projection Chooser dialog is opened.
79
AnnotationInfo This option should be used only to change projection information that is incorrect due to importing or other errors. You must use the Reproject Annotation... option below to reproject the data in the annotation layer. Note: You must rst remove any existing map projection information by selecting Edit | Delete Mapinfo from the Image Info menu bar.Then you must add the new projection information to the Map Info record with Edit | Add/Change Mapinfo.... Delete Projection ... Click to delete projection information.
Reproject Annotation ... Click to reproject the data in the annotation layer. The Reproject Annotation dialog is opened.

Help for Annotation Info Click to view the On-Line Help for this dialog.
Click to open an .ovr le for viewing the information. This is the same as selecting File | Open... from the menu bar. The File Selector dialog is opened.
Click to start a new ImageInfo window. This is the same as selecting File | New... from the menu bar.
Click to print information to the selected printer. This is the same as selecting File | Print... from the menu bar.
File Info: This group shows you basic information about the le.
The le name is displayed in parentheses next to the dialog title. Layer Name: Last Modied: Shows the name of the currently selected layer. Shows the last modication date for the layer.
Layer Info: This group of information tells you about the layer that you have selected
above. Total Elements: Arc Elements: Shows the total number of top-level elements in the layer. Shows the number of top-level arc elements in this layer. Shows the number of top-level ellipse elements in this layer.
Ellipse Elements:
80
AnnotationInfo Group Elements: Point Elements: Shows the number of top-level group elements in this layer. Shows the number of top-level point elements in this layer. Shows the number of top-level polygon elements in this layer. Shows the number of top-level polyline elements in this layer. Shows the number of top-level rectangle elements in this layer.
Polygon Elements: Polyline Elements: Rectangle Elements: Symbol Elements: Text Elements:
Shows the number of top-level symbol elements in this layer.
Shows the number of top-level text elements in this layer.
Map Info: This group shows information about the map units used in the le. If the le is not georeferenced, these elds are disabled.
Even if the elds are disabled, you can change this information once you select a map projection. Select Edit | Add/Change Mapinfo... from the menu bar. Upper Left X: Upper Left Y: Lower Right X: Lower Right Y: Unit: Shows the minimum X map coordinate of the data in the le. Shows the maximum Y map coordinate of the data in the le. Shows the maximum X map coordinate of the data in the le. Shows the minimum Y map coordinate of the data in the le.
Shows the map units used.
Projection Info: This group of information tells about the map projection used on the le.
If the le is not georeferenced, then these elds are disabled. Even if the elds are disabled, you can change this information once you select a map projection. Select Edit | Add/Change Projection... from the menu bar. Georeferenced to: Spheroid: Shows the map projection used for this le.
Shows the spheroid used. If the projection is UTM or State Plane, the zone number is shown here.
Zone Number: Datum:
Shows the datum used.
Interface manual.
81
AnnotationInfo
See the File Formats and Extensions Appendix in the ERDAS Field Guide for more
information on data stored in .img files.
82
Change Mapinfo
Change Mapinfo
This dialog enables you to modify map information. It opens when you select Edit | Add/Change Mapinfo... from the AnnotationInfo dialog.
Projection: Enter the name of the projection or click on the popup list to select from a list
of names.
Units: Click on the popup list to select the units for the map information. OK Click to use the selected map information. Cancel Click to cancel any changes to the map information and close this dialog. Help Click to view the On-Line Help for this dialog.
83
Print Options (AnnotationInfo)
Print Options (AnnotationInfo)

This dialog enables you to set up print parameters for annotation. It opens when you select File | Print Options... from the AnnotationInfo dialog.
Print: Choose to print the projection information and/or the map information.
Projection Info Click to print the projection information. Map Info Click to print the map information.
File type: Choose how to print a le.

Text Select to print as a Text le. Postscript (UNIX only) Select to print as a Postscript le. Graphics (Windows only) Select to send a le containing a graphical illustration.
OK Click to use the selected print options. Cancel Click to cancel any changes to the print options and close this dialog. Help Click to view the On-Line Help for this dialog.
84
Reproject Annotation
Reproject Annotation
This dialog enables to reproject the data in the annotation layer. This dialog opens when you select Edit | Reproject Annotation... from the AnnotationInfo dialog.
Set Projection... Click here to set the projection information. Units: Select the units for the projection. Cancel Click to cancel the reprojection. OK Click to reproject the annotation with the new parameters. Help Click to view the On-Line Help for this dialog.
85
Annotation Attributes
Annotation Attributes
This CellArray displays the attribute-type information for the annotation elements displayed in the Viewer. It also allows you to select features by attribute and to edit some of the attribute values, and it provides many of the CellArray editing features found throughout ERDAS IMAGINE. This Attribute Table opens when you select Annotation | Attributes... from the Viewer menu bar and when you right-hold Annotation Options | Show Attributes... in the Arrange Layers dialog. It also opens when you click the icon in the Annotation Tools palette.
The title bar of this dialog reflects the name of the annotation layer you are editing.
File This menu option allows you to close the current attribute table.
Close Click to close this attribute table.
Edit This menu provides many options for editing the attribute information.
Recalculate Bounding Box Click to recalculate the bounding box of the selected elements based upon the display parameters of the layer in the Viewer. This is useful when data have been imported without the knowledge of how paper units will relate to map units. See the Annotation section of the Annotation Manual for more information about paper units. Make Unique IDs Click to reset the element IDs of all elements, making them unique and consecutive. In previous versions of ERDAS IMAGINE, these IDs were not kept unique. This can be useful for selecting elements in the CellArray. Copy Click to copy the selected rows of the selected columns. Items are written to the paste buffer. Paste Click to paste the contents of the paste buffer. Click to select all columns in the CellArray. All columns will be Click to deselect any selected columns.
Select All Columns highlighted in cyan.
Deselect All Columns
Select All Rows Click to select all rows in the Attribute Table. All rows will be highlighted in yellow. If all columns are also selected, then all cells in the table will be highlighted in green. Deselect All Rows Click to deselect all currently selected rows.
86
Annotation Attributes Select Rows by Criteria... Click to select rows by entering specic selection criteria. The Selection Criteria dialog is opened.
Help Click to access the On-Line Help page for this dialog.
Help for Annotation Attributes Click to view the On-Line Help for this dialog.
(Attribute CellArray) The element attributes are displayed in this CellArray. Right-hold
with your cursor in the Record column to access the Row Selection menu. Right-hold with your cursor in any column title cell to access the Column Options menu. Within the attribute table you can use any of the CellArray tools that are discussed in the online IMAGINE Interface manual.
Interface manual.
87
Raster To Annotation
This dialog provides the capability to convert a raster image to polygons in an annotation file. Areas within the image with the same pixel value will produce an annotation polygon outlining that area. The NAME of each polygon will contain the Class_Names attribute value from the raster file. The DESCRIPTION of each polygon will contain the grid cell value from which the polygon was derived. The fill style of the polygons will be solid with the color taken from the color of the given class in the raster file.
Input Image File: Name of the input image to vectorize Output Annotation File: Name of the output annotation layer Output Annotation Root: Name of the Output File Path and Prex Neighborhood: The Neighborhood option is used to select which surrounding pixels will
be used to determine whether or not you are at the edge of a polygon.
This is selected if only the pixel above, below, left, or right of the pixel in question are to be considered to further grow a polygon.
This is selected if all eight neighboring pixels are to be considered in growing a polygon. This option allows a polygon to continue to grow to areas which are only connected by diagonal pixels.
Masking Options: The Masking Options are used to select a subset of the raster image
to be processed. Select Classes... Once an input image is selected, this option brings up a read-only version of the Raster Attribute Editor. Only those classes which correspond to the selected rows of the CellArray are processed. 1.) Select rows in the Raster Attribute Editor corresponding to classes of interest 2.) Click OK on this dialog - the Raster Attribute Editor is automatically closed and processing begins
If you dismiss the Raster Attribute Editor manually, you will get un predictable results. Changes to class colors made in the Raster Attribute Editor are not reflected in the annotation
polygons. 88
Raster To Annotation Select AOI... This option brings up the standard Choose AOI dialog. This allows an Area Of Interest to be selected to spatially subset the portion of the image to be processed.
Processing Division Options: This allows for the creation of multiple annotation les
based on either AOI Objects or rectangularly subdividing the image. Use AOI Objects If an AOI has been selected, this option may be used to produce an output annotation le for each AOI Object. The name of each of the annotation les will be of the form: name_AOI_n.ovr. NOTE: This option may be used in conjunction with the Map Series Tool to produce annotation les whose areas correspond to map series. Use Grid This option allows the area covered by the image to be subdivided horizontally and/or vertically into equally sized partitions. A separate annotation le is created for each partition. The name of each of the annotation les will be of the form: name_GRID_n.ovr. X: Y: Number of subdivisions for X Axis Number of subdivisions for Y Axis
Size Threshold: The Size Threshold provides the capability to specify the minimum
sized polygon to be retained. NOTE: This is accomplished by using the Sieve function, which will leave holes in place of the small polygons. If this is not desired, Eliminate may be run prior to running Raster to Annotation in order to ll in the small polygons from surrounding areas. Minimum: This is the minimum size polygon to form in the output annotation le(s).
minunits This popup list provides a choice of units for the minimum size polygon. Any of the following four units may be selected.
o pixels o hectares o acres o sqmiles OK Click to run the program with the options selected. Cancel Click to close this dialog without running this program.
89
90
Annotation to Raster
Annotation to Raster
The Annotation to Raster utility provides the capability to convert an annotation file containing vector graphics to a raster image file. For example, if an annotation file contains polygons of land ownership with the land owner contained in the Name or Description of the annotation polygons, this annotation file may be converted to a thematic image with raster attributes of Name and Description. In this example, a classification could then be summarized by land owner using Summary.
When converting an annotation file containing vector graphics to a raster image file, ONLY
vector graphics are converted to raster. Text will not be converted to raster.
Input Annotation File: Enter the name of the input annotation le. The default le
extension is .ovr. Click to open a File Selector dialog.
Create new layer for output If selected, a new output le is created. If this is not
selected, an existing layer will be written to.
Output Image File: Enter the name of the output image le. The default le extension
is .img. Click to open a File Selector dialog.
Select Layer: If Create new layer for output is not selected and an existing le is to be written to, then this allows for the selection of the output layer. From Inquire Box Click to dene a subset area of the data by using the Viewer Inquire
Box. When you click this button, the coordinates below are updated with the coordinates of the cursor box in the Viewer. To change these coordinates, you can move and/or resize the cursor box in the Viewer, then click this button again. The image you are using must already be displayed in a Viewer and the Inquire Box open in order to use this option.
Size Denition: Use this group to dene a rectangular area of the data to be used as
the output le. The default coordinates represent the bounding box of the input annotation. UL X: Upper Left X coordinate of area to be rasterized.
91
Annotation to Raster UL Y: LR X: LR Y: Upper Left Y coordinate of area to be rasterized. Lower Right X coordinate of area to be rasterized. Lower Right Y coordinate of area to be rasterized. Set coordinates to multiple of cell size.
Snap to Cell Size X Cell Size: Y Cell Size: Square Cells Layer Width: Layer Height:
Set the X cell Size of output pixels. Set the Y cell Size of output pixels. Make X and Y cells sizes the same. Set the width in pixels of area to be written. Set the height in pixels of area to be written.
Output Data Type: This group gives information about the output le data types.
Data Type: Layer Type: Thematic Click on this popup list to select the data type for the output le. Click on this popup list to select the layer type of output le. The output will be a thematic raster layer. The output will be a continuous raster layer.
Continuous
Set Values... Click to set output pixel values for each annotation object. OK Click to run the program with the options selected. Batch Click to include this function in a batch le. Cancel Click to close this dialog without running this program. Help Click to see this On-Line Help document.
92
Values For Rasterized Annotation
Values For Rasterized Annotation

This dialog is opened when you click on Set Values... in the Annotation To Raster dialog.
(CellArray) This CellArray displays information about each renderable element in the
input annotation le. Elements which are referenced using paper coordinates are not renderable by this program. The information displayed includes the name, description element type, and value for rendering. Value This column displays the value which will be used in rendering the annotation element into the raster layer. The initial default values are generated by numbering the elements sequentially, starting at 1. You may edit these values manually, or use the Automatic Value Generation options, described below, to set values. Name Type This column displays the name of each annotation element. This column displays the annotation element type for each element. This column displays the description of each annotation element.
Description
Automatic Value Generation: This group enables you to automatically generate

values based on element names and/or descriptions. If the Use Unique Name option is on, each unique name is given a unique value. If Use Unique Description is on, each unique description is given a unique value. If both are on, each unique pair of name and description is given a unique value. If neither is on, each element is given a unique value. In all cases, the generated values start at 1 and are incremented by 1 as each unique situation is encountered. Use Unique Name Use unique names as a criterion in automatically generating values. Use Unique Description generating values. Use unique descriptions as a criterion in automatically
Generate Click here to perform the automatic value generation. The automatic value generation is performed on all rows (i.e. all annotation elements) if no rows are selected in the CellArray. If there are rows selected, the value generation will only be applied to the selected rows.
Save As Raster Attribute: This group allows you to specify whether the Name, Type,
or Description of elements should be saved as Raster Attributes in the output raster image layer. If there is more than one name, type, or description for a particular value, only the rst one encountered will be saved in the Raster Attribute column. Name Type Save the Name column as raster attribute of output layer. Save the Type column as raster attribute of output layer.
93
Values For Rasterized Annotation Description Save the Description column as raster attribute of output layer.
Apply Click to accept these values. You must click on this button for any changes made in
this dialog to take effect.
Close Click to close this window. Any changes made since the last time the Apply button
was clicked will be discarded.
94

ERDAS - Annotation On-Line Manual

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

ERDAS - Annotation On-Line Manual

Uploaded by

Copyright:

Available Formats

Annotation

Annotation On-Line Manual

Compose Key Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Annotation On-Line Manual

Annotation On-Line Manual

How Annotation is Stored

Creating New Annotation

Editing Existing Annotation

Annotation To deselect one or all selected elements:

Annotation Map Units

Cut, Copy, and Paste

 Styles do not apply to symbols.

o the option to fill the element and a fill color, and

This is 18 point text.

This is also 18 point text.

Text Following a Polyline

Using the Arc Tool

Changes end point

Changes height of arc Left-hold to rotate entire arc

Compose Key Characters

Compose Key Characters

 A non-breaking space is generated with the sequence: Compose space space.

Compose Key Characters

^ ^ ~ ~ " " * * E e , , / / O o ^ ^ " "

^ ^ " " ~ ~ ^ ^ " " ~ ~ / / X x | | ! !

O o O o s H h ^ ^ " " x " | A a : | , O o

/ ^ ^ ^ ^ ^ ^ + 1 1 3 < > ! ? " \ ,

u * . 1 2 3 4 2 4 < > ! ? " \ ,

Use this tool in a Map Composer window only.

Click to see this On-Line Help document.

Click to lock the current tool.

Annotation Tools (Large Format)

Annotation Tools (Large Format)

Annotation Tools (Large Format)

Annotation Tools (Large Format)

Annotation Tools (Large Format)

Annotation Tools and Commands

Annotation Tools and Commands

Annotation Tools and Commands

Click to delete the selected element(s). A copy is kept in a copy/paste buffer.

Click to make a copy of the selected element(s) to a copy/paste buffer.

Click to paste the element(s) from the copy/paste buffer.

o left-hold on any side of a polygon or segment of a polyline or text polyline to

Annotation Tools and Commands

Click to combine the selected elements into a group element.

Click to break a group element into single elements.

Click to open the Properties dialog for the selected element:

o Text o Ellipse o Arc o Rectangle o Polygon/Polyline o Symbol o Map frame o Group

Click to align the selected elements. The Align dialog is opened.

Click to automatically point the selected element(s) to the north.

Click to ip selected annotation vertically.

Click to ip selected annotation horizontally.

Click open the Annotation Styles dialog.

Click to open the Annotation Attributes dialog.

Click to open the Region Growing Properties dialog.

Annotation Tools and Commands

click to lock the current tool.

Close click to close this dialog.

Annotation Tools and Commands (Large Format)

Annotation Tools and Commands (Large Format)

Annotation Tools and Commands (Large Format)

Annotation Tools and Commands (Large Format)

Click to delete the selected element(s). A copy is kept in a copy/paste buffer.

Styles do not apply to symbols.

A non-breaking space is generated with the sequence: Compose space space.
