NX Nastran 8 Verification ManualProprietary & Restricted Rights Notice © 2011 Siemens Product Lifecycle Management Software Inc. All Rights Reserved. This software and related documentation are proprietary to Siemens Product Lifecycle Management Software Ine. NASTRAN is a registered trademark of the National Aeronautics and Space Administration. ‘NX Nastran is an enhanced proprietary version developed and maintained by Siemens Product Lifecycle Management Software Inc MSC is a registered trademark of MSC,Software Corporation, MSC.Nastran and MSC.Patran are trademarks of MSC.Software Corporation. Allother trademarks are the property of their respective owners TAUCS Copyright and License TTAUCS Version 2.0, November 29, 2001. Copyright (c) 2001, 2002, 2003 by Sivan Toledo, ‘Tel-Aviv University, stoledo@tau.acil. All Rights Reserved. TAUCS License: Your use or distribution of TAUCS or any derivative code implies that you agree to this License THIS MATERIAL IS PROVIDED AS IS, WITH ABSOLUTELY NO WARRANTY EXPRESSED OR IMPLIED. ANY USE IS AT YOUR OWN RISK, Permission is hereby granted to use or copy this program, provided that the Copyright, this License, and the Availability of the original version is retained on all copies. User documentation of any code that uses this code or any derivative code must cite the Copyright, this License, the Availability note, and "Used by permission." If this code or any derivative code is accessible from within MATLAB, then typing “help taucs" must cite the Copyright, and "type taucs' must also cite this License and the Availability note. Permission to modify the code and to distribute modified code is granted, provided the Copyright, this License, and the Availability note are retained, and a notice that the code was modified is included, This software is provided to you free of charge. Availability (TAUCS) As of version 2.1, we distribute the code in 4 formats: zip and tarred-gzipped (tgz), with or without binaries for external libraries, The bundled external libraries should allow you to build the test programs on Linux, Windows, and MacOS X without installing additional software. We recommend that you download the full distributions, and then perhaps replace the bundled libraries by higher performance ones (e.g, with a BLAS library that is specifically optimized for your machine). If you want to conserve bandwidth and you want to install the required libraries yourself, download the lean distributions The zip and tgz files are identical, except that on Linux, Unix, and MacOS, unpacking the tgz file ensures that the configure script is marked as executable (unpack with tar zxvpf), otherwise you will have to change its permissions manually. 2 NE Nasran 8 Verfcation ManualContents Proprietary & Restricted Rights Notice 6.06... 0ss0eeseeeeneeneeene ene enen & Part I: Introduction Overview of the Verification Manual ...... 4.6.55 sesese Running the Test Cases .... pees BD Part Il: Linear Statics Verification Using Theoretical Solutions Overview of Linear Statics Verification Using Theoretical Solutions .. Understanding the Test Case Format Understanding Comparisons with Theoretical Solutions References Test Cases ieee eee eee eect eset eee eee e esse tenses eee eset enee eee dl Point Load on a Cantilever Beam 41 ‘Axial Distributed Load on a Linear Beam 4 Distributed Loads on a Cantilever Beam 4 Moment Load on a Cantilever Beam a ‘Edge Pressure on Beam Element - Torque Loading 4 Thermal Strain, Displacement, and Stress on Heated Beam 4 Uniformly Distributed Load on Linear Beam, 4 Membrane Loads on a Linear Quadrilateral Thin Shell Element 4 Axial Loading on Rod Element 4 Stress on a Beam as It Expands and Closes a Gap 4 Thin Wall Cylinder in Pure Tension 4 Thin Shell Beam Wall in Pure Bending 4 Strain Energy of a Truss, 4 Part III: Linear Statics Verification Using Standard NAFEMS Benchmarks Overview of Linear Statics Verification Using Standard NAFEMS Benchmarks ... 5-1 Understanding the Test Case Format 8 Reference 1 Test Cases 6 eee e reece eee rece eee eee ee nett tent ete rte n ene ene Gol Elliptic Membrane 61 Cylindrical Shell Patch Test 65 Hemisphere-Point Loads 68 Z-Section Cantilever 61 ‘Skew Plate Normal Pressure 612 Thick Plate Pressure 614 Solid Cylinder/Taper/Sphere — Temperature 618 NX Nastran 0 Verifcation Manual — 9Contents Part IV: Normal Mode Dynamies Verification Overview of Normal Mode Dynamics Verification Using Theoretical Solutions ... 7-1 Understanding the Test Case Format TH Understanding Comparisons with Theoretical Solutions 12 Reference 12 Test CASS oie eee cence erence ence renee nee nnn Een EE Natural Frequency of Circular Ring with Axisymmetric Model Undamped Free Vibration — Single Degree of Freedom Two Degrees of Freedom Undamped Free Vibration — Principle Modes Three Degrees of Freedom Torsional System Two Degrees of Freedom Vehicle Suspension System ‘Two Degrees of Freedom Vehicle Suspension System Cantilever Beam Undamped Free Vibrations Natural Frequency of a Cantilevered Mass Part V: Normal Mode Dynamics Verification Using Standard NAFEMS Benchmarks Overview of Normal Mode Dynamics Verification Using Standard NAFEMS Benchmarks ......++ssseseees Understanding the Test Case Format 91 Reference 91 Beam Element Test Cases... +0. .0se0ee0e etree eee e nes 10D Pin-ended Cross — In-plane Vibration 10-1 Pin-ended Double Cross - In-plane Vibration 10-3 Free Square Frame - In-plane Vibration 10-6 Cantilever with Off-center Point Masses 10-8 ‘Deep Simply-Supported Beam 10-8 Circular Ring —In-plane and Out-of-plane Vibration 10-11 Cantilevered Beam 10-13, Shell Element Test Cases ..... 6.0. e0e00e reece eee tener ees DLL Thin Square Cantilevered Plate — Symmetric Modes qn. Thin Square Cantilevered Plate — Anti-symmetric Modes 113 Free Thin Square Plate 116 Simply Supported Thin Square Plate 118 Simply Supported Thin Annular Plate 11-10 Clamped Thin Rhombic Plate 11:12 Cantilevered Thin Square Plate with Distorted Mesh 11-15 Simply Supported Thick Square Plate, Test A 11-19 Simply Supported Thick Square Plate, Test B 11-22 Clamped Thick Rhombic Plate 11-5 Simply Supported Thick Annular Plate 11.27 Cantilevered Square Membrane 1130 Cantilevered Tapered Membrane 1133, Free Annular Membrane 1138 Cantilevered Thin Square Plate 1138 Axisymmetric Solid and Solid Element Test Cases .. 66.6... eeee scene eee eee 12d 4 NK Naxran Verification ManualContents Free Cylinder — Axisymmetric Vibration 12-1 Thick Hollow Sphere — Uniform Radial Vibration 12-3 Simply Supported Annular Plate — Axisymmetrie Vibration 12-6 ‘Deep Simply Supported "Solid" Beam 12-8 Simply Supported "Solid" Square Plate 12-11 ‘Simply Supported "Solid" Annular Plate 12-15 Cantilevered Solid Beam 12-19 Part VI: Verification Test Cases from the Societe Francaise des Mecaniciens Overview of Verification Test Cases Provided by the Societe Francaise des Mecaniciens . Understanding the Test Case Format Reference Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements .. 14-1 Short Beam on Two Articulated Supports M4 Clamped Beams Linked by a Rigid Element 42 Transverse Bending of a Curved Pipe M4 Plane Bending Load on a Thin Arch 47 Grid Point Load on an Articulated CONROD Truss 49 Articulated Plane Truss 14-12 Beam on an Elastic Foundation 14-15 Mechanical Structures — Linear Statics Analysis with Shell Elements ......... 15-1 Plane Shear and Bending Load on a Plate Infinite Plate with a Circular Hole Uniformly Distributed Load on a Circular Plate ‘Torque Loading on a Square Tube Cylindrical Shell with Internal Pressure Uniform Axial Load on a Thin Wall Cylinder Hydrostatic Pressure on a Thin Wall Cylinder Gravity Loading on a Thin Wall Cylinder Pinched Cylindrical Shell Spherical Shell with a Hole Bending Load on a Cylindrical Shell Uniformly Distributed Load on a Simply-Supported Rectangular Plate Uniformly Distributed Load on a Simply-Supported Rhomboid Plate Shear Loading on a Plate 16. Mechanical Structures — Linear Statics Analysis with Solid Elements ......... 16-1 Solid Cylinder in Pure Tension 16-1 Internal Pressure on a Thick-Walled Spherical Container 16-7 Internal Pressure on a Thick-Walled Infinite Cylinder 16-12 Prismatic Rod in Pure Bending 16-17 Thick Plate Clamped at Edges 16-21 Mechanical Structures — Normal Mode Dynamics Analysis ........+e00e0e04 1T-L ‘Lumped Mass-Spring System 1 Short Beam on Simple Supports 14 Asial Loading on a Rod 117 NK Nasran 9 Verification Manual 5Contents Cantilever Beam with a Variable Rectangular Section Thin Circular Ring Thin Circular Ring Clamped at Two Points Vibration Modes of a Thin Pipe Elbow Cantilever Beam with Eccentric Lumped Mass Thin Square Plate (Clamped or Free) Simply-Supported Rectangular Plate Thin Ring Plate Clamped on a Hub ‘Vane of a Compressor - Clamped-free Thin Shell Bending of a Symmetric Truss Hovgaard's Problem — Pipes with Flexible Elbows Rectangular Plates Mechanical Steuctures — Normal Mode Dynamics Analysis and Model Response oo. sees e ec eceee eee ene eters ene ene ete rene enerteneeneene es 1861 Transient Response of a Spring-Mass System with Acceleration Loading 18-1 Transient Response of a Clamped-free Post 18-4 Stationary Thermal Tests — Heat Transfer Analysis 6.4.6... 0s s0se0eee es Hollow Cylinder - Fixed Temperatures Hollow Cylinder - Convection Cylindrical Rod - Flux Density Hollow Cylinder with Two Materials - Convection Wall-Convection Wall-Fixed Temperatures LPlate Orthotropie Square Hollow Sphere - Fixed Temperatures, Convection Hollow Sphere with Two Materials - Convection Thermo-mechanical Tests — Linear Statics Analysis 6.4.06. 00ss0seee0eeeees 20-1 Orthotropie Cube Thermal Gradient on a Thin Pipe Simply-Supported Arch Part VII: Material Nonlinear (Plasticity) Verification Using Standard NAFEMS Benchmarks Overview of the Material Nonlinear (Plasticity) Verification Using NAFEMS Test CASS ieee sees sees ee eeeees Understanding the Verification Format Reference Test CASS eee eee cece eee eee teat teat eee teat neat tenet ene 20 Plane Strain Elements - Perfect Plasticity Tests Plane Strain Elements - Isotropic Hardening Tests, Plane Stress Elements - Perfect Plasticity Tests Plane Stress Elements - Isotropic Hardening Tests Solid Element - Perfect Plasticity Tests Solid Element - Isotropic Hardening Tests 6 NK Naxrran Verification ManualContents Part VIII: Geometric Nonlinear Verification Using Standard NAFEMS Benchmarks Overview of the Geometric Nonlinear Verification Using NAFEMS Test Cases ... 23-1 Understanding the Verification Format 23-1 Reference 23-1 Test Cases... eee eee ee cece eee e ence eee ee erent enter eee Bed Straight Cantilever with End Moment WA Straight Cantilever with Axial End Point Load - Brick Elements 24-6 Straight Cantilever with Axial End Point Load - BEAM Elements 11 ‘Lee's Frame Buckling Problem 24-15 ‘Large Displacement Blastic Response of a Hinged Spherical Shell Under Uniform Pressure Loading 24-18 Results 24-21 Reference 24-21 NXNastran 2 Verifcation Manual 7Part I IntroductionChapter 1 Overview of the Verification Manual This guide contains verification test cases for NX Nastran. These test cases verify the funetion of the different NX Nastran analysis types using theoretical and benchmark solutions from well-known engineering test cases, Each test case contains test case data and information, such as element type and material properties, results, and references. The guide contains test cases for: © Linear Statics verification using theoretical solutions © Linear Statics verification using standard NAFEMS benchmarks © Normal Mode Dynamics verification using theoretical solutions * Normal Mode Dynamics verification using standard NAFEMS benchmarks * Verification Test Cases from the Societe Francaise des Mecaniciens © Material Nonlinear (Plasticity) verification using standard NAFEMS benchmarks (NX Nastran only) © Geometric Nonlinear verification using standard NAFEMS benchmarks N&Nastran 9 Verification Manual 4-4Chapter 2 Running the Test Cases All verification test cases are available as *.dat files and are included in the NX Nastran installation in the directory path install_dir/NXr/nast/demo, The test cases are relatively simple, and most have closed-form theoretical solutions, Differences, between finite element and theoretical solutions are in most cases negligible. Some tests would yequire an infinite number of elements to achieve an exact solution. Elements are chosen to achieve reasonable engineering accuracy with reasonable computing times Note Actual results from NX Nastran may vary insignificantly from the results presented in this document, This variation is generally due to different methods of performing real number algorithms on different systems NM Nastran 9 Verification Manual 24Part II Linear Statics Verification Using Theoretical SolutionsChapter 3 Overview of Linear Statics Verification Using Theoretical Solutions The purpose of these linear statics test cases is to verify the function of the NX Nastran software using theoretical solutions The test cases are relatively simple in form and most of them have closed-form theoretical solutions The theoretical solutions shown in these examples are from well-known engineering texts For each test case, a specific reference is cited. All theoretical reference texts are listed at the end of this topic, The finite element method is very flexible in the types of physical problems represented. The verification tests provided are not exhaustive in exploring all possible problems, but represent common types of applications This overview provides information on the following: © Understanding the test case format © Understanding comparisons with theoretical solutions © References 3.1. Understanding the Test Case Format Each test case is structured with the following information. * Test case data and information: o Physical and material properties 0 Finite element modeling (modeling procedure or hints) o Units 0 Solution type o Element type 0 Boundary conditions (loads, restraints) © Results NN Nastran 9 Verification Manual 34Chapter3 Overview of Lincar Statics Verification Using Theoretical Solutions © References (text from which a closed-form or theoretical solution was taken) In addition to these example problems, test cases from NAFEMS (National Agency for Finite Element Methods and Standards, National Engineering Laboratory, Glasgow, UIE) have been executed. Results for these test cases can be found in the next section, Linear Statics Analysis Verification Using NAFEMS Standard Benchmarks. 3.2 Understanding Comparisons with Theoretical Solutions While differences in finite element and theoretical results are, in most cases, negligible, some tests would require an infinite number of elements to achieve the exact solution, Elements are chosen to achieve reasonable engineering accuracy with reasonable computing times. Results reported here are results which you can compare to the referenced theoretical solution. Other results available from the analyses are not reported here. Results for both theoretical and finite element solutions are carried out with the same significant digits of accuracy. The closed-form theoretical solution may have restrictions, such as rigid connections, that do not exist in the real world, These limiting restrictions are not necessary for the finite element model, but are used for comparison purposes. Verification to real world problems is more difficult but should be done when possible, The actual results from the NX Nastran software may vary insignificantly from the results presented in this document. This variation is due to different methods of performing real numerical arithmetic on different systems, In addition, it is due to changes in element formulations which have been made to improve results under certain circumstances, 3.3 References The following references have been used in the Linear Statics Analysis verification problems presented: 1. Beer and Johnston, Mechanics of Materials. New York: McGraw-Hill, Inc., 1992. 2. Harris, ©. 0. Introduction to Stress Analysis, New York Macmillan1989. 3. Roark, R, and Young, W. Formulas for Stress and Strain, 5th Edition, New York: ‘McGraw-Hill Book Company, 1975. 4. Shigley, J_and Mitchel L. Mechanical Engineering Design, 4th Edition, New Yorke ‘McGraw-Hill Book Company, 1983 5, Timoshenko, S. Strength of Materials, Part I, Elementary Theory and Problems. New York: Van Norstrand Reinhold Company, 1956. 32 NX Nazran & Verification ManualChapter 4 Test Cases 4.1 Point Load on a Cantilever Beam Determine the defiection of a beam at the free end. Determine the stress at the midpoint of the beam. Test Case Data and Information Input Files mstvl001dat Units Inch NX Nastran 9 Verification Manual 4Chapter4 ‘Test Cases Model Geometry Length = 480 in. Cross Sectional Properties © Area =30x30in 67500 int y Material Properties © B= 30806 psi Finite Element Modeling Create four successive linear beam (CBAR) elements along the X axis, Boundary Conditions ° Restraints o Restrain the left end of the beam in all six degrees. * Loads o Set grid force to 50,000 Ib in. the -¥ direction. Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastran Von Mises Stress, grid point 1 (psi) 5333. 5333 Y Deflection, grid point 5 (in) 0.9102 0.9130 References Beer and Johnston, Mechanics of Materials. New York: McGraw-Hill, Inc., 1992, p. 716 42 NX Nasran £ Verification ManualTest Cases 4.2 Axial Distributed Load on a Linear Beam Determine the stress, elongation and resultant force due to an axial loading along a linear beam | 3000 in, —————_____»| element. Test Case Data and Information Input Files mstvl002.dat Units Inch Model Geometry * Length = 300 in. Cross Sectional Properties * Area =9in? © square cross section (3 in. x 3 in.) © 1=675 int Material Properties © B= 30E+6 psi Finite Element Modeling Create 30 beam element along the X axis, each 10 inches long, Boundary Conditions « Restraints o Restrain one end of the beam in all six degrees. * Loads © Set the axial distributed load (force per unit length) to 1000 Ib/in. for the 10-inch long: clement furthest from the restrained end in the X direction, ‘Nastran 0 Verication Manual 43Chapter4 ‘Test Cases The boundary conditions are shown in the following figure: Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastran ‘Von Mises Stress, grid point 1 (psi) iit iit Deffection in X, grid point 2 (in) out 0.01093 Reaction in X, grid point 1 (Ib) -1.000B4 -1.000B4 References Beer and Johnston, Mechanics of Materials.. New York: McGraw-Hill, Inc., 1992. p. 76. 4.3 Distributed Loads on a Cantilever Beam Determine the deflection of a beam at the free end. Determine the stress at the midpoint of the ‘beam and the reaction force at the restrained end 250 Tow / ine 44 NXNazran & Verification ManualTest Cases Test Case Data and Information Input Files mstvl003.dat Units Inch Model Geometry Length = 480 in. Cross Sectional Properties © Area = 900 in? Square cross section (30 in, x 30 in.) I, = 67500 in¢ Material Properties © B= 30806 psi Finite Element Modeling Create eight successive linear beam (CBAR) elements along the X axis. Boundary Conditions « Restraints o Restrain the left end of the beam in all six degrees. * Loads o Define a distributed load of 250 Ib/in. in the -Y direction. Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastran X Stress at grid point 1 (psi) 6,400 6,383 Deffection Magnitude at grid point 5 (in) 0.8190 0.8225 * Reaction Force Magnitude at grid point 1 (Ib) ‘1.20085 1.20085 * Includes shear deformation which is neglected in theoretical value. NK Nastran 9 Verification Mamual 5Chapter4 ‘Test Cases References Beer and Johnston, Mechanics of Materials. New York: McGraw-Hill, Inc., 1992, p. 716 4.4 Moment Load on a Cantilever Beam Determine the defiection of a beam at the free end. Determine the bending stress of the beam and the reaction force at the restrained end 480 in. Test Case Data and Information Input Files mstvl004.dat Units Tach Model Geometry Length = 480 in. Cross Sectional Properties © Area = 900 in? 67500 int © Square cross section 30’ x 30’ inches Material Properties © B= 308+06 psi 46 NX Nasran £ Verification ManualTest Cases Finite Element Modeling Create eight successive linear beam (CBAR) elements along the X axis. Boundary Conditions « Restraints o Restrain the left end of the beam in all six degrees. * Loads o Set the Z-moment of the end grid point to 2.5E06 in.-lb. Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastean ‘Von Mises Stress at grid point 1 (psi) 555.6 555.6 Deffection Magnitude at grid point 5 (in) 0.1423 0.1492 Reaction Force Z Direction at grid point 1 (Ib) 2.5006 2.49986 * Includes shear deformation which is neglected in theoretical value. References Beer and Johnston. Mechanics of Materials. New York: McGraw-Hill, Inc, 1992. p. 716. 4.5 Edge Pressure on Beam Element - Torque Loading Determine the stress, elongation and resultant force due to a torque applied to a hollow cylinder at the free end. NE Nastran 9 Verification Manual 4-7Chapter4 ‘Test Cases 103 ma Test Case Data and Information Input Files mstvl005.dat Units SI - meter Model Geometry Length = 15m Cross Sectional Properties * Radiusl = 0.02m * Radius‘ = 03m Material Properties © B= 2086 GPa Finite Element Modeling © Create a CBAR element along the X axis. © To find the maximum shearing stress, set the effective radius in torsion to 0.03 m. © The minimum shearing stress is located at a radius equal to 0.02 m. 48 NX Nasran £ Verification ManualTest Cases Boundary Conditions © Restraints o Restrain the left end of the beam in all six degrees © Loads © Apply an edge torque equal to 4.08 KN-m along the 10 cm linear beam (CBAR) element furthest from the restrained end Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastran ‘Max Torsional Shear Stress (MPa) 120.0 120.0 ‘Min Torsional Shear Stress (MPa) 80.00 80.00 Post Processing ‘To obtain the minimum and maximum shear stress values, a post processor which supports contour plots of the torsional shear stress on the cross section using the linear beam (CBAR) element forces must be used. The cross section location can be anywhere except the free end of the beam. References Beer and Johnston. Mechanics of Materials. New York: McGraw-Hill, Inc, 1992. p. 122. 4.6 Thermal Strain, Displacement, and Stress on Heated Beam Abeam originally 1 meter long and at-50° C is heated to 25°C. First, determine the displacement and thermal strain on a cantilever beam, Fix the beam at the free end and then determine the displacement, reaction forces, and stresses along the beam. Next, fix the beam at both ends. NE Nastran 0 Verification Mamual 4.9Chapter4 ‘Test Cases im _ 2 Test Case Data and Information Input Files mstvl007.dat Units SI - meter Model Geometry Length = 1m Cross Sectional Properties © Area = 0.01 m? Material Properties © E=2.068E11 Pa * Coefficient of thermal expansion = 1.2E-05 + v=03 Finite Element Modeling © Create 10 linear beam (CBAR) elements on the X axis and restrain the end grids in all directions © Apply a temperature on all grid points 440 -NXNastran 0 Verification ManualTest Cases Boundary Conditions « Restraints © Case 1: Restrain one end of the beam in all six directions © Case 2: Restrain both ends of the beam in all six directions, © Loads © Set grid temperatures to 26°C. Set the reference temperature to -50°C. Solution Type SOL 101 — Linear Statics Results Case 1 Result Bench Value NX Nastean X Displacement at grid 11 (m) (0008000 (0008000 Axial Thermal Strain 0009000 0008000 Case2 Result Bench Value NX Nastean X Displacement (m) 0 0 Axial Stress (Pa) 1.860E8 1.861B8 X Reaction Force (N) 1860B6 1.86186 References Beer and Johnston. Mechanics of Materials. New York: McGraw-Hill, Inc, 1992, p. 68. 4.7 Uniformly Distributed Load on Linear Beam A beam 40 feet long is restrained and loaded as shown with a distributed load of -833 Ibs. per foot, Determine the bending stress and the deflection at the middle of the beam. NW Nastran 0 Verification Manual 8-11Chapter4 ‘Test Cases Test Case Data and Information Input Files mstvl008.dat Units Inch Model Geometry Length = 480 in. Cross Sectional Properties * Rectangular cross section (1.17 in. x 43.24 in.) © I,=7892in4 442 -NKNastran 0 Verification ManualTest Cases Material Properties © B= 3006 psi Finite Element Modeling Create 4 successive linear beam (CBAR) elements that are each 10 feet long: Boundary Conditions © Restraints o Restrain the second and the fourth grids in five degrees of freedom. Do not restrain rotation about Z, © Loads © Define a distributed load (force per unit length) of -833 Ib/foot (global negative Y direction) on the end elements, Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastean Y Displacement at grid 3 (in.) 0.1820 0.182 ‘Max bending stress (psi) 1.64484 1.64484 References Beer and Johnston. Mechanics of Materials. New York: McGraw-Hill, Inc, 1992, p. 98. 4.8 Membrane Loads on a Linear Quadrilateral Thin Shell Element A circle is scribed on an unstressed aluminum plate, Forces acting in the plane of the plate cause normal stresses. Determine the change in the length of diameter AB and of diameter CD. NE Nacran 8 Verification Manual 4-13Chapter4 ‘Test Cases Test Case Data and Information Element Types equad4 Input Files mstvl009.dat Units Inch Model Geometry © Length = 15 in. * Diameter = 9 in. © Thickness = 3/4 in. 444 NNastran 0 Verification ManualTest Cases Material Properties © B= 10806 psi © Poisson's ratio = 1/3 © F(xVlL = 9,000 Ibfin © F(2V/L = 16,000 Ibiin. Finite Element Modeling Create 1/4 of the model and apply symmetry boundary conditions. Then multiply the answer by 2 for correct results, Remember to account for the ratio of the circle diameter to plate length. Boundary Conditions © Restraints o Restrain the left end of the beam in all six degrees © Loads 0 Set the edge pressure to 9,000 Ibin. in the Xdirection and 15,000 lb/in. in the Z direction, Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastean X Diameter Change (in) 4.80083 —4.800B3 Z Diameter Change (in.) 14.4083 -14.40B3 Post Processing Deflection © (dx at grid point 7 — dx at grid point 10) x 2 = (0.004 — 0.0016) x 2 = 0.0048 © (dz atgrid point 7 —dz at grid point 24) x 2 = (0.012 -0.0048) x 2 = 0.0144 References Beer and Johnston. Mechanics of Materials. New York: McGraw-Hill, Inc, 1992, p. 88. 4.9 Axial Loading on Rod Element Determine the stress, elongation, and strain due to an axial load on a rod element. NE Nasran 8 Verification Manual 4-45Chapter4 ‘Test Cases Test Case Data and Information Input Files mstvl011dat Units SI - meters Model Geometry Length = 10m Cross Sectional Properties © Area = 0.01 m? Material Properties * E=200.0 GPa Finite Element Modeling Create a rod (CROD) element along the X axis. Boundary Conditions © Restraints o Restrain an end of the rod in the 3 translational degrees. © Loads © Apply a grid point force in the positive X-direction of 500 KN, Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastean ‘Axial Stress (MPa) 50.00 50.00 Axial Strain 0.000250 0.000250 Elongation (mm) 2.500 2.500 References Beer and Johnston, Mechanics of Materials. New York: McGraw-Hill, Inc., 1992, p. 716 448 -NNastran 0 Verification ManualTest Cases 4.10 Stress on a Beam as It Expands and Closes a Gap Determine the stress on a beam as it expands thermally and closes a 0.002 inch gap. It is initially at 70 °F and is heated to 170 °F Test Case Data and Information Input Files mstvl013.dat Units Inch Model Geometry Length = 3 in. Material Properties © B= 105807 psi * Coefficient of thermal expansion = 1268-05 in/(in.—°F) Finite Element Modeling * Create a single linear beam (CBAR) element on the X axis. NENastran 8 Verification Manual 4-47Chapter4 ‘Test Cases © Create an MPC to define the closing of the gap. Boundary Conditions * Restraints o Restrain the free end of the beam in all six degrees, © Loads 0 Set grid temperature to 170 °F 0 Set the reference temperature to 70 °E Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastran Axial Stress (psi) 6 195E3 ~6.195E3 References Harris, 0. 0. Introduction to Stress Analysis 1959. p. 58 4.11 Thin Wall Cylinder in Pure Tension Determine the stress and defiection of a thin wall cylinder with a uniform axial load. 448 -NXNastran 0 Verification ManualTest Cases Test Case Data and Information Input Files mstvl014.dat Units Inch Model Geometry © R=05in * Thickness = 0.01 in. 10 in Material Properties © B= 10,000 psi fastran 8 Verification Manual 4-19Chapter4 ‘Test Cases © n=03 Finite Element Modeling Create 1/4 model of the cylinder with thin shell linear quadrilateral (CQUAD4) elements and symmetry boundary conditions. Boundary Conditions * Restraints o Restrain edges of symmetry, in translation, in hoop direction, and rotation about Z axis, o Restrain one end in Y direction, Loads © Apply membrane edge pressure of p / (piJD = 8.1831 where p = 10 psi Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastran Asial (Z) Stress (psi) 1.00083 1.00083 Axial (Z) Deflection (in.) 1.000 1.000 Radial Deflection (in.) 0.01500 0.01500 References Roark, R. and Young, W. Formulas for Stress and Strain, 6th Edition. New York: McGraw-Hill Book Company, 1989. p. 518, Case 1a 4.12 Thin Shell Beam Wall in Pure Bending Determine the maximum stress, maximum deflection, and strain energy of a thin shell beam wall with 2 uniform bending load 420 NK Nastran 0 Verification ManualTest Cases Sin Test Case Data and Information Input Files mstvl015.dat Units Inch Model Geometry © Length = 30 in © Width = 5 in © Thickness = 0.1 in. Material Properties © B= 30806 psi 0.03 NE Nactran 8 Verification Manual 4-24Chapter4 ‘Test Cases Finite Element Modeling Create a 30 in. x 5 in, plate with thing shell (CQUAD4) elements Boundary Conditions * Restraints o Restrain at one of the ends in all directions © Loads © Apply edge pressure of phv = 1.2 Ib/in. where p = 6.0 Ib Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastean ‘Max Z Deflection (in) 4.320 4264 Max Z Stress (pai) 2.16084 1.98084 ‘Total Strain Energy (Ib in.) 12.96 12.79 References Shigley, J. and Mitchel L. Mechanical Engineering Design, 4th Edition, New York: McGraw-Hill, Ine, 1983. pp. 134, 804. 4.13 Strain Energy of a Truss Determine the strain energy of a truss. The cross-sectional area of the diagonal members is twice the cross-sectional area of the horizontal and vertical members. 422 NE Nastran 0 Verification ManualTest Cases 2a 2a Test Case Data and Information Input Files mstvl016.dat Units Inch Model Geometry © Length = 10 in Cross Sectional Properties * Cross-sectional area (A) = 0.01 in? Material Properties * = 30K06 psi Finite Element Modeling Create truss shown using rod (CROD) elements. Boundary Conditions © Restraints o Restrain far left grid in directions: X, Y, Z, RX, RY. o Restrain far right grid in directions: Y, Z, RX, RY. NE Nacran 8 Verification Manual 4.23Chapter4 ‘Test Cases © Loads © Apply grid force in ¥ direction on lower center grid; F= 300 Ib. Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastean ‘Total Strain Energy (Ib in.) 5846 5.846 References Beer and Johnston, Mechanics of Materials. New York: McGraw-Hill, Inc., 1992, p. 588 424 -NENastran Verification ManualPart III Linear Statics Verification Using Standard NAFEMS BenchmarksChapter 5 Overview of Linear Statics Verification Using Standard NAFEMS Benchmarks ‘The purpose of these linear statics test cases is to verify the function of NX Nastran using standard benchmarks published by NAFEMS (National Agency for Finite Element Methods and Standards, National Engineering Laboratory, Glasgow, UK). These standard benchmark tests were created by NAFEMS to stretch the limits of the finite elements in commercial software. All results obtained using NX Nastran compare favorably with other commercial finite element analysis software. 5.1 Understanding the Test Case Format Each test case is structured with the following information: * Test case data and information o Physical and material properties 0 Finite element modeling (modeling procedure or hints) o Units 0 Finite element modeling information © Boundary conditions (loads and restraints) 0 Solution type * Results © Reference 5.2 Reference ‘The following reference has been used in these test cases: NAFEMS Finite Element Methods & Standards, The Standard NAFEMS Benchmarks. Glasgow. NAFEMS, Rev. 8, 1990. NK Nastran 9 Verification Manual 5-4Chapter 6 Test Cases 6.1 Elliptic Membrane This test is a linear elastic analysis of an elliptic membrane (shown below) using coarse and fine meshes of plane stress elements and thin shell elements. It provides the input data and results for NAFEMS Standard Benchmark Test LE1 Ellipses [L. cape aD: (8) + y= 1 psec: (g8g) + (obs Test Case Data and Information Input Files 1e101 dat (plane stress quadrilateral) 1e102.dat (plane stress triangle) 16103 dat (thin shell) ‘Nastran 2 Verication Manual 1Chapteré ‘Test Cases Physical and Material Properties ‘Thickness = 0.1m Isotropic material E = 21083 MPa v=03 Units SI Finite Element Modeling 62 Plane stress (only MID1 defined on PSHELL) linear (CQUAD4) and parabolic (CQUADS) quadrilaterals — coarse and fine mesh Plane stress (only MID1 defined on PSHELL) linear (CTRI3) and parabolic (CTRI6) triangles — coarse and fine mesh. ‘Thin shell (MID1, MID2 and MIDS defined on PSHELL) linear (CQUAD4) and parabolic (CQUADS) quadrilaterals — coarse and fine mesh. ‘The fine mesh is created by approximately halving the coarse mesh. NX Nastran 8 Verfcation ManualTest Cases Coarse Mesh Fine Mesh al B EE a A D D Parabolic Quacrilateral D c D c Pamibolic Triangle B B al al D c D c Boundary Conditions © Uniform outward pressure at outer edge BC = 10 MPa © Inner curved edge AD unloaded © Xdisplacement (edge AB N&Nastran 0 Verification Manual 63Chapteré ‘Test Cases © Y displacement (edge CD) = 0 Restreints Loneting B ® A A D c Solution Type SOL 101 — Linear Statics Results Output — tangential edge stress at D (stress in Y direction) Plane Stress Elements Test case Grid point # Bench Value NX Nastean ‘Linear quad — coarse mesh 4 27 621 Linear quad — fine mesh 204 2.7 13.6 Parabolic quad —coarse mesh 104 92.7 82.1 Parabolic quad — fine mesh 304 92.7 89.9 Linear triangle — coarse mesh 4 92.7 52.9 Linear triangle —fine mesh 204 92.7 70.8 Parabolic triangle — coarse 104 92.7 168 mesh Parabolic triangle — fine mesh 304 2.7 93.6 Thin Shell Elements Test case Grid point # Bench Value NX Nastean Linear quad — coarse mesh 4 27 621 Linear quad — fine mesh 204 2.7 13.6 Parabolic quad — coarse mesh 104 92.7 821 Parabolic quad — fine mesh 304 92.7 89.9 64 NX Nazran & Verification ManualTest Cases References NAFEMS Finite Element Methods & Standards, The Standard NAFEMS Benchmarks, Test No. LE1. Glasgow: NAFEMS, Rev. 3, 1990. 6.2 Cylindrical Shell Patch Test This test is a linear elastic analysis of a cylindrical shell (shown below) using thin shell elements and two different loadings. It provides the input data and results for NAFEMS Standard Benchmark Test LE2, Geometry Test Case Data and Information Input Files © 1e201a.dat (linear shell, case 1) © 1e201bdat (parabolic shell, case 1) © 1e202a.dat (linear shell, case 2) © 1e202bdat (parabolic shell, case 2) Physical and Material Properties © Thickness = 0.1m ‘Nastran 2 Verification Manual 65Chapteré ‘Test Cases © Isotropic material © B= 210E3 MPa * v=03 Units SI Finite Element Modeling © Thin shell linear (CQUAD4) and parabolic (CQUADS) quadrilaterals Linear Quadullaceral Panibolle Quadrilacoml A a aA E E D e D Boundary Conditions © Translations and rotations (edge AB) = 0 © Ztranslations and normal rotations (edge AD and edge BC) = 0 Case 1 loading © Uniform normal edge moment on DC = 1.0 kNavm Case 2 loading © Uniform outward normal pressure at mid-surface ABCD = 0.6 MPa © Tangential outward normal pressure on edge DC = 0.0 MPa 66 NX Nazran £ Verification ManualTest Cases Restimints/constreints z c D Loading Case 1 Case 2 Solution Type SOL 101 — Linear Statics Results Output — outer (convex) surface (top shell surface) tangential stress at point E (grid point 2) Test case Filename Bench Value _ NX Nastran Linear quad — case 1 1e2010 60.00 518 Linear quad ~ case 2 122022 60.00 Bt Parabolic quad — case 1 1e201b 60.00 564 Parabolic quad — ease 2 12202 60.00 564" * Since the shapes of the shells are an approximation to a cylindrical surface, an edge load will not be in the correct direction. To get this result, the edge load must be input as grid forces in the tangential direction, Post Processing © Stress component: Y NE Nastran 9 Verification Manual 67Chapteré ‘Test Cases © Results obtained on the element top surface in cylindrical coordinate system References NAFEMS Finite Element Methods & Standards, The Standard NAFEMS Benchmarks, Test No. LE2, Glasgow: NAFEMS, Rev. 3, 1990. 6.3 Hemisphere-Point Loads This test is a Linear elastic analysis of hemisphere point loads (shown below) using coarse and fine meshes of thin shell elements It provides the input data and results for NAFEMS Standard Benchmark Test LE3 2KN Test Case Data and Information Input Files * 1e301.dat (linear quad, coarse mesh) © 1e302.dat (linear quad, fine mesh) © 1¢803.dat (parabolic quad, coarse mesh) Physical and Material Properties © Thickness = 0.04 m 68 NX Nazran £ Verification ManualTest Cases * Isotropic material © B= 68.25 x 103 MPa 2 v=03 Units sl Finite Element Modeling © Thin shell linear (CQUAD4) and parabolic (CQUADS) quadrilaterals — coarse and fine mesh © Equally spaced grid points on AC, CE, EA © Point Gat X= Y= Z= 10 /( 32) grid point 7 Coarse Mesh Boundary Conditions * Edge AE symmetry about XZ plane (y = rotation x = rotation z = 0) Edge CE symmetry about YZ plane (x = rotation y = rotation z = 0) Point B (x=y=2=0) Allother displacements on edge AC are free. © Concentrated radial load outward at A = 2KN © Concentrated radial load inward at C = 2KN NK Nastran 0 Verification Manual 69Chapteré ‘Test Cases Restraints Loading E D c B Solution Type SOL 101 — Linear Statics Results Output — X displacement at point A Mesh Test Case Bench Value NX Nastean linear quad — coarse mesh 1e301 0.185 0.1848 linear quad — fine mesh 16302 0.185 0.1865 parabolic quad — coarse ‘1303 0.185 0.1416 mesh References NAFEMS Finite Element Methods & Standards, The Standard NAFI No. LE3, Glasgow: NAFEMS, Rev. 3, 1990. 6.4 2Z-Section Cantilever This test is a linear elastic analysis of a Z-section cantilever (shown below) using thin shell elements It provides the input data and results for NAFEMS Standard Benchmark Test LES. 610 NK Nastran 0 Verification ManualTest Case Data and Information Input Files * 1e801.dat (linear quadrilateral) © 16802.dat (parabolic quadrilateral) Physical and Material Properties © Thickness = 0.1m * Isotopic material * B=21083 MPa Finite Element Modeling © Thin shell linear (CQUAD4) and parabolic (CQUADS) quadrilaterals Boundary Conditions © All displacements on edges B1, B2, B3 = 0 © Torque of L.2MN applied at end C by two edge shears (at C1 & C3) of 0.6 MN Test Cases NW Nastran 9 Verification Manual 6-11Chapteré ‘Test Cases cL c3 x A (node 30 Solution Type SOL 101 — Linear Statics Results Output — averaged axial stress at mid-surface, point A, grid point 30 (compression) Result Bench Value NX Nastean Linear quad - point A/grid point 30 108.0 =111.0 Parabolic quad - point A/grid point 30 -108.0 110.3 References NAFEMS Finite Element Methods & Standards The Standard NAFEMS Benchmarks, Test No. LES, Glasgow: NAFEMS, Rev. 3, 1990. 6.5 Skew Plate Normal Pressure This test is a linear elastic analysis of a plate (shown below) using thin shell elements. It provides the input data and results for NAFEMS Standard Benchmark Test LE6. 30. 612 NK Nastran 0 Verification ManualTest Cases Test Case Data and Information Input Files * 1e601.dat (Linear and parabolic quad) © 1e602dat (linear and parabolic triangle) Physical and Material Properties © Thickness = 0.01m * Isotopic material © B= 21083 MPa 03 Units sl Finite Element Modeling © Thin shelllinear (CQUAD4) and parabolic (CQUADS) quadrilaterals — coarse and fine mesh © Thin shell linear (CTRIS) and parabolic (CTRI6) triangles — coarse and fine mesh Boundary Conditions © Simple supports © Zdisplacement = 0 0.71XPa in the Z direction © Normal pressure = Restraints Loading Solution Type SOL 101 — Linear Statics Results Output — maximum principal stress on the bottom surface at the plate center NE Nacran 8 Verification Manual 6-13Chapteré ‘Test Cases Case 1e601 Mesh Geid point # Bench Value NX Nastran Linear quad coarse mesh 9 0.802 0.325 Linear quad fine mesh 18 0.802 0.683 Parabolic quad coarse mesh 43 0.802 0.625 Parabolic quad fine mesh 82. 0.802 0.719 Case 1e602 Mresh Geid point # Bench NX Nastran Value Linear triangle coarse mesh 9 0.802 396 Linear triangle fine mesh «18 0.802 0.720 Parabolic triangle coarse 43. 0.802 0.926 mesh Parabolic triangle fine mesh 0.802 0.887 References NAFEMS Finite Element Methods & Standards The Standard NAFEMS Benchmarks, Test No. LE6. Glasgow: NAFEMS, Rev. 3, 1990. 6.6 Thick Plate Pressure This article provides the input data and results for NAFEMS Standard Benchmark Test LE10, This test is a linear elastic analysis of a thick (shown below) using coarse and fine meshes of solid elements Ellipses 644 NK Nastran 0 Verification ManualTest Cases Ellipse AD: Test Case Data and Information Input Files * 1e1001.dat (linear and parabolic brick) * 1e1002.dat (linear and parabolic wedge) * 161003 dat (linear and parabolic tetrahedron) © 1e1004.dat (linear and parabolic pyramid) Physical and Material Properties * Isotopic material © B= 21083 MPa =03 Units sl Finite Element Modeling Solid brick (CHEXA) linear and parabolic - coarse and fine mesh * Solid wedge (CPENTA) linear and parabolic - coarse and fine mesh * Solid tetrahedron (CTETRA) - linear and parabolic - coarse and fine mesh © Solid pyramid (CPYRAM) linear and parabolic - coarse and fine mesh (created by dividing each linear and parabolic brick element into 6 pyramid elements) NE Nastran 8 Verification Manual 6-15Chapter é Test Cases Solid Brick Coarse Mesh Linear Brisk Parubolie Brick Solid Wedge Coarse Mesh Linear Wedge Parabolic Wedge 616 NK Nastran 0 Verification ManualTest Cases Solid Tetrahedron — fine mesh only Fine Mesh Linear Tetrahedron Boundary Conditions © Uniform normal pressure on the upper surface of the plate = 1 MPa + Inner curved edge AD unloaded © Xand Y displacements on faces DOD Cand ABAG¢= 0 © Xand Y displacements on face BCB@are fixed © Zdisplacements along mid-plane are fixed Restraints/Constraints Loading Solution Type SOL 101 — Linear Statics Results Output — direct stress at point Ds, NE Nasran 8 Verification Manual 6-17Chapteré ‘Test Cases Test Case 1e1001 Mesh Geid point # Bench Value NX Nastran Linear brick — coarse mesh 4 5.50 BAL Linear brick — fine mesh 204 8.50 5.67 Parabolic brick — coarse 104 8.50 6.13 mesh Parabolic brick — fine mesh 304 5.50 6.04 Test Case le1002 Mesh Geid point # NX Nastean Linear wedge — coarse mesh 4 Linear wedge — fine mesh 204 Parabolic wedge — coarse mesh 104 Parabolic wedge — fine mesh 304 Test Case le1003 Result Grid point # Bench Value NX Nastean ‘Linear tetra — fine mesh 40 5 =241 Parabolic tetra—fine mesh 171 6.28 Test Case le1004 Mesh Geid point # Bench Value NX Nastran Linear pyramid — coarse 4 5.50 285 mesh Linear pyramid —fine mesh 204 3.83 Parabolic pyramid —coarse 104 5.50 5.60 mesh Parabolic pyramid — fine 304 5.50 572 mesh References NAFEMS Finite Element Methods & Standards The Standard NAFEMS Benchmarks, Test No, LE10. Glasgow. NAFEMS, Rev. 3, 1990. 6.7 Solid Cylinder/Taper/Sphere — Temperature ‘This test is a linear elastic analysis of a solid cylinder with a temperature gradient (shown below) using coarse and fine meshes of solid elements. It provides the input data and results for NAFEMS Standard Benchmark Test LE 11. 618 NX Nastran 0 Verification ManualTest Cases ‘0.7071 f}-— asa Test Case Data and Information Input Files © 1e1101adat (linear brick — coarse mesh) © 1e1101b dat (linear brick — fine mesh) * 1e1102a dat (parabolic brick — coarse mesh) © 1e1102b dat (parabolic brick — fine mesh) © 1e1103a dat (linear wedge — coarse mesh) © 1e1103b dat (linear wedge — fine mesh) * 1e1104a dat (parabolic wedge — coarse mesh) * 1e1104b dat (parabolic wedge — fine mesh) © 1e1105a dat (linear tetra — coarse mesh) © 1e1105b dat (linear tetra — fine mesh) * 1e1106a dat (parabolic tetra — coarse mesh) © 1e1106b.dat (parabolic tetra — fine mesh) NE Nasran 8 Verification Manual 6-19Chapteré ‘Test Cases © 1e1107adat (linear pyramid — coarse mesh) © 1e1107b dat (linear pyramid — fine mesh) © 1e1108adat (parabolic pyramid — coarse mesh) © 1e1108b dat (parabolic pyramid — fine mesh) Physical and Material Properties © Isotropic material © B=210E3 MPa * v=03 © a=23R4°C Units SI Finite Element Modeling * Solid brick (CHEXA) linear and parabolic — coarse and fine mesh. © Solid wedge (CPENTA) linear (6 grid point) and parabolic (15 grid point) — coarse and fine mesh * Solid tetrahedron (CTETRA) linear and parabolic — coarse and fine mesh © Solid pyramid (CPYRAM) linear and parabolic — coarse and fine mesh (created by dividing each linear and parabolic brick element into 6 pyramid elements) 620 NK Nastran 0 Verification ManualTest Cases Solid Brick Coarse Mesh Fine Mesh cot as He Parabolic Brick Solid Tetrahedron Coarse Mesh Fine Mesh Lear Tetrahedton Parable Tevranetror NE Nacran 8 Verification Manual 6-24Chapteré ‘Test Cases Boundary Conditions © Linear temperature gradient in the radial and axial direction TC= + NI4Z X, Y, and Z displacements = 0 Xand Y displacements on face BCB@¢are fixed Z displacements on X¥-plane face and HIH@¢face = 0 Restraints Loading oh Solution Type SOL 101 — Linear Statics Results Output - direct stress $y, at point A FileName —_ Result Geid point at Bench NX Point A Value _Nastean lel101a ‘Linear brick — coarse mesh 30 105.0 -88.50 1e1101b Linear brick — fine mesh 1 -105.0 -98.3 1e1102a Parabolic brick — coarse mesh er 105.0 -1004 161102 Parabolic brick — fine mesh 159 -105.0 -1112 1e1103a Linear wedge — coarse mesh 33 -105.0 -10.0 1e1103b Linear wedge — fine mesh 4 -1050 48.3 le1104a Parabolic wedge — coarse mesh 1 -105.0 -87.2 1e1104b Parabolic wedge — fine mesh 187 -105.0 -96.2 le1105a Linear tetra — coarse mesh 8 -105.0 -314 622 NX Nastran 0 Verifcation ManatTest Cases FileName Result Grid point at Bench NX Point A Value _Nastean 1611056 Linear tetra — fine mesh 8 =1050 -65.2 1e1106a Parabolic tetra — coarse mesh 8 -105.0 -89.6 161106 Parabolic tetra — fine mesh 8 -105.0 -97.3 1e1107a Linear pyramid — coarse mesh 30 -105.0 -87.0 11107 Linear pyramid — fine mesh 1 -1050 -79.8 1e1108a Parabolic pyramid —coarse mesh 67 -105.0 -65.8 161108 Parabolic pyramid — fine mesh 159 -105.0 -108.8 References NAFEMS Finite Element Methods & Standards. The Standard NAFEMS Benchmarks, Test No, LE11, Glasgow: NAFEMS, Rev. 3, 1990. [NE Nasrran 8 Verification Manual 23Part IV Normal Mode Dynamics Verification [NX Nastran 0 Verification ManualChapter 7 Overview of Normal Mode Dynamics Verification Using Theoretical Solutions The purpose of these normal mode dynamics test cases is to verify the function of NX Nastran using theoretical solutions The test cases are relatively simple in form and most of them have closed-form theoretical solutions The theoretical solutions shown in these examples are from well known engineering texts For each test case, a specific reference is cited. All theoretical reference texts are listed at the end of this topic, The finite element method is very flexible in the types of physical problems represented. The verification tests provided are not exhaustive in exploring all possible problems, but represent common types of applications This overview provides information on the following: © Understanding the test case format © Understanding comparisons with theoretical solutions © References 7.1 Understanding the Test Case Format Each test case is structured with the following information. * Test case data and information: o Physical and material properties 0 Finite element modeling (modeling procedure or hints) o Units 0 Solution type 0 Boundary conditions (loads and restraints/constraints) * Results © Reference NN Nastran 9 Verification Mamual 7-4Chapter? Overview of Normal Mode Dynamics Verification Using Theoretical Solutions Theoretical Solutions 7.2 Understanding Comparisons While differences in finite element and theoretical results are, in most cases, negligible, some tests would require an infinite number of elements to achieve the exact solution, Elements are chosen to achieve reasonable engineering accuracy with reasonable computing times. Results reported here are results which you can compare to the referenced theoretical solution. Other results available from the analyses are not reported here. Results for both theoretical and finite element solutions are carried out with the same significant digits of accuracy. The closed-form theoretical solution may have restrictions, such as rigid connections, that do not exist in the real world. These limiting restrictions are not necessary for the finite element model, but are used for comparison purposes. Verification to real world problems is more difficult but should be done when possible, The actual results from NX Nastran may vary insignificantly from the results presented in this document, This variation is due to different methods of performing real numerical arithmetic on different systems In addition, it is due to changes in element formulations which have been made to improve results under certain circumstances, 7.3 Reference The following references have been used in the normal mode dynamics analysis verification problems presented: 1. Blevins, R. Formulas For Natural Frequency and Mode Shape, 1st Edition, New York: Van Norstrand Reinhold Company, 1979. 2, Timoshenko and Young Vibration Problems in Engineering. New Yorks Van Norstrand Reinhold Company, 1956. 3. Tse, F, Morse, I, and Hinkle, R, Mechanical Vibrations, Theory and Applications. Boston: Allyn and Bacon, Inc, 1978, 4, Tse, F, Morse, I., and Hinkle, R, Mechanical Vibrations, 2nd Edition, Boston: Allyn and Bacon, Inc., 1978. 72. NXNazran & Verification ManualChapter 8 Test Cases 8.1 Natural Frequency of Circular Ring with Axisymmetric Model ‘Determine the frequency of radial vibration of an axisymmetric ring, R= 100 in | Test Case Data and Information Input File mstvn001.dat Units Inch Model Geometry * Thickness = 0.05 in. * Radius = 100 in. Material Properties * Density = 0.00073 Ib-sec?/in4 © B= 30R6 psi NN Nastran 9 Verification Manual 4Chapter8 ‘Test Cases Finite Element Modeling Create a linear axisymmetric thin shell element (CCONEAX) .05 inches long at a radius of 100 inches from the center Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method Results Result Bench Value NX Nastean Frequency (Hz) 3226 322.6 References Timoshenko and Young. Vibration Problems in Engineering, p. 425. New York: Van Norstrand Reinhold Company, 1956. 8.2 Undamped Free Vibration — Single Degree of Freedom Determine the natural frequency of the system shown. 82 NX Nasran £ Verification ManualTest Cases Test Case Data and Information Input File mstvn002.dat Units ‘SI - meter Model Geometry © Length = 0.5m =03m Physical Properties © mass = 20 Kg ° k=SKNm Finite Element Modeling © Create 6 rigid bar (RBAR) elements along the X axis, Bach bar should be 0.1m long * A lumped mass (CONM2) element is applied on the end grid point, © Agrid point-to-ground spring element (CELAS1) is applied 0.2 m from the lumped mass Boundary Conditions «Restrain the first grid point to allow rotation only in the Z direction Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method Results Result Bench Value NX Nastean Frequency (Hz) 1910 1910 References ‘Tse, F, Morse, I,, and Hinkle, R. Mechanical Vibrations, Theory and Applications, p. 75. Boston: Allyn and Bacon, Inc, 1978 NM Nastran 0 Verification Manual 83Chapter @ Test Cases 8.3 Two Degrees of Freedom Undamped Free Vibration — Principle Modes Determine the natural frequencies of a dynamic system with two degrees of freedom. . Test Case Data and Information Input File mstvn003.dat Units SI- meter 84 NX Nazran & Verification ManualTest Cases Element Types * ‘Translational springs (CELAS1) © Lumped mass (CONM2) Physical Properties * Mass = 1kg * k=1Nm Finite Element Modeling © Create four grid points on the Y axis © Create three linear springs (CELAS1) with stiffness of 1 N/m and with a uniaxial stiffness reference coordinate system, * Create two lumped mass elements (CONM2) with a mass of 1 kg. Boundary Conditions Restrain ends in all directions * Restrain other grid points in all directions but ¥. Solution Type Normal Mode Dynamics - SOL 103, Lanczos method Results Result Bench Value NX Nastean Frequency of Mode 1 (Hz) 0.1592, 0.1592, Frequency of Mode 2 (Hz) 0.9757 0.9787 References Tse, F, Morse, I, and Hinkle, R. Mechanical Vibrations, 2nd Bdition, pp. 145-149, Boston: Allyn and Bacon, Inc, 1978 8.4 Three Degrees of Freedom Torsional System ‘Determine the natural frequencies of a dynamic system with three degrees of freedom. NK Nastran 0 Verification Manual 85Chapter8 ‘Test Cases i Pn a e n R B Test Case Data and Information Input File mstvn004.dat Element Types © Rotational springs (CBLAS1) © Lumped mass (CONM2) Units SI — meter Physical Properties © Jed1=52=93=01 © kekl=k2=k3=1N'm Finite Element Modeling © Create four grid points on the X axis * Create three linear torsional springs (CELAS1) with stiffness of 1 N*m and with a stiffness reference coordinate system being uniaxial. * Create three lumped mass elements (CONM2) with a mass coordinate system = 1 and with mags inertia system of 0.1, 0.0, 0.0, 0.0, 0.0, 0.0. Boundary Conditions © Restrain one end in all directions. © Restrain the other grid points in all directions but RX Solution Type SOL 103 — Normal Mode Dynamics, Lanczos method 86 NX Nazran & Verification ManualTest Cases Results Result Bench Value NX Nastran Frequency of Mode 1 (Hz) 0.2240 0.2940 Frequency of Mode 2 (Hz) 0.6276 0.6276 Frequency of Mode 3 (Hz) 0.9069 0.8069 References Tse, F, Morse, I, and Hinkle, R. Mechanical Vibrations, 2nd Edition, pp. 15 Allyn and Bacon, Inc, 1978, 8.5 Two Degrees of Freedom Vehicle Suspension System ‘Determine the natural frequencies of dynamic system with two degrees of freedom, Degrees of freedom are one translational and one rotational. ; 12-20m NS Ni a ki a s : Be Ne Test Case Data and Information Input Files mstvn005.dat Units SI - meter ‘Nastran 2 Verification Manual 87Chapter8 ‘Test Cases Physical Properties © Mass = 1800 kg © Ki =42000 Nim © K2= 48000 Nim Finite Element Modeling © Create a linear translation spring (CELAS1) with stiffness of K1 © Create a linear translation spring (CELAS1) with stiffness of K2 © Create a lumped mass element (CONM2) with a mass coordinate system = 1 and mass inertia system of 0.0, 0.0, 3528, 0.0, 0.0, 0.0. © Create a three-noded rigid element (RBE2) Boundary Conditions © Nodal displacement restraints o Restrain grid points 4 and 5 in all directions o Restrain the other grid points in all directions but Y and RZ Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method Results Result Bench Value NX Nastran Frequency of Mode 1 (Hz) 1.086 1.086 Frequency of Mode 2(Hz) 1.496 1.496 References Tse, F, Morse, I., and Hinkle, R, Mechanical Vibrations, Boston: Allyn and Bacon, Inc, 1978 pp. 150-153 8.6 Two Degrees of Freedom Vehicle Suspension System Determine the natural frequencies of dynamic system with two degrees of freedom. Degrees of freedom are one translational and one rotational. 88 NX Nazran £ Verification ManualTest Cases i Lisiém ay. 12=20m NS Ni a ki a Ins ; Be Ne Test Case Data and Information Input File mstvn005.dat Element Types Translational springs (CBLAS1) © Lumped mass (CONM2) * Rigid (RBE2) Units SI — meter Model Geometry © Length = 16m © Length? = 2.0 m 14 m (gyration radius; J = m'r*r) Physical Properties mass = 1800 kg © K1=42000 Nim ‘Nastran 2 Verification Manual 89Chapter8 ‘Test Cases © K2= 48000 Nim Finite Element Modeling © Create five grid points in the XY plane with the following coordinates: © Grid point 1 = (0,0) © Grid point 2 = (12,0) © Grid point 3 = 1,0) 0 Grid point 4 = (L2,-1) 0 Grid point 5 L1-1) © Create a linear translation spring (CELAS1) with stiffness of K1 between grid point 1 and grid point 5. © Create a linear translation spring (CELAS1) with stiffness of K2 between grid point 2 and grid point 4 © Create a lumped mass element (CONM2) with a mass coordinate system = 1 and mass inertia system of 0.0, 0.0, 3528, 0.0, 0.0, 0.0. © Create a three-grid-point rigid element (RBE®) using grid point 1, grid point 2, and grid point 3 Boundary Conditions © Restrain grid points 4 and 6 in all directions © Restrain the other grid points in all directions but Y and RZ. Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method Results Result Bench Value NX Nastran Frequency of Mode 1 (Hz) 1.086 1.086 Frequency of Mode 2(Hz) 1.496 1.496 References Tse, F, Morse, I., and Hinkle, R. Mechanical Vibrations, pp. 10-153. Boston: Allyn and Bacon, Ine, 1978 8.7 Cantilever Beam Undamped Free Vibrations Determine the natural frequencies of a cantilever beam. 840 NX Nastran 0 Verification ManualTest Case Data and Information Input File mstvn006.dat Element Type Linear beam (CBEAM) Units Inch Model Geometry © Length = 100 in. ©) Height = 2 in. Physical and Material Properties * w-=1lbfn. * J=.10 * Poisson's ratio = 3 Calculated Data © A=h?=4 in? hY/12 = 133333 ©) G=B/2x 1/1 + nu = 1153846154 © m= wig = 2.59067378E-3 ane + Iyy = 2.66668 Finite Element Modeling © Create 11 grid points on X axis Test Cases NW Nastran 9 Verification Manual 8-11Chapter8 ‘Test Cases © Create 10 linear beams (CBEAM) between grid points. Boundary Conditions © Restrain one end grid point in all directions. Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method Results Result Bench Value NX Nastran Frequency of Modes 1 & 2 (Transverse 6.983 6.983 Vibration) Frequency of Modes 3 & 4 (Transverse 43.58 43.58 Vibration) Frequency of Mode 5 (Torsional Vibration) 64.68 64.68 Frequency of Modes 6 & 7 (Transverse 122.0 122.0 Vibration) Frequency of Mode 8 (Torsional Vibration) 19.9 195.7 Frequency of Modes 9 & 10 (Transverse 238.8 239.3 Vibration) References Blevins, R. Formulas For Natural Frequency and Mode Shape, 1st Edition, pp. 108,193. New York: Van Norstrand Reinhold Company, 1979. 8.8 Natural Frequency of a Cantilevered Mass Determine the natural frequencies of a dynamic system consisting of a massless beam and a lumped mass at the end. 842 NNastran 0 Verification ManualTest Cases Test Case Data and Information Input File mstvn007.dat Element Types ¢ Linear beam (CBAR) * Lumped mass (CONM2) Units Inch Model Geometry Length = 30 in. Physical and Material Properties * Mass = 0.5 lbm * B= 30K6 psi © Density = 1.0E-6 15 int Finite Element Modeling © Create 2 grid points on the X axis with coordinates (0,0,0) and (30,0,0). © Create a linear beam (CBAR) element between grid points with shear area ratio = 0. © Create a lumped mass (CONM2) on one grid point with mass of 0.5 Ibm. Boundary Conditions © Restrain wall end in all directions © Restrain mass end in directions of Z, RX, and RY. Solution Type SOL 103 — Normal Mode Dynamics, Lanczos method Results Result Bench Value NX Nastean ‘Mode 2 Frequency (Hz) 15.92 15.92 [NE Nasrran 8 Verification Manual enChapter8 ‘Test Cases References Tse, F, Morse, I, and Hinkle, R. Mechanical Vibrations, 2nd Edition, p. 72, Boston: Allyn and Bacon, Inc., 1978 844 NX Nastran 0 Verification ManualPart V == Normal Mode Dynamics Verification Using Standard NAFEMS BenchmarksChapter 9 Overview of Normal Mode Dynamics Verification Using Standard NAFEMS Benchmarks The purpose of these normal mode dynamics test cases is to verify the function of NX Nastran using standard benchmarks published by NAFEMS (National Agency for Finite Element Methods and Standards, National Engineering Laboratory, Glasgow, UK). These standard benchmark tests were created by NAFEMS to stretch the limits of the finite elements in commercial software. All results obtained using NX Nastran compare favorably with other commercial finite element analysis software, Results of these test cases using other commercial finite element analysis software programs are available from NAFEMS. 9.1 Understanding the Test Case Format Each test case is structured with the following information. * Test case data and information: o Units o Physical and material properties 0 Finite element modeling information 0 Boundary conditions (loads and restraints/constraints) 0 Solution type * Results © Reference 9.2 Reference The following reference has been used in these test cases: NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis. Glasgow: NAFEMS, Nov., 1987 NE Nastran 9 Verification Manual 9-4Chapter 10 Beam Element Test Cases 10.1 Pin-ended Cross — In-plane Vibration This test is a normal mode dynamic analysis of a pin-ended cross (shown below) using beam elements This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 1 Attributes of this test are: © Coupling between flexural and extensional behavior © Repeated and close eigenvalues Test Case Data and Information Input Files * nf001ac.dat (linear consistent) © nf001al.dat (linear lumped) NE Nacrran 8 Verification Manual 10-4Chapter 10 Beam Element Test Cases Units SI Cross Sectional Properties © Area = 015625 m? Shear ratio: * Y=0 * Z=0 Material Properties * E = 20009 N/m? 1=8000 kg/m © n= 0.29 (Poisson's ratio) G=s01E10 Finite Element Modeling © Four linear beam (CBAR) elements per arm Boundary Conditions Y =0atA,B,0,D * X= © Z=R,=R,=0 atall grid points 402 NX Nastran 8 Verifeation Manual‘Beam Element Test Cases Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method NX Nastran results were obtained in two different ways: © Using lumped mass (lumped mass on, param coupmass =-1) © Using coupled mass (lumped mass off, param coupmass = 1) Results Mode Reference NAFEMS NX Nastran Result NX Nastran Result Value (Hz) Target Value (lumped mass) (Hz) (coupled mass) (Hz) (iz) 1 1134 1134 1135 1134 2,8 a7 11.69 11.66 17.69 4 a7 1.72 11.69 172 5 45.35 45.48 45.02 45.52 67 87.39 57.36 56.06 87.43 8 87.39 57.68 56.34 81.75 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J., and Knowles, N.C.Selected Benchmarks for Natural Frequency Analysis Test No. 1, Glasgow. NAFEMS, Nov. 1987 10.2 Pin-ended Double Cross - In-plane Vibration ‘This test is a normal mode dynamic analysis of a pin-ended double cross (shown below) using beam elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 2. NE Nacran 8 Verification Manual 10-3Chapter 10 Beam Element Test Cases 50m som Attributes of this test are: © Coupling between flexural and extensional behavior © Repeated and close eigenvalues Test Case Data and Information Input Files © nf002ac.dat (linear consistent) © nf002al.dat (linear lumped) Units SI Cross Sectional Properties Key-in section: © Area = 015625 m? Shear ratio: * Y=0 * Z=0 Material Properties © B= 200809 Nim? © r= 8000 kgm’ 404 NX Nastran 9 Verification Manual‘Beam Element Test Cases Finite Element Modeling © Four linear beam (CBAR) elements per arm Boundary Conditions © X=Y=0atA,B,0,D,2,5G,H = Ry= at all grid points Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method NX Nastran results were obtained in two different ways: + Using lumped mass (Jumped mass toggle on, param coupmass = © Using coupled mass (lumped mass toggle off, param coupmass = Results Mode Reference NAFEMS Target NX Nastran NX Nastean Value (Hz) Value (Hz) Result (dumped Result (coupled mass) (Hz) mass) (Hz) 1 1134 1134 1133 1134 2,8 wm 17.69 17.66 17.69 4,5,6,7,8 wm 11.72 17.69 11.72 9 45.35 45.48 45.02 45.52 10, 11 57.39 57.36 56.06 57.43 12, 13, 14, 15, 57.39 57.68 56.34 81.75 16 NE Nastran 8 Verification Manual 105Chapter 10 Beam Element Test Cases References NAFEMS Finite Element Methods & Standards Abbassian, F, Dawswell, D. J., and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No, 2, Glasgow. NAFEMS, Nov, 1987 10.3. Free Square Frame - In-plane Vibration This test is a normal mode dynamic analysis of a free square frame (shown below) using beam elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 3 7 [= 10.0m Attributes of this test are: © Coupling between flexural and extensional behavior © Rigid body modes (3 modes) © Repeated and close eigenvalues Test Case Data and Information Input Files © nf003ae.dat (linear consistent) © nf003aldat (linear lumped) Units SI Cross Sectional Properties Shear ratio * Y=10 * Z=10 406 NX Nastran 8 Verifeation ManualMaterial Properties * E = 200E09 N/m? = 8000 kg/m? Finite Element Modeling * Four linear beam (CBAR) elements per arm Boundary Conditions * Rotations fixed, translations free Restraints Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method NX Nastran results were obtained in two different ways: © Using lumped mass (lumped mass toggle on, param coupmass © Using coupled mass (lumped mass toggle off, param coupmas ‘Beam Element Test Cases Results Mode Reference NAFEMS Target NX Nastean NX Nastran Value (Hz) Value (Hz) Result (umped Result (coupled mass) (Hz) mass) (Hz) 4 3.261 3.262 3.259 3.259 6 5.668 5.665 5.660 5.663 67 1114 1115 10.89 11.13 8 12.85 12,83 12.7. 12.80 9 24.87 24.66 23.83 24.64 10, 11 28.70 28.81 28.13 28.73 NE Nastran 8 Verification Manual 10-7Chapter 10 Beam Element Test Cases References NAFEMS Finite Element Methods & Standards Abbassian, F, Dawswell, D. J., and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No. 3, Glasgow. NAFEMS, Nov, 1987 10.4 Cantilever with Off-center Point Masses This test is a normal mode dynamic analysis of a cantilever with off-center point masses (shown below) using beam elements. This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis,Test 4. a : Oz A 2m oe Attributes of this test are: © Coupling between torsional and flexural behavior © Inertial axis non-coincident with flexibility axis © Discrete lumped mass, rigid links © Close eigenvalues Test Case Data and Information Input Files * nf004adat Units SI Cross Sectional Properties Shear ratio * Y=1198 * Z=1198 Material Properties © B= 200E09 Nim? 408 NX Nasran 9 Verification Manual‘Beam Element Test Cases 8000 kg/ms =03 Finite Element Modeling * Five linear beam (CBAR) elements along cantilever Boundary Conditions © X=Y=Z-=Rx=Ry=Rz=0ata Solution Type SOL 103 — Normal Mode Dynamics, Lanczos (Parameter COUPMASS Results Mode Reference Value | NAFEMS Target NX Nastran Result (Hz) Value (Hz) (Hz) 1 1798 1723 LT 2 1797 1797 1.720 3 7.413 7.413 1.854 4 9.972 9.972 9.954 6 18.16 18.16 17.68 6 26.96 26.97 26.78 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J., and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis, Test No. 4, Glasgow: NAFEMS, Nov, 1987 10.5 Deep Simply-Supported Beam ‘This test is a normal mode dynamic analysis of a deep simply supported beam (shown below). This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 5 NE Nastran 8 Verification Manual 109Chapter 10 Beam Element Test Cases am 100m Attributes of this test are: © Shear deformation and rotary inertial (Timoshenko beam) © Possibility of missing extensional modes when using iteration solution methods © Repeated eigenvalues Test Case Data and Information Input Files © nf005ac-dat (linear consistent, param coupmass = 1) © nf005al.dat (linear lumped, param coupmass = Units SI Cross Sectional Properties Shear ratio: © Y=1.176923 © Z=1176923 Material Properties © B= 200809 Nim? © r= 8000 kgm’ * n=03 Finite Element Modeling © Five linear beam elements (CBEAM) Boundary Conditions © X=Y=Z-Rx-0ata 4040 _NXNastran 8 Verification Mania!‘Beam Element Test Cases Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method NX Nastran results were obtained in two different ways: © Using lumped mass (lumped mass on, param coupmass =~: © Using coupled mass (lumped mass off, param coupmass = 1) Results Mode Reference NAFEMS Target NX Nastran NX Nastean Value (Hz) Value (Hz) Result (dumped Result (coupled mass) (Hz) mass) (Hz) 1,2(fexural) 42.65 43.15 43.26 3 (torsional) 77.54 17.20 11.84 4 (extensional) 125.0 124.5 125.5 5,6 (flexural) 148.3 9.8 154.9 T (torsional) 933.1 224.1 12 8,9 (flexural) 284.6 271.0 306.7 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis, Test No. 5, Glasgow: NAFEMS, Nov, 1987 10.6 Circular Ring — In-plane and Out-of-plane Vibration ‘This test is a normal mode dynamic analysis of a circular ring (shown below) using beam elements This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 6 NE Nasran 8 Verification Manual 1044Chapter 10 Beam Element Test Cases Attributes of this test are: © Rigid body modes (six modes) © Repeated eigenvalues Test Case Data and Information Input Files © nf006ae dat (param coupmass = 1) © nf006al.dat (param coupmass Units SI Cross Sectional Properties Shear ratio: © Y=1.128205 © Z= 1.128205 Material Properties * E = 200E09 Nim? * 1 =8000 kg/m? * n=03 Finite Element Modeling © 20 linear beam (CBAR) elements 4042 _NXNastran 8 Verification Mansa!‘Beam Element Test Cases Boundary Conditions ¢ X=Y-=Z-R,-R,=R, active Model is unsupported Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method NX Nastran results were obtained two different ways: * Using coupled mass (param coupmass = -1) © Using lumped mass (param coupmass = 1) Results Mode Reference NAFEMS Target NX Nastran NX Nastean Value (Hz) Value (Hz) Result (dumped Result (coupled mass) (Hz) mass) (Hz) 7, 8(outof 51.85 52.29 5162 52.38 plane) 9,10 (in plane) 53.88 53.97 54.05 53.80 11, 12 outof 148.8 49.7 1469 49.7 plane) 13, 14 (in plane) 151.0 152.4 152.2 1515 15 (outof plane) 287.0 288.3 280.4 287.3 16 in plane) 289.5 288.3 289.2 289.1 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No. 6, Glasgow. NAFEMS, Nov, 1987 10.7 Cantilevered Beam This test is a normal mode dynamic analysis of a cantilevered beam (shown below). This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 71 0.125. 100m osm, NX Nastran 9 Verification Manual 10:13Chapter 10 Beam Element Test Cases Attributes of this test are: * Ill-conditioned stiffness matrix Test Case Data and Information Input Files * nf071adat (Test 1) ¢ = nf071b.dat (Test 2) * nf071ce.dat (Test 3) Units SI Material Properties © B= 200809 Nim? © r=8000 kg/ms Finite Element Modeling ‘Three tests — all use linear beam (CBAR) elements © Test 1 a=b © Test 2: a= 10b © Test3: a = 100b Boundary Conditions * X= Rz=Oata * Ze at all grid points © Re=Ry = 0 at all grid points Y foe A 4044 _NXNastran Verification Mansa!‘Beam Element Test Cases Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method ‘Beams always use a coupled mass formulation (param coupmass = 1) Results Mode Reference Value Mesh NX Nastan Result (Hz) 2) 1 1.010 1.010 1.010 1.010 2 6.327 6.324 6.327 6.330 3 11.72 1.70 17.80 17.83 4 34.72 34.70 34.86 36.07 6 57.39 87.48 60.64 64.82 6 85.73 86.24 101.86 104.74 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J,, and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis Test No, 71. Glasgow: NAFEMS, Nov, 1987 N&Nastran 9 Verification Manual 10.45Chapter 11 Shell Element Test Cases 11.1 Thin Square Cantilevered Plate — Symmetric Modes This test is a normal mode dynamic analysis of a thin, square, cantilevered plate meshed with NX Nastran shell elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 11a, 100m 0.0m Attributes of this test are © Symmetric modes, symmetric boundary conditions along the cutting plane Test Case Data and Information Input Files © nf011a_ldat (4-noded quadrilateral, lumped mass) © nf011a_edat (4-noded quadrilateral, coupled mass) * nf011ha_Idat (S-noded quadrilateral, lumped mass) © nf011ha_cdat (S-noded quadrilateral, coupled mass) Units sl NE Nastran 0 Verification Manual 14-4Chapter 11 Shell Element Test Cases Material Properties © B= 200E09 Nim? © r= 8000 kg/ms * n=03 Finite Element Modeling Two tests © 32 linear quadrilateral thin shell (CQUAD4) elements — thickness = 0.05m © § parabolic quadrilateral thin shell (CQUADS) elements — thickness = 0.05m linear shells parabolic shells Boundary Conditions ©) X=Y=Rz=0 atall grid points © Z=Ry =Rx=0 along Yaxis © Rx=0 along ¥=5m 5.0m Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method Results were obtained in two different ways: © Using lumped mass (param coupmass = -1) 442 NXNastran 8 Verifcatton Manual‘Shell Element Test Cases © Using coupled mass (param coupmass = 1) Results Mode Reference Mesh NX Nastean NX Nastean Value (Hz) Result (lumped Result (coupled mass)(Hz) mass(Hz) 1 0.4210 Linear 0.4150 0.4180 Parabolic 0.4150 0.4180 a 2.582 Linear 2.490 2.604 Parabolic 2.478 2.567 3 3.306 Linear 3.115 3.314 Parabolic 3.134 3.971 4 6.555 Linear 6.044 6.538 Parabolic 6.163, 6.539 5 7.381 Linear 7.094 7.808 Parabolic 7.099 7.495 6 11.40 Linear 10.87 12.34 Parabolic 10.99 12.08 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J,, and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis, Test No. 11a. Glasgow: NAFEMS, Nov, 1987 11.2 Thin Square Cantilevered Plate — Anti-symmetric Modes This test is 2 normal mode dynamic analysis of a thin, square, cantilevered plate meshed with shell elements This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 11b. 100m 0.0m NU Nastran 9 Verification Manual 143Chapter 11 Shell Element Test Cases Attributes of this test are: © Anti-symmetric modes Test Case Data and Information Input Files © nfO11bdat (linear (4-noded) quadrilateral) © nf011hb dat (parabolic ($-noded) quadrilateral) Units SI Material Properties © B= 200809 Nim? © r= 8000 legyém? * n=03 Finite Element Modeling Two tests © 32 linear quadrilateral thin shell (CQUAD4) elements — thickness = 0.05m © § parabolic quadrilateral thin shell (CQUADS) elements — thickness = 0.05m Mesh only half the plate (10m x 5m). linear shells perebolic shalls Boundary Conditions * X= Rz = 0 at all grid points © Z=Ry =Rx = 0 along ¥axis © Rx=Oalong Y=5m ea NXNastran 8 Verifcatton Manual‘Shell Element Test Cases 5.0m Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method NX Nastran results were obtained in two different ways © Using lumped mass (param coupmass = —1) © Using coupled mass (param coupmass = 1) Results Mode Reference Mesh. NAFEMS NX Nastran NX Nastean Value (Hz) ‘Target Value Result Result (Hz) dumped (coupled mass)(Hz) __mass(Hz) 1 1.029 Linear 1019 1.000 1.020 Parabolic 1018 1.005, 1.022 a 3.753 Linear 3.839 3.670 3.767 Parabolic 3.710 3.597 3.726 3 1.730 Linear 8.313 7.091 8.113 Parabolic 1.168 7.026 1.186 4 8.561 Linear 9.424 8.047 9.025 Parabolic 8.483 8.183, 8.690 5 not available Linear 1.73 9.940 1169 Parabolic 119 10.15 lig 6 not available Linear 17.82 14.22 144 Parabolic 15.76 21 16.78 NK Nastran 9 Verification Manual 14-5Chapter 11 Shell Element Test Cases References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis Test No. 11b, Glasgow. NAFEMS, Nov, 1987 11.3 Free Thin Square Plate This test is a normal mode dynamic analysis of a free thin square plate meshed with shell elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 12. 100m 0.0m Attributes of this test are: © Rigid body modes (three modes) © Repeated eigenvalues Test Case Data and Information Input Files © nf0121_Idat (linear (4-noded) quadrilateral, lumped mass) © nf0121_e.dat (linear (4-noded) quadrilateral, coupled mass) © nf012h_1dat (parabolic (S-noded) quadrilateral, lumped mass) © nf012h_e.dat (parabolic (S-noded) quadrilateral, coupled mass) Units SI Material Properties © B= 200809 Nim? © r= 8000 kgm’ 446 NXNastran 8 Vertfcatton Manual‘Shell Element Test Cases 03 Finite Element Modeling ‘Two tests: * 64 linear quadrilateral thin shell (CQUAD4) elements — thickness = 0.05m. 16 parabolic quadrilateral thin shell (CQUADS) elements — thickness = 0.05m linear shells parabolic shells Boundary Conditions © X=Y-=Re = 0 atall grid points Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method Results were obtained in two different ways: © Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass = 1) Results Mode Reference Mesh. NAFEMS NX Nastran NX Nastean Value (Hz) ‘Target Value Result Result (Hz) dumped (coupled mass) (Hz) __mass) (Hz) 4 1622 Linear 1632 1678 1624 Parabolic 1532 1684 1e19 5 2.360 Linear 2.402 2.041 2.389 Parabolic 2.386 2.983, 2.363 6 2.922 Linear 3.006 2.804 2.979 Parabolic 2.861 2.808 2.929 NM Nastran 9 Verification Manual 44-7Chapter 11 Shell Element Test Cases ‘Mode Reference Mesh NAFEMS NX Nastran NX Nastran Value (Hz) Target Value Result Result (iz) dumped (coupled mass) (Hz) mass) (Hz) 7,8 4253 Linear 4281 3.931 4287 Parabolic 4.122 3.944 4.158 9 7416 Linear 7.959 6822 7.790 Parabolic 7.363 6813 TAIT 10 Not Linear 8.027 6.822 7.790 available Parabolic 7.392 6.813 TAIT References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J., and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No. 12. Glasgow. NAFEMS, Nov, 1987 11.4 Simply Supported Thin Square Plate This test is a normal mode dynamic analysis of a free thin square plate meshed with shell elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 13 100m 0.0m Attributes of this test are: © Well established © Repeated eigenvalues Test Case Data and Information Input Files © nf0131_Idat (linear quadrilateral, lumped mass) 448 NXNastran 8 Verifcatton Manual‘Shell Element Test Cases © nf0131_cdat (linear quadrilateral, coupled mass) + nf013h_1dat (parabolic quadrilateral, lumped mass) * nf013h_edat (parabolic quadrilateral, coupled mass) Units SI Material Properties © B= 200809 Nim? 8000 kg/ms =03 Finite Element Modeling ‘Two tests: * 64 linear quadrilateral thin shell (CQUAD4) elements — thickness = 0.05m. 16 parabolic quadrilateral thin shell (CQUADS) elements — thickness = 0.05m linear shells parabolic shells Boundary Conditions ©) X=Y-=Rz=0 atall grid points © Z=Rx =0 along edges X= 0 and X= 10m © Z=Ry =0 along edges Y= 0 and Y= 10m Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method NX Nastran results were obtained two different ways: * Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass v NW Nastran 9 Verification Manual 14-9Chapter 11 Shell Element Test Cases Results Mode Reference Mesh NX Nastean NX Nastean Value (Hz) Result dumped Result (coupled mass) (Hz) mass) (Hz) 1 2377 Linear 2.332 2.392 Parabolic 2.376 2.382 2,3 5.942 Linear 5,797 6.181 Parabolic 5.938 6.026 4 9.507 Linear 8,963 9.933 Parabolic 9.747 10.22 5,6 11.88 Linear 1167 13.27 Parabolic 1187 12.39 18 15.45 Linear 14.45 17.07 Parabolic 16.56 18.17 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J., and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No. 13, Glasgow. NAFEMS, Nov, 1987 11.5 Simply Supported Thin Annular Plate This test is a normal mode dynamic analysis of a free thin square plate meshed with shell elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 14 4440. -NKNastran 0 Verification Manual‘Shell Element Test Cases Attributes of this test are: * Curved boundary (skewed coordinate system) © Repeated eigenvalues Test Case Data and Information Input Files © nf0141_ldat (linear quadrilateral, lumped mass) © nf0141_cdat (linear quadrilateral, coupled mass) © nf014h_Idat (parabolic quadrilateral, lumped mass) © nf014h_edat (parabolic quadrilateral, coupled mass) Units sl Material Properties © B= 200809 Nim? © r= 8000 kg/ms * n=03 Finite Element Modeling ‘Two tests: © 160 linear quadrilateral thin shell (CQUAD4) elements — thickness = 0.06 m © 48 parabolic quadrilateral thin shell (CQUADS) elements — thickness = 0.06.m linear shells NM Nastran 9 Verification Manual 44-44Chapter 11 Shell Element Test Cases Boundary Conditions * X= Re = 0 at all grid points © Ze= Rxe= 0 around the circumference Solution Type SOL 103 — Normal Mode Dynamics, Lanczos Method NX Nastran results were obtained in two different ways © Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass Results Mode Reference Mesh NX Nastean NX Nastean Value (Hz) Result dumped Result (coupled mass) (Hz) mass) (Hz) 1 1870 Linear 1.859 1877 Parabolic 1.840 1.873 2,3 5.187 Linear 5,293 5.249 Parabolic 111 5.151 4,5 9.673, Linear 10.03, 9.983 Parabolic 9.673 9.713 6 14.85 Linear 1437 1541 Parabolic 13.95 14.92 18 15.57 Linear 16.10 15.55 Parabolic 15.71 9 18.38 Linear 19.08 Parabolic 18.52 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No, 13, Glasgow: NAFEMS, Nov, 1987 11.6 Clamped Thin Rhombic Plate This test is a normal mode dynamic analysis of a free thin square plate meshed with shell elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 15. 4442. NK Nastran 0 Verification Manual‘Shell Element Test Cases Y Le Attributes of this test are: * Distorted elements Test Case Data and Information Input Files © nf0151dat linear (lumped) * nf015ha.dat parabolic (lumped) * nf015hb dat parabolic (consistent) © nf01Shedata linear (consistent) Units SI Material Properties © B= 200809 Nim? = 8000 kg/m? 03 Finite Element Modeling Two tests: © 144 linear quadrilateral thin shell (CQUAD4) elements — thickness = 0.05 m * 36 parabolic quadrilateral thin shell (CQUADS) elements — thickness = 0.05. NE Nacran 8 Verification Manual 11-13Chapter 11 Shell Element Test Cases linear shells ZLZZZZZEZZE LETTE LILLE Boundary Conditions * X= = Rz = 0 at all grid points © Z¢= Rxt= Ry¢= 0 along all four edges Solution Type S$0L103 — Normal Mode Dynamics NX Nastran results were obtained two different ways: © Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass = Results Mode Reference Mesh NAFEMS NX Nastran NX Nastran Value (Hz) Target Value Result Result (zy dumped (coupled mass) (Hz) __ mass) (Hz) 1 7.938 Linear 8.142 7.818 7.985 Parabolic 1.873 7,902 7.929 2 12.84 Linear 13,89 12.83, 13.39 Parabolic 12.48 12.85 13.01 3 1194 Linear 20.04 1781 19.07 Parabolic 1731 11.95 18.47 4 19.18 Linear 20.17 18.55 19.24 Parabolic 18.74 18.96 19.17 8 Nastran & Verification Manual‘Shell Element Test Cases Mode Reference Mesh. NAFEMS NX Nastran NX Nastean Value (Hz) Target Value Result Result (Hz) dumped (coupled mass) (Hz) ___ mass) (Hz) 5 24.01 Linear 27.70 23.67 26.19 Parabolic 27.95 23.88 25.23 6 21.92 Linear 32.05 27.10 29.82 Parabolic 25.88 27.91 28.81 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J,, and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis, Test No. 15, Glasgow. NAFEMS, Nov, 1987 11.7 Cantilevered Thin Square Plate with Distorted Mesh This test is a normal mode dynamic analysis of a free thin square plate meshed with shell elements This document provides the input data and results for NAFEMSSelected Benchmarks for Natural Frequency Analysis, Test 16. 100m 0.0m Attributes of this test are: © Distorted meshes Test Case Data and Information Input Files © nf016a1.dat: (16 parabolic quad, lumped mass) © nf016a2.dat; (16 parabolic quad, coupled mass) © nf016b1.dat: (16 parabolic quad, lumped mass) © nf016b2.dat: (16 parabolic quad, coupled mass) NE Nacran 8 Verification Manual 11-15Chapter 11 Shell Element Test Cases © nf016e1dat: (4 parabolic quad, lumped mass) © nf016e2dat: (4 parabolic quad, coupled mass) © nf016d1.dat: (4 parabolic quad, lumped mass) © nf016d2dat: (4 parabolic quad, coupled mass) Units sl Material Properties © B= 200809 Nim? © r= 8000 kgm’ * n=03 Finite Element Modeling All tests — parabolic quadrilateral thin shell elements — thickness = 0.05m Four tests © Test 1— 16 elements © Test 2— 16 elements with specified grid points at the following XY coordinates Coordinates Node x y 1 4.000 4,000 2 2.280 2,280 3 750 2,800 4 7.280 2,780 5 7.800 7.280 6 5.280 7.280 1 5.280 7.280 8 2.280 7.280 g 2.800 4.750 1146 Nastran & Verification Manual© Test 3 — 4 elements ‘Shell Element Test Cases © Test 4 —4 elements with a specified grid point at the following XY coordinate Coordinates Node x y 1 4.000 4.000 Boundary Conditions ©) X=Y=Z=Ry=0 along Yaxis NE Nacrran 8 Verification Manual aTChapter 11 Shell Element Test Cases Solution Type S$0L103 — Normal Mode Dynamics NX Nastran results were obtained in two different ways: © Using lumped mass (param coupmass = —1) © Using coupled mass (param coupmass Results Mode Reference Test NAFEMS NX Nastran NX Nastran Value (Hz) Target Value Result Result (zy dumped (coupled mass) (Hz) __ mass) (Hz) 1 0.4210 1 0.4174 0.4139 0.4181 a 0.4174 0.4135 0.4182 3 041d 0.4021 0.4189 4 0.4145 0.4000 0.4192 2 1.029 1 1.020 0.9985 L024 a 1.020 0.9967 L024 3 0.9980 0.9347 1021 4 1.002 0.9202 1025 3 2.582 1 2.564 2.444 2.569 a 2.871 2.445 2.566 3 2.554 2.132 2.708 4 2.565 2.112 2698 4448 NK Nastran 0 Verification Manual‘Shell Element Test Cases Mode Reference Test NAFEMS NX Nastran NX Nastean Value (Hz) Target Value Result Result (Hz) dumped (coupled mass) (Hz) ___ mass) (Hz) 4 3.306 1 3.302 3.082 3.281 2 3.317 3.072 3.280 3 3.401 2.707 3.449 4 3.424 2.697 3.430 5 3.753 1 3.769 3.540 3.728 2 3.780 3.535 3.731 3 3.697 3.136 3.913 4 3.714 3.077 3.881 6 6.555 1 6.805 6018 6.551 2 6.883 5.994 6.552 3 5455 5.458 7.108 4 5.133 5.459 6.858 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J,, and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis, Test No. 16. Glasgow: NAFEMS, Nov, 1987 11.8 Simply Supported Thick Square Plate, Test A This test is a normal mode dynamic analysis of a free thin square plate meshed with shell elements This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 21a. 100m 0.0m Attributes of this test are: NE Nasran 8 Verification Manual 11-19Chapter 11 Shell Element Test Cases © Well established © Repeated eigenvalues © Effect of secondary restraints Test Case Data and Information Input Files © nf021adat: linear (lumped mass) © nf021hadat: parabolic (lumped mass) Units sl Material Properties © B= 200809 Nim? © r= 8000 legyém? * n=03 Finite Element Modeling Two tests © 64 linear quadrilateral thin shell (CQUAD4) elements — thickness = 1.0m © 16 parabolic quadrilateral thin shell (CQUADS) elements — thickness = 1.0 m linear shells parabolic shells Boundary Conditions © Z=0 along all four edges * X= Rz = 0 at all grid points © Rx=0 along edges X= 0 and X= 10 m ‘Nastran 2 Verfcation Manual‘Shell Element Test Cases © Ry =Oalongedges Y= 0 and Y= 10m Solution Type S$0L103 — Normal Mode Dynamics NX Nastran results were obtained in two different ways: © Using lumped mass (param coupmass -1) © Using coupled mass (param coupmass = 1) Results Mode Reference Mesh NAFEMS = NX Nastran NX Nastean Value (Hz) ‘Target Value Result Result (Bz) (umped (coupled mass) (Hz) mass) (Hz) 1 45.90 Linear 16.66 45.83 46.35 Parabolic 45.94 46.17 45.83 2,8 109.4 Linear 118.8 110.6 14.1 Parabolic 110.4 110.3, 109.4 4 167.9 Linear 115 164.8 174.3 Parabolic 1704 167.3, 168.8 5,6 204.5 Linear 233.4 211s 207.1 Parabolic 212.8 204.6 208.2 NE Nasran 8 Verification Manual 11-24Chapter 11 Shell Element Test Cases Mode Reference Mesh NAFEMS —- NX Nastean NX Nastran Value (Hz) Target Value Result Result (iz) dumped (coupled mass) (Hz) _mass) (Hz) 7,8 256.5 Linear 283.6 250.5 2763 Parabolic 270.0 249.3 268.4 9 336.6 Linear 3711 313.1 364.3 Parabolic 344.8 34 3194 10 336.6 Linear 3711 338.4 385.8 Parabolic 344.8 347.6 3194 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No, 21a. Glasgow: NAFEMS, Nov, 1987 11.9 Simply Supported Thick Square Plate, Test B This test is a normal mode dynamic analysis of a free thin square plate meshed with shell elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 21b. 100m 0.0m Attributes of this test are: © Well established © Repeated eigenvalues © Effect of secondary restraints 4422 NK Nastran 0 Verification Manual‘Shell Element Test Cases Test Case Data and Information Input Files * nf021b_edat (quadrilateral thin shell elements — coupled mass) © nf021b_Idat (quadrilateral thin shell elements — lumped mass) * nf021hb_cdat (parabolic thin shell elements — coupled mass) © nf021hb_Idat (parabolic thin shell elements — lumped mass) Units sl Material Properties © B= 200809 Nim? = 8000 kg/mS 03 Finite Element Modeling ‘Two tests: © 64 linear quadrilateral thin shell elements — thickness = 1.0 m © 16 parabolic quadrilateral thin shell elements — thickness = 1.0 m linear shells parabolic shells Boundary Conditions © Z=0 along all four edges; X = Y = Rz = 0 at all grid points NE Nacran 8 Verification Manual 11-23Chapter 17 ‘Shell Element Test Cases Solution Type S$0L103 — Normal Mode Dynamics NX Nastran results were obtained in two different ways © Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass Results Mode Reference Mesh NAFEMS —- NX Nastran_ NX Nastran Value (Hz) Target Value Result Result (iz) dumped (coupled mass) (Hz) _mass) (Hz) 1 45.90 Linear 44.75 44.65 14.96 Parabolic 44.13 44,89 44.49 2,3 108.4 Linear \ 112.9 108.1 1123 Parabolic 107.9 108.5 107.6 4 167.9 Linear 1703 i614 170.2 Parabolic 164.2 163.6 165.7 5,6 204.5 Linear 230.2 210.5 225.4 Parabolic 20.07 203.1 206.5 18 256.5 Linear 274.9 247.1 212.8 Parabolic 260.3, 245.7 263.6 $428 -NENastran 0 Vorifeation Manual‘Shell Element Test Cases Mode Reference Mesh NAFEMS = NX Nastran NX Nastean Value (Hz) ‘Target Value Result Result (Bz) (umped (coupled mass) (Hz) mass) (Hz) 8 3366 Linear 356.0 308.8 3584 Parabolic 342.8 307.2 318.6 10 336.6 Linear 356.0 337.6 384.8 Parabolic 342.8 346.9 318.6 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J,, and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis, Test No. 21b, Glasgow: NAFEMS, Nov, 1987 11.10 Clamped Thick Rhombic Plate ‘This test is a normal mode dynamic analysis of a free thin square plate meshed with shell elements This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 22. 10.0m 10.0m Attributes of this test are: © Distorted elements Test Case Data and Information Input Files * = nf0221ldat © = nf0221_cdat * = nf022h_ldat * = nf022h_e.dat NE Nacran 8 Verification Manual 11-25Chapter 11 Shell Element Test Cases Units SI Material Properties © B= 200809 Nim? © r= 8000 legyém? * n=03 Finite Element Modeling Two tests © 100 linear quadrilateral thin shell (CQUAD4) elements - thickness = 1.0 m © 36 parabolic quadrilateral thin shell (CQUADS) elements - thickness = 1.0m linear shells parabolic shells LZZZZZZZLLE LEZ Boundary Conditions * X= Rz = 0 at all grid points © Z¢= Rxt= Ry¢= 0 along all four edges Jere Hae ee ey Solution Type SOL 103 - Normal Mode Dynamics NX Nastran results were obtained in two different ways: © Using lumped mass (parm coupmass = -1) © Using coupled mass (param coupmass ‘Nastran 2 Verfcation Manual‘Shell Element Test Cases Results Mode Reference Mesh NAFEMS = NXNastran NX Nastran Value (Hz) Target Value Result Result (Hz) dumped (coupled mass) (Hz) mass) (Hz) i 1340 Linear w78 312 1343 Parabolic 133.9 134.9 135.2 2 2014 Linear 218.5 200.4 2119 Parabolic 203.3 204.4 2063 3 265.8 Linear 298.4 262.0 286.6 Parabolic oT 2703 2764 4 2827 Linear 2968 273.6 287.0 Parabolic 283.7 286.9 289.1 5 334.5 Linear 383.6 327.0 313.3 Parabolic 346.4 337.5 353.8 6 Not Linear 426.6 372.2 410.6 available Parabolic 386.6 384.7 394.0 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J,, and Knowles, N.C.,Selected Benchmarks for Natural Frequency Analysis, Test No. 22, Glasgow: NAFEMS, Nov, 1987 11.11 Simply Supported Thick Annular Plate This test is a normal mode dynamic analysis of a simply supported thick annular plate meshed with shell elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 23 [NE Nasrran 8 Verification Manual warChapter 11 Shell Element Test Cases 60m 18m Attributes of this test are: © Curved boundary (skewed coordinate system) © Repeated eigenvalues Test Case Data and Information Input Files nf0231ldat nf0231_c.dat nf023h_ldat nf023h_e.dat Units sl Material Properties © B= 200809 Nim? © r= 8000 kgm’ * n=03 Finite Element Modeling Two tests © 160 linear quadrilateral thin shell (CQUAD4) elements — thickness = 0.6 m © 48 parabolic quadrilateral thin shell (CQUADS) elements — thickness = 0.6 m 1128 Nastran & Verification Manual‘Shell Element Test Cases linear shells parebolic shells Boundary Conditions ©) X=Y-=Rz=0 atall grid points © Ze= Rx¢= 0 around the circumference Solution Type SOL 103 — Normal Mode Dynamics NX Nastran results were obtained in two different ways: © Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmas = 1) NE Nacran 8 Verification Manual 11-29Chapter 11 Shell Element Test Cases Results Mode Reference Mesh NAFEMS NX Nastean NX Nastran Value (Hz) Target Value Result Result (iz) dumped (coupled mass) (Hz) __mass(Hz) T 1558 Linear 1882 1540 15.64 Parabolic 18.59 18.58 18.65 2,8 48.92 Linear 49.82 50.00 50.81 Parabolic 49.02 49.22 49.41 4,5 92.59 Linear 96.06 93.09 96.00 Parabolic 92.90 93.41 93.78 6 140.2 Linear us3 134.6 147.0 Parabolic 09 140.2 143.1 18 Not Linear 153.7 44.0 162.1 available parabolic 466 u47.0 148.2 9 1684 Linear 1745 162.2 ut Parabolic 167.3 168.9 1704 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No. 23. Glasgow: NAFEMS, Nov, 1987 11.12 Cantilevered Square Membrane This test is a normal mode dynamic analysis of a cantilevered square membrane meshed with shell elements This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 31 10.0m 10.0m Attributes of this test are: 4490. -NKNastran 0 Verification Manual‘Shell Element Test Cases Well established Test Case Data and Information Input Files *nf0311dat (linear quadrilateral, lumped mass) © nf081a.dat (linear quadrilateral, coupled mass) *nf031h dat (parabolic quadrilateral, lumped mass) + nf031j.dat (parabolic quadrilateral, coupled mass) Units SI Material Properties © B= 200809 Nim? 8000 kg/m’ 03 Finite Element Modeling ‘Two tests: * 64 linear quadrilateral thin shell (CQUAD4) elements - thickness = 0.05 m 16 parabolic quadrilateral thin shell (CQUADS) elements - thickness = 0.05 m linear shells parabolic shells NE Nasran 8 Verification Manual 11-34Chapter 11 Shell Element Test Cases Boundary Conditions © X= Y= 0 along the Y axis © Z=Oatall grid points Solution Type SOL 103 — Normal Mode Dynamics NX Nastran results were obtained in two different ways: © Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass = 1) Results Mode Reference Mesh NAFEMS —- NX Nastran_ NX Nastran Value (Hz) Target Value Result Result (iz) dumped (coupled mass) (Hz) __mass) (Hz) 1 52.40 Linear 52.91 5248 52.78 Parabolic 52.64 52.30 52.60 2 196.7 Linear 126.1 125.6 126.1 Parabolic 125.9 195.7 125.9 3 40s Linear 143.2 139.6 29 Parabolic M15 139.5 uid 4 222.5 Linear 228.9 215.1 201.8 Parabolic 224.6 a4 224.3 5 14 Linear Arg 240.1 2aT Parabolic 243.3, 242.3 42.9 4492 NK Nastran 0 Verification Manuat‘Shell Element Test Cases Mode Reference Mesh NAFEMS = NX Nastran NX Nastean Value (Hz) ‘Target Value Result Result (Bz) (umped (coupled mass) (Hz) mass) (Hz) 6 Linear 260.6 252.4 259.8 Parabolic 256.8 254.6 256.6 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J,, and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No. 31. Glasgow: NAFEMS, Nov, 1987 11.13 Cantilevered Tapered Membrane This test is a normal mode dynamic analysis of a cantilevered tapered membrane meshed with shell elements This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 32 Attributes of this test are: 25m I <> 1.0m 10.0m © Shear behavior © Irregular mesh © Symmetry Test Case Data and Information Input Files © nf032l.dat (linear quadrilateral, lumped mass) © nf032a.dat (linear quadrilateral, coupled mass) © nf032h dat (parabolic quadrilateral, lumped mass) NE Nacran 8 Verification Manual 11-33Chapter 11 Shell Element Test Cases © nf039j.dat (parabolic quadrilateral, coupled mass) Units SI Material Properties © B= 200809 Nim? © r= 8000 kgm’ * n=03 Finite Element Modeling Two tests © 198 linear quadrilateral thin shell (CQUADR) elements — thickness = 0.1m © 32 parabolic quadrilateral thin shell (CQUADS) elements — thickness = 0.1m linear shells parabolic shells oe (to eee a , FREESE [i 5 LEER pp Coe ee | J Boundary Conditions * X= 0 along the Y axis © Z=Oatall grid points Nastran & Verification Manual‘Shell Element Test Cases Solution Type SOL 103 — Normal Mode Dynamics NX Nastran results were obtained in two different ways: © Using lumped mass (param coupmas = -1) © Using coupled mass (param coupmass = 1) Results Mode Reference Mesh NAFEMS = NX Nastran NX Nastean Value (Hz) ‘Target Value Result Result (Bz) dumped (coupled mass) (Hz) mass) (Hz) 1 44.62 Linear 44.91 44.66 44.78 Parabolic 44.64 44.54 44.63 a 130.0 Linear 132.1 130.3, 1318 Parabolic 130.1 129.7 130.1 3 162.7 Linear 1628 162.6 162.8 Parabolic 162.7 162.7 162.7 4 246.1 Linear 253.0 246.1 252.3 Parabolic 146.6 245.1 246.4 5 3799 Linear 393.3 377.9 393.2 Parabolic 382.0 377.9 3814 6 3914 Linear 396.3 389.7 395.0 Parabolic 3916 390.9 3915 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis, Test No. 32. Glasgow: NAFEMS, Nov, 1987 11.14 Free Annular Membrane This test is a normal mode dynamic analysis of a free annular membrane meshed with shell elements This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 33, NE Nacran 8 Verification Manual 11-35Chapter 11 Shell Element Test Cases 60m 18m Attributes of this test are: © Repeated eigenvalues © Rigid body modes (three modes) Test Case Data and Information Input Files © nf0331.dat (linear quadrilateral, lumped mass) © nf033adat (linear quadrilateral, coupled mass) © nf033h dat (parabolic quadrilateral, lumped mass) © nf033j.dat (parabolic quadrilateral, coupled mass) Units SI Material Properties © B= 200809 Nim? © r= 8000 legyém? © n=03 Nastran & Verification Manual‘Shell Element Test Cases Finite Element Modeling ‘Two tests: © 160 linear quadrilateral thin shell (CQUAD4) elements — thickness = 0.06 m © 48 parabolic quadrilateral thin shell (CQUADS) elements — thickness = 0.06 m parebolie shells Boundary Conditions © Z=Oatall grid points restraint set DOF set Solution Type SOL 103 — Normal Mode Dynamics NX Nastran results were obtained two different ways: © Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass = 1) NE Nacran 8 Verification Manual 11-37Chapter 11 Shell Element Test Cases Results Mode Reference Mesh NAFEMS —- NX Nastran_ NX Nastran Value (Hz) Target Value Result Result (iz) dumped (coupled mass) (Hz) __mass) (Hz) 4,5 129.2 Linear 129.5) 197.8 1288 Parabolic 126.5 195.7 125.8 6 226.2 Linear 228.8 204.5 225.3 Parabolic 204.3 294.0 204.2 18 234.7 Linear 234.9 229.9 234.9 Parabolic 233.0 230.8 233.0 9, 10 264.7 Linear 272.1 264.3 2712 Parabolic 264.8 262.6 263.6 11, 12 336.6 Linear 340.3, 329.0 3399 Parabolic 336.7 3316 335.7 13, 14 376.8 Linear 392.0 369.9 390.5 Parabolic 378.6 373.3 377 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No. 33. Glasgow: NAFEMS, Nov, 1987 11.15 Cantilevered Thin Square Plate This test is a normal mode dynamic analysis of a cantilevered thin square plate meshed with shell elements This document provides the input data and results for NAFEMSSelected Benchmarks for Natural Frequency Analysis, Test 73 10.0m 10.0m 4498 NK Nastran 0 Verification Manual‘Shell Element Test Cases Test Case Data and Information Input Files © nf073adat (Test 1) © nf073bdat (Test 2) * nf073e.dat (Test 3) © nf073d.dat (Test 4) Units SI Material Properties © B= 200809 Nim? © r= 8000 kegém’ Finite Element Modeling 16 parabolic quadrilateral thin shell (CQUADS) elements — thickness = 0.05 m Boundary Conditions X= = Ry = 0 along the Y axis NE Nacran 8 Verification Manual 11-39Chapter 17 Solution Type SOL 103 — Normal Mode Dynamics ‘Shell Element Test Cases NX Nastran results were obtained in two different ways © Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass = Results Mode Reference Mesh NAFEMS —- NX Nastran_ NX Nastran Value (Hz) Target Value Result Result (iz) dumped (coupled mass) (Hz) __mass) (Hz) 1 0.4210 ‘Test 1 0.4174 0.4184 0.4183 Test 2 0.4174 0.4164 0.4183 Test 3 0.4175 0.4164 0.4184 Test 4 0.4184 0.4161 0.4192 2 1.028 Test 1 1.020 1.051 1.023 Test 2 1.020 1.006 1.023 Test 3 L021 1.007 1.027 Test 4 1.032 1.015 1004 3 Test 1 2.564 2.486 2.579 Test 2 2.597 2.509 2.605 Test 3 2677 2.504 2675 Test 4 2.850 2.563 2672 4 3.306 Test 1 3.302 3.180 3.298 Test 2 3.345 3.180 3.332 Test 3 3.365 3.196 3.344 Test 4 3.871 3.373 3.535 5 3.753 Test 1 3.769 3.622 3.765 Test 2 3.888 3.713 3.862 Test 3 4,035 3.828 4.000 Test 4 5.466 4.935 6.360 6 376.8 Test 1 6.805 6.292 6719 Test 2 1817 6.901 7.399 Test 3 7.495 6.879 1.387 Test 4 —_ — — 440 _NXNastran 9 Verification Manuat‘Shell Element Test Cases References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis, Test No. 73. Glasgow: NAFEMS, Nov, 1987 NENasran 8 Verification Manual 11-84Chapter 12. Axisymmetric Solid and Solid Element Test Cases 12.1 Free Cylinder — Axisymmetric Vibration This test is a normal mode dynamic analysis of a free cylinder meshed with axisymmetric elements This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 41. | 10.0m Attributes of this test are © Rigid body modes (one mode) © Coupling between axial, radial, and circumferential behavior © Close eigenvalues Test Case Data and Information Input Files © nf041.dat (linear axisymmetric, lumped mass) © nf041adat (linear axisymmetric, coupled mass) © nf041h dat (parabolic axisymmetric, lumped mass) © nf041j.dat (parabolic axisymmetric, coupled mass) Units sl NE Nacran 8 Verification Manual 12.4Chapter12 Axisymmetric Solid and Solid Element Test Cases Material Properties © B= 200809 Nim? © r= 8000 kg /m3 * n=03 Finite Element Modeling Two tests © 16 axisymmetric solid linear quadrilateral (CQUADX) elements © 8 axisymmetric solid parabolic quadrilateral (CQUADX) elements parabolic axisymmetric Pr yULZ Boundary Conditions Unsupported Solution Type SOL 103 — Normal Mode Dynamics NX Nastran results were obtained in two different ways © Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass = 1) 422 NXNasran 9 Verifeation Manual‘Axisymmetric Solid and Solid Element Test Cases Results Mode # Reference Mesh NAFEMS NX Nastran NX Nastean Value (Hz) Target Result Result Value (Hz) (umped (coupled mass) (Hz) mass) (Hz) a 23.5 Linear 244.0 243.1 243.9 Parabolic 243.5 243.4 243.5 3 3774 Linear 3794 372.1 3784 Parabolic 377.5 3764 3774 4 394.1 Linear 395.4 385.8 394.4 Parabolic 394.3, 392.4 394.2 5 391.7 Linear 4014 386.9 398.5 Parabolic 397.9 392.8 3917.9 6 405.3 Linear 401.9 3917 415.4 Parabolic 406.4 397.2 406.0 Note ‘The reference value refers to the accepted solution to the problem. References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J,, and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis, Test No. 41. Glasgow: NAFEMS, Nov, 1987 12.2 Thick Hollow Sphere — Uniform Radial Vibration This test is a normal mode dynamic analysis of a thick hollow sphere meshed using axisymmetric elements This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 42. Zz NE Nacran 8 Verification Manual 123Chapter12 Axisymmetric Solid and Solid Element Test Cases Attributes of this test are: © Curved boundary (skewed coordinate system) © Constraint equations Test Case Data and Information Input Files © nf042.dat (linear axisymmetric, lumped mass) © nf042adat (linear axisymmetric, oupled mass) © nf042h dat (parabolic axisymmetric, lumped mass) © nf049j.dat (parabolic axisymmetric, coupled mass) Units SI Material Properties © B= 200809 Nim? © r= 8000 kgm’ © n=03 Finite Element Modeling © 10 axisymmetric solid linear quadrilateral (CQUADX) elements -a 424 NX Nastran 9 Verifeation Manual‘Axisymmetric Solid and Solid Element Test Cases Boundary Conditions © Zédisplacement = 0 at all grid points * Grid points at the same Réare constrained to have the same rédisplacement © One constraint set Retraint Set LARA * seasrane St rei Zz Solution Type SOL 103 — Normal Mode Dynamics NX Nastran results were obtained in two different ways: * Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass = 1) Results Mode # Reference Mesh NAFEMS NX Nastran NX Nastran Value (Hz) Target Result Result Value (Hz) (lumped (coupled mass) (Hz) __mass) (Hz) 1 3699 Linear 370.6 3693 369.6 Parabolic 370.0 369.7 369.7 a 838.0 Linear 841.2 828.1 837.7 Parabolic $38.1 836.2 837.7 3 Ma1 Linear 1473. ui6 1468, Parabolic 1453. M445, Ma1 4 2117, Linear 2192. 2023, 2186. Parabolic 2132, 2100. 2117, 5 2796. Linear 2976. 2595. 2967 Parabolic 2853. 2764 2799, NE Nasran 8 Verification Manual 125Chapter12 Axisymmetric Solid and Solid Element Test Cases Note The reference value refers to the accepted solution to the problem. References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J., and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis Test No. 42. Glasgow. NAFEMS, Nov, 1987 12.3 iply Supported Annular Plate — Axisymmetric Vibration This test is a normal mode dynamic analysis of a simply supported annular plate meshed with axisymmetric elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 43 1am 42m Attributes of this test are: © Well established Test Case Data and Information Input Files © nf043adat (lumped mass) © nf043bdat (coupled mass) © nf043edat (lumped mass) © nf043d.dat (coupled mass) Units SI Material Properties © E = 200E09 NA © r= 8000 kg/m? * n=03 426 NX Nastran 9 Verification Manual‘Axisymmetric Solid and Solid Element Test Cases Finite Element Modeling Two tests: * 60 axisymmetric solid linear quadrilateral (CQUADX) elements © 5 axisymmetric solid parabolic quadrilateral (CQUADX) elements Zz linear axisymmetric parabolic axisymmetric Boundary Conditions * Z=O0ata Solution Type SOL 103 — Normal Mode Dynamics NX Nastran results were obtained in two different ways: * Using lumped mass (param coupmass = —1) © Using coupled mass (param coupmass = 1) Results ‘Mode # Reference Mesh NAFEMS NX Nastean NX Nastran Value (Hz) Target Result Result Value (Hz) (lumped (coupled mass) (Hz) __ mass) (Hz) 1 18.64 Linear 18.71 18.93 18.97 Parabolic 18.58 18.48 18.55 a 150.2 Linear M55 40.9 142.6 Parabolic M456 135.9 138.6 NE Nastran 8 Verification Manual 127Chapter12 Axisymmetric Solid and Solid Element Test Cases Mode # Reference Mesh NAFEMS NXNastran NX Nastran Value (Hz) ‘Target Result Result Value (Hz) dumped (coupled mass) (Hz) __mass) (Hz) 3 204.2 Linear 204.2 204.2 294.2 Parabolic 204.2 204.1 294.2 4 388.3 Linear 385.6 366.3 376.5 Parabolic 374.1 345.3 360.3 5 629.2 Linear 689.3 1.7 617.8 Parabolic 686.0 592.7 640.2 Note The reference value refers to the accepted solution to the problem. References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No. 43, Glasgow: NAFEMS, Nov, 1987 12.4 Deep Simply Supported "Solid" Beam This test is a normal mode dynamic analysis of a deep, simply supported beam meshed with solid elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis , Test 51 2.0m 20m AY’ 4g Local coordinate system XYZ is arbitrary Attributes of this test are: © Skewed coordinate system © Skewed restraints 428 NX Nasran 9 Verifeation Manual‘Axisymmetric Solid and Solid Element Test Cases Test Case Data and Information Input Files © nf051adat (Linear brick) © nf051bdat (parabolic brick) © nf0Siedat (linear pyramid) * nf061d.dat (parabolic pyramid) Units SI Material Properties © B= 200809 Nim? = 8000 kg/m? =03 Finite Element Modeling Four tests: © 30 solid linear brick (CHEXA) elements * 5 solid parabolic brick (CHEXA) elements * 180 solid linear pyramid (CPYRAM) elements (created by dividing each linear brick element into 6 pyramid elements) * 30 solid parabolic pyramid (CPYRAM) elements (created by dividing each parabolic brick element into 6 pyramid elements) NE Nasran 8 Verification Manual 129Chapter12 Axisymmetric Solid and Solid Element Test Cases Boundary Conditions © X= Ze= 0 along AAG O along BBC © Yo= 0 at all grid points on the plane Y¢= 2.0m Solution Type SOL 103 — Normal Mode Dynamics NX Nastran results were obtained two different ways: © Using lumped mass (param coupmass = —1) © Using coupled mass (param coupmass = 1) Results Mode # Reference Mesh NAFEMS NXNastran NX Nastran Value (Hz) Target Result Result Value (Hz) (umped (coupled mass) (Hz) __mass) (Hz) 1 38.20 linear brick 42.88 37.96 38.28 linear pyramid 41.30 41.50 parabolic brick 38.82 37.85 38.24 parabolic 37.90 38.10 pyramid 4240. _NXNastran 8 Verification Mania!‘Axisymmetric Solid and Solid Element Test Cases ‘Mode # Reference Mesh NAFEMS NXNastran NX Nastran Value (Hz) Target Result Result Value (Hz) dumped (coupled mass) (Hz) __mass) (Hz) 2 85.21 linear brick 93.82 83.38 83.95 linear pyramid 89.30 89.60 parabolic brick 88.45 87.12 87.52 parabolic 86.30 86.50 pyramid 3 152.2 linear brick 170.7 152.7 187.6 linear pyramid 163.0 166.0 parabolic brick 159.4 1518 187.0 parabolic 152.0 158.0 pyramid 4 245.5 linear brick 286.1 2516 264.9 linear pyramid 269.0 276.0 parabolic brick 259.2 248.5 258.2 parabolic 250.0 255.0 pyramid 5 297.1 linear brick «318.9 288.0 298.3 linear pyramid 303.0 309.0 parabolic brick 307.9 289.6 305.6 parabolic 291.0 300.0 pyramid Note ‘The reference value refers to the accepted solution to the problem. References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J,, and Knowles, N.G,, Selected Benchmarks for Natural Frequency Analysis Test No. 51, Glasgow. NAFEMS, Nov. 1987 12.5 Simply Supported "Solid" Square Plate ‘This test is a normal mode dynamic analysis of a simply supported square plate meshed with solid elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 52 NE Nasran 8 Verification Manual 12-44Chapter12 Axisymmetric Solid and Solid Element Test Cases 10.0m 10.0m Attributes of this test are: © Well established © Rigid body modes (three modes) © Kinematically incomplete suppressions Test Case Data and Information Input Files © nf052.dat (linear brick) © nf05%b.dat (parabolic brick) © nf05%edat (linear pyramid) © nf052d.dat (parabolic pyramid) Units SI Material Properties © B= 200809 Nim? © r= 8000 legyém? © n=03 4242 NX Nastan 8 Verification Mania!‘Axisymmetric Solid and Solid Element Test Cases Finite Element Modeling Four tests: © 64 solid linear brick (CHEXA) elements * 16 solid parabolic brick (CHEXA) elements linear se zt eet ne * 384 solid linear pyramid (CPYRAM) elements (created by dividing each linear brick element into 6 pyramid elements) * 96 solid parabolic pyramid (CPYRAM) elements (created by dividing each parabolic bricks element into 6 pyramid elements) Boundary Conditions Z = 0 along the four edges on the plane Z = -0.5 m NN Nastran 9 Verification Manual 1243Chapter12 Axisymmetric Solid and Solid Element Test Cases Solution Type SOL 103 normal modes NX Nastran results were obtained in two different ways © Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass Results Mode # Reference Mesh NAFEMS NX Nastean NX Nastean Value Target Value Result Result (coupled (Bz) (Hz) dumped mass) (Hz) mass) (Hz) 4 45.90 linearbrick 51.65 44.04 45.04 linear pyramid 66.90 68.00 parabolic brick 44.76 43.81 44.16 parabolic 44.70 44.80 pyramid 5,6 1094 linear brick = 132.7 106.5 118.7 linear pyramid 154.0 160.0 parabolic brick 110.5 108.2 107.9 parabolic 108.0 110.0 pyramid 1 167.9 linearbrick 194.4 155.5 172.3 linear pyramid 195.0 197.0 parabolic brick 169.1 156.3 163.9 parabolic 166.0 169.0 pyramid 8 193.6 linearbrick 197.2 193.6 196.8 linear pyramid 207.0 212.0 parabolic brick 193.9 194.0 193.9 parabolic 194.0 194.0 pyramid 9 2062 linear brick 210.6 200.1 209.6 linear pyramid 207.0 212.0 parabolic brick 206.6 193.5 206.6 parabolic 196.0 207.0 pyramid 4244 NX Nastan 8 Verification Mansa!‘Axisymmetric Solid and Solid Element Test Cases Mode # Reference Mesh NAFEMS NX Nastran NX Nastran Value Target Value Result Result (coupled (Hz) (Hz) dumped mass) (Hz) mass) (Hz) 10 2062 Linearbrick 2106 200.1 209.6 linear pyramid 220.0 223.0 parabolic brick 206.6 193.5 206.6 parabolic 196.0 207.0 pyramid Note ‘The reference value refers to the accepted solution to the problem. References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J,, and Knowles, N ©. Selected Benchmarks for Natural Frequency Analysis, Test No. 52. Glasgow: NAFEMS, Nov, 1987 12.6 Simply Supported "Solid" Annular Plate This test is a normal mode dynamic analysis of a simply supported annular plate meshed with solid elements, This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 53 a7 ° Lam Attributes of this test are * Curved boundary (skewed coordinate system) * Constraint equations Test Case Data and Information Input Files * — nf0531.dat (linear brick) NN Nastran 0 Verification Manual 12.45Chapter12 Axisymmetric Solid and Solid Element Test Cases © nf053h dat (parabolic brick) © nf083edat (linear pyramid) © nf053d.dat (parabolic pyramid) Units SI Material Properties © B= 200809 Nim? © r= 8000 legyém? * n=03 Finite Element Modeling Four tests © 60 solid linear brick (CHEXA) elements — * 6 solid parabolic brick (CHEXA) elements — a = 10° Parabolic © 360 solid linear pyramid (CPYRAM) elements (created by dividing each linear brick element into 6 pyramid elements) © 30 solid parabolic pyramid (CPYRAM) elements (created by dividing each parabolic brick: element into 6 pyramid elements) 4248 _NXNastran 8 Verification Mansa!‘Axisymmetric Solid and Solid Element Test Cases Boundary Conditions * qdisplacement = 0 at all grid points © Zdisplacement = 0 at all grid points along AA © Grid points at same R and Z are constrained to have same z displacement © One constraint set Solution Type SOL 103 — Normal Mode Dynamics NX Nastran results were obtained in two different ways: * Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass = 1) Nastran 0 Verification Manual 12.417Chapter12 Axisymmetric Solid and Solid Element Test Cases Results Mode # Reference Mesh NAFEMS NX Nastran NX Nastean Result Value (Hz) Target Result (coupled mass) Value (Hz) (lumped (Hz) mass) (Hz) 1 18.58 linear brick | 19.66 18.67 18.61 linear pyramid 19.90 19.90 parabolic brick 18.58 18.45 18.58 parabolic 21.30 21.80 pyramid 2 140.2 linear brick. 1464 138.8 40.5 linear pyramid 47.0 u4s.0 parabolic brick 140.4 136.9 140.3 parabolic 140.0 43.0 pyramid 3 204.9 linear brick. 294.3 294.2 204.4 linear pyramid 224.0 224.0 parabolic brick 224.9 223.7 204.2 parabolic 224.0 225.0 pyramid 4 358.3 linear brick. 386.7 3618 372.1 linear pyramid 383.0 390.0 parabolic brick $74.0 3512 3719 parabolic 359.0 376.0 pyramid 5 629.2 linear brick. 689.5 643.8 6r4.7 linear pyramid 684.0 690.0 parabolic brick 686.0 624.7 679.6 parabolic 640.0 683.0 pyramid References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No. 83. Glasgow. NAFEMS, Nov, 1987 4248 _NXNastran Verification Mansa!‘Axisymmetric Solid and Solid Element Test Cases 12.7 Cantilevered Solid Beam This test is a normal mode dynamic analysis of a cantilevered solid beam meshed using solid elements This document provides the input data and results for NAFEMS Selected Benchmarks for Natural Frequency Analysis, Test 72. //200 re Om Attributes of this test are © Highly populated stiffness matrix Test Case Data and Information Input Files © nf072a dat (parabolic bricks — conventional) * nf072b.dat (parabolic bricks — unconventional) © nf072c.dat (parabolic pyramids — conventional) © nf072d.dat (parabolic pyramids — unconventional) Units sl Material Properties * E = 200E09 N/m? 8000 kg/ms 3 NN Nastran 9 Verification Manual 12.419Chapter12 Axisymmetric Solid and Solid Element Test Cases Finite Element Modeling Four tests ‘Test 1: solid parabolic brick (CHEXA) elements, conventional grid point numbering ‘Test 2: solid parabolic pyramid (CPYRAM) elements (created by dividing each brick element into 6 pyramid elements), conventional grid point numbering ‘Test 3: solid parabolic brick (CHEXA) elements, unconventional grid point numbering ‘Test 4: solid parabolic pyramid (CPYRAM) elements (created by dividing each brick element into 6 pyramid elements), unconventional grid point numbering 12.20 NXE Nastran 8 Verification Manual‘Axisymmetric Solid and Solid Element Test Cases Boundary Conditions * X=Y= = 0 at all grid points on X= 0 plane © Y= 0 atgrid points on Y= 1m plane Solution Type SOL 103 — Normal Mode Dynamics NX Nastran results were obtained in two different ways: * Using lumped mass (param coupmass = -1) © Using coupled mass (param coupmass = 1) Nastran O Verification Manual 12.24Chapter12 Axisymmetric Solid and Solid Element Test Cases Results Mode # Mesh NAFEMS NX Nastean NX Nastran ‘Target Value Result (lumped Result (coupled (Hz) mass) (Hz) mass) (Hz) 1 ‘Test 1 16.01 15.82 15.99 ‘Test 2 15.90 16.00 ‘Test 3 16.01 15.82 15.99 ‘Test 4 15.90 16.00 2 ‘Test 1 87.23 83.18 87.09 ‘Test 2 84.30 87.00 ‘Test 3 87.23 83.18 87.09 ‘Test 4 84.30 87.00 3 ‘Test 1 126.0 195.5 126.0 ‘Test 2 126.0 126.0 Test 3 126.0 195.5 126.0 ‘Test 4 126.0 126.0 4 Test 1 209.6 193.5 209.1 ‘Test 2 198.0 209.0 ‘Test 3 209.6 193.5 209.1 ‘Test 4 198.0 209.0 5 ‘Test 1 3611 310.1 349.9 ‘Test 2 323.0 360.0 ‘Test 3 3611 310.1 349.9 ‘Test 4 323.0 360.0 6 ‘Test 1 375.8 364.2 375.8 ‘Test 2 367.0 375.0 ‘Test 3 375.8 364.2 375.8 ‘Test 4 367.0 375.0 References NAFEMS Finite Element Methods & Standards, Abbassian, F, Dawswell, D. J, and Knowles, NO. Selected Benchmarks for Natural Frequency Analysis, Test No. 72, Glasgow: NAFEMS, Nov, 1987 4222 _NXNastran Verification Mansa!Part VI Verification Test Cases from the Societe Francaise des Mecaniciens [NX Nastran 0 Verification ManualChapter 13 Overview of Verification Test Cases Provided by the Societe Francaise des Mecaniciens ‘The purpose of these linear statics test cases is to verify the function of NX Nastran using standard benchmarks published by SFM (Societe Francaise des Mecaniciens, Paris, France) in Guide de validation des progiciels de calcul de structures. Included here are © Tests cases on mechanical structures using linear statics analysis, normal mode dynamics analysis, and model response © Stationary thermal test cases using heat transfer analysis © Thermo-mechanical test cases using linear statics analysis. ‘Results published in Guide de validation des progiciels de calcul de structures are compared with those computed using NX Nastran, 13.1 Understanding the Test Case Format Each test case is structured with the following information. * Test case data and information: o Input files o Units 0 Material properties 0 Finite element modeling information © Boundary conditions (loads and restraints) 0 Solution type * Results © Reference NE Nactran 8 Verification Manual 13-4Chapter 13 Overview of Verification Test Oases Provided by the Societe Francaise des Mecaniciens 13.2 Reference The following reference has been used in these test cases: Societe Francaise des Mecaniciens. Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. 422 NXNasran 9 Verification ManualChapter 14. Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements 14.1 Short Beam on Two Articulated Supports This test is a linear statics analysis of a short, straight beam with plane bending and shear loading. It provides the input data and results for benchmark test SSLL02/89 from Guide de validation des progiciels de calcul de structures. Y 4 h 7 B c zn x 1440.0 mm © Area = 31-04 m? aan © Inertia = 2810E-08 m+ © Shear area ratio = 2.42 Test Case Data and Information Input Files ssll02.dat Units sr Material Properties «© E=2E11Pa 2 n=03 NE Nasran 8 Verification Manual 18-4Chapter 14 Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Finite Element Modeling © 10 linear beam (CBAR) elements © 11 grid points The mesh is shown in the following figure Boundary Conditions © Restrain both free ends of the beam in translation DOF. 0 Bdge load = 1805 N/m in ~¥ direction The boundary conditions are shown in the following figure ALLULIDUUUCOTIUIUUTTTCVITTTUIESTUUUUIDIUUQTUNT, Solution Type SOL 101 — Linear Statics Results Result Bench Value NX Nastean Displacement at point B v (m) (Grid point 7) —1. 2598-3 =1249E-3 References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLLO2/S9, 14.2 Clamped Beams Linked by a Rigid Element This test is a linear statics analysis of a straight, cantilever beam with plane bending and a rigid element, It provides the input data and results for benchmark test SSLLO8/S9 from Guide de validation des progiciels de calcul de structures y Sp Sp oO 442 NXNasran 9 Verifeation Manual‘Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Test Case Data and Information Input File ssll05.dat Units sr Material Properties «© E=2E11Pa 4/3)B-08 mt Finite Element Modeling © 20 linear beam (CBAR) elements © Lrigid element © 26 grid points The mesh is shown in the following figure: Boundary Conditions * Points A and C: Clamped * Point D: Set nodal force = 1000 N in -Y direction The boundary conditions are shown in the following figure: Solution Type SOL 101 — Linear Statics NE Nacran 8 Verification Manual 14-3Chapter 14 Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Results Type Geid point Point Bench NX Value _Nastean v(m) Disp. Y Grid point 6 B 0.1950 -0.1250 v(m) Disp. Y Grid point 3 D 0.1950 -0.1250 V force (N) Y Grid point 1 A 500.0 500.0 M moment (Nm)Rz Grid point 1 A 500.0 500.0 V force (N)Y Grid point 4 c 500.0 500.0 Mmoment (Nm) Rz Grid point 4 c 500.0 500.0 References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990 Test No. SSLLOS/S9. 14.3. Transverse Bending of a Curved Pipe This test is a linear statics analysis (three-dimensional problem) of a curved pipe with transverse bending and bending-torque loading, It provides the input data and results for benchmark test SSLLOT/89 from Guide de validation des progiciels de calcul de structures, z B x F R 6 J * R-lm © di=0016m © A=11318-0-04 m? 4.637E-09 mt 484 NXNastran 9 Verification Manual‘Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Test Case Data and Information Input Files © ssll07adat linear beam © ssll07b.dat curved beam Units sr Material Properties «© E=2E11Pa 03 Finite Element Modeling Test 1 © 90 linear beam (CBAR) elements © 91grid points Test 2 * 90 curved beam (CBEND) elements © 91grid points ‘To obtain the point where q = 15° with accuracy, use surface mapped meshing on 1/4 of a cylinder ‘Then mesh a curved edge with the Surface Coating command and undo the mesh on the surface, ‘The mesh for Test 1 is shown in the following figure NE Nasran 8 Verification Manual 145Chapter 14 Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Boundary Conditions * Clamp point A * Grid point force F = 100 N in Z direction. The boundary conditions are shown in the following figure a. Solution Type SOL 101 — Linear Statics Results Type Geid point Point Bench Test NX Nastean Value Number u(m)Disp Z Grid point 1 B 0.1346 1 0.1346 a 0.1346 Mt (Nm)* Grid point 1 q= 15° 74.12 1 16.61 a 1181 Mf (Nm) 96.59 1 -96.37 a 95.70 Mf = bending moment Mt = torsional moment *See "Post Processing” below 446 NX Nasran 9 Verifeation Manual‘Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Post Processing Linear Beam (CBAR) Elements List beam forces on element 167, second end: * Mf= torque * Mt = bending moment Curved Beam (CBEND) Elements List beam forces on element 166, second end: * Mf= torque © Mt = bending moment References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990.Test No. SSLLOT/S9. 14.4 Plane Bending Load on a Thin Arch ‘This test is a linear statics analysis (plane problem) of a thin arc with plane bending: It provides the input data and results for benchmark test SSLLOS/S9 from Guide de validation des progiciels de calcul de structures. c ‘de a * R-lm © de=002m © di=0016m © A= 1131804 m2 © 1,4.6378-09 mt NE Nastran 8 Verification Manual 147Chapter 14 Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Test Case Data and Information Input File ssll0S.dat Units SI Material Properties © E=9E11Pa * n=03 Finite Element Modeling ¢ 10 linear beam (CBAR) elements © 11 grid points 448 NX Nasran 0 Verification Manual‘Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Boundary Conditions © Point A: Articulated Z © Point B: Sets Y and Z displacement to 0 © Force = 100N in -¥ direction The boundary conditions are shown in the following figure: Solution Type SOL 101 — Linear Statics fh, Results ‘Type Grid Point Point Bench Value NX Nastran ‘Rz (rad) a A -3.07TE2, -3.110B-2) Re (rad) 1 B 077E-2 3,110B-2 Y(m) 1 © -1.921E-2 -1934B-2 Xim) 1 B 5.391B-2 5.374B-2 References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1980. Test No. SSLLOS/S2, 14.5 Grid Point Load on an Ai ‘ulated CONROD Truss This test is a linear statics analysis of a plane truss with an articulated rod. It provides the input data and results for benchmark test SSLL11/89 from Guide de validation des progiciels de calcul de structures. NE Nasran 8 Verification Manual 149Chapter 14 Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements 06m | 05m 1.0m Test Case Data and Information Input File ssllll.dat Units SI Material Properties © B=1969811Pa 4840 NX Nastran 8 Verification Mansa!‘Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Finite Element Modeling * 41d (CONROD) elements © 4 grid points The mesh is shown in the following figure: D c A B Element Length (m) Area (m?*) ac O.5xs2 2.00084 cB O.5xs2 2.00084 cD 25 1.000B-4 BD Rp 1.000B-4 Boundary Conditions © Point A and B: Articulated * Point D: Set Nodal force = 9.81 E3 N in -¥ direction The boundary conditions are shown in the following figure: Solution Type SOL 101 — Linear Statics NENasran 8 Verification Manual 1644Chapter 14 Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Results Type Geid Point Point Bench Value NX Nastran X(m) 18.00 c 0.265283 0.26528-3 Ym) 18.00 c 0.0ss3eB-3 0,08839E-3 X(m) 2.000 D 3.479R-3 3.479B-3 Ym) 2.000 D -5.601E-3 -8.600B-3 References Societe Francaise des Mecaniciens. Guide de validation des progiciels de calcul de structures. (Paris, Afnor Technique, 1990..) Test No, SSLL11/83, 14.6 Articulated Plane Truss This test is a linear statics analysis of a straight cantilever beam with plane bending and tension-compression, It provides the input data and results for benchmark test SSLL14/S9 from Guide de validation des progiciels de calcul de structures. FA © 11-58-04 mt © 12-28-04 m+ 4812 NXNasran 8 Verification Manta!‘Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Test Case Data and Information Input Files * sslll4adat (4 elements) * sslll4b.dat (10 elements) Units sr Material Properties «© E=21811Pa Finite Element Modeling Test 1 * 4 linear beam (CBAR) elements © 5 grid points Test 2 © 10 linear beam (CBAR) elements © 11grid points The mesh for Test 2 is shown in the following figure Nastran 0 Verification Manual 18-13Chapter 14 Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Boundary Conditions © Point A and B: Articulate © Set forces and moments to the following numeric values: 0 p=-3,000 Nim 0 F1=~20,000N 0 F2=-10,000N The boundary conditions are shown in the following figure Solution Type SOL 101 — Linear Statics Results ‘Type Geia Point Bench Value Test NX Nastean Point Numbee Vertical reaction 1.000 A 3.1504 1 3.150E4 ™ 2 3.320B4 Hortizontal 1.000 A 2.0044 1 1.92084 reaction (N) 2 2. 061R4 Vertical 8.000 © 0.03072, 1 0.02100 Displacement (m) 2 5.03161 Note NX Nastran takes shear effect into account. 4844 NX Nastran Verification Manta!‘Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1980. Test No. SSLL14/89, 14.7 Beam on an Elastic Foundation This test is a linear statics analysis (plane problem) of a straight beam with plane bending and an elastic support. It provides the input data and results for benchmark test SSLL16/89 from. Guide de validation des progiciels de calcul de structures. Leos To 4 T = 1F10m Test Case Data and Information Input File ssll16.dat Units sr Material Properties «© E=21811Pa * K-=84E05 Nim © Bach spring stiffness is set to: K * L/(number of spring elements) Nastran 0 Verification Manual 14.15Chapter 14 Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Element Modeling * 50 linear beam (CBAR) elements © 49 spring (CBUSH) elements © 51 grid points The mesh is shown in the following figure 4416 NX Nastran 8 Verification Mantua!‘Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Boundary Conditions * Point A and B: Articulated © Set forces and moments to the following numeric values -F =-10000N —p = -5000 N/m -M = 15000 Nm. The boundary conditions are shown in the following figure: Y Forces and Moments Solution Type SOL 101 — Linear Statics Results ‘Type Point Bench Value NX Nastean Rotation(rad) Rz A —0.003050 0.003034 Vertical Reaction force (N) 1.167B4 1.158E4 Vertical Disp. (a) D -0.4933B-2 -0.4216B-2 Nastran 0 Verification Manual 14.17Chapter 14 Mechanical Structures — Linear Statics Analysis with Beam or Rod Elements Type Point Bench Value NX Nastran ‘M moment (Nm)* 3.384E4 3.369E4 *List beam forces on element 26, first end, z bending moment, References Societe Francaise des Mecaniciens. Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLL16/82, 4848 _NXNasran 8 Verification Mansa!Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements 15.1 Plane Shear and Bending Load on a Plate This test is a linear statics analysis (plane problem) of a plate with plane bending It provides the input data and results for benchmark test SSLPOW/S9 from Guide de validation des progiciels de calcul de structures. P 12mm ir © Thickness = 1 mm Test Case Data and Information Input File selp01dat Units sr Material Properties © E=3E10Pa 2 n=0.26 NE Nacran 8 Verification Manual 16-4Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Finite Element Modeling © 100 linear quadrilateral thin shell (CQUADA) elements © 126 grid points The mesh is shown in the following figure ps Boundary Conditions © Clamped Plate © Seta shear force with parabolic distribution on width and constant distribution on thickness. © Resultant force: p= 40 N The boundary conditions are shown in the following figure Solution Type SOL 101 — Linear Statics Results Type Geid point # Location Bench Value NX Nastean Y (mm) Grid point 3 Ly) 0.3415, 0.3408, Displacement is shown in the following figure: 482 NXNastran 9 Verification ManualMechanical Structures — Linear Statics Analysis with Shell Elements DEFORMATION: 1- B,C, 1-LOAD 1,DISPLACEMENT_1 DISPLACEMENT - MAG MIN: 0,00E+00 MAX: 3, 46E-01, FRAME OF REF: PART bpeeopmnynd = o References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1980 Test No. SSLPOW/SS. 15.2 Infinite Plate with a Circular Hole ‘This test is a linear statics analysis (plane problem) of a plate with tension-compression and a membrane effect. It provides the input data and results for benchmark test SSLP02/89 from Guide de validation des progiciels de calcul de structures. NENacran 8 Verification Manual 15:3Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements P ttttttt tt tt i 116 of plate 100 mm =r -10 mm 100 mm Test Case Data and Information Input File sslp02dat Units SI Material Properties © E-=3E10 Pa . 0.5 484 NX Nastran 9 Verifeation ManualMechanical Structures — Linear Statics Analysis with Shell Elements Finite Element Modeling © 100 linear quadrilateral thin shell (CQUAD4) elements © 121 grid points The plate is meshed using the biasing option. The mesh is shown in the following figure: | [+ Boundary Conditions * u(Oy)=0, Ry (y)=0, R, (y)=0, (z = 0, all grid points) © 1 (%,0) = 0, R, (&)=0,R, (x) =0 © Tension force P = 2.5 Nimm**2 (in plane force of 2500 Nim) The boundary conditions are shown in the following figure: vay LLL NE Nasran 8 Verification Manual 185Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Solution Type SOL 101 — Linear Statics Results Type Point Bench Value NX Nastean Sea (a, 0) 7.500B7 7.5287 Soa (a, 4) 2.50087 2.51187 Sea (a, 1/2) -2.500E7 2.45987 References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLP02/89, 15.3 Uniformly Distributed Load on a Circular Plate This test is a linear statics analysis (three-dimensional problem) of a circular plate fixed at the edge with transverse bending and a uniform load. It provides the input data and results for benchmark test SSLS03/S89 from Guide de validation des progiciels de calcul de structures. Test Case Data and Information Input Files © ssis03a.dat linear quadrilateral © sels03b.dat linear triangle Units SI 486 NX Nasran 0 Verification ManualMechanical Structures — Linear Statics Analysis with Shell Elements Material Properties © E=21x10%Pa 03 Finite Element Modeling Test 1 © 38 linear quadrilateral thin shell (CQUAD4) elements © 50 grid points Test 2 53 linear triangular thin shell (CTRIA3) elements © 38 grid points Meshing is only done on 1/4 of the plate ‘The meshes are shown in the following figure: Tee 1 Taot2 NE Nacran 8 Verification Manual 18-7Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Boundary Conditions © Clamp free edges. © Uniform pressure p = -1000 Pa, © Symmetric conditions are applied to the sides The boundary conditions are shown in the following figure Tew? Solution Type SOL 101 — Linear Statics Results Result Geid Point Point Bench Value Test Number NX Nastran Z 1.000 Center -0.006500 1 0.006600 w(m) 1.000 2 0.006500 References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLS03/S9. 15.4 Torque Loading on a Square Tube ‘This test is a linear statics analysis (three-dimensional problem) of a thin-walled tube loaded in torsion by pure shear at the free end. It provides the input data and results for benchmark test SSLS05/89 from Guide de validation des progiciels de calcul de structures, 488 NX Nasran 9 Verification ManualMechanical Structures — Linear Statics Analysis with Shell Elements Test Case Data and Information Input File ssls05.dat Units sr Material Properties © E=21x100Pa + v=03 Finite Element Modeling * 160 CQUAD4 elements * 219 grid points The mesh is shown in the following figure: NE Nasran 8 Verification Manual 189Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Boundary Conditions ° Plane X=0 © Clamped beam © Apply a torque equal to 10 Nm on the free end. The boundary conditions are shown in the following figure Solution Type SOL 101 — Linear Statics Results Result Geid Point Bench Value NX Nastran Disp. Y (m) 193.0 —6.170E—7 6170E—7 Disp. Rx (rad) 1.930B-5 1.230B-5 Stress XY Shear (Pa) -11.00B4 -11.00B4 Disp. Y (m) 208.0 -9.870B-1 -9,870E-7 Disp. Rx (rad) 1.970B-5 1.970B-5 Stress XY Shear (Pa) -11.00B4 -11.00B4 ‘Results are post-processed using the Shell surface: Bottom option. References Societe Francaise des Mecaniciens. Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLSO5/S9. 15.5 Cylindrical Shell with Internal Pressure This test is a linear statics analysis of a thin cylinder loaded by internal pressure. It provides the input data and results for benchmark test SSLS06/89 from Gutde de validation des progiciels de calcul de structures. 4840 _NXNastran 8 Verification Manta!Mechanical Structures — Linear Statics Analysis with Shell Elements Test Case Data and Information Input Files © ssis06adat © ssis06bdat Units sr Material Properties © E=21x100Pa 2 n=03 NENasran 8 Verification Manual 16-44Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Finite Element Modeling The meshes are shown in the following figure: Test 1 © 100 linear quadrilateral thin shell (CQUADA) elements © 121 grid points Test 2 © 400 liinear quadrilateral thin shell (CQUAD4) elements © 441 grid points 4842 NXNasran 8 Verification Mansa!Mechanical Structures — Linear Statics Analysis with Shell Elements Boundary Conditions © Free conditions: ‘To set free boundary conditions, use symmetry about XZ, XY, and YZ planes. © Internal pressure = 10000 Pa The boundary conditions are shown in the following figure: Solution Type SOL 101 — Linear Statics Results ‘Type Point Bench Value Test NX Nastran Number Sii(Pa) All 0 1 1720 2 4.960 S99(Pa) 5.000B5 1 4,950B5 2 4.99085 AR(m) 2.380E-6 1 2.37086 2 2,380B-6 AL(m) -1430B-6 1 -14208-6 2 -1430B-6 All results are averages. Nastran O Verification Manual 15-13Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Post Processing © 811 is the stress of z at grid point 11 (test 1) and grid point 21 (test 2) © Soo is the stress of x at grid point 111 (test 1) and grid point 421 (test 2) © AR(m) is the displacement of x at grid point 121 (test 1) and grid point 441 (test 2) © AL(m) is the displacement of z at grid point 121 (test 1) and grid point 441 (test 2) References Societe Francaise des Mecaniciens. Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLSO6/S3. 15.6 Uniform Axial Load on a Thin Wall Cylinder This test is a Linear static analysis of a thin cylinder loaded axially. It provides the input data and results for benchmark test SSLS07/S9 from Guide de validation des progiciels de calcul de structures. VRof modal ‘thicknane-20mm_ Test Case Data and Information Input Files © ssls07a.dat — parabolic quadrilateral, thin shell © ssls07b.dat — parabolic triangle, thin shell Units SI 4844 NX Nastran Verification Manta!Mechanical Structures — Linear Statics Analysis with Shell Elements Material Properties © E=21x10%Pa * n=03 Finite Element Modeling Test 1 * 200 parabolic quadrilateral thin shell (CQUADS) elements © 661 grid points Test 2 * 400 parabolic triangular thin shell (CTRIA6) elements ‘The meshes are shown in the following figure: ‘Tet 1 Test2 Nastran 0 Verification Manual 15.45Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Boundary Conditions © Asial displacement = 0 in, X= 0 section © Uniform axial load q = 10000 Ném The boundary conditions are shown in the following figure Taw 1 Tost 2 Solution Type SOL 101 — Linear Sstatics Results Type Point Bench Value Test Number NX Nastean $1(Pa) ‘Any 5.000B5 1 5.000R5 2 5.190B5 Sa9(Pa) Any 0 1 0 2 3.080B4 AL(m) Any 9.520E-6 1 9.520E-6 2 9.560E-6 AR (m) Any =1.140B-7 1 -1,140B-7 2 -1,330B-7 All results are averages. Post Processing © 811 is the stress of z at grid point 641 in coordinate system 2. 4846 _NXNastran Verification Mansa!Mechanical Structures — Linear Statics Analysis with Shell Elements * Sop is the stress of y at grid point 641 in coordinate system 2, * AR is the displacement of x at grid point 641 in coordinate system 2 © AL is the displacement of z at grid point 641 in coordinate system 2 References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLSO7/S9. 15.7 Hydrostatic Pressure on a Thin Wall Cylinder ‘This test is a linear statics analysis of a thin cylinder loaded by hydrostatic pressure. It provides the input data and results for benchmark test SSLS0S/S9 from Guide de validation des progiciels de calcul de structures. Rin Test Case Data and Information Input File ssls08.dat Units sr Material Properties © E=21x100Pa 03 N&Nastran 0 Verification Manual 15.17Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Finite Element Modeling © 200 parabolic quadrilateral thin shell (CQUADS) elements * 661 grid points The mesh is shown in the following figure 4848 _NXNasran 8 Verification Mana!Mechanical Structures — Linear Statics Analysis with Shell Elements Boundary Conditions © Restrain the grid points on side A (from grid point 21 to grid point 661) in the X translation and the Y and Z rotations. Restrain the grid points on side B (from grid point 1 to grid point 641) in the Y translation and X and Z rotations Internal pressure p = po * Z/L with po = 20000 Pa The boundary conditions are shown in the following figure: Solution Type SOL 101 — Linear Statics Results ‘Type Geid Point Point Bench Value NX Nastran 51(Pa) 3210 ‘Any 0 8.800B3 ‘L/2809 (Pa) 321.0 Wa 5.00085 4.970B5 AR (m) 321.0 Wa 2,380B-6 2.380B-6 AL (m) 1.000 x=L ~2.860E-6 ‘2.860B-6 W (rad) 321.0 1,190B-6 1.190B-6 W represents the rotation of a generator, Post Processing © Syyis the stress of z at grid point 321 in coordinate system 2 Nastran 0 Verification Manual 15.13Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements © Sop is the stress of y at grid point 321 in coordinate system 2 © AR is the displacement of x at grid point $21 in coordinate system 2 © AL is the displacement of z at grid point 1 in coordinate system 2 © Wis the rotation of y at grid point $21 in coordinate system 2 References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990, Test No. SSLSOS/S3. 15.8 Gravity Loading on a Thin Wall Cylinder This test is a Linear statics analysis of a thin cylinder loaded by its own weight, It provides the input data and results for benchmark test SSLS09/89 from Guide de validation des progiciels de calcul de structures. Test Case Data and Information Input Files © ssis09a.dat linear quadrilateral, thin shell © ssls09b.dat axisymmetric Units SI 4820 _NXNastan Verification Mania!Mechanical Structures — Linear Statics Analysis with Shell Elements Material Properties © B=21x10"Pa + n=03 © g=7.85 x 10¢ Nim? © Mass = 8002 kg/m3 Finite Element Modeling Test 1 * 65 linear quadrilateral thin shell (CQUAD4) elements © 84 grid points Test 2 © 20 linear axisymmetric (CCONEAX) elements © 21 grid points ‘The meshes are shown in the following figure: NKNastran rifcation Manual 15-24Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Boundary Conditions © Axial displacement = 0 in, Z = 0 section. © Gravity loading, gravity acts in the Z direction, The boundary conditions are shown in the following figure Solution Type SOL 101 — Linear Statics Results Type Grid Point Bench Value Test NX Nastean point Number So9(Pa) 2,000 ‘Any 0 1 34.66 2 0 $11 (Pa) 2,000 x=0 3.14085 1 3.020B5 2 3.060B5 Az (mm) 1.000 xeL 2,990B-6 1 2.99086 2 2.99086 AR (m) 2,000 x=0 -4490B-7 1 ~1,390B-16 2 —1.480B-7 W (rad) 10.00 x-L 1.120B-7 1 -1.120B-7 2 -1.120B-7 Post Processing Test 1 © 83; is the stress of z at grid point 2 in coordinate system 2 4822 _NXNasran Verification Mania!Mechanical Structures — Linear Statics Analysis with Shell Elements © Sopis the stress of x at grid point 2 in coordinate system 2 © Azis the displacement of z at grid point 1 in coordinate system 2 * AR is the displacement of x at grid point 2 in coordinate system 2 © Wis the rotation of y at grid point 10 in coordinate system 2 References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLS09/S9. 15.9 Pinched Cylindrical Shell ‘This test is a linear statics analysis of a cylindrical shell with grid point forces, F, pinching as shown, It provides the input data and results for benchmark test SSLS20/89 from Guide de validation des progiciels de calcul de structures. Y thickness = 0.084 mm F Cc F <—__—_—_ > R= 4.953 m Test Case Data and Information Input Files * ssis20a.dat linear triangle thin shells © ssls20b dat linear quadrilateral thin shells Units sl NK Nastran 9 Verification Manual 15:23Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Material Properties © E=105x108Pa © n=0.3125 Finite Element Modeling Test 1 © 296 linear triangular thin shell (CTRIA3) elements © 178 grid points Test 2 © 140 linear quadrilateral thin shell (CQUADA) elements © 165 grid points The meshes are shown in the following figure: 4824 NX Nastran 6 Verification Mana!Mechanical Structures — Linear Statics Analysis with Shell Elements Boundary Conditions © Free conditions ‘To set free boundary conditions, use symmetry about XY, XZ, and YZ planes. © Grid point forces F, = -25 N at point D The boundary conditions are shown in the following figure: Restraints Force Solution Type SOL 101 — Linear Statics Results ‘Type Point Bench Value Test Number NX Nastean Disp. ¥ (Grid point 3)nim) D 113. 95-3 1 -114.4B-3 Disp. ¥ (Grid point 3) a -113.3E-3 Post Processing © nim) is the displacement of y at grid point 3 (quadrilateral) References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLS020/82, 15.10 Spherical Shell with a Hole This test is a linear statics analysis of a spherical shell with a hole with grid point forces It provides the input data and results for benchmark test SSLS21/89 from Guide de validation des progiciels de calcul de structures. Nastran 0 Verification Manual 15:25Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Test Case Data and Information Input Files © ssls21a.dat — linear quadrilateral thing shells © ssls21b.dat — linear triangle thin shells © ssls21¢ — parabolic quadrilateral thin shells Units SI Material Properties © E=6286 x 107 Pa © n=03 4828 NXNasran Verification Mansa!Mechanical Structures — Linear Statics Analysis with Shell Elements Finite Element Modeling Test 1 © 100 linear quadrilateral thin shell (CQUAD4) elements © 121 grid points Test 2 © 200 linear triangular thin shell (CTRIA3) elements © 121 grid points Test 3 * 100 parabolic quadrilateral thin shell (CQUADS) elements © 441 grid points The mesh is shown in the following figure: Tost 1 Tee? ‘Tent 3 Nastran 0 Verification Manual 15:27Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Boundary Conditions © Free conditions ‘To set free boundary conditions, use symmetry about XY and YZ planes © Grid point forces F = 2 Newtons Due to the symmetric boundary conditions, only halfof the load is applied The boundary conditions are shown in the following figure Solution Type SOL 101 — Linear Statics Results Result Point Bench Test NX Nastran Value Number wu (mm) grid point 111 AR,0,0) 9400E-2 1 102, 08-3 Grid point 111 2 102,1B-3 Grid point 421 3 100.98-3 References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLS021/89, 15.11 Bending Load on a Cylindrical Shell This test is a linear statics analysis of a cylindrical shell with bending and membrane effect. It provides the input data and results for benchmark test SSLS23/89 from Guide de validation des progiciels de calcul de structures. 4828 NX Nastran Verification Mansa!Mechanical Structures — Linear Statics Analysis with Shell Elements osm <—_—_— A vt, 2» ° E B c —4 3m Radius-im ‘Thisknss-001m, Test Case Data and Information Input Files © ssis23a.dat (Test 1, linear) © ssls23bdat (Test 2, parabolic) Units sr Material Properties © E=21x100Pa 03 Nastran 0 Verification Manual 15:23Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Finite Element Modeling Test 1 * 60 linear quadrilateral thin shell (CQUAD4) elements © 78 grid points Test 2 © 60 parabolic quadrilateral thin shell (CQUADS) elements © 215 grid points The mesh is shown in the following figure Y Boundary Conditions © AB side: Clamped in local system coordinates, © AD and BC sides: Restrain Z translation, qx and gy. © DO side: Set bending moment OZ to 1000 Nnv/m. Set in plane force to 0.626 N/m. © ABCD surface: Set internal pressure to 0.6206 Nim"*2. © AD and DC sides are restrained in the global coordinate system. The boundary conditions are shown in the following figure Solution Type SOL 101 — Linear Statics 4890 _NXNasran Verification Mania!Mechanical Structures — Linear Statics Analysis with Shell Elements Results Use coordinate system 3 (the cylindrical coordinate system) to display the results, ‘Results are post-processed using the Shell surface middle option. Result Point Bench Value Test Number NX Nastean Grid point 35 z 60.00MPa 1 60.70 Grid point 93 2 59.60 References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1980. Test No. SSLS025/82, 15.12 Uniformly Distributed Load on a Simply-Supported Rectangular Plate ‘This test is a linear statics analysis of a plate with pressure loading and simple supports It provides the input data and results for benchmark test SSLS24/89 from Guide de validation des progiciels de calcul de structures. 4q- thicknime-O0im Test Case Data and Information Input Files * ssis24a.dat (Test 1, coarse mesh) * ssis24b.dat (Test 2, fine mesh) © ssls24edat (Test 3, very fine mesh) NM Nastran 9 Verification Manual 15.34Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Units SI Material Properties © E=10x107Pa * n=03 Finite Element Modeling Test 1—ab=1 © 100 linear quadrilateral thin shell (CQUADA) elements © 121 grid points Test 2 — a/b = 2 © 200 linear quadrilateral thin shell (CQUADA) elements © 231 grid points Test 3 — ab = 5 © 500 linear quadrilateral thin shell (CQUAD4) elements * 561 grid points The mesh is shown in the following figure Test! Tose 2 4892 _NXNasran Verification Mansa!Mechanical Structures — Linear Statics Analysis with Shell Elements Boundary Conditions Restraints © Alledges w=0 © One corner fixed Loads © Set pressure = 1 Nim"*2 in the ~Z direction The boundary conditions are shown in the following figure: Tost 1 Solution Type SOL 101 — Linear Statics ‘Tos 3 Results Result alb Parameters Bench Test NX Nastran Value Number 61z direction 1.000 1.000a) o.o0440 1 (0.004500 1162 direction 2.000 2.000a 0.01110 2 0.01110 281z direction 6.000 5.000a 0.01417 3 0.01406 61x component top 1.000 1.000b 2874, 1 2867. surface 116x component 2.000 2,000b 6102, 2 6034, top surface Nastran 0 Verification Manual 15-33Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Result: a/b Parameters Bench Test NX Nastran Value Number 28ix component 6.000 0006 TAT6. 3 7381. top surface Mazo= y= cae y = oat May Ep Where: q = distributed load b = dimension t= thickness E = elastic modules b values of reference from the Guide de Validation are incorrect, The correct values are extracted from Formulas for Stress and Strain (Roark/Young). Note Note that the shell top surface corresponds to the side of the plate with negative global Z coordinates. References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLS024/89, 15.13 Uniformly Distributed Load on a Simply-Supported Rhomboid Plate ‘This test is a linear statics analysis (three-dimensional problem) of a plate with pressure and transverse bending. It provides the input data and results for benchmark test SSLS26/89 from Guide de validation des progiciels de calcul de structures. 48.4 _NXNastran 8 Verification Manta!Mechanical Structures — Linear Statics Analysis with Shell Elements ti © Thickness = 0.01 m * b-10m 2.0m Test Case Data and Information Input Files © ssis25a.dat (Test 1) © ssis25b.dat (Test 2) Units sr Material Properties © E=36.0x106Pa 03 Nastran 0 Verification Manual 15.5Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Finite Element Modeling © Linear quadratic thin shell (CQUAD4) elements Test 1 © q=30° Test 2 © q=45° The mesh is shown in the following figure Boundary Conditions © Alledges: w = 0, one corner fixed © Pressure = 1 Nim? in the ~Z direction The boundary conditions are shown in the following figure Solution Type SOL 101 — Linear Statics 48.98 _NXNasran 8 Verification Mana!Mechanical Structures — Linear Statics Analysis with Shell Elements Results Parameter Test Case _ Bench Value NX Nastran a ‘Test 1 2 displacement 116z displacement ssls25a -3.017E-3 m -2.963E-3 m b Y stress 116y stress -5.100E3 N/m2, -5.831E3 Nim a ‘Test 2 z displacement 1162 displacement ssls25b -3.000B-3 m -2.7208-3 m b Y stress 116Y stress 5.3903 Nim2, -5.441E3 Nim moro, 28 Max y = 7222! Be Where q = distributed load b = dimension $= thickness E = elastic modulus Values of reference from the Guide de validation are incorrect, The correct values are extracted from Formulas for Stress and Strain (Roark/Young), table 26, case number 14a. References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1980. Test No. SSLS025/82, 15.14 Shear Loading on a Plate ‘This test is a linear statics analysis of a thin plate with torque and shear loading: It provides the input data and results for benchmark test SSLS27/S9 from Guide de validation des progiciels de calcul de structures. thicknme-005m. N&Nastran 0 Verification Manual 18.37Chapter 15 Mechanical Structures — Linear Statics Analysis with Shell Elements Test Case Data and Information Input Files * ssis27adat (Test 1, Mindlin) © ssls27bdat (Test 2, Kirchoff) * ssis27c.dat (Test 3, Mindlin) Units SI Material Properties © E=10x10' Pa * n=0.25 Finite Element Modeling ‘Test 1 — Mindlin © 6 linear quadrilateral thin shell (CQUAD4) elements © 14 grid points ‘Test 2 — Kirchhoff © 6 linear quadrilateral thin shell (CQUAD4) elements © 14 grid points ‘Test 3 — Mindlin © 48 linear quadrilateral thin shell (CQUAD4) elements © 75 grid points The meshes are shown in the following figure: ‘Teste Land 2 Tests All tests are executed with mapped meshing 4898 _NXNasran 8 Verification Mania!Mechanical Structures — Linear Statics Analysis with Shell Elements Boundary Conditions * Clamp AD side © Point B: grid point force Fz = -1N © Point C: grid point force -Fz = 1N The boundary conditions are shown in the following figure: Solution Type SOL 101 — Linear Statics Results at Location C Displacement at Bench Value ‘Test Number NX Nastran Geid point, 14.00 3.537E-2 1 3.585E-2 14.00 3.537E-2 a 3.573E-2 75,00 3.537E-2 3 3,603B-2 References Societe Francaise des Mecaniciens. Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLS027/89 Nastran 0 Verification Manual 15.33Chapter 16 Mechanical Structures — Linear Statics Analysis with Solid Elements 16.1 Solid Cylinder in Pure Tension This test is a linear statics analysis of a solid cylinder with tension-compression, It provides the input data and results for benchmark test SSLVO1/$9 from Guide de validation des progiciels de calcul de structures. NE Nacran 8 Verification Manual 16-4Chapter 16 Mechanical Structures — Linear Statics Analysis with Solid Elements Test Case Data and Information Input Files * ssivOladat (Test 1) * ssiv01b.dat (Test 2) © sslvOlcdat (Test 3) * ssivOlddat (Test 4) © sslvOledat (Test 5) sslv01fdat (Test 6) Units SI Material Properties © E=20x104Pa © n=0.30 462 NXNastran 9 Verifeation Manual‘Mechanical Structures — Linear Statics Analysis with Solid Elements Fi Test 1 * 155 parabolic tetrahedron (CTETRA) elements ite Element Modeling © 342 grid points Test 2 © 144 linear brick (CHEXA) elements & 48 linear solid wedge (CPENTA) elements * 307 grid points ‘Test 3 (Results for this test will be provided in the NX Nastran 7 Verification Manual) © 48 linear quadrilateral axisymmetric solid elements © 65 grid points ‘Test 4 (Results for this test will be provided in the NX Nastran 7 Verification Manual) © 96 linear triangular axisymmetric solid elements © 65 grid points ‘Test 5 (Results for this test will be provided in the NX Nastran 7 Verification Manual) * 18 parabolic quadrilateral axisymmetric solid elements © 95 grid points Test 6 * $64 linear pyramid (CPYRAM) elements created by dividing each brick element in test 2 into 6 pyramid elements. 48 linear wedge (CPENTA) elements remain. NE Nacran 8 Verification Manual 183Chapter 16 Mechanical Structures — Linear Statics Analysis with Solid Elements The meshes are shown in the following figure: 464 NX Nasran 9 Vorifeation Manual‘Mechanical Structures — Linear Statics Analysis with Solid Elements Boundary Conditions © Uniaxial deformation of the cylinder section © Set uniformly distributed force -F/A on the free end in the Z direction * F/A= 100 MPa The boundary conditions are shown in the following figure: ‘Tess 35 Solution Type SOL 101 — Linear Statics Results Linear statics * axisymmetric data will be provided in version 7 Point Grid Displacement Bench Test NX Nastran Point Value Number A&C 6 u Gm) 1508-3. 1 1.5001 A&C 27 A&C 1 A&C 4 A&C 1 NE Nasran 8 Verification Manual 185Chapter 16 ‘Mechanical Structures — Linear Statics Analysis with Solid Elements Point Grid Displacement Bench Test NX Nastran Point Value Number A&C 279 6 1.800B-3 B 4 u(m) 1.500B-3 1 1,800E-3 B 307 2 1,800E-3 B 83 3 * B 3 4 * B 39 8 * B 307 6 1,800E-3 D 7 u(m) 1.000B-3 1 1,000B-3 D 189 2 1,000B-3 D 8 3 * D 25 4 * D 7 8 * D 189 6 1,000B-3 E Al u(m) 0.5000E-3 1 0,5008-3 z 99 2 0,5008-3 z 9 3 * z 29 4 * z 13 8 * z 99 6 0,5008-3 A&C 6 w(m) -0.1500E-3 1 -0.150B-3 A&C 219 2 -0.180B-3 A&C l 3 * A&C 4 4 * A&C l 8 * A&C 279 6 -0.1500E-3 D 3 w(m) -0.15008-3 1 -0.1500E-3 D 189 2 -0.1500E-3 D 3 * D 4 * D 8 * D 189 6 -0.1500E-3 z 41 w(m) -0.1500E-3 1 -0.1500E-3 z 99 2 -0.1500E-3 z 9 3 * z 29 4 * 466 NX Nasran 9 Verifeation Manual‘Mechanical Structures — Linear Statics Analysis with Solid Elements Point Grid Displacement Bench Test NX Nastran Point Value Number E 1B 5 : E 99 6 -0,1500B-3 Post Processing ‘To view the results for Test 1 and Test 2, use coordinate system 2 (cylindrical), u is the radial displacement and w is the axial displacement, References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLVOU/S9. 16.2 Internal Pressure on a Thick-Walled Spherical Container This test is a linear statics analysis of a thick sphere with internal pressure. It provides the input data and results for benchmark test SSLV03/89 from Guide de validation des progiciels de calcul de structures. Rasim Rb=2m, Test Case Data and Information Input Files * sslv03adat (Test 1) * sslv03b.dat (Test 2) © sslv03c.dat (Test 3) * sslv03d.dat (Test 4) * sslv03e.dat (Test 5) © sslvO3fdat (Test 6) NE Nasrran 8 Verification Manual 187Chapter 16 Mechanical Structures — Linear Statics Analysis with Solid Elements Units SI Material Properties © E=2x10°Pa © n=03 Finite Element Modeling Test 1 © 1600 linear brick (CHEXA) elements & linear solid wedge (CPENTA) elements © 1898 grid points Test 2 © 200 parabolic brick (CHEXA) elements & 50 solid wedge (CPENTA) elements © 1256 grid points ‘Test 3 (Results for this test will be provided in the NX Nastran 7 Verification Manual) © 400 linear quadrilateral axisymmetric solid elements © 451 grid points ‘Test 4 (Results for this test will be provided in the NX Nastran 7 Verification Manual) © 400 parabolic quadrilateral axisymmetric solid elements © 1301 grid points Test 5 © Linear pyramid (CPYRAM) elements created by dividing each brick element in test 1 into 6 pyramid elements. Wedge (CPENTA) elements remain Test 6 * Parabolic pyramid (CPYRAM) elements created by dividing each brick element in test 2 into 6 pyramid elements. Wedge (CPENTA) elements remain 468 NX Nasran 9 Vorifeation Manual‘Mechanical Structures — Linear Statics Analysis with Solid Elements The meshes from these tests are shown in the following figure NE Nacran 8 Verification Manual 189Chapter 16 Mechanical Structures — Linear Statics Analysis with Solid Elements Boundary Conditions © The equivalent of the center of the sphere being fixed is modeled via symmetric boundary conditions © Uniform radial pressure = 100 MPa, The boundary conditions are shown in the following figure Promure ~ Teta 1,2 Tremure ~ Toots 3, 4 Reswaints - Tests 9,4 Solution Type SOL 101 — Linear Statics Results * axisymmetric data will be provided in version 7 Point Grid Displacement Bench Test NX Nastran Point Stress Value Number mim 1 8, (MPa) =100.0 1 90.15 1 2 -97.29 451 3 451 4 1 5 -90.84 1 6 -103.8 1 sq (MPa) 71.43 1 72.08 4610 _NXNastran 8 Verification Mana!‘Mechanical Structures — Linear Statics Analysis with Solid Elements Point Grid Displacement Bench Test NX Nastran Point Stcess Value Number 1 2 17.98 451 3 ‘ 451 4 ‘ 1 5 72.08 1 6 73.30 1 um 0.40008-3 1 0.40008-3 1 2 0.40008-3 451 3 ‘ 451 4 * 1 5 0.39918-3 1 6 0.4006R-3 NE Nacran 8 Verification Manual 16-44Chapter 16 Mechanical Structures — Linear Statics Analysis with Solid Elements Point Grid Displacement Bench Test NX Nastran Point Stress Value Number r=2m 1826 §,, (MPa) 0 1 0.0280 2901 2 0.2240 4ll 3 * 4ll 4 ‘ 1826 8 0.2530 2901 6 0.5269 1826 Sq (MPa) 2143 1 21.18 2901 2 21.18 4ll 3 * 4ll 4 ‘ 1826 8 21.40 2201 6 21.4 1826 u(m) 1.500R-4 1 1.600E4 2901 2 1.600E4 4ll 3 ‘ 4ll 4 * 1826 8 1606R4 2901 6 1499R-4 All stress results are averaged. Use the spherical coordinate system for the stress results References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLV03/83. 16.3 Internal Pressure on a Thick-Walled Infinite Cylinder This test is a linear statics analysis of a thick cylinder with internal pressure, It provides the input data and results for benchmark test SSLV04/89 from Guide de validation des progiciels de calcul de structures. 4642 _NXNasran 8 Verification Mania!‘Mechanical Structures — Linear Statics Analysis with Solid Elements R RaO.1m 502m Test Case Data and Information Input Files * sslv04adat (Test 1) * sslv04b.dat (Test 2) * sslv04e.dat (Test 3) * sslv04d.dat (Test 4) * sslvOde.dat (Test 5) © sslv04fdat (Test 6) Units sr Material Properties © E=2x 10° mPo 03 Finite Element Modeling Test 1 © 400 linear brick (CHEXA) elements * 902 grid points Test 2 © 240 parabolic brick (CHEXA) elements © 1873 grid points Nastran 0 Verification Manual 16-13Chapter 16 Mechanical Structures — Linear Statics Analysis with Solid Elements Test 3 © 600 linear quadrilateral axisymmetric solid elements © 656 grid points Test 4 © 600 parabolic quadrilateral axisymmetric solid elements © 1911 grid points Test 5 © Linear pyramid (CPYRAM) elements created by dividing each brick element in test 1 into 6 pyramid elements Test 6 © Parabolic pyramid (CPYRAM) elements created by dividing each brick element in test 2 into 6 pyramid elements, The brick meshes are shown in the following figure: Y Test 1 4644 _NXNasran 8 Verification Mana!‘Mechanical Structures — Linear Statics Analysis with Solid Elements Boundary Conditions © Unlimited cylinder Internal pressure p = 60 MPa The boundary conditions are shown in the following figure: Test | Y Tet2 = y Solution Type SOL 101 — Linear Statics Results All results are averaged Test Case Grid Displacement / Bench Value NX Nastran Point _ Stress ssiv0da 411 Se 60.00 (MPa) 87.00 sslv04b 977 60.00 sslv0de 616 ‘ sslv0dd 1831 . sslv0de 411. 87.30 sslvO4f 977 60.74 sslv0da 411. Sq 100.0 (MPa) 99.70 sslv04b 977 102.0 sslv0de 616 . sslv0dd 1831 ‘ sslv0de 411 99.68 sslvOdf 977 100.9 sslv0da 411 tanos 80.00 (MPa) 79.34 sslv04b 977 81.00 sslv0de 616 ‘ sslv0dd 1831 . Nastran 0 Verification Manual 16.15Chapter 16 Mechanical Structures — Linear Statics Analysis with Solid Elements Test Case Grid Displacement / Bench Value NX Nastran Point _ Stress sslv0de 411 80.82 sslv04f 977 80.82 sslv0da 411 Ue 59.00B-6(m) 59.00B-6 sslv04b 917 59.00B-6 sslv0de 616 * sslv0dd 1831 * sslv0de 411 58.85E-6 sslv04f 977 59.00B-6 sslv04a 451 Se 0 ava) 0.006500 slv04b 0.04480 salv0de * sslv04d * sslvOde 0.1563 sslv04t 0.1900 sslv04a Sq 40.00 (MPa) 39.66 slv04b 40.39 salv0de * sslv04d * sslvOde 39.84 sslv04t 40.16 sslv04a tno 20.00 (MPa) 20.08 slv04b 20.17 salv0de 20.07 sslv04d 19.99 sslvOde 20.10 sslv04t 20.17 sslv04a U, 40.00B-6(m) 40.00B-6 slv04b 40.00B-6 salv0de * sslv04d * sslvOde 39.93E-6 sslv04t 40.00B-6 4616 _NXNastran Verification Mania!‘Mechanical Structures — Linear Statics Analysis with Solid Elements References Societe Francaise des Mecaniciens Guide de validation des progiciels de calcul de structures. Paris, Afnor Technique, 1990. Test No. SSLV04/S9. 16.4 Prismatic Rod in Pure Bending This test is a linear statics analysis of a solid rod with bending, It provides the input data and results for benchmark test SSLVOS/S9 from Guide de validation des progiciels de calcul de structures. Test Case Data and Information Input Files * sslv0Sadat (Test 1) * sslv0Sb.dat (Test 2) * sslv0Se.dat (Test 3) * sslv0Sd.dat (Test 4) * sslv0Se.dat (Test 5) * sslv0Sfdat (Test 6) Units sr Nastran 0 Verification Manual 16.17
