HOSE AUTOMATIC ASSEMBLY MACHINE

OPERATION MANUAL

NINGBO ITC SPECIALIZED EQUIPMENT TECHNOLOGY CO., LTD.

TEL+86-574-63077646/+86-13777004313(WECHAT/WHATSAPP)
QQ 827971807 wechat: guxingwujiang
Emailtradeningbo@foxmail.com
FAX+86-574-63077648
WEBwww.yidexi.cn
A
ADDEUROPEAN INDUSTRIAL PARK ZONE A, HANGZHOU BAY NEW ZONE,
NINGBO, ZHEJIANG, CHINA

1

CATALOGUE

UTILITY FIELD
EQUIPMENT
PARAMETER
CONTROL PANEL
EQUIPMENT
OPERATION

2 14
03
01

04

05 02

06

07

3 14
 10

11

08

09

01- touch screen 02- vibration table of hose core

03- steel cap vibration table 04- front clamp cylinder 05-
behind clamp cylinder
06- large channel table 07- small channel table 08-
Rotary damper cylinder 09- push cylinder 10- hose core
push cylinder 11- steel cap push cylinder

4 14
 UTILITY FIELD
This machine is suitable for assembly of
hose and core, steel cap.
MACHINE PARAMETER
machine total power 800W
supply valtage AC220V/50Hz
Clean air source through the filter > 0.6Mpa
size (L*W*H) 1100 750 1320mm
total weight about 100Kg
CONTROL PANEL
1., turn on the power, press
on the start button (green) of the control panel, enter the boot interface:

5 14
2. The system enter startup interface after
touch boot interface, as shown below

1 mode choose
// Auto mode / manual mode: Automatic
mode / manual mode switch button
//

6 14
Automatic / semi-auto: automatic / semi-auto change switch. Under automatic condition,
the machine will automatic assembly hose, steel cap and hose core together, under
semi-auto condition, the machine will only automatic assembly hose and steel cap
together.
2 start button: Start button under automatic condition
3 stop button: stop button under automatic condition
4 product statistics: the number of actual assembly
5 production set: the number set according to requirement
6: reset: product statistics of quantity reset
7 manual page: manual test page open button
8 start page: turn on button of start interface
9: time set: each working cylinder action
time setting interface turn on button
10 alarm page: alarm page open button
11I/O I/O I/O signal: I/O signal page open button
12: return: page return button
3. Click manual page button, enter the manual
test page, as shown below

7 14
 Cylinder action test button under the condition of manual
1 forward and backward clamp: forward and backward
clamp cylinder action test button
2 Push steel cap: push steel cap cylinder action test
button
3 Push copper core: push copper core cylinder action
test button
4 large channel table: large channel table cylinder
action test button
5 Rotation: rotary positioning cylinder action test
button
6 Push: push cylinder action test button
7 Small channel table: small channel table cylinder
test button
4. click the time set, enter the time set the
page, as shown below

8 14
 1 Clamp time: the
time from clamp of forward and backward cylinder clamp action to the rotation of the
cylinder began to open action
2 rotation time: the
time from the rotary cylinder action began to open to small channel table cylinder forward
action

9 14
3 small channel
table time: from the beginning of push forward movement of small channel table cylinder
to steel cap cylinder launched at the beginning of the time of action
4 push the steel
cap time: from pushing the steel cap cylinder launched action to move back the channel
table cylinder start time
5 small
channel table backward time: from the start of push back action of small channel table
cylinder to cap steel cylinder control backward action start time
6 pushing the
steel cap backward time: the time of from the steel cap push cylinder begins to backward
to the big channel table cylinder began to move forward action
7 Big channel
table time: the time from the big channel table cylinder to push forward movement to
copper core cylinder launched action
8 the time of
pushing the copper core: the time from starting the action to the forward and backward
of the cylinder to release the action from the push of the copper core cylinder
9 push the
copper core backward time: the time from the forward and backward of the clamping cylinder
began to loosen the action to return the cylinder to start the action
10 push reset
time: the time from the beginning of a material returning cylinder to big channel table
cylinder movement began to backward action
11 rotation
return time: the time from the big channel table cylinder start backward movement to
the rotating cylinder reset action start
5. click the alarm page button, enter the
alarm resume page, as shown below

10 14
6. I/O click the I/O signal button, enter
the input and output monitor page, as shown below

11 14
 EQUIPMENT OPERATION
1.Switch on the power supply (must be grounded)
2.
0.6MPa 4-10 1
Connected to air supply, air supply equipment total air source must have filter
processing the clean air source, by adjusting the pressure triple pieces set pressure

12 14
more than or equal to 0.6 MPa. To ensure the oil mist lubricat in oil cup (machine action
4-10 working cycle, the oil mist suck out 1 drops of oil)
3.Press the green
start button to see whether the green start button light on, and then see whether the
touch screen light up.
4.
Put into vibration table correspond steel cap, copper core,
nut, open the vibration table controller switch, start the vibration table, see steel
cap, copper core and nut feeding is smooth or not.
5.

The system will switch to automatic mode, after steel cap, copper core and nut
channel full of material, click the foot switch to see if the machine moving around a
loop (Note: during test running, all the cylinders will exercise one time and return
to the initial state, please remove all the debris on the machine and operator body away
from the work area), if the machine is not action, please check if the machine touch
screen is in auto mode, you can try again to test.
6.

Right hand hold hose into the clamp channel (please first confirm
hose and the steel cap is matched), hose one head in the rotating bezel, step on the
switch, the machine will automatically assembly hose, a steel cap and a copper core
together, please do first piece inspection to see if hose, steel cap and copper core
are assembly perfectly. if there is anything not assembly in place, please let technical
personnel to adjust the machine parameters and the position of the clamp, if still does
not work, please contact the manufacturer. Note: before the technician adjust the machine,

13 14
please switch to manual mode, and cut off the air source, in order to prevent the operator
from been hurt.
