INTRODUCTION TO MICROPROCESSOR

LABORATORY REPORT
(EM205)

Name : Teoh Yee Cien


Student ID : 1001437330
Course : B.Eng. (Hons) Mechanical Engineering
QUESTION 1

ORG $1000
START:
LED EQU $2000
SW EQU $3000
CLR LED

MAIN
CLR D6
CLR D7
MOVE.B (SW),D2
CMP.B #1,D2
BEQ FUNC1
CMP.B #2,D2
BEQ FUNC2
CMP.B #3,D2
BEQ FUNC3
BRA START

FUNC1
MOVE.B #%11110000,D3
MOVE.B D3,LED
JSR DELAY

LOOP
ROL.B #4,D3
MOVE.B D3,LED
JSR DELAY
ADD.B #1,D7
CMP.B #9,D7
BLT LOOP
BRA MAIN

FUNC2
MOVE.B #%00000001,D3
MOVE.B D3,LED
JSR DELAY

LOOP1
LSL.B #1,D3
MOVE.B D3,LED
JSR DELAY
CMP.B #%10000000,D3
BNE LOOP1
BRA MAIN

FUNC3
MOVE.B #%11111111,D4
MOVE.B D4,LED
JSR DELAY
CLR LED
JSR DELAY
ADD.B #1,D6
CMP.B #10,D6
BLT FUNC3
BRA MAIN

DELAY
MOVE.B #50,D1
MOVE.B #23,D0
TRAP #15
RTS

EXIT
END START
QUESTION 2
ORG $1000
START:
SG7 EQU $6000
SG7B EQU $6002
SG7C EQU $6004
SW EQU $4000

SWITCH
MOVE.B (SW),D6
CMP.B #1,D6
BEQ FUNC1
CMP.B #2,D6
BEQ FUNC2
CMP.B #3,D6
BEQ FUNC3
BRA START

FUNC1
LEA DATA1,A0
MOVE.B (A0)+, $6000
MOVE.B (A0)+, $6002
MOVE.B (A0)+, $6004
MOVE.B (A0)+, $6006
MOVE.B (A0)+, $6008
MOVE.B (A0)+, $600A
MOVE.B (A0)+, $600C
MOVE.B #0, $600E
JSR DELAY
BRA START

FUNC2
LEA SG7,A0
LEA SG7B,A2
JSR CLEARSG7
LEA DATA,A2
CLR D4

F2LOOP1
LEA DATA, A1
CLR D3
ADD.B #1,D4
CMP.B #10,D4
BGT START
MOVE.B (A2)+, SG7
MOVE.B (A1)+, SG7B
JSR DELAY

F2LOOP
ADD.B #1, D3
CMP.B #9, D3
BGT F2LOOP1
MOVE.B (A1)+, SG7B
JSR DELAY
BRA F2LOOP
FUNC3
LEA SG7,A0
LEA SG7B,A2
LEA SG7C,A3
JSR CLEARSG7
LEA DATA,A3
CLR D5

F3LOOP2
LEA DATA,A2
CLR D4
ADD.B #1,D5
CMP.B #10,D5
BGT START
MOVE.B (A3)+, SG7
MOVE.B (A2),SG7B
MOVE.B (A1),SG7C

F3LOOP1
LEA DATA, A1
CLR D3
ADD.B #1,D4
CMP.B #10,D4
BGT F3LOOP2
MOVE.B (A2)+,SG7B
MOVE.B (A1)+,SG7C
JSR DELAY

F3LOOP
ADD.B #1, D3
CMP.B #9, D3
BGT F3LOOP1
MOVE.B (A1)+, SG7C
JSR DELAY
BRA F3LOOP

CLEARSG7
CLR D7
MOVE.W D7, (A0)+
CMPA.W #$600E, A0
BLE CLEARSG7
RTS

DELAY
MOVE.B #5,D1
MOVE.B #23,D0
TRAP #15
RTS

ORG $2000
DATA
DC.B 63,6,91,79,102,109,125,7,127,111

ORG $3000
DATA1
DC.B 109,56,8,49,119,109,118
END START
