Smart Home Technology: Hands-0N Technical Demonstration

CNET 327 (SEC.
002)
Technologist Project
Draft Technical Design Topology
SMART HOME
TECHNOLOGY
HANDS-0N TECHNICAL DEMONSTRATION
Proposed for:
Tridel Construction Inc.
Presented by:
TechSmart Solutions
Submitted by:
Prasad Avulam (300908435)
Harshita Gupta (300896538)
Ravi Inder Singh (300910121)
Amandeep Kaur (300931311)
Amandeep Kaur (311)
Windows Server 2012: Set Up First Domain Controller
By Installing ADDS (Active Directory Domain Service) roles and features, the windows server
2012 domain controller has become a Domain Controller. Latest security updates are applied
before installing the ADDS.
Promoted this server as a Domain Controller and created new forest with the domain name
“tridelhomes.ca”.
Created user’s multiple users within the domain an added few devices (lab desktops) to the
active directory. Login in to these computers using the users created in the Active Directory.
Administrative permissions are given by adding the users into multiple groups to obtain remote
desktop configurations. Following are few screenshots obtained during installations.
DHCP
Installed DHCP roles in the windows 2012 server. Created different scopes for the Server Farm,
VLAN101, VLAN201 included the IP addressing range, default addresses, DNS address. These
IP addresses are useful for the dynamic allocation of IP addresses for the devices with in the
network. Following screenshots includes few DHCP configurations performed.
0
DNS
Installed DNS roles. Configured forward lookup zone for the exchange server, domain forest,
and alias for the exchange server. Followed includes few screenshots of the DNS configurations.
Print Service:
Print services enables to add printers to the domain and create some policies to allow or deny the
printing operations to the users and groups. Installed the printer services and added network
printers to the domain by using the tcp/ip connection.
Microsoft Exchange
Installed Microsft Exchange 2016 on Windows Server 2012 r2 to create a mail server. Installed
all prerequisites for the exchange server installins. Installed the latest updates, .Net framework
4.7, Microsoft Unified Communications Managed api 4.0. using the appropriate Actiuve
Directory admin credentials installed exchange server . Created forward and reverse lookup
zones in DNS server.
User Login
CONFIGURATIONS
R1
show run
Building configuration...
Current configuration : 2158 bytes
! Last configuration change at 19:55:55 UTC Tue Apr 24 2018
! NVRAM config last updated at 19:43:51 UTC Tue Apr 24 2018
! NVRAM config last updated at 19:43:51 UTC Tue Apr 24 2018
version 15.1
service timestamps debug datetime msec
service timestamps log datetime msec
no service password-encryption
!
hostname R1
boot-start-marker
boot-end-marker
no aaa new-model
memory-size iomem 10
no ipv6 cef
ip source-route
ip cef
multilink bundle-name authenticated
crypto pki token default removal timeout 0
license udi pid CISCO1941/K9 sn FTX160183K3
!
!
redundancy
interface Embedded-Service-Engine0/0
no ip address
shutdown
interface GigabitEthernet0/0
no ip address
duplex auto
speed auto
interface GigabitEthernet0/0.1
encapsulation dot1Q 1 native
ip address 10.10.0.2 255.255.255.0
ip helper-address 10.0.0.5
standby 1 ip 10.10.0.1
standby 1 priority 105
standby 1 preempt
!
encapsulation dot1Q 101
ip address 10.11.101.2 255.255.255.0
standby 101 ip 10.11.101.1
standby 101 preempt
ip address 10.21.101.2 255.255.255.0
standby 201 ip 10.21.101.1
standby 201 preempt
no ip address
shutdown
duplex auto
speed auto
interface Serial0/0/0
ip address 192.168.1.1 255.255.255.0
no ip address
shutdown
clock rate 2000000
interface BRI0/1/0
no ip address
encapsulation hdlc
shutdown
router ospf 1
network 10.10.0.0 0.0.0.255 area 0
network 10.11.101.0 0.0.0.255 area 0
network 10.21.101.0 0.0.0.255 area 0
network 192.168.1.0 0.0.0.255 area 0
ip forward-protocol nd
no ip http server
no ip http secure-server
control-plane
!
line con 0
line aux 0
line 2
no activation-character
no exec
transport preferred none
transport input all
transport output pad telnet rlogin lapb-ta mop udptn v120 ssh
stopbits 1
line vty 0 4
login
transport input all
scheduler allocate 20000 1000
end
R1#
ISP
show run

!
! Last configuration change at 20:37:28 UTC Tue Apr 24 2018
version 15.1
no service timestamps debug uptime
no service timestamps log uptime
!
hostname ISP
!
boot-start-marker
boot-end-marker
!
!
!
no aaa new-model
!
!
no ipv6 cef
ip source-route
no ip cef
!
!
!
!
!
!
multilink bundle-name authenticated
!
crypto pki token default removal timeout 0
!
!
license udi pid CISCO1941/K9 sn FTX155282CB
!
!
!
redundancy
!
!
!
!
!
!
!
!
!
!
!
interface Embedded-Service-Engine0/0
no ip address
shutdown
!
no ip address
shutdown
duplex auto
speed auto
!
no ip address
shutdown
duplex auto
speed auto
!
ip address 192.168.1.2 255.255.255.0
clock rate 128000
!
ip address 192.168.2.1 255.255.255.0
!
router ospf 1
network 192.168.1.0 0.0.0.255 area 0
network 192.168.2.0 0.0.0.255 area 0
!
ip forward-protocol nd
!
no ip http server
no ip http secure-server
ip flow-export version 9
!
!
!
!
!
!
!
!
control-plane
!
!
!
line con 0
line aux 0
line 2
no activation-character
no exec
transport preferred none
transport input all
transport output pad telnet rlogin lapb-ta mop udptn v120 ssh
stopbits 1
line vty 0 4
login
transport input all
!
scheduler allocate 20000 1000
end
ISP#
R3
show run
!
version 12.4
no service timestamps debug uptime
no service timestamps log uptime
!
hostname R3
!
boot-start-marker
boot-end-marker
!
!
no aaa new-model
!
resource policy
!
mmi polling-interval 60
no mmi auto-configure
no mmi pvc
mmi snmp-timeout 180
ip subnet-zero
ip cef
!
!
!
!
!
!
!
!
interface FastEthernet0/0
no ip address
duplex auto
speed auto
!
interface FastEthernet0/0.1
encapsulation dot1Q 1 native
ip address 10.10.0.3 255.255.255.0
no snmp trap link-status
standby 1 preempt
!
ip address 10.0.0.3 255.255.255.0
standby 99 preempt
!
ip address 10.11.101.3 255.255.255.0
standby 101 ip 10.11.101.1
standby 101 preempt
!
ip address 10.21.101.3 255.255.255.0
standby 201 ip 10.21.101.1
standby 201 preempt
!
no ip address
shutdown
duplex auto
speed auto
!
no ip address
no fair-queue
clock rate 2000000
!
ip address 192.168.2.2 255.255.255.0
clock rate 128000
!
router ospf 1
log-adjacency-changes
network 10.10.0.0 0.0.0.255 area 0
network 10.11.101.0 0.0.0.255 area 0
network 10.21.101.0 0.0.0.255 area 0
network 192.168.2.0 0.0.0.255 area 0
!
ip classless
ip flow-export version 9
!
ip http server
!
!
control-plane
!
!
line con 0
line aux 0
line vty 0 4
login
!
end
R3#
SWITCH CONFIGS
SW1
show run

!
version 12.2
no service pad
service timestamps debug uptime
service timestamps log uptime
!
hostname SW1
!
!
no aaa new-model
system mtu routing 1500
ip subnet-zero
!
!
!
!
no file verify auto
spanning-tree mode pvst
spanning-tree extend system-id
!
vlan internal allocation policy ascending
!
switchport mode trunk
!
switchport access vlan 101
switchport mode access
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
interface Vlan1
ip address 10.10.0.11 255.255.255.0
no ip route-cache
!
ip default-gateway 10.10.0.1
ip http server
!
control-plane
!
!
line con 0
line vty 5 15
!
end
SW1#
SW2
show run
!
version 12.2
no service pad
!
hostname SW2
!
!
no aaa new-model
ip subnet-zero
!
!
!
!
no file verify auto
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
interface Vlan1
ip address 10.10.0.12 255.255.255.0
no ip route-cache
!
ip http server
!
control-plane
!
!
line con 0
line vty 5 15
!
end
SW2#show run

!
version 12.2
no service pad
!
hostname SW2
!
!
no aaa new-model
ip subnet-zero
!
!
!
!
no file verify auto
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
interface Vlan1
ip address 10.10.0.12 255.255.255.0
no ip route-cache
!
ip http server
!
control-plane
!
!
line con 0
line vty 5 15
!
end
SW2#
PING SCREENSHOTS
Ping from PC1 in VLAN 101 to ISP’s s0/0/1 interface (192.168.2.1)

End-to end connectivity
Implementing Bridging with tridelhomes.ca domain created using Active Directory and Domain Services
PC1 in VLAN 101 retrieved IP address via DHCP
