Contents
Specifications ........................................................................................................................................... 3
Function Test ............................................................................................................................................ 5
Tube Adjustment Specification............................................................................................................... 17
Back Up User’s Data .............................................................................................................................. 24
Recovering the Factory Default ............................................................................................................. 26
Circuit Check Specifications .................................................................................................................. 27
Circuit Diagram ...................................................................................................................................... 28
Exploded view ........................................................................................................................................ 43
Parts List ................................................................................................................................................ 44
Spare Parts Order List ............................................................................................................................ 51
Spare Parts Order Sheet ..........................................................................................................................56
Supplement 1: G9.2tt optical sensor problem..........................................................................................57
Supplement 2: G9.2tt PEDAL SW Adjustment specifications................................................................61
Importance: Harness Fixing.....................................................................................................................63
- 2 -
Downloaded from www.Manualslib.com manuals search engine

Specifications
Number of effect types 106 types
Number of effect modules 10 simultaneously usable modules
Patch memory User area : 5 patches x 20 banks = 100 (read/write enabled)

Preset area : 5 patches x 20 banks = 100 (read only)Total: 200
patches
Sampling frequency 96 kHz
A/D conversion 24-bit, 64-times oversampling
D/A conversion 24-bit, 128-times oversampling
Signal processing 32-bit
Frequency response 20 Hz - 40 kHz +1.0 dB, -3.0 dB (10 kilohm load)
Display 2-digit 7-segment LED display

16-digit 2-line backlit LCD
Inputs
Guitar input Standard monaural phone jack
Rated input level: -10 dBm
Input impedance: 1 megohm
AUX input Mini phone jack (stereo)

Rated input level: -10 dBm
Input impedance: 10 kilohms
External Return Standard mono phone jack

Rated input level: -10 dBm/+4 dBm (switchable)
-3-

Outputs
Line output Standard monaural phone jack x 2
Rated output level: -10 dBm/+4 dBm (switchable)
Maximum output level: +19 dBm (into load impedance of 10
kilohms or more)
Output impedance: 1 kilohm or less
Headphone output Standard stereo phone jack

Rated output: 60 m W (into 32-ohm load), 20 m W (into 300-ohm
load)
Output impedance: 47 ohm
External Send Standard mono phone jack

Rated output level: -10 dBm/+4 dBm (switchable)
Tube circuitry 12AX7 x 2
Control connectors MIDI OUT, MIDI IN
USB interface
PC interface 16-bit (record/play, stereo)
Sampling frequencies 32 kHz, 44.1 kHz, 48 kHz
Power requirements 15 V AC, 1.5 A (from supplied AC adapter AD-0012)
Dimensions 235 (D) x 595 (W) x 85 (H) mm
Weight 5.5 kg
• 0 dBm = 0.775 Vrms

• Design and specifications subject to change without notice.
-4-

Function Test
After the G9.2tt is assembled, the following inspections and settings should be made.
* Equipment required
· AC voltage meter (audio analyzer would be better)
· IHF-A filter (audio analyzer might include it)
· Oscillator
· AC adapter (AD-00012)
· Cables
● Set up before start up Test Mode.

* Adjust both [GAIN SW] (SW200) of OUTPUT and [GAIN SW] of EXT LOOP in -10 dBm.
* Adjust [OUTPUT LEVEL] (VR200) in MAX.
* Adjust both [TUBE] knob (VR201) of ENERGIZER and [BOOST] knob (VR202) of
ENERGIZER in 0 (turn counterclockwise extremely).
* Adjust [TUBE] knob (VR701) of ACCELERATOR in 5 (center) and [SOLIDSTATE] knob
(VR703) of ACCELERATOR in 5 (center).
1. Starting built-in inspection program.
Connect the AC-adapter.
(1)Turn on the "Power SW" while holding [AMP SELECT SYSTEM] key(SW5) and [EXIT]
key(SW19).
Or TP1 of the main PCB connect to the GND before power on. And then power will be turn on, the
set is running as Test Mode.
*AC adapter must be used AD-0012.
(2)After turning on the power, 7SEG LED will be displayed as [8.8.] and LCD, all of the SW, LED
will be ON.
*There is no sound comes out from OUTPUT in this status.
*To make sure that there is no broken or any no dark LED was found.
*After power turned on, the tube will be warm and bright.
(3)When any key will be pressed, the system will be start to DSP Download test mode.
This is the test for Test mode program downloading to the DSP.
This test methodology is comparing with the data which was written and the data which was read.
If in the case of successfully, LCD will be displayed as [DSP DOWNLOAD OK].
If in the case of fail, LCD will be displayed as [DSP DOWNLOAD NG]. If in this case all of the
testing after that will be ignored.
After holding display for 1sec, the LCD comes up all segments again, and then DSP can do a
signal processing.
(De-Emphasis and Emphasis circuit are working in this status.)
*After this the sound which is added from [INPUT] and [AUX IN] comes out from all [OUTPUT ]
(PHONE, L/MONO, R terminal).
When any key will be pressed, all LCD and LED will be off and then the system will be into
another test mode.
-5 -

2. GAIN SW check
Following the operation “1.”, input sin wave (440Hz/-20dBm) to [INPUT] jack and monitor the
output from [OUTPUT] jack (L/MONO, R) with speakers and oscilloscope.
Make sure that output level changes by switching [-10dBm] and [+4dBm]. Then, output from
[Phones] jack doesn’t change.
*Refer to “Circuit Check Specifications” about the specs of output.
3. OUTPUT LEVEL check
Turn right [LEVEL] volume.

Input audio signal to [AUX IN] jack.
Make sure that outputs level from [PHONE] jack gradually changes by turning around the
[LEVEL] volume of output.
*Insert 32 ohm load.
*Make sure output level changes smoothly by turning volume knob.
*Refer to “Circuit Check Specifications” about the specs of output.
4. VERSION, REVISION, and CRC32 check
Press the [CHANNEL A] key (SW12), and make sure that the [CHANNEL A] key lights up.
Make sure that the LCD is displayed [G9 v1.01 R9031 CRC : 3D78B445] 4/18 present
Press the [CHANNEL B] key (SW13), and make sure that the [CHANNEL B] key lights up.
Make sure that the LCD is displayed [G9F v1.07 R8011 CRC : B2FF05EA]. 4/18 present
However, this numbers are indicated only right after flash writing, and this numbers change if
some function like EX PEDAL setting or All Initialize is carried out.
*When it comes and there is no writing information (the contents of FLASH are empty), LCD is
displayed [Empty].
5. DIAL/VOLUME check
Turn the knob (DIAL/VOLUME) in the following table.

Make sure that the indications “01 ->02 -> 03 ... ->Fd ->FE ->FF” appear on the 7segment LED
display when the dial is turned clockwise, and that “FF ->FE ->Fd ... 02 -> 01 -> 00” when turned
anticlockwise.
And the LCD display is changed by every turning those knobs.
Table1. DIAL/VOLUME LCD display

DIAL/VOLUME LCD
[TYPE](SW30) TYPE
[PARM 1](SW31) PARM1
[AMP TYPE](SW35) AMP TYPE
[GAIN](VR1) GAIN
[LEVEL](VR2) LEVEL
[BASS](VR3) BASS
[MIDDLE](VR4) MIDDLE
[TREBLE](VR5) TREBLE
[PRESENCE](VR6) PRESENCE
-6 -

6. SEND / RETURN check
Input sin wave (440Hz/-20dBm) to [INPUT] jack and [RETURN] jack, and monitor the output
from [OUTPUT] jack (L/MONO, R) with speakers and oscilloscope.
Then, insert to [RETURN] jack and pull from [RETURN] jack, and make sure that the LCD
display indicates [RETURN plugged].
Press the [PEDAL1 SETTING] key, and this key lights up red and the LCD display indicates
[PEDAL1 SETTING TUNER IN/RETURN]. Besides, by pushing the key repeatedly, the
7segment LED displays [tn], [rt] alternately.
When the 7segment LED displays [tn], input sound of [INPUT] jack is outputted from
[SEND] jack.
Then, make sure output sound changes by selecting [EXT LOOP] GAIN SW.
When the 7segment LED displays [rt], input sound of [RETURN] jack is outputted from
[SEND] jack.
Then, make sure output sound doesn’t change by selecting [EXT LOOP] GAIN SW.
7. DSP-MUTE check
Press the [AMP SELECT SYSTEM] key (SW5).

Make sure the [AMP SELECT SYSTEM] key lights red, and LCD is displayed [AMP
SEL/SYSTEM DSP MUTE].
Then, no sound comes L/MONO jack from [INPUT] jack.
By pushing key repeatedly, 7segment displays [on], [oF] alternately.
*The sound from [AUX IN] jack will be no change.
8. SDRAM check
Press the [BYPASS TUNER] key (SW15).

Make sure the [BYPASS TUNER] key lights red, and LCD is displayed [BYPASS/TUNER
SDRAM].
< delay check >
Input sin wave (440Hz/-20dBm) to [INPUT] jack and monitor the output from [OUTPUT] jack
(L/MONO, R) with speakers and oscilloscope.
*The output sound from [AUX IN] does not change.
Make sure that the delayed signal is output from the [L/MONO OUTPUT] jack and left channel of
[AUX IN] jack.
(Delay time is 0.5 seconds)
9. FLASH check
Press the [PAGE] key (SW17).

Make sure the [PAGE] key lights red, and LCD is displayed [PAGE].
Device check of FLASH is performed.
After a device check, if it is OK, LCD is displayed [Flash Write OK] and 7segment LED is
displayed [ok].
When a device check is not able to be checked, or there is fault, it is displayed [Flash Write NG].
*Make sure that there is no defect on the sound (abnormal noise .etc)
-7 -

10. ANALOG-MUTE check
Press the [STORE/SWAP] key (SW16).

Make sure that the [STORE/SWAP] key lights red, and LCD is displayed [STORE/SWAP
ANALOG MUTE].
The 7segment LED turns [on] and [oF] by pressing the [STORE/SWAP] key.
When the 7segment LED turns on, sound from [PHONE] jack, [L/MONO] jack, [R] jack, and
[SEND] jack are extremely low.
11. USB-MUTE (SW) check
Press the [EXIT] key (SW19)

Make sure that the [EXIT] key lights red, and LCD is displayed [EXIT USB MUTE].
The 7segment LED turns [on] and [oF] by pressing the [EXIT] key.
12. DIRECT-MUTE check
Press the [PEDAL2 SETTING] key (SW20).

Make sure that the [PEDAL2 SETTING] key lights red, LCD is displayed [PEDAL2 SETTING
DIRECT MUTE].
The 7segment LED turns [on] and [oF] by pressing the [STORE/SWAP] key.
When the 7segment LED turns on, output sound from [PHONE] jack is lower than
ANALOG-MUTE.
*The output sound is smaller than ANALOG-MUTE, during DIRECT-MUTE on.
*The output sound from [SEND] jack doesn’t change.
13. SW/LED check
When press the key in the following table2, the pressed Key lights green.
Make sure that the indications [green -> red -> orange -> light off -> green -> red …] appear on
the press the key in the following table when it pressed repeatedly.
* Only [COMP] key (SW1), below all switches turn on if pressing that key.
Table2. SW LCD display

SW LCD
[COMP](SW1) COMP
[WAH/EFX](SW2) WAH/EFX
EXT LOOP (SW614) EXT LOOP
[ZNR](SW6) ZNR
[PRE-AMP](SW9) PRE-AMP
[EQ](SW4) EQ
[CABINET](SW7) CABINET
[MOD/EFX2](SW10) MOD/SFX
[DELAY](SW8) DELAY
[REBERB](SW11) REVERB
[TOTAL/FUNCTION](SW3) TOTAL/EFX CHAIN
-8 -

14. MIDI LOOPBACK check
Connect MIDI cable to [MIDI IN] and [MIDI OUT] (J401)

PUSH [HOLD MANUAL BANK↓] FOOT SW (SW22).
[HOLD MANUAL BANK↓] LED lights red.
LCD displays [MIDI LOOPBACK]. Confirmation of data transmission will be done.
If transmission is OK, LCD displays [MIDI LOOPBACK Success], 7 segment LED displays [ok].
Otherwise, LCD displays [MIDI LOOPBACK 00 timeouted], 7 segment LED displays [nG].
15. LCD CONTRAST check
Push [HOLD BYPASS/TUNER] FOOT SW (SW24).

[HOLD BYPASS/TUNER] LED lights red.
LCD displays [LCD CONTRAST 0123456789ABCDEF].
Check deepness of LCD contrast.
7 segment LED displays [01]-[04]. [01] presents most pale, [04] presents most deep, respectively.
16. CH A/B FUNCTION1 (SW) check
Press the [CH A/B FUNCTION1] FOOT SW (SW26).

Make sure that the [CH A/B FUNCTION1] LED lights green, and LCD is displayed [CH A/B
FUNCTION1].
The [CH A/B FUNCTION1] LED repeats [green -> red -> orange -> light off -> green -> red …]
by pressing the [CH A/B FUNCTION1] FOOT SW.
17. TAP FUNCTION2 (SW) check
Press the [TAP FUNCTION2] FOOT SW (SW 628).

Make sure that the [TAP FUNCTION2] LED lights green, and LCD is displayed [TAP
FUNCTION2].
The [TAP FUNCTION2] LED repeats [green -> red -> orange -> light off -> green -> red …] by
pressing the [TAP FUNCTION2] FOOT SW.
18. WAH/EFX1 (SW) check
Press the [WAH/EFX1] FOOT SW (SW21).

Make sure that the [WAH/EFX1] FOOT SW lights red, and LCD is displayed [TUBE
ENERGIZER].
The 7segment LED turns [on] and [oF] by pressing the [WAH/EFX1] FOOT SW.
-9 -

19. INPUT CIRCUIT NOISE check
Push [PRE-AMP] FOOT SW (SW23)

[PRE-AMP] key lights red.
LCD displays [GAIN +60].
About this check, adjust [TUBE] of ACCELERATOR, [SOLID STATE] of ACCELERATOR,
[TUBE] of ENERGIZER, and [BOOST] of ENERGIZER to 5.
Make sure that noise level increases.
When 7 segment LED displays [on], DSP has +60dB gain and increase white noise of [OUTPUT]
jack (PHONE, L/MONO, R jack) and [SEND] jack sound.
By pushing key repeatedly, 7 segment displays [on], [oF] alternately, and at the same time DSP
gain will be on/off.
20. PRE EMPHASIS check
Push [MOD/EFX2] FOOT SW (SW25)

[MOD/EFX2] key lights red.
LCD displays [PRE EMPHASIS].
By pushing key repeatedly, 7 segment displays [on], [oF] alternately.
* When 7 segment displays [on], PRE-EMPHASIS is on by DSP
21. DE EMPHASIS check
Push [DELAY] FOOT SW (SW27).

[DELAY] key lights red.
LCD displays [DE EMPHASIS].
* When 7 segment displays [on], DE-EMPHASIS is on by DSP
22. REVERB (SW) check
Press the [REVERB] FOOT SW (SW 629).

Make sure that the [REVERB] LED lights red, and LCD is displayed [TUBE ACCELARATOR].
*The output sound doesn’t change by this operation.
-10 -

23. EX PEDAL1 check
The 7segment LED is displayed EX PEDAL’s AD value if the PEDAL is moved.

Make sure that this EX PEDAL’s AD value is the same as below table and LCD displayed
[PEDAL2-V].
*MIN : raise EX PEDAL this side.
*MAX : lower EX PEDAL till that contacts gum lightly.
Table3. Expression pedal values

Expression pedal Values
MIN(raise) 07 or more
MAX(down) E0 to F9
Pushed all the way PEDAL SW ON
Make sure that difference between MIN and MAX is 60 or more in hex and this value doesn’t
decrease if EX PEDAL is pressed down.
Adjust of Trimmer potentiometer (VR600).
Carry out the EX PEDAL1 setting.
Make sure that the LCD displays [PEDAL2 ON] by pressing down the EX PEDAL stronger, and
[PEDAL2 ON] disappears by stopping pressing down that pedal.
If AD value is read right after [PEDAL2 ON] disappeared, [PEDAL2-V] is displayed again.
24. The trimmer potentiometer adjustment (VR 600)
Open the BOTTOM COVER.

With the EX PEDAL fully down, and adjust the value to the range of [EE] to [F2] by rotating the
trimmer potentiometer (VR 600) on the FOOT1 PCB (PCB-0158A). Back side of PCB is
displayed as [Pedal L Adjust].
*If the value is less than [EE], adjust the value to max.
* Use a Precision minus driver (Within 2mm in diameter).
25. PEDAL setting
Turn on the power holding the [PEDAL1 SETTING] key, and the indication [PDL Calibration
PEDAL1…min] appears on the LCD. With the EX PEDAL fully raised, press the
[STORE/SWAP] key, and the indication [PDL Calibration PEDAL1…MAX] appears on the
7segment LED.
And the EX PEDAL fully down and then lift your foot off the pedal, then press the
[STORE/SWAP] key.
And the unit returns to the play mode after the indication [ok] appears on the LCD.
After this setting, make sure that the EX PEDAL’s AD value again.
26. Weighting adjustment
Like the right figure, set a balance on the setting

point after making the EX PEDAL’s AD value
minimum. Add a weight to the balance till the EX
PEDAL starts to move. Then adjust the scale to range
of 350g to 500g (QC = 350g to 700g) by hexagon
socket head screw in the unit.
-11 -

27. EX PEDAL2 / Z PEDAL check
1.
The 7segment LED is displayed vertical AD value of EX PEDAL2 if the PEDAL is moved
vertically.
Make sure that this AD value of EX PEDAL is the same as below table and LCD displayed
[PEDAL1].
*MIN : raise EX PEDAL this side.
*MAX : lower EX PEDAL till that contacts gum lightly.

MIN(raised) 07 and more
MAX(down) E0 to F9
Pushed all the way PEDAL SW ON
decrease if EX PEDAL is pressed down.
Adjust of Trimmer potentiometer (VR500) on the FOOT1 PCB (PCB-0158A).
Carry out the EX PEDAL2 setting. Back side of PCB is displayed as [Pedal R Adjust].
Make sure that the LCD displays [PEDAL1 ON] by pressing down the EX PEDAL2 stronger,
and [PEDAL1 ON] disappears by stopping pressing down that pedal.
If AD value is read right after [PEDAL1 ON] disappeared, [PEDAL1] is displayed again.
2.
The 7segment LED is displayed horizontal AD value of Z PEDAL if the PEDAL is swung
horizontally.
Make sure that this AD value of Z PEDAL is the same as below table and LCD displayed
[PEDAL2-H].
MIN(left) 07 and more
MAX(right) 90 to EA
decrease if Z PEDAL is swung to right.
Adjust of Trimmer potentiometer (VR601) on the FOOT1 PCB (PCB-0158A). Back side of
PCB is displayed as [Pedal_3D Adjust].Carry out the EX PEDAL2 setting.
If the Lock arm is raised the Z PEDAL is steadied.
*Make sure the Z PEDAL doesn’t swing horizontally, and then the Lock arm doesn’t come
down.
28. Adjustment Trimmer potentiometer (VR500 / VR601)
Open the BOTTOM COVER.

1.
With the EX PEDAL2 fully down vertically, and adjust the value to the range of [EE] to [F2]
by rotating the trimmer potentiometer (VR 500) on the FOOT1 PCB (PCB-0158A). Back side
of PCB is displayed as [Pedal R Adjust].
*If the value is less than [EE], adjust the value to max.
2.
With the Z PEDAL fully swing to right, and adjust the value to the range of [E0] to [E5] by
rotating the trimmer potentiometer (VR 601) on the FOOT1 PCB (PCB-0158A). Back side of
PCB is displayed as [Pedal_3D Adjust].
*If the value is less than [E0], adjust the value to max.
-12 -

29. PEDAL setting
Turn on the power holding the [PEDAL2 SETTING] key, and the indication [PDL Calibration
PEDAL2-V…min] appears on the LCD. With the EX PEDAL2 fully raised, press the
[STORE/SWAP] key, and the indication [PDL Calibration PEDAL2-V…MAX] appears on the
LCD.
And the EX PEDAL2 fully down and then lift your foot off the pedal, then press the
[STORE/SWAP] key, and the LCD is displayed [PDL Calibration PEDAL2-V…min] after the
LCD is displayed [PDL Calibration ok] a few seconds.
Raise the lock arm and Z PEDAL is locked. Press the [STORE/SWAP] key after the Z PEDAL
swing to right extremely and the LCD is displayed [PDL Calibration PEDAL2-H…MAX].
Lower the lock arm and Z PEDAL is unlocked. Then the Z PEDAL swing to right extremely, and
press [STORE/SWAP] key again.
And the unit returns to the play mode after the indication [PDL Calibration ok] appears the LCD.
After this setting, make sure that the EX PEDAL and Z PEDAL’s AD value again.
30. Weighting adjustment
Like the right figure, set a balance on the setting

point after making the EX PEDAL2’s AD value
minimum. Add a weight to the balance till the EX
PEDAL starts to move. Then adjust the scale to
range of 350g to 500g (QC = 350g to 700g) by
hexagon socket head screw on the back of EX
PEDAL2.
31. Restoring Factory Defaults
Turn on the [POWER] SW while holding down the [STORE/SWAP] key (SW16), and the
indication [All Initialize? Y: STORE N: EXIT] appears on the LCD.
Then press the [STORE/SWAP] key once more.
Make sure that the LCD displayed [All Initialize Factory Revert..] and these dots go on and off.
Then LCD displayed [Complete!], and initialization is carried out and the system starts up in “Play
Mode”.
*If [EXIT] key is pressed, the system starts up in not All Initialize but Play Mode
32. Sound check 1
Turn on the [POWER] and the 7 segment LED displayed [U0], [WAH/EFX1] LED lights red, and
[CH A/B FUNCTION1] LED lights green.
Then, Input sin wave (440Hz, -10dBm) and monitor its output sound by speaker or oscilloscope.
Make sure this output sound is distortion sound and doesn’t include abnormal noise, and this
output sound isn’t abnormal sound.
-13 -

33. ACCELERATOR check
Turn the [SOLOD STATE] knob and the [TUBE] knob counterclockwise extremely, and output
sound from all [OUTPUT] jacks will be muted.
Turn the [SOLID STATE] knob clockwise, and output sound from all [OUTPUT] jacks will be
louder.
Turn the [SOLID STATE] knob counterclockwise again, and turn the [TUBE] knob clockwise,
and output sound from all [OUTPUT] jacks will be distorted and louder.
This distortion increase rapidly when the guide of knob comes up to around 8.
*The LCD display, the 7segment LED, and all LEDs are not change by turning [TUBE] knob and
[SOLID STATE] knob.
*The output sound of [SEND] jack doesn’t change.
*The output sound changes smoothly by turning the [VOLUME].
*The output sound comes from [AUX IN] jack never changes by turning any knobs.
*Refer to Check Spec regarding to output sound specification.
34. ENERGIZER check
Input sin wave (100Hz, -10dBm) and monitor its output sound by speaker or oscilloscope.
Make sure that when the [BOOST] knob will be turned right, the low frequency sound and
middle high range frequency sound will be increased from [OUTPUT] (L/MONO, R terminal).
Input sin wave (440Hz, -10dBm) and monitor its output sound by speaker or oscilloscope.
Make sure that when the [TUBE] knob will be turned right, the distortion of sound will be
increased from [OUTPUT] (L/MONO, R terminal).
*All of the display will be no change even though either [TUBE] or [BOOST] will be turned.
*The sound comes from [AUX IN] will be no change even though either [TUBE] or [BOOST]
will be turned.
*Refer to Test Specification regarding to the output sound.
35. Sound check 2
Press the [BANK ↓] SW (SW22) twice and [DELAY 4] SW once, and the 7segment LED displayed
[b8], [DELAY 4] LED lights red, and [CHA/B FUNCTION1] LED lights green and [TAP
FUNCTION2] LED blinks to orange.
.
Then, Input sin wave(440Hz, -10dBm) and monitor its output sound by speaker or oscilloscope.
Make sure this output sound is rotary sound and doesn’t include abnormal noise, and this output
sound isn’t abnormal sound.
If this output sound is normal, hit the unit’s bottom to a desk a few times with a sound inputting.
Repeat this operation again by a headphone (impedance : 32Ω).
36. EX PEDAL check
Press the [BANK ↑] SW (SW24) twice and the [WAH / EFX 1] SW once after the 35 operation,
and the 7segment LED displayed [U0], [WAH / EFX 1] LED lights red, and [CH A / B
FUNCTION 1] LED lights green.
Lower the EX PEDAL 1, and make sure output volume becomes max when the EX PEDAL’s AD
value is MAX.
Raise the EX PEDAL 1 this side, and make sure output volume becomes mute when the EX
PEDAL’s AD value is MIN.
Then make sure this output sound doesn’t include abnormal noise, and this output sound isn’t
abnormal sound, and this output sound changes smoothly when the EX PEDAL1 is moved.
-14 -

37. EX PEDAL 2 check
In the same patch as the 36 operation, set the EX PEDAL 1 and the Z PEDAL max.
First set the Z PEDAL min, make sure that output sound’s frequency is higher than that by one
octave after setting the Z PEDAL max.
abnormal sound, and this output sound changes smoothly when the Z PEDAL is moved
38. Z PEDAL check
In the same patch as the 36 operation, set the EX PEDAL 1 and the Z PEDAL max.
First swing the Z PEDAL to right extremely, make sure that output sound’s frequency is higher
than that by one octave (output sound is higher than input sound by two octave).
abnormal sound, and this output sound changes smoothly when the Z PEDAL is moved
39. TUNER check
Long press the [HOLD BYPASS/TUNER] FOOT SW (SW24).

Make sure that the TUNING MODE.
<TUNING check>
Input sin wave (440Hz/-10dBm) to [INPUT] jack
Make sure that the 7segment LED displayed [A8], and output is through sound.
Then press the [HOLD BYPASS/TUNER] FOOT SW once more.
Make sure that the returned Play mode.
40. USB interface operation check
1) Connect the unit to PC with USB cable.

2) Start up USB inspection software.
3) In the BYPASS mode, Input sin wave (440Hz/-10dBm) to [INPUT] jack and monitor the
waveform on PC.
4) Output sin wave (440Hz/-10dB) from PC, monitor the output from [OUTPUT] jack (L/MONO,
R, Phones) with speakers and oscilloscope.
*Make sure there are no defects (abnormal noise, output trouble, etc…)
*Refer to “How to use USB inspection software” about the how to use inspection software.
41. Stability
Put the G9.2tt on a surface plate, and push it diagonally.

Make sure that there is no remarkable space (less than ±0.7 mm is acceptable).
-15 -

42. Factory default setting
Set the knobs and switch as follows:
OUTPUT VOLUME Center

All EFFECT VOLUME Turn anticlockwise till limit
All ENERGIZER VOLUME Turn anticlockwise till limit
TUBE VOLUME OF ACCELERATOR Adjust to 5 (center)
SOLID STATE VOLUME OF ACCELERATOR Adjust to 5 (center)
GAIN SW (both OUTPUT and EXT LOOP) -10 dBm
EX PEDAL (both 1 and 2) MAX(contact with the gum)
Z PEDAL Move to left till limit
Lock arm raise
POWER OFF
If the unit was operated, carry out the All Initialize function for certain before shipment.
-16 -

Tube Adjustment Specification
1. Overview
This specification describes the method to adjust differences due to characteristics of
tubes.
2. ACCELERATOR (Input side) adjustment

There are two methods of adjustment. The first is the adjustment that only the
ANALOG PCB is used for, and the second is the adjustment carried out after the unit
is assembled. Choose the method which is convenient methods as the case may be.
2.1 In the case of adjust only the ANALOG PCB

2.1.1 Measurement system
Connect the ANALOG PCB and measurement equipment as below.
● Connect the ANALOG PCB and TUBE-ACC PCB
(CNA_ACC-CNB_ACC).
● Connect CN7B, CN401A, CN402B, and CNA_ACC_TUBE to the
measurement jig with harnesses.
● Connect to GUITAR INPUT (J200) on the ANALOG PCB and an
analyzer or an oscillator.
● Connect an analyzer to ANALOG PCB and the measurement jig.
Don’t connect harnesses which are not described because they are needless and may
encourage to mistake.
Refer to figure 1, figure 2, and figure 3 for details.
Oscillator
or
Analyzer
J200
GUITAR
CN401A
TP5
ACC
D166 ANALOG PCB
ch1
CNB-ACC CNA-ACC
CN7B
D166 TUBE-ACC
CN402B CNA_ACC_TUBE Audio Analyzer
ch2
AC
ADAPTOR
jig for D166 ACCELERATOR adjustment
(AD-0012)
Figure 1 block diagram of measurement
- 17 -
J200
CNB_ACC
CN7B
CN401
TP5 ACC
CN402B
CNA_ACC_TUBE
CNA_ACC
Figure 2 G9.2tt ANALOG PCB
- 18 -
TP5 ACC
VR700 VR702
Figure 3 TP5 ACC (magnified picture near adjustment trimmer)
2.1.2. Measurement and adjustment

Carry out measurement and adjustment according to below sequence.
● assemble a measurement system according to block diagram (figure 1).
*CAUTION: There is no switch, and power is turned on when connect an
AC adaptor and the power JACK.
● Input sin wave (440Hz, -40dBm) to the INPUT JACK (J200).
● Measure a level of TP5 ACC, and adjust the VR700 for fitting into range
of provided level.
● Measure a level of the measure point on the jig, and adjust the VR702 for
fitting into range of provided level.
● Change a tube if that level doesn’t fit into range of provided level, and
adjust again.
Provided levels are

[1]. [TP5 ACC: -17.0 dBm ± 1.5dBm]
[2]. [Measure point on the jig: -20.5dBm ± 1.5dBm]
Both levels can be changed by adjusting VR700. Therefore, if only level of [2]
doesn’t fit into range of provided level, make this level fit into the range by adjusting
the VR700. As long as level of [1] isn’t in out of the range.
*CAUTION: Each tubes have different characteristics, and this adjustment necessary
to adjust for matching tube with PCB. Therefore adjusted tube and
PCB must be handled in a pair.
- 19 -
2.2 In the case of adjust after assembling
2.2.1 Measurement
Refer to below sequence.
1. Open the bottom cover of G9.2tt
2. Turn on G9.2tt in Test Mode.
3. Press any keys to carry out the DSP download test.
4. Set each analog knobs, switch and pedals as below table. Setting of other
knobs and switch don’t affect.
Table 2.2.1
TUBE (ACC) 10 (MAX)
SOLID STATE (ACC) 0 (MIN)
TUBE (ENG) 0 (MIN)
BOOST (ENG) 0 (MIN)
LEVEL MAX
OUTPUT GAIN SW -10dBm
EXT LOOP GAIN SW ANY
ALL EX PEDALs ANY
5. Input sin wave (440Hz, -40dBm) to the INPUT Jack (J200).

6. Measure a level of TP5 ACC, and adjust the VR700 for fitting into range
of provided level.
7. Measure a level of L/MONO OUTPUT JACK (J202), and adjust the
VR702 for fitting into range of provided level.
8. Change a tube if that level doesn’t fit into range of provided level, and
adjusts again.
Provided levels are

[1]. [TP5 ACC: -17.0 dBm ± 1.5dBm]
[2]. [OUTPUT: -2.5dBm ± 1.5dBm]
Both levels can be changed by adjusting VR700. Therefore, if only level of [2]
doesn’t fit into range of provided level, make this level fit into the range by adjusting
the VR700. As long as the level of [1] is in the range.
For more details about the position of TP5, refer to Figure 2 and 3.
- 20 -
3. ENERGIZER (Output side) adjustment
It is the same as G7.1ut except input level and range of provided level.
3.1. Measurement system

Below figure shows appearance of G9.2tt. Connect oscillator output of an audio
analyzer to “INPUT” of the G9.2tt, and connect a USB cable between personal
computer and “USB” of the G9.2tt.
From Audio Analyzer
To PC or Oscillator
“BYPASS/TUNER” “TUBE” Knob and “BOOST” Knob

“ACC_TUBE” Knob and “SOLID STATE” Knob
Figure 4 Appearance of G9.2tt
Start up the application program of “G2.1u USB Check”. Refer to Fig 5 on next
page.
*Refer to the method of “G2.1u USB Check” which we already issued, regarding the
instruction of the application program.
- 21 -
Figure 5 USB Check program
3.2 Measurement and adjustment

Carry out measurement and adjustment according to below sequence.
1. Remove the bottom cover of the G9.2tt.
2. Turn the power on the normal mode.
3. Press the”BYPASS/TUNER” Key or “HOLD/BYPASS/TUNER” for a
while and the signal line of G9.2tt become state of “BYPASS”.
4. Turn the “TUBE” knob to 10(MAX) position and the “BOOST” knob to
0(MIN) position.
5. Turn the “ACC_TUBE” knob to 0(MIN) position and the
“SOLIDSTATE” knob to 10(MAX) position.
5. Make all EX PEDALs to be MAX.
6. Input the signal (sine wave) of -46 dBm 440Hz to “INPUT”
7. Monitor the indication level on the application program of “G2.1u USB
Check”.
Refer to Fig5.
8. .Adjust the trimmer (left ch=VR203, right ch=VR204) for fitting into
range of provided level.
9. Change a tube if that level doesn’t fit into range of provided level, and
adjusts again.
Range of provided level is, in both left channel and right channel,
[-37.5 dBm ± 2.0dB] (However, difference both channels within 1.0dB)
This level is the same with one of G7.1ut.
- 22 -
VR204
VR203
Figure 6 The location of adjuster on the analog PCB
- 23 -
Back Up User’s Data
If necessary, back up the user’s effect patch data to avoid an accidental erasing.
* Equipment required
· User’s G9.2tt as a transmitter (hereinafter referred to as “the transmitter”)
· Another G9.2tt as a receiver (hereinafter referred to as “the receiver”)
· Jumper wires
1. Connect [MIDI IN] jack of the master unit to [MIDI OUT] jack of a unit for writing,
and [MIDI OUT] jack of the master unit with [MIDI IN] jack of a unit for writing,
respectively (See below).
2. Turn on the [POWER] SW while holding [AMP SELECT/SYSTEM] key and

[STORE] key, both units are powered on in Flash Sys writing mode for service. In
this mode LCD displays [System Update All: SYS Patch: STO], and rewrite starts
by receiving MIDI data.
1). Reception of FlashSys (RX) writing side

LCD displays [System Update All: SYS Patch: STO]. Receiving MIDI data in this
state, LCD displays [System Update Erasing…] and [System Update] in a row.
And writing of FlashSys starts.
LCD display doesn’t change after writing completes.
- 24 -

2). Transmission of FlashSys (TX) master side
In the state that “LCD displays [System Update All: SYS Patch: STO]”, push
[AMP SELECT/SYSTEM] key.
Then LCD displays [Sending all… FullChip erase..] and [Sending all…] in a row.
And transmission of FlashSys starts. After transmission completes, LCD displays
[Sending all… Done…], then return to former display. And, it is possible to
transmit any number of times by pushing the key again.
In addition, there are no ways to finish without power down if operation is

completed correctly,
*About Error display
If writing is not completed correctly, following error message is displayed of the

LCD.
Message 1 : Slave timeouted.

Contents: Equipments are not connected.
Measure: Make sure connection correctry between equipments.
Message 2 : Invalid slave

Contents: Transmission has been done between difference equipments.
Measure: Make sure whether connected equipments are the same ones.
Message 3 : erase timeouted

Contents: Failure of block erasing.
Measure: Make sure whether the unit of writing side is normal.
Message 4 : Error on erase

Contents: All area hasn’t been erased.
Message 5 : Error on trans.

Contents: Writing hasn’t completed correctly.
- 25 -

Recovering the Factory Default
In the factory default condition, the patches of the user area (A0-d9) contain the same
settings as the patches of the preset area (00-39). Even after overwriting the user patches,
their original content can be restored in a single operation (“All Initialize” function).
If necessary, back up the user’s patch data. Refer to page 24, 25 for details of the back up.
1. Turn the power on while holding the [STORE] key.

The indication “AL” appears on the display.
2. To carry out the All Initialize function, press the [STORE] key once more.
All patch settings are returned to the factory default condition, and the unit switches to
play mode. To cancel All Initialize, press the [EXIT] key instead of the [STORE] key.
- 26 -

Circuit Check Specifications
Note : After power on in a testmode, press any key only once before measurement.
No. Items Specifications Inputs Conditions/notes 7seg display Keys pressed in "Test mode"
1 Current consumption 1000mA±75mA (FLASH) Short Immediately after Test mode starts All LEDs are lit. All lit None (Start up)
2 Power supply voltage +12.0V ± 0.5V Short Immediately after Test mode starts All LEDs are lit. All lit None (Start up)
-12.0V ± 0.5V Short Immediately after Test mode starts All LEDs are lit. All lit None (Start up)
+1.26V ± 0.05V Short Immediately after Test mode starts All LEDs are lit. All lit None (Start up)
3 Output level INPUT - OUTPUT L +13.5dBm ± 1.5dB 440Hz -30dBm Output waveform is not clipped. OUTPUT_GAIN SW=+4dBm All lit None (Start up)
INPUT - OUTPUT R -10.0dBm ± 1.5dB 440Hz -30dBm Output waveform is not clipped. OUTPUT_GAIN SW=+4dBm All lit None (Start up)
PC L - OUTPUT L -0.5dBm ± 2.0dB 440Hz ±0dB Output waveform is not clipped. All lit None (Start up)
PC R - OUTPUT R -0.5dBm ± 2.0dB 440Hz ±0dB Output waveform is not clipped. All lit None (Start up)
AUX L - OUTPUT L -20.0dBm ± 1.5dB (*1) 440Hz -20dBm Output waveform is not clipped. All lit None (Start up)
AUX R - OUTPUT R -20.0dBm ± 1.5dB (*1) 440Hz -20dBm Output waveform is not clipped. All lit None (Start up)
INPUT - PHONES L -2.5dBm ± 1.5dB 440Hz -30dBm Output waveform is not clipped. Load=32ohms All lit None (Start up)
INPUT - PHONES R -26.0dBm ± 1.5dB 440Hz -30dBm Output waveform is not clipped. Load=32ohms All lit None (Start up)
(TUBE_ACC circuit) INPUT - OUTPUT L -2.5dBm ± 2.0dB 440Hz -40dBm Output waveform is not clipped. SOLID STATE=MIN, TUBE(ACC)=MAX All lit None (Start up)
RETURN - SEND -20.0dBm ± 1.5dB 440Hz -20dBm Output waveform is not clipped. "rt" "PEDAL1 SETTING" key (SW618)
RETURN - SEND -20.0dBm ± 1.5dB 440Hz -20dBm Output waveform is not clipped. EXT LOOP_GAIN SW=+4dBm "rt" "PEDAL1 SETTING" key (SW618)
INPUT - SEND -20.0dBm ± 1.5dB 440Hz -20dBm Output waveform is not clipped. "tn" "PEDAL1 SETTING" key (SW618)
INPUT - SEND -6.0dBm ± 1.5dB 440Hz -20dBm Output waveform is not clipped. EXT LOOP_GAIN SW=+4dBm "tn" "PEDAL1 SETTING" key (SW618)
4 Input level INPUT - PC L -9.5dB ± 2.0dB 440Hz -40dBm Output waveform is not clipped. All lit None (Start up)
INPUT - PC R -13.0dB ± 2.0dB 440Hz -20dBm Output waveform is not clipped. All lit None (Start up)
(In Normal Mode) INPUT - PC L -37.5dB ± 2.0dB 440Hz -46dBm Normal Mode, Output waveform is not clipped. TUBE (ENG) =MAX "A" "BYPASS/TUNER" key (SW15)
(In Normal Mode) INPUT - PC R -37.5dB ± 2.0dB 440Hz -46dBm Normal Mode, Output waveform is not clipped. TUBE (ENG) =MAX "A" "BYPASS/TUNER" key (SW15)
(In Normal Mode) INPUT - PC L/R within 1.5dB 440Hz -46dBm Make sure that difference between Lch and Rch is within 1.5dB. "A" "BYPASS/TUNER" key (SW15)
Normal mode, Output waveform is not clipped. TUBE (ENG) =MAX.
5 Frequency response INPUT - OUTPUT L -1.5dBm ± 1.5dB 20Hz -30dBm Output waveform is not clipped. All lit None (Start up)
(No Load) INPUT - OUTPUT R -5.0dBm ± 1.5dB 20Hz -10dBm Output waveform is not clipped. All lit None (Start up)
INPUT - OUTPUT L -19.5dBm ± 1.5dB 20kHz -50dBm Output waveform is not clipped. All lit None (Start up)
INPUT - OUTPUT R -23.0dBm ± 1.5dB 20kHz -30dBm Output waveform is not clipped. All lit None (Start up)
RETURN - SEND -21.0dBm ± 1.5dB 20Hz -20dBm Output waveform is not clipped. All lit None (Start up)
RETURN - SEND -20.0dBm ± 1.5dB 20kHz -20dBm Output waveform is not clipped. All lit None (Start up)
- 27 -
(TUBE_ACC circuit) INPUT - OUTPUT L -7.0dBm ± 2.5dB 100Hz -40dBm Output waveform is not clipped. SOLID STATE=MIN, TUBE(ACC)=MAX All lit None (Start up)
(TUBE_ACC circuit) INPUT - OUTPUT L -8.0dBm ± 2.5dB 4kHz -40dBm Output waveform is not clipped. SOLID STATE=MIN, TUBE(ACC)=MAX All lit None (Start up)
(TUBE_ENG circuit) INPUT - OUTPUT L +8.5dBm ± 2.0dB 100Hz -30dBm Output waveform is not clipped. BOOST=MAX,TUBE(ENG)=MIN All lit None (Start up)
(TUBE_ENG circuit) INPUT - OUTPUT R -15.0dBm ± 2.0dB 100Hz -30dBm Output waveform is not clipped. BOOST=MAX,TUBE(ENG)=MIN All lit None (Start up)
(TUBE_ENG circuit) INPUT - OUTPUT L +8.5dBm ± 2.0dB 2kHz -30dBm Output waveform is not clipped. BOOST=MAX,TUBE(ENG)=MIN All lit None (Start up)
(TUBE_ENG circuit) INPUT - OUTPUT R -15.0dBm ± 2.0dB 2kHz -30dBm Output waveform is not clipped. BOOST=MAX,TUBE(ENG)=MIN All lit None (Start up)
6 Noise level OUTPUT L -65.0dBm or less Short Insert IHF-A All lit None (Start up)
(No Load) OUTPUT R -85.0dBm or less Short Insert IHF-A All lit None (Start up)
(TUBE_ACC circuit) OUTPUT L -50.0dBm or less Short Insert IHF-A, SOLID STATE=MIN, TUBE (ACC) =MAX All lit None (Start up)
RETURN - SEND -90.0dBm or less Short Insert IHF-A All lit None (Start up)
7 Harmonic distortion INPUT - OUTPUT L 0.1% or less 440Hz -30dBm Delay Mode, 20KHz-LPF None "BYPASS/TUNER" key (SW15)
(No Load) INPUT - OUTPUT R 0.1% or less 20kHz -30dBm Delay Mode, 20KHz-LPF None "BYPASS/TUNER" key (SW15)
RETURN - SEND 0.1% or less 440Hz -20dBm Delay Mode, 20KHz-LPF None "BYPASS/TUNER" key (SW15)
(TUBE_ACC circuit) INPUT - OUTPUT L 5.0％ or less 440Hz -40dBm Delay Mode, 20KHz-LPF, SOLID STATE=MIN, TUBE(ACC)=MAX None "BYPASS/TUNER" key (SW15)
(TUBE_ACC circuit) INPUT - OUTPUT L 10.0％ to 65.0% 440Hz -10dBm Delay Mode, 20KHz-LPF, SOLID STATE=MIN, TUBE(ACC)=MAX None "BYPASS/TUNER" key (SW15)
(TUBE_ENG circuit) INPUT - OUTPUT L 5.0％ to 60.0% 440Hz -22dBm Delay Mode, 20KHz-LPF, TUBE (ENG) =MAX None "BYPASS/TUNER" key (SW15)
(TUBE_ENG circuit) INPUT - OUTPUT R 5.0％ to 60.0% 440Hz -22dBm Delay Mode, 20KHz-LPF, TUBE (ENG) =MAX None "BYPASS/TUNER" key (SW15)
8 Function of DSP-MUTE INPUT - OUTPUT L/R Check function of Mute 440Hz -30dBm Press ”AMP SELECT” key and check muting on/off. "on/of" "AMP SELECT" key (SW5)
9 Function of ANALOG-MUTE INPUT - OUTPUT L/R Check function of Mute 440Hz -30dBm Press ”STORE/SWAP” key and check muting on/off. "on/of" "STORE/SWAP" key (SW16)
INPUT - PHONES L/R Check function of Mute 440Hz -30dBm Press ”STORE/SWAP” key and check muting on/off. "on/of" "STORE/SWAP" key (SW16)
RETURN - SEND Check function of Mute 440Hz -30dBm Press ”STORE/SWAP” key and check muting on/off. "on/of" "STORE/SWAP" key (SW16)
10 Function of DIRECT-MUTE INPUT - OUTPUT L/R Check function of Mute 440Hz -30dBm Press ”PEDAL2 SETTING” key and check muting on/off. "on/of" "PEDAL2 SETTING" key (SW20)
11 System operation Make sure that keys, encoders, knobs, pedals, flash, and LEDs including display and indicator normally operate.
12 EX PEDAL operation EX PEDAL1_MIN 07 or more EX PEDAL1 Make sure that displayed value is "07 or more" by hexadecimal.
EX PEDAL1_MAX E0 to F9 EX PEDAL1 Make sure that displayed value is "E0 to F9" by hexadecimal.
EX PEDAL2-V_MIN 07 or more EX PEDAL2-V Make sure that displayed value is "07 or more" by hexadecimal.
EX PEDAL2-V_MAX E0 to F9 EX PEDAL2-V Make sure that displayed value is "E0 to F9" by hexadecimal.
EX PEDAL2-H_MIN 07 or more EX PEDAL2-H Make sure that displayed value is "07 or more" by hexadecimal.
EX PEDAL2-H_MAX 90 to EA EX PEDAL2-H Make sure that displayed value is "D2 to EA" by hexadecimal.
* Conditions (if there is no note)

Power supply AC adaptor AD-0012
Input signal Sine wave to [INPUT] jack
Output load None (100 kilohms or more)
PHONES: 32 ohms
Accelerator : SOLID STATE=MAX, TUBE=MIN
Energizer : TUBE=MIN, BOOST=MIN
GAIN SW=-10dBm, LEVEL=MAX
(*1) In the measurement that uses audio analyzer KENWOOD VA-2230A,

the specification should be -24.0dBm ± 1.5dB, considering the attenuation of the analyzer output level by having connected both L/R CH.

1 2 3 4 5 6 7 8
+3.3VD
TP1
R8 TEST MODE /NMI
47k
/TEST SW_STC1
SW_STC2
SW_STC3
+3.3VD SW_STC4 AVDD
SW_STC5 CNB_EXP
SW_STC6
1
to ANALOG PCB
R9 SW_STC7 R47 EX_PEDAL D165=3pin
47k 2
1k D166=open
C4 R180 3
D165/D166
8
7
6
5
8
7
6
5
SW_STC[1..7] 0.01u 0 2.0T-1-3A/open (2mmP)

D SW_STC[1..7] D
R37 AVSS
open-r +3.3VD
AVSS AVSS
1
2
3
4
1
2
3
4
RA1 RA2
47k*
4 47k*
4
R45
1k
C2 R181
0.01u open-r
+3.3VD
AVSS AVSS AVDD
+3.3VD CNB_PDLL
R1
10k R46 1
IC5 PEDAL_L D165=open +3.3VD
2
1 4 /RESET 1k D166=3pin
VDD OUT C3 R182 3
2 3 /CPU_WRH
VSS CD 0.01u open-r R62
open/2.0T-1-3A (2mmP)
R3112Q291A C1 AVSS +3.3VD 47k
0.01u +3.3VD CN_ROM1 IC3 CN_ROM2
AVSS AVSS AVDD CPUA16 1 48 CPUA17
1 A15 A16 1
CN4 CNB_PDLR CPUA15 2 47 /BYTE
2 A14 BYTE 2
CPUA14 3 46
1 R48 1 3 A13 VSS 3
PEDAL_R To FOOT1-PCB CPUA13 4 45 CPUD15
2 2 4 A12 DQ15A-1 4
For Flash-Writer 1k CPUA12 5 44 CPUD7
3 C5 3 5 A11 DQ7 5
PEDAL_3D D165=3pin CPUA11 6 43 CPUD14
4 0.01u 4 6 A10 DQ14 6
D166=5pin CPUA10 7 42 CPUD6
5 5 7 A9 DQ6 7
CPUA9 8 41 CPUD13
6 8 A8 DQ13 8
+3.3VD 2.0T-1-3A/2.0T-1-5A (2mmP) 9 40 CPUD5
7 9 NC DQ5 9
AVSS 10 39 CPUD12
8 10 NC DQ12 10
AVSS 11 38 CPUD4
R11 R13 11 WE DQ4 11
11310808-13440000(open) /RP 12 37 C67
47k 47k 12 RP VCC 12
1mmP FFC +3.3VD 13 36 0.1u CPUD11
R49 13 NC DQ11 13
VR_PRESENCE 47k R61 14 35 CPUD3
VR_PRESENCE 14 NC DQ3 14
1k R/B 15 34 CPUD10
15 RB DQ10 15
reserved 16 33 CPUD2
R50 16 NC DQ2 16
VR_TREBLE CPUA18 17 32 CPUD9
VR_TREBLE 17 A17 DQ9 17
1k CPUA8 18 31 CPUD1
18 A7 DQ1 18
C CPUA7 19 30 CPUD8 C
R51 19 A6 DQ8 19
TP3 VR_MIDDLE CPUA6 20 29 CPUD0
VR_MIDDLE 20 A5 DQ0 20
UPDATE +3.3VD 1k CPUA5 21 28
21 A4 OE 21
CPUA4 22 27
/NMI
RA7 R52 22 A3 VSS 22

ENG_CTL_L 5 4 VR_BASS CPUA3 23 26 CPUA19
SW_STC7
SW_STC6
SW_STC5
SW_STC4
SW_STC3
SW_STC2
SW_STC1
VR_BASS 23 A2 CE 23
ENG_CTL_H 6 3 1k CPUA2 24 25 CPUA1
24 A1 A0 24
D165/D166
7 2
8 1 C6 C7 C8 C9 open CN24P (1mmP FFC) M29W400DT55N6E open CN24P (1mmP FFC)
/TEST
R12 R14 0.01u 0.01u 0.01u 0.01u R3 Flash 4M bit

47k*4
47k 47k 1k
/RESET
AVSS AVSS AVSS AVSS R53 VR_LEVEL
VR_LEVEL
ENG_CTL_L 1k
MIDI_IN +3.3VD /OEA
100
MIDI_IN
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
MIDI_OUT
MIDI_OUT R54 VR_GAIN
R64 VR_GAIN
1k
P06/INTP5/RTPTRG
P07/INTP6
P04/NITP3
P03/INTP2
P02/INTP1
P01/INTP0
P20/SI2
P14/SO1/TXD0
P13/SI1/RXD0
P00/NMI
P81/ANI9
P80/ANI8
P77/ANI7
P76/ANI6
P75/ANI5
P74/ANI4
P73/ANI3
P72/ANI2
P05/INTP4/ADTRG
P15/SCK1/ASCK0
P12/SCK0/SCL
P11/SO0
P10/SI0/SDA
P83/ANI11
P82/ANI10
0
AVDD C68 C10 C11 /CPU_RD
A_MUTE 0.01u 0.01u
+
A_MUTE
/DIR_MUTE
/DIR_MUTE
/USB_MUTE 100u/6.3V
/USB_MUTE
ENG_CTL_H 1 75 AVSS AVSS
P21/SO2 P71/ANI1
A_MUTE 2 74
to ANALOG PCB R19 R21 P22/SCK2 P70/ANI0
R15 MIDI_IN 3 73
47k 2.2k P23/RXD1 AVREF R65
47k MIDI_OUT 4 72 C16
P24/TXD1 AVSS
/DIR_MUTE 5 71 0
P25/ASCK1 AVDD
0.1u C14 6 70 0.1uAVSS /DSP_RST
VDD P65/A21 /DSP_RST
7 69 /CODEC_PD IC8
VSS P64/A20 /CODEC_PD
/USB_MUTE 8 68 CPUA19 CPUD15 3 2 CPUA15
P26/TI2/TO2 P63/A19 D0 Q0
/USB_SPND 9 67 CPUA18 CPUD13 4 5 CPUA13
/USB_SPND P27/TI3/TO3 P62/A18 R24 R25 D1 Q1
1FS 10 66 CPUA17 CPUD11 7 6 CPUA11
1FS P30/TI00 P61/A17 47k 47k D2 Q2
LCD_RS 11 65 CPUA16 CPUD9 8 9 CPUA9
LCD_RS P31/TI01 P60/A16 D3 Q3
LCD_R/W 12 IC1 64 CPUD15 CPUD8 13 12 CPUA8
to ANALOG PCB R26 LCD_R/W P32/TI10 P57/AD15 D4 Q4
LCD_E 13 UPD703015BGC-A32-8EU-A 63 CPUD14 CPUD10 14 15 CPUA10
47k LCD_E P33/TI11 P56/AD14 D5 Q5
LCD_D4 14 62 CPUD13 CPUD12 17 16 CPUA12
LCD_D4 P34/TO0/A13 P55/AD13 D6 Q6
LCD_D5 15 61 CPUD12 CPUD14 18 19 CPUA14
LCD_D5 P35/TO1/A14 P54/AD12 D7 Q7
LCD_D6 16 60 CPUD11 +3.3VD IC10
LCD_D6 P36/TI4/TO4/A15 P53/AD11
LCD_D7 17 59 CPUD10 +3.3VD 11 20 CPUA16 1
LCD_D7 P37/TI5/TO5 P52/AD10 RA8 LE VCC A1
B 18 58 CPUD9 CPUA19 5 4 1 10 CPUA17 2 15 B
IC/VPP P51/AD9 OE GND C17 A2 Y0
/SCAN0 19 57 CPUD8 CPUA18 6 3 CPUA18 3 14 /DSP_CS
R20 R22 R23 P100/RTP0/A5 P50/AD8 0.1u A3 Y1 /DSP_CS
/SCAN1 20 56 C15 CPUA17 7 2 SN74LV373ANS 13
47k 47k 47k P101/RTP1/A6 BVSS Y2
/SCAN2 21 55 CPUA16 8 1 4 12 /EX_PORT
P102/RTP2/A7 BVDD G2A Y3 /EX_PORT
/SCAN3 22 54 CPUD7 47k*4 /OEA 5 11
P103/RTP3/A8 P47/AD7 G2B Y4
/SCAN4 23 53 0.1u CPUD6 CPUA19 6 10
P104/RTP4/A9 P46/AD6 G1 Y5
/SCAN5 24 52 CPUD5 +3.3VD 9
P105/RTP5/A10 P45/AD5 Y6
/SCAN6 25 51 CPUD4 IC9 16 7
P106/RTP6/A11 P44/AD4 VCC Y7
/SCAN7 CPUD7 3 2 CPUA7 8
P90/LBEN/WRL
P107/RTP7/A12
D0 Q0 GND
P92/R/W/WRH
CPUD5 4 5 CPUA5 C19

P93/DSTB/RD
D1 Q1
P95/HLDAK
P96/HLDRQ
+3.3VD CPUD3 7 6 CPUA3 0.1u SN74LV138ANS

P120/WAIT
P91/UBEN
D2 Q2
P94/ASTB
RA3
P114/XT1
CLKOUT
/SCAN[0..7] R2 CPUD10 8 1 CPUD1 8 9 CPUA1

P40/AD0
P41/AD1
P42/AD2
P43/AD3
P110/A1
P111/A2
P112/A3
P113/A4
/SCAN[0.. 7] D3 Q3
RESET
0 CPUD11 7 2 CPUD0 13 12 CPUA0

D4 Q4
VDD
XT2
VSS
CPUD8 6 3 CPUD2 14 15 CPUA2

X2
X1
D5 Q5
CPUD9 5 4 CPUD4 17 16 CPUA4
D6 Q6
47k*4 CPUD6 18 19 CPUA6
D7 Q7
+3.3VD
RA4
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
+3.3VD CPUD15 8 1 11 20
LE VCC
CPUD14 7 2 1 10
OE GND C18
LCD_CTS0 CPUD13 6 3
LCD_CTS0 C20 R4 0.1u
LCD_CTS1 CPUD12 5 4 SN74LV373ANS
LCD_CTS1 10K
0.1u 47k*4
R189
to ANALOG PCB
47k
R193
CPUD3
RTN_DTC C73 CPUD2 CPUA[1..19]
RTN_DTC CPUA[0..19]
TUBE_ACC 0 CPUD1
CPUD0
/RESET 470p
R27 R28 +3.3VD CPUD[0..15]
CPUD[0..15]
CLK20M
open-r 47k
PORT_D2C
X1 PORT_D2C
PORT_C2D DSP Hand-shake
20MHz PORT_C2D
/ASTB
/ASTB
/CPU_RD
/CPU_RD
/CPU_WRH
/CPU_WRL
C70 /CPU_WRL
C71
1
2
3
A A
DSP_RDY D166_dsp.sch D166_uif.sch D166_midi.Sch
15p 15p DSP_RDY
R190 R191 R63

+3.3VD 47k 47k 47k D166_dsp.sch D166_uif.sch D166_midi.sch
ENG_CTL_H
ENG_CTL_H CLK20M
ENG_CTL_L
TUBE_ACC
ENG_CTL_L
TUBE_ACC G9.2tt CIRCUIT DIAGRAM
MAIN PCB(PCB-0151) CPU Circuit
- 28 -
1 2 3 4 5 6 7 8
D166/G9.2tt MAIN PCB(PCB-0151) CPU Circuit 1/5

1 2 3 4 5 6 7 8
D D
/DSP_RST
/DSP_RST
CPUD[0..7]
CPUD[0..7]
DSPD10
DSPD11
DSPD12
DSPD13
DSPD14
DSPD15
CPUD0
CPUD1
CPUD2
CPUD3
CPUD4
CPUD5
CPUD6
CPUD7
DSPD0
DSPD1
DSPD2
DSPD3
DSPD4
DSPD5
DSPD6
DSPD7
DSPD8
DSPD9
470p
GPIO7
+3.3VD +1.26VD +1.26VD +3.3VD

0.1u
C24
0.1u
0.1u
0.1u
0.1u
C25
C26
C74
C27
C28
176
175
174
173
172
171
170
169
168
167
166
165
164
163
162
161
160
159
158
157
156
155
154
153
152
151
150
149
148
147
146
145
144
143
142
141
140
139
138
137
136
135
134
133
+3.3VD
GPIO7
HD0
HD1
HD2
CVDD
HD3
HD4
HD5
HD6
CVDD
HD7
CVDD
VSS
VSS
VSS
VSS
HPIENA
TCK
TRST
TDI
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
DVDD
DVDD
RESET
TMS
TDO
EMU1/OFF
EMU0
D10
D11
D12
D13
D14
D15
D16
R34
R33
BOOTM0 BOOTM1 BOOTM2 47k 1 132
GPIO6 D17
HPI BOOT 1 0 1 GPIO4 2 131
47k GPIO4 D18
3 130
GPIO2/BOOTM2 VSS
PORT_C2D GPIO1 4 129
PORT_C2D GPIO1/BOOTM1 D19
PORT_D2C GPIO0 5 128
PORT_D2C GPIO0/BOOTM0 D20
6 127
TIM1 D21
+3.3VD 7 126
R32 TIM0 D22
R38 8 125 C72
INT0 D23
47k open-r C21 9 124
CVDD DVDD open-c
0.1u 10 123
INT1 D24
11 122
INT2 D25 C29
C C22 12 121 C
DVDD CVDD
0.1u 13 120
INT3 D26
14 119 0.1u
NMI/WDTOUT D27
15 118
IACK D28 DSPD[0..15]
16 117
VSS VSS
AD/DA Circuit 17 116
CLKR0 D29
D_RTN 18 115
D_RTN DR0 D30
19 114
FSR0 D31 C30 0.1u
to Send/Retun for D166 20 113 +3.3VD +3.3VD
CLKX0 CVDD
D_SND C23 21 112 DSPA2
D_SND CVDD A2
R66 0 0.1u 22 111 DSPA3 IC4
DX0 A3 C31
23 110 DSPA4 1 50
FSX0 A4 0.1u VCC GND
64FS 24 IC2 109 DSPD15 2 49 DSPD0
64FS CLKR1 VSS I/O0 I/O15
D_IN 25 ZFX-3 108 DSPA5 DSPD14 3 48 DSPD1
D_IN DR1 A5 I/O1 I/O14
1FS 26 107 DSPA6 4 47
1FS FSR1 A6 GNDQ GNDQ
D_OUT R67 0 27 106 DSPA7 DSPD13 5 46 DSPD2
D_OUT DX1 A7 C39 I/O2 I/O13
28 105 DSPD12 6 45 DSPD3
CLKX1 DVDD I/O3 I/O12
29 104 0.1u DSPA8 C42 7 44 C45
R192 R35 R36 VSS A8 0.1u VCCQ VCCQ 0.1u
D166_codec.sch 30 103 DSPA9 DSPD11 8 43 DSPD4
47k 47k 47k FSX1 A9 I/O4 I/O11
31 102 DSPA10 DSPD10 9 42 DSPD5
TEST A10 I/O5 I/O10
32 101 DSPA11 10 41
NC A11 C40 GNDQ GNDQ
C33 33 100 DSPD9 11 40 DSPD6
CVDD CVDD I/O6 I/O9
0.1u 34 99 0.1u DSPA12 DSPD8 12 39 DSPD7
RX A12 I/O7 I/O8
35 98 DSPA13 C43 13 38 C46
GPIO5 A13 VCCQ VCCQ
C32 36 97 DSP_BE1 0.1u 14 37 0.1u
DVDD VSS LDQM NC
0.1u 37 96 /DSP_WE 15 36 DSP_BE0
TX A14 WE UDQM
38 95 /DSP_CAS 16 35 DSP_SDCLK
GPIO3 A15 C41 CAS CLK
39 94 /DSP_RAS 17 34 DSP_SDCKE
VSS DVDD RAS CKE
40 93 0.1u /DSP_CE2 18 33
SCL A16 CS NC
41 92 DSPA13 19 32 DSPA11
SDA A17 A11 A9
CPUA1 42 91 DSPA12 20 31 DSPA10
C1/AOE/SDRAS
C0/ARE/SDCAS
C2/AWE/SDWE
HC1/HBIL VSS A10 A8

43 90 DSPA2 21 30 DSPA9
HC0/HAS A18 A0 A7
C15/HOLDA
C12/SDCKE
ECLKOUT2
ECLKOUT1
44 89 DSPA3 22 29 DSPA8
EMIFCLKS
C14/HOLD
X2/CLKIN
HCS A19 A1 A6
C13/SOE3
C3/ARDY
CLKOUT
DSPA4 23 28 DSPA7
HCNTL1
HCNTL0
C11/BE3
C10/BE2
ECLKIN
A2 A5
C9/BE1
C8/BE0
C7/CE3
C6/CE2
C5/CE1
C4/CE0
DVDD
DVDD
CVDD
HRDY
CVDD
DSPA5 24 27 DSPA6
PVDD
HR/W
HDS2
HDS1
IC23A
HINT
A3 A4
VSS
VSS
VSS
VSS
VSS
C44
A21
A20
/ASTB 1 25 26
NC
XF
X1
/ASTB VCC GND

3 /DSP_HAS
/DSP_CS 2 0.1u EM636165TS-7G
/DSP_CS SN74LV32ANS
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
B B
DSPA[2..13]
CPUA3
C37
0.1u
0.1u
C34
C38
0.1u
C35
CPUA2 C36
0.1u
0.1u
DSP_TX
CPUA4
/DSP_CAS
/CPU_WRL /DSP_RAS
/CPU_WRL
/CPU_RD
/CPU_RD
DSP_RDY /DSP_WE
DSP_RDY
TP2
+3.3VD L4 VDD_PLL DSP_TX /DSP_CE2
CPUA[1..4] BLM18AG102S
CPUA[1..4]
DSP_SDCLK
+ C82
10u/16V R40 DSP_BE0
Near IC5 pin60 open-r DSP_BE1
DSP_SDCKE
R68
CLK20M
0
X3
C80 open C81

open-c open-c
A A
G9.2tt CIRCUIT DIAGRAM

MAIN PCB(PCB-0151) DSP Circuit
- 29 -
1 2 3 4 5 6 7 8

1 2 3 4 5 6 7 8
R87 13k-F
C86
D C83 100p R55 R_OUT D
+
1k C96
+3.3VA C49 10u/16V
8
1000p
C69
INPUT R86 2 C84 + C94
0.1u C50
1 2.2u/50V
+
75k-F 0.1u
+
100u/6.3V +3.3VA 3
R186 NJM2100M IC13A 10u/16V
47k IC15
R5 C85 LOW_GAIN 1 16 C90
C48 0.1u RIN ROUT R56
4
10k HIGH_GAIN 2 15 L_OUT

+
+
LIN LOUT
+3.3VA 3 14 1k
VSS VCOM
10u/16V 4 13 /CODEC_PD C97 10u/16V
R6 + C100 VA PDN /CODEC_PD
5 12 1000p
10k 47u/6.3V R90 + C88 C55 VD BCLK
6 11
10 0.1u DEM0 MCLK
100u/6.3V 7 10
IC13B DEM1 LRCK
5 8 9 D_OUT
SDTO SDTI D_OUT
7
R88 6 AK4552VT
15k-F NJM2100M
+ C87 C54 to ANALOG PCB
10u/16V 0.1u
C101 33p R92 100 D_IN CN7A
D_IN
1
INPUT
2
+3.3VA
R89 39k-F L_OUT
3
1
4
C D600 5 C
R_OUT
C600 1SS133 C602 6
R602 7
RETURN SEND-
+
2
C608 C609 2.0T-1-7A(2mmP)

1
1k
+
10u/16V 0.1u 10u/16V

C615
R612 D603
+ C614 1000p
47k 1SS133 0.1u +3.3VA
+3.3VA 2.2u/50V CN8A
2
1
1
/A_MUTE
D602 /A_MUTE 2
IC601 /DIR_MUTE
C603 1SS133 /DIR_MUTE 3
1 16
RIN ROUT 4
DRY_IN 2 15 /USB_MUTE
LIN LOUT /USB_MUTE 5
2
+3.3VA 3 14 /USB_SPND
1
+
VSS VCOM /USB_SPND 6

10u/16V 4 13 /CODEC_PD
D601 VA PDN /CODEC_PD
R613 5 12 2.0T-1-6A(2mmP)
1SS133 R615 + C605 C611 VD BCLK
47k 6 11
DEM0 MCLK
7 10
DEM1 LRCK
2
10 100u/6.3V 0.1u 8 9 D_SND

SDTO SDTI D_SND
CN603A
AK4552VT
C604 + C610 1
DRY_IN
C607 2
10u/16V 0.1u R614 R603 3
D_RTN SEND+ RETURN
+
D_RTN 4
100 1k 5
+3.3VD C616 10u/16V SEND+
C47 6
1000p 7
IC12F SEND-
B 8 B
14
SN74LVU04ANS 9
0.1u RTN_DTC
RTN_DTC 10
13 12
2.0T-1-10A(2mmP)
256FS need GND guard pattern
to ANALOG PCB
7
EMI
IC12E IC12A IC12B IC19
11 10 1 2 3 4 R76 10 9
CK Q1 R79
0 7 64FS
Q2 64FS
SN74LVU04ANS SN74LVU04ANS SN74LVU04ANS 11 6 0
CLR Q3
5 EMI
IC12C R83 Q4
3
Q5
5 6 1M 2
Q6
R85 +3.3VD 4
X4 Q7 R80
SN74LVU04ANS 220 16 13 1FS
VCC Q8 1FS
12 0
C59 Q9
IC12D 14 EMI
C77 C78 0.1u Q10
9 8 24.576MHz 15
15p 15p Q11
8 1
GND Q12
SN74LVU04ANS
SN74LV4040ANS
A A

MAIN PCB(PCB-0151) CODEC Circuit
- 30 -
1 2 3 4 5 6 7 8

1 2 3 4 5 6 7 8
8
7
6
5
RA6
open-r +5VD +3.3VD To PANEL-PCB
CNB_LCD
12
1
2
3
4
LCD_D7
LCD_D7 11
LCD_D6
LCD_D6 10
LCD_D5
LCD_D5 9
LCD_D4
LCD_D4 8
D 7 D
LCD_E
LCD_E 6
LCD_R/W
LCD_R/W 5
LCD_RS
LCD_RS 4
LCD_V0
3
2
1
To PANEL-PCB 2.0T-1-12A(2mmP)
CNA_VR
AVSS R7 R59 R94
8 3.9k 5.1k 750
VR_GAIN
VR_GAIN 7
VR_LEVEL
VR_LEVEL 6 DT1A DT1B
VR_BASS
3
VR_BASS 5 MUN5211DW1T1G MUN5211DW1T1G
VR_MIDDLE
VR_MIDDLE 4
VR_TREBLE 2 5
VR_TREBL
E 3
VR_PRESENCE
VR_PRESENCE 2
1
AVDD
2.0T-1-8A(2mmP)
4
LCD_CTS0
LCD_CTS1
SW_DYN[0..3]
+3.3VD= +LEDV To FOOT1-PCB

CNA_FT1M
+3.3VD
24
+3.3VD SW_DYN3
8
7
6
5
23
SW_DYN2
RA5 LED[0..7] 22
C SW_DYN1 C
47k*4 21
+3.3VD SW_DYN0
R100
R101
R102
R103
R104
R105
R106
R107
20
R96
R97
R98
R99
IC20 IC18
19
SW_DYN0 2 18 CPUD12 CPUD7 2 19 LED7 LED7
A1 Y1 1D 1Q 18
1
2
3
4
SW_DYN1 3 17 CPUD13 CPUD6 3 18 LED6 LED6

A2 Y2 2D 2Q 17
To ENCODER-PCB SW_DYN2 4 16 CPUD14 CPUD5 4 17 LED5 LED5
2.2k
2.2k
2.2k
2.2k
2.2k
2.2k
2.2k
2.2k
2.2k
2.2k
2.2k
2.2k
A3 Y3 3D 3Q 16
CNA_ENC SW_DYN3 5 15 CPUD15 CPUD4 5 16 LED4 LED4
A4 Y4 4D 4Q 15
EC_TYPE_B 22k R108 TYPE_B 6 14 CPUD1 CPUD3 6 15 LED3 LED3
14 A5 Y5 5D 5Q 14
EC_TYPE_A 22k R109 TYPE_A 7 13 CPUD0 CPUD2 7 14 LED2 LED2
13 A6 Y6 6D 6Q 13
EC_PARM1_B 22k R110 PARM1_B 8 12 CPUD3 CPUD1 8 13 LED1 LED1
12 A7 Y7 7D 7Q 12
EC_PARM1_A 22k R111 PARM1_A 9 11 CPUD2 CPUD0 9 12 LED0 LED0
11 A8 Y8 8D 8Q 11
EC_PARM2_B 22k R112 +3.3VD C61
10 10
EC_PARM2_A 22k R113 1 20 /LED_
WE 11 20 /SCAN7
9 OE1 VCC CL
K VCC 9
EC_PARM3_B 22k R114 19 10 1 10 /SCAN6
8 OE2 GND C60 OC GND 8
EC_PARM3_A 22k R115 0.1u /SCAN5
7 7
EC_PARM4_B 22k R116 SN74LV541ANS SN74LV574ANS /SCAN4
6 0.1u 6
EC_PARM4_A 22k R117 /SCAN3
5 5
/SCAN2
4 4
EC_AMP_B 22k R118 IC21 /SCAN1
3 3
EC_AMP_A 22k R119 PARM2_B 2 18 CPUD5 /SCAN0
2 A1 Y1 2
PARM2_A 3 17 CPUD4
1 A2 Y2 1
PARM3_B 4 16 CPUD7
0.039u
0.039u
0.039u
0.039u
0.039u
0.039u
C108
C109
C110
C111
C112
C113
A3 Y3 /SCAN[0..7]
2.0T-1-14A(2mmP) PARM3_A 5 15 CPUD6 1.0S-12-24P
A4 Y4 /SCAN[0..7]
PARM4_B 6 14 CPUD9
A5 Y5
PARM4_A 7 13 CPUD8
A6 Y6
AMP_TYPE_B 8 12 CPUD11
0.039u
0.039u
0.039u
0.039u
0.039u
0.039u
C102
C103
C104
C105
C106
C107
A7 Y7
AMP_TYPE_A 9 11 CPUD10
A8 Y8 SW_STC[1..7]
+3.3VD To FOOT2-PCB
SW_STC[1..7]
1 20 CNA_FT2M
OE1 VCC
19 10
OE2 GND C62 1
SW_STC7
2
SN74LV541ANS SW_STC6
0.1u 3
SW_STC5
4
SW_STC4
5
SW_STC3
6
SW_STC2
7
SW_STC1
8
/CPU_RD
/CPU_RD
2.0T-1-8A(2mmP)
B IC23B B
/EX_PORT 4
/EX_PORT
6
/CPU_WRL 5
/CPU_WRL
SN74LV32ANS
CPUD[0..15]
CPUD[0..15]
+3.3VD C63
14
0.1u IC23C
12 9
11 8
13 10
IC23D SN74LV32ANS
SN74LV32ANS
7
A A

MAIN PCB(PCB-0151) UIF Circuit
- 31 -
1 2 3 4 5 6 7 8

1 2 3 4
+3.3VD +3.3VD
J401A "MIDI"
C420
R415 C422 IC403
270 0.1u 6 1
D VCC L402 D
1 R411 4 "IN" 0.1u
1
MIDI_IN 4 33 1/2WBLM18AG102SN1 2
MIDI_IN
MIDI_OUT 2 5
MIDI_OUT
5 3 3
GND
D412 BLM18AG102SN1 SW2-5-20A
PC900VONSZX 2 1SS133 L403
C423
+3.3VD open-c
J401B
C421
+3.3VD R410
33 1/2W 6
R409 L401
9 0.1u
2.2k BLM18AG102SN1 7 "OUT"
R408 10
6
2.2k BLM18AG102SN1 8
2 5 L405 SW2-5-20A FG
C C
+3.3VA
L7
L406
DT400A BLM18AG102SN1 0
1
MUN5211DW1T1G
+ C117
DT400B 100u/6.3V
MUN5211DW1T1G
JP6
SW400A open
R9D2KKFT00F1-G IC25
from ANALOG PCB uPC2933BT-AZ / uPC2933BT1D-AT
1
CN401B +5VD +3.3VD

L6
1 3
SW400B 1 Vin +3.3V
0
2
GND
AWG16-22 R9D2KKFT00F1-G
3 + C134 C64 C65 + C116 + C122
2
3.96T-3-3A (3.96mmP) open-c 0.1u 0.1u 47u/6.3V 100u/6.3V

2
B B
CN400 +3.3VD IC26 +1.26VD

3.96T-3-2A (3.96mmP) 1 5
NC 1.25V
2 2
GND G
3 4
to ANALOG PCB CE Vin C119 + C120
1
2
CN402A XC6209F12AP 1u 47u/6.3V

J400 L407
1
1 1 C118
BL02RN2-R62 2
3 1u
3
L408 3.96T-3-2A (3.96mmP)
2
2
TDC-040H-2 BL02RN2-R62
C418 C419
A 1000p 1000p A

FG FG
MAIN PCB(PCB-0151) MIDI/POWER Circuit
- 32 -
1 2 3 4

1 2 3 4 5 6 7 8
R211
TO_ACC 47k
C209
R210
FROM_ACC 8.2k
C206 1500p
open-c
+12VA C203 +12VA C207
"GUITAR" D200 0.1u to MAIN PCB
8
8
BLM18AG102SN1 C201 1SS133(open) CN7B 0.1u
J200 L200 R202 R209
2 3 IC200A 2
1
R207 1 R237
4 10k 1 FROM_ACC 22k 1 +3.3VA +12VA -12VA
D R203 2 D
0.1u-film 2 100 3 IC201A 100
C200 1M NJM4558M 3
1 L_OUT NJM4558M
R201 C205 4
SJ6335 CN8B
5
2
620 10P R_OUT C208 C226 + C227

6 1
4
4
A_MUTE +
7 0.1u 2 10u/16V 10u/16V
-12VA 0.1u -12VA /DIR_MUTE
3
2.0T-1-7A(2mmP)
C204 R208 IC201B 4
/USB_MUTE
open(0) 5
5 /USB_SPND
R236 /USB_SPND 6
open-c 7
R206 R231 6 2.0T-1-6A(2mmP)
100
15k 22k R349
C202 NJM4558M
R701 open(0)
open-c
R204
30k
15k C228
R205 C700 22p
open-r
open-c C230
R700 6 R232
7 R702
180k DRY_IN 8.2k
5 100 1500p
IC200B R234 to_ENGL
to_ENGL
NJM4558M 47k
to_ENGR
to_ENGR
from_ENGL
from_ENGL
from_ENGR
from_ENGR
R221
R214
15k
15k C216
C211
open-c open-c 5 C224
7 R226 2 J202
+
C +12VA C217 6 IC204B 330 4 C
NJM4558M 10u/16V R227 C225
8
R212 6 C214 C215 10k 1500p 1

7 R216 R218 R219 2 C219 VR200A
0.1u SJ6335
+
15k R222
5 1 F-095V5G A10K L15FC*7 (M) C221
3
IC202B 1k 1k 13k
+
NJM4558M 10u/16V 10u/16V 3 IC203A CW C220

100
+
NJM4558M 10u/16V 2
R220 C218 R225 DT202A
47p
+
10u/16V R223 MUN5112DW1T1G
13k 10k R229
4
47k 1 6 Q202
1
-12VA 0.1u 2SC3326
1
R217 4.7k
Q201
SW200A
1k
SK22H09-G9 +12VA
"OUTPUT"
2SC3326
5
C210 R215 Q200
R213
2
2SC3326
+
"AUX" 1k
2
R224
15k
10u/16V R256 2.4k
J201 2 100k 4 3 R230 Q203
4 C232 2SC3326
R238 R243 4.7k
3 Q204 +12VA C222 DT202B
+
1 2SC3326
8
15k 1k MUN5112DW1T1G
SJ-3507-5P R233 R235 10u/16V
C229 C231 3 0.1u C243
R245 Q205 1 R261 2 J203
+
30k 10p 30k 10p 2 IC204A 4
1k 330
+12VA C212 NJM4558M 10u/16V R262 C245
2SC3326 10k 1500p 1
8
0.1u 5 IC203B C237 C223

R250 SJ6335
4
3 C234 C235 7
6
1 R244 R246 R247 6 CW C238 -12VA 0.1u

+
100
+
R239 2 5 C239
IC202A 1k 1k 13k NJM4558M 10u/16V
+
15k NJM4558M 10u/16V 10u/16V 47p

+
C213 0.1u VR200B R254 R258 +3.3VA +12VA

10u/16V
R248 C236 47k
F-095V5G A10K L15FC*7 (M)
4
10k
4
open-c
1
13k SW200B
-12VA D204
R249 +3.3VA SK22H09-G9 1SS133 R228
B 47k B
C233 15k R352 R353
A_MUTE Q211
1
2
DT200 2SC3326
330 22k SEND_MUTE
6
R255 R257
open-c 100k 2.4k R354
2 /DIR_MUTE
R240 open-r
DTA124EKA
15k
3
R251 R253 +12VA C240

1k 10k
8
R241 100
3 0.1u C242
R242 + C248 R252 1 R259
+
47u/16V 47k 2 IC205A

100 47 1/4W
NJM4556M 470u/16V R260 C244
C241 1k 0.01u
-12VA -12VA
4
tube tube
C246 C247
D166_send_return.Sch D166_acc.Sch -12VA 0.1u
USB_INL + + 10u/16V C250 DT203A
USB_INL 10u/16V MUN5112DW1T1G
open-c
USB_INR 1 6 R276 Q208
USB_INR R272
USB_OUTL
4.7k 2SC3326 "PHONES OUT"
USB_OUTL R351 10k J204
/USB_MUTE 2
USB_OUTR R269 +12VA
USB_OUTR open-r
10k 3
5
1
2
SJ6336
+3.3VA D201
RB160L-40TE25
4 3 R277 Q209
R355 2SC3326
R263 4.7k
usb tube tube Q206 39k DT203B
D166_usb.Sch D166_eng.Sch D166_pwr.Sch 2SC3326 1k MUN5112DW1T1G
Q212 R356 R267 USB_VBUS 5 IC205B C251
USB_VBUS R273
7
+
39k open-r
BC807-40 6 47 1/4W
R264 R274 C252
A NJM4556M 470u/16V A
C249 1k 0.01u
1k + C326
Q207 R265 R266 R268
2SC3326 47k open-r 100u/6.3V 620
open-c R271
10k
-12VA
R270
10k

ANALOG PCB(PCB-0165) ANALOG Circuit
- 33 -
1 2 3 4 5 6 7 8

1 2 3 4 5 6 7 8
J205
57112201-2110000
C253
GND
R200
VCC
FG FG 0.1u
D+
D-
D open D
FGND FGND FGND

1
USB D- 2
USB D+ 3
4
USB_VBUS
IC211 +3.3VUSB
1 5 R357
Vin Vout
+ C259 open-r
C257 2 C258
0.1u GND 0.1u 10u/16V
3 4
CE NC
XC6213B332MR
R279 R284
22k 12k
C261
+3.3VUSB C255
R350 /USB_SPND
/USB_SPND 330p +3.3VUSB C262
8
R280 open-r
C254 0.1u
8
R278 2 C256 C260
USB_INL IC206A 1.5k 0.1u
1 R281 R282 R283 2 C263
IC207A
+
22k
+
3 IC210 1 R285
10u/16V
+
1k 12k 3.9k
+
C C272 C277 USB_OUTL C

NJM2100M open-c R288 22 1 28 open-c 3 1k
D+ SSPND C279
R289 22 2 27 NJM2100M 10u/16V
D- VDDI 3300p 1500p
3 26
VBUS DGND
4
4 25 1u
C266 DGNDU TEST1
4
VCOM + 5 24 C270
HID0 TEST0
6 23 VCOM
HID1 VCCXI
10u/16V 7 22
HID2 AGNDX
8 21 1u
SEL0 XTI C273
+3.3VUSB 9 20
SEL1 XTO
10 19
VCCCI VCCP2I
11 18 C271 C280
IC206B C265 AGNDC AGNDP 1500p IC207B C282
5 12 17 1u 5
C264 VINL VCCP1I C276 R295
7 13 16 7
+
R286 VINR VOURL R291 R292 R293 USB_OUTR
6 14 15 1u 6
+
1k
+
USB_INR VCOM VOUTR

22k NJM2100M open-c VCOM 1k 12k 3.9k NJM2100M 10u/16V
+
10u/16V PCM2904DBR open-c

R290 C278
C267 + C281
R287 1M
3300p
1u C268 C269 X200
22k
47u/16V 0.1u 12MHz 330p
R294
12k
C274 C275
18p 18p
B B
A A

ANALOG PCB(PCB-0165) USB Circuit
- 34 -
1 2 3 4 5 6 7 8

1 2 3 4 5 6 7 8
Q210A Q210B
1
12AX7 (with socket) 12AX7 (with socket)
2 7
Socket:GZC9-1B
4
9
5
3
D D
R275
TUBE-PCB 10k
C322
1
2
3
4
5
6
7
8
PCB-0166
CNB_ENG open-c
2.0T-1-8A(2mmP) +12VA C287
0.1u
8
IC213A 2 R297 10k
R307 1
100 3 R298 10k
NJM4558M C290
R296 C323
10k open-c
4
-12VA 0.1u
R327
100k
C318
R347
+12TUBEV 100k 470p
R331
220k -12VA C321
C292 R341 0.1u +12VA C288
4
C291 47k 1/4W C306 C307 C308 0.1u
8
open-c(chip) R328 3 C316
IC214A
C296 1 R316 R299 2
+
20k
open-c 0.022u film 0.022u film 0.022u film 2 1
+
NJM4558M 4.7k 47k

+12VA C283 C304 0.1u/50V 3
6
IC212A
0.1u 10u/16V C320 C289
8
NJM4558M
0.1u
3
R305
8
2 C299 22p
R333
4
1 7 CNA_ENGB R321 R312 +12VA 2 R308 -12VA 0.1u
22k
3 2.0T-1-8A(2mmP) 4.7k 47k open-r
7.5k
C C284 IC208A 0.1u film R311 +12VA C285 C314 C
NJM4558M 47k 0.1u
8
1
CNA_TONE-A
R345
4
-12VA 0.1u 2 6800p 2.0T-1-6A(2mmP)

1
8
VR203 1
+ C302 220k R325
R315 2 3 IC209A
open-c open-r C286
10k -B NJM4558M 12k
1
+ C312
3
-12TUBEV TC-655MH103 2 CNA_TUBE-A -12VA 0.1u 0.47u/50V

2.0T-1-6A(2mmP)
R322
3
from_ENGL 4.7k
from_ENGL R343
0
to_ENGL R334 R335
to_ENGL
7.5k 7.5k
from_ENGR
from_ENGR
to_ENGR
to_ENGR
R300
10k
C324
B B
open-c
+12VA +12TUBEV
R339
IC213B 6 R303
620 1/2W R309 7 10k
+ C295 5 R302
47u/16V 100
NJM4558M 10k
R301 C325
10k open-c R329
100k
-12VA -12TUBEV C319
R340
R348
620 1/2W
+12TUBEV 100k 470p
C297 R332
+ 47u/16V
220k
C294 R342
C293 47k 1/4W C309 C310 C311 IC214B
open-c(chip) R330 5 C317
C298 7 R320 R304 6
20k
+ IC212B
open-c 0.022u film 0.022u film 0.022u film 6 7
+
4.7k 47k
C305 0.1u/50V 5
1
NJM4558M
10u/16V NJM4558M
CNA_ENGA
R306 6 C300 2.0T-1-8A(2mmP) 22p
6
7 R336 2 R323 R314 C315 R310

22k
5 4.7k 47k 5 open-r
7.5k
IC208B 0.1u film R313
47k 6800p
NJM4558M
CNA_TONE-B
R346 R326
4
9
5
6 2.0T-1-6A(2mmP)
1
3
-12VA 220k 7 12k

+ C303 R317 2 5 IC209B
open-c open-r + C313
VR204 NJM4558M 0.47u/50V
4
TC-655MH103
3
-12TUBEV 5 CNA_TUBE-B
10k -B
2.0T-1-6A(2mmP)
A A
R324
6
R344 4.7k
0
R337 R338

7.5k 7.5k
ANALOG PCB(PCB-0165) TUBE Circuit

- 35 -
1 2 3 4 5 6 7 8

1 2 3 4 5 6 7 8
D D
L404
Q400 LQH55DN220M03 +5VD CN401A
2SA1213
1
22uH 2
R401
3
to MAIN PCB
IC402 0 C401
1 5 R402 + C403 3.96T-3-3A(3.96mmP)
C400 + ON/OFF VIN C402 D400
2 open-c 680 2200p 470u/16V
47u/16V VSS RB160L-40TE25
3 4
VOUT EXT
S-8520F50MC-BOJ-T2
C C
JP400
Jumper
D406
1 2
1N4003
IC400
TA7812S +12VA
1 3 JP401
Vin +12V
1
Jumper
GND
C409 C410
CN402B C411 + D408
D404
2 1 0.1u 0.1u 1N4003
from MAIN PCB 1 47u/16V
2 1N4003
2
+ C407
3.96T-3-2A(3.96mmP)
Board In 4700u/35V
B B
1
C416 D411
IC401 + C417 1N4003
0.1u 47u/16V
TA79012S -12VA
+ C413 1 3 JP402
GND -12V
2
Jumper
4700u/35V C415
Vin
D409
1 2 0.1u
L400
1N4003
2
0 D410
2 1
1N4003
A A

ANALOG PCB(PCB-0165) POWER Circuit
- 36 -
1 2 3 4 5 6 7 8

1 2 3 4
+12VA
C703
D D
RETURN C702
D700
1SS133(open)
8 0.1u CN603B
J700 R704 1
2 3 IC700A DRY_IN
1
R706 IC700B DRY_IN 2

10k 1 5
+
R708 3
3 2.2u/50V 2 10k 7 RETURN
4
1 NJM4558M 6 100
C701 R705 5
SJ6336 NJM4558M SEND+
6
2
10P 220k
7
4
C706 C732 SEND-
1
8
SW700A
9
+3.3VA SK22H09-G9 open-c RTN_DTC
10
0.1u
2.0T-1-10A(2mmP)
R747 -12VA R718 7.5k
47k R714 C705
R749
3
2
R715 0.01u-film
RTN_DTC 1k R748 5.1k 820 R716
0 open-r
C C
+3.3VA +3.3VA
R717 R720
R710 1.3k open-r to MAIN PCB
1
open-r
1SS133(open) D701
Q700 R711 R713
open-tr open-r 47k

2
C704
R712 DT700
1
R709 DTA124EKA +12VA

8.2k R729
D702 open-r C710 1500p Q701 3 1
1SS133(open) 2SC3326 4.7k
2
open-c
+12VA C712
IC701B
8
SEND- R722 6
2
7 3 0.1u C714
43k R727 J701 SEND_MUTE
SEND+ 5 1 2
+
B R725 B
2 IC701A 330 4
R721 C708 open-r NJM4558M R728 C715
43k NJM4558M 10u/16V
C713 10k 1500p 1
1500p
SJ6335
4
R723 C709
47k open-c C711 -12VA 0.1u
R724
8.2k SEND
47p R726
10k
4
SW700B
SK22H09-G9
A A
6
R730 R731
1M 2.4k
ANALOG PCB(PCB-0165) SEND/RETURN Circuit
- 37 -
1 2 3 4

1 2 3 4 5 6 7 8
+12VA
R732
2.2k 1/2W
+ C719 R736 R739

220u/16V 47k 1/4W 47k 1/4W
D TP5 D
ACC R751
open-r
C723
R750
+
6
open-r
IC702B 10u/16V
C733 C721
NJM4558M C738
5 C737 CNA_ACCB
+
7 R761 R737 7 10u/16V

2.0T-1-8A(2mmP)
+
10u/16V 0.022u film 6 15k 0
0.047u film
R757 C739 R752
1
47k 22k
open-c
8
CNA_ACCA R755 C736
C717 2.0T-1-8A(2mmP) 1M
R762 R753 2 R760
+
TO_ACC + C722 7.5k

22k 0 1500p +12VA C734
10u/16V 10u/16V 0.1u
8
F-095H5G A100K L15FC*7(M) R759
CNA_ACC_TUBEA 0 3
3
4
9
5
R763 R756 2.0T-1-6A(2mmP) 1

R740
3
4.7k -12VA 4.7k 2 2 IC702A

+ C707 C735 NJM4558M
open-c 47k
1
+ C720
4
C 2 open-c R766 -12VA 0.1u C
6
open-r 2 R738 R758

1
VR700 5 open-r open-r C724

R734 R735 2 R754 R768
3
47k TC-655MH103 open-r open-r F-095H5G A100K L15FC*7(M) R767 open-r VR702
3
CNA_ACC_TUBEB 0 TC-655MH103 22p
4
R764 VR704 2.0T-1-6A(2mmP) R769

R741
3
0 open-vr 0
R765
30k
-12VA
R733 open-r
2.2k 1/2W
C718
+ 220u/16V
C727
F-095H5N A10K L15FC*7 (M)
1
+
CNA_ACC_SOLID C728
2 R745
10u/16V
30k
+
2.0T-1-3A(2mmP) 10u/16V
3
B B
Q702A Q702B R744

1
12AX7 (with socket) 12AX7 (with socket)

30k
C730
2 7
C729 10p
Socket:GZC9-1B R742
2.4k +12VA C726
4
9
5
4700p 0.1u
8
3
6 R743 2
7 1 R746
15k FROM_ACC
5 IC703B 3 IC703A 100
NJM4558M NJM4558M
ACC-PCB
4
-12VA 0.1u
1
2
3
4
5
6
7
8
PCB-0167 C725
CNB_ACC
A 2.0T-1-8A(2mmP) A
D166 CIRCUIT DIAGRAM

ANALOG PCB(PCB-0165) ACC Circuit
- 38 -
1 2 3 4 5 6 7 8

1 2 3 4 5 6 7 8
D D
TO MAIN-PCB TO MAIN-PCB
CNB_FT17 CNB_LCD CNB_VR
PANEL1-PCB PANEL2-PCB
PEDAL SW L-PCB PCB-0154A PCB-0155A
PCB-0160A PEDAL SW R-PCB

PCB-0161A
C CNA_ACC_SOLID C
CNB_SWL CNB_SWR
CNB_FT11 CNB_FT12 CNB_TUBE CNB_TONE CNA_ACC_Tube
D166_PANEL
D166_PANEL.Sch TO MAIN-PCB
TO MAIN-PCB
CNB_ENC1 TO ANALOG-PCB
CNB_ENC2
ENCODER1-PCBA ENCODER2-PCB
PCB-0156A PCB-0157A
PHOTO Z-PCB
TO MAIN-PCB PHOTO Z PCB PCB-0164A
D166_PEDAL.SCH
CNB_PHZ
CNA_SWR
CNA_FT17 CNA_FT11 CNA_FT12
CNA_SWL CNA_PDLR
PHOTO L-PCB
PCB-0162A
PHOTO L PCB
FOOT SW 1-PCB CNA_PHZ PHOTO R-PCB
PEDAL.SCH PHOTO PCB PCB-0163A
PEDAL.SCH
PCB-0158A
CNB_PHL CNA_PHL CNB_FT1M CNA_PHR CNB_PHR
CNA_FT21
B B
D166_FOOT
D166_FOOT.SCH
TO MAIN-PCB
TO MAIN-PCB
CNB_FT21 CNB_FT2M
PEDAL-L FOOT SW 2-PCB PCB-0159A

PEDAL-R
D166_FOOT SW 2
D166_FOOT SW 2.SCH
A A

PANEL BLOCK
- 39 -
1 2 3 4 5 6 7 8

1 2 3 4 5 6 7 8
M-1
NT-C1622E-YTSNSY-B0 PANEL1-PCB PANEL2-PCB VR701B
F-095H5G A100K L15FC*7(M) VR201B VR202B
PCB-0154A PCB-0155A 4 6 F-095H5G A10K L15FC*7 (M) F-095H5G A5K L15FC*7 (M)
4 6 4 6
CW
LED+
LED-
VDD
R/W
DB0
DB1
DB2
DB3
DB4
DB5
DB6
DB7
VSS
CW
CW
VR703
V0
RS
F-095H5N A10K L15FC*7 (M)

To FOOT SW1-PCB
5
VR701A VR202A
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
9
5
CNB_FT17 F-095H5G-100K-A 1 3 VR201A
LED_COM0 1 3 F-095H5G A5K L15FC*7 (M)
10 F-095H5G A10K L15FC*7 (M)
LED_COM1 1 3 1 3
D 9 D
CW
7SEG_F
8
CW
CW
7SEG_A
7
7SEG_B
6
7SEG_DP M1
5
2
18
17
16
15
14
13
12
11
10
SEG1 7SEG_C
4
10
11
12
13
14
15
16
2
E20561-GFOR 7SEG_G 2.0T-1-16A(2mmP)
1
2
3
4
5
6
7
8
9
3
7SEG_D
2
com1
com2
1G
1A
2A
1F
2F
1B
2B
7SEG_E
1
1A 2A 2.0T-1-10A(2mmP)
Board In
1B
1
2
3
4
5
6
1
2
3
1
2
3
4
5
6
1
2
3
4
5
6
1F 2B
1G 2F 2G
CNB_ACC_TUBE CNB_ACC_SOLID CNB_TUBE CNB_TONE
DB0
DB1
DB2
DB3
DB4
DB5
DB6
DB7
1C
R510
1E 2C +3.3VD 2.0T-1-6A(2mmP) 2.0T-1-3A(2mmP) 2.0T-1-6A(2mmP) 2.0T-1-6A(2mmP)

2E Board In Board In Board In Board In
1SS133
1SS133
1SS133
1SS133
R500
R501
R502
R503
R504
R505
R506
R507
1D 1dp 2D 2dp
1
1
75
To MAIN-PCB
1dp
2dp
1D
2D
2G
1C
2C
1E
2E
F-095H5G A100K L15FC*7(M) F-095H5G A10K L15FC*7 (M) F-095H5G A5K L15FC*7 (M)
CNB_LCD
1k
1k
1k
1k
D514
D515
D516
D517
open-r
open-r
open-r
open-r
CNA_ACC_Tube CNA_TUBE CNA_TONE

12
1
2
3
4
5
6
7
8
9
LCD_D7 4 5 6 4 5 6 4 5 6
11
LCD_D6
10
LCD_D5
9
LCD_D4
8
1 2 3 1 2 3 1 2 3
7
LCD_E
6
LCD_R/W
5
LCD_RS
4
LCD_V0
3
+5VD LCD_VDD
2
DGND LCD_VSS
1
2.0T-1-12A(2mmP)
Board In
1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6
C C
LED30 LED14
CNB_ENC1
EC_TYPE_B R517 KSNR-312N-30 R524 3H4GX
11 51 1/8W 22 1/8W
EC_TYPE_A LED Red LED Green
10
EC_PARM1_B LED_COM2
9
EC_PARM1_A
8
EC_PARM2_B
7 AMP A AMP B
EC_PARM2_A
6
EC_PARM3_B SW_SCAN3
5
EC_PARM3_A SW12 SW13
4
EC_PARM4_B
3
EC_PARM4_A
2
EC_GND 1104RTA-2 1104RTA-2
1
A
A
B
2.0T-1-11A(2mmP) SW_DYN2
direct mounting SW DYN1
To MAIN-PCB
C
DGND CNB_ENC2 AVSS VR_AVSS CNB_VR

EC_AMP_B
SW30 SW31 SW32 SW33 SW34 3 8
EC_AMP_A To MAIN-PCB VR_GAIN
RE160-40E3 RE160-40E3 RE160-40E3 RE160-40E3 RE160-40E3 2 7
EC_GND2 VR_LEVEL
1 6
VR_BASS
TYPE PARM1 PARM2 PARM3 PARM4 5
2.0T-1-3AW(2mmP) side type VR_MIDDLE
4
VR_TREBLE
3
A
VR_PRESENCE
B
SW35 2
RE160-40E3 1
AVDD VR_AVDD
ENCODER1 PCB PCB-0156A AMP TYPE

2.0T-1-8A(2mmP)
Board In
2
2
C
1 3 1 3 1 3 1 3 1 3 1 3
VR1 VR3 VR5

F-095H5N B10K L15FC*7 (M) VR2 F-095H5N B10K L15FC*7 (M) VR4 F-095H5N B10K L15FC*7 (M) VR6
B F-095H5N B10K L15FC*7 (M) F-095H5N B10K L15FC*7 (M) F-095H5N B10K L15FC*7 (M) B
GAIN LEVEL BASS MIDDLE TREBLE PRESENCE
CNA_PN1 CNB_PN1
LED2 LED2
1 1
LED3 LED3
2 2
LED4 LED4
3 3
LED5 LED5 SW_DYN1
4 4
LED6 LED6
5 5
LED7 LED7
6 6
LED1
2.0T-1-6A(2mmP) 2.0T-1-6A(2mmP)
KSNR-312N-30 KSNR-312N-30 KSNR-312N-30 KSNR-312N-30 KSNR-312N-30 KSNR-312N-30 KSNR-312N-30 Board In 3A9RYGX-C 3A9RYGX-C 3A9RYGX-C 3A9RYGX-C 3A9RYGX-C 3A9RYGX-C 3A9RYGX-C 3A9RYGX-C 3A9RYGX-C 3A9RYGX-C 3A9RYGX-C
LED626 LED15 LED17 LED19 LED21 LED23 LED25 LED1 LED2 LED611 LED3 LED4 LED10 LED5 LED6 LED7 LED8 LED9
1 1 1 1 1 1 1 1 1 1 1
2 2 2 2 2 2 2 2 2 2 2
3 3 3 3 3 3 3 3 3 3 3
R620 R511 R512 R513 R514 R515 R516 R525 R526 R621 R527 R528 R529 R530 R531 R532 R533 R534
51 1/8W 51 1/8W 51 1/8W 51 1/8W 51 1/8W 51 1/8W 51 1/8W 33 1/8W 33 1/8W 33 1/8W 33 1/8W 33 1/8W 33 1/8W 33 1/8W 33 1/8W 33 1/8W 33 1/8W 33 1/8W
LED_COM4 R536 R537 R622 R538 R539 R540 R541 R542 R543 R544 R545
75 1/8W 75 1/8W 75 1/8W 75 1/8W 75 1/8W 75 1/8W 75 1/8W 75 1/8W 75 1/8W 75 1/8W 75 1/8W
PDL_SET_L SYSTEM BYPASS PAGE STORE EXIT PEDAL SET_R LED_COM7
SW_SCAN0 LED_COM6
SW_SCAN1 LED_COM3
SW618 SW5 SW15 SW17 SW16 SW19 SW20 LED_COM2
MOD COMP MOD WAH EXP LOOP MOD ZNR MOD AMP MOD EQ MOD CAB MOD MOD MOD DLY MOD REV MOD TOTAL
10
1
2
3
4
5
6
7
8
9
1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 SW_SCAN7

SW_SCAN6
CNB_FT11 SW_SCAN3
2.0T-1-10A(2mmP) SW_SCAN2
Board In SW1 SW2 SW614 SW6 SW9 SW4 SW7 SW10 SW8 SW11 SW3
To FOOT SW1-PCB
CNA_PN2 CNB_PN2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2
SW_DYN0 SW_DYN0
1 1
SW_DYN1 SW_DYN1
2 2
SW_DYN2 SW_DYN2
3 3
A SW_DYN3 SW_DYN3 A
4 4
2.0T-1-4A(2mmP) 2.0T-1-4A(2mmP)
Board In
G9.tt CIRCUIT DIAGRAM

10
11
12
1
2
3
4
5
6
7
8
9
CNB_FT12
PANEL PCB(PCB-0154A) PANEL Circuit
2.0T-1-12A(2mmP) Board In
To FOOT SW1-PCB - 40 -
1 2 3 4 5 6 7 8

1 2 3 4 5 6 7 8
D To PANEL-PCB To PANEL-PCB D
CNA_FT11
2.0T-1-10A(2mmP) CNA_FT12
2.0T-1-12A(2mmP)
10
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
To PANEL-PCB (7seg)
SW_DYN0
SW_DYN1
SW_DYN2
SW_DYN3
CNA_FT17
SW_SCAN7
SW_SCAN6
SW_SCAN3
SW_SCAN2
LED_COM0 LED_COM7
LED_COM6
LED_COM3
LED_COM2
10
LED_COM1
LED_COM4
SW_SCAN1
SW_SCAN0
9
LED1
LED2
LED3
LED4
LED5
LED6
LED7
7SEG_F R547 220 1/8W

8
7SEG_A R548 220 1/8W
7
7SEG_B R549 220 1/8W
6
7SEG_DP R550 220 1/8W
5
7SEG_C R551 220 1/8W
4
7SEG_G R552 220 1/8W
3
7SEG_D R553 220 1/8W
2
7SEG_E R554 220 1/8W
1
2.0T-1-10A(2mmP)
+LEDV
LED7
LED6 LED_COM7 3 2
LED5
LED4
LED3 DT507
LED2 BCR553
LED1 D507 SW_DYN1
LED0 SW_SCAN7 2 1 /SCAN7
1
KSNR-312N-30 KSNR-312N-30 3A9RYGX-C 3A9RYGX-C LED_COM6 1SS133 3 2 LED_COM5 R509 Q1
LED27 LED29 LED12 LED613 10k 1/8W BC817-40
1 1 CNA_SWR
2 2 DT506 R560 SW_PEDAL_R
BCR553 47k 1/8W 1
3 3
R518 R519 R535 R623 2
D506
51 1/8W 51 1/8W 33 1/8W 33 1/8W SW_SCAN6 2 1 1 /SCAN6 2.0T-1-2A(2mmP)
C R546 R624 Board In C
75 1/8W 75 1/8W LED_COM3 LED_COM5 1SS133 3 2 +LEDV
LED_COM7 R508
LED_COM5 47k 1/8W
DT505
BCR553 SW_DYN0
BANK DN BANK UP CH A/B TAP D505
SW_SCAN5 SW_SCAN5 2 1 /SCAN5
R626
1
LED_COM5 Q600
1SS133 BC817-40
SW22 SW24 SW26 SW628 10k 1/8W
LED_COM4 3 2 CNA_SWL
R634 SW_PEDAL_L
47k 1/8W 1
1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 DT504 2
SW_DYN3
SW_DYN2 BCR553 2.0T-1-2A(2mmP)
Board In
/SCAN4 +LEDV
R627
1
LED_COM3 3 2 47k 1/8W
DT503
1
2
3
4
5
6
7
8
9
+LEDV = +3.3VD
BCR553
CNA_FT21 100u/16V(open) To MAIN-PCB
2.0T-1-9A(2mmP) D503
SW_SCAN3 2 1 /SCAN3 C500
1
Board In CNB_FT1M
+
to FOOT SW2 PCB LED_COM2 1SS133 3 2

24
SW_DYN3
23
SW_DYN2
DT502 22
SW_DYN1
BCR553 21
SW_DYN0
20
D502 19
SW_SCAN2 2 1 /SCAN2 LED7
18
1
LED6
1SS133 3 17
LED_COM1 2 LED5
16
LED4
15
LED3
DT501 14
LED2
BCR553 13
LED1
12
B D501 LED0 B
11
SW_SCAN1 2 1 /SCAN1
10
1
/SCAN7
1SS133 3 9
to FOOT SW1 PCB LED_COM0 2 /SCAN6
8
/SCAN5
7
CNB_FT21 /SCAN4
DT500 6
2.0T-1-9AW(2mmP) side type
FOOT SW2 PCB PCB-0159A BCR553
/SCAN3
/SCAN2
5
4
D500 /SCAN1
3
SW_SCAN0 2 1 /SCAN0 /SCAN0
1
2
3
4
5
6
7
8
9
2
1
1SS133 1
11311124-12420000
KSNR-312N-30 KSNR-312N-30 KSNR-312N-30 KSNR-312N-30 KSNR-312N-30

LED16 LED18 LED20 LED22 LED624
R520 51 1/8W R521 51 1/8W R522 51 1/8W R523 51 1/8W R625 51 1/8W
To MAIN-PCB
FSW1 FSW2 FSW3 FSW4 FSW5 DGND CNB_FT2M
SW21 SW23 SW25 SW27 SW629 1
SW_STC7
2
SW_STC6
3
1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 1104RTA-2 SW_STC5
4
SW_STC4
5
SW_STC3
6
SW_STC2
7
SW_STC1
8
A 2.0T-1-8AW(2mmP) side type A

Board In

FOOT SW1 PCB(PCB-0158A) FOOT SW1 Circuit
- 41 -
1 2 3 4 5 6 7 8
D166/G9.2tt FOOT SW1 PCB(PCB-0158A) FOOT SW1 Circuit 1/2

1 2 3 4 5 6 7 8
C503
500ohm-B AVDD
VR500
TC-655MH501 AVDD open-c
D R559 10u/16V(open) D
2
C501
R555 110k 1/8W +
500ohm-B CNA_PHR 1 3 R558 To MAIN-PCB
VR600 110k 1/8W IC500B CNA_PDLR
1 330 1/8W
TC-655MH501 AVDD 6
2 1
7
2
C620 3 2
AVDD 5
R628 R630 3
CNA_PHL 1 3 2.0T-1-3A(2mmP)
110k 1/8W open-c 4
330 1/8W Board In AVSS NJM2100M
1 R631 10u/16V(open) 5
2 C621
AVDD 110k 1/8W AVSS 2.0T-1-5A(2mmP)
3 + To MAIN-PCB Board In
2.0T-1-3A(2mmP) CNA_PDLL AVDD
Board In AVSS R629 6 IC602B
10k 1/8W 1
7
2 R556
5
3 10k 1/8W
C622 NJM2100M
+ 2.0T-1-3A(2mmP)
R632 C627
10k 1/8W open-c open-c Board In
AVDD C623 AVSS C504 +
R557
open-c
10k 1/8W C624
AVSS
8
0.1u open-c
2 IC602A AVSS
1
3 C625
C NJM2100M C
open-c
R637
4
500ohm-B AVDD
AVSS AVSS VR601 0
AVDD TC-655MH501 AVDD
AVDD 10u/16V(open)
2
CNA_PHZ C626
R633 1 3 +
8
1 R636
2 330 1/8W open-r R638 IC500A
2
3 R639
open-r 1
4
3 open-r
2.0T-1-4A(2mmP) R635
22k 1/8W NJM2100M
Board In AVSS C502
4
AVSS AVSS
AVSS 0.1u
JP601
Jumper
SW600
CNB_SWL
1 SW500
1104RTA-2 CNB_SWR
2
1
2.0T-1-2A(2mmP) 1104RTA-2
2
B B
2.0T-1-2A(2mmP)
PEDAL SW_L PCB PCB-0160A

PEDAL SW_R PCB PCB-0161A
IC603
IC604 IC501 CNB_PHZ 4 1
CNB_PHL 4 1 CNB_PHR 4 1
1 JP600 3 2
1 1 2
3 2 3 2 Jumper
2 2 3
3 3 4 GP2S40J
NJL5167KB NJL5167KB
2.0T-1-3A(2mmP) 2.0T-1-3A(2mmP) 2.0T-1-4A(2mmP) direct mounting
PHOTO_L PCB PCB-0162A PHOTO_R PCB PCB-0163A PCB-0164A

A A

FOOT SW1 PCB(PCB-0158A) PEDAL Circuit
- 42 -
1 2 3 4 5 6 7 8

No. Parts name SPECIFICATIONS Qty
1 Z-PEDAL RUBBER Z2D-0060 1
2 Z-PEDAL PIN Z2A-0115 1
3 Z-PEDAL BASE 1 Z2B-0214 1
4 Z-PEDAL GUIDE PLATE 1 Z2B-0220-B 1
5 SCREW F3.0x4 ,BLACK chromate ,Flat head 8
6 Z-PEDAL BLAKE Z2B-0222 1
7 Z-PEDAL GUIDE PLATE 2 Z2B-0221 3
8 Z-PEDAL LOCK CAM 2 Z2B-0217 1
9 E-RING D5.0 3
10 G7.1ut SCREW M4.0X5.0,BLACK chromate, no head 6
11 Z-PEDAL LOCK CAM 1 Z2B-0216 1
12 Z-PEDAL POLE Z2A-0114 1
13 Z-PEDAL BASE 2 Z2B-0215 1
14 SCREW M4.0x8L, Black Chromate, HEXAGON SOCKET HEAD 3
15 EX-PEDAL SPRING Z2A-0123 3
16 GFX-3 CUSHION RUBBER Z2D-0042-A4 7
17 PLAIN WASHER d6.0xd3.2xt0.5 7
18 SCREW M3.0x8L,S-TIGHT, Black Chromate 24
19 G7.1ut EX PEDAL BRACKET Z2B-0210 2
20 G7.1ut EX PEDAL BRACKET PLATE Z2A-0100 2
21 G7.1ut EX PEDAL SPACER Z2B-0212 4
22 G7.1ut EX PEDAL GUIDE Z2A-0095 2
23 SCREW M3.0X9L, Black Chromate 1
24 G7.1ut FOOT SW DRESS PLATE Z2B-0206 9
25 G7.1ut VR KNOB 2 Z2B-0200 4
26 G9.2tt ROUND SPACER 3.5-12 1
27 TAPE SCREWS M3x22L,S-TIGHT 1
28 VR KNOB 2 Z2B-0161 6
29 G7.1ut ENCODER KNOB 2 Z2B-0201 5
30 G7.1ut EX PEDAL RUBBER Z2D-0058 1
31 G7.1ut EX PEDAL BASE Z2B-0211 1
32 G9.2tt MACHINE BAR Z2A-0110 1
33 CUSHION EX-PEDAL Z2D-0062 1
34 G7.1ut DISPLAY COVER Z2B-0205 1
35 G7.1ut SIDE COVER L Z2B-0203 1
36 G9.2tt SIDE BRACKET_LEFT Z2A-0124 1
37 SCREW M3x8L,P-TIGHT 24
38 G7.1ut REFLECT BRACKET Z2B-0207-A 2
39 PHOTO L PCB PCB-0162A 1
40 SPRING WASHER d5.2xd3.2xt1.0 12
41 VR KNOB 1 Z2B-0160 1
42 G9.2tt TOP CASE Z2A-0108 1
43 POWER SW R9D2KKFT00F1-G 1
44 G7.1ut CORD HOOK Z2B-0209 1
45 SCREW M2.6x5L,P-TIGHT 4
46 PLAIN WASHER d=14.0xd=8.5xt=0.5 4
47 G7.1ut SHIELD CASE Z2A-0105 1
48 G7.1ut PCB SPACER HP-13.5 2
49 G7.1ut VR KNOB 3 Z2B-0202 1
50 PEDAL SW-L PCB PCB-0160A 1
51 G7.1ut EX PEDAL BUTTON Z2B-0208 2
52 G7.1ut EX BUTTON PAD Z2D-0059 2
53 G9.2tt TUBE BRACKET A Z2A-0111 2
54 G7.1ut SWITCH BUTTON A Z2B-0195 20
55 CUSHION Z-PEDAL 1 Z2D-0063 1
56 PANEL1 PCB PCB-0154A 1
57 G7.1ut SPACER SUPPORT 2 MADM-2 7
58 G9.2tt ROUD SPACER 3-2 3
59 PANEL2 PCB PCB-0155A 1
60 G9.2tt rubber pad Z2D-0061 2
61 G9.2tt copper support Z2A-0122 2
62 G9.2tt Shield plate Z2A-0121 1
63 ACC TUBE PCB PCB-0167 1
64 G9.2tt ZM_SP_02 Z2B-0224 3
65 G7.1ut THREAD SPACER HP_12A 3
66 SPACER d=10.0 t=0.1 2
67 NUT M3.0,black 4
68 SCREW M3.0X12L, Black Chromate 4
69 G9.2tt HEAT SINK Z2A-0113 1
70 G9.2tt ZM_SP_01 Z2B-0223 3
71 MAIN PCB PCB-0151 1
72 G7.1ut AC BRACKET Z2A-0096 1
73 ANALOG PCB PCB-0165 1
74 G9.2tt TUBE COVER B Z2A-0120 1
75 G9.2tt BOTTOM PLATE Z2A-0109 1
76 SCREW D3.0X5L, S-TIGHT, Black Chromate 55
77 TAPE SCREWS M3.0X6LCOMMON HEAD, black Chromate 11
78 G9.2tt TUBE COVER A Z2A-0119 1
79 TUBE PCB PCB-0166 1
80 PEDAL SW-R PCB PCB-161A 1
81 FOOT SW 1 PCB PCB-0158A 1
82 G7.1ut LED SPACER SUPPORT 2 LED3-16 1
83 FOOT SW 2 PCB PCB-0159A 1
84 G7.1ut LED SPACER SUPPORT 1 LED-16 8
85 G7.1ut FOOT SW BRACKET Z2A-0093 2
86 FOOT SW UNIT Z2A-0089 9
87 G9.2tt FOOT SW BRACKET 2 Z2A-0116 1
88 SCREW M2.6x4L,P-TIGHT,Black Chromate 20
89 TAPE SCREW M3x8L B-TIGHT , Black Chromate 4
90 G7.1ut SIDE COVER R Z2B-0204 1
91 G7.1ut SIDE BRACKET_RIGHT Z2A-0099 1
92 Z-PEDAL REFLECT BRACKET COVER Z2B-0225-A 1
93 PHOTO_Z PCB PCB-0164A 1
94 Z-PEDAL REFLECT BRACKET Z2B-0219-A 1
95 G7.1ut EX PEDAL POLE Z2A-0101 2
Exploded View 96
97
98
G9.2tt TUBE SP BRACKET
G7.1ut DISPLAY SHEET
SCREW
Z2A-0112
Z2E-0214
M3.0X14L P_TIGHT, Black Chromate
1
1
2
99 FOOT RUBBER B Z2D-0040-A4 10
100 PLAIN WASHER d6.6xd3.2xt1.0 24
101 CUSHION Z-PEDAL 2 Z2D-0064 1
- 43 - 102
103
REFLECT SEAL
PHOTO R PCB
Z2E-5032-A4
PCB-0163A
3
1
104 ENCODER 1 PCB PCB-0156A 1
105 ENCODER 2 PCB PCB-0157A 1

ELECTRONIC PARTS LIST
Parts List
Main PCB : PCB-0151
No. NAME SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
1 MPU UPD703015BGC-A32-8EU-A LQFP-100pin Mask ROM IC1 1
2 DSP ZFX-3 QFP-176pin 0.5-26X26 IC2 1
3 Flash Memory M29W400DT55N6E TSOP-48pin 12x20mm IC3 1
ES29LV400DT-70RTG TSOP-48pin 12x20mm IC3 0
4 SDRAM EM636165TS-7G TSOP-50pin IC4 1
IS42S16100C１-７TL TSOP-50pin IC4 0
5 AD/DA AK4552VT-E2 TSSOP-16pin IC15 IC601 2
6 Logic IC SN74LVU04ANS SOP-14pin IC12 1
7 Logic IC SN74LV32ANS SOP-14pin IC23 1
11 Logic IC SN74LV541ANS SOP-20pin IC20 IC21 2
14 OPAMP NJM2100M-TE1 SOP-8pin IC13 1
15 Voltage Regulator XC6209F12AP SOT89-5 1.26V IC26 1
16 Voltage Regulator uPC2933BT1D TO-252 IC25 1
uPC29M33AT-E1 SC63 IC25 0
uPC2933BT SC63 IC25 0
17 Reset-IC R3112Q291A-TR SC82 2.9V IC5 1
XC6109N29ANRW SC82 2.9V IC5 0
18 Photo Coupler PC900VONSZX DIP-6pin IC403 1
19 Digital Tr MUN5211DW1T1G SC88 DT1 DT400 2
UMH11N SC88 DT1 DT400 0
20 Diode 1SS133T-77 Pitch=7.5mm D412 D600 D601 D602 D603 5
21 X'tal HC49S3 20MHz X1 1
22 X'tal HC49S3 24.576MHz X4 1
23 X'tal(Unmounting) open X3 0
24 Inductor BL02RN2-R62 L407 L408 2
L4 L401 L402 L403 L405
25 Chip Inductor BLM18AG102SN1 1608(0603) 6
L406
26 Capacitor 2.2u/50V D=4.0mm H=7.0-11.5mm Pitch=5mm C94 C614 2
C82 C84 C85 C86 C87
27 Capacitor 10u/16V D=4.0mm H=7.0-11.5mm Pitch=5mm C90 C600 C602 C603 C604 11
C607
28 Capacitor 47u/6.3V D=4.0mm H=7.0-11.5mm Pitch=5mm C100 C116 C120 3
C68 C69 C88 C117 C122
29 Capacitor 100u/6.3V D=4.0mm H=7.0-11.5mm Pitch=5mm 6
C605
30 Capacitor(Unmounting) open-c D=4.0mm H=7.0-11.5mm Pitch=5mm C134 C423 0
31 Chip Capacitor 15p-J CH 50V (25V) 1608(0603) C70 C71 C77 C78 4
32 Chip Capacitor 33p-J CH 50V (25V) 1608(0603) C101 1
33 Chip Capacitor 100p-J CH 50V (25V) 1608(0603) C83 1
34 Chip Capacitor 470p-J CH 50V (25V) 1608(0603) C73 C74 2
C96 C97 C418 C419 C615
35 Chip Capacitor 1000p-K B 50V (25V) 1608(0603) 6
C616
C1 C2 C3 C4 C5
36 Chip Capacitor 0.01u-K B 16V 1608(0603) C6 C7 C8 C9 C10 11
C11
C102 C103 C104 C105 C106
37 Chip Capacitor 0.039u-K B 16V 1608(0603) C107 C108 C109 C110 C111 12
C112 C113
C14 C15 C16 C17 C18

C19 C20 C21 C22 C23
C24 C25 C26 C27 C28
C29 C30 C31 C32 C33
C34 C35 C36 C37 C38
38 Chip Capacitor 0.1u-Z F 25V 1608(0603) C39 C40 C41 C42 C43 54
C44 C45 C46 C47 C48
C49 C50 C54 C55 C59
C60 C61 C62 C63 C64
C65 C67 C420 C421 C422
C608 C609 C610 C611
39 Chip Capacitor GRM188B11A105KA61D (1.0u-K B) 1608(0603) C118 C119 2

40 Chip Capacitor(Unmounting) open-c 1608(0603) C72 C80 C81 0
41 Resistor 33-J 1/2W Lead-form: Floated type pitch=10mm R410 R411 R412 3
R2 R64 R65 R66 R67
42 Chip Resister 0 1608(0603) R68 R76 R79 R80 R180 13
R193 L6 L7
43 Chip Resister(Unmounting) 0(open) 1608(0603) R181 R182 0
44 Chip Resister 10-J 1608(0603) R90 R615 2
45 Chip Resister 100-J 1608(0603) R92 R614 2
46 Chip Resister 220-J 1608(0603) R85 1
47 Chip Resistor 270-J 1608(0603) R415 1
48 Chip Resistor 750-J 1608(0603) R94 1
R3 R45 R46 R47 R48
49 Chip Resister 1k-J 1608(0603) R49 R50 R51 R52 R53 15
R54 R55 R56 R602 R603
R21 R96 R97 R98 R99
50 Chip Resister 2.2k-J 1608(0603) R100 R101 R102 R103 R104 15
R105 R106 R107 R408 R409
51 Chip Resister 3.9k-J 1608(0603) R7 1
52 Chip Resister 5.1k-J 1608(0603) R59 1
53 Chip Resister 10k-J 1608(0603) R1 R4 R5 R6 4
R108 R109 R110 R111 R112
54 Chip Resister 22k-J 1608(0603) R113 R114 R115 R116 R117 12
R118 R119
R8 R9 R11 R12 R13
R14 R15 R19 R20 R22
R23 R24 R25 R26 R28
55 Chip Resister 47k-J 1608(0603) 30
R32 R33 R34 R35 R36
R61 R62 R63 R186 R189
R190 R191 R192 R612 R613
56 Chip Resister 1M-J 1608(0603) R83 1
57 Chip Resister 13k-F 1608(0603) R87 1
- 44 -
61 Chip Resister(Unmounting) open-r 1608(0603) R38 R40 R27 R37 0
RA1 RA2 RA3 RA4 RA5
62 Resister Network 47k-J*4 RAC1608 4Element 7
RA7 RA8
63 Resister Network(Unmounting) open-r RAC1608 4Element RA6 0
64 POWER SW R9D2KKFT00F1-G Panel mounting (43) SW400 1
65 DC Power Jack TDC-040H-2 J400 1
HEC0740-010618 J400 0
66 MIDI CONNECTOR SW2-5-20A J401 1
YKF51-5048 DIN 5pin J401 0
67 Connector 3.96T-3-2A 3.96mm pitch 2pin CN400 CN402A 2
68 Connector 3.96T-3-3A 3.96mm pitch 3pin CN401B 1
69 Connector 2.0T-1-3A 2mm pitch 3pin CNB_PDLL 1
70 Connector 2.0T-1-5A 2mm pitch 5pin CNB_PDLR 1
71 Connector 2.0T-1-6A 2mm pitch 6pin CN8A 1
73 Connector 2.0T-1-8A 2mm pitch 8pin CNA_VR CNA_FT2M 2
75 Connector 2.0T-1-12A 2mm pitch 12pin CNB_LCD 1
76 Connector 2.0T-1-14A 2mm pitch 14pin CNA_ENC 1
77 FPC Connector 1.0S-12-24P 1mm pitch FFC CNA_FT1M 1
CN24P (1mmP) 52030-2429 1mm pitch FFC CNA_FT1M 0
78 Connector(Unmounting) open-cn CNB_EXP CN_ROM1 CN_ROM2 0
79 Harness ZH-0074-1: 3.96mm pitch 2pin L=55mm to Power Switch AWG18 CN400- POWER SW 1
80 Harness ZH-0074-4: 3.96mm pitch 3pin L=150mm to Analog PCB AWG22 CN401A-CN401B 1
81 Jumper(Unmounting) JP6 0
82 PCB PCB-0151 FR-4 4layer 113x95mm (71) 1
PANEL1 PCB : PCB-0154A

1 LCD Module NT-C1622E-YTSNSY-B0 M1 1
2 Diode 1SS133T-77 Pitch=7.5mm D514 D515 D516 D517 4
3 7SEG LED E20561-GFOR DIP-18pin SEG1 1
E2651-GFOR DIP-18pin SEG1 0
4 LED KSNR-312N-30 Radial 7
LED25 LED626
R511 R512 R513 R514 R515
5 Resister 51-J 1/8W Pitch=7.5mm 7
R516 R620
6 Chip Resister 75-J 1608(0603) R510 1
7 Chip Resister 1k-J 1608(0603) R504 R505 R506 R507 4
8 Chip Resister(Unmounting) open 1608(0603) R500 R501 R502 R503 0
SW5 SW15 SW16 SW17 SW19
9 TACT SW 1104RTA-2 7
SW20 SW618
10 CONNECTOR 2.0T-1-16A 2.0mm pitch 16pin M1 1
11 CONNECTOR 2.0T-1-4A 2.0mm pitch 4pin CNB_PN2 1
12 CONNECTOR 2.0T-1-6A 2.0mm pitch 6pin CNB_PN1 1
13 Harness ZH-0074-21: 2mm pitch 10pin L=100mm to FOOT1 SW PCB Flat Cable , Board In CNA_FT11-CNB_FT11 1
15 Harness ZH-0074-24: 2mm pitch 12pin L=160mm to MAIN PCB Flat Cable , Board In CNA_LCD-CNB_LCD 1
JP001 JP002 JP003 JP004 JP005
16 Jumper wire Pitch=7.65mm 7
JP006 JP028
17 Jumper wire Pitch=10mm JP205 1
18 PCB PCB-0154A FR-1 149 x 106.5mm (56) 1

1 LED KSNR-312N-30 Radial LED30 1
2 LED 3H4GX LED14 1
3 LED 3A9RYGX-C LED6 LED7 LED8 LED9 LED10 11
LED611
SPR-39MVW LED6 LED7 LED8 LED9 LED10 0
LED611
4 Resister 22-J 1/8W Pitch=7.5mm R524 1
R525 R526 R527 R528 R529
5 Resister 33-J 1/8W Pitch=7.5mm R530 R531 R532 R533 R534 11
R621
6 Resister 51-J 1/8W Pitch=7.5mm R517 1
R536 R537 R538 R539 R540
R622
SW1 SW2 SW3 SW4 SW6
8 TACT SW 1104RTA-2 SW7 SW8 SW9 SW10 SW11 13
SW12 SW13 SW614
VR1 VR2 VR3 VR4 VR5
9 Potentionmeter F-095H5N B10K L15FC*7 (M) 10k-B single vertical 6
VR6
VR1 VR2 VR3 VR4 VR5
RK09L114-F15-C0-B103 10k-B single vertical 0
VR6
VR1 VR2 VR3 VR4 VR5
RD901-40E 10K-B L=15 10k-B single vertical 0
VR6
10 Potentionmeter F-095H5G A10K L15FC*7 (M) 10k-A dual vertical VR201 1
RK9L12D-F15-C0-A103 10k-A dual vertical VR201 0
11 Potentionmeter F-095H5G A5K L15FC*7 (M) 5k-A dual vertical VR202 1
RK9L12D-F15-C0-A502 5k-A dual vertical VR202 0
12 Potentionmeter F-095H5N A10K L15FC*7 (M) 10k-A single vertical VR703 1
13 Potentionmeter F-095H5G A100K L15FC*7(M) 100k-A dual vertical VR701 1
14 CONNECTOR 2.0T-1-3A 2.0mm pitch 3pin CNB_ACC_SOLID 1
15 Harness ZH-0074-8: 2mm pitch 4pin L=130mm to PANEL 1 PCB Flat Cable , Board In CNA_PN2-CNB_PN2 1
16 Harness ZH-0074-12: 2mm pitch 6pin L=100mm to PANEL 1 PCB Flat Cable , Board In CNA_PN1-CNB_PN1 1
17 Harness ZH-0074-5: 2mm pitch 3pin L=80mm to Analog PCB Flat Cable CNA_ACC_SOLID-CNB_ACC_SOLID 1
CNA_TUBE-CNB_TUBE CNA_TONE-
18 Harness ZH-0074-11: 2mm pitch 6pin L=80mm to Analog PCB Flat Cable , Board In 2
CNB TONE
20 Harness ZH-0074-13: 2mm pitch 6pin L=80mm to Analog PCB Flat Cable , Board In CNA_ACC_TUBE-CNB_ACC_TUBE 1
21 Harness ZH-0074-17: 2mm pitch 8pin L=210mm to MAIN PCB Flat Cable , Board In CNA_VR-CNB_VR 1
JP007 JP008 JP009 JP010 JP011
JP012 JP013 JP014 JP015 JP016
22 Jumper wire Pitch=7.65mm JP017 JP018 JP019 JP020 JP021 21
JP022 JP023 JP024 JP025 JP026
JP027
23 Jumper wire Pitch=7.65mm JP200 JP201 JP202 JP203 JP204 5
24 PCB PCB-0155A Part of PANEL1 PCB (59) 1
- 45 -
ENCODER 1 PCB : PCB-0156A
1 Rotary Encoder RE160-40E3-15A-24P-017 16mm Vertical type with Nut/Washer SW30 SW31 SW32 SW33 SW34 5
REB161PVB15FHINA1-2-24PCE 16mm Vertical type with Nut/Washer SW30 SW31 SW32 SW33 SW34 0
2 CONNECTOR 2.0T-1-11A 2.0mm pitch 11pin CNB_ENC1 0
to MAIN PCB and ENCODER2 PCB(Two-way Harness)
3 Harness ZH-0074-25: 2mm pitch 14pin L=250mm CNA_ENC-CNB_ENC1/CNB_ENC2 1
AWG22 Board In (Encoder 1 PCB only)
4 PCB PCB-0156A FR-1 130 x 34mm (104) 1

1 Rotary Encoder RE160-40E3-15A-24P-017 16mm Vertical type with Nut/Washer SW35 1
REB161PVB15FHINA1-2-24PCE 16mm Vertical type with Nut/Washer SW35 0
2 CONNECTOR 2.0T-1-3AW 2.0mm pitch 3pin Side type CNB_ENC2 1
3 PCB PCB-0157A Part of ENCODER 1 PCB (105) 1
FOOT SW 1 PCB : PCB-0158A

1 IC NJM2100M-TE1 SOP-8pin IC500 IC602 2
DT500 DT501 DT502 DT503 DT504
2 Digital Tr BCR553 SC59 8
DT505 DT506 DT507
DT500 DT501 DT502 DT503 DT504
DTB123EKT146 SC59 0
DT505 DT506 DT507
3 Transistor BC817-40 SC59 Q1 Q600 2
2SC1623 SC59 Q1 Q600 0
BC817-40LT1G SC59 Q1 Q600 0
D500 D501 D502 D503 D505
4 Diode 1SS133T-77 Pitch=7.5mm 7
D506 D507
5 LED KSNR-312N-30 Radial LED27 LED29 2
6 LED 3A9RYGX-C LED12 LED613 2
SPR-39MVW LED12 LED613 0
7 Capacitor(Unmounting) open-c D=4.0mm H=7.0-11.5mm Pitch=5mm C625 C627 0
8 Capacitor(Unmounting) 10u/16V(open) D=4.0mm H=7.0-11.5mm Pitch=5mm C501 C621 C624 C626 0
9 Capacitor(Unmounting) 100u/16V(open) D=4.0mm H=7.0-11.5mm Pitch=5mm C500 0
10 Chip Capacitor 0.1u-Z F (25V) 1608(0603) C502 C623 2
11 Chip Capacitor(Unmounting) open-c 1608(0603) C503 C504 C620 C622 0
12 Resistor 0 Pitch=7.5mm R637 1
13 Resister 33-J 1/8W Pitch=7.5mm R535 R623 2
R547 R548 R549 R550 R551
16 Resister 220-J 1/8W Pitch=7.5mm 8
R552 R553 R554
17 Resister 330-J 1/8W Pitch=7.5mm R555 R628 R633 3
R509 R556 R557 R626 R629
18 Resister 10k-J 1/8W Pitch=7.5mm 6
R632
19 Resister 22k-J 1/8W Pitch=7.5mm R635 1
20 Resister 47k-J 1/8W Pitch=7.5mm R508 R560 R627 R634 4
21 Resister 110k-J 1/8W Pitch=7.5mm R558 R559 R630 R631 4
22 Resister(Unmounting) open-r Pitch=7.5mm R636 R638 R639 0
23 Trimmer potentiometer TC-655MH501 500-B VR500 VR600 VR601 3
24 TACT SW 1104RTA-2 SW22 SW24 SW26 SW628 4
25 CONNECTOR 2.0T-1-10A 2.0mm pitch 10pin CNA_FT11 CNA_FT17 2
25 CONNECTOR 2.0T-1-12A 2.0mm pitch 12pin CNA_FT12 1
26 FPC CONNECTOR 11311124-12420000 1mm pitch 24pin FFC side type CNB_FT1M 1
52807-2410 1mm pitch 24pin FFC side type CNB_FT1M 0
27 CONNECTOR 2.0T-1-2A 2.0mm pitch 2pin CNB_SWL CNB_SWR 2
28 CONNECTOR 2.0T-1-3A 2.0mm pitch 3pin CNB_PHL CNB_PHR 2
29 CONNECTOR 2.0T-1-4A 2.0mm pitch 4pin CNB_PHZ 1
30 Harness ZH-0074-7: 2mm pitch 3pin L=320mm to MAIN PCB Flat Cable , Board In CNA_PDLL-CNB_PDLL 1
31 Harness ZH-0074-10: 2mm pitch 5pin L=340mm to MAIN PCB Flat Cable , Board In CNA_PDLR-CNB_PDLR 1
33 FPC Cable ZH-0074-26: 1mm pitch 24pin L=120mm to MAIN PCB 1mm pitch FFC Cable CNA_FT1M-CNB_FT1M 1
JP001 JP002 JP003 JP004 JP005
JP006 JP007 JP008 JP009 JP010
JP011 JP012 JP013 JP014 JP015
34 Jumper wire Pitch=7.65mm 28
JP016 JP017 JP018 JP019 JP020
JP021 JP022 JP023 JP024 JP025
JP026 JP027 JP601
JP100 JP101 JP102 JP103 JP104
35 Jumper wire Pitch=10mm 6
JP105
36 Jumper wire Pitch=15mm JP300 JP301 JP302 JP303 JP304 5
37 Jumper wire Pitch=25mm JP400 1
38 PCB PCB-0158A FR-1 379 x 44mm (81) 1

1 LED KSNR-312N-30 Radial LED16 LED18 LED20 LED22 LED624 5
3 TACT SW 1104RTA-2 SW21 SW23 SW25 SW27 SW629 5
4 CONNECTOR 2.0T-1-9AW 2.0mm pitch 9pin Side type CNB_FT21 1
5 Harness ZH-0074-18: 2mm pitch 8pin L=220mm to MAIN PCB Flat Cable , Board In CNA_FT2M-CNB_FT2M 1
6 PCB PCB-0159A Part of FOOT SW 1 PCB (83) 1
PEDAL SW-L PCB : PCB-0160A

1 TACT SW 1104RTA-2 SW600 1
2 Harness ZH-0074-3: 2mm pitch 2pin L=200mm to FOOT SW 1PCB Flat Cable, Board In CNA_SWL-CNB_SWL 1
3 PCB PCB-0160A FR-1 52 x 30mm (50) 1
PEDAL SW-R PCB : PCB-0161A

1 TACT SW 1104RTA-2 SW500 1
2 Harness ZH-0074-3: 2mm pitch 2pin L=200mm to FOOT SW 1 PCB Flat Cable, Board In CNA_SWR-CNB_SWR 1
3 PCB PCB-0161A Part of PEDAL SW-L PCB (80) 1
PHOTO L PCB : PCB-0162A

1 Photo Reflector NJL5167KB DIP-4pin NJL5167K IC604 1
2 Harness ZH-0074-6: 2mm pitch 3pin L=150mm to FOOT SW 1 PCB Flat Cable, Board In CNA_PHL-CNB_PHL 1
PHOTO-R PCB : PCB-0163A

1 Photo Reflector NJL5167KB DIP-4pin NJL5167K IC501 1
2 Harness ZH-0074-6: 2mm pitch 3pin L=150mm to FOOT SW 1 PCB Flat Cable, Board In CNA_PHR-CNB_PHR 1
PHOTO Z PCB : PCB-0164A

1 Photo Reflector GP2S40J0000F DIP-4pin IC603 1
2 Harness ZH-0074-9: 2mm pitch 4pin L=250mm to FOOT SW 1 PCB Flat Cable, Direct mounting CNA_PHZ-CNB_PHZ 1
3 Jumper wire Pitch=7.65mm JP600 1
4 PCB PCB-0164A Part of FOOT SW 1 PCB (93) 1
- 46 -
ANALOG PCB : PCB-0165
1 USB CODEC PCM2904DBR SSOP-28pin IC210 1
2 OPAMP NJM4556M SOP-8pin IC205 1
IC200 IC201 IC202 IC203 IC204
3 OPAMP NJM4558M SOP-8pin IC208 IC209 IC212 IC213 IC214 14
IC700 IC701 IC702 IC703
4 OPAMP NJM2100M SOP-8pin IC206 IC207 2
5 Voltage Regulator XC6213B332MR SOT23-5 IC211 1
6 Voltage Regulator TA7812S TO220 insulated IC400 1
uPC7812AHF TO220 insulated IC400 0
7 Voltage Regulator TA79012S TO220 insulated IC401 1
uPC7912AHF TO220 insulated IC401 0
8 Voltage Regulator S-8520F50MC-BOJ-T2 SOT-23-5 IC402 1
Q200 Q201 Q202 Q203 Q204
9 Transistor 2SC3326 SC59 Q205 Q206 Q207 Q208 Q209 12
Q211 Q701
10 Transistor 2SA1213 SC62 Q400 1
2SB1571 SC62 Q400 0
11 Transistor BC807-40 SC59 Q212 1
12 Transistor(Unmounting) open-tr SC59 Q700 0
13 Digital Tr DTA124EKA SC59 DT200 DT700 2
14 Digital Tr DTA124TKA SC59 DT201 0
15 Digital Tr MUN5112DW1T1G SC88 DT202 DT203 2
XP04112 SC88 DT202 DT203 0
UMB1N SC88A DT202 DT203 0
16 Chip Shottky Diode RB160L-40TE25 PMDS SOD-106 D201 D400 2
MBRS130LT3 D201 D400 0
MBRS140T3 D201 D400 0
D404 D406 D408 D409 D410
17 Diode 1N4003 Pitch=7.5mm 6
D411
18 Diode 1SS133T-77 Pitch=7.5mm D204 1
19 Diode(Unmounting) 1SS133T-77(open) Pitch=7.5mm D200 D700 D701 D702 0
20 Crystal Oscillator HC49S3 12MHz X200 1
HC49/U 12MHz X200 0
21 Inductor LQH55DN220M03(22uH) 5.7x5.0x4.7mm pitch SMT L404 1
CDRH5D28R-220 6.2x6.3 4.6mm pitch SMT L404 0
22 Chip Inductor BLM18AG102SN1 1608(0603) L200 1
25 Capacitor 2.2u/50V D=4.0mm H=7.0-11.5mm Pitch=5mm C702 1
C210 C214 C215 C219 C220
C224 C226 C227 C232 C234
C235 C237 C238 C243 C246
26 Capacitor 10u/16V D=4.0_5.0mm H=7.0_11.5mm Pitch=5mm C247 C254 C259 C263 C264 32
C266 C282 C296 C298 C714
C717 C722 C723 C727 C728
C733 C738
C248 C268 C297 C400 C411
27 Capacitor 47u/16V D=4.0_5.0mm H=7.0_11.5mm Pitch=5mm 7
C417 C295
28 Capacitor 100u/6.3V D=4.0_6.3mm H=7.0_11.5mm Pitch=5mm C326 1
29 Capacitor 220u/16V D=4.0_5.0mm H=7.0_11.5mm Pitch=5mm C718 C719 2
30 Capacitor 470u/16V D=4.0_8.0mm H=7.0_11.5mm Pitch=5mm C242 C251 C403 3
31 Capacitor 4700u/35V D=18.0mm H=35.5mm Pitch=10mm C407 C413 2
C202 C256 C260 C265 C276
32 Capacitor(Unmounting) open-c D=4.0_6.3mm H=7.0_11.5mm Pitch=5mm 0
C302 C303 C707 C720 C739
33 Film Capacitor 0.01u-k B/63V Radial Pitch=5mm C705 1
C306 C307 C308 C309 C310
34 Film Capacitor 0.022u-k B/63V Radial Pitch=5mm 7
C311 C721
35 Film Capacitor 0.047u-k B/63V Radial Pitch=5mm C737 1
36 Film Capacitor 0.1u-k B/63V Radial Pitch=5mm C201 C299 C300 3
37 Chip Capacitor 10p-k B 1608(0603) C200 C229 C231 C701 C730 5
38 Chip Capacitor 18p-k B 1608(0603) C274 C275 2
39 Chip Capacitor 22p-k B 1608(0603) C304 C305 C700 C724 4
40 Chip Capacitor 47p-k B 1608(0603) C221 C239 C711 3
C209 C230 C225 C245 C704
43 Chip Capacitor 1500p-k B 1608(0603) 10
C708 C715 C279 C280 C736
44 Chip Capacitor 2200p-k B 1608(0603) C402 1
46 Chip Capacitor 4700p-k B 1608(0603) C729 1
48 Chip Capacitor 0.01u-k B 1608(0603) C244 C252 2
C203 C205 C207 C208 C212
C213 C217 C218 C222 C223
C240 C241 C253 C255 C257
C258 C262 C269 C283 C284
49 Chip Capacitor 0.1u-Z F 1608(0603) 40
C285 C286 C287 C288 C289
C290 C320 C321 C409 C410
C415 C416 C703 C706 C712
C713 C725 C726 C734 C735
C204 C206 C211 C216 C228

C233 C236 C249 C250 C401
50 Chip Capacitor(Unmounting) open-c 1608(0603) C291 C292 C293 C294 C322 0
C323 C324 C325 C709 C710
C732
51 Chip Capacitor GRM188B11A105KA61D (1u-k B) 1608(0603) C267 C270 C271 C272 C273 5
52 Resistor 620-J 1/2W Lead-form pitch=10mm R339 R340 2
53 Resistor 2.2k-J 1/2W Lead-form pitch=10mm R732 R733 2
54 Resistor 47-J 1/4W Lead-form pitch=10mm R259 R273 2
55 Resistor 47k-J 1/4W Lead-form pitch=10mm R341 R342 R736 R739 4
R343 R344 R401 R748 R759
56 Chip Resistor 0 1608(0603) L400 R753 R764 R767 R769 11
R737
57 Chip Resistor 22-J 1608(0603) R288 R289 2
R207 R222 R236 R237 R241
58 Chip Resistor 100-J 1608(0603) R242 R250 R307 R309 R702 12
R708 R746
59 Chip Resistor 330-J 1608(0603) R352 R226 R261 R727 4
60 Chip Resistor 620-J 1608(0603) R201 R268 2
61 Chip Resistor 680-J 1608(0603) R402 1
62 Chip Resistor 820-J 1608(0603) R715 1
R215 R216 R217 R218 R243
R244 R245 R246 R251 R260
63 Chip Resistor 1k-J 1608(0603) 18
R263 R264 R274 R281 R285
R291 R295 R749
64 Chip Resistor 1.3k-J 1608(0603) R717 1
- 47 -
66 Chip Resistor 2.4k-J 1608(0603) R224 R257 R731 R742 4
67 Chip Resistor 3.9k-J 1608(0603) R283 R293 2
R229 R230 R321 R322 R323
68 Chip Resistor 4.7k-J 1608(0603) R324 R276 R277 R316 R320 13
R729 R756 R763
R333 R334 R335 R336 R337
70 Chip Resistor 7.5k-J 1608(0603) 8
R338 R718 R760
71 Chip Resistor 8.2k-J 1608(0603) R210 R232 R712 R724 4
R202 R225 R227 R253 R258
R262 R269 R270 R271 R272
72 Chip Resistor 10k-J 1608(0603) R275 R296 R297 R298 R300 22
R301 R302 R303 R704 R706
R726 R728
R282 R284 R292 R294 R325
R326
74 Chip Resistor 13k-J 1608(0603) R219 R220 R247 R248 4
R204 R206 R212 R213 R214
R743 R761
76 Chip Resistor 20k-J 1608(0603) R328 R330 2
R209 R231 R278 R279 R286
R762
R233 R235 R701 R741 R744
R745
R211 R223 R228 R234 R252
R254 R265 R299 R304 R311
80 Chip Resistor 47k-J 1608(0603) 19
R312 R313 R314 R713 R723
R734 R747 R757 R740
R327 R329 R347 R348 R255
81 Chip Resistor 100k-J 1608(0603) 6
R256
82 Chip Resistor 180k-J 1608(0603) R700 1
84 Chip Resistor 1M-J 1608(0603) R203 R290 R730 R755 4
R200 R205 R208 R266 R267
R308 R310 R315 R317 R349
R350 R351 R354 R357 R709
85 Chip Resistor(Unmounting) open-r 1608(0603) 0
R710 R711 R716 R720 R725
R738 R751 R758 R735 R750
R754 R765 R766 R768
86 Volume F-095V5G A10K L15FC*7 (M) 10k-A dual horizontal VR200 1
87 Trimmer potentiometer TC-655MH103 10k-B VR203 VR204 VR702 VR700 4
RH0411C14J 10k-B VR203 VR204 VR702 0
88 Trimmer potentiometer(Unmounting) open-vr VR704 0
89 Slide SW SK22H09-G9 SW200 SW700 2
MCS-222N-1010 SW200 SW700 0
HSW2022-010020 Length of lever=9mm SW200 SW700 0
90 Stereo Mini Jack SJ-3507-5P with nut J201 1
91 Phone Jack SJ6335 J200 J202 J203 J701 4
92 Stereo Phone Jack SJ6336 J204 J700 2
93 USB Connector 57112201-2110000 J205 1
YKF45-0023 J205 0
94 Connector 3.96T-3-3A 3.96mm pitch 3pin CN401A 1
95 Connector 2.0T-1-3A 2mm pitch 3pin CNA_ACC_SOLID 1
CN8B CNA_TUBE CNA-TONE
96 Connector 2.0T-1-6A 2mm pitch 6pin 4
CNA ACC TUBE
97 Connector 2.0T-1-7A 2mm pitch 7pin CN7B 1
98 Connector 2.0T-1-8A 2mm pitch 8pin CNA_ENG CNA_ACC 2
99 Connector 2.0T-1-10A 2mm pitch 10pin CN603B 1
100 Harness ZH-0074-2: 3.96mm pitch 2pin L=380mm to MAIN PCB AWG18 , board in CN402A-CN402B 1
101 Harness ZH-0074-14: 2mm pitch 6pin L=220mm to MAIN PCB Flat Cable CN8A-CN8B 1
102 Harness ZH-0074-15: 2mm pitch 7pin L=200mm to MAIN PCB Flat Cable CN7B-CN7A 1
103 Harness ZH-0074-27: 2mm pitch 10pin L=185mm to MAIN PCB Flat Cable CN603A-CN603B 1
104 Jumper wire Pitch=5mm JP400 JP401 JP402 3
105 PCB PCB-0165 FR-4 2layer 284 x 100mm (73) 1
TUBE PCB : PCB-0166

1 TUBE 12AX7 MT9 Q210 1
12AX7WA MT9 Q210 0
2 TUBE SOCKET GZC9-1B PCB mounting Q210 1
3 Connector 2.0T-1-8A 2mm pitch 8pin CNB_ENG 1
4 Harness ZH-0074-19: 2mm pitch 8pin L=60mm to Analog PCB Flat Cable CNA_ENG-CNB-ENG 1
5 PCB PCB-0166 Part of ANALOG PCB (79) 1
ACC TUBE PCB : PCB-0167

1 TUBE 12AX7 MT9 Q702 1
12AX7WA MT9 Q702 0
2 TUBE SOCKET GZC9-1B PCB mounting for Q702 Q702 1
3 Connector 2.0T-1-8A 2mm pitch 8pin CNB_ACC 1
4 Harness ZH-0074-16: 2mm pitch 8pin L=60mm to Analog PCB Flat Cable CNA_ACC-CNB-ACC 1
5 PCB PCB-0167 Part of ANALOG PCB (63) 1
- 48 -
MECHANICAL PARTS LIST
No. PART NAME SPECIFICATIONS DESCRIPTION REFELENCE NO. Q'TY
1 G9.2tt TOP CASE Z2A-0108 SECC, T=1.20MM (42) Painted: black with a little silver 1
2 G9.2tt BOTTOM PLATE Z2A-0109 SECC, T=1.20MM (75) Painted: black 1
(54) SWITCH BUTTON SINGLE
3 G7.1ut SWITCH BUTTON A Z2B-0195 ABS(SMOKE CLEAR) 20
Side painted:black
4 VR KNOB 1 Z2B-0160 ABS (41) Chromium coatings 1
(28) Chromium coatings ,
5 VR KNOB 2 Z2B-0161 ABS 6
with Point mark (Color: black)
(25) KNOB _black_piont,
6 G7.1ut VR KNOB 2 Z2B-0200 ABS 4
with indicator (color: red)
7 G7.1ut ENCODER KNOB 2 Z2B-0201 ABS (29) KNOB _black_no_piont, black 5
8 G7.1ut VR KNOB 3 Z2B-0202 ABS (49) level_KNOB, black, with indicator (color: red) 1
9 G7.1ut SIDE COVER L Z2B-0203 ABS+TPE/PPU,black (35) 1
10 G7.1ut SIDE COVER R Z2B-0204 ABS+TPE/PPU,black (90) 1
11 G7.1ut DISPLAY COVER Z2B-0205 ABS,Chromium plated (34) 1
12 G7.1ut DISPLAY SHEET Z2E-0214 PC, with adhesive, t=1.0mm (97) silk print :3 colors 1
13 G7.1ut FOOT SW BRACKET Z2A-0093 SECC, T=1.00MM (85) TO SURPORT THE TOP CASE 2
(87) TO FIX THE PCB TO THE TOP CASE
14 G9.2tt FOOT SW BRACKET 2 Z2A-0116 SECC, T=1.00MM 1
under the shield plate (1/2)
15 FOOT RUBBER B Z2D-0040-A4 D1 ,NR RUBBER 3mmTH'K (99) with adhesive tape/ 40mmX15mmX3mmXR1 10
16 G7.1ut EX PEDAL GUIDE Z2A-0095 SECC, T=1.6MM (22) PAINTED BLACK 1
17 G7.1ut AC BARCKET Z2A-0096 SGCC,T=1.0 (72) 1
18 FOOT SW UNIT Z2A-0089 (86) 9
19 G7.1ut FOOT SW DRESS PLATE Z2B-0206 ABS,Chromium plated (24) 9
20 G7.1ut EX PEDAL BASE Z2B-0211 ADC12 (31) Painted silver color 1
21 G7.1ut EX PEDAL RUBBER Z2D-0058 TPE, black (30) 1
22 G7.1ut EX PEDAL POLE Z2A-0101 45#,Chromium plated (95) 1
23 G7.1ut REFLECT BRACKET Z2B-0207-A ABS. black (38) EX-PEDAL & Z-PEDAL 2
24 G9.2tt TUBE BRACKET A Z2A-0111 SECC. T=1.0 (53) 2
25 G9.2tt TUBE SP BRACKET Z2A-0112 SECC. T=1.0 (96) 1
26 G9.2tt MACHINE BAR Z2A-0110 AL, SHINING SURFACE (32) 1
27 G9.2tt SIDE BRACKET_LEFT Z2A-0124 SECC. T=1.20MM (36) 1
28 G7.1ut SIDE BRACKET_RIGHT Z2A-0099 SECC. T=1.20MM (91) 1
(102) for PHOTO REFLECTOR
29 REFLECT SEAL Z2E-5032-A4 10x10x0.05mm EX-PEDAL & Z-PEDAL 3
(16), (17) for EX PEDAL(on-off cushion)
GFX3 CUSHION RUBBER Z2D-0042-A4 KH-3 65(BLACK)
30 With washer 4
31 G7.1ut EX PEDAL BUTTON Z2B-0208 ABS, BLACK. (51) EX-PEDAL & Z-PEDAL 2
32 G7.1ut CORD HOOK Z2B-0209 ABS, BLACK. (44) 1
33 G7.1ut EX PEADAL BRACKET Z2B-0210 POM (19) 1
34 G7.1ut EX PEDAL BRACKET PLATE Z2A-0100 SECC, T=1.20MM (20) 1
35 G7.1ut EX BUTTON PAD Z2D-0059 sponge,black,T=3.0, Hardness=55 (52) EX-PEDAL & Z-PEDAL 2
36 G7.1ut SHIELD CASE Z2A-0105 SGCC t=0.5mm (47) 1
37 G7.1ut EX PEDAL SPACER Z2B-0212 POM (21) 2
38 G7.1ut LED SPACER SUPPORT 1 LED-16 NYLON (84) 8
39 G7.1ut LED SPACER SUPPORT 2 LED3-16 NYLON (82) 1
40 G7.1ut THREAD SPACER HP_12A NYLON (65) 3
41 G9.2tt ROUD SPACER 3-2 NYLON (58) 3
42 G7.1ut SPACER SUPPORT 2 MADM-2 NYLON (57) 7
43 G7.1ut foil oil 0132 1
M3.0X6LCOMMON (77) fix the plastic support -THREAD SPACER(4)
44 TAPE SCREWS SWCH(Fe), Black Chromate 8
HEAD,black ex pedal pcbX4
45 SCREW M3.0X12L SWCH(Fe), Black Chromate (68) assemble the sub_panel pcb and panel pcbx4,heat sinkx2 4
46 SCREW M3.0X14L P_TIGHT SWCH(Fe), Black Chromate, fix The ZM-SP_01/02 (98) 3
47 NUT M3.0,black SWCH(Fe), Black Chromate (67) assemble the sub panel pcb and panel pcbx2,heatsinkx2 4
(76) fix the bottom+all bracket(12),top case+bottom(8),
side cover+top case(8),tube bracket(6),
48 SCREW D3.0X5L, S-TIGHT SWCH(Fe), Black Chromate ft sw pcb+ft sw bracket(9),top case+penel pcb(2) 55
panel pcb+copper(1)
ac/dc(1),,fix the machine bar(8)
(18) fix the bottom to the side cover(6).
the tube bracket B+panel pcb(1).
49 SCREW M3.0x8L,S-TIGHT SWCH(Fe), Black Chromate 13
Fix the ex_pedal to the top casex4,cord hook(1),
reflect bracket+pcb(1)
50 SCREW M2.6x5L,P-TIGHT SWCH(Fe),Black Chromate (45) FIX THE DISPLAY COVERX4 4
51 SCREW M2.6x4L,P-TIGHT SWCH(Fe),Black Chromate (88) dress plate x18,display cover x2,machine bar x6 20
52 PLAIN WASHER d6.6xd3.2xt1.0 SWCH(Fe),Black Chromate (100) dress plate x18,,display cover x4 22
53 SPRING WASHER d5.2xd3.2xt1.0 SWCH(Fe),Black Chromate (40) ex_bracketx4 , machine barx2,z_pedalx4,heatsinkx2 12
Z2B-0032, no head
54 G7.1ut SCREW SWCH(Fe),Black Chromate (10) 2
M4.0X5.0,BLACK,
M4.0x8L, HEXAGON,
55 SCREW SWCH(Fe),Black Chromate (14) EX_BRACKET 1
SOCKET HEAD
(37) REFLECT BRACKET X2, MIDI JACKX2
56 SCREW M3.0x8L,P-TIGHT SWCH(Fe),Black Chromate 24
SIDE COVER RIGHT/LEFT+BRACKETX14,ZM-SPX6
57 G7.1ut PCB SPACER HP-13.5 NYLON (48) 2
58 G9.2tt HEATSINK Z2A-0113 al. 5052 (69) 135x60mm T=2mm alminium 1
59 G9.2ut ZM_SP_01 Z2B-0223 POM (70) 3
60 G9.2ut ZM_SP_02 Z2B-0224 POM (64) 3
61 G9.2tt TUBE COVER A Z2A-0119 SGCC (78) 1
62 G9.2tt TUBE COVER B Z2A-0120 SGCC (74) 1
63 G9.2tt Shield plate Z2A-0121 SGCC (62) T=0.5mm 1
64 G9.2tt rubber pad Z2D-0061 rubber (60) 15x10x3, with single side hesive tape. 2
65 G9.2tt copper support Z2A-0122 copper (61) d=6.0, M3.0 THR.H=7.0 2
66 G9.2tt ROUND SPACER 3.5-12 nylon (26) 1
67 TAPE SCREWS M3x22L,S-TIGHT SWCH(Fe), Black Chromate ,Cross Binding Head, (27) fix the main pcb and ft pcb support 1
68 SCREW M3.0X9L SWCH(Fe), Black Chromate (23) fix the copper and the panel pcb, 1
69 EX-PEDAL SPRING Z2A-0123 (15) d=0.4,L=7.0,D=5.2 3
70 TAPE SCREW M3x8L B-TIGHT SWCH(Fe), Black Chromate B-TIGHT (89) FLAT HEAD M3x8L 4
71 SCREW F3.0x4,S-TIGHT SWCH(Fe), Black Chromate (5) 2
72 PLAIN WASHER d=14.0xd=8.5xt=0.5 SWCH(Fe) (46) EX-PEDALX4 4
73 SPACER d=10.0 t=0.1 PAPER with adhesive (66) When EX-PEDAL & Z-PEDAL are adjusted, it uses it. 2
74 FILAMENT TAPE tape 3M 8915 Scotch 8915 Filament Tape, 12mm width, L=60mm 1
75 Glue For EX PEDAL RUBBER SL518 1
76 CUSHION EX-PEDAL Z2D-0062 sponge,black, 40x20 t=10.0 , Hardness=40 (33) 1
- 49 -

Z-PEDAL MECHANICAL PARTS LIST
No. PART NAME DROWING NO MATERIAL DESCRIPTION Q'TY
1 Z-PEDAL BASE 1 Z2B-0214 ADC12 (3) Painted silver color 1
2 Z-PEDAL BASE 2 Z2B-0215 ADC12 (13) Painted silver color 1
3 Z-PEDAL LOCK CAM 1 Z2B-0216 ADC-12 (11) 1
4 Z-PEDAL LOCK CAM 2 Z2B-0217 ADC-12 (8) 1
5 Z-PEDAL RUBBER Z2D-0060 TPE, black (1) 1
6 Z-PEDAL REFLECT BRACKET Z2B-0219 ABS,BLACK (94) 1
7 Z-PEDAL GUIDE PLATE 1 Z2B-0220 POM (4) 1
8 Z-PEDAL GUIDE PLATE 2 Z2B-0221 POM (7) 3
9 Z-PEDAL BLAKE Z2B-0222 POM (6) 1
10 Z-PEDAL POLE Z2A-0114 45#,Chromium plated (12) 1
11 Z-PEDAL PIN Z2A-0115 SUS (2) 1
12 G7.1ut EX PEDAL GUIDE Z2A-0095 SECC, T=1.6MM (22) PAINTED BLACK 1
13 G7.1ut EX PEDAL POLE Z2A-0101 45#,Chromium plated (95) 1
14 G7.1ut EX PEADAL BRACKET Z2B-0210 POM (19) 1
15 G7.1ut EX PEDAL BRACKET PLATE Z2A-0100 SECC, T=1.20MM (20) 1
(16), (17) for EX PEDAL(on-off cushion)
16
GFX-3 CUSHION RUBBER Z2D-0042-A4 KH-3 65(BLACK) With washer 3
17 G7.1ut EX PEDAL SPACER Z2B-0212 POM (21) 2
18 SCREW M3.0X8L,S-TIGHT SWCH(Fe), Black Chromate (18) fix GFX-3_CUSHION_RUBBER 3
19 SCREW M3.0x8L,P-TIGHT SWCH(Fe), Black Chromate S-TIGHT (37) PHOTO PCB 2
20 SCREW F3.0x4,S-TIGHT SWCH(Fe), Black Chromate, FLAT-HEAD (5) 6
Z2B-0032, D5.0,
21 E-RING M4.0X5.0,BLACK, 5mm,white nickel plated (9)fix poles and the pin 3
no head,
Z2B-0032, no head
22 G7.1ut SCREW SWCH(Fe),Black Chromate (10) fix poles 4
M4.0X5.0,BLACK,
M4.0x8L,
23 SCREW HEXAGON, SOCKET SWCH(Fe),Black Chromate (14) EX_BRACKET 1
HEAD
24 G7.1ut foil oil O132 1
25 PLAIN WASHER d=14.0xd=8.5xt=0.5 SWCH(Fe) (46) Z-PEDALX4 4
26 Glue For Z PEDAL RUBBER SL518 1
27 CUSHION Z-PEDAL 1 Z2D-0063 sponge,black, 40x20 T=5.0 , Hardness=40 (55) 1
28 CUSHION Z-PEDAL 2 Z2D-0064 sponge,black, 30x20 T=5.0 , Hardness=40 (101) 1
29 Z-PEDAL REFLECT BRACKET COVER Z2B-0225-A ABS (92) 1
PACKING PARTS LIST

No. PART NAME DRAWING NO MATERIAL DESCRIPTION Q'TY(US)
1 G9.2tt Gift Box Z2F-0044 corrugated cardboard. 1
Corrugated Spacer-1
2 corrugated cardboard. 2
(package_sub_card_R)
Corrugated Spacer-2
(package_adaptor_card)
Corrugated Spacer-3
(package_side_card)
Corrugated Spacer-4
(package_spacer_01)
Corrugated Spacer-5
(package_spacer_02)
Corrugated Spacer-6
(package_top_card)
8 G9.2tt MASTER Carton Box Z2F-0045 W corrugated cardboard. 0.5
9 Poly Bag for Unit 1
10 Poly Bag for Manual 200X300mm (for A5 size) 1
11 Serial Label for Carton Box Z2E-0192 0.5
12 Serial Label for Unit Z2E-0193 2.00
13 Bar-Code Label 1.5
14 USA Bar-Code Label 2
15 FCC Label Aluminum label 1
16 Destination Label Z2E-0194 0.5
17 G9.2tt Operation Manual G9.2tt-5010-1 paper of fine quality A5 80page Japanese 0
18 G9.2tt Operation Manual G9.2tt-5000-1 paper of fine quality A5 80page English 1
19 G9.2tt Operation Manual G9.2tt-5002-1 paper of fine quality A5 80page German 0
20 G9.2tt Operation Manual G9.2tt-5003-1 paper of fine quality A5 80page French 0
21 G9.2tt Operation Manual G9.2tt-5004-1 paper of fine quality A5 80page Italian 0
22 G9.2tt Operation Manual G9.2tt-5005-1 paper of fine quality A5 80page Spanish 0
23 Warranty Card US Stamp: model name for US Japanese 0
24 G9.2tt Patch List Sheet Z2I-0659 A3-->A5: folded A3 in three English 1
25 G9.2tt Patch List Sheet Z2I-0660 A3-->A5: folded A3 in three Japanese 0
26 G9.2tt Modeling Description Z2I-0664 A3-->A5: folded A3 in three English 1
27 G9.2tt Modeling Description Z2I-0665 A3-->A5: folded A3 in three Japanese 0
28 DAW Starting Manual A3-->A5: folded A3 in three 2nd edition English 1
29 DAW Starting Manual A3-->A5: folded A3 in three 2nd edition 1
30 Bundled CD with CD case (material: paper) 1
31 OS information seal for GIFT BOX Z2E-0207 2nd edition 1
32 AC Adaptor AD-0012A with gift box 100JP 0
33 AC Adaptor AD-0012D with gift box 120US / 120GL 1
34 AC Adaptor AD-0012E with gift box 220BX 0
35 AC Adaptor AD-0012F with gift box 240UK 0
36 AC Adaptor AD-0012G with gift box 240GL 0
37 Green label corresponds to a WEEE mark. below φ30mm 1
38 WEEE mark label Z2I-0679 for UNIT 1
39 WEEE explanation sheet A5 one-side printing 1
40 Pedal adjustment supplemental sheet A3-->A5: folded A3 in three Both-sides printing 1
- 50 -

Spare Parts Order List
ELECTRONIC PARTS LIST The parts with ''*'' are available from G9.2tt.
Main PCB : PCB-0151
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen )
MICRO PROCESSOR
SP02146 MPU UPD703015BGC-A32-8EU-A G7.1ut 1 570
SIGNAL PROCESSOR
SP02033 DSP ZFX-3 G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 1530
MEMORY
SP02147 Flash Memory M29W400DT55N6E G7.1ut 1 510
SP02148 SDRAM EM636165TS-7G G7.1ut 1 190
A/D,D/A CONVERTER
SP00878 AD/DA Converter AK4552VT-E2 G7.1ut, G2, G2.1u, MRS-8, MRS-802, MRS-1608 etc 1 510
DIGITAL IC
SP00063 Logic IC SN74LVU04ANS(Same as TC74VHCU04) G7.1ut, GFX-3, 504II, 505II, 506II, RFX-300 etc 1 40
SP02149 Logic IC SN74LV32ANS G7.1ut 1 30
SP00052 Logic IC SN74LV4040ANS(Same as 74HC4040F) G7.1ut, GFX-3, FIRE-30, 707II, 708II, MRS-1044 etc 1 70
SP02037 Reset-IC R3112Q291A-TR G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 40
SP02154 Photo Coupler PC900VONSZX G7.1ut 1 150
ANALOG
SP00071 OPAMP NJM2100M-TE1 G7.1ut, G2, G2.1u, GFX-1, GFX-3, MRS-8, 707II etc 1 50
POWER SUPPLY
SP02155 Voltage Regulator XC6209F12AP G7.1ut 1 40
SP01945 Voltage Regulator uPC2933BT1D (same as uPC29M33AT-E1) G7.1ut, G2, G2.1u, GFX-1, GFX-3 1 90
TRANSISTOR
SP00112 Digital Tr MUN5211DW1T1G (Same as UMH11N) G7.1ut, MRS-4, MRS-8, PS-02, MRS-1608 etc 5 150
DIODE
SP00352 Diode 1SS133T-77 G7.1ut, G2, G2.1u, GFX-3, GFX-5, MRS-1608 etc 5 100
OSCILLATOR
SP02157 X'tal HC49S3 20MHz G7.1ut 1 70
SP02042 X'tal HC49S3 24.576MHz G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 70
INDUCTOR
SP00135 Inductor BL02RN2-R62 (Same as BL02RN-2R62) G7.1ut, MRS-4, MRS-8, PS-04, MRS-1608 etc 1 30
SP01762 Chip Inductor BLM18AG102SN1 G7.1ut, G2, G2.1u, MRS-8 10 200
RESISTOR
SP00740 Resister Network 47k-J*4 G7.1ut, G2, G2.1u, GFX-5, PS-02, MRS-1608 etc 10 200
JACK, SOCKET
SP00565 DC Power Jack TDC-040H-2 (Same as HEC0740-010618) G7.1ut, GFX-4, GFX-8, RFX-1000, RFX-2000 1 90
SP00895 MIDI CONNECTOR SW2-5-20A (Same as YKF51-5048) G7.1ut, MRS-1044, MRS-1266, MRS-802, MRS-1608 1 130
OTHER PARTS
SP02160 POWER SW R9D2KKFT00F1-G G7.1ut 1 80
SP02161 Connector 3.96T-3-2A(Same as B2P-VH) G7.1ut 1 10
SP02162 Connector 3.96T-3-3A(Same as B3P-VH) G7.1ut 1 20
SP02006 Connector 2.0T-1-3A (Same as B3B-PHKS and JS-1125-3) G7.1ut, G2, G2.1u, GFX-3 1 30
* SP02270 Connector 2.0T-1-5A 1 10
SP01425 Connector 2.0T-1-6A (Same as B6B-PHKS) G7.1ut, MRS-802 1 50
SP02163 Connector 2.0T-1-7A (Same as B7B-PHKS) G7.1ut 1 70
SP02165 FPC Connector 1.0S-12-24P G7.1ut 1 60
* SP02271 Harness ZH-0074-1: 3.96mm pitch 2pin L=55mm 1 40

LCD Module
SP02169 LCD Module NT-C1622E-YTSNSY-B0 (Old type : Green) G7.1ut 1 820
SP02827 LCD Module NT-C1622G-BTSNSW-B0 (New type : Blue) G7.1ut 1 1060
DIODE
DISPLAY DEVICE
SP02046 7SEG LED E20561-GFOR G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 90
SP02049 LED KSNR-312N-30 G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 5 50
SWITCH
SP01949 TACT SW 1104RTA-2 G7.1ut, G2, G2.1u, GFX-1, GFX-3 10 100
OTHER PARTS
SP01952 CONNECTOR 2.0T-1-4A (Same as JS-1125R-4) GFX-1 1 30
SP01425 CONNECTOR 2.0T-1-6A (Same as B6B-PHKS) G7.1ut, MRS-802 1 50
SP02175 CONNECTOR 2.0T-1-16A (Same as B16B-PHKS) G7.1ut 1 20
* SP02273 Harness ZH-0074-21: 2mm pitch 10pin L=100mm 1 80
SP02179 Harness ZH-0074-22: 2mm pitch 10pin L=185mm(Same as ZH-0073-16) G7.1ut 1 90

DISPLAY DEVICE
SP02170 LED 3H4GX G7.1ut 5 20
SP02171 LED 3A9RYGX-C G7.1ut 5 50
SWITCH
POTENTIOMETER
SP02172 Potentionmeter F-095H5N B10K L15FC*7 (M) G7.1ut 1 140
SP02173 Potentionmeter F-095H5G A10K L15FC*7 (M) G7.1ut 1 140
SP02174 Potentionmeter F-095H5G A5K L15FC*7 (M) G7.1ut 1 140
* SP02275 Potentionmeter F-095H5N A10K L15FC*7 (M) 1 140
* SP02276 Potentionmeter F-095H5G A100K L15FC*7(M) 1 140
OTHER PARTS
SP02006 CONNECTOR 2.0T-1-3A (Same as JS1125-3) GFX-3 1 30
* SP02280 Harness ZH-0074-11: 2mm pitch 6pin L=80mm (Same as ZH-0074-13) 1 50
- 51 -
RE160-40E3-15A-24P-017
SP01435 Rotary Encoder G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 250
(same as REB161PVB15FHINA1-2-24PCE)

RE160-40E3-15A-24P-017
SP01435 Rotary Encoder G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 250
(same as REB161PVB15FHINA1-2-24PCE)
SP02185 CONNECTOR 2.0T-1-3AW(Same as S3B-PHKS) G7.1ut 1 10

ANALOG
SP00071 OPAMP NJM2100M-TE1 G7.1ut, G2, G2.1u, GFX-1, GFX-3, MRS-8, 707II etc 1 50
TRANSISTOR
SP01228 Digital Tr BCR553(Same as DTB123EK) G7.1ut, GFX-5, MRS-8, MRS-1608 5 140
SP02040 Transistor BC817-40LT1G G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 5 70
DIODE
DISPLAY DEVICE
SP02171 LED 3A9RYGX-C G7.1ut 5 50
POTENTIOMETER
SP02183 Trimmer potentiometer TC-655MH501 G7.1ut 1 20
SWITCH
OTHER PARTS
SP01951 CONNECTOR 2.0T-1-2A(Same as JS-1125-2) GFX-1, MRS-1608(SP01661) 1 30
SP02006 CONNECTOR 2.0T-1-3A(Same as JS1125-3) GFX-3 1 30
SP01952 CONNECTOR 2.0T-1-4A(Same as JS-1125R-4) GFX-1 1 30
SP01426 CONNECTOR 2.0T-1-10A(Same as B10B-PH-K-S) MRS-802 1 70
SP01428 CONNECTOR 2.0T-1-12A(Same as B12B-PH-K-S) G7.1ut, MRS-802 1 70
SP02187 FPC CONNECTOR 11311124-12420000 G7.1ut 1 60
* SP02287 FPC Cable ZH-0074-26: 1mm pitch 24pin L=120mm 1 60

DISPLAY DEVICE
SWITCH
OTHER PARTS
* SP02288 CONNECTOR 2.0T-1-9AW 1 10
PEDAL SW-L PCB : PCB-0160A

SWITCH
OTHER PARTS
PEDAL SW-R PCB : PCB-0161A

SWITCH
OTHER PARTS
PHOTO_L PCB : PCB-0162A

PHOTO REFLECTOR
SP00457 Photo Reflector NJL5167KB G7.1ut, G2.1u, GFX-3, GFX-5, GFX-8, 707II 1 100
OTHER PARTS
PHOTO-R PCB : PCB-0163A

PHOTO REFLECTOR
SP00457 Photo Reflector NJL5167KB G7.1ut, G2.1u, GFX-3, GFX-5, GFX-8, 707II 1 100
OTHER PARTS
PHOTO_Z PCB : PCB-0164A

PHOTO REFLECTOR
* SP02292 Photo Reflector GP2S40J 1 190
OTHER PARTS
- 52 -
ANALOG PCB : PCB-0165
USB CODEC
SP02088 USB CODEC PCM2904DBR G7.1ut, G2.1u, B2.1u, A2.1u 1 600
ANALOG
SP00078 OPAMP NJM4556M-TE1 G7.1ut, G2, G2.1u, GFX-8, MRS-1608 etc 1 50
SP00070 OPAMP NJM4558M-TE1 (Same as BA4558F) G7.1ut, G2, G2.1u, GFX-8, MRS-1608 etc 1 40
SP00071 OPAMP NJM2100M-TE1 G7.1ut, G2, G2.1u, GFX-1, GFX-3, MRS-1608 etc 1 50
POWER SUPPLY
SP02090 Voltage Regulator XC6213B332MR G2.1u, B2.1u, A2.1u 1 40
SP02196 Voltage Regulator TA7812S (Same as uPC7812AHF) G7.1ut 1 70
SP02197 Voltage Regulator TA79012S (Same as uPC7912AHF) G7.1ut 1 130
SP02198 Voltage Regulator S-8520F50MC-BOJ-T2 G7.1ut 1 60
TRANSISTOR
SP01199 Transistor 2SC3326 G7.1ut, MRS-802, MRS-1266, MRS-1608 5 50
SP02199 Transistor 2SA1213 5 80
SP02039 Transistor BC807-40LT1G G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 5 70
SP02200 Digital Tr DTA124EKA G7.1ut 5 50
SP02201 Digital Tr MUN5112DW1T1G (Same as UMB1N and XP04112) G7.1ut 5 130
DIODE
SP00704 Chip Shottky Diode RB160L-40TE25 G7.1ut, G2, G2.1u, MRT-3, MRS-4, PS-02, PS-04 5 150
SP00123 Diode 1N4003 G7.1ut, G2, G2.1u, GFX-1, GFX-3, GFX-8 etc 5 100
OSCILLATOR
SP02092 Crystal Oscillator HC49S3 12MHz G7.1ut, G2.1u, B2.1u, A2.1u 1 70
INDUCTOR
SP02202 Inductor LQH55DN220M03(22uH) (Same as CDRH5D28R-220) G7.1ut 1 110
SP01762 Chip Inductor BLM18AG102SN1 G7.1ut, G2, G2.1u, MRS-8 10 200
POTENTIOMETER
SP02203 Trimmer potentiometer TC-655MH103 G7.1ut 1 20
JACK, SOCKET
SP01499 Stereo Mini Jack SJ-3507-5P(Same as ST-214-C-02) G7.1ut, GFX-5 1 70
SP00590 Stereo Phone Jack SJ6336 (Same as HTJ-064-12D) G7.1ut, G2, G2.1u, GFX-1, GFX-3, GFX-5, GFX-8 1 100
SP00589 Phone Jack SJ6335 (Same as HTJ-064-12I) G7.1ut, G2, G2.1u, GFX-1, GFX-3, GFX-5, GFX-8 1 100
OTHER PARTS
SP00910 Slide SW SK22H09-G9 (Same as HSW2022-010020) G7.1ut, G2, G2.1u, GFX-1, GFX-3, MRS-8 etc 1 30
SP02204 Volume F-095V5G A10K L15FC*7 (M) G7.1ut 1 140
SP02093 USB Connector 57112201-2110000 G7.1ut, G2.1u, B2.1u, A2.1u 1 40
SP02162 Connector 3.96T-3-3A (Same as B3P-VH) G7.1ut 1 20
SP02006 Connector 2.0T-1-3A (Same as JS-1125-3 and B3B-PHKS) G7.1ut, G2, G2.1u, GFX-3 1 30
SP01426 Connector 2.0T-1-10A (Same as B10B-PHKS) MRS-802 1 70
TUBE PCB : PCB-0166

TUBE
SP02209 TUBE 12AX7 G7.1ut 1 1180
OTHER PARTS
SP02210 TUBE SOCKET GZC9-1B G7.1ut 1 120
ACC TUBE PCB : PCB-0167

TUBE
SP02209 TUBE 12AX7 G7.1ut 1 1180
OTHER PARTS
SP02210 TUBE SOCKET GZC9-1B G7.1ut 1 120
SP02164 Connector 2.0T-1-8A G7.1ut 1 10
PCB
CODE No. NAME SPECIFICATIONS COMMON USE Q'ty PRICE(Japanese yen)
PCB ASSEMBLY
FR-4 4layer 113x95mm
* SP40165 G9.2tt MAIN PCB Assy 1 3000
(PCB-0151 with Harness)
FR-1 One side pattern 149x106.5mm
* SP40166 G9.2tt PANEL PCB Assy 1 2000
(PCB-0154A, PCB-155A with Harness)
FR-1 One side pattern 130x34mm
* SP40167 G9.2tt ENCODER PCB Assy 1 480
(PCB-0156A, PCB-0157A with Harness)
* SP40168 G9.2tt FOOT SW PCB Assy 1 940
(PCB-0158A, PCB-0159A, PCB-164A with Harness)
* SP40169 G9.2tt PEDAL SW PCB Assy 1 250
(PCB-0160A, PCB-161A, PCB-162A, PCB-0163A with
FR-4 2layer 284x100mm
* SP40170 G9.2tt ANALOG PCB Assy 1 2000
(PCB-0165, PCB-0166, PCB-0167 with Harness)
- 53 -
MECHANICAL PARTS LIST
TOP COVER
* SP02299 G9.2tt TOP CASE Z2A-0108 1 1770
LOWER PANEL
* SP02300 G9.2tt BOTTOM PLATE Z2A-0109 1 690
SIDE COVER
SP02214 G7.1ut SIDE COVER L Z2B-0203 G7.1ut 1 110
SP02215 G7.1ut SIDE COVER R Z2B-0204 G7.1ut 1 110
BUTTON, KNOB
SP02216 G7.1ut SWITCH BUTTON A Z2B-0195 G7.1ut 1 30
SP02059 VR KNOB 1 Z2B-0160 G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 30
SP02060 VR KNOB 2 Z2B-0161 G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 30
SP02217 G7.1ut VR KNOB 2 Z2B-0200 G7.1ut 1 20
SP02218 G7.1ut ENCODER KNOB 2 Z2B-0201 G7.1ut 1 10
SP02219 G7.1ut VR KNOB 3 Z2B-0202 G7.1ut 1 20
SP02220 G7.1ut EX PEDAL BUTTON Z2B-0208 G7.1ut 1 10
RUBBER, SPRING
SP02025 GFX3 CUSHION RUBBER Z2D-0042-A4 GFX-3 1 10
SP01964 GFX-1 FOOT RUBBER B Z2D-0040-A4 GFX-1 1 10
SP02247 G7.1ut EX PEDAL RUBBER Z2D-0058 G7.1ut 1 60
SP02121 CUSHION EX-PEDAL Z2D-0062 G7.1ut 1 10
* SP02301 EX-PEDAL SPRING Z2A-0123 1 10
SHEET, COLOR FILTER
SP02248 G7.1ut DISPLAY SHEET Z2E-0214 G7.1ut 1 20
SP01535 G7.1ut REFLECT SEAL Z2E-5032-A4 G7.1ut, G2.1u, GFX-3, GFX-5 1 40
SP02249 G7.1ut EX BUTTON PAD Z2D-0059 G7.1ut 1 10
* SP02302 G9.2tt rubber pad Z2D-0061 1 10
SCREW, WASHER, NUT
SP00291 SCREW M3.0x8L P-TIGHT G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u, MRT-3 10 20
SP01285 SCREW M3.0x5L S_TIGHT, SWCH(Fe), Black Chromate MRS-1266 10 320
SP01804 TAPE SCREWS M3.0x8L B-TIGHT RT-223 10 100
SP02027 SCREW M3.0x8L S_TIGHT, SWCH(Fe), Black Chromate G7.1ut, GFX-3 10 10
SP02245 G7.1ut PCB SPACER HP-13.5 G7.1ut 10 10
SP02251 SPRING WASHER d5.2xd3.2xt1.0 G7.1ut 10 10
SP02252 G7.1ut SCREW Z2B-0032, M4.0X5.0,BLACK, no head G7.1ut 10 90
SP02253 G7.1ut SCREW M4.0x8L, SWCH(Fe),Black Chromate HEXAGON SOCKET HEAD G7.1ut 10 10
SP02258 NUT M3.0,black G7.1ut 10 10
* SP02303 SPACER d=10.0 t=0.1 10 50
* SP02305 PLAIN WASHER d6.6xd3.2xt1.0 10 10
* SP02306 SCREW M2.6x4L, P-TIGHT 10 10
* SP02307 SCREW M2.6x5L, P-TIGHT 10 10
* SP02308 SCREW M3.0x4L, S-TIGHT FLAT HEAD 10 10
* SP02309 SCREW M3.0x6L, COMMON HEAD,black 10 10
* SP02310 SCREW M3.0X12L 10 20
* SP02311 SCREW M3.0X14L, P-TIGHT 10 20
* SP02312 SCREW M3.0x22L, S-TIGHT 10 20
* SP02313 SCREW M3.0X9L 10 20
* SP02314 G9.2tt ZM_SP_01 Z2B-0223 10 80
* SP02315 G9.2tt ZM_SP_02 Z2B-0224 10 80
OTHER MOULDING PARTS
SP02062 FOOT SW UNIT Z2A-0089 G7,1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u 1 130
SP02221 G7.1ut EX PEDAL SPACER Z2B-0212 G7.1ut 1 10
SP02222 G7.1ut FOOT SW DRESS PLATE Z2B-0206 G7.1ut 1 30
SP02223 G7.1ut FOOT SW BRACKET Z2A-0093 G7.1ut 1 60
SP02224 G7.1ut DISPLAY COVER Z2B-0205 G7.1ut 1 70
SP02226 G7.1ut CORD HOOK Z2B-0209 G7.1ut 1 10
SP02227 G7.1ut AC BRACKET Z2A-0096 G7.1ut 1 10
SP02228 G7.1ut EX PEDAL BRACKET Z2B-0210 G7.1ut 1 10
SP02229 G7.1ut EX PEDAL BRACKET PLATE Z2A-0100 G7.1ut 1 10
SP02230 G7.1ut EX PEDAL GUIDE Z2A-0095 G7.1ut 1 30
SP02231 G7.1ut EX PEDAL BASE Z2B-0211 G7.1ut 1 460
SP02232 G7.1ut EX PEDAL POLE Z2A-0101 G7.1ut 1 40
SP02233 G7.1ut REFLECT BRACKET Z2B-0207 G7.1ut 1 10
SP02237 G7.1ut SIDE BRACKET_RIGHT Z2A-0099 G7.1ut 1 150
SP02238 G7.1ut SHIELD CASE Z2A-0105 G7.1ut 1 20
SP02239 G7.1ut LED SPACER SUPPORT 1 LED-16 G7.1ut 1 10
SP02240 G7.1ut LED SPACER SUPPORT 2 LED3x16 G7.1ut 1 10
SP02241 G7.1ut THREAD SPACER HP_12 G7.1ut 1 10
SP02243 G7.1ut SPACER SUPPORT 2 MADM-2 G7.1ut 1 10
* SP02316 G9.2tt ROUND SPACER 3.5-12 1 10
* SP02317 G9.2tt ROUD SPACER 3-2 1 10
* SP02318 G9.2tt MACHINE BAR Z2A-0110 1 290
* SP02319 G9.2tt TUBE BRACKET A Z2A-0111 1 50
* SP02320 G9.2tt TUBE SP BRACKET Z2A-0112 1 50
* SP02321 G9.2tt HEATSINK Z2A-0113 1 100
* SP02322 G9.2tt FOOT SW BRACKET 2 Z2A-0116 1 80
* SP02323 G9.2tt TUBE COVER A Z2A-0119 1 50
* SP02324 G9.2tt TUBE COVER B Z2A-0120 1 50
* SP02325 G9.2tt Shield plate Z2A-0121 1 130
* SP02326 G9.2tt copper support Z2A-0122 1 20
* SP02327 G9.2tt SIDE BRACKET_LEFT Z2A-0124 1 150
- 54 -
Z-PEDAL MECHANICAL PARTS LIST
RUBBER, SPRING
SP02025 GFX3 CUSHION RUBBER Z2D-0042-A4 G7.1ut, GFX-3 1 10
* SP02328 Z-PEDAL RUBBER Z2D-0060 1 40
* SP02347 CUSHION Z-PEDAL 1 Z2D-0063 1 10
* SP02348 CUSHION Z-PEDAL 2 Z2D-0064 1 10
SCREW, WASHER, NUT
SP00291 TAPE SCREWS M3.0x8L P_TIGHT, SWCH(Fe), Black Chromate G7.1ut, G2, G2.1u, B2, B2.1u, A2, A2.1u, MRT-3 10 20
SP02027 TAPE SCREWS M3.0x8L S_TIGHT, SWCH(Fe), Black Chromate G7.1ut, GFX-3 10 10
* SP02308 SCREW M3.0x4L, S-TIGHT FLAT HEAD 10 10
SP02252 G7.1ut SCREW Z2B-0032, D5.0, M4.0X5.0,BLACK, no head, G7.1ut 10 90
SP02253 G7.1ut SCREW M4.0x8L, SWCH(Fe),Black Chromate HEXAGON SOCKET HEAD G7.1ut 10 10
* SP02329 E-RING 5mm,white nickel plated 10 20
* SP02330 PLAIN WASHER d=14.0xd=8.5xt=0.5 10 120
OTHER MOULDING PARTS
SP02221 G7.1ut EX PEDAL SPACER Z2B-0212 G7.1ut 1 10
SP02228 G7.1ut EX PEDAL BRACKET Z2B-0210 G7.1ut 1 10
SP02229 G7.1ut EX PEDAL BRACKET PLATE Z2A-0100 G7.1ut 1 10
SP02230 G7.1ut EX PEDAL GUIDE Z2A-0095 G7.1ut 1 30
SP02232 G7.1ut EX PEDAL POLE Z2A-0101 G7.1ut 1 40
* SP02331 Z-PEDAL POLE Z2A-0114 1 70
* SP02332 Z-PEDAL PIN Z2A-0115 1 30
* SP02333 Z-PEDAL BASE 1 Z2B-0214 1 320
* SP02334 Z-PEDAL BASE 2 Z2B-0215 1 470
* SP02335 Z-PEDAL LOCK CAM 1 Z2B-0216 1 60
* SP02336 Z-PEDAL LOCK CAM 2 Z2B-0217 1 60
* SP02337 Z-PEDAL REFLECT BRACKET Z2B-0219 1 10
* SP02338 Z-PEDAL GUIDE PLATE 1 Z2B-0220 1 10
* SP02339 Z-PEDAL GUIDE PLATE 2 Z2B-0221 1 10
* SP02340 Z-PEDAL BLAKE Z2B-0222 1 10
PACKING PARTS LIST

CARTON BOX
* KS00169 G9.2tt MASTER Carton Box Z2F-0045 1 400
* KS00170 G9.2tt Gift Box Z2F-0044 1 460
SPACER
KS00166 G9.2tt Corrugated Spacer-1 package_sub_card_R (Same as G7.1ut Corrugated Spacer-3) G7.1ut 1 10
KS00167 G9.2tt Corrugated Spacer-2 package_adaptor_card (Same as G7.1ut Corrugated Spacer-4) G7.1ut 1 20
KS00164 G9.2tt Corrugated Spacer-3 3 package_side_card (Same as G7.1ut Corrugated Spacer-1) G7.1ut 1 10
* KS00173 G9.2tt Corrugated Spacer-6 package_top_card 1 30
CARD, SHEET
SP02261 DAW Starting Manual Japanese G7.1ut, G2.1u, B2.1u, A2.1u 1 20
SP02262 DAW Starting Manual English G7.1ut, G2.1u, B2.1u, A2.1u 1 20
* SP02341 G9.2tt Patch List Sheet Z2I-0659 Japanese 1 20
* SP02342 G9.2tt Patch List Sheet Z2I-0660 English 1 20
* SP02343 G9.2tt Modeling Description Z2I-0664 Japanese 1 20
* SP02344 G9.2tt Modeling Description Z2I-0665 English 1 20
* SP02345 Pedal adjustment supplemental sheet 1 20
- 55 -
To: ZOOM Corp. Overseas Sales Group
Parts Order Sheet page of

Code No. Product name Parts name Specifications Unit price Qty
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
SP ¥
Memo:
Company:
Signature:
Name:
ZOOM CORPORATION
2F, ITOHPIA IWAMOTO-CHO 2-CHOME BLDG.
2-11-2, Iwamoto-cho, Chiyoda-Ku, Tokyo
101-0032,Japan
PHONE: +81-3-5835-2200(MAIN)
FAX: +81-3-5835-2201
Web Site: http://www.zoom.co.jp
- 56 -

Supplement 1: G9.2tt Optical Sensor Problem
As there is an optical sensor under expression pedal for the operation, the following matters
are confirmed on the open-air stage in direct sunshine or under strong lighting;
1) The pitch of sound changes in spite of no touch to the pedal.

2) The sound might be disappeared in the setting of volume pedal.
*G9.2tt has already performed the following measure.
Measure direction to G9.2tt optical sensor problem

1. EX-PEDAL
1. Get up EX-PEDAL (Bring a bit rear rubber foot of EX-PEDAL into contact with top of
chassis) Refer Fig.1.
Fig.1 Before measure
2. Peel off guard sheet from adhesive side of CUSHION EX-PEDAL (SP02121).
Insert CUSHION EX-PEDAL and fit the cut part to projection under the pedal.
- 57 -

Fig.2 Under measure
CUSHION EX-PEDAL (SP02121)
3. Fix CUSHION EX-PEDAL on the top of chassis. Refer Fig.3.
Fig.3 After measure
- 58 -

2. Z-PEDAL
1. Get up Z-PEDAL (Bring a bit rear rubber foot of Z-PEDAL into contact with top of
chassis) Refer Fig.4.
Fig.4 Before measure
2. Peel off guard sheet from adhesive side of CUSHION Z-PEDAL (SP02347).
Insert CUSHION Z-PEDAL and fit the cut part to projection under the pedal.
Fig.5 Under measure
CUSHION Z-PEDAL 1 (SP02347)
- 59 -

3. Peel off guard sheet from adhesive side of CUSHION Z-PEDAL (SP02348).
Insert CUSHION Z-PEDAL and fit the cut part to projection under the pedal.
Fig.6 Under measure
CUSHION Z-PEDAL 2 (SP02348)
4. Fix CUSHION Z-PEDAL on the top of chassis. Refer Fig.6.
Fig.7 After measure
- 60 -

Supplement 2:
PEDAL SW Adjustment Specifications
1. G9.2tt EX PEDAL SW
In case that it is difficult to put the SW when EX PEDAL is feet or the case easily EX PEDAL
SW is put on when EX PEDAL is controlled, the adjustment below is needed.
Case1. Difficult to put the EX PEDAL SW

1. Set EX PEDAL to MIN(raised).
2. Add a spacer on the one indicated in the figure above.
3. Control EX PEDAL and measure the weight needed to put the EX PEDAL SW.
4. Repeat the procedure from 1 to 3 so that the SW is put when EX PEDAL is feet
strongly and adjust the quantity of spacer.
Case2. Easily SW is put on when EX PEDAL is controlled

1. Set EX PEDAL to MIN (raised).
2. Remove only one spacer.
3. Control EX PEDAL and make sure whether EX PEDAL SW is put or not.
4. Repeat the procedure from 1 to 3 so that the SW is put when EX PEDAL is feet strongly and
adjust the quantity of spacer.
- 61 -

2. G9.2tt Z PEDAL SW
In case that it is difficult to put the SW when Z PEDAL is feet or the case easily Z PEDAL SW
is put on when Z PEDAL is controlled, the adjustment below is needed.
Case1. Difficult to put the Z PEDAL SW

1. Set Z PEDAL to MIN(raised).
2. Add a spacer on the one indicated in the figure above.
3. Control Z PEDAL and measure the weight needed to put the Z PEDAL SW.
4. Repeat the procedure from 1 to 3 so that the SW is put when Z PEDAL is feet strongly
and adjust the quantity of spacer.
Case2. Easily SW is put on when Z PEDAL is controlled

1. Set Z PEDAL to MIN (raised).
2. Remove only one spacer.
3. Control Z PEDAL and make sure whether Z PEDAL SW is put or not.
4. Repeat the procedure from 1 to 3 so that the SW is put when Z PEDAL is feet strongly
and adjust the quantity of spacer.
- 62 -

Importance: G9.2tt Harness Fixing
(Fig1) Overall
- 63 -

(Fig2) Left side
(Fig3) Right side
- 64 -

(Fig4) Cautions
Don’t be close to the

Voltage regulators.
Don’t be close to
TUBE ACC PCB.
Don’t be close to the harnesses

in the red circle. The harnesses in the red circle
tend to pick up noise.
Don’t be close to the

Voltage regulators.
This harnesses tend to pick

up Digital noise.
- 65 -

G9.2tt Service Manual Change History
Date Page Change

Complete price list
1 Mar 2007 51-55
Correct spare parts items
19 Oct 2011 51 Added “SP02827”

Zoom g9

Uploaded by

Document Information

Original Description:

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Zoom g9

Uploaded by

Copyright:

Available Formats

Downloaded from www.Manualslib.

com manuals search engine

Function Test ............................................................................................................................................ 5

Tube Adjustment Specification............................................................................................................... 17

Back Up User’s Data .............................................................................................................................. 24

Recovering the Factory Default ............................................................................................................. 26

Circuit Check Specifications .................................................................................................................. 27

Circuit Diagram ...................................................................................................................................... 28

Exploded view ........................................................................................................................................ 43

Parts List ................................................................................................................................................ 44

Spare Parts Order List ............................................................................................................................ 51

Spare Parts Order Sheet ..........................................................................................................................56

Supplement 1: G9.2tt optical sensor problem..........................................................................................57

Supplement 2: G9.2tt PEDAL SW Adjustment specifications................................................................61

Importance: Harness Fixing.....................................................................................................................63

Downloaded from www.Manualslib.com manuals search engine

Number of effect modules 10 simultaneously usable modules

Patch memory User area : 5 patches x 20 banks = 100 (read/write enabled)

Sampling frequency 96 kHz

A/D conversion 24-bit, 64-times oversampling

D/A conversion 24-bit, 128-times oversampling

Signal processing 32-bit

Frequency response 20 Hz - 40 kHz +1.0 dB, -3.0 dB (10 kilohm load)

Display 2-digit 7-segment LED display

AUX input Mini phone jack (stereo)

External Return Standard mono phone jack

Downloaded from www.Manualslib.com manuals search engine

Headphone output Standard stereo phone jack

External Send Standard mono phone jack

Tube circuitry 12AX7 x 2

Control connectors MIDI OUT, MIDI IN

Power requirements 15 V AC, 1.5 A (from supplied AC adapter AD-0012)

Dimensions 235 (D) x 595 (W) x 85 (H) mm

• 0 dBm = 0.775 Vrms

Downloaded from www.Manualslib.com manuals search engine

● Set up before start up Test Mode.

1. Starting built-in inspection program.

Connect the AC-adapter.

Downloaded from www.Manualslib.com manuals search engine

3. OUTPUT LEVEL check

Turn right [LEVEL] volume.

4. VERSION, REVISION, and CRC32 check

Turn the knob (DIAL/VOLUME) in the following table.

Table1. DIAL/VOLUME LCD display

Downloaded from www.Manualslib.com manuals search engine

Press the [AMP SELECT SYSTEM] key (SW5).

Press the [BYPASS TUNER] key (SW15).

Press the [PAGE] key (SW17).

Downloaded from www.Manualslib.com manuals search engine

Press the [STORE/SWAP] key (SW16).

11. USB-MUTE (SW) check

Press the [EXIT] key (SW19)

12. DIRECT-MUTE check

Press the [PEDAL2 SETTING] key (SW20).

13. SW/LED check

Table2. SW LCD display

Downloaded from www.Manualslib.com manuals search engine

Connect MIDI cable to [MIDI IN] and [MIDI OUT] (J401)

15. LCD CONTRAST check

Push [HOLD BYPASS/TUNER] FOOT SW (SW24).

16. CH A/B FUNCTION1 (SW) check

Press the [CH A/B FUNCTION1] FOOT SW (SW26).

17. TAP FUNCTION2 (SW) check
