Graph

P VASUKI
 Definition
• Graph is a set of items connected by
edges. Each item is called a vertex or
node.
B

A
C

D E
 Applications
• The Graph ADT is used to represent
the relationship
• Example represents connectivity –
relationship with neighbour.
– the network may be a communications
or transportation network (of pipelines,
roads, etc.)
 Applications
• Typical graph-related problems are
to determine
– accessibility in a network
– whether removal of a node will
disconnect a network
– the cheapest path between nodes
– whether a task is an indirect
prerequisite of another
 Specialization
• directed graph
• undirected graph
• acyclic graph
• directed acyclic graph
• planar graph
• connected graph
• biconnected graph
 Specialization
• complete graph
• dense graph
• sparse graph
• labeled graph
• weighted graph
• tree.
 Notations of a graph
• V: the set of vertices of a graph
• E: the set of edges of a graph
• To say G = (V,E) is to say that
– graph G has vertex set V and edge set E
• n: the number |V| of vertices of the graph
• e: the number |E| of edges of the graph
• Note that if there are no multiple edges, then
e is O(n2)
– that is, |E| is O(|V|2)
 Representation of a graph
a. Logical Representation Y
X

b. Adjacency list Node Adj List

X Y,Z
Y X
Z X

Nod X Y z
c. Adjacency Matrix e
In weighted graph the weight x 0 1 1
represents cost. In matrix y 1 0 0
‘1’ is replaced by the cost
z 1 0 0
• Find out Time and Space complexity
in Adjacency List and Adjacency
Matrix Representation!!
 Adj List and Adj Matrix
• An adjacency matrix requires Θ(n) space
– finding a single entry takes O(1) time;
processing all vertices adjacent to a vertex v
takes Θ(n) time
• The adjacency lists of a graph, taken together,
require Θ(n+e) space
– The first operation above might visit all nodes
adjacent to v; doing so might take Θ(n) time
• For a dense graph (where e is Θ(n2)), n+e is
Θ(n2) . If instead the graph is a sparse graph, an
adjacency list is more efficient.
 Path
• Vertex w is adjacent to v in a graph iff (v,w) is in
the graph
– Note that this includes the case of an
undirected graph with an edge between v and
w
• A path in a graph is a sequence (vi) such that
vi+1 is adjacent to vi for every i
• A path of n vertices may also be considered as a
sequence of n-1 edges.
• The length of a path generally refers to the
number of edges in the path
 Graph Traversal
B

A C

D E
• Visiting in children in the subsequent level, before
visiting sibling. Depth First Search (DFS) –Preorder
traversal – uses stack data structure
• A->B->C>D->E

• Visiting all siblings and then visit children in subsequent

level is Breadth First search BFS – Uses queue data
structure
• A->B->D-> C->E
 Topological Sort
• Ordering the vertices according to the
topological order.
• An instance of the topological sort problem is a
set of tasks, each with a set of prerequisite
tasks
• The goal is to find a list of the tasks in which
each task follows all of its prerequisites
– this list is said to be sorted in topological
order
• We'll assume that the prerequisite information
is represented as a directed graph.
 Algorithm- Topological Sort
• List all nodes with in degree (the number of nodes
pointing to it)
• Initialize the data structure to contain all nodes
from the graph that have no incoming edges.(
Which has no prerequisite else all pre
• Repeatedly
– delete a node from the structure for
scheduling, and add it to the end of the output
list
– decrement the number of unmet prerequisites
for all immediate successors of the node, and
– add to the structure any node which now has
no unmet prerequisites.
• Until the structure is empty
 Topological Sort - Output
• At the end if all nodes are not
displayed in the output list, there
might be some cycle in the graph.

• Else the algorithm terminates

successfully.
 Example
Node Indegree
B
A 1 A C
B 3
C 1
D E
D 0
E 1
Output List : D – Choose a node Node Indegree
with in degree zero. A 0
B 2
C 1
Reduce the in degree of adjacent D 0
nodes of the chosen node.
E 0
 Example
Proceeding in the B
same way as A C
shown in previous
page
D E

Node Indegree
A 0
Node Indegree
B 1
A 0
C 1
B 2
D 0
C 1 E 0
D 0
E 0 Output List : D,A, E

Output List : D,A

 Example
Node Indegree
A 0 B
A C
B 0
C 1
D 0 D E
E 0
Output List : D, A, E, B
Thus D A E B C is the
Node Indegree topological order of
A 0 the given graph.
B 0
C 0
D 0
E 0

Output List : D,A, E, B, C
