Wireless H3C

H3C WA2620-AGN WLAN Access Point
Quick Start
Hangzhou H3C Technologies Co., Ltd.

http://www.h3c.com
Document version: 6PW104-20110225
Downloaded from www.Manualslib.com manuals search engine

Copyright © 2009-2011, Hangzhou H3C Technologies Co., Ltd. and its
licensors
All rights reserved
No part of this manual may be reproduced or transmitted in any form or

by any means without prior written consent of Hangzhou H3C
Technologies Co., Ltd.
Trademarks
H3C, , Aolynk, , H3Care, , TOP G, , IRF,

NetPilot, Neocean, NeoVTL, SecPro, SecPoint, SecEngine, SecPath,
Comware, Secware, Storware, NQA, VVG, V2G, VnG, PSPT, XGbus,
N-Bus, TiGem, InnoVision and HUASAN are trademarks of Hangzhou
H3C Technologies Co., Ltd.
All other trademarks that may be mentioned in this manual are the
property of their respective owners
Notice
The information in this document is subject to change without notice.

Every effort has been made in the preparation of this document to ensure
accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any
kind, express or implied.
Environmental protection
This product has been designed to comply with the environmental

protection requirements. The storage, use, and disposal of this product
must meet the applicable national laws and regulations.

Preface
H3C WA2620-AGN WLAN Access Point Quick Start describes the
basic steps necessary to install and configure your H3C WA2620-AGN
(11n 2.4+5GHz PoE) Access Point.
This preface includes:
• Audience
• Conventions
• About the H3C WA2620-AGN documentation set
• Obtaining documentation
• Technical support
• Documentation feedback
Audience
This documentation is intended for:
• Network planners
• Field technical support and servicing engineers
• Network administrators working with the WA2620-AGN WLAN Access
Point.
Conventions
This section describes the conventions used in this documentation set.

Symbols
Convention Description
An alert that calls attention to important information that if
WARNING not understood or followed can result in personal injury.
An alert that calls attention to important information that if

CAUTION not understood or followed can result in data loss, data
corruption, or damage to hardware or software.
An alert that contains additional or supplementary

NOTE
information.
About the H3C WA2620-AGN

documentation set
The H3C WA2620-AGN documentation set includes:
Category Documents Purposes
Marketing Describe product specifications and
Product brochures benefits.
description and
specifications Technology white Provide an in-depth description of
papers software features and technologies.
Provides regulatory information and

Compliance and
the safety instructions that must be
safety manual
Hardware followed during installation
specifications and Guides you through initial installation
installation and setup procedures to help you
Quick start
quickly set up and use your device
with the minimum configuration.

Category Documents Purposes
Configuration Describe software features and
guides configuration procedures.
Command Provide a quick reference to all

Software
references available commands.
configuration
Describe typical network scenarios
Configuration
and provide configuration examples
examples
and instructions.
Provide information about the product

release, including the version history,
Operations and hardware and software compatibility
Release notes
maintenance matrix, version upgrade information,
technical support information, and
software upgrading.
Obtaining documentation
You can access the most up-to-date H3C product documentation on the
World Wide Web at http://www.h3c.com.
Click the links on the top navigation bar to obtain different categories of
product documentation:
[Technical Support & Documents > Technical Documents] – Provides
hardware installation, software upgrading, and software feature
configuration and maintenance documentation.
[Products & Solutions] – Provides information about products and
technologies, as well as solutions.
[Technical Support & Documents > Software Download] – Provides the
documentation released with the software version.

Technical support
customer_service@h3c.com
http://www.h3c.com
Documentation feedback
You can e-mail your comments about product documentation to
info@h3c.com.
We appreciate your comments.

Contents
About This Guide······························································································1
AP Features······································································································· 1
Safety Information ···························································································· 3
Approved Channels························································································· 4
Mounting the AP ·······························································································5

Unpacking the AP ···························································································· 5
Preparing for Installation ················································································· 5
Mounting the AP ······························································································ 6
Wall or Electrical Box Mounting ··························································· 6
Tabletop Mounting ·················································································· 7
Ceiling Mounting····················································································· 9
Connecting Power··························································································12
Power over Ethernet (PoE) from the LAN ············································12
Power over Ethernet from a PoE Injector·············································12
Checking the LED Indicators·································································14
Connecting to the AP····················································································· 15

Finding the IP Address on Networks with a DHCP Server(FIT AP) ···········15
Finding the IP Address on Networks Without a DHCP Server(FAT AP) ···15
Log into the AP ·······························································································15
Converting your Managed AP (FIT) to a Stand-alone AP (FAT) ················16
Converting your Stand-alone AP (FAT) to a Managed AP (FIT) ················16
Optional ········································································································· 17
Optional POE injector ···················································································17
Optional Antennas·························································································17
Optional Antenna Cables ·············································································17
AppendixA Regulatory Compliance Information ········································ 18

Regulatory compliance standards ································································18
Support Antennas & Accessories information·············································19
i
EU Compliance information··········································································20
CE Marking····························································································20
EU Country Restriction in 2.4GHz band ············································24
EU Country Restriction in 5GHz band ················································24
WEEE Directive–2002/96/EC ···························································25
USA Compliance information·······································································26
US Federal Communications Commission statement·························26
RF Requirements ····················································································26
Antennas ································································································27
Industry Canada·····························································································27
RF Compliance ······················································································27
Brazil RF Compliance ····················································································28
Korea RF Compliance····················································································29
Taiwan regulatory statement·········································································29
AppendixB 产品中有毒有害物质清单全集·················································· 30
ii
About This Guide
This Quick Start Guide describes the basic steps necessary to install and
configure your H3C WA2620-AGN (11n 2.4+5GHz PoE) Access Point.
Note: This guide refers to these devices as the AP.
Before you install or move the AP, you must carefully read the safety
information of this manual.
AP Features
1
Feature Description
The Ethernet port provides a 10/100/1000 BASE-T
Ethernet connection to a switch. Use a suitable Category
Ethernet Port
5 cable with straight-through wiring and standard RJ-45
connectors to connect your AP to the network.
The LEDs indicate power and activity. See Checking the

LEDs
LED Indicators for details.
The AP has three built-in internal antennas. In addition,

Antenna Connectors three RSMA antenna connectors allow you to connect
optional external antennas.
Reset Button To reset the AP.
Provides a serial interface to the AP for diagnostic use.

RJ-45 Console Port
Default: 9600K, 8 bits, no parity, 1 stop bit.
Wall-Mounting The combined wall-mounting bracket and table-top stand

Bracket and allows you to mount the unit on a wall or stand it on a
Table-Top Stand table top.
The Suspended ceiling bracket (Ceiling bracket and

Suspended ceiling
Slider) allows you to mount the unit on a suitably ceiling
bracket
tile separator.
2
Feature Description
Dimensions (length x width x depth): 7 x 3 x 4 mm (0.28
Security slot x 0.12 x 0.16 in.) ,and a standard Kensington lock is
recommended.
Safety Information
This equipment must be installed in compliance with local and national
building codes, regulatory restrictions, and FCC rules. For the safety of
people and equipment, only professional network personnel should
install the AP.
WARNING!
Warnings contain directions that you must follow for your personal safety.
Follow all directions carefully.
You must read the following safety information carefully before you install
or remove the unit.
WARNING!
Exceptional care must be taken during installation and removal of the unit.
WARNING!
This unit operates under SELV (Safety Extra Low Voltage) conditions
according to IEC60950-1. The conditions are only maintained if the
equipment to which it is connected also operates under SELV conditions.
3
WARNING!
There are no user-replaceable fuses or user-serviceable parts inside the
unit. If you have a physical problem with the unit that cannot be solved
with problem solving actions in this guide, contact your supplier.
WARNING!
RJ-45 ports. These are RJ-45 data sockets. They cannot be used as
standard traditional telephone sockets, or to connect the unit to a
traditional PBX or public telephone network. Only connect RJ-45 data
connectors, network telephony systems, or network telephones to these
sockets.
Either shielded or unshielded data cables with shielded or unshielded
jacks can be connected to these data sockets.
WARNING!
To comply with FCC radio frequency (RF) exposure limits, a minimum
body-to-antenna distance of 20 cm must be maintained when the AP is
operational..
Approved Channels
Use of this product is only authorized for the channels approved by each
country. For proper installation, select your country from the
country-selection list.
To conform to FCC and other country restrictions, your product may be
limited in the channels that are available. If other channels are permitted
your country, please visit the web site for the latest software version:
http://www.h3c.com
4
Mounting the AP
Unpacking the AP
Make sure that you have the following items, which are included with the
AP:
• One H3C WA2620-AGN Access Point
• Wall-mounting hardware:
○ One combined wall-mounting bracket and table-top stand
○ Four screws
○ Four wall anchors
• Suspended ceiling bracket:
○ One ceiling bracket
○ One slider
○ Two screws
• Eight adhesive rubber feet
• One copy of this Quick Start Guide
• One H3C Warranty Flyer
• One console cable
Preparing for Installation

H3C recommends that you connect and check the Ethernet cable and
LEDs before you install the AP in a hard-to-reach location. Also, observe
these items before you mount or connect the AP:
5
Feature Description
To connect your wireless network to your wired network, you
Switch Port
need a switch that is connected to the AP.
Make sure that a standard Ethernet cable with straight-through

wiring is installed at the site before you install the AP.
Cabling Make sure that the cable is highly flexible and that the RJ-45
connector has no extra covering that could prevent the cable
from being routed through the mounting bracket.
Power is supplied using an 802.3af Power Over Ethernet

Power (PoE) compliant device such as a PoE switch or a PoE injector.
Requirement For maximum performance, H3C recommends that you use a
Gigabit link.
Record the AP MAC address in a safe place before the AP is

MAC Address installed in a hard-to-reach location.
The MAC address is printed on the back of the AP.
Mounting the AP
The AP can be mounted on the following types of surfaces:
• Wall or electrical box (NEMA enclosure)
• Table top
• Ceiling Mounting
Wall or Electrical Box Mounting

To install your AP on a wall or electrical box, use the mounting bracket
that comes with the device. Follow these steps:
1. Following these guidelines, screw the mounting bracket to a wall or
electrical box (NEMA enclosure):
6
• The mounting bracket tabs should be pointing upward.
• If mounting to drywall, use the 4 screws and 4 wall anchors.
• If mounting to an EU electrical box (60.3mm), use 2 threaded screws and
insert into the holes marked “A” in the diagram shown below.
• If mounting to a US electrical box (83.3mm), use 2 threaded screws and
insert into the holes marked “B” in the diagram shown below.
2. Connect the Ethernet cable (for power and network connection) to the
LAN port on the back of the AP.
3. To mount the AP onto the mounting bracket, insert the mounting-bracket
tabs into the slots on the back of the AP.
CAUTION:
If you are mounting the AP on a wall, you cannot use the slots on the
bottom narrow edge of the device. Instead, you must use the slots on back
of the AP.
Tabletop Mounting
To install the AP on a flat surface such as a table or desktop, follow these
steps:
7
1. Insert the tabs on the table stand into the slots on the side of the AP, as
shown in the illustration. Align the cable routing cut out toward the upper
part of the stand.
2. To lock the stand to the AP, slide the stand back and the AP forward, as
shown here:
3. Place the AP and table stand on the table.
8
4. Connect the Ethernet cable for power and network connection to the
LAN port on the back of the AP.
Ceiling Mounting
To install your AP on the Ceiling, use the ceiling bracket kit that comes
with the device. Follow these steps:
1. Attach the metal slider to the back of the AP using the two small screws.
The slider should still be able to slide after the screws are tightened,
Make sure that the slide is left in the same position as shown below so
that the slots are accessible.
9
2. Clip the metal ceiling bracket to a suitably located ceiling tile separator.
3. Slide the moveable section into place and tighten the screw (found
underneath) to secure it.
10
4. Position the AP so that the two tabs from the ceiling bracket can be
inserted in the slots in the AP.
5. Slide the slider across to lock the AP to the bracket.
11
Connecting Power
This section describes how to power the AP in the following ways:
• By Power over Ethernet (PoE) supplied over the LAN by an 802.3af PoE
compliant device such as a switch.
• By PoE supplied by a PoE injector or midspan (not included with the AP).
NOTE:
The PoE injector needs to be separately purchased.
Power over Ethernet (PoE) from the LAN

To power the AP using PoE provided by a switch or other 802.3af
compliant device, plug the network cable from the device into the AP’s
Ethernet port.
Power over Ethernet from a PoE Injector

To power the AP using a PoE injector or midspan (not included), follow
these steps:
12
1. Connect the LAN cable from a switch to the Switch port on the PoE
injector.
2. Connect a LAN cable from the Ethernet port on the AP to the other LAN
port on the PoE injector.
3. Plug the PoE injector into a properly grounded electric outlet. See the
illustration.
13
Checking the LED Indicators
When the AP is connected to power, LEDs indicate activity as follows:
Indicator Color State Description
Off No power
LED 1 On Failure of CPU or system
Amber
(Power/ System initiation or reset (software
Blinking
System) self- testing and loading)
Green On Powered on and ready for operation
Off Radio disabled

LED 2
Green On Radio enabled
(2.4G)
Blinking Activity
Off Radio disabled

LED 3
Green On Radio enabled
(5G)
Blinking Activity
No 10/100/1000 BASE-T link

Off detected, or administratively
disabled
Amber
10/100 BASE-T link detected; no
LED 4 On
activity
(Ethernet) Blinking 10/100 BASE-T link activity
1000 BASE-T link detected; no

On
Green activity
Blinking 1000 BASE-T link activity
14
Connecting to the AP
To connect to the AP, you must first determine the AP’s IP address in one
of these ways.
Finding the IP Address on Networks with a

DHCP Server(FIT AP)
If your network has a DHCP server, it automatically assigns an IP address
to the AP.
Finding the IP Address on Networks

Without a DHCP Server(FAT AP)
If your network does not have a DHCP server, the AP uses a default
factory configuration which includes the following information.
• Configure the IP address of the AP as 192.168.0.50.
• Configure the AP to enable the Telnet server function (the default
authentication username is admin, password is h3capadmin, case
sensitive). You can remotely manage and maintain the AP through Telnet.
• Configure the AP to enable open-system authentication mode, with the
SSID being H3C.
Log into the AP

To Log into the AP after you determine its IP address, follows these steps:
1. Connect the AP and PC, and ensure that the PC and AP can
communicate with each other properly.
15
2. Launch your PC’s web browser. In the address bar, enter your AP’s IP
address and press Enter.
3. At the AP Login Screen, type the user name and password, and the
verification code, select the language (English and Chinese are
supported at present), and click Login. The default username and
password are case-sensitive:
• Username: admin
• Password: h3capadmin
http://www.h3c.com
Converting your Managed AP (FIT) to a

Stand-alone AP (FAT)
If you plan to run this AP in stand-alone mode, without a wireless
controller, go to the web page at http://www.h3c.com to get the FAT
firmware and instructions.
Converting your Stand-alone AP (FAT) to a

Managed AP (FIT)
If you plan to run this AP in Managed AP mode with a wireless controller,
go to the web page http://www.h3c.com to get the instructions.
16
Optional
Optional POE injector

Optional POE injector 3C Number
802.3af Gigabit POE injector 3CNJPSE-GIG
Optional Antennas
Optional Antennas 3C Number
2dBi Dual-Band Omni Antenna Kit 3CWE590
6/8dBi Dual-Band Omni Antenna 3CWE591
18/20dBi Dual-Band Panel Antenna 3CWE596
8/10dBi Dual-Band Panel Antenna 3CWE598
Optional Antenna Cables

Optional Antenna Cables 3C Number
Ultra Low Loss 6 Foot Antenna Cable 3CWE580
Ultra Low Loss 20-Foot Antenna Cable 3CWE581
Ultra Low Loss 50-Foot Antenna Cable 3CWE582
R-SMA to SMA 6” Antenna Cable 3CWE586
17
AppendixA Regulatory Compliance
Information
Regulatory compliance standards

Table 1 Regulatory compliance standards
Discipline Standards
FCC Part 15.207 & 15.209 & 15.247& 15.205 &
15.407
FCC Bulletin OET-65C
IC RSS 210
ETSI EN 300 328
EMC & RF ETSI EN 301 893
EN 60601-1-2
EN 61000-3-2
EN 61000-3-3
ETSI EN 301 489-1
ETSI EN 301 489-17
UL 60950-1
CAN/CSA C22.2 No 60950-1
Safety
IEC 60950-1
EN 60950-1
18
Support Antennas & Accessories
information
This product can be used with the following antennas and accessories:
Table 2 Authorized Antennas & Accessories
Item Description Exclusions

Internal antenna None
3CWE590 Rubber Duck Antenna None
Must be used with 3CWE586

3Com 6/8dBi Dual-Band Omni and one of the following:
3CWE591
Antenna 3CWE580, 3CWE581 or
3CWE582.

18/20dBi Dual-Band Panel and one of the following:
3CWE596
Antenna 3CWE580, 3CWE581 or
3CWE582.

8/10dBi Dual-Band Panel and one of the following:
3CWE598
Antenna Product 3CWE580, 3CWE581 or
3CWE582.
3Com Ultra Low Loss 6-Foot

3CWE580 Must also use 3CWE586.
Antenna Cable

Antenna Cable

Antenna Cable
19
Item Description Exclusions
Required for all external
antennas
3Com RSMA to SMA 6- inch
3CWE586 (not required for Internal
Antenna Cable
antenna and Rubber Duck
Antenna).
• This product does not contain any user serviceable components. Any
unauthorized
• Product changes or modifications will invalidate the warranty and all
applicable regulatory certifications and approvals.
• This product must be installed by a professional technician/installer.
EU Compliance information
CE Marking
Table 3 Equipment may be operated in the following country:
AT BE CY CZ DK EE FI FR
DE GR HU IE IT LV LT LU
MT NL PL PT SK SI ES SE
GB IS LI NO CH BG RO TR
1. Select the country in which the product is installed to ensure product

operation is in compliance with local regulations. For information on
20
how to select the country, refer to the WLAN Configuration Commands
of the WLAN Command Reference in H3C WX Series Access
Controllers Command References.
2. Intended use: IEEE 802.11a/b/g and 802.11n Draft 2.0.
3. This product must maintain a minimum body to antenna distance of
20cm.Under these conditions this product will meet the Basic Restriction
limits of 1999/519/EC(Council Recommendation of 12 July 1999 on
the limitation of exposure of the general public to electromagnetic
fields(0Hz-300GHz).
Table 4 R&TTE declaration statements:
H3C Coporation tímto prohlašuje, že tento RLAN device je ve

Česky
shodě se základními požadavky a dalšími příslušnými
[Czech]
ustanoveními směrnice 1999/5/ES.
Undertegnede H3C Corporation erklærer herved, at følgende

Dansk
udstyr RLAN device overholder de væsentlige krav og øvrige
[Danish]
relevante krav i direktiv 1999/5/EF.
Hiermit erklärt H3C Corporation, dass sich das Gerät RLAN

Deutsch device in Übereinstimmung mit den grundlegenden
[German] Anforderungen und den übrigen einschlägigen Bestimmungen
der Richtlinie 1999/5/EG befindet.
Käesolevaga kinnitab H3C Corporation seadme RLAN device

Eesti
vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud
[Estonian]
direktiivist tulenevatele teistele asjakohastele sätetele.
Hereby, H3C Corporation, declares that this RLAN device is in

English compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
Por medio de la presente H3C Corporation declara que el RLAN

Español
device cumple con los requisitos esenciales y cualesquiera otras
[Spanish]
disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
21
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ H3C Corporation ΔΗΛΩΝΕΙ ΟΤΙ RLAN
Ελληνική device ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ
[Greek] ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ
1999/5/ΕΚ.
Par la présente H3C Corporation déclare que l'appareil RLAN

Français
device est conforme aux exigences essentielles et aux autres
[French]
dispositions pertinentes de la directive 1999/5/CE.
Con la presente H3C Corporation dichiara che questo RLAN

Italiano
device è conforme ai requisiti essenziali ed alle altre disposizioni
[Italian]
pertinenti stabilite dalla direttiva 1999/5/CE.
Ar šo H3C Corporation deklarē, ka RLAN device atbilst Direktīvas

Latviski
1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem
[Latvian]
noteikumiem.
Lietuvių Šiuo H3C Corporation deklaruoja, kad šis RLAN device atitinka
[Lithuanian] esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
Hierbij verklaart H3C Corporation dat het toestel RLAN device in

Nederlands
overeenstemming is met de essentiële eisen en de andere
[Dutch]
relevante bepalingen van richtlijn 1999/5/EG.
Hawnhekk, H3C Corporation, jiddikjara li dan RLAN device

Malti
jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn
[Maltese]
relevanti li hemm fid-Dirrettiva 1999/5/EC.
Alulírott, H3C Corporation nyilatkozom, hogy a RLAN device

Magyar
megfelel a vonatkozó alapvetõ követelményeknek és az
[Hungarian]
1999/5/EC irányelv egyéb elõírásainak.
Niniejszym H3C Corporation oświadcza, że RLAN device jest

Polski [Polish] zgodny z zasadniczymi wymogami oraz pozostałymi
stosownymi postanowieniami Dyrektywy 1999/5/EC.
H3C Corporation declara que este RLAN device está conforme

Português
com os requisitos essenciais e outras disposições da Directiva
[Portuguese]
1999/5/CE.
22
H3C Corporation izjavlja, da je ta RLAN device v skladu z
Slovensko
bistvenimi zahtevami in ostalimi relevantnimi določili direktive
[Slovenian]
1999/5/ES.
H3C Corporation týmto vyhlasuje, že RLAN device spĺňa

Slovensky
základné požiadavky a všetky príslušné ustanovenia Smernice
[Slovak]
1999/5/ES.
H3C Corporation vakuuttaa täten että RLAN device tyyppinen

Suomi
laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä
[Finnish]
koskevien direktiivin muiden ehtojen mukainen.
Härmed intygar H3C Corporation att denna RLAN device står I

Svenska
överensstämmelse med de väsentliga egenskapskrav och övriga
[Swedish]
relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Hér með lýsir H3C Corporation yfir því að RLAN device er í

Íslenska
samræmi við grunnkröfur og aðrar kröfur, sem gerðar eru í
[Icelandic]
tilskipun 1999/5/EC.
H3C Corporation erklærer herved at utstyret RLAN device er i

Norsk
samsvar med de grunnleggende krav og øvrige relevante krav i
[Norwegian]
direktiv 1999/5/EF.
A copy of the signed Declaration of Conformity can be downloaded

from:
• http://www.h3c.com/portal/Technical_Documents
• http://www.hp.eu/certificates
Table 5 Overview of Regulatory Requirements for Wireless LANs
Frequency Band Max Power (EIRP) (mW) Indoor and

(MHz) Level Indoor ONLY Outdoor
2400 – 2483.5 100 mW X
5150 – 5350 200 mW X
23
Frequency Band Max Power (EIRP) (mW) Indoor and
(MHz) Level Indoor ONLY Outdoor
5470 – 5725 1000 mW X
NOTE:
Dynamic Frequency Selection and Transmit Power Control is required in
the 5250- to 5350-MHz and 5470- to 5725-MHz frequency range.
EU Country Restriction in 2.4GHz band

This device may be used indoors or outdoors in all countries of the
European Community using the 2.4GHz band: Channel 1-13, except
where noted below.
In France, the output power is restricted to 10 mW EIRP when the product
is used outdoors in the band 2454 - 2483.5 MHz. There are no
restrictions when used in other parts of the 2.4 GHz band.
EU Country Restriction in 5GHz band

1. In Italy the end-user must apply for a license from the national spectrum
authority to operate this device outdoors.
2. To remain in conformance with European spectrum usage laws for
Wireless LAN operation, the above 2.4GHz and 5GHz channel
limitations apply. The user should check the current channel of operation.
If operation is occurring outside of the allowable frequencies as listed
above, the user must cease operating the WA2620-AGN at that
location and consult the local technical support staff responsible for the
wireless network.
3. This device must be used with the radar detection feature required for
European Community operation in the 5GHz bands. This device will
avoid operating on a channel occupied by any radar system in the area.
24
The presence of nearby radar operation may result in temporary
interruption in communications of this device. The Access Point’s radar
detection feature will automatically restart operation on a channel free
of radar. You may consult with the local technical support staff
responsible for the wireless network to ensure the Access Point device(s)
are properly configured for European Community operation.
Table 6 Europe-Restrictions for Use of 5GHz Frequencies in European
Community Countries
Allowed Allowed
Frenquecy Channel Countries
Bands Numbers
36,38,40,44,4 Austria, Belgium, Bulgaria, Cyprus, Czech
6,48,52,54,56 Republic, Denmark, Estonia, Finland,
5.15-5.35& ,60,62,64,100 France, Germany, Greece, Hungary,
,102,104,108, Iceland, Ireland, Italy, Latvia, Liechtenstein,
5.470-5.725G 110,112,116, Lithuania, Luxembourg, Malta,
Hz 118,120,124, Netherlands, Norway, Poland, Portugal,
126,128,132, Slovakia, Slovenia, Spain, Sweden,
134,136,140 Switzerland, U.K.
WEEE Directive–2002/96/EC
25
The products this manual refers to are covered by the Waste Electrical &
Electronic Equipment (WEEE) Directive and must be disposed of in a
responsible manner.
USA Compliance information

US Federal Communications Commission
statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference
that may cause undesired operation.
RF Requirements
RF exposure Hazard Warning
This device generates and radiates radio-frequency energy. In order to
comply with FCC radio-frequency exposure guidelines for an
uncontrolled environment, this equipment must be installed and operated
while maintaining a minimum body to antenna distance of 20 cm
(approximately 8 in.)
RF Frequency Requirements
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment. This device and its antenna must not be
co-located or operating in conjunction with any other unauthorized
antenna or transmitter.
This device is for indoor use only when using channels 36, 38, 40, 44,
46 or 48 in the 5.15 to 5.25 GHz frequency range.
26
High power radars are allocated as primary users of the 5.25 to 5.35
GHz and 5.65 to 5.85 GHz bands. These radar stations can cause
interference with and/or damage this device.
Antennas
Only use the supplied antenna. Unauthorized antennas, modifications or
change to the antennas could violate FCC regulations and void the user’s
authority to operate the equipment.
Industry Canada
RF Compliance
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conform à la norme NMB-003
du Canada.
This device complies with RSS 210 of Industry Canada.
Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of this device.
L ‘ utilisation de ce dispositif est autorisée seulement aux conditions
suivantes: (1) il ne doit pas produire de brouillage et (2) l’ utilisateur du
dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu,
même si ce brouillage est susceptible de compromettre le fonctionnement
du dispositif.
The term "IC" before the equipment certification number only signifies
that the Industry Canada technical specifications were met.
To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically
27
radiated power (EIRP) is not more than that required for successful
communication. To prevent radio interference to the licensed service, this
device is intended to be operated indoors and away from windows to
provide maximum shielding. Equipment (or its transmit antenna) that is
installed outdoors is subject to licensing.
Pour empecher que cet appareil cause du brouillage au service faisant
l'objet d'une licence, il doit etre utilize a l'interieur et devrait etre place
loin des fenetres afin de Fournier un ecram de blindage maximal. Si le
matriel (ou son antenne d'emission) est installe a l'exterieur, il doit faire
l'objet d'une licence.
High power radars are allocated as primary users of the 5.25 to 5.35
GHz and 5.65 to 5.85 GHz bands. These radar stations can cause
interference with and/or damage this device.
This device must not be co-located or operated in conjunction with any
other unauthorized antenna or transmitter.
Brazil RF Compliance
Este produto está homologado pela ANATEL, de acordo com os
procedimentos regulamentados pela Resolução 242/2000 e atende
aos requisitos técnicos aplicados.
Este equipamento opera em caráter secundário, isto é, não tem direito a
proteção contra interferência prejudicial, mesmo de estações do mesmo
tipo, e não pode causar interferência a sistemas operando em caráter
primário.
Para maiores informações, consulte o site da ANATEL –
www.anatel.gov.br
28
Korea RF Compliance
This device may cause radio interference during its operation. Therefore
service in relation to human life security is not available.
Taiwan regulatory statement

1. 經審驗合格之射頻電信終端設備，非經許可，公司商號或使用者均不
得擅自變更頻率，加大功率或變更原設計之特性及功能。
2. 射頻電信終端設備之使用不得影響飛航安全及干擾合法通信；經發現
有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。所謂
合法通信，係指依電信法規定作業之無線電信。低功率射頻電機須忍
受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
3. 輸入、製造射頻電信終端設備之公司、商號或其使用者違反本辦法規
定，擅自使用或變更無線電頻率、電功率者，除依電信法規定處罰
外，電信總局並得撤銷其審驗合格證明。
4. 本機限在不干擾合法電台與不受被干擾保障條件下於室內使用。
5. 在 5.25-5.35 秭赫頻帶內操作之無線資訊傳輸設備，限於室內使用。
6. 無線資訊傳輸設備的製造廠商應確保頻率穩定性，如依製造廠商使用
手冊上所述正常操作，發射的信號應維持於操作頻帶中。
7. 為減少電磁波干擾，請妥適使用。
29
AppendixB 产品中有毒有害物质清单
全集
NOTE:
This document contains information required by the People's Republic of
China as per their legislation titled "Management Methods for Controlling
Pollution by Electronic Information Products".
产品中有毒有害物质清单全集
有毒、有害物质和元素
部件名称多溴多溴二
汞六价铬
铅 Pb 镉 Cd 联苯苯醚
Hg Cr（VI）
PBB PBDE
机箱/隔板/其他金属
X 〇〇〇〇〇
和塑料部件
印制电路板组件（PCA） X 〇〇〇〇〇
电缆/电线 X 〇〇〇〇〇
电池〇〇〇〇〇〇
风扇/风扇盘〇〇〇〇〇〇
电源/电源适配器 X 〇〇〇〇〇
CF卡〇〇〇〇〇〇
光模块 X 〇〇〇〇〇
30
汞六价铬
Hg Cr（VI）
PBB PBDE
X 〇〇〇〇〇
硬盘
X 〇〇〇〇〇
电源适配器1
X 〇〇〇〇〇
电源适配器2
X 〇〇〇〇〇
电源适配器3
X 〇〇〇〇〇
内部电源1
X 〇〇〇〇〇
内部电源2
X 〇〇〇〇〇
内部电源3
X 〇〇〇〇〇
内部电源4
X 〇〇〇〇〇
冗余电源1
X 〇〇〇〇〇
冗余电源2
X 〇〇〇〇〇
摄像机
31
汞六价铬
Hg Cr（VI）
PBB PBDE
X 〇〇〇〇〇
麦克风
X 〇〇〇〇〇
内存条
X 〇〇〇〇〇
天线
X 〇〇〇〇〇
光模块1
X 〇〇〇〇〇
光模块2
〇：表示此部件使用的所有同类材料中此种有毒或有害物质的含量均低于
SJ/T11363-2006 规定的限制要求。
X：表示此部件使用的至少一种同类材料中，此种有毒或有害物质的含量高于
SJ/T11363-2006 规定的限制要求。
注：所引用的环保使用期限标记根据产品的正常操作使用条件（如温度和湿度）
确定。
本文档中包含的信息如有更改，恕不另行通知。
中国印刷
32

Wireless H3C

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Wireless H3C

Uploaded by

Copyright:

Available Formats

H3C WA2620-AGN WLAN Access Point

Hangzhou H3C Technologies Co., Ltd.

Document version: 6PW104-20110225

Downloaded from www.Manualslib.com manuals search engine

All rights reserved

No part of this manual may be reproduced or transmitted in any form or

H3C, , Aolynk, , H3Care, , TOP G, , IRF,

The information in this document is subject to change without notice.

This product has been designed to comply with the environmental

Downloaded from www.Manualslib.com manuals search engine

Downloaded from www.Manualslib.com manuals search engine

An alert that calls attention to important information that if

An alert that contains additional or supplementary

About the H3C WA2620-AGN

Provides regulatory information and

Downloaded from www.Manualslib.com manuals search engine

Command Provide a quick reference to all

Provide information about the product

Downloaded from www.Manualslib.com manuals search engine

Downloaded from www.Manualslib.com manuals search engine

Mounting the AP ·······························································································5

Connecting to the AP····················································································· 15

AppendixA Regulatory Compliance Information ········································ 18

The LEDs indicate power and activity. See Checking the

The AP has three built-in internal antennas. In addition,

Reset Button To reset the AP.

Provides a serial interface to the AP for diagnostic use.

Wall-Mounting The combined wall-mounting bracket and table-top stand

The Suspended ceiling bracket (Ceiling bracket and

Preparing for Installation

Make sure that a standard Ethernet cable with straight-through

Power is supplied using an 802.3af Power Over Ethernet

Record the AP MAC address in a safe place before the AP is

Wall or Electrical Box Mounting

3. Place the AP and table stand on the table.

5. Slide the slider across to lock the AP to the bracket.

Power over Ethernet (PoE) from the LAN

Power over Ethernet from a PoE Injector

Green On Powered on and ready for operation

Off Radio disabled

Off Radio disabled

No 10/100/1000 BASE-T link

1000 BASE-T link detected; no

Blinking 1000 BASE-T link activity

Finding the IP Address on Networks with a

Finding the IP Address on Networks

Log into the AP

Converting your Managed AP (FIT) to a

Converting your Stand-alone AP (FAT) to a

Optional POE injector

6/8dBi Dual-Band Omni Antenna 3CWE591

18/20dBi Dual-Band Panel Antenna 3CWE596

8/10dBi Dual-Band Panel Antenna 3CWE598

Optional Antenna Cables

Ultra Low Loss 20-Foot Antenna Cable 3CWE581

Ultra Low Loss 50-Foot Antenna Cable 3CWE582

R-SMA to SMA 6” Antenna Cable 3CWE586

Regulatory compliance standards

Item Description Exclusions

3CWE590 Rubber Duck Antenna None

Must be used with 3CWE586

Must be used with 3CWE586

Must be used with 3CWE586

3Com Ultra Low Loss 6-Foot
