Powerware 9135 HARDWARE INTRODUCTION

AND TROUBLESHOOTING
(2) Driver Circuit of Battery SCR
Located at A board

RA12 RA13

SCRA3 G G
DA8

RA18 DA10 DA11

V3 UA3
1 6
JPA3 1 2 4 RA16
2 RA17
Bon1'
RA19 1 6
V3
2 4
JPA4 12 Bs' UA4

(a) During the soft-start process of cold start, Bs’ will be low to turn on SCRA5. The
Bus capacitor will be charged by battery through RA12 and RA13.
(b) After soft-start, Bs’ will be high to turn off SCRA5 and Bon1’ will be low to turn
on SCRA3. Then the input of DC-DC converter will be supplied by battery
through SCRA3.
(c) Test JUMP:
JPA3: SCRA3 will be off no matter what Bon1’ is if JPA3 is shorted
JPA4: SCRA5 will be off no matter what Bs’ is if JPA4 is shorted
