Configuration Manual For SCADA

LabVIEW 8.2
Configuration Manual for SCADA Table of Contents

Table of Contents

Chapter 1 LabVIEW 8.2 ................................................................................................... 3

1-1 OPC Server ............................................................................................................ 4
1-2 Connect OPC Client to OPC Server through LabView 8.2 ..................................... 5

2
Chapter 1
LabVIEW 8.2
Configuration Manual for SCADA LabVIEW 8.2

1-1 OPC Server

Please create tags according to the Configuration Manual.

Later, click [ File ] Æ [ Make Active ] to activate new created configuration file.

4
LabVIEW 8.2 Configuration Manual for SCADA

1-2 Connect OPC Client to OPC Server through LabVIEW 8.2

To confirm if DSC Module has already been installed, please click [ Start ] Æ [ Programs ]
Æ [ National Instruments ] Æ [ Measurement & Automation ]

Note: DSC Module (Datalogging and Supervisory Control) should be installed first, so that
OPC Client could work normally.

5
Configuration Manual for SCADA LabVIEW 8.2

[ Start ] Æ [ National Instruments LabVIEW 8.2 ] to start LabVIEW 8.2

6
LabVIEW 8.2 Configuration Manual for SCADA

Please select [ Empty Project ].

On the tree view, please click [ My Computer ] and then press the right key select [ New ] Æ
[ I/O Server ]

7
Configuration Manual for SCADA LabVIEW 8.2

Select the OPC you need and then click [ Continue ].

Please select “Modbus30DA.3”; then click [ Ok ].

8
LabVIEW 8.2 Configuration Manual for SCADA

Item “OPC1” means the OPC Server you have just selected.

Click [ Untitled Library 1 ] ; then press the right key to select [ New ] Æ [ Variable ].

9
Configuration Manual for SCADA LabVIEW 8.2

Edit the Tags’ name and data type. Then, click [ Browse…] to display all the OPC Server.

Please select “ OPC1 “ to show up the data items.

10
LabVIEW 8.2 Configuration Manual for SCADA

Set up all the parameters; then click [ OK ].

Later on, the tag, “AI_01”, you have just edited will be created.

11
Configuration Manual for SCADA LabVIEW 8.2

Click [ Untitled Library 1]; press the right key selecting [ New ] Æ [ VI ]

Drag the “AI_01” from Pronect Explorer to Block Diagram, and then move “Number
Indicator” from Controls to Front Panel

12
LabVIEW 8.2 Configuration Manual for SCADA

Create link with tag “AI_01” and Numeric.

Complete setting process.

13
Configuration Manual for SCADA LabVIEW 8.2

Run the project to confirm the program works normally.

14
