GRAPHS

1 INTRODUCTION
We have studied one non-linear data structure so far i.e Trees. A graph is another non-linear data
structure that is widely used to solve many real-life computing problems. For example, we need to use a
graph to find out whether two places on a road-map are connected and what is the shortest distance
between them. Graphs are used in simulating electrical circuits to find out current flows and voltage drops
at various points in the circuit. Graphs are widely used in telephone and computer networks.
Graphs have great historical significance too. In 1736, the famous mathematician Euler used the
concept of a graph to solve the “Koenigsberg problem”. In the small town of Koenisberg in Prussia, the
river Pregal flows around the island of Kneiphof and then divides into two. The four land areas ( A, B, C,
D) bordering the river are connected by seven bridges ( a,b,c,d,e,f,g). The problem is to find out whether
it is possible to start walking from some area, cross each bridge exactly once and return to the starting
land area. Euler used graphs to prove that this would not be possible. A walk which achieves this is called
an “Eulerian Walk”.

{{{ Diagram }}}

In this chapter, we will study this data structure, its implementation and its applications. Before that,
we will study some definitions and terminology.

DEFINITIONS AND TERMINOLOGY

Graph
A graph G is a collection of two sets V and E. V is a finite non empty set of vertices
(or nodes) and E is a finite non empty set of edges (or arcs) connecting a pair of vertices.
An edge is represented by two adjacent vertices G is represented as G = (V,E)
Example

10 - 1
 10 - 2
Graphs
V 1
G 1= ( V ,E )
V = { V 1, V 2 V 3, V 4}
V 2
V 4 E = { ( V 1, V 2) , ( V 2, V 3) }
( V 3 , V 4) , ( V 4, V 1) }
V 3

G 1

V 1
V 1 V 1

V 2
V 4 V 2 V 3
V 2 V 3

V V
3
V 4 V 5
V 6
V 7
4

G 2 G 3 G 4

Some examples of graphs

Undirected Graph
A graph is an undirected graph if the pairs of vertices that make up the edges are unordered pairs.
i.e. an edge(Vi, Vj ) is the same as (Vj, Vi). The graph G1 shown above is an undirected graph.

Directed Graph
In a directed graph, each edge is represented by a pair of ordered vertices i.e. an edge has a specific
direction.
In such a case, edge (Vi, Vj)  (Vj, Vi)
Example
V 1 V 3

V 2 V 4

G 5

Directed graph

G5 = (V,E)
V = { V1, V2, V3, V4}
E = { (V1, V2 ), (V1,V4), (V2, V4), (V1, V3) }
For an edge (Vi, Vj) in a directed graph, vertex Vi is called the tail and V j is the head of the edge. V i is
adjacent to Vj and Vj is adjacent from Vi.
 10 - 3
Graphs

Complete Graph
If an undirected graph has n vertices, the maximum number of edges it can have is
nC2 = n (n-1) / 2. If an undirected graph G has ‘n’ vertices and nC 2 edges, it is called a complete
graph.
If the graph G is directed and has n vertices, G is complete if it has n(n-1) edges.

Multigraph
A multigraph is a graph in which the set of edges may have multiple occurrences of the same edge.
Note that it is not a graph.

Degree of Vertex
The degree of a vertex in an undirected graph is the number of edges incident to that vertex.
In the undirected graph G1, the degree of each vertex = 2.
Indegree of a Vertex
If G is a directed graph, the indegree of a vertex is the number of edges for which it is head i.e. the
numbers edges coming to it.
Example In graph G5, indegree (V4) = 2
indegree (V1) = 0
A node whose indegree is 0 is called a source node.
Outdegree of a vertex
If G is directed graph, the out degree of a vertex is the number of edges for which it is the tail i.e. the
number of edges going out of it.
Example outdegree (V1) = 3
outdegree (V2) = 1
A node whose outdegree is 0 is called a sink node.

Adjacent vertices
If (Vi, Vj) is an edge in G, then we say that V i and Vj are adjacent and the edge (Vi, Vj) is incident on
Vi and Vj.

Path
A path from vertex Vp to Vq exists if there exists vertices Vi 1, Vi2, …..Vin such that there exist edges
(Vp, Vi1) , (Vi1, Vi2),………(Vin, Vq)
 10 - 4
Graphs
Length of a Path
The length of a path is the number of edges on it.
Linear Path
A linear path is a path whose first and last vertices are distinct.
Cycle
A cycle is a path whose first and last vertices are the same.
Example V1 V2 V3 V1 is a cycle in G4. A graph with no cycles is called an acyclic graph. A directed
acyclic graph is called dag.

Connected Graph
Two vertices Vi and Vj are said to be connected if there is a path in G from Vi to Vj.
Strongly Connected Graph: A directed graph G is said to be strongly connected if for every pair of
distinct vertices Vi, Vj, there is a directed path from V i to Vj and also from
Vj to Vi.
Weakly Connected Graph : A directed graph G is said to be weakly connected there exists atleast one
set of distinct vertices Vi, Vj, such that there is a directed path from Vi to Vj but no path from Vj to Vi.
Example: The following is a weakly connected graph because there is a path from V 1 to V4 but none from
V4 to V1.

V 1 V 3

V 2 V 4

G 5

Subgraph
A subgraph of G is a graph G such that V(G)  V(G) and E(G)  E(G)
Example: The subgraphs of G1 are

V V
1
V 2
3

V V
2
3 V 4

Subgraphs of G1

Forest
A Forest is defined as an acyclic graph in which every node has one or no predecessors.
 10 - 5
Graphs
Weighted Graph or Network
A number (weight) may be associated with each edge of a graph. Such a graph is called a weighted
graph or a network.
Example
The number may represent the distance, cost, etc.

V 1
10 5

V 2
V 3 V 4

4 6
Weighted Graph

Spanning Tree
When a graph G is connected, a traversal method visits all its vertices. In this case the edges of G are
partitioned into two sets.
T for the edges traversed.
B (Back edges) which were not traversed.
The edges in T form a tree which connects all vertices of graph G. Such a tree is called a spanning
tree.
A spanning tree consists of the minimum number of edges to connect all the vertices.
Example

g ra p h ( i) ( ii) ( iii )
S p a n n in g tr e e s
A graph and its spanning trees

Minimum Cost Spanning Tree

The spanning tree having the minimum sum of weights of edges is called minimum cost spanning
tree.
These weights may represent the lengths, distances, cost, etc.
Such trees are widely used in practical applications such as network of road lines between cities, etc.

Spanning Forest
A spanning forest of a graph G = ( V, E) is a collection of vertex disjoint trees Ti = (V i, Ei), 1 i  k
such that V =  Vi for all 1 i  k and Ei  E(G), 1 i  k
 10 - 6
Graphs

GRAPH REPRESENTATION
To represent a graph in memory, we will have to store data in such a way that the information about
vertices and edges can be correctly stored and it is possible to extract the required information and
manipulate it. Hence, it is important to select the correct method of implementation so that algorithms
may be applied on the graph.
Several representations for graphs are possible. However, we shall be studying only three of them.
i. Adjacency matrix
ii. Adjacency list
iii. Adjacency multilist
The choice of a particular representation will depend upon the application.

1 Adjacency Matrix
The adjacency matrix A of a graph G is a two dimensional array of n  n elements where n is the
numbers of vertices. The entries of A are defined as
A[i][j] = 1, if there exist an edge between vertices i and j in G.
A[i][j] = 0, if no edge exists between i and j.

Example

Adjacency Matrix

The adjacency matrix for an undirected graph will be a symmetric matrix. To find out whether vertex j
is adjacent to vertex i, the matrix element A[i][j] will have to be checked. If it is 0, it indicates that j is not
adjacent to i.
 10 - 7
Graphs
Class definition
The class definition for a graph represented as an adjacency matrix will be :

class graph
{
int A[10][10]; //adjacency matrix
int no_of_vertices;

public:
// member functions
}
Calculation of Degree
i. Undirected graph
From the adjacency matrix, it is very easy to calculate the degree of vertices of an undirected
graph.
The degree of vertex i is the number of 1’s in its row (or the sum of row i )
ii. Directed graph
(Indegree) For a directed graph, the indegree of vertex i is the sum of elements in column i,
i.e.total number of 1’s in column i.
(Outdegree) The outdegree of a vertex i is the sum of row i (i.e. number of 1’s in row i )

2 Adjacency List
The above method of representation has one major drawback. It uses arrays and hence is memory
inefficient.
Adjacency list is a linked representation of a graph. In this representation, there is one list for each
vertex v in the graph. Each list stores the vertices which are adjacent to vertex v. Thus, for a graph with
‘n’ vertices, there are ‘n’ lists.
Each node of the list i contains two fields - Vertex and Link:
i. Vertex - Vertex number which is adjacent to vertex i.
ii. Link - Pointer to the next node in the list.
Each list has a head node. The array of all head-nodes represents the graph.

Example:
The adjacency list for graph G6 will be
 10 - 8
Graphs
V 1 2 3 4 N ULL

V 2 1 3 N U LL

V 3 1 2 4 N ULL
V 4 1 3 5 N ULL
V 5 3 4 NU LL

Adjacency List for G6

The adjacency list for graph G7 will be

Adjacency list for G7

Node Structure
The structure definition will be
class graphnode
{
int vertex ;
graphnode *next ;
};

The graph will now be defined as an array of pointers, each pointing to a list of nodes.

class listgraph
{
graphnode *list[MAX]; //array of pointers
int n; // number of vertices
public:
//operations
};
 10 - 9
Graphs
The following program implements a graph using an adjacency list. We will have to create the list for
each vertex by accepting adjacency information from the user. Starting with vertex 1, we will build the
adjacency list till the lists for all the vertices have been created. Each list will be created in the same
manner as we created a singly linked list i.e by creating nodes and attaching them to the end of the list.

Program : Creation of Adjacency List

class listgraph; //forward declaration

class graphnode
{
int vertex;
graphnode *next;
public:
graphnode(int n=0) //constructor
{
vertex=n;
next=NULL;
}

friend class graph;

};

class listgraph
{
graphnode *list[MAX]; //array of pointers
int n; // number of vertices
public:
listgraph(int nov) //constructor
{
n=nov;
for(int j=0; j<n;j++)
list[j]=NULL;
}
void create();
void display();
};

void listgraph::create()
{
int i, j;
graphnode *temp, *newnode;
char ans;
 10 - 10
Graphs
for(i=0; i<n;i++)
{
for(j=0;j<n;j++)
{
cout<<”\nIs there an edge between vertex “ << i+1<<”and”<<j+1;
cin>>ans;

if (ans==’y’)
{
newnode=new graphnode(j+1); //call constructor

/*** Attach newnode to list i ****/

if(list[i]==NULL)
list[i]=temp=newnode;
else
{
temp->next=newnode;
temp=newnode;
}
} /* end if */
} /* end for */
} /* end for */
}

void listgraph::display()
{
graphnode *temp;
int i;
for(i=0;i<n;i++)
{
cout << endl;
cout<< "Vertex" << i+1 << “->”;
temp=list[i];
while(temp!=NULL) /** Traverse list i **/
{
cout<< "v” <<temp->vertex <<”->“;
temp=temp->next;
}
cout<<"NULL";
}
}

int main()
{
int n;
cout<<”Enter the number of vertices :";
cin>>n;
listgraph g(n);
 10 - 11
Graphs
g.create();
g.display();
return 0;
}

Inverse Adjacency List

From the adjacency list we can calculate the outdegree of any vertex i. The total number of nodes in
list ‘i’ is its outdegree.
To obtain the indegree, we can construct an inverse adjacency list. The inverse adjacency list of G 7 is
as shown.
V 1 N U LL
V 2 1 N U LL

V 3 1 2 N U LL

V 4 1 N U LL

V 5 3 4 N U LL

Inverse Adjacency list for G7

Orthogonal List
In certain applications, we may require the indegree as well as outdegree of a vertex. In such cases,
instead of maintaining two separate lists, we can use only one representation which will allow us to
calculate indegree as well as outdegree. Such a representation is called an orthogonal list.
The node structure of an orthogonal list for any directed edge (Vi, Vj) is
Vi Vj Link of Vi Link of Vj
The link of Vi points to the node where V i is the tail and link of V j points to the node where V j is the
head.

Example
1 3

H ead
1 2 3
T a il
1 1 2 1 3

2 2 3

Orthogonal List
 10 - 12
Graphs

3 Adjacency Multilist
In the above representations, an undirected edge V i, Vj will be represented twice, once in the list of V i
and once in the list for V j. To avoid redundancy, we can use an adjacency multilist where each edge is
stored only once and can be shared among more than one vertices.

An adjacency multilist consists of several lists in which nodes can be shared among several lists.
The node structure is
flag Vi Vj Path i Path j

The flag is used to indicate whether edge (Vi, Vj) has been considered or not.
Pathi is the pointer to the next edge where vertex Vi appears.
Pathj is the pointer to the next edge where Vj appears.

Example
V V 1 e1 e 2 e3
1
e1 e2
e 3
V 2
e1 e 4 e5
V e 4
V e2 e4
2 3
V 3 e6
e5 e6 e3 e5 e6
V 4
V 4

vi vj pi p i

1 2 e 2 e4 e1

1 3 e 3 e 4 e 2
V 1

1 4 e 5 e3
V 2

V 3 2 3 e5 e6 e4
V 4
2 4 e6 e5

3 4 e6

Adjacency Multilist

There are 6 edges, e1 to e6 which are <1,2> , <1,3>, <1,4>, <2,3>, <2,4> and <3,4>. The edges are
shown with Vi representing the head and Vj the tail. Pi represents the next edge where Vi is present and
Pj represents the next edge where Vj is present. For example, in the node for e 1 , Pi is e2 where vertex 1
next appears and Pj is e4 where vertex 2 next appears
To find the adjacency list for any vertex, we start traversal from the node of that vertex. For example,
if we wanted the list corresponding to vertex 1, we have to start from node V1. From that node, it
proceeds as follows:
Node V1 points to e1. In e1, the edge is (1,2). Vertex 1 is Vi. Hence , we select Pi i.e, e2.
In e2 i.e. (1,3) we take the path to e3.
 10 - 13
Graphs
In e3 i.e. (1,4) we select the path Pi i.e NULL
 V1 : e1  e2  e3  NULL

For vertex V2, we begin from edge, e1. Since 2 is Vj, we select path Pj i.e e4.
In e4, 2 is Vi. Hence we take path e5.
In e5 ,2 is Vi. Hence we reach NULL
V2 : e1  e4  e5  NULL
Similarly we get,
V3 : e2 e4  e6  NULL
V4 : e3  e5  e6  NULL

GRAPH TRAVERSALS
Traversal is the method to reach every vertex of a graph. Graph traversals are more complicated as
compared to tree traversals because a single vertex may be visited many times and the traversal may not
terminate.
Hence, we also need a method of identifying a vertex, which has been visited previously so that we
don’t keep traversing from the same vertex again and again. This can be done by using a flag ( a
variable) which will store 0 if the vertex is not visited and 1 if visited.

Two methods are used for graph traversal

 Depth First Search
 Breadth First Search

1 Depth First Search

This method is similar to the preorder tree traversal method.
Starting from a particular vertex ‘v’ which is unvisited, we visit its unvisited adjacent vertex, mark it
visited and continue in the same way from this vertex till we reach a vertex which does not have any
unvisited neighbor. That is, starting from vertex ‘v’, we follow a path in the graph as deeply as we can go
marking the vertices in the path as ‘visited’. When there are no adjacent vertices that are not visited, we
proceed backwards (back track) to a vertex in the path which has an ‘unvisited’ adjacent vertex and
proceed from this vertex. The process continues till all vertices have been visited.
The process terminates when no unvisited vertex can be reached from any of the visited vertices.

Example
 10 - 14
Graphs
V 1

V 2 V 3

V 4 V 7
V 5 V 6

V 8

Depth First Search

This algorithm can be written in two ways

i. Recursive
ii. Non recursive
i. Recursive Depth First Search
We start with vertex v and mark it visited. A vertex w, which is adjacent to v and not visited, is
selected. A recursive call is given to the Depth First Search from w. The process stops when all vertices
are visited.
We require a global array ‘visited’ of size n , which is initialized to zero.
Algorithm recDFS (int v)
// visited is a global array initialized to zero
// v is the starting vertex
{

visited [v] = 1; /* Mark v visited */

display v
for each vertex w adjacent to v do
if (w is not visited)then
recDFS (w); //recursive call
}
ii. Non Recursive Depth First Search
In the non-recursive traversal, we require a stack in order to backtrack. The process starts from vertex
v. We mark this vertex “visited” and push it into the stack. We then find an adjacent vertex w, which is
unvisited. Mark it visited and push it into the stack. This becomes our current vertex . The same process is
followed till we reach a vertex which does not have any adjacent unvisited vertex.
At this point, we pop a vertex from the stack and proceed in the same manner. The process continues
till the stack becomes empty.
Algorithm
1. Initialize visited array to 0
2. v is the starting vertex
3. Visited [v] = 1
4. display v.
 10 - 15
Graphs
5. Push v into stack
6. Search for w which is an unvisited vertex adjacent to v.
7. if w is found
visited[w] = 1
display w
push w into stack
v = w i.e. w becomes the current vertex.
Go to step 6
8. pop
v = pop
9. Continue from 5 till stack becomes empty.
10. Stop

For example, consider the graph in Fig 10.12 above. Here, we start from vertex V 1. The steps are
shown below.

v w Visited Stack
V1 V1 V1
V1 V2 V1 V2 V1 V2
V2 V4 V1V2 V4 V1V2 V4
V4 V8 V1V2 V4 V8 V1V2 V4 V8
V8 V5 V1V2 V4 V8 V5 V1V2 V4 V8 V5
V5 Not found V1V2 V4 V8 V5 V1V2 V4 Pop,pop
V8 V6 V1V2 V4 V8 V5 V6 V1V2 V4 V8 V6
V6 V3 V1V2 V4 V8 V5 V6 V3 V1V2 V4 V8 V6 V3
V3 V7 V1V2 V4 V8 V5 V6 V3 V7 V1V2 V4 V6 V3 V7
V7 Not found V1V2 V4 V8 V5 V6 V3 V7 V1V2 V4 V6 V3 Pop
V7 Not found V1V2 V4 V8 V5 V6 V3 V7 V1V2 V4 V6 Pop
V3 Not found V1V2 V4 V8 V5 V6 V3 V7 V1V2 V4 Pop
V6 Not found V1V2 V4 V8 V5 V6 V3 V7 V1V2 Pop
V4 Not found V1V2 V4 V8 V5 V6 V3 V7 V1 Pop
V2 Not found V1V2 V4 V8 V5 V6 V3 V7 Empty Pop
V1 Not found V1V2 V4 V8 V5 V6 V3 V7 Empty
 10 - 16
Graphs
DFS and Connected Components
When DFS is initiated from a vertex v, DFS visits all vertices connected to v. So, all the vertices
visited and the edges in G, which are incident on these vertices forms a connected component of G. Thus,
DFS can be used to find all connected components of G by making repeated calls to DFS.

2 Breadth First Search

The Breadth First Search ( BFS ) is the level-wise traversal of a graph. In the Breadth first search
method, we start at vertex v. Then all unvisited vertices ‘w’ adjacent to v are visited. Then the unvisited
vertices adjacent to ‘w’ are visited and so on. The process continues till there are no more unvisited
adjacent vertices left to visit.

For the above graph in Fig 3.12, BFS will yield

V1, V2, V3, V4, V5, V6, V7, V8

We require a queue to implement BFS. The method of BFS is very simple. Starting with a vertex v, we
add it to the queue. Remove v from the queue and display. All its adjacent unvisited vertices are added to
the queue. These are removed one-by-one from the queue and their adjacent unvisited vertices are added
to the queue. The process continues till the queue becomes empty.

Algorithm
1. Initialize visited array to 0.
2. v is the starting vertex.
3. Q is an empty queue.
4. Visited [v] = 1
5. Add v to queue
6. Remove v from queue and display v.
7. for all vertices w adjacent to v
if w is unvisited
add w to queue
visited[w] = 1
8. Continue from 6 till queue becomes empty.
9. Stop

The steps can be shown as follows for the graph in Fig 10.11.

v w Visited Queue
V1 V1 V1
V1 V2 V3 V1 V2 V3 V2 V3
 10 - 17
Graphs
V2 V4 V5 V1V2 V3V4 V5 V3V4 V5
V3 V6 V7 V1V2 V3V4 V5 V6 V7 V4 V5 V6 V7
V4 V8 V1V2 V3V4 V5 V6 V7 V8 V5 V6 V7 V8
V5 Not found V1V2 V3V4 V5 V6 V7 V8 V6 V7 V8
V6 Not found V1V2 V3V4 V5 V6 V7 V8 V7 V8
V7 Not found V1V2 V3V4 V5 V6 V7 V8 V8
V8 Not found V1V2 V3V4 V5 V6 V7 V8 Empty

We can also perform BFS for a graph stored as an adjacency list. The following program illustrates
this.

APPLICATIONS OF GRAPHS
Graphs can be used in various applications like
i. Representation of electric circuits. Calculation of current flows, voltage drops at various points in
the circuits.
ii. Maps indicating connectivity and distances between different places.
iii. Telephone and computer networking.
iv. Routing from one location to another.
v. Scheduling of interdependent tasks or activities in an AOV (Activity on Vertex ) Network.
vi. Computing project completion time, delays, early start and late finish times for a project, which is
made up of several tasks.
vii. Computing the critical path in an AOE (Activity on Edge) Network using CPM ( Critical Path
Method).
viii. Several sophisticated techniques like PERT ( Performance Evaluation and Review Technique),
RAMPS ( Resource Allocation and Multi-Project Scheduling) have been developed to evaluate
projects which can be represented using network models. These techniques extensively use graphs.

We will be studying some of the most commonly used applications of a graph. Finding the Minimal
Spanning tree in a graph and Computing the Shortest Path.

Connected Components and Spanning Trees

An undirected graph is said to be “connected” if every vertex is reachable from every other vertex in
the graph.
In the case of an undirected graph, a connected component of an undirected graph is a maximal
connected subgraph. This means that a connected component of an undirected graph is a connected
 10 - 18
Graphs
subgraph containing all edges incident to any of its vertices such that no vertex outside the subgraph is
reachable from any vertex in the sub graph.

A directed graph is said to be strongly connected if for every pair of distinct vertices vi and vj, there is
a directed path from vi to vj and also from vj to vi. In the following graph, there are two strongly
connected components.

2 6 5

3 4

{2,4,3} and {2,4,6}

Spanning Trees
If G is a graph containing n vertices, then the minimum number of edges needed to connect the n
vertices = n-1. All connected graphs with n-1 edges are trees. These are called spanning trees.

Definition of Spanning Tree : Let G = (V, E) be an undirected connected graph. A subgraph t = (V,
E) of G is a spanning tree of G iff t is a tree.
A minimum spanning tree is a spanning tree with the lowest number of edges.

For example, the vertices of graph G may represent cities and the edges may represent the roads
linking these cities. In order to connect all cities, we will need n-1 links. However, there may be many
feasible combinations of the total n-1 links. Thus, a graph may have many spanning trees as seen below.

Minimum Spanning Trees of (i)

DFS Spanning Tree

The spanning tree resulting from a call to DFS is known as the DFS spanning tree. The edges of G
traversed by the DFS method form a spanning tree.
BFS Spanning Tree
The spanning tree resulting from a call to BFS is known as the BFS spanning tree. The edges of G
traversed by the BFS method form a spanning tree.
 10 - 19
Graphs
V 2

V 1
V 3 V 5

V 4
V 6

If the starting vertex is V 1, The DFS of this graph is V 1 V2 V5 V3 V6 V4 and the BFS is V1 V2 V3 V4
V5 V6

In practical situations, the edges will have some weights associated with them. These may be the
distance of the link, Cost of construction etc. Thus, we may want to select the set of edges which will
result in lowest cost of construction or having minimum total length. Hence we are interested in finding
out the spanning tree having minimum total cost.
A minimum Cost spanning tree is a spanning tree whose sum of costs of the edges is minimum.

We shall be studying two algorithms for finding the Minimum Cost Spanning tree.
1. Prim’s Algorithm
2. Kruskal’s Algorithm

1. Prim’s Algorithm
This algorithm builds the minimum cost spanning tree edge by edge. The edge to be included in the
tree T is chosen according to some optimization criteria. The criterion used here, is to select the edge
(u,v) having the smallest cost such that (u,v) is not already in the tree and T U {(uv)} is also a tree. While
including (u,v) we must ensure that it does not form a cycle. The edge addition is repeated till T contains
n–1 edges.
What is done in the Prim’s method is to select a previously unselected edge having the lowest weight.
If it does not form a cycle in the graph, it is added to the tree otherwise it is rejected. The edge added to
the tree is marked as visited so that it is not selected again. The process completes when we have added n-
1 edges to the tree.

Let us apply this method to the following graph to obtain its minimum cost spanning tree.
 10 - 20
Graphs
20
v1 v2
8
7 v3
4
v7
9 6
11
v6 v5 v4
15 10
Graph for Prim’s Algorithm

Step Consider Select Spanning Tree

v1

4
1. (V1, V6) (V1, V6)

v6

v1

(V1, V2), 4
2. (V5, V6)
(V5, V6)

v6 v5
15

v1

4
(V1, V2), (V5, V7),
3. (V4, V5)
(V4, V5)

v6 v5 v4
15 10
 10 - 21
Graphs
v1

v3
(V1, V2), (V5, V7), 4
4. (V3, V4)
(V3, V4), (V4, V7)
6

v6 v5 v4
15 10

v1 v2
8
v3
(V1, V2), (V5, V7), 4
5. (V2, V3)
(V4, V7), (V2, V3)
6

v6 v5 v4
15 10

v1 v2
8
7 v3
(V1, V2), (V5, V7), 4
6. (V2, V7)
(V4, V7), (V2, V7) v7
6

v6 v5 v4
15 10
(V1, V2), (V5, V7), (V4, V7) Forms a cycle
7.
(V4, V7)
8. (V5, V7), (V1, V2) (V5, V7) Forms a cycle
9. (V1, V2) (V1, V2) Forms a cycle

The algorithm for the above method is given below

Algorithm PRIMS (E, Cost, n)

{
/* E is the set of edges in G, Cost is the adjacency cost matrix, n are the number of vertices */

T = {0}; /* Start with vertex 0 and no edges */

while (T contains less than n–1 edges)

{
 10 - 22
Graphs
select (u,v) from E such that cost [u,v] is minimum and uT and vT
If (u,v) is found then
Add v to T
else
break;
}
if (T contains fewer than n–1 edges print - No spanning tree)
}

2. Kruskal’s Algorithm
In the Prim’s algorithm studied earlier, at any stage, the set of selected edges must form a tree.
In the Kruskal’s algorithm, however, the set of edges may not be a tree at all stages. The set will
generally be a forest and can be completed into a tree iff there are no cycles in the set. The edges will be
considered one by one such that it has minimum cost among the remaining edges and does not form a
cycle.
The method is simple. The spanning tree T is constructed edge by edge. We select the edges one-by-
one. We select an unvisited edge having smallest cost and add it to the partially complete spanning tree. If
the edge forms a cycle, it is not considered. When n-1 edges have been added to the spanning tree, the
process stops.
Example
20
v1 v2
8
7 v3
4
v7
9 6
11
v6 v5 v4
15 10
Graph for Kruskal’s Algorithm

Step Consider Spanning Tree

1 (V1, V6)
v1 v2

v3
4
v7

v6 v5 v4
 10 - 23
Graphs
2. (V3, V4)
v1 v2

v3
4
v7
6

v6 v5 v4

3. (V2, V7)
v1 v2

7 v3
4
v7
6

v6 v5 v4

4. (V2, V3)
v1 v2
8
7 v3
4
v7
6

v6 v5 v4

5. (V4, V7) Forms a Cycle, Reject

6. (V4, V5)
v1 v2
8
7 v3
4
v7
6

v6 v5 v4
10
7. (V5, V7) Forms a Cycle, Reject
 10 - 24
Graphs
8. (V5, V6)
v1 v2
8
7 v3
4
v7
6

v6 v5 v4
15 10

The Algorithm can be written as follows:

Algorithm Kruskal (E, cost, n)

{
T = 0; /* start with a Tree having no edges */

While (T contains less than n–1 edges and E is not empty)

{
choose edge (u,v) from E such that cost [u,v] is minimum
delete (u,v) from E
if (u,v) does not create a cycle in T
add (u,v) to T
else
discard (u,v)
}
if (T contains fewer than n–1 edges)
Print “no spanning tree”
}

Comparing Prim’s and Kruskal’s Algorithm

Both produce identical trees when edge weights are distinct. When G is connected, Kruskal’s algorithm
cannot produce a forest. When no weights are equal, then random edge selection cannot occur.

Shortest Path
Graphs may be used to represent the road network of a state or country with the vertices representing
cities and the edges representing the connecting roads. Each edge may be assigned a weight, which may
be the distance between the two vertices or the time taken to go from one vertex to another.
A person wishing to travel from city A to city B could require the following information.
i. Is there a path from A to B?
ii. If there is more than one path from A to B, which is the shortest?
An algorithm devised by Dijkstra is a “single source all destinations” algorithm which gives the
shortest paths from a given vertex (source) to all other vertices in the network.
 10 - 25
Graphs
Inputs
1. This algorithm takes the input graphs in the form of a cost matrix which is an adjacency matrix
with each element,
A[i] [j] = cost of edge (i,j), if it exists
= infinity, otherwise
2. visited is an array of n elements which indicates whether a vertex has been visited or not.
3. dist is an array of n elements which stores the distances of all vertices from the source vertex.

Algorithm
1. V is the starting vertex
2. Initialize visited array to 0.
3. Initialize all elements of distance array as
dist [i]= cost [v] [i]
4. visited[v] = 1
5. num = 1
6. while (num < n)
{
u = choose(dist, n) ; num = num + 1;

/* choose is a function which returns u such that dist[u] = min{ dist [w]} where visited[w]
is false */

for w = 1 to n
{ if (! visited[w])
if (dist[u] + cost[u][w]<dist[w])
dist[w] = dist[u]+cost[u][w]
}
}
7. dist array contains the shortest paths from V to all other destinations.
8. Stop

Analysis
In this algorithm , the dist array initially contains distances from v to all the vertices which are
adjacent to it. The remaining are .
In the next steps, we select a vertex u, which is closest to v. Using u, find out the distances from v to
the vertices w, which are connected to u . Compare the distance vw and distance (vu)+(uw). If
this new distance happens to be less than the distance in the distance array (vw), the new distance is put
in the array. This means that there is a shorter path to a vertex w (which is adjacent to u) from vertex u as
compared to the current path from (vw)
The process continues till all vertices have been considered.
Note: This algorithm only gives the shortest distances from starting vertex v to all other vertices. It does
not store the paths to these vertices. For that, we will have to use some additional logic.
 10 - 26
Graphs

Example: Consider the 8 vertex digraph (directed graph) with cost adjacency matrix as shown
80 120 150
V1 V2 V3 V4

30 100 25
100
V 0
V 5

170 1 40 90

V 7
V 6
100
Weighted graph

0 1 2 3 4 5 6 7
0 0       
1 30 0      
2 100 80 0     
3   120 0    
4    150 0 25  
5    100  0 90 140
6       0 100
7 170       0

Starting vertex = V4 . All paths are calculated with respect to V4

Dist Array Remarks
Step Visited u
0 1 2 3 4 5 6 7
0 - -    150 0 25  
1 4 5    125 0 25 115 165 Shorter dist to 3, 6 , 7 via 5
2 4,5 6    125 0 25 115 165 No change via 6
3 4,5,6 3   245 125 0 25 115 165 Shorter dist to 2 via 3
4 4,5,6,3 7 335  245 125 0 25 115 165 Shorter dist to 0 via 7
5 4,5,6,3,7 2 335 325 245 125 0 25 115 165 Shorter dist to 1 via 2
6 4,5,6,3,7,2 1 335 325 245 125 0 25 115 165 No change via 1
7 4,5,6,3,7,2,1 0 335 325 245 125 0 25 115 165 No change via 0
8 4,5,6,3,7,2,1,0 - 335 325 245 125 0 25 115 165
 10 - 27
Graphs

Topological Sort
Graphs are commonly used for project planning which consists of many interdependent activities.
These activities are represented as vertices and the directed edges represent the order of the activities.
Such a graph is called an Activity on Vertex (AOV) network.

AOV network: A directed graph in which the vertices represent activities or tasks and the edges
represent the precedence is called an AOV network.
Vertex i in an AOV network is a predecessor of vertex j if there is a directed path from i to j. This
means that unless activity i is completed, j cannot be performed. There should be no cycles in an AOV
network i.e there should be atleast one activity which does not have a predecessor.
Example

V 2 V 2

V 1
V 4 V 1
V 4

V 3 V 3

f e a s ib le n o t f e a s ib le
AOV networks
In the first AOV network, V1 does not have any predecessor and hence it is the starting activity.
In the second network, there is a cycle i.e. each activity is dependent on some other activity. Hence
the project represented by this graph is not feasible.

Topological Sort
If we have an AOV network, then we would like to find out whether the project is feasible or not and
if it is feasible, then in what order should the activities be performed so that the project can be completed.
This can be done using a method called the “Topological Sort”.

The process of converting a set of precedences represented by an AOV network into a linear list in
which no later activity precedes an earlier one is called Topological Sorting. This method identifies the
order of the activities.
The process is very simple. We start with the activity / activities having no predecessor i.e. having
indegree 0. These are then marked as visited and pushed into a stack. We then pop an activity from the
stack, find out the activities dependent on this activity and reduce their indegrees by 1. The same process
repeats again till all the activities have been visited and the stack is empty.

Algorithm
1. Accept AOV network in adjacency list form
2. S is an empty stack
3. Search for vertex v whose indegree is 0.
 10 - 28
Graphs
4. if v is found
mark v as visited
make indegree of v = –1
push v into stack

5. If v is not found
If stack is empty
Go to 7
Else
pop v from the stack and display.
Reduce the indegree of all vertices adjacent to v by 1.
6. Repeat from step 3 till all vertices have been visited.
7. If all vertices are not visited
Display “Project not feasible”
8. Stop.

Since we need the indegree of the vertices, the node structure has to be modified. Each list will have a
head node which also stores the indegree of the vertex. We can use the first node of each list to store the
indegrees.

Example
A O V n e tw o rk A d ja c e n c y lis t
In d e g re e p tr
V 0 2 3 NULL
V 2
V 4
1

V 2
1 4 NULL

V 1 4 5 NULL
V 1
3

V 4 2 5 NULL
V 3 V 5 V 2 N U LL
5

AOV network

Vertex Indegrees
considered Remarks
No. Stack Display
V1 V2 V3 V4 V5
1 V1 -1 1 1 2 2 v1 Push v1, Make indegree -1
Pop 1, Display
2. None -1 0 0 2 2 Empty 1 Reduce indegrees of v2 and
v3
V2, v3 Push vertices with indegree =
3. -1 -1 -1 2 2 V2,V3
0, Make indegree -1
 10 - 29
Graphs
None Pop 3, Display
4. -1 -1 -1 1 1 V2 1, 3 Reduce indegrees of v4 and
v5
None Pop v2, Display
5. -1 -1 -1 0 1 Empty 1,3, 2
Reduce indegree of v4
6. V4 -1 -1 -1 -1 1 V4 Push v4, Make indegree -1
5. None -1 -1 -1 -1 0 Empty 1,3,2 ,4 Pop v4 , reduce indegree of v5
6. V5 -1 -1 -1 -1 -1 V5 Push V5
7. None -1 -1 -1 -1 -1 Empty 1,3,2,4,5 Pop V5, Display

Thus , the topological order is

V1, V3, V2, V4, V5
