SPARE PARTS LIST
BRUSHCUTTERS/CLEARING SAWS
345 FR
ACCESSORIES 345 FR
ACCESSORIES 345 FR
Ref Part No Description Remark QTY KIT
1 502 15 70-02 SUPPORT CUP 1
2 544 35 91-01 TRANSPORT GUARD 1
3 537 31 29-01 TRANSPORT GUARD 1
4 577 04 39-01 WINTER KIT 1
5 575 94 80-01 PROTECTIVE COVER 1 4
6 522 55 09-01 WINTER COVER 1 4
7 503 21 70-10 SCREW CCRPANT 3 4
ACCESSORIES 345 FR
ACCESSORIES 345 FR
Ref Part No Description Remark QTY KIT
1 502 21 60-13 ACCESSORY BAG 1
2 501 60 02-03 SCREWDRIVER 1 1
3 502 11 46-03 KEY 1 1
4 502 21 58-01 L-NYCKEL 4 mm 1 1
5 503 55 86-02 SPANNER 5 mm 1 1
6 502 28 59-01 STOP 1 1
7 501 19 22-01 TOOL CASING 1
8 537 36 21-01 COMBINATION WRENCH 1
9 531 00 92-48 FILTER OIL 1
10 503 97 64-01 GREASE 1
11 503 80 17-01 GREASE 1
ACCESSORIES 345 FR
ACCESSORIES 345 FR
Ref Part No Description Remark QTY KIT
1 503 95 43-01 TRIMMER GUARD 1
2 503 21 07-16 SCREW IHSCFT 1 1
3 503 79 88-01 BLADE 1 1
4 503 74 29-01 DECAL 1 1
5 537 28 85-01 GRASS BLADE GUARD 1
ACCESSORIES 345 FR
ACCESSORIES 345 FR
Ref Part No Description Remark QTY KIT
1 537 31 09-02 SAW BLADE GUARD 1
Spare part with Captive
2 574 55 54-01 CLAMP 1 1
Screw
3 573 99 43-04 SCREW IHSCFMO Captive Screw 2 1, 2
4 504 00 33-01 ADAPTER 1 1
5 537 21 71-04 BLADE GUARD 1 1
6 503 20 03-16 SCREW IHSCFM 4 1
7 574 03 95-01 LOCKING NUT 4 1
ACCESSORIES 345 FR
ACCESSORIES 345 FR
Ref Part No Description Remark QTY KIT
1 544 46 43-01 COMBI GUARD 1
2 537 39 63-01 SPLASH GUARD 1 1
3 503 21 07-16 SCREW IHSCFT 1 1, 2
4 503 79 88-01 BLADE 1 1, 2
5 537 38 72-01 SNAP 1 1, 2
ACCESSORIES 345 FR
ACCESSORIES 345 FR
Ref Part No Description Remark QTY KIT
1 544 84 29-01 SHREDDER BLADE KIT EU only 1
Spare part with Captive
2 544 11 87-01 CLAMP 1 1
Screw
3 573 99 43-04 SCREW IHSCFMO Captive Screw 4 1, 2
Spare part with Captive
4 544 11 88-01 BRACKET 1 1
Screw
5 573 99 43-04 SCREW IHSCFMO Captive Screw 4 1, 4
6 544 02 65-02 GRASS BLADE GUARD 1 1
7 522 82 54-01 BLADE EU only 1 1
8 510 13 94-01 SUPPORT FLANGE 1 1
9 537 19 49-01 TRANSPORT GUARD 2 1
BEVEL GEAR 345 FR
BEVEL GEAR 345 FR
Ref Part No Description Remark QTY KIT
1 502 23 52-01 GEAR ASSY 1
2 738 21 01-10 BALL BEARING 1 1
3 503 25 08-01 BEARING 1 1
4 503 26 17-01 SEALING 1 1
5 503 75 89-01 COVER WASHER 1 1
6 735 31 33-10 CIRCLIP 1 1
7 738 21 87-12 BALL BEARING 2 1
8 735 31 17-00 CIRCLIP 1 1
9 735 31 31-10 CIRCLIP 1 1
10 503 20 15-01 SCREW IHHM 1 1
11 503 20 02-25 SCREW IHSCFM 2 1
12 537 29 07-01 SP PARTS KIT 1 1
13 502 23 51-01 GEAR HOUSING 1 1
14 537 35 14-02 DRIVER 1
15 537 29 24-01 CUP 1 14
16 544 21 78-01 SUPPORT FLANGE 1
17 502 29 11-01 NUT BLADE 1
18 503 95 45-01 ATTACHMENT PLATE 1
19 537 18 95-01 SCREW 1
20 732 21 16-01 NUT 1
CARBURETOR 345 FR
CARBURETOR 345 FR
Ref Part No Description Remark QTY KIT
1 574 32 91-01 CARBURETTOR ASSY Walbro WTE 12 1
2 505 31 67-36 RING 1 1
3 575 46 37-01 LEVER 1 1
4 544 17 77-01 LEVER 1 1
5 574 35 81-01 COVER 1 1
6 503 58 43-01 COVER 1 1
7 577 01 67-01 SHAFT ASSY 1 1
8 544 04 40-01 SHAFT 1 1
9 544 97 08-01 LIMITER CAP 2 1
10 503 93 51-01 VALVE 1 1
11 537 10 96-01 VALVE 1 1
12 503 56 34-01 VALVE INLET NEEDLE 1 1
13 502 84 68-01 NOZZLE ASSY 1 1
14 502 84 69-01 PLUG 1 1
15 501 46 85-01 BALL-CHOKE FRICTION 1 1
16 504 35 09-06 GASKET 1 1, 42
17 504 13 09-06 GASKET 1 1, 42
18 577 01 66-01 DIAPHRAGM 1 1, 42
19 576 68 45-01 DIAPHRAGM ASSY 1 1, 42
20 501 46 87-01 SCREW 1 1
21 502 84 71-01 SCREW 1 1
22 501 46 69-01 SCREW 1 1
23 537 00 34-01 SCREW 1 1
24 537 00 31-01 SCREW 4 1
25 537 40 82-01 SCREW 1 1
26 501 46 84-01 SPRING 1 1
27 501 79 59-01 SPRING 1 1
28 501 66 78-01 SPRING 1 1
29 525 75 54-01 SPRING 2 1
30 544 17 76-01 SPRING 1 1
31 544 97 11-01 SPRING 1 1
32 502 84 72-01 NEEDLE 1 1
33 502 84 73-01 NEEDLE 1 1
34 577 01 68-01 FITTING 1 1
35 544 97 16-01 FITTING 1 1
36 501 66 61-01 SCREEN-INLET 1 1
37 505 52 01-25 PIN-METERING LEVER 1 1
38 502 84 74-01 LEVER 1 1
39 544 11 15-01 SCREW 1 1
40 505 42 69-01 JET 1 1
41 503 57 43-01 PLUG-WELCH 1 1
42 515 99 96-01 KIT 1
43 574 29 79-01 HOUSING 1
44 522 54 33-01 LINK 1 43
45 574 32 39-01 SHAFT 1 43
46 544 97 18-01 SPRING 1 43
47 501 02 19-01 BUSHING 1 43
48 501 02 20-01 BUSHING 1 43
49 503 51 55-01 SCREW 1 43
50 522 54 35-01 VALVE 1 43
51 537 00 34-01 SCREW 1 43
CARBURETOR & AIR FILTER 345 FR
CARBURETOR & AIR FILTER 345 FR
Ref Part No Description Remark QTY KIT
1 503 20 07-76 SCREW IHSCFM 1
2 525 28 92-01 INSULATION WALL 1
3 575 23 95-01 GROMMET 1
4 574 44 03-01 INLET PIPE 1
5 503 20 25-16 SCREW IHSCM 4
6 503 93 66-01 PRIMER HOUSING 1
7 537 04 24-07 FUEL HOSE 1
8 576 12 27-01 FRAME 1
9 576 12 37-01 FRAME 1
10 576 22 37-01 SEALING RING 1
11 574 29 79-01 HOUSING 1
12 522 54 33-01 LINK 1
13 580 80 39-01 CARBURETTOR 1
14 581 75 61-40 FUEL HOSE 1
15 523 05 68-01 FUEL HOSE 1
16 574 85 12-01 SEALING 1
17 523 04 48-01 FILTER HOLDER ASSY 1
18 522 44 99-01 CHOKE CONTROL 1
19 524 85 30-01 SPRING 1
20 503 74 01-02 SNAP 3
21 537 01 65-01 SUPPORT 1
22 574 85 13-01 COVER PLATE 1
23 503 20 07-74 SCREW IHSCFM 2
24 537 31 60-01 SCREW IHSCFM 4
25 503 26 32-04 O-RING 1
26 576 46 62-01 AIR INLET 1
27 576 47 58-01 AIR INLET 1
28 576 47 59-01 LOCKING SPRING 1
29 575 26 84-01 COVER LID ASSY 1
30 503 21 29-10 SCREW CCRPANT 4
31 510 18 97-01 FILTER COVER 1
32 574 66 80-01 FILTER 1
33 537 41 08-01 FILTER 1
34 580 45 17-01 CLIP 1
CLUTCH 345 FR
CLUTCH 345 FR
Ref Part No Description Remark QTY KIT
1 503 95 41-03 CLUTCH COVER 1
2 738 22 02-19 BALL BEARING 1 1
3 735 31 33-10 CIRCLIP 1 1
4 503 20 02-30 SCREW IHSCFM 2
5 503 20 02-20 SCREW IHSCFM 4
6 503 20 20-01 SCREW IHSCM 1
7 544 90 07-01 CLUTCH DRUM ASSY 1
8 503 95 35-01 CLUTCH ASSY 1
9 537 13 53-01 WASHER 1 8
10 503 20 18-18 SCREW EHHM 3 8
11 503 95 36-01 CLUTCH SHOE 3 8
12 537 13 54-01 BEARING BUSHING 3 8
13 503 95 37-01 CLUTCH HUB 1 8
14 505 43 53-01 CLUTCH SPRING 3 8
CRANKCASE 345 FR
CRANKCASE 345 FR
Ref Part No Description Remark QTY KIT
1 585 47 02-01 CRANKCASE ASSY 1
2 577 32 49-01 RADIAL SEAL 1 1
3 501 27 08-01 GUIDE BUSHING s/n from 20132700001 – 2 1
3 720 13 07-10 PARALLEL PIN s/n up to – 20132699999 2
4 503 25 08-01 BEARING 2 1
5 505 27 57-19 SEALING RING 1 1
6 510 24 11-01 GASKET s/n up to – 20132699999 1
6 584 46 96-01 GASKET s/n from 20132700001 – 1 1
7 725 53 31-55 SCREW IHSCM 5 1
8 510 37 60-01 WALL 1 1
9 510 17 99-01 CABLE HOLDER 1
10 525 85 84-01 SHORT CIRCUIT CABLE 1
CRANKSHAFT 345 FR
CRANKSHAFT 345 FR
Ref Part No Description Remark QTY KIT
1 577 27 48-01 CRANKSHAFT 1
2 577 32 49-01 RADIAL SEAL 1 1
3 503 25 63-01 NEEDLE BEARING 1 1
4 503 25 08-01 BEARING 2 1
5 505 27 57-19 SEALING RING 1 1
6 537 15 85-01 CUP 2
CYLINDER COVER 345 FR
CYLINDER COVER 345 FR
Ref Part No Description Remark QTY KIT
1 510 04 75-01 CYLINDER COVER 1
2 573 99 43-04 SCREW IHSCFMO Captive Screw 3
3 576 92 00-01 HEAT PROTECTOR 1
4 503 20 07-74 SCREW IHSCFM 1
5 510 42 22-01 PROTECTIVE COVER 1
6 503 20 07-74 SCREW IHSCFM 2
7 576 99 86-01 LABEL FX 1
8 576 99 86-02 LABEL FXT 1
9 576 99 86-03 LABEL RXT 1
10 576 99 86-04 LABEL RX 1
11 576 99 86-05 LABEL FR 1
CYLINDER PISTON 345 FR
CYLINDER PISTON 345 FR
Ref Part No Description Remark QTY KIT
1 577 27 49-01 CYLINDER 1
2 522 62 63-02 PISTON ASSY 1 1
3 522 62 65-01 PISTON RING 2 1, 2
4 737 44 10-00 SNAP RING 2 1, 2
5 503 25 63-01 NEEDLE BEARING 1 1
6 544 20 00-01 DECOMPRESSION VALVE 1
7 725 53 31-55 SCREW IHSCM 4
8 521 90 81-01 GASKET 1
FUEL TANK 345 FR
FUEL TANK 345 FR
Ref Part No Description Remark QTY KIT
1 503 20 02-16 SCREW IHSCFM 1
2 537 17 25-02 COVER 1
2 537 17 25-01 COVER 1
3 544 07 69-02 TANK CAP 1
4 537 18 49-01 O-RING 1
5 581 75 61-16 FUEL HOSE 1
6 537 18 49-01 O-RING 1
7 503 44 32-01 FILTER 1
8 503 23 00-11 WASHER 2
9 503 20 02-16 SCREW IHSCFM 2
10 503 94 93-01 FUEL TANK 1
11 503 22 10-12 HEXAGON NUT 2
12 537 21 99-01 HOSE GUARD 1
13 503 21 71-16 SCREW IHSCT 1
14 510 20 87-01 ANTIVIBRATION ELEMENT 2
HARNESS 345 FR
HARNESS 345 FR
Ref Part No Description Remark QTY KIT
1 504 04 52-01 HARNESS 1
1 505 40 62-01 HARNESS US 1 1
2 544 90 17-01 HIP PAD 1 1
3 503 99 61-03 BAND 1 1
4 503 99 61-01 BAND 3 1
5 537 15 35-01 STRAP 1 1
6 537 28 84-01 FRONT PIECE 1 1
7 537 28 83-01 FRONT PIECE 1 1
8 537 33 15-01 BUCKLE 1 1
9 537 11 35-01 RETAINER 1 1
10 544 96 07-02 WELT HOOK 1 1
11 502 02 29-02 HOOK 1 1, 10
12 502 02 30-02 LOCK 1 1, 10
13 502 02 38-01 SPRING 1 1, 10
14 735 31 09-20 E-CLIP 1 1, 10
15 537 30 66-01 BAG Triobalance Tool bag 1
HARNESS 345 FR
HARNESS 345 FR
Ref Part No Description Remark QTY KIT
1 505 20 42-01 HARNESS 1
2 504 54 52-01 FRONT PIECE US 1 1
3 504 54 51-01 FRONT PIECE 3 1
4 504 63 75-01 SNAP LOCKING 1 1
5 537 33 15-01 BUCKLE 1 1
6 544 90 17-01 HIP PAD 1 1
7 544 96 07-02 WELT HOOK 1 1
8 502 02 30-02 LOCK 1 1, 7
9 502 02 38-01 SPRING 1 1, 7
10 502 02 29-02 HOOK 1 1, 7
11 735 31 09-20 E-CLIP 1 1, 7
13 537 15 35-01 STRAP 1 1
14 503 99 61-04 BAND 1 1
15 537 11 35-01 RETAINER 1 1
16 503 99 61-07 BAND 1
17 505 44 46-01 BUCKLE 1
18 504 63 74-01 SNAP LOCKING 1
IGNITION SYSTEM 345 FR
IGNITION SYSTEM 345 FR
Ref Part No Description Remark QTY KIT
1 585 07 39-01 IGNITION SYSTEM FR, RX, RXT 1
FX, FXT, s/n up to –
1 525 85 00-02 IGNITION MODULE 1
20122300180
FX, FXT, s/n from
1 525 85 00-03 IGNITION MODULE 1
20122300181 –
2 576 88 95-01 SPARK PLUG CAP 1 1
3 537 32 38-01 CONTACT SPRING 1
4 503 20 07-74 SCREW IHSCFM 2
5 525 85 84-01 SHORT CIRCUIT CABLE 1
6 574 51 96-01 SPARK PLUG 1
7 537 25 63-01 GENERATOR STATOR 1
8 503 21 66-18 SCREW IHSCT 2
9 503 95 33-01 FLYWHEEL 1
10 503 81 24-01 STARTER PAWL 2 9
11 503 23 00-42 WASHER 2 9
12 501 81 99-03 SCREW 2 9
13 503 81 29-01 SPRING 2 9
14 503 22 04-01 NUT 1
MUFFLER 345 FR
MUFFLER 345 FR
Ref Part No Description Remark QTY KIT
1 522 60 98-01 MUFFLER ASSY CAT 1
2 724 12 87-59 SCREW CRPANM 1 1
3 522 60 95-01 SPARK ARRESTOR SCREEN 1 1
4 522 93 87-01 HEAT DEFLECTOR 1
5 522 95 44-01 GASKET 1
6 503 23 04-02 WASHER 1
7 503 20 07-76 SCREW IHSCFM 3
MUFFLER 345 FR
MUFFLER 345 FR
Ref Part No Description Remark QTY KIT
1 522 80 12-01 MUFFLER ASSY 1
2 522 93 87-01 HEAT DEFLECTOR 1
3 522 95 44-01 GASKET 1
4 503 23 04-02 WASHER 1
5 503 20 07-76 SCREW IHSCFM 3
SHAFT 345 FR
SHAFT 345 FR
Ref Part No Description Remark QTY KIT
1 586 26 26-07 TUBE ASSY FX, FXT 1
1 577 26 21-04 TUBE ASSY RXT, RX 1
1 577 26 21-06 TUBE ASSY FR 1
2 544 02 94-01 SPACER 1 1
3 506 11 03-01 O-RING 1 1
4 537 30 98-01 ANTIVIBRATION ELEMENT 1 1
5 537 30 97-01 TAPE 1 1
6 544 02 94-01 SPACER FR, FX, FXT 1 1
7 523 01 88-01 BEARING SHAFT FX, FXT, RX 1 1
7 523 01 88-03 BEARING SHAFT FR 1 1
8 503 92 44-03 DRIVE SHAFT FR 1
9 537 29 47-07 LABEL 1
9 537 29 47-03 LABEL US, CAN 1
SHORT BLOCK 345 FR
SHORT BLOCK 345 FR
Ref Part No Description Remark QTY KIT
1 585 45 15-01 CRANKCASE SYSTEM 1
STARTER 345 FR
STARTER 345 FR
Ref Part No Description Remark QTY KIT
1 573 96 08-01 STARTER 1
2 510 20 50-01 COOLING AIR CONDUCTOR 1
3 503 21 69-16 SCREW IHSCT 1 1
4 503 95 73-01 STARTER PULLEY 1 1
5 502 20 06-01 SPRING CASSETTE ASSY 1 1
6 503 21 29-10 SCREW CCRPANT 2 1
7 505 30 51-25 STARTER CORD 1 1
8 537 23 25-01 STARTER HANDLE 1 1
9 523 34 30-01 STARTER HOUSING 1 1
10 573 99 43-04 SCREW IHSCFMO Captive Screw 4 1
11 576 46 81-01 LABEL 1
SUSPENSION 345 FR
SUSPENSION 345 FR
Ref Part No Description Remark QTY KIT
1 503 20 02-16 SCREW IHSCFM 2
2 503 95 53-06 HOLDER ANTIVIBRATION 1
3 503 22 10-12 HEXAGON NUT 2
4 503 20 02-25 SCREW IHSCFM 2
5 537 29 97-01 ANTIVIBRATION ELEMENT 2
8 502 19 71-01 SQUARE NUT 1
9 503 85 73-02 COVER 1
12 537 19 89-05 SUSPENSION R, Rx, Magnesium 1
13 502 19 71-01 SQUARE NUT 1
14 503 85 73-02 COVER 1
15 503 95 59-06 SUSPENSION F, Fx, FxT, FR, Magnesium 1
17 515 97 98-01 SUSPENSION R, Composit 1
18 577 22 47-01 WEAR PROTECTION R 1
19 576 63 00-01 WEAR PROTECTION R 1 18
20 722 78 18-02 BLIND RIVET R 1 18
21 502 43 36-01 HANDLEBAR BRACKET R 4
22 502 43 35-01 HOLDER ANTIVIBRATION R 1
23 577 37 57-01 LOOP ASSY 1
24 537 19 79-01 BAND 1 23
25 537 20 18-03 LOOP 1 23
26 577 29 93-01 GUIDE RAIL 1 23
27 577 20 83-01 LEVER 1 23
28 537 42 73-01 NUT 1 23
29 503 20 07-25 SCREW IHSCFM 1 23
30 503 23 00-11 WASHER 1 23
31 544 25 07-01 WEAR PROTECTION 1
THROTTLE CONTROLS 345 FR
THROTTLE CONTROLS 345 FR
Ref Part No Description Remark QTY KIT
1 577 07 19-02 THROTTLE HANDLE ASSY FR 1
2 504 20 98-04 THROTTLE HANDLE ASSY 1 1
3 537 18 08-11 HANDLE HALF RIGHT 1 1, 2
4 537 18 07-11 HANDLE HALF LEFT 1 1, 2
5 537 16 07-01 STARTER THROTTLE LOC 1 1, 2
6 537 17 42-01 SPRING THROTTLE TRIG 1 1, 2
7 506 49 77-01 THROTTLE CONTROL 1 1, 2
8 537 17 43-01 SPRING 1 1, 2
9 503 21 66-18 SCREW IHSCT 2 1, 2
10 525 41 98-02 WIRING ASSY FR 1 1
11 503 21 66-16 SCREW IHSCT 1 1, 10
12 537 41 90-01 SWITCH 1
13 537 17 28-03 HANDLE 1
14 731 23 14-05 HEXAGON NUT 1
15 537 17 29-02 BRACKET 1
16 503 20 02-45 SCREW IHSCFM 1
17 725 23 82-85 SCREW EHHM 1
18 502 20 38-01 KNOB 1
19 537 12 90-01 HANDLEBAR BRACKET 1
20 502 28 21-01 WASHER 1
21 503 20 02-25 SCREW IHSCFM 2
22 505 43 33-03 HANDLEBAR 1
23 537 12 91-01 HANDLEBAR BRACKET 1
24 503 20 07-35 SCREW IHSCFM 1
25 503 22 10-13 HEXAGON NUT 1
26 537 04 83-01 CLUTCH SPRING 1
Illustrated Parts List - IPL Update
Product Name(s)
545 FX, 545 FXT, 545 RX, 545 RXT, 345 FR
Description of change
Changed article numbers
Comments
Introduced from
Serial number / Date Remark
IPL updates
Page Title Ref. New part no Name Excl. part no. Remark
no
Carburettor 14 581 75 61-40 Fuel Hose 515 98 80-01
& Air Filter Straight
Fuel Tank 5 581 75 61-16 Fuel Hose 544 29 49-32 Correct length = 260 mm
Straight
Ignition 2 576 88 95-01 Spark Plug Cap 537 23 73-01
System
Ignition 3 537 32 38-01 Contact Spring 501 48 56-01
System
Ignition 9 503 95 33-01 Flywheel 545 FX/RX/RXT, 345 FR only
System
Ignition 9 503 95 33-01 Flywheel 503 95 33-02 545 FXT only
System
Ignition 1 585 07 39-01 Ignition Module 525 85 00-01 RX, RXT, FR
System
Shaft 1 586 26 26-07 Tube Assy 577 26 21-02 FX, FXT
Form no:MERN-8SJE6Q Rev no: 4 Page 1 of 1
