DVA 410 NANSC

TECHNO POWER
TRAINING
TECHNICAL SUPPORT TEAM ESF

Wim Thijs
Technical Service Manager

Noel Moreno Oscar Navarrete Pedro De Cortes


Generators <200Kva Generators 200-800Kva Generators >800Kva
Light Towers

David Labrador David Davila


Parts Specialist Diesel Driven Pumps
AGENDA
 Monday 29th:
Factory tour
Technical Specs
DVA 410 LS E Product Training (Generator Description)

 Tuesday 1st:
Wiring diagram
Cubicle components/DSE7320 Controller introduction.

 Wednesday 2nd:
DSE Accessories

External fuel system


Alternator LSA (Theorical/Maintenance/Troubleshooting)

 Thursday 3rd:

Practical session (Engine\alternator maintenance)

AVR Setup.
Generator running test

 Friday 4th :
ATS??, Generator setup recomendations
Discussion session & Closure
PROJECT SPECIFICATIONS DVA410
PROJECT SPECTS DVA 410 Data Sheet

Generator Model: DVA 410 E LS 380/220V 50Hz AEFOS

Alternator: Leroy Sommers LSA47.2S4


 Auxiliary winding, AREP.
 Winding insulation: System 4 Agresive atmosphere
• High performance dielectric varnish
• Reinforced over-coating on main stator/rotor & sciter stator/rotor
• Protection of mecanical parts and conections of electronic components.
 Alternator voltaje regulator AVR R450.

Engine & accessories:


 Volvo TAD 1343 GE (ECU Electronic control unit EMS-2)
 Engine heaters 1000W + Selector ON-OFF
 No canopy exhaust, 35dB(A)
 No fuel tank
PROJECT SPECTS
Generator Model: DVA 410 E LS 380/220V 50Hz AEFOS
Control cubicle.
 Control Unit: DSE 7320
 Working modes: AEFOS
• AUTO mode: Mains failure or Remote Start/Stop (Factory configuration Remote S/S)
• MANUAL mode.
 Accessories:
• Fuel filling system. External fuel pump, control & power. Selector AUT-OFF.MAN
• Battery charger Deep Sea 9255 + Selector ON-OFF + Failure detection.
• Inputs module Deep Sea 2130 (4 I/O inputs – 4 Analog.inputs)
Input programmed as “Fire Alarm”.
• Outputs module Deep Sea 2157 (8 relay outputs, 4 NO, 4 changeover outputs)
PROJECT SPECTS

Generator Model: DVAS410 E LS 380/220V 50Hz AEFOS

Power cubicle.
 Terminal board : 3P + Neutral + TT
 Manual Circuit Breaker Schneider CVS 630 3P + N
CONTROL PANEL DVA410
DVA 410 CONTROL PANEL
S4 Coolant Heater switch

S3 Battery charger switch

S2 Fuel filling
AUTO/OFF/MAN

SB1 Emergency Stop

A1 Controller
DSE7320

P2 B/C Ammeter

Service Port
DVA 410 CONTROL CUBICLE LAYOUT
DVA 410 CONTROL CUBICLE LAYOUT

KA30 Fuel tank


KA46 Coolant Heater KA49 Overfill fuel level KA60 Genset in AUTO
leakage

KA6 Stop Relay

A3 DSE2130
Expansion Dig-In

KA3 Crank relay


DVA 410 CONTROL CUBICLE LAYOUT

FU1-2-3 Mains
Voltage reference

KM1 External refilling


fuel pump

QM1 External refilling


FU4-5-6 Generator fuel pump
voltage reference

FU7 Controller FU9 24VDC for relays FU13 24VDC from


FU11 Battery +
Power supply and sensors charging alternator
DVA 410 CONTROL CUBICLE LAYOUT

A2 DSE2157
Expansion Dig-Out

CB1 Battery charger

QS10 External Digital outputs


AC Supply to customer
DVA 410 POWER CUBICLE LAYOUT

TA1-2-3 Current
transformers

QS1 Main Breaker

50/51 Electronic trip unit

Main Connector
CIRCUIT BREAKER
Fundamental features

Rated voltage Ue (6).

Rated current In. (Picture Nº7, CVS100F).

Tripping-current-level adjustment ranges


for overload protection Ir or Irth and for
short-circuit protection Im,(Indicated in the
control unit).

Short-circuit current breaking rating, Icu


(Picture Nº5)
ELECTRONIC TRIP UNIT

In=630A

Neutral tripping value Shortcircuit current


Setting 3xIn
SERVICE POINTS DVA410

Volvo TAD1343GE
SERVICE POINTS
TAD1343GE

Starter Motor

Oil drain
pump

Radiator drain
valve

Oil filters
SERVICE POINTS
TAD1343GE

Charging Alternator ECU

Oil filler cap

Oil dipstick
Relief hose from
pressure cap

Fuel Prefilter
Fuel filter Crankcase breather
Water separator
SERVICE POINTS
TAD1343GE

Air filter
Alternator

Pressure cap

Filler cap

Batteries

Expansion tank Radiator


SERVICE POINTS
TAD1343GE
Alternator power
wires Turbocharger

Coolant Heater
Battery Switch
COMMITTED TO
SUSTAINABLE PRODUCTIVITY.
