Chapter 1: Migrating to Ansys Fluent 2022 R2
The purpose of the Ansys Fluent Migration Manual is to help you transition from the previous version
for the meshing mode and solution mode of Ansys Fluent. Read through the entire document to under-
stand the changes that have taken place. The information is enclosed in the following chapters:

• Fluent Release Notes (p. 3)

• Resolved Issues and Limitations in Ansys Fluent 2022 R2 (p. 25)

• New Limitations in Ansys Fluent 2022 R2 (p. 27)

• Text Command Changes in Ansys Fluent 2022 R2 (p. 29)

If you are upgrading across several releases, you may find it helpful to consult the Migration Manuals
for the intervening releases as well. You can find these in the Ansys Help on the customer site, by se-
lecting the appropriate release from the drop-down menu on the Home page.

When you write journals using this release, then you should add the text command /file/set-tui-
version "22.2" at the top of the file. This text command will help when you run the journal in a
future release, as it will hide any new text user interface (TUI) prompts that have been added and will
restore any prompts that have been removed. It is intended to help with backwards compatibility with
future releases (up to two full releases after the release the journal file was created in/for).

For information about past, present, and future operating system and platform support, see the Platform
Support section of the Ansys Website.

Note that beta features have not been fully tested and validated. ANSYS, Inc. makes no commitment
to resolve defects reported against these prototype features. Changes in the solution behavior are
sometimes expected and are not captured in this document. However, if there are solution differences
between beta features and the Release 2022 R2 standard Fluent features that concern you, contact
technical support for assistance. Your feedback is appreciated and will help us improve the overall
quality of the product.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 1
 Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
2 of ANSYS, Inc. and its subsidiaries and affiliates.
Chapter 2: Fluent Release Notes
The following sections contain release information for Ansys Fluent 2022 R2.
2.1. Supported Platforms for Ansys Fluent 2022 R2
2.2. New Features in Ansys Fluent 2022 R2
2.3. Updates Affecting Ansys Fluent 2022 R2 Code Behavior
2.4. Features To Be Removed in a Future Release

Backwards Compatibility: Ansys Fluent 2022 R2 can generally read case files and data files from all
past Fluent releases. Solver and model settings from previous case files are typically respected. However,
in some cases due to defect fixes and core improvements to improve robustness and/or performance,
convergence behavior and/or results obtained may be different. Such release-to-release changes are
documented in the Fluent Migration Manual, along with instructions to recover the previous behavior
when possible.

2.1. Supported Platforms for Ansys Fluent 2022 R2

Information about past, present, and future operating system and platform support is viewable via the
Ansys website.

2.2. New Features in Ansys Fluent 2022 R2

The following sections list the new features available in Ansys Fluent:
2.2.1. Meshing Mode
2.2.2. Solution Mode
2.2.3. Fluent Applications

2.2.1. Meshing Mode

New features available in the meshing mode of Ansys Fluent 2022 R2 are listed below.

General Notes

• In addition to the existing, separate, mesh quality and diagnostic tools, you can now access
many of the same tools and more using the new Mesh category in the ribbon. The ribbon lets
you easily perform checking and reporting on mesh statistics and diagnostics, in addition to
access to the new Diagnostics Tools dialog box. See Performing Meshing Diagnostics for details.

• Searching for and displaying items in some selection lists has been enhanced in Fluent Meshing
to support filtering and the use of wildcards. This enhancement is available in some list selection
controls in various dialog boxes such as the Display Grid dialog box, and some zone selection
lists for non-object-based dialog boxes.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 3
Fluent

The filter text entry box allows you to search and organize a list using a text string. The text
string can include wildcards and regular expressions, such as *, ?, [], Boolean NOT (^), Boolean
AND (&), as well as Boolean OR (|), which allow you to perform pattern matching. For example,
searching *let* finds surfaces such as inlets and outlets, including those with longer names,
such as "upper-inlet-5". If you have walls separated by a number, you can search example-
wall-?-23, which would show example-wall-1-23, example-wall-2-23, and so on.

Fluent Guided Meshing Workflows

• General Improvements

– Most tasks that support object-based and/or zone-based selection now support label-based
selection where applicable.

• The Watertight Geometry Workflow

– The workflow now supports multi-zone meshing when specified in the Describe Geometry
task, resulting in the addition of two multi-zone related tasks. See Describing the Geometry,
Adding Multizone Controls and Generating the Multizone Mesh for details.

Related changes to the Manage Zones task lets you insert the task prior to generating the
volume mesh so that you can perform zonal operations such as separation, cylindrical
splitting, and edge extraction. See Managing Zones for details.

– The workflow now supports creating non-conformal interfaces between objects when spe-
cified in the Describe Geometry task. See Describing the Geometry for details.

• The Fault-tolerant Meshing Workflow

– The Choose Mesh Control Options task now allows you to more easily specify wrap and
target size control files when reading existing size control files. See Choosing Mesh Control
Options for details.

– You can now more selectively update meshing objects in the Import CAD and Part Man-
agement task, increasing the speed and effectiveness of updating the task, especially for
complex geometries with numerous meshing objects. See Working with the Meshing Model
Tree for details.

You can now apply a sizing method to the gap coverings you define in the Create Gap
Cover task. See Creating Gap Covers for details.

– You can now add boundary layer controls to any newly appended replacement parts through
the Choose Part Replacement task. See Choosing Part Replacement Options for details.

– You can now create patches around any problematic contact areas using the Create Contact
Patch task when you want to avoid sharp angle meshing issues in and around contact areas
(such as between tires and the ground). See Creating Contact Patches for details.

– The Create Porous Regions task now lets you define non-rectangular porous region(s)
based on a selected object, label, or zone. See Creating Porous Regions for details.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
4 of ANSYS, Inc. and its subsidiaries and affiliates.
 New Features in Ansys Fluent 2022 R2

2.2.2. Solution Mode

New features available in the solution mode of Ansys Fluent 2022 R2 are listed below. Where appro-
priate, references to the relevant section in the User's Guide are provided.

User Experience

• You can customize the font size of the Fluent graphical user interface (GUI), allowing you to
adjust it for your operating system, screen resolution, and personal preference. The font size
is controlled by the Application Font Size field in the Appearance branch of Preferences.

• Point surface and structural point surface creation are improved with automatic snapping to
the nearest node or cell center when you pick a location using the mouse probe tool in the

graphics window—that is, either by right-clicking or setting the left-mouse-button to probe ( ).

Refer to Point Surfaces and Structural Point Surfaces in the Fluent User's Guide for additional
information.

• The Transparency toolbar button ( ) now allows you to remove transparency from a selected
surface, rather than removing all applied transparencies.

• Transcript files now record the wall-clock time taken to complete each iteration.

• You can use the new slider control to specify the transparency of global mesh displays. Refer
to Controlling Mesh Transparency in the Fluent User's Guide for additional information.

• The speed of case and data file reading from the Fluent Launcher is now comparable to that
of a session started using the command line with a journal file to read the case and data files.

• The -case and -data command line startup options allow you to launch Fluent and imme-
diately read a case and data file pair without having to use a journal file. Refer to Command
Line Startup Options in the Fluent User's Guide for additional information.

• Basic summary information is now saved in the case and mesh files including the Fluent version
last used for this file, the dimension, and total cell, face, and node counts. This summary is
available when a case or mesh file is selected in the Fluent Launcher by clicking Case/Mesh
File Info or from the File>Read>Case/Mesh Info... menu option within a running Fluent
session.

• The console can optionally be docked as a tab with warnings and errors in the Messages
dialog box, making it so that the console is viewable as a completely separate window. This
also allows for maximizing the size of the graphics window for visualization. When the console
is docked with the messages, the progress bar is located at the bottom of the Fluent window
and is always visible.

You can use this layout by selecting Console>In Message Window from the "arrange the

workspace" drop-down ( ) in the upper-right corner of the Fluent application window.

• Plane and quadric surface creation time is improved.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 5
Fluent

Files

• You can now export solution data to CGNS format on specific cell zones or surfaces, rather
than just the entire domain.

• You can now export solution data on cell zones or surfaces in EnSight DVS format.

• Writing profiles using the Write Profile dialog box is made easier with the addition of filtering
capabilities to the Values list.

• Profiles can now be visualized as a cloud of points, as shown in Figure 2.1: Preview of Profile
as a Point Cloud (Black) with Mesh Overlayed (Pastel Green) (p. 6). See Viewing Profile Data
in the Fluent User's Guide for additional information.

Figure 2.1: Preview of Profile as a Point Cloud (Black) with Mesh Overlayed (Pastel Green)

• Transient exporting to CDAT for CFD-Post & EnSight now supports the ability to export case
files only once or only when the case/mesh changes.

Solver-Meshing

• For dynamic mesh simulations, the radial basis function smoothing method is now supported
as a full feature. It is well suited for motions that undergo rotation, meshes that contain poly-
hedral cells, and/or when the smoothing zones contain deforming conformal periodic
boundaries. (Smoothing Methods)

• When defining a deforming boundary zone as part of a dynamic mesh simulation, it is now
possible to specify that the mesh motion is included in the boundary conditions. (Deforming
Motion)

• When using the unified remeshing method for a dynamic mesh simulation, the prism controls
now provide additional offset types that allow the wedge cell layers to be based on a specified
aspect ratio or smooth transition rate, rather than just a uniform height. (Prism Controls)

Cell Zones and Boundary Conditions

• For the mass-flow inlet boundary, the default value for the Direction Specification Method
has changed from Direction Vector to Normal to Boundary.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
6 of ANSYS, Inc. and its subsidiaries and affiliates.
 New Features in Ansys Fluent 2022 R2

Materials

• You can use expressions to define orthotropic thermal conductivity. Refer to Orthotropic
Thermal Conductivity for additional information.

• A graphical user interface (GUI) has been added for the NIST real gas model, and the text user
interface (TUI) has been consolidated for other density methods. Existing cases with the NIST
model are automatically migrated to the new workflow upon reading a case file. However, the
legacy TUI from previous releases remains available for backwards compatibility. (The NIST
Real Gas Models)

• The Granta MDS materials database in Fluent has been updated to the latest version by Granta,
which now also includes fluid materials such as mixtures of ethylene-glycol or propylene-glycol
with water at various ratios.

Heat Transfer/Radiation

• For transient conjugate heat transfer problems, you can now use the moving average option
as present in Data Sampling for Time Statistics to compute time averaged heat flow on the
fluid side. Upon enabling this option, Fluent automatically creates the required unsteady
datasets for each coupled wall. Time-averaged heat flow is computed at the end of each
coupling cycle. (Time Averaged Explicit Thermal Coupling)

• You can control the frequency that the radiation field is updated as the continuous phase
solution proceeds for steady and transient simulations. (Iteration Parameters For Radiation
Solve Frequency)

• You can now specify anisotropic thermal conductivity in solids where the directions follow the
curvature of the geometry using a Curvilinear Coordinate System. (Anisotropic Thermal Con-
ductivity with Curvilinear Coordinate System (CCS))

• You can now use the accelerated DO model with Soot models.

• When simulating conjugate heat transfer (CHT), you can now select a method for calculating
the heat flux that provides greater stability and robustness when a solid cell zone is defined
with highly anisotropic thermal conductivity properties (that is, a zone that has a conductivity
in one direction that is more than 100 times the value in another direction). (High Anisotropy
Heat Flux for Solid Zones)

Acoustics

• Exporting sound source data in CGNS format for the Simcenter 3D Acoustics solver by Siemens
is now enabled for polyhedral meshes. Previously, it was possible only for non-polyhedral
meshes.

• You can now have multiple active sponge layer definitions (based on the density) during a
simulation. Previously, only one sponge layer could be active. (Sponge Layers)

Turbulence

• The coefficients for the GEKO model, curvature correction coefficient, and corner flow correction
coefficient can now all be specified using an expression.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 7
Fluent

• The initial velocity field generated by hybrid initialization has been improved to be more ac-
curate for cases that have both pressure-far-field and pressure-outlet boundary conditions.

Turbomachinery

• You can now perform Aerodynamic Damping (blade flutter analysis) with the Wet Steam
model for steam turbine applications. (Aerodynamic Damping (Blade Flutter Analysis))

• As pre-requisite to some turbo features, you can create a Turbomachine Description that
contains some general information about the turbomachine being modeled. (Turbomachinery
Description)

• Complex mode shape profiles can now be replicated (expanded) using the Replicate Profile
dialog box. (Complex Mode Shape Profile Replication)

• The Create/Edit Turbo Interfaces dialog box for generating mesh interfaces has been enhanced
to provide greater ease-of-use for selecting, viewing, and filtering interfaces and interface
zones. (Creating and Editing General Turbo Interfaces)

Reacting Flows

• For the species and composition PDF transport models, the Inlet Diffusion option is no longer
available in the Species Model dialog box because it is not considered a physically plausible
boundary condition. However, you can still enable it via the define/models/species/in-
let-diffusion text command.

Discrete Phase Model

• For simulations that involve the species transport model, you can now disable the linearization
of the species source terms for the discrete phase by setting the define/models/dpm/in-
teraction/linearized-dpm-species-source-terms? text command to no.

• A Text User Interface (TUI) option has been added to disable the random diameter sampling
for the tabulated size distribution:

define/models/dpm/injections/injection-properties/set/size-distri-
bution/use-randomized-diameter-sampling?

This option can be useful in situations where the number of initial particle positions is so small
that the random sampling approach cannot accurately represent the diameter distribution of
a spray.

• For simulations that involve overset meshes, a new text command, define/models/dpm/nu-
merics/high-resolution-tracking/particle-relocation/overset-reloca-
tion-robustness-level, has been added. This command provides a trade-off between
performance and robustness when relocating particles in overset meshes.

• The tabulated specification of the particle diameter distribution is now supported for volume
injections.

• You can now print properties of selected injection(s) in the Ansys Fluent console. (Listing In-
jection Properties)

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
8 of ANSYS, Inc. and its subsidiaries and affiliates.
 New Features in Ansys Fluent 2022 R2

• For unsteady particle tracking, you can now inject wall film particles from surfaces. (Injecting
Wall Film Particles )

• For simulations that involve the dense discrete phase model (DDPM), enhanced packing limit
numerics is now fully supported. In addition to the text user interface command
define/models/dpm/numerics/enhanced-packing-limit-numerics? available
as a beta feature in the previous release, the Enhanced Numerics option has been added to
the Discrete Phase Model dialog box (Numerics tab).

• The blockage effect is now fully supported. It allows you to include the volume displacement
effect of particles in your simulation. The effect can now be enabled directly in the Discrete
Phase Model dialog box by selecting the Volume Displacement option (Physical Models
tab). (Including the Volume Displacement of Particles)

• For cases, that include inert or combusting particles, the constant-HTC, Nusselt-number, and
Gunn correlations are now fully supported for modeling heat transfer between the dispersed
and carrier phases. They were available as a beta feature in the previous release. In addition,
the Tomiyama and Hughmark correlations are now available. These models can be used for
modeling heat transfer in standard, bubbly, or dense flows. (Heat Transfer Coefficient)

• The DEFINE_DPM_BODY_FORCE user-defined function (UDF) is now supported for wall-film

particles. Previously, the UDF was only available for regular particles.

• You can now use the massless particle type with volume injections. (Point Properties for Volume
Injections)

Multiphase Models

• For the Wet Steam model, Real Gas Property (RGP) tables can now be used to determine the
fluid mixture properties when using the density-based solver.

• For VOF and mixture multiphase simulations that involve automatic pseudo-time step calcula-
tions, the advanced stepping method that takes into account viscous and surface tension time
scales along with time-step size variation controls is now available for better stability. (Text
User Interface for VOF Stability Controls)

• The semi-mechanistic boiling (SMB) model has been generalized and is no longer restricted
to meshes with y+ > 12 only. However, for better stability, it is recommended to use it for
meshes with y+ > 5.

• The following postprocessing variables have been added:

– Non-local boundary field model (NLBF) model (in the Temperature... category):

→ NLBF Averaged Temperature

– Semi-mechanistic boiling (SMB) model (in the Wall Fluxes... category):

→ SMB Nucleate Boiling Heat Flux

→ SMB Single Phase Heat Flux

See Alphabetical Listing of Field Variables and Their Definitions in the Fluent User's Guide for
their definitions.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 9
Fluent

• The particle model (ia-particle) is now supported for mixture multiphase cases to estimate
the interfacial area.

• You can now use the Higbie method for calculating the interphase mass transfer coefficients.
This method is suitable for modeling mass transfer between gas and liquid phases in the
simulation of oxygen dissolution in mixing tanks. (Higbie Model)

Population Balance Model

• For the quadrature method of moments (QMOM), a new text command, define/models/mul-
tiphase/population-balance/expert/qmom/retain-qmom-sources-for-low-
vof?, has been added. This command allows you to invoke the QMOM source calculation for
cells with low secondary phase volume fractions, which can improve solution robustness in
some cases. (Solution Strategies)

• New methods, Martinez-Bazan and Inverted U-PDF, are now available for specifying the
breakage frequency and the probability density function (PDF) of particle breakage, respectively.
The Martinez-Bazan frequency predicts the breakage frequency of parent bubbles/particles
based on the local values of a maximum stable bubble size. The Inverted U-PDF assumes that
the probability of parent bubble/particle breakage into equi-sized daughter bubbles/particles
is the highest. This has been shown to produce more physical results in simulations of certain
impeller-agitated mixing tanks. These methods are widely used in stirred tank reactors. (Mar-
tinez-Bazan Breakage Kernel, Inverted U-PDF)

Electric Potential Field Model

• The following field variables have been added (in the Potential... category):
– X Current
– Y Current
– Z Current
– dPotential/dx
– dPotential/dy
– dPotential/dz

See Field Function Definitions in the Fluent User's Guide for their definitions.

• For cases with the Include Joule Heating in Energy Equation option, the contribution from
the total heating source due to Joule heating in the domain is now reported in the Joule
Heating Source field in the Flux Reports dialog box.

Eulerian Wall Film Model

• For transient cases, you can now solve the eulerian wall film at the end of the flow time step
by entering 0 either for Per Flow Iterations in the graphical user interface (GUI) or at the
Film Solution per Flow Iterations prompt under the define/models/euleri-
an-wallfilm/solution-options text command.

• For cases that involve DPM coupling, a new option called Source Smoothing is now available
in the Eulerian Wall Film dialog box (DPM Interaction tab). When this option is enabled,
smoothing is applied to the discrete phase impingement source terms to reduce the impact
of spotty source distributions.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
10 of ANSYS, Inc. and its subsidiaries and affiliates.
 New Features in Ansys Fluent 2022 R2

Battery Model

• You can now use the Ansys Fluent built-in tool to define the cylindrical orthotropic thermal
conductivity of the battery material for all battery active zones. (Defining Cylindrical Orthotropic
Thermal Conductivity)

• For the Newman's P2D battery model, you can now include swelling effects due to battery
charge or discharge in your simulation. (Battery Swelling Model)

Structural Model for Intrinsic Fluid-Structure Interaction (FSI)

• The structural model now allows you to simulate battery cell deformation caused by electro-
chemical effects and deformation of the battery electrode layer.

Solver

• When using the density-based solver, there are additional options for FMG (Full Multigrid)
initialization to include viscous terms and volumetric reactions. (Additional FMG Initialization
Options with the Density-Based Solver)

• The Automatic Solution Initialization and Case Modification dialog box has been replaced
by a more robust interface, including a new Case Modification Manager dialog box, an asso-
ciated Auto Initialization Method dialog box, and a Modify Case dialog box. These allow for
more flexibility in defining more complicated case modification commands. (Automatic Initial-
ization of the Solution and Case Modification)

• When the SIMPLEC or PISO pressure-velocity coupling scheme is selected, you can now use
an enhanced formulation for the skewness correction that computes the pressure-correction
gradient. In a mesh with very skewed elements, the enhanced formulation may improve solver
robustness, without affecting accuracy. (User Inputs)

Density-based Solver

• An enhanced version of the Convergence Acceleration for Stretched Meshes (CASM) method
that is more robust on very high aspect ration meshes is now available. (Enhanced Convergence
Acceleration for Stretched Meshes in the Fluent User's Guide)

• High-Speed-Numerics (HSN) has been improved for better shock-capturing accuracy and
deeper iterative convergence. (Enabling High-Speed Numerics)

• The Two-Temperature equation model has been reformulated to improve its robustness and
convergence behavior. This enhancement allows the solver to operate at a more aggressive
setting from the start of the iteration to drive the solution to faster convergence (without
sacrificing accuracy) compared to prior releases. (Modeling Hypersonic Flows using the Two-
Temperature Model)

• A Partially Catalytic Wall boundary condition is now available for hypersonic flows to model
the recombination of atoms at the wall. (Partially Catalytic Boundary Conditions for Walls)

Adjoint Solver Module

• The adjoint solver has been enhanced to consider the contribution of the gradient (for example,
pressure/velocity gradient) when building the AMG matrix. The gradient contribution enhance-

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 11
Fluent

ment can be disabled by entering adjoint/expert/undo-2022r2-default-changes?

in the console.

• The adjoint solver has been enhanced to free the design tool after performing mesh modific-
ation. By freeing the design tool, the optimal displacements for the mesh won't be available.
Freeing the design tool can be disabled by entering adjoint/expert/undo-2022r2-
default-changes? in the console.

• Default settings within adjoint solution methods now specify partial as the coupling scheme.

• The adjoint solver now supports the Normal Surface Shape Sensitivity field variable within
the Sensitivities... category and the Sensitivity to Surface Shape vector field variable to be
used for postprocessing of adjoint sensitivity data.

• Postprocessing of adjoint sensitivity data is now defined within the Adjoint Postprocess Op-
tions dialog box. Within the Adjoint Postprocess Options dialog box the sensitivity orientation
for plotting adjoint sensitivity data can be specified, and the surface shape sensitivity
smoothness can be adjusted.

• Single-valued scalar user-defined expressions can now be used as adjoint observables. Addi-
tionally, volume integral and surface integral observables can be created for certain field variable
expressions (Defining Observables Using Expressions in the Fluent User's Guide).

• A remeshing option for the geometry after mesh modification is now available within the
Design Tool and Gradient-Based Optimizer dialog boxes. Additionally a smoothing option
has been added within the Mesh Quality group box of the Gradient-Based Optimizer dialog
box.

Graphics, Reporting, and Postprocessing

• 2D plots (XY plots, histograms, asd so on) are now rendered as enhanced plots, by default,
allowing you to zoom in and hover to instantly see the values at that point. Refer to Enhanced
Interactive Plots in the Fluent User's Guide for additional information.

• Line integral convolutions plots (LICs) are now available for flow field visualization. Refer to
Displaying Line Integral Convolutions (LICs) in the Fluent User's Guide for additional information.

Figure 2.2: Example LICs Plot Colored by Velocity

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
12 of ANSYS, Inc. and its subsidiaries and affiliates.
 New Features in Ansys Fluent 2022 R2

• You can now create empty iso-surfaces and iso-clips, with values outside of the current range
of the selected quantity. This can be beneficial in cases where you want to define a surface
that will become valid later in a simulation.

• You can now save images of the graphics window in GLB format.

• Steady and unsteady statistics gathered while Fluent is solving can now be computed as a
moving average, when they are set up using the Zone-Specific Sampling Options dialog box.

• You can now create mesh report definitions for the cell count (that is, the number of cells
within one or more cell zones) and/or the face count (that is, the number of faces within one
or more boundary zones). Such reports can be useful for simulations that involve adaption,
dynamic mesh remeshing, and so on. (Mesh Report Definitions)

• Light ID can now be included when saving display states for graphics objects. Refer to Con-
trolling the Display State and Modifying the View in the Fluent User's Guide for additional in-
formation.

• You can control how many points are displayed in a report plot that is being plotted in a new
Fluent session (the default is 1000 points), using the Report Plot and Data History Size field
in the Simulation branch of Preferences.

• Colors and/or realistic material colors can now be assigned to surfaces so that they always
appear consistently in subsequent displays. Refer to Realistic Rendering of Materials in the
Fluent User's Guide for additional information.

• Expression Volumes allow you to create a custom volume for the purposes of visualization.
These volumes can be complex and defined using the Fluent Expression language or they can
be as simple as specifying a cell register as the definition. You can use the Create Volume
Surface option in the appropriate cell register dialog box as a shortcut for creating expression
volumes based on cell registers. Refer to Expression Volumes in the Fluent User's Guide for ad-
ditional information.

• Animation definitions are written, by default, to the same directory as the case file. The storage
directory is saved as a relative path, which is now represented by a dot (.). The relative path
ensures that if a case file is moved or shared, the animation will still be written to a viable
directory.

Parametric Studies

• If you have an Ansys Fluent case file with input and/or output parameters, you can perform
a parametric case study directly within the Ansys Fluent interface. Both sequential and concur-
rent (on the same shared memory machines) simulations are supported. See Performing
Parametric Studies for more information.

Command Execution

• The Execute Commands dialog box (Execute Commands Dialog Box) has been improved to
allow for more complicated, multi-lined commands. In addition, you can manage your series
of commands using the Execute Commands Manager dialog box (Execute Commands Manager
Dialog Box) See Executing Commands During the Calculation for more information.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 13
Fluent

Simulation Reports

• You can choose to play AVZ animations that are embedded within your simulation reports by
hovering over and clicking on the static proxy image associated with the animation.

Turbo Workflow

• The workflow now more effectively processes Turbo Grid files, improving the default mapping
so that you are less likely to have to overwrite workflow preferences.

• The Describe Component task now contains additional context menu options for inserting
rows above and below a selected row, as well as for removing rows in the component table.
See Describing the Components of the Turbo Machine for details.

• Preferences are now available for saving task-based workflow files and for making the workflow
tasks a dockable window. See Applying Preferences to the Turbo Workflow for details.

Cell Registers

• When using a cell register based on a field variable, you now can compute the average value
and standard deviation of the field variable, and define the register to mark cells inside or
outside of a certain range defined in terms of the standard deviation, or with values below or
above a limit defined in terms of the standard deviation. (Setting Up a Field Variable Cell Re-
gister)

User-Defined Functions (UDFs)

• When defining a DEFINE_GRID_MOTION UDF, you can now use a Move_And_Project

API to specify that the motion of a boundary is to be composed of a rigid body component
while also being projected along a surface. (Example 2)

Checkpointing an Ansys Fluent Simulation

• When checkpointing a simulation while running multiple Fluent sessions with the same
working directory, you can now specify which particular session you want to exit through the
exit-fluent / exit-fluent.txt file. (Checkpointing an Ansys Fluent Simulation in the
Fluent User's Guide)

Load Managers

• The following new options are available from the command line when running Fluent under
any of the schedulers that are supported on Linux:

– You can now list all available queues.

– You can now set the working directory for the scheduler job, so that scheduler output is
written to a directory of your choice rather than the home directory or the directory used
to launch Fluent.

For details, see the Running Fluent Using a Load Manager manual.

• The following new options are available when running Fluent under Slurm:

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
14 of ANSYS, Inc. and its subsidiaries and affiliates.
 New Features in Ansys Fluent 2022 R2

– You can now use a command line option or an environment variable to set the number of
node processes per cluster node (rather than leaving it to the cluster configuration). For
details, see Submitting a Fluent Job from the Command Line and Submitting a Fluent Job
Using Fluent Launcher in the Running Fluent Using a Load Manager manual.

– You can now use a command line option to set the number of graphics processing units
(GPUs) per cluster node. For details, see Submitting a Fluent Job from the Command Line
in the Running Fluent Using a Load Manager manual.

• When running Fluent under PBS Professional, you can now specify the queue name in Fluent
Launcher. (Submitting a Fluent Job Using Fluent Launcher in the Running Fluent Using a Load
Manager manual)

Add-Ons

• For cases that involve the SOFC with unresolved electrolyte model, you can now include effects
of Knudsen diffusion in your simulation. This model offers more accurate computation of ef-
fective gas diffusion in the porous electrodes when the average pore size is similar to the
length of mean free path. (Modeling Fluid Flow, Heat Transfer, and Mass Transfer)

• For the following add-on modules, you can now compile user-defined functions directly in the
graphical user interface (GUI):

– Solid Oxide Fuel Cell (SOFC) module: in the Advanced Options tab of the SOFC Model
dialog box (Customizing the Fuel Cell and Electrolyses Module)

– Fuel Cell and Electrolysis module: in the Customized UDFs tab of the Fuel Cell and Electro-
lysis Models dialog box (Customizing the Fuel Cell and Electrolyses Module)

– PEM Fuel Cell module: in the Customized UDFs tab of the Fuel Cell and Electrolysis
Models dialog box (Customizing the PEM Fuel Cell Module)

Beta Features

• There are also some exciting new enhancements available as beta features that you may be
interested in trying out. Detailed documentation is in the Fluent 2022 R2 Beta Features Manual.

2.2.3. Fluent Applications

New features available in the client applications of Ansys Fluent 2022 R2 are listed below.

Fluent Icing

Fluent Icing allows you to easily conduct in-flight icing simulations within a dedicated Fluent
Application Client environment. The following additional functionality has been added in this
release.

• General

– Improved layouts, including console relocation to the pop-up message box. The size
of the panels is maintained across separate sessions.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 15
Fluent

– A queuing system is now supported in the initial Fluent Launcher where the Icing
workspace is selected. The queuing settings will apply to the workspaces launched by
Fluent Icing. The queuing settings can also be included in the icing command line.

• Improvements and Additions to Fluent Solver Settings

– Air conditions now presented with absolute pressure.

– Turbulence intensity and turbulent viscosity ratio are added to inlet boundary conditions.

– The density based solver (DBNS) is now an option offered in the solver type settings.

– Hybrid initialization is followed by a temperature patch operation to replace the boundary-

averaged value with the one provided in the reference conditions.

– FMG is now available as an initialization option.

• Particles

– Custom droplet distributions can now be used, edited interactively, and imported/exported
using .csv files.

– Droplet distribution computations can be set to restart from the previous size’s solution or
the uniform initial condition. Restarting usually leads to less iterations for the overall process.

– Preset Appendix O distributions are now provided as choices.

• Improvements to the Multi-Shot Remeshing Process

– Support for disabled walls is added to the remeshing process, allowing you to deactivate
certain surfaces in the model to reduce the mesh and problem size for the icing module. It
is provided as a beta feature pending extended testing.

– CAD defeaturing problem (airfoils getting thinner, etc.) associated with the repetitive
remeshing of the same uniced walls is now resolved by including both the iced and the
initial clean surfaces in the remeshing process.

• Impact Ice Density Model (Beta)

– The impact ice density model which was released as beta for Ansys FENSAP-ICE 2022 R1 is
now available in Fluent Icing. This model computes an ice density based on local droplet
impact angle and freezing fraction on the surface. You can review Fluent Icing and FENSAP-
ICE Beta Features Manual for more information.

Fluent Aero

Fluent Aero allows you to easily explore the aerodynamic performance of aircrafts under a wide
range of flight regimes, from subsonic to hypersonic conditions, all within a dedicated Fluent
Application Client environment. A streamlined workflow guides you through the creation of a
matrix of flight conditions or design points where single and multiple flight parameters, such as
angle of attack, mach number, altitude, etc., can vary. Most common models, solvers, and con-
vergence settings of Fluent are tuned using the latest best practices for external aerodynamic
problems and are available in Fluent Aero’s user interface. In this manner, simulations can be
conducted in a quick and user-friendly environment. The full capabilities of the Fluent Solution

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
16 of ANSYS, Inc. and its subsidiaries and affiliates.
 New Features in Ansys Fluent 2022 R2

workspace remain accessible when its session is displayed through Workspaces → Solution
within the Fluent Aero ribbon. Tutorials are available to provide examples on how to conduct
exploratory simulations using single and multiple flight parameters.

In this release, a broad range of features have been added and are described below.

• A new Design Points ribbon has been added to manage the generation and calculation of
design points in the Design Points Table and to monitor their status.

• A new Parameter Search beta feature has been implemented to search for an input parameter
that satisfies a target output parameter. Currently, this feature searches for an angle-of-attack
that meets a target lift force or lift coefficient.

• Turbulence boundary conditions can now be applied to all inlet boundaries directly from Fluent
Aero.

• Selected airflow properties are now considered during the calculation of CFD boundary condi-
tions when Reynolds number, Mach number, Total Pressure or Total Temperature are set
as input parameters. This enhances consistency between airflow properties at the boundary
surfaces and within the computational domain.

• Single design point simulations can now be calculated using python scripts in full batch mode
(without the user interface displayed). Multiple design point simulations can still be calculated
using python scripts in interactive batch mode (with the user interface displayed).

• A beta feature has been added to export Fluent Aero’s results to an advanced .aero file
compatible with STK Aviator. This allows the performance of the aircraft to be defined by
Fluent Aero’s CFD calculations.

• The console logs of the client (Fluent Aero) and the server (Fluent Solution) have been combined
into a single console window. This provides better monitoring of the sequence of operations
done between the client and the server. Furthermore, layout controls have been added to
hide or display the console.

• Cluster scheduler settings, such as Slurm settings, can now be applied directly in the initial
Fluent Launcher panel that opens Fluent Aero. These settings are automatically stored and
used when the user later creates or opens a simulation within Fluent Aero, resulting in a more
user-friendly experience.

Fluent Materials Processing

Many of the powerful features of Ansys Polyflow are now available directly in Ansys Fluent
through the new Fluent Materials Processing workspace. The Fluent Materials Processing workspace
is a means to explore manufacturing applications such as polymer extrusion, blowmolding, fiber
spinning, etc. within the Fluent environment. The workspace supports:

• Extrusion / Fiber spinning

• Blow Molding / Thermoforming

• Pressing / Forming

• 2D planar, 2D axisymmetric, Shell, and 3D geometries

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 17
Fluent

• Steady-state, Time-dependent / Transient, and Generalized Newtonian (isothermal & non-iso-

thermal) flows.

• Other features such as Film Casting, Porous Media, Mesh Superposition Technique, and Vis-
coelastic models are available as beta features.

See Fluent Materials Processing Workspace for more information.

2.3. Updates Affecting Ansys Fluent 2022 R2 Code Behavior

The following sections list the code changes in Ansys Fluent 2022 R2.
2.3.1. Meshing Mode
2.3.2. Solution Mode
2.3.3. Fluent Applications

General

2.3.1. Meshing Mode

This section contains a list of code changes implemented in the meshing mode of Ansys Fluent 2022
R2 that may cause behavior and/or output that is different from the previous release.

Mesh Generation

• For the Watertight Geometry Meshing workflow, periodic improvements have been made such
that, after volume meshing, periodic boundary names are processed with a "periodic-" prefix
followed by the name of adjacent cell zone, instead of the previous numbering scheme, making
for an enhanced user experience especially when working with complex models.

• The enhanced orthogonal quality definition is now improved to better represent the quality
of the mesh.

• Changes have been introduced to better handle cases containing surface bodies defined in
SCDM/DM. These changes may impact existing journals and/or workflow files where corrections
were made to region assignments, as those corrections may no longer be necessary.

• For the Fault-tolerant Meshing workflow, improvements have been made to the Choose Part
Replacement Options task. For instance, soft size controls are now applied to scaled bound-
aries, zone naming is more consistent for porous objects, and scoped size controls that are
not valid are now filtered out.

• For the Fault-tolerant Meshing workflow, improvements have been made to the Choose Part
Replacement Options task. For instance, soft size controls are now applied to scaled bound-
aries, zone naming is more consistent for porous objects, and scoped size controls that are
not valid are now filtered out.

• The following changes are made to the Rapid Octree mesher:

– The user interface is improved: the Rapid Octree dialog box now has labels that are more
user-friendly; and text commands are now available that allow you to list all size function

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
18 of ANSYS, Inc. and its subsidiaries and affiliates.
 Updates Affecting Ansys Fluent 2022 R2 Code Behavior

definitions, as well as to change and/or delete individual size function definitions (previously
this was only possible through the Rapid Octree dialog box).

– The Boundary Projection treatment is improved to better handle small faults in the
boundary geometry. Note that because of this improvement, you are no longer prompted
by a Question dialog box to indicate your approval to continue the meshing process for
problematic geometries.

– When using the Bound by Bounding Box volume specification, the default names for the
face zones that are created for the sides of the bounding box are now tunnel-<dom_ext>,
where <dom_ext> represents the domain extent (tunnel-xmax, tunnel-xmin, tunnel-ymax,
and so on). Previously, the names were wall-<ID>. To use the previous naming convention,
enter the following text command prior to meshing: file/set-tui-version "22.1".

For details about the Rapid Octree mesher, see Generating Rapid Octree Meshes in the Fluent
User's Guide.

2.3.2. Solution Mode

This section contains a list of code changes implemented in the solution mode of Ansys Fluent 2022
R2 that may cause behavior and/or results that are different from the previous release.

Solver-Meshing

• When you enable remeshing for a dynamic mesh simulation, the unified remeshing method
is now selected by default (instead of methods-based remeshing). The unified remeshing
method simplifies the setup and can provide increased robustness, especially for parallel sim-
ulations. The use of this method is controlled by the following text command: define/dy-
namic-mesh/controls/remeshing-parameters/unified-remeshing?. Answer
no to revert to the default behavior of the previous release (for example, for a mesh that re-
quires the 2.5D remeshing method), and then enable the relevant methods using the
define/dynamic-mesh/controls/remeshing-parameters/remeshing-methods
text command; or answer yes to take advantage of the unified remeshing method for a case
file created using a previous release. For details about dynamic mesh remeshing, see
Remeshing.

• The algorithm for the polyhedral unstructured mesh adaption (PUMA) method is enhanced so
that it is no longer necessary to encapsulate all child cells of a refined parent to its respective
partition in parallel. By default this encapsulation is now disabled; this improves the load balance
of cells across partitions, particularly for higher levels for refinement. The encapsulation is
controlled by the following text command: mesh/adapt/set/encapsulate-children?;
answer yes to revert to the default behavior of the previous release (for example, for a case
that is negatively impacted because it undergoes frequent dynamic adaption), or answer no
to take advantage of this improvement for a case file created using a previous release. For
details about adaption, see Adapting the Mesh.

• When using the predefined criterion to adapt the mesh of a combustion simulation along a
progressing flame front, the field variable cell registers automatically defined now use limits
that are based on the standard deviation of the field variables rather than isovalues, and the
gradient of temperature is used rather than the curvature. This should reduce the overall cell
count, without affecting the accuracy. To revert to the cell register definitions from the previous

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 19
Fluent

release, enter the following text command prior to selecting the adaption criterion: file/set-
tui-version "22.1".

• The enhanced orthogonal quality definition is now improved to better represent the quality
of the mesh. For further details about this definition, see Mesh Quality.

• The gap model (used to simulate flow through narrow gaps that open or close) is improved,
as the parameters used to mark fluid cells for flow blockage / deceleration are now tuned to
promote better performance. Consequently, the gap shapes that result may be different when
compared to the previous release. To revert to the marking behavior and performance of the
previous release, enter the following Scheme command in the console: (rpsetvar 'narrow-
gaps/marking/smoothing-by-adjacent-cells? #t). For further details about the
gap model, see Controlling Flow in Narrow Gaps for Valves and Pumps.

Solver-Numerics

• When using the pressure-based solver, the auto select option for the mass flux computation
is improved (with regard to the criteria used to decide which Rhie-Chow formulation is more
likely to be robust for the flow models and mesh attributes of your case) and is now enabled
by default. This option is defined using the following text command: solve/set/flux-
type; answer no to the first prompt if you read a mesh file and want to revert to the default
behavior of the previous release (and then enter your preferred flux type in the prompt that
follows), or answer yes to the first prompt if you want to take advantage of this improved
option for a case file created using a previous release.

Note that if you enabled the auto select option in a case file saved in a previous release, the
Rhie-Chow: distance based option is no longer automatically selected for all cases that use
a compressible fluid when you read it with release 2022 R2, but is now automatically selected
only for the following combination: a transient simulation that uses a Scale-Resolving Simulation
(SRS) model, a compressible fluid, and an adapted mesh. If the automatically selected flux type
changes for your case (as noted in an Information dialog box that opens when you read the
case file) and you want to revert to the less robust flux type used in a previous release, enter
the following text command: solve/set/flux-type no 0.

For further details about the mass flux settings, see Mass Flux Types.

• The default convergence criterion for locally scaled residuals for transient flows is increased
from 10-5 to 10-4 in order to reduce the number of iterations required within a single time
step. You can use the following text command if you want to revert this setting for a mesh
file to the value used in the previous release, or if you want to specify the new value for a case
file created in a previous release: solve/monitors/residual/convergence-criteria.

• To improve usability, the input control for defining the Pseudo Time Method in the Solution
Controls task page is no longer a check box that is enabled / disabled, but is now a drop-
down list from which you can select Off, Global Time Step, or Local Time Step. The following
also changed as part of this improvement: for the Local Time Step method, the Under-Relax-
ation Factors group box in the Solution Controls task page is now renamed Pseudo Time
Under-Relaxation Factors; and for the VOF model, the Pseudo-Transient Stabilization option
in the Stabilization Methods dialog box is now renamed Pseudo Time Stabilization.

Note that as part of the enhancements to the pseudo time methods, it is possible that the
pseudo time method settings will change for cases that were created using release 16.0 or

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
20 of ANSYS, Inc. and its subsidiaries and affiliates.
 Updates Affecting Ansys Fluent 2022 R2 Code Behavior

older (such as whether Global Time Step is selected from the Pseudo Time Method drop-
down list, and how the Expert tab of the Advanced Solution Controls dialog box is set up),
and would need to be adjusted if you want to reproduce the previous solution behavior.

For further details about the pseudo time methods, see Performing Calculations with a Pseudo
Time Method.

Cell Zones and Boundary Conditions

• By default, the shadow zones for conformal periodic boundary zone pairs are now shown in
any list of boundary zones presented by the user interface. Like the primary periodic zone, the
shadow zone is of type periodic. When a new conformal periodic boundary zone pair is created,
the shadow zone retains its original name or (if it uses a default name) is renamed automatically
as periodic-<ID>; if you read a case file created in a previous release, the name of the shadow
zone is the primary zone name with -shadow appended to it. To revert to the behavior in
previous releases, enter the following text command: mesh/show-periodic-shadow-
zones? no. For further details on periodic boundary zone pairs, see Creating Periodic Zones
and Interfaces.

• The solution results may now be more accurate for a transient case that has a porous media
cell zone adjacent to a velocity inlet or mass-flow inlet boundary condition, due to a correction
in the pressure treatment at such boundaries. Cases that are unaffected by this correction are
those that use PRESTO! for the pressure discretization scheme and/or those in which you have
used the following text command to disable the extrapolation of pressure on flow inlets:
solve/set/bc-pressure-extrapolations. For further details about porous media
cell zones, see Porous Media Conditions.

Turbulence

• For the Synthetic Turbulence Generator (STG), frequencies of individual harmonics are now
stabilized by a time averaging procedure. This prevents corruption in the phase of the STG
harmonic function when inlet velocity is not constant in time (pressure inlet or velocity inlet
with a time-dependent inlet velocity). To revert to the previous behavior, use the following
command: (rpsetvar 'synthetic-turb/stg/incremental-time-argument?
#f).

Turbo Workflow

• When using the Describe Component task in the Turbo Workflow, the default value for the
Tip Gap? option is now automatically set to No for stators and Yes for rotors. In addition, if
the Tip Gap? option is set to Yes for a stator region, it will be considered to be a hub gap
with a moving boundary condition assigned to the associated hub surface.

Discrete Phase Model

• In cases that involve Lagrangian wall film (LWF) particles, the LWF particles are no longer in-
cluded in the DPM concentration calculation. Consequently, when postprocessing the DPM
Concentration field variable, the solution results will now be more realistic. If you want to
include the LWF particles in the DPM concentration calculation, you can use the
define/models/dpm/options/include-lwf-particles-in-dpm-concentration?
text command.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 21
Fluent

Multiphase Models

• For the semi-mechanistic boiling (SMB) model, a few improvements have been implemented,
especially in the calculations of reference quantities and wall evaporation. The solution results
are now expected to be more accurate.

• The algorithm of the non-local boundary field model (NLBF) model has been improved. This
will result in more accurate predictions of line-averaged temperature in boiling cases that use
the NLBF correction.

Eulerian Wall Film Model

• The default impingement model of the EWF model has been changed to the Ansys Fluent
model described in The Stanton-Rutland Model in the Fluent Theory Guide to provide the same
solution results as those for the Lagrangian Wall Film model. Previously, the default impingement
model was based on the original model by Stanton and Rutland (see D. W. Stanton and C. J.
Rutland "Modeling Fuel Film Formation and Wall Interaction in Diesel Engines", SAE Paper
960628, 1996). If you are observing significant changes in results, you can revert to the old
default impingement model by issuing the following Scheme command in the Ansys Fluent
console:
(enable-impinge-stanton-rutland #t)

Parallel Processing

• For Fluent sessions that use a small number of solver processes, the reading of large mesh or
case files is now faster (up to 48% faster).

• For cases with large numbers of cell zones, the calculations of the Algebraic Multigrid (AMG)
solver should now be faster when running with a large number of solver processes (approxim-
ately 100 processes or more). The solutions may be calculated on the order of 5% faster.

When using parallel Fluent on Linux, the default version of the Intel message passing interface
(MPI) is now upgraded to 2021 update 3. Two known limitations for this MPI are:

1) Memory consumption increases by about 100-150 MB for each MPI process. If this memory
increase cannot be tolerated, you can attempt to revert to Intel MPI 2018 using a fallback
feature, as described in the Intel 2018 Message Passing Interface Fallback.

2) On some old CPUs, the affinity settings applied by the new default MPI may cause a per-
formance degradation. In such scenarios, expected performance can be recovered by selecting
the Fluent-managed process affinities as described in Parallel Options.

User-Defined Functions (UDFs)

• The thermal conductance (the product of the heat transfer coefficient (h) and the interfacial
area (A)) is now stored directly in the Trackt_Particle structure and can be accessed/mod-
ified in a UDF through the variable tp->htcA. In previous releases, it was stored in the DPM-
sources structure. Existing UDFs that use the old variable location tp->source.htcA
must be updated to instead use the new variable tp->htcA. The contribution from this
variable to the linearized part of the DPM source term is now handled internally by Ansys
Fluent. The variable has units of W/K.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
22 of ANSYS, Inc. and its subsidiaries and affiliates.
 Features To Be Removed in a Future Release

2.3.3. Fluent Applications

This section contains a list of code changes implemented in the client applications of Ansys Fluent
2022 R2 that may cause behavior and/or output that is different from the previous release.

2.4. Features To Be Removed in a Future Release

This section contains a list of features that are supported in Release 2022 R2, but will be removed in a
future release of Ansys Fluent. It is recommended that you begin to migrate any cases that use these
features at your earliest convenience.

Solution Mode

• The use of mesh interfaces created with the many-to-many interface method will not be supported
in a future release. It is recommended that you migrate your cases to use the default one-to-one
interface method through the following text command: define/mesh-interfaces/one-
to-one-pairing? yes. For a list of the advantages of using the one-to-one method, see
Using a Non-Conformal Mesh in Ansys Fluent in the Fluent User's Guide. Note that the automatic
naming convention for mesh interfaces may be different with the one-to-one method, as described
in Interface Zones Automatic Naming Conventions in the Fluent User's Guide.

• The contact marks method for flow control (available when contact detection is enabled in a
dynamic mesh simulation) is deprecated and will be removed in a future release. It is recommen-
ded that you disable flow control and use the gap model instead. Flow control can be disabled
using the following text command: define/dynamic-mesh/controls/contact-para-
meters/flow-control? no. The gap model can then be set up through the following text
command menu: define/gap-model/. For details on the gap model, see Controlling Flow
in Narrow Gaps for Valves and Pumps in the Fluent User's Guide.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 23
 Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
24 of ANSYS, Inc. and its subsidiaries and affiliates.
Chapter 3: Resolved Issues and Limitations in Ansys
Fluent 2022 R2
For lists of issues that have been resolved in the meshing mode and solution mode of Ansys Fluent
2022 R2, see the Resolved Issues and Limitations document.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 25
 Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
26 of ANSYS, Inc. and its subsidiaries and affiliates.
Chapter 4: New Limitations in Ansys Fluent 2022 R2
For lists of new or recently discovered limitations known to exist in the meshing mode and solution
mode of Ansys Fluent 2022 R2, see the Known Issues and Limitations document.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 27
 Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
28 of ANSYS, Inc. and its subsidiaries and affiliates.
Chapter 5: Text Command Changes in Ansys Fluent
2022 R2
The following sections list the text command changes in Ansys Fluent 2022 R2.
5.1. Meshing Mode
5.2. Solution Mode

5.1. Meshing Mode

Changes to each of the text command menus are listed. Note that a modified text command may have
new, revised, and/or removed prompts, while a new text command is one that did not exist in previous
releases of the meshing mode of Ansys Fluent.

diagnostics/

manage-summary (New)

Allows you to manage the contents of the diagnostics summary (to be printed to the console
using the perform-summary command. You are presented with a collection of prompts for
diagnostic tests that you can include in or exclude from the summary. For instance, you can
determine whether or not to check the face quality, set the maximum face skew limit, check
the cell quality, check for free faces, check face self proximity, and so on. By default, all diagnostic
test prompts are set to yes, with the maximum face skewness limit is set to 0.99, the minimum
cell orthogonal limit is set to 0.01, and the maximum aspect ratio limit is set to 10000.

diagnostics/

modify-defaults (New)

Allows you to change the default values for the number of plot partitions (from 10), the auto-
matic delta range (set to 0.05), and the clip cluster view factor (set to 1).

diagnostics/

perform-summary (New)

Generates a mesh diagnostics summary and prints it to the console. The level of detail in the
printed diagnostic summary is controlled by the manage-summary command, however, by
default, the summary includes surface and volume mesh details such as the total number of
faces, maximum skewness, minimal cell orthogonal limit, maximum aspect ratio, and so on.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 29
Text Command Changes in Ansys Fluent 2022 R2

diagnostics/

set-scope (New)

Allows you to define the extent of the meshing diagnostics. You can choose to set the diagnostics
scope to selected objects or not, and specify corresponding face and cell zones as needed.

mesh/rapid-octree/mesh-sizing/

boundary-layers (Deleted)

This text command is replaced by mesh/rapid-octree/mesh-sizing/surface-

coarsening-layers.

mesh/rapid-octree/mesh-sizing/

buffer-layers (Deleted)

This text command is replaced by mesh/rapid-octree/mesh-sizing/mesh-coarsen-

ing-exponent.

mesh/rapid-octree/mesh-sizing/

change-surface-sizing (New)

Changes a size function definition. This text command is only available when the Boundary
Projection treatment is selected through the /mesh/rapid-octree/boundary-treatment
text command.

mesh/rapid-octree/mesh-sizing/

delete-surface-sizing (New)

Deletes a single size function definition. This text command is only available when the Boundary
Projection treatment is selected through the /mesh/rapid-octree/boundary-treatment
text command.

mesh/rapid-octree/mesh-sizing/

list-surface-sizings (New)

Lists all of the size function definitions. This text command is only available when the Boundary
Projection treatment is selected through the /mesh/rapid-octree/boundary-treatment
text command.

mesh/rapid-octree/mesh-sizing/

mesh-coarsening-exponent (New)

Controls the transition from fine cells near the surfaces to the coarse cells deeper in the fluid
volume. Enter 0 for the fastest possible transition, or higher numbers for a slower transition; as
the value increases, so too will the thickness of cell layers of the same size at each stage of the
transition. The number of layers at each intermediate stage of coarsening will be at least 2 to
the power of the number you enter here.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
30 of ANSYS, Inc. and its subsidiaries and affiliates.
 Solution Mode

mesh/rapid-octree/mesh-sizing/

surface-coarsening-layers (New)

Sets the minimum number of layers of constant-size cells that are added to the layer adjacent
to the surfaces of the geometry. These cells are generally isotropic, with the dimensions determ-
ined by the surface mesh.

5.2. Solution Mode

Changes to each of the text command menus are listed. Note that a modified text command may have
new, revised, and/or removed prompts, while a new text command is one that did not exist in previous
releases of Fluent.

define/

curvilinear-coordinate-system/ (New)

Enters the curvilinear coordinate system menu.

define/curvilinear-coordinate-system/

calculation-settings (New)

Specifies settings for the diffusion-based direction calculations.

define/curvilinear-coordinate-system/

delete (New)

Deletes a curvilinear coordinate system.

define/curvilinear-coordinate-system/

edit (New)

Edits a previously defined curvilinear coordinate system.

define/curvilinear-coordinate-system/

new (New)

Creates a new curvilinear coordinate system.

define/dynamic-mesh/controls/remeshing-parameters/prism-controls/

add (Changed)

A new offset-type setting is available in this text command, along with new related settings
named first-aspect-ratio and transition-rate. Together, these provide new ways
to specify how the first layer of wedge cells (adjacent to the boundary zone) are generated for
the prism controls definition during remeshing.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 31
Text Command Changes in Ansys Fluent 2022 R2

define/dynamic-mesh/controls/remeshing-parameters/prism-controls/

edit (Changed)

A new offset-type setting is available in this text command, along with new related settings
named first-aspect-ratio and transition-rate. Together, these provide new ways
to specify how the first layer of wedge cells (adjacent to the boundary zone) are generated for
the prism controls definition during remeshing.

define/dynamic-mesh/controls/smoothing-parameters/

smoothing-method (Changed)

A new radial method is available, which allows you to specify that the smoothing is based
on a radial basis function interpolation.

define/dynamic-mesh/zones/

create (Changed)

When creating or editing a dynamic zone for a boundary zone with the motion type set to de-
forming, a new prompt is included that allows you to specify whether to exclude the mesh
motion from contributing to the boundary conditions.

define/mesh-interfaces/

one-to-one-pairing? (Changed)

If you answer no to this text command, a new prompt now warns you that the many-to-many
interface method will not be available in a future release of Fluent and verifies if you want to
proceed.

define/models/acoustics/sponge-layers/

add (Changed)

When you use this text command to add an additional sponge layer definition, it no longer
deactivates any previously active definition (as multiple sponge layer definitions can now be
active at the same time).

define/models/acoustics/sponge-layers/

deactivate (Changed)

This text command no longer automatically deactivates the most-recently-activated sponge

layer definition, but instead has a new prompt so that you can specify which definition you
want to deactivate.

define/models/acoustics/sponge-layers/

list-active (New)

Prints the names of the active sponge layer definitions in the console.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
32 of ANSYS, Inc. and its subsidiaries and affiliates.
 Solution Mode

define/models/battery-model/

swelling-model-parameters (New)

Sets parameters for the physics-based swelling model (see Inputs for the Newman’s P2D Model
in the Fluent User's Guide for details).

define/models/battery-model/

use-cyl-orthotropic-material? (New)

Defines cylindrical orthotropic thermal conductivity for the battery material (see Defining Cyl-
indrical Orthotropic Thermal Conductivity in the Fluent User's Guide for details).

define/models/cht/explicit-time-averaged-coupling/

coupling-controls (Changed)

New prompts are available for setting up time averaged heat flow.

define/models/dpm/injections/injection-properties/set/general-settings/

(New)

Enters the menu for general settings. This option is available only if at least one injection has
been selected using define/injections/properties/set/pick-injections-to-
set.

define/models/dpm/injections/injection-properties/set/general-settings/

inject-wall-film-particles? (New)

Enables the injection of wall-film particles.

define/models/dpm/injections/injection-properties/set/general-settings/

reference-frame (Changed)

This text command replaces the define/models/dpm/injections/injection-prop-

erties/set/location/ command. The existing script and journal files are respected.

define/models/dpm/injections/injection-properties/set/physical-models/

heat-exchange (New)

Enters the menu for setting the heat exchange with the continuous phase. This item is available
for cases with inert or combusting particles only.

define/models/dpm/injections/injection-properties/set/physical-models/heat-
exchange/

heat-transfer-coefficient (New)

Allows you to choose the heat transfer coefficient correlation. The options include constant-
HTC, Nusselt-number, Ranz-Marshall (default), Hughmark, Tomiyama, and Gunn.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 33
Text Command Changes in Ansys Fluent 2022 R2

define/models/dpm/injections/injection-properties/set/size-distribution/

use-randomized-diameter-sampling? (New)

Enables/disables the use of the randomized diameter sampling for the tabulated size distribution.
When this text option is disabled, particles from each tabulated diameter class are injected from
each particle starting position.

define/models/dpm/injections/

list-injection-properties (New)

Lists properties of the selected injection(s) in the console window.

define/models/dpm/interaction/

ddpm-energy-coupling-via-source-term? (New)

Enables/disables the energy coupling between the discrete phases (DDPM) and the primary
phase via the source term. Note that when this option is enabled, the Total Heat Transfer Rate
flux report for the mixture currently generates inaccurate results.

define/models/dpm/interaction/

enable-flow-blocking-by-particles? (New)

Enables/disables the inclusion of DPM volume fraction in continuous flow.

define/models/dpm/interaction/

linearized-dpm-species-source-terms? (New)

Enables/disables the linearization of the species source terms for the discrete phase. This item
is available with the species transport model.

define/models/dpm/interaction/

max-vf-allowed-for-blocking (New)

Sets the maximum DPM volume fraction in the continuous flow. This item is available only when
the define/models/dpm/interaction/enable-flow-blocking-by-particles?
option is enabled.

define/models/dpm/numerics/

enhanced-packing-limit-numerics? (New)

Enables/disables enhanced packing limit numerics to avoid exceeding the packing limit for
granular phases. This item is available only when the DDPM model is used.

define/models/dpm/numerics/high-resolution-tracking/

particle-relocation/ (New)

Enters the particle relocation menu.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
34 of ANSYS, Inc. and its subsidiaries and affiliates.
 Solution Mode

define/models/dpm/numerics/high-resolution-tracking/particle-relocation/

enhanced-cell-relocation-method? (New)

When enabled, Ansys Fluent uses a more rigorous method of locating the cell in which the
particle is currently contained. This approach is computationally more expensive than the default
method; however, it is recommended for cases when Fluent reports that particles are lost after
the mesh has been changed due to MDM, dynamic adaption, or repartitioning.

define/models/dpm/numerics/high-resolution-tracking/particle-relocation/

enhanced-wallfilm-location-method? (Changed)

This text command replaces the define/models/dpm/numerics/high-resolution-

tracking/enhanced-wallfilm-location-method? command.

define/models/dpm/numerics/high-resolution-tracking/particle-relocation/

load-legacy-particles? (Changed)

This text command replaces the define/models/dpm/numerics/high-resolution-

tracking/load-legacy-particles? command.

define/models/dpm/numerics/high-resolution-tracking/particle-relocation/

overset-relocation-robustness-level (New)

Sets the performance/robustness trade-off when relocating particles in overset meshes. The
default value is 1, which corresponds to a more robust algorithm. Performance may be improved
by setting the value to 0; however, this may result in particle loss, particularly if the mesh is
moving. You need to make sure that no particle loss occurs.

define/models/dpm/numerics/high-resolution-tracking/particle-relocation/

use-legacy-particle-location-method? (Changed)

This text command replaces the define/models/dpm/numerics/high-resolution-

tracking/use-legacy-particle-location-method? command.

define/models/dpm/numerics/high-resolution-tracking/particle-relocation/

wallfilm-relocation-tolerance-scale-factor (Changed)

This text command replaces the define/models/dpm/numerics/high-resolution-

tracking/wallfilm-relocation-tolerance command.

define/models/dpm/options/

include-lwf-particles-in-dpm-concentration? (New)

When enabled, the mass of the Lagrangian wall film particles is included in the calculation of
the concentration. This option is disabled by default.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 35
Text Command Changes in Ansys Fluent 2022 R2

define/models/dpm/options/

remove-wall-film-temperature-limiter? (Changed)

The prompt for reporting the Leidenfrost temperature on the wall faces is now also available
for cases with the removed wall temperature limit.

define/models/

energy (Changed)

For species and composition PDF transport model cases with the PBNS solver, the Include
diffusion at inlets? prompt has been removed as it is not considered a physically
plausible boundary condition.

define/models/eulerian-wallfilm/

model-options (Changed)

New prompts for enabling and setting the film DPM source smoothing option have been added.

define/models/multiphase/population-balance/

expert/ (New)

Enters the population balance expert menu.

define/models/multiphase/population-balance/expert/

qmom/ (New)

Enter the menu for the quadrature method of moments (QMOM).

define/models/multiphase/population-balance/expert/qmom/

retain-qmom-sources-for-low-vof? (New)

If enabled, retains the QMOM sources for the low volume fraction of the secondary phase.

define/models/multiphase/population-balance/phenomena/

breakage (Changed)

New methods, martinez-bazan-model and inverted-u-pdf, have been added for spe-
cifying the breakage frequency and the probability density function (PDF) of the particle
breakage, respectively.

define/models/radiation/

radiation-model-parameters (Changed)

There are new prompts to control the frequency that the radiation field is updated as the con-
tinuous phase solution proceeds for steady and transient simulations.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
36 of ANSYS, Inc. and its subsidiaries and affiliates.
 Solution Mode

define/models/sofc-model/

pore-size-interface (New)

Sets fuel cell average pore size interface.

define/phases/set-domain-properties/interaction-domain/heat-mass-reactions/

mass-transfer (Changed)

A new method, higbie, for specifying the interphase mass transfer coefficient has been added.

define/profiles/

display-profile-point-cloud-data (New)

Display the profile as a cloud of points.

define/profiles/

overlay-profile-point-cloud-data (New)

Preview a profile as a cloud of points and overlay an existing mesh or contour graphics object
in the same graphics window.

define/profiles/

overlay-profile-surface (New)

Preview a profile as a surface (only available for profiles with node-connectivity data) and
overlay an existing mesh or contour graphics object in the same graphics window.

define/profiles/

replicate-profiles (Changed)

There are new prompts for the creation of a complex pair (real and imaginary components of
a complex mode shape).

define/profiles/

set-preference-profile-point-cloud-data (New)

Set the marker symbol, size, and color for previewing a profile as a point cloud.

display/objects/

add-to-graphics (Changed)

This command has an additional option for LIC plots, if any are defined.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 37
Text Command Changes in Ansys Fluent 2022 R2

display/objects/

copy (Changed)

This command has an additional option for LIC plots, if any are defined.

display/objects/

create (Changed)

This command has an additional option for LIC plot.

display/objects/

delete (Changed)

This command will now also list any defined LIC plots.

display/objects/

display (Changed)

This command will now list any defined LIC plots.

display/objects/

edit (Changed)

This command will now list any defined LIC plots.

display/set/colors/

by-surface/ (New)

Enter the menu for specifying global surface rendering properties, for all mesh displays colored
by surface.

display/set/colors/by-surface/

list-surfaces-by-color (New)

Prints the names of each color that is in use, and the surfaces assigned that color, to the console.

display/set/colors/by-surface/

list-surfaces-by-material (New)

Prints the names of each material that is in use, and the surfaces assigned that material, to the
console.

display/set/colors/by-surface/

reset? (New)

Overwrites any color/material assignments and reverts to the default colors.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
38 of ANSYS, Inc. and its subsidiaries and affiliates.
 Solution Mode

display/set/colors/by-surface/

surfaces (New)

Asks for the names/IDs of one or more surfaces and allows you to specify a color and/or mater-
ial for the provided surfaces.

display/set/colors/by-surface/

use-inherent-material-color? (New)

For surfaces with both a color and material assigned, the color is ignored and the color inherent
to the specified material is used instead.

display/set/colors/

by-type/ (New)

Enter the menu for specifying global zone type color and material assignments, for all mesh
displays colored by type.

display/set/colors/by-type/

only-list-case-boundaries? (New)

Only the boundary types used in this case are listed, rather than all possible boundary types.

display/set/colors/by-type/

reset? (New)

Overwrites any color/material assignments and reverts to the default colors.

display/set/colors/by-type/

type-name/ (New)

Asks for the boundary type and allows you to assign a color and/or material to the specified
type.

display/set/colors/by-type/

use-inherent-material-color? (New)

For types with both a color and material assigned, the color is ignored and the color inherent
to the specified material is used instead.

file/export/

cgns (Changed)

There is an additional prompt after the name of the file, requesting the scope of the domain
you want exported. The default full-domain is consistent with the behavior of prior releases.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 39
Text Command Changes in Ansys Fluent 2022 R2

file/export/

ensight-dvs-surfaces (New)

Writes an EnSight DVS file for the specified surfaces and quantities.

file/export/

ensight-dvs-volume (New)

Writes an EnSight DVS file for the specified volumes and quantities.

file/transient-export/

cdat-for-cfd-post-&-ensight (Changed)

The yes/no Write Case File Every Time? prompt is changed to Write Case File: with choices
for every-time, only-on-change, and only-once.

mesh/adapt/cell-registers/

add (Changed)

When adding a cell register of the field-value type, the following new options are available:
between-std-dev, outside-std-dev, less-than-std-dev, and more-than-std-
dev. These options allow you to mark cells inside or outside of a certain range defined in terms
of the standard deviation, or with values below or above a limit defined in terms of the standard
deviation, respectively.

mesh/adapt/cell-registers/

edit (Changed)

When editing a cell register of the field-value type, the following new options are available:
between-std-dev, outside-std-dev, less-than-std-dev, and more-than-std-
dev. These options allow you to mark cells inside or outside of a certain range defined in terms
of the standard deviation, or with values below or above a limit defined in terms of the standard
deviation, respectively.

mesh/

show-periodic-shadow-zones? (New)

Enables/disables the showing of shadow zones for conformal periodic boundary zone pairs in
any list of boundary zones presented by the user interface. This text command is enabled by
default. If any shadow zones exist when this text command is disabled, they are deleted (though
the behavior of the related periodic boundary zones will not be affected).

parametric-study/

(New)

Enter the parametric study menu.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
40 of ANSYS, Inc. and its subsidiaries and affiliates.
 Solution Mode

parametric-study/design-points/

(New)

Enter the design point menu for a parametric study.

parametric-study/design-points/

add-design-point (New)

Adds the design point to the parametric study.

parametric-study/design-points/

delete-design-point (New)

Removes the design point from the parametric study.

parametric-study/design-points/

get-capture-simulation-report-data (New)

Retrieves the design point's setting for capturing its data for the simulation report.

parametric-study/design-points/

get-current-design-point (New)

Retrieves the design point set as "current."

parametric-study/design-points/

get-input-parameters-of-dp (New)

Retrieves the value(s) of the design point's input parameters.

parametric-study/design-points/

get-output-parameters-of-dp (New)

Retrieves the value(s) of the design point's output parameters.

parametric-study/design-points/

get-write-data (New)

Retrieves the design point's status of writing its data upon update.

parametric-study/design-points/

set-as-current (New)

Sets the designated design point to be "current."

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 41
Text Command Changes in Ansys Fluent 2022 R2

parametric-study/design-points/

set-capture-simulation-report-data (New)

Sets the design point to capture data for the simulation report.

parametric-study/design-points/

set-input-parameters-of-dp (New)

Set the value(s) of the design point's input parameters.

parametric-study/design-points/

set-write-data (New)

Sets the design point to write its data upon update.

parametric-study/

initialize (New)

Initializes and starts the parametric study.

parametric-study/update/

(New)

Enter the update menu for a parametric study.

parametric-study/update/

get-number-of-concurrent-dps (New)

Retrieves the number of concurrent design points.

parametric-study/update/

get-update-method (New)

Retrieves the method used for updating design points.

parametric-study/update/

set-number-of-concurrent-dps (New)

Sets the number of concurrent design points.

parametric-study/update/

set-update-method (New)

Sets the method used for updating design points.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
42 of ANSYS, Inc. and its subsidiaries and affiliates.
 Solution Mode

parametric-study/update/

update-all (New)

Updates all design points.

parametric-study/update/

update-current (New)

Updates the design point set as "current."

preferences/appearance/

application-font-size (New)

Set the font size for the Fluent graphical user interface (GUI).

preferences/graphics/

transparency/ (New)

Enter the menu for specifying transparency preferences.

preferences/graphics/transparency/

algorithm-for-modern-drivers (New)

Specify how Fluent applies transparency in the graphics window: Depth Peeling - best balance
of performance and control, Z-Sort - Transparency is applied to all specified objects.

preferences/graphics/transparency/

depth-peeling-layers (New)

Specify how much transparency is applied to the interior of an object. Increasing the number
of layers can increase rendering cost.

solve/animate/pulse/

hardcopy/ (New)

Enter the pulse hardcopy menu.

solve/animate/pulse/hardcopy/

color-mode/ (New)

Enters the hardcopy/save-picture color mode menu.

solve/animate/pulse/hardcopy/colormode/

color (New)

Plots hardcopies in color.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 43
Text Command Changes in Ansys Fluent 2022 R2

solve/animate/pulse/hardcopy/colormode/

gray-scale (New)

Converts color to grayscale for hardcopy.

solve/animate/pulse/hardcopy/colormode/

list (New)

Displays the current hardcopy color mode.

solve/animate/pulse/hardcopy/colormode/

mono-chrome (New)

Converts color to monochrome (black and white) for hardcopy.

solve/animate/pulse/hardcopy/

dpi (New)

Sets the resolution for EPS and Postscript files; specifies the resolution in dots per inch (DPI)
instead of setting the width and height.

solve/animate/pulse/hardcopy/

driver/ (New)

Enters the set hardcopy driver menu.

solve/animate/pulse/hardcopy/driver/

eps (New)

Produces encapsulated PostScript (EPS) output for hardcopies.

solve/animate/pulse/hardcopy/driver/

glb (New)

Produces GLB output for hardcopies.

solve/animate/pulse/hardcopy/driver/

hsf (New)

Produces HOOPS Visualize Stream Format (HSF) output for hardcopies.

solve/animate/pulse/hardcopy/driver/

jpeg (New)

Produces JPEG output for hardcopies.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
44 of ANSYS, Inc. and its subsidiaries and affiliates.
 Solution Mode

solve/animate/pulse/hardcopy/driver/

list (New)

Lists the current hardcopy driver.

solve/animate/pulse/hardcopy/driver/

options (New)

Sets the hardcopy options. Available options are: “no gamma correction", disables gamma cor-
rection of colors; “pen speed = f", where f is a real number in [0,1]; “physical size = (width,
height)", where width and height are the actual measurements of the printable area of the page
in centimeters; “subscreen = (left, right, bottom, top)", where left, right, bottom, and top are
numbers in [-1,1] describing a subwindow on the page in which to place the hardcopy. The
options may be combined by separating them with commas. The pen speed option is only
meaningful to the HPGL driver.

solve/animate/pulse/hardcopy/driver/

png (New)

Uses PNG output for hardcopies. (This is the default file type.)

solve/animate/pulse/hardcopy/driver/

post-format/ (New)

Enters the PostScript driver format menu.

solve/animate/pulse/hardcopy/driver/post-format/

fast-raster (New)

Enables a raster file that may be larger than the standard raster file, but will print much more
quickly.

solve/animate/pulse/hardcopy/driver/post-format/

raster (New)

Enables the standard raster file.

solve/animate/pulse/hardcopy/driver/post-format/

rle-raster (New)

Enables a run-length encoded raster file that will be about the same size as the standard raster
file, but will print slightly more quickly.

solve/animate/pulse/hardcopy/driver/post-format/

vector (New)

Enables the standard vector file.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 45
Text Command Changes in Ansys Fluent 2022 R2

solve/animate/pulse/hardcopy/driver/

post-script (New)

Produces PostScript output for hardcopies.

solve/animate/pulse/hardcopy/driver/

ppm (New)

Produces PPM output for hardcopies.

solve/animate/pulse/hardcopy/driver/

tiff (New)

Produces TIFF output for hardcopies.

solve/animate/pulse/hardcopy/driver/

vrml (New)

Uses VRML output for hardcopies.

solve/animate/pulse/hardcopy/

invert-background? (New)

Save the image with a white background.

solve/animate/pulse/hardcopy/

jpeg-hardcopy-quality (New)

Controls the size and quality of how JPEG files are saved based on a scale of 0-100, with zero
being low quality small files and 100 being high quality larger files.

solve/animate/pulse/hardcopy/

landscape? (New)

Specify the orientation of the picture. If this option is enabled, the picture is made in landscape
mode; otherwise, it is made in portrait mode.

solve/animate/pulse/hardcopy/

preview (New)

Applies the settings of the color-mode, invert-background (white or as seen in the graphics
window), and landscape options to the currently active graphics window to preview the appear-
ance of printed hardcopies.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
46 of ANSYS, Inc. and its subsidiaries and affiliates.
 Solution Mode

solve/animate/pulse/hardcopy/

use-window-resolution? (New)

Disables/enables the use of the current graphics window resolution when saving an image of
the graphics window. If disabled, the resolution will be as specified for x-resolution andy-
resolution.

solve/animate/pulse/hardcopy/

x-resolution (New)

Sets the width of raster-formatted images in pixels (0 implies current window size).

solve/animate/pulse/hardcopy/

y-resolution (New)

Sets the height of raster-formatted images in pixels (0 implies current window size).

solve/animate/pulse/

video/ (New)

Enters the pulse video menu.

solve/animate/pulse/video/

advanced-quality/ (New)

Enters the advanced quality menu.

solve/animate/pulse/video/advanced-quality/

bitrate-scale (New)

Sets the bitrate scale for saving the pulse video file. The best is 64000 | high is 32000 | medium
is 16000 | low is 8000.

solve/animate/pulse/video/advanced-quality/

enable-h264 (New)

Controls whether H.264 encoding is used when the pulse video file is written.

solve/animate/pulse/video/

format (New)

Specifies what format the pulse video file will be written in (MP4 | AVI | FLV | MOV | MPEG).

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 47
Text Command Changes in Ansys Fluent 2022 R2

solve/animate/pulse/video/

fps (New)

Sets the target frames per second (FPS) for the saved pulse video file.

solve/animate/pulse/video/

name (New)

Sets the name of the saved pulse video file.

solve/animate/pulse/video

quality (New)

Sets the quality of the saved pulse video file.

solve/animate/pulse/video/

scale (New)

Expands or collapses the resolution based on this scaling factor.

solve/animate/pulse/video/

use-original-resolution (New)

Controls whether the resolution of the saved pulse video file matches that of the images used
to create it.

solve/cell-registers/

add (Changed)

When adding a cell register of the field-value type, the following new options are available:
between-std-dev, outside-std-dev, less-than-std-dev, and more-than-std-
dev. These options allow you to mark cells inside or outside of a certain range defined in terms
of the standard deviation, or with values below or above a limit defined in terms of the standard
deviation, respectively.

solve/cell-registers/

edit (Changed)

When editing a cell register of the field-value type, the following new options are available:
between-std-dev, outside-std-dev, less-than-std-dev, and more-than-std-
dev. These options allow you to mark cells inside or outside of a certain range defined in terms
of the standard deviation, or with values below or above a limit defined in terms of the standard
deviation, respectively.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
48 of ANSYS, Inc. and its subsidiaries and affiliates.
 Solution Mode

solve/initialize/

set-fmg-options/ (New)

Enters the menu for FMG initialization options.

solve/initialize/set-fmg-options/

set-turbulent-viscosity-ratio (New)

Sets value for the turbulent viscosity ratio used during FMG initialization.

solve/initialize/set-fmg-options/

species-reaction? (New)

Enables/disables volumetric reactions during FMG initialization.

solve/initialize/set-fmg-options/

viscous-terms? (New)

Enables/disables the inclusion of viscous terms during FMG initialization.

solve/report-definitions/

add (Changed)

The report-definition-type prompt now has the following new options: cell-count
allows you to report the number of cells within one or more cell zones; and face-count allows
you to report the number of faces within one or more boundary zones.

solve/report-definitions/

compute (New)

Computes the value of the specified report definition(s) and prints it in the console.

solve/set/advanced/

anisotropic-heat-flux (New)

Allows you to select the method for calculating the heat flux. The high-anisotropy-flux
method provides greater stability and robustness when a solid cell zone is defined with highly
anisotropic thermal conductivity properties (that is, a zone that has a conductivity in one direction
that is more than 100 times the value in another direction), though it may increase the number
of iterations / time steps. This text command is only available when using the pressure-based
solver with the energy equation enabled and a solid zone with an anisotropic option (other
than biaxial) selected for the thermal conductivity.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 49
Text Command Changes in Ansys Fluent 2022 R2

solve/set/advanced/

skewness-correction-enhanced (New)

Enables/disables an enhanced formulation for the skewness correction that computes the
pressure-correction gradient. In a mesh with very skewed elements, the enhanced formulation
should improve solver robustness (though in rare cases it may decrease stability). The enhanced
skewness formulation is only used during the simulation when the SIMPLEC scheme is selected
with one or more active skewness correction iterations or when the PISO scheme is selected
with one or more active skewness correction iterations, no active neighborhood correction iter-
ations, and the Non-Iterative Time Advancement (NITA) option is disabled. This text command
is only available with the pressure-based solver, when the Coupled scheme is not selected and
the NITA option is disabled.

solve/set/data-sampling-options/

add-datasets (Changed)

There is an additional prompt asking if you want to do a moving average computation of the
specified quantity(s).

solve/set/data-sampling-options/

add-rtdft-datasets (Changed)

There is an additional prompt asking if you want to do a moving average computation of the
specified quantity(s).

solve/set/multiphase-numerics/advanced-stability-controls/

pseudo-time/ (New)

Enters the stability control menu for steady-state multiphase cases with a pseudo time method
selected.

solve/set/multiphase-numerics/advanced-stability-controls/pseudo-time/

auto-dt-advanced-controls/ (New)

Enters the menu for the automatic time step controls. These text commands are available only
when the Automatic time step method is used for pseudo time step calculations.

solve/set/multiphase-numerics/advanced-stability-controls/pseudo-time/auto-
dt-advanced-controls/

dt-factor-max (New)

Sets the maximum limit for increasing the size of the pseudo time step. Default: 1.2.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
50 of ANSYS, Inc. and its subsidiaries and affiliates.
 Solution Mode

solve/set/multiphase-numerics/advanced-stability-controls/pseudo-time/auto-
dt-advanced-controls/

dt-factor-min (New)

Sets the minimum limit for increasing the pseudo time step size. Default: 0.25.

solve/set/multiphase-numerics/advanced-stability-controls/pseudo-time/auto-
dt-advanced-controls/

dt-init-limit (New)

Sets the maximum pseudo time step size for the first iteration. Default: 0.01s.

solve/set/multiphase-numerics/advanced-stability-controls/pseudo-time/auto-
dt-advanced-controls/

dt-max (New)

Sets the maximum pseudo time step size for the entire simulation. Default: 1000s.

solve/set/multiphase-numerics/advanced-stability-controls/pseudo-time/auto-
dt-advanced-controls/

enable? (New)

Enables/disables the advanced automatic time step method for better stability.

solve/set/multiphase-numerics/advanced-stability-controls/pseudo-time/auto-
dt-advanced-controls/

max-velocity-ratio (New)

Sets the maximum velocity ratio (maximum velocity to average velocity) above which the solver
freezes the time step size for better solution stability. Default: 100.

solve/set/multiphase-numerics/advanced-stability-controls/pseudo-time/

false-time-step-linearization? (New)

When enabled, provides additional stability for buoyancy-driven flows with a pseudo time
method selected by increasing the diagonal dominance using the false time step size.

solve/set/multiphase-numerics/advanced-stability-controls/pseudo-time/

smoothed-density-stabilization-method? (New)

Smooths the cell density near the interface, therefore avoiding unphysical acceleration of the
lighter phase in the vicinity of interface. The default number of density smoothings is 2. In case
of very large unphysical velocities across the interface, you can increase this number when
prompted with Number of density smoothings.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
of ANSYS, Inc. and its subsidiaries and affiliates. 51
Text Command Changes in Ansys Fluent 2022 R2

solve/set/multiphase-numerics/advanced-stability-controls/

pseudo-transient/ (Deleted)

This text command menu is removed and replaced with solve/set/multiphase-numer-

ics/advanced-stability-controls/pseudo-time/.

solve/set/multiphase-numerics/advanced-stability-controls/pseudo-transient/

false-time-step-linearization? (Deleted)

This text command is removed and replaced with solve/set/multiphase-numerics/ad-

vanced-stability-controls/pseudo-time/false-time-step-linearization?.

solve/set/multiphase-numerics/advanced-stability-controls/pseudo-transient/

smoothed-density-stabilization-method? (Deleted)

This text command is removed and replaced with solve/set/multiphase-numerics/ad-

vanced-stability-controls/pseudo-time/smoothed-density-stabilization-
method?.

solve/set/multiphase-numerics/solution-stabilization/additional-stabilization-
controls/

pseudo-time-stabilization? (New)

Enables/disables the pseudo time momentum stabilization and false time step linearization
methods.

solve/set/multiphase-numerics/solution-stabilization/additional-stabilization-
controls/

pseudo-transient-stabilization? (Deleted)

This text command is removed and replaced with solve/set/multiphase-numerics/solu-

tion-stabilization/additional-stabilization-controls/pseudo-time-
stabilization?.

Release 2022 R2 - © ANSYS, Inc. All rights reserved. - Contains proprietary and confidential information
52 of ANSYS, Inc. and its subsidiaries and affiliates.
