P441/P442/P444
Numerical Distance Protection
Version B1.2
Technical Manual
P44x/EN T/E33
Technical Guide P44x/EN T/E33
GENERAL CONTENT
BLANK PAGE
SAFETY SECTION Px4xx/EN SS/A11
SAFETY SECTION
SAFETY SECTION Px4xx/EN SS/A11
Page 1/8
CONTENTS
2. SAFETY SECTION 4
6. TECHNICAL SPECIFICATIONS 7
Px4xx/EN SS/A11 SAFETY SECTION
Page 2/8
BLANK PAGE
SAFETY SECTION Px4xx/EN SS/A11
Page 3/8
Page 4/8
2. SAFETY SECTION
This Safety Section should be read before commencing any work on the
equipment.
Health and safety
The information in the Safety Section of the product documentation is intended to
ensure that products are properly installed and handled in order to maintain them in
a safe condition. It is assumed that everyone who will be associated with the
equipment will be familiar with the contents of the Safety Section.
Explanation of symbols and labels
The meaning of symbols and labels which may be used on the equipment or in the
product documentation, is given below.
!
Important: Important:
refer to the product documentation risk of electrocution
Page 5/8
Page 6/8
Page 7/8
6. TECHNICAL SPECIFICATIONS
Protective fuse rating
The recommended maximum rating of the external protective fuse for this equipment
is 16A, Red Spot type or equivalent, unless otherwise stated in the technical data
section of the product documentation.
Page 8/8
BLANK PAGE
Introduction P44x/EN IT/E33
INTRODUCTION
Introduction P44x/EN IT/E33
CONTENT
1. INTRODUCTION TO MiCOM 3
BLANK PAGE
Introduction P44x/EN IT/E33
1. INTRODUCTION TO MiCOM
MiCOM is a comprehensive solution capable of meeting all electricity supply requirements. It
comprises a range of components, systems and services from AREVA T&D Protection and
Control.
Central to the MiCOM concept is flexibility.
MiCOM provides the ability to define an application solution and, through extensive
communication capabilities, to integrate it with your power supply control system.
The components within MiCOM are:
Zn 1/5 A 50/60 Hz
SER N o Vx V
DIAG N o Vn V
LCD
TRIP
Fixed ALARM
function
OUT OF SERVICE
LEDs
HEALTHY
User programable
= CLEAR function LEDs
= READ
= ENTER
Keypad
SK 1 SK 2
Bottom
cover
Battery compartment Front comms port Download/monitor port
P0103ENa
The front panel of the relay includes the following, as indicated in figure 1:
• 12 LEDs; 4 fixed function LEDs on the left hand side of the front panel and 8
programmable function LEDs on the right hand side.
Under the top hinged cover:
• the relay serial number, and the relay’s current and voltage rating information*.
Under the bottom hinged cover:
• battery compartment to hold the 1/2 AA size battery which is used for memory
back-up for the real time clock, event, fault and disturbance records.
• a 9-pin female D-type front port for communication with a PC locally to the relay (up to
15m distance) via an EIA(RS)232 serial data connection.
• a 25-pin female D-type port providing internal signal monitoring and high speed local
downloading of software and language text via a parallel data connection.
The fixed function LEDs on the left hand side of the front panel are used to indicate the
following conditions:
Trip (Red) indicates that the relay has issued a trip signal. It is reset when the associated
fault record is cleared from the front display. (Alternatively the trip LED can be configured to
be self-resetting)*.
Alarm (Yellow) flashes to indicate that the relay has registered an alarm. This may be
triggered by a fault, event or maintenance record. The LED will flash until the alarms have
been accepted (read), after which the LED will change to constant illumination, and will
extinguish when the alarms have been cleared.
Out of service (Yellow) indicates that the relay’s protection is unavailable.
Healthy (Green) indicates that the relay is in correct working order, and should be on at all
times. It will be extinguished if the relay’s self-test facilities indicate that there is an error with
the relay’s hardware or software. The state of the healthy LED is reflected by the watchdog
contact at the back of the relay.
3.1.2 Relay rear panel
The rear panel of the relay is shown in figure 2. All current and voltage signals, digital logic
input signals and output contacts are connected at the rear of the relay. Also connected at
the rear is the twisted pair wiring for the rear EIA(RS)485 communication port, the IRIG-B
time synchronising input and the optical fibre rear communication port which are both
optional.
Introduction P44x/EN IT/E33
A B C D E F
Power supply
connection
(Terminal
block F)
Rear comms
port (RS485)
A C D E F G H J
B
IRIG -B
TX
RX
Optional fibre optic Current and voltage Digital input connections Rear comms port
connection input terminals (Terminal blocks D & E) (RS485) (TB J)
(Terminal block A) (Terminal block C) P3024ENa
A B C D E F G H J K L M N
1
1 2 3 19
2
3
3
3
3
4 5 6 20
4
4
4
5
5
IRIG-B
6
7 8 9 21
7
7
8
8
9
9
10 11 12 22
10
10
10
10
10
10
10
10
11
11
11
11
11
11
11
11
12
12
12
12
12
12
12
12
13
13
13
13
13 14 15 23
13
13
13
13
TX
RX
14
14
14
14
14
14
14
14
15
15
15
15
15
15
15
15
16 17 18 24
16
16
16
16
16
16
16
16
17
17
17
17
17
17
17
17
18
18
18
18
18
18
18
18
Optional fibre 1A/5A Programmable
optic connection Current and voltage digital input Rear comms port
IEC60870-5-103 input terminals connections (RS485)
(VDEW) (Terminal block C) (Terminal blocks D, E & F) P3025ENa
• the front panel user interface via the LCD and keypad.
• the rear port which supports one protocol of either Courier, Modbus,
IEC 60870-5-103 or DNP3.0. The protocol for the rear port must be specified when the
relay is ordered.
The measurement information and relay settings which can be accessed from the three
interfaces are summarised in Table 1.
Column
data
settings
• reset LEDs
• communications settings
• measurement settings
• commissioning settings
∗
may vary according to relay type/model
P44x/EN IT/E33 Introduction
TABLE 2
Each of the two passwords are 4 characters of upper case text. The factory default for both
passwords is AAAA. Each password is user-changeable once it has been correctly entered.
Entry of the password is achieved either by a prompt when a setting change is attempted, or
by moving to the ‘Password’ cell in the ‘System data’ column of the menu. The level of
access is independently enabled for each interface, that is to say if level 2 access is enabled
for the rear communication port, the front panel access will remain at level 0 unless the
relevant password is entered at the front panel. The access level enabled by the password
entry will time-out independently for each interface after a period of inactivity and revert to
the default level. If the passwords are lost an emergency password can be supplied - contact
AREVA with the relay’s serial number. The current level of access enabled for an interface
can be determined by examining the 'Access level' cell in the 'System data' column, the
access level for the front panel User Interface (UI), can also be found as one of the default
display options.
The relay is supplied with a default access level of 2, such that no password is required to
change any of the relay settings. It is also possible to set the default menu access level to
either level 0 or level1, preventing write access to the relay settings without the correct
password. The default menu access level is set in the ‘Password control’ cell which is found
in the ‘System data’ column of the menu (note that this setting can only be changed when
level 2 access is enabled).
3.5 Relay configuration
The relay is a multi-function device which supports numerous different protection, control
and communication features. In order to simplify the setting of the relay, there is a
configuration settings column which can be used to enable or disable many of the functions
of the relay. The settings associated with any function that is disabled are made invisible, i.e.
they are not shown in the menu. To disable a function change the relevant cell in the
‘Configuration’ column from ‘Enabled’ to ‘Disabled’.
The configuration column controls which of the four protection settings groups is selected as
active through the ‘Active settings’ cell. A protection setting group can also be disabled in the
configuration column, provided it is not the present active group. Similarly, a disabled setting
group cannot be set as the active group.
The column also allows all of the setting values in one group of protection settings to be
copied to another group.
To do this firstly set the ‘Copy from’ cell to the protection setting group to be copied, then set
the ‘Copy to’ cell to the protection group where the copy is to be placed. The copied settings
are initially placed in the temporary scratchpad, and will only be used by the relay following
confirmation.
Introduction P44x/EN IT/E33
To restore the default values to the settings in any protection settings group, set the ‘Restore
defaults’ cell to the relevant group number. Alternatively it is possible to set the ‘Restore
defaults’ cell to ‘All settings’ to restore the default values to all of the relay’s settings, not just
the protection groups’ settings. The default settings will initially be placed in the scratchpad
and will only be used by the relay after they have been confirmed. Note that restoring
defaults to all settings includes the rear communication port settings, which may result in
communication via the rear port being disrupted if the new (default) settings do not match
those of the master station.
3.6 Front panel user interface (keypad and LCD)
When the keypad is exposed it provides full access to the menu options of the relay, with the
information displayed on the LCD.
The ', (, ", # and $ keys which are used for menu navigation and setting value changes
include an auto-repeat function that comes into operation if any of these keys are held
continually pressed. This can be used to speed up both setting value changes and menu
navigation; the longer the key is held depressed, the faster the rate of change or movement
becomes.
P0105ENa
Alarms/Faults
Present
Entry to the menu structure of the relay is made from the default display and is not affected if
the display is showing the ‘Alarms/Faults present’ message.
3.6.2 Menu navigation and setting browsing
The menu can be browsed using the four arrow keys, following the structure shown in figure
4. Thus, starting at the default display the # key will display the first column heading. To
select the required column heading use the ( and " keys. The setting data contained in the
column can then be viewed by using the $ and # keys. It is possible to return to the column
header either by holding the [up arrow symbol] key down or by a single press of the clear key
!. It is only possible to move across columns at the column heading level. To return to the
default display press the # key or the clear key ! from any of the column headings. It is not
possible to go straight to the default display from within one of the column cells using the
auto-repeat facility of the # key, as the auto-repeat will stop at the column heading. To
move to the default display, the # key must be released and pressed again.
3.6.3 Password entry
When entry of a password is required the following prompt will appear:
Enter password
**** Level 1
NOTE: The password required to edit the setting is the prompt as shown
above
A flashing cursor will indicate which character field of the password may be changed. Press
the # and $ keys to vary each character between A and Z. To move between the
character fields of the password, use the ( and " keys. The password is confirmed by
pressing the enter key %. The display will revert to ‘Enter Password’ if an incorrect password
is entered. At this point a message will be displayed indicating whether a correct password
has been entered and if so what level of access has been unlocked. If this level is sufficient
to edit the selected setting then the display will return to the setting page to allow the edit to
continue. If the correct level of password has not been entered then the password prompt
page will be returned to. To escape from this prompt press the clear key !. Alternatively, the
password can be entered using the ‘Password’ cell of the ‘System data’ column.
For the front panel user interface the password protected access will revert to the default
access level after a keypad inactivity time-out of 15 minutes. It is possible to manually reset
the password protection to the default level by moving to the ‘Password’ menu cell in the
‘System data’ column and pressing the clear key ! instead of entering a password.
Introduction P44x/EN IT/E33
Press clear to
reset alarms
To clear all alarm messages press !; to return to the alarms/faults present display and
leave the alarms uncleared, press &. Depending on the password configuration settings, it
may be necessary to enter a password before the alarm messages can be cleared (see
section on password entry). When the alarms have been cleared the yellow alarm LED will
extinguish, as will the red trip LED if it was illuminated following a trip.
Alternatively it is possible to accelerate the procedure, once the alarm viewer has been
entered using the & key, the ! key can be pressed, this will move the display straight to the
fault record. Pressing ! again will move straight to the alarm reset prompt where pressing
! once more will clear all alarms.
3.6.5 Setting changes
To change the value of a setting, first navigate the menu to display the relevant cell. To
change the cell value press the enter key % which will bring up a flashing cursor on the LCD
to indicate that the value can be changed. This will only happen if the appropriate password
has been entered, otherwise the prompt to enter a password will appear. The setting value
can then be changed by pressing the or " keys. If the setting to be changed is a binary value
or a text string, the required bit or character to be changed must first be selected using the
' and " keys. When the desired new value has been reached it is confirmed as the new
setting value by pressing %. Alternatively, the new value will be discarded either if the clear
button ! is pressed or if the menu time-out occurs.
For protection group settings and disturbance recorder settings, the changes must be
confirmed before they are used by the relay. To do this, when all required changes have
been entered, return to the column heading level and press the key. Prior to returning to the
default display the following prompt will be given:
Update settings?
Enter or clear
Pressing % will result in the new settings being adopted, pressing ! will cause the relay to
discard the newly entered values. It should be noted that, the setting values will also be
discarded if the menu time out occurs before the setting changes have been confirmed.
Control and support settings will be updated immediately after they are entered, without
‘Update settings?’ prompt.
P44x/EN IT/E33 Introduction
MiCOM relay
Laptop
SK 2
25 pin
download/monitor port
9 pin
Battery front comms port Serial communication port
(COM 1 or COM 2)
Serial data connector
(up to 15m) P0107ENa
None of the other pins are connected in the relay. The relay should be connected to the
serial port of a PC, usually called COM1 or COM2. PCs are normally Data Terminal
Equipment (DTE) devices which have a serial port pin connection as below (if in doubt check
your PC manual):
25 Way 9 Way
Pin no. 3 2 Rx Receive data
Pin no. 2 3 Tx Transmit data
Pin no. 7 5 0V Zero volts common
For successful data communication, the Tx pin on the relay must be connected to the Rx pin
on the PC, and the Rx pin on the relay must be connected to the Tx pin on the PC, as shown
in figure 6. Therefore, providing that the PC is a DTE with pin connections as given above, a
‘straight through’ serial connector is required, i.e. one that connects pin 2 to pin 2, pin 3 to
pin 3, and pin 5 to pin 5. Note that a common cause of difficulty with serial data
communication is connecting Tx to Tx and Rx to Rx. This could happen if a ‘cross-over’
serial connector is used, i.e. one that connects pin 2 to pin 3, and pin 3 to pin 2, or if the PC
has the same pin configuration as the relay.
PC
MiCOM relay
Protocol Courier
Baud rate 19,200 bits/s
Courier address 1
Message format 11 bit - 1 start bit, 8 data bits, 1 parity bit (even parity), 1 stop bit
The inactivity timer for the front port is set at 15 minutes. This controls how long the relay will
maintain its level of password access on the front port. If no messages are received on the
front port for 15 minutes then any password access level that has been enabled will be
revoked.
P44x/EN IT/E33 Introduction
RS232 K-Bus
PC
KITZ protocol
PC serial port converter
Modem
PC
Modem
Move down the ‘Communications’ column from the column heading to the first cell down
which indicates the communication protocol:
Protocol
Courier
The next cell down the column controls the address of the relay:
Remote address
1
Inactivity timer
10.00 mins
The inactivity timer controls how long the relay will wait without receiving any messages on
the rear port before it reverts to its default state, including revoking any password access
that was enabled. For the rear port this can be set between 1 and 30 minutes.
Note that protection and disturbance recorder settings that are modified using an on-line
editor such as PAS&T must be confirmed with a write to the ‘Save changes’ cell of the
‘Configuration’ column. Off-line editors such as MiCOM S1 do not require this action for the
setting changes to take effect.
3.8.2 Modbus communication
Modbus is a master/slave communication protocol which can be used for network control. In
a similar fashion to Courier, the system works by the master device initiating all actions and
the slave devices, (the relays), responding to the master by supplying the requested data or
by taking the requested action.
Modbus communication is achieved via a twisted pair connection to the rear port and can be
used over a distance of 1000m with up to 32 slave devices.
To use the rear port with Modbus communication, the relay’s communication settings must
be configured. To do this use the keypad and LCD user interface.
In the relay menu firstly check that the ‘Comms settings’ cell in the ‘Configuration’ column is
set to ‘Visible’, then move to the ‘Communications’ column.
Four settings apply to the rear port using Modbus which are described below. Move down
the ‘Communications’ column from the column heading to the first cell down which indicates
the communication protocol:
Protocol
Modbus
The next cell down controls the Modbus address of the relay:
Modbus address
23
Up to 32 relays can be connected to one Modbus spur, and therefore it is necessary for each
relay to have a unique address so that messages from the master control station are
accepted by one relay only. Modbus uses an integer number between 1 and 247 for the
relay address. It is important that no two relays have the same Modbus address. The
Modbus address is then used by the master station to communicate with the relay.
Introduction P44x/EN IT/E33
Inactivity timer
10.00 mins
The inactivity timer controls how long the relay will wait without receiving any messages on
the rear port before it reverts to its default state, including revoking any password access
that was enabled. For the rear port this can be set between 1 and 30 minutes.
The next cell down the column controls the baud rate to be used:
Baud rate
9600 bits/s
Modbus communication is asynchronous. Three baud rates are supported by the relay,
‘9600 bits/s’, ‘19200 bits/s’ and ‘38400 bits/s’. It is important that whatever baud rate is
selected on the relay is the same as that set on the Modbus master station.
The next cell down controls the parity format used in the data frames:
Parity
None
The parity can be set to be one of ‘None’, ‘Odd’ or ‘Even’. It is important that whatever parity
format is selected on the relay is the same as that set on the Modbus master station.
3.8.3 IEC 60870-5 CS 103 communication
The IEC specification IEC 60870-5-103: Telecontrol Equipment and Systems, Part 5:
Transmission Protocols Section 103 defines the use of standards IEC 60870-5-1 to
IEC 60870-5-5 to perform communication with protection equipment. The standard
configuration for the IEC 60870-5-103 protocol is to use a twisted pair connection over
distances up to 1000m. As an option for IEC 60870-5-103, the rear port can be specified to
use a fibre optic connection for direct connection to a master station. The relay operates as a
slave in the system, responding to commands from a master station. The method of
communication uses standardised messages which are based on the VDEW communication
protocol.
To use the rear port with IEC 60870-5-103 communication, the relay’s communication
settings must be configured. To do this use the keypad and LCD user interface. In the relay
menu firstly check that the ‘Comms settings’ cell in the ‘Configuration’ column is set to
‘Visible’, then move to the ‘Communications’ column. Four settings apply to the rear port
using IEC 60870-5-103 which are described below. Move down the ‘Communications’
column from the column heading to the first cell which indicates the communication protocol:
Protocol
IEC 60870-5-103
The next cell down controls the IEC 60870-5-103 address of the relay:
Remote address
162
The next cell down the column controls the baud rate to be used:
Baud rate
9600 bits/s
IEC 60870-5-103 communication is asynchronous. Two baud rates are supported by the
relay, ‘9600 bits/s’ and ‘19200 bits/s’. It is important that whatever baud rate is selected on
the relay is the same as that set on the IEC 60870-5-103 master station.
The next cell down controls the period between IEC 60870-5-103 measurements:
Measure’t period
30.00 s
The IEC 60870-5-103 protocol allows the relay to supply measurements at regular intervals.
The interval between measurements is controlled by this cell, and can be set between 1 and
60 seconds.
The next cell down the column controls the physical media used for the communication:
Physical link
EIA(RS)485
The default setting is to select the electrical EIA(RS)485 connection. If the optional fibre optic
connectors are fitted to the relay, then this setting can be changed to ‘Fibre optic’.
The next cell down can be used to define the primary function type for this interface, where
this is not explicitly defined for the application by the IEC 60870-5-103 protocol*.
Function type
226
Protocol
DNP 3.0
The next cell controls the DNP 3.0 address of the relay:
Upto 32 relays can be connected to one DNP 3.0 spur, and therefore it is necessary for each
relay to have a unique address so that messages from the master control station are
accepted by only one relay. DNP 3.0 uses a decimal number between 1 and 65519 for the
relay address. It is important that no two relays have the same DNP 3.0 address.
The DNP 3.0 address is then used by the master station to communicate with the relay.
Introduction P44x/EN IT/E33
The next cell down the column controls the baud rate to be used:
Baud rate
9600 bits/s
DNP 3.0 communication is asynchronous. Six baud rates are supported by the relay
‘1200bits/s’, ‘2400bits/s’, ‘4800bits/s’, ’9600bits/s’, ‘19200bits/s’ and ‘38400bits/s’. It is
important that whatever baud rate is selected on the relay is the same as that set on the
DNP 3.0 master station.
The next cell down the column controls the parity format used in the data frames:
Parity
None
The parity can be set to be one of ‘None’, ‘Odd’ or ‘Even’. It is important that whatever parity
format is selected on the relay is the same as that set on the DNP 3.0 master station.
The next cell down the column sets the time synchronisation request from the master by the
relay:
Time Synch
Enabled
The time synch can be set to either enabled or disabled. If enabled it allows the DNP 3.0
master to synchronise the time.
3.9 Second rear Communication Port
For relays with Courier, Modbus, IEC60870-5-103 or DNP3 protocol on the first rear
communications port there is the hardware option of a second rear communications port,
(P442 and P444 only) which will run the Courier language. This can be used over one of
three physical links: twisted pair K-Bus (non polarity sensitive), twisted pair EIA(RS)485
(connection polarity sensitive) or EIA(RS)232.
The settings for this port are located immediately below the ones for the first port as
described in previous sections of this chapter. Move down the settings unit the following sub
heading is displayed.
The next cell down indicates the language, which is fixed at Courier for RP2.
RP2 Protocol
Courier
The next cell down indicates the status of the hardware, e.g.
The choice is either IEC60870 FT1.2 for normal operation with 11-bit modems, or 10-bit no
parity.
The next cell down controls the comms port address.
RP2 Address
255
Courier communications is asynchronous. Three baud rates are supported by the relay,
‘9600 bits/s’, ‘19200 bits/s’ and ‘38400 bits/s’.
Relay Description P44x/EN HW/E33
RELAY DESCRIPTION
Relay Description P44x/EN HW/E33
CONTENT
2. HARDWARE MODULES 8
2.1 Processor board 8
2.2 Co-processor board 8
2.3 Internal communication buses 8
2.4 Input module 9
2.4.1 Transformer board 9
2.4.2 Input board 9
2.4.3 Universal opto isolated logic inputs 9
2.5 Power supply module (including output relays) 10
2.5.1 Power supply board (including RS485 communication interface) 11
2.5.2 Output relay board 11
2.6 IRIG-B board (P442 and P444 only) 11
2.7 2nd rear communication and InterMiCOM teleprotection board (optional) 11
2.8 Mechanical layout 12
3. RELAY SOFTWARE 13
3.1 Real-time operating system 13
3.2 System services software 13
3.3 Platform software 14
3.3.1 Record logging 14
3.3.2 Settings database 14
3.3.3 Database interface 14
P44x/EN HW/E33 Relay Description
4. DISTANCE ALGORITHMS 17
4.1 Distance and Resistance Measurement 17
4.1.1 Phase-to-earth loop impedance 19
4.1.2 Impedance measurement algorithms work with instantaneous values (current and voltage).20
4.1.3 Phase-to-phase loop impedance 20
4.2 "Deltas" Algorithms 21
4.2.1 Fault Modelling 21
4.2.2 Detecting a Transition 23
4.2.3 Confirmation 26
4.2.4 Directional Decision 26
4.2.5 Phase Selection 27
4.2.6 Summary 27
4.3 "Conventional" Algorithms 28
4.3.1 Convergence Analysis 29
4.3.2 Start-Up 29
4.3.3 Phase Selection 30
4.3.4 Directional Decision 31
4.3.5 Directional Decision during SOTF/TOR (Switch On To Fault/Trip On Reclose) 31
4.4 Faulted Zone Decision 32
4.5 Tripping Logic 33
4.6 Fault Locator 34
4.6.1 Selecting the fault location data 35
4.6.2 Processing algorithms 35
4.7 Power swing detection 36
4.7.1 Power swing detection 36
4.7.2 Line in one pole open condition (during single-pole trip) 37
4.7.3 Conditions for isolating lines 37
4.7.4 Tripping logic 37
4.7.5 Fault Detection after Single-phase Tripping (one-pole-open condition) 38
4.8 Double Circuit Lines 38
Relay Description P44x/EN HW/E33
BLANK PAGE
Relay Description P44x/EN HW/E33
Battery Flash
backed-up E²PROM SRAM
EPROM
SRAM
CPU
Parallel test port
Timing data
Comms between
IRIG-B signal main & coprocessor CPU code & data
IRIG-B board boards
optional
Fibre optic
rear comms
port optional
FPGA SRAM
CPU
Serial data bus
(sample data)
Coprocessor board
inputs
P3026ENb
2. HARDWARE MODULES
The relay is based on a modular hardware design where each module performs a separate
function within the relay operation. This section describes the functional operation of the
various hardware modules.
2.1 Processor board
The relay is based around a TMS320C32 floating point, 32-bit digital signal processor (DSP)
operating at a clock frequency of 20MHz. This processor performs all of the calculations for
the relay, including the protection functions, control of the data communication and user
interfaces including the operation of the LCD, keypad and LEDs.
The processor board is located directly behind the relay’s front panel which allows the LCD
and LEDs to be mounted on the processor board along with the front panel communication
ports. These comprise the 9-pin D-connector for RS232 serial communications (e.g. using
MiCOM S1 and Courier communications) and the 25-pin D-connector relay test port for
parallel communication. All serial communication is handled using a two-channel 85C30
serial communications controller (SCC).
The memory provided on the main processor board is split into two categories, volatile and
non-volatile: the volatile memory is fast access (zero wait state) SRAM which is used for the
storage and execution of the processor software, and data storage as required during the
processor’s calculations. The non-volatile memory is sub-divided into 3 groups: 2MB of flash
memory for non-volatile storage of software code and text together with default settings,
256kB of battery backed-up SRAM for the storage of disturbance, event, fault and
maintenance record data and 32kB of E2PROM memory for the storage of configuration
data, including the present setting values.
2.2 Co-processor board
A second processor board is used in the relay for the processing of the current differential
protection algorithms. The processor used on the second board is the same as that used on
the main processor board. The second processor board has provision for fast access (zero
wait state) SRAM for use with both program and data memory storage. This memory can be
accessed by the main processor board via the parallel bus, and this route is used at power-
on to download the software for the second processor from the flash memory on the main
processor board. Further communication between the two processor boards is achieved via
interrupts and the shared SRAM. The serial bus carrying the sample data is also connected
to the co-processor board, using the processor’s built-in serial port, as on the main processor
board.
The co-processor board also handles all communication with the remote differential relay(s).
This is achieved via optical fibre communications and hence the co-processor board holds
the optical modules to transmit and receive data over the fibre links.
From software version B1.0, coprocessor board woks at 150Mhz.
2.3 Internal communication buses
The relay has two internal buses for the communication of data between different modules.
The main bus is a parallel link which is part of a 64-way ribbon cable. The ribbon cable
carries the data and address bus signals in addition to control signals and all power supply
lines. Operation of the bus is driven by the main processor board which operates as a
master while all other modules within the relay are slaves.
The second bus is a serial link which is used exclusively for communicating the digital
sample values from the input module to the main processor board. The DSP processor has a
built-in serial port which is used to read the sample data from the serial bus. The serial bus is
also carried on the 64-way ribbon cable.
Relay Description P44x/EN HW/E33
Up to 5
CT
CT
VT
VT
4
Transformer board
Input board
Up to 5
Anti-alias filters
single
single
single
single
Diffn
Diffn
Diffn
Diffn
to
to
to
to
4
Up to 5
pass
pass
filter
filter
pass
pass
filter
filter
Low
Low
Low
Low
4
16:1
Multiplexer
isolator
Optical
Noise
filter
Buffer
8 digital inputs
16-bit
ADC
Sample
control
Interface
Calibration
Serial
E²PROM
isolator
Optical
Noise
filter
processor board
Trigger from
data bus
Serial sample
Parallel bus
Buffer
Parallel bus
P3027ENa
SK4 : The InterMiCOM board (available with next version C1.0) is used to connect to an
EIA(RS)232 link, allowing up to eight programmable signalling bits to be transferred from/to
the remote line end relay. A suitable EIA(RS)232 link must exist between the two line ends,
for example a MODEM, or via a compatible multiplexer (check compatibility before ordering
the relay).
The second rear comms/InterMiCOM board, and IRIG-B board are mutually exclusive since
they use the same hardware slot. For this reason two versions of second rear comms board
are available ; one with an IRIG-B input and one without. (See also the Cortec code in
P44x/EN BR).
2.8 Mechanical layout
The case materials of the relay are constructed from pre-finished steel which has a
conductive covering of aluminium and zinc. This provides good earthing at all joints giving a
low impedance path to earth which is essential for performance in the presence of external
noise. The boards and modules use a multi-point earthing strategy to improve the immunity
to external noise and minimise the effect of circuit noise. Ground planes are used on boards
to reduce impedance paths and spring clips are used to ground the module metalwork.
Heavy duty terminal blocks are used at the rear of the relay for the current and voltage signal
connections. Medium duty terminal blocks are used for the digital logic input signals, the
output relay contacts, the power supply and the rear communication port. A BNC connector
is used for the optional IRIG-B signal. 9-pin and 25-pin female D-connectors are used at the
front of the relay for data communication.
Inside the relay the PCBs plug into the connector blocks at the rear, and can be removed
from the front of the relay only. The connector blocks to the relay’s CT inputs are provided
with internal shorting links inside the relay which will automatically short the current
transformer circuits before they are broken when the board is removed.
The front panel consists of a membrane keypad with tactile dome keys, an LCD and 12
LEDs mounted on an aluminium backing plate.
Relay Description P44x/EN HW/E33
3. RELAY SOFTWARE
The relay software was introduced in the overview of the relay at the start of this chapter.
The software can be considered to be made up of four sections:
Supervisor task
Settings Remote
database communications
interface - Modbus
Sampling function -
copies samples into Control of output contacts and Front panel Local & Remote
2 cycle buffer programmable LEDs interface - LCD & communications
keypad interface - Courier
Relay hardware
P0128ENa
• to control the logging of records that are generated by the protection software,
including alarms and event, fault, and maintenance records.
• to store and maintain a database of all of the relay’s settings in non-volatile memory.
• to provide the internal interface between the settings database and each of the relay’s
user interfaces, i.e. the front panel interface and the front and rear communication
ports, using whichever communication protocol has been specified (Courier, Modbus,
IEC60870-5-103).
3.3.1 Record logging
The logging function is provided to store all alarms, events, faults and maintenance records.
The records for all of these incidents are logged in battery backed-up SRAM in order to
provide a non-volatile log of what has happened. The relay maintains four logs: one each for
up to 32 alarms, 250 event records, 5 fault records and 5 maintenance records. The logs are
maintained such that the oldest record is overwritten with the newest record. The logging
function can be initiated from the protection software or the platform software is responsible
for logging of a maintenance record in the event of a relay failure. This includes errors that
have been detected by the platform software itself or error that are detected by either the
system services or the protection software function. See also the section on supervision and
diagnostics later in this chapter.
3.3.2 Settings database
The settings database contains all of the settings and data for the relay, including the
protection, disturbance recorder and control & support settings. The settings are maintained
in non-volatile E2PROM memory. The platform software’s management of the settings
database includes the responsibility of ensuring that only one user interface modifies the
settings of the database at any one time. This feature is employed to avoid conflict between
different parts of the software during a setting change. For changes to protection settings
and disturbance recorder settings, the platform software operates a ‘scratchpad’ in SRAM
memory. This allows a number of setting changes to be applied to the protection elements,
disturbance recorder and saved in the database in E2PROM. (See also chapter 1 on the
user interface). If a setting change affects the protection & control task, the database advises
it of the new values.
3.3.3 Database interface
The other function of the platform software is to implement the relay’s internal interface
between the database and each of the relay’s user interfaces. The database of settings and
measurements must be accessible from all of the relay’s user interfaces to allow read and
modify operations. The platform software presents the data in the appropriate format for
each user interface.
3.4 Protection and control software
The protection and control software task is responsible for processing all of the protection
elements and measurement functions of the relay. To achieve this it has to communicate
with both the system services software and the platform software as well as organise its own
operations. The protection software has the highest priority of any of the software tasks in
the relay in order to provide the fastest possible protection response. The protection &
control software has a supervisor task which controls the start-up of the task and deals with
the exchange of messages between the task and the platform software.
Relay Description P44x/EN HW/E33
4. DISTANCE ALGORITHMS
The operation is based on the combined use of two types of algorithms:
• "Deltas" algorithms using the superimposed current and voltage values that are
characteristic of a fault. These are used for phase selection and directional
determination. The fault distance calculation is performed by the "impedance
measurement algorithms ” using Gauss-Seidel.
• "Conventional" algorithms using the impedance values measured while the fault
occurs. These are also used for phase selection and directional determination.
The fault distance calculation is performed by the "impedance measurement
algorithms." Using Gauss-Seidel.
The "Deltas" algorithms have priority over the "Conventional" algorithms if they have been
started first. The latter are actuated only if "Deltas" algorithms have not been able to clear
the fault within two cycles of its detection.
4.1 Distance and Resistance Measurement
MiCOM P44x distance protection is a full scheme distance relay. To measure the distance
and apparent resistance of a fault, the following equation is solved on the loop with a fault:
IL I
R
Z SL (n).ZL (1-n).ZL Z SR
Relay Relay
VL VR
RF I F = I + I'
Local Remote
Source Source
V L = (ZL x I x D)+ RF x IF
= ((r +jx) x I x D) +RF x IF where
V L = local terminal relay voltage
r = line resistance (ohm/mile)
x = line reactance (ohm/mile)
IF = current flowing in the fault (I + I')
I = current measured by the relay on the faulty phase
= current flowing into the fault from local terminal
I' = current flowing into the fault from remote terminal
D = fault location (permile or km from relay to the fault)
R = fault resistance
R F = apparent fault resistance at relay; R x (1 + I'/I)
The following describes how to solve the above equation (determination of D fault distance
and R fault resistance). The line model used will be the 3×3 matrix of the line impedance
(resistive and inductive) of the three phases, and mutual values between phases.
2. X 1 + X 0 X 0 − X1
ωLaa = ωLbb = ωLcc = ωLab = ωLbc = ωLac =
3 and 3
and
X1 : positive sequence reactance
X0 : zero-sequence reactance
The line model is obtained from the positive and zero-sequence impedance. The use of four
different residual compensation factor settings is permitted on the relay, as follows:
kZ1: residual compensation factor used to calculate faults in zones 1 and 1X.
kZ2: residual compensation factor used to calculate faults in zone 2.
kZp: residual compensation factor used to calculate faults in zone p.
kZ3/4: residual compensation factor used to calculate faults in zones 3 and 4.
The solutions "Dfault " and "Rfault " are obtained by solving the system of equations (one
equation per step of the calculation) using the Gauss Seidel method.
n n
∑ (I
n0
fault )²
R fault (n) =
n n
∑ (V
n0
L. Z 1. IL ) − Rfault.( n − 1).∑ ( Z 1. IL.IFault )
n0
n
∑ (Z .I )²
n0
1 L
Dfault (n) =
Rfault and Dfault are computed for every sample (12 samples per cycle).
With IL equal to Iα+k0.3 x I0 for phase-to-earth loop or IL equal to Iαβ for phase-to-phase
loop.
Relay Description P44x/EN HW/E33
Z1
Zs iB Z1
Z Fault
Zs iA Z1
R / Phase
VCN VBN VAN kS ZS VA VB VC k0 Z1 RFault
Location
of Distance Relay
P3031ENa
with α = phase A, B or C
The model for the current IF circulating in the fault is (3 x I0) during the first 40 ms and then
Iα.
The (3 x I0) current is used for the first 40 milliseconds to model the fault current, thus
eliminating the load current before the circuit breakers are operated during the 40ms (one
pole tripping). After the 40ms, the phase current is used.
VAN = Z1.Dfault.(IA+k0.3xI0)+Rfault.Ifault
VBN = Z1.Dfault.(IB+k0.3xI0)+Rfault.Ifault
VCN = Z1.Dfault.(IC+k0.3xI0)+Rfault.Ifault
x 4 kO residual compensation factors
= 12 phase-to-earth loops are continuously monitored and computed for each samples.
P44x/EN HW/E33 Relay Description
R0–R1 + j.(X0–X1)
VαN = (R1+j.X1).Dfault.(Iα + .3I0) + Rfault.Ifault
3.(R1-jX1)
R0–R1 + j.(X0–X1)
VαN = (R1+j.X1).Dfault.Iα + .Dfault.3I0 + Rfault.Ifault
3
R0–R1 j.(X0–X1)
VαN = R1.Dfault.Iα + .Dfault.3I0 + j.X1. Dfault.Iα + .Dfault.3I0 + Rfault.Ifault
3 3
R0–R1 j.(X0–X1)
VαN = R1.Dfault.Iα + .Dfault.3I0 + j.X1. Dfault.Iα + .Dfault.(IA+IB+IC) + Rfault.Ifault
3 3
R0–R1 (X +2.X1) dI (X –X ) dI (X –X ) dI
VAN = R1.Dfault.IA + .Dfault.3I0 + 0 .Dfault. A + 0 1 .Dfault. B + 0 1 .Dfault. C + Rfault.Ifault
3 3 dt 3 dt 3 dt
R0–R1 dI dI dI
VAN = R1.Dfault.IA + .Dfault.3I0 + LAA.Dfault. A + LAB.Dfault. B + LAC.Dfault. C + Rfault.Ifault
3 dt dt dt
R0–R1 dI dI dI
VBN = R1.Dfault.IB + .Dfault.3I0 + LAB.Dfault. A + LBB.Dfault. B + LBC.Dfault. C + Rfault.Ifault
3 dt dt dt
R0–R1 dI dI dI
VCN = R1.Dfault.IC + .Dfault.3I0 + LAC.Dfault. A + LBC.Dfault. B + LCC.Dfault. C + Rfault.Ifault
3 dt dt dt
4.1.2 Impedance measurement algorithms work with instantaneous values (current and voltage).
Derivative current value (dI/dt) is obtained by using FIR filter.
4.1.3 Phase-to-phase loop impedance
Zs i Z1 X / Phase R Fault/ 2
C
Z1
Zs iB Z1
Z Fault
Zs iA Z1 RFault
R / Phase
VCN VBN VAN VC
Location
of Distance Relay P3032ENa
The model for the current Ifault circulating in the fault Iαβ.
VAB = 2Z1.Dfault.IAB + Rfault.Ifault
VBC = 2Z1.Dfault.IBC + Rfault.Ifault
VCA = 2Z1.Dfault.ICA + Rfault.Ifault
= 3 phase-to-phase loops are continuously monitored and computed for each sample.
dIαβ
Vαβ = 2R1.Dfault.Iαβ + 2X1.Dfault. + Rfault.Ifault
dt
dIA dI dI R
VAB = R1.Dfault.(IA – IB) + (LAA–LAB).Dfault. + (LAB–LBB).Dfault. B + (LAC–LBC).Dfault. C + fault.Ifault
dt dt dt 2
dIA dI dI R
VBC = R1.Dfault.(IB – IC) + (LAB–LAC).Dfault. + (LBB–LBC).Dfault. B + (LBC–LCC).Dfault. C + fault.Ifault
dt dt dt 2
dIA dI dI R
VCA = R1.Dfault.(IC – IA) + (LAC–LAA).Dfault. + (LBC–LAB).Dfault. B + (LCC–LAC).Dfault. C + fault.Ifault
dt dt dt 2
Impedance measurement algorithms work with instantaneous values (current and voltage).
Derivative current value (dI/dt) is obtained by using FIR filter.
4.2 "Deltas" Algorithms
The patented high-speed algorithm has been proven with 10 years of service at all voltage
levels from MV to EHV networks. The P440 relay has ultimate reliability of phase selection
and directional decision far superior to standard distance techniques using superimposed
algorithms. These algorithms or delta algorithms are based on transient components and
they are used for the following functions:
Detection of the fault
By comparing the superimposed values to a threshold which is low enough to be crossed
when a fault occurs and high enough not to be crossed during normal switching outside of
the protected zones.
Establishing the fault direction
Only a fault can generate superimposed values; therefore, it is possible to determine
direction by measuring the transit direction of the superimposed energy.
Phase selection
As the superimposed values no longer include the load currents, it is possible to make high-
speed phase selection.
4.2.1 Fault Modelling
Consider a stable network status-the steady-state load flow prior to any start. When a fault
occurs, a new network is established. If there is no other modification, the differences
between the two networks (before and after the fault) are caused by the fault. The network
after the fault is equivalent to the sum of the values of the status before the fault and the
values characteristic of the fault. The fault acts as a source for the latter, and the sources
act as passive impedance in this case.
P44x/EN HW/E33 Relay Description
VR IR VR IR
R F R F
ZS ZL ZL ZR
Relay Relay
V F (prefault voltage)
ZS ZL ZL ZR
Relay Relay
RF
V R ' = Voltage at Relay Location
VR IR VR IR
R F R F
ZS ZL ZL ZR
Relay Relay
-V F
Fault Inception
P3033ENa
• The circuit breaker(s) should be closed just prior to fault inception (2 cycles of healthy
pre-fault data should be stored) – the line is energised from one or both ends,
• The source characteristics should not change noticeably (there is no power swing or
out-of-step detected).
• Power System Frequency is being measured and tracked (24 samples per cycle at 50
or 60Hz).
Relay Description P44x/EN HW/E33
No fault is detected :
• all nominal phase voltages are between 70% and 130% of the nominal value.
• the residual voltage (3.V0) is less than 10% of the nominal value
• the residual current (3.I0) is less than 10% of the nominal value + 3.3% of the
maximum load current flowing on the line
The measured loop impedance are outside the characteristic, when these requirements are
fulfilled, the superimposed values are used to determine the fault inception (start), faulty
phase selection and fault direction. The network is then said to be "healthy" before the fault
occurrence.
4.2.2 Detecting a Transition
In order to detect a transition, the MiCOM P441, P442 and P444 compares sampled current
and voltage values at the instant "t" with the values predicted from those stored in the
memory one period and two periods earlier.
2T
G
G = Current or Voltage
T
G(t)
G(t-2T) G(t-T)
Gp(t)
Time
t-2T t-T t
P3034ENa
V = line-to-ground voltage = U / √3
G(t) = G(t) - Gp(t) is the transition value of the reading G.
4.2.3 Confirmation
In order to eliminate the transitions generated by possible operations or by high frequencies,
the transition detected over a succession of three sampled values is confirmed by checking
for at least one loop for which the two following conditions are met:
The start-up of the high-speed algorithms will be confirmed if ∆U AND ∆I are detected on
three consecutive samples.
4.2.4 Directional Decision
The "Delta" detection of the fault direction is determined from the sign of the energy per
Phase for the transition values characterising the fault.
VR
IR
F
ZS ZL ZL ZR
Relay
-V F
Forward Fault
VR
IR
R
ZS ZL ZL ZR
Relay
-V F
Reverse Fault
P3035ENa
ni ≥ n 0 + 5 ni ≥ n 0 + 5 ni ≥ n 0 + 5
SA = ∑n0
(∆VANi . ∆IA i ) SB = ∑n0
(∆VBNi . ∆IB i ) SC = ∑ (∆V
n0
CNi . ∆ICi )
Where no is the instant at which the fault is detected, ni is the instant of the calculation and S
is the calculated transition energy.
If the fault is in the forward direction, then S i <0 (i = A, B or C phase).
If the fault is in the reverse direction, then S i >0.
The directional criterion is valid if
S >5 x (10% x Vn x 20% x In x cos (85° )
This sum is calculated on five successive samples.
RCA angle of the delta algorithms is equal to 60° (-30°) if the protected line is not serie
compensated (else RCA is equal to 0°).
Relay Description P44x/EN HW/E33
ni ≥ n 0 + 4 ni ≥ n 0 + 4
SAN = ∑ (∆I ' A i )²
n0
SAB = ∑ (∆I '
n0
ABi )²
ni ≥ n 0 + 4 ni ≥ n 0 + 4
SBN = ∑ (∆I ' Bi )²
n0
SBC = ∑ (∆I '
n0
BC i )²
ni ≥ n 0 + 4 ni ≥ n 0 + 4
SCN = ∑ (∆I ' C i )²
n0
SCA = ∑ (∆I '
n0
CAi )²
The phase selection is valid if the sum (SAB+SBC+SCA) is higher than a threshold. This
sum is not valid if the positive sequence impedance on the source side is far higher than the
zero sequence impedance. In this case, the conventional algorithms are used to select the
faulted phase(s).
Sums on one-phase and two-phase loops are performed. The relative magnitudes of these
sums determine the faulted phase(s).
For examples, assume :
If SAB<SBC<SCA and If SAB<<SBC, the fault has had little effect on the loop A to B. If
SAN<SBN<SCN , the fault declared as single phase fault C.
If the fault is not detected as single-phase by the previous criterion, the fault conditions are
multi-phase.
If SAN<SBN<SCN and If SAB<<SBC, the fault is B to C.
If SAN<SBN<SCN and If SAB•SBC•SCA and if SAN•SBN•SCN, the fault is three-phase (the
fault occurs on the three phases).
4.2.6 Summary
Confirmation
Phase selection
Start Directional decision
P3036ENa
• A breaker closing occurs during a fault. By SOTF, only the Conventional Algorithms
can be used as there are not 2 cycles of healthy network stored.
• The fault is not recent and so the operating conditions of the generators have
changed, or corrective action has been taken, i.e., opening the circuit breakers. This
occurs generally after the first trip. High Speed algorithms are used only during the
first 2 cycles after the fault detection.
-D = X4
lim
P3037ENa
• Rfault (n-1)< Rlim, and Rfault (n)< Rlim, and Rfault (n-1) - Rfault (n)< 10% x Rlim
• Dfault (n-1)< Dlim and Dfault (n) < Dlim and Dfault (n-1) - Dfault (n) < 10% x Dlim
with Rlim being the resistance limit for the single and multi phase faults. This convergence is
dependent on the equations not being collinear thus allowing the terms in Dfault and Rfault
to be discriminated.
Theoretically, zone limits are Z3, Z4, +/- R3G-R4G or +/- R3Ph-R4Ph, if zones 3 and 4 are
enabled. The slope of the characteristic mimics the characteristic of the line.
To model the fault current:
• Two-phase loops: the values (IA - IB), (IB - IC), or (IC - IA) are used.
• Single-phase loops: (IA+ k0.3 x I0), (IB + k0.3 x I0), or (IC + k0.3 x I0) are used.
The results of these algorithms are mainly used as a backup; therefore, the circuit breaker
located at the other end is assumed to be open.
4.3.2 Start-Up
Start-up is initiated when at least one of the six measuring loops converges within the
characteristic (ZAN, ZBN, ZCN, ZAB, ZBC, ZCA).
P44x/EN HW/E33 Relay Description
• If I'C > S2, I'B > S1 and I'A < S1, the fault is two-phase, on phases B and C.
• If I'C > S2 and I'B < S1, the fault is single-phase, on phase C.
• If I'C < S2, the current phase selection cannot be used. Impedance phase selection
should then be used.
Impedance Phase Selection
Impedance phase selection is obtained by checking the convergence of the various
measuring loops within the start-up characteristic, as follows:
• RAN = ZAN x ZBC with ZBC = convergence within the characteristic of the loop
BC (Logical Information).
• RBN = ZBN x ZCA with ZCA = convergence within the characteristic of the loop
CA (Logical Information).
• RCN = ZCN x ZAB with ZAB = convergence within the characteristic of the loop
AB (Logical Information).
• RAB = ZAB x ZCN with ZCN = convergence within the characteristic of the loop
C (Logical Information).
• RBC = ZBC x ZAN with ZAN = convergence within the characteristic of the loop
A (Logical Information).
• RCA = ZCA x ZBN with ZBN= convergence within the characteristic of the loop
B (Logical Information).
Relay Description P44x/EN HW/E33
Single-phase fault
The reference voltage is stored in memory when the fault appears. When the fault is
eliminated by single-phase tripping, the high-speed single-phase auto-reclose (HSAR) is
started.
If a fault appears less than three cycles after the AR starts, the stored voltage value remains
valid as the reference and is used to calculate direction.
If no fault appears during the three cycles after the AR starts, the reference voltage value
becomes that of one of the healthy phases.
If a fault appears during the continuation of the AR cycle or reclosure occurs, the stored
voltage value remains valid for 10 seconds.
If a stored voltage does not exist (SOTF) when one or more loops are convergent within the
start-up characteristic, the directional is forced forward and the trip is instantaneous (if
“SOTF All Zones “ is set or according to the zone location if SOTF Zone 2, etc. is set). If the
settable switch on to fault current threshold I>3 is exceeded on reclosure, the relay
instantaneously trips three-phase.
Two-phase or three-phase fault
The reference voltage is stored in memory when the fault appears. When the fault is
cleared, the stored voltage value remains valid for 10 seconds. If reclosure occurs during
these 10 seconds, the direction is calculated using the stored voltage value.
If a stored voltage does not exist when one or more loops are convergent within the start-up
characteristic, the forward direction is forced and the trip is instantaneous when protection
starts (SOTF All Zones). If the switch on to fault current threshold I>3 is exceeded on
reclosure, the relay trips instantaneously three-phase (TOR All Zones).
The distance element trips immediately as soon as one or more loops converge within the
start-up characteristic during SOTF (SOTF All Zones).
Other modes can be selected to trip selectively by SOFT or TOR according to the fault
location (SOTF Zone 1, SOTF Zone 2, etc., TOR Zone 1, TOR Zone 2, etc. depending from
the software version - from V3.1 available) – (See section 2.12, in chapter P44x/EN AP).
4.4 Faulted Zone Decision
The Decision of the faulted zone is determined by either the zone "Deltas" or "Conventional"
algorithms.
The zones are defined for a convergence between the Dfault and Rfault limits related to
each zone. So, the solution pair (Rfault, Dfault) is said to be convergent if:
• Rfault (n-1) < Rfault (i) and Rfault (n) < Rfault (i) and |Rfault (n-1) – Rfault (n)| < 10% x
Rfault (i)
• Dfault (n-1) < Dfault (i) and Dfault (n) < Dfault (i) and |Dfault (n-1) - Dfault (n)| < k% x
Dfault (i)
where .
k= 5% for zones 1 and 1X
and
10% for other zones Z2, Z3, Zp and Z4.
i=1, 1X, 2, p, 3 and 4.
Relay Description P44x/EN HW/E33
Z1
2 1 0
3
4..
R
P3028ENa
Zone Time
Z1 T1
Z1X T1
Z2 T2
Zp Tp
Z3 T3
Z4 T4
There are five time delays associated with the six zones present. Zone 1 and extended zone
1 have the same time delay.
P44x/EN HW/E33 Relay Description
BC : Ifault∆ (IB–IC)
CA : Ifault∆ (IC–IA)
R0–R1 dI dI dI dI
VBN = R1.Dfault.IB + .Dfault.3I0 + LAB.Dfault. A + LBB.Dfault. B + LBC.Dfault. C + Rfault.Ifault + Rm.Im + Lm. m
3 dt dt dt dt
R0–R1 dI dI dI dI
VCN = R1.Dfault.IC + .Dfault.3I0 + LAC.Dfault. A + LBC.Dfault. B + LCC.Dfault. C + Rfault.Ifault + Rm.Im + Lm. m
3 dt dt dt dt
With:
Rm: zero-sequence mutual resistance
Lm: zero-sequence mutual inductance
Im: zero-sequence mutual current
dIA dI dI R
VBC = R1.Dfault.(IB – IC) + (LAB – LAC).Dfault. + (LBB – LBC).Dfault. B + (LBC – LCC).Dfault. C + fault.Ifault
dt dt dt 2
dIA dI dI R
VAC = R1.Dfault.(IC – IA) + (LAC – LAA).Dfault. + (LBC – LAB).Dfault. B + (LCC – LAC).Dfault. C + fault.Ifault
dt dt dt 2
Relay Description P44x/EN HW/E33
With:
∆IA - ∆IB
∆IB - ∆IC
∆IC - ∆IA
4.6.1 Selecting the fault location data
Selection of the analogue data that is used depends on
• Single lines.
Powerswing Z3
Boundary Stable R
Characteristic Unstable
Swing Swing
Z4
P3038ENa
• At least one single-phase impedance is within the start-up zone after having crossed
the power swing band in more than 5 ms.
• The three impedance points have been in the power swing band for more than 5 ms.
• At least two poles of the breaker are closed (impedance measurement possible on two
phases).
Relay Description P44x/EN HW/E33
• At least one single-phase impedance is within the start-up zone after having crossed
the power swing band in more than 5ms.
• The two impedance points have been in the power swing band for more than 5 ms.
NOTE: During an open-pole condition, the P44x monitors the power swing on
two single-phase loops. No external information is needed if the
voltage transformers are on the line side. If the voltage transformers
are on the bus side, the «pole discrepancy» signal should be used.
The «pole discrepancy» input represents a «one-circuit-breaker-pole-
open» condition.
4.7.3 Conditions for isolating lines
If there is a power swing, it may be necessary to trip and disconnect the two out-of-step
sources. There are various tripping and blocking options available that are used to select if
the line is tripped for power swings or not.
The selective blocking of remote zones allows the P44x to separate the network near the
electrical zero by tripping zone 1 only. Therefore, in the example given in figure 15, the relay
D trips out.
Electrical
Zero
A B C D E F
Where:
kr = an adjustable coefficient for residual or zero sequence current (3 x I0),
ki: = an adjustable coefficient for negative sequence current (I2),
Imax(t): maximum instantaneous current detected on one phase (A, B or C),
IN: nominal current
4.7.5 Fault Detection after Single-phase Tripping (one-pole-open condition)
After a circuit breaker pole has opened, there is no current and voltage on the applicable
phase, which allows the protection unit to detect whether a one-pole cycle of the voltage
transformer are on a line side.
The reception of «poles discrepancy» input signal allows the protection unit to detect one-
pole-open condition blocking if the voltage transformer is on the bus side.
If another fault appears during a one-pole cycle or just after the voltage has been restored on
the applicable phase, direction is defined and phase selection performed.
4.8 Double Circuit Lines
Double circuit lines must be taken into account in the operating principle of the protection
scheme to avoid unwanted tripping of «sound» phases, which could be the result of an
excessively general phase selection.
Phase selection for an inter-circuit fault
During a two-phase fault selection, for example on loop AB, the P44x checks direction on the
two adjacent ground loops, (A to Neutral and B to Neutral). The direction is determined
using either the conventional algorithm or the high-speed algorithm (using superimposed
quantities), depending on fault severity. If superimposed components are used, the
transient (fault) energy is summated phase by phase.
n
∑ (∆V
n
FaultDirec tionLoop _ AN = ∑ (∆V AN .∆I A ) FaultDirectionLoop_ BN = BN.∆IB )
n0 and n0
Z1 AN fault Z1 BN fault
The directions of the two adjacent ground loops are compared, as follows:
• If the two directions are forward, the fault is a two-phase fault on the protected line.
• If only one of the directions is forward, for instance Sa, the fault is single-phase
(A to Neutral) on the protected line.
• If the two directions are reverse, the fault is not on the protected line.
Relay Description P44x/EN HW/E33
Reverse Forward
3 4
3 4
Weak 1 2 Strong
Source Forward Forward Source
1 2
All breakers closed
Relay 3 senses reverse current
3 4
Forward Reverse
3 4
Weak 1 2 Strong
Source Source
1 Forward 2
Breaker 1 opens
Relay 3 senses forward current
P3041ENa
• The main operating mode, directional comparison protection uses the signalling
channel and is a communication-aided scheme.
• ∆I ≥ 0.05 IN
• ∆V ≥ 0.1 VN (L-G)
A fault is confirmed if these thresholds are exceeded for more then 1 ½ cycles
4.9.2 Directional determination
The fault direction is determined by measuring the angle between the residual voltage and
the residual current derivative. The fault is forward if the angle is between –14° and +166°.
A negative or zero sequence polarisation is selectable in order to determinate the earth fault
direction.
4.9.3 Phase selection
The phase is selected in the same way as for distance protection except that the current
threshold is reduced (∆I ≥ 5% x IN and ∆V ≥ 10% x VN)
NOTE: If the phase has not been selected within one cycle, a three-phase
selection is made automatically.
Relay Description P44x/EN HW/E33
Abbreviation Definition
Vr> Threshold of residual or zero sequence voltage (3Vo)
Ied Threshold of residual current for forward fault
Forward Forward directional with zero/negative sequence polarisation
Reverse Reverse directional with zero/negative sequence polarisation
DEF blocking Blocking of DEF element
Carrier Receive DEF Carrier received for the principal line protected (same channel as
distance protection)
Iev Threshold of residual current (0.6 x Ied)
Tripping mode Single or three-phase tripping (selectable)
Z< starting Convergence at least 1 of 6 loops within the tripping
characteristic (internal starting of the distance element)
t_cycle Additional time delay (150ms) of 1 pole AR cycle
t_delay Tripping time delay
t_trans Carrier Send delay settable
Forward Startup
Vr>threshold
Ied threshold
Forward decision & & Carrier Send DEF
Reverse decision &
Blocking DEF
Carrier Received DEF &
Reverse decision
Vr>threshold
& & Reversal Startup
Tripping mode
1 pole dead 0
1
T
Z< starting t-cycle
&
Independant & Three Phase Trip
channels DIST/DEF
Three
2 Pole or 3 Pole Selection 1
P3042ENa
Forward Startup
Vr>threshold
Ied threshold 0
Forward decision & & &
Reverse decision T
t-trans
Tripping Mode
& Reversal Startup
1 pole dead 0
1
T
Z< starting t-cycle
&
Independant & Three Phase Trip
channels DIST/DEF
Three
2 Pole or 3 Pole Selection 1
P3043ENa
CTS Block
&
IN>x start
& SBEF
Slow VTS
Block
& Directional
Check
Trip
Vx > Vs & IDMT/DT
Ix > Is
• the integrity of the battery backed-up SRAM that is used to store event, fault and
disturbance records.
• the voltage level of the field voltage supply which is used to drive the opto-isolated
inputs.
• the flash EPROM containing all program code and language text is verified by a
checksum.
• the code and constant data held in SRAM is checked against the corresponding data
in flash EPROM to check for data corruption.
• the SRAM containing all data other than the code and constant data is verified with a
checksum.
• the integrity of the digital signal I/O data from the opto-isolated inputs and the relay
contacts is checked by the data acquisition function every time it is executed. The
operation of the analogue data acquisition system is continuously checked by the
acquisition function every time it is executed, by means of sampling the reference
voltages.
• the operation of the IRIG-B board is checked, where it is fitted, by the software that
reads the time and date from the board.
In the unlikely event that one of the checks detects an error within the relay’s subsystems,
the platform software is notified and it will attempt to log a maintenance record in battery
backed-up SRAM. If the problem is with the battery status or the IRIG-B board, the relay will
continue in operation. However, for problems detected in any other area the relay will initiate
a shutdown and re-boot. This will result in a period of up to 5 seconds when the protection is
unavailable, but the complete restart of the relay including all initialisations should clear most
problems that could occur. As described above, an integral part of the start-up procedure is a
thorough diagnostic self-check. If this detects the same problem that caused the relay to
restart, i.e. the restart has not cleared the problem, then the relay will take itself permanently
out of service. This is indicated by the ‘Healthy’ LED on the front of the relay, which will
extinguish, and the watchdog contact which will operate.
Application Notes P44x/EN AP/E33
APPLICATION NOTES
Application Notes P44x/EN AP/E33
CONTENT
1. INTRODUCTION 7
1.1 Protection of overhead lines and cable circuits 7
1.2 MiCOM distance relay 7
1.2.1 Protection Features 8
1.2.2 Non-Protection Features 9
1.2.3 Additional Features for the P441 Relay Model 9
1.2.4 Additional Features for the P442 Relay Model 9
1.2.5 Additional Features for the P444 Relay Model 10
1.3 Remark 10
4.2 Voltage transformer supervision (VTS) – Main VT for minZ measurement 110
4.2.1 VTS logic description 110
4.2.2 The internal detection FUSE Failure condition 112
4.2.3 Fuse Failure Alarm reset 112
4.2.4 Loss of One or Two Phase Voltages 113
4.2.5 Loss of All Three Phase Voltages Under Load Conditions 113
4.2.6 Absence of Three Phase Voltages Upon Line Energisation 113
4.2.7 Menu Settings 114
4.2.8 INPUT / OUTPUT used in VTS logic: 115
4.3 Current Transformer Supervision (CTS) 115
4.3.1 The CT Supervision Feature 115
4.3.2 Setting the CT Supervision Element 116
4.4 Check synchronisation 116
4.4.1 Dead Busbar and Dead Line 118
4.4.2 Live Busbar and Dead Line 118
4.4.3 Dead Busbar and Live Line 118
4.4.4 Check Synchronism Settings 119
4.4.5 Logic inputs / Outputs from synchrocheck function 123
4.5 Autorecloser 125
4.5.1 Autorecloser Functional Description 125
4.5.2 Benefits of Autoreclosure 127
4.5.3 Auto-reclose logic operating sequence 128
4.5.4 Scheme for Three Phase Trips 134
4.5.5 Scheme for Single Pole Trips 134
4.5.6 Logical Inputs used by the Autoreclose logic 136
4.5.7 Logical Outputs generated by the Autoreclose logic 142
4.5.8 Setting Guidelines 149
4.5.9 Choice of Protection Elements to Initiate Autoreclosure 149
4.5.10 Number of Shots 149
4.5.11 Dead Timer Setting 150
4.5.12 De-Ionising Time 150
4.5.13 Reclaim Timer Setting 151
4.6 Circuit breaker state monitoring 152
4.6.1 Circuit Breaker State Monitoring Features 152
4.6.2 Inputs / outputs DDB for CB logic: 156
4.7 Circuit breaker condition monitoring 157
4.7.1 Circuit Breaker Condition Monitoring Features 157
4.7.2 Setting guidelines 159
4.7.3 Setting the Number of Operations Thresholds 159
4.7.4 Setting the Operating Time Thresholds 160
4.7.5 Setting the Excessive Fault Frequency Thresholds 160
4.7.6 Inputs/Outputs for CB Monitoring logic 160
Application Notes P44x/EN AP/E33
8. DDB DESCRIPTION FOR ALL TYPES P441/P442 & P444 MODELS 189
P44x/EN AP/E33 Application Notes
BLANK PAGE
Application Notes P44x/EN AP/E33
1. INTRODUCTION
1.1 Protection of overhead lines and cable circuits
Overhead lines are amongst the most fault susceptible items of plant in a modern power
system. It is therefore essential that the protection associated with them provides secure
and reliable operation. For distribution systems, continuity of supply is of para mount
importance. The majority of faults on overhead lines are transient or semi-permanent in
nature, and multi-shot autoreclose cycles are commonly used in conjunction with
instantaneous tripping elements to increase system availability. Thus, high speed, fault
clearance is often a fundamental requirement of any protection scheme on a distribution
network. The protection requirements for sub-transmission and higher voltage systems must
also take into account system stability. Where systems are not highly interconnected the
use of single phase tripping and high speed autoreclosure is commonly used. This in turn
dictates the need for high speed protection to reduce overall fault clearance times.
Underground cables are vulnerable to mechanical damage, such as disturbance by
construction work or ground subsidence. Also, faults can be caused by ingress of ground
moisture into the cable insulation, or its buried joints. Fast fault clearance is essential to limit
extensive damage, and avoid the risk of fire, etc.
Many power systems use earthing arrangements designed to limit the passage of earth fault
current. Methods such as resistance earthing make the detection of earth faults difficult.
Special protection elements are often used to meet such onerous protection requirements.
Physical distance must also be taken into account. Overhead lines can be hundreds of
kilometres in length. If high speed, discriminative protection is to be applied it will be
necessary to transfer information between the line ends. This not only puts the onus on the
security of signalling equipment but also on the protection in the event of loss of this signal.
Thus, backup protection is an important feature of any protection scheme. In the event of
equipment failure, maybe of signalling equipment or switchgear, it is necessary to provide
alternative forms of fault clearance. It is desirable to provide backup protection which can
operate with minimum time delay and yet discriminate with the main protection and
protection elsewhere on the system.
1.2 MiCOM distance relay
MiCOM relays are a range of products from T&D EAI. Using advanced numerical
technology, MiCOM relays include devices designed for application to a wide range of power
system plant such as motors, generators, feeders, overhead lines and cables.
Each relay is designed around a common hardware and software platform in order to
achieve a high degree of commonality between products. One such product in the range is
the series of distance relays. The relay series has been designed to cater for the protection
of a wide range of overhead lines and underground cables from distribution to transmission
voltage levels.
The relay also includes a comprehensive range of non-protection features to aid with power
system diagnosis and fault analysis. All these features can be accessed remotely from one
of the relays remote serial communications options.
P44x/EN AP/E33 Application Notes
• 21G/21P : Phase and earth fault distance protection, each with up to 5 independent
zones of protection. Standard and customised signalling schemes are available to
give fast fault clearance for the whole of the protected line or cable.
• 50/51 : Instantaneous and time delayed overcurrent protection - Four elements are
available, with independent directional control for the 1st and 2nd element. The fourth
element can be configured for stub bus protection in 1½ circuit breaker arrangements.
The 3rd element can be used for SOFT/TOR logic.
• Four Setting Groups - Independent setting groups to cater for alternative power
system arrangements or customer specific applications.
• Remote Serial Communications - To allow remote access to the relays. The following
communications protocols are supported: Courier, MODBUS, IEC60870-5/103 and
DNP3 (UCA2 soon available).
• Circuit Breaker Control - Opening and closing of the circuit breaker can be achieved
either locally via the user interface / opto inputs, or remotely via serial
communications.
• Circuit Breaker Condition Monitoring - Provides records / alarm outputs regarding the
number of CB operations, sum of the interrupted current and the breaker operating
time.
• 8 Logic Inputs - For monitoring of the circuit breaker and other plant status.
• 14 Output relay contacts - For tripping, alarming, status indication and remote
control.
1.2.4 Additional Features for the P442 Relay Model
• Real Time Clock Synchronisation - Time synchronisation is possible from the relay
IRIG-B input. (IRIG-B must be specified as an option at time of order).
• 16 Logic Inputs - For monitoring of the circuit breaker and other plant status.
• 21 Output relay contacts - For tripping, alarming, status indication and remote
control.
P44x/EN AP/E33 Application Notes
• Real Time Clock Synchronisation - Time synchronisation is possible from the relay
IRIG-B input. (IRIG-B must be specified as an option at time of order).
• 24 Logic Inputs - For monitoring of the circuit breaker and other plant status.
• 32 Output relay contacts - For tripping, alarming, status indication and remote
control.
1.3 Remark
The PSL screen copy extracted from S1, uses the different types of model P44x (07, 09…).
(See the DDB equivalent table with the different model number).
Example : check synch OK (model 07) = DDB204
check synch OK (model 09) = DDB236
Application Notes P44x/EN AP/E33
X( /phase)
ZONE 3
ZONE P
ZONE 2
ZONE 1X
ZONE 1
ZONE 4
P0470ENa
All phase fault protection elements are quadrilateral shaped, and are directionalied as
follows:
• Zone 4 - Directional reverse zone. Note that zone 3 and zone 4 can be set with
same Rloop value to provide a general start of the relay.
Remark: If any zone i presents a Rloop i bigger than R3=R4, the limit of the
start is always given by R3. See also the "Commissioning Test"
chapter.
2.3 Earth fault distance protection
The P441, P442 and P444 relays have 5 zones of earth (ground) fault protection, as shown
in the earth loop impedance plot Figure 2 below.
Type of fault can be selected in MiCOM S1 (only Phase/Phase or P/P & P/Ground)
X( /phase)
ZONE 3
ZONE P (Programmable)
ZONE 2
ZONE 1X
ZONE 1
ZONE P Reverse
ZONE 4
P0471ENa
All earth fault protection elements are quadrilateral shaped, and are directionalised as per
the phase fault elements. The reaches of the earth fault elements use residual
compensation of the corresponding phase fault reach. The residual compensation factors
are as follows:
• If Zp is a forward zone
− Z1 ! Z2 < Zp < Z3
− tZ1 < tZ2 < tZp < tZ3
− R1G < R2G < RpG < R3G = R4G
− R1Ph < R1extPh < R2Ph < RpPh < R3Ph
• If Zp is a reverse zone
− Z1 < Z2 < Z3
− Zp > Z4
− tZ1 < tZ2 < tZ3
− tZp < tZ4
− R1G < R2G < R3G
− RpG < R3G = R4G
− R1Ph < R2Ph < R3Ph
− RpPh < R3Ph = R4Ph
− R3G < UN / (1.2 X √3 IN)
− R3Ph < UN / (1.2 X √3 IN)
Remarks: 1. If Z3 is disabled, the forward limit element becomes the
smaller zone Z2- (or Zp if selected forward)
2. If Z4 is disabled, the directional limit for the forward zone is: 30°
(since version A4.0)
3. For older version than A4.0, the directional limit is: 0° (when Z4
is selected: disable).
Conventional rules are used as follows:
− Distance Timers are initiated as soon as the relay has picked up – CVMR pickup
distance
(CVMR = Start & Convergence)
− The minimum tripping time even with Carrier received is T1
− Zone 4 is always Reverse
Application Notes P44x/EN AP/E33
(*) the use of an apostrophe in the above logic (Z'1) is explained in section 2.7.2.1 Figure 3
P44x/EN AP/E33 Application Notes
2.5.3 Outputs
2.6.2 Outputs
• Serial Compensated Line : If enabled, the Directional used in the Deltas Algorithms is
set at 90°
(Fwd = Quad1&4 / Rev = Quad 2&3)
REV FWD
REV FWD
P0472ENa
Application Notes P44x/EN AP/E33
• If disable, the Directional of the Deltas algorithms is set at -30° like conventional
algorithms
FWD FWD
R
REV FWD
REV -30˚
P0473ENa
• Overlap Z Mode: If enable, for a fault in Zp (fwd), then Z1 & Z2 will be displayed in
LCD/Events/Drec – The internal logic is not modified
2.7.2 Zone Logic Applied
Normally the zone logic used by the distance algorithm is as below:
Z1'
Z2'
Z4'
P0462XXa
Z1x
& Z1x'
unblock PS ≥1
in Z1
Z1<ZL &
≥1
1
& Z1'
Z1
Reversal
Guard
&
PermZ2
≥1
Power
Swing
≥1 & Z2'
Unblock PS
≥1 unblock PS
in Z2
Z2
&
PermFwd
≥1 Forward'
&
Forward
unblock PS ≥1
in Z3
& Z3'
Z3 Z2'
unblock PS
in Z4 ≥1
Z4 & Z4'
Zp_Fwd
&
unblock PS
in Zp
≥1
Zp'
Zp &
Reverse
Reverse'
≥1
P0474ENa
2.7.2.2 Inputs
2.7.2.3 Outputs
For guidance on Line Length, Line Impedance, kZm Mutual Compensation and kZm mutual
compensation Angle settings, refer to section 4.1.
2.7.3 Zone Reaches
All impedance reaches for phase fault protection are calculated in polar form: Z ∠θ, where Z
is the reach in ohms, and θ is the line angle setting in degrees, common to all zones.
The line parameters can be adjusted in polar or rectangular mode to give the total positive
impedance of the protected line:
• The zone 1 elements of a distance relay should be set to cover as much of the
protected line as possible, allowing instantaneous tripping for as many faults as
possible. In most applications the zone 1 reach (Z1) should not be able to respond to
faults beyond the protected line. For an underreaching application the zone 1 reach
must therefore be set to account for any possible overreaching errors. These errors
come from the relay, the VTs and CTs and inaccurate line impedance data. It is
therefore recommended that the reach of the zone 1 distance elements is restricted to
80 - 85% of the protected line impedance (positive phase sequence line impedance),
with zone 2 elements set to cover the final 20% of the line. (Note: Two of the channel
aided distance schemes described later, schemes POP Z1 and BOP Z1 use
overreaching zone 1 elements, and the previous setting recommendation does not
apply).
• The zone 2 elements should be set to cover the 20% of the line not covered by zone
1. Allowing for underreaching errors, the zone 2 reach (Z2) should be set in excess of
120% of the protected line impedance for all fault conditions. Where aided tripping
schemes are used, fast operation of the zone 2 elements is required. It is therefore
beneficial to set zone 2 to reach as far as possible, such that faults on the protected
line are well within reach. A constraining requirement is that, where possible, zone 2
does not reach beyond the zone 1 reach of adjacent line protection. Where this is not
possible, it is necessary to time grade zone 2 elements of relays on adjacent lines.
For this reason the zone 2 reach should be set to cover ≤50% of the shortest adjacent
line impedance, if possible. When setting zone 2 earth fault elements on parallel
circuits, the effects of zero sequence mutual coupling will need to be accounted for.
The mutual coupling will result in the Zone 2 ground fault elements underreaching. To
ensure adequate coverage an extended reach setting may be required, this is covered
in Section 2.7.7.
• The zone 3 elements would usually be used to provide overall back-up protection for
adjacent circuits. The zone 3 reach (Z3) is therefore set to approximately 120% of the
combined impedance of the protected line plus the longest adjacent line. A higher
apparent impedance of the adjacent line may need to be allowed where fault current
can be fed from multiple sources or flow via parallel paths.
• Zone P is a reversible directional zone. The setting chosen for zone P, if used at all,
will depend upon its application. Typical applications include its use as an additional
time delayed zone or as a reverse back-up protection zone for busbars and
transformers. Use of zone P as an additional forward zone of protection may be
required by some users to line up with any existing practice of using more than three
forward zones of distance protection. Zone P may also be useful for dealing with some
mutual coupling effects when protecting a double circuit line, which will be discussed
in section 2.7.7.
• The zone 4 elements would typically provide back-up protection for the local busbar,
where the offset reach is set to 25% of the zone 1 reach of the relay for short lines
(<30km) or 10% of the zone 1 reach for long lines. Setting zone 4 in this way would
also satisfy the requirements for Switch on to Fault, and Trip on Reclose protection, as
described in later sections. Where zone 4 is used to provide reverse directional
decisions for Blocking or Permissive Overreach schemes, zone 4 must reach further
behind the relay than zone 2 for the remote relay. This can be achieved by setting:
Z4 ≥ ((Remote zone 2 reach) x 120%) minus the protected line impedance.
P44x/EN AP/E33 Application Notes
• The zone 1 time delay (tZ1) is generally set to zero, giving instantaneous operation.
However, a time delay might be employed in cases where a large transient DC
component is expected in the fault current, and older circuit breakers may be unable
to break the current until zero crossings appear.
• The zone 2 time delay (tZ2) is set to co-ordinate with zone 1 fault clearance time for
adjacent lines. The total fault clearance time will consist of the downstream zone 1
operating time plus the associated breaker operating time. Allowance must also be
made for the zone 2 elements to reset following clearance of an adjacent line fault and
also for a safety margin. A typical minimum zone 2 time delay is of the order of
200ms. This time may have to be adjusted where the relay is required to grade with
other zone 2 protection or slower forms of back-up protection for adjacent circuits.
• The zone 3 time delay (tZ3) is typically set with the same considerations made for the
zone 2 time delay, except that the delay needs to co-ordinate with the downstream
zone 2 fault clearance. A typical minimum zone 3 operating time would be in the
region of 400ms. Again, this may need to be modified to co-ordinate with slower forms
of back-up protection for adjacent circuits.
• The zone 4 time delay (tZ4) needs to co-ordinate with any protection for adjacent lines
in the relay’s reverse direction. If zone 4 is required merely for use in a Blocking
scheme, tZ4 may be set high.
Remark: In MiCOM S1, timers settable are: tZi but in the DDB corresponding
cells are: Ti
2.7.5 Residual Compensation for Earth Fault Elements
For earth faults, residual current (derived as the vector sum of phase current inputs
(Ia + Ib + Ic) is assumed to flow in the residual path of the earth loop circuit. Thus, the earth
loop reach of any zone must generally be extended by a multiplication factor of (1 + kZ0)
compared to the positive sequence reach for the corresponding phase fault element. kZ0 is
designated as the residual compensation factor, and is calculated as:
Where:
Z1 = Positive sequence impedance for the line or cable;
Z0 = Zero sequence impedance for the line or cable.
kZ0 CALCULATION DESCRIPTION
If we consider a phase to ground fault AN with analog values VA and IA.
Using symetrical components, VA is described as above:
(1) VA = V1 + V2 + V0 = Z1I1 + Z2I2 + Z0I0
Z2 = Z1 (for a line or a cable)
(2) VA = Z1 (I1 + I2) + Z0I0
we can write also: IA = I1 + I2 +I0
(3) (I1 + I2) = IA – I0
with (3) in (2) we obtain:
(4) VA = Z1 (IA – I0) + Z0I0
The physical fault current is IR = 3I0 – if put in (4) – we obtain:
VA = Z1 [IA – IR/3 + Z0IR/3Z1] = Z1 [IA + IR (Z0–Z1)/3Z1]
but: (Z0 – Z1)/3Z1 = kZ0
Application Notes P44x/EN AP/E33
That is the form used for the result of Z measured with injector providing U, I, ϕ
Separate compensation for each zone (KZ1, KZ2, KZ3/4 and KZp) allows more accurate
earth fault reach control for elements which are set to overreach the protected line, such that
they cover other circuits which may have different zero sequence to positive sequence
impedance ratios (Example: underground cable & overhead line in the protected line).
2.7.6 Resistive Reach Calculation - Phase Fault Elements
In MiCOM S1 all resistances are set per loop
The P441, P442 and P444 relays have quadrilateral distance elements, thus the resistive
reach (RPh) is set independently of the impedance reach along the protected line/cable.
RPh defines the maximum amount of fault resistance additional to the line impedance for
which a distance zone will trip, regardless of the location of the fault within the zone. Thus,
the right hand and left hand resistive reach constraints of each zone are displaced by +RPh
and -RPh either side of the characteristic impedance of the line, respectively. RPh is
generally set on a per zone basis, using R1Ph, R2Ph and RpPh. Note that zones 3 and 4
share the resistive reach R3Ph-R4Ph.
When the relay is set in primary impedance terms, RPh must be set to cover the maximum
expected phase-to-phase fault resistance. In general, RPh must be set greater than the
maximum fault arc resistance for a phase-phase fault, calculated as follows:
Ra = (28710 x L) / If1.4
RPh ≥ Ra
Where:
If = Minimum expected phase-phase fault current (A);
L = Maximum phase conductor separation (m);
Typical figures for Ra are given in Table 1 below, for different values of minimum expected
phase fault current.
TABLE 1 - TYPICAL ARC RESISTANCES CALCULATED USING THE VAN WARRINGTON FORMULA
The maximum phase fault resistive reach must be limited to avoid load encroachment trips.
Thus, R3Ph and other phase fault resistive reach settings must be set to avoid the heaviest
allowable loading on the feeder. An example is shown in Figure 3 below, where the worst
case loading has been determined as point “Z”, calculated from:
Zone 3
∆R
R3PG-R4PG
Z
LOAD
Zone 4
P0475ENa
A typical resistive reach coverage would be 40Ω on the primary system. The same load
impedance as in section 2.4.4 must be avoided. Thus R3G is set such as to avoid point Z by
a suitable margin. Zone 3 must never reach more than 80% of the distance from the line
characteristic impedance (shown dotted in Figure 3), towards Z.
For high resistance earth faults, the situation may arise where no distance elements could
operate. In this case it will be necessary to provide supplementary earth fault protection, for
example using the relay Channel Aided DEF protection.
2.7.8 Effects of Mutual Coupling on Distance Settings
Where overhead lines are connected in parallel or run in close proximity for the whole or part
of their length, mutual coupling exists between the two circuits. The positive and negative
sequence coupling is small and can be neglected. The zero sequence coupling is more
significant and will affect relay measurement during earth faults with parallel line operation.
Zero sequence mutual coupling will cause a distance relay to underreach or overreach,
depending on the direction of zero sequence current flow in the parallel line. However, it can
be shown that this underreach or overreach will not affect relay discrimination during parallel
line operation (ie. it is not be possible to overreach for faults beyond the protected line and
neither will it be possible to underreach to such a degree that no zone 1 overlap exists). A
channel-aided scheme will therefore still respond to faults within the protected line and
remain secure during external faults. Some applications exist, however, where the effects of
mutual coupling should be addressed.
2.7.9 Effect of Mutual Coupling on Zone 1 Setting
For the case shown in Figure 5, where one circuit of a parallel line is out of service and
earthed at both ends, an earth fault at the remote bus may result in incorrect operation of the
zone 1 earth fault elements. It may be desirable to reduce the zone 1 earth loop reach for
this application. This can be achieved using an alternative setting group within the relay, in
which the residual compensation factor kZ1 is set at a lower value than normal (typically ≤
80% of normal kZ1).
P44x/EN AP/E33 Application Notes
Z1 G/F (Optional)
Z1 G/F (Normal)
ZMO
P3048ENa
ZMO
(i) Group 1
2.8.1 Settings
• Zone1 (CSZ1)
• Zone2 (CSZ2)
Z1'
Z2'
Z4' Z2'(*)
P0476XXa
(There is a 10ms delay in drop of on the carried send to avoid a logic race between this
signal and the zone pick up.)
2.8.2.2 Inputs
2.8.2.3 Outputs
− 1PZ1 & CR : Trip 1Pole in T1 for fault in Z1 and also in case of Carrier Received
(aided Trip)
− 1PZ1, Z2 & CR : Trip 1Pole for T1 & T2 in T1 for fault in Z1 and CR (aided Trip) and
also in Z2 with CR
Several defined aided trip logic can be selected or an open logic can be designed by user
(see also section 4.5 from chapter P44x/EN HW).
Application Notes P44x/EN AP/E33
Unblocking Basic
+
Aided
Schemes
+
Weak-Infeed
Trip
Distance
Protection
PSB
TOR
+ SOTF
RVG
LOL
• The unblocking function if enabled, carries out a function similar to Carrier receive
logic. (see explanations in section 2.9.4)
• Weak infeed allows for the case where there may be no zone pick up from local end.
• TOR & SOTF applies specific logic in case of manual closing or AR closing logic.
• Trip Distance Protection manages the Trip order regarding the distance algorithm
outputs, the type of trip1P or 3P, the distance timers, and the logic datas such as
power swing blocking.
• Loss of Load manages a specific logic for tripping 3P in Z2 accelerated without carrier.
2.8.3 The Basic Scheme
The Basic distance scheme is suitable for applications where no signalling channel is
available. Zones 1, 2 and 3 are set as described in Sections 2.7.3 to 2.7.10. In general
zones 1 and 2 provide main protection for the line or cable as shown in Figure 9 below, with
zone 3 reaching further to provide back up protection for faults on adjacent circuits.
P44x/EN AP/E33 Application Notes
Z2A
ZL
A Z1A B
Z1B
Z2B
P3050XXa
FIGURE 9 - MAIN PROTECTION IN THE BASIC SCHEME (NO REQUIREMENT FOR SIGNALLING
CHANNEL)
Key:
A, B = Relay locations;
ZL = Impedance of the protected line.
Application Notes P44x/EN AP/E33
Protection A Protection B
Z1' Z1'
& &
T1
tZ1 T1
tZ1
Z2' Z2'
& &
T2
tZ2 T2
tZ2
Trip Trip
Z3' Z3'
T3
tZ3
& ≥1 ≥1 &
T3
tZ3
Zp' Zp'
& &
Tzp
tZp Tzp
tZp
Z4' Z4'
& &
T4
tZ4 T4
tZ4
P0543ENa
Z1 Extension (A)
ZL
A Z1A B
Z1B
Z1 Extension (B)
P3052ENa
Remark: To enable the Z1X logic, the DDB "Z1X extension" cell must be linked
in the PSL (opto/reclaim time…)
Z1'
&
T1
INP_Z1EXT &
None
& >1
Z1x'
T2
Z1X channel fail & & PDist_Trip
Z2'
UNB_Alarm ≥1
Z3'
&
T3
Zp'
&
Tzp
Z4'
&
T4
P0478ENa
2.8.4.2 Outputs
Z2
Z1
Z1 Z1
Z1
Z2
LOL-A
LOL-B
&
LOL-C
18ms
0 & Trip
40ms 0
&
Z2
1
P3053ENa
2.8.5.2 Outputs
Activ_LOL
TRIP _Any
Force_3P_Dist Yes
Force3P_DEF 3p &
Activ WI = WI/echo &
WI_1pTrip = No
UNB_CR_Alarm
&
&
PZ1, PZ2, PFwd ≥1
Z1<ZL
None
S
&
0 Q
R
T
LOL Wind
&
IA_LOL<
&
IB_LOL<
IC_LOL< &
≥1 T
Flt A & 0 S
LOL_Trip3P
Q
18 ms R
Flt B &
Flt C
Flt AB
&
Flt BC
Flt AC
&
Z2'
P0479ENa
• Current reversal guard logic to prevent maloperation of any overreaching zone used in
a channel aided scheme, when fault clearance is in progress on the parallel circuit of a
double circuit line.
2.9.1 Permissive Underreach Transfer Trip Schemes PUP Z2 and PUP Fwd
To provide fast fault clearance for all faults, both transient and permanent, along the length
of the protected circuit, it is necessary to use a signal aided tripping scheme. The simplest
of these is the permissive underreach protection scheme (PUP), of which two variants are
offered in the P441, P442 and P444 relays. The channel for a PUP scheme is keyed by
operation of the underreaching zone 1 elements of the relay. If the remote relay has
detected a forward fault upon receipt of this signal, the relay will operate with no additional
delay. Faults in the last 20% of the protected line are therefore cleared with no intentional
time delay.
Listed below are some of the main features/requirements for a permissive underreaching
scheme:
• The scheme has a high degree of security since the signalling channel is only keyed
for faults within the protected line.
• If the remote terminal of a line is open then faults in the remote 20% of the line will be
cleared via the zone 2 time delay of the local relay.
• If there is a weak or zero infeed from the remote line end, (ie. current below the relay
sensitivity), then faults in the remote 20% of the line will be cleared via the zone 2 time
delay of the local relay.
• If the signalling channel fails, Basic distance scheme tripping will be available.
Z2A
ZL
A Z1A B
Z1B
Z2B
P3054XXa
Protection A Protection B
Signal Signal
Send Z1' Send Z1'
Z1' Z1'
tZ1 & & tZ1
Z3' Z3'
& &
tZ3 tZ3
Zp' Zp'
& &
tZp tZp
Z4'
≥1 Trip Trip
≥1 Z4'
& &
tZ4 tZ4
tZ2 tZ2
& &
Z2' Z2'
&
&
P3055ENa
2.9.1.2 Permissive Underreach Protection Tripping via Forward Start (PUP Fwd)
This scheme is similar to that used in the AREVA EPAC and PXLN relays, allowing an
instantaneous Z2 or Z3 trip on receipt of the signal from the remote end protection. Figure
19 shows the simplified scheme logic.
Z1' Z1'
Z3' Z3'
& &
tZ3 tZ3
Zp' Zp'
tZp & &
tZp
Trip
Z4' ≥1
Trip
≥1
Z4'
&
tZ4 & tZ4
tZ2
tZ2
&
Z2' & Z2'
Fwd' Fwd'
P3056ENa
• Current reversal guard logic is used to prevent healthy line protection maloperation for
the high speed current reversals experienced in double circuit lines, caused by
sequential opening of circuit breakers.
• If the signalling channel fails, Basic distance scheme tripping will be available.
2.9.2.1 Permissive Overreach Protection with Overreaching Zone 2 (POP Z2)
This scheme is similar to that used in the AREVA LFZP and LFZR relays. Figure 20 shows
the zone reaches, and Figure 21 the simplified scheme logic. The signalling channel is
keyed from operation of the overreaching zone 2 elements of the relay. If the remote relay
has picked up in zone 2, then it will operate with no additional delay upon receipt of this
signal. The POP Z2 scheme also uses the reverse looking zone 4 of the relay as a reverse
fault detector. This is used in the current reversal logic and in the optional weak infeed echo
feature.
Z2A
ZL
A Z1A B
Z1B
Z2B
P3054XXa
Z1' Z1'
tZ1 tZ1
& &
Z3' Z3'
Zp' Zp'
tZ2 tZ2
& &
Z2' Z2'
& &
P3058ENa
Z2A
Z1A
A ZL B
Z1B
Z2B
P3059XXa
Z2' Z2'
Z3' Z3'
& &
tZ3 tZ3
Zp' Zp'
&
&
Z1' Z1'
& &
tZ1 tZ1
P3060ENa
Def_Reverse
Reverse
0 &
Distance start
T
FFUS_Confirmed 150 ms
WI Logic confirmed
0
UNB_CR T
60 ms &
Pulse
Timer
200 ms
Activ_WI Echo or WI/echo
P0480ENa
WI logic
& WI_CS
UNB_CR
Echo send:
(NB: For UNB_CR explanation see Unblocking logic in next section 2.9.4)
VA<_WI
& WI_A
CB 52a_phA
& FLT_A
VB<_WI
& WI_B
CB 52a_phB
& FLT_B
VC<_WI
& WI_C
CB 52a_phC
WI_A
WI_B ≥1
≥1 WI_PhaseA
WI_C &
WI/echo
Activ_WI
Trip1P_WI Yes
≥1 WI_PhaseB
&
&
≥1 WI_PhaseC
&
P0482ENa
WI_Phase A
T
WI_Phase B ≥1 0
TtripWI
WI_Phase C
& WI_TripA
& WI_TripB
& WI_TripC
Autor_WI
P0531ENa
2.9.3.1 Inputs
2.9.3.2 Outputs
• Inputs signals [binary inputs: CR (Carrier Receive) COS (Carrier Out of Service)]
• Settings used for the distance channel & DEF aided trip channel
• Carrier Out of Service (INP_COS - binary input for distance logic) and
(INP_COS_DEF - binary input for DEF logic)
2.9.4.1 None
This mode is designed for use with frequency shift keyed (FSK) power line carrier
communications. When the protected line is healthy a guard frequency is sent between line
ends, to verify that the channel is in service. However, when a line fault occurs and a
permissive trip signal must be sent over the line, the power line carrier frequency is shifted to
a new (trip) frequency. Thus, distance relays should receive either the guard, or trip
frequency, but not both together. With any permissive scheme, the PLC communications
are transmitted over the power line which may contain a fault. So, for certain fault types the
line fault can attenuate the PLC signals, so that the permissive signal is lost and not received
at the other line end. To overcome this problem, when the guard is lost and no “trip”
frequency is received, the relay opens a window of time during which the permissive scheme
logic acts as though a “trip” signal had been received. Two opto inputs to the relay need to
be assigned, one is the Channel Receive opto, the second is designated Loss of Guard (the
inverse function to guard received). The function logic is summarised in Table 3.
Application Notes P44x/EN AP/E33
150 ms
0
S
=1 Q UNB Alarm
R
Pulse Timer
Indicates by digital input
200 ms
the Loss of guard
INP COS
&
INP CR
≥1 UNB CR
10 ms
0
S
&
Q
R
Pulse Timer
150 ms
P3061ENa
150 ms
0 S
Q UNB Alarm
R
Pulse Timer
INP COS
&
UNB CR
INP CR ≥1
10 ms
0
S
&
Q
R
Pulse Timer
150 ms
P3062ENa
NOTE: For DEF the logic will used depende upon which settings are enabled:
2.9.4.5 Outputs
• Reverse looking Zone 4 is used to send a blocking signal to the remote end to prevent
unwanted tripping.
• When a simplex channel is used, a BOP scheme can easily be applied to a multi-
terminal line provided that outfeed does not occur for any internal faults.
• The blocking signal is transmitted over a healthy line, and so there are no problems
associated with power line carrier signalling equipment.
• Fast tripping will occur at a strong source line end, for faults along the protected line
section, even if there is weak or zero infeed at the other end of the protected line.
• If a line terminal is open, fast tripping will still occur for faults along the whole of the
protected line length.
• If the signalling channel fails to send a blocking signal during a fault, fast tripping will
occur for faults along the whole of the protected line, but also for some faults within
the next line section.
P44x/EN AP/E33 Application Notes
• If the signalling channel is taken out of service, the relay will operate in the
conventional Basic mode.
• A current reversal guard timer is included in the signal send logic to prevent unwanted
trips of the relay on the healthy circuit, during current reversal situations on a parallel
circuit.
• To allow time for a blocking signal to arrive, a short time delay on aided tripping, Tp,
must be used, as follows:
Recommended Tp setting = Max. signalling channel operating time + 14ms
2.9.5.1 Blocking Overreach Protection with Overreaching Zone 2 (BOP Z2)
This scheme is similar to that used in the other ALSTOM distance relays. Figure 30 shows
the zone reaches, and Figure 31 the simplified scheme logic. The signalling channel is
keyed from operation of the reverse zone 4 elements of the relay. If the remote relay has
picked up in zone 2, then it will operate after the Tp delay if no block is received.
Z4A Z2A
ZL
A Z1A B
Z1B Z4B
Z2B
P3063XXa
Protection A Protection B
Signal
Emission Signal
Emission
Send Z4'
Téléac Send Z4'
Téléac
Z1' Z1'
Z3' Z3'
& &
tZ3
T3 tZ3
T3
Zp' Zp'
& &
tZp
Tzp tZp
Trip Tzp
≥1 Trip ≥1
Z4' Z4'
& &
tZ4
T4 tZ4
T4
Tp Tp
& &
Z2' Z2'
tZ2
T2 & & tZ2
T2
P0533ENa
Z4A Z2A
Z1A
A ZL B
Z1B
Z4B
Z2B
P3065XXa
Z2' Z2'
tZ2 & & tZ2
Z3' Z3'
& &
tZ3 tZ3
Zp' Zp'
& &
tZp tZp
≥1 Trip Trip ≥1
Z4' Z4'
& &
tZ4 tZ4
&
&
Z1' Z1'
tZ1 tZ1
& &
Tp Tp
P3066ENa
t2(C) t2(D)
Fault Fault
A L1 B A L1 B
Strong Weak
source C L2 D source C L2 D
− V< is either a fixed threshold 20% Vn or equal to V Dead Line threshold of the check
synchro function if enabled, (default value for V< dead line = 20% VN)
− I< is either a fixed threshold of 5% In or equal to the I< threshold of the Breaker
Failure protection (default value for I< CB fail = 5% IN).
TOR Enable logic is activated in 2 cases :
1. When internal AR is activated or when the reclaim signal from an external AR is
connected to a digital input (opto):
As soon as the reclaim time starts, the « TOR Enable » is activated . It will be reset at the
end of the internal or external reclaim time.
2. Without any reclaim time (internal AR disabled or external opto input Reclaim Time not
assigned in the PSL):
TOR Enable will be activated during a 200 ms time window, following the detection of pole
dead detection. The TOR logic will be reset (TOR Enable) ONLY 500 ms after the drop off of
any pole dead detection.
This behaviour has been designed to avoid any maloperation on a parallel line, in case of an
incorrect Any Pole Dead detection performed by the internal level detectors (Ex: Fault front
of Busbar on a parallel line and weak source on the other end of the line)
A delay of 200ms will allow the adjacent line to be tripped and the level detectors will then
reset the timer :
• TOR protection logic is enabled any time that any circuit breaker pole has been open
longer than 200ms but not longer than 110s default value (ie. First shot autoreclosure
is in progress)- the timer is configurable from version A3.0 /allows variation of the
duration when dead pole is detected before the internal logic detects line dead and
activates the SOTF logic and also where the relay logic detects that further delayed
autoreclose shots are in progress.
Trip
Reclosing
200 ms 500 ms
TOR Enable
P0532ENa
• SOTF protection is enabled any time that the circuit breaker has been open 3 pole for
longer than 110s, that timer is configurable from version A3.0 /allows variation of the
duration when dead pole is detected before the internal logic detects line dead and
activates the SOTF logic and autoreclosure is not in progress. Thus, SOTF protection
is enabled for manual reclosures, not for autoreclosure.
P44x/EN AP/E33 Application Notes
AR_RECLAIM
Pulse
>1
T
INP_RECLAIM >1 TOR Enable
500 ms
1P or 3P AR
INP_RECLAIM >1
Assigned
T
& 0
200 ms S
Q
>1
>1 R
Any Pole Dead 0
T
500 ms
>1
R
T Q SOTF Enable
All Pole Dead
0 S
>1
TSOTF Enable &
(by default:110 s)
SOTF HS
CBC_Closing Order
CB_Control &
activated
&
INP_CB_Man_Close
P0485ENa
Zone 4
Zone 3
Directional
line (not used)
P0535ENa
SOTF Z1 SOTF trip DIST trip DIST trip x DIST trip DIST trip
(Zp Fwd) T0 T2 TZp T3 T4
SOTF Z2 SOTF trip SOTF trip DIST trip x DIST trip DIST trip
(Zp Fwd) T0 T0 TZp T3 T4
SOTF Z3 SOTF trip SOTF trip SOTF trip x SOTF trip DIST trip
(Zp Fwd) T0 T0 T0 T0 T4
SOTF Z1+Rev (Zp Fwd) SOTF trip DIST trip DIST trip x DIST trip SOTF trip
T0 T2 TZp T3 T0
SOTF Z2+Rev (Zp Fwd) SOTF trip SOTF trip DIST trip x DIST trip SOTF trip
T0 T0 TZp T3 T0
SOTF Z1+Rev (Zp Rev) SOTF trip DIST trip x SOTF trip DIST trip DIST trip
T0 T2 T0 T3 T4
SOTF Z2+Rev (Zp Rev) SOTF trip SOTF trip x SOTF trip DIST trip DIST trip
T0 T0 T0 T3 T4
SOTF Dist. Sch. (Zp fwd) SOTF trip SOTF trip SOTF trip x SOTF trip SOTF trip
(With a 3Plogic) T1 T2 TZp T3 T4
SOTF Disable DIST trip DIST trip DIST trip x DIST trip DIST trip
(Distance scheme & 1P) T1* T2 TZp* T3 T4
No setting in SOTF DIST trip DIST trip DIST trip x DIST trip DIST trip
(All Bits at 0) & No I>3 T1* T2 TZp T3 T4
Level detectors SOTF trip SOTF trip SOTF trip x SOTF trip SOTF trip
T0 T0 T0 T0 T0
*No Ban Tri: Distance trip logic is applied without any 3P trip logic forced by SOTF.
TOR Trip logic results
2.12.3 Switch on to Fault and Trip on Reclose by I>3 Overcurrent Element (not filtered for inruch
current):
Inside the 500 ms time window initiated by SOTF/TOR logic, an instantaneous 3 phases trip
logic will be issued, if a faulty current is measured over the I>3 threshold value (adjusted in
MiCOM S1).
After the 500 ms TOR/SOTF time windows has ended, the I>3 overcurrent element remains
in service with a trip time delay equal to the setting I>3 Time Delay. This element would trip
for close-up high current faults, such as those where maintenance earth clamps are
inadvertently left in position on line energisation.
2.12.4 Switch on to Fault and Trip on Reclose by Level Detectors
TOR/SOTF level detectors (Bit6 in SOTF logic), allows an instantaneous 3 phases tripping
from any low set I< level detector, provided that its corresponding Live Line level detector
has not picked up within 20ms. When closing a circuit breaker to energize a healthy line,
current would normally be detected above setting, but no trip results as the system voltage
rapidly recovers to near nominal. Only when a line fault is present will the voltage fail to
recover, resulting in a trip.
• SOTF/TOR trip by level detectors per phase: If Vphase< 70% Vn AND if Iphase> 5% In
during 20 ms (to avoid any maloperation due to unstable contact during reclosing
order), an instantaneous trip order is issued.
P44x/EN AP/E33 Application Notes
The logic diagram for this, and other modes of TOR/SOTF protection is shown in Figure 37:
T
Va > & 0 & TOC A
Ia < 20 ms
Vb >
T
& 0 & TOC B
Ib <
20 ms
Vc > T
& 0 & TOC C
Ic <
20 ms
SOTF Z1 Enable
&
≥1
Z1 &
Zp
&
Z4
1
Zp Reverse &
Z1+Z2
&
SOTF Z2 Enable
≥1 SOTF/TOR trip
SOTF Z3 Enable
&
Z1+Z2+Z3
PHOC_Start_3Ph_I>3
SOTF Enable
TOR Z1 Enable
&
Z1
TOR Z2 Enable
Z1+Z2 &
TOR Z3 Enable
& ≥1
Z1+Z2+Z3
&
TOR All Zones Enable
&
All Zones
TOR Enable
P0486ENa
• When the overcurrent option is enabled, the I>3 current setting applied should be
above load current, and > 35% of peak magnetising inrush current for any connected
transformers as this element has no second harmonic blocking. Setting guidelines for
the I>3 element are shown in more detail in Table below.
2.12.5.2 Outputs
Man Close CB
Digital input (opto) 6 is assigned by default PSL to "Man Close CB"
The DDB Man Close CB if assigned to an opto input in PSL and when energized, will initiate
the internal SOTF logic enable (see Figure 35) without CB control.
If CB control is activated SOTF will be enable by internal detection (CB closing order
managed by CB control)
AR Reclaim
The DDB AR Reclaim if assigned to an opto input in PSL and when energized, will start the
internal logic TOR enable (see Figure 35).- (External AR logic applied).
CB aux A
CB aux B
CB aux C
The DDB CB Aux if assigned to an opto input in PSL and when energized, will be used for
Any pole dead & All pole dead internal detection
2.12.6.2 Outputs
SOTF Enable
The DDB SOTF Enable if assigned in PSL, indicates that SOTF logic is enabled in the relay
– see logic description in Figure 37
TOR Enable
The DDB TOR Enable if assigned in PSL, indicates that TOR logic is activated in the relay -
see logic description in Figure 37
TOC Start A
The DDB TOC Start A if assigned in PSL, indicates a Tripping order on phase A issued by
the SOTF levels detectors - see Figure 37
TOC Start B
The DDB TOC Start B if assigned in PSL, indicates a Tripping order on phase B issued by
the SOTF levels detectors - see Figure 37
TOC Start C
The DDB TOC Start C if assigned in PSL, indicates a Tripping order on phase C issued by
the SOTF levels detectors - see Figure 37
SOTF/TOR Trip
The DDB SOTF/TOR Trip if assigned in PSL, indicates a 3poles trip by TOR or SOTF logic -
see Figure 37
2.13 Power swing blocking (PSB)
Power swings are oscillations in power flow which can follow a power system disturbance.
They can be caused by sudden removal of faults, loss of synchronism across a power
system or changes in direction of power flow as a result of switching. Such disturbances can
cause generators on the system to accelerate or decelerate to adapt to new power flow
conditions, which in turn leads to power swinging. A power swing may cause the impedance
presented to a distance relay to move away from the normal load area and into one or more
of its tripping characteristics. In the case of a stable power swing it is important that the relay
should not trip. The relay should also not trip during loss of stability since there may be a
utility strategy for controlled system break up during such an event.
∆X
Zone 3
Power
swing
∆R ∆R bundary
Zone 4
∆X
P3068ENa
A fault on the system results in the measured impedance rapidly crossing the ∆R band, en
route to a tripping zone. Power swings follow a much slower impedance locus. A power
swing is detected where all three phase-phase measured impedances have remained within
the ∆R band for at least 5ms, and have taken longer than 5ms to reach the trip characteristic
(the trip characteristic boundary is defined by zones 3 and 4). PSB is indicated on reaching
zone 3 or zone 4. Typically, the ∆R and ∆X band settings are both set with: 0.032 x ∆f x
Rmin load.
AnyPoleDead
Loop AN detected
≥1 &
S ≥2
in PS bundary ∆t
Q S
≥1 R Q PS loop AN
≥1
Tunb &
Loop BN detected ≥1
in PS bundary S
∆t
Q S
≥1 R Q PS loop BN
Tunb
≥1
Loop CN detected
in PS bundary S
Q
∆t
S ≥1 & S
≥1 R Q PS loop CN Q
Power Swing Detection
R
R
Tunb
Inrush AN
Inrush BN
Inrush CN
Fault clear ≥1
Healthy Network
PS disabled
Iphase>(Imax line>) S
Q
Unblocking Imax disabled R
∆ Tunblk
IN> threshold S
≥1 S
Q
R
Unblocking IN disabled Q
Power Swing unblocking
∆Tunblk ≥1 R
I2> threshold S
Q
R
Unblocking I2> disabled
P0488ENa
Z1x
& Z1x'
Unblock Z1
≥1
Z1'
Z1 &
Unblock Z3
≥1
Z3'
&
Z3
≥1
Zp_Fwd Zp'
& &
Unblock Zp
Zp
P0489ENa
Parameter Minimum Setting (to avoid Maximum Setting (to ensure Typical
maloperation for asymmetry unblocking for line faults) Setting
in power swing currents)
IN> > 30% < 100% 40%
I2> > 10% < 50% 30%
The inverse time delayed characteristics listed above, comply with the following formula:
t=T× + L
K
(I/Is) α
–1
Where:
t = operation time
K = constant
I = measured current
Is = current threshold setting
α = constant
L = ANSI/IEEE constant (zero for IEC curves)
T = Time multiplier Setting
Note that the IEEE and US curves are set differently to the IEC/UK curves, with regard to the
time setting. A time multiplier setting (TMS) is used to adjust the operating time of the IEC
curves, whereas a time dial setting is employed for the IEEE/US curves. Both the TMS and
Time Dial settings act as multipliers on the basic characteristics but the scaling of the time
dial is 10 times that of the TMS, as shown in the previous menu. The menu is arranged such
that if an IEC/UK curve is selected, the I> Time Dial cell is not visible and vice versa for the
TMS setting.
Application Notes P44x/EN AP/E33
Time
I>1
I>2
Z3,tZ3
Z4, tZ4
Zp,tZp
Z2,tZ2
Reverse Z1,tZ1 Forward
P3069ENa
I phase
I 1>
Trip
I 2>
No trip
t
tI1> tI2> P0483ENa
If a low current setting is chosen, I>3 will need to discriminate with local and remote distance
protection. This principle is shown in Table 9.
TABLE 9 - CURRENT AND TIME DELAY SETTINGS FOR THE I>3 ELEMENT
Key:
As the instantaneous highset trips three pole it is recommended that the I>3 Time
Delay is set ≥ tZ2 in single pole tripping schemes, to allow operation of the correct
single pole autoreclose cycle.
I>4 Stub Bus Protection
When the protected line is switched from a breaker and a half arrangement it is possible to
use the I>4 overcurrent element to provide stub bus protection. When stub bus protection is
selected in the relay menu, the element is only enabled when the opto-input Stub Bus
Isolator Open (Stub Bus Enable) is energised. Thus, a set of 52b auxiliary contacts (closed
when the isolator is open) are required.
V=0
I>0
Open isolator
Busbar 2
P0536ENa
Although this element would not need to discriminate with load current, it is still common
practice to apply a high current setting. This avoids maloperation for heavy through fault
currents, where mismatched CT saturation could present a spill current to the relay. The I>4
element would normally be set instantaneous, t>4 = 0s.
P44x/EN AP/E33 Application Notes
• In certain applications, residual current may not be detected by an earth fault relay
due to the system configuration. For example, an earth fault relay applied on the delta
side of a delta-star transformer is unable to detect earth faults on the star side.
However, negative sequence current will be present on both sides of the transformer
for any fault condition, irrespective of the transformer configuration. Therefore, an
negative phase sequence overcurrent element may be employed to provide time-
delayed back-up protection for any uncleared asymmetrical faults downstream.
• Where rotating machines are protected by fuses, loss of a fuse produces a large
amount of negative sequence current. This is a dangerous condition for the machine
due to the heating effects of negative phase sequence current and hence an upstream
negative phase sequence overcurrent element may be applied to provide back-up
protection for dedicated motor protection relays.
• It may be required to simply alarm for the presence of negative phase sequence
currents on the system. Operators may then investigate the cause of the unbalance.
The negative phase sequence overcurrent element has a current pick up setting ‘I2> Current
Set’, and is time delayed in operation by the adjustable timer ‘I2> Time Delay’. The user
may choose to directionalise operation of the element, for either forward or reverse fault
protection for which a suitable relay characteristic angle may be set. Alternatively, the
element may be set as non-directional.
2.15.1 Setting Guidelines
The relay menu for the negative sequence overcurrent element is shown below:
–E Z
I2F = Z Z + Z Zg 0+ Z Z
1 2 1 0 2 0
Where:
Eg = System Voltage
Z0 = Zero sequence impedance
Z1 = Positive sequence impedance
Z2 = Negative sequence impedance
Therefore:
I2F Z0
=
I1F Z0 + Z2
Application Notes P44x/EN AP/E33
It follows that, for an open circuit in a particular part of the system, I2/I1 can be determined
from the ratio of zero sequence to negative sequence impedance. It must be noted however,
that this ratio may vary depending upon the fault location. It is desirable therefore to apply as
sensitive a setting as possible. In practice, this minimum setting is governed by the levels of
standing negative phase sequence current present on the system. This can be determined
from a system study, or by making use of the relay measurement facilities at the
commissioning stage. If the latter method is adopted, it is important to take the
measurements during maximum system load conditions, to ensure that all single phase
loads are accounted for.
Note that a minimum value of 8% negative phase sequence current is required for
successful relay operation.
Since sensitive settings have been employed, it can be expected that the element will
operate for any unbalance condition occurring on the system (for example, during a single
pole autoreclose cycle). Hence, a long time delay is necessary to ensure co-ordination with
other protective devices. A 60 second time delay setting may be typical.
The following table shows the relay menu for the Broken Conductor protection, including the
available setting ranges and factory defaults:-
Note that the elements are set in terms of residual current, which is three times the
magnitude of zero sequence current (Ires = 3I0). The IDMT time delay characteristics
available for the IN>1 element, and the grading principles used will be as per the phase fault
overcurrent elements.
To maintain protection during periods of VTS detected failure, the relay allows an IN> Time
Delay VTS to be applied to the IN>1 and IN>2 elements. On VTS pickup, both elements are
forced to have non-directional operation, and are subject to their revised definite time delay.
V2
I2
Negative sequence
Polarisation Directional SBEF Fwd
VN Residual zero
Calculation SBEF Rev
sequence Polarisation
IN
IN> Pick-up
IN> Pick-up
CTS Blocking
&
0
P0490ENa
CTS Block
SBEF Start
SBEF
Overcurrent
SBEF
IDMT/DT
Trip SBEF Trip
SBEF Timer Block
P0484ENa
CTS Block
SBEF
Overcurrent SBEF Start
Slow VTS
Block Directional
Check
Vx > Vs
Ix > Is
IDMT/DT
SBEF Trip
SBEF Timer Block
P0533ENa
V2
Negative
I2 Polarisation Directionnal DEF Fwd
VN Residual
Calculation DEF Rev
Polarisation
IN
Negative
V2 Polarisation
V> DEF V>
Residual
VN Polarisation
INRev>
IN IN>
INRev = 0.6*INFwd
INFwd>
P0545ENa
FWD FWD
R
-14˚
REV REV
P0491ENa
DEF Fwd
IN Fwd>
DEF V>
0
Any Pole Dead
150 ms
T
& DEF Trip
IN Rev>
0
t_delay
UNB CR DEF
P0546ENa
DEF Fwd
IN Fwd>
DEF V>
t_delay
UNB CR DEF
P0547ENa
P3070ENa
DEF Fwd
IN Fwd>
Tp
DEF V> 0
Reversal Guard
IN Rev>
T
& & DEF Trip
0
0 t_delay
Any Pole Dead
150 ms
UNB CR DEF
DEF Rev
& DEF CS
IN Rev>
DEF V>
P0548ENa
DEF Fwd
IN Fwd>
DEF V>
Reversal Guard 0
IN Rev>
T
& Tp
0
DEF Rev
IN Rev>
& DEF CS
DEF V>
P0549ENa
P0550ENa
IN>1 t t IN>1
0 0
Trip Trip
IN>2 t
0 >1 >1 0
t IN>2
P0551ENa
• Faults occurring on the power system result in a reduction in voltage of the phases
involved in the fault. The proportion by which the voltage decreases is directly
dependent upon the type of fault, method of system earthing and its location with
respect to the relaying point. Consequently, co-ordination with other voltage and
current-based protection devices is essential in order to achieve correct discrimination.
This function will be blocked with VTS logic or could be disabled if CB open.
Both the under and overvoltage protection functions can be found in the relay menu “Volt
Protection”. The following table shows the undervoltage section of this menu along with the
available setting ranges and factory defaults.
As can be seen from the menu, the undervoltage protection included within the P441, P442
and P444 relays consists of two independent stages. These are configurable as either
phase to phase or phase to neutral measuring within the V< Measur’t Mode cell.
Stage 1 may be selected as either IDMT, DT or disabled, within the V<1 Function cell.
Stage 2 is DT only and is enabled/disabled in the V<2 Status cell.
Two stages are included to provide both alarm and trip stages, where required.
Alternatively, different time settings may be required depending upon the severity of the
voltage dip.
The IDMT characteristic available on the first stage is defined by the following formula:
K
t=
1–M
Where:
K = Time Multiplier Setting (TMS)
T = Operating Time in Seconds
M = Measured Voltage / relay Setting Voltage (V<)
Application Notes P44x/EN AP/E33
• During earth fault conditions on a power system there may be an increase in the
healthy phase voltages. Ideally, the system should be designed to withstand such
overvoltages for a defined period of time.
As previously stated, both the over and undervoltage protection functions can be found in the
relay menu “Volt Protection”. The following table shows the overvoltage section of this menu
along with the available setting ranges and factory defaults.
As can be seen, the setting cells for the overvoltage protection are identical to those
previously described for the undervoltage protection. The IDMT characteristic available on
the first stage is defined by the following formula:
t = K / (M - 1)
Where:
K = Time Multiplier Setting
T = Operating Time in Seconds
M = Measured Voltage / relay Setting Voltage (V>)
P44x/EN AP/E33 Application Notes
• Use of the IDMT characteristic gives the option of a longer time delay if the
overvoltage condition is only slight but results in a fast trip for a severe overvoltage. As
the voltage settings for both of the stages are independent, the second stage could
then be set lower than the first to provide a time delayed alarm stage if required.
• Alternatively, if preferred, both stages could be set to definite time and configured to
provide the required alarm and trip stages.
Enable tBF1
CBF1_Status
& 0
tBF1 Trip 3Ph
Pulsed output latched in UI
>1
tBF1
Breaker
Any Internal Trip A
0
& 0
>1 Fail
1
Alarm
2
3 4 tBF2 - tBF1
S
Ia<
0
Q
tBF1 & 0
tBF2 Trip 3Ph
&
1
R
2 0
4
>1
3
0
1
2 S CBF2_Status Enable
Q
>1
3 4
Any Internal Trip A
& 0 R
Non Current Prot Trip 1
2
3 4
CBA_A
Setting:
Non I Trip
Reset:
0) I< Only
1) /Trip & I<
2) CB & I<
3) Disable
4) /Trip or I<
External Trip A 1
2
S
3 4 Q
R
Ia< 1
0
>1
&
2
3 4
Setting:
Ext. Trip
>1 Reset:
0) I< Only
1) /Trip & I<
2) CB & I<
CBA_A
& 3) Disable
4) /Trip or I<
Ib<
PHASE B
Non Current Prot Trip Same logic as A
CBA_B
phase
WI Trip A
External Trip B
WI Trip B
WI Trip C
V<2 Trip
Any Internal Trip C
V>1 Trip
Ic< PHASE C
V>2 Trip
Non Current Prot Trip Same logic as A
phase
CBA_C
• Simple CBF, where only ‘CB Fail 1 Timer’ is enabled. For any protection trip, the ‘CB
Fail 1 Timer’ is started, and normally reset when the circuit breaker opens to isolate
the fault. If breaker opening is not detected, ‘CB Fail 1 Timer’ times out and closes an
output contact assigned to breaker fail (using the programmable scheme logic). This
contact is used to backtrip upstream switchgear, generally tripping all infeeds
connected to the same busbar section.
• A re-tripping scheme, plus delayed backtripping. Here, ‘CB Fail 1 Timer’ is used to
route a trip to a second trip circuit of the same circuit breaker. This requires
duplicated circuit breaker trip coils, and is known as re-tripping. Should re-tripping fail
to open the circuit breaker, a backtrip may be issued following an additional time
delay. The backtrip uses ‘CB Fail 2 Timer’, which is also started at the instant of the
initial protection element trip.
P44x/EN AP/E33 Application Notes
CBF elements ‘CB Fail 1 Timer’ and ‘CB Fail 2 Timer’ can be configured to operate for trips
triggered by protection elements within the relay or via an external protection trip. The latter
is achieved by allocating one of the relay opto-isolated inputs to ‘External Trip’ using the
programmable scheme logic.
2.21.2 Reset Mechanisms for Breaker Fail Timers
It is common practice to use low set undercurrent elements in protection relays to indicate
that circuit breaker poles have interrupted the fault or load current, as required. This covers
the following situations:
• Where circuit breaker auxiliary contacts are defective, or cannot be relied upon to
definitely indicate that the breaker has tripped.
• Where a circuit breaker has started to open but has become jammed. This may result
in continued arcing at the primary contacts, with an additional arcing resistance in the
fault current path. Should this resistance severely limit fault current, the initiating
protection element may reset. Thus, reset of the element may not give a reliable
indication that the circuit breaker has opened fully.
For any protection function requiring current to operate, the relay uses operation of
undercurrent elements (I<) to detect that the necessary circuit breaker poles have tripped
and reset the CB fail timers. However, the undercurrent elements may not be reliable
methods of resetting circuit breaker fail in all applications. For example:
+ + +
I< T
T
- - -
- - -
P0553ENa
2.21.2.1 Inputs
2.21.2.2 Outputs
Resetting of the CBF is possible from a breaker open indication (from the relay’s pole dead
logic) or from a protection reset. In these cases resetting is only allowed provided the
undercurrent elements have also reset. The resetting options are summarised in the
following table.
Application Notes P44x/EN AP/E33
The ‘CBF Blocks I>‘ and ‘CBF Blocks IN>‘ settings are used to remove starts issued from the
overcurrent and earth elements respectively following a breaker fail time out. The start is
removed when the cell is set to Enabled.
P44x/EN AP/E33 Application Notes
CB Fail Reset Mechanism tBF time delay Typical delay for 2½ cycle
circuit breaker
Initiating element reset CB interrupting time + element 50 + 50 + 10 + 50
reset time (max.) + error in tBF = 160 ms
timer + safety margin
CB open CB auxiliary contacts 50 + 10 + 50
opening/closing time (max.) + = 110 ms
error in tBF timer + safety
margin
Undercurrent elements CB interrupting time + 50 + 25 + 50
undercurrent element operating = 125 ms
time (max.) + safety margin
Note that all CB Fail resetting involves the operation of the undercurrent elements. Where
element reset or CB open resetting is used the undercurrent time setting should still be used
if this proves to be the worst case.
The examples above consider direct tripping of a 2½ cycle circuit breaker. Note that where
auxiliary tripping relays are used, an additional 10-15 ms must be added to allow for trip
relay operation.
2.21.3.2 Breaker Fail Undercurrent Settings
The phase undercurrent settings (I<) must be set less than load current, to ensure that I<
operation indicates that the circuit breaker pole is open. A typical setting for overhead line or
cable circuits is 20% In, with 5% In common for generator circuit breaker CBF.
Application Notes P44x/EN AP/E33
80 Km
100 Km 60 Km
System Data
Green Valley - Blue River transmission line 21 21
System voltage 230kv
System grounding solid
CT ratio 1200/5
VT ratio 230000/115
Line length 100km
Line impedance
Z1 = 0.089 + J0.476 OHM/km
Z0 = 0.426 + J1.576 OHM/km
Faults levels
Green Valley substation busbars maximum 5000MVA, minimum 2000MVA
Blue River substation busbars maximum 3000MVA, minimum 1000MVA P3074ENa
Relay Line Angle settings -90° to 90° in 1° steps. Therefore, select Line Angle = 80° for
convenience.
Therefore set Line Impedance and Line Angle: = 5.81 / 80° Ω secondary.
P44x/EN AP/E33 Application Notes
Z4 = 0.464 / 79.4°
= 3.95 / 79.4°
= 1.15 / 72.9°
1.15 / 72.9°
kZ0 = = 0.79 / –6.5°
3 × 0.484 / 79.4°
Therefore, select:
kZ0 Res. Comp = 0.79 (Set for kZ1, kZ2, kZp, kZ4).
kZ0 Angle = –6.5° (Set for kZ1, kZ2, kZp, kZ4).
3.1.11 Resistive Reach Calculations
All distance elements must avoid the heaviest system loading. Taking the 5A CT secondary
rating as a guide to the maximum load current, the minimum load impedance presented to
the relay would be:
From Table 1 (see §2.4.4), taking a required primary resistive coverage of 14.5Ω for phase
faults, and assuming a typical earth fault coverage of 40Ω, the minimum secondary reaches
become:
Typically, the ∆R and ∆X band settings are both set between 10 - 30% of R3Ph. This gives
a secondary impedance between 0.6 and 1.8Ω. For convenience, 1.0Ω could be set.
The width of the power swing band is calculated as follows:
∆R = 0.032 × ∆f × RLOAD
To ensure that a power swing frequency of 5 Hz is detected, the following is obtained:
∆R = 0.16 × RLOAD
Where:
Case 2:
A Ia Ib B
Zat Zbt
Ic
Zct
C
Va = Ia Zat + Ib Zbt Impedance seen by relay A = Va
Ia
Ib = Ia + Ic Za = Zat + Zbt + Ic Zbt
Ia
Va = Ia Zat + Ia Zbt + Ic Zbt
P3075ENa
(i) A B
Z1A Z1C
= area where no zone 1 overlap exists
C
(ii) A B
Z1A Z1B
C
No infeed
(iii) A B
21
P440
21 21
Feeder 1 Feeder 2
P3077ENa
• Default PSL: To enable the setting group via binary inpputs, the opto input 1 and 2
must be removed from the PSL.
(If assigned in the PSL, instead of Dist DEF Carrier Receive Logic Start, a setting
group change will occur)
Note that each setting group has its own dedicated PSL, which should be configured and
sent to the relay independently)
Application Notes P44x/EN AP/E33
• Or using the relay operator interface / remote communications. Should the user issue
a menu command to change group, the relay will transfer to that settings group, and
then ignore future changes in state of the bit 0 and bit 1 opto-inputs. Thus, the user is
given greater priority than automatic setting group selection.
Binary State of SG Change bit 1 Binary State of SG Change bit 0 Setting Group
Activated
Opto 2 Opto 1
0 0 1
0 1 2
1 0 3
1 1 4
The following table shows the relay menu for the fault locator, including the available setting
ranges and factory defaults:-
FAULT LOCATOR
kZm Mutual Comp 0 0 7 0.01
kZm Angle 0° 0° +360° 1°
Relay Line Angle settings 0° to 360° in 1° steps. Therefore, select Line Angle = 80° for
convenience.
P44x/EN AP/E33 Application Notes
Therefore set Line Impedance and Line Angle: = 5.81 / 80° Ω (secondary).
No residual compensation needs to be set for the fault locator, as the relay automatically
uses the kZ0 factor applicable to the distance zone which tripped.
Should a CT residual input be available for the parallel line, mutual compensation could be
set as follows:
= 0.40 / 0°
Therefore set kZm Mutual Comp = 0.40
kZm Angle = 0°
4.2 Voltage transformer supervision (VTS) – Main VT for minZ measurement
4.2.1 VTS logic description
The voltage transformer supervision (VTS) feature is used to detect failure of the analog ac
voltage inputs to the relay. This may be caused by internal voltage transformer faults,
overloading, or faults on the interconnecting wiring to relays. This usually results in one or
more VT fuses blowing. Following a failure of the ac voltage input there would be a
misrepresentation of the phase voltages on the power system, as measured by the relay,
which may result in maloperation of the distance element.
The VTS logic in the relay is designed to detect the voltage failure (with internal thresholds or
external opto input), and automatically adjust the configuration of protection elements
(Distance element is blocked but may be unblocked on I1,I2 or I0 conditions in case of fault
during VTS conditions) whose stability would otherwise be compromised (Distance, DEF,
Weak infeed, Directionnal phase current& all directional elements used in the internal logic).
A settable time-delayed alarm output is also available (min1sec to Max 20sec).
The condition of this alarm is given by:
INP_F.Failure_Line
VN >F.Failure
I2 >F.Failure
&
≥1
VTS Time
I0 >F.Failure ≥1 delay
S
I >F.Failure Q FFUS_Confirmed
R
∆I>F.Failure Fuse_Failure
Any_pole_dead S
& R
Q
Healthy network
V<F.Failure
≥1
All Pole Dead
P0530ENa
• VTS Timer: A settable alarm from 1 to 20s by step of 1s gives the possibility to signal
by an alarm the Failure. This alarm is instantaneous in case of opto energized by
external INP FFU signal (issued from contact of MCB). During no load, the timer
covers the duration of Dead time1 HSAR cycle (Vo&/IO in case of no load) which
could be detected as VT failure 1 pole.
• INP_FFUS Line :The external information given by the MCB to the opto input is
secure and will block instantaneously the distance function and the functions which
are use directional element.
(Vr AND /I0 AND /l2 Et /I>) OR (FusFus_tri AND /Any_pole_dead AND V< AND /∆Ι )
Vr>_FFUS : The residual voltage is bigger than a fixed threshold := 0,75Vn
I0>_FFUS : The zero sequence current is bigger than a settable threshold :
From 0.01 to 1.00 In by step of 0.01
I2>_FFUS : The negative sequence current is bigger than a settable threshold
identical to the I0 threshold.
I>_FFUS : The direct current is bigger than a fixed threshold equal to 2,5IN.
V<_FFUS : All the voltages are lower than a settable threshold from 0.05 à 1
Un by step of 0.1
∆Ι>_FFUS : The line currents have a variation bigger than a settable value from
0.01 to 0.5 In by step of 0.01 In
FuseFailure_3P : Parameter in MiCOM S1 which allows the FFU tri pole detection
Any pole dead : Cycle in progress.
• The I0 criteria (zero sequence current threshold) gives the possibility to UNBLOCK the
distance protection in case of phase to ground fault (if the fuse failure has not been yet
confirmed).
• The criteria (V< AND /∆Ι) gives the possibility to detect the 3Poles Fuse Failure(No
more phase voltage and no variation of current) (no specific logic about line
energisation).
4.2.3 Fuse Failure Alarm reset
In case of Fuse Failure confirmed, the condition which manages the Reset are given by :
Fusion_Fusible = 0
And
INP_FFUS_Line = 0
And
/All Pole Dead Or Healthy Network
• All Pole Dead: No current AND no voltage OR CB Opened ((52a) if assigned in PSL)
• Healthy Network:
Rated Line voltage AND
No V0 and No I0 AND
No start element AND
No Power Swing
Application Notes P44x/EN AP/E33
There are three main aspects to consider regarding the failure of the VT supply. These are
defined below:
1. Loss of one or two phase voltages
2. Loss of all three phase voltages under load conditions
3. Absence of three phase voltages upon line energisation
4.2.4 Loss of One or Two Phase Voltages
The VTS feature within the relay operates on detection of residual voltage without the
presence of zero and negative phase sequence current, and earth fault current (ΣIph). This
gives operation for the loss of one or two phase voltages. Stability of the VTS function is
assured during system fault conditions, by the presence of I0 and/or I2 current. Also, VTS
operation is blocked (and distance element unblocked) when any phase current exceeds 2.5
x In.
Zero Sequence VTS Element:
The thresholds used by the element are:
• Instantaneous blocking of distance protection elements (if opto used); and others
protection functions using voltage measurement
VTS”.(if selected)
The VTS block is latched after a user settable time delay ‘VTS Time Delay’. Once the signal
has latched then two methods of resetting are available. (See Reset logic description in
section 4.2.3).
If not blocked the time delay associated can be modified as well (Time VTS):
Application Notes P44x/EN AP/E33
MCB/VTS Line
The DDB:MCB/VTS Line if linked to an opto in the PSL and when energized, informs the
P44X about an internal maloperation from the VT used for the impedance measurement
reference. (Line in this case means Main VT ref measurement / even if the main VT is on the
bus side and the Synchro VT is on the line side).
MCB/VTS Bus
The DDB:MCB/VTS Bus if linked to an opto in the PSL and when energized, informs the
P44X about an internal maloperation from the VT used for synchrocheck control (See
CheckSync logic in section 4.4).
4.2.8.2 Outputs
VTS Fast
Set high for internal FFAilure detection made with internal logic.
Ir>
Temporisation
& 0<->10sec
Vr<
P0554ENa
The residual voltage setting, CTS VN< Inhibit and the residual current setting, CTS IN> set,
should be set to avoid unwanted operation during healthy system conditions. For example
CTS VN< Inhibit should be set to 120% of the maximum steady state residual voltage. The
CTS IN> set will typically be set below minimum load current. The time-delayed alarm,
CTS Time Delay, is generally set to 5 seconds.
Where the magnitude of residual voltage during an earth fault is unpredictable, the element
be disabled to prevent a protection elements being blocked during fault conditions.
4.3.2.1 Inputs/outputs in CTS logic:
CT Fail Alarm
The DDB cell indicates a CT Fail detected after timer is issued
4.4 Check synchronisation
The check synchronism option is used to qualify reclosure of the circuit breaker so that it can
only occur when the network conditions on the busbar and line side of the open circuit
breaker are acceptable. If a circuit breaker were closed when the two system voltages were
out of synchronism with one another, i.e. a difference in voltage magnitudes or phase angles
existed, the system would be subjected to an unacceptable ‘shock’, resulting in loss of
stability and possible damage to connected machines.
Check synchronising therefore involves monitoring the voltage on both sides of a circuit
breaker and, if both sides are ‘live’, the relative synchronism between the two supplies. Such
checking may be required to be applied for both automatic and manual reclosing of the
circuit breaker and the system conditions which are acceptable may be different in each
case. For this reason, separate check synchronism settings are included within the relay for
both manual and automatic reclosure of the circuit breaker. With manual closure, the CB
close signal is applied into the logic as a pulse to ensure that an operator cannot simply keep
the close signal applied and wait for the system to come into synchronism. This is often
referred to as guard logic and requires the close signal to be released and then re-applied if
the closure is unsuccessful.
Application Notes P44x/EN AP/E33
The check synchronising element provides two ‘output’ signals which feed into the manual
CB control and the auto reclose logic respectively. These signals allow reclosure provided
that the relevant check-synch criteria are fulfilled.
KEY: “Diff” denotes the differential between Line VT and Busbar VT measurements.
− At least one condition of c/s scheme must be selected in the 3 bits, to activate the c/s
check logic.
− Man CB, check sync condition is tallen in account, only if a logic of STF has been
enabled by S1.
− If SOTF is disabled in S1, a dedicated PSL must be created using Deb B (live L or live
B/Dead L) – live/live could not be managed – in that case.
P44x/EN AP/E33 Application Notes
Note that the combination of the Diff Phase and Bus-Line Delay settings can also be equated
to a differential frequency, as shown below:
(This facility with cells (Dead Line/Dead Bus) is available since version A3.0 model 05)
This setting might also be used to allow manual close with specific test conditions on the CB.
4.4.2 Live Busbar and Dead Line
Where a radial feeder is protected, tripping the circuit breaker will isolate the infeed, and the
feeder will be dead. Provided that there is no local generation which can backfeed to
energise the feeder, reclosure for live busbar / dead line conditions is acceptable. This
setting might also be used to allow re-energisation of a faulted feeder in an interconnected
power system, which had been isolated at both line ends. Live busbar / dead line reclosing
allows energising from one end first, which can then be followed by live line / live busbar
reclosure with voltages in synchronism at the remote end.
4.4.3 Dead Busbar and Live Line
If there was a circuit breaker and busbar at the remote end of the radial feeder mentioned
above, the remote breaker might be reclosed for a dead busbar / live line condition.
Application Notes P44x/EN AP/E33
Enable_SYNC
VTS_Slow
1
INP_Fuse Failure Bus
AR_Force_Sync
INP_AR_Cycle_1P S
Q
INP_AR_Reclaim R
INP_AR_Cycle_Conf
1 CHECK
SYNC
INP_AR_Reclaim_Conf 1
Conditions
0 & verified
Any_Pole_Dead &
t 1
&
All_Pole_Dead 200ms
Dead L/Live B
t
V< Dead Line &
0
Live L/Dead B
t
V> Live L &
0
Live L/Live B
V> Live B t
0
&
V> Live L
Bus Line Delay
Diff voltage
Diff frequency
Diff phase
P0492ENa
X1 X2
b0 i0
b1 i1
sample
T sample
P0493ENa
VLine
VBus
x1 x2
Ta
∆T
y1 y2
VBus
VLine
y2 y3
Ta
∆T
x1 x2
P0494ENa
∆T = Ta + (x1-y2)
A phase shift calculation requests a change of sign from both signals.
All the angles will be between 0° and 180°. For a phase shift of 245°,
(360 –245) = 115° will be displayed
Application Notes P44x/EN AP/E33
MCB/VTS Bus
The DDB:MCB/VTS Bus if assigned to an opto input in PSL and when energized, will inform
the P44X about an internal maloperation from the VT used for synchrocheck ref. (BUS in
that case means Checksync ref measurement / even if the main VT is on the bus side and
the Synchro VT is on the line side)
When this opto picks up it will block the internal logic of Synchrocheck.
MCB/VTS Line
The DDB:MCB/VTS Line if assigned to an opto input in PSL and when energized, will inform
the P44X about an internal maloperation from the VT used for impedance measurement ref.
(Line in that case means Main VT ref measurement / even if the main VT are bus side and
the Synchro VT is line side)
When that opto picks up it will block the internal logic of Synchrocheck.
4.4.5.2 Logic DDB outputs issued by the check sync logic
Check Sync OK
Set high when Check Synchro conditions are verified
[Used with AR close in dedicated PSL – "AND" gate : [(AR Close) & (CheckSync OK)]
V<Dead Line
Set high when the Dead line condition is verified (voltage below the V<Dead Line threshold
value (settable in MiCOM S1) – The measured voltage is always calculated as a single
phase voltage
V>Live Line
Set high when the Live line condition is verified (voltage above the V>Live Line threshold
value (settable in MiCOM S1) - always calculated as a single phase voltage ref
V<Dead Bus
Set high when the Dead Bus condition is verified (voltage below the V<Dead Bus threshold
value (settable in MiCOM S1) - always calculated as a single phase voltage ref
V>Live Bus
Set high when the Live Bus condition is verified (voltage above the V>Live Bus threshold
value (settable in MiCOM S1) - always calculated as a single phase voltage ref
Control No C/S
Set high when the internal Check Sync conditions are not verified
P0537ENa
PSL Output
assigned
AR_Force_Sync
AR_Fail
AReclose AR_Close
AR_Cycle_1P
AR_Cycle_3P
Closing command
& with check sync
1 conditions verified
CB Control CBC_Recl_3P
CBC_No_Check_Sync
P0495ENa
Output_AR_force_Sync
Output_closing order
P0496ENa
Output_Sync
1
Output_AR_force_Sync External closing order
External with internal C. Sync
AR close order &
conditions verified
Output_AR_Close
1
Output_closing order
P0497ENa
• A high speed trip and reclose cycle clears the fault without threatening system
stability.
When considering feeders which are partly overhead line and partly underground cable, any
decision to install auto-reclosing would be influenced by any data known on the frequency of
transient faults. When a significant proportion of the faults are permanent, the advantages of
auto-reclosing are small, particularly since reclosing on to a faulty cable is likely to aggravate
the damage.
At subtransmission and transmission voltages, utilities often employ single pole tripping for
earth faults, leaving circuit breaker poles on the two unfaulted phases closed. High speed
single phase autoreclosure then follows. The advantages and disadvantages of such single
pole trip/reclose cycles are:
• Synchronising power flows on the unfaulted phases, using the line to maintain
synchronism between remote regions of a relatively weakly interconnected system.
• However, the capacitive current induced from the healthy phases can increase the
time taken to de-ionise fault arcs.
P44x/EN AP/E33 Application Notes
Trip_1P or Trip_3P
Dead Time_1P or
Dead Time_3P
Close Pulse
AR_Trip_3ph
Reclaim Time
P0555ENa
Trip_1P or Trip_3P
Dead Time_1P
Dead Time_3P
Close Pulse
AR_Trip_3ph
Reclaim Time
P0556ENa
FIGURE 77 - SUCCESSIVE AR CYCLE – SECOND TRIP ORDER BEFORE RECLAIM TIME IS ISSUED
Application Notes P44x/EN AP/E33
(The reclaim time is reset when the reclaim timer adjusted in MiCOM S1 Timer is issued or if
a new trip order 1P or 3P occurs – see Figure 78)
CHECK SYNC OK
R
Q
End of Dead Time 2 AR_Fail
& S
S
& Q AR_Force_Sync
1 R
End of 1P Dead Time 1
1
& S
Q AR_RECLAIM
R
AR_Enable 0
& t
1 Reclaim Time
Block AR
1
INP_CBHealthy
1 S
Q AR_Close
TRIP_1P
R
1 0
1
t
TRIP_3P
Close pulse Time
P0498ENa
FIGURE 78 - LOGIC FOR RECLAIM TIME /AR CLOSE / AR FAIL AND AR FORCE_SYNC
(AR FAIL is reseted with 3 pole closed)
P44x/EN AP/E33 Application Notes
AR_Enable
Block AR
1
AR lock out
inhibit
CBA_Discrepency
& S & AR_lock out
Q
1
R
0
t
End of 1P Dead Time 1 Reclaim
Time
1
End of 3P Dead Time 1
S
&
Q
TRIP_1P
1 R
TRIP_3P
Reset TRIP 1P
1
Reset TRIP 3P
TPAR enable
AR_Cycle_1P & S
Q
AR_Discrimination R
TRIP_3P
Reset TRIP 3P 1
& S
Q
R
P0499ENa
S
Q >1
AR 1P in Prog
>1 &
AR 3P in Prog
BAR_Block_T2 Enable
&
T2
BAR_Block_T3 Enable
&
T3
BAR_Block_Tzp Enable
&
Tzp
T4
BAR_Block_LOL Enable
&
LOL_Trip_3P
BAR_Block_I> Enable
&
TRIP 3P_I>1
BAR_Block_I>2 Enable
&
TRIP 3P_I>2
BAR_Block_V<1 Enable
&
TRIP 3P_V<1
&
BAR_Block_V<2 Enable
&
>1
TRIP 3P_V<2 >1 Block AR
BAR_Block_V>1 Enable
&
TRIP 3P_V>1
BAR_Block_V>2 Enable
&
TRIP 3P_V>2
BAR_Block_IN>1 Enable
&
SBEF_TRIP 3P_IN>1
BAR_Block_IN>2 Enable
&
SBEF_TRIP 3P_IN>2
BAR_Block_DEF Enable
&
DEF_TripA
DEF_TripB >1
DEF_TripC
BRK_Trip 3P
SOTF_Enable
&
SOTF/TOR trip
PHOC_Trip_3P_I>4
CBF1_Trip_3P
CBF2_Trip_3P
INP_BAR
P0500ENa
− With AR Lock out (Block AR) activated, the AR does not initiate any additional AR
cycle. If AR lock out picks up during a cycle, the AR close is blocked.
− A dedicated PSL can be created, for performing an AR lock out in case of Fuse
Failure confirmed.
P44x/EN AP/E33 Application Notes
AR_Enable
SPAR enable
& & S
1 AR lockout_Shots>
Q
R
TRIP_1P
1
TRIP_3P
&
TPAR enable
Reset TRIP_1P
1
Reset TRIP_3P
P0501ENa
AR_Enable
P0502ENa
Trip1P
Dead time(1P)
AR_BAR
AR_Trip_3ph
CBA_Discrepency
P0503ENa
Trip1P or Trip 3P
Dead time1 or
Dead time 3P
AR_Close
AR_BAR
P0557ENa
FIGURE 84 - TRIP ORDER STILL PRESENT AT THE END OF DEAD TIME WILL FORCE AR LOCK OUT
(AR _BAR)
Application Notes P44x/EN AP/E33
CNF_52b
CNF_52a
&
INP_52a_A &
S
Q
& R
INP_52b_A &
1 CBA_A
&
xor
&
INP_52a_B &
S
Q 1 CBA_ANY
& R
INP_52b_B &
1 CBA_B
&
xor
&
INP_52a_C & &
S
Q
& R
INP_52b_C &
1 CBA_C
&
& t
1 0 CBA_Status_Alarm
xor
CBA_Time_Alarm
CBA_Time_Disc
1 t
INP_DISCREPENCY CBA_Disc
0
P0504ENa
(The first 3P_HSAR cycle can be controlled by the check Sync logic)
Scheme Number of Single Pole HSAR Shots Number of Three Pole DAR Shots
1 1 None
1/3 1 1
1/3/3 1 2
1/3/3/3 1 3
Trip_1P or Trip_3P
1P_Dead Time
AR_Discrimination Timer
3P_Dead Time
AR_Trip_3ph
AR_BAR
P0505ENa
Trip_1P or Trip_3P
1P_Dead Time
AR_Discrimination Timer
3P_Dead Time
AR_Trip_3ph
AR_BAR
P0506ENa
SPAR Enable
The DDB SPAR Enable if assigned to an opto input in the PSL (in default PSL is inverted
and recorded to opto8) and when energized, will enable the 1P AR logic (The priority of that
input is higher than the settings done via MiCOM S1 or by front panel - that means the 1P
AR can be disabled even if activated in MiCOM S1; as the opto input is not energized.
(to be valid opto must be energized >1,2 sec).
SPAR
1 AR SPAR enable
INP_SPAR
P0507ENa
FIGURE 88
TPAR Enable
The DDB TPAR Enable if assigned to an opto input in the PSL (in default PSL is inverted
and recorded to opto8) and when energized, will enable the 3P AR logic (The priority is
higher than the settings done via MiCOM S1 or by front panel - that means the 3P AR can be
disabled even if activated in MiCOM S1; as that opto is not energized.
(to be valid opto must be energized >1,2 sec).
TPAR
1 AR TPAR enable
INP_TPAR
P0508ENa
FIGURE 89
NOTE: After a new PSL loaded in the relay (which includes "TPAR" or
"SPAR" cells); it is necessary to transfer again the settings
configuration (from PC to relay) for adjusting the datas in RAM and
EEPROM (otherwise discrepency could appear in the logic status of
AR enable).
A/R Internal
The DDB A/R Internal if assigned to an opto input in the PSL and when energized, will
enable the internal AR logic. This opto input could be connected to an external condition like
the Wdog of protection Main1 – which activates the internal AR of Main 2 (P44x) in case of
internal failure of the Main1.
AR_Internal
TPAR enable
P0509ENa
A/R 1p in Prog
The DDB A/R 1P in Prog if assigned to an opto input in the PSL and when energized, will
block the internal DEF as an external single pole AR cycle is in progress.
A/R 3p in Prog
The DDB A/R 3P in Prog if assigned to an opto input in the PSL and when energized, will
inform the P44X about the presence of an external 3P cycle.That data could be used in case
of evolving fault
A/R Close
The DDB A/R Close if assigned to an opto input in the PSL and when energized, could be
linked with the internal check sync condition to control the external CB closing command.
A/R Reclaim
The DDB A/R Reclaim if assigned to an opto input in the PSL and when energized, will
inform the protection about an external reclaim time in progress; and will initiate the internal
TOR logic. (That information extension logic, by using a dedicated PSL could be used also
in Z1x.
BAR
Block Autoreclose (via Opto Input or PSL) – see Figure 80.
The DDB: BAR input will block the autoreclose and lockout the AR if in progress. If a single
pole cycle is in progress a three pole trip and lockout will be issued. It can be used when
protection operation without autoreclose is required. A typical example is on a transformer
feeder, where autoreclosing may be initiated from the feeder protection but blocked from the
transformer protection. Similarly, where a circuit breaker low gas pressure or loss of vacuum
alarm occurs during the dead time, autoreclosure, should be blocked – and BAR can be
used to realise that blocking logic.
CB Healthy
(via Opto Input)
The majority of circuit breakers are only capable of providing one trip-close-trip cycle. It is
necessary to re-establish sufficient energy in the circuit breaker before the CB can be
reclosed. The DDB: CB Healthy input is used to ensure that there is sufficient energy
available to close and trip the CB before initiating a CB close command. If on completion of
the dead time, sufficient energy is not detected by the relay within a period given by the AR
Inhibit Wind window, lockout will result and the CB will remain open (AR BAR Picks up –
see Figure 79) If the CB energy becomes healthy during the time window, autoreclosure will
occur. This check can be disabled by not allocating an opto input. In this case, the DDB cell
“CB Healthy” is considered invariant for the logic of the relay. This will mean that the signal
is always high within the relay (when the logic required a high level) and at 0, if low level is
requested. It is an invariant status for the firmware (Same logic is applied for every optional
opto – if not linked in the PSL these cells are managed as invariant data for internal logic).
P44x/EN AP/E33 Application Notes
INhWind
1P Dead Time or
3P Dead Time
INP_CB_Healthly
Close pulse
AR_Trip_3ph
AR_RECLAIM
P0510ENa
Start of INhWind is
INhWind issued
INhWind
1P_Dead Time or
3P_Dead Time
INP_CB_Healthy
AR_Close
AR_Trip_3ph
AR_BAR
P0511ENa
FIGURE 92 - CB_HEALTHY DID NOT PICKS UP WHEN INHWIND IS ISSUED (AR BAR PICKS UP)
The CB healthy logic is used as a negative logic (due to an inverter in the scheme – see
Figure 82 (logic of inhibit window) but the DDB takes into account the CB healthy as a
positive logic [1=opto energised during inhwind (MiCOM S1 setting) =AR close pulse]
Force 3P Trip
The DDB Force 3P Trip if assigned to an opto input in the PSL and when energized, will
force the internal single phase protection to trip three phases. (external order from Main1 to
Main2 (P44x)) – next Trip will be 3P (Figure 92 & Figure 93)
INP_Trp_3P
1 BAN3
AR_Trip_3Ph
AR_internal
P0512ENa
Trip_3P_SBEF_IN>1
Trip_3P_SBEF_IN>2
Trip_3P_I2>
TOR_Trip_3P
LOL_Trip_3P
BRK_Trip_3P
Trip_3P_I>1
Trip_3P_I>2 1
Trip_3P_I>3
Trip_3P_I>4
Trip_3P_V<1
Trip_3P_V<2 1
Trip_3P_V>1
Trip_3P_V>2 1 1 TRIP_Any Pole
PW_trip
R
Q
& S Dwell
1 Timer
BAN3
Trip_timer
PDist_Trip_A
Dwell
Weak_Trip_A 1 Trip_A
1
Timer
DEF_Trip_A
80 ms
User_Trip_A
1 TRIP_Any_A
INP_EXTERNAL_ProtA 1
& &
1 TRIP_3Poles
Trip_timer
PDist_Trip_B
Dwell 1
Weak_Trip_B Trip_B
1
Timer
DEF_Trip_B 80 ms
User_Trip_B
1 TRIP_Any_B
1
INP_EXTERNAL_ProtB
& TRIP_1Pole
xor
xor
Trip_timer
PDist_Trip_C
Dwell 1 Trip_C
Weak_Trip_C 1
Timer
DEF_Trip_C
80 ms
User_Trip_C
1 TRIP_Any_C
1
INP_EXTERNAL_ProtC
P0513ENa
Manual Close CB
(via Opto Input, Local or Remote Control)
Manual closure of the circuit breaker will force the autorecloser in a lockout logic, if selected
in the menu (see SOTF logic Figure 35).
P44x/EN AP/E33 Application Notes
Any fault detected within 500ms of a manual closure will cause an instantaneous three pole
tripping, without autoreclosure (See next Figure 80 BAR logic)
With AR Lock out (AR_BAR) activated, the AR does not initiate any additional AR cycle. If
AR lock out picks up during a cycle, the AR close is blocked.
This prevents excessive circuit breaker operations, which could result in increased circuit
breaker and system damage, when closing onto a fault.
Manual Trip CB
The DDB Force Manual Trip CB if assigned to an opto input in the PSL and when
energized, will inform the protection about an external trip command on the CB by the CB
control function (if activated).
Application Notes P44x/EN AP/E33
SUP_Trip_Loc
& Manual/Remote/Local Trip
1
CBC_Local_Control
&
SUP_Close_Loc
SUP_Trip_Rem
&
CBC_Remote_Control
&
SUP_Close_Rem
INP_CB_Trip_Man
&
TRIP
& S CBC_Trip_Pulse
CBA_3P_C
Q CBC_Trip_3P
1
R
t
Pulsed output latched in UI
0 &
CBC_Failed_To_Trip
CBA_3P
CLOSE
CBA_Status_Alarm
& S
Q CBC_Close_In_Progress
AR_Cycle_1P R
1
INP_AR_Cycle_1P t
0
1
AR_Cycle_3P 1 CBC_Delay_Close
INP_AR_Cycle_3P & S
Q
CBA_3P R
CBA_Disc
TRIP_Any
1
INP_AR_Close
Pulsed output latched in UI
CBA_Any
&
INP_CB_Healthy
CBC_Healthy_Window
t
0 & CBC_UnHeathly
CBC_CS_Window
t
0 & CBC_No_Check_Syn
SYNC
P0514ENa
CB Discrepancy
The DDB CB Discrepancy if assigned to an opto input in the PSL and when energized, will
inform the protection about a pole Discrepancy status. 1 pole opened and two other poles
closed. Must be Set to high logical level before Dead time 1 is issued (see Figure 83) -can
be generated also internally (see Figure 85 and Figure 109 Cbaux logic).
External TripA
External TripB
External TripC
From External Protection Devices (via Opto Inputs)- see General trip logic Figure 94.
Opto inputs are assigned as External Trip A, External Trip B and External Trip C (external
Trip Order issued by main 2 or in order to initiate the internal AR backup protection).
External trip is integrated in the DDB: Any Trip. No Dwell timer is associated as for an
internal trip (see Figure 94: trip logic).
4.5.7 Logical Outputs generated by the Autoreclose logic
The following DDB signals can be masked to a relay contact in the PSL or assigned to a
Monitor Bit in Commissioning Tests, to provide information about the status of the
autoreclose cycle. These are described below, identified by their DDB signal text.
AR Lockout Shot>
Indicates an unsuccessful autoreclose (definitive trip following the last AR shot). The relay
will be driven to lockout and the autoreclose function will be disabled until the lockout
condition has been reset. An alarm, "AR Lockout Shots>" (along with AR Lockout) will be
raised. – (see Figure 79 and Figure 81)
AR Fail
If the check sync conditions are not meet prior to reclose within the time window, an alarm
"AR Fail" will be raised. (see Figure 78)
AR Close
Initiates the reclosing command pulse for the circuit breaker. This output feeds a signal to
the Reclose Time Delay timer, which maintains the assigned reclose contact closed for a
sufficient time period to ensure reliable CB mechanism operation. This DDB signal may also
be useful during relay commissioning to check the operation of the autoreclose cycle.
Where three single pole circuit breakers are used, the AR Close contact will need to
energise the closing circuits for all three breaker poles (or alternatively assign three CB
Close contacts). (See Figure 78)
AR 1P In Prog.
A single pole autoreclose cycle is in progress. This output will remain activated from the
initiating protection trip, until the circuit breaker is closed successfully, or the AR function is
Locked Out, thus indicating that dead time timeout is in progress. This signal may be useful
during relay commissioning to check the operation of the autoreclose cycle.
Application Notes P44x/EN AP/E33
SPAR enable
&
TRIP_1P
AR_Cycle_3P S
& Q AR__1P in prog
CBA_Discrepency
R
BAR t
1
0
S
Q AR_Discrimination
R
1 t
0
Discrimination Time
P0515ENa
AR 3P In Prog.
A three phase autoreclose cycle is in progress. This output will remain activated from the
initiating protection trip, until the circuit breaker is closed successfully, or the AR function is
Locked Out, thus indicating that dead time timeout is in progress. This signal may be useful
during relay commissioning to check the operation of the autoreclose cycle.
HS_AR_3P
1 AR_3P in prog
DAR_3P
P0516ENa
AR_1P in prog
TPAR enable
&
1 S
TRIP_3P Q HSAR_3P
R
&
AR_discrimination t
0
P0517ENa
3Par
&
& S
TRIP_3P
Q DAR_3P
0 < Trip counter < setting R
Block AR t
1
0
Dead Time 2
P0518ENa
AR 1st in Prog.
DDB: AR 1st in Prog. is used to indicate that the autorecloser is timing out its first dead
time, whether a high speed single pole or three pole shot.
HSAR_3P
1 AR_1st_Cycle
AR_1P in prog
P0519ENa
AR 234 in Prog.
DDB: AR 234 in Prog. is used to indicate that the autorecloser is timing out delayed
autoreclose dead times for shots 2, 3 or 4. Where certain protection elements should not
initiate autoreclosure for DAR shots, the protection element operation is combined with AR
234 in Prog. as a logical AND operation in the Programmable Scheme Logic, and then set to
assert the DDB: BAR input, forcing lockout.
DAR_3P 1 AR_234th_Cycle
P0520ENa
AR Trip 3 Ph
This is an internal logic signal used to condition any protection trip command to the circuit
breaker(s). Where single pole tripping is enabled, fixed logic converts single phase trips for
faults on autoreclosure to three pole trips.
AR_1P in prog
1
AR_3P in prog
&
TRIP_1P
Block AR 1
AR_RECLAIM
&
inhibit 1 AR_Trip_3Ph
AR_Internal
&
SPAR enable
P0521ENa
AR Reclaim
Indicates that the reclaim timer following a particular autoreclose shot is timing out. The
DDB: AR Reclaim output would be energised at the same instant as resetting of any Cycle
outputs. AR Reclaim could be used to block low-set instantaneous protection on
autoreclosure, which had not been time-graded with downstream protection. This technique
is commonly used when the downstream devices are fuses, and fuse saving is implemented.
This avoids fuse blows for transient faults. See Figure 78.
Application Notes P44x/EN AP/E33
AR Discrim
Start with the trip order.
When a single pole trip is issued by the relay, a 1 pole AR cycle is initiated. The Dead time1
and Discrimination timer (from version A3.0) are started. If the AR logic detects a single pole
or three poles trip (internal or external) during the discrimination timer, the 1P HSAR cycle is
disabled and replaced by a 3P HSAR cycle, if enable. If no AR 3P is enable in MiCOM S1,
the relay trip 3 poles and AR is blocked. (see Figure 86)
If the AR logic detect a 3 poles trip (internal or external) when the Discrimination Timer is
issued, and during the 1P dead time; the single pole AR cycle is stopped and the relay trip 3
phases and block the AR. (see Figure 87 and Figure 96)
SPAR enable
&
TRIP_1P
AR_3P in prog S
& Q AR_1P in prog
CBA_Discrepency
R
Block AR t
1
0
S
Q AR_Discrimination
R
1 t
0
Discrimination Time
P0522ENa
If an evolving occurs during the discrimination timer, the first single pole high speed
AR cycle (1P HSAR) is stopped and removed by a 3 pole high speed AR cycle (3P HSAR)
P0523ENa
FIGURE 105
To inhibit the discrimination timer logic (fixed logic) ; the value should be equal to the 1P
cycle dead time. (1P Dead Time 1).
AR Enable
Indicates that the autoreclose function is in service. (See Figure 90)
AR SPAR Enable
Single pole AR is enabled. (See Figure 88)
AR TPAR Enable
Three poles AR is enabled. (See Figure 89)
AR Lockout
If protection operates during the reclaim time, following the final reclose attempt, the relay
will be driven to lockout and the autoreclose function will be disabled until the lockout
condition is reset. This will produce an alarm, AR Lockout. Secondly, the DDB: BAR input
will block autoreclose and cause a lockout if autoreclose is in progress. Lockout will also
occur if the CB energy is low and the CB fails to close. Once the autorecloser is locked out,
it will not function until a Reset Lockout or CB Manual Close command is received
(depending on the Reset Lockout method chosen in CB Monitor Setup).
DEC_3P
AR_Cycle_3P
SYNC
AR_Close
AR_Trip_3ph
RECLAIM
AR_Force_Sync
P0558ENa
FIGURE 106 – CHECK SYNC SIGNAL PICK-UP AT THE END OF THE DEAD TIME (AR CYCLE)
DEC_3P
AR_Cycle_3P
SYNC
AR_Close
AR_Trip_3ph
AR_RECLAIM
AR_Fail
AR_Force_Sync
P0559ENa
FIGURE 107 - THE CHECK SYNC SIGNAL IS FORCED AT THE END OF DEAD TIME
(SEE FIGURE 78)
Check Sync;OK
(See Checksync logic description – section 4.4.5.2)
V<Dead Line
(See Checksync logic description – section 4.4.5.2)
V>Live Line
(See Checksync logic description – section 4.4.5.2)
V<Dead Bus
(See Checksync logic description – section 4.4.5.2)
Application Notes P44x/EN AP/E33
V>Live Bus
(See Checksync logic description – section 4.4.5.2)
Control Trip
CB Trip command by internal CB control
Control Close
CB close command by internal CB control
• CB Opening + Reset time (Trip coil energised → Trip mechanism reset): 200ms (b);
• 280ms (e) for a three phase trip. (560ms for a single pole trip).
The minimum relay dead time setting is the greater of:
(a) + (c) = 50 + 80 = 130ms, to allow protection reset;
(a) + (e) - (d) = 50 + 280 - 85 = 245ms, to allow de-ionising (three pole);
= 50 + 560 - 85 = 525ms, to allow de-ionising (single pole).
In practice a few additional cycles would be added to allow for tolerances, so 3P Rcl - Dead
Time 1 could be chosen as ≥ 300ms, and 1P Rcl - Dead Time 1 could be chosen as ≥
600ms. The overall system dead time is found by adding (d) to the chosen settings, and
then subtracting (a). (This gives 335ms and 635ms respectively here).
4.5.13 Reclaim Timer Setting
A number of factors influence the choice of the reclaim timer, such as;
• Fault incidence/Past experience - Small reclaim times may be required where there
is a high incidence of recurrent lightning strikes to prevent unnecessary lockout for
transient faults.
• Spring charging time - For high speed autoreclose the reclaim time may be set
longer than the spring charging time. A minimum reclaim time of >5s may be needed
to allow the CB time to recover after a trip and close before it can perform another trip-
close-trip cycle. This time will depend on the duty (rating) of the CB. For delayed
autoreclose there is no need as the dead time can be extended by an extra CB
healthy check AR Inhibit Wind window time if there is insufficient energy in the CB.
• Switchgear Maintenance - Excessive operation resulting from short reclaim times can
mean shorter maintenance intervals.
• The Reclaim Time setting is always set greater than the tZ2 distance zone delay.
P44x/EN AP/E33 Application Notes
• CB is in isolated position
Should both sets of contacts be closed, only one of the following two conditions would apply:
Sol3: Two optos used for 52a & 52b (3 poles breaker)
Where ‘None’ is selected no CB status will be available. This will directly affect any function
within the relay that requires this signal, for example CB control, auto-reclose, etc. Where
only 52a is used on its own then the relay will assume a 52b signal from the absence of the
52a signal. Circuit breaker status information will be available in this case but no discrepancy
alarm will be available. The above is also true where only a 52b is used. If both 52a and 52b
are used then status information will be available and in addition a discrepancy alarm will be
possible, according to the following table. 52a and 52b inputs are assigned to relay opto-
isolated inputs via the PSL.
Where single pole tripping is used (available on P442 and P444) then an open breaker
condition will only be given if all three phases indicate and open condition. Similarly for a
closed breaker condition indication that all three phases are closed must be given. For single
pole tripping applications 52a-A, 52a-B and 52a-C and/or 52b-A, 52b-B and 52b-C inputs
should be used.
With 52a&52b both present, the relay memorizes the last valid status of the 2 inputs
(52a=/52b). If no valid status is present (52a=52b) when the Alarm timer is issued
(value=150 msec), CBA_Status Alarm is activated. See Figure 109.
Application Notes P44x/EN AP/E33
CNF_52b
CNF_52a
&
INP_52a_A &
S
Q
& R
INP_52b_A &
1 CBA_A
&
xor
&
INP_52a_B &
S
Q 1 CBA_ANY
& R
INP_52b_B &
1 CBA_B
&
xor
&
INP_52a_C & &
S
Q
& R
INP_52b_C &
1 CBA_C
&
CBA_Time_Alarm
& t
1 CBA_Status_Alarm
0
xor
150 ms
CBA_Time_Disc
1 t
INP_DISC CBA_Discrepancy
0
150 ms P0524ENa
INP_52a_A
INP_52a_A
CBA_A
CBA_STATUS_ALARM
P0525ENa
FIGURE 110 - NON COMPLEMENTARY OF 52a/52b NOT LONG ENOUGH FOR GETTING THE ALARM
P44x/EN AP/E33 Application Notes
INP_52a_A
INP_52b_A
CBA_A
CBA_STATUS_ALARM
P0526ENa
FIGURE 111 - COMPLEMENTARY OF 52a/52b IS LONG ENOUGH FOR GETTING THE ALARM
INP_52a_A
CBA_A
CBA_STATUS_ALARM
P0527ENa
INP_52b_A
CBA_A
CBA_STATUS_ALARM
P0528ENa
External TripA
External TripB
External TripC
From External Protection Devices (via Opto Inputs)- see General trip logic Figure 94.
If these optos inputs are assigned as External Trip A, External Trip B and External Trip C
– their change will update the CB Operation counter.
(External trip is integrated in the DDB: Any Trip.No Dwell timer is associated as for an
internal trip. (see Figure 94: trip logic)
CB aux A(52a)
CB aux B(52a)
CB aux C(52a)
CB aux A(52b)
CB aux B(52b)
CB aux C(52b)
The DDB CB Aux if assigned to an opto input in the PSL and when energized, will be used
for Any pole dead & All pole dead internal logic & Discrepency logic
CB Discrepancy
Used for internal CBA_Disc issued by external (opto) or internal detection (CB Aux)
Application Notes P44x/EN AP/E33
4.6.2.2 Outputs
CB Status Alarm
Picks up when CB Discrepancy status is detected after CBA timer issued externally by opto
or internally by CB Aux
CB aux A
CB aux B
CB aux C
Pole A+B+C detected Dead pole by internal logic or CB status
The above counters may be reset to zero, for example, following a maintenance inspection
and overhaul.
The following table, detailing the options available for the CB condition monitoring, is taken
from the relay menu. It includes the setup of the current broken facility and those features
which can be set to raise an alarm or CB lockout.
The circuit breaker condition monitoring counters will be updated every time the relay issues
a trip command.One counter is incremented by phase,.the highest counter value is
compared to two thresholds values settable (value n):
Application Notes P44x/EN AP/E33
Note that when in Commissioning test mode the CB condition monitoring counters will not be
updated.
4.7.2 Setting guidelines
For OCB’s, the dielectric withstand of the oil generally decreases as a function of Σ I2t. This
is where ‘I’ is the fault current broken, and ‘t’ is the arcing time within the interrupter tank (not
the interrupting time). As the arcing time cannot be determined accurately, the relay would
normally be set to monitor the sum of the broken current squared, by setting ‘Broken I^’ = 2.
For other types of circuit breaker, especially those operating on higher voltage systems,
practical evidence suggests that the value of ‘Broken I^’ = 2 may be inappropriate. In such
applications ‘Broken I^’ may be set lower, typically 1.4 or 1.5. An alarm in this instance may
be indicative of the need for gas/vacuum interrupter HV pressure testing, for example.
The setting range for ‘Broken I^’ is variable between 1.0 and 2.0 in 0.1 steps. It is
imperative that any maintenance programme must be fully compliant with the switchgear
manufacturer’s instructions.
4.7.3 Setting the Number of Operations Thresholds
Every operation of a circuit breaker results in some degree of wear for its components.
Thus, routine maintenance, such as oiling of mechanisms, may be based upon the number
of operations. Suitable setting of the maintenance threshold will allow an alarm to be raised,
indicating when preventative maintenance is due. Should maintenance not be carried out,
the relay can be set to lockout the autoreclose function on reaching a second operations
threshold. This prevents further reclosure when the circuit breaker has not been maintained
to the standard demanded by the switchgear manufacturer’s maintenance instructions.
P44x/EN AP/E33 Application Notes
Certain circuit breakers, such as oil circuit breakers (OCB’s) can only perform a certain
number of fault interruptions before requiring maintenance attention. This is because each
fault interruption causes carbonising of the oil, degrading its dielectric properties. The
maintenance alarm threshold (N° CB Ops Maint) may be set to indicate the requirement for
oil sampling for dielectric testing, or for more comprehensive maintenance. Again, the
lockout threshold (N° CB Ops Lock) may be set to disable autoreclosure when repeated
further fault interruptions could not be guaranteed. This minimises the risk of oil fires or
explosion.
4.7.4 Setting the Operating Time Thresholds
Slow CB operation is also indicative of the need for mechanism maintenance. Therefore,
alarm and lockout thresholds (CB Time Maint / CB Time Lockout) are provided and are
settable in the range of 5 to 500ms. This time is set in relation to the specified interrupting
time of the circuit breaker.
4.7.5 Setting the Excessive Fault Frequency Thresholds
A circuit breaker may be rated to break fault current a set number of times before
maintenance is required. However, successive circuit breaker operations in a short period of
time may result in the need for increased maintenance. For this reason it is possible to set a
frequent operations counter on the relay which allows the number of operations (Fault Freq
Count) over a set time period (Fault Freq Time) to be monitored. A separate alarm and
lockout threshold can be set.
4.7.6 Inputs/Outputs for CB Monitoring logic
4.7.6.1 Inputs
I^Maint Alarm
An alarm maintenance is issued when the maximum broken current (1st level) calculated by
the CB monitoring function is reached
CB Ops Maint
An alarm is issued when the maximum of CB operations is reached [initiated by internal (any
protection function) or external trip (via opto)] (1st level:CB Ops Maint)
CB Ops Lockout
An alarm is issued when the maximum of CB operations is reached [initiated by internal or
external trip] (2nd level:CB Ops Lock)
CB Op Time Maint
An alarm is issued when the operating tripping time on any phase pass over the CB Time
Maint adjusted in MiCOM S1 (slowest pole detection calculated by I< from CB Fail logic)
CB Op Time Lock
An alarm is issued when the operating tripping time on any phase pass over the CB Time
Lockout adjusted in MiCOM S1 (slowest pole detection calculated by I< from CB Fail logic)
Application Notes P44x/EN AP/E33
FF Pre Lockout
An alarm is issued at (n-1) value in the counters of Main lock out or Fault frequency
FF Lock
An alarm is issued at (n) value in the counters of Main lock out or Fault frequency
Lockout Alarm
An alarm is issued with: CBC Unhealthy or CBC No check sync or CBC Fail to close or CBC
fail to trip or FF Lock or CB Op Time Lock or CB Ops Lock
4.8 Circuit Breaker Control
The relay includes the following options for control of a single circuit breaker:
Protection + ve
trip
Remote
control
trip Trip
0
Remote close
control
close
Local
Remote
Trip Close
ve
P3078ENa
SUP_Trip_Loc
&
1
CBC_Local_Control
&
SUP_Close_Loc
SUP_Trip_Rem
&
CBC_Remote_Control
&
SUP_Close_Rem
INP_CB_Trip_Man
&
CBC_Input_Control
1
&
INP_CB_Man
& S CBC_Trip_Pulse
CBA_3P_C
Q CBC_Trip_3P
1
R
t
Pulsed output latched in UI
0 &
CBC_Failed_To_Trip
CBA_3P
CBA_Status_Alarm
& S
Q CBC_Close_In_Progress
AR_Cycle_1P R
1
INP_AR_Cycle_1P t
0
1
AR_Cycle_3P 1 CBC_Delay_Close
INP_AR_Cycle_3P & S
Q
CBA_3P R
CBA_Disc
TRIP_Any
1
INP_AR_Close
Pulsed output latched in UI
CBA_Any
&
INP_CB_Healthy
CBC_Healthy_Window
t
0 & CBC_UnHeathly
CBC_CS_Window
t
0 & CBC_No_Check_Syn
SYNC
P0529ENa
The length of the trip or close control pulse can be set via the ‘ManualTrip Pulse Time’ and
‘Close Pulse Time’ settings respectively. These should be set long enough to ensure the
breaker has completed its open or close cycle before the pulse has elapsed.
NOTE : The manual close commands for each user interface are found in the
System Data column of the menu.
If an attempt to close the breaker is being made, and a protection trip signal is generated,
the protection trip command overrides the close command.
Where the check synchronism function is set, this can be enabled to supervise manual
circuit breaker close commands. A circuit breaker close output will only be issued if the
check synchronism criteria are satisfied. A user settable time delay is included (‘C/S
Window’) for manual closure with check synchronising. If the checksynch criteria are not
satisfied in this time period following a close command the relay will lockout and alarm.
In addition to a synchronism check before manual reclosure there is also a CB Healthy
check if required. This facility accepts an input to one of the relays opto-isolators to indicate
that the breaker is capable of closing (circuit breaker energy for example). A user settable
time delay is included (‘Healthy Window’) for manual closure with this check. If the CB does
not indicate a healthy condition in this time period following a close command then the relay
will lockout and alarm.
Where auto-reclose is used it may be desirable to block its operation when performing a
manual close. In general, the majority of faults following a manual closure will be permanent
faults and it will be undesirable to auto-reclose. The "man close" input without CB Control
selected OR the "CBClose in progress" with CB control enabled: will initiate the SOTF logic
for which auto-reclose will be disabled following a manual closure of the breaker during
500msec (see SOTF logic in section 2.12.1, Figure 35).
If the CB fails to respond to the control command (indicated by no change in the state of CB
Status inputs) a ‘CB Fail Trip Control’ or ‘CB Fail Close Control’ alarm will be generated
after the relevant trip or close pulses have expired. These alarms can be viewed on the relay
LCD display, remotely via the relay communications, or can be assigned to operate output
contacts for annunciation using the relays programmable scheme logic (PSL).
CBA_3P_C
SUP_Trip OR
INP_CB_Trip_Man
0.1 to 5 Sec
CBC_Trip_3P
CBC_Failed_To_Trip
P0560ENa
FIGURE 116 - STATUS OF CB IS INCORRECT CBA3P C (3POLES ARE CLOSED) STAYS – AN ALARM
IS GENERATED “CB FAIL TO TRIP” (SEE ALSO FIGURE 109 & FIGURE 115)
Application Notes P44x/EN AP/E33
CBA_3P
SUP_Close OR
INP_CB_Man
CBC_Close_In_Progress
0 to 60 Sec
0.1 to 10 Sec
CBC_Recl_3P
CBC_ Fail_To_Close
P0561ENa
FIGURE 117 - STATUS OF CB IS INCORRECT CBA3P (3POLES ARE OPENED) STAYS – AN ALARM IS
GENERATED “CB FAIL TO CLOSE” (SEE ALSO FIGURE 109 & FIGURE 115)
Note that the ‘Healthy Window’ timer and ‘C/S Window’ timer set under this menu section are
applicable to manual circuit breaker operations only. These settings are duplicated in the
Auto-reclose menu for Auto-reclose applications.
The ‘Lockout Reset’ and ‘Reset Lockout by’ setting cells in the menu are applicable to CB
Lockouts associated with manual circuit breaker closure, CB Condition monitoring (Number
of circuit breaker operations, for example) and auto-reclose lockouts.
4.9 Event Recorder
The relay records and time tags up to 250 events and stores them in non-volatile (battery
backed up – installed behind the plastic cover in front panel of the relay)) memory. This
enables the system operator to establish the sequence of events that occurred within the
relay following a particular power system condition, switching sequence etc. When the
available space is exhausted, the oldest event is automatically overwritten by the new one
(First in first out).
The real time clock within the relay provides the time tag to each event, to a resolution of
1ms.
The event records are available for viewing either via the frontplate LCD or remotely, via the
communications ports or via MiCOM S1 with a PC. connected to the relay (event extracted
from relay & loaded in PC):
1. Established the communication [ Device\open connection\address (always1 by serial
front port\Password (AAAA) ]
FIGURE 118
2. Select the extraction of events:
P44x/EN AP/E33 Application Notes
Local viewing on the LCD is achieved in the menu column entitled ‘VIEW RECORDS’. This
column allows viewing of event, fault and maintenance records and is shown below:-
VIEW RECORDS
LCD Reference Description
Select Event Setting range from 0 to 249.
This selects the required event record from the possible 250 that
may be stored. A value of 0 corresponds to the latest event and so
on.
Time & Date Time & Date Stamp for the event given by the internal Real Time
Clock
Event Text Up to 32 Character description of the Event (refer to following
sections)
Event Value Up to 32 Bit Binary Flag or integer representative of the Event
(refer to following sections)
Select Fault Setting range from 0 to 4.
This selects the required fault record from the possible 5 that may
be stored. A value of 0 corresponds to the latest fault and so on.
The following cells show all the fault flags, protection starts,
protection trips, fault location, measurements etc. associated with
the fault, i.e. the complete fault record.
Select Report Setting range from 0 to 4.
This selects the required maintenance report from the possible 5
that may be stored. A value of 0 corresponds to the latest report
and so on.
Report Text Up to 32 Character description of the occurrence (refer to following
sections)
Report Type These cells are numbers representative of the occurrence. They
form a specific error code which should be quoted in any related
correspondence to AREVA T&D.
Report Data
Reset Indication Either Yes or No. This serves to reset the trip LED indications
provided that the relevant protection element has reset.
For extraction from a remote source via communications, refer to Chapter P44x/EN CM,
(Commissioning) where the procedure is fully explained.
Note that a full list of all the event types and the meaning of their values is given in chapter
P44x/EN GC (Configurations Mapping).
Application Notes P44x/EN AP/E33
Types of Event
An event may be a change of state of a control input or output relay, an alarm condition,
setting change etc. The following sections show the various items that constitute an event:-
The Event Value is an 8 or 16 bit word showing the status of the opto inputs, where the least
significant bit (extreme right) corresponds to opto input 1 etc. The same information is
present if the event is extracted and viewed via PC.
4.9.2 Change of state of one or more output relay contacts.
If one or more of the output relay contacts has changed state since the last time that the
protection algorithm ran, then the new status is logged as an event. When this event is
selected to be viewed on the LCD, three applicable cells will become visible as shown below;
The Event Value is a 7, 14 or 21 bit word showing the status of the output contacts, where
the least significant bit (extreme right) corresponds to output contact 1 etc. The same
information is present if the event is extracted and viewed via PC.
P44x/EN AP/E33 Application Notes
The previous table shows the abbreviated description that is given to the various alarm
conditions and also a corresponding value between 0 and 31. This value is appended to
each alarm event in a similar way as for the input and output events previously described. It
is used by the event extraction software, such as MiCOM S1, to identify the alarm and is
therefore invisible if the event is viewed on the LCD. Either ON or OFF is shown after the
description to signify whether the particular condition has become operated or has reset.
4.9.4 Protection Element Starts and Trips
Any operation of protection elements, (either a start or a trip condition), will be logged as an
event record, consisting of a text string indicating the operated element and an event value.
Again, this value is intended for use by the event extraction software, such as MiCOM S1,
rather than for the user, and is therefore invisible when the event is viewed on the LCD.
4.9.5 General Events
A number of events come under the heading of ‘General Events’ - an example is shown
below:-
FIGURE 120
4.10 Disturbance recorder
The integral disturbance recorder has an area of memory specifically set aside for record
storage. The number of records that may be stored is dependent upon the selected
recording duration but the relays typically have the capability of storing a minimum of 20
records, each of 10.5 second duration.
NOTE: 1. Compressed Disturbance Recorder used for Kbus/Modbus/DNP3
reach that typical size value (10.5 sec duration)
2. Uncompressed Disturbance Recorder used for IEC 60870-5/103
could be limited to 2 or 3 secondes.
Disturbance records continue to be recorded until the available memory is exhausted, at
which time the oldest record(s) are overwritten to make space for the newest one.
The recorder stores actual samples which are taken at a rate of 24 samples per cycle.
Each disturbance record consists of eight analogue data channels and thirty-two digital data
channels. Note that the relevant CT and VT ratios for the analogue channels are also
extracted to enable scaling to primary quantities).
P44x/EN AP/E33 Application Notes
Note
The available analogue and digital signals may differ between relay types and models and
so the individual courier database in Appendix should be referred to when determining
default settings etc.
The pre and post fault recording times are set by a combination of the ‘Duration’ and ‘Trigger
Position’ cells. ‘Duration’ sets the overall recording time and the ‘Trigger Position’ sets the
trigger point as a percentage of the duration. For example, the default settings show that the
overall recording time is set to 1.5s with the trigger point being at 33.3% of this, giving 0.5s
pre-fault and 1s post fault recording times.
If a further trigger occurs whilst a recording is taking place, the recorder will ignore the trigger
if the ‘Trigger Mode’ has been set to ‘Single’. However, if this has been set to ‘Extended’, the
post trigger timer will be reset to zero, thereby extending the recording time.
As can be seen from the menu, each of the analogue channels is selectable from the
available analogue inputs to the relay. The digital channels may be mapped to any of the
opto isolated inputs or output contacts, in addition to a number of internal relay digital
signals, such as protection starts, LED’s etc. The complete list of these signals may be found
by viewing the available settings in the relay menu or via a setting file in MiCOM S1. Any of
the digital channels may be selected to trigger the disturbance recorder on either a low to
high or a high to low transition, via the ‘Input Trigger’ cell. The default trigger settings are that
any dedicated trip output contacts (e.g. relay 3) will trigger the recorder.
Application Notes P44x/EN AP/E33
FIGURE 121
Trigger choices:
(Minimum one trigger condition must be present ; for providing Drec file.)
It is not possible to view the disturbance records locally via the LCD; they must be extracted
using suitable software such as MiCOM S1. This process is fully explained in Chapter 6.
After extraction the Drec file can be displayed by the viewer integrated in MiCOM S1(See
Commissioning test section – chap CT)
PA PB
Z os1 x . Zol (1-x).Zol Z os2
P3100XXa
Po Vo
1 1
0,5 0,5
0 0
PA Fault PB
P3101ENa
Selective fault clearance of the protection for forward faults is provided by the power
measurement combined with a time-delay inversely proportional to the measured power.
The protection does not send any trip commands for reverse faults.
In compliance with sign conventions (the zero-sequence power flows from the fault towards
the sources) and with a mean characteristic angle of the zero-sequence source impedances
of the equal to 75°, the measured power is determined by the following formula:
P3837ENa
3-pole trip is sent out when the residual power threshold “Residual Power" is overshot, after
a time-delay "Basis Time Delay" and a IDMT time-delay adjusted by the “K” time delay
factor.
The basis time-delay is set at a value greater than the 2nd stage time of the distance
protection of the concerned feeder if the 3-pole trip is active, or at a value greater than the
single-phase cycle time if single-pole autorecloser shots are active.
The IDMT time-delay is determined by the following formula:
T(s) = K x (Sref/Sr)
With: K: Adjustable time constant from 0 to 2sec (Time delay factor)
Sref: Reference residual power at:
10 VA for In = 1A
50 VA for In = 5A
Sr: Residual power generated by the fault
The following chart shows the adjustment menu for the zero-sequence residual overcurrent
protection, the adjustment ranges and the default in-factory adjustments.
5.1.2 Settings & DDB cells assigned to zero sequence power (ZSP) function
The ZSP TRIP cell at 1 indicates that the Zero Sequence Power
function has performed a trip command (after the start and when associated timers are
issued)
P44x/EN AP/E33 Application Notes
• The residual voltage is greater than the setting threshold during a delay greater then T
5.2.2 Settings & DDB cells assigned to Capacitive Voltage Transformers Supervision (CVT)
function
• Enables the mapping of opto-isolated inputs, relay output contacts and the
programmable LED’s.
• Fault Recorder start mapping, i.e. which internal signals initiate a fault record.
• Enables customer specific scheme logic to be generated through the use of the PSL
editor inbuilt into the MiCOM S1 support software.
Further information regarding editing and the use of PSL can be found in the MiCOM S1
user manual. The following section details the default settings of the PSL. Note that
changes to these defaults can only be carried out using the PSL editor and not via the relay
front-plate.
6.1 HOW TO USE PSL Editor?
OFF Line method:
− Open first the application free software delivered with the relay : MiCOM S1 (can be
also downloaded from the web)
− Open a blancking scheme or a default scheme with the good model number
(File\New\Default Scheme or Blanck Scheme)
Selection of type of relay & model number is done in that window (Version software is
displayed for compatibility ) – Italian is available with model ?40X?
ON Line method:
− Any group from 1 to 4 can be modified (ref of group must be validated before
resenting the file from PC to relay)
Before creating a dedicated PSL for covering customized application ; please refer to the
DDB description cell by cell (conditions of set & reset) in the table included in the annex A at
the end of that technical guide.
Some additive cells can be present regarding the type of model used by the software
embedded in the relay.
The type of model used by the relay in the settings or PSL is displayed in the bottom of your
screen by that line:
− Memory Capacity still available (decrease with the numbers of cells & logical gates
linked in the dedicated PSL)
(See also the section commissioning for deeper tools explanations)
P44x/EN AP/E33 Application Notes
− Version A : Optos are in 48VDC polarised (can be energised with the internal field
voltage offered by the relay (–J7/J9-J8/J10 in a P441)
− Version B : Optos are universal and opto range can be selected in MiCOM S1 by:
Opto A - 48VDC:
The opto inputs are specified to operate between 30 and 60V to ensure there is enough
current flowing through the opto diode to guarantee operation with component tolerances,
temperature and CTR degradation over time.
Between 13-29V is the uncertainty band.
Below 12V, logical status is guaranteed Off
Opto B – Universal opto inputs:
These margins ensure that ground faults on substation batteries do not create mal-operation
of the opto inputs.
Or “Custom” can be selected in the menu to offer the possibility to adjust a different voltage
pick-up for any optos inputs:
Application Notes P44x/EN AP/E33
Opto
Input P441 Relay P442 Relay P444 Relay
N°
1 Channel Receive (Distance Channel Receive (Distance Channel Receive (Distance
or DEF) or DEF) or DEF)
2 Channel out of Service Channel out of Service Channel out of Service
(Distance or DEF) (Distance or DEF) (Distance or DEF)
3 MCB/VTS Line MCB/VTS Line MCB/VTS Line
(Z measurement-Dist) (Z measurement-Dist) (Z measurement-Dist)
4 Block Block Block
Autoreclose(LockOut) Autoreclose(LockOut) Autoreclose(LockOut)
5 Circuit Breaker Healthy Circuit Breaker Healthy Circuit Breaker Healthy
6 Circuit breaker Manual Circuit breaker Manual Circuit breaker Manual
Close external order Close external order Close external order
7 Reset Lockout Reset Lockout Reset Lockout
8 Disable Autoreclose (1pole Disable Autoreclose (1- Disable Autoreclose (1-
and 3poles) pole and 3poles) pole and 3poles)
9 Not allocated Not allocated
10 Not allocated Not allocated
11 Not allocated Not allocated
12 Not allocated Not allocated
13 Not allocated Not allocated
14 Not allocated Not allocated
15 Not allocated Not allocated
16 Not allocated Not allocated
17 Not allocated
18 Not allocated
19 Not allocated
20 Not allocated
21 Not allocated
22 Not allocated
23 Not allocated
24 Not allocated
Application Notes P44x/EN AP/E33
Relay
Contact P441 Relay P442 Relay P444 Relay
N°
1 TripA+B+C & Z1 TripA+B+C & Z1 TripA+B+C & Z1
2 Any Trip Phase A Any Trip Phase A Any Trip Phase A
3 Any Trip Phase B Any Trip Phase B Any Trip Phase B
4 Any Trip Phase C AnyTrip Phase C Any Trip Phase C
5 Signal send (Dist. or DEF) Signal send (Dist. or DEF) Signal send (Dist. or DEF)
6 Any Protection Start Any Protection Start Any Protection Start
7 Any Trip Any Trip Any Trip
8 General Alarm General Alarm General Alarm
9 DEF A+B+C Trip DEF A+B+C Trip DEF A+B+C Trip
+ IN>1Trip + IN>1Trip + IN>1Trip
+ IN>2Trip + IN>2Trip + IN>2Trip
10 Dist. Trip &Any Dist. Trip &Any Dist. Trip &Any
Zone&DistUnb CR Zone&DistUnb CR Zone&DistUnb CR
11 Autoreclose lockout Autoreclose lockout Autoreclose lockout
12 Autoreclose 1P+3P cycle Autoreclose 1P+3P cycle Autoreclose 1P+3P cycle
in progress in progress in progress
13 A/R Close A/R Close A/R Close
14 Power Swing Detected Power Swing Detected Power Swing Detected
15 Not allocated Not allocated
16 Not allocated Not allocated
17 Not allocated Not allocated
18 Not allocated Not allocated
19 Not allocated Not allocated
20 Not allocated Not allocated
21 Not allocated Not allocated
22 Not allocated Not allocated
23 Not allocated
24 Not allocated
25 Not allocated
26 Not allocated
27 Not allocated
28 Not allocated
29 Not allocated
30 Not allocated
31 Not allocated
32 Not allocated
Note that when 3 pole tripping is selected in the relay menu, all trip contacts: Trip A, Trip B,
Trip C, and Any Trip close simultaneously.
P44x/EN AP/E33 Application Notes
Relay
Contact P441 Relay P442 Relay P444 Relay
N°
1 Straight Straight Straight
2 Straight Straight Straight
3 Straight Straight Straight
4 Straight Straight Straight
5 Straight Straight Straight
6 Straight Straight Straight
7 Straight Straight Straight
8 Straight Straight Straight
9 Straight Straight Straight
10 Straight Straight Straight
11 Straight Straight Straight
12 Straight Straight Straight
13 Straight Straight Straight
14 Straight Straight Straight
15 Not allocated Not allocated
16 Not allocated Not allocated
17 Not allocated Not allocated
18 Not allocated Not allocated
19 Not allocated Not allocated
20 Not allocated Not allocated
21 Not allocated Not allocated
22 Not allocated Not allocated
23 Not allocated
24 Not allocated
25 Not allocated
26 Not allocated
27 Not allocated
28 Not allocated
29 Not allocated
30 Not allocated
31 Not allocated
32 Not allocated
NOTE: Others conditions of relays logic are available in the relays design by
PSL.
Pulse Timer
Pick UP/Drop Off Timer
Dwell Timer
Pick Up Timer
Drop Off Timer
Latching
Straight (Transparent)
Application Notes P44x/EN AP/E33
Input
Output Pulse setting
Pulse Timer Input
Output Pulse setting
Input
Input
Input
Timer setting
Output
Pick Up Timer Input
Timer setting
Output
Input
P0562ENa
FIGURE 126
If the fault recorder trigger is not assigned in the PSL, no Fault recorder can be initiated and
displayed in the list by the LCD front panel.
Application Notes P44x/EN AP/E33
BLANK PAGE
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
Changement of Group by Optos
∗
No cell assigned In Opto1 opto energised (>1 sec)( ) – Must be not assigned in the PSL opto power off
At1 :LSB Bit (see table in section 3.3.1 in chap AP) At 0 : (see table in section 3.3.1 in chap AP)
No cell assigned In Opto2 opto energised (>1 sec)(*) – Must be not assigned in the PSL opto power off
At1 :MSB Bit (see table in section 3.3.1 in chap AP) At 0 : (see table in section 3.3.1 in chap AP)
SG-opto Invalid Out Setting Group selected via opto are invalid Set 0 : No alarm is present
Example :1group is requested by the optos status but that group is not
present in the settings
(Gr3 requested but only Gr1&2 are present in MiCOM S1-The settings
restart with GR1 & that cell switch on at 1)
OPTOS INPUTS (48Vcc Version A / Universal Version B-C)
Opto In P441 / P442 / P444 P441 / P442 / P444
Label
Opto energised for a minimum time : 7 ms (48Vdc), 10 ms (universal) to be See Hysteresis description in sect 6.2 chapter P44x/EN AP
1/8
validated by internal logic
See Hysteresis description in sect 6.2 chapter P44x/EN AP
Opto In P442 / P444 P442 / P444
Label
Opto energised for a minimum time : 7 ms (48Vdc), 10 ms (universal) to be See Hysteresis description in sect 6.2 chapter P44x/EN AP
9/16
validated by internal logic
See Hysteresis description in sect 6.2 chapter P44x/EN AP
Opto In P444 P444
Label
Opto energised for a minimum time : 1,2 sec to be validated by internal See Hysteresis description in sect 6.2 chapter P44x/EN AP
17/24
logic
See Hysteresis description in sect 6.2 chapter P44x/EN AP
Opto In Not Used Not Used
Label
25/32
∗
Minimum time >1 sec for: changement Gr/TPAR/SPAR/AR enable
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
OUTPUT RELAYS
Relay Out P441 / P442 / P444 P441 / P442 / P444
Label
Set1 :For any DDB cell at 1 if linked by PSL & regarding the type of logic Set 0 :For any DDB cell at 0 if linked by PSL & regarding
selected in PSL by MiCOM S1 the type of logic selected in PSL by MiCOM S1
Programmable Relays : All relays are assigned in Type of Logic:
01/14
The default PSL (See DDB table description) Pulse timer
Type of Logic: Pick Up/Drop Off Timer
Pulse timer Dwell Timer
Pick Up/Drop Off Timer Pick Up Timer
Dwell Timer Drop Off Timer
Pick Up Timer Latching
Drop Off Timer Straight (used in default PSL)
Latching
Straight (used in default PSL)
Relay Out P442 / P444 P442 / P444
Label
Set1 :For any DDB cell at 1 if linked by PSL & regarding the type of logic Set 0 :For any DDB cell at 0 if linked by PSL & regarding
selected in PSL by MiCOM S1 the type of logic selected in PSL by MiCOM S1
15/21
Programmable Relay – Not assigned in default PSL Type of Logic: (See Description above)
Type of Logic: (See Description above)
Relay Out P444 P444
Label
Set1 :For any DDB cell at 1 if linked by PSL & regarding the type of logic Set 0 :For any DDB cell at 0 if linked by PSL & regarding
selected in PSL by MiCOM S1 the type of logic selected in PSL by MiCOM S1
22/32
Programmable Relay– Not assigned in default PSL Type of Logic: (See Description above)
Type of Logic: (See Description above)
LEDS (Right side – Front panel)
LED 1 Led Set1 : For any DDB cell at 1 if linked by PSL Set 0 : For any DDB cell at 0 if linked by PSL & regarding
Programmable Led : ANY TRIP A in the default PSL the type of logic selected in PSL by MiCOM S1
(Latched or not Latched)
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
LED 2 Led Set1 : For any DDB cell at 1 if linked by PSL Set 0 : For any DDB cell at 0 if linked by PSL & regarding
Programmable Led : ANY TRIP B in the default PSL the type of logic selected in PSL by MiCOM S1
(Latched or not Latched)
LED 3 Led Set1 : For any DDB cell at 1 if linked by PSL Set 0 : For any DDB cell at 0 if linked by PSL & regarding
Programmable Led : ANY TRIP C in the default PSL the type of logic selected in PSL by MiCOM S1
(Latched or not Latched)
LED 4 Led Set1 : For any DDB cell at 1 if linked by PSL Set 0 : For any DDB cell at 0 if linked by PSL & regarding
Programmable Led : General Start in the default PSL the type of logic selected in PSL by MiCOM S1
(Latched or not Latched)
LED 5 Led Set1 : For any DDB cell at 1 if linked by PSL Set 0 : For any DDB cell at 0 if linked by PSL & regarding
Programmable Led : Z1+Aided Trip in the default PSL the type of logic selected in PSL by MiCOM S1
(Latched or not Latched)
LED 6 Led Set1 : For any DDB cell at 1 if linked by PSL Set 0 : For any DDB cell at 0 if linked by PSL & regarding
Programmable Led : Dist FWD in the default PSL the type of logic selected in PSL by MiCOM S1
(Latched or not Latched)
LED 7 Led Set1 : For any DDB cell at 1 if linked by PSL Set 0 : For any DDB cell at 0 if linked by PSL & regarding
Programmable Led : Dist REV in the default PSL the type of logic selected in PSL by MiCOM S1
(Latched or not Latched)
LED 8 Led Set1 : For any DDB cell at 1 if linked by PSL Set 0 : For any DDB cell at 0 if linked by PSL & regarding
Programmable Led : Auto Reclose Enable in the default PSL the type of logic selected in PSL by MiCOM S1
(Latched or not Latched)
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
AUTO RECLOSE (AR) Logic
SPAR Enable In Opto8 opto energised (> 1 sec) if linked by PSL Reset at 0 : opto power off
+Inv At1 :1P AR internal is enabled in the AR logic At 0 : AR 1P internal is disabled
(higher priority than MiCOM S1) (even if selected enable by MiCOM S1)
AR logic becomes 3P only with AR 3P cycle -if TPAR =1
TPAR Enable In Opto8 opto energised (> 1 sec) if linked by PSL Reset at 0 : opto power off
+Inv At1 :3P AR internal is enabled in the AR logic At 0 : AR 3P internal is disabled
(higher priority than MiCOM S1) (even if selected enable by MiCOM S1)
logic becomes :no more 3P cycle available (1P could exist
if SPAR at 1)
A/R Internal In opto energised (> 1 sec) if linked by PSL Reset at 0 : opto power off
At1 :AR internal becomes present At 0 :no Ban Tri logic available.
[AR becomes enable by external contact AR is disable
example :Wdog of Main1 when pick up activates the internal AR in
Main2(P44x)]
A/R 1p in Prog In Relay opto energised if linked by PSL Reset at 0 : opto power off
12 At1 : External 1P AR cycle in progress – requested for blocking the internal
DEF function
A/R 3p in Prog In Relay opto energised if linked by PSL Reset at 0 : opto power off
12 External 3P Arcycle in progress - requested for blocking the internal DEF
function – (pb of Pole Operating Time)
A/R Close In Relay opto energised if linked by PSL Reset at 0 : opto power off
13 At1 :External AR gives a CB closing order – for using internal synchro
conditions of P44X
A/R reclaim In opto energised if linked by PSL Reset at 0 : opto power off
At1 :Reclaim time from external AR in progress – requested to initiate
internal TOR logic / Used in Z1X logic (by specific PSL)
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
BAR In Opto opto energised if linked by PSL Reset at 0 : opto power off
4 Set at1 :External condition which blocks the internal AR AR Lock out is reseted
(other internal blocking conditions can be selected in MiCOM
S1 :Autoreclose/Block AR) – see also logic AR lockout figure..
Ext Chk Synch In opto energised if linked by PSL Reset at 0 : opto power off
OK At1 :External check synchro condition satisfied – to be used with internal Conditiond of external synchro are unvailable
AR close by specific PSL – (With AND logic between Arclose&CsyncExt)
CB Healthy In Opto opto energised if linked by PSL Reset at 0 : opto power off
5 At1 :contact from CB when CB is operationnal (gas pressure/mechanical At 0 : AR cycle is stopped (if that cell is assigned in the
state)- Must be at 1 inside the time window (adjusted by MiCOM S1 : PSL). At the end of InhWInd the signal AR BAR picks up.
group1/Autoreclose mode/AR Inhibit Wind) during an AR cycle (signals :AR
close & AR Reclaim pick up when CB healthy is detected during the
InhWind timer)
Force 3P trip In opto energised if linked by PSL Reset at 0 : opto power off
At1 :External command for tripping 3P only (Order issued from Main1 to
Main2) – next trip will be 3P
Man.Close CB In Opto opto energised if linked by PSL Reset at 0 : opto power off
6 At1 :External manual close command – requested to initiate SOTF logic &
to close CB (Arlock out during SOTF logic)
Man.Trip CB In opto energised if linked by PSL Reset at 0 : opto power off
At1 :External manual trip command to provide a CB trip command by CB
control if selected in MiCOM S1
CB In opto energised if linked by PSL Reset at 0 : opto power off
Discrepancy At1 : OR
Contact from external status of CB poles (one pole opened) – that data drop Off Internal Logic
must be at 1 before end of Dead time1 if assigned in the PSL At 0 : Stop the 1P cycle if absent at the end of dead time1.
OR AR is ofrced in AR Lock Out
Internal logic = Any pole &Not All pole Dead
(CB Aux must be connected 52a or 52b)
External TripA In opto energised if linked by PSL Reset at 0 : opto power off
At1 :External trip command A
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
Activate a Trip command phase A (DDB :Any TripA)
(No dwell timer is associated as for an internal trip)
Activate internal AR
Integrated in the Any Trip & Any TripA cell
External TripB In opto energised if linked by PSL Reset at 0 : opto power off
At1 :External trip command B
Activate a Trip command phase B(DDB :Any TripB)
(No dwell timer is associated as for an internal trip)
Activate internal AR
Integrated in the Any Trip & Any TripB cell
External TripC In opto energised if linked by PSL Reset at 0 : opto power off
At1 :External trip command C
Activate a Trip command phase C(DDB :Any TripC)
(No dwell timer is associated as for an internal trip)
Activate internal AR
Integrated in the Any Trip & Any TripC cell
AR Lockout Out AR is blocked by passing over the number of shots selected in Auto At0 : AR Cycles continue if fault still present
Shot> Reclose/trip mode (in MiCOM S1) (not erased by the previous Arcycle)
Set at 1 : Reset at 0 :
(AR Enable) & Reset Trip1P + Reset Trip3P
[(Trip1P&No SPAR)+(Trip3P&NoTPAR)
+(Trip1P+Trip3P)&(Number of shots=MiCOM S1 value)]
AR Fail Out Set at 1 : Absence of check sync condition involve AR failure (For 3P cycle) Reset at 0 : by 3 Poles Closed
A/R close Out Relay 13 Set at 1 :AR internal command :CB Close Reset at 0 with :
Starts as AR Reclaim Close Pulse Time (Setting)
OR
Trip1P or Trip3P
A/R 1p in Prog Out Relay 12 1P AR cycle in progress (could be connected to external Main2 for Blocking Set 0 with :
DEF) End of 1P Dead Time
+AR Lock out (BAR)
+ 3P TRip
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
A/R 3p in Prog Out Relay 12 3P AR cycle in progress (could be connected to external Main2) Set 0 with :
End of 3P Dead time (DAR)
+AR Lock Out (BAR)
+End of Dead time1 (HSAR)
A/R 1st in Prog Out First high speed AR Cycle in progress (could be connected to external Set 0 with :
Main2) End of 3P Dead time (DAR)
+AR Lock Out (BAR)
+End of Dead time1 (HSAR)
A/R 234 in Prog Out Further delayed AR Cyles in progress (could be connected to external Set 0 with :
Main2) End of 3P Dead time (DAR)
+AR Lock Out (BAR)
+End of Dead time1 (HSAR)
A/R Trip 3P Out AR signal which force all trips to be 3P – picks up at the end of the first trip At 0 : AR1P could operate if programmed
(1P or 3P)
- Can be connected to Main2 as an external Ban Tri
Set at 1 : Reset at 0 :
(AR enable MiCOM S1)&(No SPAR) SPAR & AR enable MiCOM S1
+ (InhibitWind at 0)
A/R Reclaim Out Set at 1 :Reclaim timer in progress.(Value adjusted in MiCOM S1) Reset at 0 with :
Picks up at the end of the dead time –in synchronism with AR Close order End of Reclaim time (MiCOM S1)
- Can be connected to Main2 for cycle in progress external information OR
- Initiate the internal TOR logic Reset (Trip1P or Trip3P)
(See Figure 78 section 4.5.3)
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
AR Discrim Out Dicrim status detected (inter or Externaly)-timer in progress Rest 0 :
End of Discrim timer (MiCOM S1)
+Trip 3P (DEC 3P)
+AR Lock Out (BAR)
A/R Enable Out Led 8 Copy of status AR Enable
Set at 1 : Reset at 0: If SPAR and TPAR Optos at 0 (if integrated in
[(optos SPAR) +(optoTPAR)]& (AR enable byMiCOM S1) PSL) + AR Disable in MiCOM S1
A/R SPAR Out Set at 1 :1P AR activated (copy of opto SPAR or MiCOM S1) Reset at 0: if SPARopto=0 or AR Disable in MiCOM S1
Enable
A/R TPAR Out Set at 1 :3P AR activated (copy of opto TPAR or MiCOM S1) Reset at 0: if TPARopto=0 or AR Disable in MiCOM S1
Enable
A/R Lockout Out Relay 11 AR function locked out/No more cycle is initiated by the AR (Pole is kept At0 : AR is activated
opened) – Reset must be done for enabling the AR logic again (AR Reset at 0 =
counters are resetted) [Reset(Trip1P)+Reset(Trip3P)]
Set at 1 = & (End of RC timer)
ARenable & & Reset (BAR )
[(BAR =1 (see internal logic figure.. section..) & Reset (AR BAR n shot>)
+(AR BAR n shot>) AR lockout by number of shots & Reset (No CB Healty)
+(No CB Healthy at the end of InhWind(MiCOM S1)) & Reset (No Discrepancy)
+[No Discrepancy (opto or internal by CBAux if present in PSL) at the end
of 1P Dead time1]
+ (Trip 1P or3P maintained /still present at the end of the1Por3P Dead
time)
+(After discrim timer if Trip3P occures during a 1PAR Cycle) ]
A/R Force Sync Out Force the Synchro condition ok at 1 Reset 0 :
(Could be used during test for getting Arclose whatever are the real With Reset of A/R Reclaim (See DDB description)
conditions of CheckSyn )
LED 8 AR Enable Latched by PSL design
(See DDB Description)
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
CHECK SYNC Logic
Check Out Set at 1 : Check Synchro conditions are satisfied Set at 0 : Conditions of checksyn unsatisfied (thresholds of
Synch .OK Used with AR close in dedicated PSL – AND gate : dead & live definied in MiCOM S1 :system checks)
[(AR Close) or (Manual Close) & (Checksync OK)]
Control No C/S Out Set at 1 : Internal conditions of Csync are not fulfilled Set at 0 :CSYnc conditions available
V<Dead line Out Set at 1 : Condition of Dead line at 1 (voltage below the threshold value Set at 0 : Condition of Dead line at 0 (voltage above the
(settable in MiCOM S1) – Default value is 13V threshold value (settable in MiCOM S1)
V>Live line Out Set at 1: Condition of Live line at 1 (voltage above the threshold value Set at 0 : Condition of Live line at 0 (voltage below the
(settable in MiCOM S1) – Default value is 32V threshold value (settable in MiCOM S1)
V<Dead Bus Out Set at 1: Condition of Dead Bus at 1 (voltage below the threshold value Set at 0 : Condition of Dead Bus at 0 (voltage above the
(settable in MiCOM S1) – Default value is 13V threshold value (settable in MiCOM S1)
V>Live Bus Out Set at 1: Condition of Live Bus at 1 (voltage above the threshold value Set at 0 : Condition of Live Bus at 0 (voltage below the
(settable in MiCOM S1) – Default value is 32V threshold value (settable in MiCOM S1)
MCB/VTS Bus In Set at 1 :Internal fault in VT used for synchro ref Reset at 0 : opto power off
Csync function is blocked
MCB/VTS Line In Set at 1 :Internal fault in VT used for Z measurement ref (Main VT) Reset at 0 : opto power off
Distance &all Directionnal functions are blocked(can unblocked with
different VTS timer- see MiCOM S1 settings)
Ctrl Cls In Prog Out Set at 1 :Manual close in progress – using CB control (Timer manual Set at 0 :End of Timer manual closing
closing delay in progress)
Control Close Out Set at1 :CB Close 3P command by internal CB Control Reset at 0 :
(Control with synchrocheck manual condition could be used in dedicated End of Timer MiCOM S1 (Close pulse timer)
PSL – MiCOM S1Chk scheme ManCB) +Any Trip
See CB Control logic sect 4.8 fig 115 +CBC No Csync
+CBC Unhealthy
See CB Control logic sect 4.8 fig 115
Control Trip Out Set at 1 :CB Trip 3P command by internal CB Control Reset at 0 :
See CB Control logic sect 4.8 fig 115 End of timer MiCOM S1 (Trip pulse timer)
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
SOTF – TOR Logic
Man Close CB In Opto opto energised if linked by PSL Reset at 0 : opto power off
6 At1 :
AND no CB Control is activated in MiCOM S1
External command for closing manualy the CB
Will initiate SOTF logic if SOTF not disable in MiCOM S1(BitD)
AND CB control enable will initiate CB close in progress if All pole dead =
SOTF Enable
AR Reclaim In opto energised if linked by PSL Reset at 0 : opto power off
When at 1 (See AR DDB) start the TOR logic
CB Aux A In opto energised if linked by PSL Reset at 0 : opto power off
(See CB DDB ) used for Any pole dead/All pole dead
CB Aux B In opto energised if linked by PSL Reset at 0 : opto power off
(See CB DDB ) used for Any pole dead/All pole dead
CB Aux C In opto energised if linked by PSL Reset at 0 : opto power off
(See CB DDB ) used for Any pole dead/All pole dead
SOTF Enable Out When SOTF logic is enable Timer 500msec issued after Any pole Dead
Set at 1 : + Reset of one conditions requested for SOTF enable
[Sotf not disable (Bit D in MiCOM S1)] AND
All pole dead & End Timer (110sec/default)
+ Input Man Close
+ (CB control & Close in progress)
TOR Out When SOTF logic is enable Reset 500ms after Any pole dead stops
Enable Set at 1 :
By a Pulse of 500msec initiated by :
AR Reclaim internal+AR reclaim External Input
OR
Any pole opened for more than 200ms
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
TOC Start A Out Set1 :Trip order phase A initiated by levels detectors in SOTF logic (Pickup Set 0 : Reset of Level detectors logic
20ms delayed )
TOC Start B Out Set1 :Trip order phase B initiated by levels detectors in SOTF logic (Pickup Set 0 : Reset of Level detectors logic
20ms delayed )
TOC Start C Out Set1 :Trip order phase C initiated by levels detectors in SOTF logic (Pickup Set 0 : Reset of Level detectors logic
20ms delayed )
AR Reclaim Out When at 1 (See AR DDB) start the TOR logic Set 0 : (See AR DDB)
SOTF/TOR Out Set1 :Trip order initiated by any condition fulfilled in the SOTF/TOR logic Set 0 :When conditions reset
Trip (See logic section 2.12 – fig 37) (See logic section 2.12 – fig 37)
Any Pole Dead Out Set1 :Minimum 1 pole is open Set 0 :All poles are detected not dead
Pole Dead A+Pole DeadB+Pole Dead C
Detection of pole status made by Cbaux or internal thresholds (see dead Detection of pole status made by Cbaux or internal
pole logic in SOTF section 2.12 – fig 35) thresholds
All Pole Dead Out Set1 :All poles are open Set 0 :1pole is detected not dead
Pole DeadA & P.DeadB & P.Dead C
Detection of pole status made by Cbaux or internal thresholds (see dead Detection of pole status made by Cbaux or internal
pole logic in SOTF section 2.12 – fig 35) thresholds
CIRCUIT BREAKER Logic (CB Control / CB Monitoring / CB Fail)
CB Aux A (52a) In opto energised if linked by PSL Reset at 0 : opto power off
At1 :Status input from CB-Pole A is closed Set 0 :Pole A is opened
CB Aux A (52b) In opto energised if linked by PSL Reset at 0 : opto power off
At1 :Status input from CB-Pole A is opened Set 0 :Pole A is closed
CB Aux B (52a) In opto energised if linked by PSL Reset at 0 : opto power off
At1 :Status input from CB-Pole B is closed Set 0 :Pole B is opened
CB Aux B (52b) In opto energised if linked by PSL Reset at 0 : opto power off
At1 :Status input from CB-Pole B is opened Set 0 :Pole B is closed
CB Aux C (52a) In opto energised if linked by PSL Reset at 0 : opto power off
At1 :Status input from CB-Pole C is closed Set 0 :Pole A is opened
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
CB Aux C (52b) In opto energised if linked by PSL Reset at 0 : opto power off
At1 :Status input from CB-Pole C is opened Set 0 :Pole C is closed
CB Healthy In Opto 5 See DDB description of AR Logic (CB control not used) See DDB description of AR Logic
Man Close CB In Opto 6 See DDB Description in SOTF logic (CB control not used) See DDB Description in SOTF logic
Man Trip CB In See DDB description of AR Logic See DDB description of AR Logic
CB Discrepancy In See DDB description of AR Logic See DDB description of AR Logic
Reset Lockout In Opto 7 opto energised if linked by PSL Reset at 0 : opto power off
At1 :Provides a CB monitoring lockout reset (all counters & values are
reset)
Reset All Values In opto energised if linked by PSL Reset at 0 : opto power off
At1 :Provides a CB monitoring reset (all counters & values are reset)
CB Fail Alarm Out Set 1 :For any Breaker failure on any trip for any phase Reset 0 : (selectable in MiCOM S1 : CB fail & I< logic)
Iphase<
+ CB open & Iphase<
+Trip reset & Iphase
+Trip reset OR Iphase<<
I^ Maint Alarm Out Set1 : :Alarm Maintenace picks up when the maximum broken current (1st
level) calculated by monitoring task is reached (set in MiCOM
S1 :I^Maintenance)
(min1/Max 25000A)
I^ Lockout Alarm Out Set1 : Lockout :Alarm picks up when the maximum broken current (2nd Set 0 :When the maximum broken current (2nd level)
level) calculated by monitoring task is reached (set in MiCOM calculated by monitoring task is not reached
S1 :I^Maintenance)
(min1/Max 25000A)
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
CB Ops Maint Out Set1 :Alarm picks up when the maximum number of CB operations initiated Set 0 :untill number of operations is bellow the MiCOM S1
by internal or external Trip (set in MiCOM S1 :CB Ops Maint) is reached value
(min1/Max 10000) Counter can be reseted by « Reset all values »
CB Ops Lockout Out Set1 :When CB is lockout due to number of CB operations bigger than in Set 0 :untill number of operations is bellow the MiCOM S1
MiCOM S1 value(CB Ops Lock) value
(min1/Max 10000) Counter can be reseted by « Reset all values »
CB Op Time Out Set1 :Alarm picks up for an excessive operating time on any phase (slowest Set 0 :untill operating time is bellow the MiCOM S1 value
Maint pole detection calculated by I< of CB Fail logic))
In MiCOM S1-CB Time maint (min5/Max 500 msec)
CB Op Time lock Out Set1 :Alarm picks up for an excessive operating time on any phase (slowest Set 0 :untill operating time is bellow the MiCOM S1 value
pole detection calculated by I< of CB Fail logic)
In MiCOM S1-CB Time Lockout (min5/Max 500 msec)
F.F Pre Lockout Out Set1 :CB Trip Prelockout Alarm ReSet 0 : end of timer in MiCOM S1 (Fault Freq Time)
With (Maint Lockout –1) + (Fault Frequency-1) at 1 (min0/Max 9999 sec)
F.F Lock Out Set1 : CB Trip Lockout Alarm Reset 0 : By user interface OR CB Close
With : (Maint Lockout =1) + (Fault Frequence=1) (selectable in MiCOM S1)
Lockout Alarm Out Set1 :Lockout Alarm with Reset 0 : By user interface OR CB Close
CBC Unhealthy (selectable in MiCOM S1)
+CBC No Check Sync
+CBC Fail to Close
+CBC Fail To Trip
+FF Lock
+CB OpTime Lock
+CB Ops Lock
CB Status Alarm Out Displayed with 2 LSB of « Plan Status « at 00 or 11 from LCD of relay Set 0 : When conditions reset
Set1 :When CB discrepency status is detected after CBA timer issued by Opto or internal logic
opto input or internaly by CBAux logic – Alarm issued after 5 sec.
See CB aux Logic in sect 4.7.1 Figure 109
Man CB trip Fail Out Set1 :CB Fail on Manual Trip Set 0 :
See CB Control logic section 4.8 Figure 115 See CB Control logic section 4.8 Figure 115
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
Man CB Cls Fail Out Set1 :CB Fail on Manual Close Set 0 :
See CB Control logic section 4.8 Figure 115 See CB Control logic section 4.8 Figure 115
Man CB Out Set1 : CB Unhealthy for Manual Control Set 0 :
Unhealthy See CB Control logic section 4.8 Figure 115 See CB Control logic section 4.8 Figure 115
CB Aux A Out Set1 :Pole A is opened Set 0 :Pole A is closed
CB Pole A Status detceted by internal logic & CBAux optos input status CB Pole A Status detceted by internal logic & CBAux optos
(See CB Section 4.6 – Figure 109) input status (See CB Section 4.6 – Figure 109)
CB Aux B Out Set1 :Pole B is opened Set 0 :Pole B is closed
CB Pole A Status detceted by internal logic & CBAux optos input status CB Pole A Status detceted by internal logic & CBAux optos
(See CB Section 4.6 – Figure 109) input status (See CB Section 4.6 – Figure 109)
CB Aux C Out Set1 :Pole C is opened Set 0 :Pole C is closed
CB Pole A Status detceted by internal logic & CBAux optos input status CB Pole A Status detceted by internal logic & CBAux optos
(See CB Section 4.6 – Figure 109) input status (See CB Section 4.6 – Figure 109)
Any Pole Dead Out See DDB Description in SOTF logic See DDB Description in SOTF logic
All Pole Dead Out See DDB Description in SOTF logic See DDB Description in SOTF logic
TBF1 Trip Out Trip Order :Breaker Failure trip from timer tBF1 in CB Fail ogic Reset end of Timer tBF1
TBF2 Trip Out Trip order : Breaker Failure trip from timer tBF2 in CB Fail ogic Reset end of Timer tBF2
DISTANCE PROTECTION Logic
DIST.Chan Recv In Opto1 opto energised if linked by PSL Reset at 0 : opto power off
At1 :Signal (carrier)received on main channel for Distance scheme logic Set 0 :No carrier received
(depending on MiCOM S1 settings :Program mode/standard Mode)
DIST COS In Opto2 opto energised if linked by PSL Reset at 0 : opto power off
At1 :Signal (Loss of carrier/Loss of Guard) is detected out of service by
external device
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
Z1X Extension In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off
At1 :Signal will initiate Z1 extension logic if selected in MiCOM S1.
That cell can be assigned to any external/Internal condition for starting Z1X
logic
(See Z1X logic section 4.5.4 Figure 13 Figure 14)
MCB/VTS Line In Opto3 opto energised if linked by PSL Reset at 0 : opto power off
(Z measure At1 :Fuse Failure by external MCB status on Main VT (Z measurement) .All
VT main) Distance & Directionnality will be blocked after a FFU timer adjusted by
MiCOM S1
(See Fuse Failure logic section 4.2 Figure 66)
Even if Main VT are Bus side – that cell must be linked to MCB status)
MCB/VTS Bus In See Check Sync DDB description See Check Sync DDB description
(Sync Ref) (Used in Synchrocheck logic) (Used in Synchrocheck logic)
VTS Fast Out Set1 :Copy of Instantaneous unconfirmed Fuse Failure (in internal logic Set 0 :Rest of one of the conditions
detection)
(See Fuse Failure logic section 4.2 Figure 66) (See FFailure logic in section 4.2 Figure 66)
Protections blocked.Min Z can be unblocked by I>&I2>&IN&∆I (for
1P/2P/3P Failure)
VTS Fail Alarm Out Set1 :VT Alarm indication with : Reset 0 :
internal logic after timer is issued+ MCB by opto at1 Healthy network detected
The Distance/WInfeed & Directionnal functions are blocked (only Non direc + All pole Dead
I> are working)
(See Fuse Failure logic section 4.2 Figure 66) (See FFailure logic in section 4.2 Figure 66)
Dist Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
(Usefull during test) OR
Set1 :The DIST Timer will be blocked & DIST will start but will not perform a DDB at 0 if assigned to a DDB cell
Trip command.
COS Alarm Out Set1 :Alarm for Carrier Out Of Service Set 0 : Rest of initiale condition
DIST Sig Send Out Relay 05 Set1 :Signal send in Distance Protection scheme Set 0 :
(See logic of distance section 2.8.2.4)
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
DIST UNB CR Out Set1 :Unblock Main channel signal received Set 0 :
See Led 5 / Relay 10 description
Dist Fwd Out Led6 Set1 :Directionnal Forward detected in distance Algorithms (Deltas or Set 0 : With reset of Any Start/Dist Start
Classical) AND (CVMR)
See Description of Algorithms in chapter P44x/EN HW, item 4)
Assigned to Led 6 by default
Dist Rev Out Led7 Set1 :Directionnal Reverse detected in distance Algorithms (Deltas or Set 0 : With reset of Any Start/Dist Start
Classical) AND (CVMR)
(See Description of Algorithms in chapter P44x/EN HW, item 4)
Assigned to Led 7 by default
Dist Trip A Out Set1 :Trip Phase A with Distance protection logic Set 0 :Reset Dist Trip signal
(See Trip logic in Section 2.5 Figure 94) (fixed pulse duration is 80ms)
Dist Trip B Out Set1 :Trip Phase B with Distance protection logic Set 0 :Reset Dist Trip signal
(See Trip logic in Section 2.5 Figure 94) (fixed pulse duration is 80ms)
Dist Trip C Out Set1 :Trip Phase C with Distance protection logic Set 0 :Reset Dist Trip signal
(See Trip logic in Section 2.5 Figure 94) (fixed pulse duration is 80ms)
DIST Start A Out Set1 : Distance Protection logic start phase A Set 0 : Reset of R/X computation made by All pole Dead
(See Description of Algorithms in chapter 3) detection
I Dead calculated by Laurent (3 or 4 samples requested)
V Dead calculated by CB Fail (More than 10ms requested)
DIST Start B Out Set1 : Distance Protection logic start phase B Set 0 : Reset of R/X computation made by All pole Dead
(See Description of Algorithms in chapter 3) detection
I Dead calculated by Laurent (3 or 4 samples requested)
V Dead calculated by CB Fail (More than 10ms requested)
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
DIST Start C Out Set1 : Distance Protection logic start phase C Set 0 : Reset of R/X computation made by All pole Dead
(See Description of Algorithms in chapter 3) detection
I Dead calculated by Laurent (3 or 4 samples requested)
V Dead calculated by CB Fail (More than 10ms requested)
DIST Sch Accel. Out Set1 :Distance scheme accelerating - POP Set 0 : If disabled in MiCOM S1
(Copy of MiCOM S1 setting Dist scheme)
DIST Sch Perm Out Set1 :Distance scheme Permissive - PUP Set 0 : If disabled in MiCOM S1
(Copy of MiCOM S1 setting Dist scheme)
DIST Sch Block Out Set1 :Distance scheme Blocking – BOP Z1 – BOP Z2 Set 0 : If disabled in MiCOM S1
(Copy of MiCOM S1 setting Dist scheme)
Z1 = Z'1 Out Led5 Set1 :Fault is detected in Z1(convergence of loop in Z1) Set 0 : Reset of R/X computation made by All pole Dead
Relay See Led 5/Relay01/Relay 10 description detection (See Dist Start DDB reset description)
01-10
Z1X = Z'1x Out Led5 Set1 :Fault is detected in Z1x(convergence of loop in Z1x) and filtered by Set 0 : Reset of R/X computation made by All pole Dead
Relay blocking/unblocking PSwing/Rguard logic detection (See Dist Start DDB reset description)
10 See Led 5/Relay10 description
Z2 = Z'2 Out Led5 Set1 :Fault is detected in Z2(convergence of loop in Z2) and filtered by Set 0 : Reset of R/X computation made by All pole Dead
Relay blocking/unblocking PSwing/Rguard logic detection (See Dist Start DDB reset description)
10 See Relay 10 / Led5 description
Z3 = Z'3 Out Led5 Set1 :Fault is detected in Z3(convergence of loop in Z3) and filtered by Set 0 : Reset of R/X computation made by All pole Dead
Relay blocking/unblocking PSwing/Rguard logic detection (See Dist Start DDB reset description)
10 See Relay 10 / Led5 description
Z4 = Z'4 Out Led5 Set1 :Fault is detected in Z4(convergence of loop in Z4) and filtered by Set 0 : Reset of R/X computation made by All pole Dead
Relay blocking/unblocking PSwing/Rguard logic detection (See Dist Start DDB reset description)
10 See Relay 10 / Led5 description
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
Zp Out Led5 Set1 :Fault is detected in Zp(convergence of loop in Zp) – See Relay 10 / Set 0 : Reset of R/X computation made by All pole Dead
Relay Led5 description detection (See Dist Start DDB reset description)
10
T1 Out Set1 :Timer Distance for Z1 (tZ1 in MiCOM S1) is issued (If T1=0 picks up Set 0 : Timer Distance T1 is not issued
when relay starts (CVMR or Predef)
End of Timer =1
T2 Out Set1 :Timer Distance for Z2 (tZ2 in MiCOM S1) is issued Set 0 : Timer Distance T2 is not issued
End of Timer =1
T3 Out Set1 :Timer Distance for Z3 (tZ3 in MiCOM S1) is issued Set 0 : Timer Distance T3 is not issued
End of Timer =1
T4 Out Set1 :Timer Distance for Z4 (tZ4 in MiCOM S1) is issued Set 0 : Timer Distance T4 is not issued
End of Timer =1
Tzp Out Set1 :Timer Distance for Zp (tZp in MiCOM S1) is issued Set 0 : Timer Distance T Zp is not issued
End of Timer =1
Dist Fwd No Filt Out Set1 :Directionnal Forward decision made by Distance logic without any Set 0 : Identical to Dist Fwd reset logic
filter by CVMR or Zone
Picks up quicker than Dist Fwd
Dist Rev No Filt Out Set1 :Directionnal Reverse decision made by Distance logic without any Set 0 : Identical to Dist Rev reset logic
filter by CVMR or Zone
Picks up quicker than Dist Rev
Dist Out Set1 : logic with CVMR at 1 (Minimum 1 loop has been detected in the Set 0 : Reset of R/X computation made by All pole Dead
Convergency quad) detection (See Dist Start DDB reset description)
Cross Country Out Set1 : Cross country logic is activated Set 0 : With reset of initiale conditions
Filt (1 Fault Fwd/1 Fault Rev detected)
Relay Out Assigned in default PSL : »TRIP Z1 » - Default logic Set 0 : See PSL logic
Label Z1&[( Dist TripA)+ (Dist TripB)+ (Dist TripC)]
01
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
Relay Out Assigned in default PSL : »Dist Aided Trip » - Default logic Set 0 : See PSL logic
Label [( Dist TripA)+ (Dist TripB)+ (Dist TripC)]
10 & Dist Unb CR
& (Z1+Z1x+Z2+Z3+Zp+Z4)
LED 5 Led Assigned in default PSL : »Z1+Aided Trip » Set 0 : See PSL logic
Relay10 + Z1 + Z1x
Associated DISTANCE PROTECTION Logic
Power Swing Out Relay Set1 : Power Swing detected Set 0 : Reset of initiale conditions
14 (See description logic in section 2.14 Figure 40)
Reversal Guard Out Set1 :Reversal guard logic is activated (Directionnal switching from Rev to Set 0 :
Fwd in parallel line application)
See Description logic in section 2.8.2.4 Figure 3)
WI Trip A Out Set1 : For Trip phase A in Weak infeed logic Set 0 :
(See Weak Infeed logic section 2.9.3 Figure 24) (See Weak Infeed logic section 2.9.3 Figure 24)
WI Trip B Out Set1 : For Trip phase B in Weak infeed logic Set 0 :
(See Weak Infeed logic section 2.9.3 Figure 24) (See Weak Infeed logic section 2.9.3 Figure 24)
WI Trip C Out Set1 : For Trip phase C in Weak infeed logic Set 0 :
(See Weak Infeed logic section 2.9.3 Figure 24) (See Weak Infeed logic section 2.9.3 Figure 24)
Aided DEF PROTECTION Logic
DEF.Chan Recv In Opto1 opto energised if linked by PSL opto power off
At1 :Signal (carrier)received on main channel for DEF scheme logic Set 0 :No carrier received
(depending on MiCOM S1 settings :Aided DEF/Scheme logic)
Selected shared by default – Can operate as an independant scheme with
adifferent opto from Dist
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
DEF COS In Opto2 opto energised if linked by PSL Reset at 0 : opto power off
At1 :Signal (Loss of carrier/Loss of Guard) is detected out of service by
external device
Selected shared by default – Can operate as an independant scheme with
adifferent opto from Dist
DEF Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The DEF Timer will be blocked & DEF will start but will not perform OR
any Trip command. DDB at 0 if assigned to a DDB cell
DEF Sig Send Out Relay Set1 :Signal send in DEF Protection scheme Set 0 :
05 (See logic of DEF section 2.18 Figure 48 and Figure 49)
DEF UNB CR Out Set1 :Unblock DEF Channel Set 0 :
DEF Rev Out Set1 :Directionnal Reverse detected in DEF Algorithms (Deltas or Set 0 : Reset of R/X computation made by All pole Dead
Classical) detection (See Dist Start DDB reset description)
See Description of Algorithms in section 2.18 Figure 50)
DEF Fwd Out Set1 :Directionnal Foward detected in DEF Algorithms (Deltas or Classical) Set 0 : Reset of R/X computation made by All pole Dead
(See Description of Algorithms in section 2.18 Figure 50) detection (See Dist Start DDB reset description)
DEF Start A Out Set1 :Start Phase A with DEF protection logic Set 0 : Reset of R/X computation made by All pole Dead
(See Trip logic in section 2.18) detection (See Dist Start DDB reset description)
DEF Start B Out Set1 :Start Phase B with DEF protection logic Set 0 : Reset of R/X computation made by All pole Dead
(See Trip logic in section 2.18) detection (See Dist Start DDB reset description)
DEF Start C Out Set1 :Start Phase C with DEF protection logic Set 0 : Reset of R/X computation made by All pole Dead
(See Trip logic in section 2.18) detection (See Dist Start DDB reset description)
DEF Trip A Out Relay Set1 : DEF Protection logic Trip phase A Set 0 : Reset DEF Trip Order
09 (See Description of Algorithms in Figure 52)
DEF Trip B Out Relay Set1 : DEF Protection logic Trip phase B Set 0 : Reset DEF Trip Order
09 (See Description of Algorithms in Figure 52)
DEF Trip C Out Relay Set1 : DEF Protection logic Trip phase C Set 0 : Reset DEF Trip Order
09 (See Description of Algorithms in Figure 52)
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
ZERO SEQUENCE POWER PROTECTION ZSP Logic (since version B1.0)
ZSP Timer Block In Input energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set 1:The ZSP Timer will be blocked & ZSP will start but will not perform OR
any Trip command DDB at 0 if assigned to a DDB cell
ZSP Start Out Set 1:Zero sequence power function Start (Timer associated picks up) Set 0:Reset with IN or SR below the threshold IN> or SR>
with fixed time delay first and IDMT curve timer Hysteresis=
(See Pole Dead description in Figure 60)
ZSP Trip Out Set 1:3P Trip order performed by Zero sequence power function when Set 0:Reset ZSP Trip Order
associated timers are issued
BACK UP OVERCURRENT PROTECTION IN>1/IN>2/I2>/I>1/I>2/I>3/I>4 Logic
IN>1 Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The IN>1 Timer will be blocked & IN>1 will start but will not perform OR
any Trip command. DDB at 0 if assigned to a DDB cell
IN>2 Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The IN>2 Timer will be blocked & IN>2 will start but will not perform OR
any Trip command. DDB at 0 if assigned to a DDB cell
I>1 Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The I>1 Timer will be blocked & I>1 will start but will not perform any OR
Trip command. DDB at 0 if assigned to a DDB cell
I>2 Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The I>2 Timer will be blocked & I>2 will start but will not perform any OR
Trip command. DDB at 0 if assigned to a DDB cell
I>3 Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The I>3 Timer will be blocked & I>3 will start but will not perform any OR
Trip command. DDB at 0 if assigned to a DDB cell
I>4 Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The I>4 Timer will be blocked & I>4 will start but will not perform any OR
Trip command. DDB at 0 if assigned to a DDB cell
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
I2> Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The I2> Timer will be blocked & I2> will start but will not perform any OR
Trip command with negative overcurrent detection DDB at 0 if assigned to a DDB cell
IN>1 Trip Out Relay Set1 : Earth Fault stage 1 – 3Poles Trip order performed when associated Set 0 : Reset IN>1 Trip Order
09 timer is issued
IN>2 Trip Out Relay Set1 : Earth Fault stage 2 – 3Poles Trip order performed when associated Set 0 : Reset IN>2Trip Order
09 timer is issued
IN>1 Start Out Set1 : Earth Fault stage 1 – Start function (Timer associated picks up) Set 0 : Reset with IN below the threshold IN>1
Directionnal or not - with DT or IDMT curves Hysteresis=
Negative or positive sequence polarisation (See Pole Dead description in Figure 60)
IN>2 Start Out Set1 : Earth Fault stage 2 – Start function (Timer associated picks up) Set 0 : Reset with IN below the threshold IN>2
Directionnal or not - DT only Hysteresis=
Negative or positive sequence polarisation (See Pole Dead description in Figure 60)
I2> Start Out Set1 : Negative sequence current detection – Start function (Timer Set 0 : Reset with IN below the threshold I2>
associated picks up) Hysteresis=
Directionnal or not - with DT curves
Negative polarisation (See Pole Dead description in Figure 60)
I2> Trip Out Set1 : Negative sequence current detection – 3P Trip order performed Set 0 : Reset I2> Trip Order
when associated timer is issued
I>Start Out Set1 :Any Overcurrent function start for phase A Set 0 : Reset with Iphase A below the lowest threshold I>1
Any A Hysteresis=
(See Pole Dead description in Figure 60)
I>Start Out Set1 :Any Overcurrent function start for phase B Set 0 : Reset with Iphase B below the lowest threshold I>1
Any B Hysteresis=
(See Pole Dead description in Figure 60)
I>Start Out Set1 :Any Overcurrent function start for phase C Set 0 : Reset with Iphase C below the lowest threshold I>1
Any C Hysteresis=
(See Pole Dead description in Figure 60)
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
I>1 Start Out Set1 :Overcurrent stage1 start Set 0 : Reset with Iphase A below the threshold I>1
Directionnal or not - with DT or IDMT curves Hysteresis=
Directionnal managed by Deltas Algorithms
VTS Block timer facility (See Pole Dead description in Figure 60)
I>2 Start Out Set1 :Overcurrent stage2 start Set 0 : Reset with Iphase A below the threshold I>2
Directionnal or not - with DT or IDMT curves Hysteresis=
Directionnal managed by Deltas Algorithms
VTS Block timer facility (See Pole Dead description in Figure 60)
I>3 Start Out Set1 :Overcurrent stage3 start Set 0 : Reset with Iphase A below the threshold I>3
Not Directionnal with DT curves Hysteresis=
Use without timer for SOTF
(see description in section 2.12 Figure 35) (See Pole Dead description in Figure 60)
I>4 Start Out Set1 :Overcurrent stage4 start Set 0 : Reset with Iphase A below the threshold I>4
Not Directionnal with DT curves Hysteresis=
Use without timer for SOTF
(see description in section 2.14) (See Pole Dead description in Figure 60)
I>1 Trip Out Set1 :Overcurrent Stage 1 Trip 3P performed when associated timer is Set 0 : Reset I>1 Trip Order
issued
I>2 Trip Out Set1 :Overcurrent Stage 2 Trip 3P performed when associated timer is Set 0 : Reset I>2 Trip Order
issued
I>3 Trip Out Set1 :Overcurrent Stage 3 Trip 3P performed when associated timer is Set 0 : Reset I>3 Trip Order
issued
I>4 Trip Out Set1 :Overcurrent Stage 4 Trip 3P performed when associated timer is Set 0 : Reset I>4 Trip Order
issued
Stub Bus Enable Out opto energised if linked by PSL Reset at 0 : opto power off if assigned to an opto
At1 :Status input from HV line isolator opened – indicates that line is dead
& disconnected
At1 : I>4 is activated as a back up Stub Bus protection
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
BACK UP VOLTAGE PROTECTION V<1/V<2/V>1/V>2 Logic
V<1 Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The V<1 Timer will be blocked & V<1 will start but will not perform OR
any Trip command. DDB at 0 if assigned to a DDB cell
V<2 Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The V<2 Timer will be blocked & V<2 will start but will not perform OR
any Trip command. DDB at 0 if assigned to a DDB cell
V>1 Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The V>1 Timer will be blocked & V>1 will start but will not perform OR
any Trip command. DDB at 0 if assigned to a DDB cell
V>2 Timer Block In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :The V>2 Timer will be blocked & V>2 will start but will not perform OR
any Trip command. DDB at 0 if assigned to a DDB cell
V<1 Alarm Out Set1 :1st stage undervoltage Alarm picks up when V<1 starts Set 0 : Reset with V measure over the threshold V<1
Hysteresis=
V<2 Alarm Out Set1 :2nd stage undervoltage Alarm picks up when V<1 starts Set 0 : Reset with V measure over the threshold V<2
Hysteresis=
V>1 Alarm Out Set1 :1st stage Overvoltage Alarm picks up when V<1 starts Set 0 : Reset with V measure below the threshold V>1
Hysteresis=
V>2 Alarm Out Set1 :2nd stage Overvoltage Alarm picks up when V<1 starts Set 0 : Reset with V measure below the threshold V>2
Hysteresis=
V<Start Out Set1 :Any Undervoltage function start for phase A Set 0 : Reset with V phase A measure over the lowest
Any A threshold V<
Hysteresis=
V<Start Out Set1 :Any Undervoltage function start for phase B Set 0 : Reset with V phase B measure over the lowest
Any B threshold V<
Hysteresis=
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
V<Start Out Set1 :Any Undervoltage function start for phase C Set 0 : Reset with V phase C measure over the lowest
Any C threshold V<
Hysteresis=
V<1 Start Out Set1 :1st Stage Undervoltage function start for any phase Set 0 : Reset with V measure over the threshold V<1
Hysteresis=
V<2 Start Out Set1 :2nd Stage Undervoltage function start for any phase Set 0 : Reset with V measure below the threshold V<2
Hysteresis=
V<1 Trip Out Set1 :1st Stage Undervoltage function trip 3 phase Set 0 : Reset of V<1 Trip order
nd
V<2 Trip Out Set1 :2 Stage Undervoltage function trip 3 phase Set 0 : Reset of V<2 Trip order
V>Start Out Set1 :Any Overvoltage function start for phase A Set 0 : Reset with V phase A measure below the lowest
Any A threshold V<
Hysteresis=
V>Start Out Set1 :Any Overvoltage function start for phase B Set 0 : Reset with V phase B measure below the lowest
Any B threshold V<
Hysteresis=
V>Start Out Set1 :Any Overvoltage function start for phase C Set 0 : Reset with V phase C measure below the lowest
Any C threshold V<
Hysteresis=
V>1 Start Out Set1 :1st Stage Overvoltage function start for any phase Set 0 : Reset with V measure below the threshold V>1
Hysteresis=
V>2 Start Out Set1 :2nd Stage Overvoltage function start for any phase Set 0 : Reset with V measure below the threshold V>2
Hysteresis=
V>1 Trip Out Set1 :1st Stage Overvoltage function 3 phase TRIP Set 0 : Reset of V>1 Trip order
V>2 TRip Out Set1 :2nd Stage Overvoltage function 3 phase TRIP Set 0 : Reset of V>2 Trip order
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
ALARMS
F out of Range Out Set1 :Alarm when frequency tracking does not operate correctly and Set 0 : With frequency tracking operating correctly
provides a Frequency out of range
CT Fail Alarm Out Set1 :Alarm from the current transformers supervision Set 0 :No CT Fail Alarm detected
Brok.Cond. Out Set1 : Alarm from the Start of Broken Conductor function Set 0 :No Brok.Cond.Alarm detected
Alarm
CVT Alarm Out Set 1:Alarm from the capacitive voltage transformers supervision Set 0 :No CVT Fail Alarm detected
Field Volt Fail Out Set1 : Field Voltage Failure (Internal 48Vcc delivered by the relay can be Set 0 :With reset of min Field voltage detection
used for Optos polarisation)
Alarm User1 In Set1 : Alarm for user – application customized must be linked to dedicated Set 0 :With reset of conditions linked to that cell
DDB cells
Alarm User2 In Set1 : Alarm for user – application customized must be linked to dedicated Set 0 :With reset of conditions linked to that cell
DDB cells
Alarm User3 In Set1 : Alarm for user – application customized must be linked to dedicated Set 0 :With reset of conditions linked to that cell
DDB cells
Alarm User4 In Set1 : Alarm for user – application customized must be linked to dedicated Set 0 :With reset of conditions linked to that cell
DDB cells
Alarm User5 In Set1 : Alarm for user – application customized must be linked to dedicated Set 0 :With reset of conditions linked to that cell
DDB cells
General Alarm Out Relay Set1 :For any Alarm started & included in the list : Set 0 : Reset if all initiale condition reset
08 Battery Fail
Field Volt Fail
General Alarm
Prot’n Disabled
F out of range
VT Fail Alarm
CT Fail Alarm
CVT Fail Alarm
CB Fail Alarm
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
General Alarm Out Relay I^Maint Alarm Set 0 : Reset if all initiale condition reset
08 I^Lockout Alarm
CB Ops Maint
CB Ops Lockout
CB Op Time Maint
CB Op Time Lock
F.F. Pre Lockout
F.F Lock
Lockout Alarm
CB Status Alarm
Man CB Trip Fail
Man CB Cls Fail
Man CB Unhealthy
Control No C/C
AR Lockout Shot>
SG-opto Invalid
A/R Fail
V<1 Alarm
V<2 Alarm
V>1 Alarm
V>2 Alarm
COS Alarm
User Alarlm1
User Alarm2
START LOGIC
Any Start Out Led4 Set1 :Any Protection start loig with any phase Set 0 :Reset with reset from all started function
Relay Assigned to Led 4 by default (21/67N/50/51…)
06 (Fault record Trigger in default PSL with 20ms Dwell Timer)
1ph Fault Out Set1 : Single phase fault detected with Distance Funct. Set 0 : with Distance Reset
2ph Fault Out Set1 : Two phase fault detected with Distance Funct. Set 0 : with Distance Reset
3ph Fault Out Set1 : Three phase fault detected with Distance Funct. Set 0 : with Distance Reset
P44x/EN AP/E33 Application Notes
In
DDB label Default PSL Set with : Reset with :
Out
TRIP LOGIC
User Trip A In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :Trip A Internal input managed with the general trip logic(With OR
AR/Evolving fault…) DDB at 0 if assigned to a DDB cell
Can be assigned by external condition
User Trip B In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :Trip B Internal input managed with the general trip logic(With OR
AR/Evolving fault…) DDB at 0 if assigned to a DDB cell
Can be assigned by external condition
User Trip C In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :Trip C Internal input managed with the general trip logic(With OR
AR/Evolving fault…) DDB at 0 if assigned to a DDB cell
Can be assigned by external condition
Any Trip Out Relay Set1 :Any Trip 1P or 3P initiated by internal Trip or external Trip decision Set 0 :Reset conditions
07 (Fault record Trigger in default PSL)
Any Int Trip A Out Set1 : Any Internal Trip with Phase A with any internal protection decision Set 0 :Reset conditions
Any Int Trip B Out Set1 : Any Internal Trip with Phase B with any internal protection decision Set 0 :Reset conditions
Any Int Trip C Out Set1 : Any Internal Trip with Phase C- with any internal protection decision Set 0 :Reset conditions
Any Trip A Out Led1 Set1 :Any Internal or External Trip phase A – with any protection decision Set 0 :Reset conditions
Relay (internal or external)
02 Assigned to Led 1 by default
Any Trip B Out Led2 Set1 :Any Internal or External Trip phase B – with any protection decision Set 0 :Reset conditions
Relay (internal or external)
03 Assigned to Led 2 by default
Any Trip C Out Led3 Set1 :Any Internal or External Trip phase C – with any protection decision Set 0 :Reset conditions
Relay (internal or external)
04 Assigned to Led 3 by default
1P Trip Out Set1 :Single pole Trip decision (int or Ext) Set 0 :Reset conditions
Application Notes P44x/EN AP/E33
In
DDB label Default PSL Set with : Reset with :
Out
3P Trip Out Set1 :Three pole Trip decision (int or Ext) Set 0 :Reset conditions
Brk Conduct. Out Set1 :3P Trip decision by Broken Conductor protection Set 0 :Reset conditions
Trip
Loss.Load Out Set1 :3P Trip decision by Loss of Load protection (in application without Set 0 :Reset conditions
Trip communication scheme & a 3P Trip logic)
MISCELLANEOUS LOGIC
BLK Protection In opto energised if linked by PSL OR any internal DDB by dedicated PSL Set 0 :Reset conditions
Set1 :All protections functions are blocked (21/67N/50/51…)
Prot’n Disabled Out Set1 :When TEST MODE is enable Set 0 :Reset conditions – No blocking conditions available :
All the protections functions are out of order. (Test mode disable) + (Opto BLK Protec =0)
Reset Latches In opto energised if linked by PSL OR any internal DDB by dedicated PSL Reset at 0 : opto power off if assigned to an opto
Set1 :Permanent Alarms & Leds & relayslatched are reset OR
DDB at 0 if assigned to a DDB cell
P44x/EN AP/E33 Application Notes
BLANK PAGE
Technical Data P44x/EN TD/E33
TECHNICAL DATA
Technical Data P44x/EN TD/E33
CONTENT
1. RATINGS 5
1.1 Currents 5
1.2 Voltages 5
1.3 Auxiliary Voltage 6
1.4 Frequency 6
1.5 Logic inputs 6
1.6 Output Relay Contacts 7
1.7 Field Voltage 7
1.8 Loop through connections 7
1.9 Wiring requirements 7
2. BURDENS 8
2.1 Current Circuit 8
2.2 Voltage Circuit 8
2.3 Auxiliary Supply 8
2.4 Optically-Isolated Inputs 8
3. ACCURACY 9
3.1 Reference Conditions 9
3.2 Measurement Accuracy 9
3.3 Protection accuracy 10
3.4 Influencing Quantities 12
3.5 High Voltage Withstand IEC60255-5:1977 12
3.5.1 Dielectric Withstand 12
3.5.2 Impulse 12
3.5.3 Insulation Resistance 12
4. ENVIRONMENTAL COMPLIANCE 13
4.1 Electrical Environment 13
4.1.1 DC Supply Interruptions IEC60255-11:1979 13
4.1.2 AC Ripple on DC Supply IEC60255-11:1979 13
4.1.3 Disturbances on AC Supply - EN61000-4-11:1994 13
4.1.4 High Frequency Disturbance IEC60255-22-1:1988 13
4.1.5 Fast Transient IEC60255-22-4:1992 13
4.1.6 Electrostatic Discharge IEC60255-22-2:1996 13
4.1.7 Conducted Emissions EN 55011:1991 13
4.1.8 Radiated Emissions EN 55011:1991 13
4.1.9 Radiated Immunity IEC60255-22-3:1989 14
P44x/EN TD/E33 Technical Data
7. MEASUREMENT SETTINGS 26
7.1 Disturbance Recorder Settings 26
7.2 Fault Locator Settings 26
BLANK PAGE
Technical Data P44x/EN TD/E33
1. RATINGS
1.1 Currents
All current inputs will withstand the following, with any current function setting:
Withstand Duration
4 Ιn Continuous rating
4.5 Ιn 10 minutes
5 Ιn 5 minutes
6 Ιn 3 minutes
7 Ιn 2 minutes
30 Ιn 10 seconds
50 Ιn 3 seconds
100 Ιn 1 second
1.2 Voltages
Duration Withstand
(Vn = 100/120V)
Continuous rating (2Vn) 240Vph - ph rms
10 seconds (2.6Vn) 312Vph - ph rms
P44x/EN TD/E33 Technical Data
1.4 Frequency
The nominal frequency (Fn) is dual rated at 50/60Hz, the operate range is 45Hz to 65Hz.
1.5 Logic inputs
All the logic inputs are independent and isolated, relay types P441 provide 8 inputs, 16
inputs are provided by the P442.
Rating Range
Logical “off” 0Vdc 0 - 12Vdc
Logical “on” 50Vdc 30 - 60Vdc
Higher voltages can be used in conjunction with an external resistor, value of the resistor is
determined by the following equation:
Watchdog Contact
Break DC: 30W resistive
DC: 15W inductive (L/R = 40ms)
AC: 275W inductive (P.F. = 0.7)
2. BURDENS
2.1 Current Circuit
* Nominal is with 50% of the optos energised and one relay per card energised
** Maximum is with all optos and all relays energised.
For each energised Opto powered from the Field Voltage or each energised Output Relay:
3. ACCURACY
For all accuracies specified, the repeatability is ±2.5% unless otherwise specified.
If no range is specified for the validity of the accuracy, then the specified accuracy shall be
valid over the full setting range.
3.1 Reference Conditions
I 2 I 2 I 2
Broken conductor protection 0.2 to 1.0 ±5% 0.95 ±5% greater of ±2% or 20ms
I1 I1 I1
Transient Overreach 2 to 20 Is <5% (for a system - --
X/R of up to 90)
Relay overshoot 2 to 20 Is <50ms - -
Breaker fail timers 0 to 10s - - greater of ±2% or 20ms
P44x/EN TD/E33 Technical Data
The product will withstand without damage impulses of 5kV peak, 1.2/50µs, 0.5J across:
Each independent circuit and the case with the terminals of each independent circuit
connected together.
Independent circuits with the terminals of each independent circuit connected together.
Terminals of the same circuit except normally open metallic contacts.
3.5.3 Insulation Resistance
4. ENVIRONMENTAL COMPLIANCE
The product complies with the following specifications :
4.1 Electrical Environment
4.1.1 DC Supply Interruptions IEC60255-11:1979
The product will withstand a 20ms interruption in the auxiliary voltage in its quiescent
condition.
4.1.2 AC Ripple on DC Supply IEC60255-11:1979
The product will operate with 12% AC ripple on the DC auxiliary supply without any
additional measurement errors.
4.1.3 Disturbances on AC Supply - EN61000-4-11:1994
The products satisfies the requirements of EN61000-4-11 for voltage dips and short
interruptions.
4.1.4 High Frequency Disturbance IEC60255-22-1:1988
The product complies with Class III 2.5kV common mode and 1kV differential mode for 2
seconds at 1MHz with 200Ω source impedance, without any mal-operations or additional
measurement errors.
4.1.5 Fast Transient IEC60255-22-4:1992
The product complies with all classes up to and including class IV/4kV without any mal-
operations or additional measurement errors.
Fast transient disturbances on power supply 4kV, 5ns rise time, 50ns decay time, 5kHz
(common mode only) repetition time, 15ms burst, repeated every
300ms for 1min in each polarity, with a 50Ω
source impedance.
Fast transient disturbances on I/O signal, 4kV, 5ns rise time, 50ns decay time, 5kHz
data and control lines (common mode only) repetition time, 15ms burst, repeated every
300ms for 1min in each polarity, with a 50Ω
source impedance.
In = 1 A In = 5 A
Setting Range Step size Range Step size
Positive sequence impedance 0.001 - 500 Ω 0.001 Ω 0.002 - 0.002 Ω
(Z1) 199,8 Ω
Setting In = 1 A In = 5 A
Range Step size Range Step size
Impedance reaches 0.001 - 500 Ω 0.001 Ω 0.0002 - 0.0002 Ω
(Zone 1, Zone 2, Zone 3, Zone P, 100 Ω
Zone 4)
Resistive reaches for phase - 0 - 400 Ω 0.01 Ω 0 - 80 Ω 0.002 Ω
earth faults
(Zone 1, Zone 2, Zones 3 & 4,
Zone P)
Resistive reaches for phase - 0 - 400 Ω 0.01 Ω 0 - 80 Ω 0.002 Ω
earth faults
(Zone 1, Zone 2, Zones 3 & 4,
Zone P)
In = 1 A In = 5 A
Setting Range Step size Range Step size
Powerswing detection boundaries:
Delta R 0 - 400 Ω 0.01 Ω 0 - 80 Ω 0.002 Ω
Delta X 0 - 400 Ω 0.01 Ω 0 - 80 Ω 0.002 Ω
Setting Range
Signal Send Zone No Signal Send/Signal send on Z1/ Signal send on Z2/
Signal send on Z4
Type of Scheme on signal None/None+Z1X/Aided scheme for Z1 faults/Aided
Receive scheme for Z2 faults/ Aided scheme for forward faults/
Blocking scheme for Z1 faults/ Blocking scheme for Z2
faults
TD K
t= × + L
(I/I S )
7 α
−1
Where
t = operation time
K = constant
I = measured current
IS = current threshold setting
α = constant
L = ANSI/IEEE constant (zero for IEC/UK curves)
TMS = Time Multiplier Setting for IEC/UK curves
TD = Time Dial Setting for IEEE/US curves
Technical Data P44x/EN TD/E33
IDMT Characteristics
The Inverse Reset characteristics are dependent upon the selected IEEE/US IDMT curve as
shown in the table below. Thus if IDMT reset is selected the curve selection and Time Dial
setting will apply to both operate and reset.
All inverse reset curves conform to the following formula:
TD tr
t Re set = ×
7 1 − ( I I ) α
S
Where
tReset = reset time
tr = constant
I = measured current
IS = current threshold setting
α = constant
TD = Time Dial Setting (Same setting as that employed by IDMT curve)
P44x/EN TD/E33 Technical Data
K
t=
(1 − M )
Where
K = Time Multiplier Setting
T = Operating time in seconds
M = Applied input voltage / Relay setting voltage (Vs)
P44x/EN TD/E33 Technical Data
K
t=
( M − 1)
Where
K = Time Multiplier Setting
T = Operating time in seconds
M = Applied input voltage / Relay setting voltage (Vs)
7. MEASUREMENT SETTINGS
7.1 Disturbance Recorder Settings
8.2 Auto-Reclose
8.2.1 Options
The Auto-recloser in the distance protection allows either single* or three pole for the first
shot. The following shots are three pole only. Due to the complexity of the logic the
Application notes should be referred to.
NOTE: *P442 and P444 only
8.2.2 Auto-recloser settings
INSTALLATION
Installation P44x/EN IN/E33
CONTENT
1. RECEIPT OF RELAYS 3
2. STORAGE 3
3. UNPACKING 3
4. RELAY MOUNTING 4
4.1 Rack mounting 5
4.2 Panel mounting 6
5. RELAY WIRING 8
5.1 Medium and heavy duty terminal block connections 8
5.2 RS485 port 8
5.3 IRIG-B connections (if applicable) 9
5.4 RS232 port 9
5.5 Download/monitor port 9
5.6 Earth connection 9
P44x/EN IN/E33 Installation
BLANK PAGE
Installation P44x/EN IN/E33
1. RECEIPT OF RELAYS
Protective relays, although generally of robust construction, require careful treatment prior to
installation on site. Upon receipt, relays should be examined immediately to ensure no
external damage has been sustained in transit.
If damage has been sustained, a claim should be made to the transport contractor and
AREVA T&D Protection & Control should be promptly notified.
Relays that are supplied unmounted and not intended for immediate installation should be
returned to their protective polythene bags and delivery carton.
Section 3 of this chapter gives more information about the storage of relays.
2. STORAGE
If relays are not to be installed immediately upon receipt, they should be stored in a place
free from dust and moisture in their original cartons. Where de-humidifier bags have been
included in the packing they should be retained. The action of the de-humidifier crystals will
be impaired if the bag is exposed to ambient conditions and may be restored by gently
heating the bag for about an hour prior to replacing it in the carton.
To prevent battery drain during transportation and storage a battery isolation strip is fitted
during manufacture. With the lower access cover open, presence of the battery isolation strip
can be checked by a red tab protruding from the positive side.
Care should be taken on subsequent unpacking that any dust which has collected on the
carton does not fall inside. In locations of high humidity the carton and packing may become
impregnated with moisture and the de-humidifier crystals will lose their efficiency.
Prior to installation, relays should be stored at a temperature of between –25˚C to +70˚C.
3. UNPACKING
Care must be taken when unpacking and installing the relays so that none of the parts are
damaged and additional components are not accidentally left in the packing or lost.
NOTE: With the lower access cover open, the red tab of the battery isolation
strip will be seen protruding from the positive side of the battery
compartment. Do not remove this strip because it prevents battery
drain during transportation and storage and will be removed as part of
the commissioning tests.
Relays must only be handled by skilled persons.
The site should be well lit to facilitate inspection, clean, dry and reasonably free from dust
and excessive vibration. This particularly applies to installations which are being carried out
at the same time as construction work.
P44x/EN IN/E33 Installation
4. RELAY MOUNTING
MiCOM relays are dispatched either individually or as part of a panel/rack assembly.
Individual relays are normally supplied with an outline diagram showing the dimensions for
panel cut-outs and hole centres. This information can also be found in the product
publication.
Secondary front covers can also be supplied as an option item to prevent unauthorised
changing of settings and alarm status. They are available in sizes 40TE (GN0037 001) and
60TE (GN0038 001). Note that the 60TE cover also fits the 80TE case size of the relay.
The design of the relay is such that the fixing holes in the mounting flanges are only
accessible when the access covers are open and hidden from sight when the covers are
closed.
If a P991 or MMLG test block is to be included, it is recommended that, when viewed from
the front, it is positioned on the right-hand side of the relay (or relays) with which it is
associated. This minimises the wiring between the relay and test block, and allows the
correct test block to be easily identified during commissioning and maintenance tests.
P0146XXa
P0147XXa
Further details on mounting MiDOS relays can be found in publication R7012, “MiDOS Parts
Catalogue and Assembly Instructions”.
5. RELAY WIRING
This section serves as a guide to selecting the appropriate cable and connector type for
each terminal on the MiCOM relay.
5.1 Medium and heavy duty terminal block connections
Loose relays are supplied with sufficient M4 screws for making connections to the rear
mounted terminal blocks using ring terminals, with a recommended maximum of two ring
terminals per relay terminal.
If required, AREVA T&D Protection & Control can supply M4 90° crimp ring terminals in three
different sizes depending on wire size (see Table 3). Each type is available in bags of 100.
The IRIG-B input and BNC connector have a characteristic impedance of 50Ω. It is
recommended that connections between the IRIG-B equipment and the relay are made
using coaxial cable of type RG59LSF with a halogen free, fire retardant sheath.
5.4 RS232 port
Short term connections to the RS232 port, located behind the bottom access cover, can be
made using a screened multi-core communication cable up to 15m long, or a total
capacitance of 2500pF. The cable should be terminated at the relay end with a 9-way, metal
shelled, D-type male plug. Chapter 2, Section 3.7 of this manual details the pin allocations.
5.5 Download/monitor port
Short term connections to the download/monitor port, located behind the bottom access
cover, can be made using a screened 25-core communication cable up to 4m long. The
cable should be terminated at the relay end with a 25-way, metal shelled, D-type male plug.
Chapter 2, Section 3.7 of this manual details the pin allocations.
5.6 Earth connection
Every relay must be connected to the local earth bar using the M4 earth studs in the bottom
left hand corner of the relay case. The minimum recommended wire size is 2.5mm2 and
should have a ring terminal at the relay end. Due to the limitations of the ring terminal, the
maximum wire size that can be used for any of the medium or heavy duty terminals is
6.0mm2 per wire. If a greater cross-sectional area is required, two parallel connected wires,
each terminated in a separate ring terminal at the relay, or a metal earth bar could be used.
NOTE: To prevent any possibility of electrolytic action between brass or
copper earth conductors and the rear panel of the relay, precautions
should be taken to isolate them from one another. This could be
achieved in a number of ways, including placing a nickel-plated or
insulating washer between the conductor and the relay case, or using
tinned ring terminals.
Before carrying out any work on the equipment, the user should be familiar with the
contents of the Safety and Technical Data sections and the ratings on the equipment's
rating label
P44x/EN IN/E33 Installation
BLANK PAGE
Commissioning P44x/EN CM/E33
COMMISSIONING
Commissioning P44x/EN CM/E33
CONTENT
1. INTRODUCTION 3
2. SETTING FAMILIARISATION 4
4. PRODUCT CHECKS 6
4.1 With the Relay De-energised 6
4.1.1 Visual Inspection 7
4.1.2 Current Transformer Shorting Contacts 8
4.1.3 External Wiring 9
4.1.4 Insulation 9
4.1.5 Watchdog Contacts 10
4.1.6 Auxiliary Supply 10
4.2 With the Relay Energised 10
4.2.1 Watchdog Contacts 10
4.2.2 Date and Time 10
4.2.3 With an IRIG-B signal 11
4.2.4 Without an IRIG-B signal 11
4.2.5 Light Emitting Diodes (LEDs) 11
4.2.6 Field Voltage Supply 12
4.2.7 Input Opto-isolators 12
4.2.8 Output Relays 13
4.2.9 Rear Communications Port 15
4.2.10 Current Inputs 16
4.2.11 Voltage Inputs 16
5. SETTING CHECKS 18
5.1 Apply Application-Specific Settings 18
5.2 Check Application-Specific Settings 18
5.3 Demonstrate Correct Distance Function Operation 19
5.3.1 Functional Tests : Start control & Distance characteristic limits 19
5.3.2 Distance scheme test (if validated in S1 & PSL) 34
5.3.3 Loss of guard/loss of carrier TEST 35
5.3.4 Weak infeed mode test 35
5.3.5 Protection function during fuse failure 36
P44x/EN CM/E33 Commissioning
6. ON-LOAD CHECKS 40
6.1 Voltage Connections 40
6.2 Current Connections 41
7. FINAL CHECKS 42
8. MAINTENANCE 43
8.1 Maintenance Period 43
8.2 Maintenance Checks 43
8.2.1 Alarms 43
8.2.2 Opto-isolators 43
8.2.3 Output Relays 43
8.2.4 Measurement accuracy 43
8.3 Method of Repair 44
8.3.1 Replacing the Complete Relay 44
8.3.2 Replacing a PCB 45
8.4 Recalibration 52
8.5 Changing the battery 52
8.5.1 Instructions for Replacing The Battery 52
8.5.2 Post Modification Tests 53
8.5.3 Battery Disposal 53
Commissioning P44x/EN CM/E33
1. INTRODUCTION
The MiCOM P440 distance protection relays are fully numerical in their design, implementing
all protection and non-protection functions in software. The relays employ a high degree of
self-checking and, in the unlikely event of a failure, will give an alarm. As a result of this, the
commissioning tests do not need to be as extensive as with non-numeric electronic or
electro-mechanical relays.
To commission numeric relays, it is only necessary to verify that the hardware is functioning
correctly and the application-specific software settings have been applied to the relay. It is
considered unnecessary to test every function of the relay if the settings have been verified
by one of the following methods:
Extracting the settings applied to the relay using appropriate setting software (Preferred
method)
Via the operator interface.
To confirm that the product is operating correctly once the application-specific settings have
been applied, a test should be performed on a single protection element.
Unless previously agreed to the contrary, the customer will be responsible for determining
the application-specific settings to be applied to the relay and for testing of any scheme logic
applied by external wiring and/or configuration of the relay’s internal programmable scheme
logic.
Blank commissioning test and setting records are provided at the end of this chapter for
completion as required.
As the relay’s menu language is user-selectable, it is acceptable for the Commissioning
Engineer to change it to allow accurate testing as long as the menu is restored to the
customer’s preferred language on completion.
To simplify the specifying of menu cell locations in these Commissioning Instructions, they
will be given in the form [courier reference: COLUMN HEADING, Cell Text]. For example,
the cell for selecting the menu language (first cell under the column heading) is located in the
System Data column (column 00) so it would be given as [0001: SYSTEM DATA,
Language].
Before carrying out any work on the equipment, the user should be familiar with the contents
of the ‘safety section’ and chapter P44x/EN IN, ‘installation’, of this manual.
P44x/EN CM/E33 Commissioning
2. SETTING FAMILIARISATION
When commissioning a MiCOM P440 relay for the first time, sufficient time should be
allowed to become familiar with the method by which the settings are applied.
Chapter P44x/EN IT contains a detailed description of the menu structure of the relays.
With the secondary front cover in place all keys except the [Enter] key are accessible. All
menu cells can be read. LEDs and alarms can be reset. However, no protection or
configuration settings can be changed, or fault and event records cleared.
Removing the secondary front cover allows access to all keys so that settings can be
changed, LEDs and alarms reset, and fault and event records cleared. However, menu cells
that have access levels higher than the default level will require the appropriate password to
be entered before changes can be made.
Alternatively, if a portable PC is available together with suitable setting software (such as
MiCOM S1), the menu can be viewed a page at a time to display a full column of data and
text. This PC software also allows settings to be entered more easily, saved to a file on disk
for future reference or printed to produce a setting record. Refer to the PC software user
manual for details. If the software is being used for the first time, allow sufficient time to
become familiar with its operation.
Commissioning P44x/EN CM/E33
4. PRODUCT CHECKS
These product checks cover all aspects of the relay that need to be checked to ensure that it
has not been physically damaged prior to commissioning, is functioning correctly and all
input quantity measurements are within the stated tolerances.
If the application-specific settings have been applied to the relay prior to commissioning, it is
advisable to make a copy of the settings so as to allow their restoration later. This could be
done by:
• Obtaining a setting file on a diskette from the customer (This requires a portable PC
with appropriate setting software for transferring the settings from the PC to the relay)
• Extracting the settings from the relay itself (This again requires a portable PC with
appropriate setting software)
• Manually creating a setting record. This could be done using a copy of the setting
record located at the end of this chapter to record the settings as the relay’s menu is
sequentially stepped through via the front panel user interface.
If password protection is enabled and the customer has changed password 2 that prevents
unauthorised changes to some of the settings, either the revised password 2 should be
provided, or the customer should restore the original password prior to commencement of
testing.
NOTE: In the event that the password has been lost, a recovery password
can be obtained from AREVA by quoting the serial number of the
relay. The recovery password is unique to that relay and will not work
on any other relay.
4.1 With the Relay De-energised
The following group of tests should be carried out without the auxiliary supply being applied
to the relay and with the trip circuit isolated.
The current and voltage transformer connections must be isolated from the relay for these
checks. If an MMLG test block is provided, the required isolation can easily be achieved by
inserting test plug type MMLB01 which effectively open-circuits all wiring routed through the
test block.
Before inserting the test plug, reference should be made to the scheme (wiring) diagram to
ensure that this will not potentially cause damage or a safety hazard. For example, the test
block may also be associated with protection current transformer circuits. It is essential that
the sockets in the test plug which correspond to the current transformer secondary windings
are linked before the test plug is inserted into the test block.
DANGER: NEVER OPEN CIRCUIT THE SECONDARY CIRCUIT OF A CURRENT
TRANSFORMER SINCE THE HIGH VOLTAGE PRODUCED MAY BE
LETHAL AND COULD DAMAGE INSULATION.
If a test block is not provided, the voltage transformer supply to the relay should be isolated
by means of the panel links or connecting blocks. The line current transformers should be
short-circuited and disconnected from the relay terminals. Where means of isolating the
auxiliary supply and trip circuit (e.g. isolation links, fuses, MCB, etc.) are provided, these
should be used. If this is not possible, the wiring to these circuits will have to be
disconnected and the exposed ends suitably terminated to prevent them from being a safety
hazard.
Commissioning P44x/EN CM/E33
A B C D E F
P3001ENa
A B C D E F G H J
IRIG-B
TX
RX
P3002ENa
A B C D E F G H J K L M N
1
1
1
1 2 3 19
2
2
3
3
3
4 5 6 20
4
4
5
5
5
IRIG-B
6
6
6
7 8 9 21
7
7
8
8
9
9
9
10 11 12 22
10
10
10
10
10
10
10
10
11
11
11
11
11
11
11
11
12
12
12
12
12
12
12
12
13 14 15 23
13
13
13
13
13
13
13
13
TX
RX
14
14
14
14
14
14
14
14
15
15
15
15
15
15
15
15
16 17 18 24
16
16
16
16
16
16
16
16
17
17
17
17
17
17
17
17
18
18
18
18
18
18
18
18
P3003ENa
2
3
20
4
4
5
6
21
7
8
9
10
11
12
22
10
11
12
13
14
15
23
13
14
16
17
18
24
15
16
17
18
Connection Terminal
K-Bus Modbus or VDEW P441 P442 P444
Screen Screen F16 J16 N16
1 +ve F17 J17 N17
2 –ve F18 J18 N18
The measured voltage values on the relay will either be in primary or secondary volts. If cell
[0D02: MEASURE’T SETUP, Local Values] is set to ‘Primary’, the values displayed on the
relay should be equal to the applied voltage multiplied by the corresponding voltage
transformer ratio set in the ‘VT and CT RATIOS’ menu column (see table 11). If cell [0D02:
MEASURE’T SETUP, Local Values] is set to ‘Secondary’, the value displayed should be
equal to the applied voltage.
The measurement accuracy of the relay is ±2%. However, an additional allowance must be
made for the accuracy of the test equipment being used.
5. SETTING CHECKS
The setting checks ensure that all of the application-specific relay settings (i.e. both the
relay’s function and programmable scheme logic settings) for the particular installation have
been correctly applied to the relay.
If the application-specific settings are not available, ignore sections 5.1 and 5.2.
5.1 Apply Application-Specific Settings
There are two methods of applying the settings:
• Transferring them from a pre-prepared setting file to the relay using a portable PC
running the appropriate software (see compatibility with S1 version in chapter VC) via
the relay’s front RS232 port, located under the bottom access cover, or rear
communications port (with a KITZ protocol converter connected). This method is the
preferred for transferring function settings as it is much faster and there is less margin
for error. If programmable scheme logic other than the default settings with which the
relay is supplied are to be used then this is the only way of changing the settings.
If a setting file has been created for the particular application and provided on a
diskette, this will further reduce the commissioning time and should always be the
case where programmable scheme logic changes are to be applied to the relay.
• Enter them manually via the relay’s operator interface. This method is not suitable for
changing the programmable scheme logic.
• Extract the settings from the relay using a portable PC running the appropriate
software via the front RS232 port, located under the bottom access cover, or rear
communications port (with a KITZ protocol converter connected). Compare the
settings transferred from the relay with the original written application-specific setting
record. (For cases where the customer has only provided a printed copy of the
required settings but a portable PC is available).
• Step through the settings using the relay’s operator interface and compare them with
the original application-specific setting record.
Unless previously agreed to the contrary, the application-specific programmable scheme
logic will not be checked as part of the commissioning tests.
Due to the versatility and possible complexity of the programmable scheme logic, it is
beyond the scope of these commissioning instructions to detail suitable test procedures.
Therefore, when programmable scheme logic tests must be performed, written tests which
will satisfactorily demonstrate the correct operation of the application-specific scheme logic
should be devised by the Engineer who created it. These should be provided to the
Commissioning Engineer together with the diskette containing the programmable scheme
logic setting file.
Commissioning P44x/EN CM/E33
AAAA
N.B. : Every action managed by a laptop, could be done as well by the LCD
front panel (only PSL and Text Editor use a computer)
IA 0,2 IN 0°
Currents IB 0,4 IN - 120°
IC 0,8 IN + 120°
TEST 1
VAN 30 V 0°
Voltages VBN 40 V - 120°
VCN 50 V + 120°
− Control the displayed values in the relay’s front face (LCD) : "system/meas1"
− Or primary values (control of ratios VT & CT) – If selected in MiCOM S1 – See Fig 3.
P44x/EN CM/E33 Commissioning
FIGURE 3
NB1 : Control the measurement reference (ref. angle of phase shift) in :
"Measurt set up/Measurement ref." (VA by default).
The monitoring can be selected also in MiCOM S1 for providing a polling of the network
parameters (I/U/P/Q/f…)
NB2 : In LCD : IN=3I0
After this step the mistakes on phases orders, ratios of CT, VT and
wiring (Analogic input only) will be detected.
NB3 : See connections drawing in P44x/EN CO
NB4 : See LCD structure in test tools
Commissioning P44x/EN CM/E33
IA IN 20°
Currents IB IN -100°
IC IN +140°
TEST 2
VAN 57 V 0°
Voltages VBN 57 V -120°
VCN 57 V +120°
− If one phase is missing the output Fuse Failure alarm will pick up & the led general
alarm in the front panel will light up (see FFU description P44x /EN AP)
Measurement mode 0 1 2 3
P + - + -
Q - - + +
Selected in S1 by:
W0002ENa
FIGURE 5
P P P P
i u u i u u i u u i u u
i i i i
Q Q Q Q
i u u i u u i u u i u u
i i i i P3014ENa
FIGURE 6
− Control the signs of values P,Q to LCD ("Measurements 2 ") – settable with LCD (see
figure 5)
The primary side orientation remains to be achieved (repeat
previously points with a primary injection)
See LCD Structure in chapter HI
Commissioning P44x/EN CM/E33
MEASURE'T SETUP
Default Display
Plant Reference
P3016ENa
− The Vphase voltage has to remain lower than the rated voltage value
Test of the impedance for zone 1 :
I1 = 1A
Rfault = R loop
Distance X
Xlim
E
Z
-Rlim ϕ Resistance R
Rlim
P3017ENa
• For phase to phase: Argument of the positive impedance of the line (Z1)
W0003ENa
W0004ENa
FIGURE 10 - EVOLVING IMPEDANCE FROM THE LOAD AREA TO THE FINAL FAULT IMPEDANCE IN
ZONE1
To simulate a default in a zone, it’s necessary to vary progressively the current to move the
point from the load area inside the desired zone.
A single-phase starting characteristic with different values of K0 can be created :
(K0x = (Zx0 - Z1) /(3 Z1) (See P44x /EN AP).
(In S1 there are up to four possibilities KZ1 & KZ2, KZp, KZ3/4)
This solution is carried in case of the underground cable/overhead line section (KZ1
different from KZ2 = KZp = KZ3/4) where arguments between Z01 & Z02 can be very
different (HV Line at 80° and cable at 45°).
Nevertheless the most common injection devices don’t offer the possibility to manage
several values of K0 (the same for ZGraph) ; so it will be necessary for an accurate control of
zones limits,to generate several characteristics files (as much Rio file as KZ values – ref to
ZGraph user ).
P44x/EN CM/E33 Commissioning
W0005ENa
W0006ENa
FIGURE 12
Commissioning P44x/EN CM/E33
In the characteristic above, the marked parts A, B et C are intersections between several
zones.
− Zp < Z4
− RpG ≤ R4G
− RpPh ≤ R4Ph
− The Z minimum value measured by the relay is: 60 mohms (Z1mini adjusted in S1, is
1ohm with CT 1Amp & 200 mohms with CT 5Amp)
− There is no limit for the R/X ratio, because a floating point processor is used for the R
calculation & X calculation (separated dynamic range for each calculation). In
consequence the limit will be given by the angle error of the CT.
For example in PUR with CT accuracy angle at 1° (for IN) it gives a R/X = 5,7 – for keeping
10% of error in the X1 measurement.
• Limit of R: min 0 /Max 80 ohms (CT 5Amp) – min 0/Max400 ohms (CT 1Amp)
• Limit of X: min0,2/100 ohms (CT 5Amp) – min1/Max 500 ohms (CT 1Amp)
P44x/EN CM/E33 Commissioning
− the voltage reference is the line to line voltage between phases, Uab for example;
− the reference current is the difference between the phases current, Ia - Ib for example;
W0007ENa
U12
Fault simulation = 2 x Zd + Rfault
I1
With :
U12 : fault voltage phase-to-phase
I1 : fault current
ϕ1 : fault angle
Rfault = R loop
For a triphase fault :
V1 Rfault
Fault simulation = Zd +
I1 2
With :
V1 : fault voltage phase-to-phase
I1 : fault current
ϕ1 : fault angle
Remark : With z graph’s help a Rio format characteristic can be created. This
Rio file can be loaded in a numeric injector which accept this kind of
files. The active settings (distance elements) can be modified by
Zgraph and relay can be upgraded with new distance parameters
For more precision refer to item: Test tools : "Z graph user "
Commissioning P44x/EN CM/E33
W0008ENa
FIGURE 13
Control of single-phase fault characteristic’
CAUTION : IF DIFFERENT K0 ARE USED – SEE § 5.3.1.2
1. Energise MiCOM P440 with a healthy 3phase network (without unbalanced condition)
with load (during a minimum time of 500 msec). This is for:
– Enabling the use of deltas algorithms
– Avoiding the start of SOTF logic (see SOTF logic description in P44x /EN AP)
2. Reduce the current value to obtain a relation between V et I following the attached
table (For Rlim – phase-shift at 0°, for Z limit – phase-shift corresponding to Z1 (in
multiphase default) or corresponding to 2Z1+Z0 (in single fault).
3. Check that the tripping order (DDB: Any trip / Any Trip A/ Any Trip B/ Any Trip C – see
in the chapter AP section 6.3 ”output contact mapping”, the description of DDB for
models 01 to 06) is transmitted when the concerned zone time delay is issued.(For
distance scheme with transmission and all distance trip logic see in P44x /EN AP).
NOTE : The DDB signal any Trip A is a OR gate between
Ext Trip A
Int Trip A
4. See as well the test report model provided in chapter RS Test tools.
5. Control also in the PSL (programmable scheme logic) the tripping orders addressing
(Any Trip is linked by default to the relay 7).
By default: see the wiring diagram in chapter CO (for assignment of inputs/outputs).
Usefultip: - For controlling the logic level of internal datas (DDB cells), all or part of the 8 red
led in the front panel could be assigned using the PSL.
P44x/EN CM/E33 Commissioning
LED 8
Z1
Z1 Latching
DDB #191 DDB #069
Z2
LED 7
Z2 Latching DDB #070
DDB #193
Non- LED 8
T2
T2
DDB #198 Latching DDB #071
P3018ENa
FIGURE 14
If Led are latched, the reset latch could be activated by a dedicated PSL, to avoid useless
keyboard access: during the tests :
P3019ENa
FIGURE 15
Usefultip: - For controlling the logic level of internal datas (DDB cells), monitor bit control can
be used in "commissioning Test/Opto/Relay/Test port status/Led status/Monitor bit1 to bit
8".Any cells from the DDB can be assigned and then displayed as 1 of the 8 bits.(See User
Tools )
NB1: See LCD structure in chapter HI
COMMISSION TESTS
Monitor Bit 1
Relay O/P Status 64
0000000000100
Monitor Bit 1 Monitor Bit 1
64 64
LED Status
00000000
P3020ENa
FIGURE 16 - LCD MENU FOR A CONTROL OF INPUT/OUTPUT/ & MONITOR BITS CONTROL
Commissioning P44x/EN CM/E33
W0009ENa
P44x/EN CM/E33 Commissioning
W0010ENa
If Z3 is deactivated, the resistance limits R3-R4 are not more visible in S1.
NOTE : All other characteristic point can be tested after having calculated the
impedance and the phase shift between U et I.
NOTE : All these examples use the default settings.
W0011ENa
W0012ENa
W0013ENa
Z3
Z2
Z1
- Rlim R1 R2 R3
-Zp
W0014ENa
• Ref to the description feature in P44x /EN AP item 2.4 & 2.5:
⇒ Settings in S1
⇒ DDB cells
1. From MiCOM S1, select a one of the mode in the table 5.6 in P44x /EN AP (last
column).
2. Implement the indicated default in the panel first column , The carrier signal input
being activated (with TAC).
3. Check the tripping contact have been energised at the issue of the indicated time
delay indicated in the same column (With TAC).
4. Repeat step 2 and 3 but without teleaction input and by checking the indicated time
delay in the panel’s 2nd column (Without TAC).
Repeat step 2 and 4 for the others zones defaults by checking, whatever the teleaction input
condition, the associated time delays to every zones are not modified (according to the 4th
column equations)
NOTE : – TAC can be simulated by inverting the opto.
– TAC transmissions can also be checked by generating
defaults according to the 3rd column.
– To make easy the relay I/O control condition, the LEDs
affectation in PSL can be modified. Another possibility is in S1 –
See Testing tools (monitor bit control).
Commissioning P44x/EN CM/E33
FIG WINF2
P44x/EN CM/E33 Commissioning
Put into service the weak infeed mode (Possibility of Single pole except for P441) ;
1. Inhibit tripping authorisation and phase selection.
2. Activate the teleaction input.
3. Check :
- the teleaction transmission signal is activated;
- the tripping contact is not activated.
From MiCOM S1, validate the three-phase authorisation.
FIGURE 21
1. Activate the teleaction input.
2. Check:
- the teleaction signal is activated ;
- the tripping contacts closing.
From MiCOM S1, validate the minimum voltage phase selection, set under voltage
threshold to 0,4 Vn, put VB = -VC = Vn, validate the single phase tripping
authorisation.
1. Activate the teleaction input.
2. Check :
- the teleaction transmission signal is activated;
- the protection trips the phase A single phase.
5.3.5 Protection function during fuse failure
See internal logic description in P44x /EN AP – item 4.2
Relay locking (1 or 2 phases loss)
1. Supply MiCOM P440 with a "healthy" network with charge:
2. Take off the A phase supply .((V0) & (/I0) creation)
3. Check :
- the fuse failure sign is activated at the end of the time delay sign;
- The protection starting and tripping sign are not activated.
Relay unlocking
1. Keep the A phase supply cut and make a fault (Single or two) of which the fault
current (IR>3I0) is superior to the programmed threshold.(I2 or I0)
2. Check the tripping contact is activated.
Relay locking (3 phases loss)
1. Repeat the 1 then open the 3 voltages channels without creating delta I. Check as in 3
Commissioning P44x/EN CM/E33
Outside sign :
1. Polarised the input : and check the outputs change condition :
Sign repercussions :
The sign (VT fail alarm) fall if :
Fuse_Failure = 0
and
INP_FFUS_Line = 0
and
(All Pole Dead Or healthy network)
All Pole Dead :
No current And no voltage on the line or open circuit-breaker
Healthy network :
Rated voltage on the line And
− No starting And
− No pumping
5.4 Demonstrate Correct Overcurrent Function Operation
This test, performed on stage 1 of the overcurrent protection function in setting group 1,
demonstrates that the relay is operating correctly at the application-specific settings.
It is not considered necessary to check the boundaries of operation where cell [3502:
GROUP 1 OVERCURRENT, I>1 Direction] is set to ‘Directional Fwd’ or ‘Directional Rev’ as
the test detailed already confirms the correct functionality between current and voltage
inputs, processor and outputs and earlier checks confirmed the measurement accuracy is
within the stated tolerance.
5.4.1 Connect the Test Circuit
Determine which output relay has been selected to operate when an I>1 trip occurs by
viewing the relay’s programmable scheme logic.
The programmable scheme logic can only be changed using the appropriate software. If this
software has not been available then the default output relay allocations will still be
applicable.
If the trip outputs are phase-segregated (i.e. a different output relay allocated for each
phase), the relay assigned for tripping on ‘A’ phase faults should be used.
If stage 1 is not mapped directly to an output relay in the programmable scheme logic, output
relay 3 should be used for the test as it operates for any trip condition.
The associated terminal numbers can be found either from the external connection diagram
(P44x/EN CO) or table 5.
Connect the output relay so that its operation will trip the test set and stop the timer.
Connect the current output of the test set to the ‘A’ phase current transformer input of the
relay (terminals C3 and C2 where 1A current transformers are being used and terminals C1
and C2 for 5A current transformers).
P44x/EN CM/E33 Commissioning
If [3502: GROUP 1 OVERCURRENT, I>1 Direction] is set to ‘Directional Fwd’, the current
should flow out of terminal C2 but into C2 if set to ‘Directional Rev’.
If cell [351D: GROUP 1 OVERCURRENT, VCO Status] is set to ‘Enabled’ (overcurrent
function configured for voltage controlled overcurrent operation) or [3502: GROUP 1
OVERCURRENT, I>1 Direction] has been set to ‘Directional Fwd’ or ‘Directional Rev’ then
rated voltage should be applied to terminals C19 and C22.
Ensure that the timer will start when the current is applied to the relay.
NOTE: If the timer does not start when the current is applied and stage 1 has
been set for directional operation, the connections may be incorrect
for the direction of operation set. Try again with the current
connections reversed.
5.4.2 Perform the Test
Ensure that the timer is reset.
Apply a current of twice the setting in cell [3503: GROUP 1 OVERCURRENT, I>1 Current
Set] to the relay and note the time displayed when the timer stops.
5.4.3 Check the Operating Time
Check that the operating time recorded by the timer is within the range shown in table 13.
NOTE: Except for the definite time characteristic, the operating times given in
table 13 are for a time multiplier or time dial setting of 1. Therefore, to
obtain the operating time at other time multiplier or time dial settings,
the time given in table 13 must be multiplied by the setting of cell
[3505: GROUP 1 OVERCURRENT, I>1 TMS] for IEC and UK
characteristics or cell [3506: GROUP 1 OVERCURRENT, Time Dial]
for IEEE and US characteristics.
In addition, for definite time and inverse characteristics there is an
additional delay of up to 0.02 second and 0.08 second respectively
that may need to be added to the relay’s acceptable range of
operating times.
For all characteristics, allowance must be made for the accuracy of
the test equipment being used.
6. ON-LOAD CHECKS
Remove all test leads, temporary shorting leads, etc. and replace any external wiring that
has been removed to allow testing.
If it has been necessary to disconnect any of the external wiring from the relay in order to
perform any of the foregoing tests, it should be ensured that all connections are replaced in
accordance with the relevant external connection or scheme diagram.
The following on-load measuring checks ensure the external wiring to the current and
voltage inputs is correct but can only be carried out if there are no restrictions preventing the
energisation of the plant being protected.
6.1 Voltage Connections
Using a multimeter measure the voltage transformer secondary voltages to ensure they are
correctly rated. Check that the system phase rotation is correct using a phase rotation
meter.
Compare the values of the secondary phase voltages with the relay’s measured values,
which can be found in the MEASUREMENTS 1 menu column.
If cell [0D02: MEASURE’T SETUP, Local Values] is set to ‘Secondary’, the values displayed
on the relay should be equal to the applied secondary voltage. The relay values should be
within 1% of the applied secondary voltages. However, an additional allowance must be
made for the accuracy of the test equipment being used.
If cell [0D02: MEASURE’T SETUP, Local Values] is set to ‘Primary’, the values displayed on
the relay should be equal to the applied secondary voltage multiplied the corresponding
voltage transformer ratio set in the ‘VT & CT RATIOS’ menu column (see table 14). Again
the relay values should be within 1% of the expected value, plus an additional allowance for
the accuracy of the test equipment being used.
7. FINAL CHECKS
The tests are now complete.
Remove all test or temporary shorting leads, etc. If it has been necessary to disconnect any
of the external wiring from the relay in order to perform the wiring verification tests, it should
be ensured that all connections are replaced in accordance with the relevant external
connection or scheme diagram.
Ensure that the relay has been restored to service by checking that cell [0F0D:
COMMISSIONING TESTS, Test Mode] is set to ‘Disabled’.
If the relay is in a new installation or the circuit breaker has just been maintained, the circuit
breaker maintenance and current counters should be zero. These counters can be reset
using cell [0608: CB CONDITION, Reset All Values]. If the required access level is not
active, the relay will prompt for a password to be entered so that the setting change can be
made.
If a MMLG test block is installed, remove the MMLB01 test plug and replace the MMLG
cover so that the protection is put into service.
Ensure that all event records, fault records, disturbance records, alarms and LEDs have
been reset before leaving the relay.
If applicable, replace the secondary front cover on the relay.
Commissioning P44x/EN CM/E33
8. MAINTENANCE
8.1 Maintenance Period
It is recommended that products supplied by AREVA T&D Protection & Control receive
regular monitoring after installation. As with all products some deterioration with time is
inevitable. In view of the critical nature of protective relays and their infrequent operation, it
is desirable to confirm that they are operating correctly at regular intervals.
AREVA protective relays are designed for a life in excess of 20 years.
MiCOM P440 distance relays are self-supervising and so require less maintenance than
earlier designs of relay. Most problems will result in an alarm so that remedial action can be
taken. However, some periodic tests should be done to ensure that the relay is functioning
correctly and the external wiring is intact.
If a Preventative Maintenance Policy exists within the customer’s organisation then the
recommended product checks should be included in the regular program. Maintenance
periods will depend on many factors, such as:
F E D C B A
Power supply
Relay board Input board Transformer board Not used IRIG-B board
board
J H G F E D C B A
Power supply
Relay board Relay board Opto board Not used Input board Transformer board Not used IRIG-B board
board
P3007XXa
A B C D E F G H J
IRIG-B
TX
RX
P3008XXa
ZN0007 C
SERIAL No.
P3009XXa
Refit the front panel using the reverse procedure to that given in section 8.3.2. After refitting
and closing the access covers on case sizes 60TE, press at the location of the hinge-
assistance T-pieces so that they click back into the front panel moulding.
Once the relay has been reassembled after repair, it should be recommissioned in
accordance with the instructions in sections 1 to 7 inclusive of this chapter.
8.3.2.3 Replacement of the input module
The input module comprises of two boards fastened together, the transformer board and the
input board.
The module is secured in the case by two screws on its right-hand side, accessible from the
front of the relay, as shown in figure 27. Remove these screws carefully as they are not
captive in the front plate of the module.
Input module
Handle
P3010ENa
P3011XXa
1
2 PL2
3 ZN0002 D
4
SERIAL No.
P3012XXa
P3013XXa
Ensure that the battery is securely held in its socket and that the battery terminals are
making good contact with the metal terminals of the socket.
Close the bottom access cover.
8.5.2 Post Modification Tests
To ensure that the replacement battery will maintain the time and status data if the auxiliary
supply fails, check cell [0806: DATE and TIME, Battery Status] reads ‘Healthy’.
8.5.3 Battery Disposal
The battery that has been removed should be disposed of in accordance with the disposal
procedure for Lithium batteries in the country in which the relay is installed.
P44x/EN CM/E33 Commissioning
BLANK PAGE
Commissioning Test & Record P44x/EN RS/E33
Sheets
COMMISSIONING TEST
& RECORD SHEETS
Commissioning Test & Record P44x/EN RS/E33
Sheets
CONTENT
BLANK PAGE
Commissioning Test & Record P44x/EN RS/E33
Sheets
Station Circuit
System Frequency
*Delete as appropriate
[ Phase CT Primary]
_______A/na*
Phase CT Ratio [ Phase CT Sec' y]
[ Mutual CT Primary]
_______A/na*
Mutual CT Ratio [ Mutual CT Sec' y]
[ Main VT Primary]
_______V/na*
Main VT Ratio [ Main VT Sec' y]
[ C/S VT Primary]
_______V/na*
C/S VT Ratio [ C/S VT Secondary]
[Main VT Primary]
_______V/na*
Main VT Ratio [Main VT Sec' y]
[C/S VT Primary]
_______V/na*
C/S VT Ratio [C/S VT Secondary]
[Phase CT Primary]
_______A/na*
Phase CT Ratio [Phase CT Sec' y]
[Mutual CT Primary]
_______A/na*
Mutual CT Ratio [Mutual CT Sec' y]
Date Date
Connection Diagrams P44x/EN CO/E33
CONNECTION DIAGRAMS
Connection Diagrams P44x/EN CO/E33
CONTENT
BLANK PAGE
1.
18
10.35 181.3 4.5 16 24
202.0 17 18
MiCOM P441/P442 & P444
200.0
IRIG-B
ALARM
OUT OF SERVICE
HEALTHY
= CLEAR
= READ
177.0 157.5 MAX.
= ENTER
TX
RX
THE TERMINATION POSITIONS
SHOWN ARE TYPICAL ONLY
SIDE VIEW
206.0 30.0
P44x/EN CO/E33
Page 3/12
DIRECTION OF FORWARD CURRENT FLOW
A
MiCOM P441 (PART)
F11
WATCHDOG
2.
P2 P1 F12 CONTACT
A F13
S2 S1 WATCHDOG
B F14 CONTACT
C B
Page 4/12
PHASE ROTATION E1
C
E2 RELAY 1
E3
MiCOM P441 (PART) E4 RELAY 2
C1 5A E5
IA E6 RELAY 3
C2 D1 E7
A B C
P44x/EN CO/E33
-
1A D2 OPTO 1 E8 RELAY 4
NOTE 4. C3 +
E9
C4 5A D3
N - E10
IB D4 OPTO 2
+ E11 RELAY 5
n C5 D5 E12
-
1A OPTO 3 E13
C6 D6
+ E14
a b c C7 5A D7 RELAY 6
- E15
IC
D8 OPTO 4 F17
+ E16
C8
D9 E17
1A - RELAY 7
C9 RS485
D10 OPTO 5 PORT F18 E18
C10 5A +
D11 B1
- F16
IM
SCN B2 RELAY 8
D12 OPTO 6
C11 + B3
SEE NOTE 2. SK2
1A D13 DATA READY 1 RELAY 9
C12 - B4
DIRECTION OF FORWARD CURRENT FLOW D14 OPTO 7 DATA 10 B5
+ ACKNOWLEDGE
A B6 RELAY 10
P2 P1 D15 EXTERNAL
- 16
A RESET B7
D16 OPTO 8
S2 S1 + DOWNLOAD B8
B 17 RELAY 11
D17 TEST/ COMMAND B9
C C B COMMON DOWNLOAD
PHASE ROTATION D18 DO-D7 2-9 B10
CONNECTION
B11 RELAY 12
PARALLEL LINE 11,12,15,13,
TO-T7 B12
PROTECTION 20,21,23,24
B13
0V 19,18,22,25
B14 RELAY 13
NOT B15
14
CONNECTED
MiCOM P441 – WIRING DIAGRAM (1/2)
B16
B17 RELAY 14
C19 1 SK1 B18
TX 2
RX 3
VA
4
SERIAL
0V 5
C20 PORT
6
CTS 7
RTS 8
VB
9
C21 *
F1
-
AC OR DC
Vx AUX SUPPLY +
F2
VC
C22
F7
+
C23
F8
+
48V DC FIELD
V BUSBAR VOLTAGE OUT F9
-
(SEE NOTE 3.)
NOTES 1. F10
C24 -
(a) C.T. SHORTING LINKS
CASE
EARTH
F F F F F F F F F E E E E E E E E E D D D D D D D D D C C C C C C C C C
1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 20 22 24
F F F F F F F F F E E E E E E E E E D D D D D D D D D C C C C C C C C C
2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 19 21 23
PL1 PL1
* * * *
SK2 SK1
PL3
BATTERY SERIAL TEST/DOWNLOAD
B B B B B B B B B
1 3 5 7 9 11 13 15 17
B B B B B B B B B
2 4 6 8 10 12 14 16 18
Page 5/12
12 OFF HOLES Æ3.4 3 TERMINAL BLOCK DETAIL 4.
23.25 116.55 142.45 1 2
1 19
Page 6/12
18
10.3 155.4 129.5 4.5
16 24
305.5 17 18
303.5
TRIP
IRIG-B
ALARM
OUT OF SERVICE
HEALTHY
= CLEAR 177.0
= READ
157.5 MAX.
= ENTER
TX
RX
TERMINAL BLOCKS -
309.6 30.0 SIDE VIEW SEE DETAIL
THE TERMINATION POSITIONS
SHOWN ARE TYPICAL ONLY
MiCOM P441/P442 & P444
Connection Diagrams
5.
A F1 J11
DIRECTION OF FORWARD CURRENT FLOW RELAY 15 WATCHDOG
F2 J12 CONTACT
P2 P1
A F3 J13
RELAY 16 WATCHDOG
S2 S1 F4 J14 CONTACT
B
C B F5 H1
C PHASE ROTATION RELAY 17 F6 H2 RELAY 1
F7 H3
MV PLATFORM F8 H4 RELAY 2
DISTANCE PROTECTION (PART) RELAY 18
C1 5A F9 H5
F10 H6 RELAY 3
IA
D1 RELAY 19 F11 H7
A B C C2 - F12 H8 RELAY 4
1A D2 OPTO 1
NOTE 4. C3 + F13 H9
C4 5A D3 F14 H10
N - RELAY 20
IB D4 OPTO 2 F15 H11
+ RELAY 5
n C5 D5 F16 H12
Connection Diagrams
- F17 H13
1A OPTO 3 RELAY 21
C6 D6
+ F18 H14 RELAY 6
a b c C7 5A D7 H15
IC - J17
D8 OPTO 4 H16
C8 +
H17
MiCOM P441/P442 & P444
D9 RELAY 7
1A - RS485
C9 PORT J18 H18
D10 OPTO 5
C10 5A + G1
D11 J16
SCN G2 RELAY 8
IM -
D12 OPTO 6 G3
C11 + SK2
SEE NOTE 2. DATA READY 1 RELAY 9
1A D13 G4
C12 - DATA
DIRECTION OF FORWARD CURRENT FLOW OPTO 7 10 G5
D14 ACKNOWLEDGE
+ G6 RELAY 10
A EXTERNAL
P2 P1 D15 16
- RESET G7
A P442
D16 OPTO 8 DOWNLOAD G8
S2 S1 + 17 RELAY 11
B TEST/ COMMAND G9
D17
C B
DOWNLOAD
C COMMON DO-D7 2-9 G10
PHASE ROTATION D18 CONNECTION G11 RELAY 12
11,12,15,13,
E1 TO-T7
PARALLEL LINE 20,21,23,24 G12
-
PROTECTION E2 OPTO 9 G13
+ 0V 19,18,22,25
G14 RELAY 13
E3
- NOT G15
E4 OPTO 10 14
CONNECTED G16
+
MiCOM P442 – WIRING DIAGRAM (1/2)
E5 G17
- RELAY 14
1 SK1 G18
C19 E6 OPTO 11
+ 2
TX
E7
- RX 3 2nd REAR COM 1 N.C.
E8 OPTO 12
VA + 4 2 RxD
SERIAL SK4 (OPTIONNAL)
E9 0V 5 3 TxD.
- PORT EIA485 -1(+ve)
C20 OPTO 13 6 DTR#
E10 4
+ CTS 7 5 0V
E11
- RTS 8 6 N.C.
VB E12 OPTO 14 9 EIA485 -2(-ve)
+ 7 RTS#
E13 8 CTS#
C21 - J1 *
OPTO 15 - 9 N.C.
E14 AC OR DC
+ Vx AUX SUPPLY J2
+
VC E15 TX
- FIBRE OPTIC
C22 E16 OPTO 16 J7 COMMUNICATION
+ +
(OPTIONAL)
C23 E17 J8 RX
+
COMMON 48V DC FIELD
E18 CONNECTION J9
V BUSBAR VOLTAGE OUT - IRIG-B INPUT
(SEE NOTE 3.) J10 (OPTIONAL)
NOTES 1. -
C24
MV PLATFORM
(a) C.T. SHORTING LINKS CASE
DISTANCE PROTECTION (PART)
EARTH
Page 7/12
6.
STANDARD INPUT MODULE GN0010 013 (110V)
J J J J J J J J J H H H H H H H H H F F F F F F F F F D D D D D D D D D C C C C C C C C C
1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 20 22 24
J J J J J J J J J H H H H H H H H H F F F F F F F F F D D D D D D D D D C C C C C C C C C
2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 19 21 23
Page 8/12
G G G G G G G G G E E E E E E E E E
1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17
G G G G G G G G G E E E E E E E E E BNC FIBRE OPTIC
2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18 TRANSDUCERS
Optical fiber +
RearCom2 + IRIGB (optional) RearCom2 (optional) IRIG-B PCB IRIG-B PCB
01 ZN0025001 01 ZN0025002 01 ZN0007 001 01 ZN0007 002
Rx1 Tx1
SK4 SK5 (unused) SK4 SK5 (unused)
1 3 5 7 9 1 3 5 7 9 1 3 5 7 9 1 3 5 7 9
2 4 6 8 2 4 6 8 2 4 6 8 2 4 6 8
P442
BOARD CONTAINS SALETY CRITICAL COMPONENTS.
* P3911ENa
MiCOM P441/P442 & P444
Connection Diagrams
7.
74.9 116.55 142.45 12 OFF HOLES Dia. 3.4 TERMINAL BLOCK DETAIL
3
1 2
1 19
HEAVY DUTY MEDIUM DUTY
4
159.0 168.0
18
62.0 155.4 129.5 FLUSH MOUNTING
PANEL CUT-OUT 16 24
17 18
MiCOM P441/P442 & P444
408.9 DETAIL.
406.9
TERMINAL SCREWS : M4 x 7 BRASS CHEESE HEAD SCREWS WITH LOCK WASHERS PROVIDED.
TRIP IRIG-B
ALARM
OUT OF SERVICE
HEALTHY
CLEAR
= 177.0 157.5 MAX.
= READ TX
RX
ENTER
=
16
TERMINAL BLOCKS -
SIDE VIEW SEE DETAIL
413.2 30.0
THE TERMINATION POSITIONS
SHOWN ARE TYPICAL ONLY
P44x/EN CO/E33
Page 9/12
8.
A
N11
DIRECTION OF FORWARD CURRENT FLOW WATCHDOG
N12 CONTACT
P2 P1
A N13
WATCHDOG
S2 S1 N14 CONTACT
B C B
PHASE ROTATION
C
J1 L1
MV PLATFORM J2 RELAY 25 L2 RELAY 9
Page 10/12
+ J8 RELAY 28 L8 RELAY 12
C4 5A D7
N - J9 L9
IB D8 OPTO 4
+ J10 RELAY 29 L10 RELAY 13
n C5 D9
- J11 L11
1A D10 OPTO 5
C6 + J12 RELAY 30 L12 RELAY 14
D11
a b c C7 5A - J13 L13
D12 OPTO 6
IC + N17 J14 L14
D13
RELAY 31 RELAY 15
C8 - J15 L15
D14 OPTO 7
1A + RS485 J16 L16
C9 D15 PORT N18
- J17 RELAY 32 L17 RELAY 16
C10 5A D16 OPTO 8
+ N16 J18 L18
IM D17 SCN
COMMON
C11 D18 CONNECTION
SEE NOTE 2. DATA READY 1 SK2
1A E1
C12 - DATA
DIRECTION OF FORWARD CURRENT FLOW E2 OPTO 9 10 P444
+ ACKNOWLEDGE
E3 EXTERNAL
A - 16 K1 M1
P2 P1 OPTO 10 RESET
E4 RELAY 17 RELAY 1
A + K2 M2
S2 S1 E5 DOWNLOAD
-
17 K3 M3
B TEST/ COMMAND
E6 OPTO 11 RELAY 18 RELAY 2
+ DOWNLOAD K4 M4
C C B DO-D7 2-9
E7
PHASE ROTATION - K5 M5
E8 OPTO 12 11,12,15,13, RELAY 19 RELAY 3
+ TO-T7 K6 M6
PARALLEL LINE E9 20,21,23,24
PROTECTION - K7 M7
E10 OPTO 13 RELAY 20 RELAY 4
+ 0V 19,18,22,25 K8 M8
E11 K9 M9
-
E12 OPTO 14 NOT RELAY 21 RELAY 5
14 K10 M10
+ CONNECTED
E13 K11 M11
-
E14 OPTO 15 RELAY 22 RELAY 6
K12 M12
MiCOM P444 – WIRING DIAGRAM (1/2)
+ SK1
C19 1
E15 K13 M13
- TX 2
E16 OPTO 16 K14 M14
+ RX 3 RELAY 23 RELAY 7
E17 K15 M15
VA COMMON 4
E18 CONNECTION SERIAL K16 M16
0V 5
F1 PORT K17 M17
C20 - 6 RELAY 24 RELAY 8
F2 OPTO 17 K18 M18
+ CTS 7
F3
- RTS 8
F4 OPTO 18 2nd REAR COM
VB + 9
F5 SK4 (OPTIONNAL) 1 N.C.
-
C21 F6 OPTO 19 N1 * 2 RxD
+ - TX
F7 AC OR DC 3 TxD.
- Vx AUX SUPPLY N2 EIA485 -1(+ve)
OPTO 20 + FIBRE OPTIC 4 DTR#
F8
VC + RX COMMUNICATION
F9 (OPTIONAL) 5 0V
C22 - N7
F10 OPTO 21 + 6 N.C.
C23 +
F11
N8 IRIG-B INPUT 7 RTS# EIA485 -2(-ve)
+
- 48V DC FIELD (OPTIONAL) CTS#
F12 OPTO 22 N9 8
V BUSBAR + VOLTAGE OUT -
9 N.C.
(SEE NOTE 3.) F13
NOTES 1. - N10 CASE
C24 OPTO 23
-
F14 EARTH
+
(a) C.T. SHORTING LINKS F15 MV PLATFORM
- DISTANCE PROTECTION (PART)
F16 OPTO 24
+
F17 POWER SUPPLY VERSION 24/54V D.C. ONLY
COMMON
*
(b) PIN TERMINAL (P.C.B. TYPE) F18 CONNECTION
N N N N N N N N N M M M M M M M M M L L L L L L L L L D D D D D D D D D C C C C C C C C C
1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 20 22 24
N N N N N N N N N M M M M M M M M M L L L L L L L L L D D D D D D D D D C C C C C C C C C
2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 19 21 23
* * * * *
Connection Diagrams
* * * * *
MAIN PROCESSOR & RELAY PCB UNIVERSEL OPTO UNIVERSEL OPTO
RELAY PCB INPUT PCB INPUT PCB
USER INTERLACE PCB CIRCUIT DIAG. CIRCUIT DIAG.
CIRCUIT DIAG. 01 ZN0006 01 01 Zn0019 01 CIRCUIT DIAG. CIRCUIT DIAG.
01 Zn0019 01 01 Zn0017 02 01 ZN0017 02
SK2 SK1
BATTERY SERIAL TEST/DOWNLOAD
J J J J J J J J J K K K K K K K K K F F F F F F F F F E E E E E E E E E
1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17 1 3 5 7 9 11 13 15 17
J J J J J J J J J K K K K K E K K K F F F F F F F F F E E E E E E E E E
2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18 2 4 6 8 10 12 14 16 18
MiCOM P444 – WIRING DIAGRAM (2/2)
P444
BOARD CONTAINS SALETY CRITICAL COMPONENTS.
BLANK PAGE
Configuration / Mapping P44x/EN GC/E33
CONFIGURATION /
MAPPING
P44x/EN GC/E33 Configuration / Mapping
Model number
P441-------09-C
P442-------09-C
P444-------09-C
For other models / software versions, please contact ALSTOM T&D Protection and
Control for the relevant information.
Configuration / Mapping P44x/EN GC/E33
Configuration / Mapping
This Chapter is split into several sections, these are as follows:
References
Chapter IT: Introduction : User Interface operation and connections to relay
Chapter CT: Communications: Overview of communication interfaces
Courier User Guide R6512
Modicon Modbus Protocol Reference Guide PI-MBUS-300 Rev. E
IEC60870-5-103 Telecontrol Equipment and Systems - Transmission Protocols –
Companion
Standard for the informative interface of Protection Equipment
Configuration / Mapping P44x/EN GC/E33
GROUP 3
PROTECTION SETTINGS
70 00 Repeat of Group 1 columns/rows 45000 46999
GROUP 4
PROTECTION SETTINGS
90 00 Repeat of Group 1 columns/rows 47000 48999
Configuration / Mapping P44x/EN GC/E33
G1 UNSIGNED INTEGER
eg. 5678 stored as 5678
G2 NUMERIC SETTING
See 50300.3110.004
G7 VTS Indicate/Block
0 Blocking
1 Indication
G11 YES/NO
0 No
1 Yes
G17 ACTIVE/INACTIVE
0 Card not fitted
1 Card failed
2 Signal healthy
3 No Signal
G19 LANGUAGE
0 English
1 Francais
2 Deutsch
3 Espanol
G32 Digital channel assignment this mapping depend of the model (P441 P442 P444)
0 8/16/24 Optos These are example values. Need one to be unassigned
to 14/21/32 Relays
8 Feedback
1024 72 - 1024 Internal Signals
G44 DIRECTION
0 Non-Directional
1 Directional Fwd
2 Directional Rev
G46 POLARISATION
0 Zero Sequence
1 Neg Sequence
G49 V0 INPUT
0 Measured
1 Derived
Configuration / Mapping P44x/EN GC/E33
G62 SAVE AS
0 No Operation
1 Save
2 Abort
2 User Set
3 Pulse Set
G71 PROTOCOL
0 Courier
1 IEC870-5-103
2 Modbus
G77 Auto-Reclose
0 Out of Service
1 In Service
G80 Visible/Invisible
0 Invisible
1 Visible
G88 Alarms
0 Alarm Disabled
1 Alarm Enabled
2 Group 3
3 Group 4
G92 Lockout
0 No Lockout
1 Lockout
G98 Copy to
0 No Operation
1 Group 1
2 Group 2
3 Group 3
4 Group 4
G99 CB Control
0 Disabled
1 Local
2 Remote
3 Local+Remote
4 Opto
5 Opto+local
6 Opto+Remote
7 Opto+Rem+local
G123 DIRECTION
0 Directional Fwd
1 Directional Rev
DDB_ENTRY (DDB_OUTPUT_LED_4 99 LED 4 Programmable LED 4 (By default GENERAL START) LED
DDB_ENTRY (DDB_OUTPUT_LED_5 100 LED 5 Programmable LED 5 (By default ZONE 1 + AIDED TRIP) LED
DDB_ENTRY (DDB_OUTPUT_LED_6 101 LED 6 Programmable LED 6 (By default FORWARD) LED
DDB_ENTRY (DDB_OUTPUT_LED_7 102 LED 7 Programmable LED 7 (By default REVERSE) LED
DDB_ENTRY (DDB_OUTPUT_LED_8 103 LED 8 Programmable LED 8 (By default AUTORECLOSE ENABLE) LED
DDB_ENTRY (DDB_INP_52A_A 104 CB Aux A (52-A) Circuit breaker pole A closed/Status input from CB PSL (IN) CB STATUS
DDB_ENTRY (DDB_INP_52B_A 105 CB Aux A (52-B) Circuit breaker pole A closed/Status input from CB PSL (IN) CB STATUS
DDB_ENTRY (DDB_INP_52A_B 106 CB Aux B (52-A) Circuit breaker pole A closed/Status input from CB PSL (IN) CB STATUS
DDB_ENTRY (DDB_INP_52B_B 107 CB Aux B (52-B) Circuit breaker pole A closed/Status input from CB PSL (IN) CB STATUS
DDB_ENTRY (DDB_INP_52A_C 108 CB Aux C (52-A) Circuit breaker pole A closed/Status input from CB PSL (IN) CB STATUS
DDB_ENTRY (DDB_INP_52B_C 109 CB Aux C (52-B) Circuit breaker pole A closed/Status input from CB PSL (IN) CB STATUS
DDB_ENTRY (DDB_INP_SPAR 110 SPAR Enable Enable internal single pole autorecloser PSL (IN) Autorecloser
DDB_ENTRY (DDB_INP_TPAR 111 TPAR Enable Enable internal three pole autorecloser PSL (IN) Autorecloser
DDB_ENTRY (DDB_INP_AR_INTERNAL 112 A/R Internal Give internal autorecloser present (visible) PSL (IN) Autorecloser
DDB_ENTRY (DDB_INP_AR_CYCLE_1P 113 A/R 1p In Prog. One-pole external autoreclose cycle in progress PSL (IN) Autorecloser
DDB_ENTRY (DDB_INP_AR_CYCLE_3P 114 A/R 3p In Prog. Three-pole external autoreclose cycle in progress PSL (IN) Autorecloser
DDB_ENTRY (DDB_INP_AR_CLOSING 115 A/R Close Circuit Breaker closing order from external autoreclose PSL (IN) Autorecloser
DDB_ENTRY (DDB_INP_RECLAIM 116 A/R Reclaim External autorecloser in reclaim PSL (IN) Autorecloser
DDB_ENTRY (DDB_INP_BAR 117 BAR Block internal autoreclose PSL (IN) Autorecloser
Autorisation signal from external check Synchroniser for
DDB_ENTRY (DDB_INP_CTL_CHECK_SYNCH 118 Ext Chk Synch OK PSL (IN) Autorecloser
reclosing with internal A/R
DDB_ENTRY (DDB_INP_CB_HEALTHY 119 CB Healthy Circuit breaker operational (gas pressure, mechanical state) PSL (IN) CB STATUS
Block all protection functions
DDB_ENTRY (DDB_INP_BLK_PROTECTION 120 BLK Protection PSL (IN) All protection
(21/67N/50/51/…)
DDB_ENTRY (DDB_INP_TRP_3P 121 Force 3P Trip Three pole tripping only PSL (IN)
DDB_ENTRY (DDB_INP_CB_MAN 122 Man. Close CB Circuit breaker manual close - order received PSL (IN) CB Status
DDB_ENTRY (DDB_INP_CB_TRIP_MAN 123 Man. Trip CB Circuit breaker manual trip - order received PSL (IN) CB Status
DDB_ENTRY (DDB_INP_DISC 124 CB Discrepancy CB Discrepancy (one pole open) PSL (IN) CB Status
DDB_ENTRY (DDB_INP_PROTA 125 External Trip A Phase A trip by external protection relay PSL (IN)
DDB_ENTRY (DDB_INP_PROTB 126 External Trip B Phase B trip by external protection relay PSL (IN)
DDB_ENTRY (DDB_INP_PROTC 127 External Trip C Phase C trip by external protection relay PSL (IN)
DDB_ENTRY (DDB_INP_CR 128 DIST. Chan Recv Signal receive on main channel (Distance) PSL (IN) Un-blocking logic
DDB_ENTRY (DDB_INP_CR_DEF 129 DEF. Chan Recv Signal receive on DEF channel PSL (IN) Un-blocking logic
Distance scheme channel out of service / Loss of Guard (Carrier
DDB_ENTRY (DDB_INP_COS 130 DIST. COS PSL (IN) Un-blocking logic
out of service)
DDB_ENTRY (DDB_INP_COS_DEF 131 DEF. COS DEF scheme channel out of service / Loss of Guard PSL (IN) Un-blocking logic
DDB_ENTRY (DDB_INP_Z1X_EXT 132 Z1X Extension Zone 1 Extension Input PSL (IN)
Fuse failure on busbar VT or MCB open (blocks voltage
DDB_ENTRY (DDB_INP_MCB_VTS_BUS 133 MCB/VTS Bus PSL (IN) VTS
dependant functions)
Fuse failure on line VT or MCB open (blocks voltage dependant
DDB_ENTRY (DDB_INP_MCB_VTS_LINE 134 MCB/VTS Line PSL (IN) VTS
functions)
DDB_ENTRY (DDB_INP_SBEF_TIMER_BLOCK_2 135 IN>1 Timer Block Block earth fault stage 1 time delay PSL (IN) Earth Fault
DDB_ENTRY (DDB_INP_SBEF_TIMER_BLOCK_3 136 IN>2 Timer Block Block earth fault stage 2 time delay PSL (IN) Earth Fault
DDB_ENTRY (DDB_INP_DEF_TIMER_BLOCK 137 DEF Timer Block Block aided DEF time delay PSL (IN) DEF
DDB_ENTRY (DDB_INP_PHOC_TIMER_BLOCK_1 138 I>1 Timer Block Block phase overcurrent stage 1 time delay PSL (IN) I>1
DDB_ENTRY (DDB_INP_PHOC_TIMER_BLOCK_2 139 I>2 Timer Block Block phase overcurrent stage 2 time delay PSL (IN) I>2
DDB_ENTRY (DDB_INP_PHOC_TIMER_BLOCK_3 140 I>3 Timer Block Block phase overcurrent stage 3 time delay PSL (IN) I>3
DDB_ENTRY (DDB_INP_PHOC_TIMER_BLOCK_4 141 I>4 Timer Block Block phase overcurrent stage 4 time delay PSL (IN) I>4
DDB_ENTRY (DDB_INP_NPS_TIMER_BLOCK 142 I2> Timer Block Block negative sequence overcurrent time delay PSL (IN) I>4
DDB_ENTRY (DDB_INP_UNDU_TIMER_BLOCK_1 143 V<1 Timer Block Block phase undervoltage stage 1 time delay PSL (IN) V<1
DDB_ENTRY (DDB_INP_UNDU_TIMER_BLOCK_2 144 V<2 Timer Block Block phase undervoltage stage 2 time delay PSL (IN) V<2
DDB_ENTRY (DDB_INP_OVEU_TIMER_BLOCK_1 145 V>1 Timer Block Block phase overvoltage stage 1 time delay PSL (IN) V>1
DDB_ENTRY (DDB_INP_OVEU_TIMER_BLOCK_2 146 V>2 Timer Block Block phase overvoltage stage 2 time delay PSL (IN) V>2
DDB_ENTRY (DDB_INP_DISTANCE_TIMER_BLOCK 147 DIST. Tim. Block Block distance element time delay PSL (IN) Distance
DDB_ENTRY (DDB_INP_CB_RESET_LOCKOUT 148 Reset Lockout CB monitoring lockout reset PSL (IN) CB Monitoring
DDB_ENTRY (DDB_INP_CB_RESET_ALL_VALUES 149 Reset All values Reset all values of CB monitoring PSL (IN) CB Monitoring
DDB_ENTRY (DDB_INP_RESET_RELAYS_LEDS 150 Reset Latches Reset all permanent alarms + led and relay lached PSl (IN)
Enable I>4 Element for stub bus protection (isolator of HV line
DDB_ENTRY (DDB_INP_STUB_BUS 151 Stub Bus Enable PSL (IN)
open - status isolator must be connected to an opto input)
DDB_ENTRY (DDB_INP_TRIP_A_USER 152 User Trip A Internal input for trip logic A PSL (IN) Trip Logic
DDB_ENTRY (DDB_INP_TRIP_B_USER 153 User Trip B Internal input for trip logic B PSL (IN) Trip Logic
DDB_ENTRY (DDB_INP_TRIP_C_USER 154 User Trip C Internal input for trip logic C PSL (IN) Trip Logic
DDB_ENTRY (DDB_INP_ZSP_TIMER_BLOCK 155 ZSP Timer Block Zero Sequence Power - Timer Block PSL (IN) ZSP
Configuration / Mapping P44x/EN GC/E33
DDB_ENTRY (DDB_ALARM_UNUSED0 160 Field Volt Fail Field voltage failure (48V DC for optos) PSL (OUT)
DDB_ENTRY (DDB_ALARM_PROT_DISABLED 162 Prot'n Disabled Test mode enabled - every protections out of order PSL(OUT) Commission Test
DDB_ENTRY (DDB_ALARM_F_OUT_OF_RANGE 163 F out of Range Frequency out of range PSL (OUT) Freq. Tracking
DDB_ENTRY (DDB_ALARM_VTS_SLOW 164 VT Fail Alarm Fuse failure indication (VT alarm) PSL (OUT) VT Supervision
DDB_ENTRY (DDB_ALARM_CTS 165 CT Fail Alarm Current transformers supervision indication PSL (OUT) CT Supervision
DDB_ENTRY (DDB_ALARM_BREAKER_FAIL 166 CB Fail Alarm Circuit breaker failure on any trip PSL (OUT) Breaker Fail
DDB_ENTRY (DDB_ALARM_I_BROK_MAINT 167 I^ Maint Alarm Broken current maintenance alarm (1st level) PSL (OUT) CB monitoring
DDB_ENTRY (DDB_ALARM_I_BROK_LOCKOUT 168 I^ Lockout Alarm Broken current lockout alarm (2nd level) PSL (OUT) CB monitoring
DDB_ENTRY (DDB_ALARM_CB_OPS_MAINT 169 CB Ops Maint Alarm on number of circuit breaker operations PSL (OUT) CB monitoring
DDB_ENTRY (DDB_ALARM_CB_OPS_LOCKOUT 170 CB Ops Lockout Lockout on number of circuit breaker operations PSL (OUT) CB monitoring
DDB_ENTRY (DDB_ALARM_CB_OP_TIME_MAINT 171 CB Op Time Maint Alarm on CB excessive operating time PSL (OUT) CB monitoring
DDB_ENTRY (DDB_ALARM_CB_OP_TIME_LOCKOUT 172 CB Op Time Lock CB locked out due to excessive operating time PSL (OUT) CB monitoring
Excessive Fault Frequency CB Trip pre lockout Alarm (number of
DDB_ENTRY (DDB_ALARM_PRE_LOCKOUT 173 F.F. Pre Lockout PSL (OUT) CB monitoring
fault maxi)
DDB_ENTRY (DDB_ALARM_EFF_LOCKOUT 174 F.F. Lock Excessive Fault Frequency CB Trip Lockout Alarm PSL (OUT) CB monitoring
DDB_ENTRY (DDB_LOCKOUT_ALARM 175 Lockout Alarm Lockout Alarm PSL (OUT) CB monitoring
DDB_ENTRY (DDB_ALARM_CB_STATUS 176 CB Status Alarm Discrepancy in status of 52a and 52b auxiliary contacts PSL (OUT) CB Status
DDB_ENTRY (DDB_ALARM_CB_FAIL_TRIP 177 Man CB Trip Fail CB fail on manual trip PSL (OUT) CB control
DDB_ENTRY (DDB_ALARM_CB_FAIL_CLOSE 178 Man CB Cls Fail CB fail on manual close PSL (OUT) CB control
DDB_ENTRY (DDB_ALARM_CB_CONTROL_UNHEALTHLY 179 Man CB Unhealthy CB unhealthy for manual control PSL (OUT) CB control
DDB_ENTRY (DDB_ALARM_NO_CHECK_SYNC_CONTROL 180 Control No C/S No internal check synchronism available PSL (OUT) CB control
DDB_ENTRY (DDB_ALARM_AR_LOCKOUT_MAX_SHOTS 181 AR Lockout Shot> Autoreclose lockout following final programmed attempt PSL (OUT) Autorecloser
DDB_ENTRY (DDB_ALARM_SG_OPTO_INVALID 182 SG-opto Invalid Setting group selected via opto (1 & 2 only) input invalid PSL (OUT)
DDB_ENTRY (DDB_ALARM_CB_FAIL_AR 183 A/R Fail No check sync / autorecloser failed PSL (OUT) Autorecloser
DDB_ENTRY (DDB_ALARM_UNDER_V_1 184 V<1 Alarm 1st stage undervoltage alarm PSL (OUT) V<1
DDB_ENTRY (DDB_ALARM_UNDER_V_2 185 V<2 Alarm 2nd stage undervoltage alarm PSL (OUT) V<2
DDB_ENTRY (DDB_ALARM_OVER_V_1 186 V>1 Alarm 1st stage overvoltage alarm PSL (OUT) V>1
DDB_ENTRY (DDB_ALARM_OVER_V_2 187 V>2 Alarm 2nd stage overvoltage alarm PSL (OUT) V>2
DDB_ENTRY (DDB_ALARM_COS 188 COS Alarm HF carrier anomaly alarm PSL(OUT) Unblocking logic
DDB_ENTRY (DDB_ALARM_BROKEN_COND 189 Brok. Cond. Alarm broken Conductor Alarm PSL(OUT) Broken conductor
DDB_ENTRY (DDB_ALARM_CVTS 190 User Alarm User-definable alarm (application customized) PSL (IN)
DDB_ENTRY (DDB_PRT_AR_CLOSE 223 A/R Close Autorecloser Close command to CB PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_1POLE_IN_PROG 224 A/R 1P In Prog One-pole autoreclose cycle in progress PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_3POLE_IN_PROG 225 A/R 3P In Prog Three-pole autoreclose cycle in progress PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_1ST_CYCLE_IN_PROG 226 A/R 1st In Prog First high speed autoreclose cycle in progress PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_234TH_CYCLE_IN_PROG 227 A/R 234 In Prog Further autoreclose cycles in progress PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_TRIP_3PH 228 A/R Trip 3P Autorecloser signal to force all trips to be 3 Ph PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_RECLAIM 229 A/R Reclaim Reclaim timer timeout in progress PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_DISCRIM 230 AR Discrim. Discrim. Time window in progress PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_ENABLE 231 A/R Enable Autorecloser enabled / in service PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_1PAR_ENABLE 232 A/R SPAR Enable Single pole autorecloser activated PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_3PAR_ENABLE 233 A/R TPAR Enable Three pole autorecloser activated PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_LOCKOUT 234 A/R Lockout Autorecloser locked-out (no autoreclosure possible until reset) PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_AR_FORCE_SYNC 235 A/R Force Sync. Force synchronism check to be made PSL (OUT) Autorecloser
DDB_ENTRY (DDB_PRT_SYNC 236 Check Synch. OK Check Synchronism conditions satisfied PSL (OUT) Synchro Check
DDB_ENTRY (DDB_PRT_DEAD_LINE 237 V< Dead Line Check Synch. Dead Line PSL (OUT) Synchro Check
DDB_ENTRY (DDB_PRT_LIVE_LINE 238 V> Live Line Check Synch. Live Line PSL (OUT) Synchro Check
DDB_ENTRY (DDB_PRT_DEAD_BUS 239 V< Dead Bus Check Synch. Dead Bus PSL (OUT) Synchro Check
DDB_ENTRY (DDB_PRT_LIVE_BUS 240 V> Live Bus Check Synch. Live Bus PSL (OUT) Synchro Check
DDB_ENTRY (DDB_PRT_CONTROL_CLOSE_IN_PROG 241 Ctrl Cls In Prog Manual (control) close in progress PSL (OUT) CB Control
DDB_ENTRY (DDB_PRT_CARRIER_SEND 242 DIST Sig. Send Distance protection schemes - Signal Send PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_UNB_CR 243 DIST UNB CR Unblock main channel received PSL(OUT) Unblocking Logic
DDB_ENTRY (DDB_PRT_DIST_FWD 244 DIST Fwd Distance protection: Forward fault detected PSL (OUT) Distance
Configuration / Mapping P44x/EN GC/E33
DDB_ENTRY (DDB_PRT_DIST_REV 245 DIST Rev Distance protection: Reverse fault detected PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_DIST_TRIP_A 246 DIST Trip A Distance protection: Phase A trip PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_DIST_TRIP_B 247 DIST Trip B Distance protection: Phase B trip PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_DIST_TRIP_C 248 DIST Trip C Distance protection: Phase C trip PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_DIST_START_A 249 DIST Start A Distance protection started on phase A PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_DIST_START_B 250 DIST Start B Distance protection started on phase B PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_DIST_START_C 251 DIST Start C Distance protection started on phase C PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_DIST_CR_ACC 252 DIST Sch. Accel. Distance scheme Accelerating PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_DIST_CR_PERM 253 DIST Sch. Perm. Distance scheme Permissive PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_DIST_CR_BLOCK 254 DIST Sch. Block. Distance scheme Blocking PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_Z1X 256 Z1X Fault in zone 1 extended PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_T1 261 T1 Timer in zone 1 elapsed (at 1 = end of timer) PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_T2 262 T2 Timer in zone 2 elapsed (at 1 = end of timer) PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_T3 263 T3 Timer in zone 3 elapsed (at 1 = end of timer) PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_T4 264 T4 Timer in zone 4 elapsed (at 1 = end of timer) PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_TZP 265 Tzp Timer in zone p elapsed (at 1 = end of timer) PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_WI_TRIP_A 266 WI Trip A Phase A trip on weak infeed PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_WI_TRIP_B 267 WI Trip B Phase B trip on weak infeed PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_WI_TRIP_C 268 WI Trip C Phase C trip on weak infeed PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_POWER_SWING 269 Power Swing Power swing detected PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_REVERSAL_GUARD 270 Reversal Guard Current reversal guard logic in action PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_DEF_CARRIER_SEND 271 DEF Sig. Send DEF protection schemes - Signal Send PSL (OUT) Aided DEF
DDB_ENTRY (DDB_PRT_UNB_CR_DEF 272 DEF UNB CR Unblock DEF channel PSL (OUT) Unblocking logic
DDB_ENTRY (DDB_PRT_DEF_REV 273 DEF Rev Channel Aided DEF: reverse fault PSL (OUT) Aided DEF
DDB_ENTRY (DDB_PRT_DEF_FWD 274 DEF Fwd Channel Aided DEF: forward fault PSL (OUT) Aided DEF
DDB_ENTRY (DDB_PRT_DEF_START_AN 275 DEF Start A Channel Aided DEF: start phase A PSL (OUT) Aided DEF
DDB_ENTRY (DDB_PRT_DEF_START_BN 276 DEF Start B Channel Aided DEF: start phase B PSL (OUT) Aided DEF
DDB_ENTRY (DDB_PRT_DEF_START_CN 277 DEF Start C Channel Aided DEF: start phase C PSL (OUT) Aided DEF
DDB_ENTRY (DDB_PRT_DEF_TRIP_A 278 DEF Trip A Channel Aided DEF: trip phase A PSL (OUT) Aided DEF
DDB_ENTRY (DDB_PRT_DEF_TRIP_B 279 DEF Trip B Channel Aided DEF: trip phase B PSL (OUT) Aided DEF
DDB_ENTRY (DDB_PRT_DEF_TRIP_C 280 DEF Trip C Channel Aided DEF: trip phase C PSL (OUT) Aided DEF
DDB_ENTRY (DDB_PRT_IN_SUP_2_TRIP 281 IN>1 Trip Earth fault stage 1 trip PSL (OUT) Earth Fault 1
DDB_ENTRY (DDB_PRT_IN_SUP_3_TRIP 282 IN>2 Trip Earth fault stage 2 trip PSL (OUT) Earth Fault 2
DDB_ENTRY (DDB_PRT_IN_SUP_2_PICK_UP 283 IN>1 Start Earth fault stage 1 start PSL (OUT) Earth Fault 1
DDB_ENTRY (DDB_PRT_IN_SUP_3_PICK_UP 284 IN>2 Start Earth fault stage 2 start PSL (OUT) Earth Fault 2
DDB_ENTRY (DDB_PRT_UNDER_V_ANY_PICK_UP_A 285 V< Start Any A Any undervoltage start detected on phase A PSL (OUT) Undervoltage
DDB_ENTRY (DDB_PRT_UNDER_V_ANY_PICK_UP_B 286 V< Start Any B Any undervoltage start detected on phase B PSL (OUT) Undervoltage
DDB_ENTRY (DDB_PRT_UNDER_V_ANY_PICK_UP_C 287 V< Start Any C Any undervoltage start detected on phase C PSL (OUT) Undervoltage
DDB_ENTRY (DDB_PRT_UNDER_V_1_PICK_UP 288 V<1 Start Undervoltage stage 1 start PSL (OUT) Undervoltage
DDB_ENTRY (DDB_PRT_UNDER_V_2_PICK_UP 289 V<2 Start Undervoltage stage 2 start PSL (OUT) Undervoltage
DDB_ENTRY (DDB_PRT_UNDER_V_1_TRIP 290 V<1 Trip Undervoltage stage 1 trip PSL (OUT) Undervoltage
DDB_ENTRY (DDB_PRT_UNDER_V_2_TRIP 291 V<2 Trip Undervoltage stage 2 trip PSL (OUT) Undervoltage
DDB_ENTRY (DDB_PRT_OVER_V_ANY_PICK_UP_A 292 V> Start Any A Any overvoltage start detected on phase A PSl (OUT) Overvoltage
DDB_ENTRY (DDB_PRT_OVER_V_ANY_PICK_UP_B 293 V> Start Any B Any overvoltage start detected on phase B PSl (OUT) Overvoltage
DDB_ENTRY (DDB_PRT_OVER_V_ANY_PICK_UP_C 294 V> Start Any C Any overvoltage start detected on phase C PSl (OUT) Overvoltage
DDB_ENTRY (DDB_PRT_OVER_V_1_PICK_UP 295 V>1 Start Overvoltage stage 1 start PSl (OUT) Overvoltage
DDB_ENTRY (DDB_PRT_OVER_V_2_PICK_UP 296 V>2 Start Overvoltage stage 2 start PSl (OUT) Overvoltage
DDB_ENTRY (DDB_PRT_OVER_V_1_TRIP 297 V>1 Trip Overvoltage stage 1 trip PSl (OUT) Overvoltage
DDB_ENTRY (DDB_PRT_OVER_V_2_TRIP 298 V>2 Trip Overvoltage stage 2 trip PSl (OUT) Overvoltage
DDB_ENTRY (DDB_PRT_I2_SUP_PICK_UP 299 I2> Start Negative Sequence Current Start PSL (OUT) Neg Seq. O/C
DDB_ENTRY (DDB_PRT_I2_SUP_TRIP 300 I2> Trip Negative Sequence Current Trip PSL (OUT) Neg Seq. O/C
DDB_ENTRY (DDB_PRT_I_SUP_ANY_PICK_UP_A 301 I> Start Any A Any overcurrent start for phase A PSL (OUT) Phase Overc.
DDB_ENTRY (DDB_PRT_I_SUP_ANY_PICK_UP_B 302 I> Start Any B Any overcurrent start for phase B PSL (OUT) Phase Overc.
Configuration / Mapping P44x/EN GC/E33
DDB_ENTRY (DDB_PRT_I_SUP_ANY_PICK_UP_C 303 I> Start Any C Any overcurrent start for phase C PSL (OUT) Phase Overc.
DDB_ENTRY (DDB_PRT_I_SUP_1_PICK_UP 304 I>1 Start Overcurrent stage 1 start PSL (OUT) Phase Overc.
DDB_ENTRY (DDB_PRT_I_SUP_2_PICK_UP 305 I>2 Start Overcurrent stage 2 start PSL (OUT) Phase Overc.
DDB_ENTRY (DDB_PRT_I_SUP_3_PICK_UP 306 I>3 Start Overcurrent stage 3 start PSL (OUT) Phase Overc.
DDB_ENTRY (DDB_PRT_I_SUP_4_PICK_UP 307 I>4 Start Overcurrent stage 4 start PSL (OUT) Phase Overc.
DDB_ENTRY (DDB_PRT_I_SUP_1_TRIP 308 I>1 Trip Overcurrent stage 1 trip PSL (OUT) Phase Overc.
DDB_ENTRY (DDB_PRT_I_SUP_2_TRIP 309 I>2 Trip Overcurrent stage 2 trip PSL (OUT) Phase Overc.
DDB_ENTRY (DDB_PRT_I_SUP_3_TRIP 310 I>3 Trip Overcurrent stage 3 trip PSL (OUT) Phase Overc.
DDB_ENTRY (DDB_PRT_I_SUP_4_TRIP 311 I>4 Trip Overcurrent stage 4 trip PSL (OUT) Phase Overc.
DDB_ENTRY (DDB_PRT_SOTF_ENABLE 312 SOTF Enable Switch On To Fault enable PSL (OUT) SOTF
DDB_ENTRY (DDB_PRT_I_TOR_ENABLE 313 TOR Enable Trip On Reclose enable PSL (OUT) TOR
DDB_ENTRY (DDB_PRT_TOC_START_A 314 TOC Start A Trip on Close start on phase A PSL (OUT) SOTF
DDB_ENTRY (DDB_PRT_TOC_START_B 315 TOC Start B Trip on Close start on phase B PSL (OUT) SOTF
DDB_ENTRY (DDB_PRT_TOC_START_C 316 TOC Start C Trip on Close start on phase C PSL (OUT) SOTF
DDB_ENTRY (DDB_PRT_ANY_START 317 Any start Any protection start PSL (OUT) All protection
DDB_ENTRY (DDB_PRT_1PH 318 1ph Fault Single phase fault PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_2PH 319 2ph Fault Two phase fault PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_3PH 320 3ph Fault Three phase fault PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_ANY_TRIP 321 Any Trip Single or three pole trip or external protection trip PSL (OUT) All protection
DDB_ENTRY (DDB_PRT_ANY_INTERNAL_TRIP_A 322 Any Int. Trip A Any internal protection A phase trip PSL (OUT) All protection
DDB_ENTRY (DDB_PRT_ANY_INTERNAL_TRIP_B 323 Any Int. Trip B Any internal protection B phase trip PSL (OUT) All protection
DDB_ENTRY (DDB_PRT_ANY_INTERNAL_TRIP_C 324 Any Int. Trip C Any internal protection C phase trip PSL (OUT) All protection
DDB_ENTRY (DDB_PRT_ANY_TRIP_A 325 Any Trip A Any trip A (internal or external protection) PSL (OUT) All protection
DDB_ENTRY (DDB_PRT_ANY_TRIP_B 326 Any Trip B Any trip B (internal or external protection) PSL (OUT) All protection
DDB_ENTRY (DDB_PRT_ANY_TRIP_C 327 Any Trip C Any trip C (internal or external protection) PSL (OUT) All protection
DDB_ENTRY (DDB_PRT_1P_TRIP 328 1P Trip Single pole trip (internal or external) PSL (OUT) All protection
DDB_ENTRY (DDB_PRT_3P_TRIP 329 3P Trip Three pole trip (internal or external) PSL (OUT) All protection
DDB_ENTRY (DDB_PRT_BROKEN_CONDUCTOR_TRIP 330 Brk.Conduct.Trip Broken conductor trip PSL (OUT) Broken Cond.
DDB_ENTRY (DDB_PRT_LOSS_OF_LOAD_TRIP 331 Loss. Load Trip Loss of load trip PSL (OUT) Loss of load
DDB_ENTRY (DDB_PRT_SOTF_TOR_TRIP 332 SOTF/TOR Trip Switch on to fault trip or trip on reclose PSL (OUT) SOTF
DDB_ENTRY (DDB_PRT_TBF1_TRIP_3PH 333 tBF1 Trip Breaker fail trip from tBF1 PSL (OUT) Breaker failure
DDB_ENTRY (DDB_PRT_TBF2_TRIP_3PH 334 tBF2 Trip Breaker fail trip from tBF2 PSL (OUT) Breaker failure
DDB_ENTRY (DDB_PRT_CONTROL_TRIP 335 Control Trip Control trip command from user PSL (OUT) CB control
DDB_ENTRY (DDB_PRT_CONTROL_CLOSE 336 Control Close Control close command from user PSL (OUT) CB control
DDB_ENTRY (DDB_PRT_VTS_FAST 337 VTS Fast Unstantaneous unconfirmed fuse failure internal detection PSL (OUT) VTS
DDB_ENTRY (DDB_PRT_ANY_POLE_DEAD 341 Any Pole Dead Any circuit breaker pole dead (one or more poles open) PSL (OUT) Poledead
DDB_ENTRY (DDB_PRT_ALL_POLE_DEAD 342 All Pole Dead All circuit breaker poles dead (breaker open 3 phase) PSL (OUT) Poledead
DDB_ENTRY (DDB_PRT_DIR_AV_WIT_FILT 343 DIST Fwd No Filt Distance protection: Forward fault detected not filtered PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_DIR_AM_WIT_FILT 344 DIST Rev No Filt Distance protection: Reverse fault detected not filtered PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_CVMR 345 DIST Convergency Distance protection: Internal characteristic PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_CROSS_COUNTRY 346 Cross Count. Flt Cross Country Fault PSL (OUT) Distance
DDB_ENTRY (DDB_PRT_ZSP_START 347 ZSP Start Zero Sequence Power - Start PSL (OUT) ZSP
DDB_ENTRY (DDB_PRT_ZSP_TRIP 348 ZSP Trip Zero Sequence Power - Trip PSL (OUT) ZSP
DDB_ENTRY (DDB_OUTPUT_CON_1 364 Relay 1 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_2 365 Relay 2 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_3 366 Relay 3 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_4 367 Relay 4 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_5 368 Relay 5 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_6 369 Relay 6 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_7 370 Relay 7 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_8 371 Relay 8 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_9 372 Relay 9 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_10 373 Relay 10 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_11 374 Relay 11 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_12 375 Relay 12 PSL Input Equivalent to Relay Output Condition PSL
Configuration / Mapping P44x/EN GC/E33
DDB_ENTRY (DDB_OUTPUT_CON_13 376 Relay 13 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_14 377 Relay 14 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_15 378 Relay 15 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_16 379 Relay 16 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_17 380 Relay 17 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_18 381 Relay 18 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_19 382 Relay 19 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_20 383 Relay 20 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_21 384 Relay 21 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_22 385 Relay 22 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_23 386 Relay 23 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_24 387 Relay 24 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_25 388 Relay 25 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_26 389 Relay 26 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_27 390 Relay 27 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_28 391 Relay 28 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_29 392 Relay 29 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_30 393 Relay 30 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_31 394 Relay 31 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_32 395 Relay 32 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_33 396 Relay 33 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_34 397 Relay 34 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_35 398 Relay 35 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_36 399 Relay 36 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_37 400 Relay 37 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_38 401 Relay 38 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_39 402 Relay 39 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_40 403 Relay 40 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_41 404 Relay 41 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_42 405 Relay 42 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_43 406 Relay 43 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_44 407 Relay 44 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_45 408 Relay 45 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_46 409 Relay 46 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_47 410 Relay 47 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_48 411 Relay 48 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_49 412 Relay 49 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_50 413 Relay 50 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_51 414 Relay 51 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_52 415 Relay 52 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_53 416 Relay 53 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_54 417 Relay 54 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_55 418 Relay 55 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_56 419 Relay 56 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_57 420 Relay 57 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_58 421 Relay 58 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_59 422 Relay 59 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_60 423 Relay 60 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_61 424 Relay 61 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_62 425 Relay 62 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_63 426 Relay 63 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_OUTPUT_CON_64 427 Relay 64 PSL Input Equivalent to Relay Output Condition PSL
DDB_ENTRY (DDB_LED_CON_1 428 LED Con IN 1 PSL Input Equivalent to LED Output Condition PSL
DDB_ENTRY (DDB_LED_CON_2 429 LED Con IN 2 PSL Input Equivalent to LED Output Condition PSL
DDB_ENTRY (DDB_LED_CON_3 430 LED Con IN 3 PSL Input Equivalent to LED Output Condition PSL
DDB_ENTRY (DDB_LED_CON_4 431 LED Con IN 4 PSL Input Equivalent to LED Output Condition PSL
DDB_ENTRY (DDB_LED_CON_5 432 LED Con IN 5 PSL Input Equivalent to LED Output Condition PSL
DDB_ENTRY (DDB_LED_CON_6 433 LED Con IN 6 PSL Input Equivalent to LED Output Condition PSL
Configuration / Mapping P44x/EN GC/E33
DDB_ENTRY (DDB_LED_CON_7 434 LED Con IN 7 PSL Input Equivalent to LED Output Condition PSL
DDB_ENTRY (DDB_LED_CON_8 435 LED Con IN 8 PSL Input Equivalent to LED Output Condition PSL
DDB_ENTRY (DDB_TIMERIN_1 436 Timer in 1 PSL Input from Auxiliary Timer 1 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_2 437 Timer in 2 PSL Input from Auxiliary Timer 2 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_3 438 Timer in 3 PSL Input from Auxiliary Timer 3 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_4 439 Timer in 4 PSL Input from Auxiliary Timer 4 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_5 440 Timer in 5 PSL Input from Auxiliary Timer 5 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_6 441 Timer in 6 PSL Input from Auxiliary Timer 6 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_7 442 Timer in 7 PSL Input from Auxiliary Timer 7 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_8 443 Timer in 8 PSL Input from Auxiliary Timer 8 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_9 444 Timer in 9 PSL Input from Auxiliary Timer 9 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_10 445 Timer in 10 PSL Input from Auxiliary Timer 10 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_11 446 Timer in 11 PSL Input from Auxiliary Timer 11 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_12 447 Timer in 12 PSL Input from Auxiliary Timer 12 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_13 448 Timer in 13 PSL Input from Auxiliary Timer 13 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_14 449 Timer in 14 PSL Input from Auxiliary Timer 14 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_15 450 Timer in 15 PSL Input from Auxiliary Timer 15 Auxiliary Timer
DDB_ENTRY (DDB_TIMERIN_16 451 Timer in 16 PSL Input from Auxiliary Timer 16 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_1 452 Timer out 1 PSL Ouput from Auxiliary Timer 1 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_2 453 Timer out 2 PSL Ouput from Auxiliary Timer 2 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_3 454 Timer out 3 PSL Ouput from Auxiliary Timer 3 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_4 455 Timer out 4 PSL Ouput from Auxiliary Timer 4 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_5 456 Timer out 5 PSL Ouput from Auxiliary Timer 5 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_6 457 Timer out 6 PSL Ouput from Auxiliary Timer 6 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_7 458 Timer out 7 PSL Ouput from Auxiliary Timer 7 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_8 459 Timer out 8 PSL Ouput from Auxiliary Timer 8 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_9 460 Timer out 9 PSL Ouput from Auxiliary Timer 9 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_10 461 Timer out 10 PSL Ouput from Auxiliary Timer 10 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_11 462 Timer out 11 PSL Ouput from Auxiliary Timer 11 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_12 463 Timer out 12 PSL Ouput from Auxiliary Timer 12 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_13 464 Timer out 13 PSL Ouput from Auxiliary Timer 13 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_14 465 Timer out 14 PSL Ouput from Auxiliary Timer 14 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_15 466 Timer out 15 PSL Ouput from Auxiliary Timer 15 Auxiliary Timer
DDB_ENTRY (DDB_TIMEROUT_16 467 Timer out 16 PSL Ouput from Auxiliary Timer 16 Auxiliary Timer
Part F - DNP3
X Object name Event Class P444 P442 P441
H
D DDB_OUTPUT_RELAY_1 2 0 0 0
D DDB_OUTPUT_RELAY_2 2 1 1 1
D DDB_OUTPUT_RELAY_3 2 2 2 2
D DDB_OUTPUT_RELAY_4 2 3 3 3
D DDB_OUTPUT_RELAY_5 2 4 4 4
D DDB_OUTPUT_RELAY_6 2 5 5 5
D DDB_OUTPUT_RELAY_7 2 6 6 6
D DDB_OUTPUT_RELAY_8 2 7 7 7
D DDB_OUTPUT_RELAY_9 2 8 8 8
D DDB_OUTPUT_RELAY_10 2 9 9 9
D DDB_OUTPUT_RELAY_11 2 10 10 10
D DDB_OUTPUT_RELAY_12 2 11 11 11
D DDB_OUTPUT_RELAY_13 2 12 12 12
D DDB_OUTPUT_RELAY_14 2 13 13 13
D DDB_OUTPUT_RELAY_15 2 14 14
D DDB_OUTPUT_RELAY_16 2 15 15
D DDB_OUTPUT_RELAY_17 2 16 16
D DDB_OUTPUT_RELAY_18 2 17 17
D DDB_OUTPUT_RELAY_19 2 18 18
D DDB_OUTPUT_RELAY_20 2 19 19
D DDB_OUTPUT_RELAY_21 2 20 20
D DDB_OUTPUT_RELAY_22 2 21
D DDB_OUTPUT_RELAY_23 2 22
D DDB_OUTPUT_RELAY_24 2 23
D DDB_OUTPUT_RELAY_25 2 24
D DDB_OUTPUT_RELAY_26 2 25
D DDB_OUTPUT_RELAY_27 2 26
D DDB_OUTPUT_RELAY_28 2 27
D DDB_OUTPUT_RELAY_29 2 28
D DDB_OUTPUT_RELAY_30 2 29
D DDB_OUTPUT_RELAY_31 2 30
D DDB_OUTPUT_RELAY_32 2 31
H
D DDB_OPTO_ISOLATOR_1 2 32 21 14
D DDB_OPTO_ISOLATOR_2 2 33 22 15
D DDB_OPTO_ISOLATOR_3 2 34 23 16
D DDB_OPTO_ISOLATOR_4 2 35 24 17
D DDB_OPTO_ISOLATOR_5 2 36 25 18
D DDB_OPTO_ISOLATOR_6 2 37 26 19
D DDB_OPTO_ISOLATOR_7 2 38 27 20
D DDB_OPTO_ISOLATOR_8 2 39 28 21
D DDB_OPTO_ISOLATOR_9 2 40 29
D DDB_OPTO_ISOLATOR_10 2 41 30
D DDB_OPTO_ISOLATOR_11 2 42 31
D DDB_OPTO_ISOLATOR_12 2 43 32
D DDB_OPTO_ISOLATOR_13 2 44 33
D DDB_OPTO_ISOLATOR_14 2 45 34
D DDB_OPTO_ISOLATOR_15 2 46 35
D DDB_OPTO_ISOLATOR_16 2 47 36
D DDB_OPTO_ISOLATOR_17 2 48
D DDB_OPTO_ISOLATOR_18 2 49
D DDB_OPTO_ISOLATOR_19 2 50
D DDB_OPTO_ISOLATOR_20 2 51
D DDB_OPTO_ISOLATOR_21 2 52
D DDB_OPTO_ISOLATOR_22 2 53
D DDB_OPTO_ISOLATOR_23 2 54
D DDB_OPTO_ISOLATOR_24 2 55
H
D DDB_ALARM_GENERAL 2 56 37 22
D DDB_ALARM_PROT_DISABLED 2 57 38 23
D DDB_ALARM_F_OUT_OF_RANGE 2 58 39 24
D DDB_ALARM_VTS_SLOW 2 59 40 25
D DDB_ALARM_CTS 2 60 41 26
D DDB_ALARM_BREAKER_FAIL 2 61 42 27
D DDB_ALARM_I_BROK_MAINT 2 62 43 28
D DDB_ALARM_I_BROK_LOCKOUT 2 63 44 29
D DDB_ALARM_CB_OPS_MAINT 2 64 45 30
D DDB_ALARM_CB_OPS_LOCKOUT 2 65 46 31
D DDB_ALARM_CB_OP_TIME_MAINT 2 66 47 32
D DDB_ALARM_CB_OP_TIME_LOCKOUT 2 67 48 33
D DDB_ALARM_PRE_LOCKOUT 2 68 49 34
Configuration / Mapping P44x/EN GC/E33
Part F - DNP3
X Object name Event Class P444 P442 P441
D DDB_ALARM_EFF_LOCKOUT 2 69 50 35
D DDB_LOCKOUT_ALARM 2 70 51 36
D DDB_ALARM_CB_STATUS 2 71 52 37
D DDB_ALARM_CB_FAIL_TRIP 2 72 53 38
D DDB_ALARM_CB_FAIL_CLOSE 2 73 54 39
D DDB_ALARM_CB_CONTROL_UNHEALTHLY 2 74 55 40
D DDB_ALARM_NO_CHECK_SYNC_CONTROL 2 75 56 41
D DDB_ALARM_AR_LOCKOUT_MAX_SHOTS 2 76 57 42
D DDB_ALARM_SG_OPTO_INVALID 2 77 58 43
D DDB_ALARM_CB_FAIL_AR 2 78 59 44
D DDB_ALARM_UNDER_V_1 2 79 60 45
D DDB_ALARM_UNDER_V_2 2 80 61 46
D DDB_ALARM_OVER_V_1 2 81 62 47
D DDB_ALARM_OVER_V_2 2 82 63 48
D DDB_ALARM_COS 2 83 64 49
D DDB_ALARM_BROKEN_COND 2 84 65 50
D DDB_ALARM_CVTS 2 85 66 51
D DDB_ALARM_USER1 2 86 67 52
D DDB_ALARM_USER2 2 87 68 53
D DDB_ALARM_USER3 2 88 69 54
D DDB_ALARM_USER4 2 89 70 55
H
D DATABASE 2 90 71 56
D DATABASE 2 91 72 57
H
D DDB_INP_52A_A 3 92 73 58
D DDB_INP_52B_A 3 93 74 59
D DDB_INP_52A_B 3 94 75 60
D DDB_INP_52B_B 3 95 76 61
D DDB_INP_52A_C 3 96 77 62
D DDB_INP_52B_C 3 97 78 63
D DDB_INP_SPAR 3 98 79 64
D DDB_INP_TPAR 3 99 80 65
D DDB_INP_AR_INTERNAL 3 100 81 66
D DDB_INP_AR_CYCLE_1P 3 101 82 67
D DDB_INP_AR_CYCLE_3P 3 102 83 68
D DDB_INP_AR_CLOSING 3 103 84 69
D DDB_INP_RECLAIM 3 104 85 70
D DDB_INP_BAR 3 105 86 71
D DDB_INP_CTL_CHECK_SYNCH 3 106 87 72
D DDB_INP_CB_HEALTHY 3 107 88 73
D DDB_INP_BLK_PROTECTION 3 108 89 74
D DDB_INP_TRP_3P 3 109 90 75
D DDB_INP_CB_MAN 3 110 91 76
D DDB_INP_CB_TRIP_MAN 3 111 92 77
D DDB_INP_DISC 3 112 93 78
D DDB_INP_PROTA 3 113 94 79
D DDB_INP_PROTB 3 114 95 80
D DDB_INP_PROTC 3 115 96 81
D DDB_INP_CR 3 116 97 82
D DDB_INP_CR_DEF 3 117 98 83
D DDB_INP_COS 3 118 99 84
D DDB_INP_COS_DEF 3 119 100 85
D DDB_INP_Z1X_EXT 3 120 101 86
D DDB_INP_MCB_VTS_BUS 3 121 102 87
D DDB_INP_MCB_VTS_LINE 3 122 103 88
D DDB_INP_SBEF_TIMER_BLOCK_2 3 123 104 89
D DDB_INP_SBEF_TIMER_BLOCK_3 3 124 105 90
D DDB_INP_DEF_TIMER_BLOCK 3 125 106 91
D DDB_INP_PHOC_TIMER_BLOCK_1 3 126 107 92
D DDB_INP_PHOC_TIMER_BLOCK_2 3 127 108 93
D DDB_INP_PHOC_TIMER_BLOCK_3 3 128 109 94
D DDB_INP_PHOC_TIMER_BLOCK_4 3 129 110 95
D DDB_INP_NPS_TIMER_BLOCK 3 130 111 96
D DDB_INP_UNDU_TIMER_BLOCK_1 3 131 112 97
D DDB_INP_UNDU_TIMER_BLOCK_2 3 132 113 98
D DDB_INP_OVEU_TIMER_BLOCK_1 3 133 114 99
D DDB_INP_OVEU_TIMER_BLOCK_2 3 134 115 100
D DDB_INP_DISTANCE_TIMER_BLOCK 3 135 116 101
D DDB_INP_CB_RESET_LOCKOUT 3 136 117 102
D DDB_INP_CB_RESET_ALL_VALUES 3 137 118 103
D DDB_INP_RESET_RELAYS_LEDS 3 138 119 104
Configuration / Mapping P44x/EN GC/E33
Part F - DNP3
X Object name Event Class P444 P442 P441
D DDB_INP_STUB_BUS 3 139 120 105
D DDB_INP_TRIP_A_USER 3 140 121 106
D DDB_INP_TRIP_B_USER 3 141 122 107
D DDB_INP_TRIP_C_USER 3 142 123 108
D DDB_INP_ZSP_TIMER_BLOCK 3 143 124 109
D DDB_PRT_AR_CLOSE 3 144 125 110
D DDB_PRT_AR_1POLE_IN_PROG 3 145 126 111
D DDB_PRT_AR_3POLE_IN_PROG 3 146 127 112
D DDB_PRT_AR_1ST_CYCLE_IN_PROG 3 147 128 113
D DDB_PRT_AR_234TH_CYCLE_IN_PROG 3 148 129 114
D DDB_PRT_AR_TRIP_3PH 3 149 130 115
D DDB_PRT_AR_RECLAIM 3 150 131 116
D DDB_PRT_AR_DISCRIM 3 151 132 117
D DDB_PRT_AR_ENABLE 3 152 133 118
D DDB_PRT_AR_1PAR_ENABLE 3 153 134 119
D DDB_PRT_AR_3PAR_ENABLE 3 154 135 120
D DDB_PRT_AR_LOCKOUT 3 155 136 121
D DDB_PRT_AR_FORCE_SYNC 3 156 137 122
D DDB_PRT_SYNC 3 157 138 123
D DDB_PRT_DEAD_LINE 3 158 139 124
D DDB_PRT_LIVE_LINE 3 159 140 125
D DDB_PRT_DEAD_BUS 3 160 141 126
D DDB_PRT_LIVE_BUS 3 161 142 127
D DDB_PRT_CONTROL_CLOSE_IN_PROG 3 162 143 128
D DDB_PRT_CARRIER_SEND 3 163 144 129
D DDB_PRT_UNB_CR 3 164 145 130
D DDB_PRT_DIST_FWD 3 165 146 131
D DDB_PRT_DIST_REV 3 166 147 132
D DDB_PRT_DIST_TRIP_A 3 167 148 133
D DDB_PRT_DIST_TRIP_B 3 168 149 134
D DDB_PRT_DIST_TRIP_C 3 169 150 135
D DDB_PRT_DIST_START_A 3 170 151 136
D DDB_PRT_DIST_START_B 3 171 152 137
D DDB_PRT_DIST_START_C 3 172 153 138
D DDB_PRT_DIST_CR_ACC 3 173 154 139
D DDB_PRT_DIST_CR_PERM 3 174 155 140
D DDB_PRT_DIST_CR_BLOCK 3 175 156 141
D DDB_PRT_Z1 3 176 157 142
D DDB_PRT_Z1X 3 177 158 143
D DDB_PRT_Z2 3 178 159 144
D DDB_PRT_Z3 3 179 160 145
D DDB_PRT_Z4 3 180 161 146
D DDB_PRT_Zp 3 181 162 147
D DDB_PRT_T1 3 182 163 148
D DDB_PRT_T2 3 183 164 149
D DDB_PRT_T3 3 184 165 150
D DDB_PRT_T4 3 185 166 151
D DDB_PRT_TZP 3 186 167 152
D DDB_PRT_WI_TRIP_A 3 187 168 153
D DDB_PRT_WI_TRIP_B 3 188 169 154
D DDB_PRT_WI_TRIP_C 3 189 170 155
D DDB_PRT_POWER_SWING 3 190 171 156
D DDB_PRT_REVERSAL_GUARD 3 191 172 157
D DDB_PRT_DEF_CARRIER_SEND 3 192 173 158
D DDB_PRT_UNB_CR_DEF 3 193 174 159
D DDB_PRT_DEF_REV 3 194 175 160
D DDB_PRT_DEF_FWD 3 195 176 161
D DDB_PRT_DEF_START_AN 3 196 177 162
D DDB_PRT_DEF_START_BN 3 197 178 163
D DDB_PRT_DEF_START_CN 3 198 179 164
D DDB_PRT_DEF_TRIP_A 3 199 180 165
D DDB_PRT_DEF_TRIP_B 3 200 181 166
D DDB_PRT_DEF_TRIP_C 3 201 182 167
D DDB_PRT_IN_SUP_2_TRIP 3 202 183 168
D DDB_PRT_IN_SUP_3_TRIP 3 203 184 169
D DDB_PRT_IN_SUP_2_PICK_UP 3 204 185 170
D DDB_PRT_IN_SUP_3_PICK_UP 3 205 186 171
D DDB_PRT_UNDER_V_ANY_PICK_UP_A 3 206 187 172
D DDB_PRT_UNDER_V_ANY_PICK_UP_B 3 207 188 173
D DDB_PRT_UNDER_V_ANY_PICK_UP_C 3 208 189 174
D DDB_PRT_UNDER_V_1_PICK_UP 3 209 190 175
D DDB_PRT_UNDER_V_2_PICK_UP 3 210 191 176
Configuration / Mapping P44x/EN GC/E33
Part F - DNP3
X Object name Event Class P444 P442 P441
D DDB_PRT_UNDER_V_1_TRIP 3 211 192 177
D DDB_PRT_UNDER_V_2_TRIP 3 212 193 178
D DDB_PRT_OVER_V_ANY_PICK_UP_A 3 213 194 179
D DDB_PRT_OVER_V_ANY_PICK_UP_B 3 214 195 180
D DDB_PRT_OVER_V_ANY_PICK_UP_C 3 215 196 181
D DDB_PRT_OVER_V_1_PICK_UP 3 216 197 182
D DDB_PRT_OVER_V_2_PICK_UP 3 217 198 183
D DDB_PRT_OVER_V_1_TRIP 3 218 199 184
D DDB_PRT_OVER_V_2_TRIP 3 219 200 185
D DDB_PRT_I2_SUP_PICK_UP 3 220 201 186
D DDB_PRT_I2_SUP_TRIP 3 221 202 187
D DDB_PRT_I_SUP_ANY_PICK_UP_A 3 222 203 188
D DDB_PRT_I_SUP_ANY_PICK_UP_B 3 223 204 189
D DDB_PRT_I_SUP_ANY_PICK_UP_C 3 224 205 190
D DDB_PRT_I_SUP_1_PICK_UP 3 225 206 191
D DDB_PRT_I_SUP_2_PICK_UP 3 226 207 192
D DDB_PRT_I_SUP_3_PICK_UP 3 227 208 193
D DDB_PRT_I_SUP_4_PICK_UP 3 228 209 194
D DDB_PRT_I_SUP_1_TRIP 3 229 210 195
D DDB_PRT_I_SUP_2_TRIP 3 230 211 196
D DDB_PRT_I_SUP_3_TRIP 3 231 212 197
D DDB_PRT_I_SUP_4_TRIP 3 232 213 198
D DDB_PRT_SOTF_ENABLE 3 233 214 199
D DDB_PRT_I_TOR_ENABLE 3 234 215 200
D DDB_PRT_TOC_START_A 3 235 216 201
D DDB_PRT_TOC_START_B 3 236 217 202
D DDB_PRT_TOC_START_C 3 237 218 203
D DDB_PRT_ANY_START 3 238 219 204
D DDB_PRT_1PH 3 239 220 205
D DDB_PRT_2PH 3 240 221 206
D DDB_PRT_3PH 3 241 222 207
D DDB_PRT_ANY_TRIP 3 242 223 208
D DDB_PRT_ANY_INTERNAL_TRIP_A 3 243 224 209
D DDB_PRT_ANY_INTERNAL_TRIP_B 3 244 225 210
D DDB_PRT_ANY_INTERNAL_TRIP_C 3 245 226 211
D DDB_PRT_ANY_TRIP_A 3 246 227 212
D DDB_PRT_ANY_TRIP_B 3 247 228 213
D DDB_PRT_ANY_TRIP_C 3 248 229 214
D DDB_PRT_1P_TRIP 3 249 230 215
D DDB_PRT_3P_TRIP 3 250 231 216
D DDB_PRT_BROKEN_CONDUCTOR_TRIP 3 251 232 217
D DDB_PRT_LOSS_OF_LOAD_TRIP 3 252 233 218
D DDB_PRT_SOTF_TOR_TRIP 3 253 234 219
D DDB_PRT_TBF1_TRIP_3PH 3 254 235 220
D DDB_PRT_TBF2_TRIP_3PH 3 255 236 221
D DDB_PRT_CONTROL_TRIP 3 256 237 222
D DDB_PRT_CONTROL_CLOSE 3 257 238 223
D DDB_PRT_VTS_FAST 3 258 239 224
D DDB_PRT_CB_AUX_A 3 259 240 225
D DDB_PRT_CB_AUX_B 3 260 241 226
D DDB_PRT_CB_AUX_C 3 261 242 227
D DDB_PRT_ANY_POLE_DEAD 3 262 243 228
D DDB_PRT_ALL_POLE_DEAD 3 263 244 229
D DDB_PRT_DIR_AV_WIT_FILT 3 264 245 230
D DDB_PRT_DIR_AM_WIT_FILT 3 265 246 231
D DDB_PRT_CVMR 3 266 247 232
D DDB_PRT_CROSS_COUNTRY 3 267 248 233
D DDB_PRT_ZSP_START 3 268 249 234
E DDB_PRT_ZSP_TRIP 3 269 250 235
Configuration / Mapping P44x/EN GC/E33
Part F - DNP3
M 1
X Distance relay DNP3.0 Object type 10 definition
X Point reference Database Supports
X P444 Object name Col Row Latch Pulse
H Activate setting groups
D 0 Activate setting group 1 0xFF 0x01 Y Y
D 1 Activate setting group 2 0xFF 0x02 Y Y
D 2 Activate setting group 3 0xFF 0x03 Y Y
D 3 Activate setting group 4 0xFF 0x04 Y Y
H Controls
D 4 CB Trip 0xFF 0x10 Y Y
D 5 CB Close 0xFF 0x11 Y Y
D 6 Reset Indication 0x01 0xFF Y Y
D 7 Reset Demand 0x03 0x25 Y Y
D 8 Reset CB Data 0x06 0x08 Y Y
D 9 Reset Total A/R 0x06 0x0B Y Y
D 10 Clear Events 0x0B 0x01 Y Y
D 11 Clear Faults 0x0B 0x02 Y Y
D 12 Clear Maint 0x0B 0x03 Y Y
D 13 Contact Test 0x0F 0x11 Y Y
D 14 Test LEDs 0x0F 0x12 Y Y
D 15 Autoreclose Test - 3 Phase 0xFF 0x12 Y Y
D 16 Autoreclose Test - Phase A 0xFF 0x13 Y Y
D 17 Autoreclose Test - Phase B 0xFF 0x14 Y Y
D 18 Autoreclose Test - Phase C 0xFF 0x15 Y Y
E 19 Lockout Reset 0x10 0x11 Y Y
M 1
X Distance relay DNP3.0 Object type 20 definition
X Point reference Counter
X P444 Object name Col Row Running Frozen
D 0 CB A Operations 0x06 0x01 Y Y
D 1 CB B Operations 0x06 0x02 Y Y
D 2 CB C Operations 0x06 0x03 Y Y
D 3 Total 1P Reclosures 0x06 0x09 Y Y
E 4 Total 3P Reclosures 0x06 0x0A Y Y
Configuration / Mapping P44x/EN GC/E33
Part F - DNP3
M1
X Distancerelay DNP3.0 Object type 30 definition
X Point reference Database
X P444 Object name Col Row Event Class Type Deadband Scaling Units
H Active group
D 0 Active group 0x00 0x0E 1 D9 1 x1 [None]
H Measurements 1
D 1 IA Magnitude 0x02 0x01 2 D1 0.1 x In / 500 A
D 2 IA Phase Angle 0x02 0x02 2 D4 1 x 0,01 deg
D 3 IB Magnitude 0x02 0x03 2 D1 0.1 x In / 500 A
D 4 IB Phase Angle 0x02 0x04 2 D4 1 x 0,01 deg
D 5 IC Magnitude 0x02 0x05 2 D1 0.1 x In / 500 A
D 6 IC Phase Angle 0x02 0x06 2 D4 1 x 0,01 deg
D 7 IN Derived Mag 0x02 0x09 2 D1 0.1 x In / 500 A
D 8 IN Derived Angle 0x02 0x0A 2 D4 1 x 0,01 deg
D 9 I1 Magnitude 0x02 0x0D 2 D1 0.1 x In / 500 A
D 10 I2 Magnitude 0x02 0x0E 2 D1 0.1 x In / 500 A
D 11 I0 Magnitude 0x02 0x0F 2 D1 0.1 x In / 500 A
D 12 VAB Magnitude 0x02 0x14 2 D3 5 x Vn /(110 x 100) V
D 13 VAB Phase Angle 0x02 0x15 2 D4 1 x 0,01 deg
D 14 VBC Magnitude 0x02 0x16 2 D3 5 x Vn /(110 x 100) V
D 15 VBC Phase Angle 0x02 0x17 2 D4 1 x 0,01 deg
D 16 VCA Magnitude 0x02 0x18 2 D3 5 x Vn /(110 x 100) V
D 17 VCA Phase Angle 0x02 0x19 2 D4 1 x 0,01 deg
D 18 VAN Magnitude 0x02 0x1A 2 D3 5 x Vn /(110 x 100) V
D 19 VAN Phase Angle 0x02 0x1B 2 D4 1 x 0,01 deg
D 20 VBN Magnitude 0x02 0x1C 2 D3 5 x Vn /(110 x 100) V
D 21 VBN Phase Angle 0x02 0x1D 2 D4 1 x 0,01 deg
D 22 VCN Magnitude 0x02 0x1E 2 D3 5 x Vn /(110 x 100) V
D 23 VCN Phase Angle 0x02 0x1F 2 D4 1 x 0,01 deg
D 24 VN Derived Mag 0x02 0x22 2 D3 5 x Vn /(110 x 100) V
D 25 VN Derived Ang 0x02 0x23 2 D4 1 x 0,01 deg
D 26 V1 Magnitude 0x02 0x24 2 D3 5 x Vn /(110 x 100) V
D 27 V2 Magnitude 0x02 0x25 2 D3 5 x Vn /(110 x 100) V
D 28 V0 Magnitude 0x02 0x26 2 D3 5 x Vn /(110 x 100) V
D 29 Frequency 0x02 0x2A 2 D5 0.5 x 0,01 Hz
D 30 C/S Voltage Mag 0x02 0x2B 2 D3 5 x Vn /(110 x 100) V
D 31 C/S Voltage Ang 0x02 0x2C 2 D4 1 x 0,01 deg
D 32 IM Magnitude 0x02 0x2F 2 D1 0.1 x In / 500 A
D 33 IM Angle 0x02 0x30 2 D4 1 x 0,01 deg
D 34 A Phase Watts 0x03 0x01 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 35 B Phase Watts 0x03 0x02 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 36 C Phase Watts 0x03 0x03 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 37 A Phase VArs 0x03 0x04 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 38 B Phase VArs 0x03 0x05 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 39 C Phase VArs 0x03 0x06 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 40 A Phase VA 0x03 0x07 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 41 B Phase VA 0x03 0x08 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 42 C Phase VA 0x03 0x09 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 43 3 Phase Watts 0x03 0x0A 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 44 3 Phase VArs 0x03 0x0B 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 45 3 Phase VA 0x03 0x0C 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 46 Zero Seq Power 0x03 0x0D 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 47 3Ph Power Factor 0x03 0x0E 2 D8 0.1 x 0,001 [None]
D 48 APh Power Factor 0x03 0x0F 2 D8 0.1 x 0,001 [None]
D 49 BPh Power Factor 0x03 0x10 2 D8 0.1 x 0,001 [None]
D 50 CPh Power Factor 0x03 0x11 2 D8 0.1 x 0,001 [None]
D 51 3Ph W Fix Demand 0x03 0x16 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 52 3Ph VArs Fix Dem 0x03 0x17 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 53 3Ph W Peak Demand 0x03 0x20 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
D 54 3Ph VArs Peak Demand 0x03 0x21 2 D6 1 0,1 x In .Vn / 110 W/Var/VA
E 55 Slip Frequency 0x02 0x31 2 D5 0.5 x 0,01 Hz
Configuration / Mapping
abcd P44x/EN GC/E33
Part F: DNP3
MAINTENANCE TYPE
Fault type Test type Comments
0 Initialisation "fast W'Dog Error"
1 Initialisation "Battery Failure"
2 Initialisation "BBRAM Failure"
3 Initialisation "Field Volt Fail"
4 Initialisation "Bus Reset Error"
5 Initialisation "Slow W'Dog Error"
6 Permanent "SRAM Failure Bus"
7 Permanent "SRAM Failure Blk"
8 Permanent "FLASH Failure"
9 Permanent "Code Verify Fail"
10 Permanent "BBRAM Failure"
11 Permanent "Battery Failure"
12 Permanent "Field Volt Fail"
13 Permanent "EEPROM Failure"
14 Permanent "Software Failure"
15 Permanent "Hard Verify Fail"
16 Permanent "Non Standard"
MAINTENANCE DATA
Column
A 2 first digits of LCD 0x For hexadecimal number
B Software type 0 Plateform error
B Software type 8 Application error
C Software task or module N
D Element in the task or module NN
E 4 digits to print internal data NNNN
G R = stop + reboot D = definitive stop M = Msg maint
H Type of maintenance message
DEFAULT PROGRAMMABLE
SCHEME LOGIC (PSL)
P44x/EN GC/E33 Configuration / Mapping
Input-Opto Couplers
DIST. COS
DDB #130
Opto Label 02
DDB #065
DEF. COS
DDB #131
SPAR Enable
DDB #110
Opto Label 08
DDB #071
TPAR Enable
DDB #111
Output Contact
Z1 0
DDB #255 Relay Label 01
Straight DDB #000 Trip Z1
0
DIST Trip A
DDB #246
DIST Trip B
DDB #247
DIST Trip C
DDB #248
DIST UNB CR
DDB #243
Z1
DDB #255
Z1X
DDB #256
0
Z2 Distance
DDB #257 Straight Relay Label 10
DDB #009
0 Aided Trip
Zp
DDB #260
Z3
DDB #258
Z4
DDB #259
LED
Z1
DDB #255 Latching LED 5 Z1 +
DDB #100
Aided Trip
Z1X
DDB #256
0
Any Trip A
DDB #325 Straight Relay Label 02
DDB #001 Trip A
0
0
Any Trip B
DDB #326 Straight Relay Label 03
DDB #002 Trip B
0
0
Any Trip C
DDB #327 Straight Relay Label 04
DDB #003 Trip C
0
Output Contact
0
Any Start
DDB #317 Straight Relay Label 06
DDB #005 General Start
0
LED
Any Start
DDB #317 Latching LED 4
DDB #099 General Start
20
Any Start
DDB #317 Dwell
0
Any Trip
Fault_REC_TRIG
DDB #468 Starting
DDB #321
Fault Recorder
0
Any Trip
DDB #321 Straight Relay Label 07
DDB #006 General Trip
0
0
General Alarm
DDB #161 Straight Relay Label 08
DDB #007 General Alarm
0
IN>1 Trip
DDB #281
IN>2 Trip
DDB #282
0
DEF Trip A
Straight Relay Label 09 Trip
DDB #278 DDB #008
DEF Trip B
0 DEF + SBEF
DDB #279
DEFTrip C
DDB #280
0
A/R Lockout
DDB #234 Straight Relay Label 11
DDB #010 A/R lockout
0
A/R 1P In Prog
DDB #224 0
Straight Relay Label 12 A/R
DDB #011
A/R 3P In Prog
DDB #225
0 in Progress
0
A/R Close Relay Label 13
DDB #223 Straight DDB #012 A/R Close
0
0
Power Swing
DDB #269 Straight Relay Label 14
DDB #013
Power Swing
0
SYSTEM DATA
VIEW RECORDS MEASUREMENTS 1 MEASUREMENTS 2 CB CONDITION CB CONTROL DATE and TIME CONFIGURATION
CT AND VT RATIOS
RECORD CONTROL
DISTURB RECORDER
OUTPUT LABELS
MEASURE'T SETUP
GROUP 1
INPUT LABELS
COMMUNICATIONS
GROUP 1
AUTORECLOSE COMMISSION
GROUP 1 TESTS
1
SUPERVISION CB FAIL & I> NEG SEQUENCE O/C BACK-UP I> DISTANCE SCHEMES DISTANCE UNIVERSAL
POWER-SWING
GROUP 1 GROUP 1 GROUP 1 GROUP 1 GROUP 1 GROUP 1 INPUTS
GROUP 1
Menu Content Tables P44x/EN HI/E33
SYSTEM DATA VIEW RECORDS MEASUREMENTS 1 MEASUREMENTS 2 CB CONDITION CB CONTROL DATE and TIME CONFIGURATION
Language Select Event IA Magnitude VAN Magnitude A Phase Watts CB A Operations CB Control by Date Restore Defaults Aided D.E.F
English [0…256] 0 0A 0V 0W 0 Enable 18 Mar 2004 No Operation Enabled
Password Menu Cell Ref IA Phase Angle VAN Phase Angle B Phase Watts CB B Operations Close Pulse Time Time Setting Group Volt Protection
o o
XXXX (From Record) 0 0 0W 0 0.5 ms 16:25:53 Select via Menu Disabled
(1)
Description Time & Date IB Magnitude VBN Magnitude C Phase Watts CB C Operations Trip Pulse Time IRIG-B Sync Active Settings CB Fail & I<
MiCOM (From Record) 0A 0V 0W 0 0.5 ms Disabled Group 1 Enabled
(1)
Plant Reference Event Text IB Phase Angle VBN Phase Angle A Phase VArs Total IA Broken Man Close Delay IRIG-B Status Save Changes Supervision
o
ALSTOM 0 0o 0 Var 0A 10 s 0 No Operation Enabled
(1)
Model Number Event Value IC Magnitude VCN Magnitude B Phase VArs Total IB Broken Healthy Window Battery Status Copy From System Checks
P442311B1A0090C 0A 0V 0 Var 0A 5s Healthy Group 1 Disabled
(1)
Serial Number Select Fault IC Phase Angle VCN Phase Angle C Phase VArs Total IC Broken C/S Window Battery Alarm Copy to Internal A/R
o o
123456A [0…4] 0 0 0 0 Var 0A 5s Enabled No Operation Disabled
Frequency Active Group IN Derived Mag VN Derived Mag A Phase VA CB Operate Time A/R Single Pole Setting Group 1 Input Labels
50 0 0A 0V 0 VA 0s Disabled Enabled Visible
Comms Level Select Maintenance IN Derived Angle VN Derived Ang B Phase VA Reset CB Data A/R Three Pole Setting Group 2 Output Labels
o o
2 [0…0] 0 0 0 0 VA No Disabled Disabled Visible
Relay Address Reset Indication I1 Magnitude V1 Magnitude C Phase VA Total 1P Reclose Setting Group 3 CT & VT Ratios
255 No 0A 0V 0 VA 0 Disabled Visible
Plant Status Relay O/P Status1 I2 Magnitude V2 Magnitude 3 Phase Watts Total 3P Reclose Setting Group 4 Record Control
0000000000000000 0A 0V 0W 0 Disabled Invisible
Control Status Alarm Status 1 I0 Magnitude V0 Magnitude 3 Phase VArs Reset Total A/R Dist. Protection Disturb Recorder
0000000000000000 0A 0V 0 Var No Enabled Invisible
Active Group Alarm Status 2 VAB Magnitude Frequency 3 Phase VA Power-Swing Measure't Setup
1 0V 0 0 VA Enabled Invisible
(1)
CB Trip/Close Alarm Status 3 VAB Phase Angle C/S Voltage Mag Zero Seq Power 3Ph W Fix Demand Back-Up I> Comms Settings
o
No Operation 0000000000000000 0 0V 0 0 Wh Disabled Visible
Software Ref. 1 Access Level VBC Magnitude C/S Voltage Ang 3Ph Power Factor 3Ph VArs Fix Dem Neg Sequence O/C Commission Tests
o
B1.2 2 0V 0 0 0 Varh Disabled Invisible
Opto I/P Status Password Control VBC Phase Angle IM Magnitude APh Power Factor 3Ph W Peak Demand Broken Conductor Setting Values
o
0001100100001000 2 0 0A 0 0 Wh Disabled Secondary
Relay O/P Status Password Level 1 VCA Magnitude IM Angle BPh Power Factor 3Ph VArs Peak Demand Earth Fault O/C
o
0000000000000000 **** 0V 0 0 0 Varh Disabled
Alarm Status 1 Password Level 2 VCA Phase Angle Slip Frequency CPh Power Factor Reset Demand
o
0000000000000000 **** 0 0 0 Wh No
(1) CB control must be enable to display the cells above
Menu Content Tables P44x/EN HI/E33
COMMISSION
CT AND VT RATIOS RECORD CONTROL DISTURB RECORDER MEASURE'T SETUP COMMUNICATIONS
TESTS
(2)
Main VT Primary Clear Events Duration Default Display Rear Protocol ETHERNET COMMS NSAP Address IED View Select Opto I/P Status
110.0 V No 1.500 s Description Courier 0 0x00000000h 0 0001011001000011
Main VT Sec'y Clear Faults Trigger Position Local Values Remote Address IP Address Transport Select IED Recvd Msgs Relay O/P Status
110.0 V No 33.30 % Secondary 255 000.000.000.000 00.00.00.00 0 0001011001000011
C/S VT Primary Clear Maint Trigger Mode Remote Values Remote Address Subnet Mask Session Select IED Last Seq/Msg Rx Test Port Status
110.0 V No Single Primary 1 000.000.000.000 00.00 0 0001011001000011
C/S VT Secondary Alarm Event Analog Channel 1 Measurement Ref Remote Address Number of Routes Present. Select IED Missed Msgs LED Status
110.0 V Enabled VA VA 1 0 00.00 0 0001011001000011
Phase CT Primary Relay O/P Event Analog Channel 2 Measurement Mode Remote Address Router Address 1 AP Title IED Missed Chngs Monitor Bit 1
1A Enabled VB 0 1 000.000.000.000 000.000.000.000 0 Relay Label 01
Phase CT Sec'y Opto Input Event Analog Channel 3 Demand Interval Inactivity Timer Target Network 1 AE Qual. Used IED Timeouts
1A Enabled VC 30.00 mins 15.00 mins 000.000.000.000 Not Used 0
Mcomp CT Primary Central Event Analog Channel 4 Distance Unit Baud Rate AE Qualifier IED Stats Reset Monitor Bit 8
1A Enabled VN Kilometres 19200 bits/s 0 Our IED Relay Label 08
Mcomp CT Sec'y Fault Rec Event Analog Channel 5 Fault Location Baud Rate Target Network 4 Ethernet Media Loopback Mode Test Mode
1A Enabled IA Distance 19200 bits/s 000.000.000.000 Copper No Action Disabled
C/S Input Maint Rec Event Analog Channel 6 Baud Rate Inactivity Timer GOOSE STATISTICS Reload Mode Test Pattern 1
A-N Enabled IB 19200 bits/s 15 No Action 0
Main VT Location Protection Event Analog Channel 7 Parity Default Pass Lvl Enrolled Flags RP2 Protocol Test Pattern 2
Line Enabled IC None 2 0x00000000h Courier 0
DDB element 31 - 0 Analog Channel 8 Parity GOOSE Min Cycle Our Tx Msg Cnt. RP2 Card Status Contact Test
1111111111111111 IN None 10 0 0 No Operation
DDB element 63 - 32 Digital Input 1 Measure't Period GOOSE Min Cycle Our Rx Msg Cnt. RP2 Port Config Test LEDs
1111111111111111 Relay Label 01 10 0 0 EIA232 (RS232) No Operation
Input 1 Trigger Physical Link GOOSE Increment Our DDB Changes RP2 Comms Mode Autoreclose Test
No Trigger RS485 900 0 IEC60870 FT1.2 No Operation
DDB element 1022 - 992 Time Sync GOOSE Startup Our Last Seq Tx RP2 Address
1111111111111111 Disabled Broadcast 0 255
Digital Input 32 CS103 Blocking GOOSE VIP Status Our Last Msg Tx RP2 InactivTimer
Not Used Disabled 000.000.000.000 0 15
Broken I^ Global threshold Line Setting R2G tZp Program Mode Delta R I>1 Function I2> Status Broken Conductor
2 24-27V Group 1 20 Ω 0.400 s Standard Scheme 5Ω DT Enabled Enabled
I^ Maintenance Opto Input 1 Line Length R2Ph Serial Comp Line Standard Mode Delta X I>1 Directional I2> Directional I2/I1 Setting
Alarm Disabled 24-27V 100 km 20 Ω Disabled Basic + Z1X 5Ω Directional Fwd Non-Directional 0.2
(3)
I^ Maintenance Opto Input 2 Line Impedance tZ2 Zone Overlap Mode Fault Type IN > Status I>1 VTS Block I2> VTS I2/I1 Time Delay
1000 24-27V 12 Ω 200 ms Disabled Both Enabled Enabled Non-Directional Non-Directional 60 s
I^ Lockout Line Angle kZ3/4 Res Comp Fault Locator Trip Mode IN > (% Imax) I>1 Current Set I2> Current Set I2/I1 Trip
Alarm Disabled 70 ° 1 Group 1 Force 3 Poles 40 % 1.500 A 200 mA Disabled
(3) (5)
I^ Lockout Opto Input 32 Zone Setting kZ3/4 Angle kZm Mutual Comp Sig. Send Zone I2 > Status I>1 Time Delay VTS I2> Time Delay
2000 24-27V 0 0° 0 None Enabled 1.000 s 10 s
(5)
N° CB Ops Maint Zone Status Z3 kZm Angle DistCR I2 > (% Imax) I>1 TMS I2> Char Angle
Alarm Disabled 11110 30 Ω 0° None 30 % 1 -45 °
(3) (6)
N° CB Ops Maint kZ1 Res Comp R3G - R4G Tp Imax Line > Status I>1 Time Dial
10 1 30 Ω 0.02 Enabled 7
N° CB Ops Lock kZ1 Angle R3Ph - R4Ph tReversal Guard Imax Line > I>1 Reset Char
Alarm Disabled 0° 30 Ω 0.02 3A DT
(3)
N° CB Ops Lock Z1 tZ3 Unblocking Logic Unblocking Delay I>1 tRESET
20 10 Ω 0.6 None 15 0
(3)
CB Time Maint Z1X Z4 TOR-SOTF Mode Blocking Zones I>2 Function
Alarm Disabled 15 Ω 40 Ω 0000000011000000 00001 DT
(3)
CB Time Maint R1G tZ4 SOFT Delay I>2 Directional I>2 tRESET
0.1 10 Ω 1 110 s Non-Directional 0
CB Time Lockout R1Ph Zone P - Direct. Z1Ext Fail I>2 VTS Block I>3 Status
Alarm Disabled 10 Ω Directional Fwd o
Disabled Non-Directional Enabled
(3)
CB Time Lockout tZ1 kZp Res Comp Weak Infeed Loss Of Load I>2 Current Set I>3 Current Set
0.2 0 1 Group 1 Group 1 2A 3A
Fault Freq Lock kZ2 Res Comp kZp Angle WI :Mode Status LoL: Mode Status I>2 Time Delay VTS I>3 Time Delay
Alarm Disabled 1 0° Disabled Disabled 2s 3s
(3)
Fault Freq Count kZ2 Angle Zp WI: Single Pole LoL. Chan. Fail I>2 TMS I>4 Status
10 0° 25 Ω Disabled Disabled 1 Disabled
(3) (3) (4)
Fault Freq Time Reset Lockout by Z2 RpG WI : V< Thres. LoL: I< I>2 Time Dial I>4 Current Set
3600 CB Close 20 Ω 25 Ω 45 V 500 mA 7 4A
(3) (4)
Lockout Reset Man Close RstDly RpPh WI : Trip Time Delay LoL: Window I>2 Reset Char I>4 Time Delay
No 5 25 Ω 60 ms 40ms DT 4s
(7)
2 VOLT 3 CB 4 5 6 7
EARTH FAULT O/C AIDED D.E.F. idem for GROUP
PROTECTION FAIL & I> SUPERVISION SYSTEM CHECK AUTORECLOSE INPUT LABELS OUTPUT LABELS
GROUP 1 GROUP 1 2, 3 & 4
GROUP 1 GROUP 1 GROUP 1 GROUP 1 GROUP 1 GROUP 1 GROUP 1
IN>1 Function Channel Aided DEF Status V< & V> MODE BREAKER FAIL VT SUPERVISION C/S Check Schem. for A/R AUTORECLOSE MODE Opto Input 1 Relay 1 PSL Data
DT Enabled 0 7 Opto Label 01 Relay Label 01
IN>1 Directional Polarisation UNDER VOLTAGE CB Fail 1 Status VTS Time Delay C/S Check Schem. for Man CB 1P Trip Mode P441/2/4 P441/2/4
Directional Fwd Zero Sequence 0 Enabled 5 7 1
IN>1 VTS Block V> Voltage Set V< Measur't Mode CB Fail 1 Timer VTS I2> & I0> Inhibit V< Dead Line 3P Trip Mode Opto Input 8 Relay 14
Non-Directional 1 Phase-Neutral 0.2 0.05 13 1 Opto Label 08 Relay Label 14
IN>1 Current Set IN Forward V<1 Function CB Fail 2 Status Detect 3P V> Live Line 1P Rcl - Dead Time 1 P442/4 P442/4
0.2 0.1 DT Disabled Disabled 32 1
IN>1 Time Delay Time Delay V<1 Voltage Set CB Fail 2 Timer Threshold 3P V< Dead Bus 3P Rcl - Dead Time 1 Opto Input 16 Relay 21
1 0 50 0.4 30 13 1 Opto Label 16 Relay Label 21
IN>1 Time Delay VTS Scheme Logic V<1 Time Delay CBF Non I Reset Delta I> V> Live Bus Dead Time 2 P444 P444
0.2 Shared 10 1 0.1*I1 32 60
IN>1 TMS Tripping V<1 TMS CBF Ext Reset CT SUPERVISION Diff Voltage Dead Time 3 Opto Input 24 Relay 32
1 Three Phase 1 1 0 6.5 180 Opto Label 24 Relay Label 32
IN>1 Time Dial V<2 Status UNDER CURRENT CTS Status Diff Frequency Dead Time 4
7 Disabled Disabled 0.05 180
IN>1 Reset Char ZERO SEQ. POWER V<2 Voltage Set I < Current Set CTS VN< Inhibit Diff Phase Reclaim Time
DT GROUP 1 38 0.05*I1 1 20 180
IN>1 tRESET Zero Seq Power Status V<2 Time Delay CTS IN> Set Bus-Line Delay Reclose Time Delay
0 Enabled 5 0.1 0.2 0.1
IN>2 Status K Time Delay Factor OVERVOLTAGE CTS Time Delay Discrimination Time
Enabled 0 0 5 5
IN>2 Directional Basis Time Delay V> Measur't Mode CVT SUPERVISION A/R Inhbit Wind
Non-Directional 1 Phase-Neutral 5
IN>2 VTS Block Residual Current V>1 Function CVTS Status C/S on 3P Rcl DT1
Non-Directional 0.1 DT Disabled Enabled
IN>2 Current Set Residual Power V>1 Voltage Set CVTS VN> AUTORECLOSE LOCKOUT
0.3 0.5 75 1
IN>2 Time Delay VTS V>1 Time Delay CVTS Time Delay Block A/R
2 10 100 16383
BLANK PAGE
Hardware / Software-Version P44x/EN VC/E33
HARDWARE / SOFTWARE
VERSION HISTORY AND
COMPATIBILITY
(Note: Includes versions released and supplied to customers only)
Hardware / Software-Version P44x/EN VC/E33
Backward Compatibility
Software Hardware Model Date of S1
Full Description of changes
version version number issue Compatibility Setting Menu
PSL
Files Text Files
Branch A2.x: First Model – P441/P442 (P444 not available) – Modbus/Kbus/IEC103 – 4 languages – Optos 48Vcc (Hardware=A)
Documentation: TG 1.1671-C & OG 1.1671-B
VDEW-ModBus-Kbus cells/CBaux/IRIGB/WeakInfeed/Reset No compatibility with branch A1.x
03 10/2000 V1.09
IDMT/SyncCheck/AR Led (model 02)
A2.6 VDEW-ModBus-Kbus cells/CBaux/IRIGB/ WeakInfeed/Reset
04 10/2000 IDMT/ SyncCheck/AR Led V2.0 03 03 03
New S1 version
No compatibility with branch A1.x
03 04/2001 Frequency out of range (major correction)- 1/3 pole AR logic V1.10
(model 02)
A2.7
Frequency out of range (major correction)- 1/3 pole AR logic
04 04/2001 V2.0 03 03 03
A New S1 version
Communication improvement / Floc with 5Amp / IrigB / SOTF-TOR
A2.8 04 07/2001 V2.0 03 03 03
/ U-I prim sec
3P fault in Power Swing/SOTF logic/CB Fail/Ext. Trip + 5 ms/Z1-Z2
A2.9 04 01/ 2002 V2.0 03 03 03
measure for small characteristic
EEPROM correction / Blocking scheme improvement / RCA angle /
A2.10 04 05/2002 V2.0 03 03 03
DEF correction / New general distance Trip equation
Last A2.x branch version: Retrip CB/Ffailure/31th Dec/Disturbance
A2.11 04 09/2003 compressed function and communication correction/Voltage V2.0 03 03 03
memory/DEF/Ext Csync/P.Phase ref Csync/Sync live-live
Note : Software version / hardware version / model number can be found by setting in “system data” with MiCOM S1 or LCD front panel.
P44x/EN VC/E33 Hardware / Software-Version
Backward Compatibility
Software Hardware Model Date of S1
Full Description of changes
version version number issue Compatibility Setting Menu
PSL
Files Text Files
Branch A3.x : P444 model with 24optos/32 outputs (Omron) -Universal optos – Italian Language – DNP3
Documentation: TG 1.1671-C & OG 1.1671-B
P444/DNP3/NCIT/universal input/5 languages
Italian model 4050A for P444
No compatibility with branch A2.x
A3.0 05 05/2001 P441/P442 models 050A (48Vcc) or 050B (Universal optos) V2.02 + patch
(model 03 or 04)
DDB with 1022cells/Discrimination timer in AR/New DDB distance
A or B cells/DEFlogic/SOTF timer/Broken Conductor
for P441/442
SOTF / Z4 block Pswing / CB Fail / IEC103 disturbance / Prim-sec 05
A3.1 06 12/2001 / Kms-Miles / 3P fault in Power Swing / Z1-Z2 measure for small V2.02 + patch N/A 05
charateristic (Same DDB)
A
for P444 EEPROM correction / Blocking scheme improvement/RCA angle / 05
A3.2 06 05/2002 V2.02 + patch N/A 05
IEC 103 corrections / Fault Loc (Same DDB)
Backward Compatibility
Software Hardware Model Date of S1
Full Description of changes
version version number issue Compatibility Setting Menu
PSL
Files Text Files
Branch A4.x : Second Rear Port - more alarms - new application feature
Documentation: TG 1.1671-C & OG 1.1671-B
Second rear port/overlap mode/slip frequency/Z4/VDEW fault
locator/Retrip CB/VTS phase selec/PPGround phase
A4.0 07 09/2002 V2.05 + patch
selection/Extraction PSL/Serial Cmp Line/New DDB cells/Overlap
Z/ Rev with X4 limit/Winfeed/Floc in IEC /Ffailure/31th Dec
A or B
A4.1 for P441/442 07 12/ 2002 Bi phase ground phase selection/Synchro VT bus side V2.07
No compatibility with branch A3.x
Voltage memory improvement/compliant IEC103 with Px3x /31th (model 05 or 06)
A4.3 07 04/ 2003 V2.07
A Dec/DEF
for P444
Last A4.x branch version: Disturbance (compressed or not
compressed) and communication correction / DEF/ Ext
A4.5 07 09/2003 V2.07
Csync/P.Phase ref Csync / Sync live-live / I broken Cond./ Px4X
with Px3x in IEC103/Battery Alarm IEC 103
Note 1 : Software version / hardware version / model number can be found by setting in “system data” with MiCOM S1 or LCD front panel.
Note 2 : Version A4.2 & A4.4 not distributed
P44x/EN VC/E33 Hardware / Software-Version
Backward Compatibility
Software Hardware Model Date of S1
Full Description of changes
version version number issue Compatibility Setting Menu
PSL
Files Text Files
Branch B1.x : New Hardware Platform (Coprocessor Board 150MHz-2nd rear port-Triptime= 1,1Cycle - 48 samples/T) & New functions (32N & 59N)
Documentation: P44x/EN T/E33
New platform/model 080C/coprocessor board at 150 MHz/PW
B1.0 08 12/2002 (32N)/TCT (59N) new functions/ Px4X with Px3x in IEC103 / Retrip V2.09 No compatibility with branch A.x
CB/Ffu / 31st dec
C Synchrocheck ext correction & PPhase ref / 32N correction / Line V2.09 +
B1.1 09 07/2003 08 08 08
angle<55° / Voltage memory / Power swing patch*
Disturbance compressed & not compressed function and V2.09 +
B1.2 09 09/2003 08 08 08
communication correction patch*
Note : Software version / hardware version / model number can be found by setting in “system data” with MiCOM S1 or LCD front panel.
* Patch 09 will be included with MiCOM S1 version V2.10
Publication: P44x/EN T/E33
