POWER PRODUCTS LLC.

GARDEN MASTER SERIES

OPERATING INSTRUCTIONS
 POWER PRODUCTS LLC.

CONTENTS

Description of Symbols.................................................3

Specifications.............................................................3

Unpacking......................................................3

Carton Contents.................................................4

Safety Instructions.................................................5

Effects of Vibration.................................................6

Repetitive Strain Injury (RSI)........................................6

Safe Operating Practices..............................................7

Thrown Debris.......................................................7

Blade Thrust (Kickback)................................................7

Assembly.............................................................8

Fuel & Lubrication........................................................9

Starting Checklist.................................................10

Starting the Multi-Tool.................................................10

Operating the Multi-Tool.............................................11

Maintenance............................................................11

The Spark Plug..........................................................12

The Air Filter.........................................................12

The Line Trimmer Head..............................................13

The Chainsaw Pruning Attachment............................14

The Hedge Trimmer Attachment................................14

Storing Your Multi-Tool...............................................14

Troubleshooting .................................................15

Parts List.............................................................16

Warranty..............................................................17

2.
DESCRIPTION OF SYMBOLS SPECIFICATIONS
The rating plate on your tool may show symbols. These
represent important information about the product or Engine Displacement 33cc
instructions on its use.
Bore & Stroke 36mm x 32mm
Conforms to relevant safety standards
Maximum Engine
1.0KW@ 6500 rpm
Wear hearing protection. Wear eye protection. Wear Power
head protection. Maximum Engine
7000 rpm
Speed
Read these instructions for use carefully. Failure to
follow operating instructions and safety precautions Air Cooled, Single Cylinder,
Engine Type
can result in serious injury. 2 Stroke Cycle, Full Crank

Fuel Type Unleaded Petrol, 2 Stroke Mix 40:1

Wear safety footwear.
Fuel Tank Capacity 1.2L
Wear safety gloves. NGK LD LBRTF TORCH BM6A
Spark Plug
CHAMPION CJB
Wear protective clothing Weight (Engine &
5.9KG
Extension Only)

Warning - Safety alert. Indicates danger, warning or Sound Power Level 113dB(A)
caution. Attention is required in order to avoid serious
personal injury.

Thrown objects can cause severe injury.

Keep all bystanders, especially children and pets at UNPACKING

least 15m from the operating area.
No naked flame - explosive material.
Extremely hot surface. Do not touch hot muffler, gear
box or cylinder, you may get burned. These parts get
extremely hot from operation and remain hot for a
short time after the unit is turned off.
Due to modern mass production techniques, it is unlikely that
your Qualcut 4 in 1 Multi-tool is faulty or that a part is missing.
If you find anything wrong, do not operate the tool until the
parts have been replaced or the fault has been rectified.
Failure to do so could result in serious personal injury.
The packaging material is made of recyclable materials.
Please dispose of packaging materials in accordance with
regulations.

Fuel inlet (Position: under the fuel tank cap)

On/Off (Position: on the on/off switch)

Setting the on/off switch to OFF stops the engine
immediately.

Do not remove safety guard. Operation without safety

guard can result in serious injury.

3.
 POWER PRODUCTS LLC.

CARTON CONTENTS

The Qualcut 4 in 1 Multi-tool is supplied with the following accessories as standard.

1. 33cc Engine and extension shaft assembly

2. Line Trimmer / Brush Cutter Attachment
3. Pruning Saw Attachment
4. Hedge Trimmer Attachment
5. Pruning Saw Bar
6. Pruning Saw Chain
7. Main Shaft Handle
8. Shoulder Strap
9. Line Trimmer/ Brush Cutter Safety Guard
10. Fuel Mixing Bottle
11. Line Trimmer Head
12. Brush Cutter 3T Blade
15. Pruning Saw Bar Cover
Hardware/ Tool Kit
Instruction Manual

Assembly Tools:
• Sparkplug Wrench I Screwdriver
• Allan Key (x2)
• Spanner
• Backing Plates (x2)
• Screws I Washers

4.
SAFETY INSTRUCTIONS
Save these instructions.
1) Work Area
a) Clear the area to be cut before each use. Remove all
objects such as rocks, broken glass, nails, wire, string etc.
that can be thrown or become entangles in the cutting
attachment.
b) Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases, or
dust. Power tools create sparks which may ignite the dust or
fumes.
c) Take extra care in dangerous environments. To avoid
falling, do not use the product in damp or wet locations.
2) Personal Safety
a) Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired, ill or under the influence of drugs,
alcohol, or medication. Operate unit only if you are physically
and mentally well. A moment of inattention while operating
power tools may result in serious personal injury.
b) Use safety equipment. Always wear eye protection.
Safety equipment such as non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions will reduce
personal injuries. Wear no-slip, heavy-duty work gloves to
improve your grip on the handle. Gloves also reduce the
transmission of machine vibration to your hands.
c) Always wear protective clothing - long heavy pants,
boots and gloves. Do not wear loose clothing, jewellery,
short pants, open toed shoes or go barefoot. Secure hair so
that it is above shoulder level to avoid entanglement in
moving parts.
d) Choose the right time of day. Heavy protective clothing
can increase operator fatigue which may lead to heat stroke.
Schedule heavy work for early morning or late afternoon
hours when temperatures are cooler.
e) Do not over-reach. Keep proper footing and balance at all
times. This enables better control of the power tool in
unexpected situations.
f) Keep pets, children, and bystanders outside a 15m
radius.
3) Power Tool Use And Care
a) Check condition of multi-tool before use. The multi-tool
should be assembled as per manufacturer's instructions. Do
not attach any blade to a product without proper installation of
all required parts. Failure to use the proper parts can cause
the blade to fly off and seriously injure the operator and/or
bystanders. Discard blades that are bent, warped, cracked,
broken or damaged in any way.
b) Never start or run the product inside a closed room or
building. Breathing exhaust fumes can cause illness or
death.
c) Mix and pour fuel outdoors where there are no sparks
or flames. Slowly remove the fuel cap only after stopping the
engine. Do not smoke while fuelling or mixing fuel. Wipe
spilled fuel from the product immediately. Move at least 9m
from the fuelling source and site before starting engine.
d) Keep the cutting attachment below waist level. Keep all
parts of your body away from the rotating cutting attachment
and hot surfaces.
e) Do not force the power tool. Use the correct power tool
for your application. The correct power tool will do the job
better and safer at the rate for which it was designed, taking
into account the working conditions and the work to be
performed. Use of the power tool for operations different from
intended could result in a hazardous situation.
f) Beware of blade thrust. Blade thrust may occur when the
spinning blade contacts an object that it does not immediately
cut. A blade thrust can be violent enough to cause the product
and/or operator to be propelled in any direction and possibly
lase control of the product. Blade thrust can occur if the blade
snags, stalls or binds. This is more likely to occur in areas
where it is difficult to see the material being cut.
g) Do not use the power tool if the switch does not tum it
on and off. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
h) Tum tool off completely before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
i) Stopping the multi-tool. A coasting blade can cause injury
while it continues to spin after the engine is stopped or the
throttle is released. Maintain proper control until the blade has
completely stopped rotating.
j) Taking care with adjustments. During carburetor
adjustments the cutting attachment may spin. Therefore you
should wear protective equipment and observe all safety
instructions when adjusting the carburetor.
5.
 POWER PRODUCTS LLC.
k) Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power tools
are dangerous in the hands of untrained users.
l) Maintain power tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that
may affect the power tool's operation. If damaged, have the
power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
m) Inspect the product before each use. Replace damaged
parts. Check for fuel leaks. Make sure all fasteners are in
place and secure. Replace cutting attachment parts that are
cracked chipped or damaged in any way. Make sure the
cutting attachment guard is properly installed and in the
position recommended by the manufacturer. NEVER use wire
or wire rope which can break off and become a dangerous
projectile.
n) Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
o) Remove any adjusting key or wrench before turning the
tool on. A wrench or a key that is left attached to a rotating
part of the power tool may result in personal injury.
4) Service
a) Have your power tool serviced by a qualified repair
personnel using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
EFFECTS OF VIBRATION
It is believed that a condition called Raynaud's Phenomenon,
which affects the fingers of certain individuals, may be bought
about by exposure to vibration and cold – it may cause
tingling and burning sensations, followed by loss of colour and
numbness in the fingers.
If you continue to use high-vibration tools these symptoms will
probably get worse, for example:
• The numbness in your hands could become
permanent and you won't be able to feel things at all;
• You will have difficulty picking up small objects such as
screws or nails;
• The vibration white finger could happen more
frequently and affect more of your fingers.
6.
Protecting your Body from Vibration
The following precautions are strongly recommended, because
the minimum exposure, which may trigger the ailment is
unknown.
1. Always use the right tool for each job (to do the job more
quickly and expose you to less hand-arm vibration).
2. Check tools before using them to make sure they have been
properly maintained and repaired to avoid increased
vibration caused by faults or general wear.
3. Make sure cutting tools are kept sharp so that they remain
efficient.
4. Reduce the amount of time you use a tool in one go, by
doing other jobs in between. Try to fill each day with jobs
where operating the unit or other hand-held power
equipment is not required.
5. Avoid gripping or forcing a tool or workpiece more than you
have to.
6. Store tools so that they do not have very cold handles when
next used.
7. If you experience discomfort, redness, swelling of the fingers
followed by whitening and loss of feeling, consult your
physician before further exposing yourself to cold and vibration.
8. Maintain good blood circulation by:
• Keeping your body warm, especially the head, neck,
feet, ankles, hands and wrists.
• Giving up or cutting down on smoking because
smoking reduces blood flow
• Performing vigorous arm exercises during frequent
work breaks.
REPETITIVE STRESS INJURY (RSI)
It is believed that overusing the muscles and tendons of the
fingers, arms, hands and shoulders may cause swelling,
soreness, numbness, weakness or extreme pain in those
areas. Certain repetitive hand activities may put you at a high
risk for developing a Repetitive Stress Injury (RSI).
An extreme RSI condition is Carpel Tunnel Syndrome (CTS)
which can occur when your wrist swells and squeezes a vital
nerve that runs through the area. It is believed that prolonged
exposure to vibration may contribute to CTS. CTS can cause
severe pain for months or even years.
To reduce the risks of RSI/ CTS do the following:

• Avoid using your wrist in a bent, extended or twisted

position. Instead try to maintain a straight wrist
position. Also, when grasping, use your whole hand,
not just the thumb and index finger.

• Take periodic breaks to minimize repetition and rest

your hands.

• Reduce the speed and force with which you do the

repetitive movement.

• Do exercise to strengthen the hand and arm muscles.

• Immediately stop using all your power equipment and
consult a doctor if you feel tingling, numbness or pain
in the fingers, hands, wrists or arms. The sooner RSI/
CTS is diagnosed, the more likely permanent muscle
damage can be prevented.
Gravel, loose stones, etc. can be picked up by the nylon
cutting lines or blade and thrown many feet with enough force
to cause serious personal injury and/or property damage.
Before crossing graveled areas, release the throttle trigger to
stop the cutting line head or blade.

SAFE OPERATING PRACTICES

Be very careful when operating the multi-tool over uneven or
rough ground, and when the ground is wet and slippery.
Watch out for hidden obstacles that could cause you to
stumble. Operate the multi-tool only under conditions with
good visibility. Do not operate the multi-tool where you cannot
see what it is cutting.
! WARNING! Keep all bystanders, especially children
WARNING! Rotating cutting lines can cause serious and pets at least 15m from the operating area.
!
abrasions and cuts, and blades can cut deeply.

• Keep away from the cutting lines or blade whenever BLADE THRUST (KICKBACK)
the engine is running.
Blade thrust (kickback) is the sudden, forceful, and
• Always stop the engine, and be sure the cutting line un-controlled movement of a blade-equipped multi-tool that
head has stopped turning, before inspecting or may occur if the blade binds in the cut or strikes a solid object.
handling the cutting lines or blade. It throws the multi-tool in the direction opposite blade rotation
at the point of contact, and the
jolt received by the operator
can result in further loss
THROWN DEBRIS of control.
The multi-tool will throw debris in the direction of blade
movement at the point of contact.The cutting line head or
blade on the Qualcut multi-tool rotates anti-clockwise as
viewed from the operator's position, so tilting the cutting line
head to the right will throw debris away from you, and tilting to
the left will throw debris towards you.

If the cutting line head or blade is held parallel to the ground,

debris will scatter in all directions, and there will be greater
friction which will wear out the cutting line or blade sooner. Blade
When operating the trimmer near a hard surface such as a thrust
wall, work from an angle where debris that strikes the hard
surface will ricochet away from you.
7.
 POWER PRODUCTS LLC.

To reduce the risk of loss of control: ASSEMBLY

• Replace or re-sharpen dull blades. Dull blades are Main Engine/ Shaft Assembly
more likely to bind in the cut and cause blade thrust.
1. Fit the shoulder strap (8)
• Watch out for hidden obstacles, such as rocks, stumps, to the main shaft (1).
roots, etc., that could cause the blade to kick back if
struck. Blade thrust is more likely to occur in areas 2. Attach the main shaft
where it is difficult to see what is being cut. handle (7) to the shaft (1)
by removing the attaching
• Understand the reaction forces of the blade. the clamp around the shaft
and tightening the bolts.
• When using a brush blade to saw through heavy brush
and small saplings, saw with the side of the brush
blade that is moving toward you and tends to pull the Line Trimmer/ Brush Cutter
multi-tool away from you. Attachment Assembly
• Blades on Qualcut multi-tools rotate counterclockwise, 1. Assemble the safety guard
as viewed from the operator's position. Therefore, the (8) to the lint trimmer/ brush
left side of the blade is moving toward you. Sawing cutter attachment.
with the left side of a brush blade will give you better
control and less risk of kickback, though it will throw the 2. Release the nut. Line up
sawdust toward you. the two holes of flange and
shield. Use screwdriver to
• Cut from the side of saplings that will cause them to fall hold the flange and turn the
away from the multi-tool. This will help prevent the socket wrench clockwise
blade from binding in the cut and kicking back. (G). The nut will be released.

• Accelerate the engine to maximum speed before

starting the cut, and saw through with uniform Fitting the Nylon Cutting Head
pressure.
1. To fit the nylon cutting
head, remove the shield
Operation on Slopes after releasing the nut.
Still holding the flange,
• Start on the low side of a slope, and work upward. This place the nylon cutting
will reduce your risk of slipping and falling, and it will head on the shaft and
give you a cutting angle that will better enable you to rotate counterclockwise
direct debris away from you. (H). The nylon cutting
head is now fitted.
• Do not let the cutting line or blade dig into the slope,
because that can cause stones and dirt to be thrown at 2. To remove the nylon cutting head, use screwdriver to hold
you. flange and rotate clockwise.
• Do not raise the cutting attachment above waist level
during operation, because that would increase the risk Fitting the Blade
of thrown objects striking your face.
1. To fit the blade, take the
• Avoid steep slopes that would require holding the outer flange off after releasing
cutting attachment above waist level. Avoid slippery the main nut, then put the
slopes that might cause you to lose your balance. blade, outer flange shield and
nut according to priority (1).
Note the blade rotation
direction (J). Use screwdriver
to hold flange and tighten nut
counterclockwise. Ensure the
nut is well tightened.
8.
2. To release the blade, use FUEL & LUBRICATION
screwdriver to hold flange
and release nut, the blade
than then be removed.
! WARNING! Petrol is extremely flammable and
explosive. A fire or explosion from petrol will burn you
and others

Mixing the Fuel

This product is powered by a 2 stroke engine and requires

! WARNING! Please make sure the cutting head has
been assembled correctly before use.
Pruning Saw Attachment Assembly
1. Remove the chain cover from the pruning saw attachment
head
2. Fit the bar (5) to the pruning saw head.
3. Fit the saw chain (6) to the bar.
premixing petrol and 2 stroke oil.
The oil mix should be 40:1. Never mix petrol and oil directly
in the engine tank.
Use unleaded petrol intended for motor vehicle use with an
Octane rating of 87 ( [R + M] / 2) or higher. Purchase fuel
from a reputable fuel supplier.
Use the mixing container provided to mix the oil and petrol in
the correct quantities.

4. Adjust the chain tension as necessary. PETROL OIL

5. Replace the chain cover. 1 Litre 25mI

21 Litres 50ml

! WARNING! Please ensure the pruning attachment

= 40:1
31 Litres 75ml
bar/ chain lubrication tank is filled with bar lube oil
before operating. Oil capacity- 150ml. 41 Litres 100ml
51 Litres 125ml

Hedge Trimming Attachment

Assembly
1. The hedge trimming attachment comes pre-assembled and is
ready for use. All that is required for operation is the cutting head
to be set to the desired angle and set in place. Then remove the
safety covers from the cutting blades.
Assembling Attachments to Main
Engine Shaft
1. Loosen the shaft coupling handle and release the locking
catch.
Mix only enough fuel for your immediate needs.
Fuel should not be stored for more than 30 days.
Follow these steps to mix the fuel:
1. Use the container provided for mixing fuel.
2. Mix the 2 stroke engine oil with unleaded petrol in the
container provided at the rate of 40 parts petrol to 1 part
oil.
3. Mix the fuel thoroughly and also each time before
re-fuelling.
4. Mix in small quantities. Do not mix more fuel than you
expect to use within a 30 day period.

2. Slide the attachment shaft into the attachment shaft,
ensuring the main shaft locating pin lines up with the hole in
the attachment shaft. Check the drive spline on the motor
drive shaft has located correctly into the attachment drive
shaft. This may require the attachment head or the engine
to be rotated slightly.
3. Replace the locking catch into place and tighten the shaft
coupling handle.
5. Store fuel only in a clean, safe, approved container for
petrol - DO NOT store fuel in the fuel mixing bottle
provided.
! WARNING! Always stop the engine before filling the
tank. Never add fuel to a machine with a running or hot
engine.
9.
 POWER PRODUCTS LLC.

STARTING CHECKLIST STARTING THE MULTI-TOOL

IMPORTANT: Do not start the unit until it has been
completely assembled. Before switching on the unit, always
check the oil.
Check Machine before Use
Check the safety condition of the device:
1. Check the machine for leaks.
2. Check the machine for visual defects.
3. Check that all parts of the machine have been securely
fitted.
4. Check that all safety devices are in proper condition.
! WARNING! Do not operate this machine if you have
found any faults. To operate this machine with faults
could result in serious injury. Make sure to replace
faulty parts before using the machine again.
Adjusting the Harness
Check the safety condition of the device:
1. Check the machine for leaks.
2. Check the machine for visual defects.
3. Check that all parts of the machine have been securely
fitted.
4. Check that all safety devices are in proper condition.
Starting the product depends on whether the engine is cold or
warm.
! WARNING! The recoil starter can be damaged by
abuse.
- Never pull the starter cord to its full length.
- Always engage the starter before cranking the engine.
- Always rewind the starter cord slowly.
Once the machine has been correctly assembled and setup for
operation, start the engine as follows:
1. Press the fuel primer bulb (6) 8 times or until no air bubbles
are flowing through the primer bulb.
2. Turn the engine switch (9) in the on position
3. Move the carburettor choke lever (2) to the ‘on’ position.
4. Pull the recoil starter handle (4) slowly until it engages, then
pull briskly. Repeat this step until the engine fires and starts
running.
5. Once the engine is warmed up after a few seconds, adjust
the choke lever (2) back to the ‘off’ position.
6. To control the engine speed, hold down the safety catch
(10) on the shaft handle (11) and pull the throttle trigger (12).
When re-starting a warm engine (that has already been
running), choke activation is not required.

Single-strap
Shoulder Harness

Quick-release
Latch

Balancing the Multi-tool on the

Shoulder Harness
1. Hang the machine on the harness hook, and see how it
balances.

2. Adjust the shoulder strap (8), the harness attachment on

the engine extension tube and the shaft handle (7) so the
attachment head balances at the required height.
10.
To Start a Flooded Engine
1. Disconnect the spark plug boot and use the spark plug
wrench supplied to remove the plug in a counter-
clockwise direction.
2. If the spark plug is fouled or is soaked with fuel, clean or
replace the plug as required.
3. Turn the product so that the spark plug hole is aimed at
the ground.
4. Clear excess fuel from the combustion chamber by
cranking the engine several times while the spark plug is
removed.
5. Install the spark plug and firmly tighten it with the spark
plug wrench supplied. DO NOT OVERTIGHTEN.
6. Reconnect the spark plug boot. Incorrect spark plug
installation can result in serious engine damage.
! WARNING! Incorrect sparkplug installation can result
in serious engine damage.
Stopping the Engine
1. Cool the engine by allowing it to run at idle for 2-3
minutes.
2. Slide the ON/OFF switch to the OFF position.
OPERATING THE MULTI-TOOL
Follow these steps to operate the multi-tool:
1. Remove blade guard from the blade.
2. Start the multi-tool.
3. Hold the multi-tool at waist level with your right hand (arm
extended) on the trigger handle and your left hand on the
front handle.
4. Place the product on the right side
of your body with the engine
behind and away from your body.
5. Brushcut weeds and vines in a
right-to-left motion with the blade
parallel to the ground.
Refer to pages 7 and 8 for more
information.
! WARNING! Do not cut with a dull, cracked or
damaged metal blade. Before cutting growth, inspect
for obstructions such as rocks, metal stakes or strands
of wire from fences. If an obstruction cannot be
removed, mark its location so that you can avoid it with
the blade. Wires can catch on the blade head and be
thrown in the air.
! WARNING! Do not touch these types of objects with
the blade.
MAINTENANCE
Suitable care & maintenance is essential for effective and
trouble free operation of your Qualcut RA0043LS-VII Multitool.
Failure caused by lack of, or incorrect, care and maintenance
is not covered under warranty. Some basic tips are outlined in
the following section. It is recommended that unless the
operator is experienced and skilled in the maintenance and
repair of outdoor power equipment, maintenance and servic-
ing is carried out by an authorised Qualcut Service Agent.
Service Agents also have access to the full range of genuine
parts and accessories available for the product. Please
contact the Euroquip support office for details of your nearest
service agent.
WARNING! Before performing any maintenance on
!
this machine, stop the engine and disconnect the
sparkplug.
Before Each Use:
• Inspect the engine, tank and hoses for possible fuel
leaks and repair as necessary.
• Inspect the engine cooling fins for accumulation of
debris and clean as necessary.
• Inspect the entire machine for damage, loose and
missing components or fasteners and repair as
necessary.
11.
 POWER PRODUCTS LLC.

Cleaning the Product ! WARNING! Depending on the type of fuel used,

• Stop the product before cleaning.
• Clean the exterior of the product with a damp cloth.
• Avoid using solvents when cleaning plastic parts.
Most plastics are susceptible to damage from various
types of commercial solvents and may be damaged
by their use.
the type and amount of oil used and/or your
operating conditions, the exhaust port and muffler
may become blocked with carbon deposits. If you
notice a power loss with your petrol powered tool
you may need to remove these deposits to restore
performance. We highly recommend that only
qualified service technicians perform this service.

• Scrape debris away from air intake vents on both

sides of the motor housing. THE AIR FILTER

! WARNING! When replacing parts other than engine or

emissions parts, use only Qualcut replacement parts.
Use of any other parts may create a hazard or cause
product damage.

Service Procedure
Fuel Tank Assembly (includes Fuel Lines,
Fuel Cap and Fuel Filter): Inspect before each use
Clean Air Filter: Every 10 - 15 hours or yearly
Replace Spark Plug: Every 10 - 15 hours or yearly

Cleaning the Air Filter

THE SPARK PLUG
The Qualcut RA0043LS-Vll uses the following sparkplugs:
NGK LD L8RTF Torch BM6A Champion CJ82.
Replacing the Spark Plug
NOTE: Before removing the spark plug, thoroughly clean the
spark plug and cylinder head area.
Follow these steps to replace the spark plug:
1. Ensure the engine is cool before servicing the spark plug.
2. Remove the spark plug boot.
3. Loosen the spark plug by turning it counter clockwise with
a socket.
Follow these steps to clean the air filter:
1. Stop the engine.
2. Remove the spark plug boot.
3. Loosen the air cleaner cover by turning the knob counter
clockwise.
4. Remove the air filter cover.
5. Remove the air filter element.
6. Inspect the element. If the element is distorted or
damaged replace it with a new one.
7. Wash the element in clean fuel and squeeze or blow dry.
8. Wash the air cleaner in clean fuel and wipe or blow dry.
9. Rinse the air filter and let it dry completely.
10. Work two drops of oil into the air filter.
11. Replace the air filter (fits only one way).
12. Replace the air filter cover.

4. Remove the spark plug. 13. Tighten the air filter cover by turning the knob clockwise.

5. Hand thread the new spark plug, turning it clockwise. Do 14. Replace the spark plug boot.
not over tighten.

CAUTION: Be careful not to cross-thread the spark plug. ! WARNING! Keeping air intake vents free of grass and
Cross threading will seriously damage the product. debris prevents motor overheating and possible failure.
12.
THE LINE TRIMMER HEAD
! WARNING! Read and understand these operating
instructions, as well as the information supplied with
your machine, and follow all warnings and safety
instructions. Failure to do so can result in serious injury
to the operator and/or bystanders.
• To advance the nylon line, bump the downward
protruding button onto the ground while maintaining
engine speed.
• Do not bump the head to attempt to feed line when
operating the machine above 4500 revolutions per
minute.
• Optimum cutting speed is approximately 5000
revolutions per minute.
• If the head does not properly extend nylon line, check
the head for damage and rewind cutting line.
5. Wind the line firmly with one strand on either side of the
center divider according to the directional arrow indicated
on the spool (Fig 3).
6. Hook the line strands to the line holding notches on one
of the outer flanges of the spool. This will help to hold the
line in place while the spool is installed in the body of the
head (Fig 4). Leave 4 - 6 inches of the lines protruding
from the notches.
7. The tension spring should stay in the housing hub. Put
the spool onto the housing, positioning it to move up and
down freely against the spring tension.
8. Put the lines into the respective eyelets (Fig 5 & 6).
9. Put the cover onto the housing, aligning the locking tabs
on the cover. Make sure the tabs are fully locked into
place in the cover (Fig 7).
Fig 3.

Fig 1.

Fig 4.
Leave 4-6 inches of lines from the notch.
Fig 2. Leave approx.
3 inches

NOTE: Do not let the lines loosen.

There are 2 holes on spool drum
Fig 5.
Rewinding the Head
1. Remove the cover by depressing the locking tabs located
180 degrees opposite of each other (Fig 1).
2. Remove the line spool from the housing.
3. Fold 18ft. of cutting line in two halves, leaving one half 3
inches longer than the other, (the three additional inches
will make the line even on both sides of the head when NOTE: Do not let the lines loosen.
wound on the spool).
4. The spool is divided in the center and has a slot to
accommodate the folded portion of the nylon line (Fig 2).
13.
 POWER PRODUCTS LLC.

Fig 6. Mark for usable limit on cover. STORING YOUR MULTI-TOOL

Storing the product differs depending on the amount of time
it will be in storage.

Follow these steps to store the product short term:

1. Clean all foreign material from the product.
2. Store in a well-ventilated place that is inaccessible to
Slit on eyelet part. children.

If you do not intend to use the product for more than one
Fig 7. month, follow these steps to store the product long term:

1. Drain all fuel from tank into a container approved for

petrol.
2. Run the engine until it stops.
3. Clean all foreign materials from the product.

IMPORTANT! The latches fully spread
in the windows. (Shaded area)
THE CHAINSAW PRUNING
ATTACHMENT
• Ensure chain is kept well sharpened and replaced when
worn.
• Replace guide bar and chain drive sprocket when worn.
• Use only designated, fresh chain bar lubricant in the bar
lubricating system.
• Check and adjust chain tension every hour of operation
and following first 10 minutes of operation with a new
chain.
• Do not allow the chain to come in contact with any other
object other than wood while performing a cut, as this will
blunt/ damage the chain immediately.
4. Remove the spark plug boot, and then the sparkplug.
5. Pour approximately 5ml oil into the cylinder through the
sparkplug hole.
6. Pull the recoil starter 2 or 3 times to distribute the oil over
the cylinder walls.
7. Reinstall the spark plug. Follow the instructions for
sparkplug replacement.
8. Reconnect the spark plug boot.
9. Store the product in a well-ventilated place that is
inaccessible to children.
CAUTION: Keep the product away from corrosive agents
such as garden chemicals.
IMPORTANT: Abide by all federal and local regulations for
the safe storage, handling and disposal of petrol. Never
store this product with any fuel remaining in the tank, fuel
lines or carburettor. Your warranty does not include
coverage for damage covered by stale or contaminated
fuels.

THE HEDGE TRIMMER

ATTACHMENT
• Ensure blades are kept sharp and covered when not in
use.
• Ensure gearbox and blades are regularly lubricated with
quality lithium based grease.
• Check and adjust correct blade clearance regularly.

14.
TROUBLESHOOTING

15.
 POWER PRODUCTS LLC.

PARTS LIST

RA0043LS-V2
Please quote the above part number when ordering parts.

S0043-A14 Engine Air Filter Element

S0043-A3 Upper (Engine end) Drive Shaft - 763mm
S0043-A3-2 Shaft Connector Assembly
S0043-A37 Recoil Starter Engagement Cup
S0043-A39 Recoil Starter Assembly
S0043-A51 Spark Plug
S0043-A67 Engine Fuel Cap (Suits RA0043LS, RA330ST)
S0043-B1 Complete Engine Assembly including Clutch Housing
S0043-B3 Shaft Assembles Complete
S0043-B3-6 Lower (Attachment) Drive Shaft - 767mm
S0043-B4-13 3 Tooth Blade
S0043-B4-4 Brush Cutter Guard Assembly Complete
S0043-CS Chainsaw Attachment
S0043-D25 Chain Bar Lube Tank Cap
S0043-D34 Chain Drive Sprocket
S0043-D37 Chainsaw Bar
S0043-D38 Chainsaw Chain 10"
S0043-D39 Chainsaw Bar Cover
S0043-D64 Engine Fuel Filter
S0043-HT Hedge Trimmer Attachment
S0043-LH Line Head
S0043-LT RA0043LS Line Trimmer Attachment Complete
S0043-TC Throttle/ Control Handle Assembly

16.
WARRANTY
Whilst every effort is made to ensure your complete satisfaction with
this tool, occasionally, due to the mass manufacturing techniques, a
tool may not live up to our required level of performance and you may
need the assistance of our service department.
This product is warranted for a 12 month period for home domestic
use from the date of the original purchase. If found to be defective in
materials or workmanship, the tool or the offending faulty component
will be replaced free of charge with another of the same item. A small
freight charge may apply. Proof of purchase is essential.
We reserve the right to reject any claim where the purchase cannot
be verified. This warranty does not include damage or defects to the
tool caused by or resulting from abuse, accidents, alterations or
commercial or business use. It also does not cover any bonus items
or included accessories. Only the chainsaw is covered under this
warranty.
Please ensure that you store your receipt in a safe place. Conditions
apply to the above warranty.
1. DURATION: The manufacturer warrants that it will repair or
replace, at no charge for parts or labour, the QUALCUT
RA0043SL Multi-tool, if proven defective in material or
workmanship, during the following time period(s) after date of
original retail purchase:
For1 Year:
The QUALCUT RA0043LS-Vll Multi-tool (excluding accessories)
2. WHO GIVES THIS WARRANTY {Warrantor):
EUROQUIP
109 Bolt Road Stoke, Nelson, New Zealand 7011
Service Line ++64 3 547 8409
3. WHO RECEIVES THIS WARRANTY (Purchaser):
The original purchaser of this QUALCUT RA0043SL Multi-tool.
4. WHAT IS COVERED UNDER THIS WARRANTY:
Defects in material and workmanship which occur within the
duration of the warranty period.
5. WHAT IS NOT COVERED UNDER THIS WARRANTY:
A. Implied warranties, including those of merchantability and
FITNESS for a particular purpose are limited in duration to this
express warranty. After this period, all risks of loss, from
whatever reason, shall be on the purchaser.
B. ANY INCIDENTAL, INDIRECT, OR CONSEQUENTIAL LOSS,
DAMAGE, OR EXPENSE THAT MAY RESULT FROM ANY
DEFECT, FAILURE OR MALFUNCTION OF THIS PRODUCT.
C. This warranty does not apply to any accessory or consumable
items included with the product which are subject to wear from
usage; the repair or replacement of these items shall be at the
expense of the owner. These items include, but are not limited
to: blades, sparkplugs, nylon heads, safety guards, etc. In
addition, this warranty does not extend to any damage caused
by the untimely replacement or maintenance of any of the
previously listed CONSUMABLE parts.
D. Any failure that results from accident, purchaser's abuse,
neglect or failure to operate products in accordance with
instructions provided in the owner's manual(s) supplied with the
product.
E. Pre-delivery service, i.e. assembly and adjustment.
6. RESPONSIBILITIES OF WARRANTOR UNDER THIS
WARRANTY: Repair or replace, at Warrantor's option,
products or components which have failed within duration of the
warranty period.
7. RESPONSIBILITIES OF PURCHASER UNDER THIS
WARRANTY:
A. Please call your re-seller or the number listed above for
warranty assistance.
B. Provide dated proof of purchase and maintenance records.
C. All machines must be delivered or shipped to the nearest Service
Agent or re-seller. Freight costs, if any, must be borne by the
purchaser.
D. Use reasonable care in the operation and maintenance of the
products as described in the owner's manual(s).
E. No warranty costs incurred will be considered for, or covered if
Euroquip has not been contacted and prior permission for repair
I replacement has been granted.
8. WHEN WARRANTOR WILL PERFORM REPAIR OR
REPLACEMENT UNDER THIS WARRANTY:
Repair or replacement will be scheduled and serviced according to
the normal work flow at the servicing location and depending on the
availability of replacement part.
17.
 POWER PRODUCTS LLC.

18.
19.
Congratulations on your new Qualcut product.
We are proud to have you as our customer
and will strive to provide you with the best
service and reliability in the industry. This
product is backed by our extensive warranty
and world-wide service network.

Euroquip NZ: 0800 387 678,

Euroquip Australia: 1-800-040947
service@euroquip.co.nz
