Seaboard International

Wellhead Equipment and Gate Valves

API 6A and ISO 9001:2000

Contents

Casing Heads and Spools

S-22 Casing Heads and Spools .............................................................................................. 1-2
Fas-Loc Wellhead System ....................................................................................................... 3
SMB-22 Multibowl System ....................................................................................................... 4
SS-L Buttweld Sub and CMH Hanger System ......................................................................... 4

Tubing Heads, Casing Hangers, Secondary Seals

S Tubing Heads ....................................................................................................................... 5
SD Tubing Heads ..................................................................................................................... 5
SP, SP-H, and IP Secondary Seals ......................................................................................... 5
S-22 Casing Hangers ............................................................................................................... 6
S-22-NL Casing Hangers ......................................................................................................... 6
S-22-HL Casing Hangers ......................................................................................................... 6

Tubing Completion Systems

SM-E Tubing Hangers .............................................................................................................. 7
SM-T Tubing Hangers .............................................................................................................. 7
SM-E-CL Tubing Hangers ........................................................................................................ 8
SM-T-CL Tubing Hangers ........................................................................................................ 8
ESP Feed Through Systems ................................................................................................... 9
SD and SD-CL Dual Completion Hangers ............................................................................... 9
Tension Tubing Hangers ......................................................................................................... 10
Slim Line Tubing Hangers ....................................................................................................... 10

Specialty Equipment
Communication Slick Joint ...................................................................................................... 11
NW-A Casing Heads .............................................................................................................. 12
NW-B Diverter Heads ............................................................................................................. 12

Gate Valves
Model 500 Wedge Gate (3M/5M) ..........................................................................................13-14
Model 1520 Wedge Gate (10M)............................................................................................ 13-14
Model 1540 Wedge Gate (10M/15M) ..................................................................................... 15
Model 1540S Slab Gate (20M) ............................................................................................... 16
Model 640 Slab Gate (3M/5M) ................................................................................................ 17
Model 1640 Slab Gate (10M/15M) .......................................................................................... 17
Gate Valve Trim Chart ............................................................................................................. 18

Cover photograph courtesy of Jack Richburg Photography. Catalog and contents © Seaboard International.
 Developing innovative

S-22 Casing Heads and Spools

The Seaboard conventional wellhead system incorporates the S-22
straight bowl design with a 45 degree load shoulder.

Significant advantages of the S-22 bowl:

• One bowl design that universally accepts slip-type or mandrel casing hangers
• Low-weight hangers for tieback applications and high capacity hangers are also accommodated due to
the straight bowl and 45 degree load shoulder which diminishes hoop stress on the casing heads and
spools
• Design concept is carried forward into the Fas-Loc and SMB-22 multibowl systems for component
interchangeability and retention of superior design characteristics
• Damage during drilling activities is minimized, thereby decreasing the frequency of maintenance and/
or potential replacement
• Wear bushings can enhance the protection of important sealing surfaces
• Test plugs and wear bushings often wedge in tapered bowls under pressure, a possibility virtually
eliminated with the S-22 bowl design

1
wellhead systems and quality gate valves for over 30 years

System Features
• Scope
o 2,000 through 20,000 PSI
o API 6A PSL-1 through PSL-4
o Appendix F Qualified
• Top Connections S-22-R
S-22-R S-22-AP
S-22-AP
o API Flanges
o API Hubs
• Bottom Connections
o Threaded
o Slip-on Weld
o NW-A Sliplock
o Baseplates (Welded or threaded)
• Secondary Seals - Casing Spools
o Elastomer Seal Bushings (SP)
o High pressure Seal Bushings (SP-H)
o Integral Seal Bottoms (IPS) Lockscrew Detail
• Lockscrews (optional)
• Outlets
o Threaded
o Studded
S-22 Casing Spool Sizing Data
o Flanged
Rated Working Bottom Flange Top Flange Minimum Weight
Pressure Size (in.) PSI Size (in.) PSI Bore (in.) (lbs.)
3,000 psi 11 3,000 11 3,000 10.00 745
13-5/8 3,000 11 3,000 10.00 1050
16-3/4 3,000 11 3,000 10.00 1145

S-22 Casing Head Sizing Data 16-3/4 3,000 13-5/8 3,000 12.50 1170
21-1/4 2,000 13-5/8 3,000 12.50 1450
Rated Working Casing Top Flange Minimum Weight 20-3/4 3,000 16-3/4 3,000 15.38 2710
Pressure Size (in.) Size (in.) PSI Bore (in.) (lbs.) 5,000 psi 11 3,000 11 5,000 10.00 760
2,000 psi 20 21-1/4 2,000 19.00 1,550 11 5,000 11 5,000 10.00 1250
3,000 psi 8-5/8 11 3,000 8.00 470 13-5/8 3,000 11 5,000 10.00 1260
9-5/8 11 3,000 9.00 450 13-5/8 5,000 11 5,000 10.00 1395
10-3/4 11 3,000 10.00 430 16-3/4 3,000 11 5,000 10.00 1220
13-3/8 13-5/8 3,000 12.50 645 16-3/4 3,000 13-5/8 5,000 12.50 1325
16 16-3/4 3,000 15.38 825 20-3/4 3,000 13-5/8 5,000 12.50 2530
20 20-3/4 3,000 19.00 1,640 20-3/4 3,000 16-3/4 5,000 15.38 3005
5,000 psi 8-5/8 11 5,000 8.00 720 21-1/4 5,000 13-5/8 5,000 12.50 2840
9-5/8 11 5,000 9.00 617 21-1/4 5,000 16-3/4 5,000 15.38 3305
10-3/4 11 5,000 10.00 600 10,000 psi 13-5/8 5,000 11 10,000 10.00 2190
13-3/8 13-5/8 5,000 12.50 675 16-3/4 5,000 11 10,000 10.00 2380
16 16-3/4 5,000 15.38 1,655 16-3/4 5,000 13-5/8 10,000 12.50 2905
20 21-1/4 5,000 19.00 1,825 21-1/4 5,000 13-5/8 10,000 12.50 3365

2
 Developing innovative

Fas Loc
The Fas-Loc wellhead system was developed to meet all of the needs of conventional equipment while reducing
much of the associated time, costs and risks. The Fas-Loc wellhead system significantly reduces rig time and
associated rig costs over those utilizing conventional wellhead equipment. For multiple well programs, the
diverter adapter and BOP service adapters may be transferred from well to well, eliminating the time required to
nipple up and down between locations. Safety is enhanced with the Fas-Loc casing head by eliminating the
requirements for torch cutting and welding operations normally associated with casing head installation. Another
time saving feature is the ability to land the casing head through the BOP, eliminating the need to wait on
cement. The Fas-Loc casing head bowl is designed to accept standard slip hanger arrangements. Further
reducing time, the Fas-Loc tubing head makes up quickly without special tools. The Fas-Loc wellhead system
easily adapts to accommodate intermediate casing strings according to the requirements of the drilling program.

• Overall system designed to save time/rig costs

• Dedicated diverter adapter

o Transfers from well to well
o Makes up quickly with no special tools

• Dedicated BOP service adapter

o Transfers from well to well
o Makes up quickly with no special tools

• Increases safety by eliminating torch cutting/

welding operations for casing head installation

• Fas-Loc casing head is landed through BOP

o Eliminates waiting on cement

• Fas-Loc casing head accepts standard slip

hanger arrangements

• Fas-Loc tubing head makes up quickly without

special tools

• Fas-Loc tubing head accepts any Seaboard

tubing hanger arrangement

• Fas-Loc system easily adapts to accept

intermediate casing string/spool if needed

3
wellhead systems and quality gate valves for over 30 years

SMB-22 Multibowl Systems

SS-L Buttweld Sub and CMH Hanger System
Installing and removing the BOP stack is a time
consuming procedure performed each time a
conventional head or spool is added during drilling
operations. During BOP removal, there is a potential
for disaster either through a blowout or injury to the
drilling crew. The compact SMB-22 multibowl wellhead
system eliminates the need for one nipple up by landing
multiple casing strings in one head.
The SMB-22 multibowl wellhead assembly is a full-
bore design. The lower casing hanger is fluted to allow
ample by-pass for circulating mud and cement. The seal
assembly, which lands on the flutes, also acts as a
support for the upper hanger. A wide choice of tubing
hanger designs are available for various service
conditions.
Emergency suspension systems are available for the
lower hanger.
The SS-L buttweld sub and CMH hanger is a versatile
wellhead system offering a flanged and non-flanged
means of nippling up a diverter system. Conductor and
surface casing can be run through the diverter, thus
saving time (one less nipple down), money, and safety.
Rig time is saved by utilizing the SM-E mandrel hanger
for the surface casing, which allows for faster installation
of a conventional wellhead, or multibowl system,
because no welding is required. The SS-L buttweld
sub system is flexible to most casing programs and
offers emergency equipment options.

Additional Features:
• Conductor hanger may be tested externally
once landed
• Conductor hanger seals may be re-energized,
if necessary
• Surface casing hanger may be landed prior to
cementing, eliminating the need to reciprocate
• Annular seal for surface casing hanger may
be run through the diverter, locked in place
(flanged diverter head) and tested externally
• Annular seal for surface casing hanger may
be re-energized, if necessary
• All running/retrieving tools run on casing

4
 Developing innovative

S Tubing Heads
The S tubing head is designed to be full opening
even over 7-5/8” casing. The straight bowl and
45° load shoulder allows the use of one bowl
design for virtually all applications. A variety of
single and dual tubing hangers are available for
a wide array of service conditions and operating
preferences.
Multiple Completion Options
SD dual tubing heads are equipped with two
MC (multi-completion) guide pins located 180°
apart just above the 45° load shoulder. When
landing the dual tubing hanger, the MC guide
pins are run in to orient the tubing hanger
segments.
Tubing Head Bottom Connections
Standard bottom preparations for tubing heads
include single or double IP seals, SP or SP-H
packoff bushings. For IP secondary seal
configurations, the tubing head provides
injection ports through which plastic can be
injected to enhance the IP seal.

S Tubing Head

SP, SP- H, and Double IP Seals

SP SP- H Double IP
Secondary Seal Secondary Seal Secondary Seal

The SP seal is a simple press energized design comprised of an elastomer element sandwiched between two
compression plates. The assembly is retained in the pocket with a snap ring.
The SP- H seal is similar in design to the SP, but is better suited for use in higher pressure applications. The
assembly is retained in the pocket by a threaded ring.
The Double IP seal is ideal for use as crossover where moderately severe service is expected. Each seal is
plastic energized, which can also be tested via a port located between the seals to verify seal integrity.

5
wellhead systems and quality gate valves for over 30 years

S-22 Casing Hangers

The S-22 casing hanger is a slip style hanger which
automatically seals the casing annulus.
During installation, the hanger is wrapped around the
casing and the slip retaining screws are removed,
allowing the slips to ride down the internal taper. As
the casing slides through the hanger, the segmented
slips grab and wedge between the tapered bowl and
the casing. The annulus seal below the bowl is
automatically energized by the weight of the casing as S-22 Casing Hanger
it is transferred through the slips to the 45° load shoulder
in the head or spool.
Minimum Casing Loads for
S-22 Casing Hangers
Casing Bowl Sizes
Casing weight must meet or exceed those listed in the
Size 11” 13-5/8” 16” 20”
chart to the right. If the minimum weight is not met, the
elastomer seal may not extrude sufficiently to seal 4-1/2” - 5-1/2” 55,000
against the casing’s surface. If the casing weight is in 7” - 7-5/8” 40,000
excess of 50% of the casing joint strength, the seal 8-5/8” - 9-5/8” 58,000
may over-extrude and become ineffective. Alternate 10-3/4” 77,000
hangers are available for these conditions. 13-3/8” 150,000

The S-22-NL casing hanger is appropriate for no load

or mudline applications. The slips are set by pulling
slight tension on the casing. When the tension is
released, the slight casing movement sets the slips.
The annulus seal above the slips is energized manually
after the BOP stack is removed.

S-22-NL Casing Hanger

The S-22-HL casing hanger accommodates loads in

excess of 50% of the casing joint strength. The double
wedge back slip design permits the same length of slip
to support a higher load without impinging the casing.
The design also features a positive stop which limits
extrusion of the seal.

S-22-HL Casing Hanger

6
 Developing innovative

Single Completion Tubing Hangers and Adapters for Land Installations

SM-E Tubing Hangers

The SM-E tubing hanger is a versatile design using
elastomer seals. The hanger can be equipped with a
suspension style control line preparation and isolation
seals on the neck to accommodate traditional control
line porting through the adapter. The control line porting
can be used or ignored without affecting the functioning
of the tubing hanger.
The tubing hanger consists of a main body, an
elastomer seal and a compression/support ring. The
annulus seal is automatically energized by the weight
of the tubing string. Extrusion of the seal is controlled
by a positive stop between the compression/support
ring and the hanger body. If the tubing weight is not
sufficient to extrude the seals, it will be energized by
the lockscrews used to retain the hanger in the bowl.
An internal profile is provided for setting a back pressure
valve.

SM-E Tubing Hanger

SM-T Tubing Hangers

The SM-T tubing hanger uses a metal taper design on
the hanger’s neck to isolate the production flow. Metal
seals are far superior to elastomers making this hanger
suitable for more critical service applications.
During installation, the hanger is landed and the
lockscrews run in to retain the hanger and energize
the annulus seal. The metal seal on the hanger neck is
energized by making up the adapter. The taper on the
ID of the adapter slightly opposes the OD of the tubing
hanger neck, causing the neck to deform slightly. This
deformation is safely within the elastic limits of the yield
strength of the hanger material, permitting the
connection to be broken and remade repeatedly without
damaging the sealing surfaces.
An internal profile is provided for setting a back pressure
valve.

SM-T Tubing Hanger

7
wellhead systems and quality gate valves for over 30 years

Single Completion Tubing Hangers and Adapters for Offshore Installations

SM-E-CL Tubing Hangers

The SM-E-CL tubing hanger provides a continuous
control line setting using elastomer seals in the both
hanger bowl and hanger neck.
The tubing hanger consists of a main body, an
elastomer seal and a compression ring. During
installation, the hanger is landed and the lockscrews
run in to retain the hanger and energize the annulus
seal. The neck of the tubing hanger uses S seals to
seal against the straight bore of the adapter.
The continuous control line is supported and sealed
above and below the hanger with common ferrule-type
fittings. The control line exits through the adapter and
is sealed off in a specially designed exit block (shown)
or nipple/tapped bull plug arrangement.
An internal profile is provided for setting a back pressure
valve.

SM-E-CL Tubing Hanger

SM-T-CL Tubing Hangers

The SM-T-CL tubing hanger provides a continuous
control line setting while using metal seals in the hanger
neck to isolate the production flow. Metal seals are far
superior to elastomers making this hanger suitable for
more critical service applications.
The tubing hanger consists of a main body, an
elastomer seal and a compression ring. During
installation, the hanger is landed and the lockscrews
run in to retain the hanger and energize the annulus
seal. The metal seal on the hanger neck is energized
by making up the adapter. The taper on the ID of the
adapter slightly opposes the OD of the tubing hanger
neck, causing the neck to deform slightly. This
deformation is safely within the elastic limits of the yield
strength of the hanger material, permitting the
connection to be broken and remade repeatedly without
damaging the sealing surfaces.
The continuous control line is supported and sealed
above and below the hanger with common ferrule-type
fittings. The control line exits through the adapter and
is sealed off in a specially designed exit block.
SM-T-CL Tubing Hanger An internal profile is provided for setting a back pressure
valve.

8
 Developing innovative

ESP Feed Through Systems

When the oil is heavy or reservoir pressure is depleted,
it is often necessary to resort to artificial lift methods
for bringing the oil to the surface. A commonly used
device is the electric submersible pump.
The pump is made up into the bottom of the tubing
string as it is run in the hole. An electric cable, which
will eventually transmit power to the pump, is run side
by side with the tubing string. The ESP tubing hanger
is eccentrically aligned, offsetting the tubing string to
allow passage of the electric cable through the hanger
to the outside. A mandrel with a uniquely designed,
pigtail style electric plug connector on each end creates
a totally sealed conduit for passing the electricity from
the outside power source through the wellhead housing
and into the production annulus.
ESP equipment is designed for hostile environments
and can be adapted for temperatures up to 350°F,
pressures up to 10,000 psi and for highly corrosive
service.
Adapter Assemblies
ESP systems are often used in rework applications.
Adapter assemblies are available in common sizes and
pressure ratings to connect to existing wellheads
without removing the tubing head. They are completely
compatible with the ESP hangers and mandrels and
provide the simplest method for converting a well to an
ESP system.

SD and SD-CL Dual Completion Tubing Hangers

Dual completion tubing hangers are segmented designs
available for both offshore and onshore applications
(with or without continuous control lines). Both designs
can be used in the SD tubing head.
The annulus seal is energized by running in the
lockscrews after both hanger segments are landed. The
SD-CL hangers provide a control line nipple which
supports and seals the control line while protecting it
from the extrusion seal. Both the SD and SD-CL designs
use seal subs which are installed after the hanger is
landed to seal on the dual adapter.
An internal profile is provided in each hanger segment
for setting a back pressure valve.

9
wellhead systems and quality gate valves for over 30 years

Tension Tubing Hangers

The Tension tubing head and hanger system was
designed to allow the tubing string to be lowered into
the production casing in order to provide an overpull
of the string weight prior to engaging the load pins in
the landed position. This compensates for elongation
due to temperature variations during the completion
of the well to ensure that the tubing string is not
exposed to buckling that can occur with conventional
tubing hanger applications. Tension tubing hangers
utilize an MRS metal seal between the hanger neck
and adapter to isolate the production flow. A continuous
control line feature is standard with the Tension tubing
hanger system that allows the control line to exit
through the adapter and be sealed in a specially
designed exit block. The Tension tubing head and
hanger system is available in applications up to 20,000
psi and all API trim levels.
Additional Features:
• Fluted thru-bore Tension hanger available for
liquid or N2 type annular completions
• BOP slick joint utilized to maintain N 2 in
annulus during hanger completion
• DHCV pressure controlled during completions

Slim Line Tubing Hangers

The SL tubing hanger system is designed for use over
TLC (Tubingless Completion) equipment. Once
production through a larger tubing string begins to slow,
the operator may choose to install a smaller tubing string
in order to continue lifting fluids. In this application, the
SL tubing head can be installed between the TLC
adapter and lower master valve. The SL tubing head
features a retractable tag pin that allows for full opening
bore for passage of back pressure valves and ensures
positive tubing hanger location. The SL tubing hanger
is landed through the tree, secured in place and may
begin taking production. If so desired, the operator may
also choose to utilize a crossover adapter in order to
install a smaller bore tree over the installed SL tubing
hanger.

10
 Developing innovative

Communication Slick Joint

The Communication Slick Joint was designed to allow

operators to reciprocate tubing up to 24 feet for
displacement during completion or de-completion of a
well where hydraulic control lines are necessary for
downhole control valves. An annular seal is maintained
with the S wrap around tubing hanger, and an external
shroud provides protection for the DHCV line during
controlled reciprocation while under pressure.

Additional Features Include:

• Separate suspension nut eliminates galling
during installation and allows for easy make-
up without requiring the rotation of the tree

• PolyPak ® seals separate DHCV ports,

expediting installation and maximizing years
of trouble-free service

• Metal seal between coupling and adapter

provides leak-proof integrity

• External fitting allows testing of flow bore seal

• Modular two piece design allows for

disassembly and seal access without
disturbing tubing

• Shroud has an integral stop to prevent over

extending during reciprocation

• Available for working pressures through

15,000 psi

11
wellhead systems and quality gate valves for over 30 years

NW-A and NW-B Connectors

Shutting in a production platform during installation of welded casing and diverter heads is costly, yet necessary
for the safety of personnel and the environment. The only safe way to continue platform activities uninterrupted
is to use an alternative connection method which requires no open flame. The NW series of diverter and casing
heads provides a simple, safe and reliable solution to this problem.

Casing Heads
The NW-A casing head consists of a standard S-22 bowl with a manually locked slip mechanism. The seal
between the conductor and the wellhead is achieved with injectable elastomers.

NW-A Casing Head

Diverter Heads
The NW-B diverter head consists of a full-open bore and friction pin locking mechanism which makes the head
easily removable. The low pressure seal is formed by injectable elastomers.

NW-B Diverter Head

12
 Developing innovative

Model 500 Gate Valves

Seaboard International Model 500 gate valves are designed with an expanding split gate and non-rising stem.
Metal-to-metal sealing technology is utilized throughout the valve to increase performance integrity. These valves
are available for applications from 3,000 to 5,000 psi. Trim levels are available to suit all types of oil and gas
service. Flanged or threaded configurations are available in standard bore sizes from 2-1/16 through 6-3/8.

Model 1520 Gate Valves

Seaboard International Model 1520 gate valves are designed with an expanding split gate and a pressure-
balancing stem. Metal-to-metal sealing technology is utilized throughout the valve to increase performance
integrity. These valves are available for applications through 10,000 psi. Trim levels are available to suit all types
of oil and gas service. Flanged end configurations are available in standard bore sizes from 1-13/16 through 4-
1/16.

Model 500

Model 1520

13
wellhead systems and quality gate valves for over 30 years

Key Features:
Full-Bore Through-Conduit Design
All Model 500/1520 gate valves utilize a full-bore
through-conduit seat/gate design.
• Maximizes valve life by eliminating the collection
of destructive particles
• Unrestricted flow reduces turbulence and pressure
drops
Sealing Technology
Dependable seals are critical to valve safety and
performance. Model 500/1520 gate valves utilize
reliable metal-to-metal sealing technology.
• Seals are stable, thermally insensitive, and environ-
mentally resistant
• Utilized in the gate/seat, body/ bonnet, and body/
seat interfaces
Parallel Expanding Gate Design
The expanding action of the gate provides a positive
mechanical seal across the seats both upstream and
downstream.
• Wedging only occurs in the full open or full closed
positions
• Provides a positive mechanical seal regardless of
line pressure
Low Operating Torque
Ease of operation is inherent in the design of all Model
500/1520 gate valves.
• The 500 features non-rising stems using durable
Acme threads
• Roller thrust bearings are isolated from cavity pres-
sure
• Lubrication ports in body
Body Lubrication
Although Model 500/1520 gate valves do not require
lubrication to seal, only the highest quality lubricants
are used to reduce operating torque and inhibit
corrosion.
• Gate guides act as skirts, assisting in retention of
lubricants
• Prevents potential corrosion and collection of sol-
ids
In-line Repairability
A routine maintenance program keeps repairs to a
minimum. Should repairs be necessary, vital valve
components may be replaced.
• Gates, seats, stems and other critical parts are eas-
ily replaced in the field
• Stem packing can be re-energized while the valve
is under pressure
Extended Stem Life
As the primary operating component of the valve, Model
1520 gate valve stems are designed with threads
located outside of the valve cavity.
• Stem threads are not exposed to wellbore particles
• Design of the stem/stem nut interface offers en-
hanced galling resistance

Pressure Venting Capabilities

A safe method for bleeding pressure from the valve
cavity is essential.
• Wedge gates in the full closed position provide a
positive mechanical seal isolating valve cavity from
wellbore pressure
• Block and bleed design isolates line pressure

14
 Developing innovative

Model 1540 Gate Valves

Seaboard International Model 1540 gate valves are designed with a forged body, expanding split gate, and a
pressure-balancing stem. Metal-to-metal sealing technology is utilized throughout the valve to increase
performance integrity. These valves are available for applications from 10,000 to 15,000 psi. Trim levels are
available to suit all types of oil and gas service. Flanged end configurations are available in standard bore sizes.

Key Features:
Full-Bore Through-Conduit Design
• Maximizes valve life by eliminating the collection of
destructive particles
• Unrestricted flow reduces turbulence and pressure
drops
Sealing Technology
• Seals are stable, thermally insensitive, and environ-
mentally resistant
• Utilized in the gate/seat, body/ bonnet, and body/
seat interfaces
Parallel Expanding Gate Design
• Wedging only occurs in the full open or full closed
positions
• Provides a positive mechanical seal regardless of
line pressure
Low Operating Torque
• Roller thrust bearings are isolated from cavity pres-
sure
• Lubrication ports in body
In-line Repairability
• Gates, seats, stems and other critical parts are easily
replaced in the field
• Stem packing can be re-energized while the valve
is under pressure
Reduction of Lost Body Lubrication
• Gate guides act as skirts, assisting in retention of
lubricants
• Prevents potential corrosion and collection of solids
Pressure Venting Capabilities
• Wedge gates in the full closed position provide a
positive mechanical seal isolating valve cavity from
wellbore pressure Model 1540
• Block and bleed design isolates line pressure
Extended Stem Life
• Stem threads are not exposed to wellbore particles
• Design of the stem/stem nut interface offers en-
hanced galling resistance

15
wellhead systems and quality gate valves for over 30 years

Model 1540S Gate Valves

Seaboard International Model 1540S gate valves are designed with a forged body, bi-directional slab gate,
pressure balancing stem, metal-to-metal sealing technology, and stem backseating capability. The one-piece
slab gate utilizes floating seats that co-opt line pressure to supply the sealing force. S tem packing is chemically
inert, using spring energizing rings which require no adjustment or plastic injection. These valves are specifically
designed for 20,000 psi service. Trim levels are available to suit all types of oil and gas service. Flanged end
configurations are available in standard bore sizes.

Key Features:
Metal-to-Metal Seals
• Seals are stable, thermally insensitive, and
environmentally resistant
• Utilized in the gate/seat, body/ bonnet, and stem/
bonnet backseat
Selective Backseat
• Provides unparalleled safety during venting, lubri-
cation, and stem packing replacement
• Premature backseating is prevented by a positive
stop in the bearing cap that controls stem travel
• Allows stem packing replacement without remov-
ing valve from service
• Backseat can be employed without shifting posi-
tion of the gate
Slab Gate
• Excessive force is not required to close and seal
the valve
• Potential for valve cavity pressure lock is eliminated
• Assures smooth operation during extreme thermal
cycles
Floating Seats
• Allows bi-directional use
• Spring-energized seals pre-load the seats to main-
tain constant contact with gate, ensuring low pres-
sure sealing
• Requires no lubrication to seal
Threaded Packing Gland
• Transfers stem packing loads to the bonnet, pro-
tecting the bearing assemblies Model 1540S
• Accommodates replacement of bearings and shear
pin at full pressure differential
No Body Penetrations In-line Repairability
• A single lubrication injection port is located outboard • Gates, seats, stems and other critical parts are eas-
of the backseat in the each bonnet allowing cavity ily replaced without the use of special tools
lubrication or venting of trapped pressure after • Stem packing can be replaced while the valve is
backseat operation under pressure

16
 Developing innovative

Model 640 /1640 Gate Valves

Seaboard International Model 640 and Model 1640 gate valves are designed with a bi-directional slab gate,
metal-to-metal sealing technology, and stem backseating capability. The one-piece parallel sided slab gate
utilizes floating seats that co-opt line pressure to supply the sealing force. Stem packing is chemically inert,
using spring energizing rings which require no adjustment or plastic injection. These valves are available for
applications from 3,000 to 15,000 psi. Trim levels are available to suit all types of oil and gas service. Flanged
end configurations are available in standard bore sizes from 1-13/16 through 5-1/8.

Key Features:
Metal-to-Metal Seals
• Seals are stable, thermally insensitive, and envi-
ronmentally resistant
• Utilized in the gate/seat, body/ bonnet, and stem/
bonnet backseat
Selective Backseat
• Provides unparalleled safety during venting, lubri-
cation, and stem packing replacement
• Premature backseating is prevented by a positive
stop in the bearing cap that controls stem travel.
This design feature also protects the metal-to-metal
sealing surface
• Allows stem packing replacement without remov-
ing valve from service
• Backseat can be employed without shifting posi-
tion of the gate
Slab Gate
• Excessive force is not required to close and seal
the valve
• Potential for valve cavity pressure lock is eliminated
• Assures smooth operation during extreme thermal Model 1640
cycles
Floating Seats
• Allows bi-directional use Non-Rising Stem
• Spring-energized seals pre-load the seats to main- • Reduces tearing of stem packing
tain constant contact with gate, ensuring low pres- • Acme thread enhances durability and lowers torque
sure sealing requirements
• Requires no lubrication to seal Stem Shear Pin
Threaded Packing Gland • Protects valve stem from being damaged due to
• Transfers stem packing loads to the bonnet, pro- excessive torque
tecting the bearing assemblies In-line Repairability
• Accommodates replacement of bearings and shear • A routine maintenance program keeps repairs to a
pin at full pressure differential minimum. Should repairs be necessary, vital valve
No Body Penetration components may be replaced
• A single lubrication injection port is located above • Gates, seats, stems and other critical parts are eas-
the backseat in the bonnet allowing cavity lubrica- ily replaced without the use of special tools
tion or venting of trapped pressure after backseat • Stem packing can be replaced while the valve is
operation under pressure

17
wellhead systems and quality gate valves for over 30 years

Seaboard International Gate Valve Trim Chart

Service Conditions API Trim Body Bonnet Gate Seats Stem

General Service AA 4130 4130 Alloy (1) Alloy (1) 4140

Non-Corrosive

General Service BB 4130 4130 410SS (1) 410SS (1) 17-4PHSS

Slightly Corrosive

General Service CC 410SS 410SS 410SS (1) 410SS (1) 17-4PHSS

Moderate to Highly Corrosive

Sour Service DD 4130 4130 Alloy (1) Alloy (1) 4140

Non-Corrosive

Sour Service DD-1 4130 4130 Alloy (2) Alloy (2) 17-4PHSS
Non-Corrosive

Sour Service EE 4130 4130 410SS (1) 410SS (1) 17-4PHSS

Slightly Corrosive

Sour Service EE-1 4130 4130 410SS (2) 410SS (2) 17-4PHSS
Slightly Corrosive

Sour Service EE-7 4130 (4) 4130 (4) 17-4PHSS (1) 17-4PHSS (1) 17-4PHSS
Slightly Corrosive

Sour Service FF 410SS 410SS 410SS (1) 410SS (1) 17-4PHSS

Moderate to Highly Corrosive

Sour Service FF-1 410SS 410SS 410SS (2) 410SS (2) 17-4PHSS
Moderate to Highly Corrosive

Sour Service HH 4130 (3) 4130 (3) Inconel® Stellite Inconel®

Highly Corrosive

Notes:
(1) Nitrided
(2) Stellite Overlay or Equivalent
(3) Inconel® Clad
(4) Xylan Coated

The chart above includes Seaboard International’s standard trim designations. Additional trims are available to meet
special customer requirements and well conditions. Please contact Seaboard International for assistance with special
trim requirements.

18
 Headquarters
13815 South Freeway
P.O. Box 450989
Houston, Texas 77245-0989
Phone: 713-644-3535
Fax: 713-644-3737
www.seaboardusa.com
Ecuador
Interoil Services LLC.
Phone: 51-1-442-5364
sales@interoilusa.com
Mexico
International Tool & Supply
Phone: 993-3-57-30-00
Itsmexico1@prodigy.net.mx
Peru
Interoil Services L.L.C.
Phone: 51-1-442-5364
jsayan@viabcp.com
Venezuela
Hot-Hed de Venezuela, S.A.
Phone: 58-261-7363737
maracaibo@hot-hed.com
73 74 76
75
Burleson, Texas Corpus Christi, Texas Kilgore, Texas Oklahoma City, Oklahoma
Phone: 817-783-3298 Phone: 361-289-6853 Phone: 903-983-4481 Phone: 405-619-3099
Fax: 817-783-5311 Fax: 361-289-0216 Fax: 903-983-5408 Fax: 405-619-7365
Conway, Arkansas Houston, Texas Odessa, Texas Scott, Louisiana
Phone: 501-513-1951 Phone: 713-644-3535 Phone: 432-385-0389 Phone: 337-237-8399
Fax: 501-764-1142 Fax: 713-433-3730 Fax: 432-385-0706 Fax: 337-269-0046
China Pakistan
MSP / Drilex Indentors International
Phone: 86-21-6553-8126 Phone: 92-51-2271943
mspstaff@msp-drilex.com.cn indentor@comsats.net.pk
India Singapore
Ellson Offshore Equipment Valcon-Matic Pacific PTE, Ltd.
Phone: 91-22-287-65831 Phone: 65-6569-1662
aurtechconst@sify.com sales@valconmatic.com
Abu Dhabi Libya
Uni-Arab Engineering and Oilfield Services West Oasis Oil Services, Ltd.
Phone: 00971-2-6273-400 Phone: 00218-21-4627889
uniarab@emirates.net.ae info@westoasis.com
Dubai Malta
Technology Ventures, Inc. Medina Offshore Services, Ltd.
Phone: 971-4-324-1572 Phone: 00356-99498720
tvime@emirates.net.ae info@sgmlt.com
Egypt Oman
NAPESCO Sharikat Hani, L.L.C.
Phone: 202-35-84062 Phone: 968-24-562477
napsami@link.net raviendran.va@hanillc.com
Kuwait
77 78 79
Saudi
81
Arabia 82 83 84
Al Fassam Trading and Investment Abdel Hadi Abdullah Al-Qhatani & Sons
Phone: 965-484-9905 80 Phone: 966-3-826-1477 85
houseofelegance@hotmail.com info@ahqsons.com
