PARTS CATALOGUE

DATE : 17.08.2011
 6

4
2 3
4
1
5
5
 INDEX
1. CYLINDER HEAD ASSEMBLY
17. HANDLEBAR SWITCH & CABLE ASSY.
2. CYLINDER BLOCK & CRANKSHAFT ASSY.
18. HEAD LAMP ASSY. TSL LH RH
3. CRANKCASE LH, RH & OIL PUMP ASSY.
19. PANEL . LH, RH & REAR FENDER ASSY
4. CLUTCH & COVER CLUTCH ASSY.
20. SPEEDOMETER ASSEMBLY
5. MAGNETO & IGN COIL ASSEMBLY
21. REAR LAMP ASSEMBLY & TS LAMP
6. MUFFLER ASSEMBLY
22. WIRING, REGULATORS & BATTERY
7. CARBURETTOR ASSEMBLY
23. FRONT FORK ASSEMBLY
8. AIR CLEANER ASSEMBLY
24. FRONT WHEEL ASSEMBLY
9. SECONDARY AIR INJECTION ASSY
25. REAR WHEEL ASSEMBLY
10. KICK STARTER ASSEMBLY
26. SWINGING ARM ASSEMBLY.
11. TRANSMISSION ASSEMBLY
27. SHOCK ABSORBER & CHAIN COVER ASSY.
12. GEAR SHIFT MECHANISM ASSY.
28. TOOL KIT
13. FUEL TANK & FUEL COCK ASSY.

14. FRAME & SAREE GUARD ASSEMBLY 29. COLOUR MATRIX & PART NOS.

15. CENTER STAND & FOOTREST ASSY.

16. SEAT ASSEMBLY.

 CYLINDER HEAD ASSEMBLY
FIG.No. 01

1 M1200470 HEX FLANGE BOLT M6x30 3

2 N5010270 COVER COMP. CYLINDER HD RH 1
3 N5010650 GASKET COVER CYLINDER HD R 1
4 N2010330 SHAFT VALVE ROCKER ARM 2

5 M1180030 SPARK PLUG NGK (CR7E) 1

6 - ROLLER OUTER VALVE ROCKER 2 N.S

7 - PIN VALVE ROCKER 2 N.S
8 M1200050 DOMED CAP NUT FLANGE M8 4
9 S1010130 WASHER CYLINDER HEAD 3
10 N2010610 VALVE INTAKE 1
11 N2200500 HEX FLANGE BOLT M6x25 4
12 N2010820 CAP INSPECTION 2
13 S1010210 O RING CAP INSPECTION 2
14 N5010580 HEAD COMP. CYLINDER 1
15 N5200340 HEX SCREW M6x16 2
16 N5010320 SPROCKET CAMSHAFT 1
17 N5010400 WASHER SPROCKET 1
18 M1200940 HEX SCREW M5x10 2
19 N5010080 O RING COVER CYLINDER HEAD LH
1
20 N5010250 COVER L CYLINDER HEAD 1
21 S1200030 HEX FLANGE BOLT M6x20 2
22 M1010490 PIN SPROCKET 1
CYLINDER HEAD ASSEMBLY
23 N8010140 CAMSHAFT ASSY. 1
 CYLINDER HEAD ASSEMBLY
FIG.No. 01

24 S1200130 BALL BEARING 15x32x9 1

25 N2010620 VALVE EXHAUST 1

26 S1010340 SEAT VALVE SPRING 2

27 M1010620 SEAL VALVE STEM 2

28 N2010350 VALVE SPRING OUTER 2

29 N2010340 VALVE SPRING INNER 2

30 N2011040 RETAINER VALVE SPRING 2

31 S1010320 COTTOR VALVE 4

32 N8010080 ARM VALVE COMP ROCKER 2

33 S1010240 SCREW TAPPET ADJUSTING 2

34 S1010250 NUT TAPPET ADJUSTING 2

35 N5010350 GASKET CYLINDER HEAD NUT 1

36 N5040340 PIPE ASSY. INTAKE 1

37 N2200470 HEX SOCKET HD CAP SC M6x20 2
38 N8040210 GASKET PIPE INTAKE 1
39 N5200500 HEX SCREW M6x25 2
40 N5010630 CYLINDER HEAD ASSY. 1 N.I '*'

N.S - NOT SERVICED

CYLINDER HEAD ASSEMBLY N.I - NOT ILLUSTRATED
'*' - REF. KIT & KIT CONTENS
 CYLINDER BLOCK & CRANKSHAFT ASSY.
FIG.No. 02

1 S1200270 TUBLER DOWEL 2

2 N5010350 GASKET CYLINDER HEAD 1

3 N5010010 CYLINDER BLOCK 1

4 N5010560 GASKET TENSIONER ADJUSTER 1

5 N5010470 ADJUSTER ASSY. TENSIONER 1

6 420462700 HEX BOLT M6x20 2

7 N5010170 GASKET CYLINDER 1

8 - PISTON STD 1

9 N5320440 RING SET PISTON STD 1

9.1 N5320450 RING SET PISTON I O/S 1

9.2 N5320460 RING SET PISTON II O/S 1

10 N5320410 PISTON KIT STD 1

10.1 N5320420 PISTON KIT I O/S 1

10.2 N5320430 PISTON KIT II O/S 1

11 N3080170 KEY 4x4x15 1

12 N2200390 BALL BEARING 25x52x15 2

13 N5020080 CRANKSHAFT COMP. 1

14 420702000 WOODRUFF KEY 1

15 N5010550 PIN PISTON 1
16 N2200340 CIRCLIP PIN PISTON 2
17 N5010310 TENSIONER CAMCHAIN 1
CYLINDER BLOCK & CRANKSHAFT ASSY. 18 N2010920 CAM CHAIN 90 LINKS 1
FIG.No. 02 CYLINDER BLOCK & CRANKSHAFT ASSY.

19 N5010330 GUIDE CAM CHAIN 1

20 N2010710 BOLT CAMCHAIN TENSIONER 1

21 N5200520 HEX SCREW M8x20 1

22 S1010430 O RING CYLINDER 1

23 N5320480 CYLINDER BL.&PISTON KIT STD 1 N.I '**'

'**' - KIT CONSISTS OF '*' MARKED ITEMS

N.I - NOT ILLUSTRATED

CYLINDER BLOCK & CRANKSHAFT ASSY.

FIG.No. 03
CRANKCASE LH, RH & OIL PUMP ASSY.

1 M1200470 HEX FLANGE BOLT M6x30 1

2 N5010180 STUD CYLINDER HEAD RH 2
3 N5030040 CRANKCASE RH 1
4 N5030120 GASKET CRANKCASE 1
5 420602000 BALL BEARING 12x32x10 1
6 420462700 HEX SCREW M6x16 2
7 N5080330 PLATE RATCHET GUIDE 1
8 N2200400 BALL BEARING 12x28x8 1
9 N5030020 CRANKCASE COMP. LH 1
10 N8080410 DUST COVER GEAR SHIFT CAM 1

11 0335618 PUNCHED WASHER 6.5x20x1.6 1

12 0331618 HEX SCREW M6x12 1

13 N8060010 CLAMP GEAR SHIFT SWITCH 1

14 0332028 CRR PAN HEAD SCREW M5x8 1
15 N5200160 HEX FLANGE BOLT M6x45 8
16 M1200440 HEX FLANGE BOLT M6x75 1
17 N5060080 GEAR SHIFT SWITCH 1
18 T4080540 OIL SEAL SHAFT DRIVE 17x29x6 1
19 N2081720 OIL SEAL GEAR SHIFT SHAFT 1
20 N5060170 RESISTOR 2
21 S1200270 DOWEL PIN 11x12 2
22 N5010190 STUD CYLINDER HEAD LH 2
CRANKCASE LH , RH & OIL PUMP ASSY.
FIG.No. 03 CRANKCASE LH, RH & OIL PUMP ASSY.

23 S1011290 SEALING WASHER 1

24 S1200900 PLUG COMP. OIL DRAIN 1

25 N5080410 PUMP ASSY. OIL 1
26 0332248 CRR CSK HEAD SCREW M6x20 2

27 N5320950 CRANKCASE KIT RH 1 NEW

CRANKCASE LH , RH & OIL PUMP ASSY.

 CLUTCH & COVER CLUTCH ASSY.
FIG.No. 04

1 N5200350 HEX FLANGE BOLT M5x20 4

2 N2200400 BALL BEARING 12x28x8 1
3 N5070130 PLATE CLUTCH RELEASE 1
4 N5070090 SPRING CLUTCH 4
5 N5070070 HUB CLUTCH 1
6 N5070100 NUT CLUTCH SHAFT 1
7 N5070110 SPRING DISC 1
8 N5070140 PLATE CLUTCH DRIVE 4
9 3067010 PLATE CLUTCH DRIVEN (METAL) 4
10 N5200160 HEX FLANGE BOLT M6x45 2
11 S1200860 O RING 2
12 N2081150 GUAGE OIL LEVEL 1
13 N5200170 HEX FLANGE BOLT M6x35 7
14 N5080600 BRACKET CLUTCH ABUTMENT 1
15 N8030060 COVER CLUTCH 1
16 N5080360 ROD COMP. CLUTCH RELEASE 1
17 S1200270 TUBULAR DOWEL 9x14 2

18 N5080420 SPRING CLUTCH CABLE RETURN 1

19 N2080810 O RING 1
20 N5030130 GASKET COVER CLUTCH 1

21 N5080460 OIL FILTER 1

22 N5200030 SPLIT WASHER 2

CLUTCH & COVER CLUTCH ASSY. 23 N5200020 SHIM 1
FIG.No. 04
CLUTCH & COVER CLUTCH ASSY.

24 N5200040 CUP WASHER 1

25 N5070050 DISC CLUTCH PRESSURE 1
26 N5070080 SPACER CLUTCH 1
27 N5080010 GEAR ASSY. PRIMARY DRIVEN 1

28 420402000 BALL DIA 5/32 1

29 N5070240 PIN ASSY. CLUTCH RELEASE 1
30 M1200250 HEX NUT M16x1.5 1

31 S1201050 DISC SPRING 1

32 N5080190 GEAR PRIMARY DRIVE 1

33 N5070270 PLATE CLUTCH DRIVE JUDDER 1

34 N5070250 SPRING CLUTCH JUDDER 1

35 N5070260 WASHER CLUTCH JUDDER 1

36 N5070220 PIN CLUTCH RELEASE 1

37 N5070230 ADAPTER PIN CLUTCH RELEASE 1

CLUTCH & COVER CLUTCH ASSY.

 MAGNETO & IGNITION ASSEMBLY
FIG.No. 05

1 N5200070 O RING 95.5x2 1

2 N8060040 BACK PLATE MAGNETO 1

3 - PULSER COIL 1

4 0331708 CRR PAN HD SCREW M5x12 2

5 N5060210 STATOR ASSY. 1

6 N5060200 ROTOR COMP. 1

7 N8060020 MAGNETO ASSY. 1

8 M1200770 HEX FLANGE NUT M12x1.25 1

9 N8030130 COVER COMP. MAGNETO 1

10 M1200510 HEX FLANGE BOLT M6x25 6

11 K200700 SCREW COIL 2

12 0332228 CRPH SCREW M6x16 2
13 N5200050 O RING 6x1.7 2
14 N5200270 OIL SEAL 20x30x6 1
15 M1200670 CRPH SCREW M6x20 1
16 N5060250 IGNITION COIL 1
17 N2180130 SEAL HIGH TENSION CORD 1

18 N3060150 SUPPRESS0R CAP ASSY. 1

19 S1060310 SEAL SPARK PLUG 1

MAGNETO & IGNITION COIL ASSY.

FIG.No. 06 MUFFLER ASSEMBLY

1 0331688 HEX SCREW M6x8 4

2 0330408 WAVE SPRING WASHER M6 4

3 0335578 PUNCHED WASHER 6.5x13x1 4

4 N5050280 GUARD EXHAUST (FRONT) 1

5 N5050430 GUARD MUFFLER EXHAUST (RR) 1

6 T4050180 GASKET EXHAUST 1

7 N3200200 HEX BOLT M8x55 1

8 N3200210 PUNCHED WASHER 8.2x25x2 2

9 N3050350 SPACER MUFFLER BRKT 1

10 N5050110 MUFFLER COMP. 1

11 - MUFFLER ASSY. (WITH GUEARD) 1

12 413050000 NYLON LOCK NUT M8 1

13 N8120440 CUSHION 1

14 P1200060 HEX NUT M6 2

15 N5050600 MUFFLER (BLACK) 1 DLX

16 N5321050 MUFFLER ASSY. (BLACK) 1 DLX

MUFFLER ASSEMBLY
 CARBURETTOR ASSEMBLY
FIG.No. 07

1 N8040220 CARBURETTOR ASSY. 1

2 N2320380 TOP CAP 1

3 N2320560 CAP THROTTLE 1

4 N2320370 SPRING PISTON VALVE 1

5 N2320610 HOLDER JET NEEDLE 1

6 N2320330 SPRING JET NEEDLE 1

7 N2320340 E RING JET NEEDLE 1

8 N5320210 RING JET NEEDLE (2.6) 1

9 N5320220 JET NEEDLE 1 (NEEDLE)

10 N5320200 PISTON VALVE - CA 1

11 N2320630 WASHER JET NEEDLE 1

12 N5320190 ADJUSTER (PISTON VALVE) 1

13 N2320440 SPRING (TS) 1

14 N2320450 WASHER (TS) 1

15 N2320460 O RING (TS) 1

16 N2320390 AIR SCREW (AS) 1

17 N2320400 SPRING AS 1

18 N2320410 WASHER (AS) 1

19 N2320420 O RING (AS) 1

20 - FLOAT BODY ASSY. 1 N.S

21 N5320330 RING (CHOKE LEVER) 1
22 N5320340 SCREW ASSY (CHOKE LEVER) 1
23 N5320290 LEVER (CHOKE) 1
CARBURETTOR ASSEMBLY
24 N5320240 PACKING (CHOKE LEVER) 1
 CARBURETTOR ASSEMBLY
FIG.No. 07

25 N5320310 SPRING (CHOKE LEVER) 1

26 N5320320 BALL (CHOKE LEVER) 1
27 N5320400 CLIP (HOSE) 2
28 N2320320 SEAL BOWL 1
29 N5320140 MIXING BODY 1
30 N5320500 SCREW FLOAT CHAMFER 4
31 N5320300 HOSE DRAIN 1

32 N2320310 SCREW DRAIN 1

33 N5320230 HOSE AIR VENT 1

34 N2320510 PIN FLOAT 1

35 N2320520 FLOAT ASSY 1

36 N2320290 NEEDLE VALVE ASSY 1

37 N2320480 SCREW VALVE SEAT 1

38 N2320470 PLATE VALVE SEAT 1

39 N5320180 MAIN JET (81.3) 1

40 N2320250 JET HOLDER 1

41 N5320170 NEEDLE JET (O-6) 1 (JET)

42 N5320160 PILOT JET (12.5) 1
43 N2320570 O RING CARB. FLANGE 1
44 N8040130 INSULATOR PAD 1
45 N5320280 PLUNGER STARTER 1
46 N5320270 SPRING STARTER 1
47 N5320260 GUIDE HOLDER ASSY 1
CARBURETTOR ASSEMBLY
48 N5320250 CAP (CHOKE) 1
 AIR CLEANER ASSEMBLY
FIG.No. 08

1 K200520 CRR PAN HEAD SCREW M5x10 2

2 N5040550 COVER RH AIR CLEANER 1
3 N5040440 CASE COMP. LH AIR CLEANER 1
4 0335608 PUNCHED WASHER 6.5x16x1.2 2
5 N5200340 HEX SCREW M6x16 2
6 N5040410 AIR CLEANER ASSY. 1
7 414147000 HOSE CLIP 42 3

8 N5040490 PIPE PCV 1

9 M1040170 TRAP COMP. FLAME 1
10 M1040700 FILTER COMP. AIR CLEANER 1
11 N5040460 INLET COMP AIR CLEANER 1
12 N5040580 COVER LH AIR CLEANER 1
13 N5200490 CRR PAN HEAD SCREW M5x20 4
14 - - 1
15 S1200840 HOSE CLIP 42 1
16 A143300 HOSE FUEL 1

AIR CLEANER ASSEMBLY

FIG.No. 09
SECONDARY AIR INJECTION ASSY.

1 N8040280 HOSE AIR INLET 1

2 N2041150 HOSE CLIP 2
3 420305700 HEX NUT M6 2
4 0335608 PUNCHED WASHER 6.5x16x1.2 2
5 N2041670 CUSHION VALVE MOUNTING 2
6 N8040250 SECONDARY AIR INJEC VALVE 1
7 N8040290 HOSE AIR CUT VALVE 1
8 414147000 HOSE CLIP 2
9 N3200190 HEX SCREW M6x30 2
10 N5040510 HOSE1 DECELERATION CUT OFF 1
11 N5160170 ACTUATOR ASSY. 1
12 N8040350 HOSE CLIP AIR INJECTION 2
13 M7040060 HOSE AIR OUTLET 1
14 N8040300 PIPE COMP. AIR INJECTION 1
15 N8040340 O RING 1.9x10 AIR INJECTION 1
16 M1200940 HEX SCREW M5x10 1
17 0330408 WAVE SPRING WASHER M6 1

SECONDARY AIR INJECTION ASSY.

FIG.No. 10
KICK STARTER ASSEMBLY

1 N8080360 LEVER ASSY. KICK STARTER 1

2 N2081760 RUBBER KICK STARTER LEVER 1
3 N5081040 LEVER KICK STARTER 1
4 N8080390 PIN KICKSTARTER LEVER 1
5 420476700 HEX SCREW M6x30 1
6 N8080400 SPRING KICKSTARTER LEVER 2
7 N2081440 BALL KICKSTARTER LEVER 2
8 N8080380 JOINT LEVER KICK STARTER 1
9 N3200240 E RING 1
10 0335024 SHIM 17x24x1 1
11 0330174 CIRCLIP EXTERNAL 20x1.2 2
12 N5080240 SPRING K S RATCHET 1
13 N5080220 RETAINER K S SPRING 1
14 N5080200 RATCHET KICK STARTER 1
15 N5200140 SHIM 20.5x25.5x1.5 1
16 N5080810 GEAR K S DRIVE (22T) 1
17 N5080230 SHAFT KICK STARTER 1
18 N5080340 SPRING KICK STARTER 1
19 N5080320 RETAINER KICK STARTER 1

20 P200030 CIRCLIP EXTERNAL 16x1 1

21 N5200150 OIL SEAL 1

KICK STARTER ASSEMBLY

 TRANSMISSION ASSEMBLY
FIG.No. 11

1 N5200080 SHIM 12.7x22x1.5 1

2 N5080170 GEAR 4th DRIVEN (24T) 1
3 N2080330 SHIM 3
4 N5080150 GEAR 3rd DRIVEN (26T) 1
5 0330174 CIRCLIP 20x1.2 2
6 N5080130 GEAR 2nd DRIVEN (35T) 1
7 N5080060 BUSH Ist DRIVEN 1
8 N5080110 GEAR 1st DRIVEN 1
9 N5080100 SHAFT DRIVE 1
10 N5081080 CHAIN ASSY. 102 LINK 1
11 N3080040 SPROCKET ENGINE (14T) 1

12 - LINK SET CHAIN 1

13 T4080520 LOCK PLATE SPROCKET 1
14 M1200940 HEX SCREW M5x10 1
15 N5080160 GEAR 4TH DRIVE (24T) 1
16 N5200110 SHIM 17.1x12x1 2
17 N5200130 CIRCLIP 17x1.2 2
18 N5080140 GEAR 3RD DRIVE (21T) 1
19 N5080120 GEAR 2ND DRIVE (20T) 1
20 N5080080 SHAFT CLUTCH (11T) 1
21 N5320360 CHAIN & SPROCKET KIT 1

TRANSMISSION ASSEMBLY
FIG.No. 12
GEAR SHIFT ASSEMBLY

1 N2080500 SPRING GEAR SHIFT PAWL 1

2 N5080970 SHAFT COMP. GEAR SHIFT 1
3 0331320 BOLT GEAR SHIFT CAM STOPPE 1
4 8200300 WASHER 1
5 N5080930 SPRING GEAR SHIFT CAM STOP 1
6 N5080910 STOPPER GEAR SHIFT CAM 1
7 N5080920 HOOK SPRING GS CAM STOPPE 1

8 0332228 CRR CSK HEAD SCREW M6x16 1

9 3040013 RETAINER G S CAM DRIVE 1
10 3044034 ROLLER CAM DRIVE 5
11 N2081570 SPACER ROL. GR.SH. FORK PIN 2
12 N5080909 CAM GEAR SHIFT 1
13 N5080280 FORK GEAR SHIFT LOW SPEED 1
14 N5080270 SHAFT SHIFT FORK 2
15 N5080620 CONTACT GEAR SHIFT SWITCH 1
16 N5080290 FORK GEAR SHIFT HIGH SPEED 1
17 N2081170 SPRING SHIFT SHAFT RETURN 1
18 N2081720 OIL SEAL GEAR SHIFT SHAFT 1
19 420462700 HEX BOLT M6x20 1
20 N2081740 RUBBER LEVER GEAR SHIFT 1

21 N5080820 LEVER ASSY GEAR SHIFT 1

GEAR SHIFT MECHANISM ASSY.

FIG.No. 13 FUELTANK & FUEL COCK ASSY

1 N5140070 CAP ASSEMBLY FUEL TANK 1

2 420515000 CRR PAN HEAD SCREW M4x10 2
3 M1210430 STICKER PROTECTION 1
4 420476700 HEX SCREW M6x30 2
5 0335876 PUNCHED WASHER 6.5x24x1.6 2
6 N3140150 SPACER FUEL TANK REAR 2
7 N3140160 CUSHION FUEL TANK RR UPPER 2
8 - TANK COMP. FUEL 1 REF.COLOR PHOTO

9 K122810 CUSHION FRAME COVER 2

10 N3140170 CUSHION FUEL TANK RR LOWER 2
11 S1140390 CLIP OIL HOSE No.1 2
12 A143300 FUEL HOSE 1
13 N3140120 GASKET FUELCOCK 1

14 N5140250 FUEL COCK ASSY. 1

15 420001700 PUNCHED WASHER 2
16 420518700 CRR PAN HD SCREW M6x20 2
17 - TAPE SET - WINE RED 1 (LACQUERED)
17.1 - TAPE SET - HG BLACK 1 (LACQUERED)
17.2 - TAPE SET - TETTIAN BLUE 1 (LACQUERED)
18 M1200940 HEX SCREW M5x10 5
19 - PACKING FUEL GUAGE 1
20 N5140140 FUEL GUAGE ASSY. 1
FUELTANK & FUEL COCK ASSY
21 M7140090 CUSHION FUEL TANK FRONT 2
FIG.No. 14
FRAME & SAREE GUARD ASSEMBLY

1 N3120940 HOLDER ASSY RH PILLION 1

2 N3120630 RUBBER FOOTREST PILLION 2
3 N3120650 HOLDER RH F.REST PILLION 2
4 S1125300 PIN PILLION FOOTREST 2

5 420452700 HEX SCREW M8x20 2

6 0330318 WAVE SPRING WASHER M8 2
7 N8120540 TUBE COMP.PILLION F.REST RH 1

8 N2121060 CUSHION EXHAUST MTG 1

9 N3050350 SPACER MUFFLER BRKT 1

10 N5110760 PEDAL COMP. BRAKE 1

11 N5200630 SPLIT PIN 3.2x25 1

12 N5200640 PUNCHED WASHER 15.5x26x2.3 1
13 N5120010 FRAME COMP. 1
14 N5111170 RETURN SPRING BRAKE 1
15 0335558 PUNCHED WASHER 5.5x12x1.0 1
16 N2110600 PIN REAR BRAKE CONNECTOR 1
17 N8110240 ROD REAR BRAKE COMP. 1
18 0335578 PUNCHED WASHER 6.5x13x1 1
19 N3110360 SPRING REAR BRAKE ROD ADJ. 1
20 S1111930 PIN REAR BRAKE ROD LEVER 1
21 N3110360 SPRING REAR BRAKE ROD ADJ. 1
22 N5200300 HEX SOC HD CAP SCREW M8x74 2
FRAME & SAREE GUARD ASSEMBLY
23 N5200290 HEX SOC HD CAP SCREW M8x60 2
FIG.No. 14 FRAME & SAREE GUARD ASSEMBLY

24 N5120350 PILLION HANDLE COMP. 1

25 N5300010 SAREEGUARD COMP. 1

26 0138050 CUSHION COVER FRAME 2

27 N2121260 GROMMET COVER FRAME 2

28 0336018 PUNCHED WASHER 8.5x20x2 1

29 0331058 HEX BOLT+WAVE SPR. W M8x16 1

30 N5200330 HEX FLANGE BOLT M8x100 3

31 N8120580 TUBE COMP. PILLION F.REST LH 1
32 N5200430 PUNCHED WASHER 8.5x16x1.2 1
33 N5200420 HEX BOLT M8x16 (+SPRING W) 1
34 0335728 PUNCHED WASHER 20x32x2 2

35 N3120890 PLATE FOOTREST 2

36 N5200620 SPLIT PIN 2.0x20 2
37 N3120920 BUSH FOOTREST PILLION 2

38 420452700 HEX SCREW M6x12 2

39 N3120910 HOLDER ASSY LH PILLION 1

40 N5121840 PLUG TUBE 2

41 N5200360 HEX FLANGE U NUT M8x1.25 3

FRAME & SAREE GUARD ASSEMBLY

 CENTER STAND & FOOTREST ASSY.
FIG.No. 15

1 N5122070 RIDER FOOTREST ASSY. 1

2 N5120120 RUBBER FOOTREST 2
3 N5121990 BAR, FOOT REST COMP. FRONT 1

4 N5122050 BUSH RUBBER RIDER F.REST 8

5 N5122040 BUSH INNER RIDER FOOTREST 4
6 N5200430 PUNCHED WASHER 8.5x16x1.2 4
7 N5200530 HEX BOLT M8x35 4
8 N5200380 HEX NUT M10 2
9 N5120730 PROP STAND COMP. 1
10 N5200390 HEX BOLT M10x1.25x27 1

11 N5121610 SPRING PROP STAND 1

12 P121660 RETAINER FOOTREST RUBBER 2

13 0330408 WAVE SPRING WASHER M6 2

14 420464700 HEX SCREW M6x16 2
15 N5121600 SPRING CENTER STAND 1
16 N5120160 CENTER STAND COMP. 1
17 N5200370 HEX FL. BOLT M10x1.25x110 1
18 N3121540 SPACER CENTER STAND 1

19 0330328 WAVE SPRING WASHER M10 1

20 N5200380 HEX NUT M10x1.25 1

21 N5300020 CRASH GUARD COMP. 1

22 0335516 PUNCHED WASHER 8.5x16x1.2 4

CENTER STAND & FOOTREST ASSY. 23 0331058 HEX BOLT M8x16 (+SPRING W) 4
24 N5320540 KIT PROP STAND 1
FIG.No. 16
SEAT ASSEMBLY

1 N5130010 SEAT ASSY. 1

2 N5130040 COVER COMP. SEAT 1

3 N5130020 SEAT FOAM 1

4 N5130030 SEAT BASE 1

5 N3130060 GROMMET SEAT BASE 2

6 0335928 PUNCHED WASHER 6.5x18x1.6 2

7 420462700 HEX SCREW M6x20 2

8 N3130070 BUSH SEAT BASE 2

9 N3130040 SEAT REST REAR 8

SEAT ASSEMBLY
FIG.No. 17 HANDLEBAR, SWITCH & CABLE ASSY.

1 N3150070 GRIP THROTTLE 1

2 N3150210 TUBE THROTTLE GRIP 1
3 N3150140 THROTTLE HOLDER ASSY. 1
4 N3150340 STUD LEVER HANDLE 2
5 N3150510 LEVER AND SUPPORT ASSY. RH 1
6 N3150310 LEVER FRONT BRAKE 1
7 - HEX NUT (NYLOCK) 2
8 N3160500 SWITCH STOP LAMP FRONT 1
9 N3150360 BRKT LEVER RH 1
10 N5150080 MIRROR ASSY. RH RR VIEW 1
11 N5150070 MIRROR ASSY. LH RR VIEW 1
12 N3200270 HEX FLANGE BOLT M6x30 4
13 N3150250 HANDLE HOLDER (UPPER) 2
14 N3150240 HANDLE HOLDER COMP. (LOW) 2
15 9200150 3D WASHER A12.5 2
16 N3150230 CUSHION UPPER 2
17 N5200340 HEX SCREW M6x16 2
18 0330408 WAVE SPRING WASHER M6 4
19 K200700 CRR PAN HEAD SCREW M6x25 2

20 N3200040 NYLOC NUT M10x1.25 2

21 9200160 3D WASHER A10.3 2
22 N3150220 CUSHION BOTTOM 2
HANDLEBAR, SWITCH & CABLE ASSY.
23 N2100020 UPPER BRACKET COMP. 1
FIG.No. 17 HANDLEBAR, SWITCH & CABLE ASSY.

24 N5150100 BRKT LEVER LH 1

25 N5150090 LEVER AND SUPPORT ASSY. LH 1
26 N5150110 LEVER CLUTCH 1
27 N5101999 HEX. BOLT 2
28 N5101989 PLAIN WASHER 2
29 N5150030 HANDLE BAR 1
30 7200120 HEX BOLT M6x25 2
31 0335936 PUNCHED WASHER 6.5x13x1 2
32 N5150230 SWITCH ASSY. HANDLE LH 1
33 N3150060 GRIP LH 1
34 0334268 NUT FRONT BRAKE CABLE ADJ. 1
35 S1111940 PIN FRONT CABLE LEVER 1
36 N2110680 DUST SEAL FRONT BR. CABLE 1
37 N5110590 SPRING FRONT BRAKE CABLE 1
38 N5170020 CABLE ASSY. BRAKE FRONT 1
39 8200320 CIRCLIP 5.0 TYPE E 1
40 N3170060 DUST COVER CLUTCH & BRAKE 2
41 N5170030 CABLE ASSY. CLUTCH 1
42 N5170040 CABLE ASSY. THROTTLE 1
43 N5150160 BRACKET LEVER RH 1 DLX
44 N5150130 BRACKET LEVER LH 1 DLX
45 N5150140 LEVER & SUPPORT ASSY. LH 1 DLX
46 N5150170 LEVER & SUPPORT ASSY. RH 1 DLX
47 N5220290 COVER HANDLE ASSY. 1 DLX
HANDLEBAR, SWITCH & CABLE ASSY.
FIG.No. 18 HEAD LAMP ASSEMBLY & TSL LH, RH

1 N5160100 TURN SIGNAL LAMP ASSY. FR RH1

2 N3160230 BULB TURN SIGNAL LAMP 2
3 - BULB HOLDER TSL 2 N.S
4 N5160260 LENS TURN SIGNAL LAMP 2
5 - PUNCHED WASHER 2 N.S
6 - HEX NUT 2 N.S
7 N5121670 CUSHION HEAD LAMP 1
8 S1160200 WASHER 6
9 N5160010 HEAD LAMP ASSY. 1

10 S1160190 GROMMET HEAD LAMP 2

11 S1201000 CRR PAN HEAD TAP SCR4.2x25 1

12 K3160500 HOLDER HEAD LAMP 1
13 N5120999 BRKT COMP. HOUSING HD LAMP 2
14 N5200440 CRR PAN HEAD SCREW M6x20 4
15 N5200480 PUNCHED WASHER 6.5x11x1.6 2
16 7130140 WASHER 4
17 8200130 PUNCHED WASHER 6.5x11x1.6 2
18 N5200400 HEX SCREW M6x25 2

19 N5120570 HEAD LAMP HOUSING REAR 1

20 N5100920 HEAD LAMP HSG. MTG. COMP. 1

21 420001700 PUNCHED WASHER A6.6 2

22 420452700 HEX SCREW M6x12 2

HEAD LAMP ASSEMBLY & TSL LH, RH
23 - BOOT HEAD LAMP 1 N.S
FIG.No. 19
PANEL LH,RH & REAR FENDER ASSY.

1 0332275 CRR PAN HD SCREW M6x16 1

2 - COVER FRAME RH 1
3 - COVER SEAT TAIL RH 1
4 M1201000 CRR FL. PAN HD.TAP SCR 4x13 4

5 - COVER CENTER SEAT TAIL 1 .

6 N5121810 BKT COMP COVER SEAT TAIL 1

7 N5121780 CHANNEL COVER SEAT TAIL 1
8 N3121250 LICENCE PLATE COMP RR 1
9 N3120600 GROMMET TAIL COVER 4
10 - COVER SEAT TAIL LH 1

11 420462700 HEX BOLT M6x20 9

12 0335618 PUNCHED WASHER 6.5x20x1.6 5

13 N3120130 GROMMET 5

14 N3120140 BUSH TAIL COVER 4

15 - COVER FRAME LH 1
16 N2210010 LOCK ASSY COVER FRAME 1
17 N2210030 PLATE LOCK ASSY. MTG 1
18 0330408 WAVE SPRING WASHER M6 3
19 420305700 HEX NUT M6 2
20 N5120250 FENDER ASSY. REAR 1
21 N5120310 BODY FRONT FENDER REAR 1

22 S1200700 RETAINER CLIP COMP. PANEL 1

PANEL LH, RH & REAR FENDER ASSY.
FIG.No. 20
SPEEDO METER ASSEMBLY

1 N5150180 SPEEDO METER ASSY. 1

2 N5320580 TOP COVER SPEEDO METER 1
3 - SCREW 3
4 N3160610 BULB 12V (CAPLESS) 2
5 N5320680 BULB 12V, 1.2W 6
6 N5320690 WIRING HARNESS (SP METER) 1
7 N5320600 BRKT SPEEDO METER 1
8 - CUSHION SPEEDO METER 3

9 N5320590 BOTTOM COVER SP METER 1

10 - SCREW 3

SPEEDO METER ASSEMBLY

FIG.No. 21 TAIL LAMP ASSEMBLY & TSL LAMP

1 N5160020 LAMP ASSY. RR COMBINATION 1

2 420522700 CRR PAN HEAD SCREW M4x25 2
3 N5160270 LENS RC LAMP 1
4 N3160520 BULB RC LAMP 1
5 N3160510 HOLDER RC LAMP 1
6 N3120130 GROMMET HEAD LAMP 3
7 0335618 PUNCHED WASHER 6x20x1.5 4
8 420305700 HEX NUT M6 2
9 N5160330 CUSHION RC LAMP 1

10 N5160260 LENS TURN SIGNAL LAMP 2

11 N3160230 BULB TSL LAMP 2
12 N5160300 TURN SIGNAL LAMP RR LH 1
13 N5160310 TURN SIGNAL LAMP RR RH 1

LAMP ASSEMBLY REAR & TSL LH, RH

FIG.No. 22
WIRING, REGULATORS & BATTERY ASSY.

1 N5160030 WIRING HARNESS 1 N5160340

2 8200120 CRPH TAPPING SCREW M5x12 2
3 0330408 WAVE SPRING WASHER M6 6
4 N5160140 THROTTLE POTENTIO METER 1
5 N5210080 LOCK SET (ASSY.) 1
6 N5160230 STEERING/IGNITION LOCK 1
7 K200700 RECEES PAN HD SCREW M6x25 2
8 N5121760 UTILITY BOX 1
9 N5060260 LEAD WIRE 1
10 N3160340 CLAMP WIRING HARNESS 2
11 N3060120 REGULATOR DC 1
12 0331748 CRR PAN HD SCREW M6x16 1
13 N5060230 DIGITAL 4 CURVE CDI AC 1
14 N5060240 ELECTRONIC REG. CONT. UNIT 1
15 N5170070 CLAMP CABLES 1

16 N3160250 SWITCH ASSY STOP LAMP 1

17 N5120800 SPRING STOP LAMP SWITCH 1
18 N5160220 HORN ASSY 1

19 N5200430 PUNCHED WASHER 8.5x16x1.2 1

20 N5200520 HEX SCREW M8x20 1
21 S1060300 RELAY ASSY. 12V-10+10W 1
22 1162350 BAND BATTERY 1
23 N3060110 BATTERY BREATHER HOSE 1

24 N3060060 BATTERY ASSY. 12V-2.5 1

WIRING, REGULATORS & BATTERY ASSY. 25 0335608 PUNCHED WASHER 6.5x16x1.2 2

26 420452700 HEX SCREW M6x12 2
27 N5160170 ACTUATOR ASSY. 1
FIG.No. 23 FRONT FORK ASSEMBLY

1 N8100040 FORK ASSY. FRONT 1

2 - FENDER FRONT 1 REF.COLOR MATRIX

3 N3100230 CLIP 1
4 N3100220 GUIDE CABLE 1
5 N5101690 BRACE FENDER FRONT 1

6 N5101200 SPACER 4
7 0330318 WAVE SPRING WASHER M8 4
8 420454700 HEX SCREW M8x20 4
9 N5101819 OUTER TUBE RH 1
10 N5101899 PACKING ALEN SCREW 2

11 N5101909 HEX ALEN SCREW 2

12 N5101829 OUTER TUBE LH 1

13 N5101839 OIL SEAL 2

14 N5101849 CIRCLIP FRONT FORK 2

15 N5101929 DUST SEAL 2

16 N5101919 SPINDLE TAPER 2
17 N5101889 INNER TUBE FRONT FORK 2
18 N5101979 NUT FRONT FORK 2
19 N5101969 O-RING 2
20 N5101959 BUSH FRONT FORK 2
21 N5101949 SPRING GUIDE 2
22 N5101939 SPRING FRONT FORK 2
FRONT FORK ASSEMBLY
23 N5101859 PISTON 2
FIG.No. 23 FRONT FORK ASSEMBLY

24 N5101869 PISTON RING 2

25 N5101879 SUB SPRING 1

26 420955700 HEX SCREW M8x40 2

27 N5200610 WAVE SPRING WASHER M8 2

28 420464700 HEX SCREW M6x16 2

29 0330408 WAVE SPRING WASHER M6 2

30 N5320560 UNDER BRKT COMP. 1

31 M1100450 DUST STEEL STEERING LOWER 1

32 M1100460 CONE BOTTOM 1
33 S1100890 STEERING BALL LOWER (7.93) 19

34 420404000 BALL STEERING (4.762) 22

35 S1101150 RACE STEERING OUTER 1

36 S1101140 DUST SEAL 1
37 N2100180 ARRESTER STEERING STEM 1
38 N5101770 SPECIAL WASHER 1
39 N2100170 LOCK NUT STEERING 1
40 N5101580 LEG ASSEMBLY LH 1
41 N5101590 LEG ASSEMBLY RH 1

42 N5320380 STEERING CONE KIT 1 N.I

FRONT FORK ASSEMBLY N.I - NOT ILLUSTRATED

FIG.No. 24 FRONT WHEEL ASSEMBLY

1 0330010 SPLIT PIN 2.5x20x1 1

2 0334558 SLOTTED NUT M10x1.25 1
3 N5110890 SPACER COMPLETE 1
4 N8110550 BALL BEARING 10x30x9 2
5 N5110210 SPACER COMP. FRONT HUB 1
6 N5111010 TYRE COMP. FRONT 2.75"x18" 1
7 N3110430 TUBE ASSY. 2.5" / 2.75"-18" 1
8 N3110450 PROTECTOR WHEEL IN TUBE 1
9 N5110820 RIM WHEEL 1.6"x18" 1
10 N5110830 WHEEL ASSY. FRONT 1
11 N8110830 OIL SEAL FRONT BRAKE PANEL 1
12 N5111140 SET BRAKE SHOE ASSY. 1
13 N8110820 GEAR SPEEDOMETER 24T 1
14 N5110790 THRUST WASHER SPEEDO GEAR 1
15 N5110920 PANEL BRAKE FRONT 1
16 N3110120 THRUST WASHER S.M. PINNION 1
17 N3110110 PINNION SPEEDOMETER 1
18 N3110460 BUSHING S.M PINNION 1
19 0335078 THRUST WASHER S.M 1
20 N5110900 SPACER FRONT WHEEL 1
21 0335628 PUNCHED WASHER 10.5x24x2.3 2
22 N5110860 AXLE COMP. FRONT 1
FRONT WHEEL ASSEMBLY
23 0178030 O RING CAM BRAKE 1
FIG.No. 24 FRONT WHEEL ASSEMBLY

24 0335698 PUNCHED WASHER 14.5x22x1.6 1

25 420001700 PUNCHED WASHER A6.6 1

26 420304700 HEX NUT M6 1
27 N5110630 LEVER FRONT BRAKE CAM 1
28 0331248 HEX BOLT M6x33 1
29 K3110470 CAM BRAKE 1
30 N5320520 SPOKE & NIPPLE ASSY. INNER 18
31 N5320530 SPOKE & NIPPLE ASSY. OUTER 18
32 N8110110 HUB COMP. FRONT WHEEL 1

FRONT WHEEL ASSEMBLY

 REAR WHEEL ASSEMBLY
FIG.No. 25

1 S1200790 HEX FLANGE U NUT M12x1.25 1

2 N3200080 PUNCHED WASHER 12.5x32x3.2 1
3 N8110390 SPACER RH REAR AXLE 1
4 420305700 HEX NUT M6 1
5 0335578 PUNCHED WASHER 6.5x13x1 1
6 N5110740 LEVER REAR BRAKE CAM 1
7 0331248 HEX BOLT M6x33 1
8 0178030 O RING BRAKE CAM 1
9 N2110290 BRAKE PANEL REAR COMP. 1
10 N3200070 PUNCHED WASHER 14.5x22x1.6 1
11 S1111710 CAM BRAKE 1
12 C8110090 SET SHOE BRAKE ASSY. (REAR) 1
13 N3200010 BALL BEARING 12x37x12 1
14 N5111030 TYRE 2.75" x 18" 1
15 N3110430 TUBE ASSY. 2.5" / 2.75"-18" 1
16 N3110450 PROTECTOR WHEEL INNER TUBE1
17 N5110820 RIM WHEEL 1.6" x 18" 1
18 N5320520 SPOKES & NIPPLE ASSY INNER 18
19 N5320530 SPOKES & NIPPLE ASSY OUTER 18
20 N2110190 SPACER COMP FRONT HUB 1
21 N3200010 BALL BEARING 12x37x12 1
22 N2110670 WATER SEAL RING 1
REAR WHEEL ASSEMBLY
23 N5110980 WHEEL ASSY REAR 1
 REAR WHEEL ASSEMBLY
FIG.No. 25

24 N2110250 HUB COMP REAR WHEEL 1

25 N2110360 ABSORBER SHOCK REAR HUB 4
26 N5111080 SHAFT MTG RR SPROCKET DR. 1
27 0331318 BOLT REAR SPROCKET 4
28 N2110370 DRUM REAR SPROCKET MTG 1
29 N5110410 SPROCKET 41T 1
30 N3200090 BALL BEARING 20x42x12 1
31 N3110470 WASHER SPROCKET 2
32 0334548 HEX NUT M8 4
33 N8110380 SPACER LH REAR AXLE 1
34 J200030 HEX NUT M18 1
35 N5200310 PUNCHED WASHER 18.5x30x3.2 1
36 N5111050 AXLE COMP. REAR 1

REAR WHEEL ASSEMBLY

FIG.No. 26
SWING ARM ASSEMBLY

SWING ARM ASSEMBLY

FIG.No. 27
SHOCK ABSORBER & CHAIN COVER ASSY.

1 N5320550 CHAIN CASE SET 1

2 N5091090 CHAIN CASE COMP UPPER 1

3 N5090820 CHAIN CASE COMP LOWER 1

4 0334047 DOMED CAP NUT M10x1.25 2

5 0335628 PUNCHED WASHER 10.5x24x2.3 6

6 N5090860 SHOCK ABSORBER REAR 2

7 0335538 PUNCHED WASHER 125x22x2.3 3

8 N3200050 HEX FLANGE BOLT M10x1.5x36 2

9 N3200250 HEX SCREW M6x10 4

10 0335928 PUNCHED WASHER 6.5x18x1.6 4

11 409198000 DUST SEAL CHAIN COVER 1

SHOCK ABSORBER & CHAIN COVER ASSY.

FIG.No. 28 FIG.No. 28 TOOL KIT

1 N5210120 TOOL KIT SET 1

2 - TOOL BAG 1 N.S
3 - GRIP DRIVER 1 "
4 - BIT (+) (-) 1 "
5 - SPANNER 14x17 1 "
6 - SPANNER 10x12 1 "
7 - BOX SPANNER 16/18 1 "

SPECIAL TOOL

1 N5310010 CLUTCH NUT TIGHTENING TOOL 1 N.I

2 N5310020 CLUTCH HOLDING TOOL 1 N.I

N.S - NOT SERVICED

N.I - NOT ILLUSTRATED

TOOL KIT
 TVS CENTRA PAINTED PARTS
WINE RED

3 2 S.No. PART No. DESCRIPTION

1 N51016406G FENDER FRONT WINE RED

8 7 6 5 4
2 N51202806G HOUSING HEADLAMP FRONT

3 N51402306G TANK COMP FUEL

1 4 N51215706G COVER FRAME RH

5 N51215606G COVER FRAME LH

6 N51202006G COVER SEAT TAIL RH

7 N51201906G COVER SEAT TAIL LH

8 N51202706G COVER SEAT TAIL CENTER

9 ----- TAPE SET LACQUERED

HIGH GLOSS BLACK

3 2 S.No. PART No. DESCRIPTION

1 N51016400D FENDER FRONT WINE RED

8 7 6 5 4
2 N51202800D HOUSING HEADLAMP FRONT

3 N51402300D TANK COMP FUEL

1 4 N51215700D COVER FRAME RH

5 N51215600D COVER FRAME LH

6 N51202000D COVER SEAT TAIL RH

7 N51201900D COVER SEAT TAIL LH

8 N51202700D COVER SEAT TAIL CENTER

9 ----- TAPE SET LACQUERED

‘-----’ LINE INDICATES LH SIDE NEXT PAGE

 TVS CENTRA PAINTED PARTS
TEITIAN BLUE
2 S.No. PART No. DESCRIPTION
3
1 N51016407B FENDER FRONT WINE RED
8 7 6 5 4
2 N51202807B HOUSING HEADLAMP FRONT

3 N51402307B TANK COMP FUEL

1 4 N51215707B COVER FRAME RH

5 N51215607B COVER FRAME LH

6 N51202007B COVER SEAT TAIL RH

7 N51201907B COVER SEAT TAIL LH

8 N51202707B COVER SEAT TAIL CENTER

9 ----- TAPE SET LACQUERED

‘-----’ LINE INDICATES LH SIDE

 PAINTED PARTS FOR TVS CENTRA/CENTRA DLX - W/O STICKER

MKTG/SP/40/2010-11
31/01/2010

Alternate Part
# Old Part No Description MODEL Description MRP
Number

1 N51016400D FENDER FRONT BLACK CENTRA BASIC / DLX N51016400D FENDER FRONT BLACK 497.00

2 N51016404L FENDER FRONT JEWEL GREEN CENTRA BASIC N51016404L FENDER FRONT JEWEL GREEN 497.00

3 N51016406G FENDER FRONT FLAME RED CENTRA BASIC / DLX N51016406G FENDER FRONT FLAME RED 473.00

4 N51016407B FENDER FRONT TEITIAN BLUE CENTRA BASIC N51016407B FENDER FRONT TEITIAN BLUE 497.00

5 N5101640C FENDER FRONT SIL GREY CENTRA BASIC N5101640C FENDER FRONT SIL GREY 497.00

6 N51201900D COVER SEAT TAIL L+TAPESET BLACK CENTRA BASIC

7 N51201900DA COVER SEAT TAIL L+TAPESET BLACK COPPER CENTRA DLX N51201990D COVER SEAT TAIL LH BLACK W/O STICKER 338.00

8 N51201900DB COVER SEAT TAIL L+TAPESET BLACK GOLD CENTRA DLX

9 N51201904L COVER SEAT TAIL L+TAPESET JEWEL GREEN CENTRA BASIC N51201994L COVER SEAT TAIL LH J. GREEN W/O STICKER 338.00

10 N51201906G COVER SEAT TAIL L+TAPESET FLAME RED CENTRA BASIC

11 N51201906GA COVER SEAT TAIL L+TAPESET RED GOLD CENTRA DLX N51201996G COVER SEAT TAIL LH FLAME RED W/O STICKER 338.00

12 N51201906GB COVER SEAT TAIL LH RED SILV -CENTR CENTRA DLX

13 N51201907B COVER SEAT TAIL L+TAPESET TEITIAN BLUE CENTRA BASIC N51201997B COVER SEAT TAIL LH TEI. BLUE W/O STICKER 338.00

14 N5120190C COVER SEAT TAIL L+TAPESET SIL GREY CENTRA BASIC N5120199C COVER SEAT TAIL LH SIL GREY W/O STICKER 338.00

15 N51202000D COVER SEAT TAIL R+TAPESET BLACK CENTRA BASIC

16 N51202000DA COVER SEAT TAIL RH BLACK COPPER -CENTRA CENTRA DLX N51202090D COVER SEAT TAIL RH BLACK W/O STICKER 338.00
 Alternate Part
# Old Part No Description MODEL Description MRP
Number

17 N51202000DB COVER SEAT TAIL RH BLACK GOLD -CENTRA CENTRA DLX

18 N51202004L COVER SEAT TAIL R+TAPESET JEWEL GREEN CENTRA BASIC N51202094L COVER SEAT TAIL RH J. GREEN W/O STICKER 338.00

19 N51202006G COVER SEAT TAIL R+TAPESET FLAME RED CENTRA BASIC

20 N51202006GA COVER SEAT TAIL RH FLAME RED GOLD -CENTR CENTRA DLX N51202096G COVER SEAT TAIL RH FLAME RED W/O STICKER 338.00

21 N51202006GB COVER SEAT TAIL RH FL. RED SILVER -CEN CENTRA DLX

22 N51202007B COVER SEAT TAIL R+TAPESET TEITIAN BLUE CENTRA BASIC N51202097B COVER SEAT TAIL RH TEI. BLUE W/O STICKER 338.00

23 N5120200C COVER SEAT TAIL R+TAPESET SIL GREY CENTRA BASIC N5120209C COVER SEAT TAIL RH SIL GREY W/O STICKER 338.00

24 N51202700D COVER CENTER SEAT TAIL+TAPESET BLACK CENTRA BASIC / DLX N51202700D COVER SEAT TAIL CTR BLACK W/O STICKER 107.00

25 N51202704L COVER CENTER SEAT TAIL+TAPESET J GREEN CENTRA BASIC N51202704L COVER SEAT TAIL CTR J.GREEN W/O STICKER 107.00

26 N51202706G COVER CENTER SEAT TAIL FLAME RED CENTRA BASIC / DLX N51202706G COVER SEAT TAIL CTR FL.RED W/O STICKER 107.00

27 N51202707B COVER CEN SEAT TAIL TEITIAN BLUE CENTRA BASIC N51202707B COVER SEAT TAIL CTR TEI.BLUE W/O STICKER 107.00

28 N5120270C COVER CENTER SEAT TAIL+TAPESET SIL GREY CENTRA BASIC N5120270C COVER SEAT TAIL CTR SIL.GREY W/O STICKER 107.00

29 N51202800D HSG HEAD LAMP+TAPESET BLACK CENTRA BASIC

30 N51202800DA HSG HEADLAMP BLACK COPPER -CENTRA CENTRA DLX N51202890D HSG HEADLAMP BLACK W/O STICKER 466.00

31 N51202800DB HSG HEADLAMP BLACK GOLD -CENTRA CENTRA DLX

32 N51202804L HSG HEAD LAMP+TAPESET JEWEL GREEN CENTRA BASIC N51202894L HSG HEADLAMP JEW. GREEN W/O STICKER 466.00

33 N51202806G HSG HEAD LAMP+TAPESET FLAME RED CENTRA BASIC

34 N51202806GA HSG HEADLAMP FLME RED GOLD -CENTRA CENTRA DLX N51202896G HSG HEADLAMP FLAME RED W/O STICKER 466.00

35 N51202806GB HSG HEADLAMP FLME RED SILVER -CENTRA CENTRA DLX

36 N51202807B HSG HEAD LAMP+TAPESET TEITIAN BLUE CENTRA BASIC N51202897B HSG HEADLAMP TEI.BLUE W/O STICKER 466.00

37 N5120280C HSG HEAD LAMP+TAPESET SIL GREY CENTRA BASIC N5120289C HSG HEADLAMP SIL.GREY W/O STICKER 466.00
 Alternate Part
# Old Part No Description MODEL Description MRP
Number

38 N51215600D COVER FRAME L+TAPESET BLACK CENTRA BASIC

39 N51215600DA COVER FRAME LH BLACK -CENTRA CENTRA DLX N51215690D COVER FRAME LH BLACK W/O STICKER 411.00

40 N51215600DB COVER FRAME LH BLACK GOLD- CENTRA CENTRA DLX

41 N51215604L COVER FRAME L+TAPESET JEWEL GREEN CENTRA BASIC N51215694L COVER FRAME L JEW. GRN W/O STICKER 411.00

42 N51215606G COVER FRAME L+TAPESET FLAME RED CENTRA BASIC

43 N51215606GA COVER FRAME LH FLAME RED GOLD- CENTRA CENTRA DLX N51215696G COVER FRAME LH F. RED W/O STICKER 411.00

44 N51215606GB COVER FRAME LH FLAME RED SILVER -CENTRA CENTRA DLX

45 N51215607B COVER FRAME L+TAPESET TEITIAN BLUE CENTRA BASIC N51215697B COVER FRAME L TEI. BLUE W/O STICKER 411.00

46 N5121560C COVER FRAME LH SILVER GRAY CENTRA BASIC N5121569C COVER FRAME LH SIL. GREY W/O STICKER 411.00

47 N51215700D COVER FRAME R+TAPESET BLACK CENTRA BASIC

48 N51215700DA COVER FRAME RH BLACK COPPER - CENTRA CENTRA DLX N51215790D COVER FRAME RH BLACK W/O STICKER 411.00

49 N51215700DB COVER FRAME RH BLACK GOLD- CENTRA CENTRA DLX

50 N51215704L COVER FRAME R+TAPESET JEWEL GREEN CENTRA BASIC N51215794L COVER FRAME R JEW GRN W/O STICKER 411.00

51 N51215706G COVER FRAME R+TAPESET FLAME RED CENTRA BASIC

52 N51215706GA COVER FRAME RH FLAME RED GOLD- CENTRA CENTRA DLX N51215796G COVER FRAME RH F. RED W/O STICKER 411.00

53 N51215706GB COVER FRAME RH FLAME RED SILVER - CENTRA CENTRA DLX

54 N51215707B COVER FRAME R+TAPESET TEITIAN BLUE CENTRA BASIC N51215797B COVER FRAME R TEI. BLUE W/O STICKER 411.00

55 N5121570C COVER FRAME R+TAPESET SIL GREY CENTRA BASIC N5121579C COVER FRAME R SIL GREY W/O STICKER 411.00

56 N51402300D TANK COMP FUEL+TAPESET BLACK CENTRA BASIC

57 N51402300DA TANK COMP FUEL BLACK COPPER -CENTRA CENTRA DLX N51402390D TANK COMP FUEL BLACK W/O STICKER 2829.00

58 N51402300DB TANK COMP FUEL BLACK GOLD-CENTRA CENTRA DLX

 Alternate Part
# Old Part No Description MODEL Description MRP
Number

59 N51402304L TANK COMP FUEL+TAPESET JEWEL GREEN CENTRA BASIC N51402394L TANK COMP FUEL JEW. GRN W/O STICKER 2829.00

60 N51402306G TANK COMP FUEL+TAPESET FLAME RED CENTRA BASIC

61 N51402306GA TANK COMP FUEL FLAME RED GOLD -CENTRA CENTRA DLX N51402396G TANK COMP FUEL FL. RED W/O STICKER 2829.00

62 N51402306GB TANK COMP FUEL FLAME RED SILVER- CENTRA CENTRA DLX

63 N51402307B TANK COMP FUEL+TAPESET TEITIAN BLUE CENTRA BASIC N51402397B TANK COMP FUEL TEI BLUE W/O STICKER 2829.00

64 N5140230C TANK COMP FUEL+TAPESET SIL GREY CENTRA BASIC N5140239C TANK COMP FUEL SIL GREY W/O STICKER 2829.00
 TVS CENTRA KIT AND KIT DETAILS
KIT CONTENTS
Sl No. KIT No. KIT DESCRIPTION SL NO PART NO. DESCRIPTION QTY
1 N5010580 CYLINDER HEAD ASSY 1

2 M1010620 SEAL VALVE STEM OIL 2

3 M1180030 SPARK PLUG FIERO 1
4 M1200470 HEX FLANGE BOLT M6x30 3
5 N2010330 SHAFT VALVE ROCKER ARM 1
6 N2010340 SPRING VALVE INNER 2
7 N2010350 SPRING VALVE OUTER 2
8 N2010610 VALVE INTAKE 1
9 N2010620 VALVE EXHAUST 1
10 N2010820 CAP INSPECTION PAINTED 2
11 N2011040 RETAINER VALVE SPRING 2
12 N5010080 O-RING CYLINDER HEAD COVER 1
13 N5010250 COVER L CYLINDER HEAD 1
1 N5010630 CYLINDER HEAD ASSY. KIT 14 N5010270 COVER COMP CYL HEAD R 1
15 N5010650 GASKET CYLINDER HEAD COVER R 1
16 N5200510 STUD BOLT CYLINDER NO.1 2
17 N8010080 ARM COMP ROCKER 2
18 N8010140 CAMSHAFT COMP 1
19 S1010210 O-RING CAP INSPECTION 2
20 S1010240 SCREW TAPPET ADJUSTING 2
21 S1010250 NUT TAPPET ADJUSTING 2
22 S1010320 COTTER VALVE 4
23 S1010340 SEAT VALVE SPRING 2
24 S1010430 O-RING CYLINDER 1
25 S1200010 HEX FLANGE BOLT M6x25 4
26 S1200030 HEX. FLANGE BOLT M6x20 2
27 S1200130 BALL BEARING 15x32x9 C3 6002Z 1
 1 N5081080 CHAIIN ASSY. 1
2 N3080040 SPROCKET 14T 1
2 N5320360 CHAIN SPROCKET KIT
3 N5081020 SPROCKET 41T (REAR WHEEL) 1
4 N3110470 WASHER REAR SPROCKET 2

2 N3200010 BRG. REAR WHEEL RH 2

3 N3320100 REAR WHEEL BEARING KIT
3 N3200090 BRG. REAR SPROCKET DRUM 1

1 S1125290 RACE STEERING INNER 1

2 S1101150 RACE STEERING OUTER 1
3 S1100890 STEERING BALL LOWER 19
4 N5320380 STEERING CONE KIT 4 420404 STEERING BALL 22
5 M1100450 DUST SEAL 1
6 M1100460 CONE, BOTTOM 1
7 S1100870 CUP, BOTTOM 1

6 ------- CRANK SHAFT 1

5 N5020080 CRANK SHAFT ASSY 7 N2200390 BALL BEARING 6205 VQ 091 2
8 N5020109 SPROCKET 17T CAMCHAIN DRIVE 1

1 N5010490 PISTON STD 1

4 N5320440 RING SET STD 1
6 N5320410 PISTON KIT STD
2 N5010550 PISTON PIN 1
3 N2200340 CIRCLIP 2

1 N5320010 PISTON I O/S 1

2 N5320450 RING SET I O/S 1
7 N5320420 PISTON KIT I O/S
2 N5010550 PISTON PIN 1
4 N2200340 CIRCLIP 2

1 N5320020 PISTON II O/S 1

2 N5320440 RING SET II O/S 1
8 N5320430 PISTON KIT II O/S
3 N5010550 PISTON PIN 1
4 N2200340 CIRCLIP 2
 1 S1200120 BALL BEARING 17x35x10 C3 6003 1
9 N8010140 CAM SHAFT ASSY 2 N5010469 FLANGE CAMSHAFT 1
3 N5010600 CAMSHAFT 1

1 N5010520 RING PISTON TOP STD 1

10 N5320440 RING SET PISTON STD 2 N5010530 RING PISTON BOTTOM STD 1
3 N5010540 OIL RING SET STD 3

1 N5320030 RING PISTON TOP I O/S 1

11 N5320450 RING SET PISTON I O/S 2 N5320050 RING PISTON BOTTOM I O/S 1
3 N5320070 OIL RING SET I O/S 1

1 N5320040 RING PISTON TOP II O/S 1

12 N5320460 RING SET PISTON II O/S 2 N5320060 RING PISTON BOTTOM II O/S 1
3 N5320080 OIL RING SET II O/S 1

1 N5010010 CYLINDER BLOCK 1

2 N5320410 PISTON KIT STD 1
13 N5320480 CYLINDER BLOCK AND PISTON KIT
3 N5010350 GASKET CYLINDER HEAD 1
4 N5010170 GASKET CYLINDER 1

1 N5110700 SPOKE WHEEL FRONT INNER 18

14 N5320520 SPOKE AND NIPPLE INNER
2 N3110200 NIPPLE SPOKE WHEEL 18

1 N5110690 SPOKE WHEEL FRONT INNER 18

15 N5320530 SPOKE AND NIPPLE OUTER
2 N3110200 NIPPLE SPOKE WHEEL 18

1 N5120730 PROP STAND 1

2 N5121610 SPRING PROP STAND 1
16 N5320540 KIT PROP STAND
3 0331508 HEX BOLT 1
4 0334038 WASHER 1

1 N5091090 CHAIN CASE UPPER 1

17 N5320550 CHAIN CASE SET
2 N5090820 CHAIN CASE LOWER 1
 1 N5070270 PLATE CLUTCH DRIVE JUDDER 1
N5320670 SET CLUTCH PLATE DRIVE
4
18 2 N5070140 CLUTCH PLATE DRIVE

19 N5320680 SET CLUTCH PLATE DRIVEN 1 3062020 CLUTCH PLATE DRIVEN 4

1 N2320410 WASHER ( AS) 1

2 N2320420 O RING ( AS) 1
3 N2320450 WASHER ( TS) 1
4 N2320460 O RING ( TS) 1
20 N5320570 CARBURETTOR REPAIR KIT 5 N2320320 SEAL BOWL 1
6 N2320630 WASHER JET NEEDLE 1
7 N2320340 O RING JET NEEDLE 1
8 N5320240 PACKING CHOKE LEVER 1
9 N5320330 RING CHOKE LEVER 1

1 S1010210 O RING CAP INSPETION 2

2 N5010080 O RING COVER CYLINDE HEAD LH 1
3 N2320570 O RING CARBURETTOR FLANGE 1
21 N5320630 O RING KIT ENGINE 4 S1010430 O RING CYLINDER 1
5 N2080810 O RING 1
6 N5200070 O RING 95.5X2 1
7 N8040340 O RING AIR INJECTION 1

1 N5010650 CASKET COVER CYLINDER HEAD R 1

2 N8040210 GASKET PIPE INLET 1
3 N5010350 GASKET CYLINDER HEAD NUT 1
22 N5320640 ENGINE MINOR GASKET KIT
4 T4050180 GASKET EXHUST MANIFOLD 1
5 N5030130 GASKET COVER CLUTCH 1
6 N5010560 GASKET TENSIONER ADJUSTER 1

1 N5101610 UNDER BRACKET COMP 1

23 N5320560 UNDER BRACKET ASSY 2 M1100450 DUST SEAL STEERING LOWER 1
3 M1100460 CONE BOTTOM 1
