UJ440

Original Instructions
uK440i Spare Parts Book

UJ440i-EN-160922
uK440i
©Copyright 2022 Sandvik Mining & Rock Technology
All rights reserved. No parts of this document may be reproduced or copied in any form or by any
means without written permission from Sandvik. All data and information in this manual may be
changed without further notice. Reservation for misprints.
Sandvik Ltd
T/As Sandvik Construction Mobile Crushers and Screens
Tullyvannon, Ballygawley, Co. Tyrone, Northern Ireland BT70 2HW
Tel. +44 (0)28 8556 7799
W: www.construction.sandvik.com
E: info.mobilecs@sandvik.com
uK440i SPARE PARTS BOOK
Spare Parts Book

INTRODUCTION
Introduction
1. Ordering Procedure
WARNING
UNAUTHORISED PARTS HAZARD
Use of unauthorised parts present an uncontrolled risk and
could cause death or severe injury. The use of unauthorised
parts will also invalidate warranty. It is the user’s
responsibility to use only authorised parts as listed in the
parts manual.
The following illustrations indicate spare parts available for order, identify relevant part/s and provide the
following detail during the ordering process.
This ensures correct delivery of replacement parts with a minimum delay:
• Machine, model and serial number.
• Year of manufacture.
• Part number identified from the parts list.
• Part description identified from the parts list.
• Issue reference of manual, illustration title and page number.
• Quantity required.
2. Safety Decals
For location and part numbers. refer to Safety section of Operator’s Manual.
Copyright © Sandvik Mining & Rock Technology

8
UJ440i Standard Machine

9
BASE UNIT UJ440I
700-3125-901 - REV 20
5
Crusher Installation - Hammer Option
10
Crusher Installation - Standard build Option
11
4
13
18
16
19
17
1
15
20
8
19
2
19 22
7 12
21 14
BASE UNIT UJ440I
700-3125-901 - REV 20
PARTS LIST
ITEM PART No. ITEM NAME QTY REMARKS
1 700-0085-901 HOOD 1
2 700-0314-90 UJ440i Hydraulic equipment, Assembly 1
3 700-0844-901 Hydraulic box, RH side, assembly 1
4 700-0866-901 Toolbox assembly 1
5 700-1213-901 ASSY OF V-BELT COVERS 1
6 700-3180-901 Hydraulic & fuel tank, Assy 1
7 700-4764-901 ASSEMBLY OF UJ440i CHASSIS 1
8 700-5339-901 UJ440i Installation rail, Assembly 1
9 700-6438-901 CONVEYOR ARRANGEMENT 1
10 700-8181-901 CRUSHER STATION AR WITH HAMMER 1
11 700-8708-901 ASSEMBLY OF CRUSHER STATION 1
12 703-0180-901 ASSEMBLY OF L.H. ACCESS PLATFORM - R.H. HINGE 1
13 703-0507-901 UJ440I SIDE PODS ASSEMBLY 1
14 703-0821-901 FOLDING PLATFORM ASSEMBLY 1
15 BG01224772 Centre Platform Assy 1
16 BG01246028 SPIRIT LEVEL ASSY 1
17 BG01345856 HOOD ASSY 1
18 BG01345859 COVER ASSY 1
19 BG01499163 Emergency Stop Assembly 3
20 BG01499466 Cover Assembly 2
21 EL10776 UJ440i Electrical Control System 1
22 HHK0135 UJ440I HOSE KIT - CRUSHER 1
UJ440i Hydraulic equipment, Assembly
700-0314-90 - REV 2
39 36 35 2 26 38 43
7
5
33 37
19
A 42
40
17
37
42
31 6
42 30
8
20 A(0.050) 28
16
34 3
41
38
30 47 44
32
23
46
37 42
13
30
42
14
27 11
24 12
47 1 48
9
30
18
21 15
4
29
44
22
25
45
10
UJ440i Hydraulic equipment, Assembly
700-0314-90 - REV 2
PARTS LIST
1 700-0708-00 VALVE BRACKET 1
2 700-2423-901 US440i/UH440i/UJ440i Drain connection, Front, Assy 1
3 700-2428-901 UJ440i / US440i / UH440i Brake valve, Assembly 1
4 700-2444-901 High pressure filter, Left, Assy 1
5 700-2445-901 Cooling fan block, Assy 1
6 700-2450-901 Drain filter, Assembly 1
7 700-2474-901 Hydraulic oil cooler, Assembly 1
8 700-2475-901 Transmission cooler, Assembly 1
9 700-2507-901 Motor, Right 1
10 700-2508-901 Motor, Left 1
11 700-4990-901 Rubber, Assembly 2
12 700-5631-901 Drain connection, Rear, Assy 1
13 700-5644-901 High pressure filter, Right, Assy 1
14 700-5646-901 Check valve, Assembly 1
15 700-5669-901 UJ440i Valve DGMS-3-3E-40R 1
16 700-5718-901 Valve CSS-adjusting 1
17 700-5736-901 Return block, Assembly 1
18 700-5993-901 HYDRAULIC BLOCK ASSY 1
19 700-6023-901 Reverse conveyor coupl. 1
20 700-6164-901 VALVE 3M4-15-2X, RIGHT, ASSY 1
21 700-6176-901 VALVE 2M-15-2X LEFT, ASSY. 1
22 700-6658-901 NF CONV. QUICK-C. FRAME ASSY 1
23 700-6688-901 Hang. scr. prep. Assy RH side 1
24 700-6692-901 HANG. SCR. PREP. ASSY LH SIDE 1
25 840-0016-00 SCREW M6S 6X50 8.8 FZB ISO 401 (USE 840.0016-00) 2
26 840-0017-00 SCREW M6S 6x60 8.8 ZP ISO 4014 (USE 840.0017-00) 2
27 840-0021-00 SCREW M6S M8x20 8.8 ISO4017 FZB 5
28 840-0023-00 SCREW M6S M8X25 8.8 ZP (840.0023-00) 2
29 840-0026-00 SCREW M6S 8x40 8.8 FZB ISO 4014 (USE 840.0026-00) 4
30 840-0033-00 SCREW M6S 10X20 8.8 ISO4017 (USE 840.0033-00) 14
31 840-0036-00 SCREW M6S 10X30 8.8 ISO 4017 (USE 840.0036-00) 4
32 840-0039-00 SCREW M6S 10X45 8.8(USE 840.0039-00) 4
33 840-0618-00 SCREW M6S 10x130 8.8 2
34 840-0979-00 SKRUV M6S 6x60 H 2
35 841-0571-00 SCREW MC6S 8x160 12.9 2
36 845-0205-00 LOCK NUT M8 8 FZB ISO 7040 (USE 845.0205-00) 4
38 845-0217-00 NUT LOCK ISO 7040 M6 8 FZB (USE 845.0217-00) 6
39 847-0012-00 WASHER BRB 8,4X16 HB200 ISO 7089 (USE 847.0012-00) 8
40 847-0047-00 WASHER S4B Ø11x30 SQ DIN 436. 4
41 847-0133-00 WASHER TBRSB 8,4X26(USE 847.0133-00) 2
42 847-0144-00 WASHER BRB 10.5x22 HB200 ZP ISO 7089 (USE 847.0144-00) 22
44 847-0286-00 WASHER NL-M8 (USE 847.0286-00) 9
45 847-0313-00 WASHER NL-M6 2
46 847-0317-00 WASHER SRKB 7x19x1,5 FZB 6
47 847-0353-00 WASHER NL M10SP (USE 847.0353-00) 8
48 900-2484-00 HOSE CLAMP 2-217,2/17,2-PAH 4
Drain connection, Rear, Assy
700-5631-901 - REV 1
1 8 4 3 5 2
7
Drain connection, Rear, Assy
700-5631-901 - REV 1
PARTS LIST
1 900-2302-00 PLUG - VSTI - G 1/2-ED. 1
2 900-2350-00 Adapter LOO 1363 1
3 900-2353-00 Adaptor SOG 1106 G3/8B. 1
4 900-2431-00 ADAPTER SOG 1306 2
5 900-2443-00 ADAPTER NOP 13 1
6 900-2502-00 PLUG G3/8B. 3
7 900-2546-00 ADAPTER SOG 1908 G1/2B 1
8 902-0919-00 DISTRIBUTION BLOCK 1
US440i/UH440i/UJ440i Drain connection, Front, Assy
700-2423-901 - REV 4
10
3 8
9
6
11 4
US440i/UH440i/UJ440i Drain connection, Front, Assy
700-2423-901 - REV 4
PARTS LIST
1 873-0383-00 Sealing Ring Tredo 16 1
2 873-0538-00 SEAL RING TREDO NR 12 1
3 900-1095-00 REDUCER RI-06-02 3/8''-1/8' 1
4 900-2349-00 ADAPTER TEE M/FM/M LOO 1161 1
5 900-2350-00 Adapter LOO 1363 1
6 900-2353-00 Adaptor SOG 1106 G3/8B. 4
7 900-2431-00 ADAPTER SOG 1306 1
8 900-2522-00 PLUG NOP 11 1
9 900-2546-00 ADAPTER SOG 1908 G1/2B 2
10 902-0919-00 DISTRIBUTION BLOCK 1
11 912-0184-00 PRESSURE SWITCH FIOT O FIOTF 1
UJ440i / US440i / UH440i Brake valve, Assembly
700-2428-901 - REV 3
2
UJ440i / US440i / UH440i Brake valve, Assembly
700-2428-901 - REV 3
PARTS LIST
1 900-2353-00 Adaptor SOG 1106 G3/8B. 1
2 900-2460-00 Adapter WOG 1106 2
3 902-0934-00 Valve WK 1
4 902-0935-00 HOUSING G 3/8 1
High pressure filter, Right, Assy
700-5644-901 - REV 1
1
High pressure filter, Right, Assy
700-5644-901 - REV 1
PARTS LIST
1 900-2371-00 ADAPTER WOG 2316 1
2 900-2441-00 ADAPTER WOO 2373 1
3 900-2445-00 ADAPTER SOG 2320 1
4 900-2472-00 REDUCING RI-20-16-JE 1
5 912-0229-00 FILTER DF BNHC240 TE20 C1.0/B6 1
High pressure filter, Left, Assy
700-2444-901 - REV 2
1
High pressure filter, Left, Assy
700-2444-901 - REV 2
PARTS LIST
1 900-2441-00 ADAPTER WOO 2373 2
2 900-2445-00 ADAPTER SOG 2320 2
3 912-0229-00 FILTER DF BNHC240 TE20 C1.0/B6 1
Cooling fan block, Assy
700-2445-901 - REV 4
1
Cooling fan block, Assy
700-2445-901 - REV 4
PARTS LIST
1 900-2343-00 ADAPTER WOO 1363 2
2 900-2354-00 ADAPTER STRAIGHT SOG 1308 G1/2 6
3 900-2450-00 ADAPTER WOG 1308 2
4 902-0911-00 RELIEF VALVE UNIT 2
VALVE 3M4-15-2X, RIGHT, ASSY
700-6164-901 - REV 2
8 10 3 11 15
22
10
2
23
14
21
20
19
1
4
6
14 12
26
7
19
18
25
19
17
16
13
24 5
6 14 9
VALVE 3M4-15-2X, RIGHT, ASSY
700-6164-901 - REV 2
PARTS LIST
1 873-0385-00 BONDED SEAL - G 1/2 1
2 900-2344-00 Adapter WOO 1969 1
3 900-2347-00 ADAPTER ROO 1973 1
5 900-2350-00 Adapter LOO 1363 1
6 900-2352-00 ADAPTER SOG 1104 G1/4B 3
7 900-2355-00 Adapter SOG 1912 1
8 900-2356-00 ADAPTOR - SOG 2316. 1
9 900-2367-00 ADAPTER ROO 1113 1
10 900-2368-00 ADAPTER LOO 2373 2
11 900-2369-00 ADAPTER SOG 2312 1
12 900-2373-00 ADAPTER FM/FM SSO 5461 2
13 900-2432-00 ADAPTER SOG 0904 G1/4B 1
14 900-2433-00 ADAPTER SOG 1312 G3/4B 3
15 900-2434-00 ADAPTER WOG 2316 90 DEG 1
16 900-2435-00 Adapter WOG 1912 1
17 900-2436-00 ADAPTER LOO 0959 1
18 900-2437-00 ADAPTER SSO 5459 1
19 900-2438-00 TEST POINT (USE 900.2438-00) 3
20 900-2458-00 ADAPTOR - 204 - 12 1
21 900-2471-00 ADAPTER TOO 1161 2
22 900-2500-00 ADAPTER WOG 2312 1
23 900-2564-00 ADAPTER ROO 1373 1
24 900-2571-00 ADAPTER TOG 0904 1
25 902-0858-93 Main valve RH 1
26 984-1212-00 PRESSURE TRANSMITTER MBS 3050 1
Drain filter, Assembly
700-2450-901 - REV 2
1
Drain filter, Assembly
700-2450-901 - REV 2
PARTS LIST
1 900-2355-00 Adapter SOG 1912 1
2 900-2435-00 Adapter WOG 1912 1
3 912-0185-00 LEAKAGE FILTER FRCA 60/02 1
Check valve, Assembly
700-5646-901 - REV 3
4
8
11
6
10
7
7 3
Check valve, Assembly
700-5646-901 - REV 3
PARTS LIST
1 703-1125-001 CLAMP 6S-6057,2-PP 2
2 840-1182-00 SCREW M6S 12x220 2
4 847-0014-00 WASHERS, BRB,ISO 7089,STEEL HB 200 MIN 2
5 900-2347-00 ADAPTER ROO 1973 1
6 900-2368-00 ADAPTER LOO 2373 1
7 900-2445-00 ADAPTER SOG 2320 3
8 900-2542-00 COVER PLATE DPAL-6S 2
9 900-2717-00 ADAPTER LOG 2720 1
10 900-2718-00 ADAPTER ROO 1977 1
11 902-0916-00 CHECK VALVE 8.0 B 2
Hydraulic oil cooler, Assembly
700-2474-901 - REV 3
1 8 5 13 11 9
10
4
14
12 2 15 13 11
Hydraulic oil cooler, Assembly
700-2474-901 - REV 3
PARTS LIST
1 453-7081-01 Cover 1
2 453-7083-01 Spacer 8
3 700-0362-00 OIL COOLER SUPPORT PLATE 1
4 840-0027-00 SCREW M6S 8x45 8.8 6
5 840-0028-00 SCREW M6S 8x50 8.8(USE 840.0028-00) 2
7 847-0013-00 WASHER BRB 10x18 HB200 SS70 8
8 847-0318-00 WASHER SRKB 9x28x2 FZB 16
9 900-1933-00 PLUG VSTI R 1 1/2''-ED 1
10 900-2350-00 Adapter LOO 1363 1
12 900-2446-00 ADAPTER STRAIGHT 3224 G1 1/2 2
13 900-2543-00 CONNECT. FALANGE T30-13.5-R1/2. 2
14 900-2596-00 ADAPTER SOG 1304 G1/4B 1
15 910-0105-90 COOLER HP 60-14V/HYD/8CC 1
Transmission cooler, Assembly
700-2475-901 - REV 3
7 3
3
4
8
1
9 11 10
Transmission cooler, Assembly
700-2475-901 - REV 3
PARTS LIST
1 453-7081-01 Cover 1
2 453-7083-01 Spacer 6
3 840-0026-00 SCREW M6S 8x40 8.8 FZB ISO 4014 (USE 840.0026-00) 6
4 847-0318-00 WASHER SRKB 9x28x2 FZB 12
5 900-0582-00 REDUCERING RI-20-12 1 1/4"-3/4 2
6 900-2352-00 ADAPTER SOG 1104 G1/4B 1
8 900-2355-00 Adapter SOG 1912 2
9 900-2433-00 ADAPTER SOG 1312 G3/4B 2
10 910-0127-00 COOLER 06134002080C1 1
11 923-0510-00 THERMOSTAT TK 60-48GR NC 1
Return block, Assembly
700-5736-901 - REV 2
8 1 7 9 15
11
10
12
13 16 6 14
Return block, Assembly
700-5736-901 - REV 2
PARTS LIST
1 453-4051-01 RETURN BLOCK CM1208H, S/H4800 1
2 840-0036-00 SCREW M6S 10X30 8.8 ISO 4017 (USE 840.0036-00) 8
3 840-0045-00 SCREW M6S 12x30 ZP 8.8 FT (USE 840.0045.00) 8
4 847-0229-00 LOCK WASHER NL-M10 (USE 847.0229-00) 8
5 847-0258-00 WASHER NL M12 (USE 847.0258-00) 8
6 873-1313-00 O-RING 32,93X3,53 NITRIL 90GR 1
7 900-2201-00 Flange half SAE 3000 2" 2
8 900-2265-00 BLANKING PLUG 3/4" 3
9 900-2302-00 PLUG - VSTI - G 1/2-ED. 1
10 900-2345-00 ADAPTER REDUCER ROO 1119 1
11 900-2355-00 Adapter SOG 1912 1
12 900-2384-00 FLANGE HALF SAE 3000PSI 2
13 900-2385-00 FLANGE HALF SAE 3000 1'' 2
14 900-2414-00 PLUG VSTI M48X2-ED 1
15 900-2447-00 ADAPTER SOG 1108 1
16 900-2521-00 FLANGE 3000-16 SAE 1'' 1
Motor, Right
700-2507-901 - REV 1
4
Motor, Right
700-2507-901 - REV 1
PARTS LIST
1 000-0190-001 Hydraulic motor 1
2 841-0529-00 SCREW MC6S 14x45 12,9 8
3 873-0382-00 BONDED SEAL - G 1/4 1
5 900-2352-00 ADAPTER SOG 1104 G1/4B 1
6 900-2378-00 FLANGE HALF SAE 6000 1 1/4 4
7 900-2475-00 ADAPTER SOCKET G1/4 1
Valve CSS-adjusting
700-5718-901 - REV 3
1
23
14 15
17
12 18
13 16
22
6
7
8
21
11
3
13
9
10
19
2
4 20
2
7
Valve CSS-adjusting
700-5718-901 - REV 3
PARTS LIST
1 841-0570-00 SCREW MC6S 5X100 12.9 4
2 873-0382-00 BONDED SEAL - G 1/4 2
3 873-0384-00 Seal, Bonded, G 1/2 3
4 900-0652-00 ADAPTER M/M G1/4B x G1/4B 1
5 900-1030-00 REDUCING BUSH M/FM G1/2B x G1/4 1
6 900-2302-00 PLUG - VSTI - G 1/2-ED. 2
7 900-2432-00 ADAPTER SOG 0904 G1/4B 2
8 900-2436-00 ADAPTER LOO 0959 1
9 900-2438-00 TEST POINT (USE 900.2438-00) 1
10 900-2447-00 ADAPTER SOG 1108 2
11 900-2470-00 ELBOW ADAPTOR WOG 1108 1/2 1
12 900-2487-00 TEST CONNECTOR ST02-R-JE-PC 1
13 900-2519-00 ADAPTER G 1/2 BXG 1/4 B 2
14 902-0875-00 VALVE DG4V-3-2A-M-U-H7-60 1
15 902-0897-00 SOLENOID VALVE INCKL. SOLENOID 1
16 902-0901-00 PRESS. REDUCER DGMX2 2
17 902-0924-00 RESTRICTOR PLUG DIA 1,5 1
18 902-0966-00 VALVE CDAA-BBN-GBS 1
19 902-0969-00 MOUNTING PLATE CETOP 3-2E-20 1
20 902-0979-00 CHECK VALVE G 1/4 1
21 904-0497-00 HOSE 821-P71-04-09-P71-04-09 1
22 984-1087-00 PRESSURE SWITCH 0184459031009 1
23 FASKT05X70 M5 X 70 HEX SOCKET CAP HEAD SCREW FZB 12.9 4
Reverse conveyor coupl.
700-6023-901 - REV 1
8 4
3
1
A(0.150)
Reverse conveyor coupl.
700-6023-901 - REV 1
PARTS LIST
1 900-2344-00 Adapter WOO 1969 1
3 900-2355-00 Adapter SOG 1912 1
4 900-2469-00 ADAPTER LOG 1219 1
5 900-2945-00 ADAPTER SGO 0869 1
6 902-0867-00 CHECK VALVE 3/4", 0.35BAR 1
7 902-1038-00 BALL VALVE KHB-G1/2" 1
8 904-0293-00 HOSE 821-P70-08-13-P71-08-13 L=3100 1
9 904-0752-00 HOSE 833-P70-12-19-P70-12-19 L=3200 1
HYDRAULIC BLOCK ASSY
700-5993-901 - REV 2
1
2
3
HYDRAULIC BLOCK ASSY
700-5993-901 - REV 2
PARTS LIST
1 700-5115-001 HYDRAULIC BLOCK 1
2 900-2353-00 Adaptor SOG 1106 G3/8B. 4
3 900-2460-00 Adapter WOG 1106 2
VALVE 2M-15-2X LEFT, ASSY.
700-6176-901 - REV 2
17 7 20 21 9 8 8 16
2
19
13
16
23
3
22
1
15
6
14
18
10
12
13
11 16 12 6
VALVE 2M-15-2X LEFT, ASSY.
700-6176-901 - REV 2
PARTS LIST
1 873-0382-00 BONDED SEAL - G 1/4 2
2 873-0385-00 BONDED SEAL - G 1/2 1
3 900-0652-00 ADAPTER M/M G1/4B x G1/4B 1
4 900-1645-00 COUPLING G 1/4 BXG 1/4 1
5 900-2265-00 BLANKING PLUG 3/4" 3
6 900-2352-00 ADAPTER SOG 1104 G1/4B 2
7 900-2355-00 Adapter SOG 1912 2
8 900-2356-00 ADAPTOR - SOG 2316. 2
9 900-2368-00 ADAPTER LOO 2373 1
10 900-2369-00 ADAPTER SOG 2312 1
11 900-2373-00 ADAPTER FM/FM SSO 5461 1
12 900-2432-00 ADAPTER SOG 0904 G1/4B 2
13 900-2433-00 ADAPTER SOG 1312 G3/4B 2
14 900-2436-00 ADAPTER LOO 0959 1
15 900-2437-00 ADAPTER SSO 5459 1
16 900-2438-00 TEST POINT (USE 900.2438-00) 4
17 900-2458-00 ADAPTOR - 204 - 12 1
18 900-2471-00 ADAPTER TOO 1161 1
19 900-2476-00 ADAPTER TGG 5454 1
20 900-2500-00 ADAPTER WOG 2312 1
21 900-2564-00 ADAPTER ROO 1373 1
22 902-0857-92 MAIN VALVE LH 1
23 984-1212-00 PRESSURE TRANSMITTER MBS 3050 1
Hang. scr. prep. Assy RH side
700-6688-901 - REV 1
11
14
10
15
17
16
11
12
13
5
Hang. scr. prep. Assy RH side
700-6688-901 - REV 1
PARTS LIST
1 900-2325-00 Quick coupling male 3/4" 1
2 900-2326-00 Quick coupling 3/4" female 1
3 900-2327-00 COUPLING - QUICK - MALE - G 1/2. 1
4 900-2329-00 Dust cap 3/4" Female 1
5 900-2330-00 Dust cap 3/4" Male 1
6 900-2331-00 DUST CAP - G 1/2. 1
7 900-2352-00 ADAPTER SOG 1104 G1/4B 1
8 900-2442-00 ADAPTER BOO 1313 1
9 900-2462-00 ADAPTER SGO 1269 2
10 900-2467-00 ADAPTER SGO 0863 1
11 900-2490-00 ADAPTER BOO 1919 2
12 900-2703-00 QUICK COUPLING 1/4"" MALE 1
13 900-2704-00 QUICK COUPLING 1/4" FEMALE 1
14 900-2705-00 ADAPTER BOO 0909 1
15 900-2714-00 RESTRICTOR ADAPTER SGO 0459 D 1
16 919-0221-00 DUST CAP 1/4"" MALE 1
17 919-0222-00 DUST CAP 1/4" FEMALE 1
HANG. SCR. PREP. ASSY LH SIDE
700-6692-901 - REV 1
11
10
13
3
12
7
HANG. SCR. PREP. ASSY LH SIDE
700-6692-901 - REV 1
PARTS LIST
3 900-2329-00 Dust cap 3/4" Female 1
4 900-2330-00 Dust cap 3/4" Male 1
5 900-2352-00 ADAPTER SOG 1104 G1/4B 1
6 900-2462-00 ADAPTER SGO 1269 2
7 900-2490-00 ADAPTER BOO 1919 2
8 900-2703-00 QUICK COUPLING 1/4"" MALE 1
9 900-2704-00 QUICK COUPLING 1/4" FEMALE 1
10 900-2705-00 ADAPTER BOO 0909 1
11 900-2714-00 RESTRICTOR ADAPTER SGO 0459 D 1
12 919-0221-00 DUST CAP 1/4"" MALE 1
13 919-0222-00 DUST CAP 1/4" FEMALE 1
NF CONV. QUICK-C. FRAME ASSY
700-6658-901 - REV 1
1
10
9
6
8
4
6
NF CONV. QUICK-C. FRAME ASSY
700-6658-901 - REV 1
PARTS LIST
1 900-2327-00 COUPLING - QUICK - MALE - G 1/2. 1
2 900-2328-00 QUICK COUPLING 1/2"" FEMALE 1
3 900-2331-00 DUST CAP - G 1/2. 1
4 900-2332-00 DUST CAP 1/2"" FEMALE 1
5 900-2367-00 ADAPTER ROO 1113 1
6 900-2442-00 ADAPTER BOO 1313 3
8 900-2466-00 Dust cap 3/8" Male 1
9 900-2467-00 ADAPTER SGO 0863 2
10 900-2482-00 ADAPTER SGO 0663 G3/8B 1
CRUSHER STATION AR WITH HAMMER
700-8181-901 - REV 3
6
CRUSHER STATION AR WITH HAMMER
700-8181-901 - REV 3
PARTS LIST
1 700-0366-00 Hopper, Feed 1
2 700-1163-901 ASSEMBLY OF CRUSHER 1
3 700-8132-901 Platform 1
4 BG01180364 Support Assembly 2
6 BG01180511 Ladder Assy 1
ASSEMBLY OF CRUSHER
700-1163-901 - REV 8
11 10 12 1
6 5
13
3
8
9
ASSEMBLY OF CRUSHER
700-1163-901 - REV 8
PARTS LIST
1 700-2542-901 FEED HOPPER SUPPORT BRKT - L.H. 1
2 700-2543-901 FEED HOPPER SUPPORT BRKT - R.H. 1
3 700-3524-00 Fixing Bar Assy 1
4 700-3524-90 Fixing Bar Assy 1
5 840-0669-00 SCREW M6S M24X70 8.8 ZP (USE 840.0669-00) 12
6 847-0124-00 WASHER BRB 25x45 HB200 ZP ISO 7089 (USE 847.0124-00) 12
7 BG01172936 Bracket, Mounting, Assy 4
8 BG01173132 DUST SEALING ASSY 2
9 BG01173162 Hood Assembly 1
10 BG01180010 Plate 2
11 BG01180016 Plate 2
12 BG01651615 Sensor Assembly 1
13 CJ412-ARB001 CJ412 HD/R-CC T=6 1
Fixing Bar Assy
700-3524-90 - REV 0
6 8 3 1 4 2 7 9
9 5
Fixing Bar Assy
700-3524-90 - REV 0
PARTS LIST
1 453-6961-02 Rubber Cloth 1
2 650-6100-00 CLAMPING PLATE (PLATE 355MCD) 9
3 700-1148-001 Plate 1
4 700-4107-001 Clamping rod Ø8x1800 1
5 840-0041-00 SCREW M6S 10x60 GR 8.8 ISO 4014. 9
6 840-0076-00 SCREW M6S M20X40 8.8 ZP FT (USE 840.0076.00) 3
8 847-0132-00 WASHER ROUND 21X36 ZP 3
Fixing Bar Assy
700-3524-00 - REV 0
1 3 6 8
4 9 7 2 5 9
Fixing Bar Assy
700-3524-00 - REV 0
PARTS LIST
1 453-6961-02 Rubber Cloth 1
3 700-1148-001 Plate 1
4 700-4107-001 Clamping rod Ø8x1800 1
5 840-0041-00 SCREW M6S 10x60 GR 8.8 ISO 4014. 9
8 847-0132-00 WASHER ROUND 21X36 ZP 3
DUST SEALING ASSY
BG01173132 - REV A
1
DUST SEALING ASSY
BG01173132 - REV A
PARTS LIST
1 700-2814-001 DUST SEALING 1
2 700-2815-001 Plate 1
3 840-0665-00 SCREW M6S 24x50 8.8(USE 840.0665-00) 2
Hood Assembly
BG01173162 - REV A
2
4 6
7 3
1
Hood Assembly
BG01173162 - REV A
PARTS LIST
1 453-6961-01 RUBBER CLOTH 1
2 700-3261-901 HOOD ASSY 1
3 840-0038-00 SCREW M6S 10x40 8.8 FZB (USE 840.0038-00) 10
6 847-0132-00 WASHER ROUND 21X36 ZP 4
8 BG00713608 WASHER HRSB 13,5x29x2 10
Bracket, Mounting, Assy
BG01172936 - REV A
2
Bracket, Mounting, Assy
BG01172936 - REV A
PARTS LIST
1 700-0530-00 Spacer 2
2 700-0839-901 V BELT GUARD MOUNTING BRACKET. 1
3 840-0072-00 SCREW M6S 16X70 8.8 ISO 4014 (USE 840.0072-00) 2
4 847-0016-00 WASHER BRB 17x30 HB200 ISO 7089 (USE 847.0016-00) 2
Hopper, Feed
700-0366-00 - REV 6
6
Hopper, Feed
700-0366-00 - REV 6
PARTS LIST
1 700-0333-00 Plate, Wear, Assy 1
2 700-0937-901 Ultrasonic sensor bracket, LH 1
3 700-1007-901 Ultrasonic sensor bracket, RH 1
4 700-2545-901 FEEDER HOPPER FABRICATION. 1
5 BG01170834 Rubber Assembly 1
6 BG01170871 Rubber Assembly 1
7 BG01170933 Rubber Curtain Assembly 1
Plate, Wear, Assy
700-0333-00 - REV 0
6 8
11
4
9
1
10
3
Plate, Wear, Assy
700-0333-00 - REV 0
PARTS LIST
1 700-0333-01 Wear Plate 1
2 700-0333-02 Wear Plate 1
3 700-0333-03 Plate, Wear 1
4 700-0333-04 Wear Liner 1
5 700-0333-05 Wear Liner 1
6 700-0333-06 Wear Liner 1
7 700-0333-07 Wear Liner 1
8 700-0333-08 Wear Liner 1
9 841-0435-00 SCREW MF6S 10X40 8.8(USE 841.0435-00) 50
Rubber Curtain Assembly
BG01170933 - REV A
5 4
3 5
Rubber Curtain Assembly
BG01170933 - REV A
PARTS LIST
1 700-0344-00 RUBBER CLOTH 1
2 700-3522-901 FIXING BAR 1
3 840-0636-00 SCREW M6S 16x110 8.8 ISO4014 FZB (USE 840.0636-00) 5
Rubber Assembly
BG01170834 - REV A
7 6
1 5
4
Rubber Assembly
BG01170834 - REV A
PARTS LIST
2 700-4021-001 Rubber, Cloth 1
3 700-4036-001 Clamping rod Ø8 x 270 1
4 700-4038-001 CLAMPING ROD 8 X 360 1
5 840-0038-00 SCREW M6S 10x40 8.8 FZB (USE 840.0038-00) 6
Rubber Assembly
BG01170871 - REV A
1 5
6 7 2
3
Rubber Assembly
BG01170871 - REV A
PARTS LIST
2 700-4021-001 Rubber, Cloth 1
3 700-4036-001 Clamping rod Ø8 x 270 1
4 700-4038-001 CLAMPING ROD 8 X 360 1
5 840-0038-00 SCREW M6S 10x40 8.8 FZB (USE 840.0038-00) 6
Support Assembly
BG01180364 - REV A
6 5
4 6
5 6
Support Assembly
BG01180364 - REV A
PARTS LIST
1 700-0734-00 PLATFORM SUPPORT BRACKET 1
2 700-0807-001 Plate, Clamping 1
3 840-0048-00 SCREW M6S M12X45 8.8 ZP PT (USE 840.0048-00) 2
4 840-0050-00 SCREW M6S 12x55 8,8 ISO 4017 (USE 840.0050-00) 4
6 847-0147-00 WASHER BRB 13,5x24 HB200 ISO 7089 (USE 847.0147-00) 12
Platform
700-8132-901 - REV 2
6
1 12
12
11
8
8
9
4
7 3
13 7 10 13
11 12 8 12
Platform
700-8132-901 - REV 2
PARTS LIST
1 700-8131-901 Rail 1
2 700-8135-901 Bottom 1
3 700-8147-901 Rail 1
4 700-8148-901 Gate 1
5 700-8273-901 Gable 1
6 703-1076-001 ANTI-SLIP TAPE 3
7 840-0047-00 SCREW M6S M12X40 8.8 ZP (USE 840.0047-00) 2
8 840-0080-00 SCREW M6S 20X80 8.8(USE 840.0080-00) 4
12 847-0132-00 WASHER ROUND 21X36 ZP 12
Support Assembly
BG01180374 - REV A
2 6
5 3
4 6
Support Assembly
BG01180374 - REV A
PARTS LIST
1 700-8182-001 Plate 1
2 840-0049-00 SCREW M6S M12x50 8.8ZP ISO4014 (USE 840.0049-00) 4
3 840-0650-00 SCREW M6S 20x65 8.8 ISO 4017 (USE 840.0650-00) 2
5 847-0132-00 WASHER ROUND 21X36 ZP 2
Ladder Assy
BG01180511 - REV A
3
5 7 6 7
6 2
7
Ladder Assy
BG01180511 - REV A
PARTS LIST
1 700-8742-901 Ladder Handrail 2
2 700-8799-001 Support, Plate 1
3 700-8800-901 Ladder 1
4 840-0046-00 SCREW M6S M12x35 8.8 ZP (USE 840.0046-00) 2
5 840-0047-00 SCREW M6S M12X40 8.8 ZP (USE 840.0047-00) 12
ASSEMBLY OF CRUSHER STATION
700-8708-901 - REV 5
4
ASSEMBLY OF CRUSHER STATION
700-8708-901 - REV 5
PARTS LIST
1 700-0366-00 Hopper, Feed 1
2 700-1163-901 ASSEMBLY OF CRUSHER 1
3 703-0913-901 ASSEMBLY OF CRUSHER PLATFORM 1
4 BG01174606 Ladder, Assy 1
Support Assembly
BG01174621 - REV A
9 7
5
3 8 10 9
4 10
9
2
7
Support Assembly
BG01174621 - REV A
PARTS LIST
1 700-0734-00 PLATFORM SUPPORT BRACKET 2
2 700-0807-001 Plate, Clamping 2
3 703-0998-001 Plate, Support 1
4 840-0015-00 SCREW M6S 6x35 8.8 (USE 840.0015-00) 4
6 840-0050-00 SCREW M6S 12x55 8,8 ISO 4017 (USE 840.0050-00) 8
ASSEMBLY OF CRUSHER PLATFORM
703-0913-901 - REV 0
11 10 8 11
3
9
8
8
8
9
5
9 6
10
9
11
10 11 7 11
9 9
9
9 11
7 7
7
7
4
ASSEMBLY OF CRUSHER PLATFORM
703-0913-901 - REV 0
PARTS LIST
1 700-9341-001 PLATFORM TREAD PLATE 1
2 703-0914-901 ASSEMBLY OF CRUSHER PLATFORM REAR PANEL 1
3 703-0917-901 ASSEMBLY OF CRUSHER PLATFORM GATE 1
4 703-0920-501 CRUSHER PLATFORM BASE FABRICATION 1
5 703-0923-501 CRUSHER PLATFORM HANDRAIL FABRICATION - R.H. 1
6 703-0924-501 CRUSHER PLATFORM HANDRAIL FABRICATION - FRONT 1
8 840-0046-00 SCREW M6S M12x35 8.8 ZP (USE 840.0046-00) 6
Ladder, Assy
BG01174606 - REV A
4
6
10 10 3
10 8 8 10 9
7
7 10
9 10
9 10
7 10
10 7 10 9
10
7
2
1
Ladder, Assy
BG01174606 - REV A
PARTS LIST
1 700-8744-901 PLATFORM LADDER 1
2 700-8768-001 Plate, Support, Ladder 1
3 703-0925-501 CRUSHER FRONT PLATFORM BASE FABRIC 1
4 703-0926-501 CRUSHER FRONT PLATFORM HANDRAIL FABRICATION 1
5 703-0927-501 CRUSHER PLATFORM LADDER HANDRAIL FABRICATION 2
6 703-1064-001 ANTI-SLIP TAPE 3
7 840-0047-00 SCREW M6S M12X40 8.8 ZP (USE 840.0047-00) 18
8 840-0622-00 SCREW M6S 12x20 8.8 FZB (USE 840.0622-00) 2
ASSY OF V-BELT COVERS
700-1213-901 - REV 9
21
2
6
21
9
5
7
20 14 18 12
4 POS( 2 EACH GUARD)
18 12
2 POS(1 EACH GUARD)
4 POS(2 EACH GUARD) 15 17 10 17
11 18 16 POS
4 POS
19
18 POS
17
16
10
19
17
13
15
ASSY OF V-BELT COVERS
700-1213-901 - REV 9
PARTS LIST
1 63-0027-00 Assy of V-Belt Guard 1
2 453-4054-00 Flywheel cover 1
3 453-4059-00 MOUNTING BRACKET - NON DRIVE. 1
4 453-4059-90 MOUNTING BRACKET - DRIVE 1
5 453-4069-001 Rubber Element 4
6 703-0815-501 DRIVE GUARD INNER COVER FABRICATION - UPPER 1
7 703-0816-501 DRIVE GUARD INNER COVER FABRICATION - LOWER 1
8 703-0817-501 NON DRIVE GUARD INNER COVER FABRICATION - UPPER 1
9 703-0818-501 NON DRIVE GUARD INNER COVER FABRICATION - LOWER. 1
10 840-0023-00 SCREW M6S M8X25 8.8 ZP (USE 840.0023-00) 34
18 847-0059-00 WASHER TBRSB 13,5X36(USE 847.0059-00) 10
19 847-0060-00 WASHER TBRSB 17x42 1370(USE 847.0060-00) 16
21 864-0131-00 RUBBER COMPRESSION MOUNTING 2
Hydraulic & fuel tank, Assy
700-3180-901 - REV 5
15 11
7 19
8 15
15 11 20
21
15 8
21
6 14 20
4
1
3 17
5 14
13 9
10 16
18
12 13
Hydraulic & fuel tank, Assy
700-3180-901 - REV 5
PARTS LIST
1 700-0329-00 DIESEL PUMP ASSY 1
2 700-1459-901 Fuel tank, assy 1
3 700-2990-901 TIR III Hydraulic fluid tank assembly 1
4 700-3284-001 Plate 2
5 840-0032-00 SCREW M6S M10x16 8.8 ZP ISO 4017 (USE 840.0032-00) 4
6 840-0036-00 SCREW M6S 10X30 8.8 ISO 4017 (USE 840.0036-00) 4
8 840-0046-00 SCREW M6S M12X35 8.8 ZP (USE 840.0046-00) 8
9 840-0068-00 SCREW M6S M16x50 8.8 ZP (USE 840.0068-00) 8
10 840-0077-00 SCREW M6S M20X50 8.8 ZP (USE 840.0077-00) 4
16 847-0402-00 WASHER 21X44X8 ZP DIN7349 4
17 864-0129-00 Cushyfloat 17-1600-65 2
18 864-0130-00 CUSHYFLOAT 17-1657-65 4
19 900-2201-00 Flange half SAE 3000 2" 2
20 BG01180112 Plate 4
21 BG01180114 Plate 4
22 HHK0133 DIESEL & HYDRAULIC HOSE KIT - ALL 440i 1
TIR III Hydraulic fluid tank assembly
700-2990-901 - REV 8
15 10 18 17
5 7
6
1
14
3
2
16
19
22
23
21
25 13
24
12 20
20
11
TIR III Hydraulic fluid tank assembly
700-2990-901 - REV 8
PARTS LIST
1 700-1243-901 Cover 1
2 700-1248-001 Gasket, Rubber 1
3 700-3020-901 HYDRAULIC TANK BODY 1
4 840-0023-00 SCREW M6S M8X25 8.8 ZP (USE 840.0023-00) 24
5 840-0036-00 SCREW M6S 10X30 8.8 ISO 4017 (USE 840.0036-00) 4
8 849-0313-00 Blind rivet nut, M8HX 6001 24
9 873-0384-00 Seal, Bonded, G 1/2 1
10 873-0385-00 BONDED SEAL - G 1/2 1
11 900-2302-00 PLUG - VSTI - G 1/2-ED. 1
12 900-2351-00 Adapter LOO 1969 1
13 900-2435-00 Adapter WOG 1912 1
14 900-2508-00 Clamp, Hose 1
15 900-2684-00 Adapter G1"-G3/4" 1
16 904-0527-00 Hose 602-40 (2 1/2") 1
17 912-0209-00 Filter FIOTF 800/02 1
18 912-0235-00 Tank breather filter 1
19 923-0504-00 Temperatur sensor, MBT 3560-0000-0070-62-42 1
20 923-0505-00 Oil level gauge FSK254 2.4/0/12 2
21 HA1000002 1" X 1" M/F SWIVEL ADAPTOR 1
22 HA1000033 1" BSP MALE/MALE ADAPTOR 1
23 HADW10000 BONDED SEAL - G 1" 2
24 HAP100001 G 1" HEX PLUG 1
25 HV8007 1" BSP LOW PRESSURE BALL VALVE 1
Fuel tank, assy
700-1459-901 - REV 5
10 7
27 16
4
22
25 28 11 8 9
3
16
12
26
21
21
14
13 23
17
17 23
24
13
18
19
15
13
18 14
13
24
20
Fuel tank, assy
700-1459-901 - REV 5
PARTS LIST
1 10-22-4010 TANK CAP 1
2 10-22-4012 TANK SIEVE 1
3 700-1248-001 Gasket, Rubber 1
4 700-1380-901 DIESEL TANK FABRICATION 1
5 703-0165-501 Diesel Tank Lid 1
6 819-0332-00 HOSE TRANSP PU/PVC D18,7/12,5 1
7 840-0023-00 SCREW M6S M8X25 8.8 ZP (USE 840.0023-00) 24
12 849-0313-00 Blind rivet nut, M8HX 6001 24
13 873-0384-00 Seal, Bonded, G 1/2 4
14 900-0020-00 Elbow A4/90 Elbow A4/90 1/2" A4 SMS 435 2
15 900-0654-00 Adapter G 1/2 BxG 1/2 B 1
16 900-1355-00 Hose clips 11-17 2
17 900-1356-00 Hose clip 20 SMS 2298 2
18 900-1510-00 ADAPTOR - G 1/2 B x G 1/2. 2
19 900-1694-00 Nipple G 1/2" KR 1/2" 1
20 900-2302-00 PLUG - VSTI - G 1/2-ED. 1
22 900-2356-00 ADAPTOR - SOG 2316. 1
23 900-2695-00 Adapter G1/2"-1/2" 2
24 902-0871-00 Tap G 1/2" 2
25 906-0512-00 Sensor, Level 1
26 984-1049-00 Level Indicator S2-1200 1
27 EN10047 VOLVO TAD1442VE & TAD1462VE ENGINE DIESEL TANK BREATHER 1
28 HH70007 1/4" ID 6MM WP 20BAR MULTIOIL FUEL HOSE L=170MM 1
UJ440I SIDE PODS ASSEMBLY
703-0507-901 - REV 2
23 15
9
16 23
8
16 23
17 23
22 13
7
19
22 19 17 23
22
5
16
21
13 22
17 21
23 16
10
22 13
19 22
13 22
4 23 17
14
22
19 22
1
16
21 12 20
23 16
1 2
17
6
20 18
21
22 14
22 19
14 22
14 22 19 22
11 3 17 23
22 19
UJ440I SIDE PODS ASSEMBLY
703-0507-901 - REV 2
PARTS LIST
1 700-2022-901 Console 2
2 700-2084-901 Console 1
3 700-2114-901 Right Rear Pod 1
4 700-9786-901 REAR SIDE POD FABRICATION - L.H. 1
5 700-9789-901 SIDE POD SUPPORT 1
6 703-0462-501 RIGHT FRONT POD WITH RIBS 1
7 703-0484-002 REAR DEF TANK SUPPORT PLATE 1
8 703-0484-003 FRONT DEF TANK SUPPORT PLATE 1
9 703-0488-901 UREA TANK MOUNTING ASSY - VOLVO STAGE 4 1
10 703-0514-901 FRONT LEFT SIDE POD ASSEMBLY 1
11 703-0547-501 RIGHT REAR SUPPORT BRACKET 1
12 840-0023-00 SCREW M6S M8X25 8.8 ZP (USE 840.0023-00) 2
13 840-0035-00 SCREW M6S 10X25 8.8 ISO 4017 (USE 840.0035-00) 13
14 840-0037-00 SCREW M6S 10X35 8.8 (USE 840.0015-00) 11
16 840-0047-00 SCREW M6S M12X40 8.8 ZP (USE 840.0047-00) 17
FRONT LEFT SIDE POD ASSEMBLY
703-0514-901 REV - 3
6 9 18
9 18
25 16
26
7 5 18 9
12
9 4
18
20
22
18
21
16 15
2
14 19
17 13 18
22
1
10
3
19 14
11
23
8 19 24

272
FRONT LEFT SIDE POD ASSEMBLY
703-0514-901 REV - 3
PARTS LIST
1 700-5836-001 Mounting clamp 2
2 700-5962-001 TOOLBOX LOCKING PLATE 1
3 700-9784-901 SIDE POD DOOR FABRICATION 1
4 703-0506-901 LEFT FRONT SIDE POD FABRICATION 1
5 703-0509-001 ACCESS PANEL OVER DEF TANK 1
6 703-0513-501 FRONT SIDE POD DOOR GUARD 1
7 703-0516-501 FRONT LEFT POD ACCESS FABRICATION 1
8 840.0011-00 SCREW M6S 6x20 8.8 6
9 840.0035-00 SCREW M6S 10X25 8.8 9
10 843.0008-00 SLOTT CHEESE HEAD SCREW MCS 4x16 GR 5.8 2
11 843.0022-00 Slotted Cheese head screws MCS 6x16 5.8 4
12 845.0006-00 NUT M6M M10 8 FZB 1
13 845.0205-00 LOCK NUT M8 8 FZB 2
14 845.0217-00 NUT LOCK ISO 7040 M6 8 FZB 10
15 845.0229-00 LOCK NUT M4 8 FZB 2
16 847.0009-00 WASHER BRB 4,3x9 HB200 4
17 847.0012-00 WASHER BRB 8,4X16 HB200 2
18 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 14
19 847.0164-00 WASHER BRB 6,4X12 HB200 16
20 853-0175-00 CLEVIS PIN 10x25 SMS 2373 2
21 853-0176-00 CLEVIS PIN 10x30 SMS 2373 2
22 853-0239-00 SPLIT PIN 3,2X20 SMS 66 4
23 881-0205-00 DOOR LOCK / HANDLE, EIGENBRODT 120632 1
24 899-0480-00 GAS SPRING 150N 2
25 FAS04X16 SCREW M4x16 GR 8.8 ISO 4017. 2
26 FD2007 HANDLE PLASTIC D 1

273
Toolbox assembly
700-0866-901 - REV 2
18 16
15
12
14
8
9
13
4
6
3
11
10
2
17
5 13
9 13
7
Toolbox assembly
700-0866-901 - REV 2
PARTS LIST
1 700-0854-901 TOOLBOX BODY FABRICATION. 1
4 700-5991-901 TOOLBOX DOOR FABRICATION. 1
5 840-0010-00 Screw, Hexagon Head, Full Thread 6
6 843-0007-00 Slotted Cheese head screws MCS 4x12 5.8 2
10 845-0229-00 LOCK NUT M4 8 FZB ISO 7040 2
11 847-0010-00 WASHER BRB 5,3x10(USE 847.0010-00) 2
14 853-0231 Split cotter SP 2,5x20 SMS66 2
15 853-0996 Bolt HCB 10x30 SMS 2360 2
16 881-0112-00 TIGHTENER L 280 2
18 899-0480-00 GAS SPRING 150N 2
Hydraulic box, RH side, assembly
700-0844-901 - REV 7
12
18
17
22
21 24
18
13
11
3
10
18 9
23
5
16 2
2 20 17 8
15
14 19 19 7 6 19
14
Hydraulic box, RH side, assembly
700-0844-901 - REV 7
PARTS LIST
1 700-0810-901 Hydaulic box 1
2 700-1691-901 Bracket 2
3 700-4052-001 Bracket 1
6 700-5996-901 Door 2
7 840-0010-00 Screw, Hexagon Head, Full Thread 12
8 840-0020-00 SCREW M6S M8X16 8.8 ZP 8
9 840-0613-00 SCREW M6S 10x55 8.8 ISO 4014 2
10 843-0008-00 SLOTTED CHEESE HEAD SCREW MCS 4x16 GR 5.8 ISO 1207. 4
15 845-0229-00 LOCK NUT M4 8 FZB ISO 7040 4
16 847-0010-00 WASHER BRB 5,3x10(USE 847.0010-00) 4
21 853-0231 Split cotter SP 2,5x20 SMS66 4
22 853-0996 Bolt HCB 10x30 SMS 2360 4
24 899-0480-00 GAS SPRING 150N 4
ASSEMBLY OF L.H. ACCESS PLATFORM - R.H. HINGE
703-0180-901 - REV 0
7 8
8 6
5 8
8 7
1
ASSEMBLY OF L.H. ACCESS PLATFORM - R.H. HINGE
703-0180-901 - REV 0
PARTS LIST
1 703-0094-501 ACCESS PLATFORM FAB L.H. 1
2 703-0181-901 ASSEMBLY OF HANDRAIL & SELF CLOSING GATE - R.H. HINGE. 1
3 703-0184-501 ACCESS PLATFORM HANDRAIL - L.H. 1
4 703-1063-001 ANTI-SLIP TAPE 3
5 840-0046-00 SCREW M6S M12x35 8.8 ZP (USE 840.0046-00) 8
6 840-0047-00 SCREW M6S M12X40 8.8 ZP (USE 840.0047-00) 4
Centre Platform Assy
BG01224772 - REV A
6 5
Centre Platform Assy
BG01224772 - REV A
PARTS LIST
1 700-1185-001 CENTRE PLATFORM 1
2 703-1064-001 ANTI-SLIP TAPE 4
3 703-1077-001 ANTI-SLIP TAPE 2
4 840-0049-00 SCREW M6S M12x50 8.8ZP ISO4014 (USE 840.0049-00) 8
FOLDING PLATFORM ASSEMBLY
703-0821-901 - REV 1
11
23
19
13 23
23 13
17 23 5
13 23
1
23 19
23 16
21
19 23
14 23 15
18 22 18 22 12 3 21
20
13 23
4
2
10
17
14 23
19 23
24 23
6 19
23 14 17
7
23
23 19
FOLDING PLATFORM ASSEMBLY
703-0821-901 - REV 1
PARTS LIST
1 703-0822-501 FOLDING PLATFORM FABRICATION 1
2 703-0825-501 PLATFORM EXTENSION 1
3 703-0826-501 LOWER SUPPORT BRACKET 1
4 703-0827-501 LOWER SUPPORT STRUT 1
5 703-0831-501 UPPER SUPPORT STRUT 1
6 703-0832-901 LINK ASSEMBLY 1
7 703-0835-501 LADDER SUPPORT 1
8 703-0836-901 HANDRAIL ASSEMBLY LH 1
9 703-0837-901 HANDRAIL ASSEMBLY RH 1
10 703-1060-001 ANTI-SLIP TAPE 3
11 703-1061-001 ANTI-SLIP TAPE 3
12 840-0038-00 SCREW M6S 10x40 8.8 FZB (USE 840.0038-00) 1
13 840-0046-00 SCREW M6S M12x35 8.8 ZP (USE 840.0046-00) 10
14 840-0055-00 SCREW M6S 12X90 8.8 (USE 840.0055-00) 4
15 840-0068-00 SCREW M6S M16x50 8.8 ZP (USE 840.0068-00) 4
16 840-0625-00 SCREW M6S 12x130 8.8(USE 840.0625-00) 1
17 840-0627-00 SCREW M6S M12X150 8.8 (USE 84.0627-00) 3
18 845-0006-00 NUT M6M M10 8 ZP ISO4032 (USE 845.0006-00) 2
24 PN1291 DIA 16 TOW PIN 1
ASSEMBLY OF UJ440i POWERPACK PLATFORM.
700-8572-901 - REV 4
10 6
3
4
7 11
7 11
8
11
7 9
9
8
11 11 8 11 7
7
700-8572-901 - REV 4
PARTS LIST
1 700-9683-901 ENGINE PLATFORM LADDER 1
2 700-9723-901 ASSEMBLY OF ENGINE GRAB RAIL / SAFETY GATE. 1
3 700-9746-901 ENGINE PLATFORM FABRICATION 1
4 703-0805-501 ENGINE HANDRAIL - R.H. 1
5 703-1062-001 ANTI-SLIP TAPE 3
6 840-0044-00 SCREW M6S 12x25 8.8 FZB (USE 840.0044-00) 6
7 840-0046-00 SCREW M6S M12x35 8.8 ZP (USE 840.0046-00) 12
Feed Station, Classic Arrangment
700-3058-901 - REV 5
9
8
13
30 25
2
29 24
30 25
2
10
32
31
10
26 20
17 23 21
7 22
5
14
33
21 23 17 34
11
15
27 16
28 28
18 21
12
4
27 19
Feed Station, Classic Arrangment
700-3058-901 - REV 5
PARTS LIST
1 10-26-0060 20MM DOUBLE HOSE CLAMP 16
2 66-0212-01 Pivot Pin 4
3 700-0290-00 Spring Guide 4
4 700-2143-901 ASSEMBLY OF CHUTE 1
5 700-3225-901 FEED HOPPER UJ440 1
6 700-3226-901 FEEDER FRAME UJ440I 1
7 700-3266-001 Spacer 4
8 700-3302-901 HOPPER FOLDING SIDE FABRICATION - R.H. 1
9 700-3341-901 HOPPER FOLDING SIDE FAB. LH 1
10 700-3472-901 Hydraulic Locking Device 2
11 700-3484-901 Connection block AS 1
12 700-3485-901 Connection Block AS 1
13 700-4201-901 Cover Assy. 2
14 720-0595-901 Spring Kit L=290 16
15 720-0596-901 Spring Kit Assy. L=230 4
16 840-0031-00 SCREW M6S 8X70 8.8 ISO 4014 FZB (USE 840.0031-00) 2
17 840-0078-00 SCREW M6S 20x60 8.8 ISO 4014 (USE 840.0078-00) 32
18 840-0079-00 SCREW M6S 20X70 8.8 ISO 4017 (USE 840.0079-00) 24
19 840-0608-00 SCREW M6S M8x130 GR 8.8 ISO 4014. 2
20 841-0268-00 SCREW CAP HD MC6S 12x35 12.9 12
23 847-0017-00 WASHER BRB 20X36 HB200 ISO 7089 (USE 847.0017-00) 64
25 847-0125-00 WASHER BRFB 31X58 ZP 8
26 847-0258-00 WASHER NL M12 (USE 847.0258-00) 12
27 847-0286-00 WASHER NL-M8 (USE 847.0286-00) 4
29 853-0268-00 SPLIT PIN 8X40 SMS 66 4
30 853-0608-00 Spiral Pin Prym N 10X55 8
31 900-2353-00 Adaptor SOG 1106 G3/8B. 8
32 908-0456-00 Hydraulic Cylinder D50/3x400 4
33 BG01153398 SW1252/3H:3 Feeder (Classic) - Assembly 1
34 BG01154747 SS1012C Screen Assembly (Classic) 1
35 HHK0075 UJ440I HOSE KIT - CLASSIC SCREEN (CHASSIS) 1
36 HHK0076 UJ440I HOSE KIT - CLASSIC FEEDER 1
Hydraulic Locking Device
700-3472-901 - REV 1
10
8 7 9
700-3472-901 - REV 1
PARTS LIST
1 453-4029-90 Hydrualic Locking Device 1
2 700-1251-001 Locking Pin 1
3 700-1252-001 Sleeve 1
4 841-0294-00 SCREW MC6S M16X90 8.8 FZB 1
7 847-0132-00 WASHER ROUND 21X36 ZP 1
8 853-0260-00 Pin, Split, 6.3x32 SMS 66 1
9 900-2353-00 Adaptor SOG 1106 G3/8B. 2
10 908-0457-00 Hydraulic Cylinder 1
Connection Block AS
700-3485-901 - REV 2
5 1 6
9 7 2 3 2
10 5
5
8 3
2
4
6
Connection Block AS
700-3485-901 - REV 2
PARTS LIST
1 700-0048-00 Terminalblock 1
2 873-0383-00 Sealing Ring Tredo 16 4
3 900-0653-00 Straight adapter G3/8 BxG 3/8 B 2
4 900-2045-00 Swivel elbow adapter G 3/8 2
5 900-2353-00 Adaptor SOG 1106 G3/8B. 12
6 900-2460-00 Adapter WOG 1106 2
7 900-2463-00 Quick coupling 3/8" male 1
9 900-2465-00 Dust cap 3/8" female 1
10 900-2466-00 Dust cap 3/8" Male 1
ASSEMBLY OF CHUTE
700-2143-901 - REV 6
20 17 16 20 22
3 5 13
13
4
14
12
18 19 21
19 21 15
18 21 19
11
7 9 10 1
ASSEMBLY OF CHUTE
700-2143-901 - REV 6
PARTS LIST
1 453-7158-00 RUBBER CLOTH 1
3 700-0381-1 WEAR PLATE 1
4 700-0381-2 WEAR PLATE 1
5 700-0381-3 WEAR PLATE 1
6 700-0381-4 WEAR PLATE 1
7 700-0584-00 COVER 1
8 700-0584-90 COVER 1
9 700-1870-001 CLAMP 1
10 700-1871-001 CLAMP 2
11 700-2144-901 SIDE FABRICATION - R.H. 1
12 700-2149-901 SIDE FABRICATION - L.H. 1
13 700-2166-001 RUBBER CLOTH 2
14 700-3626-001 CLAMPING BAR 2
16 841-0433-00 SCREW MF6S M10X30 8.8 12
17 841-0436-00 SCREW MF6S 10x45 10.9(USE841.0436-00) 10
18 841-0451-00 SCREW MF6S 12x40 10.9 (USE 841.0451-00) 8
Cover Assy.
700-4201-901 - REV 1
1
3
4
Cover Assy.
700-4201-901 - REV 1
PARTS LIST
2 700-0005-00 Cover 1
3 700-3452-001 Clamping rod 8x1700 1
4 840-0038-00 SCREW M6S 10x40 8.8 FZB (USE 840.0038-00) 9
7 847-0058-00 WASHER TBRSB 10X28 1370 2
8 881-0112-00 TIGHTENER L 280 2
SS1012C Screen Assembly (Classic)
BG01154747 - REV A
5 7 2 1
15
10 12 11 13
14
3 9
8 6
SS1012C Screen Assembly (Classic)
BG01154747 - REV A
PARTS LIST
1 700-4232-901 Connection block, Assembly 1
2 840-0603-00 SCREW M6S 8x80 8.8 (840.0603-00) 2
3 841-0253-00 SCREW MC6S 10x35 8.8(USE 841.0253-00) 16
4 845-0012-00 NUT M6M M24 8 ZP 4
10 900-1807-00 Split Flange SAE 6000 3/4" 8
11 900-2412-00 ADAPTER SOM 1622 - M22x1,5 2
12 900-2525-00 ADAPTER LOO 1666 1
13 BG00358970 Vibrator Unit, Hydraulic 2 S&F Ref. BG00287326
14 BG00740718_BG THREADED BAR PSH M24X310 4 Refer to BG00740717
15 SS1012C-OS SS1012C Screen 1 S&F Ref. 720.0466-901
Connection block, Assembly
700-4232-901 - REV 2
4
5
4 3
1 2 5
Connection block, Assembly
700-4232-901 - REV 2
PARTS LIST
1 65-0001-00 Connection block 1
2 900-2279-00 Plug VSTi R1/4" 2
3 900-2344-00 Adapter WOO 1969 2
4 900-2355-00 Adapter SOG 1912 3
5 900-2435-00 Adapter WOG 1912 3
SW1252/3H:3 Feeder (Classic) - Assembly
BG01153398 - REV A
10
5 3
2
7 1 4
7 8 6 1 4
SW1252/3H:3 Feeder (Classic) - Assembly
BG01153398 - REV A
PARTS LIST
1 841-0253-00 SCREW MC6S 10x35 8.8(USE 841.0253-00) 16
2 843-1564-00 THREADED BAR PSH M30X500 8.8 12
5 847-0340-00 WASHER BRB 31X56 ZP (USE 847.0340-00) 24
6 900-1807-00 Split Flange SAE 6000 3/4" 8
7 900-2412-00 ADAPTER SOM 1622 - M22x1,5 2
8 900-2525-00 ADAPTER LOO 1666 1
9 BG00287328-BG OMB Hydraulic Vibrator SK-HD 12000/10 2 Refer to BG00287328
10 SW1252-3H-3-OS SW1252/3H:3 - Feeder (Classic) 1 S&F Ref. BG00395292
Feed Station, Comfort Arrangement
700-3059-901 - REV 5
9
8
13
27 23
2
27 23
2
26 22
29
28
10
10
5
24 18
7 16 21 19
20
30
14
19 21 16
25 15 11
3
12
25 17
Feed Station, Comfort Arrangement
700-3059-901 - REV 5
PARTS LIST
1 10-26-0060 20MM DOUBLE HOSE CLAMP 16
2 66-0212-01 Pivot Pin 4
3 453-4025-901 Feeder (Comfort) Chute Assembly 1
4 700-0290-00 Spring Guide 4
5 700-3225-901 FEED HOPPER UJ440 1
6 700-3226-901 FEEDER FRAME UJ440I 1
7 700-3266-001 Spacer 4
8 700-3302-901 HOPPER FOLDING SIDE FABRICATION - R.H. 1
9 700-3341-901 HOPPER FOLDING SIDE FAB. LH 1
10 700-3472-901 Hydraulic Locking Device 2
11 700-3484-901 Connection block AS 1
12 700-3485-901 Connection Block AS 1
13 700-4201-901 Cover Assy. 2
14 720-0595-901 Spring Kit L=290 16
15 840-0031-00 SCREW M6S 8X70 8.8 ISO 4014 FZB (USE 840.0031-00) 2
16 840-0078-00 SCREW M6S 20x60 8.8 ISO 4014 (USE 840.0078-00) 32
17 840-0608-00 SCREW M6S M8x130 GR 8.8 ISO 4014. 2
18 841-0268-00 SCREW CAP HD MC6S 12x35 12.9 12
21 847-0017-00 WASHER BRB 20X36 HB200 ISO 7089 (USE 847.0017-00) 72
23 847-0125-00 WASHER BRFB 31X58 ZP 8
24 847-0258-00 WASHER NL M12 (USE 847.0258-00) 12
25 847-0286-00 WASHER NL-M8 (USE 847.0286-00) 4
26 853-0268-00 SPLIT PIN 8X40 SMS 66 4
27 853-0608-00 Spiral Pin Prym N 10X55 8
28 900-2353-00 Adaptor SOG 1106 G3/8B. 8
29 908-0456-00 Hydraulic Cylinder D50/3x400 4
30 BG01155298 SW1253/3H:4 Feeder (Comfort) - Assembly 1
31 HHK0077 UJ440I HOSE KIT - COMFORT FEEDER 1
700-3472-901 - REV 1
10
8 7 9
700-3472-901 - REV 1
PARTS LIST
1 453-4029-90 Hydrualic Locking Device 1
2 700-1251-001 Locking Pin 1
3 700-1252-001 Sleeve 1
4 841-0294-00 SCREW MC6S M16X90 8.8 FZB 1
7 847-0132-00 WASHER ROUND 21X36 ZP 1
8 853-0260-00 Pin, Split, 6.3x32 SMS 66 1
9 900-2353-00 Adaptor SOG 1106 G3/8B. 2
10 908-0457-00 Hydraulic Cylinder 1
Connection block AS
700-3484-901 - REV 4
12
902.0945-00 Relief Valve
Supplied with Valve block
2
12 3
2
11
4
9
11
10
4
8 7
Connection block AS
700-3484-901 - REV 4
PARTS LIST
1 65-0019-00 CONNECTION BLOCK (USE 65.0019-00) 1
2 873-0385-00 BONDED SEAL - G 1/2 8
3 900-0655-00 Adapter 3/4" 4
4 900-0964-00 Swivel elbow adapter 3/4" 2
7 900-2329-00 Dust cap 3/4" Female 1
8 900-2330-00 Dust cap 3/4" Male 1
9 900-2355-00 Adapter SOG 1912 2
10 900-2438-00 TEST POINT (USE 900.2438-00) 1
11 900-2630-00 Adapter SOG 1912 Str. 4.2 2
12 902-0981-00 0.5 BAR 3/4" CHECK VALVE RESTRICTED TO 0.8MM (USE 902.0981-00) 2
Feeder (Comfort) Chute Assembly
453-4025-901 - REV 11
17 20 16 16 20 17
11
6
10
2
9
3
16 17 20
17 20 16
5
7
4
1 17 20 16
8
17 20 14 14 20 17
15 19 18
12
13
Feeder (Comfort) Chute Assembly
453-4025-901 - REV 11
PARTS LIST
1 700-1303-901 Chute 1
2 700-1330-01 Wear Plate 1
3 700-1330-02 Wear Plate 1
4 700-1330-03 Wear Plate 1
5 700-1330-04 Wear Plate 1
6 700-1330-05 Wear Plate 1
7 700-1330-06 Wear Plate 1
8 700-1330-07 Wear Plate 1
9 700-1330-08 Wear Plate 1
10 700-1330-09 Wear Plate 1
11 700-1330-10 Wear Plate 1
12 700-1513-901 Chute Assembly 1
13 700-1515-901 Chute, Assembly 1
14 840-0037-00 SCREW M6S 10X35 8.8 (USE 840.0015-00) 24
15 840-0071-00 SCREW M6S 16X65 8.8 ISO 4014 (USE 840.0071-00) 2
16 841-0433-00 SCREW MF6S M10X30 8.8 40
Chute Assembly
700-1513-901 - REV 3
3 12 16 14
13
4
13 6
1 16 10 7
10 16
14 5
15
14
1 15 11
2
1 1 14
Chute Assembly
700-1513-901 - REV 3
PARTS LIST
2 700-0073-00 Rubber Cloth 1
3 700-0381-11 Wear Plate 2
4 700-0381-12 Wear Plate 2
5 700-1514-901 Chute - Welding 1
6 700-1517-001 Plate 1
7 700-2556-001 Clamping rod Ø8 x 900 2
8 700-3789-001 Clamping rod Ø8 x 600 2
9 700-3790-001 Clamping rod Ø8 x 720 1
10 840-0040-00 SCREW M6S 10X50 8.8(USE 840.0040-00) 7
11 840-0041-00 SCREW M6S 10x60 GR 8.8 ISO 4014. 5
12 841-0433-00 SCREW MF6S M10X30 8.8 12
13 841-0437-00 Screw MF6S 10x50 - C,Sunk Head 11
Chute, Assembly
700-1515-901 - REV 2
5 9
9 11 7
11
5 2
8 10
1
Chute, Assembly
700-1515-901 - REV 2
PARTS LIST
1 453-7147-01 Rubber Cloth 1
3 700-1516-901 Chute. Welding 1
4 700-2556-001 Clamping rod Ø8 x 900 2
5 700-3535-001 Clamping rod Ø8 x 425 2
6 700-3902-001 Clamping rod Ø8 x 450 1
7 840-0040-00 SCREW M6S 10X50 8.8(USE 840.0040-00) 16
8 840-0041-00 SCREW M6S 10x60 GR 8.8 ISO 4014. 4
SW1253/3H:4 Feeder (Comfort) - Assembly
BG01155298 - REV A
10
5 3
2
7 1 4
7 8 6 1 4
SW1253/3H:4 Feeder (Comfort) - Assembly
BG01155298 - REV A
PARTS LIST
1 841-0253-00 SCREW MC6S 10x35 8.8(USE 841.0253-00) 16
2 843-1564-00 THREADED BAR PSH M30X500 8.8 12
6 900-1807-00 Split Flange SAE 6000 3/4" 8
7 900-2412-00 ADAPTER SOM 1622 - M22x1,5 2
8 900-2525-00 ADAPTER LOO 1666 1
9 BG00287328-BG OMB Hydraulic Vibrator SK-HD 12000/10 2 Refer to BG00287328
10 SW1253-3H-4-OS SW1253 Feeder (Comfort) 1 S&F Ref BG00395264
Conveyor Arrangement
700-6438-901 REV - 3.
9
1
5 4
B(0.150) B 7
17 12
14 17 18
19
22
18 13
15 18
A(0.060)
10 16
6
11
20
21
3

70
Conveyor Arrangement
700-6438-901 REV - 3.
PARTS LIST
1 650-5170-01 Pin, Linch Ø11x63 2
2 700-0266-901 Sensor Mounting 1
3 700-0471-01 Bracket 1
4 700-0898-901 Support Pin 2
5 700-0900-001 Washer 2
6 700-1026-001 Cover 1
7 700-5894-901 Cylinder, Hydraulic 2
8 700-6404-001 Chain 2
9 703-0329-901 Conveyor Assembly, Product 1
10 840.0020-00 SCREW M6S M8X16 8.8 ZP 2
11 840.0023-00 SCREW M6S M8X25 8.8 ZP 1
12 840.0048-00 SCREW M6S M12X45 8.8 ZP PT 20
13 840.0080-00 SCREW M6S 20X80 8.8 2
14 845.0030-00 LOCK NUT M12 8 FZB 20
15 845.0203-00 LOCK NUT M20 8 FZB 2
16 847.0012-00 WASHER BRB 8,4X16 HB200 2
17 847.0147-00 WASHER BRB 13,5x24 HB200 40
18 847.0359-00 WASHER BRB 21x37 HB200 6
19 853-0241-00 SPLIT PIN 3,2X32 2
20 964-2335-00 Nut for Mounting Rail M8 1
21 967-0181-00 INDUCT. TRANSMIT. XS630B4PAM12 1
22 FADL1015 DEE SHACKLE M12 WLL 3.2T 2

71
Conveyor Assembly, Product
703-0329-901 - REV A
FOR NON-MAGNET 24
10 OPTION
22
2
FOR MAGNET
8 OPTION
23 12
14
16 18
21
3 20 FOR NON-MAGNET
1 OPTION
8
19
10
15
13
5
10 8 3
17
11
A(0.040)

72
Conveyor Assembly, Product
703-0329-901 - REV A
PARTS LIST
1 700-1734-90 Speed, Conveyor 1
2 840.0037-00 SCREW M6S 10X35 8.8 4
3 840.0038-00 SCREW M6S 10x40 8.8 FZB 22
4 840.0048-00 SCREW M6S M12X45 8.8 ZP PT 8
5 840.0080-00 SCREW M6S 20X80 8.8 4
6 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 8
7 845.0203-00 LOCK NUT M20 8 FZB ISO 7040 4
8 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 26
9 847.0147-00 WASHER BRB 13,5x24 HB200 ISO 7089 16
10 847.0337-00 WASHER BRB 10,5x20 HV200 ZP ISO 7089 52
11 847.0359-00 WASHER BRB 21x37 HB200 ISO 7089 8
12 BG00267292 Belt, Conveyor 1
13 BG01113419 Conveyor Mid-Section Assembly 1 See Assy: BG01113419
14 BG01116664 Conveyor Head Section Assembly 1 See Assy: BG01116664
17 BG01146154 Conveyor Tail Section Assembly 1 See Assy: BG01146154
18 BG01157365 Cover Assembly 1 See Assy: BG01157365
19 BG01157380 Support, Conveyor 1
20 BG01157390 Plate 1
21 BG01157391 Plate 1
22 BG01158764 Rubber, Skirting 2
23 BG01158766 Rubber, Skirting 2

73
Conveyor Tail Section Assembly
BG01146154 - REV A
3 7 9 30 31 16 19 18
30 1
31 28
22
7 33
21
A(0.050)
13
29
17
A 24
19
20
5
25
4
27 23
3
2
15
12
10
11
32
26 14 8

74
BG01146154 - REV A
PARTS LIST
1 12-02-0016 LINCH PIN AND CHAIN 2
2 840.0051-00 SCREW M6S 12x60 8.8 ZP ISO 4014 14
3 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 123
5 891-0500-003 T-Bolt M12x50 78
6 891-0521-902 IMPACT_BAR_75X100X1520 13
7 BG00952044 Washer, Plain, Large 31
8 BG01130868 Scraper, Conveyor 1 See Assy: BG01130868
9 BG01145961 HEX SOCKET BUTTON HEAD SCREW M12X50 ISO7380 26
12 BG01146152 Roller Assembly 1 See Assy: BG01146152
13 BG01146153 Liner Kit 2 See Assy: BG01146153
16 BG01146171 Support Assembly 1 See Assy: BG01146171
18 BG01146179 Plate 2
21 BG01146189 Plate, Wear 2
22 BG01146191 Plate, Wear 2
23 BG01146192 Plate 12
24 BG01146202 Plate 1
25 BG01146205 Plate 2
26 BG01146209 Plate, Side 1
28 BG01146215 Rubber, Wear 1
32 BG01146219 Drum Assembly 1 See Assy: BG01146219
33 BG01146303 HEX SOCKET BUTTON HEAD SCREW M12X60 ISO7380 5

75
Roller Assembly
BG01146186 - REV A

76
Roller Assembly
BG01146186 - REV A
PARTS LIST
1 840.0019-00 Screw M6S 8x12 8.8 ISO4017 2
2 840.0046-00 SCREW M6S M12x35 8.8 ZP 8
3 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 8
4 847.0012-00 WASHER BRB 8,4X16 HB200 ISO 7089 2
6 BG00267264 Roller - TS89E-20B-1400 1
7 BG00267267 Roller - LA108E-20B-250 & Buffer Rings 2
8 BG01146193 Roller Bracket 1
9 BG01146199 Plate 2

77
Support Assembly
BG01146171 - REV A
1
6

78
Support Assembly
BG01146171 - REV A
PARTS LIST
1 840.0047-00 SCREW M6S M12X40 8.8 ZP 18
2 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 18
5 BG01146200 Plate 1
6 BG01146203 Section, Angle 4

79
Support Assembly
BG01146173 - REV A
1 2 3

80
Support Assembly
BG01146173 - REV A
PARTS LIST
1 840.0047-00 SCREW M6S M12X40 8.8 ZP 18
2 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 18
5 BG01146201 Plate 1

81
Drum Assembly
BG01146219 - REV A
3
4
5
1

82
Drum Assembly
BG01146219 - REV A
PARTS LIST
1 840.0058-00 SCREW M6S 12x120 8.8 4
2 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 4
4 BG00267290 Tail Drum - BTF50-250T-1460J 1 Ref:BT10106 Bearing Part
of Roller
5 BG01146175 Plate 2
6 BG01146176 Plate 4

83
Roller Assembly
BG01146152 - REV A
1 5 3
2 4 6

84
Roller Assembly
BG01146152 - REV A
PARTS LIST
1 840.0024-00 SCREW M6S 8x30 8.8 ISO4017 FZB 2
2 840.0066-00 SCREW M6S M16x40 8.8 FZB 8
3 845.0205-00 LOCK NUT M8 8 FZB ISO 7040 2
4 845.0215-00 LOCK NUT M16 8 FZB ISO 7040 8
7 BG00267266 Roller - TS159E-40B-1400* & BEARINGS 21308 1
8 BG01146177 Plate 2
9 BG01146178 Plate 2

85
Liner Kit
BG01146153 - REV A

86
Liner Kit
BG01146153 - REV A
PARTS LIST
1 840.0046-00 SCREW M6S M12x35 8.8 ZP 13
2 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 13
4 BG01146174 Liner, Wear 1

87
Support Assembly
BG01146183 - REV A
5
2
7
4

88
Support Assembly
BG01146183 - REV A
PARTS LIST
1 840.0026-00 SCREW M6S 8x40 8.8 FZB ISO 4014 1
2 840.0047-00 SCREW M6S M12X40 8.8 ZP 2
3 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 2
4 845.0205-00 LOCK NUT M8 8 FZB ISO 7040 1
7 BG01146182 Bracket, Linkage 1

89
Scraper, Conveyor
BG01130868 - REV A
13 8 7 3 6 1
5 4 2
10
1 6 3 12 9 11

90
Scraper, Conveyor
BG01130868 - REV A
PARTS LIST
1 840.0040-00 SCREW M6S 10X50 8.8 8
2 840.0639-00 SCREW M6S 16x140 ZP 1
3 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 8
4 845.0215-00 LOCK NUT M16 8 FZB ISO 7040 1
8 853-0255-00 SPLIT PIN SP 5X40 ZP 2
11 BG01130866 Scraper assy 1
12 BG01130870 Plate 2

91
Conveyor Mid-Section Assembly
BG01127932 - REV A
15
12
39 40 32
15 11
15 33
12 38
12 15
3 3
16 12
36 2
37 18
26
42
22
31
34
C
28
30
6
5 35
12
15 21
19
18 15
27
7
B A 4 12 20
25
12 15
43
15
29
15
12 15 1
3 15 C(0.034)
41
6
10 13 16
12
A(0.034)
23
15
24
14
9
17
B(0.034)

92
BG01127932 - REV A
PARTS LIST
1 840.0046-00 SCREW M6S M12x35 8.8 ZP 16
2 840.0047-00 SCREW M6S M12X40 8.8 ZP 19
3 840.0048-00 SCREW M6S M12X45 8.8 ZP PT 28
4 840.0049-00 SCREW M6S M12x50 8.8ZP ISO4014 19
5 840.0050-00 SCREW M6S 12x55 8,8 ISO 4017 12
6 840.0051-00 SCREW M6S 12x60 8.8 ZP ISO 4014 5
7 840.0053-00 SCREW M6S 12x70 8.8 2
8 840.0622-00 SCREW M6S 12x20 8.8 FZB 4
9 841.0206-00 SOCKET HEAD CAP SCREW M5x16 8
10 841.0433-00 SCREW MF6S M10X30 8.8 12
11 843.1517-00 SCREW, CSK SQ NECK, M12X35 20
12 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 120
13 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 12
14 847.0010-00 WASHER BRB 5,3x10 8
17 BG01113410 Plate 4
21 BG01127909 Plate 2
22 BG01127910 Plate 2
23 BG01127911 Plate 2
24 BG01127912 Plate 2
25 BG01127917 Plate, Support 1
27 BG01127920 Guide Roller 2 See Assy: BB01127920
28 BG01127926 Plate 1
29 BG01127927 Plate 1
32 BG01127945 Plate 2
33 BG01127946 Plate, Cover 1
36 BG01127954 Plate 1
37 BG01127955 Plate 1
38 BG01127956 Plate 1
39 BG01127957 Plate 1
40 BG01152724 Roller Assembly 4
41 BG01154440 BLIND CAPTIVE NUT-M5-FTT Zn 8

93
Roller Assembly
BG01152724 - REV A

94
Roller Assembly
BG01152724 - REV A
PARTS LIST
1 853-0581-00 Pin, Cotter, (d6x32) 4
2 BG00267275 Roller - NT3-108E-25-1400Z (315-750-315) MDN1-25-L 1
3 BG01113411 Pin 2

95
Roller Assembly
BG01155661 - REV A
1 6
3
1 6
10
4 5 7

96
Roller Assembly
BG01155661 - REV A
PARTS LIST
1 840.0020-00 SCREW M6S M8X16 8.8 ZP 4
2 840.0047-00 SCREW M6S M12X40 8.8 ZP 2
3 840.0048-00 SCREW M6S M12X45 8.8 ZP PT 10
4 840.0050-00 SCREW M6S 12x55 8,8 ISO 4017 2
5 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 14
8 BG00267269 Roller - LA108E-20B-315 & Buffer Rings 2
9 BG01127938 Roller Bracket 1
10 BG01129495 Plate 4

97
Roller Assembly
BG01162262 - REV A
2 4 6
1

98
Roller Assembly
BG01162262 - REV A
PARTS LIST
1 840.0023-00 SCREW M6S M8X25 8.8 ZP 2
2 840.0036-00 SCREW M6S 10X30 8.8 ISO 4017 4
3 845.0205-00 LOCK NUT M8 8 FZB ISO 7040 2
4 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 4
7 BG00267270 Roller - RB108E-25B-1430* (ZR12-7) & support rings 1
8 BG01113409 Plate 2
9 BG01113412 Plate 2

99
Cover Assembly
BG01157365 - REV A
12
5
B
8
10
11
1
1
4
4
5 5 6
5 4 1
5 4
A(0.050)
2 4 5
B(0.050)

100
Cover Assembly
BG01157365 - REV A
PARTS LIST
1 840.0036-00 SCREW M6S 10X30 8.8 ISO 4017 48
2 840.0037-00 SCREW M6S 10X35 8.8 4
3 840.0038-00 SCREW M6S 10x40 8.8 FZB 10
4 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 62
6 BG01157366 Cover, Dust 1
7 BG01157369 Cover, Dust 1
8 BG01157374 Rubber 1
9 BG01157375 Plate 2
10 BG01157376 Pipe Assembly 10
11 BG01157379 Plate 1

101
Cover Assembly
BG01160727 - REV A
5 2

102
Cover Assembly
BG01160727 - REV A
PARTS LIST
1 703-0858-501 DUST BOX SUPPORT FABRICATION 1
2 840.0024-00 SCREW M6S 8x30 8.8 ISO4017 FZB 12
3 840.0038-00 SCREW M6S 10x40 8.8 FZB 8
4 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 8
7 BG01160728 Plate 1

103
BG01113419 - REV A
35
10 10 10
14 14 14
33
4 9 3
28
23
32
30
36 24 25
11
37
16
31
7
22
27
17
5 21
26
14
34
10
20
18 29
1
8
6
15
13 19 14
2 10
12
15
12

104
BG01113419 - REV A
PARTS LIST
1 840.0038-00 SCREW M6S 10x40 8.8 FZB 22
2 840.0043-00 SCREW M6S M10X90 8.8 ZP 2
3 840.0047-00 SCREW M6S M12X40 8.8 ZP 2
4 840.0048-00 SCREW M6S M12X45 8.8 ZP PT 12
5 840.0049-00 SCREW M6S M12x50 8.8ZP ISO4014 14
6 840.0053-00 SCREW M6S 12x70 8.8 12
7 840.0079-00 SCREW M6S 20X70 8.8 ISO 4017 4
10 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 50
11 845.0203-00 LOCK NUT M20 8 FZB ISO 7040 4
12 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 24
13 847.0010-00 WASHER BRB 5,3x10 12
17 BG00267273 Roller, Guide 2
18 BG01113410 Plate 6
19 BG01113418 Plate 2
20 BG01113420 Plate 2
23 BG01113426 Plate 1
24 BG01113427 Plate 1
26 BG01113434 Plate 2
28 BG01113440 Plate 2
29 BG01113441 Plate 1
30 BG01113442 Plate 1
31 BG01113443 Plate 2
32 BG01113444 Plate 2
33 BG01113445 Plate 2
37 BG01154717 Support, Conveyor 2 See Assy: BG01154717

105
Roller Assembly
BG01115977 - REV A
11
3
2
9
7
10
12
1
2 7 5
6

106
Roller Assembly
BG01115977 - REV A
PARTS LIST
1 840.0023-00 SCREW M6S M8X25 8.8 ZP 2
2 840.0036-00 SCREW M6S 10X30 8.8 ISO 4017 7
3 840.0037-00 SCREW M6S 10X35 8.8 4
4 845.0205-00 LOCK NUT M8 8 FZB ISO 7040 2
5 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 11
8 BG00267270 Roller - RB108E-25B-1430* (ZR12-7) & support rings 1
9 BG01113409 Plate 2
10 BG01113412 Plate 2
11 BG01113413 Support, Adjustable 1
12 BG01113417 Plate 1

107
Support, Conveyor
BG01154717 - REV A

108
Support, Conveyor
BG01154717 - REV A
PARTS LIST
1 840.0047-00 SCREW M6S M12X40 8.8 ZP 14
2 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 14

109
BG01120034 - REV A
40 12 9 3 34 35
27
37
36
9 28 9
16
12 2 20
12 5
4
9
30
25 D
3
32
C 19
33 38
23
16
B 22 29
3
26 A
18
20
9
21
12
19 16 17 39 2 31
9 12
13 10 1
11 12 9 8
7
41
3
15
A(0.040) B(0.040) C(0.044)
14 9
12
13 10 6
24 D(0.044)

110
BG01120034 - REV A
PARTS LIST
1 840.0043-00 SCREW M6S M10X90 8.8 ZP 2
2 840.0047-00 SCREW M6S M12X40 8.8 ZP 22
3 840.0048-00 SCREW M6S M12X45 8.8 ZP PT 24
4 840.0049-00 SCREW M6S M12x50 8.8ZP ISO4014 2
5 840.0054-00 SCREW M6S M12X80 8.8 FZB ISO 4014 16
6 840.0615-00 SCREW M6S 10x100 8.8 ISO 4014 4
9 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 80
10 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 6
11 847.0010-00 WASHER BRB 5,3x10 12
14 BG01113410 Plate 6
15 BG01113418 Plate 2
16 BG01113420 Plate 4
17 BG01113434 Plate 2
19 BG01113439 Plate 2
20 BG01113443 Plate 2
26 BG01120035 Plate 1
27 BG01120036 Plate 1
32 BG01120053 Plate 1
33 BG01120054 Plate 1
34 BG01120055 Plate 1
35 BG01120056 Plate 1
36 BG01120057 Plate 2
37 BG01120058 Plate 2

111
Roller Assembly
BG01152632 - REV A
1 9 7

112
Roller Assembly
BG01152632 - REV A
PARTS LIST
1 840.0009-00 SCREW M6S M6X12 8.8 ZP 4
2 840.0047-00 SCREW M6S M12X40 8.8 ZP 13
3 840.0049-00 SCREW M6S M12x50 8.8ZP ISO4014 4
4 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 17
7 BG00267262 Roller - TS89E-20B-950 1
9 BG01120043 Plate 2

113
Guide Roller
BG01127920 - REV A
1
4
11
12
8
6
3
10

114
Guide Roller
BG01127920 - REV A
PARTS LIST
1 840.0020-00 SCREW M6S M8X16 8.8 ZP 6
2 840.0037-00 SCREW M6S 10X35 8.8 4
3 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 4
6 855-0010-00 RETAINING RING 25x1.2 DIN471 2
7 BG00273580 Bearing 6205-RS1 2
8 BG01127921 Plate 2
9 BG01127922 Roller, Guide 1
10 BG01127923 Shaft 1
11 BG01127924 Plate 2
12 BG01127925 Plate 2

115
Conveyor Head Section Assembly
BG01116664 - REV A
10
12
11
4 7

116
BG01116664 - REV A
PARTS LIST
1 840.0047-00 SCREW M6S M12X40 8.8 ZP 4
2 840.0068-00 SCREW M6S M16x50 8.8 ZP 4
3 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 4
4 845.0215-00 LOCK NUT M16 8 FZB ISO 7040 4
7 BG00267260 Scraper 1
8 BG00267271 Roller, Idler 1
9 BG01116683 Plate 2
10 BG01151848 Conveyor Head Section Assembly 1 See Assy: BG01151848
11 BG01151852 Conveyor Head Section LHS 1
12 BG01151854 Conveyor Head Section RHS 1

117
BG01151848 - REV B
8 1 16
6
11 Motor Adaptor Plate 10 17
- Supplied with Drum Assmbly 3
5 8 2 15
12
9 14
13

118
BG01151848 - REV B
PARTS LIST
2 840-0047-00 SCREW M6S M12X40 8.8 ZP (USE 840.0047-00) 10
4 845-0013-00 NUT M6M M30 8 FZB ISO 4032 (USE 845.0013-00) 8
10 BG00267259 Motor, Hydraulic 1
11 BG00267291 Head Drum: ZD30-320X-60-1500. Lagging 10 mm 60 ShA cross 1
12 BG00307424 Bearing UCT 212 1
13 BG01116665 Bar, Tension 2
14 BG01116668 Plate 1
15 BG01116669 Plate 1
16 BG01116682 Section, Bar 4
17 BG01116684 Plate 1
18 BG01724237 Plate, Mounting 1 Supplied with Drum Assy.

119
Conveyor Assembly, Natural
Fines 703-0645-901 - REV 1
1 4
5

120
Conveyor Assembly, Natural Fines
703.0645-901 - REV 1
PARTS LIST
1 BG00528781 Rubber 2
2 BG00528781 Rubber
3 BG00570353 Belt, Conveyor 1
4 BG00570370 ZG2-14 (right-hand switch XY2-CE1C 250) 1
5 BG01126042 Conveyor Tail Section Assembly 1 SEE ASSY: BG01126042
6 BG01129662 Conveyor Assembly, Mid Section 1 SEE ASSY: BG01129662
7 BG01130861 Conveyor Assembly, Mid Section 1 SEE ASSY: BG01130861
8 BG01143181 Conveyor Head Section Assembly 1 SEE ASSY: BG01143181

121
BG01126042 - REV A
15
14
10
17
20
11
19 16
5
7 1 2 3
13
12
18

122
BG01126042 - REV A
PARTS LIST
2 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 4
4 BG00570368 Rubber 1
5 BG01120100 Bracket, Mounting 2
8 BG01121678 Clamp Assembly 1 SEE ASSY: BG01121678
9 BG01121909 Plate 1
10 BG01122167 Plate 1
13 BG01122791 Scraper, Conveyor 1 SEE ASSY: BG01122791
14 BG01123158 Guard Assembly 1
15 BG01123347 Scraper, Conveyor 1 SEE ASSY: BG01123347
16 BG01124228 Drum Assembly 1 SEE ASSY: BG01124228
20 BG01126029 Plate, Blanking 4

123
Clamp Assembly
BG01121678 - REV A
4
1
1 2 3
3 2

124
Clamp Assembly
BG01121678 - REV A
PARTS LIST
2 845.0030-00 LOCK NUT M12 8 FZB 22
3 847.0147-00 WASHER BRB 13,5x24 HB200 22
4 BG01121679 Plate 1
5 BG01121680 Plate 1
6 BG01121681 Plate 1

125
Clamp Assembly
BG01122331 - REV A
3 2

126
Clamp Assembly
BG01122331 - REV A
PARTS LIST
2 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 22
4 BG01122332 Plate 1
5 BG01122333 Plate 1
6 BG01122334 Plate 1

127
Scraper, Conveyor
BG01122791 - REV A
1 9
11
12
7 4
8
6 3
10
2 6 14
13
1 7

128
Scraper, Conveyor
BG01122791 - REV A
PARTS LIST
1 840.0038-00 SCREW M6S 10x40 8.8 FZB 4
2 840.0056-00 SCREW M6S 12X100 8.8 1
3 845.0030-00 LOCK NUT M12 8 FZB 1
4 845.0213-00 LOCK NUT M10 8 FZB 4
5 847.0016-00 WASHER BRB 17x30 HB200 2
6 847.0147-00 WASHER BRB 13,5x24 HB200 2
7 847.0358-00 WASHER BRB 10,5x20 HB200 8
8 BG00570358 Rubber 1
9 BG00570359 Rubber 1
10 BG01116408 Pin, Split, 6.3x36 2
12 BG01122741 Clamp Assembly 1

129
Scraper, Conveyor
BG01123347 - REV A
1 6
1 2
4 3

130
Scraper, Conveyor
BG01123347 - REV A
PARTS LIST
3 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 7
5 BG00570356 Rubber 1
6 BG01123348 Plate 1
7 BG01123349 Plate 1

131
Drum Assembly
BG01124228 - REV A
5 1 4 6 8 11 9
10
10
3 4
3
7
4

132
Drum Assembly
BG01124228 - REV A
PARTS LIST
1 840.0055-00 SCREW M6S 12X90 8.8 4
3 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 12
5 BG00521291 Drum, Tail 1
8 BG01124229 Plate 2
9 BG01124230 Plate 4
10 BG01124231 Plate 4
11 BG01124232 Plate 2

133
Conveyor Assembly, Mid Section
BG01129662 - REV A
13
12
8
7
2
5
6
1
14
15
11
10

134
BG01129662 - REV A
PARTS LIST
1 10-26-0063 22mm HOSE CLAMP 2
2 700.2376-001 Rubber 1
4 BG01120117 Roller Assembly 2 SEE ASSY: BG01120117
6 BG01125903 Bracket, Mounting 2 SEE ASSY: BG01125903
8 BG01127121 Plate 1
9 BG01127151 Plate 1
10 BG01127278 Support, Conveyor 1 SEE ASSY: BG01127278
15 BG01147535 RAIL DIN 46277/2 1

135
Support, Conveyor
BG01127278 - REV A
3 1
4
2 3

136
Support, Conveyor
BG01127278 - REV A
PARTS LIST
1 840.0614-00 SCREW M6S 10X75 ISO4014 4
2 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 4
5
6

137
Bracket, Mounting
BG01125903 - REV A
6 4
3 5

138
Bracket, Mounting
BG01125903 - REV A
PARTS LIST
1 841.0400-00 SCREW MF6S 6x25 8.8 CSK 4
3 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 6
4 845.0217-00 NUT LOCK ISO 7040 M6 8 FZB 4
7 BG01125904 Plate 1
8 BG01125905 Plate 2

139
Roller Assembly
BG01120117 - REV A

140
Roller Assembly
BG01120117 - REV A
PARTS LIST
1 853.0581-00 Pin, Cotter, (d6x32) 4
3 BG01120112 Pin 2
4
5
6

141
Bracket, Mounting
BG01129661 - REV A
1 4 3
1
1
6
1
7
2 4 3
2
2
5

142
Bracket, Mounting
BG01129661 - REV A
PARTS LIST
1 843.1323-00 843.1323-00 8
3 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 12

143
BG01130861 - REV B
12
11
10
13
8 8
3 4 2

144
BG01130861 - REV B
PARTS LIST
1 700-1734-00 Speed, Conveyor (180mm) 1
2 840.0036-00 SCREW M6S 10X30 8.8 ISO 4017 2
3 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 2
9 BG01129972 Plate 1
10 BG01130020 Plate 1
13 BG01130791 Roller Guard Assembly 1

145
Clamp Assembly
BG01130169 - REV A
4
2
3 2
1 1

146
Clamp Assembly
BG01130169 - REV A
PARTS LIST
2 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 18
4 BG01130170 Plate 1
5 BG01130171 Plate 1

147
Clamp Assembly
BG01130544 - REV A
3 2
3 2

148
Clamp Assembly
BG01130544 - REV A
PARTS LIST
2 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 18
4 BG01130545 Plate 1
5 BG01130546 Plate 1

149
Roller Guard Assembly
BG01130791 - REV A
4 7
9
3 12
10 6
6 5
1 6
11
2 6

150
Roller Guard Assembly
BG01130791 - REV A
PARTS LIST
1 840.0019-00 Screw M6S 8x12 8.8 ISO4017 4
2 840.0023-00 SCREW M6S M8X25 8.8 ZP 8
4 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 4
5 845.0205-00 LOCK NUT M8 8 FZB ISO 7040 8
8 BG01120108 Guard 1
9 BG01130769 Roller, Steel 1
10 BG01130792 Plate 2
11 BG01130793 Plate 2
12 BG01130794 Plate 2

151
BG01143181 - REV A
7
12
17
3
20
2
18 1
2
16
13
1
2 4 5
10 21
20
19
1
8 9
14
11
15

152
BG01143181 - REV A
PARTS LIST
1 10-26-0063 22mm HOSE CLAMP 3
4 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 10
10 BG01142341 Drum Assembly 1 SEE ASSY: BG01142341
11 BG01143010 Scraper, Belt 1 SEE ASSY: BG01143010
13 BG01143179 Plate 1
14 BG01143180 Plate 1
16 BG01145774 Plate 1
17 BG01145783 Plate 1
20 BG01149908 Pulley, Conv Stop Assy 2 SEE ASSY: BG01149908
21 BG01209909 Plate 1

153
Scraper, Belt
BG01143010 - REV A
12
9 2
13
3 6
14
7 11
15
13
10
5 4
8 3
6
7 14

154
Scraper, Belt
BG01143010 - REV A
PARTS LIST
1 840.0051-00 SCREW M6S 12x60 8.8 ZP ISO 4014 3
3 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 7
4 845.0215-00 LOCK NUT M16 8 FZB ISO 7040 2
7 853.0262-000 Pin, Split, 6.3X40 SMS 66 2
8 BG00570361 Scraper, Blade 1
9 BG00570371 Cylinder, Gas 2
11 BG01143011 Plate 1
12 BG01143012 Plate 1
13 BG01143013 Plate 2
14 BG01143014 Pin 2
15 BG01143015 Plate 2

155
Drum Assembly
BG01142341 - REV A
8 2 8 6
10
14
7 1 19
20
3
5 3
5
18 16
3
3
16
3
17 11
4 3
1 7
15
21
4
3 3 3 6 8
3 5
16 4
9
9
16 7
5 13
14 1 12

156
Drum Assembly
BG01142341 - REV A
PARTS LIST
1 840.0023-00 SCREW M6S M8X25 8.8 ZP 20
2 840.0049-00 SCREW M6S M12x50 8.8ZP ISO4014 10
5 845.0012-00 NUT M6M M24 8 ZP 6
6 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 40
9 847.0360-00 WASHER BRB 25x44 ZP 6
10 BG00570349 Motor, Hydraulic 1
11 BG00570351 Drum, Drive 1
12 BG01140392 Adjuster, Threaded Bar 1
13 BG01140398 Bracket 1
16 BG01140414 Bar, Square 4
18 BG01140424 Bracket, Motor 1
19 BG01140431 Adjuster, Threaded Bar 1
21 BG01140434 Plate 1

157
Bracket, Mounting
BG01145729 - REV A
2 4

158
Bracket, Mounting
BG01145729 - REV A
PARTS LIST
3 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 12

159
Clamp Assembly
BG01146142 - REV A
3 5

160
Clamp Assembly
BG01146142 - REV A
PARTS LIST
2 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 25
4 BG01146143 Plate 1
5 BG01146144 Plate 1
6 BG01146145 Plate 1

161
Pulley, Conv Stop Assy
BG01149908 - REV A
1 6
5 3
4 6

162
Pulley, Conv Stop Assy
BG01149908 - REV A
PARTS LIST
1 840.0039-00 SCREW M6S 10X45 8.8 1
3 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 2
4 845.0213-00 LOCK NUT M10 8 FZB ISO 7040 1
7 BG01143455 Pipe 1
8 BG01145927 Plate 1
9 BG01149904 Pulley 1

163
Clamp Assembly
BG01146234 - REV A
2 3

164
Clamp Assembly
BG01146234 - REV A
PARTS LIST
2 845.0030-00 LOCK NUT M12 8 FZB ISO 7040 25
4 BG01146235 Plate 1
5 BG01146236 Plate 1
6 BG01146237 Plate 1

165
POWERPACK OPTIONS ( UJ440 )
BG01490960 REV - B

166
POWERPACK OPTIONS ( UJ440 )
BG01490960 REV - B

1 700-9741-901 UJ440 VOLVO TIER 2 POWERPACK ASSEMBLY 1
2 703-0567-901 UJ VOLVO STAGE 4 / TIER 4 POWERPACK ASSEMBLY 1
3 BG01387002 Powerpack Assembly - UJ440 - Volvo D13 Stage 5 1

167
UJ440 VOLVO TIER 2 POWERPACK ASSEMBLY
700-9741-901 REV - 6

168
UJ440 VOLVO TIER 2 POWERPACK ASSEMBLY
700-9741-901 REV - 6

1 700-0637-00 ASSEMBLY OF TENSION BAR 2
2 700-8572-901 ASSEMBLY OF UJ440i POWERPACK PLATFORM. 1
3 700-9274-001 AIR CLEANER MOUNT 1
4 700-9734-901 ASSEMBLY OF OIL FILTER STATION. 1
5 700-9735-901 ASSEMBLY OF RADIATOR 1
6 700-9799-901 ASSEMBLY OF AIR INTAKE & SCAVENGE SYSTEM - UJ 1
7 700-9800-901 ASSEMBLY OF LIGHTING POLE - 3 WARNING COLOURS 1
8 700-9810-901 TRANSPORT SUPPORT FABRICATION. 1
9 700-9811-001 M16 LOCKING SCREW. 1
10 700-9820-901 HANDRAIL FABRICATION. 1
11 700-9959-901 UJ TIER 2 - VOLVO ENGINE & DRIVE TRAIN 1
12 700-9960-901 VOLVO TIER 2 EXHAUST ASSEMBLY 1
13 700-9987-901 BATTERY COVER FABRICATION. 1
14 703-0528-901 CANOPY ASSEMBLY 1
15 703-0560-501 BATTERY INFILL TRAY ASSEMBLY 1
16 703-0572-501 UJ OMKA BLANKET PLATE ASSY - VOLVO STAGE 4 2
17 703-0713-501 BLANKING PLATE FABRICATION 1
18 703-1105-901 U-RANGE TELEMATICS INSTALLATION ASSY. 1
20 840-0023-00 SCREW M6S M8X25 8.8 ZP (USE 840.0023-00) 4
21 840-0035-00 SCREW M6S 10X25 8.8 ISO 4017 (USE 840.0035-00) 2
23 840-0066-00 SCREW M6S M16x40 8.8 FZB (USE 840.0066-00) 2
24 841-0431-00 SCREW M6FS 10x20 CSK 8.8(USE 841.0431-00) 2
34 EL9739 BATTERY 12 VOLT EXTREME HEAVY DUTY. 2
35 EL9778 Isolator, Main, Battery 1
36 EL9852 L8 Powerpack box with cabling, Parts list 1
37 EN10523 ACM UNIT FOR TAD1372VE ENGINE. 1
38 EN9791 VOLVO SOLENOID VALVE - TANK HEATER 1
39 HHK0087 VOLVO POWER PACKS - ALL 440I 1

169
700-8572-901 REV - 4
10 6
3
4
7 11
7 11
8
11
7 9
9
8
11 11 8 11 7

170
700-8572-901 REV - 4
PARTS LIST
5 703-1062-001 ANTI-SLIP TAPE 3
6 840.0044-00 SCREW M6S 12x25 8.8 FZB 6
7 840.0046-00 SCREW M6S M12x35 8.8 ZP 12
8 845.0030-00 LOCK NUT M12 8 FZB 10
9 847.0014-00 WASHERS, BRB,ISO 7089,STEEL HB 200 MIN 16
10 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 6
11 847.0147-00 WASHER BRB 13,5x24 HB200 6

171
ASSEMBLY OF OIL FILTER STATION.
700-9734-901 REV - 4
10
10 1
9
4
Engine Remote Filter Assy.

912.0280-00 Oil Filter
6 10 8
13
11 14
11 7 12 2 12

172
700-9734-901 REV - 4
PARTS LIST
1 700-9062-901 OIL FILTER MOUNTING FABRICATION. 1
2 700-9387-001 FUEL PRE FILTER TRAY 1
3 700-9555-001 TRAY SUPPORT 1
4 700-9860-901 VOLVO T3B FUEL SYSTEM ASSEMBLY 1
5 840.0021-00 SCREW M6S M8x20 8.8 ISO4017 FZB 4
6 841.0235-00 SCREW CAP HD MC6S 8x20 8.8 ISO4762 4
7 841.0252-00 SCREW CAP HD MC6S 10x30 12.9. 2
8 845.0005-00 NUT M6M M8 8 FZB ISO 4032 2
9 845.0241-00 NUT WING VM M8. 1
10 847.0012-00 WASHER BRB 8,4X16 HB200 10
11 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 4
12 900-2355-00 Adapter SOG 1912 2
13 912-0194-00 HYDRAULIC DRAINAGE FILTER FRCA 80/6. 1
14 BG01314548 SCREW CAP HD MC6S 10x110 8.8 2

173
ASSEMBLY OF RADIATOR
700-9735-901 REV - 3
4 13 14 13 1 2
13
14
9 10 8
12
13 11
16 6 10
12 12 15
13 14 13 5 13 14 13 7
10

174
700-9735-901 REV - 3
PARTS LIST
1 700-5119-901 COOLER SUPPORT FABRICATION 1
2 700-5811-901 ASSEMBLY OF ENGINE COOLER. 1
3 700-9259-001 COOLER SUPPORT PLATE. 1
4 700-9268-001 VOLVO TIER UPPER CHARGE PIPE 1
5 700-9363-001 VOLVO TIER3B LOWER CHARGE PIPE 1
6 840.0032-00 SCREW M6S M10x16 8.8 ZP 2
7 840.0033-00 SCREW M6S 10X20 8.8 1
8 840.0037-00 SCREW M6S 10X35 8.8 4
9 845.0213-00 LOCK NUT M10 8 FZB 4
10 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 11
11 864-0146-00 RUBBER MOUNT B50/30 M10x28. 4
12 900-2084-00 HOSE CLAMP SINGLE SC 68-73. 4
13 900-2088-00 HOSE CLAMP SINGLE SC Ø98-103mm. 16
14 904-0714-00 HOSE CONNECTOR Ø90. 4
15 EN9770 VOLVO TIER 4i LOWER RAD PIPE. 1
16 EN9771 VOLVO TIER 4i UPPER RAD PIPE. 1

175
ASSEMBLY OF ENGINE COOLER
700-5811-901 REV - 3
6 8
984-1482-00 COOLER - AFTERMARKET REF. PARTS EN9642 - NISSENS

RADIATOR COOLER FAN GUARD
HV8672 - NISSENS RADIATOR COOLER MOTOR + BYPASS VALVE ASSY EN10464 - R/H COOLER
BLOCK FOR 910.0157-00 ENGINE COOLER EN10465 - L/H COOLER BLOCK FOR 910.0157-00 ENGINE
COOLER EN10466 - FAN BLADE ASSY FOR 910.0157-00 ENGINE COOLER

176
700-5811-901 REV - 3
PARTS LIST
1 700-5848-001 ADAPTOR Ø3 RESTRICTION G 1/4. 1
2 873-0382-00 BONDED SEAL - G 1/4 1
3 900-2454-00 ADAPTOR SOU 1917 1 3/16 UNF x 1 1/16 UNF. 2
4 900-2563-00 ADAPTOR WOG 1104 90° 11/16 UNF x G 1/4. 1
5 900-2855-00 ADAPTOR SOU 1109 11/16 UNF x 9/16 UNF. 1
6 910-0157-00 ENGINE COOLER. 1
7 964-2861-00 HOSE COUPLING P70-06-11 11/16 UNF x 3/8 HOSE. 1
8 984-1482-00 Level Indikator M14x1,5 1

177
AIR INTAKE SYSTEM
700-9799-901 REV - 3
11
12
9
3 11
8
5
10
19
18
1 4
13
20
6
22 16
7 14
25
21
24
24
23
11
17
11
15

178
AIR INTAKE SYSTEM
700-9799-901 REV - 3
PARTS LIST
1 840.0020-00 SCREW M6S M8X16 8.8 ZP 4
2 840.0045-00 SCREW M6S 12x30 ZP 8.8 FT 4
3 845.0030-00 LOCK NUT M12 8 FZB 2
4 847.0012-00 WASHER BRB 8,4X16 HB200 4
5 847.0147-00 WASHER BRB 13,5x24 HB200 6
7 900-2173-00 CLAMP HRRBS 6L Ø 60,3 PP/ST 1
8 958-1250-00_UJ440 AIR FILTER RADIAL SEAL 1
9 958-1261-00 RAIN COVER 203 MM 1
10 958-1262-00 MOUNTING CLAMP 457MM 2
11 958-1263-00 CLAMP BRZ HI-TORQUE Ø210-232. 4
12 958-1264-00 RUBBER ELBOW 90° 203mm BORE. 1
13 958-1265-00 PRESSURE SENSOR VOLVO/CAT. 1
14 958-1269-00 RUBBER REDUCER 127/101.5 1
15 958-1276-00 CLAMP CT-450L 1
16 958-1277-00 CLAMP CT-550L 1
17 EN9756 200MM STRAIGHT HUMP 1
18 EN9758 HOSE MOUNTING CLAMP Ø200mm. 2
19 EN9767 TIER 3B AIR INTAKE PIPE. 1
20 EN9768 ECCENTRIC INLET CHARGE PIPE. 1
21 EN9777 DONALDSON 50-32mm INLINE CHECK VALVE. 1
22 EN9778 VOLVO 3B SCAVENGE PIPE 1
23 EN9960 VOLVO TIER 2 32MM I.D. SCAVENGE PIPE 1
24 FAHC1005 40-55MM HOSE CLAMP 2

179
UJ TIER 2 - VOLVO ENGINE & DRIVE TRAIN
700-9959-901 REV - 2
21 21
19 23 17 22 14 8 26 25 11 10 16
20
2 22
15
9 18
19 23 6 24
13
12 23 19
15 22 20
1
5 4 5 4

180
UJ TIER 2 - VOLVO ENGINE & DRIVE TRAIN
700-9959-901 REV - 2
PARTS LIST
1 700-1632-901 LIFTING LUG FABRICATION 3
2 700-2861-901 POWER TAKE OFF CM1208 ASSY (UJ) 1
3 700-2862-901 FLUID COUPLING CM1208 ASSY 1
4 700-8543-901 ASSEMBLY OF POWERPACK MOUNTS - FRONT. 2
5 700-8544-901 ASSEMBLY OF POWERPACK MOUNTS - REAR. 2
6 700-9188-901 TIER 4 INTERIM BASE FRAME 1
7 700-9195-001 VOLVO D13 CHARGE INLET MANIFOLD 1
8 700-9355-001 ENGINE MOUNTING FOOT 4
9 700-9770-901 BELT GUARD LOWER 1
10 703-0187-501 VOLVO T2 CHARGE AIR INTAKE 1
11 840.0023-00 SCREW M6S M8X25 8.8 ZP 4
12 840.0036-00 SCREW M6S 10X30 8.8 3
13 840.0053-00 SCREW M6S 12x70 8.8 9
14 840.0065-00 SCREW M6S M16X35 8.8 ZP PT 16
15 840.0070-00 SCREW M6S 16x60 8.8 ZP 24
16 840.0605-00 SCREW M6S 8x100 8.8 4
17 843.1608-00 STUD PS M10x40 DIN 938. 12
18 845.0030-00 LOCK NUT M12 8 FZB 9
19 845.0213-00 LOCK NUT M10 8 FZB 27
20 845.0215-00 LOCK NUT M16 8 FZB 24
21 847.0012-00 WASHER BRB 8,4X16 HB200 8
22 847.0016-00 WASHER BRB 17x30 HB200 64
23 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 30
24 847.0147-00 WASHER BRB 13,5x24 HB200 18
25 873-0237-00 O-RING 89,5X3 SMS 1586 1
26 EN9599 VOLVO D13 TIER2 ENGINE 1

181
FLUID COUPLING CM1208 ASSY
700-2862-901 REV - 6
22 18 12 16 14 19 5 14 17 21
23
11
15
13
3
7
9
2
1
11
15
10
13
20

176
182
700-2862-901 REV - 6
PARTS LIST
1 700-2518-901 Fluid Coupling Mount 2
2 700-2874-901 PULLEY CM1208 ASSY 1
3 700-2916-00 OIL DRAINAGE HOSE ASSY. 1
4 700-2963-901 RPM-SENSOR INSTALLATION ASSY 1
5 700-9858-901 ASSEMBLY OF FILLER PORT EXTENSION 1
6 840.0071-00 SCREW M6S 16X65 8.8 4
7 845.0215-00 LOCK NUT M16 8 FZB 4
8 847.0016-00 WASHER BRB 17x30 HB200 4
9 847.0060-00 WASHER TBRSB 17x42 1370 4
10 873-0384-00 Seal, Bonded, G 1/2 1
11 873-0386-00 BONDED SEAL - G1 2
13 900-0673-00 Adapter RI-16-08 2
14 900-2344-00 Adapter WOO 1969 2
16 900-2355-00 Adapter SOG 1912 1
17 900-2526-00 Adapter SOG 1916 G1" 1
18 900-2683-00 Adapter G1/8" G1/4" 1
19 912-0205-00 FILTER BFP3G10W1.0 AIR BREATHER CAP 1
21 930-0293-00 FLUID COUPLING KPTO 21 1
22 984-1217-00 PRESS. TRANSDUCER 3050 0-10BAR 1
23 912.0316-00 FILTERHEAD COUPLING WITH FILTER 1

183
POWER TAKE OFF CM1208 ASSY
700-2861-901 REV - 7
14
1
15
14
2 13
11
12
10
17
16
12
10

184
700-2861-901 REV - 7
PARTS LIST
1 700-2863-901 PUMP 3-PIECE ASSSY 1
2 700-2864-901 POWER TAKE OFF BREATHER ASSY 1
3 700-2865-901 PUMP REXROTH LEFT ASSY 1
4 700-2866-901 PUMP REXROTH RIGHT ASSY 1
5 700-2867-901 SUCTION TUBE LEFT ASSY 1
6 700-2868-901 SUCTION TUBE RIGHT ASSY 1
7 700-2869-901 LEVEL INDICATOR ASSY 1
9 841.0077-00 SCREW UC6S 1/2UNCX45 12.9 8
10 847.0258-00 WASHER NL M12 (USE 847.0258-00) 8
12 900-2378-00 FLANGE HALF SAE 6000 1 1/4 4
13 900-2413-00 T-ADAPTER TOO 1363 1
14 900-2431-00 ADAPTER SOG 1306 2
15 900-2450-00 ADAPTER WOG 1308 1
16 900-2533-00 CONNECTION TOG 1308 1
17 930-0296-00 POWER TAKE OFF OMKA 1:1.3 1

185
SUCTION TUBE LEFT ASSY
700-2867-901 REV - 2
9 8 5
1
6 7 7 4
3 6 7

186
700-2867-901 REV - 2
PARTS LIST
1 649-0188-07 M10 X 85 DN64 U-Bolt 1
2 700-1293-901 SUCTION TUBE 1
3 700-2547-901 POWER TAKE OFF SUCTION PIPE LEFT MOUNT 1
4 840.0037-00 SCREW M6S 10X35 8.8 2
5 841.0077-00 SCREW UC6S 1/2UNCX45 12.9 4
6 845.0213-00 LOCK NUT M10 8 FZB 4
7 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 6
8 847.0258-00 WASHER NL M12 4
9 873-1295-00 O-ring 214-40 1

187
SUCTION TUBE RIGHT ASSY
700-2868-901 REV - 2.
9 8 5 4 3 7 6
2 1 7 6

188
700-2868-901 REV - 2.
PARTS LIST
1 453-4081-90 SUCTION PIPE CM1208H 1
2 649-0188-07 M10 X 85 DN64 U-Bolt 1
3 700-2548-901 SUCTION TUBE SUPPORT FABRICATION. 1
4 840.0037-00 SCREW M6S 10X35 8.8 2
5 841.0077-00 SCREW UC6S 1/2UNCX45 12.9 4
6 845.0213-00 LOCK NUT M10 8 FZB 4
7 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 6
8 847.0258-00 WASHER NL M12 4
9 873-1295-00 O-ring 214-40 1

189
CANOPY ASSEMBLY
703-0528-901 REV - 3
16
26
4 20 26
18 6
12 9
31 32 34 33
14
35
1
10 22 28
19 15
2 11 7
27
32
32
24
5 17 30 25
3 34
33
33 34 32 7 13 8

190
CANOPY ASSEMBLY
703-0528-901 REV - 3
PARTS LIST
1 700-8677-901 ASSEMBLY OF TIER 3B TOP DOOR. 1
2 700-8678-901 ASSEMBLY OF TIER 3B LOWER DOOR. 1
3 700-8679-901 ASSEMBLY OF BOTTOM DOOR PANEL. 1
4 700-9065-901 ASSEMBLY OF DRIVE BELT GUARD COVER. 1
5 700-9386-001 REMOTE OIL FILTER TRAY 1
6 700-9415-001 L8 BOX BRACKET 1
7 700-9552-001 TIER 3B PP CANOPY COVER PLT 2
8 700-9573-901 ASSEMBLY OF DOOR. 1
9 700-9664-901 VENT PANEL FABRICATION. 1
10 700-9834-001 UH OMKA TOP COVER PLT 1
11 703-0030-501 DOOR LOCKOUT ASSEMBLY 1
12 703-0529-501 ENGINE HOOD FABRICATION 1
13 703-0530-501 OMKA CANOPY FABRICATION 1
14 703-0532-901 ASSEMBLY OF BATTERY BAY DOOR 1
15 703-0583-001 EJECTOR CHECK VALVE BRACKET 1
16 703-0982-901 RADIATOR GUARD ASSEMBLY 1
17 840.0017-00 SCREW M6S 6x60 8.8 ZP 1
18 840.0021-00 SCREW M6S M8x20 8.8 2
19 840.0023-00 SCREW M6S M8X25 8.8 ZP 2
20 840.0024-00 SCREW M6S 8x30 8.8 2
21 840.0047-00 SCREW M6S M12X40 8.8 ZP 8
22 840.0543-00 SCREW M6S 10x65 8.8 8
23 845.0030-00 LOCK NUT M12 8 FZB 8
24 845.0205-00 LOCK NUT M8 8 FZB 2
25 845.0217-00 NUT LOCK ISO 7040 M6 8 FZB 1
26 847.0012-00 WASHER BRB 8,4X16 HB200 4
27 847.0013-00 WASHER BRB 10x18 HB200 SS70 4
28 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 8
29 847.0147-00 WASHER BRB 13,5x24 HB200 16
30 847.0164-00 WASHER BRB 6,4X12 HB200 2
31 BG01306680 800N GAS STRUT - ASSEMBLY 2
32 FA9113 STUD - HEX RECESS HEAD - SIZE 9x16. 16
33 FA9115 RECEPTACLE-CLIP ON-SIZE 9 (D8-339-300-121) 16
34 FA9116 RETAINER-PUSH ON STEEL-SIZE 9 (D8-329-101-200) 16
35 RU5202 EDGE TRIP 1

191
ASSEMBLY OF LIGHTING POLE - 3 WARNING COLOURS
700-9800-901 REV - 05
9 11 4
8 12
10 12 6
12 5

192
700-9800-901 REV - 05
PARTS LIST
1 700-2167-901 TOP LIGHTING POLE ASSY - 3 WARNING COLOURS 1
2 700-9801-901 BOTTOM POLE FABRICATION 1
3 700-9805-901 MID POLE FABRICTION 1
4 840.0031-00 SCREW M6S 8X70 8.8 1
5 840.0035-00 SCREW M6S 10X25 8.8 3
6 840.0043-00 SCREW M6S M10X90 8.8 ZP 2
7 843.1495-00 EYE BOLT M10x50. 1
8 845.0006-00 NUT M6M M10 8 FZB 1
9 845.0205-00 LOCK NUT M8 8 FZB 1
10 845.0213-00 LOCK NUT M10 8 FZB 2
11 847.0012-00 WASHER BRB 8,4X16 HB200 2
12 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 8

193
TOP LIGHTING POLE ASSEMBLY - 3 WARNING COLOURS
700-2167-901 REV - 04
4 8 11 5
18
7 10 9
12
19
JUNCTION BOX ASSEMBLY

EL10499 SUPPLIED IN ELECTRIC KITS
REFER TO LATEST TOP LEVEL ELECTRICAL KITS

194
TOP LIGHTING POLE ASSEMBLY - 3 WARNING COLOURS
700-2167-901 REV - 04
PARTS LIST
1 14-05-0187 24V SQUARE WORKLAMP 4 Replaced 970.0166-00 Light
2 700-0892-001 RUBBER WASHER 1

3 700-0893-001 RUBBER DISTANCE 1
4 700-0894-001 PLATE 1
5 700-0895-001 Bar, Threaded 2
6 700-2161-901 TOP POLE WELDED ASSY 1
7 840.0004-00 SCREW M6S 5X20 8.8 4
8 845.0217-00 NUT LOCK ISO 7040 M6 8 FZB 4
9 845.0218-00 LOCK NUT M5 8 4
10 847.0010-00 WASHER BRB 5,3x10 8
11 847.0164-00 WASHER BRB 6,4X12 HB200 4
12 900-1136-00 TUBE CLAMP RSGU 1100 10/12 4
13 960-0555-00 CABLE OLFLEX 400 P 2X1,5 1
14 960-0558-00 CABLE OLFLEX 4X1.5 1
15 964-1581-00 NUT 15,2 PLASTIC 4
16 964-1691-00 GLAND 15,2 SKINTOP-ST9 4
17 964-2453-00 GLAND SKINTOP-ST M20 1
Replaces 970.0179-00 / 970.0178-00
18 BG01640848 Light, Unit 1 970.0177-00 Lights
19 EL10499 JUNCTION BOX 1

195
VOLVO TIER 2 EXHAUST ASSEMBLY
700-9960-901 REV - 2
3 9 7 11 13 5 10
7 9
8 11 6
12
12

196
VOLVO TIER 2 EXHAUST ASSEMBLY
700-9960-901 REV - 2
PARTS LIST
1 700-9055-901 VOLVO TIER 2 EXHAUST PIPE 1
2 700-9686-901 SILENCER ASSEMBLY (PURCHASE DRAWING) 1
3 703-0621-501 EXHAUST MUFFLER MOUNTING BRACKET 1
4 703-0622-001 MOUNTING ANGLE BRACKET 1
5 840.0042-00 SCREW M6S 10x70 8.8 3
6 840.0046-00 SCREW M6S M12x35 8.8 ZP 2
7 840.0065-00 SCREW M6S M16X35 8.8 ZP PT 4
8 845.0030-00 LOCK NUT M12 8 FZB 4
9 847.0016-00 WASHER BRB 17x30 HB200 4
10 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 3
11 847.0147-00 WASHER BRB 13,5x24 HB200 6
12 900-2852-00 HOSE CLAMP SINGLE Ø130-140mm. 2
13 958-1243-00 EXHAUST RAINHOOD 1

197
UJ VOLVO STAGE 4 / TIER 4 POWERPACK ASSEMBLY
703-0567-901 REV - 7

198
UJ VOLVO STAGE 4 / TIER 4 POWERPACK ASSEMBLY
703-0567-901 REV -7

6 700-9811-001 M16 LOCKING SCREW. 1
8 700-9987-901 BATTERY COVER FABRICATION. 1
9 703-0527-901 VOLVO SCR CRADLE 1
10 703-0528-901 CANOPY ASSEMBLY 1
11 703-0557-901 NEW ASSEMBLY OF RADIATOR_VOLVO STAGE 4 1
12 703-0559-901 ASSEMBLY OF AIR INTAKE & SCAVENGE SYSTEM - UJ 1
14 703-0569-901 UJ - VOLVO ENGINE & DRIVE TRAIN 1
20 840-0023-00 SCREW M6S M8X25 8.8 ZP (USE 840.0023-00) 4
21 840-0035-00 SCREW M6S 10X25 8.8 ISO 4017 (USE 840.0035-00) 2

199
700-8572-901 REV - 4
10 6
3
4
7 11
7 11
8
11
7 9
9
8
11 11 8 11 7

200
700-8572-901 REV - 4
PARTS LIST
5 703-1062-001 ANTI-SLIP TAPE 3
6 840.0044-00 SCREW M6S 12x25 8.8 FZB 6
7 840.0046-00 SCREW M6S M12x35 8.8 ZP 12
8 845.0030-00 LOCK NUT M12 8 FZB 10
10 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 6
11 847.0147-00 WASHER BRB 13,5x24 HB200 6

201
700-9734-901 REV - 4
10
10 1
9
4

6 10 8
13
11 14
11 7 12 2 12

202
700-9734-901 REV - 4
PARTS LIST
3 700-9555-001 TRAY SUPPORT 1
5 840.0021-00 SCREW M6S M8x20 8.8 ISO4017 FZB 4
6 841.0235-00 SCREW CAP HD MC6S 8x20 8.8 ISO4762 4
7 841.0252-00 SCREW CAP HD MC6S 10x30 12.9. 2
8 845.0005-00 NUT M6M M8 8 FZB ISO 4032 2
9 845.0241-00 NUT WING VM M8. 1
10 847.0012-00 WASHER BRB 8,4X16 HB200 10
11 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 4
12 900-2355-00 Adapter SOG 1912 2
14 BG01314548 SCREW CAP HD MC6S 10x110 8.8 2

203
703-0557-901 REV - 2
6 14 15 5 14 15 14
1 2
10
14
11
15
14 13 9 12
17
7 11
13
13 16
14 15 14 4 14 15 14 8
11

204
703-0557-901 REV - 2
PARTS LIST
2 700-5811-901 ASSEMBLY OF ENGINE COOLER. 1 See Drg 700-5811-901
5 703-1007-001 UPPER CHARGE PIPE 1
7 840.0032-00 SCREW M6S M10x16 8.8 ZP 2
8 840.0033-00 SCREW M6S 10X20 8.8 1
9 840.0037-00 SCREW M6S 10X35 8.8 4
10 845.0213-00 LOCK NUT M10 8 FZB 4
11 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 11
12 864-0146-00 RUBBER MOUNT B50/30 M10x28. 4
15 904-0714-00 HOSE CONNECTOR Ø90. 5

205
700-5811-901 REV - 3
6 8


206
700-5811-901 REV - 3
PARTS LIST
2 873-0382-00 BONDED SEAL - G 1/4 1

207
AIR INTAKE & SCAVENGE ASSY
703-0559-901 REV - 4
24 11
16
7
18 12
9
10 11
6
21
23
20
5 8
17
3
2
24
1
15
22
11
24 19
11
4
14
24 13

208
AIR INTAKE & SCAVENGE ASSY
703-0559-901 REV - 4
PARTS LIST
1 703-0554-001 TURBO INLET HOSE - VOLVO STAGE 4 1
2 703-0555-001 ECCENTRIC INLET CHARGE PIPE - VOLVO STAGE 4 1
3 703-0561-001 SCAVENGE PIPE - VOLVO STAGE 4 1
4 703-0579-001 SILICON CHARGE AIR CONNECTOR FOR UJ - VOLVO STAGE 4 1
5 840.0020-00 SCREW M6S M8X16 8.8 ZP 4
6 840.0045-00 SCREW M6S 12x30 ZP 8.8 FT 4
7 845.0030-00 LOCK NUT M12 8 FZB 2
8 847.0012-00 WASHER BRB 8,4X16 HB200 4
9 847.0147-00 WASHER BRB 13,5x24 HB200 6
11 958-1263-00 CLAMP BRZ HI-TORQUE Ø210-232. 4
13 958-1276-00 CLAMP CT-450L 1
14 958-1277-00 CLAMP CT-550L 1
15 EN10271 Air filter unit, end cover 1
16 EN10272 AIR FILTER PRE-CLEANER RAIN CAP 203DIA 1
17 EN10360 VOLVO AIR SWITCH ADAPTOR 1
18 EN10383 DONALDSON FRG2 AIR CLEANER 1
19 EN9756 200MM STRAIGHT HUMP 1
21 EN9767 TIER 3B AIR INTAKE PIPE. 1
22 EN9899 DONALDSON 50-50MM EJECTOR CHECK VALVE 1
23 EN9989 VOLVO D13 SCR PRIMARY INDICATOR SENSOR 1

209
VOLVO ENGINE & DRIVE TRAIN
703-0569-901 REV - 2.
NOTE:
ENGINE OPTION ( TIER 4 / STAGE 4 )
- EN10188 VOLVO TAD1372VE 315KW, STAGE 4 ( EU BUILD SPECIFICATION - STOCK CONSUMED JUNE 2020
- EN10140 VOLVO TAD1372VE 315KW, TIER 4 FINAL ( USA / EPA BUILD SPECIFICATION
17 11 7 20
15 18 13
16
17
12
2
8 14
15 18 6
19
10
9 18 15
12 17 16
1
5 4 5 4

210
VOLVO ENGINE & DRIVE TRAIN
703-0569-901 REV - 2.
PARTS LIST
2 700-2861-901 POWER TAKE OFF CM1208 ASSY (UJ) 1 See Drg 700-2861-901
3 700-2862-901 FLUID COUPLING CM1208 ASSY 1 See Drg 700-2862-901
4 700-8543-901 ASSEMBLY OF POWERPACK MOUNTS - FRONT. 2 See Drg 700-8543-901
5 700-8544-901 ASSEMBLY OF POWERPACK MOUNTS - REAR. 2 See Drg 700-8544-901

9 840.0036-00 SCREW M6S 10X30 8.8 3
10 840.0053-00 SCREW M6S 12x70 8.8 9
11 840.0065-00 SCREW M6S M16X35 8.8 ZP PT 16
12 840.0070-00 SCREW M6S 16x60 8.8 ZP 24
13 843.1608-00 STUD PS M10x40 DIN 938. 12
14 845.0030-00 LOCK NUT M12 8 FZB 9
15 845.0213-00 LOCK NUT M10 8 FZB 27
16 845.0215-00 LOCK NUT M16 8 FZB 24
17 847.0016-00 WASHER BRB 17x30 HB200 64
18 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 30
19 847.0147-00 WASHER BRB 13,5x24 HB200 18
20 EN10188 VOLVO TAD1372VE 315KW, STAGE 4 EU BUILD SPEC 1

211
700-2862-901 REV - 6
22 18 12 16 14 19 5 14 17 21
23
11
15
13
3
7
9
2
1
11
15
10
13
20

206
212
700-2862-901 REV - 6
PARTS LIST
2 700-2874-901 PULLEY CM1208 ASSY 1
6 840.0071-00 SCREW M6S 16X65 8.8 4
7 845.0215-00 LOCK NUT M16 8 FZB 4
8 847.0016-00 WASHER BRB 17x30 HB200 4
9 847.0060-00 WASHER TBRSB 17x42 1370 4
10 873-0384-00 Seal, Bonded, G 1/2 1
11 873-0386-00 BONDED SEAL - G1 2
13 900-0673-00 Adapter RI-16-08 2
14 900-2344-00 Adapter WOO 1969 2
16 900-2355-00 Adapter SOG 1912 1
17 900-2526-00 Adapter SOG 1916 G1" 1
18 900-2683-00 Adapter G1/8" G1/4" 1

213
700-2861-901 REV - 7
14
1
15
14
2 13
11
12
10
17
16
12
10

214
700-2861-901 REV - 7
PARTS LIST
9 841.0077-00 SCREW UC6S 1/2UNCX45 12.9 8
10 847.0258-00 WASHER NL M12 (USE 847.0258-00) 8
12 900-2378-00 FLANGE HALF SAE 6000 1 1/4 4
13 900-2413-00 T-ADAPTER TOO 1363 1
14 900-2431-00 ADAPTER SOG 1306 2
15 900-2450-00 ADAPTER WOG 1308 1
16 900-2533-00 CONNECTION TOG 1308 1

215
700-2867-901 REV - 2
9 8 5
1
6 7 7 4
3 6 7

216
700-2867-901 REV - 2
PARTS LIST
1 649-0188-07 M10 X 85 DN64 U-Bolt 1
2 700-1293-901 SUCTION TUBE 1
4 840.0037-00 SCREW M6S 10X35 8.8 2
5 841.0077-00 SCREW UC6S 1/2UNCX45 12.9 4
6 845.0213-00 LOCK NUT M10 8 FZB 4
7 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 6
8 847.0258-00 WASHER NL M12 4
9 873-1295-00 O-ring 214-40 1

217
700-2868-901 REV - 2.
9 8 5 4 3 7 6
2 1 7 6

218
700-2868-901 REV - 2.
PARTS LIST
1 453-4081-90 SUCTION PIPE CM1208H 1
2 649-0188-07 M10 X 85 DN64 U-Bolt 1
4 840.0037-00 SCREW M6S 10X35 8.8 2
5 841.0077-00 SCREW UC6S 1/2UNCX45 12.9 4
6 845.0213-00 LOCK NUT M10 8 FZB 4
7 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 6
8 847.0258-00 WASHER NL M12 4
9 873-1295-00 O-ring 214-40 1

219
CANOPY ASSEMBLY
703-0528-901 REV - 3
16
26
4 20 26
18 6
12 9
31 32 34 33
14
35
1
10 22 28
19 15
2 11 7
27
32
32
24
5 17 30 25
3 34
33
33 34 32 7 13 8

220
CANOPY ASSEMBLY
703-0528-901 REV - 3
PARTS LIST
1 700-8677-901 ASSEMBLY OF TIER 3B TOP DOOR. 1
2 700-8678-901 ASSEMBLY OF TIER 3B LOWER DOOR. 1
3 700-8679-901 ASSEMBLY OF BOTTOM DOOR PANEL. 1
4 700-9065-901 ASSEMBLY OF DRIVE BELT GUARD COVER. 1
5 700-9386-001 REMOTE OIL FILTER TRAY 1
6 700-9415-001 L8 BOX BRACKET 1
7 700-9552-001 TIER 3B PP CANOPY COVER PLT 2
8 700-9573-901 ASSEMBLY OF DOOR. 1
9 700-9664-901 VENT PANEL FABRICATION. 1
10 700-9834-001 UH OMKA TOP COVER PLT 1
11 703-0030-501 DOOR LOCKOUT ASSEMBLY 1
12 703-0529-501 ENGINE HOOD FABRICATION 1
13 703-0530-501 OMKA CANOPY FABRICATION 1
14 703-0532-901 ASSEMBLY OF BATTERY BAY DOOR 1
15 703-0583-001 EJECTOR CHECK VALVE BRACKET 1
16 703-0982-901 RADIATOR GUARD ASSEMBLY 1
17 840.0017-00 SCREW M6S 6x60 8.8 ZP 1
18 840.0021-00 SCREW M6S M8x20 8.8 2
19 840.0023-00 SCREW M6S M8X25 8.8 ZP 2
20 840.0024-00 SCREW M6S 8x30 8.8 2
21 840.0047-00 SCREW M6S M12X40 8.8 ZP 8
22 840.0543-00 SCREW M6S 10x65 8.8 8
23 845.0030-00 LOCK NUT M12 8 FZB 8
24 845.0205-00 LOCK NUT M8 8 FZB 2
25 845.0217-00 NUT LOCK ISO 7040 M6 8 FZB 1
26 847.0012-00 WASHER BRB 8,4X16 HB200 4
27 847.0013-00 WASHER BRB 10x18 HB200 SS70 4
28 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 8
29 847.0147-00 WASHER BRB 13,5x24 HB200 16
30 847.0164-00 WASHER BRB 6,4X12 HB200 2
31 BG01306680 800N GAS STRUT - ASSEMBLY 2
32 FA9113 STUD - HEX RECESS HEAD - SIZE 9x16. 16
33 FA9115 RECEPTACLE-CLIP ON-SIZE 9 (D8-339-300-121) 16
34 FA9116 RETAINER-PUSH ON STEEL-SIZE 9 (D8-329-101-200) 16
35 RU5202 EDGE TRIP 1

221
VOLVO SCR CRADLE
703-0527-901 REV - 4
6 3
9 8 17 19 10 7 9 8
16
18
14 15 13
1 12 11

222
VOLVO SCR CRADLE
703-0527-901 REV - 4
PARTS LIST
1 703-0564-501 EXHAUST PIPE - VOLVO STAGE 4 1
2 703-0565-501 VENTURI EXHAUST OUTLET ASSY - VOLVO STAGE 4 1
3 703-0623-501 SCR MOUNTING BRACKET 1
4 703-0628-001 EXHAUST JACKET ASSEMBLY - TAD1372VE 1
5 703-0981-001 PIPE SUPPORT 1
6 840.0046-00 SCREW M6S M12x35 8.8 ZP 3
7 840.0047-00 SCREW M6S M12X40 8.8 ZP 2
8 845.0030-00 LOCK NUT M12 8 FZB 8
9 847.0147-00 WASHER BRB 13,5x24 HB200 13
10 900-2781-00 U-Bolt - M8 - 138 C/C - 125mm Leg Length 2
11 EN10534 V-BAND CLAMP 1
12 EN10535 RING INSERT 1
13 EN10536 V-CLAMP 2
14 EN10537 FLANGE SCREW 2
15 EN10538 FLANGE NUT 2
16 EN10539 TEMPERATURE SENSOR 1
17 EN10540 NOX SENSOR 1
18 EN10541 DOSING VALVE 1
19 EN9683 RAIN CAP 1

223
703-0626-901 REV - 04
9 11 4
8 12
10 12 6
12 5

224
703-0626-901 REV - 04
PARTS LIST
3 703-0624-901 TOP LIGHTING POLE ASSEMBLY 1
4 840.0031-00 SCREW M6S 8X70 8.8 1
5 840.0035-00 SCREW M6S 10X25 8.8 3
6 840.0043-00 SCREW M6S M10X90 8.8 ZP 2
7 843.1495-00 EYE BOLT M10x50. 1
8 845.0006-00 NUT M6M M10 8 FZB 1
9 845.0205-00 LOCK NUT M8 8 FZB 1
10 845.0213-00 LOCK NUT M10 8 FZB 2
11 847.0012-00 WASHER BRB 8,4X16 HB200 2
12 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 8

225
TOP LIGHTING POLE ASSEMBLY
703-0624-901 REV - 04
4 8 11 6
18
7 10 9
12
19


226
703-0624-901 REV - 04
PARTS LIST

4 700-0894-001 PLATE 1
6 703-0625-001 THREADED BAR - M6 2
7 840.0004-00 SCREW M6S 5X20 8.8 4
8 845.0217-00 NUT LOCK ISO 7040 M6 8 FZB 4
9 845.0218-00 LOCK NUT M5 8 4
10 847.0010-00 WASHER BRB 5,3x10 8
11 847.0164-00 WASHER BRB 6,4X12 HB200 4
12 900-1136-00 TUBE CLAMP RSGU 1100 10/12 4
13 960-0555-00 CABLE OLFLEX 400 P 2X1,5 1
14 960-0558-00 CABLE OLFLEX 4X1.5 1
15 964-1581-00 NUT 15,2 PLASTIC 4
16 964-1691-00 GLAND 15,2 SKINTOP-ST9 4
Replaces 970.0179-00 / 970.0178-00
18 BG01640672 Light, Unit 1 970.0177-00 / EL10309 Lights

227
Powerpack Assembly - UJ440 - Volvo D13
BG01387002 REV - C

228
Powerpack Assembly - UJ440 - Volvo D13
BG01387002 REV - C

6 700-9811-001 M16 LOCKING SCREW. 1
8 703-0557-901 NEW ASSEMBLY OF RADIATOR_VOLVO STAGE 4 1
15 840-0035-00 SCREW M6S 10X25 8.8 ISO 4017 (USE 840.0035-00) 2
27 BG01387006 Engine Assembly - UJ440 - Volvo D13 1
28 BG01387007 Air Cleaner Assembly 1
29 BG01387011 Aftertreatment Assembly 1
30 BG01388102 CANOPY ASSEMBLY 1

229
700-8572-901 REV - 4
10 6
3
4
7 11
7 11
8
11
7 9
9
8
11 11 8 11 7

230
700-8572-901 REV - 4
PARTS LIST
5 703-1062-001 ANTI-SLIP TAPE 3
6 840.0044-00 SCREW M6S 12x25 8.8 FZB 6
7 840.0046-00 SCREW M6S M12x35 8.8 ZP 12
8 845.0030-00 LOCK NUT M12 8 FZB 10
10 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 6
11 847.0147-00 WASHER BRB 13,5x24 HB200 6

231
700-9734-901 REV - 4
10
10 1
9
4

6 10 8
13
11 14
11 7 12 2 12

232
700-9734-901 REV - 4
PARTS LIST
3 700-9555-001 TRAY SUPPORT 1
5 840.0021-00 SCREW M6S M8x20 8.8 4
6 841-0235-00 SCREW CAP HD MC6S 8x20 8.8 4
7 841-0252-00 SCREW CAP HD MC6S 10x30 12.9. 2
8 845.0005-00 NUT M6M M8 8 FZB 2
9 845.0241-00 NUT WING VM M8. 1
10 847.0012-00 WASHER BRB 8,4X16 HB200 10
11 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 4
12 900-2355-00 Adapter SOG 1912 2
14 BG01314548 SCREW CAP HD MC6S 10x110 8.8 ISO4762 2

233
703-0557-901 REV - 2
6 14 15 5 14 15 14
1 2
10
14
11
15
14 13 9 12
17
7 11
13
13 16
14 15 14 4 14 15 14 8
11

234
703-0557-901 REV - 2
PARTS LIST
2 700-5811-901 ASSEMBLY OF ENGINE COOLER. 1 See Drg 700-5811-901
7 840.0032-00 SCREW M6S M10x16 8.8 ZP 2
8 840.0033-00 SCREW M6S 10X20 8.8 1
9 840.0037-00 SCREW M6S 10X35 8.8 4
10 845.0213-00 LOCK NUT M10 8 FZB 4
11 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 11
12 864-0146-00 RUBBER MOUNT B50/30 M10x28. 4
15 904-0714-00 HOSE CONNECTOR Ø90. 5

235
700-5811-901 REV - 3
6 8


236
700-5811-901 REV - 3
PARTS LIST
2 873-0382-00 BONDED SEAL - G 1/4 1

237
Engine Assembly - UJ440 - Volvo D13
BG01387006 REV - A
2 15 18 13 17 11 7 20
17
16
12
8 14
15 18
19
10
1
9
18
15
6 5 4 5 4

238
Engine Assembly - UJ440 - Volvo D13
BG01387006 REV - A
PARTS LIST
2 700-2861-901 POWER TAKE OFF CM1208 ASSY (UJ) 1
3 700-2862-901 FLUID COUPLING CM1208 ASSY 1
4 700-8543-901 ASSEMBLY OF POWERPACK MOUNTS - FRONT. 2
5 700-8544-901 ASSEMBLY OF POWERPACK MOUNTS - REAR. 2
9 840.0036-00 SCREW M6S 10X30 8.8 I 3
10 840.0053-00 SCREW M6S 12x70 8.8 9
11 840.0065-00 SCREW M6S M16X35 8.8 ZP PT 16
12 840.0070-00 SCREW M6S 16x60 8.8 ZP 24
13 843.1608-00 STUD PS M10x40 DIN 938. 12
14 845.0030-00 LOCK NUT M12 8 FZB 9
15 845.0213-00 LOCK NUT M10 8 FZB 27
16 845.0215-00 LOCK NUT M16 8 FZB 24
17 847.0016-00 WASHER BRB 17x30 HB200 64
18 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 30
19 847.0147-00 WASHER BRB 13,5x24 HB200 18
20 EN10953 VOLVO ENGINE - 315KW, STAGE 5, TAD1382 1

239
700-2862-901 REV - 6
22 18 12 16 14 19 5 14 17 21
23
11
15
13
3
7
9
2
1
11
15
10
13
20

240
700-2862-901 REV - 6
PARTS LIST
2 700-2874-901 PULLEY CM1208 ASSY 1
6 840.0071-00 SCREW M6S 16X65 8.8 4
7 845.0215-00 LOCK NUT M16 8 FZB 4
8 847.0016-00 WASHER BRB 17x30 HB200 4
9 847.0060-00 WASHER TBRSB 17x42 1370 4
10 873-0384-00 Seal, Bonded, G 1/2 1
11 873-0386-00 BONDED SEAL - G1 2
13 900-0673-00 Adapter RI-16-08 2
14 900-2344-00 Adapter WOO 1969 2
16 900-2355-00 Adapter SOG 1912 1
17 900-2526-00 Adapter SOG 1916 G1" 1
18 900-2683-00 Adapter G1/8" G1/4" 1

241
700-2861-901 REV - 7
14
1
15
14
2 13
11
12
10
17
16
12
10

242
700-2861-901 REV - 7
PARTS LIST
9 841.0077-00 SCREW UC6S 1/2UNCX45 12.9 8
10 847.0258-00 WASHER NL M12 8
12 900-2378-00 FLANGE HALF SAE 6000 1 1/4 4
13 900-2413-00 T-ADAPTER TOO 1363 1
14 900-2431-00 ADAPTER SOG 1306 2
15 900-2450-00 ADAPTER WOG 1308 1
16 900-2533-00 CONNECTION TOG 1308 1

243
700-2867-901 REV - 2
9 8 5
1
6 7 7 4
3 6 7

244
700-2867-901 REV - 2
PARTS LIST
1 649-0188-07 M10 X 85 DN64 U-Bolt 1
2 700-1293-901 SUCTION TUBE 1
4 840.0037-00 SCREW M6S 10X35 8.8 2
5 841.0077-00 SCREW UC6S 1/2UNCX45 12.9 4
6 845.0213-00 LOCK NUT M10 8 FZB 4
7 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 6
8 847.0258-00 WASHER NL M12 4
9 873-1295-00 O-ring 214-40 1

245
700-2868-901 REV - 2.
9 8 5 4 3 7 6
2 1 7 6

246
700-2868-901 REV - 2.
PARTS LIST
1 453-4081-90 SUCTION PIPE CM1208H 1
2 649-0188-07 M10 X 85 DN64 U-Bolt 1
4 840.0037-00 SCREW M6S 10X35 8.8 2
5 841.0077-00 SCREW UC6S 1/2UNCX45 12.9 4
6 845.0213-00 LOCK NUT M10 8 FZB 4
7 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 6
8 847.0258-00 WASHER NL M12 4
9 873-1295-00 O-ring 214-40 1

247
Air Cleaner Assembly
BG01387007 REV - B
B
14
16 22 8
B
14
18 13
*
7
21
4 6 3 19
15 2 5
17
9
1
22
ASSEMBLY NOTE: 20
DIRECTION ARROW 14
22
POINTS AWAY FROM
AIR CLEANER B 12
11
10
22
ASSEMBLY NOTE:
ADJUST PIPE WORK TO
ENSURE MAXIMUM
CLEARANCE WITH
ADJACENT ENGINE BLOCK

248
Air Cleaner Assembly
BG01387007 REV - B
PARTS LIST
1 703-0561-001 SCAVENGE PIPE - VOLVO STAGE 4 1
2 840.0020-00 SCREW M6S M8X16 8.8 ZP 4
3 840.0045-00 SCREW M6S 12x30 ZP 8.8 FT 4
4 845.0030-00 LOCK NUT M12 8 FZB 2
5 847.0012-00 WASHER BRB 8,4X16 HB200 4
6 847.0147-00 WASHER BRB 13,5x24 HB200 6
9 958-1265-00 PRESSURE SENSOR VOLVO/CAT. 1
10 958-1276-00 CLAMP CT-450L 1
11 BG01387008 Pipe, Air Cleaner 1
12 BG01387009 Pipe, Air Cleaner 1
13 BG01430464 Pipe, Air 1
14 BG01526174 Clamp, Hose 3
15 EN10271 Air filter unit, end cover 1
16 EN10272 AIR FILTER PRE-CLEANER RAIN CAP 203DIA 1
17 EN10360 VOLVO AIR SWITCH ADAPTOR 1
18 EN10383 DONALDSON FRG2 AIR CLEANER 1
20 EN9899 DONALDSON 50-50MM EJECTOR CHECK VALVE 1
21 EN9989 VOLVO D13 SCR PRIMARY INDICATOR SENSOR 1

249
Aftertreatment Assembly
BG01387011 REV - B
7 7 7
23 9 9 9
21 22 4 3 11 5 24
18
17
25
2 9 7
20 13 16
9 1
15
19
26
10
25 14 22 21 6 8 12
23

250
Aftertreatment Assembly
BG01387011 REV - A
PARTS LIST
1 840.0045-00 SCREW M6S 12x30 ZP 8.8 FT 3
2 840.0047-00 SCREW M6S M12X40 8.8 ZP 2
3 840.0049-00 SCREW M6S M12x50 8.8ZP 4
4 840.0054-00 SCREW M6S M12X80 8.8 FZB 2
5 840.0055-00 SCREW M6S 12X90 8.8 2
6 840.0068-00 SCREW M6S M16x50 8.8 ZP 7
7 845.0030-00 LOCK NUT M12 8 FZB 10
8 847.0016-00 WASHER BRB 17x30 HB200 7
9 847.0147-00 WASHER BRB 13,5x24 HB200 23
10 900-2781-00 U-Bolt - M8 - 138 C/C - 125mm Leg Length 1
13 BG01387465 Bracket, Support 1
14 BG01387472 Pipe, Exhaust 1
15 BG01387477 Volvo Muffler Mounting Kit 1
16 BG01387480 Volvo Muffler EATS A700 1
17 BG01387481 Volvo Dosage Valve 1
18 BG01387803 Pipe, Exhaust 1
19 BG01465390 Plate, Deflector 1
20 EN10534 V-BAND CLAMP 1
21 EN10536 V-CLAMP 2
22 EN10537 FLANGE SCREW 2
23 EN10538 FLANGE NUT 2
24 EN10539 TEMPERATURE SENSOR 1
25 EN10540 NOX SENSOR 2
26 EN9683 RAIN CAP 1

251
CANOPY ASSEMBLY
BG01388102 REV - B
16 24 5 30 14
3
8 16 24
29
12 36
9 20 26 6 33 35 34
17 13 18
25 2
10
4
22
2
34 35 33
4
34 35 33 6
32
21 27 19 11 7

252
CANOPY ASSEMBLY
BG01388102 REV - B
PARTS LIST
1 700-8677-901 EDGE TRIP 1
2 700-8678-901 RETAINER-PUSH ON STEEL-SIZE 9. 1
3 700-9065-901 RECEPTACLE-CLIP ON-SIZE 9. 1
4 700-9386-001 STUD - HEX RECESS HEAD - SIZE 9x16. 1
5 700-9415-001 Door Assembly 1
6 700-9552-001 Plate, Cover 2
7 700-9573-901 CANOPY ENGINE HOOD FABRICATION 1
8 700-9661-001 800N GAS STRUT - ASSEMBLY 2
9 700-9834-001 WASHER BRB 6,4X12 HB200 1
10 703-0030-501 WASHER BRB 13,5x24 HB200 1
11 703-0530-501 WASHER BRB 10.5x22 HB200 ZP 1
12 703-0532-901 WASHER BRB 10x18 HB200 SS70 1
13 703-0583-001 WASHER BRB 8,4X16 HB200 1
14 703-0982-901 NUT LOCK ISO 7040 M6 8 FZB 1
15 840.0017-00 LOCK NUT M8 8 FZB 1
16 840.0021-00 LOCK NUT M12 8 FZB 10
17 840.0023-00 SCREW M6S 10x65 8.8 2
18 840.0024-00 SCREW M6S M12X40 8.8 ZP 2
19 840.0047-00 SCREW M6S 8x30 8.8 8
20 840.0543-00 SCREW M6S M8X25 8.8 ZP 8
21 845.0030-00 SCREW M6S M8x20 8.8 8
22 845.0205-00 SCREW M6S 6x60 8.8 ZP 2
23 845.0217-00 RADIATOR GUARD ASSEMBLY 1
24 847.0012-00 EJECTOR CHECK VALVE BRACKET 12
25 847.0013-00 ASSEMBLY OF BATTERY BAY DOOR 4
26 847.0144-00 OMKA CANOPY FABRICATION 8
27 847.0147-00 DOOR LOCKOUT ASSEMBLY 16
28 847.0164-00 UH OMKA TOP COVER PLT 2
29 BG01306680 VENT PANEL 2
30 BG01388091 ASSEMBLY OF DOOR. 1
31 BG01388097 TIER 3B PP CANOPY COVER PLT 1
32 BG01529229 L8 BOX BRACKET 1
33 FA9113 REMOTE OIL FILTER TRAY 12
34 FA9115 ASSEMBLY OF DRIVE BELT GUARD COVER. 12
35 FA9116 ASSEMBLY OF TIER 3B LOWER DOOR. 12
36 RU5202 ASSEMBLY OF TIER 3B TOP DOOR. 1

253
Cover Assembly
BG01390210 REV - B
4 4 4 4
3 2 5 7 2 6 1 4 3
4 3

254
Cover Assembly
BG01390210 REV - B
PARTS LIST
1 840.0021-00 SCREW M6S M8x20 8.8 4
2 840.0023-00 SCREW M6S M8X25 8.8 ZP 6
3 840.0031-00 SCREW M6S 8X70 8.8 23
4 847.0012-00 WASHER BRB 8,4X16 HB200 33
5 BG01387868 Cover, Inspection 1
7 FD7056 DOOR LATCH E3-16-25 (GRIP 52.5-68MM) 1

255
Cover Assembly
BG01469045 REV - B
1 2
1 2

256
Cover Assembly
BG01469045 REV - B
PARTS LIST
1 840.0023-00 SCREW M6S M8X25 8.8 ZP (USE 840.0023-00) 7
2 847.0012-00 WASHER BRB 8,4X16 HB200 ISO 7089 (USE 847.0012-00) 7

257
703-0626-901 REV - 04
9 11 4
8 12
10 12 6
12 5

258
703-0626-901 REV - 04
PARTS LIST
3 703-0624-901 TOP LIGHTING POLE ASSEMBLY 1
4 840.0031-00 SCREW M6S 8X70 8.8 1
5 840.0035-00 SCREW M6S 10X25 8.8 3
6 840.0043-00 SCREW M6S M10X90 8.8 ZP 2
7 843.1495-00 EYE BOLT M10x50. 1
8 845.0006-00 NUT M6M M10 8 FZB 1
9 845.0205-00 LOCK NUT M8 8 FZB 1
10 845.0213-00 LOCK NUT M10 8 FZB 2
11 847.0012-00 WASHER BRB 8,4X16 HB200 2
12 847.0144-00 WASHER BRB 10.5x22 HB200 ZP 8

259
703-0624-901 REV - 04
4 8 11 6
18
7 10 9
12
19


260
703-0624-901 REV - 04
PARTS LIST

4 700-0894-001 PLATE 1
6 703-0625-001 THREADED BAR - M6 2
7 840.0004-00 SCREW M6S 5X20 8.8 4
8 845.0217-00 NUT LOCK ISO 7040 M6 8 FZB 4
9 845.0218-00 LOCK NUT M5 8 4
10 847.0010-00 WASHER BRB 5,3x10 8
11 847.0164-00 WASHER BRB 6,4X12 HB200 4
12 900-1136-00 TUBE CLAMP RSGU 1100 10/12 4
13 960-0555-00 CABLE OLFLEX 400 P 2X1,5 1
14 960-0558-00 CABLE OLFLEX 4X1.5 1
15 964-1581-00 NUT 15,2 PLASTIC 4
16 964-1691-00 GLAND 15,2 SKINTOP-ST9 4
Replaces 970.0179-00 / 970.0178-00
18 BG01640672 Light, Unit 1 970.0177-00 / EL10309 Lights

261
Emergency Stop Assembly
BG01685305 REV A
Emergency Stop Assembly
BG01685305 REV A

1 841-0220-00 Screw, Socket Head, Hexagon 4
3 847-0011-00 WASHER BRB 6,7X14 HB200 SS70 8
5 BG01590331 Guard 1
Magnet Assembly
700-3920-901 - REV 7
13
12 7 12 9
14 7
12
4
12
11 10
8
11 6
1
Magnet Assembly
700-3920-901 - REV 7
PARTS LIST
1 700-6170-901 SUPPORT BRACKET - R.H. 1
2 700-6173-901 SUPPORT BRACKET - L.H. 1
3 700-7820-001 Plate, Guide 2
4 700-7821-001 Plate, Guide 2
5 703-0160-501 Chute, Discharge, Magnet 1
7 840-0078-00 SCREW M6S 20x60 8.8 ISO 4014 (USE 840.0078-00) 4
8 840-0634-00 SCREW M6S M16X25 8.8 ZP 4
13 BG01307567 MAGNET SUPPORT ASSY 1
14 MA2037 Magnet Assembly 1
MAGNET SUPPORT ASSY
BG01307567 - REV A
12
2
4
5
2 4
2
12
2
7
1
9
11
11
6
10
10
8
8
6
10
10
3
MAGNET SUPPORT ASSY
BG01307567 - REV A
PARTS LIST
1 700-6171-901 MAGNET SUPPORT FABRICATION. 1
2 700-7186-001 Chain Wheel 4
3 700-7784-001 Plate, Guide 2
4 700-9545-901 Chain, Lifting, Magnet 2
5 700-9546-901 Chain, Lifting, Magnet 2
7 840-0700-00 SCREW M6S M30X180 8.8 ZP (USE 840.0700-00) 4
12 877-0316-00 TURNBUCKLE M20 M CLAMP 1480 2
UJ440i_UHUS440i_SPC_Powe
Strickland Tracks
UJ440i / UH/US440i © Strickland Tracks Ltd. 1

22
Strickland Tracks
PARTS LIST
ITEM PART No(Strckland) ITEM NAME QTY(per track) QTY(per pair)
010 FDM785-GD201AJ Track Drive Gear Box c/w Hydraulic Motor 1 2
020 BHM 524200090-12 Socket Head Capscrew - Torque 1160 Nm (855 lbs/ft) 20 40
030 MOT0AJ-FDMOTOR Fixed Displacement Hydraulic Motor 1 1
040 FDG CAR-DRNPLG Oil Fill Drain Plug 2 4
050 POL 00280W/90-0 Gear Oil SAE 80W/90 10 lit 10 lit
060 N/A Brake Release Stand Off Pipe N/A N/A
070 FMVA04-BM 16mm Brake Release Adaptor 1 1
080 FMV16M-MDBS Brake Release Seal 1 2
090 SPA 500-DNGD22 Drive Sproket 1 2
100 BHM 524200080-12 Socket Head Capscrew - Torque 1160 Nm (855 lbs/ft) 20 40
110 LRG 000SC60A-A Single Flanged Lower Roller 12 24
120 BHM 016200100-0 Hex Head Bolt - Torque 314Nm ( 232 lbs/ft) 48 96
130 WFH 019-2 Hardened Washer 48 96
140 IDG 660550-A Front Idler Group 1 2
150 IDY 913-8-HD Idler Yoke 1 2
160 BHM 016200045-0 Hex Head Bolt - Torque 314Nm ( 232 lbs/ft) 4 8
170 WSH 015-2 Spring Washer 4 8
180 TRG 094-2-4268 Elastomer 1 2
190 TLG 080-9 Grease Gun Adaptor N/A N/A
200 MMP 094-2-4268 Tension seal Kit 1 2
210 TG-0942-RH9-3SL-500 Track Group 1 2
220 TCA 07152-0 Track link Assembly 1 2
230 TBG 026500-34-0 Track Shoe (500mm wide triple grouser) 52 104
240 TSB 025-6 Track Shoe Bolt - Torque 620 Nm ( 457 lbs/ft) 208 416
250 TSN 016-3 Track Shoe Nut 208 416
260 TSL 105-8 Track Repair Link Kit N/A N/A
270 MPG 3102-5 Master Pin and Collars 1 2
Note: For more details on Parts Breakdown Please refer to EXPLODED VIEW: 008

23
Strickland Tracks
DN425L-GD201AJ-DT00
2. Required Connections
Highlighted below are the main connections required to operate the track drive.
A & B. l>fain Flow Ports
Conne«ions. 1-1/4" SAE
3. Hydraulic Schematic 4. Direction of Rotation

Below is the general hydraulic circuit diagram for the When connecting to the track drives, it is
track drive gearbox and fixed displacement motor important to check that the direction of rotation
combination with no motion control and brake corresponds to forwards movement of the
release valve fitted. machine, when the drives are positioned at the
rear of the machine.
The diagram above shows the direction of

rotation of the track drive in relation to the input
Directional Control Valve from
flow to motor.
Madline

24
Strickland Tracks
DN425F-GD201AJ-DT00
5. Hydraulic Port Description and Sizes
T, Motor Case
Drain Port
F. Gearbox Brake
Release Port
Flow Ports
Ports Size on Gearbox and Motor

A & B, Motor Main Flow Ports 1-1/4" SAE
T, Motor Case Drain Port M18 x 1.5
F. Gearbox Brake Release Port M16 x 1.5
6. Hydraulic Specifications
O=ratina Pressures / Flows
Maximum Continuous Pressure 345 bar
Maximum Pem1issible Case Drain Pressure at Port T 2 bar
(Min} 18 bar
Brake Release Pressure
{Max) 100 bar
(Min} NIA
Variable Speed Control Pressure at Port X
(Max} NIA
Maximum Oil Inlet Flow through Ports A & B 4551/min
Gearbox Oil Tvoe, Volume and Ooeratinq Temo,rature
Oil Tvoe SAE80W/90
Oil Volume 10L per Gearbox
Minimum On<>ratina temoerature of Oil -25'c
Maximum Ooeratina temn<>rature of Oil 90 ° c
7. Hydraulic Filtration and Cleanliness

Before connecting track drives to hydraulic circuit, ensure all pipes are removed and flushed through with the
hydraulic system prior to connection.
To ensure proper function of hydraulic motor, the filtration of pressure fluid must provide a cleanliness level
of at least: 20/18/18 according to ISO 4406.

25
U-RANGE TELEMATICS INSTALLATION ASSY.
703-1105-901 REV - A
2 4 5 3

290
U-RANGE TELEMATICS INSTALLATION ASSY.
703-1105-901 REV - A
PARTS LIST
1 20-30-0009 9MM SPLIT FLEX CONDUIT 1
2 840.0015-00 SCREW M6S 6x35 8.8 2
3 845.0217-00 NUT LOCK ISO 7040 M6 8 FZB 2
4 847.0164-00 WASHER BRB 6,4X12 HB200 4
5 BG01237412 U-RANGE TELEMATICS KIT (UJ440/UH440/US440) 1

291
CM8H UJ440i High Pressure Water System Assy
700-2001-00 REV - 7
13 16 2 28 37 4 31 20 34
38
15
42
18
46 14
20 11
19
A(0.040)
5 9
A
SPRAY BAR ON
MAIN CONV 20 31
28
34
46
11 31
20
34 42
18
38 20 38
42 15
A
46 B(0.040)
SPRAY NOZZLE
E(0.040) TOP OF JAW
SPRAY NOZZLE
BOTTOM OF JAW
B
30
E
47
6
E 41 48
52
C 49
19
14
50 C D
35
36
6 43
22
8 44
23
33 24 26
25
39 27
12 17 10 21
32 7 40
51
9 33 29 45
D(0.040) 1
C(0.040) 19
14

292
CM8H UJ440i High Pressure Water System Assy
700-2001-00 REV - 7
PARTS LIST
1 10-21-0003 1" SUCTION FILTER 1
2 649-0188-03 M8 X 50 U-BOLT 2
3 700-2050-001 Bracket 2
4 700-2051-901 Pipe Assembly 1
5 700-2056-001 Cover HPWS 1
6 700-2092-901 HIGH PRESSURE WATER SPRAY, HYDRAULICS 1
7 703-0694-001 BRACKET FOR HIGH PRESSURE WATER SYSTEM 1
8 703-1005-001 SUPPORT PLATE 1
9 840.0037-00 SCREW M6S 10X35 8.8 8
10 840.0048-00 SCREW M6S M12X45 8.8 ZP PT 2
11 840.0573-00 SCREW M6S M5x60 GR 8.8 4
12 845.0030-00 LOCK NUT M12 8 FZB 2
13 845.0205-00 LOCK NUT M8 8 FZB 4
14 845.0213-00 LOCK NUT M10 8 FZB 8
15 845.0218-00 LOCK NUT M5 8 4
16 847.0012-00 WASHER BRB 8,4X16 HB200 4
17 847.0147-00 WASHER BRB 13,5x24 HB200 4
18 847.0164-00 WASHER BRB 6,4X12 HB200 8
19 847.0337-00 WASHER BRB 10,5x20 HV200 ZP 16
20 873-0382-00 BONDED SEAL - G 1/4 8
21 900-0623-00 SLANGKOPPLING 1801-12 G3/4" 1
22 900-0652-00 ADAPTER M/M G1/4B x G1/4B 4
23 900-0655-00 Adapter 3/4" 1
24 900-2041-00 ADAPTER ST G3/4B x G3/4 2
25 900-2057-00 Coupling KLO-NI 19 3/4" 913061 1
26 900-2058-00 Coupling KLO-UG R3/4" 913061 1
27 900-2113-00 ADAPTER G 3/4 BXG 3/4 1
28 900-2234-00 CLAMP SP322 PP-DP-AS STAUF 4
29 900-2352-00 ADAPTER SOG 1104 G1/4B 1
30 900-2353-00 Adaptor SOG 1106 G3/8B. 1
31 900-2432-00 ADAPTER SOG 0904 G1/4B 3
32 900-2436-00 ADAPTER LOO 0959 3
33 900-2437-00 ADAPTER SSO 5459 5
34 900-2475-00 ADAPTER SOCKET G1/4 4
35 900-2553-00 ADAPTER WOG 0904 G1/4B 3
37 900-2571-00 ADAPTER TOG 0904 1
38 900-2577-00 Adapter G1/4" - R1/4" 203-04 4
39 900-2705-00 ADAPTER BOO 0909 4
40 900-2848-00 Adapter, Hydraulic 2
41 900-2849-00 HP WATER HOSE REEL 1
42 900-2850-00 COUPLING S.S.CO 11430-BSPT 4
43 902-1018-00 BALL VALVE MHA GERMANY BKH 4
44 906-0547-00 Pump Assembly, Water 1
45 912-0285-00 Filter, Suction 1
46 958-1295-00 NOZZLE 7890 11/16-16 SSP 4
47 958-1297-00 WATER SPRAY PISTOL 1
48 958-1298-00 LANCE (Water spray gun) 1
49 958-1299-00 NOZZLE (Water spray gun) 1
50 964-2433-00 CONNECTOR 2X0,75 Incl LED L=5M 1
51 HA03400030 3/4" - 1" BSP Male/Male Adaptor 1
52 HHK0187 UJ440I HOSE KIT - HPWS SYSTEM 1

293
Hanging Screen, Complete (PREP. FOR BOOM OPTION)
703-1017-901 REV - 1
10
3 2
8
11
7 9

294
Hanging Screen, Complete (PREP. FOR BOOM OPTION)
703-1017-901 REV - 1
PARTS LIST
1 700-3143-901 Counterbalance Assy 1
2 700-3322-901 Rubber Curtain Assembly 1
3 700-3337-901 Steel Cable Assy 2
4 700-3692-901 Hanging Screen, Base Unit 1
5 700-6041-901 Electrical Kit 1
6 703-0049-901 CONVEYOR ASSEMBLY B4XL 1
7 703-0051-901 Steel Cable Assy 1
8 703-1035-901 STEEL CABLE ASSY 1
9 843-1613-00 BOLT WITH CHAIN 19X112 2
11 HHK0083 HANGING SCREEN HOSE KIT (OPEN CIRCUIT) 1

295
BOOM & HANGING SCREEN OPTION
703-1038-901 REV - 1.
11 15 14 18 12
1
16 9
A(0.020)
7
20 13
4 B(0.020)
C 13 16
22
19 10
A
5
10
21
B
2 6
17 8
C(0.020)

296
BOOM & HANGING SCREEN OPTION
703-1038-901 REV - 1.
PARTS LIST
1 703-0586-501 UJ440I HAMMER SUPPORT 1
2 703-0933-501 PARKING BRACKET 1
3 703-0934-501 TRANSPORT BRACKET 1
4 703-0935-901 HAMMER INSTALLATION - ELECTRICS 1
5 703-0936-901 HAMMER INSTALLATION - HYDRAULICS 1
6 703-1017-901 Hanging Screen, Complete (PREP. FOR BOOM OPTION) 1
7 703-1018-901 SUPPORT BRACKET 1
8 840.0066-00 SCREW M6S M16x40 8.8 FZB 4
9 840.0070-00 SCREW M6S 16x60 8.8 ZP 2
10 840.0080-00 SCREW M6S 20X80 8.8 15
11 840.0640-00 SCREW M6S 16X150 8,8 ZP 3
12 840.0669-00 SCREW M6S M24X70 8.8 ZP 12
13 845.0203-00 LOCK NUT M20 8 FZB 12
14 845.0215-00 LOCK NUT M16 8 FZB 5
15 847.0016-00 WASHER BRB 17x30 HB200 6
16 847.0069-00 WASHER HRSB 21x50x4 SPECIAL 14
17 847.0120-00 WASHER TBRB 17X30 4
18 847.0124-00 WASHER BRB 25x45 HB200 ZP 12
19 847.0359-00 WASHER BRB 21x37 HB200 17
20 BG00786238 Hammer Boom 1
21 BG00786239 Hydraulic Hammer BR777 c/w Moil Point Tool BJ803 1
22 HHK0295 UJ440I - BOOM OPTION HOSE KIT 1

297
JAW AUTOMATIC GREASING OPTION
BG01497781 REV - A.
900-2223-00 ADAPTERS
FITTED TO JAW
VALVE BLOCK
PART OF 906-0513-00
FITTED TO BRACKET
ON JAW
2 1

298
JAW AUTOMATIC GREASING OPTION
BG01497781 REV - A.
PARTS LIST
1 840.0573-00 SCREW M6S M5x60 GR 8.8 2
2 847.0164-00 WASHER BRB 6,4X12 HB200 2
3 900-2223-00 AF/MB06-FB04 ADAPTER M/M G3/8B x G1/4B 4
4 906-0513-00 LINCOLN QUICKLUBE GREASE PUMP 1
6 CN6073 ALBIDA EP2 GREASE 12.5KG TIN 1

299

UJ440

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

UJ440

Uploaded by

Copyright:

Available Formats

Original Instructions

uK440i Spare Parts Book

Spare Parts Book

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Crusher Installation - Standard build Option

4 POS( 2 EACH GUARD)

2 POS(1 EACH GUARD)

4 POS(2 EACH GUARD) 15 17 10 17

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology

Copyright © Sandvik Mining & Rock Technology
