Intro: Breadboard How To
This instructable will guide someone with no experience in electronics through prototyping their first circuits on a breadboard. You will need a few basic components to
get started:
LED: white , red , green , blue
220 resistor
5V power supply/battery/arduino board
solderless breadboard
22 gauge solid core jumper wire - It's a good idea to get many colors of wire (esp black and red) so that you can keep your breadboard organized.
Step 1: The Basics
The purpose of the breadboard is to make quick electrical connections between components- like resistors, LEDs, capacitors, etc- so that you can test your circuit before
permanently soldering it together. Breadboards have many small sockets on them, and some groups of sockets are electrically connected to each other. On the
underside of the board there are many small metal strips which physically connect certain groups of sockets together and allow electricity to flow freely between them.
These strips are probably not visible on the underside of your breadboard, but the third picture shows how they are organized.
Breadboards are usually divided into four sections, two outer sections and two inner sections. Each row of five sockets in the inner sections are electrically connected to
each other (see the blue lines in figure 3). The two outer sections of the breadboard are usually used exclusively for power. On many breadboards these sockets will be
labeled with colors denoting positive voltage (usually red) and ground (black or blue). There is nothing special about the outer sections of the breadboard that makes
particularly suitable for power other than that they run the length of the board, but if you choose to use these rows for other things you may confuse others or even
yourself, so it is good practice to use these for power only.
[Link]
Step 2: Getting Started
The first thing to do is send power to the breadboard. Breadboards do not have their own power supply. Some breadboards come with a power supply attached, but it is
usually not connected directly to the power lines on the breadboard.
Power supplies come in many shapes and sizes, you may have to dial in the voltage or your power supply may only let you chose from one or a few types voltage levels.
For this tutorial (and for many of your future projects) we will be using 5V DC power. This means that you will make two connections to your power supply, +5 and
ground.
Alternative power supplies:
-use the +5 volt and GND (ground) pins of an arduino (you must plug the arduino into a computer or wall socket via usb first)
-battery- will require an attachment to connect to your breadboard
Connect ground and +V to one side of your breadboard as shown in figure 2. Many breadboards separate each of the two power rows into two sections (electricity cannot
flow across the center of the board), so you'll need to connect these groups with jumper cables to ensure that power is being sent across the length of the board (see
figures 5 and 6). Figure 6 shows a breadboard with power on across its entire length and on both sides.
Now the breadboard is powered. Convince yourself by using a multimeter to measure the voltage of any of the sockets in the power lines of the board.
[Link]
[Link]
Step 3: Hello World!
Your first circuit will turn an LED on. The circuit diagram is given in figure 2; it includes an LED and a resistor connected in series to power. I posted an alternate
schematic (figure 3) to demonstrate that it does not matter which order the LED and resistor are connected, as long as they close a circuit between 5V and ground.
The resistor is there to prevent too much current from going through the LED; we call it a "current-limiting resistor." If you connect an LED to your 5V power supply
directly it will most likely burn out, this may be accompanied by a cracking sound, a smell, smoke, or even a small explosion, so be careful!
I'm using a 1/4 watt 220ohm resistor for my current limiting resistor, if you know the specs of your LED you can find the best resistor value for your circuit using an online
LED calculator. Using too much resistance in this circuit will never damage the LED, it will just glow slightly dimmer, but anything between 200 and 1000ohms should be
fine.
Electric current always runs from high voltage to ground in a circuit. Some components only work when current flows through them in one direction (and they may even
be damaged by wiring them backwards). As the first images indicate, LEDs must be wired so that current flows from the anode (the longer lead) to the cathode (the
shorter lead). Resistors do not have directionality, this mean that you can flip a resistor around in a circuit and it will behave exactly the same.
While you are putting components into your breadboard it is a good idea to turn off the power to the board; this prevents accidental short circuits which may burn out
parts.
STEPS:
-connect the anode of the LED to +5V and the cathode to a row of pins in the middle section of the breadboard (figure 5)
-connect one resistor lead to ground and the other lead to a pin in the same row as the LED cathode (figure 6)
-connect power to the board- the LED should light up
As you can see, connecting the LED and the resistor to the same row of sockets on the breadboard created an electrical connection between these two components.
[Link]
Image Notes
1. LED
2. resistor
3. this is the schematic I used
Image Notes
1. battery
2. resistor
[Link]
Step 4: 7 Segment Display on a Breadboard: Part 1
This project is a little more challenging, but the idea is basically the same as the last circuit.
Parts List:
7 segment display (common cathode)
7x150ohm resistors
4x10kohm resistors
4511 decoder chip
A 7 segment display is a component that contains 7 rectangular LEDs (we'll ignore the DP LED for now) arranged so that they can display the numbers 0-9 (see figure 2).
Each of the LEDs in the display are connected to a common cathode. By looking at the diagram at the bottom of figure 2, we can see that pins 1, 2, 4, 6, 7, 9, and 10
each connect to an anode of one of the seven LEDs and pins 3 and 8 both connect to the common cathode (see the bottom diagram in figure 2).
As in the last circuit, we need to use current limiting resistors to prevent damaging the LEDs in the display. In this step we will wire 7 current limiting resistors and
individually control the 7 LEDs.
The first step is to calculate the resistance we need for the current limiting resistors.
From the 7 segment display datasheet: each LED has a forward voltage of 2.2V at 25mA of current.
Using Ohm's Law (V=IR) we can calculate our current limiting resistance as follows:
2.2V = 0.025 A * R
R = 88ohms
to be safe we won't run the LEDs at their maximum power ratings, so we'll use 150ohm resistors.
Wiring Steps:
-again, disconnect power to your breadboard to avoid damaging your components
-press the 7 segment display into breadboard so the it straddles the center section of the board (figure 1)
-connect one of the common cathode pins of the display (pins 3 or 8) to ground (figure 3)
-connect power across to the other side of the board (figure 4)
-insert 7 current limiting resistors onto breadboard so that they connect pins 1, 2, 4, 6, 7, 9, and 10 to 5V (figure 5)
-turn on power (figure 6)
Your 7 segment display should light up to display the number "8." Experiment with disconnecting some of the jumper wires between the current limiting resistors and the
display to make other numbers/letters; I made the letter "E" in the last image by disconnecting pins 4 and 6 on the display.
[Link]
Image Notes
1. pin numbers
[Link]
Step 5: 7 Segment Display on a Breadboard: Part 2
In this step we will use a chip called a 4511 binary to 7 segment decoder to make displaying numbers on the 7 segment display much more simple. This chip connects to
the 7 segment display so that when we give it a binary number input (0000-1001), it will output the base ten value (numbers 0-9) on the display.
The pin configuration of the 4511 is given in the datasheet , and I've copied it in figure 2. Notice how pin numbering starts at 1 at the top left of the chip (indicated with a
semicircle or sometimes a dot) and wraps around the outside of the chip until ending at 16 in the top right.
Wiring Steps:
-disconnect power to the board
-put the 4511 on the breadboard so that it straddles the middle section of the board (figure 4)
-disconnect the 5V connections of the 150ohm resistors and connect to 4511 pins Qa-Qg. You will probably need to use jumper wires to extend these connections (green
wires in figures 5, 6, and 7). Pin numbering/letters are given in the diagram at the bottom of figure 3 for the display and in figure 2 for the 4511.
-use four 10kOhm resistors to create a connection between the 4511 input pins (1, 2, 6, and 7) and four spare rows on the breadboard (figure 8)
-connect 5v to 4511 pins 3, 4, and 16 (red wires in figure 9)
-connect ground to 4511 pins 5 and 8 (black wires in figure 10)
-connect the free ends of the 10kohm resistors to ground (red wires in figure 11)
-power on, you should see the number 0 (figures 12 and 13)
Try connecting the 4511 input pins (red wires connected to 10kOhm resistors to 5V to make different numbers. Here is a table that shows you how to convert from binary
to decimal:
[Link]
D0(pin 7) D1(pin 1) D2(pin 2) D3(pin 6) decimal
00000
10001
01002
11003
00104
10105
01106
11107
00018
10019
So if you connect D0 to 5V and D1-3 to ground you should see a 1(figure 14)
D0 and D1 to 5V and D2 and D3 to ground gives a 2 (figure 15)
Troubleshooting:
Since there are so many connections, it is easy to make a small mistake that causes the whole project to malfunction. If the display is not lighting up at all: check to see if
all your components are powered and are connected in the correct orientation. If it is on but displaying nonsense: carefully check the schematic and make sure your
connections between pins a-g are correct.
I've also attached a fritzing document for this circuit for your reference, find it below.
