C:\FreePCB\lib\sm_sot.

pdf page 1

SOT23 Scale 2:1


Author: Ivex
Size: 140 x 168 mil

PAD
PIN(s)
TYPE SHAPE SIZE HOLE
1-3 SMT Rect 40 x 48 mil ---

RSOT-23 Scale 2:1


Author: Ivex
Source: SIEMENS PACKAGE INFORMATION DATA BOOK 1.93
Size: 3.2 x 2.9 mm

PAD
PIN(s)
TYPE SHAPE SIZE HOLE
1-3 SMT Rect 0.8 x 0.9 mm ---

WSOT-23 Scale 2:1


Author: Ivex
Source: SIEMENS PACKAGE INFORMATION DATA BOOK 1.93
Size: 3.4 x 4 mm

PAD
PIN(s)
TYPE SHAPE SIZE HOLE
1-2 SMT Rect 1.3 x 1.5 mm ---
3 SMT Rect 1.6 x 1.5 mm ---

RSOT-89 Scale 2:1


Author: Ivex
Source: SIEMENS PACKAGE INFORMATION DATA BOOK 1.93
Size: 4.5 x 4.15 mm

PAD
PIN(s)
TYPE SHAPE SIZE HOLE
1 SMT Rect 0.8 x 1.2 mm ---
2 SMT Rect 0.8 x 2.4 mm ---
3 SMT Rect 0.8 x 1.2 mm ---

WSOT-89 Scale 2:1


Author: Ivex
Source: SIEMENS PACKAGE INFORMATION DATA BOOK 1.93
Size: 4.5 x 4.15 mm

PAD
PIN(s)
TYPE SHAPE SIZE HOLE
1 SMT Rect 0.8 x 1.5 mm ---
2 SMT Rect 0.8 x 2.4 mm ---
3 SMT Rect 0.8 x 1.5 mm ---
C:\FreePCB\lib\sm_sot.pdf page 2

RSOT-143 Scale 2:1


Author: Ivex
Source: SIEMENS PACKAGE INFORMATION DATA BOOK 1.93
Size: 3 x 2.9 mm

PAD
PIN(s)
TYPE SHAPE SIZE HOLE
1 SMT Rect 1.2 x 0.9 mm ---
2-4 SMT Rect 0.8 x 0.9 mm ---

WSOT-143 Scale 2:1


Author: Ivex
Source: SIEMENS PACKAGE INFORMATION DATA BOOK 1.93
Size: 3.4 x 4 mm

PAD
PIN(s)
TYPE SHAPE SIZE HOLE
1 SMT Square 1.5 mm ---
2-4 SMT Rect 1.3 x 1.5 mm ---

RSOT-223 Scale 2:1


Author: Ivex
Source: SIEMENS PACKAGE INFORMATION DATA BOOK 1.93
Size: 6.5 x 7.6 mm

PAD
PIN(s)
TYPE SHAPE SIZE HOLE
1-3 SMT Rect 1.2 x 1.4 mm ---
4 SMT Rect 3.5 x 1.4 mm ---

WSOT-223 Scale 2:1


Author: Ivex
Source: SIEMENS PACKAGE INFORMATION DATA BOOK 1.93
Size: 6.5 x 8.2 mm

PAD
PIN(s)
TYPE SHAPE SIZE HOLE
1-3 SMT Rect 1.4 x 1.7 mm ---
4 SMT Rect 4 x 1.7 mm ---

RSOT-323 Scale 2:1


Author: Ivex
Source: SIEMENS PACKAGE INFORMATION DATA BOOK 1.93
Size: 2 x 2.9 mm

PAD
PIN(s)
TYPE SHAPE SIZE HOLE
1-3 SMT Rect 0.6 x 0.8 mm ---
C:\FreePCB\lib\sm_sot.pdf page 3

WSOT-323 Scale 2:1


Author: Ivex
Source: SIEMENS PACKAGE INFORMATION DATA BOOK 1.93
Size: 2.2 x 3.7 mm

PAD
PIN(s)
TYPE SHAPE SIZE HOLE
1-3 SMT Rect 0.8 x 1.2 mm ---
