L914D1003

TABLE OF CONTENTS LH514 190730

12. BOOM / BUCKET HYDRAULICS

* BG00349235 HYDRAULICS, BUCKET ............................................................................................................................................. 2
** 56023866 HYDRAULICS, BUCKET ............................................................................................................................................... 4
*** 56019399 ADAPTER ASSEMBLY ............................................................................................................................................. 6
** BG00373907 VALVE ASSEMBLY - BUCKET/BOOM MAIN VALVE ................................................................................................................ 8
*** BG00375473 VALVE, DIRECTIONAL ........................................................................................................................................ 10
** BG00361439 BLOCK ...................................................................................................................................................................... 12
** BG00567531 CYLINDER ................................................................................................................................................................ 14
** BG00506737 CYLINDER, TILT ...................................................................................................................................................... 16
*** BG00959954 PIPING - TILT CYL. NEW SEALS ............................................................................................................................................ 18
* BG00353725 SUSPENSION, BOOM ................................................................................................................................................. 20
** BG00408257 VALVE ASSEMBLY - BOOM SUSPENSION .............................................................................................................................. 22
*** 56048023 VALVE ASSEMBLY - BOOM SUSPENSION AND FLOATING .................................................................................................... 24
** BG00175716 ACCUMULATOR - LEFT ............................................................................................................................................................. 26
*** BG00175261 ACCUMULATOR, PISTON - 6L, 70BAR ............................................................................................................................... 28
** BG00175304 ACCUMULATOR - RIGHT ........................................................................................................................................................... 30
*** BG00175264 ACCUMULATOR, PISTON - 6L, 20BAR ............................................................................................................................... 32
** 56212088 SUSPENSION, BOOM - PARTS IN HYDRAULIC TANK ................................................................................................................. 34
** BG00202232 SUSPENSION, BOOM - BOOM SUSPENSION AND RIDE CONTROL ELECTRICS ............................................................... 36

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00349235 gG
1 (37) HYDRAULICS, BUCKET 190730

20 18 24 5 6 19 2 11 3

17

21

24

4 19 10 12 7

1 14

27 4

13 10
9 25
22

19

23
26
15 6
27 7

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00349235 gG
190730 HYDRAULICS, BUCKET 2 (37)

Ref. Part no. Name Description Qty

e
1 56023866 HYDRAULICS, BUCKET SEE PAGE 12-4 1
2 BG00373907 VALVE ASSEMBLY SEE PAGE 12-8 1
3 BG00361439 BLOCK SEE PAGE 12-12 1
4 BG00567531 CYLINDER SEE PAGE 12-14 2
5 BG00506737 CYLINDER, TILT SEE PAGE 12-16 1
. . . . .
6 BG00436585 HOSE, HYDRAULIC 4SH-16-1560-F16A-F16B-0-0 1
7 56211744 HOSE, HYDRAULIC R2T-04-1150-V4A-V4A-0-0 1
9 BG00382775 HOSE, HYDRAULIC R2T-6-1600-V6A-V6D-0-0 2
10 56035250 HOSE, HYDRAULIC 4SH-12-1380-F12A-F12A-0-0 4
11 BG00427647 HOSE, HYDRAULIC R2T-16-0950-F16B-F20B-225-0 1
. . . . .
12 BG00508045 HOSE, HYDRAULIC 4SH-16-0950-F16B-6F20B-180-0 1
13 56021952 PIPE 1
14 56023170 PIPE 1
15 56029658 HOSE, HYDRAULIC R2T-6-660-V6A-V6D 2
17 07615528 MOUNTING PIECE 3000 PSI 8
. . . . .
18 07615527 MOUNTING PIECE 3000 PSI 1" 4
19 BG00406106 BUSHING 35/18-35 5
20 09370302 O-RING 32,9X3.5, FKM, 80 SHORE, 279-16 2
21 09370301 O-RING 25X3.5, FKM, 80 SHORE 4
22 AF02300007 WASHER, PLAIN, NORMAL M12 2
. . . . .
23 56016586 WASHER M 16, 18X30X8 5
24 06530423 HEXAGON HEAD SCREW (FULL THREAD) M10X30-8.8), ISO 4017 24
25 AF00100843 SCREW, HEXAGON HEAD, PARTIAL THREAD M12X70 2
26 AF00101226 SCREW, HEXAGON HEAD, PARTIAL THREAD M16X75 5
27 BG00405371 HOSE, HYDRAULIC 4SH-16-1650-F16A-F16B-0-0 1
. . . . .

Sandvik Mining and Construction Oy Loaders Turku © 2019

 56023866
3 (37) HYDRAULICS, BUCKET 190730

8 10 9 3 7 8 10 9

11 13 12 1 6

5 2 3 4

Sandvik Mining and Construction Oy Loaders Turku © 2019

 56023866
190730 HYDRAULICS, BUCKET 4 (37)

Ref. Part no. Name Description Qty

e
1 56019399 ADAPTER ASSEMBLY SEE PAGE 12-6 1
2 56023093 PIPE 1
3 56023092 PIPE 1
4 56024157 HOSE, HYDRAULIC 4SH-16-1400-F16A-V16A-0-0 1
5 56023935 HOSE, HYDRAULIC 4SH-20-1110-6F20A-6F20B-0-SS 1
. . . . .
6 56024266 HOSE, HYDRAULIC 4SH-16-0950-6F20B-6F20B-270-0 1
7 04182004 ADAPTER, HYDRAULIC ORFS 13/16 UNION 1
8 06429034 CLAMP, BLOCK D=12 MM, SINGLE 3
9 56000217 CUP, BASE PLATE 30-DP-1A, 6-12 3
10 06530391 HEXAGON HEAD BOLT (HALF THREAD) M6X40 - 8.8, ISO 4014 6
. . . . .
11 06429204 CLAMP, BLOCK, COMPLETE 1
12 06429313 CLAMP, PIPE, TOP PLATE 1
13 06530392 HEXAGON HEAD BOLT (HALF THREAD) M6X45 - 8.8, ISO 4014 1

Sandvik Mining and Construction Oy Loaders Turku © 2019

 56019399 fF
5 (37) ADAPTER ASSEMBLY 190730

7
6
2
4
12
9

16
17
3

15
2

18
12
13
11

14
10

1
5
10
11

Sandvik Mining and Construction Oy Loaders Turku © 2019

 56019399 fF
190730 ADAPTER ASSEMBLY 6 (37)

Ref. Part no. Name Description Qty

e
1 56019427 BLOCK, DISTRIBUTION 1
2 09370302 O-RING 32,9X3.5, FKM, 80 SHORE, 279-16 2
3 56012774 VALVE, CHECK 1 BAR SAE 1 1
3.1 56042903 O-RING 1
4 56019531 CONNECTOR SAE 1 1/4 - SAE 1 1/4 - R 1/4 1
. . . . .
5 09370307 O-RING 37,7X3.5, FKM, 80 SHORE, 279-20 2
6 07615527 MOUNTING PIECE 3000 PSI 1" 2
7 06530698 HEXAGON HEAD BOLT (HALF THREAD) M10X140 4
9 04130190 CONNECTOR, PRESSURE GAUGE G 1/4 1
10 56202478 MOUNTING PIECE FOR M12 BOLT 4
. . . . .
11 06530444 HEXAGON HEAD SCREW (FULL THREAD) M12X45 - 8.8 , ISO 4017 8
12 04910138 HEXACON SOCKET HEAD PLUG G 1/4 2
13 06530423 HEXAGON HEAD SCREW (FULL THREAD) M10X30-8.8), ISO 4017 4
14 56023183 SUPPORTING BLOCK 1
15 06530441 HEXAGON HEAD SCREW (FULL THREAD) M12X30 - 8.8, ISO 4017 2
. . . . .
16 55158399 TRANSMITTER, PRESSURE 400 BAR 1
17 06581409 WASHER, PLAIN M12 - 8, SFS 2041 2
18 06581408 WASHER, PLAIN 10, SFS 2041 4

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00373907 cC
7 (37) VALVE ASSEMBLY - BUCKET/BOOM MAIN VALVE 190730

202 203 204

24
32
200 201

36 28

34
29
23
22
5

4 26

13

31 12 19

19 9 11 19

19 10

209 27 1 35

205 210
41 44
17
42 46
33

30

8 8

15

22 25

206 207 208 211 212

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00373907 cC
190730 VALVE ASSEMBLY - BUCKET/BOOM MAIN VALVE 8 (37)

Ref. Part no. Name Description Qty

e
1 BG00375473 VALVE, DIRECTIONAL SEE PAGE 12-10 1
4 56019385 VALVE, PRESSURE RELIEF 330 BAR 1
5 BG00224940 VALVE, SPOOL, DIRECTIONAL 2/2 SEQUENCE VALVE 1
8 56212165 BLOCK, DISTRIBUTION 2
9 BG00229876 PIPE 1
. . . . .
10 BG00229885 PIPE 1
11 BG00229887 PIPE 1
12 BG00229888 PIPE 1
13 BG00229894 PIPE 1
15 BG00229952 PIPE 1
. . . . .
17 BG00229965 PIPE 1
19 BG00229974 SEAL 1
22 04182200 ADAPTER, HYDRAULIC ORFS 9/16 - G 1/8 3
23 04182201 ADAPTER, HYDRAULIC ORFS 9/16 - G 1/4 2
24 04182818 ADAPTER, HYDRAULIC ORFS 13/16 - M14X1.5 4
. . . . .
25 04182820 ADAPTER, HYDRAULIC ORFS 9/16 - M 14X1.5 1
26 56029113 ADAPTER, ELBOW ORFS 9/16 - M14X1.5 5
27 04182603 ADAPTER, ELBOW ORFS 13/16 SWIVEL NUT 3
28 55078851 CONNECTOR, PRESSURE GAUGE 6
29 55038599 CONNECTOR, GAUGE M14X1,5 - M16X2 2
. . . . .
30 04910140 HEXACON SOCKET HEAD PLUG G 3/4 10
31 04910138 HEXACON SOCKET HEAD PLUG G 1/4 1
32 04910139 HEXACON SOCKET HEAD PLUG G 1/8 3
33 06530443 HEXAGON HEAD SCREW (FULL THREAD) M12X40 - 8.8, ISO 4017 3
34 06530438 HEXAGON HEAD SCREW (FULL THREAD) M12X20 - 8.8, ISO 4017 4
. . . . .
35 44256470 HEXAGON HEAD SCREW (FULL THREAD) M10X45 - 8.8 32
36 06530423 HEXAGON HEAD SCREW (FULL THREAD) M10X30-8.8), ISO 4017 54
40 BG00230318 O-RING, RUBBER 24.99X3.53 4
41 55186509 O-RING 32.92X3.53 10
42 55095482 O-RING 37.69X3.53 1
. . . . .
44 06530422 HEXAGON HEAD SCREW (FULL THREAD) M10X25 - 8.8, ISO 4017 2
46 55100013 O-RING 44.04X3.53 1
200 56028954 VALVE, PRESSURE RELIEF VALVE, PRESSURE RELIEF 3
201 56035368 VALVE, PRESSURE RELIEF PLC182-350-20 1
202 56032191 SOLENOID 24 VDC 4
. . . . .
203 55161915 SEAL KIT PS25, SEAL-KIT, 5 PCS 1
204 56035371 SEAL KIT PC/FPC INCL.202 1
205 BG00519511 SPOOL SPOOL ACTUATOR PC+FPC 1
206 BG00520007 ORIFICE 0,9 MM PS25 5PCS 1
207 56035385 ORIFICE PILOT ORIFICE, SET OF 5 PCS 1
. . . . .
208 BG00520011 ORIFICE 1.2 MM PS25 5PCS 1
209 56048551 VALVE, SEQUENCE 1
210 56035389 COVER ASSEMBLY SPOOL COVER ASSEMBLY PC-PC 1
211 56041858 VALVE, SEQUENCE 4
212 56035384 COUNTER PRESSURE VALVE 4BAR/20L/MIN 1
. . . . .

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00375473 bB
9 (37) VALVE, DIRECTIONAL 190730

13

14

10 9

10 9

14
7

7 6
7
1
15
7 6

10 9

14

10 9

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00375473 bB
190730 VALVE, DIRECTIONAL 10 (37)

Ref. Part no. Name Description Qty

e
1 56035384 COUNTER PRESSURE VALVE 4BAR/20L/MIN 1
2 56028954 VALVE, PRESSURE RELIEF VALVE, PRESSURE RELIEF 1
3 56035368 VALVE, PRESSURE RELIEF PLC182-350-20 1
4 56032191 SOLENOID 24 VDC 1
5 56035388 SEAL KIT PS25, SET OF 5 PCS 1
. . . . .
6 56035371 SEAL KIT PC/FPC INCL.4 1
7 56035389 COVER ASSEMBLY SPOOL COVER ASSEMBLY PC-PC 1
8 56035385 ORIFICE PILOT ORIFICE, SET OF 5 PCS 1
9 56041917 VALVE, SEQUENCE INCL.10 1
10 56041918 SEAL KIT 1
. . . . .
11 56048551 VALVE, SEQUENCE 1
12 BG01119558 VALVE, CHECK - 1
13 BG00399287 VALVE, SHUTTLE 1

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00361439 bB
11 (37) BLOCK 190730

5
6
9
6
1
5

3
6

3
10

10

3
3
10
10
10
3

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00361439 bB
190730 BLOCK 12 (37)

Ref. Part no. Name Description Qty

e
1 BG00353380 BLOCK LUBRICATION 1
3 04182401 ADAPTER, ELBOW ORFS 9/16 - G 1/4 7
5 04182205 ADAPTER, HYDRAULIC ORFS 11/16 - G 1/4 4
6 04182201 ADAPTER, HYDRAULIC ORFS 9/16 - G 1/4 4
7 04182921 CAP 1
. . . . .
8 56020535 ADAPTER, MEASURING ORFS 9/16 1
9 04182600 ADAPTER, ELBOW ORFS 9/16 SWIVEL NUT 1
10 04910138 HEXACON SOCKET HEAD PLUG G 1/4 5

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00567531 cC
13 (37) CYLINDER 190730

22

22

21 25 9 4 1 2 6 3 26 24 28 27

27 28 21

9 23
17 22
16 16 10
18
7
18
14
15
20
5

13

8 12
19 19
11

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00567531 cC
190730 CYLINDER 14 (37)

Ref. Part no. Name Description Qty

e
1 56018324 TUBE, CYLINDER 1
2 BG00434965 ROD, PISTON LH514 LIFT CYL. 1
3 BG00567532 COVER, END LIFT CYLINDER 1
4 BG00434964 PISTON D160 X 98 1
5 29602219 GUARD 1
. . . . .
6 BG01015606 PIPE 25X3 1
7 BG00561157 O-RING 160X2, NBR 70 1
8 BG00561028 O-RING 77,2X5,7, NBR 90 1
9 BG01043130 SEAL 25/33X3 2
10 09370076 O-RING 154,3X5,7 NBR 90 1
. . . . .
11 09370614 SEAL, ROD 90X105X8.5 1
12 09370615 SEAL, ROD 90X105X11,4 1
13 09370616 RING, WIPER 90X110X10 1
14 09370602 RING, BACKING 77X87X1,7 2
15 09370569 RING, BACKING 155X165 1
. . . . .
16 09373677 RING, PISTON 2
17 09373674 SEAL, PISTON 160X139X8 1
18 09376827 RING, SLIP 160X154X19,5 2
19 09370613 GUIDE RING, PISTON ROD 90X95X15 2
20 AF01000270 SCREW, SET, SOCKET, HEXAGON, CUP POINT M12X20 2
. . . . .
21 04910139 HEXACON SOCKET HEAD PLUG G 1/8 2
22 04139914 PLUG, HEAD, HEXAGON SOCKET G 1/2 HEX SOCKET HEAD 3
23 AF00100641 SCREW, HEXAGON HEAD, PARTIAL THREAD M10X60 4
24 AF00500331 SCREW, SOCKET HEAD, HEXAGON M8X25 6
25 AF00100640 SCREW, HEXAGON HEAD, PARTIAL THREAD M10X55 4
. . . . .
26 06532087 HEXAGON SOCKET HEAD SCREW (FULL THREAD) M16X55 - 8.8, ISO 4762 18
27 06590398 CIRCLIP 150X4 , DIN 472 4
28 06743229 BEARING 2
200 BG00560924 SEAL KIT INCL.7-8, 10-19 1

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00506737 dD
15 (37) CYLINDER, TILT 190730

7 6 2 1 4 3 7

24 25 6 25 24

17 23
23 14
8
14

26 9 21

10

19

18 22
20 13
18 15

11
12
5

16

13

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00506737 dD
190730 CYLINDER, TILT 16 (37)

Ref. Part no. Name Description Qty

e
1 BG00506853 TUBE, CYLINDER BOLTED TUBES 1
2 BG00959954 PIPING SEE PAGE 12-18 1
3 BG00507422 COVER, END TILT CYLINDER 1
4 BG00396125 ROD, PISTON TILT CYLINDER 1
5 29602259 GUARD 1
. . . . .
6 56018915 PISTON 1
7 04180630 ADAPTER, ELBOW JIC 7/16 - R 1/8 2
8 04910140 HEXACON SOCKET HEAD PLUG G 3/4 1
9 AF01000270 SCREW, SET, SOCKET, HEXAGON, CUP POINT M12X20 2
10 AF00500330 SCREW, SOCKET HEAD, HEXAGON M8X20 6
. . . . .
11 AF00500844 SCREW, SOCKET HEAD, HEXAGON M16X70 23
12 09370608 SEAL, ROD 140X160X14.5 1
13 09370607 GUIDE RING, PISTON ROD 140X145X15 3
14 56018968 RING, SLIP 220X214X19,5 2
15 09370609 SEAL, ROD 140X160X14.5 1
. . . . .
16 09370610 RING, WIPER 140/155X9X12 1
17 56018967 SEAL, PISTON 220X199X8 1
18 56018971 RING, BACKING 210X220X1,7 2
19 09370929 RING, BACKING 120X130X1,7, PU 2
20 BG00507464 O-RING 209,3X5,7, NBR, 90 SHORE 1
. . . . .
21 09370085 O-RING 119,2X5,7, NBR 90 1
22 BG00507813 O-RING 200,0X2,0 1
23 56018969 RING, PISTON 220X9,51 2
24 06743234 JOINT, BALL 2
25 06590428 CIRCLIP 210X5, DIN 472 4
. . . . .
200 BG00507817 SEAL KIT INCL.12-23 1

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00959954 aB
17 (37) PIPING - TILT CYL. NEW SEALS 190730

4 2 5 3

1
4 5

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00959954 aB
190730 PIPING - TILT CYL. NEW SEALS 18 (37)

Ref. Part no. Name Description Qty

e
1 BG00844329 PIPE 1
2 BG00959961 PIPE DETACHABLE, NEW SEAL 1
3 06530442 HEXAGON HEAD SCREW (FULL THREAD) M12X35 - 8.8, ISO 4017 4
4 AF00100641 SCREW, HEXAGON HEAD, PARTIAL THREAD M10X60 8
5 BG00840583 SEAL 32/40X3 2
. . . . .

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00353725 dD
19 (37) SUSPENSION, BOOM 190730

4
1

22

21

24

13 11 7 8 6 8

12 14
19

20

23 19 24

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00353725 dD
190730 SUSPENSION, BOOM 20 (37)

Ref. Part no. Name Description Qty

e
1 BG00408257 VALVE ASSEMBLY SEE PAGE 12-22 1
2 BG00175716 ACCUMULATOR SEE PAGE 12-26 1
3 BG00175304 ACCUMULATOR SEE PAGE 12-30 1
4 BG00373345 PIPE ORFS D 25X2.5 1
5 02825680 HOSE, HYDRAULIC R2T-04-0600-V4A-V4A-0-0 1
. . . . .
6 BG00392933 PIPE ORFS D 25X2.5 1
7 BG00392913 PIPE ORFS D 25X2.5 1
8 AF10520019 FITTING, MALE STUD ELBOW ORFS 1 7/16 - BSPP 3/4 2
9 56212088 SUSPENSION, BOOM SEE PAGE 12-34 1
10 BG00202232 SUSPENSION, BOOM SEE PAGE 12-36 1
. . . . .
11 AF00100840 SCREW, HEXAGON HEAD, PARTIAL THREAD M12X55 4
12 06530424 HEXAGON HEAD SCREW (FULL THREAD) M10X35 - 8.8, ISO 4017 4
13 AF02400007 WASHER, PLAIN, THICK M12 4
14 AF02300006 WASHER, PLAIN, NORMAL M10 4
19 AF11570004 FITTING, TUBE END REDUCER ORFS 1 3/16 - ORFS 1 7/16 3
. . . . .
20 29605029 HOSE, HYDRAULIC R2T-12-1200-V12A-V12D-0-0 1
21 BG00531817 HOSE, HYDRAULIC 4SH-12-0740-V12A-V12B-0-0 1
22 BG00531795 HOSE, HYDRAULIC 4SH-12-0500-V12A-V12B-0-0 1
23 AF10730005 FITTING, SWIVEL NUT ELBOW ORFS 1 3/16 1
24 AF10730006 FITTING, SWIVEL NUT ELBOW ORFS 1 7/16 2
. . . . .

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00408257 bB
21 (37) VALVE ASSEMBLY - BOOM SUSPENSION 190730

10
3

5
2

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00408257 bB
190730 VALVE ASSEMBLY - BOOM SUSPENSION 22 (37)

Ref. Part no. Name Description Qty

e
1 56048023 VALVE ASSEMBLY SEE PAGE 12-24 1
2 04182460 ADAPTER, ELBOW ORFS 1.7/16 - G 1 1
3 04182401 ADAPTER, ELBOW ORFS 9/16 - G 1/4 1
4 04182610 ADAPTER, ELBOW ORFS 1.7/16 SWIVEL NUT 1
5 56024664 ADAPTER, TEE ORFS 1.7/16 - G 1 1
. . . . .
6 04182263 ADAPTER, HYDRAULIC ORFS 1.7/16 - G 1 1
7 04182252 ADAPTER, HYDRAULIC ORFS 1.3/16 - G 1 1
8 04182784 REDUCER, TUBE END ORFS 1.3/16 - 1.7/16 1
9 56020545 ADAPTER, MEASURING 1
10 04910138 HEXACON SOCKET HEAD PLUG G 1/4 1
. . . . .

Sandvik Mining and Construction Oy Loaders Turku © 2019

 56048023
23 (37) VALVE ASSEMBLY - BOOM SUSPENSION AND FLOATING 190730

6.1
6.3 6.2
7.1
7.3 7.2

4 5 3

8 13

7 8
7.1 6.1 6.2 7.2

7.3 6.3 5
13 9

4 3

Sandvik Mining and Construction Oy Loaders Turku © 2019

 56048023
190730 VALVE ASSEMBLY - BOOM SUSPENSION AND FLOATING 24 (37)

Ref. Part no. Name Description Qty

e
3 56210328 CARTRIDGE 1
4 56210329 CARTRIDGE 1
5 56210330 CARTRIDGE 1
6 56021212 VALVE, DIRECTIONAL INCL.200 3
7 56017692 COIL 28VDC-20W 4
. . . . .
8 56017691 CARTRIDGE 1
9 55078851 CONNECTOR, PRESSURE GAUGE 1
13 56021211 VALVE, SHUTTLE 1
200 56006264 SEAL KIT 1

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00175716 cC
25 (37) ACCUMULATOR - LEFT 190730

9 11 11 3

7
5

13 6

10 12

11

2 4

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00175716 cC
190730 ACCUMULATOR - LEFT 26 (37)

Ref. Part no. Name Description Qty

e
1 BG00175458 PLATE, MOUNTING 1
2 BG00175535 PLATE 1
3 56024027 CLIP 1
4 BG00175261 ACCUMULATOR, PISTON SEE PAGE 12-28 1
5 56030769 SUPPORTING BLOCK 2
. . . . .
6 56012762 STRAP, METAL 2
7 04182784 REDUCER, TUBE END ORFS 1.3/16 - 1.7/16 1
8 04182075 ADAPTER, HYDRAULIC ORFS 1.7/16 BULKHEAD UNION 1
9 AF02400011 WASHER, PLAIN, THICK M20 1
10 AF02300006 WASHER, PLAIN, NORMAL M10 2
. . . . .
11 AF00101342 SCREW, HEXAGON HEAD, FULL THREAD M20X50 4
12 06530424 HEXAGON HEAD SCREW (FULL THREAD) M10X35 - 8.8, ISO 4017 2
13 06530423 HEXAGON HEAD SCREW (FULL THREAD) M10X30-8.8), ISO 4017 4

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00175261 bB
27 (37) ACCUMULATOR, PISTON - 6L, 70BAR 190730

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00175261 bB
190730 ACCUMULATOR, PISTON - 6L, 70BAR 28 (37)

Ref. Part no. Name Description Qty

e
1 56024386 ACCUMULATOR, PISTON PRE-CHARGE PRESSURE=0 BAR 1
1 PISTON SEAL 140X119X8.1 1
2 PISTON GUIDE 140X135X14.8 1
3 O-RING 129.3X5.7 1
4 BACKING RING 130X140X1.7 1
. . . . .
5 PISTON Ø140 1

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00175304 cC
29 (37) ACCUMULATOR - RIGHT 190730

7 10

6 9

1 2 3
7 10

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00175304 cC
190730 ACCUMULATOR - RIGHT 30 (37)

Ref. Part no. Name Description Qty

e
1 BG00175458 PLATE, MOUNTING 1
2 BG00175535 PLATE 1
3 BG00175264 ACCUMULATOR, PISTON SEE PAGE 12-32 1
4 56030769 SUPPORTING BLOCK 2
5 56012762 STRAP, METAL 2
. . . . .
6 AF02400006 WASHER, PLAIN, THICK M10 2
7 AF02400011 WASHER, PLAIN, THICK M20 4
8 AF00100528 SCREW, HEXAGON HEAD, FULL THREAD M10X30 4
9 AF00100529 SCREW, HEXAGON HEAD, FULL THREAD M10X35 2
10 AF00101342 SCREW, HEXAGON HEAD, FULL THREAD M20X50 4
. . . . .

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00175264 aA
31 (37) ACCUMULATOR, PISTON - 6L, 20BAR 190730

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00175264 aA
190730 ACCUMULATOR, PISTON - 6L, 20BAR 32 (37)

Ref. Part no. Name Description Qty

e
1 56024386 ACCUMULATOR, PISTON PRE-CHARGE PRESSURE=0 BAR 1
1 PISTON SEAL 140X119X8.1 1
2 PISTON GUIDE 140X135X14.8 1
3 O-RING 129.3X5.7 1
4 BACKING RING 130X140X1.7 1
. . . . .
5 PISTON Ø140 1

Sandvik Mining and Construction Oy Loaders Turku © 2019

 56212088
33 (37) SUSPENSION, BOOM - PARTS IN HYDRAULIC TANK 190730

Sandvik Mining and Construction Oy Loaders Turku © 2019

 56212088
190730 SUSPENSION, BOOM - PARTS IN HYDRAULIC TANK 34 (37)

Ref. Part no. Name Description Qty

e
1 04182262 ADAPTER, HYDRAULIC ORFS 1.7/16 - G 3/4 1
2 56212008 PIPE ORFS D 25X2.5 1
3 56212132 CONNECTOR 45 DEG SWIVEL NUT ELBOW 1
4 04182088 ADAPTER, ELBOW ORFS 1.7/16 BULKHEAD UNION 1
5 04182830 LOCK NUT ORFS 1.7/16 1
. . . . .
6 04182784 REDUCER, TUBE END ORFS 1.3/16 - 1.7/16 1
7 56212040 PLATE, MOUNTING 1
8 06530421 HEXAGON HEAD SCREW (FULL THREAD) M10X20 - 8.8, ISO 4017 2
9 56016597 WASHER M10, 10.5X25X4 2

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00202232 aA
35 (37) SUSPENSION, BOOM - BOOM SUSPENSION AND RIDE CONTROL ELECTRICS 190730

Sandvik Mining and Construction Oy Loaders Turku © 2019

 BG00202232 aA
190730 SUSPENSION, BOOM - BOOM SUSPENSION AND RIDE CONTROL ELECTRICS 36 (37)

Ref. Part no. Name Description Qty

e
1 BG00202264 HARNESS, WIRING RIDE CONTROL VALVES, X2160 1
16 04730779 SWITCH ON/OFF SWITCH, 2-POSITION, OPEN 2
44 56009749 SWITCH, ROCKER WITH RIDE CONTROL SYMBOL 1
47 56015262 SWITCH, ROCKER WITH BOOM SUSPENSION SYMBOL 1
55 56018367 SEAL GASKET FOR SWITCH AND INDICATOR 2
. . . . .

Sandvik Mining and Construction Oy Loaders Turku © 2019
