cps-group.
com
Powerful Synergies
108
HIGH POWER
MODEL
COPMA 108
Performance & Power
108 HAS THE HIGHEST LIFTING
RANGE AND TOP POWER-WEIGHT
RATIO COMBINING ADVANCED
TECHNOLOGY FEATURES FOR
MORE PERFORMANCE.
• HIGH POWER model, load category - 10 Ton/Mt
• Essential in design, powerful in performance
• Robust arm system
• Simple and reliable
• Excellent operational safety
2 CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP S.P.A.
THE MOST
POWERFUL
CRANE FOR
THE TOUGHEST
MARKETS
CPS STEEL CPS COPMA PESCI PESCI MARINE 2019WWWW All rights reserved CPS GROUP S.P.A.
COPMA 108
More Safety & Security
DESIGNED WITH THE HIGHEST
HYDRAULIC SYSTEMS AND THE
TOUGHEST STRUCTURAL STEEL
TO PERFORM THE MAXIMUM
LIFTING CAPACITY.
• Optimized and reliable hydraulic technology
• Column with high mechanical characteristics
• High Degree of User Friendliness
• Efficiency and Reliability thanks to essential design
• Excellent weight/performance ratio
4 CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP S.P.A.
DESIGNED
FOR FLEXIBLE
SERVICES
CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP 5
COPMA 108
Technical Features
CUTTING EDGE FEATURES
FOR MAXIMUM LIFTING
POWER,STABILITY AND
OPERATIONAL SAFETY IN EVERY
WORKING CONDITION.
Standard features
* * * *
• control
• structure
optional features
• easy use
• control
*E.C. market specific equipment
6 CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP
Transport TES
2.0
Truck Electronic
Alert control Stability
Device 2.0
Sensors on the basement control the correct closing of the beams Active stability control for performance optimization according
and a column switch sensor indicates if the crane is in a folded to the type of stabilization (2) to guarantee maximum safety in all
position, no more than 4 Mt in height. The operator is warned with working conditions. Mandatory in the CE market, it helps a better
light and sound signals in the truck cabin. vehicle-crane configuration.
CMS
1.0
Crane Monitoring CMS
2.0
Crane Monitoring
control System control System
1.0 2.0
Crane stability control system TES1-TES2, with safety control and Crane stability control system TES2-TES3 with safety and
overload control for medium-small cranes. Controls the crane in 4 work overload controls and HPVE lifting speed management.
areas, and each zone can have custom lifting settings depending on the Active control on 4-8 working areas according to the model and
vehicle stability. vehicle stability requirements.
Rotation
Rack
Pinion
The rotation system with rack and pinion is the best optimal
solution for the most performative lifting capacity, it reduce
the weights and crane dimension for the most compact
configuration.
CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP 7
RRC
2.0
Radio Remote Radio Remote
control Control Control
2.0 3.0
The rotation system with rack and pinion is the best optimal solution Radio control with directly flanged actuation electronics with
for the most performative lifting capacity, it reduce the weights and proportional distribution.
crane dimension for the most compact configuration. The remote control allows operating the crane while constantly
monitoring the areas of operation.
HLS
1.0
Hydraulic Lifting ERD Electronic
easy use Stabilizers easy use Radio
1.0 Display
Radio control with directly flanged actuation electronics with A display on the remote control allows the operator to maintain
proportional distribution. This system assists the operator with the the total control of all the crane functions in real time by managing
possibility of using the radio control for stabilizing the crane and save the work mode, the stability control, and oversee any maintenance
operative time in increasing the security of the setup. and diagnostic messages.
8 CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP
108 HIGH POWER
Load Charts
1 extensions 2 extensions
0 ft. 5 10 15 20 0 ft. 5 10 15 20 25 30
35 0m 1 2 3 4 5 6 7 8 9
0m 1 2 3 4 5 6 7 40
12
10
30 11
9 35
10
8
25 30 9
7
8
25
20 6 7
5 20 6
15
5
4 15
4800* 2330 1580 kg 4
10 3
2,00 4,10 5,90 m 10
4600* 2220 1510 1130 kg
3 2,00 4,15 5,95 7,90 m
2 5140 3480 lb
2 4890 3330 2490 lb
5 6'7" 13'5" 19'4" ft
5 6'7" 13'7" 19'6" 25'11" ft
1 1
ft. 0 0m ft. 0 0m
3 extensions 4 extensions
0 ft. 5 10 15 20 25 30 35 0 ft. 5 10 15 20 25 30 35 40
17 0m 1 2 3 4 5 6 7 8 9 10 11 12 13
0m 1 2 3 4 5 6 7 8 9 10 11 55
14 16
45
50
13 15
40 14
12 45
13
11
35 40
12
10
11
30 35
9
10
8 30 9
25
7 8
25
20 6 7
20 6
5
15
5
4 15
4450* 2140 1445 1060 830 kg 4
10 3 2,00 4,15 5,95 7,90 10,00 m 4200* 2000 1350 960 730 600 kg
10 3 2,00 4,20 6,05 7,95 10,10 12,15 m
9810* 4720 3190 2340 1830 lb
2 6'7" 13'7" ft
9260* 4410 2980 2120 1610 1320 lb
19'6 25'11" 32'9" 2
5 5
6'7" 13'9" 19'10" 26'1" 33'1" 39'10" ft
1 1
ft. 0 0m ft. 0 0m
CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP 9
108.3 + J1 108.3 + J2
10 CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP
108 HIGH POWER
Crane Dimensions
back cabin left top cabin
869
[ 2'-5" ] [ 2'-10" ] 400°
with TRACK CHAIN
rear truck
2323 2322
[ 7'-7" ] [ 7'-7" ]
1511 811 1496 826
[ 5'-0" ] [ 2'-8" ] [ 4'-11" ] [ 2'-9" ]
[ 6'-11" ]
2106
2350
CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP 11
operational
20°
390 6779
[ 1'-3" ] [ 22'-3" ]
276 4282
[ 11" ] [ 14'-1" ]
[ 9'-2" ]
2781
[ 7'-4" ]
[ 6'-11" ]
2225
2102
[ 6'-0" ]
[ 5'-8" ]
1823
1733
extended outriggers
[ 2'-4" ]
[ 4" ]
113
713
350
[ 1'-2" ]
1412 712
[ 2'-7" ]
[ 4'-8" ] [ 2'-4" ]
780
2124
[ 7'-0" ]
2527 1827
[ 8'-3" ] [ 6'-0" ]
4354
[ 14'-3" ]
2957 2257
[ 9'-8" ] [ 7'-5" ]
5214
[ 17'-1" ]
* Note:
Technical features are not binding.
The company reserves itself the right to any modification without notice
12 CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP
108 HIGH POWER
Technical Data
summarized data
kN.m bar l/min kg ° mm mm mm mm
108.1 93.7 280 25 1000 400 2323 737 2106 4350/5200
108.2 90.4 280 25 1100 400 2323 737 2106 4350/5200
108.3 87.1 280 25 1190 400 2323 737 2106 4350/5200
108.3J1 87.1 280 25 1310 400 2323 869 2350 4350/5200
108.3J2 87.1 280 25 1350 400 2323 869 2350 4350/5200
108.4 61.7 280 25 1260 400 2323 737 2106 4350/5200
lbs.ft psi gal/min lbs ° ft/inc ft/inc ft/inc ft/inc
108.1 69109 4060 6,6 2205 400 7’7’’ 2’1” 6’1” 14’9”/16’11”
108.2 66675 4350 6,6 2425 400 7’7’’ 2’1” 6’1” 14’9”/16’11”
108.3 64242 4350 6,6 2620 400 7’7’’ 2’1’’ 6’1’’ 14’9”/16’11”
108.3J1 64242 4350 6,6 2890 400 7’7’’ 2’10’’ 7’9’’ 14’9”/16’11”
108.3J2 64242 4350 6,6 2975 400 7’7’’ 2’10’’ 7’9’’ 14’9”/16’11”
108.4 32549 4350 6,6 2775 400 7’7’’ 2’1” 6’1” 14’9”/16’11”
technical data
Max. lifting moment 93.7 kNm 69109 ft.lbs
Max. hydraulic outreach 12.4 m 40’8”
Slewing angle 400° 400°
Slewing torque 1200 daNm 8680 ft.lbs
Stabilizer spread 4.35/5.20 mt 14’9”/16’11”
Fitting space required (min./max) 0.73/0.86 m 2’1”/2’9”
Width folded 2.3 m 7’7”
Max. operating pressure 280 bar 4350 psi
Recommended pump capacity 25 l/min 6.6 US gal./min
Dead weight (vers .1) 1000 kg 2205 lbs
* Note:
Technical features are not binding.
The company reserves itself the right to any modification without notice
CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP 13
14 CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP
GET READY TO A
BETTER LIFTING
EXPERIENCE
CPS STEEL CPS COPMA PESCI PESCI MARINE 2019 All rights reserved CPS GROUP 15
COPMA
108
knuckle
boom
cranes
COPMA MODEL 108 HIGH POWER 6-2019 all rights reserved CPS GROUP
Powerful Synergies
CPS GROUP S.P.A.
281 Via Emilia , Castel Bolognese (RA) , 48018
Italy
T +39 0546 653 711
sales.cpsgroup@cps-group.com
service.cpsgroup@cps-group.com
cps-group.com
Technical features, design and specifications are not binding, CPS GROUP S.P.A. reserves itself the right to any modifications without prior notice.
COPMA , PESCI, PESCI MARINE and CPS are registered trademarks of CPS GROUP S.P.A. in Italy and other countries.
