MTGBUC11797
Kit
INSTALLATION INSTRUCTIONS
Wide Area Mower and Front Mower
UC37271 06SEP24 (ENGLISH)
1600 Wide Area Mower, 1550, 1570, 1575, 1580, and 1585
John Deere Turf Care
UC37271 (06SEP24)
PRINTED IN U.S.A.
COPYRIGHT © 2024
DEERE & COMPANY
Moline, Illinois
All rights reserved.
A John Deere ILLUSTRUCTION ™ Manual
Previous Editions
Copyright © 2023
UC37271-19-06SEP24
BUC11797
Download Instructions
RG38138 —UN—21FEB24
DX,DOWNLOADINSTRUCTIONS,AT -19-02APR24-1/1
UC37271 (06SEP24) 1 091624
PN=3
BUC11797
Parts in Kit
APY592655 —UN—05SEP23
Legends Part Number Description Quantity
A 03M7184 Bolt 2
B 14M7396 Lock Nut 5
C 19M7866 Screw 3
D AUC21876 Wiring Harness 1
E GX22456 Screw 2
F M78480 Tie Band 2
G M84309 Nut 2
H TCU20995 Washer Rubber 2
I TCU33282 Screw 4
J UC37656 Bracket (For Wide Area 1
Mower Only)
K UC37714 Bracket (For Front Mower Only) 1
L Ph85244422 Module 1
NOTE: Module (L) is not a part of the kit.
czhk963,1693374876526 -19-11SEP23-1/1
Parking Safely 6. Remove the key.
1. Stop machine on a level surface, not on a slope. 7. Wait for engine and all moving parts to stop before you
2. Disengage mower blades or any other attachments. leave the operator’s seat.
3. Lower attachments to the ground. 8. Close fuel shut-off valve, if your machine is equipped.
4. Lock the park brake. 9. Disconnect the negative battery cable or remove
the spark plug wire(s) (for gasoline engines) before
5. Stop the engine. servicing the machine.
OUO1023,0000035 -19-13AUG24-1/1
UC37271 (06SEP24) 2 091624
PN=4
BUC11797
Installation of MTG On Front Mower
1. Remove the styling panel (A) with the help of two
screws (D) and two knobs (C).
2. Remove the screen (B) from air intake (E).
A—Styling Panel D—Screw (2 used)
B—Screen E—Air Intake
C—Knob (2 used)
APY592638 —UN—04SEP23
e48f9rz,1724237913961 -19-21AUG24-1/15
3. For 1570, 1575, 1580, and 1585. Disconnect the
connectors from VCU.
APY592639 —UN—04SEP23
e48f9rz,1724237913961 -19-21AUG24-2/15
4. Remove wing nuts (A) on front and back of battery
cover (B) and remove cover.
5. Disconnect — negative battery cable.
6. Loosen clamp and disconnect air cleaner hose from
side cover.
A—Wing Nut B—Cover
TCT008087 —UN—19NOV13
Continued on next page e48f9rz,1724237913961 -19-21AUG24-3/15
UC37271 (06SEP24) 3 091624
PN=5
BUC11797
7. Remove bolt (C) from front of side panel.
C—Bolt
TCT008088 —UN—19NOV13
e48f9rz,1724237913961 -19-21AUG24-4/15
8. Remove bolt (D) from rear of side panel and remove
panel.
D—Bolt
TCT008089 —UN—19NOV13
Continued on next page e48f9rz,1724237913961 -19-21AUG24-5/15
UC37271 (06SEP24) 4 091624
PN=6
BUC11797
9. Drill two holes (G) and (H) of 9 mm in panel (I) at a
distance of 120 mm and 170 mm from the center of
the grommet (F).
F— Grommet H—Hole
G—Hole I— Panel
APY592640 —UN—04SEP23
e48f9rz,1724237913961 -19-21AUG24-6/15
10. Install an MTG bracket (J) with the help of two bolts
(M) and two holding clips (K) and two lock nuts (L).
J— MTG Bracket L— Lock Nut (2 used)
K—Holding Clip (2 used) M—Bolt (2 used)
APY592641 —UN—04SEP23
Continued on next page e48f9rz,1724237913961 -19-21AUG24-7/15
UC37271 (06SEP24) 5 091624
PN=7
BUC11797
11. Install bolt and washer (A) and nut (B) to rear side
cover mount.
A—Bolt B—Nut
TCT009356 —UN—19NOV13
e48f9rz,1724237913961 -19-21AUG24-8/15
12. Install bolt and washer (C) into front side cover mount.
13. Connect negative battery cable.
C—Bolt
TCT008088 —UN—19NOV13
Continued on next page e48f9rz,1724237913961 -19-21AUG24-9/15
UC37271 (06SEP24) 6 091624
PN=8
BUC11797
14. Install battery cover (D) and secure on each end with
wing nut (E).
D—Cover E—Wing Nut
TCT009357 —UN—19NOV13
e48f9rz,1724237913961 -19-21AUG24-10/15
15. Attach MTG Module (N) to bracket using MTG
adhesive.
N—MTG Module
APY592642 —UN—04SEP23
e48f9rz,1724237913961 -19-21AUG24-11/15
16. Connect MTG connector (O) to MTG Module .
17. Wind excess harness (Q) inside of panel with the help
of tie and route connector (R) to the other side of the
grommet (P).
NOTE: Operator's seat needs to lift up.
O—MTG Connector Q—Excess Harness
P—Grommet R—Connector
APY592643 —UN—04SEP23
Continued on next page e48f9rz,1724237913961 -19-21AUG24-12/15
UC37271 (06SEP24) 7 091624
PN=9
BUC11797
18. Route MTG harness along with main vehicle harness
utilizing zip ties.
NOTE: Lift the seat pan along with seat to gain
the access for connection.
19. Uncap and connect the MTG connector (S) to the
connectivity breakout connector (T) of vehicle harness.
TC644387 —UN—22AUG24
S—MTG Connector T— Connectivity Breakout
Connector
e48f9rz,1724237913961 -19-21AUG24-13/15
20. For 1570, 1575, 1580, and 1585. Reconnect the
connectors to the VCU.
21. After connection the MTG harness, start up the vehicle
and check for correct LEDs that are flashing on the
MTG module.
APY592639 —UN—04SEP23
e48f9rz,1724237913961 -19-21AUG24-14/15
22. Reinstall the Screen (B) to air intake (E).
23. Reinstall the styling panel (A) with the help of two
screws (D) and two knobs (C).
A—Styling Panel D—Screw (2 used)
B—Screen E—Air Intake
C—Knob (2 used)
APY592638 —UN—04SEP23
e48f9rz,1724237913961 -19-21AUG24-15/15
UC37271 (06SEP24) 8 091624
PN=10
BUC11797
Installation of MTG On Wide Area Mower
1. Remove the console panel (A) by removing the latch
(B).
A—Console Panel B—Latch
APY592645 —UN—04SEP23
czhk963,1693282152413 -19-19OCT23-1/9
2. Remove the connectors from the control module (C).
3. Remove the three cap screws (D) and three lock nuts
(E).
4. Take out the bracket (F) along with the control module
out of the console.
5. Remove the control module (C) from the bracket by
removing the four screws (G).
APY592646 —UN—04SEP23
C—Control Module F— Bracket
D—Cap Screw (3 used) G—Screw (4 used)
E—Lock Nut (3 used)
APY592647 —UN—04SEP23
Continued on next page czhk963,1693282152413 -19-19OCT23-2/9
UC37271 (06SEP24) 9 091624
PN=11
BUC11797
6. Install the control module (C) on a new MTG bracket
(F) by using four screws (G).
7. Reconnect the connectors to the control module (C).
C—Control Module G—Screw (4 used)
F— MTG Bracket
APY592648 —UN—04SEP23
APY592653 —UN—04SEP23
czhk963,1693282152413 -19-19OCT23-3/9
8. Install a new MTG bracket (F) on the machine console
by using three screws (H) and lock nuts (I).
NOTE: For Installation of MTG use either step 9 or step 10.
F— MTG Bracket I— Lock Nut (3 used)
H—Screw (3 used)
APY592649 —UN—04SEP23
Continued on next page czhk963,1693282152413 -19-19OCT23-4/9
UC37271 (06SEP24) 10 091624
PN=12
BUC11797
9. Install MTG module (J) on MTG Bracket (F) with the
help of two rubber washers (L) and two screws (K).
F— MTG Bracket K—Screw (2 used)
J— MTG Module L— Washer (2 used)
APY592650 —UN—04SEP23
czhk963,1693282152413 -19-19OCT23-5/9
10. Install MTG module (J) on MTG Bracket (F) with the
help of two adhesive strips (R).
F— MTG Bracket R—Strip (2 used)
J— MTG Module
APY592654 —UN—19OCT23
czhk963,1693282152413 -19-19OCT23-6/9
11. Connect the harness connector (P) to the MTG module
(J), roll the excess harness (N) above the MTG using
two tie bands (M), then connect the MTG module to
the main harness breakout using a connector (O).
J— MTG Module O—Connector
M—Tie Band (2 used) P—Harness Connector
N—Excess Harness
APY592651 —UN—04SEP23
Continued on next page czhk963,1693282152413 -19-19OCT23-7/9
UC37271 (06SEP24) 11 091624
PN=13
BUC11797
12. Now turn the key switch to on position and check the
light (Q) on the MTG module is flashing.
Q—Light
APY592652 —UN—04SEP23
czhk963,1693282152413 -19-19OCT23-8/9
13. Install console panel (A) with the help of a latch (B).
A—Console Panel B—Latch
APY592645 —UN—04SEP23
czhk963,1693282152413 -19-19OCT23-9/9
