INTRODUCTION

SIRC specialises in the production of REFRACTORY ANCHORS for

the Petrochemical, Chemical and Furnace Building industries and the
production of Computerised Semi Automatic STUD WELDING.

All refractory anchors are produced in our own, purpose built, factory using
modern machinery and production techniques. This, coupled with our
large stock-holding of stainless steel allows us to confidently offer short
delivery times for high quality products.

Certain popular styles of REFRACTORY ANCHORS you will find

documented in this brochure. Due to the large variety of fixings possible,
we request you, in the case of special or custom purpose models that you
may require to send us a sketch or sample such that we can make you a
competitive offer.

For the standard documented models we request you to state the

dimensions as they appear on the drawings. This will facilitate verbal
enquiries and prices can be quoted almost immediately.

REFRATTARI SIRC SRL

Via Gulf Italiana, n° 1
26827 TERRANOVA DEI PASSERINI (LO)
ITALY
Tel. : +39(0)377 85329
Fax. : +39(0)377 855056
E-mail : sirc@refrattarisirc.com
Web : www.refrattarisirc.com
Sirc Refractory Anchors Issue 1/2013

Date : 07 January 2003 Rev. 0

Page 2/11

TABLE of Contents - Refractory Anchors

1 Brick Anchoring systems (serie A)

A-01 Staples Rev. 0 - 01/13

2 Concrete Anchoring systems for one component linings (serie B)

B-01 SPLIT Y Rev. 0 - 01/13

B-02 SYMPLE V Rev. 0 - 01/13
B-03 BULLHORN Rev. 0 - 01/13
B-04 HEAVY BULLHORN Rev. 0 - 01/13
B-05 CORRUGATED H Rev. 0 - 01/13
B-06 FCV Rev. 0 - 01/13
B-07 HTV Rev. 0 - 01/13
B-08 CORRUGATED BULLHORN Rev. 0 - 01/13

3 Concrete anchoring systems for two component linings (serie C)

C-01 TWIN PIN Rev. 0 - 01/13

C-02 ’V’ ON NUT Rev. 0 - 01/13
C-03 THREADED V - CH Rev. 0 - 01/13

4 Ceramic Fibre anchoring systems (serie D)

D-01 R-Pin SYSTEM Rev. 0 - 01/13

D-02 FIBERBLOCK SYSTEM Rev. 0 - 01/13
D-03 PRESS ON CLICK Rev. 0 - 01/13
D-04 MAS System Rev. 0 - 01/13

Approved by : Quality Control Manager

Signature :
Sirc Refractory Anchors Issue 1/2013

Date : 07 January 2003 Rev. 0

Page 3/11

ANCHORS FOR REFRACTORY BRICK LININGS (SERIES A)

Several systems are available to retain brick linings, each model custom
made depending on the design and application. Due to the relatively high
temperatures at which these bricks are applied, care must be taken in the
selection of the correct alloy.

SIRC offers many systems for brick retaining that during the
preparation of this issue have not been documented and coded in a
manner like all the other products. Please consult our office for the
available standards.

SERIES A-01 :
The STAPLE system offers good retention of Insulating Bricks. For the
more dense bricks the heavier staples are also well suited.

Page Anchor style

A-01/01 STAPLE
A-01/02 BRICK STAPLE
A-01/03 ASTP1
A-01/04 ASTP2
A-01/05 ASTP3
Sirc Refractory Anchors Issue 1/2013

Date : 07 January 2003 Rev. 0

Page 4/11

ANCHORS FOR ONE COMPONENT LININGS (SERIES B)

Sirc supplies different anchoring systems for single component linings
available from 4mm diam. wire for the low density linings up to 20mm diam.
bar for the high density linings. All models can be corrugated or specially
deformed for superior holding power. Sirc can produce the anchors to
suit either stud welding or hand welding techniques or the mechanical bolt
on technique of fixing to the vessel.

SERIES B-01 :
The Split ’Y’ System is a simple anchoring system used for light to very
dense refractories. For Hand and Stud welding.

Page Anchor style

B-01/01 SPLIT Y
B-01/02 BYA

SERIES B-02 :
The SYMPLE ’V’ Anchor system is a simple basic anchoring system used
for light to very dense refractories. For Hand welding only.

Page Anchor style

B-02/01 SIMPLE V
B-02/02 SIMPLE V SYSTEM
B-02/03 SV1
B-02/04 SV2
B-02/05 SV3
B-02/06 SV4
B-02/07 SVM

SERIES B-03 :
The Bullhorn is a 3-dimensionally corrugated anchor for light and medium
density refractories. Very effective and designed for stud welding.

Page Anchor style

B-03/01 BULLHORN
B-03/02 CORRUGATED BULLHORN
B-03/03 CCBS
B-03/04 CSBS
Sirc Refractory Anchors Issue 1/2013

Date : 07 January 2003 Rev. 0

Page 5/11

ANCHORS FOR ONE COMPONENT LININGS (SERIES B)

SERIES B-04 :
The Heavy Bullhorn is a 3-dimensionally corrugated anchor for very high
density refractories. Effective and only suited for hand welding.

Page Anchor style

B-04/01 HEAVY BULLHORN
B-04/02 HEAVY BULLHORN SYSTEM

B-04/03 DHBH
B-04/04 DHBR
B-04/05 DHBV

SERIES B-05 :
The Corrugated ’H’ anchors are two types of 2- and one type of a
3-dimensionally corrugated anchor for light, medium and dense
refractories. These are specially designed for hand welding.
Page Anchor style
B-05/01 CORRUGATED H
B-05/02 CORRUGATED H SYSTEM
B-05/03 ECH1
B-05/04 ECH2
B-05/05 ECH3
B-05/06 ECH4

SERIES B-06 :
The FCV is a round sectioned and stud weldable studs offering
anchoring properties due to its excellent 2- and 3- dimensional
characteristics. It is used for light and medium weight refractories and
the anchors are suited for stud welding.

Page Anchor style

B-06/01 FCV
B-06/02 FCV ROUND SYSTEM
B-06/03 FCV1
B-06/04 FCV2
B-06/05 FCV3
Sirc Refractory Anchors Issue 1/2013

Date : 07 January 2003 Rev. 0

Page 6/11

ANCHORS FOR ONE COMPONENT LININGS (SERIES B)

SERIES B-07 :
The HTW Anchor is a multipurpose anchor for all types of refractory.
Suitable for hand welding or bolting to the steel casing. Also ideal for using
as a ’movable’ anchor in rotary kilns and for general medium to heavy
weight refractories.

Page Anchor style

B-07/01 HTW
B-07/02 HTW ANCHOR SYSTEM
B-07/03 HTWA
B-07/04 HTWU
B-07/05 HTWM
B-07/06 HTWS

SERIES B-08 :
The Corrugated Bullhorn is much like B-03 except with a wide base to
make it suitable for hand welding. Generally used in the Steel and
Petrochemical Industry.
Page Anchor style
B-08/01 CORRUGATED BULLHORN
B-08/02 CORRUGATE BULLHORN SYSTEM
B-08/03 MCBH
B-08/04 MSBH
Sirc Refractory Anchors Issue 1/2013

Date : 07 January 2003 Rev. 0

Page 7/11

ANCHORS FOR ONE COMPONENT LININGS (SERIES C)

SERIES C-01 :

The TWIN PIN anchor is a round sectioned anchor suited for applications
using a backup layer and light or heavy weight refractories. This anchor
can be hand welded, stud welded or bolted to the casing.

Page Anchor style

C-01/01 TWIN PIN
C-01/02 TWIN PIN SYSTEM
C-01/03 NSTP
C-01/04 NSTH
C-01/05 NSTB
C-01/06 NCTP
C-01/07 NCTH
C-01/08 NCTB
C-01/09 NHTP
C-01/10 NHTH
C-01/11 NHTB

SERIES C-02 :

The V ON NUT SYSTEM is a ’V’ shaped anchor welded onto a Nut suited
for dual concrete/backup linings.

Page Anchor style

C-02/01 V ON NUT
C-02/02 V ON NUT SYSTEM
C-02/03 OVNP
C-02/04 OVNM
C-02/05 OVNMCBH
C-02/06 OVNECH2
C-02/07 OVNECH3

SERIES C-03 :

The THREADED V / CH is a screw-on anchor suited for dual linings.

The advantages of this system are : low cost and quick availability.
Page Anchor style
C-03/01 THREADED V / CH
C-03/02 THREADED V / CH SYSTEM
C-03/03 QTCH1
C-03/04 QTCH2
C-03/05 QTV1
Sirc Refractory Anchors Issue 1/2013

Date : 07 January 2003 Rev. 0

Page 8/11

ANCHORS FOR ONE COMPONENT LININGS (SERIES D)

One of the fastest growing materials for heat conservation is ceramic fibre
in blanket, modules and board form. These high temperature fibres
provide fuel savings, operating flexibility and thermal shock resistance in
periodic and tunnel kilns, heating and annealing furnaces and
petrochemical process furnaces.

SIRC offers several systems suitable for anchoring ceramic fibre over
a range of temperature.

Shown here are several widely used systems: S, H and T at the end of
the code signify stud welding, hand welding or threaded fixing.

SERIES D-01 :
The R-Pin studs offer a support to steel plates when mounted on the hot
face. Allow for blanket as well as hard backup insulating systems.

Page Anchor style

D-01/01 R-PIN
D-01/02 R-PIN SYSTEM
D-01/03 RIPH
D-01/04 RIPS
D-01/05 RIPT
D-01/06 RTPH
D-01/07 RTPS
D-01/08 RTPT
D-01/09 SSRN
D-01/10 STSR
D-01/11 TSCD / TWCD
D-01/12 UCIP

SERIES D-02 :
The FIBERBLOCK studs are round in shape and offer dimensional stability.
These are used with LOCKWASHERS and/or CUPLOCKS.

Page Anchor style

D-02/01 FIBERBLOCK
D-02/02 FIBERBLOCK SYSTEM
D-02/03 FIBERBLOCK SYSTEM WITH CUPLOCKS

D-02/04 FIBERBLOCK SYSTEM FOR VENEERING

D-02/05 VFFH
D-02/06 VFFS
D-02/07 VFFT
D-02/08 ZLFF
D-02/09 ACFF
Sirc Refractory Anchors Issue 1/2013

Date : 07 January 2003 Rev. 0

Page 9/11

ANCHORS FOR ONE COMPONENT LININGS (SERIES D)

SERIES D-03 :
The PRESS ON CLIP system in combination with a threaded PDRS stud (M5
or M6) allows for 1mm increment adjustment of depth, quick installation
suitability in combination with fibre board and great cost effectiveness.
Suitability in combination with fibre board.

Page Anchor style

D-03/01 PRESS ON CLIP
D-03/02 PRESS ON CLIPC SYSTEM
D-03/03 WITH FIBRE BOARD
D-03/04 WITH METAL SHEET
D-03/05 BDRP
D-03/06 BDRS
D-03/07 BDRH
D-03/08 BDRT
D-03/09 END CLIPS
D-03/10 ECDR
D-03/11 SMTC
D-03/12 FLDR

SERIES D-04 :
The MAS / I MPU pins are specifically designed for a stack bonded
module, giving strong and reliable support. These can be combined with
R-Pins for use in dual lining constructions.
Page Anchor style
D-04/01 MAS
D-04/02 MAS SYSTEM
D-04/03 HMWC
D-04/04 RTPH
D-04/05 BDRS
D-04/06 RTMAR
D-04/07 FTMAW
D-04/08 HMWC
D-04/09 LMRC
D-04/10 IMPU
Sirc Refractory Anchors Brick Staple System Issue 1/2013

The STAPLE anchor for brick linings

ASTP1

ASTP2

ASTP3

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Staple
Updated :
07/01/2013 System Series :

A-01
This drawing is the property of Refrattari BRICK STAPLE
Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. A-01/01
Sirc Refractory Anchors Brick Staple System Issue 1/2013

The STAPLE anchor for brick linings

ASTP1

Anchor support Insulating panel Insulating refractory brick

This drawing is the property of Refrattari BRICK STAPLE

Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. A-01/02
Sirc Refractory Anchors Brick Staple System Issue 1/2013

Ordering examples and standard alloys available

Example ASTP1
ASTP1.6 - 30/150/60 - 310
Dmax = 7.1 mm
Dmin = 4.4 mm
Anchor type Diameter Length (WxLxS) Alloy type

W
ØD

This drawing is the property of Refrattari BRICK STAPLE

Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. A-01/03
Sirc Refractory Anchors Brick Staple System Issue 1/2013

Ordering examples and standard alloys available

Example ASTP2
ASTP2.6 - 50/260/80 - 310
Dmax = 12.0 mm
Dmin = 4.4 mm
Anchor type Diameter Length (WxLxS) Alloy type

W S

ØD

This drawing is the property of Refrattari BRICK STAPLE

Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. A-01/04
Sirc Refractory Anchors Brick Staple System Issue 1/2013

Ordering examples and standard alloys available

Example ASTP3
ASTP3.6 - 50/260/80 - 310
Dmax = 7.1 mm
Dmin = 4.4 mm
Anchor type Diameter Length (WxLxS) Alloy type

ØD

W R=10

This drawing is the property of Refrattari BRICK STAPLE

Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. A-01/05
Sirc Refractory Anchors Split “Y” System Issue 1/2013

The Split ’Y’ anchor system

BYA

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Split “Y”
Updated :
07/01/2013 System Series :

B-01
This drawing is the property of Refrattari SPLIT “Y”
Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-01/01
Sirc Refractory Anchors Split “Y” System Issue 1/2013

Ordering examples and standard alloys available

Example BYA
BYA. 30/4(60) - 150 ( 75 ) - 330
Anchor type Angle a Length L Step S Alloy type
B x Dmax = 80 x 8 mm

Strip Size B x D

ao

S
D

This drawing is the property of Refrattari SPLIT “Y”

Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-01/02
Sirc Refractory Anchors Symple “V” System Issue 1/2013

The Symple “ V ” type anchors

SV1

SV2

SV3

SV4

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Symple “V”
Updated :
07/01/2013 System Series :

B-02
This drawing is the property of Refrattari SIMPLE “V”
Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-02/01
Sirc Refractory Anchors Symple “V” System Issue 1/2013

The Symple “ V ” type anchors

Refractory SV4
FIBRETECH AISI 310

Steel casing

This drawing is the property of Refrattari SIMPLE “V”

Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-02/02
Sirc Refractory Anchors Symple “V” System Issue 1/2013

Ordering examples and standard alloys available

Example SV1
SV 1. 6 (60) - 065 (15) - 310 Dmax = 12.0 mm
Dmin = 4.0 mm

Anchor type Diameter (Angle a) Length L (c) Alloy type Lmax = 350 mm
Lmin = 20 mm

Available alloys ss 304, ss 310, ss 330, ss 321

ao

ØD
L

This drawing is the property of Refrattari SIMPLE “V”

Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-02/03
Sirc Refractory Anchors Symple “V” System Issue 1/2013

Ordering examples and standard alloys available

Example SV2
SV 2. 6 (70) - 125 (10) - 310 Dmax = 12.0 mm
Dmin = 4.0 mm

Anchor type Diameter (Angle a) Length L (c) Alloy type Lmax = 350 mm
Lmin = 35 mm

Available alloys ss 304, ss 310, ss 330, ss 321

ao
ØD

18

This drawing is the property of Refrattari SIMPLE “V”

Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-02/04
Sirc Refractory Anchors Symple “V” System Issue 1/2013

Ordering examples and standard alloys available

Example SV3
V 3.8(60)-250(10) / 20.30-310 Dmax = 12.0 mm
Dmin = 4.0 mm

Anchor type. Diam. (Angle a) Length L (c) Wings e1.e2 Alloy type Lmax = 325 mm
Lmin = 30 mm

Available alloys ss 304, ss 310, ss 330, ss 321

e2

e1
c

ØD ao

This drawing is the property of Refrattari SIMPLE “V”

Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-02/05
Sirc Refractory Anchors Symple “V” System Issue 1/2013

Ordering examples and standard alloys available

Example SV4
V 4.8(60)-125(10) / 15.25-310 Dmax = 12.0 mm
Dmin = 4.0 mm

Anchor type. Diam. (Angle a) Length L (c) Wings e1.e2 Alloy type Lmax = 325 mm
Lmin = 30 mm

Available alloys ss 304, ss 310, ss 330, ss 321

e2

e1
c

ao
ØD
L

18

This drawing is the property of Refrattari SIMPLE “V”

Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-02/06
Sirc Refractory Anchors Symple “V” System Issue 1/2013

Ordering examples and standard alloys available

Example SVM
SVM.8 (60) - 175 (25) - 310 Dmax = 12.0 mm
Dmin = 4.0 mm

Anchor type. Diam. (Angle a) Length L (c) Alloy type Lmax = 325 mm
Lmin = 50 mm

Available alloys ss 304, ss 310, ss 330, ss 321

ØD
c

ao

18- 25

This drawing is the property of Refrattari SIMPLE “V”

Sirc Srl. Unauthorised use of patented SYSTEM
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-02/07
Sirc Refractory Anchors Corrugated Bullhorn System Issue 1/2013

The CORRUGATED BULLHORN anchor for

Concrete linings

CSBS

CCBS

0.5L

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : Bullhorn
B-03
This drawing is the property of Refrattari Corrugated
Sirc Srl. Unauthorised use of patented
Bullhorn System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-03/01
Sirc Refractory Anchors Corrugated Bullhorn System Issue 1/2013

The CORRUGATED BULLHORN application

Refractory CCBS FIBRETECH AISI 310

Steel casing

This drawing is the property of Refrattari

Corrugated
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this Bullhorn System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-03/02
Sirc Refractory Anchors Corrugated Bullhorn System Issue 1/2013

Ordering examples and standard alloys available

Example CC B S
CCBS. 6 - 150 - 310
Dmax = 8.0 mm
Dmin = 6.0 mm
Anchor type Diameter Length Alloy type
Lmax = 350 mm
Lmin = 80 mm

ØD
25
o
60

50

15o

50
0.5L

35
25

This drawing is the property of Refrattari

Corrugated
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this Bullhorn System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-03/03
Sirc Refractory Anchors Corrugated Bullhorn System Issue 1/2013

Ordering examples and standard alloys available

Example CSBS
CSBS. 6 - 260 - 310
Dmax = 8.0 mm
Dmin = 6.0 mm
Anchor type Diameter Length Alloy type
Lmax = 350 mm
Lmin = 80 mm

25
ØD

25

60o

25

L
25

25

35
25

This drawing is the property of Refrattari

Corrugated
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this Bullhorn System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-03/04
Sirc Refractory Anchors Heavy Bullhorn System Issue 1/2013

Heavy duty BULLHORN anchor for

dense refractrory concrete linings

DHBH

0.6L

DHBV

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : Heavy Bullhorn
B-04
This drawing is the property of Refrattari Heavy
Sirc Srl. Unauthorised use of patented
Bullhorn System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-04/01
Sirc Refractory Anchors Heavy Bullhorn System Issue 1/2013

Heavy duty BULLHORN anchor for

dense refractrory concrete linings

Refractory DHBH
FIBRETECH AISI 310

Steel casing

This drawing is the property of Refrattari Heavy

Sirc Srl. Unauthorised use of patented
Bullhorn System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-04/02
Sirc Refractory Anchors Heavy Bullhorn System Issue 1/2013

Ordering examples and standard alloys available

Example DHBH
DHBH. 16 - 325 - 330
Dmax = 18.0 mm
Dmin = 10.0 mm
Anchor type Diameter Length Alloy type
Lmax = 800 mm
Lmin = 160 mm

Available alloys ss 304, ss 310, ss 330, ss 321

ØD 55o 60

60
15o

L
60

0.6L
60
D10 - B=35 mm
D12 - B=40 mm B
D16 - B=50 mm
D18 - B=50 mm
50

This drawing is the property of Refrattari

Heavy
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this Bullhorn System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-04/03
Sirc Refractory Anchors Heavy Bullhorn System Issue 1/2013

Ordering examples and standard alloys available

Example DHBR
DHBR. 12 - 360 - 310
Dmax = 18.0 mm
Dmin = 10.0 mm
Anchor type Diameter Length Alloy type
Lmax = 800 mm
Lmin = 160 mm

Available alloys ss 304, ss 310, ss 330, ss 321

ØD 55o
60

60
15o

L
60

D10 - B=35 mm 0.6L

D12 - B=40 mm 60

D16 - B=50 mm
D18 - B=50 mm B

50

This drawing is the property of Refrattari

Heavy
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this Bullhorn System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-04/04
Sirc Refractory Anchors Heavy Bullhorn System Issue 1/2013

Ordering examples and standard alloys available

Example DHBV
DHBV. 12 (50) - 360 - 310
Dmax = 18.0 mm
Dmin = 10.0 mm
Anchor type Diameter (Angle) Length Alloy type
Lmax = 800 mm
Lmin = 160 mm

Available alloys ss 304, ss 310, ss 330, ss 321

ØD 60

60

ao

L
60

D10 - B=35 mm
D12 - B=40 mm
D16 - B=50 mm
60
D18 - B=50 mm
B

50

This drawing is the property of Refrattari

Heavy
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this Bullhorn System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-04/05
Sirc Refractory Anchors Corrugated “H” System Issue 1/2013

The Corrugated ’H’ type anchors

ECH2

ECH3

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : Corrugated “H”
B-05
This drawing is the property of Refrattari
Corrugated “H”
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-05/01
Sirc Refractory Anchors Corrugated “H” System Issue 1/2013

The Corrugated ’H’ type anchors

These anchors to be
welded by hand only

For thermal shock application it is highly recommended that stainless steel fibres such FIBRETECH AISI 310 are
addend to reinforce the refractory concrete.

Refractory
FIBRETECH AISI 310 ECH3

Steel casing

This drawing is the property of Refrattari

Corrugated “H”
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-05/02
Sirc Refractory Anchors Corrugated “H” System Issue 1/2013

Ordering examples and standard alloys available

Example ECH1
ECH1. 6 (60) - 325 - 330
Dmax = 8.0 mm
Dmin = 5.0 mm
Anchor type Diameter (Angle) Length Alloy type
Lmax = 350 mm
Lmin = 30 mm

Available alloys ss 304, ss 310, ss 330, ss 321

ØD

ao

18

18

This drawing is the property of Refrattari

Corrugated “H”
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-05/03
Sirc Refractory Anchors Corrugated “H” System Issue 1/2013

Ordering examples and standard alloys available

Example ECH2
ECH2. 6 (70) - 125 - 310
Dmax = 8.0 mm
Dmin = 5.0 mm
Anchor type Diameter (Angle) Length Alloy type
Lmax = 350 mm
Lmin = 50 mm

Available alloys ss 304, ss 310, ss 330, ss 321

ØD ao

18

18

This drawing is the property of Refrattari

Corrugated “H”
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-05/04
Sirc Refractory Anchors Corrugated “H” System Issue 1/2013

Ordering examples and standard alloys available

Example ECH3
ECH3. 8 (60) - 250 - 330
Dmax = 8.0 mm
Dmin = 5.0 mm
Anchor type Diameter (Angle) Length Alloy type
Lmax = 325 mm
Lmin = 90 mm

Available alloys ss 304, ss 310, ss 330, ss 321

ØD ao

18

18

This drawing is the property of Refrattari

Corrugated “H”
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-05/05
Sirc Refractory Anchors Corrugated “H” System Issue 1/2013

Ordering examples and standard alloys available

Example ECH4
ECH4. 8 (60) - 225 - 310
Dmax = 8.0 mm
Dmin = 5.0 mm
Anchor type Diameter (Angle) Length Alloy type
Lmax = 325 mm
Lmin = 75 mm

Available alloys ss 304, ss 310, ss 330, ss 321

ØD ao

18

18

This drawing is the property of Refrattari

Corrugated “H”
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-05/06
Sirc Refractory Anchors Corrugated “V” Anchor Issue 1/2013

The Corrugated ’V’ anchors

FCV3 FCV2 FCV1

FCV x

Ferrule

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : “FCV” Anchor
B-06
This drawing is the property of Refrattari
“FCV” Round
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-06/01
Sirc Refractory Anchors Corrugated “V” Anchor Issue 1/2013

The CORRUGATED “V” anchors

Stud welding gun

The ceramic ring is broken off

and the anchor can be inspected.

The ECV3 anchor is suitable for heavy density concrete and offers superior holding power of the refractory due to the
3-dimensional corrugation of the anchor. FIBRETECH AISI 310 reinforcing fibres are recommended for maximum refractory
toughness and thermal shock resistance.

FCV3
FIBRETECH AISI 310

Steel casing

This drawing is the property of Refrattari

FCV Round
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-06/02
Sirc Refractory Anchors Corrugated “V” Anchor Issue 1/2013

Ordering examples and standard alloys available

Example FCV1
FCV1. 6 (60) - 250 (15) -310
Dmax = 8.0 mm
Dmin = 5.0 mm
Anchor type Diameter D (Angle A) Length L Alloy type Angle A° = 50° - 80°
Lmax = 35 mm
Lmin = 250 mm

If a length difference is required in height of legs then specify

the difference in length in brackets.

ØD

Ao

25

Use Ceramic Ferrules FFER-125 for D=5

Use Ceramic Ferrules FFER-126 for D=6
Use Ceramic Ferrules FFER-168 for D=8

This drawing is the property of Refrattari

FCV Round
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-06/03
Sirc Refractory Anchors Corrugated “V” Anchor Issue 1/2013

Ordering examples and standard alloys available

Example FCV2
FCV2. 6 (80) - 150 (00) -330
Dmax = 8.0 mm
Dmin = 5.0 mm
Anchor type Diameter D (Angle A) Length L Alloy type Angle A° = 50° - 80°
Lmax = 45 mm
Lmin = 250 mm

If a length difference is required in height of legs then specify

the difference in length in brackets.

ØD

Ao

25

Use Ceramic Ferrules FFER-125 for D=5

Use Ceramic Ferrules FFER-126 for D=6
Use Ceramic Ferrules FFER-168 for D=8

This drawing is the property of Refrattari

FCV Round
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-06/04
Sirc Refractory Anchors Corrugated “V” Anchor Issue 1/2013

Ordering examples and standard alloys available

Example FCV3
FCV3. 8 (60) - 225 (00) -310
Dmax = 8.0 mm
Dmin = 5.0 mm
Anchor type Diameter D (Angle A) Length L Alloy type Angle A° = 50° - 80°
Lmax = 85 mm
Lmin = 250 mm

If a length difference is required in height of legs then specify

the difference in length in brackets.

ØD

Ao

25

Use Ceramic Ferrules FFER-125 for D=5

Use Ceramic Ferrules FFER-126 for D=6
Use Ceramic Ferrules FFER-168 for D=8

This drawing is the property of Refrattari

FCV Round
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-06/05
Sirc Refractory Anchors HTW Anchors Issue 1/2013

The HTW series of anchors

HTW x

HTWA HTWM HTWS

HTWU

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : “HTW” Anchor
B-07
This drawing is the property of Refrattari
“HTW” Anchor
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-07/01
Sirc Refractory Anchors HTW Anchors Issue 1/2013

The HTW anchor application

FIBRETECH AISI 310 fibres are recommended for thermal shock resistance
FIBRETECH AISI 310
HTWM

Steel casing

This drawing is the property of Refrattari

HTW Anchor
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-07/02
Sirc Refractory Anchors HTW Anchors Issue 1/2013

Ordering examples and standard alloys available

Example HTWA
HTWA. 6 250 (125) - 310
Dmax = 12.0 mm
Dmin = 5.25 mm
Anchor type Diameter D Length L Alloy type Standard Angle A° = 60°
Lmax = 250 mm
Lmin = 45 mm

D5.25 > T = 13.0 mm

D6.00 > T = 13.0 mm
D8.00 > T = 13.0 mm or T = 20.0 mm When T=20 specify explicitly HTWA.8 B - 125 (050) - 310
D10.00 > T = 15.0 mm

ØD
60o

35 (B=45)

This drawing is the property of Refrattari

HTW Anchor
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-07/03
Sirc Refractory Anchors HTW Anchors Issue 1/2013

Ordering examples and standard alloys available

Example HTWU
HTWU. 8 100 (00) - 330
Dmax = 12.0 mm
Dmin = 5.25 mm
Anchor type Diameter D Length L Step S Alloy type Standard Angle A° = 60°
Lmax = 250 mm
Lmin = 65 mm

D5.25 > T = 13.0 mm

D6.00 > T = 13.0 mm
D8.00 > T = 13.0 mm or T = 20.0 mm When T=20 specify explicitly HTWU.8 B - 125 (050) - 310
D10.00 > T = 15.0 mm

ØD

60o

35 (B=45)

This drawing is the property of Refrattari

HTW Anchor
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-07/04
Sirc Refractory Anchors HTW Anchors Issue 1/2013

Ordering examples and standard alloys available

Example HTWM
HTWM. 8 225 (100) - 310
Dmax = 12.0 mm
Dmin = 5.25 mm
Anchor type Diameter D Length L Step S Alloy type Standard Angle A° = 60°
Lmax = 350 mm
Lmin = 85 mm

D5.25 > T = 13.0 mm

D6.00 > T = 13.0 mm
D8.00 > T = 13.0 mm or T = 20.0 mm When T=20 specify explicitly HTWU.8 B - 125 (050) - 310
D10.00 > T = 15.0 mm

ØD

60o

L
T

35 (B=45)

This drawing is the property of Refrattari

HTW Anchor
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-07/05
Sirc Refractory Anchors HTW Anchors Issue 1/2013

Ordering examples and standard alloys available

Example HTWS
HTWS. 10 325 (200) - 310
Dmax = 12.0 mm
Dmin = 5.25 mm
Anchor type Diameter D Length L Step S Alloy type Standard Angle A° = 60°
Lmax = 250 mm
Lmin = 45 mm

D5.25 > T = 13.0 mm

D6.00 > T = 13.0 mm
D8.00 > T = 13.0 mm or T = 20.0 mm When T=20 specify explicitly HTWU.8 B - 125 (050) - 310
D10.00 > T = 15.0 mm

ØD

100
60o

T L

35 (B=45)

This drawing is the property of Refrattari

HTW Anchor
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-07/06
Sirc Refractory Anchors Corrugated Bullhorn System Issue 1/2013

The Corrugated BULLHORN anchors

MSBH
60o

MCBH
60o

15o

0.5L

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : Corrugated Bullhorn
B-08
This drawing is the property of Refrattari
Corrugated
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
Bullhorn System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-08/01
Sirc Refractory Anchors Corrugated Bullhorn System Issue 1/2013

The Corrugated BULLHORN anchors

Typical applications for these anchors can be found in :

1. Cement Industries
2. Petrochemical industries

For thermal shock applications it is highly recommended that stainless steel fibres such as FIBRET ECH AISI 310
added to reinforce the refractory concrete.

Refractory MCBH
FIBRETECH AISI 310
Refractaire

Steel casing

This drawing is the property of Refrattari

Corrugated
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
Bullhorn System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-08/02
Sirc Refractory Anchors Corrugateg Bullhorn Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example MCBH
MCBH. 8 - 325 - 310
Dmax = 10.0 mm
Dmin = 5.25 mm
Anchor type Diameter Length Alloy type
Lmax = 350 mm
Lmin = 80 mm

Available alloys ss 304, ss 310, ss 330, inc 601

ØD

60o
25

25
15o

L 25

25

0.5L
B 25

15

D10 - B=35 mm
D8 - B=25 mm
D6 - B=20 mm These anchors are suitable for manual welding only
D5.25 - B=20 mm

This drawing is the property of Refrattari

Corrugated
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this Bullhorn System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-08/03
Sirc Refractory Anchors Corrugateg Bullhorn Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example MSBH
MSBH. 6 - 160 - 310
Dmax = 8.0 mm
Dmin = 5.25 mm
Anchor type Diameter Length Alloy type
Lmax = 250 mm
Lmin = 60 mm

Available alloys ss 304, ss 310, ss 330, inc 601

ØD

60o 25

25
L

B 25

15

D8 - B=25 mm
D6 - B=20 mm
D5.25 - B=15 mm

These anchors are suitable for manual welding only

This drawing is the property of Refrattari

Corrugated
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this Bullhorn System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. B-08/04
Sirc Refractory Anchors Twin Pin System Issue 1/2013

The TWIN PIN anchor system for dual linings

NCTP NSTP

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : Twin Pin anchor
C- 01
This drawing is the property of Refrattari
TWIN PIN
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-01/01
Sirc Refractory Anchors Twin Pin System Issue 1/2013

The TWIN PIN anchor system for dual linings

Stage 1. After welding, backup insulation is placed over the anchors.
Stage 2. A washer is then placed over the backup so that the tines can be opened at the backup layer
Stage 3. The tines are then opened at the desired angle (60o- 80o is recommended)

NCTP

Washer
Welding ferrule Backup insulation

Steel casing

This system is suggested for light and medium density refractory concretes.

This drawing is the property of Refrattari

TWIN PIN
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-01/02
Sirc Refractory Anchors Twin Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example NSTP
NSTP. 8 - 150 - 310
Drange = 5.25, 6.0 and 8.0 mm

Anchor type Diameter (D) Length (L) Alloy type

Lmin-max 5.25 mm= 45-250 mm
Lmin-max 6.00 mm= 45-350 mm
Lmin-max 8.00 mm= 50-450 mm

ØD L

Use the following respective washers

D5.25 = WRIN.30-0
11(2.0)-xxx
D6.00 = WRIN.30-012(2.0)-xxx
D8.00 = WRIN.38-016(2.0)-xxx

Use the following respective ferrules

D5.25 = FFER-125-000
D6.00 = FFER-126-000
D8.00 = FFER-168-000

This drawing is the property of Refrattari

TWIN PIN
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-01/03
Sirc Refractory Anchors Twin Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example NSTH
NSTH. 8 - 120/35 - 304
Drange = 5.25, 6.0 and 8.0 mm

Anchor type Diameter (D) Length (L/B) Alloy type

Lmin-max 5.25 mm= 45-250 mm
Lmin-max 6.00 mm= 45-350 mm
Lmin-max 8.00 mm= 50-450 mm

ØD

Use the following respective washers

D5.25 = WRIN.30-0-011(2.0)-XXX
D6.00 = WRIN.30-012(2.0)-xxx
D8.00 = WRIN.38-016(2.0)-xxx

This drawing is the property of Refrattari

TWIN PIN
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-01/04
Sirc Refractory Anchors Twin Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example NSTB
NSTB. 6 - 230/40 - 310
Drange = 5.25, 6.0 and 8.0 mm

Anchor type Diameter (D) Length (L/B) Alloy type

Lmin-max 5.25 mm= 45-250 mm
Lmin-max 6.00 mm= 45-350 mm
Lmin-max 8.00 mm= 50-450 mm

Use the following respective washers

D5.25 = WRIN.50-024(2.0)-xxx ØD
D6.00 = WRIN.50-027(2.0)-xxx
D8.00 = WRIN.60-030(2.0)-xxx

L
Use the following respective studs
either for hand welding or stud welding.

D5.25 = SDRx.10-027-xxx
D6.00 = SDRx.12-027-xxx
D8.00 = SDRx.12-027-xxx

B 13

This drawing is the property of Refrattari

TWIN PIN
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-01/05
Sirc Refractory Anchors Twin Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example NCTP
NCTP. 8 - 150 (040) - 310
Drange = 5.25, 6.0 and 8.0 mm

Anchor type Diameter (D) Length L (step S) Alloy type

Lmin-max 5.25 mm= 45-250 mm
Lmin-max 6.00 mm= 45-350 mm
Lmin-max 8.00 mm= 50-450 mm

18
Use the following respective
washers

D5.25 = WRIN. 30 - 011(2.0)-XXX 18

D6.00 = WRIN. 30 - 012(2.0)-XXX
D8.00 = WRIN. 38 - 016(2.0)-XXX

18

18

Displacement L
Dmin = 1.2D
18

18
Use the following ferrules
when stud welding.

18
D5.25 = FFER-125-000
D6.00 = FFER-126-000
D8.00 = FFER-168-000
ØD
S

This drawing is the property of Refrattari

TWIN PIN
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-01/06
Sirc Refractory Anchors Twin Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example NCTH
NCTH. 6 - 250/25 (90) - 330
Drange = 5.25, 6.0 and 8.0 mm

Anchor type Diameter (D) Length (L/B) (step s) Alloy type

Lmin-max 5.25 mm= 45-250 mm
Lmin-max 6.00 mm= 45-350 mm
Lmin-max 8.00 mm= 50-450 mm

18
Use the following respective
washers
D5.25 = WRIN. 30 - 011(2.0)-XXX 18
D6.00 = WRIN. 30 - 012(2.0)-XXX
D8.00 = WRIN. 38 - 016(2.0)-XXX

18

Displacement
Dmin = 1.2D
18

L
18

18

18

ØD

This drawing is the property of Refrattari

TWIN PIN
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-01/07
Sirc Refractory Anchors Twin Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example NCTB
NCTB. 8 - 125/50 (50) - 310
Drange = 5.25, 6.0 and 8.0 mm

Anchor type Diameter (D) Length (L/B) (step s) Alloy type

Lmin-max 5.25 mm= 45-250 mm
Lmin-max 6.00 mm= 45-350 mm
Lmin-max 8.00 mm= 50-450 mm

18

Use the following respective washers

D5.25 = WRIN.50-024(2.0)-xxx 18
D6.00 = WRIN.50-027(2.0)-xxx
D8.00 = WRIN.60-030(2.0)-xxx
18

Displacement
Dmin = 1.2D
18 L

Use the following respective studs 18

either for hand welding or stud welding.

D5.25 = SDRx.10-027-xxx 18
D6.00 = SDRx.12-027-xxx
D8.00 = SDRx.12-027-xxx

18

ØD
S

B 13

This drawing is the property of Refrattari

TWIN PIN
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-01/08
Sirc Refractory Anchors Twin Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example NHTP
NHTP. 10 - 250 (090) - 310
Drange = 8,00 and 10.0 mm

Anchor type Diameter (D) Length (L/B) (step s) Alloy type

Lmin-max 8.00 mm= 125-450 mm
Lmin-max 10.00 mm= 175-550 mm

25

Use the following respective washers

D 8.00 = WRIN.38-016(2.0)-xxx
D10.00 = WRIN.50-020(2.0)-xxx 25

Displacement
Dmin = 1.6D

25

25

Only 8,00 mm can be stud

welded. Use ferrule type 25

D8,00 = FFER-168-000

ØD S

This drawing is the property of Refrattari

TWIN PIN
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-01/09
Sirc Refractory Anchors Twin Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example NHTH
NHTH. 10 - 150/40 (90) - 310
Drange = 8,00 and 10.0 mm

Anchor type Diameter (D) Length (L/B) (step s) Alloy type Lmin-max 8,00 mm = 125-450 mm
Lmin-max 10.00 mm = 175-550 mm

25

Use the following respective washers

D 8.00 = WRIN.38-016(2.0)-xxx
D10.00 = WRIN.50-020(2.0)-xxx 25

25

Displacement
Dmin = 1.6D
L

25

25

ØD

This drawing is the property of Refrattari

TWIN PIN
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-01/10
Sirc Refractory Anchors Twin Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example NHTB
NHTB. 10 - 150/50 (80) - 310
Drange = 8,00 and 10.0 mm

Anchor type Diameter (D) Length (L/B) (step s) Alloy type Lmin-max 8,00 mm = 125-450 mm
Lmin-max 10.00 mm = 175-550 mm

25

Use the following respective washers

D 8.00 = WRIN.50-032(2.0)-xxx
D10.00 = WRIN.60-036(2.0)-xxx 25

25

Displacement
Dmin = 1.6D
L
25

25

ØD

B 15

This drawing is the property of Refrattari

TWIN PIN
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-01/11
Sirc Refractory Anchors “V” on Nut System Issue 1/2013

’V’ anchors welded on round Nut for dual linings

OVNM OVNP

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : ’V’ on Nut
C- 02
This drawing is the property of Refrattari
“V” ON NUT
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-02/01
Sirc Refractory Anchors “V” ON NUT System Issue 1/2013

’V’ anchors welded on round Nut for dual linings

Plastic cap
Backup insulation PDRS stud

OVNP FIBRETECH AISI 310

Steel casing

This drawing is the property of Refrattari

“V” ON NUT
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-02/02
Sirc Refractory Anchors “V” on Nut Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example OVNP
OVNP. 8(60) - 100(15) -310 M10
Drange = 5.25, 6.0 and 8.0 mm

Anchor type Diameter D (angle A°) Alloy type/Thread M

Lmin-max 5.25 mm= 45-250 mm
Lmin-max 6.00 mm= 45-350 mm
Length L(difference C) Lmin-max 8.00 mm= 50-450 mm

ØD

Ao

15

16 M*

This drawing is the property of Refrattari

“V” ON NUT
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-02/03
Sirc Refractory Anchors “V” on Nut Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example OVNM
OVNM. 6(60) - 125(10) -310 M10
Drange = 5.25, 6.0 and 8.0 mm

Anchor type Diameter D (angle A°) Alloy type/Thread M

Lmin-max 5.25 mm= 45-250 mm
Lmin-max 6.00 mm= 45-350 mm
Length L(difference C) Lmin-max 8.00 mm= 50-450 mm

ØD

Ao

15

16 M*

This drawing is the property of Refrattari

“V” ON NUT
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-02/04
Sirc Refractory Anchors “V” on Nut Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example O V N MCBH
OVNMCBH. 6(60) - 125 - 310 M10
Drange = 5.25, 6.0 and 8.0 mm

Anchor type (see section B-08 Alloy type/Thread M Lmin-max 6.00 mm= 80-300 mm
as reference for Lmin-max 8.00 mm= 100-350 mm
MCBH anchors)

15

M* 16

Available Round Nut sizes M8, M10 and M12.

This drawing is the property of Refrattari

“V” ON NUT
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-02/05
Sirc Refractory Anchors “V” on Nut Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example O V N ECH2
OVNECH2. 8(60) - 150(10)- 330 M8
Drange = 5.25, 6.0 and 8.0 mm

Anchor type (see section B-05 Alloy type/Thread M Lmin-max 5.25 mm= 45-250 mm
as reference for Lmin-max 6.00 mm= 50-350 mm
ECH2 anchors) Lmin-max 8.00 mm= 60-450 mm

15

M* 16

Available Round Nut sizes M8, M10 and M12.

This drawing is the property of Refrattari

“V” ON NUT
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-02/06
Sirc Refractory Anchors “V” on Nut Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example O V N ECH3
OVNECH3. 6(60) - 175(10) -310 M10
Drange = 5.25, 6.0 and 8.0 mm

Anchor type (see section B-05 Alloy type/Thread M

Lmin-max 5.25 mm= 75-250 mm
as reference for
Lmin-max 6.00 mm= 75-325 mm
ECH3 anchors) Lmin-max 8.00 mm= 90-350 mm

15

M* 16

Available Round Nut sizes M8, M10 and M12.

This drawing is the property of Refrattari

“V” ON NUT
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-02/07
Sirc Refractory Anchors Threaded V/CH System Issue 1/2013

The Threaded “V” and “CH” type anchors

QTCH1

QTCH2

These anchors are only suitable for screwing onto a stud

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : Threaded ’V / CH’
C- 03
This drawing is the property of Refrattari
Threaded “ V/CH”
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-03/01
Sirc Refractory Anchors “V” ON NUT System Issue 1/2013

The Threaded ’CH’ type anchors

QTCH2

Backup refractory lining

Réfractaire sous couche
PDRS

Steel casing

Hot-face refractory lining

FIBRETECH
AISI 310

This drawing is the property of Refrattari

Threaded “ V/CH”
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-03/02
Sirc Refractory Anchors Threaded V/CH Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example QT C H 1
QTCH1. 8(60) - 325 - 330 M8
Anchor type Diameter D (a°) Alloy type (M8) Lmax = 200 mm
Length L Lmin = 45 mm

Available alloys ss 304, ss 310, ss 330, inc 601

Ø8

ao

18

18
3

M8

These anchors are suitable for screwing over an M8 stud only

This drawing is the property of Refrattari

Threaded “V/CH ”
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-03/03
Sirc Refractory Anchors Threaded V/CH Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example QT C H 2
QTCH2. 8(70) - 125 - 310 M8
Anchor type Diameter D (a°) Alloy type (M8) Lmax = 200 mm
Length L Lmin = 45 mm

Available alloys ss 304, ss 310, ss 330, inc 601

Ø8
ao

18

18
3

M8

These anchors are suitable for screwing over an M8 stud only

This drawing is the property of Refrattari

Threaded “V/CH ”
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-03/04
Sirc Refractory Anchors Threaded V/CH Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example QTV1
QTV1. 12(60) - 125 - 310 M10 Dmax = 12.0 mm
Dmin = 8.0 mm

Anchor type Diameter D (a°) Alloy type (M*) Lmax = 250 mm

Length L Lmin = 45 mm

Available alloys ss 304, ss 310, ss 330, inc 601

ØD

ao

0.4 x D

M*

These anchors are suitable for screwing over an M8 or M10 stud only

This drawing is the property of Refrattari

Threaded “V/CH ”
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. C-03/05
Sirc Refractory Anchors R-Pin System Issue 1/2013

The R-Pin System

Type RIPH RIPS RIPT RTPS RTPH RTPT

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : R-Pin System
D- 01
This drawing is the property of Refrattari
R-Pin System
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/01
Sirc Refractory Anchors R-Pin System Issue 1/2013

The R-Pin System

This system is particularly suited for high gas velocity ducts. Several R-Pin systems can be used to
facilitate mounting of the steel plates.

RIPH Stainless Steel Plate Fibre Insulation

RING
SMTC

Steel casing

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented R-Pin System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/02
Sirc Refractory Anchors R-Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example RIPH
RIPH. 10 - 225(20) - 310 Dmax = 13.0 mm
Dmin = 5.25 mm

Anchor type Diameter Alloy type Lmax = 350 mm

Length L(Head H) Lmin = 30 mm

Available alloys Mild Steel, ss 304, ss 310, ss 330, ss 321

MIN1.5D

ØD

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
R-Pin System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/03
Sirc Refractory Anchors R-Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example RIPS
RIPS. 12 - 250(20) - 310 Dmax = 12.0 mm
Dmin = 5.25 mm

Anchor type Diameter Alloy type Lmax = 350 mm

Length L(Head H) Lmin = 35 mm

Available alloys Mild Steel, ss 304, ss 310, ss 330, ss 321

Use the following respective

ferrules
H

D 5.25 = FFER-052-000
D 6.00 = FFER-060-000
D 7.12 = FFER-072-000
D 8.00 = FFER-080-000
D 8.90 = FFER-089-000
D10.00 = FFER-100-000
D10.76 = FFER-107-000 MIN1.5D
D12.00 = FFER-120-000

ØD

Ferrule FER-xxx
These anchors are suitable for stud welding only

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
R-Pin System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/04
Sirc Refractory Anchors R-Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example RIPT
RIPT. 10 - 215(20) - 310 Dmax = 12.5 mm
Dmin = 5.25 mm

Anchor type Diameter Alloy type Lmax = 350 mm

Length L(Head H) Lmin = 50 mm

Available alloys Mild Steel, ss 304, ss 310, ss 330, ss 321

Diameters of stud with

respect to thread size.
H

D 5.25 = M6
D 7.12 = M8
D 8.90 = M10
D10.76 = M12

MIN1.5D

ØD

Ferrule FER-xxx
These anchors are suitable for stud welding only

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
R-Pin System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/05
Sirc Refractory Anchors Issue 1/2013

Ordering examples and standard alloys available

Example RTPH
RTPH. 10 - 125(30) - 310 Dmax = 12.0 mm
Dmin = 5.25 mm

Anchor type Diameter Alloy type Lmax = 350 mm

Length L(Head H) Lmin = 50 mm

Available alloys Mild Steel, ss 304, ss 310, ss 330, ss 321

M*
H

Diameters of stud with

respect to thread size.

D 5.25 = M6
D 7.12 = M8
D 8.90 = M10
D10.76 = M12 MIN1.5D

ØD

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
R-Pin System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/06
Sirc Refractory Anchors R-Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example RTPS
RTPS. 12 - 145(25) - 310 Dmax = 12.0 mm
Dmin = 6 mm

Anchor type Diameter Alloy type Lmax = 350 mm

Length L(Head H) Lmin = 50 mm

Available alloys Mild Steel, ss 304, ss 310, ss 330, ss 321

M*

Use the following respective

ferrules

M6 / D 5.25 = FFER-052-000
M8 / D 7.12 = FFER-072-000
M10 / D 8.90 = FFER-089-000
M12 / D10.76 = FFER-107-000
MIN1.5D

ØD

Ferrule FER-xxx
These anchors are suitable for Stud welding only

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
R-Pin System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/07
Sirc Refractory Anchors R-Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example RTPT
RTPT. 12 - 145(25) - 310 Dmax = 12.0 mm
Dmin = 6 mm

Anchor type Diameter Alloy type Lmax = 350 mm

Length L(Head H) Lmin = 50 mm

Available alloys Mild Steel, ss 304, ss 310, ss 330, ss 321

M*
H

Diameters of stud with

respect to thread size.

D 5.25 = M6
D 7.12 = M8
D 8.90 = M10
D10.76 = M12 MIN1.5D

ØD

M* 25

These anchors are fixed by bolting

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
R-Pin System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/08
Sirc Refractory Anchors R-Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example SRIN / SSRN

SSRN. 60 - 012(2.5) - 310 Hmax = 90 mm
Hmin = 25 mm

Anchor type Dia / Square (H) Alloy type Smax = 3.0 mm

Hoòe M* / Thick. S Smin = 1.0 mm

Available alloys Mild Steel, ss 304, ss 310, ss 330, ss 321

SRIN SSRN

ØH H

S S

Ø Dp Ø Dp

IMPORTANT !! Ø Dp = Pin or Thread diameter + 0.5 mm

Always specify PIN (Ø D) or THREAD (M*) DIAMETER in Product Code

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
R-Pin System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/09
Sirc Refractory Anchors R-Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example STRN / STSR

STSR. 50 - 010(5.0) - 310 Hmax = 90 mm
Hmin = 25 mm

Anchor type Dia / Square (H) Alloy type Smax = 3.0 mm

Hoòe M* / Thick. S Smin = 1.0 mm

Available alloys Mild Steel, ss 304, ss 310, ss 330, ss 321

STRN / STSR SCREW-ON WASHERS AREALWAYS THREADED

ØH H

S S

M* M*

STRN STSR

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
R-Pin System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/10
Sirc Refractory Anchors R-Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example TSCD / TWCD

TSCD. 040 - ST278 - support
TWCD. 055 - ST293 - s. washer Ø D = 55 mm

TWCD. 080 - ST279 - l. washer Ø D = 80 mm

Ø 8.7 Material : Mullite (max. 1300o C)

Suitable for 35 mm wide heating elements

3.0

Ø 23

TWCD
TSCD
30.0

ØD

2.0 94.0

38.0
7.0

5.0 Ø 28

Ø 20

Ø 32

Ø 58
This drawing is the property of Refrattari
Sirc Srl. Unauthorised use of patented
R-Pin System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/11
Sirc Refractory Anchors R-Pin Sysytem Issue 1/2013

Ordering examples and standard alloys available

Example UCIP
UCIP-150-099-Cuplock
Material : Alumina 99.0% (max. 1550o C)
Suitable for a minimum 200 mm lining
Ø 55

Top View Ø 27

Side View
160

Ø 55

Ø 18

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
R-Pin System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-01/12
Sirc Refractory Anchors Fiberblock System Issue 1/2013

The Fiberblock System

ZLFF040 ZFFH ZFFT ZFFS

310

ZLFF060
SIRC
310

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : Fiberblock System
D- 02
This drawing is the property of Refrattari
Sirc Srl. Unauthorised use of patented Fiberblock System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-02/01
Sirc Refractory Anchors Fiberblock System Issue 1/2013

The Fiberblock System

Application with ceramic fibre insulation.

Optional vapour
barrier VFFS
Fibre Insulation
ZLFF
SMTC

Steel casing

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented Fiberblock System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-02/02
Sirc Refractory Anchors Fiberblock System Issue 1/2013

The Fiberblock System with ceramic CUPLOCKS

Cuplocks may be filled with Fibre Insulation

ceramic fibre mastic as an ACFF-050-000
VFFS
option.

SMTC-045

Steel casing

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented Fiberblock System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-02/03
Sirc Refractory Anchors Fiberblock System Issue 1/2013

The Fiberblock System for veneering

Lining over Refractory

Old refractory concrete Ceramic Fibre Lining

Steel casing

ZLFF-060
VFFT

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented Fiberblock System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-02/04
Sirc Refractory Anchors Fiberblock System Issue 1/2013

Ordering examples and standard alloys available

Example VFFH
VFFH - 225 (20) - 310

Anchor type Alloy type Lmax = 550 mm

Length (Base B) Lmin = 35 mm

Available alloys ss 304, ss 308, ss 310, ss 330, Inc 601

These anchors are suitable for manual welding only

Ø 5.25

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented Fiberblock System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-02/05
Sirc Refractory Anchors Fiberblock System Issue 1/2013

Ordering examples and standard alloys available

Example VFFS
VFFS - 250 - 310

Anchor type Alloy type Lmax = 550 mm

Length Lmin = 35 mm

Available alloys ss 304, ss 308, ss 310, ss 330, inc 601

10

12.5

Ø 5.25

Use the following ferrule to weld VFFS

Bottom Curved
D 5.25 = FFER-052-000

These anchors are suitable for stud welding only

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented Fiberblock System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-02/06
Sirc Refractory Anchors Fiberblock System Issue 1/2013

Ordering examples and standard alloys available

Example VFFT
VFFT - 315/20 - 310

Anchor type Alloy type Lmax = 350 mm

Length L / M Lmin = 50 mm

Available alloys ss 304, ss 308, ss 310, ss 330, inc 601

Other qualities on request

10

12.5

Ø 5.25 M6
M6

D 10.0 = FFER-100-000
30 M6 M 30

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented Fiberblock System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-02/07
Sirc Refractory Anchors Fiberblock System Issue 1/2013

Ordering examples and standard alloys available

Example ZLFF
ZLFF 040 - 330
Anchor type Diameter Alloy type

Available alloys ss 304, ss 310, ss 330, inc 601

601

Ø 40
SIR C
330

Ø 60

26
10

ZLFF-040
50

ZLFF-060
This drawing is the property of Refrattari
Sirc Srl. Unauthorised use of patented Fiberblock System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-02/09
Sirc Refractory Anchors Fiberblock System Issue 1/2013

Ordering examples and standard alloys available

Example AC F F
ACFF - 050
Material : Mullite (max 1300o C)

These Cuplocks are only suitable for the use with the Fiberblock system

Top view of ACFF slot Ø 52

9.5

ACFF-050
Ø 52

69
9.5

ACFF-075

94
Ø 48

9.5

ACFF-025 36

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented Fiberblock System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-02/09
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

The Press On Clip System

BDRP BDRS BDRT BDRH

CPOC

CLPC

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : Press On Clip
D- 03
This drawing is the property of Refrattari
Sirc Srl. Unauthorised use of patented Press On Clip
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/01
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

The Press On Clip System

Application with ceramic fibre insulation. The clip is adjustable in 1 mm increments

Ceramic Fibre Insulation

CPOC
Steel casing

PDRS

CPOC

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
Press On Clip
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/02
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

The Press On Clip System

Application with ceramic fibre BOARD insulation. The clip is adjustable in 1 mm increments

CPOC
Steel casing

PLDRS

CPOC

Ceramic fibre BOARD Insulation

Backup fibre Insulation

This drawing is the property of Refrattari

Press On Clip
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/03
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

The Press On Clip System

Application with ceramic fibre insulation and a METAL SHEET. The clip is adjustable in 1 mm increments

CPOC
Steell casing

PDRS

Steel Plate
Ceramic Fibre Lining

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
Press On Clip
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/04
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

Ordering examples and standard alloys available

Example BD R P
BDRP . 6 - 225 - 310 Lmax = 550 mm
Lmin = 25 mm
Anchor type Thread (M) Length (L) Alloy type
Mmin = M5
Mmax = M20

Available alloys ss 304, ss 308, ss 310, ss 330, Inc 601

Note :
When L<100 mm, the threaded section is 0.5 L 50 / 0.5L

ØM

These anchors are suitable for manual welding only

This drawing is the property of Refrattari

Press On Clip
Sirc Srl. Unauthorised use of patented
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/05
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

Ordering examples and standard alloys available

Example BDRS
BDRS . 6 - 250 - 310 Lmax = 550 mm
Lmin = 25 mm
Anchor type Thread (M) Length (L) Alloy type
Mmin = M5
Mmax = M20

Available alloys ss 304, ss 308, ss 310, ss 330, Inc 601

Note :
When L<100 mm, the threaded section is 0.5 L 50 / 0.5L

ØM

L law

Use the following ferrule to weld BDRS

M6 5.25 = FFER-052-000
M8 7.12 = FFER-072-000
M10 8.90 = FFER-089-000
M12 10.76 = FFER-107-000

These anchors are suitable for stud welding only

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
Press On Clip
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/06
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

Ordering examples and standard alloys available

Example BDRH
BDRH . 8 - 315(30) - 330 Lmax = 550 mm
Lmin = 25 mm
Anchor type Thread (M) Length (L) Alloy type
Mmin = M5
Mmax = M20

Available alloys ss 304, ss 308, ss 310, ss 330, Inc 601

Note :
When L<100 mm, the threaded section is 0.5 L 50 / 0.5L

ØM

These anchors are suitable for manual welding only

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
Press On Clip
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/07
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

Ordering examples and standard alloys available

Example BDRT
BDRT . 8 - 200 - 330 Lmax = 550 mm
Lmin = 25 mm
Anchor type Thread (M) Length (L) Alloy type
Mmin = M5
Mmax = M20

Available alloys ss 304, ss 308, ss 310, ss 330, Inc 601

Note :
When L<100 mm, the threaded section is 0.5 L 50 / 0.5L

ØM

Cold face threaded section is standard 25 mm.

25

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
Press On Clip
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/08
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

Ordering examples and standard alloys available

Example End Clips

CPOC . 6 - 330
Anchor type For thread (M*) Alloy type

Available alloys ss 304, ss 308, ss 310, ss 330, Inc 601

CLPC CPOC

Ø 40

Ø 60

50

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
Press On Clip
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/09
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

Ordering examples and standard alloys available

Example ECD R
ECDR - 050
Material : Mullite (max 1300o C)
Cuplocks are only suitable for the use with BDRS.6 + M6 Nut

Top view of ECDR slot Ø 52

9.5

ECDR-050
Ø 52

9.5 69

ECDR-075

94
Ø 48

9.5

ECDR-025
36

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
Press On Clip
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/10
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

Ordering examples and standard alloys available

Example SMTC
SMTC - 045 - 302
Anchor type Diam. of hole (Ø M) Alloy type

ØM

42

T=0.3mm

37

Use the following combinations for different wire diameters D :

D= 3.00 mm SMTC-025
D= 4.00-5.00 mm SMTC-035
D= 5.00-6.00 mm SMTC-045
D= 7.12-8.00 mm SMTC-065
D= 8.90-10.0 mm SMTC-082

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
Press On Clip
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/11
Sirc Refractory Anchors PRESS ON Clip System Issue 1/2013

Ordering examples and standard alloys available

Example FL D R
FLDR . 6 - 040 - 310
Anchor type Thread (M 6) Diameter Alloy type

FLDRs are only suitable for the use with BDRS.6

Ø 40

M6

27

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
Press On Clip
feautures and / or and reproduction of this System
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-03/12
Sirc Refractory Anchors MAS System Issue 1/2013

Modular Anchoring System

FTMAW RTMAR

Flat Type Round Type

Commenced On : 07/01/2013 Drawn by :

SIRC Product description :

Updated :
07/01/2013 System Series : MAS System
D- 04
This drawing is the property of Refrattari
Sirc Srl. Unauthorised use of patented MAS System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-04/01
Sirc Refractory Anchors MAS System Issue 1/2013

Mechanical Anchoring System

FTMAW anchor is welded directly onto the casing

Steel casing
Ceramic Fibre Insulation

FTMAW

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented MAS System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-04/02
Sirc Refractory Anchors MAS System Issue 1/2013

Mechanical Anchoring System

Steel casing

HMWC
HMWC anchor is welded
directly onto the casing

Ceramic fibre Insulation

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented MAS System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-04/03
Sirc Refractory Anchors MAS System Issue 1/2013

Mechanical Anchoring System with backup layer

RTPH

Steel casing

Ceramic Fibre Lining

IMPU

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented MAS System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-04/04
Sirc Refractory Anchors MAS System Issue 1/2013

Mechanical Anchoring System without backup layer

IMPU

IMPU anchors interlink

Steel casing

Ceramic Fibre Lining

BDRS.8

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented MAS System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-04/05
Sirc Refractory Anchors MAS System Issue 1/2013

Ordering examples and standard alloys available

Example RTMAR
RTMAR6 . 050 - 225 / 50 - 310 Hmax = 550 mm
Hmin = 25 mm
Anchor type (D) Step (S) Length (H x P) Alloy type
Dmin = 4.4 mm
Dmax = 8.0 mm

Available alloys ss 304, ss 308, ss 310, ss 330, inc 601

ØD

25

S
13
This drawing is the property of Refrattari
Sirc Srl. Unauthorised use of patented
MAS System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-04/06
Sirc Refractory Anchors MAS System Issue 1/2013

Ordering examples and standard alloys available

Example FTM A W
FTMAW. 060 - 250 / 50 - 310 Hmax = 550 mm
Hmin = 25 mm
Anchor type Step (S) Length (H x P) Alloy type
Flat 12 x 3 mm only

Available alloy ss 310

35

S
12 15
This drawing is the property of Refrattari
Sirc Srl. Unauthorised use of patented
MAS System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-04/07
Sirc Refractory Anchors MAS System Issue 1/2013

Ordering examples and standard alloys available

Example HMWC
HMWC. 050 - 315 / 25 - 310 (1100) Hmax = 550 mm
Hmin = 25 mm
Anchor type Step (S) Length (H x P) Alloy type (R)
Flat 12 x 3 mm only

Available alloy ss 310

Rrad

S
12 15
This drawing is the property of Refrattari
Sirc Srl. Unauthorised use of patented
MAS System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-04/08
Sirc Refractory Anchors MAS System Issue 1/2013

Ordering examples and standard alloys available

Example LMRC
LMRC . 075 - 200 / 50 - 330 (750) Lmax = 350 mm
Lmin = 25 mm
Anchor type Step (S) Length (H x P) Alloy type (R)
Dmin = 4.4 mm
Dmax = 8.0 mm

Available alloys ss 304, ss 308, ss 310, ss 330, inc 601

R
ØD

25

S
13
This drawing is the property of Refrattari
Sirc Srl. Unauthorised use of patented
MAS System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-04/09
Sirc Refractory Anchors MAS System Issue 1/2013

Ordering examples and standard alloys available

Example IM P U
IMPU2.6.075.25(25/4)-250/50-330

Anchor type (D) (S) (X) (B) (T) (H) (P) Alloy

Available alloys ss 304, ss 308, ss 310, ss 330

ØD

Mechanically fixed to strip

H

T
B

P R=10
S

This drawing is the property of Refrattari

Sirc Srl. Unauthorised use of patented
MAS System
feautures and / or and reproduction of this
drawing is strictly prohibited.
VIA GULF ITALIANA, 1 - 26827 TERRANOVA DEI PASSERINI (LO) TEL. +39(0) 377 85329 FAX. +39(0) 377 855056 Dwg nr. D-04/10
