Planning Guide

EWT 9175 I EGN 9271 I EKB 9471

2 3
New dimensions
of refrigerating
and freezing.
⸺

ECBN 9673 I FrenchDoor

4 5
There are refrigerators.
And then there is Liebherr.
⸺
How do you deliver outstanding quality?
To always be one step ahead of technological
innovations? And to constantly set new
standards, even in design? By specialising in
what you can do best: building refrigerators and
freezers.

Every Liebherr development, every new feature,

operating element and design detail contains
over 65 years’ specialist experience in refrigeration
and freezing. This includes our luxury segment,
the fully integrated Monolith series.

You can’t get greater than the Monolith. And

we’re not just talking about its imposing height
of 2.13 metres. These appliances are more than
a new generation of fully integrated refrigerator
and freezer compartments and wine cabinets.
They are a statement.

A statement of exceptional quality and pioneering

technologies which make refrigeration
and freezing the highlight of the kitchen.
Discover the secret of their perfection.

EGN 9671 I EKB 9671

6 7
Model overview
⸺

Refrigerators Fridge-freezers

Model Features Door hinges 1 Panels ² Model Features Door hinges 1 Panels ²
on delivery *optional accessories on delivery *optional accessories

EKB 9271 variant -001 right, reversible customer-spec. door panel / ECBN 9471 variant -001 right, reversible customer-spec. door panel /
*stainless steel panel variant -617 left, reversible *stainless steel panel set
61.0 76.2

EKB 9471 variant -001 right, reversible customer-spec. door panel / ECBN 9671 variant -001 right, reversible customer-spec. door panel /
*stainless steel panel variant -617 left, reversible *stainless steel panel set
76.2 91.4

EKB 9671 variant -001 right, reversible customer-spec. door panel / ECBN 9673 variant -001 left, fixed / right, fixed customer-spec. door panel /
*stainless steel panel (FrenchDoor) *stainless steel panel set
91.4 91.4

Freezers Wine cabinets

Model Features Door hinges 1 Panels ² Model Features Door hinges 1 Panels ²
on delivery *optional accessories on delivery *optional accessories

EGN 9171 variant -617 left, reversible customer-spec. door panel / EWT 9175 variant -001 right, reversible customer-spec. door panel /
*stainless steel panel variant -617 left, reversible *stainless steel panel
45.7 45.7

EGN 9271 variant -617 left, reversible customer-spec. door panel / EWT 9275 variant -001 right, reversible customer-spec. door panel /
*stainless steel panel variant -617 left, reversible *stainless steel panel
61.0 61.0

EGN 9471 variant -617 left, reversible customer-spec. door panel /

*stainless steel panel
76.2

EGN 9671 variant -617 left, reversible customer-spec. door panel /

*stainless steel panel
91.4

¹ Door hinge exchange set on page 55 required for reversing hinges. Reversals to be performed by a Liebherr authorised engineer.
² Door panel dimensions and weights on pages 52/53 & 57.

8 9
Side-by-Side combinations
⸺
The Monolith series offers a range of options for your new dream kitchen, as a stand-alone unit or a Side-by-Side combination,
consisting of two or more appliances. Discreetly installed behind the respective kitchen panels or as a visible design highlight
enhanced with matt polish stainless steel panels and selected handles, the possibilities for optimal storage of foods and wine
are endless. Some common combinations are listed below as an example.

The Side-by-Side set on page 54 is required if there is less than 102 mm spacing between appliances.
Please refer to page 59 for detailed information about the cut-out niche measurements.

Examples
(all depicted with a stainless steel panel and angular handle made of brushed aluminium, available as an accessory)

Cut-out width 106.7 cm Cut-out width 121.9 cm Cut-out width 182.9 cm Cut-out width 213.4 cm

45.7 61.0 45.7 76.2 91.4 91.4 76.2 61.0 76.2

EGN 9171 I EKB 9271 EWT 9175 I ECBN 9471 ECBN 9671 I ECBN 9671 EGN 9471 I EWT 9275 I EKB 9471

Cut-out width 137.2 cm Cut-out width 152.4 cm Cut-out width 243.8 cm Cut-out width 274.3 cm

61.0 76.2 76.2 76.2 91.4 61.0 91.4 45.7 91.4 91.4 45.7

EWT 9275 I EKB 9471 EGN 9471 I EKB 9471 ECBN 9671 I EWT 9275 I ECBN 9671 EWT 9175 I EGN 9671 I EKB 9671 I EWT 9175

10 11
Refrigerators

EGN 9171 I EKB 9471

12 13
Refrigerators
Features
⸺

InfinitySwipe SmartDevice BioFresh-Plus

The InfinitySwipe electronic touch control consists of a The Monolith is supplied with a SmartDeviceBox which At a temperature of slightly above 0 °C and in controllable humidity, fruit and vegetables, meat and dairy products keep fresh for
bright and clear 3.5 inch display and, with “touch & swipe” establishes a connection between a smartphone or tablet considerably longer than in a conventional refrigeration compartment as a result of BioFresh technology. While the practical
technology, is intuitive to use. and the Monolith. This allows settings and functions to be FlexSystem helps with the sorting and clear organisation in the preferred BioFresh safe. the InfinityBeam LED lighting ensures
activated also while you are on the move. Push messages perfect illumination of the BioFresh safes. The third BioFresh safe in the Monolith goes a step further: Here it can reach temperatures
report, for example, open doors.* of -2 °C, ideal for the storage of fresh fish and seafood. However, drinks can also be cooled down quickly in this safe. All BioFresh
safes are equipped with SoftTelescopic, the convenient self-closing mechanism gentle cushioned door closure, making it practical
*SmartDevice functions not available in all countries. and safe for everyday use.

InfinitySpring PowerCooling InfinityLight Flexible door rack & storage shelves

The InfinitySpring water dispenser is flush-mounted, making The high-performance PowerCooling system ensures rapid The full-surface integrated LED lighting on the side wall The generous door racks provide plenty of space even for
it virtually invisible and allows standard-sized containers to and even cooling of food in the interior and – due to the creates an elegant and even light throughout the entire very large bottles and containers with a volume of several
be filled with cold water. A replaceable water filter ensures a special air ducting – also of food stored in the door racks. refrigeration compartment. This produces a soft light when litres. All storage shelves in the interior are made from
constant supply of pure water. This is easily accessible and is The integrated FreshAir activated charcoal filter prevents the door is opened. The stunning InfinityLight not only adds safety glass and are easily height-adjustable. This provides
located in the front section of the appliance plinth. odours from forming and cleans the incoming air. flair, but thanks to the reduced heat emission, also protects plenty of scope for use to meet your needs and individual
the quality of the food. requirements.

14 15
Refrigerator Refrigerator

Appliance dimensions
602 mm
IMPORTANT! Inset door panel
The adjustable feet are fully retracted A = 273 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 658 mm
EKB 9271 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
Energy efficiency class raised using the adjustable feet – in A = 279 mm
each case from the front of the appliance – B = 12.5 mm
Energy consumption in kWh (year / 24h) 156 / 0.427
so that the appliance comes into C = 670 mm
Noise output in dB(A) / Noise class 37 / C contact with the anti-tipping device. To
Total volume* in litres 335 achieve the minimal plinth panel height Dimension A = without
of 102 mm, the adjustable feet have to fitted door handle
Volume of refrigerator compartment in litres 192.9
be raised by 6 to 8 mm. If the plinth
Volume of BioFresh compartment in litres 142.4 panel should be higher than 102 mm,
Number of storage shelves, of which height-adjustable 4/3 the adjustable feet can be raised by a
Number of door racks 3 maximum of 19 mm.

Number of BioFresh / BioFresh-Plus safes with LED lighting

Electronic control system
2/1
InfinitySwipe
Recess dimensions A
Unit depth
Automatic SuperCool function yes Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Temperature range of refrigerator in °C +2 °C to +7 °C with inset door panel installation: 635 mm + thickness
Defrosting method automatic 610 mm 610 mm
of the custom panel. Further details on page 57.

Interior lighting InfinityLight B

Point at which the mains cable exits from the rear of the
Integrated water dispenser no D D D D
76 mm 76 mm 76 mm 76 mm
appliance (19 mm from the left and 127 mm from the
Water filter no floor). The free length of the mains cable is 2.5 m.
Door hinge right, reversible**
C
Appliance dimensions in cm (H / W / D) 212.6 / 60.2 / 61 2134 mm 2134 mm The appliance has a recess in this area for cable and
Recess dimensions in cm (H / W / D) 213.4 / 61 / 63.5 water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
Net weight in kg 152.0

72 - 106 mm
Voltage in V~ / Connected load in A 220-240 / 1.5 B B D
E C E This surface is visible when the appliance door is
C
A A opened. Designed finish is therefore recommended.
102 mm
E
The anti-tipping device positioned at the base of the
appliance must be secured to the floor or to the wall.
61.0 * In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer
(rounded off) and the volume of the frozen compartments and refrigeration compartments to one
Door panel dimensions
place after the decimal point.
and dimensions of free length for power
** Please contact the authorised Liebherr Monolith customer service for reversing the door hinge.
You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a. Inset installation
B
W H = 2029 mm
Optional accessories
W = 603 mm

· Flat brushed aluminium handle Overlay installation

H = 2032 mm
· Square brushed aluminium handle (plus the dimensions of overlapping of the panel on
· Round stainless steel handle the top)
· Stainless steel panel H W = 610 mm
· Stainless steel plinth panel (plus the dimensions of overlapping of the panel on
· Side-by-Side set both sides)
· Door hinge exchange set Thickness of the panel: min. 16 mm* / max. 30 mm
Weight of panel: max. 30 kg
~2400 ~1850 C
Optional accessories on page 52-55. Installations behind the appliance are not possible.
* If a five-piece shaker style panel is used, which is thinner than the minimum panel thickness, shorter screws than those supplied in the accessory pack must be used.

For further relevant planning and safety requirements, see pages 56-63.
16 17
Refrigerator Refrigerator

Appliance dimensions
754 mm
IMPORTANT! Inset door panel
The adjustable feet are fully retracted A = 337 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 810 mm
EKB 9471 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
Energy efficiency class raised using the adjustable feet – in A = 343 mm
each case from the front of the appliance – B = 12.5 mm
Energy consumption in kWh (year / 24h) 171 / 0.468
so that the appliance comes into C = 822 mm
Noise output in dB(A) / Noise class 37 / C contact with the anti-tipping device. To
Total volume* in litres 440 achieve the minimal plinth panel height Dimension A = without
of 102 mm, the adjustable feet have to fitted door handle
Volume of refrigerator compartment in litres 250.5
be raised by 6 to 8 mm. If the plinth
Volume of BioFresh compartment in litres 190.3 panel should be higher than 102 mm,
Number of storage shelves, of which height-adjustable 4/3 the adjustable feet can be raised by a
3 maximum of 19 mm.
Number of door racks
Number of BioFresh / BioFresh-Plus safes with LED lighting
Electronic control system
2/1
InfinitySwipe
Recess dimensions A
Unit depth
Automatic SuperCool function yes Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Temperature range of refrigerator in °C +2 °C to +7 °C with inset door panel installation: 635 mm + thickness
Defrosting method automatic 762 mm 762 mm
of the custom panel. Further details on page 57.

Interior lighting InfinityLight B

Point at which the mains cable exits from the rear of the
Integrated water dispenser /Fixed water connection 3/4" InfinitySpring D D D D
76 mm 76 mm 76 mm 76 mm
appliance (19 mm from the left and 127 mm from the
Water filter yes floor). The free length of the mains cable is 2.5 m.
Door hinge right, reversible**
C
Appliance dimensions in cm (H / W / D) 212.6 / 75.4 / 61 2134 mm 2134 mm The appliance has a recess in this area for cable and
Recess dimensions in cm (H / W / D) 213.4 / 76.2 / 63.5 water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
Net weight in kg 179.0

72 - 106 mm
Voltage in V~ / Connected load in A 220-240 / 1.5 B B D
E E This surface is visible when the appliance door is
C C
A A opened. Designed finish is therefore recommended.
102 mm
E
The anti-tipping device positioned at the base of the
appliance must be secured to the floor or to the wall.
76.2 * In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer
(rounded off) and the volume of the frozen compartments and refrigeration compartments to one
Door panel dimensions
place after the decimal point.
and dimensions of free length for power / water
** Please contact the authorised Liebherr Monolith customer service for reversing the door hinge.
You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a. Inset installation
B
W H = 2029 mm
Optional accessories W = 756 mm

· Flat brushed aluminium handle Overlay installation

H = 2032 mm
· Square brushed aluminium handle (plus the dimensions of overlapping of the panel on
· Round stainless steel handle the top)
· Stainless steel panel H W = 762 mm
· Stainless steel plinth panel (plus the dimensions of overlapping of the panel on
· Side-by-Side set both sides)
· Door hinge exchange set ~1850 ~2250 Thickness of the panel: min. 16 mm* / max. 30 mm
Weight of panel: max. 35 kg
~2400 ~1700 C
Optional accessories on page 52-55. Installations behind the appliance are not possible.
* If a five-piece shaker style panel is used, which is thinner than the minimum panel thickness, shorter screws than those supplied in the accessory pack must be used.

For further relevant planning and safety requirements, see pages 56-63.
18 19
Refrigerator Refrigerator

Appliance dimensions
906 mm
IMPORTANT! Inset door panel
The adjustable feet are fully retracted A = 400 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 962 mm
EKB 9671 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
Energy efficiency class raised using the adjustable feet – in A = 406 mm
each case from the front of the appliance – B = 12.5 mm
Energy consumption in kWh (year / 24h) 185 / 0.506
so that the appliance comes into C = 975 mm
Noise output in dB(A) / Noise class 37 / C contact with the anti-tipping device. To
Total volume* in litres 542 achieve the minimal plinth panel height Dimension A = without
of 102 mm, the adjustable feet have to fitted door handle
Volume of refrigerator compartment in litres 308.0
be raised by 6 to 8 mm. If the plinth
Volume of BioFresh compartment in litres 234.8 panel should be higher than 102 mm,
Number of storage shelves, of which height-adjustable 4/3 the adjustable feet can be raised by a
3 maximum of 19 mm.
Number of door racks
Number of BioFresh / BioFresh-Plus safes with LED lighting
Electronic control system
2/1
InfinitySwipe
Recess dimensions A
Unit depth
Automatic SuperCool function yes Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Temperature range of refrigerator in °C +2 °C to +7 °C with inset door panel installation: 635 mm + thickness
Defrosting method automatic 914 mm 914 mm
of the custom panel. Further details on page 57.

Interior lighting InfinityLight B

Point at which the mains cable exits from the rear of the
Integrated water dispenser / Fixed water connection 3/4" InfinitySpring D D D D
76 mm 76 mm 76 mm 76 mm
appliance (19 mm from the left and 127 mm from the
Water filter yes floor). The free length of the mains cable is 2.5 m.
Door hinge right, reversible**
C
Appliance dimensions in cm (H / W / D) 212.6 / 90.6 / 61 2134 mm 2134 mm The appliance has a recess in this area for cable and
Recess dimensions in cm (H / W / D) 213.4 / 91.4 / 63.5 water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
Net weight in kg 198.0

72 - 106 mm
Voltage in V~ / Connected load in A 220-240 / 1.5 B B D
E E This surface is visible when the appliance door is
C C
A A opened. Designed finish is therefore recommended.
102 mm
E
The anti-tipping device positioned at the base of the
appliance must be secured to the floor or to the wall.
91.4 * In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer
(rounded off) and the volume of the frozen compartments and refrigeration compartments to one
Door panel dimensions
place after the decimal point.
and dimensions of free length for power / water
** Please contact the authorised Liebherr Monolith customer service for reversing the door hinge.
You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a. Inset installation
B
W H = 2029 mm
Optional accessories
W = 908 mm

· Flat brushed aluminium handle Overlay installation

H = 2032 mm
· Square brushed aluminium handle (plus the dimensions of overlapping of the panel on
· Round stainless steel handle the top)
· Stainless steel panel H W = 914 mm
· Stainless steel plinth panel (plus the dimensions of overlapping of the panel on
· Side-by-Side set both sides)
· Door hinge exchange set ~1775 ~2175 Thickness of the panel: min. 16 mm* / max. 30 mm
Weight of panel: max. 40 kg
~2400 ~1550 C
Optional accessories on page 52-55. Installations behind the appliance are not possible.
* If a five-piece shaker style panel is used, which is thinner than the minimum panel thickness, shorter screws than those supplied in the accessory pack must be used.

For further relevant planning and safety requirements, see pages 56-63.
20 21
Freezers

EGN 9171 I EKB 9471

22 23
Freezers
Features
⸺

IceMaker NoFrost

The automatic IceMaker creates 1.6 kg of filtered ice in 24 NoFrost technology freezes frozen food with cooled re-circulated air and removes the humidity. This keeps the freezer compartment
hours. The production capacity can be increased even further ice-free at all times, and food is no longer covered in frost. NoFrost convenience means defrosting is no longer necessary. The
by activating the SuperFrost function. With a storage volume enclosed removable freezer drawers of the FrostSafe system protect the frozen food from unwanted air exchange and from the loss
of 1.8 kg to 3.5 kg (depending on the model), there is always of cold air when the door is opened. The drawers are transparent and fitted with telescopic rails and the InfinityBeam LED lighting to
sufficient ice available. A replaceable water filter is located provide a perfect overview. All drawers are equipped with SoftTelescopic: the convenient self-closing mechanism gentle cushioned
in the front section of the appliance plinth and is easily door closure, making it practical and safe for everyday use.
accessible.

SoftSystem InfinityLight Flexible door rack SuperFrost

Thanks to the SoftSystem closing damping, the doors close The full-surface integrated LED lighting on the side wall In the Monolith, food is stored not only in innovative, The SuperFrost function quickly lowers the temperature to
gently and quietly even when fully loaded. Depending on the creates an elegant and even light throughout the entire smooth-running freezer drawers but also in the door. The preserve vitamins when freezing. Once the freezing is complete,
size of the Monolith, its door hinges can hold up to 40 kg. freezer compartment. This produces a soft light when the transparent door racks in the freezer door are height-adjustable, it switches back to normal operation after a maximum of
door is opened. The stunning InfinityLight not only adds flair, providing lots of space for smaller items. The special air 65 hours and helps save electricity. This and other functions
but thanks to the reduced heat emission, also protects the ducting system in the freezer area ensures that the cold can also be easily controlled via SmartDevice services when
quality of the food. air is able to move constantly. This keeps the temperature you are on the move.*
constant, which optimises food storage.
*SmartDevice functions not available in all countries.

24 25
Freezer Freezer

Appliance dimensions
450 mm
IMPORTANT! Inset door panel
The adjustable feet are fully retracted A = 210 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 505 mm
EGN 9171 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
Energy efficiency class raised using the adjustable feet – in A = 216 mm
each case from the front of the appliance – B = 12.5 mm
Energy consumption in kWh (year / 24h) 311 / 0.851 so that the appliance comes into C = 517 mm
Noise output in dB(A) / Noise class 37 / C contact with the anti-tipping device. To
Total volume* in litres 245 achieve the minimal plinth panel height Dimension A = without
of 102 mm, the adjustable feet have to fitted door handle
Number of storage shelves, of which height-adjustable 4/3
be raised by 6 to 8 mm. If the plinth
Number of door racks 3 panel should be higher than 102 mm,
Number of FrostSafe drawers 3 the adjustable feet can be raised by a
Electronic control system
maximum of 19 mm.
InfinitySwipe
Automatic SuperFrost function
Temperature range of freezer in °C
yes
-14 °C to -27 °C
Recess dimensions A
Unit depth
Defrosting method automatic Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Interior lighting InfinityLight with inset door panel installation: 635 mm + thickness
IceMaker fixed water connection 3 / 4" 457 mm 457 mm
of the custom panel. Further details on page 57.

Water filter yes B

Point at which the mains cable exits from the rear of the
Ice cube production in 24 h / in kg 1.3 D D D D
76 mm 76 mm 76 mm 76 mm
appliance (19 mm from the left and 127 mm from the
Ice cube storage capacity in kg 1.8 floor). The free length of the mains cable is 2.5 m.
Storage time in event of a fault in hours 8
C
Freezing capacity in 24 h / in kg 16 2134 mm 2134 mm The appliance has a recess in this area for cable and
Door hinge left, reversible** water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
Appliance dimensions in cm (H / W / D) 212.6 / 45 / 61

72 - 106 mm
Recess dimensions in cm (H / W / D) 213.4 / 45.7 / 63.5 B B D
E E This surface is visible when the appliance door is
Net weight in kg 136.0 C C
A A opened. Designed finish is therefore recommended.
102 mm
Voltage in V~ / Connected load in A 220-240 / 2.0
E
The anti-tipping device positioned at the base of the
appliance must be secured to the floor or to the wall.
45.7 Door panel dimensions
and dimensions of free length for power / water
* In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer
(rounded off). Inset installation
B
W H = 2029 mm
Optional accessories ** Please contact the authorised Liebherr Monolith customer service for reversing the door hinge.
W = 451 mm
You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a.

· Flat brushed aluminium handle Overlay installation

H = 2032 mm
· Square brushed aluminium handle (plus the dimensions of overlapping of the panel on
· Round stainless steel handle the top)
· Stainless steel panel H W = 457 mm
· Stainless steel plinth panel (plus the dimensions of overlapping of the panel on
· Side-by-Side set both sides)
· Door hinge exchange set ~2000 ~2400 Thickness of the panel: min. 16 mm* / max. 30 mm
Weight of panel: max. 25 kg
~2400 ~2000 C
Optional accessories on page 52-55. Installations behind the appliance are not possible.
* If a five-piece shaker style panel is used, which is thinner than the minimum panel thickness, shorter screws than those supplied in the accessory pack must be used.

For further relevant planning and safety requirements, see pages 56-63.
26 27
Freezer Freezer

Appliance dimensions
602 mm
IMPORTANT! Inset door panel
The adjustable feet are fully retracted A = 273 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 658 mm
EGN 9271 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
Energy efficiency class raised using the adjustable feet – in A = 279 mm
each case from the front of the appli- B = 12.5 mm
Energy consumption in kWh (year / 24h) 359 / 0.984 ance – so that the appliance comes into C = 670 mm
Noise output in dB(A) / Noise class 37 / C contact with the anti-tipping device. To
Total volume* in litres 352 achieve the minimal plinth panel height Dimension A = without
of 102 mm, the adjustable feet have to fitted door handle
Number of storage shelves, of which height-adjustable 4/3
be raised by 6 to 8 mm. If the plinth
Number of door racks 3 panel should be higher than 102 mm, the
Number of FrostSafe drawers 3 adjustable feet can be raised by a maxi-
mum of 19 mm.
Electronic control system InfinitySwipe
Automatic SuperFrost function
Temperature range of freezer in °C
yes
-14 °C to -27 °C
Recess dimensions A
Unit depth
Defrosting method automatic Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Interior lighting InfinityLight with inset door panel installation: 635 mm + thickness
IceMaker fixed water connection 3 / 4" 610 mm 610 mm
of the custom panel. Further details on page 57.

Water filter yes B

Point at which the mains cable exits from the rear of the
Ice cube production in 24 h / in kg 1.1 D D D D
76 mm 76 mm 76 mm 76 mm
appliance (19 mm from the left and 127 mm from the
Ice cube storage capacity in kg 2.4 floor). The free length of the mains cable is 2.5 m.
Storage time in event of a fault in hours 18
C
Freezing capacity in 24 h / in kg 12 2134 mm 2134 mm The appliance has a recess in this area for cable and
Door hinge left, reversible** water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
Appliance dimensions in cm (H / W / D) 212.6 / 60.2 / 61

72 - 106 mm
Recess dimensions in cm (H / W / D) 213.4 / 61 / 63.5 B B D
E C E This surface is visible when the appliance door is
Net weight in kg 156.0 C
A A opened. Designed finish is therefore recommended.
102 mm
Voltage in V~ / Connected load in A 220-240 / 2.0
E
The anti-tipping device positioned at the base of the
appliance must be secured to the floor or to the wall.
61.0 Door panel dimensions
and dimensions of free length for power / water
* In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer
(rounded off). Inset installation
B
W H = 2029 mm
Optional accessories ** Please contact the authorised Liebherr Monolith customer service for reversing the door hinge.
You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a. W = 603 mm

· Flat brushed aluminium handle Overlay installation

H = 2032 mm
· Square brushed aluminium handle (plus the dimensions of overlapping of the panel on
· Round stainless steel handle the top)
· Stainless steel panel H W = 610 mm
· Stainless steel plinth panel (plus the dimensions of overlapping of the panel on
· Side-by-Side set both sides)
· Door hinge exchange set ~1925 ~2325 Thickness of the panel: min. 16 mm* / max. 30 mm
Weight of panel: max. 30 kg
~2400 ~1850 C
Optional accessories on page 52-55. Installations behind the appliance are not possible.
* If a five-piece shaker style panel is used, which is thinner than the minimum panel thickness, shorter screws than those supplied in the accessory pack must be used.

For further relevant planning and safety requirements, see pages 56-63.
28 29
Freezer Freezer

Appliance dimensions
754 mm
IMPORTANT! Inset door panel
The adjustable feet are fully retracted A = 337 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 810 mm
EGN 9471 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
Energy efficiency class raised using the adjustable feet – in A = 343 mm
each case from the front of the appliance – B = 12.5 mm
Energy consumption in kWh (year / 24h) 407 / 1.115 so that the appliance comes into C = 822 mm
Noise output in dB(A) / Noise class 38 / C contact with the anti-tipping device. To
Total volume* in litres 457 achieve the minimal plinth panel height Dimension A = without
of 102 mm, the adjustable feet have to fitted door handle
Number of storage shelves, of which height-adjustable 4/3
be raised by 6 to 8 mm. If the plinth
Number of door racks 3 panel should be higher than 102 mm,
Number of FrostSafe drawers 3 the adjustable feet can be raised by a
maximum of 19 mm.
Electronic control system InfinitySwipe
Automatic SuperFrost function
Temperature range of freezer in °C
yes
-14 °C to -27 °C
Recess dimensions A
Unit depth
Defrosting method automatic Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Interior lighting InfinityLight with inset door panel installation: 635 mm + thickness
IceMaker fixed water connection 3 / 4" 762 mm 762 mm
of the custom panel. Further details on page 57.

Water filter yes B

Point at which the mains cable exits from the rear of the
Ice cube production in 24 h / in kg 1.1 D D D D
76 mm 76 mm 76 mm 76 mm
appliance (19 mm from the left and 127 mm from the
Ice cube storage capacity in kg 3.0 floor). The free length of the mains cable is 2.5 m.
Storage time in event of a fault in hours 18
C
Freezing capacity in 24 h / in kg 22 2134 mm 2134 mm The appliance has a recess in this area for cable and
Door hinge left, reversible** water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
Appliance dimensions in cm (H / W / D) 212.6 / 75.4 / 61

72 - 106 mm
Recess dimensions in cm (H / W / D) 213.4 / 76.2 / 63.5 B B D
E E This surface is visible when the appliance door is
Net weight in kg 161.0 C C
A A opened. Designed finish is therefore recommended.
102 mm
Voltage in V~ / Connected load in A 220-240 / 2.0
E
The anti-tipping device positioned at the base of the
appliance must be secured to the floor or to the wall.
76.2 Door panel dimensions
and dimensions of free length for power / water
* In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer
(rounded off). Inset installation
B
W H = 2029 mm
Optional accessories ** Please contact the authorised Liebherr Monolith customer service for reversing the door hinge.
You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a. W = 756 mm

· Flat brushed aluminium handle Overlay installation

For further relevant planning and safety requirements, see pages 56-63.
30 31
Freezer Freezer

Appliance dimensions
906 mm
IMPORTANT! Inset door panel
The adjustable feet are fully retracted A = 400 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 962 mm
EGN 9671 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
Energy efficiency class raised using the adjustable feet – in A = 406 mm
each case from the front of the appliance – B = 12.5 mm
Energy consumption in kWh (year / 24h) 456 / 1.250 so that the appliance comes into C = 975 mm
Noise output in dB(A) / Noise class 37 / C contact with the anti-tipping device. To
Total volume* in litres 564 achieve the minimal plinth panel height Dimension A = without
of 102 mm, the adjustable feet have to fitted door handle
Number of storage shelves, of which height-adjustable 4/3
be raised by 6 to 8 mm. If the plinth
Number of door racks 3 panel should be higher than 102 mm,
Number of FrostSafe drawers 3 the adjustable feet can be raised by a
maximum of 19 mm.
Electronic control system InfinitySwipe
Automatic SuperFrost function
Temperature range of freezer in °C
yes
-14 °C to -27 °C
Recess dimensions A
Unit depth
Defrosting method automatic Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Interior lighting InfinityLight with inset door panel installation: 635 mm + thickness
IceMaker fixed water connection 3 / 4" 914 mm 914 mm
of the custom panel. Further details on page 57.

Water filter yes B

Point at which the mains cable exits from the rear of the
Ice cube production in 24 h / in kg 1.3 D D D D
76 mm 76 mm 76 mm 76 mm
appliance (19 mm from the left and 127 mm from the
Ice cube storage capacity in kg 3.5 floor). The free length of the mains cable is 2.5 m.
Storage time in event of a fault in hours 19
C
Freezing capacity in 24 h / in kg 26 2134 mm 2134 mm The appliance has a recess in this area for cable and
Door hinge left, reversible** water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
Appliance dimensions in cm (H / W / D) 212.6 / 90.6 / 61

72 - 106 mm
Recess dimensions in cm (H / W / D) 213.4 / 91.4 / 63.5 B B D
E E This surface is visible when the appliance door is
Net weight in kg 191.0 C C
A A opened. Designed finish is therefore recommended.
102 mm
Voltage in V~ / Connected load in A 220-240 / 2.0
E
The anti-tipping device positioned at the base of the
appliance must be secured to the floor or to the wall.
91.4 Door panel dimensions
and dimensions of free length for power / water
* In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer
(rounded off). Inset installation
B
W H = 2029 mm
Optional accessories ** Please contact the authorised Liebherr Monolith customer service for reversing the door hinge.
You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a. W = 908 mm

· Flat brushed aluminium handle Overlay installation

For further relevant planning and safety requirements, see pages 56-63.
32 33
Fridge-freezers

ECBN 9673 I FrenchDoor

34 35
Fridge-freezers
Features
⸺

InfinitySwipe DuoCooling InfinityLight Individually opening doors

The InfinitySwipe electronic touch control consists of a With two independently controlled cooling circuits, The full-surface integrated LED lighting on the side wall With two completely noiseless and independently opening
bright and clear 3.5 inch display and, with “touch & swipe” DuoCooling controls the temperature in fridge-freezers creates an elegant and even light throughout the entire and closing doors, you can enjoy a refrigeration volume of
technology, is intuitive to use. separately and with precision for the refrigerator and refrigeration compartment. This produces a soft light when almost 326 litres with the FrenchDoor fridge-freezer. The
freezer compartments. There is no air exchange between the door is opened. The stunning InfinityLight not only adds unique FrenchDoor sealing system by Liebherr ensures that
the refrigerator and freezer compartments. Odour transfer is flair, but thanks to the reduced heat emission, also protects every door is always completely closed. This means that you
prevented and stored foods do not dry out. the quality of the food. save energy and always have the right temperature in your
refrigerator compartment.

InfinitySpring BioFresh-Plus IceMaker SmartDevice

The InfinitySpring water dispenser is flush-mounted, making BioFresh-Plus guarantees the perfect climate for much longer The automatic IceMaker creates 1.6 kg of ice from filtered The Monolith is supplied with a SmartDeviceBox which
it virtually invisible and allows standard-sized containers to freshness. The BioFresh-Plus safe can be variably divided into water in 24 hours. The ice production can be increased establishes a connection between a smartphone or tablet
be filled with cold water. A replaceable water filter ensures a different temperature zones and therefore used for different further by activating the SuperFrost function. The upper and the Monolith. This allows settings and functions to be
constant supply of pure water. This is easily accessible and is foods: With a constant temperature of just over 0 °C – ideal draw in the NoFrost freezer compartment is enclosed and activated also while you are on the move. Push messages
located in the front section of the appliance plinth. for meat and dairy products. Or at an icy -2 °C in the entire protects the frozen goods from undesired loss of cooled air report, for example, open doors.*
compartment, which fish and seafood love. And, on request, by means of the FrostSafe system.
divided as well: left -2 °C, right just over 0 °C, in between a *SmartDevice functions not available in all countries.
dividing wall as a temperature limit. And fruit and vegetables,
too, can be stored in the BioFresh-Plus safe at just over 0 °C,
considerably longer than in the normal refrigerator compartment.
36 37
LargeDoor fridge-freezer LargeDoor fridge-freezer

Appliance dimensions
754 mm

754 mm 610 mm IMPORTANT! Inset door panel

The adjustable feet are fully retracted A = 377 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 810 mm
ECBN 9471 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
2126 mm raised using the adjustable feet – in A = 343 mm
Energy efficiency class
each case from the front of the appliance – B = 12.5 mm
Energy consumption in kWh (year / 24h) 296 / 0.812 so that the appliance comes into C = 822 mm
Noise output in dB(A) / Noise class 38 / C contact with the anti-tipping device. To D = 400 mm
Total volume* in litres 400 achieve the minimal plinth panel height
96 mm
of 102 mm, the adjustable feet have to Dimension A = without
Volume of refrigerator compartment in litres 190.0
65 mm be raised by 6 to 8 mm. If the plinth fitted door handle
Volume of BioFresh compartment in litres 69.0 panel should be higher than 102 mm,
Volume of freezer compartment in litres 141.0 the adjustable feet can be raised by a
Number of storage shelves 3 maximum of 19 mm.

Number of door racks

Number of FrostSafe drawers
2
1
Recess dimensions A
Unit depth
Electronic control InfinitySwipe Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Automatic SuperCool function yes 762 mm 762 mm with inset door panel installation: 635 mm + thickness
Automatic SuperFrost function yes of the custom panel. Further details on page 57.

Temperature range of refrigerator compartment in °C +2 °C to +7 °C B

D D D D Point at which the mains cable exits from the rear of the
Temperature range of freezer compartment in °C −14 °C to −27 °C
76 mm 76 mm 76 mm 76 mm appliance (19 mm from the left and 127 mm from the
Defrosting method automatic floor). The free length of the mains cable is 2.5 m.
Interior lighting InfinityLight
C
2134 mm 2134 mm
Integrated water dispenser / Fixed water connection 3/4" InfinitySpring The appliance has a recess in this area for cable and
Water filter yes water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
IceMaker fixed water connection 3/4"

72 - 106 mm
B B D
Ice cube production in 24 h / in kg 1.6
E E C This surface is visible when the appliance door is
Ice cube storage capacity in kg 3.0 C A
A 102 mm opened. Designed finish is therefore recommended.
Door hinge right, reversible**
E
Appliance dimensions in cm (H / W / D) 212.6 / 75.4 / 61 The anti-tipping device positioned at the base of the
Recess dimensions in cm (H / W / D) 213.4 / 76.2 / 63.5 appliance must be secured to the floor or to the wall.
Net weight in kg 184.0 Door panel dimensions
Voltage in V~ / Connected load in A 220-240 / 3.0 and dimensions of free length for power / water
76.2 This appliance is also available as variant -617: with left door hinges
B
W
Inset installation
H1 = 1255 mm / H2 = 768 mm / HS = 6 mm / W = 756 mm
Optional accessories
Overlay installation
1 H1 = 1258 mm (plus the dimensions of overlapping of the panel
· Flat brushed aluminium handle H1 on the top)
· Square brushed aluminium handle H2 = 768 mm
· Round stainless steel handle HS = 6 mm
· Stainless steel panel set * In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer W = 762 mm (plus the dimensions of overlapping of the panel on
(rounded off) and the volume of the frozen compartments and refrigeration compartments to one HS both sides)
· Stainless steel plinth panel
· Side-by-Side set place after the decimal point.
H2 Thickness of the panel: min. 16 mm* / max. 30 mm
** Please contact the authorised Liebherr Monolith customer service for reversing the door hinge. ~1850 2 ~2250 Weight of panel 1: max. 35 kg
· Door hinge exchange set
You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a.
~ 2400 ~1700 Weight of panel 2: max. 25 kg
C
Optional accessories on page 52-55. Installations behind the appliance are not possible.
* If a five-piece shaker style panel is used, which is thinner than the minimum panel thickness, shorter screws than those supplied in the accessory pack must be used.

For further relevant planning and safety requirements, see pages 56-63.
38 39
LargeDoor fridge-freezer LargeDoor fridge-freezer

Appliance dimensions
906 mm
610 mm
906 mm IMPORTANT! Inset door panel
The adjustable feet are fully retracted A = 400 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 962 mm
ECBN 9671 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
Energy efficiency class 2126 mm raised using the adjustable feet – in A = 406 mm
each case from the front of the appliance – B = 12.5 mm
Energy consumption in kWh (year / 24h) 266 / 0.728
so that the appliance comes into C = 975 mm
Noise output in dB(A) / Noise class 38 / C contact with the anti-tipping device. To D = 400 mm
Total volume* in litres 514 96 mm
achieve the minimal plinth panel height
of 102 mm, the adjustable feet have to Dimension A = without
Volume of refrigerator compartment in litres 242.6
65 mm be raised by 6 to 8 mm. If the plinth fitted door handle
Volume of BioFresh compartment in litres 87.1 panel should be higher than 102 mm,
Volume of freezer compartment in litres 184.3 the adjustable feet can be raised by a
Number of storage shelves 3 maximum of 19 mm.

Number of door racks

Number of FrostSafe drawers
2
1
Recess dimensions A
Unit depth
Electronic control InfinitySwipe Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Automatic SuperCool function yes 914 mm 914 mm with inset door panel installation: 635 mm + thickness
Automatic SuperFrost function yes of the custom panel. Further details on page 57.

Temperature range of refrigerator compartment in °C +2 °C to +7 °C B

D D D D Point at which the mains cable exits from the rear of the
Temperature range of freezer compartment in °C −14 °C to −27 °C
76 mm 76 mm 76 mm 76 mm appliance (19 mm from the left and 127 mm from the
Defrosting method automatic floor). The free length of the mains cable is 2.5 m.
Interior lighting InfinityLight
C
Integrated water dispenser / Fixed water connection 3/4" InfinitySpring 2134 mm 2134 mm
The appliance has a recess in this area for cable and
Water filter yes water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
IceMaker fixed water connection 3/4"

72 - 106 mm
Ice cube production in 24 h / in kg 1.6 B B D
E E This surface is visible when the appliance door is
Ice cube storage capacity in kg 3.0 C C
A A opened. Designed finish is therefore recommended.
102 mm
Door hinge right, reversible**
E
Appliance dimensions in cm (H / W / D) 212.6 / 90.6 / 61 The anti-tipping device positioned at the base of the
Recess dimensions in cm (H / W / D) 213.4 / 91.4 / 63.5 appliance must be secured to the floor or to the wall.
Net weight in kg 190.0 Door panel dimensions
Voltage in V~ / Connected load in A 220-240 / 3.0 and dimensions of free length for power / water
91.4 This appliance is also available as variant -617: with left door hinges
B
W
Inset installation
H1 = 1255 mm / H2 = 768 mm / HS = 6 mm / W = 908 mm
Optional accessories
Overlay installation
1 H1 = 1258 mm (plus the dimensions of overlapping of the panel
· Flat brushed aluminium handle H1 on the top)
· Square brushed aluminium handle H2 = 768 mm
· Round stainless steel handle HS = 6 mm
· Stainless steel panel set * In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer W = 914 mm (plus the dimensions of overlapping of the panel on
(rounded off) and the volume of the frozen compartments and refrigeration compartments to one HS both sides)
· Stainless steel plinth panel
· Side-by-Side set place after the decimal point.
Thickness of the panel: min. 16 mm* / max. 30 mm
** Please contact the authorised Liebherr Monolith customer service for reversing the door hinge. 2 H2
· Door hinge exchange set ~1775 ~2175 Weight of panel 1: max. 40 kg
You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a.
~ 2400 ~1550 Weight of panel 2: max. 30 kg
C
Optional accessories on page 52-55. Installations behind the appliance are not possible.
* If a five-piece shaker style panel is used, which is thinner than the minimum panel thickness, shorter screws than those supplied in the accessory pack must be used.

For further relevant planning and safety requirements, see pages 56-63.
40 41
FrenchDoor fridge-freezer FrenchDoor fridge-freezer

Appliance dimensions
906 mm
610 mm
906 mm IMPORTANT! Inset door panel
The adjustable feet are fully retracted A = 210 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 510 mm
ECBN 9673 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
Energy efficiency class 2126 mm raised using the adjustable feet – in A = 210 mm
each case from the front of the appliance – B = 12.5 mm
Energy consumption in kWh (year / 24h) 422 / 1.156 so that the appliance comes into C = 510 mm
Noise output in dB(A) / Noise class 38 / C contact with the anti-tipping device. To D = 400 mm
Total volume* in litres 510 96 mm
achieve the minimal plinth panel height
of 102 mm, the adjustable feet have to Dimension A = without
Volume of refrigerator compartment in litres 239.6
65 mm be raised by 6 to 8 mm. If the plinth fitted door handle
Volume of BioFresh compartment in litres 86.8 panel should be higher than 102 mm,
Volume of freezer compartment in litres 184.0 the adjustable feet can be raised by a
Number of storage shelves 3
maximum of 19 mm.

Number of door racks

Number of FrostSafe drawers
4
1
Recess dimensions A
Unit depth
Electronic control InfinitySwipe Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Automatic SuperCool function yes 914 mm 914 mm with inset door panel installation: 635 mm + thickness
Automatic SuperFrost function yes of the custom panel. Further details on page 57.

Temperature range of refrigerator compartment in °C +2 °C to +7 °C B

D D D D Point at which the mains cable exits from the rear of the
Temperature range of freezer compartment in °C −14 °C to −27 °C
76 mm 76 mm 76 mm 76 mm appliance (19 mm from the left and 127 mm from the
Defrosting method automatic floor). The free length of the mains cable is 2.5 m.
Interior lighting InfinityLight
C
Integrated water dispenser / Fixed water connection 3/4" InfinitySpring 2134 mm 2134 mm
The appliance has a recess in this area for cable and
Water filter yes water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
IceMaker fixed water connection 3/4"

91.4 B1
W1 B1
W1
HS Inset installation
H1 = 1255 mm / H2 = 768 mm / HS = 6 mm
W1 = 451 mm / W2 = 908 mm
Optional accessories
1 1 Overlay installation
H1
H1 = 1258 mm (plus the dimensions of overlapping of the panel on the top)
· Flat brushed aluminium handle H2 = 768 mm
· Square brushed aluminium handle * In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer
HS = 6 mm
(rounded off) and the volume of the frozen compartments and refrigeration compartments to one
· Round stainless steel handle HS
W1 = 454 mm (plus the dimensions of overlapping of the panel exterior)
place after the decimal point.
· Stainless steel panel set W2 = 914 mm (plus the dimensions of overlapping of the panel on both sides)
You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a.
· Stainless steel plinth panel H2 Thickness of the panel: min. 16 mm* / max. 30 mm
~1775 2 ~2175
· Side-by-Side set Weight of panel 1: max. 40 kg
~ 2400 ~1550
Weight of panel 2: max. 30 kg
C
Optional accessories on page 52-55. B2
W2 Installations behind the appliance are not possible.
* If a five-piece shaker style panel is used, which is thinner than the minimum panel thickness, shorter screws than those supplied in the accessory pack must be used.

For further relevant planning and safety requirements, see pages 56-63.
42 43
Wine cabinets

EGN 9271 I EWT 9275 I EKB 9471

44 45
Wine cabinets
Features
⸺

InfinityLight Aluminium labelling strip InfinitySwipe InfinityProtection

Monolith’s integrated LED side wall lighting casts a beautiful The aluminium labelling strip brings structure to your wine The Monolith’s intuitive InfinitySwitch touch control makes it In order to protect the wines from strong temperature
and even glow throughout the space. InfinityLight includes collection. The label for each stored wine can be applied very easy to control every function in the wine cabinet. The fluctuations, the Monolith wine cabinets have two temperature
a soft brightening effect upon opening the doors and the directly to the aluminium labelling strip. This gives you a bright and clear 3.5 inch touch & swipe display shows up to sensors in each wine safe. Only Liebherr offers this function.
lighting can be fine-tuned according to your personal taste. good overview of your wine supply. three temperatures for wine cabinets with multiple zones. As soon as the InfinityProtection sensors register a critical
The InfinityLight LED technology emits less heat and is more temperature change, there is an immediate notification in
efficient than traditional lighting, preserving both your wines order to protect the wines from becoming too warm or too cold.
and the environment.

FreshAir activated charcoal filter SoftSystem SoftTelescopic InfinityBoard

Your wine collections deserve the best air quality. That’s why The Monolith’s SoftSystem technology ensures that the The Monolith’s high-quality wooden shelves sit on A special feature of the Monolith wine cabinet is the
the Monolith has a FreshAir activated charcoal filter in each doors close particularly gently every time. This avoids smooth-running telescopic rails with a self-closing mechanism InfinityBoard. On the pull-out shelf, bottles can be stored
wine safe. This ensures that your treasured wines are always vibrations due to slamming doors, so that the wine bottles and soft closing damping. Additional wooden bars enable temporarily while the wine collection is being sorted or added
well protected. The incoming air is cleaned and unpleasant are optimally protected. you to adapt the interior in the best possible way to your to. Serving is also easier: the wine can be opened and tasted
odours are filtered out. assortment of variously sized wine and champagne bottles. directly at the Monolith.
Now all the bottles in your wine collection can be optimally
accommodated and the possibilities of the wine cabinet can
be completely utilised.

46 47
Wine cabinet Wine cabinet

Appliance dimensions
450 mm 610 mm IMPORTANT! 450 mm Inset door panel
The adjustable feet are fully retracted A = 210 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 505 mm
EWT 9175 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
Energy efficiency class 2126 mm raised using the adjustable feet – in A = 216 mm
each case from the front of the appliance – B = 12.5 mm
Energy consumption in kWh (year / 24h) 154 / 0.423
so that the appliance comes into C = 517 mm
Noise output in dB(A) / Noise class 38 / C contact with the anti-tipping device. To
Total volume* in litres 232 achieve the minimal plinth panel height Dimension A = without
96 mm of 102 mm, the adjustable feet have to fitted door handle
Max. Bordeaux bottles (0.75 l) 75
65 mm be raised by 6 to 8 mm. If the plinth
Number of storage shelves 9 panel should be higher than 102 mm,
Of which on telescopic rails 9 the adjustable feet can be raised by a
yes maximum of 19 mm.
InfinityBoard
Storage shelf material
Electronic control system
aluminium / beech
InfinitySwipe
Recess dimensions A
Unit depth
Temperature range in °C +5 °C to +20 °C Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Temperature zones 2 with inset door panel installation: 635 mm + thickness
Temperature alarm visual and audible 457 mm 457 mm
of the custom panel. Further details on page 57.

Interior lighting InfinityLight B

Point at which the mains cable exits from the rear of the
Door alarm audible D D D D
76 mm 76 mm 76 mm 76 mm
appliance (19 mm from the left and 127 mm from the
Safety thermostat yes floor). The free length of the mains cable is 2.5 m.
FreshAir activated charcoal filter yes
C
Door type insulated glass door 2134 mm 2134 mm The appliance has a recess in this area for cable and
Door hinge left, reversible** water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
Appliance dimensions in cm (H / W / D) 212.6 / 45 / 61

72 - 106 mm
Recess dimensions in cm (H / W / D) 213.4 / 45.7 / 63.5 B B D
E E This surface is visible when the appliance door is
Net weight in kg 132.0 C C
A A opened. Designed finish is therefore recommended.
102 mm
Voltage in V~ / Connected load in A 220-240 / 1.5
E
This unit is also available as variant -001: with right door hinges The anti-tipping device positioned at the base of the
appliance must be secured to the floor or to the wall.
Door panel dimensions
45.7 and dimensions of free length for power

Inset installation
* In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer W H = 2029 mm / h = 1495 mm
Optional accessories (rounded off). W = 451 mm / w = 280 mm
** Please contact the authorised Liebherr Monolith customer service for reversing the door hinge.
· Flat brushed aluminium handle You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a. w Overlay installation
H = 2032 mm
· Square brushed aluminium handle (plus the dimensions of overlapping of the panel on
· Round stainless steel handle the top)
· Stainless steel panel h H W = 457 mm
· Stainless steel plinth panel (plus the dimensions of overlapping of the panel on
· Side-by-Side set both sides)
· Door hinge exchange set Thickness of the panel: min. 16 mm* / max. 30 mm
Weight of panel: max. 24 kg
~2400 ~ 2000 C
Optional accessories on page 52-55. Installations behind the appliance are not possible.
* If a five-piece shaker style panel is used, which is thinner than the minimum panel thickness, shorter screws than those supplied in the accessory pack must be used.

For further relevant planning and safety requirements, see pages 56-63.
48 49
Wine cabinet Wine cabinet

Appliance dimensions
602 mm 610 mm IMPORTANT! 602 mm Inset door panel
The adjustable feet are fully retracted A = 273 mm
for the minimum height stated. B = 12.5 mm
The appliance height is raised by turning C = 658 mm
EWT 9275 the adjustable feet. Once the appliance
has been positioned in the recess, it is Overlay door panel
Energy efficiency class raised using the adjustable feet – in A = 279 mm
2126 mm
each case from the front of the appliance – B = 12.5 mm
Energy consumption in kWh (year / 24h) 180 / 0.493
so that the appliance comes into C = 670 mm
Noise output in dB(A) / Noise class 38 / C contact with the anti-tipping device. To
Total volume* in litres 320 achieve the minimal plinth panel height Dimension A = without
96 mm of 102 mm, the adjustable feet have to fitted door handle
Max. Bordeaux bottles (0.75 l) 100
be raised by 6 to 8 mm. If the plinth
Number of storage shelves 9 65 mm
panel should be higher than 102 mm,
Of which on telescopic rails 9 the adjustable feet can be raised by a
yes maximum of 19 mm.
InfinityBoard
Storage shelf material
Electronic control system
aluminium / beech
InfinitySwipe
Recess dimensions A
Unit depth
Temperature range in °C +5 °C to +20 °C Individual plinth panel Continuous plinth panel with overlay door panel installation: 635 mm
Temperature zones 3 with inset door panel installation: 635 mm + thickness
Temperature alarm visual and audible 610 mm 610 mm
of the custom panel. Further details on page 57.

Interior lighting InfinityLight B

Point at which the mains cable exits from the rear of the
Door alarm audible D D D D
76 mm 76 mm 76 mm 76 mm
appliance (19 mm from the left and 127 mm from the
Safety thermostat yes floor). The free length of the mains cable is 2.5 m.
FreshAir activated charcoal filter yes
C
Door type insulated glass door 2134 mm 2134 mm The appliance has a recess in this area for cable and
Door hinge right, reversible** water line routing: Depth is 25 mm, and height 140 mm
across the entire appliance width.
Appliance dimensions in cm (H / W / D) 212.6 / 60.2 / 61

72 - 106 mm
Recess dimensions in cm (H / W / D) 213.4 / 61 / 63.5 B B D
E C E This surface is visible when the appliance door is
Net weight in kg 158.0 C
A A opened. Designed finish is therefore recommended.
102 mm
Voltage in V~ / Connected load in A 220-240 / 1.5
E
The anti-tipping device positioned at the base of the
appliance must be secured to the floor or to the wall.
Door panel dimensions
61.0 and dimensions of free length for power
* In accordance with Regulation EU 2019/2016, we indicate the total volume to the nearest integer
(rounded off).
Inset installation
W H = 2029 mm / h = 1495 mm
Optional accessories ** Please contact the authorised Liebherr Monolith customer service for reversing the door hinge.
You can find the full range of efficiency classes on page 64. As per (EU) 2017/1369 6a.
W = 603 mm / w = 432 mm

· Flat brushed aluminium handle w

Overlay installation
H = 2032 mm
· Square brushed aluminium handle (plus the dimensions of overlapping of the panel on
· Round stainless steel handle the top)
· Stainless steel panel h H W = 610 mm
· Stainless steel plinth panel (plus the dimensions of overlapping of the panel on
· Side-by-Side set both sides)
· Door hinge exchange set Thickness of the panel: min. 16 mm* / max. 30 mm
Weight of panel: max. 24 kg
~2400 ~ 1850 C
Optional accessories on page 52-55. Installations behind the appliance are not possible.
* If a five-piece shaker style panel is used, which is thinner than the minimum panel thickness, shorter screws than those supplied in the accessory pack must be used.

For further relevant planning and safety requirements, see pages 56-63.
50 51
Optional accessories
⸺

Stainless steel panels Stainless steel panel set

The holes for fitting the handle have been drilled centrally with a spacing of 770 mm in order that the stainless steel panel can be turned The holes for fitting the handle have been drilled centrally with a spacing of 770 mm in order that the stainless steel panel can be turned by
by 180° in the event that a door hinge is changed. 180° in the event that a door hinge is changed. On the freezer compartment panel of the unit ECBN 9471, the distance of the holes is 618 mm.

Refrigerators and freezers

LargeDoor
45.7 cm (dimensions: 2029 mm x 451 mm x 19 mm, weight: 18.4 kg) 9901 916 for model: EGN 9171
76.2 cm (refrigerator compartment panel dimensions: 756 mm x 1255 mm x 19 mm, weight: 17.8 kg) 9903 020 for model: ECBN 9471
61.0 cm (dimensions: 2029 mm x 603 mm x 19 mm, weight: 24 kg) 9901 883 for model: EKB 9271, EGN 9271
(freezer compartment panel dimensions: 756 mm x 768 mm x 19 mm, weight: 11 kg)
76.2 cm (dimensions: 2029 mm x 756 mm x 19 mm, weight: 28 kg) 9901 872 for model: EKB 9471, EGN 9471
91.4 cm (refrigerator compartment panel dimensions: 908 mm x 1255 mm x 19 mm, weight: 21.4 kg) 9903 019 for model: ECBN 9671
91.4 cm (dimensions: 2029 mm x 908 mm x 19 mm, weight: 32 kg) 9901 458 for model: EKB 9671, EGN 9671 (freezer compartment panel dimensions: 908 mm x 768 mm x 19 mm, weight: 13.8 kg)
Wine cabinets FrenchDoor
45.7 cm (dimensions: 2029 mm x 451 mm x 19 mm, weight: 10 kg) 9901 535 for model: EWT 9175 91.4 cm (refrigerator compartment panel dimensions per door: 451 mm x 1255 mm x 19 mm, weight: 11 kg) 9903 022 for model: ECBN 9673
61.0 cm (dimensions: 2029 mm x 603 mm x 19 mm, weight: 11.3 kg) 9901 533 for model: EWT 9275 (freezer compartment panel dimensions: 908 mm x 768 mm x 19 mm, weight: 13.8 kg)

Refrigerators and freezers Wine cabinets LargeDoor (2-part set) FrenchDoor (3-part set)

45.7 61.0 76.2 91.4 45.7 61.0 76.2 91.4 91.4

52 53
Optional accessories 1 2 3
Sidewall heater
The sidewall heater prevents the formation of condensation when installing Side-by-Side units in separate unit carcasses and must be
⸺ used if the distance between two integrated units is less than 102 mm.
Sidewall heater 9903 061 for all Monolith model combinations

Door hinge exchange set

To exchange hinges assembled ex works. Reversals to be performed by a Liebherr authorised engineer.

Door hinge exchange set 9902 399 for all Monolith model combinations except for ECBN 9673

Handles
Fastening screws are included in the scope of delivery. The distance between the two screw holes is 770 mm, except for the freezer com-
partment of the unit ECBN 9471; in this case, the distance is 618 mm. FlexSystem
1 Flat brushed aluminium handle 810 mm 9901 461 for all refrigerators, freezers and wine cabinets / refrigerator compartment 61.0 cm 9901 828 for model: EKB 9271
(depth: 48 mm, weight: 0.8 kg) ECBN 9471, ECBN 9671, ECBN 9673 / freezer compartment ECBN 9671, ECBN 9673
76.2 cm 9901 838 for model: EKB 9471
1 Flat brushed aluminium handle 658 mm 9901 549 for freezer compartment ECBN 9471
(depth: 48 mm, weight: 0.9 kg) 91.4 cm 9902 348 for model: EKB 9671

2 Square brushed aluminium handle 810 mm 9901 492 for all refrigerators, freezers and wine cabinets / refrigerator compartment
(depth: 55 mm, weight: 2.3 kg) ECBN 9471, ECBN 9671, ECBN 9673 / freezer compartment ECBN 9671, ECBN 9673
2 Square brushed aluminium handle 658 mm 9901 924 for freezer compartment ECBN 9471
(depth: 55 mm, weight: 2.2 kg)
3 Round stainless steel handle 810 mm 9901 489 for all refrigerators, freezers and wine cabinets / refrigerator compartment
(depth: 62 mm, weight: 1.2 kg) ECBN 9471, ECBN 9671, ECBN 9673 / freezer compartment ECBN 9671, ECBN 9673
Filters
3 Round stainless steel handle 658 mm 9901 545 for freezer compartment ECBN 9471 FreshAir activated charcoal filter 9882 471 for model: EKB 9271, EKB 9471, EKB 9671, EWT 9175, EWT 9275,
(depth: 62 mm, weight: 0.8 kg) ECBN 9471, ECBN 9671, ECBN 9673
FreshAir activated charcoal filter (2 pieces) 9881 116 for model: EKB 9271, EKB 9471, EKB 9671, EWT 9175
FreshAir activated charcoal filter (3 pieces) 9882 304 for model: EWT 9275
Stainless steel plinth panels FreshAir activated charcoal filter and water 9903 047 for model: EKB 9471, EKB 9671, ECBN 9471, ECBN 9671, ECBN 9673
filter set
45.7 cm 9901 493 for model: EGN 9171, EWT 9175
Water filter 9880 980 for model: EKB 9471, EKB 9671, EGN 9171, EGN 9271, EGN 9471,
61.0 cm 9901 496 for model: EKB 9271, EGN 9271, EWT 9275 EGN 9671, ECBN 9471, ECBN 9671, ECBN 9673
76.2 cm 9901 530 for model: EKB 9471, EGN 9471, ECBN 9471
91.4 cm 9902 349 for model: EKB 9671, EGN 9671, ECBN 9671, Ice
ECBN 9673 / According to Side-by-Side combination
106.7 cm 9901 552 for model: According to Side-by-Side combination Ice cube scoop 9901 841 for model: EGN 9171, EGN 9271, EGN 9471, EGN 9671, ECBN 9471, ECBN
9671, ECBN 9673
121.9 cm 9901 765 for model: According to Side-by-Side combination
Ice cube tongs 9901 871 for model: EGN 9171, EGN 9271, EGN 9471, EGN 9671, ECBN 9471, ECBN
137.1 cm 9901 787 for model: According to Side-by-Side combination
9671, ECBN 9673
152.4 cm 9902 366 for model: According to Side-by-Side combination
167.6 cm 9902 819 for model: According to Side-by-Side combination
182.8 cm 9902 390 for model: According to Side-by-Side combination Wine
Stainless steel plinth panels (102 mm high)
Stainless steel bottle presenter 9882 303 for model: EWT 9175, EWT 9275
Set of 3 bars for wooden shelf 9903 024 for model: EWT 9175, EWT 9275
Side-by-Side set
The Side-by-Side sets include sidewall heater to prevent condensation between appliances as well as metal brackets and screws for
connecting the appliances. Decorative trim is also included for covering the gap (approx. 6-8 mm) between the two appliances installed. Cleaning & care
No additional mains connection is required for the sidewall heater, a slot is provided for this on the rear of the appliance. The use of the
Side-by-Side set increases the energy consumption by 0.4 kWh / 24 for two units, and by 0.8 kWh / 24 h for three units. Stainless steel care product 250 ml 8409 030 for all Monolith models
Stainless steel cleaner 250 ml 8409 022 for all Monolith models
Side-by-Side set 9901 428 for all Monolith model combinations

54 55
Planning information
⸺ Standard overlap Overlay door panel Inset door panel

635 mm + thickness of the custom panel

Installation space* Installation space* Installation space*

Appliance depth

Appliance depth
Cut-out depth

Cut-out depth

Cut-out depth
635 mm

635 mm
610 mm

610 mm

610 mm
Installation space requirements Recess requirements

The space in which the appliance is to be installed must meet When planning the recess and secure installation, it is
the following requirements: important to make sure that the top and carcass walls line
up flush with the appliance at a depth of at least 102 mm
· The floor must be capable of bearing the weight of the from the outside edge and are comprised of appropriately thick
appliance plus – depending on the net capacity of the model – material (at least 16 mm). *The installation space constitutes the space between the unit rear wall and the kitchen rear wall. This intermediate space enables
approx. min. 218 kg to max. 544 kg of food. convenient installation of the electricity and water connection, as well as the anti-tipping device. If needed, the installation space
Because the unit recess is partially visible when the appliance can be reduced (e.g. cut-out depth 610 mm).
· The floor should be level. The appliance must be supported or door is opened, it should be ensured that the inside matches
levelled at floor level to ensure that the ventilation openings the unit surface at the top and at the side and also has a
are clear. minimum depth of 76 mm. Because the carcass sides are
visible, designed carcass finishes from the kitchen Door panel dimensions and weights
· The recess dimensions in the installation location have been manufacturer are recommended.
correctly measured.
Monolith appliances are designed for flush installation in units H B H B Max.
Model
· The power socket is located in the correct position. with a depth of 635 mm with stainless steel panels or Inset installation Inset installation Overlay installation Overlay installation panel weight
customer-specific panels, according to the design of the
In order to transport the Monolith to the installation location, kitchen, available as an accessory. EKB 9271 2029 mm 603 mm 2032 mm 1 610 mm 2 30 kg
the door heights must also be considered on the route taken
for transportation with the appliance packed and tilted: For customer-specific custom panels, it must also be ensured EKB 9471 2029 mm 756 mm 2032 mm 1 762 mm 2 35 kg
that the maximal permitted panel weight for the door hinge of
the respective model is not exceeded. If the maximum panel EKB 9671 2029 mm 908 mm 2032 mm 1 914 mm 2 40 kg
Model Max. height (mm) weight is not exceeded, other materials made of wood with a
maximum thickness of 30 mm can also be used. EGN 9171 2029 mm 451 mm 2032 mm 1 457 mm 2 25 kg
EGN 9171
EGN 9271 EGN 9271 2029 mm 603 mm 2032 mm 1 610 mm 2 30 kg
The scope of supply of the Monolith appliances includes a
EKB 9271 2396 decorative trim for covering the gap between the appliance
EWT 9175 EGN 9471 2029 mm 756 mm 2032 mm 1 762 mm 2 35 kg
and side walls of the fitted unit.
EWT 9275
EGN 9471 The depth of the Monolith appliances is 610 mm, which means EGN 9671 2029 mm 908 mm 2032 mm 1 914 mm 2 40 kg
EKB 9471 2414 that they may be installed without difficulty in a fitted unit of
ECBN 9471 X standard European depth (610 mm) but also in deeper cut-outs EWT 9175 2029 mm 451 mm 2032 mm 1 457 mm 2 24 kg
of 635 mm in order to provide flexible installation options.
EGN 9671
EWT 9275 2029 mm 603 mm 2032 mm 1 610 mm 2 24 kg
EKB 9671
2469 In the case of flush installation, the door panel dimensions for
ECBN 9671
installation with an Inset door panel must be used. ECBN 9471 1255 mm 756 mm 1258 mm 1 762 mm 2 35 kg
ECBN 9673 Refrigerator compartment
For all other installation options, the door spacing requirements ECBN 9471 768 mm 756 mm 768 mm 1 762 mm 2 25 kg
The appliance should only be installed next to Liebherr must be observed (page 61) in order to determine the door Freezer compartment
refrigerators, freezers or wine cabinets. The Liebherr models panel dimensions. ECBN 9671 1255 mm 908 mm 1258 mm 1 914 mm 2 40 kg
are designed to be set up Side-by-Side. A Side-by-Side set is Refrigerator compartment
necessary for this (for separate accessories, see page 54). ECBN 9671 768 mm 908 mm 768 mm 1 914 mm 2 30 kg
If a Monolith appliance is installed next to another refrigerator, Freezer compartment
freezer or wine cabinet, this may result in condensation or
ECBN 9673 1255 mm 451 mm 3 1258 mm 1 454 mm 2.3 40 kg
damage the Liebherr appliance. Refrigerator compartment

ECBN 9673 768 mm 908 mm 768 mm 1 914 mm 2 30 kg

Freezer compartment
IMPORTANT
1
Overlap of the panel at the top not taken into account.
In order to prevent potential damage to the appliance, the
² Overlap of the panel on right and left not taken into account.
appliance should be left to stand for one hour in the installation
³ Distance between the FrenchDoor refrigerator panels at least 5 mm.
location before switching on in order that the fluids in the
coolant and lubrication system can be distributed evenly.

56 57
Installation options Side-by-Side installation
⸺ ⸺

In order to determine the cut-out width for the Side-by-Side combinations, add together the individual widths of the appliances used
Individual posi- All Monolith appliances can be installed as stand-alone appliances with the hinge in the combination. You can find the recess dimensions for a combination of two or three units as follows. The widths for four or more
on the left or the right. When sizing the fitted unit, take into account the thickness units are available on request. If the distance between the appliances is less than 102 mm, you need the Side-by-Side set described
tioning of the door panel and the handle.
on page 54.
In order to prevent the appliance door, including the handle, from colliding with
adjoining walls or elements of the kitchen, a minimum spacing of 76 mm must be W2
included for a door opening limited to 90°. individual
W1 (mm) W2 (mm) W3 (mm)
See also “Requirements for door spacing” on page 61.
D D
76 mm 76 mm 457 914 1372
Side-by-Side Monolith appliances may be installed Side-by-Side in a fitted unit. For this, a 610 1067 1524
Side-by-Side set which is separately available is required if the spacing between
in a the installed appliances is less than 102 mm. When sizing the fitted unit, take into
2134 mm 762 1219 1676
fitted unit account the thickness of the door panel and the handle.
914 1372 1829
B B1
In order to prevent the appliance doors, including the handles, from colliding with 1524 1981
adjoining walls or elements of the kitchen, a minimum spacing of 76 mm must be E E
C
A
included for a door opening limited to 90°. 1676 2134

See also “Requirements for door spacing” on page 61. 1829 2286
continuous 2438

72 - 106 mm
B B1
2591
E E
A
C 2743
102 mm

Side-by-Side in Monolith appliances may be installed Side-by-Side in different units. If the dividing
wall between the units has a thickness of less than 102 mm, a separately available
separate units W3 W2 F W1
Side-by-Side set is required. individual
In order to prevent the appliance doors, including the handles, from colliding with
D D D D
adjoining walls or elements of the kitchen, a minimum spacing of 76 mm must be 76 mm 76 mm 76 mm
76 mm
included for a door opening limited to 90°.

In the case of back-to-back door positioning (as shown in adjacent drawing, top 2134 mm 2134 mm
right), a minimum spacing of 154 mm must be included.

Liebherr provides a 102 mm high plinth panel made of stainless

steel as an optional accessory. This is available in the relevant
Width of the Monolith model and possible Side-by-Side combina- Inset door panel installation Overlay door panel installation
tions (from 45.7 cm to 182.8 cm). View from above View from above
Panel thickness 30 mm (example) Panel thickness 30 mm (example)
The plinth panel, the position depth of which can be varied, is
assembled by means of an adhesive joint (pre-assembled on the
A A
appliance). B
5 10 2
20 30 40 mm
5 10 2
20 30 40 mm
See “Optional accessories” on page 54. 5
5
10 10
B 20
20

30 30

40 40

D
C
D
C

A = Furniture framing (here 19 mm, for example) A = 19 mm unit carcass

B = Panel – door closed B = Panel – door closed. Overlap on the panel frame of the unit
C = Panel with door opened 90° carcass is 8 mm. The dashed line shows an overlap of 17
mm over the panel frame. This overlap only applies if the
D = Panel with maximum door opening angle of 115°
appliance is at the end of the kitchen units.
C = Panel with door opened 90°
D = Panel with maximum door opening angle of 115°

IMPORTANT
The minimum permitted size of the gap between the panels is
3 mm.

60 61
Safety requirements
⸺

Ambient temperatures Secure mounting Warnings Electrical safety

· The appliances are intended for refrigerating, freezing and In order to prevent the appliance from tipping over following · Water connection work must not be performed if the appli- · The appliance must only be operated using alternating cur-
storing food and for making ice (if equipped accordingly). installation, the anti-tipping device must be fitted. Please note ance is connected to an electrical socket. rent.
in this regard the information in the chapter “Secure mounting”
· The appliances are designed for operation within the ambient
in the installation instructions. · A shut-off valve must be installed between the hose line and · The permitted voltage and frequency according to the appli-
temperature limit values which depend on the climate class.
the mains water supply in order that the water supply can be ance design must be adhered to for the relevant country.
· The climate class describes the ambient temperature at which InfinitySpring (integrated water dispenser) and stopped if necessary. The shut-off valve must not be installed
the appliances may be operated in order to achieve optimal behind the appliance. · Power sockets must be earthed and electrically protected in
IceMaker (depending on model)
cooling performance. accordance with regulations.
· The connection to the water supply must only be undertaken
· The climate class of all refrigerators and freezers is SN-T, and Monolith appliances fitted with an InfinitySpring or IceMaker
by a trained and licensed plumber. · Power sockets must not be located behind the appliance and
for wine cabinets SN-ST. must be connected to a water supply. The water pressure must
must be easily accessible in order to be able to disconnect the
be between 2.8 and 6.2 bar.
· The water quality must comply with the drinking water regula- appliance from the mains if necessary.
tions for the region in which the appliance is operated.
Only the supply hose delivered with the appliance must be
· A separate circuit is recommended for the appliance in order
Climate class Ambient temperature used to feed water to the InfinitySpring/IceMaker.
· The IceMaker is solely for the purpose of producing ice cubes to prevent defrosting or spoiling food as a result of an elec-
SN 10 °C to 32 °C in normal household quantities and must only be used with tricity failure caused by other appliances.
If the degree of hardness of the water at the installation loca-
water appropriate for this purpose.
N 16 °C to 32 °C tion is high, we recommend installing a water softener. A filter
must also be used in case solids such as sand are contained in
ST 16 °C to 38 °C · All repairs and work on the InfinitySpring/IceMaker must only WARNING!
the water.
be undertaken by customer service employees or other trained
T 16 °C to 43 °C
individuals. Risk of fatal electric shock.
All devices and systems used to supply the appliance with
SN-ST 10 °C to 38 °C
water must meet the relevant applicable provisions in your Do not connect the appliance to unearthed power sockets.
SN-T 10 °C to 43 °C · The manufacturer assumes no responsibility for damage as a
region.
result of devices or water pipes located between the solenoid Failure to observe this instruction may result in severe inju-
valve and the water supply. ries or death.
All appliances fitted with InfinitySpring or IceMaker have a
water filter which is located in the front section of the appli-
IMPORTANT ance base. The water filter must be replaced regularly. An WARNING!
InfinitySwipe alarm reminds you when it is time to replace the
Do not operate the appliances outside of the ambient tempera- water filter.
ture ranges specified. Fire hazard
· The refrigerant circuits have been checked for tightness.
· Do not connect the appliance using an extension cable or
· The appliances meet the applicable safety regulations. multi-socket. There is a risk of overheating or fire due to
potentially poor connector contacts.

· Do not connect the appliance using an inverter. There is a risk

of overheating and a fire hazard for the control electronics
due to imperfect sine wave voltage of various inverters.

Failure to observe these instructions may result in fire, severe

injuries or death.

62 63
EU energy label
for electrical appliances
⸺

It is now once again possible to distinguish more easily between efficient and inefficient appliances.

With the reform of the energy label, appliances will again be distributed on the efficiency scale from A to G.
This will make things much clearer in future.

1 QR-Code to identify the product in the EU database

1
EPREL (European Product Database for Energy
Labelling).
2

2 The model identifier for manual identification of the

product in the EU database EPREL, using the article
number for example.

3 The new efficiency scale from A to G.

However, “G” is solely used for wine coolers.
3

4 The sum of the volumes of the freezer

compartments.

4 5
5 The total volume of all cold storage and refrigerator
compartments.

6 The noise level is now classified in classes “A” to “D”.

EWT 9175 I ECBN 9671

Do you still have questions? If so, please contact your Liebherr sales representative.

64 65
home.liebherr.com/monolith
Subject to changes. For latest available data, see home.liebherr.com/monolith.
Printed in Germany by Typodruck. 7900 986-02/08.21/EN

Liebherr Built-in Refrigeration Overview
No ratings yet
Liebherr Built-in Refrigeration Overview
63 pages
Liebherr Freestanding Refrigerator User Manual
No ratings yet
Liebherr Freestanding Refrigerator User Manual
38 pages
MD 2019 Refrigeration Planning Guidelines
No ratings yet
MD 2019 Refrigeration Planning Guidelines
12 pages
Gaggenau Vario 400 Series Cooling Planning Notes
No ratings yet
Gaggenau Vario 400 Series Cooling Planning Notes
10 pages
Liebherr Integrated Fridge-Freezer Features
No ratings yet
Liebherr Integrated Fridge-Freezer Features
2 pages
Transfair Refrigerator Cabinet Design-Part3
No ratings yet
Transfair Refrigerator Cabinet Design-Part3
19 pages
Elan Pro
No ratings yet
Elan Pro
8 pages
Refrigerator Selection Guide
No ratings yet
Refrigerator Selection Guide
12 pages
Asber Holodilnye Shkafy Green Line
No ratings yet
Asber Holodilnye Shkafy Green Line
25 pages
Aeg Cooling Brochure - September 2008 PDF
No ratings yet
Aeg Cooling Brochure - September 2008 PDF
16 pages
AEG Santo Fridge Freezer Features Guide
No ratings yet
AEG Santo Fridge Freezer Features Guide
16 pages
Bespoke Ref Installation Guide Web
No ratings yet
Bespoke Ref Installation Guide Web
13 pages
Planning Guide For Modular Refrigeration
No ratings yet
Planning Guide For Modular Refrigeration
17 pages
General Electric
No ratings yet
General Electric
1 page
GE Monogram Refrigerator Installation Instructions
No ratings yet
GE Monogram Refrigerator Installation Instructions
40 pages
Love Food. Love Liebherr.: Perfecting Preservation Since 1954
No ratings yet
Love Food. Love Liebherr.: Perfecting Preservation Since 1954
23 pages
SBS Catalog Digital 2025
No ratings yet
SBS Catalog Digital 2025
30 pages
Commercial Refrigeration Solutions
No ratings yet
Commercial Refrigeration Solutions
16 pages
Data Sheet PDF 625 xPRO
No ratings yet
Data Sheet PDF 625 xPRO
3 pages
8630 Miele Built in Brochure 2013 Pureline 2
No ratings yet
8630 Miele Built in Brochure 2013 Pureline 2
28 pages
The Space Wonder Made in Italy
No ratings yet
The Space Wonder Made in Italy
52 pages
LP Ice Creamchest Freezers - 2015 Aus Nov Email
No ratings yet
LP Ice Creamchest Freezers - 2015 Aus Nov Email
16 pages
ELANPRO Range Brochure - Oct 2021
No ratings yet
ELANPRO Range Brochure - Oct 2021
12 pages
Energy-Efficient Refrigeration Features
100% (1)
Energy-Efficient Refrigeration Features
18 pages
Ref Catalog Sbs 2024
No ratings yet
Ref Catalog Sbs 2024
30 pages
Commercial Kitchen Equipment
No ratings yet
Commercial Kitchen Equipment
205 pages
Professional Kitchens
No ratings yet
Professional Kitchens
12 pages
Freestanding Home Appliance Collection 2018: Middle East
No ratings yet
Freestanding Home Appliance Collection 2018: Middle East
27 pages
Trufrost Butler Refrigeration Catalogue
No ratings yet
Trufrost Butler Refrigeration Catalogue
116 pages
GE Brochure 2012 - Updated
No ratings yet
GE Brochure 2012 - Updated
24 pages
Elfin Compact Kitchens Brochure 2024/25
No ratings yet
Elfin Compact Kitchens Brochure 2024/25
40 pages
Side by Side Refrigerator Installation Guide
No ratings yet
Side by Side Refrigerator Installation Guide
1 page
2024-11-1906-Liebherr Built in Catalogue Copy 7
No ratings yet
2024-11-1906-Liebherr Built in Catalogue Copy 7
23 pages
SpecificationSheets Build 2024915 494418549
No ratings yet
SpecificationSheets Build 2024915 494418549
8 pages
Thermador Design Guide - Freedom Refrigeration
No ratings yet
Thermador Design Guide - Freedom Refrigeration
50 pages
LHI CBU Edition Brochure 2022
No ratings yet
LHI CBU Edition Brochure 2022
41 pages
Ei23bc35k 0613
No ratings yet
Ei23bc35k 0613
3 pages
Elfin Kitchenmanual
No ratings yet
Elfin Kitchenmanual
9 pages
Premium Wine Coolers and Refrigerators
No ratings yet
Premium Wine Coolers and Refrigerators
28 pages
Catalog: ISSUE 50 - 2023
No ratings yet
Catalog: ISSUE 50 - 2023
364 pages
Liebherr 2023/24 Freestanding Fridges
No ratings yet
Liebherr 2023/24 Freestanding Fridges
91 pages
Srs636scls Specs
No ratings yet
Srs636scls Specs
3 pages
30" Dual-Fuel Slide-In Range FGDS3065K
No ratings yet
30" Dual-Fuel Slide-In Range FGDS3065K
2 pages
30" Dual-Fuel Slide-In Range FGDS3065K
No ratings yet
30" Dual-Fuel Slide-In Range FGDS3065K
2 pages
New Range Catalogue 16 Page Jan 14
No ratings yet
New Range Catalogue 16 Page Jan 14
16 pages
EBG en 10 Internet
No ratings yet
EBG en 10 Internet
40 pages
2024-10-14 MasterCool III Bottom Mounts - New Generation - EU
No ratings yet
2024-10-14 MasterCool III Bottom Mounts - New Generation - EU
46 pages
Mitsubishi Electric Fridge Range Catalogue
No ratings yet
Mitsubishi Electric Fridge Range Catalogue
32 pages
Quick Reference Guide Model 650
No ratings yet
Quick Reference Guide Model 650
2 pages
Bespoke Ref Installation Guide v3
No ratings yet
Bespoke Ref Installation Guide v3
24 pages
Opal Emerald Brochure
No ratings yet
Opal Emerald Brochure
21 pages
MCDOC03187759 BSH Updated Fridge Brochure PDF
No ratings yet
MCDOC03187759 BSH Updated Fridge Brochure PDF
14 pages
Built in Catalogue - 20121122145501
No ratings yet
Built in Catalogue - 20121122145501
52 pages
Ksss36mdx05 Installation Instructions
No ratings yet
Ksss36mdx05 Installation Instructions
30 pages
Liebherr CounterTop Fridge & Freezer Guide
No ratings yet
Liebherr CounterTop Fridge & Freezer Guide
4 pages
Gorenje UK - Built-In Appliances 2009 - Layout 03
100% (2)
Gorenje UK - Built-In Appliances 2009 - Layout 03
100 pages
First Break All The Rules
0% (1)
First Break All The Rules
15 pages
Managerial Functions
No ratings yet
Managerial Functions
15 pages
Marketing Management Course Overview
No ratings yet
Marketing Management Course Overview
5 pages
MAJORSERVICE400
100% (1)
MAJORSERVICE400
6 pages
SoE ABVP-SLVD Manifesto 25
No ratings yet
SoE ABVP-SLVD Manifesto 25
4 pages
1980 Toronto Workshop Transcript by Moshe Feldenkrais
100% (2)
1980 Toronto Workshop Transcript by Moshe Feldenkrais
174 pages
WP 118
No ratings yet
WP 118
72 pages
Chemical Reaction Calculations Guide
No ratings yet
Chemical Reaction Calculations Guide
4 pages
Qualitative Response Regression Insights
No ratings yet
Qualitative Response Regression Insights
10 pages
Math 8 Q4
91% (22)
Math 8 Q4
166 pages
Dev C++ & Allegro Install Guide
No ratings yet
Dev C++ & Allegro Install Guide
15 pages
Survey and Study Techniques Guide
No ratings yet
Survey and Study Techniques Guide
5 pages
Postcard Writing Lesson Plan
No ratings yet
Postcard Writing Lesson Plan
3 pages
G5 Vibracare Percussor Service Manual
No ratings yet
G5 Vibracare Percussor Service Manual
4 pages
Social Media's Influence on Student Buying
No ratings yet
Social Media's Influence on Student Buying
20 pages
V200 Wheel Balancer Manual
No ratings yet
V200 Wheel Balancer Manual
30 pages
Chapter 3 The Information Age
No ratings yet
Chapter 3 The Information Age
24 pages
Thermometer Accuracy Check Guidelines
No ratings yet
Thermometer Accuracy Check Guidelines
1 page
Effective SQ3R Reading Strategies
No ratings yet
Effective SQ3R Reading Strategies
4 pages
Research Methodology Overview Guide
No ratings yet
Research Methodology Overview Guide
17 pages
Grouping Factors For Cables Laid Direct in The Ground
No ratings yet
Grouping Factors For Cables Laid Direct in The Ground
4 pages
Salient Pole Synchronous Machine
No ratings yet
Salient Pole Synchronous Machine
2 pages
Final - MATATAG WAP Template 3 - School Heads - SDO Cabuyao
95% (44)
Final - MATATAG WAP Template 3 - School Heads - SDO Cabuyao
8 pages
Managing Quality in Operations Management
No ratings yet
Managing Quality in Operations Management
45 pages
Module 1 Fundamental of Management Notes
No ratings yet
Module 1 Fundamental of Management Notes
35 pages
Ubiquitous Photography
No ratings yet
Ubiquitous Photography
5 pages
Art Appreciation: Origin and Scope
No ratings yet
Art Appreciation: Origin and Scope
3 pages
Resume Tendering
No ratings yet
Resume Tendering
2 pages
Updated Second Semester 2024-2025 Exam Timetable For Faculty of Science
No ratings yet
Updated Second Semester 2024-2025 Exam Timetable For Faculty of Science
20 pages
Entrep12 L5 - L6
No ratings yet
Entrep12 L5 - L6
6 pages

Monolith Planning Guide

Uploaded by

Monolith Planning Guide

Uploaded by

Planning Guide

EWT 9175 I EGN 9271 I EKB 9471

ECBN 9673 I FrenchDoor

Every Liebherr development, every new feature,

You can’t get greater than the Monolith. And

A statement of exceptional quality and pioneering

EGN 9671 I EKB 9671

Freezers Wine cabinets

EGN 9471 variant -617 left, reversible customer-spec. door panel /

EGN 9671 variant -617 left, reversible customer-spec. door panel /

45.7 61.0 45.7 76.2 91.4 91.4 76.2 61.0 76.2

EGN 9171 I EKB 9471

InfinitySwipe SmartDevice BioFresh-Plus

InfinitySpring PowerCooling InfinityLight Flexible door rack & storage shelves

Number of BioFresh / BioFresh-Plus safes with LED lighting

Interior lighting InfinityLight B

· Flat brushed aluminium handle Overlay installation

Interior lighting InfinityLight B

· Flat brushed aluminium handle Overlay installation

Interior lighting InfinityLight B

· Flat brushed aluminium handle Overlay installation

EGN 9171 I EKB 9471

SoftSystem InfinityLight Flexible door rack SuperFrost

Water filter yes B

· Flat brushed aluminium handle Overlay installation

Water filter yes B

· Flat brushed aluminium handle Overlay installation

Water filter yes B

· Flat brushed aluminium handle Overlay installation

Water filter yes B

· Flat brushed aluminium handle Overlay installation

ECBN 9673 I FrenchDoor

InfinitySwipe DuoCooling InfinityLight Individually opening doors

InfinitySpring BioFresh-Plus IceMaker SmartDevice

754 mm 610 mm IMPORTANT! Inset door panel

Number of door racks

Temperature range of refrigerator compartment in °C +2 °C to +7 °C B

Number of door racks

Temperature range of refrigerator compartment in °C +2 °C to +7 °C B

Number of door racks

Temperature range of refrigerator compartment in °C +2 °C to +7 °C B

EGN 9271 I EWT 9275 I EKB 9471

InfinityLight Aluminium labelling strip InfinitySwipe InfinityProtection

FreshAir activated charcoal filter SoftSystem SoftTelescopic InfinityBoard

Interior lighting InfinityLight B

Interior lighting InfinityLight B

· Flat brushed aluminium handle w

Stainless steel panels Stainless steel panel set

Refrigerators and freezers

45.7 61.0 76.2 91.4 45.7 61.0 76.2 91.4 91.4

Door hinge exchange set

635 mm + thickness of the custom panel

ECBN 9673 768 mm 908 mm 768 mm 1 914 mm 2 30 kg

See also “Requirements for door spacing” on page 61.

Liebherr provides a 102 mm high plinth panel made of stainless

A = Furniture framing (here 19 mm, for example) A = 19 mm unit carcass

Ambient temperatures Secure mounting Warnings Electrical safety

· Do not connect the appliance using an inverter. There is a risk

Failure to observe these instructions may result in fire, severe

1 QR-Code to identify the product in the EU database

2 The model identifier for manual identification of the

3 The new efficiency scale from A to G.

4 The sum of the volumes of the freezer

6 The noise level is now classified in classes “A” to “D”.

EWT 9175 I ECBN 9671

You might also like
