EXP1: Programming using Arithmetic, Logical, branching, and loop

operations by 8051 Microcontroller.


AIM: To write an Assembly Language Program to perform Arithmetic, Logical, branching, and
loop instructions of 8051
APPARATUS:
1. Lab Computer

2. Keil Software

PROCEDURE:

ARITHMETIC OPERATIONS

Program: 8 Bit Addition

ORG 00h
MOV A,#12
MOV B,#45
ADD A,B
END
Program: 8 Bit Subtraction

ORG 00h
MOV A,#45
MOV B,#15
SUBB A,B
END
Program: 8 Bit Multiplication

ORG 00h
MOV A,#12h
MOV B,#12h
MUL AB
END
Program: 8 Bit Division

ORG 00h
MOV A,#45h
MOV B,#05h
DIV AB
ENDS
LOGICAL OPERATIONS

Program: AND Operation

ORG 00h
MOV A,#22h
MOV R0,#0Fh
ANL A,R0
END
Program: OR Operation

ORG 00h
MOV A,#22h
MOV R0,#0Fh
ORL A,R0
END
Program: XOR Operation

ORG 00h
MOV A,#22h
MOV R0,#0Fh
XRL A,R0
END
Program: Bit Manipulation Instructions

ORG 00h
MOV A,#55h
CPL A
END
BRANCHING AND LOOP OPERATIONS

Program: Write a program to add 2 to register A 100 times using looping.

ORG 00h
MOV A, #00
MOV R1, #100
LOOP: ADD A, #02
DJNZ R1, LOOP
END

RESULT: Programming using arithmetic, logical, branching, and loop instructions of 8051

Viva:
1) What are the features of 8051 microcontrollers?
2) Explain PSW?
3) What are bank registers?
4) What is internal memory in 8051?
5) Explain about shift and rotate instruction?
