AK 150 RTX

CONTENT:

Use original spare parts

Important............................................................2
General information ............................................... 3

Motorcycle cleaning process...........................16

Identification data..........................................................18
Technical specifications..............................................19

Fuel and oil recommendations…………………………....21

Part location.............................................................22
Command functions....................................................25

Speedometer and indicator lights……………………………………...39

Usage recommendations................................................30
Post-maintenance table..................................................31
 ORIGINAL PARTS

To preserve the vehicle's performance, each spare part must be designed and built.
with strict specifications for optimal performance. "Original parts
AKT" are made with the same materials and quality patterns used to build the
motorcycle. No part is released to the market without meeting the requirements set by our
standards and without being subjected to exhaustive testing and quality control by
our engineers.

For the above reasons, when a repair or replacement of any part is necessary,
purchase 'Original AKT Parts' at AKT parts sales points. If you purchase
a cheaper product from a brand different from ours, we do not guarantee its quality nor
durability, in addition this will cause a decrease in the performance of your vehicle, as well as
possible problems with your motorcycle.
Repair or replacement of any part, acquire 'Original AKT Spare Parts' at the locations
for sale of AKT spare parts. If you purchase a cheaper product from a different brand
our, we do not guarantee its quality or durability, furthermore this will cause a decrease in the
features of your vehicle, as well as possible problems with your motorcycle.

Alltheinformation,illustrations,photographs,andspecificationscontainedinthismanual
are based on the most recent information available at the time of this publication. Akt
they may modify them without prior notice.
 ! IMPORTANT

BEFORE STARTING THE MOTORCYCLE

CHECK THE OIL LEVEL OF THE TRANSMISSION
(FOUR TIMES)

AKT Motors
Recommend

Super + 4T
SAE 20w50

JASO MA SAE 20W50

API SG
 GENERAL INFORMATION

OIL BOX 4T
To check the oil level, support your motorcycle on the center stand.
to make a correct measurement; then remove the measuring plug from
oil it, clean it and insert it without screwing it back into the hole,
I finally noticed that the whole end
the marker is imbued
of oil.

The oil level must be checked.

cold motorcycle completely.
Make the oil changes according to the
periodic maintenance table (each
2000 Km.
AKT Motors
Recommend
Amount of oil: 1,000 cc

Super + 4T
SAE 20w50
JASO MA SAE 20W50 API SG
Front brake
The brake system fluid reservoir
of the front disk, it is located on the part
right of the handlebar, its level must be
reviewed periodically.
This review is only visual to determine
In what condition is it?
If the liquid level is low and is observed from
dark color needs to be changed completely
The fluid in the system may be degraded or contaminated with water.
If the liquid level is low and it is not dark in color, check first
the wear of the pads before adding brake fluid. Type DOT4
(recommended) until reaching the optimal level.
If the liquid appears contaminated with dirt or water, do your
completely changes.
Change the brake fluid only at authorized points.
ACT.MOTOS

The brake fluid change should be done every year, as

It is recommended in the periodic maintenance table located
at the end of this manual.
FRONT BRAKE PADS INSPECTION
Inspect the front brake pads periodically. If they
detects that the pills are near the boundary line, proceed
as soon as possible to a Technical Service Center to be
replaced.
Inspect the braking system daily before driving your vehicle.
motorcycle, please consider the following points:
lLiquid leaks throughout the system.
lCondition of the hose that conducts the liquid from the pump
towards the gag.
lWear of the pads.
lHardness of the front brake lever.

! ATTENTION
Driving with worn brake pads reduces the
brake effectiveness causes wear
disk herniation and increases the risk of
accidents. Drive carefully when
I installed a new brake pad game.
REAR BRAKE
The rear brake pedal is located on the right side.
motorcycle next to the footrest.
Inspect the brake daily before starting your motorcycle, if
detect any anomaly in some of the brake components
please go to the nearest Technical Service Center as soon as possible.
after inspecting the brake, it detects that the
the pedal is too low, it needs to be adjusted.

HOW TO ADJUST THE BRAKE.

lPress the rear lever towards
forward to loosen the screw of
adjustment of the rod.
lAdjust the screw at the end of the
stick.
l Release and check that the pedal has
a normal tour.
lIf the screw needs to be tightened too much, go to the Service Center.
Closest technician to carry out the respective verification of the status and
wear of the bands.
 BATTERY
The LaAK 150 RTX has a battery of 12V-9A, this
is located within the side cover
right.
Check the electrolyte level of each cell
periodically, this must be found among the
upper and lower levels marked on the battery, in
in case any cell has a low level, add water
distilled. Tap water is not a substitute for distilled water, use it
it will reduce the battery life.

lDo not add acid after the initial charge.

lAfter the initial load, always add water
distilled because this is the one that evaporates and not the acid.
l Charge only at Service Centers
authorized by AKT.
lAvoid contact with battery liquids
mainly in the eyes or in any part of the body, if something were to occur
accident, wash the affected area with plenty of water and seek immediate assistance at
nearest health center.
FINAL DISPOSAL OF BATTERIES

The assembler AKT motorcycles in

compliance with the resolution
0361 of March 3, 2011
has a plan for the
final disposal of batteries
the collection is carried out through
our service centers
authorized technician from all over the country,
contributing in this way to the
ecological support of
p l a n e t a .
 TIRES
Check the tire pressure periodically to extend their
useful life. If there is too much pressure, the tire will wear out.
center and when braking it bounces, and if it has low pressure it will wear out
It slides on the sides and when braking or in turns. In any case.
In both cases, the braking is ineffective.
A lot of pressure
Check the condition and pressure of the tires before
drive your motorcycle.
lAvoid overloading the motorcycle.
lChange the tires when they are worn out.
or have some kind of cut or crack.
lAlways use the type and dimension of the Low Pressure
recommended tires for the AK150 RTX

FRONT 26 PSI
BACK 28 PSI
REAR with passenger 32 PSI
This will increase the lifespan of your tires. Ideal Pressure
and it will reduce fuel consumption.
 CAUTION
If there is any problem with the tire pressure or any crack or cut;
the stability of the motorcycle will decrease and the risk of suffering an
accident.

ATTENTION

TIRE TYPE.
lType Street. (On Road).
lDimensions:
Front: 90/90 17
Rear: 110/80 17
TRANSMISSION CHAIN
The chain allows the engine to transmit its
power to the rear tire of the motorcycle, for
this reason requires maintenance 1.5 to 2.5 cm
newspaper and keep it under constant observation.

The chain should be checked for tension at least once a

week; just hold the motorcycle on the center stand to observe that it does not
it presents a very high or very low tension, if it is too loose or too tight
it could cause damage to the motorcycle or even to its user, if it were to break or get tangled it must
take it to an Authorized AKT Service Center for its repair.

CHAIN INSPECTION

To correctly carry out the inspection of the chain, the following steps must be taken:
l Raise the motorcycle on the central support (jack).
l Turn the rear wheel and find the part of the chain where there is the greatest tension, there adjust it.
string from top to bottom to recognize the distance it travels vertically, this
the distance should be approximately between 1.5-2.5cm. If the distance does not meet these parameters, it is
It is necessary to approach an authorized AKT Technical Service Center for proper inspection.
Palanque changes

LaAK 150 RTX comes equipped with a

5-speed gearbox that
operates according to the graph, it is located
located to the left of the engine. For
activate the changes in a way
appropriate, it must be acted upon
Time the clutch and decelerate, each time
to select a change, the
lever
returns to his
initial position and ready for
select another change. Push towards
up to increase the changes and towards
down decreases. The neutral is
find between first and second, for
place the motorcycle in this gear
must have a speed equal to zero.
AIRFILTER
The air filter is located behind.
from the left side cover.
If this gets contaminated with dust and blocks the
normal aspiration of the motorcycle,
the power will decrease, it will increase the
gasoline consumption and can produce a
premature wear of the internal parts of the
motor. If the motorcycle is used regularly in
dusty areas, it is advisable to change the
air filter more frequently than indicated in the table
periodic maintenance.
Change the air filter as indicated below.
lRemove the left side cover.
lRemove the screws from the filter box cover.
lRemove the filter and install the new filter.
lMake sure the lid fits well.

NOTE: the air filter should be changed every 6,000

kilometers, or every 3,000 kilometers if the terrain is
dusty. by no means clean air under pressure.
CHOKE
The choke or throttle lever is used to start the motorcycle.
when it is cold, remember to deactivate this element when the
the optimal engine temperature has been reached.

EAR VALVE
EXHAUST AIR RECIRCULATION

The EAR valve "exhaust air recirculation" dilutes the

exhaust gas volume through the addition of
air, thus reducing the percentage of particles
pollutants released into the environment
caused by the internal combustion of the engine.
CLUTCH ADJUSTMENT

The clutch lever is located

located on the far left of the handlebar,
This usually tends to relax so it should
periodically check, the normal adjustment of
this element is a game of 2 to 3
2 millimeters between the lever and the base

HOW TO ADJUST THE LEVER.

lRemove the plastic protector (1)

sliding it along the cable.
l Loosen the lock nut (2).
3 lAdjust the screw (3) until it gives the
2 or 3 mm desired adjustment.
lTighten the lock nut (2).
lSlide the plastic protector (1) to
1 starting point.
MOTORCYCLE CLEANING PROCESS
Washing the motorcycle is a necessary activity of
preventive maintenance helps to keep everything in good condition
vehicle systems, it also facilitates the inspection of the components of
the motorcycle when required.

The accumulation of dirt in the engine and in the muffler interferes with the
adequate cooling and hides potential damage that could harm the
good functioning of the engine.

Washing the motorcycle with high-pressure water machines can cause damage.
some components can lift the paint from plastic parts
involved. Never use detergent-type soaps (semi-particles
solid), they can scratch painted and plastic parts, always wash with
soft soaps and plenty of water.
Rinse the motorcycle with clean water and dry it with a cloth or towel.
absorbent.
 SIDE PANEL HANDLING

To remove the side covers of the motorcycle, it is recommended to follow

the next step, according to the lid you wish to remove.

TAP ON THE RIGHT SIDE

Remove the star screw located at the bottom of the
lid, remove the lid from the rubber supports by pulling up
outside and remove the cover towards the part
front of the motorcycle. TOP LEFT

LEFT LATERAL TAP

TOP RIGHT Remove the star screw located in the
bottom of the lid, remove the lid from
pull the rubber supports outward and remove the cover towards the
front part of the motorcycle.
To assemble them again, repeat the previous procedure but
inverting the sequence of the steps.

DO NOT abruptly remove the covers because can

To break them.
 IDENTIFICATION DATA
LOCATION OF THE NUMBER
OF THE MOTOR:

The engine number of the AK 150 RTX is

located in the housing
left, below the gearshift axis.

LOCATION OF THE NUMBER OF

CHASSIS:
xxxxxxxx
The chassis number of the AK RTX is located
located at the front of the chassis,
exactly behind the front light.
 TECHNICAL SPECIFICATIONS
Technical data AK150 RTX
Motor 4T SOHC
Engine displacement 149 cc
Compression ratio 9.2:1
Maximum Power (hp) @ rpm 12.5 hp @ 7000 RPM
Maximum Torque N.m @ rpm 12 @ 5500 RPM
Start Electric
Lighting CDI
Front suspension Hydraulic telescopic
Rear suspension Double shock absorber
Brakes (front and rear) Disk/Drum
Front/Rear Tire Specifications FR 90/90-17 RR110/80-17
Length x Width x Height (cm) 2000×760×1040
Dry weight kg 117
Tank capacity 14.5L (3.8Gal)
Reservation 3.1L (0.81Gal)
Maximum Speed km/h * 105
Origin China assembled in Colombia
Guarantee 15monthsor20,000kilometers

Under specific conditions

 BOX OIL AKT Motorcycles

(4 Times) Recommend

Always use oil for motorcycles. If a oil is used for

good quality for four-stroke engines and it is made Super + 4T
periodic change as indicated by the lubrication chart, SAE 20w50
will extend the lifespan of your motorcycle.
Engine oil specifications
System of Degree JASO MA SAE 20W50
classification API SG
API SG or Superior
SAE 20W-50
If you do not have availability of a SAE20W-50 motor oil, choose one.
alternative according to the table.
System of 20W50
classification 15W40 15W50
10W40 10W50
10W30
C° -30 -20 -10 0 10 20 30 40
Temperature
F° -22 -4 14 32 50 68 86 104
FUEL AND OIL RECOMMENDATIONS

GASOLINE
Always use regular unleaded gasoline, unleaded gasoline extends the lifespan of
the spark plug and the components of the exhaust system.

CAUTION
Spilling gasoline on any painted surface can cause damage to it,
if this happens, wash immediately with plenty of water.
ATTENTION
Never add gasoline to the tank near flames, sparks, or heat sources. No
If you overfill the tank, it needs space for storage.
gases and for the expansion of gasoline with changes in temperature.

NOTE: The compression ratio of this engine is 9.2:1, which is why

which can use regular gasoline without causing any damage
for the motor.
 PARTS LOCATION

SWITCH ON:

The power switch has three positions:

OFF: Engine off, electrical system isolated.

ON: Motor on, electrical equipment can be used and the

Ignition key cannot be removed.

BLOCK: The steering will only be locked with the handlebar.

in the far left position, turning the key until the
blocking position.

! WARNING: Do not leave the switch in the ON position with the engine
turned off, it can reduce the lifespan of your battery.
FUEL TANK CAP
To open the gas tank cover, you must follow the following steps.
steps:
lLift the tab that covers the switch of the tank cover.
gasoline
lInsert the key into the slot and turn it clockwise.
of the clock.
lLift the cover without removing the key from the motorcycle.
proceed to fill the tank.

! IMPORTANT
Do not overfill the gas tank as it may spill.
and causing damage to the elements of the motorcycle.

Use regular gasoline.

GASOLINE NOZZLE

The stopcock of Down

gasoline is located
on the side
left of the tank
gasoline, this has the
following stars
positions:
Center
Below: Reserve position when not held
sufficient gasoline. It should refuel as soon as possible.
possible.

Center: Tap closed, no passage of

flammable.
Up
Above: Position when one has enough
gasoline above the reserve level.
 COMMAND FUNCTIONS

LEFT COMMAND
PASS
SWITCH CHANGE
OF LIGHTS

DIRECTIONAL

PITO
 switch must remain in this
Directionals: position.
Esteswitch has three positions.
This switch must be positioned
manually.
LeftPosition:
It is used when one wishes to turn to the
left. Both will light up Pito:
left turn signals and the light Press the horn button to honk
left turn indicator
on the board. Change of Lights
The headlight switch has
Right position: two positions:
It is used when one wants to turn to the
right. Both will light up Position activated:
right turn signals and the light In this position the light turns on
right directional indicator in altaysu pilot indicator.
the board.
Disabled position:
Central position: In this position, the light turns on.
No indicator lights up in lower.
this position. As long as it does not
They need the right turn signals.
 COMMAND FUNCTIONS

COMMAND RIGHT
SWITCH ON
ON/OFF SWITCH ON
ON/OFF LIGHTS

POWER BUTTON
ELECTRIC
SWITCH ON/OFF LIGHTS SWITCH ON/OFF
Esteswitch has three positions: This switch isolates or activates the system
electric motorcycle preventing or
Right position: it's off, it has two positions:
The dashboard lights, stop, and streetlight are in the forward position isolates and in the
they are found turned off. the active system positions back.

Intermediate position:
Dashboard lights, stop and headlight (light
They will be turned on during the day.

Left position:
The dashboard lights, indicators, headlight and
they will stop turning on.

START BUTTON
Remember to turn off the lights before
press the start button. Use the
start pedal for starting in
cold.
 SPEEDOMETER AND INDICATOR PILOTS
INDICATOR PILOTP LIGHT INDICATOR
MEASURING DEVICE OF
RESERVE HIGH DIRECTIONAL
REVOLUTIONS
INDICATOR IND. RIGHT
DIRECTIONAL NEUTRAL
LEFT

7 8 9
6 10
5
4 11
ODO Km 3 12
GEAR

2 13
F E km/h 1 14
X1000r/min
0

METER OF
GASOLINE
SPEEDOMETER
INDICATOR INDICATOR OF
FUEL STARTING POSITION
RECOMMENDATIONS TO ACHIEVE OPTIMAL VEHICLE PERFORMANCE

To ensure that your AK 150 RTX motorcycle performs excellently, follow these
recommendations:

ü Read and follow the vehicle's warranty manual in detail.

You will find important aspects for the care of your motorcycle.

ü Follow the instructions for proper engine takeoff (refer to

warranty manual

ü Use only the lubricant recommended by the manufacturer.

ü Change the engine oil at each mandatory inspection.

ü Keep the engine oil level at the indicated level.

ü Ensure that the battery is in optimal condition because of this.

It depends on the motorcycle ignition. (this model does not have)
crank pedal

ü Change the air filter according to the recommendation made in this manual
 MAINTENANCE SCHEDULE

V: verificar, L: limpiar, A:ajusar, C: cambiar
