Sliding Headstock Type CNC Automatic Lathe
Switch between guide bushing
and non-guide bushing type
Acclaimed for its excellent cost to performance ratio, the A20 has The performance of the machine has been improved too. The high
evolved as a 5-axis machine for ø20 mm applications with the ad- speed 10,000 rpm spindle enables optimized machining operations
vantage that it can be used with or without a guide bushing. Use on smaller diameter bar material. The machining length per chucking
as a regular guide bushing automatic lathe when machining long, is now extended to 200 mm enabling the number of re-chuckings
slender workpieces or without a guide bushing for shorter parts and therefore cycle times to be reduced when machining long
with minimal bar end remnants. The guide bushing can be quickly workpieces. As an option, bar material of up to ø25 mm can also
and easily mounted and removed. be machined extending the range of workpieces.
02 Cincom A320
Tooling System
Rotary tools for One rotary tool position
cross machining: is Quill Type
4
X1
Y1
Turning tools on
the gang tool post:
Tools for 5 (½”)
front drilling:
4 (1”) Z1
X2 Z2 Rotary tools on the back
tool post (option)
Tools for back
drilling:
8 (4+4, 1”)
A20 Tooling
Example
Guide bushing type
Switchable
Non-guide bushing type
Cincom A320 03
More speed, more stroke, more capacity
• The A20 features a new capability to switch between guide bushing
and non-guide bushing operating modes.
• The machine’s performance, including spindle speed and machining
length per chucking, has been increased.
• It is designed for ease of use and convenience with good chip
clearance for fast set-ups.
Maximum spindle speed of 10,000 rpm 200 mm/1 chucking Support for stock material up to ø25 mm
The maximum speed of the front spindle A longer 200 mm machining stroke reduces (option)
is high at 10,000 rpm enabling optimized the need for re-chucking workpieces, which With its spindle through hole diameter of
machining conditions on small diameter in turn, reduces cycle time. 26 mm, the A20 is capable of machining bar
bar material or using small diameter cut- stock up to ø25 mm by installing the optional
ting tools. 25 mm size chuck device — enabling a wider
range of workpieces to be produced over
the standard 20 mm machine.
Productivity Improvements
Idle time is slashed using the preprocessing function the Cincom Control
that analyses the machining program before it is run to minimize process-
ing and calculation times.
Zero Conventional
Conven- Stop
point machine
tional rotation
return
machine
Rotating Indexing
Axis feed
overlap areas
A20 A20
Direct
C-axis
indexing
Rotating Indexing Reduced idle
time
Direct C-axis indexing function Axis feed overlap function
Direct C-axis indexing enables deceleration of direct to chosen in- The next axis feed motion starts without waiting for completion of
dex position eliminating the wasted time of performing zero return. the current motion of another axis. This cuts out wasteful idle time
and also suppresses unwanted vibration.
04 Cincom A320
Upgraded machine performance and usability
Work Light USB/PC card slot
Low energy illumination is provided as standard in the NC programs can be input and output using the USB slot or
machining area giving an environment that is bright with PC card slot on the front face of the control panel.
ideal visibility.
Coolant nozzle Parts collection
Coolant nozzles are provided at the appropriate locations to The large collection box reduces the frequency of empty-
ensure that sufficient coolant can be supplied to the point ing. The optional workpiece conveyor discharges to the left
of machining. front of the machine.
Coolant tank/chip collection box Adjustable operation panel
A 150-litre coolant tank is standard, enabling extended peri- The pivoting operation panel enables easy operation while
ods of operation. The chip outlet port has been increased to simultaneously viewing the machining process.
improve chip removal. Optional chip conveyors are available
to suit the type of chip material.
Cincom A320 05
User friendly
Screen Display is Easy to View and Read
On-machine program check function Display of code list
Using manual hand feed, operations can be run in the forward The function displays the list of G, M, and T codes including
or reverse directions, can be paused to edit the program, and explanations - a useful aid to programming.
restart.
Easy viewing with text size change
Two text size settings can be applied to each screen (large
text display illustrated).
06 Cincom A320
Machine Layout
A20 Standard Machine
A20 Option-installed Machine
Cincom A320 07
Machine Specifications
Item A20VII (A20-3F7) Standard NC functions
Max. machining diameter (D) ø20 mm (ø25 option) NC unit dedicated to the A20
Max. machining length (L) GB:200 mm/1chucking (188 mm: ø25 spec.) NGB: 2.5D 8.4 inch color LCD
Spindle through-hole diameter ø26 mm On-machine program check function
Main spindle speed Max.10,000 rpm Operating time display function
Spindle speed of the gang rotary tool Max. 6,000 rpm (Rating 4,500 rpm) Preparation function
Max. chuck diameter of back spindle ø20 mm (ø25 option) Spindle speed change detector
Max. protrusion length of back spindle workpiece 50 mm Nose radius compensation
Max. protrusion length 100 mm Constant surface speed control function
Back spindle speed Max. 8,000 rpm Program storage capacity: 80m
Number of tools to be mounted 21 (approx. 32KB)
Tool size Product counter indication (up to 8 digits)
Tool (gang tool post) 1/2” Automatic power-off function
Sleeve 1” Continuous thread cutting function
Chuck and bushing Pre-processing function
Main spindle collet chuck TF25 (TF30: ø25 mm) Tool offset pairs: 49
Back spindle collet chuck TF25 (TF30: ø25 mm) Sub micron commands
Rotary tool collet chuck ER11, ER16 Spindle synchronized function
Chuck for drill sleeves ER11, ER16 High speed rigid tapping function
Guide bushing TD25NS (CD25: ø25 mm) Chamfering, corner R
Rapid feed rate Canned cycle drilling
All axes (except X1) 32 m/min Drawing dimension direct input
X1 axis 18 m/min Multiple repetitive cycle for turning
Motors User macros
Spindle drive 2.2 / 3.7 kW Y-axis offset
Tool spindle drive 0.75 kW Front/Back spindle C-axis function
Back spindle drive 1.1 / 1.5 kW Tool life management I
Coolant oil 0.4 kW Tool life management II
Lubricating oil 0.003 kW Network I/O function
Center height 1,050 mm Inch command
Rated power consumption 7.1 kVA Sub/inch command
Full-load current 20.2A
Main breaker capacity 30A Optional NC functions
Air pressure & air flow rate for pneumatic devices 0.5 MPa • 47NL Program storage capacity 2560m
Weight 4,851 lbs (approx. 1MB)
Hob/polygon function B
Optional block skip (9 sets)
Standard accessories Optional accessories External memory program driving
• Main spindle chucking device • Fixed guide bushing device
• Back spindle chucking device • Knock-out jig for through-hole
• Rotary guide bushing device workpiece
• Cut-off tool breakage detection • Callback chute
• Lighting • Long workpiece unit
• Workpiece separator • Workpiece conveyor
• Coolant unit with level detector • Chip conveyor
• Lubricating oil supply unit with • Coolant flow rate detector
level detector • Signal lamp
• Door lock • 3-color signal tower
• Pneumatic device for air sealing
• Machine relocation detector
