♣ Devices Interfaces
Basics
Internetwork Operating System (IOS)
Collection of network operating systems used on devices
3
PURPOSE OF OS
P C operating systems (Windows 8 & O S X) perform technical
functions that enable
• File, memory and process management,
• Handling input and output, and
• Controlling peripheral devices such as disk drives and printer
• Switch or router I O S provides options to
Configure interfaces
Enable routing and switching functions
All networking devices come with a default I O S
Basics
Possible to upgrade the I O S version or feature set
4
LOCATION OF THE IOS
Basics
Quantity of flash and RAM memory determines IOS
that can be used
5
IOS FUNCTIONS
Major functions performed or enabled by routers and switches include
Routing
Qos
Security
Addressing
Interfaces
Basics
Managing resources etc.
6
DEVICE INTERFACES
• Networking devices have several types of interfaces
associated with them.
1. Fast Ethernet interface :is used for connecting cables that
terminate with L A N devices such as computers and switches.
2. Serial interface : is used for connecting WAN devices to the
CSU/DSU
3. Console interface : is the primary interface for initial
configuration of a router or switch
4. Auxiliary interface: The auxiliary (AUX) interface is used for
remote management of the router.
Typically, a modem is connected to the A U X interface for dialup
Basics
•
access.
8
CONSOLE ACCESS METHOD
Most common methods to access the Command Line Interface(CLI)
Console
Telnet or S S H
A U X port
Basics
9
CONSOLE ACCESS METHOD…
Console port
D evice is accessible even if no networking services have been
configured (out-of-band)
Need a special console cable
Allows configuration commands to be entered
Should be configured with passwords to prevent unauthorized
access
Device should be located in a secure room so console port can not be
easily accessed
Basics
10
TELNET, SSH, AND AUX ACCESS METHODS
Telnet
Method for remotely accessing the C L I over a network
Require active networking services and one active interface that is
configured
Aux Port
Out-of-band connection
Uses telephone line
C a n be used like console port
Basics
11
TERMINAL EMULATION PROGRAMS
Software available for
connecting to a networking
device
PuTT Y
Tera Term
Secure C RT
HyperTerminal
O S X Terminal
Basics
12
For simulation we use Packet tracer to configure logical devices
IOS MODES OF OPERATION
Basics
Each mode has a distinctive prompt
13
NAVIGATING THE IOS
PRIMARY MODES
Basics
14
PRIMARY MODES
The two primary modes of operation are user E X E C mode and
privileged E X E C mode.
The privileged E X E C mode has a higher level of authority in what it
allows the user to do with the device.
User E X E C Mode
The user E X E C mode has limited capabilities but is useful for some
basic operations.
This mode is the first mode encountered upon entrance into the C L I of
an I O S device.
This is often referred to as view-only mode.
Basics
The user E X E C level does not allow the execution of any
commands that might change the configuration of the device. 15
CONT…
By default, there is no authentication required to access the user
E X E C mode from the console.
However, it is a good practice to ensure that authentication is
configured during the initial configuration.
The user E X E C mode is identified by the C L I prompt that
ends with the > symbol.
This is an example that shows the > symbol in the prompt: Switch>
Privileged E X E C Mode
The execution of configuration and management commands requires
Basics
that the network administrator use the privileged E X E C mode, or a
more specific mode in the hierarchy.
16
CONT...
authentication.
Basics
configuration modes can only be reached from the
privileged E X E C mode. 17
NAVIGATING THE IOS
GLOBAL CONFIGURATION MODE AND SUBMODES
Basics
18
GLOBAL CONFIGURATION MODE AND SUBMODES
mode.
Basics
Switch# configure terminal
19
Switch(config)#
CONT.
From the global config mode, the user can enter different sub
configuration modes.
Each of these modes allows the configuration of a particular part or
function of the I O S device.
Interface mode - to configure one of the network interfaces
(Fa0/0, S0/0/0)
L i n e mode - to configure one of the physical or virtual lines
(console, A U X , VTY)
As commands are used and modes are changed, the prompt
Basics
changes to reflect the current context.
20
NAVIGATING BETWEEN IOS MODES (CONTINUED)
Basics
21
THE COMMAND STRUCTURE
IOS COMMAND STRUCTURE
Basics
22
IOS COMMAND STRUCTURE…
Basics
is the 10.10.10.5.
20
CONT...
Basics
24
THE COMMAND STRUCTURE
IOS EXAMINATION COMMANDS
Basics
25
IOS EXAMINATION COMMANDS…
Basics
currently running configuration file.
26
HOSTNAMES
WHY THE SWITCH
Let’s focus on
1. Creating a two P C network connected via a switch
Basics
27
1. HOSTNAMES
DEVICE NAMES
Some guidelines for naming conventions are that names should:
Contain no spaces
Basics
configuration purposes.
28
HOSTNAMES
HOSTNAMES
Hostnames allow
devices to be identified
by network
administrators over a
network or the Internet.
Basics
29
2. LIMITING ACCESS TO DEVICE CONFIGURATIONS
SECURING DEVICE ACCESS
Basics
30
SECURING DEVICE ACCESS
Basics
administrator, because these are easily guessed
31
LIMITING ACCESS TO DEVICE CONFIGURATIONS
Basics
32
LIMITING ACCESS TO DEVICE CONFIGURATIONS
SECURING USER EXEC ACCESS
Console port must be secured
• Reduces the chance of unauthorized personnel physically plugging a
cable into the device and gaining device access
Service password-encryption
• Prevents passwords from showing up as plain text when viewing the configuration
• Purpose of this command is to keep unauthorized
individuals
Basics
from viewing passwords in the configuration file once applied.30
LIMITING ACCESS TO DEVICE CONFIGURATIONS
BANNER MESSAGES
Basics
31
3.SAVING CONFIGURATIONS
CONFIGURATION FILES
Switch# reload
⚫System configuration has
been modified. Save?
[yes/no]: n
⚫Proceed with reload?
[confirm]
Startup configuration is
removed by using
the erase startup-
config
⚫Switch# erase startup-
config
On a switch you must
also issue the delete
vlan.dat
⚫ Switch# delete
Basics
vlan.dat
⚫ Delete filename
[vlan.dat]?
[confirm]
⚫ Delete 32
flash:vlan.dat?
CONFIGURATION FILES
[confirm]
Confirm is the default response.
To confirm and erase the startup configuration file, press .
Pressing any other key will abort the process.
Basics
36
The End!
Q?
