Kohler Quick Reference Guide

Call 888-652-3990 Online at OPEengines.
com
FAST MOVING PARTS

Call 888-652-3990 Online at OPEengines.com
TABLE OF CONTENTS
Section Page Number

Air Filters............................................................................................................................3
Retail Packaged Air Filter Kits.......................................................................................12
Fuel Filters ......................................................................................................................15
Oil Filters..........................................................................................................................16
Oil.....................................................................................................................................17
Fuel Pumps ....................................................................................................................18
Carburetor Kits................................................................................................................21
Ignition.............................................................................................................................27
Maintenance Kits............................................................................................................36
Electric Starters..............................................................................................................38
7KLVLQIRUPDWLRQLVSURYLGHGLQUHIHUHQFHRQO\7RREWDLQSUHFLVHSDUWQXPEHUV\RXZLOOQHHGWKHPRGHOVSHFL¿FDWLRQQXPEHUDQGWKH
Kohler parts look-up system.
2
AIR FILTERS
K-Series K91, K161
Air Filter Precleaner

Part No.: 230840-S Part No.: 234870-S
Air Filter Dimensions 4.4” O.D. x 1.6” H
K-Series K181

Part No.: 231847-S Part No.: 234869-S
K-Series K241-K321
Magnum M8

Part No.: 235116-S Part No.: 237421-S
Also available in retail version 25 883 03-S1
3
AIR FILTERS
K-Series K532, K582

Part No.: 277138-S Part No.: 277593-S
Command CV11-CV16

Part No.: 12 083 05-S Part No.: 12 083 08-S
Air Filter Dimensions 4.5” L x 2.8” H
Command PRO CV11-CV16, CV430-CV493

Part No.: 12 083 10-S Part No.: 12 083 12-S
Air Filter Dimensions 4.5” L x 3.3” H
Also available in the retail version 12 883 10-S1
4
AIR FILTERS
Courage XT-7

Part No.: 14 083 01-S Part No.: 14 083 02-S
Air Filter Dimensions 5.7” L x 3.5” W
Command PRO CH6

Part No.: 15 083 06-S Part No.: 234870-S
Air Filter Dimensions 4.4” O.D. x 1.6” W
Courage SV470-SV620

Part No.: 20 083 02-S Part No.: 20 083 03-S
Air Filter Dimensions 7.8” W x 1.4” H
5
AIR FILTERS
Command PRO CH18-CH26, CH620-CH750, CV18-CV25, CV620-CV740

Part No.: 24 083 03-S Part No.: 24 083 05-S
Air Filter Dimensions 7” O.D. x 2.9” H
Command PRO CH18-CH26, CH620-CH1000, CV17-CV26, CV620-CV1000

Aegis LH630-LH775
HDAC Primary Air Filter HDAC Safety Filter

Part No.: 25 083 01-S Part No.: 25 083 04-S
Command PRO CV460-CV493

Triad OHC TH16, TH18, TH520, TH575
HDAC Primary Air Filter HDAC Safety Filter

Part No.: 25 083 02-S Part No.: 25 083 03-S
6
AIR FILTERS

Part No.: 28 083 03-S Part No.: 28 083 02-S
Courage SV710-SV740

Part No.: 32 083 03-S Part No.: 32 083 05-S
Courage PRO SV810-SV840

Part No.: 32 083 06-S Part No.: 32 083 08-S
7
AIR FILTERS
Command CV17-CV26, CV620-CV745
Magnum M10-M20, MV16-MV20
K-Series K341, KT17, KT19

Part No.: 45 083 02-S Part No.: 45 083 01-S
Command CH11-CH16, CH410-CH450

Magnum M18-M20
K-Series KT17, KT19

Part No.: 47 083 01-S Part No.: 52 083 01-S
Command CH18-CH25, CH620-CH740, CV17-CV23, CV620-CV670

Part No.: 47 083 03-S Part No.: 24 083 05-S
8
AIR FILTERS
Command PRO CS8.5 (300cc), CS10, CS12 (500 Series)

Part No.: 63 083 01-S Part No.: 63 083 02-S
Command PRO CS4, CS6

Part No.: 63 083 03-S Part No.: 63 083 04-S
HD Cyclonic Air Filter Cyclonic Precleaner

Part No.: 63 083 07-S Part No.: 63 083 08-S
Air Filter Dimensions 3.6” O.D. x 3” H
9
AIR FILTERS
Command PRO CS8.5-CS12
HD Cyclonic Air Filter Cyclonic Precleaner

Part No.: 63 083 10-S Part No.: 63 083 09-S
Command PRO CS8.5 (250cc)

Part No.: 63 083 11-S Part No.: 63 083 12-S
Command PRO CS10-CS12.75

Part No.: 63 083 15-S Part No.: 63 083 16-S
10
AIR FILTERS
Aegis LV625-LV680

Part No.: 66 083 01-S Part No.: 66 083 03-S
Air Filter Dimensions 8.5”O.D. x 4”H
11
AIR FILTER KITS
Command CV11-CV16 Command PRO CV11-CV16, CV430-CV493
Air Filter/Precleaner Air Filter/Precleaner

Part No.: 12 883 05-S1 Part No.: 12 883 10-S1
Contains Air Filter 12 083 05-S (page 4) Contains Air Filter 12 083 10-S (page 4)
Courage XT-7 Courage SV470-SV620
Air Filter Air Filter/Precleaner

Part No.: 14 083 01-S1 Part No.: 20 883 02-S1
Contain Air Filter 14 083 01-S (page 5) Contains Air Filter 20 083 02-S (page 5)
12
AIR FILTER KITS
Command PRO CH18-CH26, CH620-CH750 K-Series K241-K321
CV18-CV25, CV620-CV740 Magnum M8

Part No.: 24 883 03-S1 Part No.: 25 883 03-S1
Contains Air Filter 24 083 03-S (page 6) Contains Air Filter 235116-S (page 3)
Courage SV710-SV740 Courage PRO SV810-SV840

Part No.: 32 883 03-S1 Part No.: 32 883 06-S1
13
AIR FILTER KITS
Command CV17-CV26, CV620-CV745 Command CH11-CH16, CH410-CH450

Magnum M10-M20, MV16-MV20 Magnum M18-M20
K-Series K341, KT17, KT19 K-Series KT17, KT19

Part No.: 45 883 02-S1 Part No.: 47 883 01-S1
Command CH18-CH25, CH620-CH740, CV17-

CV23, CV620-CV670
Air Filter/Precleaner
Part No.: 47 883 03-S1
Contains Air Filter 47 083 03-S (page 8)
14
FUEL FILTERS
Command EFI CH26, CH735, CH745, CV26, Command PRO CH18-CH25, CH620-CH740,
CV735, CV745 CH750, CH940-CH1000, CV17-CV25, CV670-CV740,
Aegis EFI LH775 CV750, CV940-CV1000
Courage SV710-SV740, SV810-SV840
Aegis LH630-LH755, LV625-LV680
Fuel Filter
8-10 microns
Part No.: 24 050 03-S
Command CV11-CV16
K-Series K181-K341, KT17, KT19
Magnum M8-M20 Extra Capacity Fuel Filter
9-12 microns
Part No.: 24 050 13-S
Command CH11-CH16, CH18-CH25, CH410-

CH450, CH620-CH730, CV13-CV16, CV430-CV493,
CV17-CV25, CV670-CV730
Courage SV470-SV740
Fuel Filter
75 microns
Part No.: 25 050 07-S
Command CH11-CH16, CH410-CH450, CV13-

CV16, CV430-CV493
Courage SV470-SV620
Fuel Filter (Fuel Pump Fed Carburetors)

51 microns
Part No.: 25 050 22-S
Fuel Filter (Gravity Fed Carburetors)

75 microns
Part No.: 25 050 21-S
15
OIL FILTERS
Fits all models Fits most models
Standard Oil Filter Extra Capacity Oil Filter

Part No.: 12 050 01-S Part No.: 52 050 02-S
Dimensions 3” W x 2.6” L Dimensions 3” W x 3.4” L
Also available in retail version 12 050 01-S1 Also available in retail version 52 050 02-S1
All Courage PRO models K-Series K532-K582
Extra Capacity Oil Filter Oil Filter

Part No.: 25 050 34-S Part No.: 277233-S
Dimensions 3” W x 3.4” L Dimensions 3” W x 5.1” L
16
OIL
K-Series Command
Magnum Courage
Aegis
30W Oil (32 oz.) 10W-30 Oil (32 oz.)

Part No.: 25 357 03-S Part No.: 25 357 06-S
17
FUEL PUMPS
Command CH6 Command CH18-CH25, CH620-CH730, CH740,
CH750-CH1000, CV17-CV25, CV620-CV730, CV740,
CV750-CV1000
All Courage SV470-SV840
Aegis LV625-LV680
Pulse Fuel Pump

Part No.: 15 393 01-S
Command EFI CH26, CH735, CH745, CV26,

CV735, CV745 Pulse Fuel Pump
Aegis EFI LH775 Part No.: 24 393 16-S
Command CH18-CH25, CH620-CH730, CH740,

CH750
Electric Fuel Pump

Part No.: 24 393 20-S
Command CH11-CH16, CH410-CH450,

CV11-CV16, CV430-CV493
Mechanical Fuel Pump

Part No.: 24 559 10-S

Part No.: 12 559 02-S
18
FUEL PUMPS
Triad OHC TH16, TH18, TH520, TH575 K-Series K161, K181
Magnum M8
Mechanical Fuel Pump Mechanical Fuel Pump

Part No.: 28 559 06-S Part No.: 41 559 05-S
K-Series K241-K361 K-Series K241-K361

Magnum M10-M16 Magnum M10-M16

Part No.: 47 559 10-S Part No.: 47 559 11-S
K-Series K532, K582 K-Series K532, K582

Part No.: 48 559 05-S Part No.: 48 559 06-S
19
FUEL PUMPS
K-Series KT17, KT19 Command PRO CH940-CH1000

Part No.: 52 559 03-S Part No.: 62 559 01-S
Aegis LH630-LH755

Part No.: 66 559 02-S
20
CARBURETOR KITS
Command CH11-CH15, CV11-CV16
Carburetor Repair Kit Float Repair Kit Solenoid Repair Kit

Part No.: 12 757 01-S Part No.: 12 757 02-S Part No.: 12 757 33-S
(Walbro Carburetor)
Command CH11-CH16, CH410-CH450, CV11-CV16, CV430-CV450

Courage SV470-SV620

(Walbro Carburetor)
Command CH15, CV15
Float included in the carburetor

repair kit
Carburetor Repair Kit Solenoid Repair Kit

Part No.: 12 757 27-S Part No.: 12 757 28-S
(Nikki Carburetor)
21
CARBURETOR KITS
Command CH5
Solenoid Kit
Not Applicable
Carburetor Repair Kit Float Repair Kit

Part No.: 15 757 02-S Part No.: 12 757 02-S
(Walbro Carburetor)
Command CH5, CH6
Solenoid Kit
Not Applicable

Part No.: 15 757 07-S Part No.: 15 757 03-S
(Keihin Carburetor)
Command CH18-CH25, CH620-CH740

Aegis LH630-LH755

(Keihin Carburetor)
22
CARBURETOR KITS
Command CV17-CV22 (624cc), CV25, CV620-CV670, CV724-CV740

repair kit

Part No.: 24 757 18-S Part No.: 24 757 22-S
(Nikki Carburetor)
Aegis LV625-LV680

repair kit

Part No.: 24 757 18-S Part No.: 66 757 01-S
(Nikki Carburetor)
Command CV22 (674cc), CV23, CV675-CV680


(Keihin Carburetor)
23
CARBURETOR KITS
Command PRO CH750, CH940-CH1000, CV750, CV940-CV1000

(Keihin Carburetor)
K-Series K91-K321
Magnum M8-M14
Solenoid Kit
Not Applicable

Part No.: 25 757 01-S Part No.: 25 757 03-S
(Kohler Carburetor)

Magnum M14-M20

(Kohler Carburetor)
24
CARBURETOR KITS

(Walbro Carburetor)

(Nikki Carburetor)
Command PRO CS8.5 (300cc), CS10, CS12 (500 series)
Solenoid Kit
Not Applicable

Part No.: 63 757 01-S Part No.: 63 757 02-S
(Mikuni Carburetor)
25
CARBURETOR KITS
Solenoid Kit
Not Applicable

Part No.: 63 757 04-S Part No.: 63 757 05-S
(Mikuni Carburetor)
Command PRO CS8.5 (250cc), CS10-CS12.75 (600 series)
Solenoid Kit
Not Applicable

Part No.: 63 757 10-S Part No.: 63 757 08-S
(Mikuni Carburetor)
26
IGNITION
Spark Plugs
All Command K-Series K241-K361, K532- All Command PRO (excluding

All Courage K582 CH/CV940-1000, CS4-CS12.75,
Triad OHC Magnum M10-M16 Aegis LH630-LH775, LV625-LV680)
All Courage PRO
Spark Plug Spark Plug High-Performance Spark Plug

Magnum M8 K-Series K91-K181 K-Series KT17, KT19

Spark Plug Spark Plug Spark Plug

Command PRO CH940- Command PRO CS4-CS12.75 Courage XT-6, XT-7

CH1000, CV940-CV1000 Aegis LH630-LH775, LV625-
LV680
Spark Plug Spark Plug Spark Plug

27
IGNITION
Breaker Ignition
K-Series K91 K-Series K161-K341
Ignition Coil (Magneto) Ignition Coil (Magneto)

Part No.: 220435-S Part No.: 47 755 20-S
Ignition Coil (Battery) Ignition Coil (Battery)

Part No.: 41 519 21-S Part No.: 277375-S
K-Series KT17, KT19 K-Series Single Cylinder Models with

Magneto Ignition Only
Ignition Coil (Battery) Electronic Ignition Kit (Conversion)

Part No.: 52 755 48-S Part No.: 25 757 10-S
28
IGNITION
Breaker Ignition
K-Series K91 K-Series K161-K341
Condenser Condenser (Magneto Ignition)

Part No.: 220434-S Part No.: 47 147 01-S
K-Series K91-K361 K-Series KT17, KT19
Condenser (Battery Ignition) Condenser

Part No.: 230722-S Part No.: 52 755 13-S
K-Series K91-K361, KT17, KT19 K-Series K532, K582
Breaker Points Breaker Points (Socket-Head Capscrew Adjuster)

Part No.: 47 150 03-S Part No.: 48 150 03-S
29
IGNITION
Electronic Ignition Modules
Command CH11-CH15, CH410-CH450, CV11- Command CH11-CH15, CH410-CH450, CV11-

CV15, CV430-CV493 CV15, CV430-CV493
Ignition Module (Electric Start Models) Ignition Module (Retractable Start Models)
Part No.: 12 584 04-S Part No.: 12 584 05-S
Command CH16, CV16 Command CH16, CV16
Speed Advance Module Ignition Module

Part No.: 12 584 12-S Part No.: 12 584 17-S
Courage XT-7 Courage XT-7
Ignition Module (Used with Cast Iron Flywheel) Ignition Module (Used with Aluminum Flywheel)
Part No.: 14 584 04-S Part No.: 14 584 05-S
30
IGNITION
Command CH5 Command PRO CH6
Ignition Module Ignition Module

Part No.: 15 584 01-S Part No.: 15 584 07-S
Courage SV470-SV620 Command EFI CH26, CH735, CH745, CV26,

CV735, CV745
Aegis LH775
Ignition Module Ignition Coil

Part No.: 20 584 03-S Part No.: 24 519 02-S
Command CH22 (624cc), CH25, CH740, CH750,

CV22 (624cc), CV25, CV740, CV750
Courage SV735, SV740
Ignition Module
Part No.: 24 584 36-S
31
IGNITION
Command CH22 (624cc), CH25, CV22 (624cc), Command CH18, CH20, CH22 (674cc), CH23,
CV25 CH620-CH730, CV17-CV20, CV22 (674cc), CV23,
CV620-CV730
Speed Advance Module Ignition Module

(Power & Ground Spade Terminal Leads) Part No.: 24 584 45-S
Part No.: 24 584 09-S
Speed Advance Module Speed Advance Module

(Power & Ground Bullet Connector Leads) (Power & Ground Spade Terminal Leads)
Part No.: 24 584 38-S Part No.: 24 584 39-S

Courage SV735, SV740, SV840
Spark Advance Ignition Module (DSAI) Spark Advance Ignition Module (DSAI)
Part No.: 24 584 52-S Part No.: 24 584 53-S
32
IGNITION
Command PRO CH940-CH980, CV940-CV980 Command PRO CV1000
Ignition Module Spark Advance Ignition Module (DSAI)

Part No.: 62 584 04-S Part No.: 62 584 11-S
Command PRO CH1000 Command PRO CS8.5 (300cc), CS10,

CS12 (500 series)
Spark Advance Ignition Module (DSAI) Ignition Module

Part No.: 62 584 07-S Part No.: 63 755 02-S
Command PRO CS4, CS6 (9015xx and Command PRO CS4, CS6 (9615xx and
9115xx specs) 9715xx specs)

Part No.: 63 755 06-S Part No.: 63 755 40-S
33
IGNITION
Command PRO CS8.5 (250cc) Command PRO CS10-CS12.75 (600 series)

Part No.: 63 755 12-S Part No.: 63 755 19-S
Magnum M8 Magnum M10-M16

Part No.: 41 584 03-S Part No.: 47 584 03-S
Magnum M18-M20, MV16-MV20 Aegis LV625-LV680

Part No.: 52 584 02-S Part No.: 66 584 04-S
34
IGNITION
Aegis LH630-LH755 Aegis LH630-LH755

Triad OHC TH16, TH18, TH520, TH575 Triad OHC TH16, TH18, TH520, TH575
Ignition Module (#1 cylinder) Ignition Module (#2 cylinder)

Part No.: 66 584 09-S Part No.: 66 584 10-S
35
MAINTENANCE KITS
Command CV11-CV16 Command PRO CV11-CV16, CV430-CV493
Maintenance Kit Maintenance Kit

Part No.: 12 789 01-S Part No.: 12 789 02-S
Courage SV470-SV620 Command CH18-CH25, CH620-CH740, CV17-

CV23, CV670

Part No.: 20 789 01-S Part No.: 24 789 01-S
36
MAINTENANCE KITS
Command PRO CH18-CH25, CH620-CH740, Command CV17-CV25, CV730-CV740
CH750, CV18-CV25, CV670-CV740
Maintenance Kit
Maintenance Kit Part No.: 24 789 03-S
Part No.: 24 789 02-S Wide Area Walk Behind Engines
Command CH18-CH25, CH620-CH740, CH750, Courage SV710-SV740

CV18-CV25, CV670-CV740, CV750

Part No.: 25 789 01-S Part No.: 32 789 01-S
Heavy Duty Air Cleaner Equipped Engines
37
ELECTRIC STARTERS
Command CH11-CH15, CH410-CH450 Command CV11-CV15, CV430-CV493
Electric Starter - Bendix Drive Electric Starter - Bendix Drive

13 Tooth 13 Tooth
Part No.: 12 098 21-S Part No.: 12 098 22-S
Courage SV470-SV620 Command CH18-CH23, CH620-CH640, CV18-

CV23

14 Tooth 10 Tooth
Part No.: 20 098 05-S Part No.: 25 098 07-S
Command CH13-CH26, CH410-CH1000, CV16- Triad OHC TH16, TH18, TH520, TH575
CV26, CV460-CV1000
Aegis LH630-LH775, LV625-LV680
Electric Starter - Solenoid Shift Electric Starter - Bendix Drive

10 Tooth 10 Tooth
Part No.: 25 098 09-S Part No.: 28 755 30-S
38
ELECTRIC STARTERS
Courage SV710-SV740, SV810-SV840 Magnum M8-M16

10 Tooth 10 Tooth
Part No.: 32 098 01-S Part No.: 41 098 06-S

16 Tooth 10 Tooth-High Mount Style
Part No.: 41 098 08-S Part No.: 45 098 09-S
K-Series K241-K361 K-Series K532, K582

10 Tooth-Low Mount Style 9 Tooth
Part No.: 45 098 10-S Part No.: 48 098 04-S
39
ELECTRIC STARTERS
K-Series KT17, KT19 Magnum MV20

9 Tooth 9 Tooth
Part No.: 52 098 12-S Part No.: 52 098 13-S
Command PRO CS8.5 (300cc), Command PRO CS6

CS10-CS12 (500 series)

9 Tooth 9 Tooth
Part No.: 63 098 01-S Part No.: 63 098 02-S
Command PRO CS8.5 (250cc),

CS10-CS12.75 (600 series)
Electric Starter - Solenoid Shift

9 Tooth
Part No.: 63 098 04-S
40

Kohler Quick Reference Guide

Uploaded by

Document Information

Original Description:

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Kohler Quick Reference Guide

Uploaded by

Copyright:

Available Formats

Call 888-652-3990 Online at OPEengines.

FAST MOVING PARTS

Section Page Number

Retail Packaged Air Filter Kits.......................................................................................12

Fuel Filters ......................................................................................................................15

Fuel Pumps ....................................................................................................................18

Air Filter Precleaner

Air Filter Precleaner

Air Filter Precleaner

Air Filter Precleaner

Air Filter Precleaner

Command PRO CV11-CV16, CV430-CV493

Air Filter Precleaner

Air Filter Precleaner

Command PRO CH6

Air Filter Precleaner

Air Filter Precleaner

Air Filter Precleaner

Command PRO CH18-CH26, CH620-CH1000, CV17-CV26, CV620-CV1000

HDAC Primary Air Filter HDAC Safety Filter

Command PRO CV460-CV493

HDAC Primary Air Filter HDAC Safety Filter

Air Filter Precleaner

Air Filter Precleaner

Courage PRO SV810-SV840

Air Filter Precleaner

Air Filter Precleaner

Command CH11-CH16, CH410-CH450

Air Filter Precleaner

Command CH18-CH25, CH620-CH740, CV17-CV23, CV620-CV670

Air Filter Precleaner

Air Filter Precleaner

Command PRO CS4, CS6

Air Filter Precleaner

Command PRO CS4, CS6

HD Cyclonic Air Filter Cyclonic Precleaner

HD Cyclonic Air Filter Cyclonic Precleaner

Command PRO CS8.5 (250cc)

Air Filter Precleaner

Command PRO CS10-CS12.75

Air Filter Precleaner

Air Filter Precleaner

Air Filter/Precleaner Air Filter/Precleaner

Courage XT-7 Courage SV470-SV620

Air Filter Air Filter/Precleaner

Air Filter/Precleaner Air Filter/Precleaner

Courage SV710-SV740 Courage PRO SV810-SV840

Air Filter/Precleaner Air Filter/Precleaner

Command CV17-CV26, CV620-CV745 Command CH11-CH16, CH410-CH450

Air Filter/Precleaner Air Filter/Precleaner

Command CH18-CH25, CH620-CH740, CV17-

Command CH11-CH16, CH18-CH25, CH410-

Command CH11-CH16, CH410-CH450, CV13-

Fuel Filter (Fuel Pump Fed Carburetors)

Fuel Filter (Gravity Fed Carburetors)

Fits all models Fits most models

Standard Oil Filter Extra Capacity Oil Filter

All Courage PRO models K-Series K532-K582

Extra Capacity Oil Filter Oil Filter

30W Oil (32 oz.) 10W-30 Oil (32 oz.)

Pulse Fuel Pump

Command EFI CH26, CH735, CH745, CV26,
