TECHNICAL SPECIFICATIONS

BLUE
PAPERS
OCCAM
TECHNICAL MANUAL

TECHNICAL SPECIFICATIONS

CONTENT

GEOMETRY AND SPECIFICATIONS

FRAME MATERIAL AND CARE
PARTS AND HARDWARE
TORQUE SPECIFICATIONS
SUSPENSION SETUP
ORBEA WARRANTY
ADDITIONAL INFORMATION

3
5
6
20
21
22
23

TECHNICAL SPECIFICATIONS

GEOMETRY AND
SPECIFICATIONS

SIZE (mm)

XS

Crank

170

170

175

175

Stem

70

90

90

120

Handlebar

710

710

710

710

SIZES (mm)

XS

1.

Seat tube

394

432

470

520

150-165

XS

2.

Top tube (EFF)

556

585

612

639

160-175

3.

Head tube

110

120

130

145

170-185

4.

Chain stay

420

180-198

5.

BB height

323/354 (26x2.2)

6.

BB offset

12

7.

Wheelbase

8.

Head angle

68.5/67.5

9.

Seat angle

74.5/73.5

10.

Standover

769

11.

Reach

12.

Stack

13.

Fork length

1078

1108

1136

1165

775

781

787

401

428

452

475

559

568

577

591

493/511mm (120mm/140mm travel)

*Altura orientativa y que puede variar segn morfologia del usuario y preferencias geometricas y de uso.

HEIGHT (cm)

SIZES

TECHNICAL SPECIFICATIONS

GEOMETRY AND
SPECIFICATIONS

SIZE (mm)

Crank

170

175

175

Stem

60 (turbine 50)

70

90

670

670

670

Handlebar

SIZES (mm)

1.

Seat tube

420 mm

470 mm

520 mm

160-175

2.

Top tube (EFF)

577 mm

612 mm

639 mm

170-185

3.

Head tube

110 mm

120 mm

135 mm

180-198

4.

Chain stay

5.

BB height

6.

BB offset

7.

Wheelbase

8.

Head angle

70/69

9.

Seat angle

74/73

10.

Standover

720 mm

755 mm

780 mm

11.

Reach

402 mm

435 mm

458 mm

12.

Stack

608 mm

618 mm

632 mm

13.

Fork length

445 mm
327 mm (29x2.2tire)

327 mm (29x2.2tire)

327 mm (29x2.2tire)

44 mm
1098 mm

1133 mm

1161 mm

501 mm/521 mm

*Altura orientativa y que puede variar segn morfologia del usuario y preferencias geometricas y de uso.

HEIGHT (cm)

SIZES

TECHNICAL SPECIFICATIONS

FRAME AND MATERIAL

Orbea frames are carefully designed to be durable,
efficient, and easy to maintain. Occam tubes are stiff
and light, giving excellent steering precision and pedaling efficiency. Occam carbon frame is extremely
resistant to corrosion, making it perfect for riding off
road. With only a minimum amount of maintenance,
its easy to keep your Oiz in top condition.

1) Keep your mountain bike clean

Washing your bike with mild soap and water will keep
you looking stylish and allow you to check the condition of the frame and components. Donts use high
water pressure and avoid spraying water into bearings
or frame tubes. Citrus degreasers are biodegradeable and do a great job of removing dirty grease from
gears and chain.

2) Keep your mountain bike lubed

Once your bike is clean, its a good time to put fresh
lube on the chain. Use only enough to get inside the
links and wipe off any excess because it will attract
dirt. Headset and pivot bearings should be inspected
every few months for smoothness and to ensure that
the seals are intact and lube is clean.

3) Inspect your mountain bike before you ride

Do a quick check before every ride to make sure your
bike is in excellent condition. It is very common to discover small issues at home that can become big problems on the trail. CHAIN Is the chain dirty, noisy or
dry? Clean and lube your chain before riding. BRAKES
Check your brakes to make sure they are working
correctly. Check for missing/loose caliper and rotor
bolts. TIRES Look for damage to the sidewalls of your

tires. Check and adjust tire pressure. WHEELS Spin

the wheels and look for wobbles, check for loose or
broken spokes. Check quick release levers to make
sure they are functioning properly. FRONT END Stand
over the saddle, pull on the brakes and rock the bike
back and forth. Feel for any play or knocking that might indicate a loose headset, loose brake rotors or calipers, or worn fork bushings. TEST RIDE Take a quick
ride up and down the street to make sure your bike
is shifting and braking properly. Listen for unusual
noises.

AFTER A CRASH OR IMPACT

Falling is part of mountain biking and its impossible
to avoid minor accidents. If you crash your Occam,
please make sure you are okay and seek medical attention if necessary. If you are not injured, you should
check your bike before continuing:
1) Inspect your frame and components for damage. Do not ride your bike if any problems are detected.

WHAT TO LOOK FOR

Inspect Frame and fork for evidence of cracking or
bending. If cracks are discovered, discontinue use
immediately.
Check the drivetrain and spin the wheels to make sure
components are operating correctly. If you discover
damage to your components, discontinue use immediately.
Even if you dont find any damage, pay careful attention to the sound of your bike when you continue
riding. Unusual noises can be caused by cracks or
other problems. A well-maintained bike will be quiet
and free of creaks or squeaks. Investigate and locate
the source of any new noises.
2) Bring your bike to your Orbea dealer for professional inspection. Some damage can only be detected by disassembling the bike to check for cracks
or other signs of stress.
A crash or impact can put extraordinary stress
on your bike and components, causing them
to fail or to fatigue prematurely. Failure can
happen suddenly with no warning, causing loss
of control, serious injury or death.

TECHNICAL SPECIFICATIONS

PARTS & HARDWARE

Name/Description

Number

1. EJE DE 12MM

Cod: (Dorado): 154300D3 / (Rojo): 154300D4

*RODAMIENTOS: EXT.= 26MM / INT.= 17MM / E= 5MM

/ REF. 154300D4
KIT PUNTERAS EJE X12 ROJO MODELOS OCCAM.

/ REF. 154300D3
KIT PUNTERAS EJE X12 NARANJA MODELOS
OCCAM.

Kit de punteras compatible con las bicicletas:

- Occam de aluminio de ruedas 26 y 29 del ao
2012, 2013 y 2014
- Occam de carbono de ruedas de 26 del ao 2012,
2013 y 2014

Kit de punteras compatible con las bicicletas:

- Occam de aluminio de ruedas 26 y 29 del ao
2013 y 2014
- Occam de carbono de ruedas de 26 del ao 2012,
2013 y 2014

TECHNICAL SPECIFICATIONS

Name/Description

Number

2. EJE DE 12MM

Cod: (Dorado): 14140034

/ REF. 14140034
KIT DE PATAS RECAMBIABLES STANDARD 9 MM
MODELOS OCCAM.
Kit de patas recambiables compatible con las
bicicletas:
- Occam de aluminio de ruedas 26 y 29
del ao 2013
- Occam de carbono de ruedas de 26 del ao 2013

TECHNICAL SPECIFICATIONS

Name/Description

Number

3. CIERRE TRASERO OCCAM OCP 9MM

Cod: 11103382 (Dorado) / 11103381 (Rojo)

*RODAMIENTOS: EXT.= 28MM / INT.= 15MM / E= 7MM

/ REF. 11103381
CIERRE TRASERO ROJO ROJO MODELOS OCCAM

/ REF. 11103382
CIERRE TRASERO NARANJA MODELOS OCCAM.

Cierre trasero compatible con las bicicletas:

Occam de carbono y aluminio de rueda de 26 y 29
de los aos 2012, 2013 y 2014

Cierre trasero compatible con las bicicletas:

Occam de carbono y aluminio de rueda de 26 y 29
de los aos 2012, 2013 y 2014

TECHNICAL SPECIFICATIONS

Name/Description

Number

4. MAIN PIVOT EJE DE GIRO PRINCIPAL

Cod: (Dorado): 14140041 / (Rojo): 14140042

/ REF. 14140041
KIT PUNTO DE GIRO ENTRE BASE Y TRIANGULO
DELANTERO NARANJA MODELOS OCCAM.

/ REF. 14140042
KIT PUNTO DE GIRO ENTRE BASE Y TRIANGULO
DELANTERO ROJO MODELOS OCCAM.

Kit de punto de giro entre base y tringulo delantero

compatible con las bicicletas:
- Occam de aluminio de ruedas 26 y 29 del ao
2012, 2013 y 2014
- Occam de carbono de ruedas de 26 del ao 2012,
2013 y 2014

Kit de punto de giro entre base y tringulo delantero

compatible con las bicicletas:
- Occam de aluminio de ruedas 26 y 29 del ao
2012, 2013 y 2014
- Occam de carbono de ruedas de 26 del ao 2012,
2013 y 2014

10

TECHNICAL SPECIFICATIONS

Name/Description

Number

KIT PUNTO DE GIRO ENTRE TIRANTE Y BIELETA

Cod: (Dorado): 14140036 / (Rojo): 14140037

Name/Description

Number

TORNILLO DE TIRANTE ALUMINIO

Cod: (Dorado): 12301546 / (Rojo): 12301545

*RODAMIENTOS: EXT.= 24MM / INT.= 15MM / E= 5MM

/ REF. 14140036
KIT PUNTO DE GIRO ENTRE TIRANTE Y BIELETA
NARANJA MODELOS OCCAM.

/ REF. 14140037
KIT PUNTO DE GIRO ENTRE TIRANTE Y BIELETA
ROJO MODELOS OCCAM.

Kit de punto de giro entre tirante y bieleta compatible

con las bicicletas:
- Occam de aluminio de ruedas 26 y 29 del ao
2012, 2013 y 2014
- Occam de carbono de ruedas de 26 del ao 2012,
2013 y 2014

Kit de punto de giro entre tirante y bieleta compatible

con las bicicletas:
- Occam de aluminio de ruedas 26 y 29 del ao
2012, 2013 y 2014
- Occam de carbono de ruedas de 26 del ao 2012,
2013 y 2014

/ REF. 12301545
TORNILLO DE TIRANTE ALUMINIO ROJO
MODELOS OCCAM SILVER.

/ REF. 12301546
TORNILLO DE TIRANTE ALUMINIO NARANJA
MODELOS OCCAM SILVER.

Tornillo de tirante compatible con las bicicletas:

- Occam de aluminio de rueda de 29 de los aos
2013 y 2014
- Occam de carbono de rueda de 29 de los aos
2013
- Occam de carbono y aluminio de rueda de 26 de los
aos 2012, 2013 y 2014

Tornillo de tirante compatible con las bicicletas:

- Occam de aluminio de rueda de 29 de los aos
2013 y 2014
- Occam de carbono de rueda de 29 de los aos
2013
- Occam de carbono y aluminio de rueda de 26 de los
aos 2012, 2013 y 2014

11

TECHNICAL SPECIFICATIONS

Name/Description

Number

KIT PUNTO DE GIRO ENTRE BIELETA Y TRIANGULO DELANTERO

Cod: 14140040

/ REF. 14140040
KIT PUNTO DE GIRO ENTRE BIELETA Y
TRIANGULO DELANTERO MODELOS OCCAM.
Kit de punto de giro entre bieleta y tringulo delantero
compatible con las bicicletas:
- Occam de aluminio de ruedas 26 y 29 del ao
2012, 2013 y 2014
- Occam de carbono de ruedas de 26 del ao 2012,
2013 y 2014

*RODAMIENTOS: EXT.= 19MM / INT.= 10MM / E= 5MM

12

TECHNICAL SPECIFICATIONS

Name/Description

Number

KIT PUNTO DE GIRO ENTRE AMORTIGUADOR Y TRIANGULO

DELANTERO

Cod: (Dorado): 14140038 / (Rojo): 14140039

/ REF. 14140038
KIT PUNTO DE GIRO ENTRE AMORTIGUADOR Y
TRIANGULO DELANTERO NARANJA MODELOS
OCCAM.

/ REF. 14140039
KIT PUNTO DE GIRO ENTRE AMORTIGUADOR Y
TRIANGULO DELANTERO ROJO MODELOS
OCCAM.

Kit de punto de giro entre amortiguador y tringulo

delantero compatible con las bicicletas:
- Occam de aluminio de ruedas 26 y 29 del ao
2012, 2013 y 2014
- Occam de carbono de ruedas de 26 del ao 2012,
2013 y 2014

Kit de punto de giro entre amortiguador y tringulo

delantero compatible con las bicicletas:
- Occam de aluminio de ruedas 26 y 29 del ao
2012, 2013 y 2014
- Occam de carbono de ruedas de 26 del ao 2012,
2013 y 2014

13

TECHNICAL SPECIFICATIONS

Name/Description

Number

PROTECTOR DE BASE PLSTICO

Cod: 11000356

/ REF. 11000356
PROTECTOR DE BASE PLASTICO MODELOS OCCAM SILVER Y OCCAM HYDRO.
Protector de base compatible con las bicicletas:
- Occam de aluminio y carbono de ruedas de 26 y
de 29 del ao 2012, 2013 y 2014

14

TECHNICAL SPECIFICATIONS

Name/Description

Number

*Solo para modelos 26

Cod: 11000355

15

TECHNICAL SPECIFICATIONS

Name/Description

Number

PROTECTOR TUBO DIAGONAL GOMA

Cod: 11000357

/ REF. 11000357
PROTECTOR TUBO DIAGONAL GOMA MODELOS
OCCAM SILVER.
Protector de tubo diagonal compatible con las
bicicletas:
- Occam de carbono de ruedas de 26 y 29 del ao
2012, 2013 y 2014

16

TECHNICAL SPECIFICATIONS

Name/Description

Number

OCCAM TOP TUBE CABLE GUIDE

Cod: 11001174

/ REF. 11207551
OCCAM TOP TUBE CABLE GUIDE - ORANGE.
Tope inferior del tubo horizontal compatible con las
bicicletas:
- Occam de aluminio de rueda de 29 de los aos
2013 y 2014
- Occam de aluminio y carbono de rueda de 26 de los
aos 2012, 2013 y 2014
- El precio mostrado es por unidad, para un cuadro se
requieren 2 unidades.

/ REF. 11207552
TOPE INFERIOR DEL TUBO HORIZONAL ROJO MODELOS OCCAM.
Tope inferior del tubo horizontal compatible con las
bicicletas:
- Occam de aluminio de rueda de 29 de los aos
2013 y 2014
- Occam de aluminio y carbono de rueda de 26 de los
aos 2012, 2013 y 2014
- El precio mostrado es por unidad, para un cuadro se
requieren 2 unidades.

17

TECHNICAL SPECIFICATIONS

Name/Description

Number

TOPE SUPERIOR DEL TUBO DIAGONAL

Cod: (Dorado): 11207553 / (Rojo): 11207554

/ REF. 11207553
TOPE SUPERIOR DEL TUBO DIAGONAL NARANJA
MODELOS OCCAM.

/ REF. 11207554
TOPE SUPERIOR DEL TUBO DIAGONAL ROJO MODELOS OCCAM.

Tope superior del tubo diagonal compatible con las

bicicletas:
- Occam de aluminio de rueda de 29 de los aos
2013 y 2014
- Occam de aluminio y carbono de rueda de 26 de los
aos 2012, 2013 y 2014
- El precio mostrado es por unidad, para un cuadro se
requieren 3 unidades.

Tope superior del tubo diagonal compatible con las

bicicletas:
- Occam de aluminio de rueda de 29 de los aos
2013 y 2014
- Occam de aluminio y carbono de rueda de 26 de los
aos 2012, 2013 y 2014
- El precio mostrado es por unidad, para un cuadro se
requieren 3 unidades.

18

TECHNICAL SPECIFICATIONS

Name/Description

Number

BIELETA CARBON

Cod: (Azul): 520909D3 / (Rojo): 520904D4

Name/Description

Number

BIELETA ALUMINIO

Cod: (Dorado): 532901D2 / (Rojo): 532901D1

19

TECHNICAL SPECIFICATIONS

Name/Description

Number

ABRAZADERA

Cod: (Plata): 11160825 / (Rojo): 11160817

/ REF. 11160817
ABRAZADERA DE SILLIN 349 ALUMINIO NEGRO
ROJO MODELOS RALLON Y OCCAM.

/ REF. 11160825
ABRAZADERA DE SILLIN 349 ALUMINIO NEGRO
PLATA MODELOS RALLON Y OCCAM.

Abrazadera compatible con las bicicletas:

- Occam de Carbono y aluminio, modelos de rueda
26 y 29, de los aos 2012, 2013 y 2014
- Rallon de los aos 2011, 2012 y 3 2014

Abrazadera compatible con las bicicletas:

- Occam de Carbono y aluminio, modelos de rueda
26 y 29, de los aos 2012, 2013
- Rallon 2014

20

TECHNICAL SPECIFICATIONS

TORQUE SPECS

OCCAM TORQUE SPECIFICATIONS

Required tools

Torque

6 mm hex x 5 mm hex

12 Nm

3 mm hex

2 Nm

5 mm hex

8 Nm

4 mm hex x 10 mm wrench

5 Nm

6 mm hex

15 Nm

22 mm wrench

15 Nm

3
1

Fastener

5
6

CHECKING AND ADJUSTING TORQUE

Bolt tightening torques should be checked frequently,
specially if any kind of malfunctioning, noise, play or
vibration is detected in the bike.

21

TECHNICAL SPECIFICATIONS

-Occam 26 (Shock dimensions

7,875 x 2 // 200 x 51 mm)

-Occam 29 (Shock dimensions:

7,25 x 1,75 // 184 x 44 mm)
Feel for any play or knocking that might indicate a loose headset, loose brake rotors or calipers, or worn fork bushings.
TEST RIDE Take a quick ride up and down the street.

SHOCK PRESSURE CHART

m(kg)

P(psi)

Rebound clicks (counting from completely open)

60

120

65

130

70

140

75

150

80

160

85

170

10

90

180

11

95

190

12

100

200

13

22

TECHNICAL SPECIFICATIONS

ORBEA WARRANTY
HOW DO I ACTIVATE MY
LIFETIME WARRANTY?
Orbea provides a lifetime warranty on all its frames.
Only a brand that knows the materials, masters the
technologies and has the skills can guarantee that
your frame is totally invincible. Only Orbea takes you
a step beyond.
Orbeas lifetime warranty is activated using the registration number you will find on all frames from the
2009 range onwards. When you have activated it at
your dealer or at www.orbea.com, your bike will automatically receive its lifetime warranty. The registration
number is a unique, non-transferable code that you
will find on the underside of your bikes downtube.
Activate your frames warranty using this number at
your dealers or at www.orbea.com.

WHAT ARE THE ADVANTAGES?

Lifetime guarantee of your frame against breakage.
Two-year guarantee on all components.
Identification of your bicycle and all its characteristics
to our Technical Assistance Service so that wecan provide our best response to any problems. Access to
special offers, events and prize drawings.

ORBEA WARRANTY
The ongoing efforts we make at Orbea to design highend bicycles enable us to provide customerswith the
following warranty:
1) We back each frame and rigid fork in our bicycles
with a lifetime warranty against materials and manufacturing defects. Frames with travel longer than 170
mm are covered by a 2-year warranty. We warrant
each frame and fork in our bikes against paint or varnish defects and corrosion for 3 years. This warranty
covers the original purchaser only and is non-transferable. For the lifetime warranty to be valid,customers
must fill in the online warranty form within one month of purchase, and proof of purchase in the form of
cash register receipt or sales ticket is required.
2) Warranty claims are subject to the decision made
by our technical staff about the nature of the defect
after thorough inspection of the faulty part.
3) All the parts assembled in our bicycles are protected against assembly or manufacturing defects for 2
years, and repairs qualifying under this warranty will
be performed by authorized dealers in each country.
4) This warranty does not cover parts that naturally
wear over time, such as tires, brake pads, handlebar
grips, cranksets, bearings, etc.
5) This warranty does not cover damages or defects
caused by negligence, improper use, assembly ofparts
or accessories that are not original, or defective repair
or maintenance work. of the bicycle, nonoriginal accessories being fitted to it, or unsuitable maintenance
operations or handling.

6) This warranty includes only replacement or repair

coverage of the parts under it and in no case shall it
cover personal damages directly or indirectly caused
by the failure of said parts during use.
7) All claims must be reported to an authorized dealer.
In case there is no such a dealer near the buyers location, please contact Orbea so that we can decide
how to solve the problem.
8) In case of crashes, the Orbea warranty shall be considered null and void.

23

TECHNICAL SPECIFICATIONS

ADDITIONAL INFORMATION
Orbea participates actively on facebook and Twitter
with our fantastic global community of riders. Looking to find spots to ride or plan a vacation? Someone will have the answers:

FACEBOOK
www.facebook.com/OrbeaBicycles

TWITTER
https://twitter.com/Orbea/

TECH VIDEOS
Visit our Orbea Channel on YouTube for a variety of
helpful setup and tech videos:
http://www.youtube.com/user/OrbeaBicycles/

INSTAGRAM
instagram.com/orbeabicycles

ORBEA CONTENT
View and download photos, videos and documents.
http://content.orbea.com/

YOUR ORBEA DEALER

Our dealers are experts and should be able to assist
you with setting up and maintaining your Orbea bicycle. A complete listing of Orbea dealers and distributors can be located on our website:
http://www.orbea.com/int-en/dealers/?country=INT/

AFTER SALES SERVICE

Our service technicians are trained to handle any
questions you might have about your Orbea bicycle.
mailto:Orbea@Orbea.com

TECHNICAL SPECIFICATIONS

BLUE
PAPERS
OCCAM
TECHNICAL MANUAL

24
