THREE PHASE

TRANSFORMERS

Jurieve R. Bagay
Saturday, August 3, 2013 JURIEVE R. BAGAY 2
Purpose of Three Phase Transformer

In order to supply three phase


source.
In order to bridge the three
phase high voltage system
and the low voltage three
phase loads.
JURIEVE R. BAGAY 3
Types of Three Phase Transformer

A. One (1) Bulk Three phase


Transformer
Types:
1. Dry Type
2. Oil Immersed Type

JURIEVE R. BAGAY 4
Types of Three Phase Transformer
A. One (1) Bulk Three phase Transformer
Types:
1. Dry Type – Indoor Type Transformers
2. Oil Immersed Type – Outdoor Type
Transformers
- Pole Mounted Type Transformers

JURIEVE R. BAGAY 5
Types of Three Phase Transformer
B. Transformer Bank
Two or more single phase transformer
that are interconnected on either delta
or wye connection.

6
JURIEVE R. BAGAY
Types of Transformer Bank
1. Delta – Delta
2. Wye – Wye
3. Delta – Wye
4. Wye – Delta
5. Open Delta

7
JURIEVE R. BAGAY
JURIEVE R. BAGAY 8
JURIEVE R. BAGAY 9
JURIEVE R. BAGAY 10
JURIEVE R. BAGAY 11
Application of Transformer Bank
1. Delta – Delta = Continuity of Service
2. Wye – Wye = Multi-voltages, Neutral
Connection, Balancing of Phase Voltages
3. Delta – Wye = Step – Up Application
4. Wye – Delta = Step Down Application
5. Open Delta = Economical Three Phase
Source

JURIEVE R. BAGAY 13
KVA CAPACITY
For Three Phase Transformer bank that is
composed of three identical transformers,

ST  3Seach
For Open Delta Transformer Bank,

ST  3Seach
JURIEVE R. BAGAY 14
Three Phase System
WYE CONNECTED DELTA CONNECTED
SYSTEM SYSTEM

Line _ Voltage  3Phase _ Voltage Line _ Voltage  Phase _ Voltage

VL  3V VL  V

Line _ Current  Phase _ Current Line _ Current  3Phase _ Current

I L  I I L  3I
JURIEVE R. BAGAY 15
Scott Connection Transformer
Scott Connection also called T-
Connected Transformer Bank is used to
transform or convert three phase supply
into two phase supply or vice versa.
These transformers consist of two
identical single phase transformers but
with different tapping point.

JURIEVE R. BAGAY 16
Scott Connection Transformer
One has a 50% tap and the other has
86.8 % tap on their primary windings.
Basically the one with 50% tap is said to
be a teaser transformer and the one that
has an 86.6 % tap is said to be main
transformer.

JURIEVE R. BAGAY 17
JURIEVE R. BAGAY 18
JURIEVE R. BAGAY 19
JURIEVE R. BAGAY 20
JURIEVE R. BAGAY 21
JURIEVE R. BAGAY 22
“A great person has the
desire and ability to
transform ordinary people
into great one.”
– Jurieve
JURIEVE R. BAGAY
23
THANK YOU!!!

Jurieve R. Bagay
TIPQC EE Faculty
