Top Drive

“Helping Our Customers Achieve Superior Results”

Intelligent
Accessories
Canrig’s commitment to drilling efficiency has resulted
in the development of a line of intelligent top drive
accessories. Each blends innovation with excellence
in engineering.

Advanced Diagnostics System

The Advanced Diagnostics System (ADS) monitors
strategic points of the top drive unit and its associated
control and power system, making intelligent assessments
of malfunctions and reporting possible causes. The ADS
communicates with the operator via a color monitor with
a touch-sensitive screen to respond to messages. This
operator interface terminal also allows inputting correction
factors and shutdown of non-essential functions in case of
equipment failure.

Traveling Equipment Anti-Collision System

Canrig has developed the Traveling Equipment Anti-
Collision System (TAC) which sounds an alarm whenever
contact between certain rig components is about to occur.
If the alarm sounds and the problem is not corrected,
the action in question is stopped utilizing an automatic
shutdown device. Two different versions of the system are
available, including TAC I for rigs without top drives and
TAC II for rigs with top drives.

Equipment Condition Monitoring System

Equipment Condition Monitoring (ECM) of drilling rig
equipment in real time is not only possible but proven
to be effective. Using sophisticated sensors, purpose
built software and web-based data collection, Canrig can
deliver an even greater level of equipment reliability
and performance.

Enhanced Well Control (Optional)

The Lower Well Control Valve (LWCV) actuator is a
significant upgrade in reliability and functionality from
any similar device. Designed as a replacement for existing
actuators, it is field retrofittable to lower well control
valves in use today. The dual rack and pinion open / close
mechanism is not affected when operation is attempted
while the pipe is rotating. The LWCV actuator is capable
of functioning values in either direction against 2,500
psi differential pressure.

TDSU-Grasshopper (Optional)
The TDSU-Grasshopper enables fast and orderly rig-up
of the cables and hoses that are required to run from the
TDSU to the rig floor. This is accomplished through the
use of a hydraulically powered telescoping post combined
with a series of articulating cable trays.
 Top Drive
Rig-Up
Efficiency
Canrig’s exclusive folding
torque guide enables the safest
and fastest rig-up and rig-down
in the industry.
• Folds into a single,
transportable skid
• Installed vertically after
mast erection
• Single-point disconnect
allows electrical and hydraulic
services to stay with the unit
during moves
• Bolting and flanges
are eliminated
• Minimal rig interface
• Adjustable telescoping
top section
• Variable-length lower
sections
• Multi-block interface
• Compact design accommodates
shorter masts
Canrig is one of the world’s leading suppliers of top drive drilling systems
for the oil and gas industry. The company manufactures, markets and
services a full range of critically engineered portable and fixed top drive
systems for most land and offshore rigs. This includes top drives in every
size and configuration to meet any drilling application whether marine,
desert, jungle or Arctic environments.
Canrig top drives are engineered and manufactured to API 8-C standards
and carry the API monogram. They set the standard for safety, reliability
Canrig top drives set the standard for safety, reliability and efficiency.
Superbly engineered products and unparalleled service have moved the
company to the forefront of the top drive drilling industry.
Systems Configurations
Land
Portable Systems
• Exclusive folding torque guide for fastest, safest rig-up
• Independent VFD house can easily be connected to the
rig power source
• Optional engine-generator system for mechanical or
underpowered rigs
• Land configuration skid with Top Drive Support Unit (TDSU)
house grasshopper cable tray and spare parts storage
• Complete system ships in two self-contained loads
Integrated Systems
• Integrated or stand-alone VFD
• All electric and hydraulic controls can be fully integrated into
rig’s master control system
• Torque can be reacted through mast legs eliminating the need
for torque guide
• Top drive can be permanently fixed into the mast eliminating the
need for removal during transport
• Multiple console options
Offshore
• Fixed torque guide sized with mast or wide flange track
• Highly adaptable to a variety of torque tracks
• Retract feature for pipe handling
• Design includes work platforms for easy, safe access to the top drive
• Corrosion-resistant coatings and sub assemblies
• Load capabilities to 750 tons
• ABS and ATEX certification
Footprint Dimensions
TD Model A B C D
4017AC-122 (with 8-ft links) 18' 4" 46" 21.5" 39"
6027AC-939 (with 8-ft links) 16' 8" 49" 23.5" 40"
1235AC-500 (with 11-ft links) 20' 54" 26" 48"
8050AC-681 (with 11-ft links) 21' 2" 57" 29" 48"
1250AC-681 (with 11-ft links) 21' 2" 57" 29" 48"
TOP VIEW
1250AC-685 (with 11-ft links) 22' 4" 57" 29" 48"
1275AC-681 (with 11-ft links) 21' 2" 57" 29" 48"
1275AC-865 (with 11-ft links) 22' 4" 57" 29" 48"
1575AC-865 (with 11-ft links) 22' 4" 57" 30" 48"

Model Performance
AC Top drives
4017AC 6027AC 8050AC 1235AC
Load Rating tons 175 275 500 350
tonnes 159 249 454 318
Output Power HP 400 600 800 1,150
(Continuous) kW 300 450 590 860
Gear Ratio 12.262:1 9.387:1 6.808:1 5.000:1
Maximum ft-lb 21,400 30,000 40,250 37,800
Continuous Torque N-m 29,000 40,700 54,600 51,200
Maximum Speed RPM 215 225 265 265
Connection ft-lb 32,000 60,000 90,000 87,500
Breakout Torque N-m 43,400 81,300 122,000 118,600
Weight lb 15,000 18,000 29,000 27,000
kg 6,800 8,200 13,200 12,200

AC Top drives
1250AC 1275AC 1575AC
Load Rating tons 500 500 750 750 750
tonnes 454 454 680 680 680
Output Power HP 1,150 1,150 1,150 1,150 1,500
(Continuous) kW 860 860 860 860 1,120
Gear Ratio 6.808:1 8.654:1 6.808:1 8.654:1 8.654:1
Maximum ft-lb 51,400 65,300 51,400 65,300 75,700
Continuous Torque N-m 69,700 88,600 69,700 88,600 102,700
Maximum Speed RPM 265 225 265 225 270
Connection ft-lb 95,000 95,000 95,000 95,000 104,000
Breakout Torque N-m 128,800 128,800 128,800 128,800 141,000
Weight lb 29,000 32,000 30,000 32,000 35,000
kg 13,200 15,500 13,600 14,500 15,900
ISOMETRIC VIEW
 4 0 1 7 AC To r q u e C u r ve 1235AC

Capable of fitting into masts as small as 300k lbs, this unit sets the With its unique performance characteristic, this 1,000-HP
4017AC standard for AC top drives installed in small drilling and workover rigs.
1235AC unit is ideally suited for high-speed applications.
6 0 2 7 AC To r q u e C u r ve 1 2 3 5 AC

120000

105000 8.6:1 @ 1200HP 6.8:1 @ 1200HP

90000

The only 600-HP top drive in the 250-ton market,

6027AC this unit delivers 30,000 ft/lbs of continuous drilling torque.
1250AC The most powerful 500-ton top drive on the market.

80 50 A C
1275A C

120000

105000 8.6:1 6.8:1

90000

Developed for deep drilling applications, this unit is equipped

8050AC A 500-ton unit ideally packaged for value and performance. 1275AC with a 4" bore and 7,500 psi pressure rating.

1575AC

• Integral swivel
Benefits

120000
• Hydraulic torque boost
105000
• Industry exclusive floating quill for soft
90000 stabbing and thread-advanced compensation
• Polymer slide guide runners
• Counterbalance feature
• Wireline guide system
• Direct connection to rig’s traveling block
• Disc brake
• Pressurized upper seal
• Remote control pipe handler orientation
and lock
• Bidirectional link tilt function
1575AC A 750-ton unit optimized for value and performance. • Load path integrity
