Euler's Column Formula

Buckling of columns

Sorry to see that you are blocking ads on The Engineering ToolBox!
If you find this website valuable and appreciate it is open and free for everybody - please contribute by

• disabling your adblocker on The Engineering ToolBox!    •• How to?

You can make ads in the Engineering ToolBox more useful to you!

Columns fail by buckling when their critical load is reached. Long columns can be analysed with the Euler
column formula

F = n π2 E I / L 2                             (1)
where
F = allowable load (lb, N)
n = factor accounting for the end conditions

E = modulus of elastisity (lb/in2, Pa (N/m 2))

This website use cookies. By continuing to browse you are agreeing to our use of cookies! Learn more
L = length of column (in, m)
Got it!
I = Moment of inertia (in4, m 4)

Factor Counting for End Conditions

https://www.engineeringtoolbox.com/euler-column-formula-d_1813.html[15-Jul-19 12:14:13 PM]

Euler's Column Formula

column pivoted in both ends : n = 1

both ends fixed : n = 4
one end fixed, the other end rounded : n = 2
one end fixed, one end free : n = 0.25

Note!
Equation (1) is sometimes expressed with a k factor accounting for the end conditions:

F = π2 E I / (k L) 2                             (1b)
where

k = (1 / n) 1/2    factor accounting for the end conditions

n 1 4 2 0.25
k 1 0.5 0.7 2

Example - A Column Fixed in both Ends

An column with length 5 m is fixed in both ends. The column is made of an Aluminium I-beam 7 x 4 1/2 x 5.80
with a Moment of Inertia iy = 5.78 in4. The Modulus of Elasticity of aluminum is 69 GPa (69 109 Pa) and the
factor for a column fixed in both ends is 4.

The Moment of Inertia can be converted to metric units like

Iy = 5.78 in 4 (0.0254 m/in) 4

    = 241 10 -8  m 4

The Euler buckling load can then be calculated as

F = 4 π2 (241 10 -8  m 4) (69 10 9 Pa) / (5 m) 2

 =  262594 N
 = 263 kN
