5/21/2015 prog1

clc;
clear all;
close all;

% problem u_t = beat u_xx

% beta 4/pi^2
% exact solution
%
% u(x,t) = exp(-t) * sin(pi/2*x) + exp(-t/4)* sin(pi/4*x)
%

u =@(x,t) exp(-t).*sin(pi/2.*x)+exp(-t/4).*sin(pi/4.*x);

t0 = 0;
tn = 0.08;
x0 = 0;
xn = 4;

dx = 0.2;
dt = 0.04;

x = (x0:dx:xn)';
t = (t0:dt:tn)';

beta = 4/pi^2;
s = beta*dt/dx^2;

nx = (xn-x0)/dx;
nt = (tn-t0)/dt;

% we start indexing from zero

nx_int = nx-1; % number of interior points in spatial dim

nt_int = nt-1; % number of interior points in temporal dim

% construction of tridiagonal matrix

indx1 = ones(1,nx-2);
indx2 = ones(1,nx-1);
a1 = -s*indx1;
a2 = (1+2*s)*indx2;
a3 = -s*indx1;
A = full(gallery('tridiag',a1,a2,a3));

% boundary conditions
% U(0,k) = 0
% U(20,k) = 0

% initial condition

int_cond = @(x) sin(pi/4*x).*(1+2*cos(pi/4*x));

+
% A U(k 1) = U(k) + b

1/5
5/21/2015 prog1

U=zeros(nx+1,nt+1);
U_exact=zeros(nx+1,nt+1);

U(1,:)=0;
U(nx+1,:)=0;
U(:,1) = int_cond(x);

for k=1:nt_int+1
U(2:nx_int+1,k+1) = A\U(2:nx_int+1,k);
end

% exact solution construxtion

for k=1:nt+1
U_exact(1:nx+1,k) =u(x,t(k));
end

Numerical_sol = U
Analytical_sol = U_exact

figure(1)
mesh(t,x,U)
xlabel('Temporal dim')
ylabel('Spatial dim')
zlabel('Numerical sol')

figure(2)
mesh(t,x,U_exact)
xlabel('Temporal dim')
ylabel('Spatial dim')
zlabel('Analytical sol')

figure(3)
mesh(t,x,U_exact-U)
xlabel('Temporal dim')
ylabel('Spatial dim')
zlabel('Error in sol')

Numerical_sol =

0 0 0
0.4655 0.4521 0.4392
0.8968 0.8713 0.8467
1.2630 1.2277 1.1935
1.5388 1.4967 1.4561
1.7071 1.6620 1.6183
1.7601 1.7158 1.6730
1.7000 1.6603 1.6219

fi 2/5
5/21/2015 prog1

1.5388 1.5070 1.4761

1.2967 1.2752 1.2542
1.0000 0.9901 0.9803
0.6787 0.6807 0.6824
0.3633 0.3763 0.3886
0.0820 0.1041 0.1250
-0.1420 -0.1137 -0.0868
-0.2929 -0.2617 -0.2319
-0.3633 -0.3328 -0.3036
-0.3550 -0.3286 -0.3034
-0.2788 -0.2594 -0.2408
-0.1526 -0.1423 -0.1325
-0.0000 0 0

Analytical_sol =

0 0 0
0.4655 0.4518 0.4386
0.8968 0.8707 0.8455
1.2630 1.2268 1.1918
1.5388 1.4957 1.4541
1.7071 1.6609 1.6162
1.7601 1.7147 1.6709
1.7000 1.6594 1.6202
1.5388 1.5063 1.4748
1.2967 1.2748 1.2534
1.0000 0.9900 0.9802
0.6787 0.6810 0.6829
0.3633 0.3769 0.3896
0.0820 0.1048 0.1265
-0.1420 -0.1128 -0.0849
-0.2929 -0.2607 -0.2300
-0.3633 -0.3318 -0.3018
-0.3550 -0.3278 -0.3018
-0.2788 -0.2588 -0.2397
-0.1526 -0.1420 -0.1319
-0.0000 -0.0000 -0.0000

3/5
5/21/2015 prog1

4/5
5/21/2015 prog1

Published with MATLAB® R2014a
