Speech Communication 111 (2019) 29–43

Contents lists available at ScienceDirect

Speech Communication
journal homepage: www.elsevier.com/locate/specom

Anomaly detection based pronunciation verification approach using speech

attribute features
Mostafa Shahin a,b,1,∗, Beena Ahmed a,b,1
a
Department of Electrical and Computer Engineering, Texas A&M University, Doha 23874, Qatar
b
School of Electrical Engineering and Telecommunications, The University of New South Wales, UNSW Sydney, NSW 2052, Australia

a r t i c l e i n f o a b s t r a c t

Keywords: Computer aided pronunciation training tools require accurate automatic pronunciation error detection algorithms
Anomaly detection to identify errors made by their users. However, the performance of these algorithms is highly dependent on
One class SVM the amount of mispronounced speech data used to train them and the reliability of its manual annotation. To
Pronunciation verification
overcome this problem, we turned the mispronunciation detection into an anomaly detection problem, which
Speech attributes
utilize algorithms trained with only correctly pronounced speech data. In this work we adopted the One-Class
SVM as our anomaly detection model, with a specific model built for each phoneme. Each model was fed with a
set of speech attribute features, namely the manners and places of articulation, extracted from a bank of binary
DNN speech attribute detectors. We also applied multi-task learning and dropout approaches to alleviate the
overfitting problem in the DNN speech attribute detectors. We trained the system using the WSJ0 and TIMIT
standard data sets which contain only native English speech data and then evaluated it using three different
data sets, a native English speaker corpus with artificial errors, a foreign-accented speech corpus and a children’s
disordered speech corpus. Finally, we compared our system with the conventional Goodness-of-Pronunciation
(GOP) algorithm to demonstrate the effectiveness of our method. The results show that our method reduced the
false-acceptance and false-rejection rates by 26% and 39% respectively compared to the GOP method.

1. Introduction Assisted Pronunciation Training (CAPT) application with simple Auto-

Automatic pronunciation verification tools are widely used in a
variety of applications including Computer Aided Language Learning
(CALL), Computer Aided Speech and Language Therapy (CASLT), lan-
guage proficiency tests and foreign accent detection systems. Their main
purpose is to automate the process of assessing the speaker’s pronunci-
ation and reduce or, in some cases, eliminate the need of human inter-
vention significantly saving cost and time.
Pronunciation verification can be performed at different levels, start-
ing from speaker-level, where a single score representing the speaker’s
pronunciation fluency is estimated from a few sentences, as commonly
used in proficiency test applications, down to phoneme-level pronun-
ciation verification where evaluation is performed for each individual
phoneme. The task becomes more challenging as the level of pronun-
ciation verification goes lower, towards phoneme level. Phoneme-level
evaluation can provide rich information about the position and the type
of error made by the user, which then can be used to generate informa-
tive and corrective feedback to improve the learning process (Neri et al.,
2008; Neri et al., 2006). Neri et al. (2008) found that using a Computer
matic Speech Recognition (ASR) to teach children English as a foreign
language achieved short-term improvement in pronunciation compara-
ble to traditional teacher-led learning. However, for the feedback to be
effective, it is essential that the pronunciation verification algorithms
used be accurate and reliable as inaccurate feedback may lead the user
to lose motivation or even negatively impact their progress.
Several approaches have been proposed to address the phoneme-
level pronunciation verification problem, which can be categorized, in
terms of the detection algorithm, into three main groups: confidence-
score based, rule based and classification based methods. In the
confidence-score based approach, a single score measuring the pro-
nunciation quality of each pronounced phoneme is computed and the
phoneme then accepted or rejected based on a predefined threshold,
such as the posterior probability and log likelihood ratio (Kim et al.,
1997). The rule-based approach is a task-specific method where a
set of predefined rules representing the expected pronunciation errors
for a particular task are estimated either manually by a language ex-
pert (Abdou et al., 2006) or automatically using a data-driven method
(Lo et al., 2010). Finally, in the classification-based approach each
phoneme is classified as either correctly or incorrectly pronounced

∗
Corresponding author.
E-mail address: m.shahin@student.unsw.edu.au (M. Shahin).
1
Member, IEEE

https://doi.org/10.1016/j.specom.2019.06.003
Received 31 May 2018; Received in revised form 23 April 2019; Accepted 7 June 2019
Available online 11 June 2019
0167-6393/© 2019 Elsevier B.V. All rights reserved.
M. Shahin and B. Ahmed
after prior training of the classifier using both correct and incorrect pro-
nunciations of the phoneme (Franco et al., 2014). A detailed discussion
of each approach is provided in the next section. Most of these meth-
ods are highly dependent on the availability and quality of sufficient
annotated non-native training corpora, which is hard to collect. More-
over, human labeling of mispronounced data is more challenging than
correctly pronounced data (Bonaventura et al., 2000), which adds an
additional source of error in the training data.
In this paper we propose a novel method for achieving phoneme-
level pronunciation verification by treating the problem as an anomaly
detection task, thus requiring only correct pronunciations of each
phoneme to train a phoneme-specific One-Class Support Vector Machine
(OCSVM) model. We trained the OCSVM model using a set of attribute
features, namely the manners and places of articulation, derived from a
bank of Deep Neural Network (DNN) based attribute detectors. Speech
attribute features derived from detectors of the manners and places of
articulation have recently been used to tackle the phoneme-level pro-
nunciation verification problem (Duan et al., 2016; Li et al., 2017b).
We then tested the algorithm with three speech corpora: 1) two stan-
dard English native-speakers databases, namely the WSJ0 and TIMIT
(Paul and Baker, 1992; Garofolo et al., 1993), 2) the GMU foreign-
accented English speech collected from speakers with different L1 lan-
guages (Weinberger, 2015) and 3) a disordered speech corpus recorded
from children with Childhood Apraxia of Speech (CAS). Furthermore,
we compared our method to the most commonly used pronunciation
verification method, the Goodness Of Pronunciation (GOP) (Witt and
Young, 2000) to show the effectiveness of our approach.
The rest of the paper is organized as follows. An overview of pro-
nunciation verification approaches is given in Section 2. The method
and the speech corpora used are explained in Section 3. Section 4 rep-
resents the experiments and results. Finally, conclusions are drawn in
Section 5.
2. Related work
A number of different approaches have been implemented to achieve
phoneme-level pronunciation error detection, as outlined below.
2.1. Confidence score-based methods
These methods compute a confidence score representing how close
the pronunciation is to the target phoneme and then compare it to a
predefined threshold to accept or reject the produced phoneme. Methods
used to compute the confidence score include a posterior-probability
based score (Kim et al., 1997), a log-likelihood score and a log-likelihood
ratio (LLR) of two different acoustic models trained on both correct and
mispronounced non-native speaker speech (Jo et al., 1998; Franco et al.,
1999). Though the log-likelihood ratio (LLR) was shown to outperform
posterior-probability scores, it needed large amounts of annotated non-
native data to build the mispronounced acoustic model (Jo et al., 1998).
The most widely used confidence score is the goodness of pro-
nunciation (GOP) introduced by Witt and Young in 1999 (Witt and
Young, 2000). The GOP approximates the posterior probability of each
phoneme by taking the ratio between the forced alignment likelihood
and the maximum likelihood of the free-phone loop decoding using
a Hidden Markov Model (HMM) acoustic model. It has a high corre-
lation with human rating, specifically when using a phoneme-specific
threshold (Witt and Young, 2000) and thus been adopted as a standard
method to measure phoneme-level pronunciation quality in a range of
applications (Mak et al., 2003; Al Hindi et al., 2014; Maier et al., 2009;
Saz et al., 2009; Pellegrini et al., 2014; de Wet et al., 2009; Luo et al.,
2009). Variations to the GOP include the generalized posterior proba-
bility (GPP), first proposed to compute the word posterior probability
(Soong et al., 2004) and then modified to be used with the GOP score
on the phoneme level to relax the time boundaries produced by forced
alignment (Zheng et al., 2007). Mispronunciation detection error rates
30
Speech Communication 111 (2019) 29–43
of the GOP have been improved using scaling (Zhang et al., 2008), linear
transformation of the posterior score and discriminative training of the
acoustic model (Yan and Gong, 2011; Sim, 2009). A DNN-HMM based
version of the GOP averages the frame-level posterior probabilities out-
put from the last softmax layer for each phoneme (Hu et al., 2013).
The GOP algorithm is very sensitive to the quality of the acoustic
model used. It affects not only the estimation of the posterior proba-
bility but also the accuracy of time boundaries obtained from forced
alignment. In addition, as the decision threshold is determined using a
mispronunciation dataset, it can be error specific and thus very hard to
generalize to different types of pronunciation errors.
2.2. Rule based methods
Rule based methods require a priori knowledge of expected mispro-
nunciations rules. Unlike previous methods, they offer the advantage
of not only detecting the position of the pronunciation error but also
the type of error made by the speaker. However, as the rules are cus-
tomized to a specific problem they can fail if the speaker produces errors
not catered for by the designed rules.
Typically, the mispronunciation rules are developed by domain
experts. These have been implemented using techniques such as a
phoneme mispronunciation network of common expert-defined errors
made by speakers of Quranic Arabic, decoded using a HMM based ASR
system (Abdou et al., 2006). The error rate was decreased by replac-
ing the conventional GMM-HMM acoustic model with a hybrid DNN-
HMM in addition to implementing Minimum Phone Error (MPE) dis-
criminative training (Elaraby et al., 2016). A similar approach was
adopted to identify errors made by second language learners (Al-
Barhamtoshy et al., 2014; Harrison et al., 2009). In our previous work
on recognizing children’s disordered speech, we used a lattice consisting
of the correct phoneme sequence and an alternate garbage node to col-
lect the pronunciation errors (Shahin et al., 2015). We added alternative
nodes representing expected pronunciation errors specified by a speech
and language pathologist (Shahin et al., 2014). We were also able to
improve the error detection rate by using a DNN-HMM acoustic model
instead of a GMM-HMM acoustic model (Shahin et al., 2014). Instead
of using expert defined rules, mispronunciation rules automatically de-
rived from a L2 speech corpus have shown to improve performance
(Lo et al., 2010). Error rates have also been decreased by integrating the
rule-based method with the GOP score (Wang and Lee, 2012); either by
using the GOP to double check the output of the rule-based decoder or
evaluating each phoneme based on which method can handle it better.
Most recently, Li et al. (2017c); Ryu and Chung, (2017) introduced the
acoustic-graphemic-phonemic model (AGPM) by combining the acous-
tic features along with the graphemes and canonical transcription in one
multi-distribution DNN model.
2.3. Classifier based-methods
As phoneme level error detection can be treated as a binary classifi-
cation problem where each phoneme is classified as “correct” or “mis-
pronounced”, conventional classification methods such as SVM, decision
tree, ANN, etc. have also been applied to this problem. When LDA and
a decision tree were used to assess the pronunciation of three Dutch
sounds produced by non-native speakers (Truong et al., 2004), only the
LDA classifier outperformed the GOP method and on only one Dutch
sound (Strik et al., 2007). However, a SVM classifier (Franco et al., 2014)
outperformed the LLR confidence score when used on non-native Span-
ish speakers; the best performance was obtained using a simple weighted
combination of both systems.
Different features have also been experimented with to improve clas-
sifier performance. A comparison of a linear kernel SVM used with three
types of extracted features, the GOP score, Mel-Frequency Cepstral Co-
efficients (MFCCs) and formants frequencies, found the MFCCs were
best at detecting pronunciation errors of Dutch vowels (van Doremalen
M. Shahin and B. Ahmed
et al., 2009). Another feature set used to improve SVM performance
includes the difference between an utterance distance matrix of the
production consisting of the distances between a specific phoneme and
other phonemes in the same utterance to a similar matrix extracted from
a native Chinese utterance (Zhao et al., 2012). To cope with the pronun-
ciation variations of each phoneme, Pronunciation Space Models (PSMs)
have been used to develop phoneme-specific SVM models (Wei et al.,
2009), while DNNs have been used to extract phoneme-level features to
train phoneme-specific logistic regression classifiers (Hu et al., 2014).
Although all these classifiers led to a significant improvement com-
pared to confidence score methods such as GOP, they still need sufficient
amounts of accurately annotated non-native data to model the mispro-
nounced phonemes. Moreover, the mispronounced data has to include
all possible pronunciation errors, which is usually not feasible.
In this work we tackle the limitations of the three methods discussed
above in two ways. Firstly, we use speech attribute features. Speech at-
tribute features (manners and places of articulation) are more robust
against speech variations due to speakers, environmental noise, dialect
etc. compared to traditional features. In addition, mispronunciations, in
nature, can be defined as a change in one or more attributes of the pro-
nounced phoneme making them more effective in detecting pronuncia-
tion errors. Despite their potential, speech attribute features have found
limited use in the phoneme-level pronunciation error detection prob-
lem. In early work by Jo et al. (1998), pair-wise manner and place of
articulation classifiers were used to detect missing articulation feature/s
in mispronounced phonemes. They have also been used to improve the
performance of the GOP in (Stouten and Martens, 2006) where acoustic
features were converted to the corresponding phonological features us-
ing a set of ANN speech attributes detectors and in (Yoon et al., 2009),
the posterior probability of each phoneme was estimated using speech
landmark-based SVMs for combination with the conventional GOP-score
in a second SVM. Recently, speech attribute features have been used
with a DNN classifier and a binary Long Short-Term Memory (LSTM)
classifier to detect phoneme-level mispronunciations in L2 speech (Duan
et al., 2016; Li et al., 2017b).
Secondly, we utilize anomaly detection to identify the phoneme level
mispronunciations. Anomaly detection eliminates the need of a mispro-
nunciation training dataset instead enabling training with only native-
speech corpora, which are abundantly available for languages such as
English. A variety of methods have been proposed for anomaly detec-
tion, e.g. decision trees, neural networks, nearest neighbors, Bayesian
classifiers and the one-class SVM (OCSVM) (Chandola et al., 2009;
Khan and Madden, 2014), however we advocated the one-class SVM ap-
proach. The OCSVM is a novelty detection method that performs very
well when the training data is pure and not contaminated with outliers
(Khan and Madden, 2014) because its decision boundary is affected sig-
nificantly by outliers. This high sensitivity makes it is well suited to our
problem. We trained the OCSVM using the speech attribute features of
the correct pronunciation of each phoneme, making the anomaly de-
tection model sensitive to abnormal changes in the attribute features
caused by mispronunciations.
3. Method
3.1. System overview
Fig. 1 presents the flow diagram of our proposed pronunciation er-
ror detection method. The system consists of four main stages: pre-
processing, forced alignment, speech attribute detection and OCSVM
model building.
In the pre-processing stage, the speech signal is framed with a Ham-
ming window of 25 msec width and sampling rate of 10 msec. From
each window, two types of features are obtained: (1) 26 filter bank fea-
tures extracted by applying triangular filters on the Mel-scale to the
power spectrum and (2) MFCC coefficients, which are the decorrelated
and compressed version of the filter bank features produced by applying
31
Speech Communication 111 (2019) 29–43
Discrete Cosine Transform (DCT) on the filter banks and yield typically
12 coefficients. The filter bank coefficients are fed to the DNN speech at-
tribute detectors, given they have proven to be more efficient with deep
learning architectures than traditional MFCC features (Mohamed et al.,
2012). The MFCC features are used to train context dependent GMM-
HMM acoustic models employed in the forced alignment stage.
As our method is text-dependent, the prompted word/sentence is
known ahead and therefore the phonetic transcription can be extracted
using any existing pronunciation dictionary. In this work, we adopted
the CMU pronunciation dictionary and standard ARPAbet phonetic sym-
bols (C. M. University 2014). The resultant phoneme sequence is then
passed to the forced alignment stage along with the MFCC features ex-
tracted from the speech signal to determine the time boundary of each
phoneme.
In the speech attribute detection stage, a separate binary DNN clas-
sifier is trained to recognize the existence or absence of each attribute
in the current frame. A mapping step is performed first to map each
phoneme to its corresponding speech attributes. Each phoneme is then
modeled using an OCSVM which is trained by the speech attribute fea-
tures produced from the previous stage.
In the verification mode, forced alignment is performed first and
then the frames of each individual phoneme are classified as in-class,
i.e. belongs to the underlying phoneme, or out-of-class, i.e. anomalous
pronunciation, using the phoneme-specific OCSVM model. The whole
phoneme is accepted or rejected based on the ratio between the number
of in-class and out-of-class frames. As the OCSVM is an anomaly de-
tection method based solely on the correct data set, only native speech
corpora were used for its training.
3.2. Speech attribute detectors
The speech attributes, namely the manners and places of articula-
tion, provide a knowledge-rich representation of speech articulation.
The motivations behind the choice of these features are that they are
robust against background noise and inter-speaker variations due to di-
alect, age and/or gender of the speakers (Lee and Siniscalchi, 2013).
Furthermore, these features are shared among multiple languages and
hence speech corpora from different languages can be utilized in train-
ing one universal speech attribute model (Behravan et al., 2014), thus
overcoming the shortage of labeled speech corpora from low-resource
languages (Wang et al., 2014).
In this work, we utilized 25 manner and place of articulation at-
tributes in addition to silence. Silence was used to measure the absence
or existence of speech. A complete list of the adopted speech attributes
and their associated phonemes is shown in Table 1. For each attribute,
a separate binary frame-level DNN classifier was trained to determine
the existence or absence of the attribute.
Furthermore, we examined different DNN methods to improve the
performance of the speech attribute detectors, including multi-task
learning (MTL) and dropout regularization (Dout). Bottleneck (BN) fea-
tures were also employed to better represent the phonetic variations
within each speech attribute by increasing the dimensionality of the ex-
tracted features. As depicted in Fig. 2, a set of DNN models were trained
using filter-bank features to detect the existence or absence of each of
the 26 speech attributes. The resultant feature vector either had 26 fea-
tures, when features were formed from the output of the softmax layer,
or 260, when a bottleneck layer with 10 neurons was used for each
speech attribute detector. The extracted features from each DNN con-
figuration were then used to train phoneme-specific OCSVM models. In
other words, each phoneme had 4 different OCSVM models each trained
using features extracted from one DNN configuration. The 4 OCSVM
models of each phoneme were then evaluated using a validation set and
the model that achieved the best performance was selected. In the fol-
lowing subsections we detail each of these methods.
M. Shahin and B. Ahmed Speech Communication 111 (2019) 29–43

Fig. 1. The system flow chart.

Table 1
List of speech attributes.

Attribute Phonemes

Vowels ao, aa, iy, uw, eh, ih, uh, ah, ax, ae, ey, ay, ow, aw, oy, er, axr
Stops p, b, t, d, k, g
Affricates ch, jh
Fricatives f, v, th, dh, s, z, sh, zh, hh
Nasals m, n, em, en, ng, eng
Liquids l, el, r, dx
Semivowels y, w
Approximant w, y, l, r
Coronal d, l, n, s, t, z
High ch, ih, iy, jh, sh, uh, uw, y, ow, g, k, ng
Dental dh, th
Glottal hh
Labial b, f, m, p, v, w
Low aa, ae, aw, ay, oy
Mid ah, eh, ey, ow
Velar g, k, ng
Back ay, aa, ah, ao, aw, ow, oy, uh, uw, g, k
Retroflex er, r
Anterior b, d, dh, f, l, m, n, p, s, t, th, v, z, w
Continuant ao, aa, iy, ay, r, ey, ih, uw, eh, uh, ah, ae, ow, aw, oy, er, f, v, th, dh, s, z, sh, l, y, w
Round aw, ow, uw, ao, uh, v, y, oy, r, w
Tense aa, ae, ao, aw, ay, ey, iy, ow, oy, uw, ch, s, sh, f, th, p, t, k, hh
Voiced aa, ae, ah, aw, ay, ao, b, d, dh, eh, er, ey, g, ih, iy, jh, l, m, n, ng, ow, oy, r, uh, uw, v, w, y, z
Monophthongs ao, aa, iy, uw, eh, ih, uh, ah, ax, ae
Diphthongs ey, ay, ow, aw, oy
Silence Silence

3.2.1. Deep neural network (DNN) architecture
We used a feed-forward deep neural network (DNN) as our attribute
detector as shown in Fig. 3. The input to the DNN was the set of 26 filter
bank features extracted from each frame along with their delta and ac-
celeration coefficients. To identify context, we combined features from
11 frames (5 neighboring frames on either side of the underlying frame)
to form one 858 size super feature vector. The output layer consisted of
2 neurons, one fired when the input was a +ve example, i.e. where the
frame belonged to the attribute, while the other neuron fired when the
input was a –ve example, i.e. where the attribute is absent. The softmax
function was then applied to the output to convert the arbitrary out-
put values to probabilities. The softmax output of the j-th neuron was
calculated as follows:
( ) 𝑒𝑧𝑗
𝑓 𝑧𝑗 = ∑𝑛
𝑖=1 𝑒𝑧𝑖
where n is the number of output neurons.
Following the work done in (Yu et al., 2012) on the Wall Street Jour-
nal (WSJ0), we used 5 hidden layers each with typically 2048 non-linear
neurons with the Rectified Linear Unit (ReLU) adopted for the hidden
neurons, defined as follows:
𝑓 (𝑥) = 𝑚𝑎𝑥(0, 𝑥) (2)
As the ReLU function has been shown to alleviate the vanishing gra-
dient problem making pre-training less effective (Li et al., 2017a), we
did not apply pre-training and the weights were initialized randomly
based on uniform distribution (Glorot and Bengio, 2010):
[ √ √ ]
6 6
𝑊 ∼𝑈 − , (3)
𝑓 𝑎𝑛𝐼𝑛 + 𝑓 𝑎𝑛𝑂𝑢𝑡 𝑓 𝑎𝑛𝐼𝑛 + 𝑓 𝑎𝑛𝑂𝑢𝑡
where fanIn is the number of inputs to the neuron and the fanOut is the
number of outputs.
(1)
The Mini-Batch Stochastic Gradient Decent (MBSGD) method was
used to fine-tune the network with a mini-batch size of 100 samples.
The learning rate started with 0.1 and remained unchanged as long as

32
M. Shahin and B. Ahmed
Fig. 2. Comparison amongst the four different DNN configurations used in our speech attribute detectors.
Fig. 3. The feed-forward DNN architecture used in the speech attribute detec-
tors.
the loss in a separate validation set was greater than a certain threshold,
otherwise the learning rate was halved and the weights returned to their
previous values. Training continued until the learning rate reached its
minimum threshold of typically 0.0001. We used the binary cross en-
tropy as our objective function, which is defined as below:
𝑵
1 ∑[ ( ) ( )]
𝑪=− 𝒕 ln 𝒚 𝒊 + 1 − 𝒕𝒊 𝐥𝐧 1 − 𝒚 𝒊 (4)
𝑵 𝒊=1 𝒊
where N is the number of samples in the mini-batch and ti and yi are the
target and predicted values of the sample i.
A separate DNN classifier was trained and tuned for each of the 26
attributes used in this work. As the classifier outputs are probabilities
derived from the softmax function, we used the value of only one of
the two output neurons, i.e. either the +ve neuron, which represented
how likely it was that the attribute existed in the current frame, or the
–ve neuron, which represented how likely it was that the attribute was
absent in the current frame. The filter-banks features of each frame were
then converted to a feature vector containing the 26 speech attributes.
33
Speech Communication 111 (2019) 29–43
Fig. 4. The architecture of DNN with bottleneck layer of 2048 nodes.
3.2.2. Bottleneck features
As using a single output from each attribute classifier was inefficient
in discriminating between frames of different phonemes that shared the
existence or absence of the same attributes, we utilized bottleneck fea-
tures to increase the dimensionality of the features extracted from each
attribute. These features were taken from a bottleneck layer, i.e. a hid-
den layer with a significantly lower number of non-linear ReLU neurons
compared to other hidden layers in the DNN network, as shown in Fig. 4.
We used a bottleneck hidden layer with typically 10 neurons. We tried
different number of neurons in the bottleneck layer, namely 20, 15 and
10 with no significant impact on the performance of the whole system.
A slight improvement in the performance was obtained using 10 neu-
rons. The size of the speech attribute feature vector of each frame was
increased from 26 to 260 values, where 10 values represented a single
attribute.
M. Shahin and B. Ahmed
Fig. 5. The architecture of multi-task learning with (1) attribute detection as
the main task and (2) phoneme classification as the secondary task. Each task
has its own output layer but shares the same input and hidden layers.
3.2.3. Multi-task learning (MTL)
We used multi-task learning, as it has been shown to improve the
generalization of the main classification task by learning secondary
different but related tasks, which share the same model parameters
(Ferber, 1999; Collobert and Weston, 2008; Zhang et al., 2014b). Multi-
task learning can be achieved on the DNN using either hard or soft
parameter sharing (Ruder, 2017). In hard parameter sharing, all tasks
share the same model parameters but have a separate output layer, while
in soft parameter sharing, each task is trained using its own model and
regularization used to decrease the distance among the models’ param-
eters.
We adopted hard parameter sharing method, the most commonly
used method to avoid overfitting (Baxter, 1997). As shown in Fig. 5,
we trained each DNN attribute classifier to achieve two tasks; the main
task was the binary classification of each frame’s attribute, while the
secondary task was phoneme classification task. Unlike the attribute de-
tector which has two output neurons, the phoneme classifier has 120
output neurons representing the states of the 40 phonemes, 3 states per
phoneme. Using phoneme classification as a secondary task not only al-
lowed us to improve the performance of the attribute classification task
but more importantly allowed the network to learn variations amongst
phonemes that shared the same attribute class and hence produce more
discriminative features.
We employed a simple implementation similar to the one proposed
by Huang et al. (2013). All the hidden layers were shared between the
main and secondary tasks, while each task had its own softmax layer.
The dataset was divided into batches and each batch was fed to the
network twice for the first and second tasks. During training, the error
computed from the objective function belonging to a specific task was
used to update the shared hidden layers weights and only the softmax
layer parameters of this specific task, while the parameters of the soft-
max layer of the other task remained intact.
3.2.4. Dropout regularization
In addition to the MTL, we utilized the dropout approach to further
reduce the effect of the overfitting, a major issue in DNN training, as
proposed by Srivastava et al. (2014). It works by randomly selecting a
percentage of nodes in input and hidden layers to be inactive (dropped-
out) with probability p during the training process, which means that all
fan-in and fan-out connections of this node are removed and the weighs
are not updated; Fig. 6 shows the network structure with and without
34
Speech Communication 111 (2019) 29–43
dropout. During the testing phase, all nodes were active and fully con-
nected, however the fan-out weights of each neuron were scaled by 1-
p, where p is the probability of being dropped-out during the training
phase. Based on recommendations in (Srivastava et al., 2014) and previ-
ous studies on speech processing problems (Xu et al., 2015; Zhang et al.,
2014a), we chose dropout probability values of 0.2 for the input layer
and 0.3 for all hidden layers.
3.3. One class support vector machine (OCSVM)
As aforementioned, we treated the pronunciation error detection
problem as an anomaly detection problem, where the model was trained
on only the normal (correct) samples and anomalies (mispronounced)
classified as outliers.
The one class SVM is a special variation of the SVM classifier intro-
duced by Schölkopf et al. (2001) to solve the one class classification
problem. Unlike the traditional binary SVM classifier, where samples
from +ve and –ve classes are available in the training set, the OCSVM
is trained on only the +ve samples to find the hyperplane that separate
them from the origin. This is achieved by developing a decision func-
tion with value +1 in a “small” region that includes most of the training
samples and −1 elsewhere with a maximum margin from the origin as
shown in Fig. 7.
The OCSVM training was tuned using two parameters. First, the reg-
ularization parameter 𝜐, which takes values in the interval [0, 1] and
represents the maximum number of training samples allowed on the
negative side of the decision hyperplane. And second, the minimum
number of support vectors as a percentage of the total number of the
training samples. A Gaussian kernel function was used, as it has been
shown to be the most successful kernel for the OCSVM (Bounsiar and
Madden, 2014), with the function defined as:
( )
𝐾 𝑋𝑖 , 𝑋𝑗 = exp −𝛾𝑋𝑖 − 𝑋𝑗 2 , 𝛾 > 0 (5)
where the value of 𝛾 was determined empirically.
The OCSVM model was trained using the speech attributes features
produced from the bank of DNN attribute detectors. The size of the in-
put feature vector was either 26 when taken from the +ve node of the
last softmax layer with one value for each attribute, or 260 when the
attribute features were taken from the bottleneck layer with 10 values
for each attribute.
3.4. Goodness of pronunciation (GOP)
For comparison purposes, we implemented the GOP as proposed
in (Witt and Young, 2000) where the posterior probability of each
phoneme was estimated using the following equation:
( )
( ) 𝑃 𝑂∕𝑝𝑖
𝑃 𝑝𝑖 ∕𝑂 = ( ( )) (6)
𝑚𝑎𝑥𝑝𝑗 ∈𝑄 𝑃 𝑂∕𝑝𝑗
where pi is the underlying phoneme and the numerator P(O/pi ) is the
phoneme likelihood computed from the forced alignment step and O
is the observation segment of pi obtained from the forced alignment.
A free-phoneme recognition step was performed using a phoneme loop
grammar created from the list of phonemes in Q. The denominator was
the maximum likelihood from the free-phoneme recognition of the ob-
servation segment O. Fig. 8 summarizes the GOP algorithm.
We used a DNN-HMM acoustic model to estimate the posterior prob-
ability in the GOP algorithm which consists of 5 hidden layers with 2048
neurons in each layer. The activation of the hidden units is ReLU and
the output layer is a softmax layer with 120 units representing the 3
states of the 40 monophones (Mohamed et al., 2012b).
The log value of the computed score was first normalized over the
phoneme duration and then compared to a predefined threshold in order
to accept or reject the pronunciation. The specific threshold for each
phoneme was tuned to maximize the phoneme F1 score in the validation
set.
M. Shahin and B. Ahmed
Fig. 7. The one-class SVM decision regions.
3.5. Speech corpora
We used four different speech corpora to evaluate the algorithms,
two of which were collected from English native speakers and the other
two corpora contain foreign-accented and disordered speech.
To validate and test our algorithms, we used two native speech
corpora. (1) The speaker independent subset (SI84) in the standard
Wall Street Journal (WSJ0) dataset, which consists of 101 speakers and
13,048 sentences (∼21 h in total). (2) The TIMIT dataset, which contains
6300 sentences produced by 630 speakers (∼3.5 h in total). The overall
validation set consisted of 1400 sentences from 76 speakers, while the
test set consisted of 1500 sentences from 100 speakers.
To evaluate the effectiveness of the method in detecting pronuncia-
tion errors, we used two other datasets that contain natural pronuncia-
tion errors. (1) The GMU foreign-accented speech, which was collected
from non-native English speakers from a variety of L1 language back-
grounds reading a common paragraph carefully selected to cover all
English phonemes. The data was transcribed by 2 to 4 native English
speakers who were phonetically educated (Weinberger, 2015). In this
work we used 15 non-native English speakers with 4 different L1 lan-
guages: Arabic (5 speakers), Dutch (4 speakers), German (4 speakers),
and Farsi (2 speakers). (2) A disordered speech corpus collected from
children with Childhood Apraxia of Speech (CAS). The recording and
annotation process were performed by speech and language patholo-
gists (SLPs) at the University of Sydney. The corpus contained speech
from 11 children pronouncing 450 single word prompts.
35
Speech Communication 111 (2019) 29–43
Fig. 6. The DNN architecture (a) without and (b) with dropout
(Srivastava et al., 2014).
4. Experiments and results
We conducted three separate experiments to optimize the parame-
ters of each module separately and then evaluated the whole system in
detecting mispronunciation errors.
In the first experiment, we studied the speech attribute detection
module and tuned the parameters of the DNN classifiers to achieve best
performance for each detector using a native-speaker English corpus. In
the second experiment, we looked at the effectiveness of the phoneme-
specific OCSVM models, trained using the speech attribute features, in
modeling the correct pronunciation of each phoneme.
Finally, in the last experiment, we evaluated the integrated system
in pronunciation verification of native-speaker English test set with ar-
tificial errors, foreign-accented English test set and children disordered
speech. We compared these results to the DNN-GOP algorithm.
4.1. Results on speech attribute detection
In this experiment, we studied the extraction of the speech attribute
features. A separate binary DNN classifier was trained for each of the
26 speech attributes in Table 1 evaluating the existence or absence of
the attribute in the input frame. Both the WSJ0 and TIMIT speech cor-
pora were used to train, validate and test the DNN classifiers. Frames of
all the phonemes that belonged to the underlying attribute formed the
+ve examples, while all other frames that were not included in the +ve
samples formed the –ve examples. The training, validation and testing
sets were balanced by randomly choosing equal numbers of +ve and –
ve samples to prevent biasing of the model. The exact number of frames
used in the training, validation and testing of each speech attribute are
listed in Table 2.
With a balanced test set, the classification accuracy score can be used
to represent the performance of the attribute detector. Fig. 9 shows the
accuracy of the 26 attribute detectors over the training, validation and
testing sets using a shallow ANN (with one hidden layer) and a DNN
(with 5 hidden layers). For both models the number of neurons is fixed
to 2048 ReLUs. The results show that the DNN model outperformed the
single hidden layer ANN. The average performance of the shallow ANN
was 89% ± 3%, while the 5 layers DNN achieved average performance
of 91% ± 2%. Affricates and retroflex achieved the best performance
of around 94% accuracy, while tense and mid attributes gave the least
accuracy of around 85%. Overall, the average accuracy of all attributes
was 90% with a standard deviation of 2.7%.
It is obvious from the results that the DNN models overfit the train-
ing data, with an accuracy of almost 100% reached in classifiers such as
affricates and semivowels. To relax this overfitting and improve the gen-
eralization of the model, we employed two different techniques, dropout
regularization and MTL. A dropout rate of 20% was used for the input
M. Shahin and B. Ahmed Speech Communication 111 (2019) 29–43

Fig. 8. The flow diagram of the GOP algorithm

(Witt and Young, 2000).

Table 2 Table 3
The distribution of the dataset over the training, validation The distribution of training samples over different phonemes.
and testing sets.
Phoneme N# training Phoneme N# training Phoneme N# training
Attribute N# training N# validation N# testing
ae 221,085 er 213,735 v 117,585
Vowels 6639,500 719,958 545,282 t 440,685 sh 837,27 ow 127,005
Stops 3129,490 354,896 236,484 eh 207,897 aa 176,252 b 101,506
Affricates 200,818 19,364 15,740 n 413,451 l 221,794 uw 98,513
Fricatives 2914,646 319,510 224,296 iy 286,984 m 184,162 y 50,256
Nasals 1465,152 166,466 104,850 s 378,509 jh 40,670 aw 48,422
Liquids 1124,678 119,766 93,590 dh 94,311 z 207,143 ey 176,512
Semivowels 319,916 33,346 29,082 ah 594,392 w 77,548 oy 17,406
Approximant 4580,322 477,940 390,168 d 245,684 k 315,311 uh 13,529
Coronal 1406,386 153,112 115,094 f 186,781 p 252,357 g 43,651
High 4316,732 489,946 327,352 ao 104,796 ay 146,427 th 52,698
Dental 3656,524 379,804 291,956 r 246,965 ng 57,559 ch 38,046
Glottal 328,972 36,862 26,336 ih 337,133 hh 119,823 zh 5461
Labial 267,900 30,126 16,086
Low 2081,142 234,694 160,284
Mid 1526,916 162,298 133,810
Velar 2434,322 286,848 178,306 Fig. 11 presents 2-D scatter plots of the attribute features of frames
Back 978,232 103,570 71,136 from different phonemes selected randomly from the validation set.
Retroflex 1048,488 116,674 82,670 Each frame was converted to its corresponding 26 attribute features us-
Anterior 6726,846 761,502 513,972
Continuant 3876,888 431,238 297,094
ing the pre-trained attribute detectors and then reduced to 2 dimensions
Round 5346,482 572,188 426,176 using t-Distributed Stochastic Neighbor Embedding (t-SNE) (Maaten and
Tense 2204,564 230,514 184,400 Hinton, 2008). The figures show how effective the attribute features are
Voiced 7750,246 844,118 634,428 in discriminating between the different phonemes. It is obvious from
Monophthongs 4848,766 529,628 387,524
the plots that each phoneme has a dominant region clearly separated
Diphthongs 1257,336 135,772 109,012
Silence 1111,396 88,178 118,294 from other phonemes in most cases. Fig. 12 shows the effect of MTL
and Dropout techniques in further improving the discriminability of the
attribute features. Here also the samples were randomly selected from
the validation set.
layer, while a rate of 30% was used for each of the 5 hidden layers for
all the attribute detectors. 4.2. Results on OCSVM phoneme specific models
In the MTL, each attribute detector was trained to classify each frame
as +ve or –ve, as a primary task, and to assign each frame to one of the In this experiment we studied the effectiveness of the OCSVM
monophone states, as a secondary task. There were 40 monophones with phoneme-specific model in discriminating between the in-class frames,
3 states, each forming 120 units in the output layer of the secondary task. i.e. the frames belonging to the underlying phoneme, and the out-of-
State alignment was performed using a context dependent GMM-HMM class frames, i.e. frames from other phonemes. Here also the WSJ0 and
acoustic model trained on the same training data. the TIMIT data sets were used to train and validate the OCSVM mod-
The effect of using dropout, multi-task learning and the combination els. The training set consisted of only in-class frames. 30% of the val-
of both techniques is demonstrated in Fig. 10. The average training ac- idation set consisted of randomly selected in-class frames, with the re-
curacy dropped from 97.5% ± 1.9 to around 92.7% ± 2.3 as opposed to maining frames randomly selected from all the other phonemes, with
a reduction in the test set classification error ranging from 5% to 18% all phonemes contributing equally. Table 3 shows the number of frames
when applying only dropout. On the other hand, MTL maintained the used in the training of each phoneme, while the validation set was fixed
average performance of the training set with a decrease in the test set er- to 2000 frames. Due to the imbalance in the validation set we chose
ror rate varying from 1% up to around 13%. Combining both techniques model parameters that maximize the F1 score, computed as follows:
further improved the accuracy of almost all the attribute detectors; the
2𝑇 𝐴
classification accuracy of the affricates and coronal attributes increased 𝐹1 = (7)
(2𝑇 𝐴 + 𝐹 𝐴 + 𝐹 𝑅)
from 94.7% and 87.7% using the DNN model without any regulariza-
tion techniques to 95.8% and 90% respectively when using both MTL where TA, FA and FR are the true-acceptance, false-acceptance and false-
and dropout methods. rejection respectively.

36
M. Shahin and B. Ahmed Speech Communication 111 (2019) 29–43

Fig. 9. The accuracy of the speech attribute de-

tectors of the training, validation and test sets
when using a shallow neural network (1 hidden
layer) and a deep neural network (5 hidden lay-
ers).

Fig. 10. The accuracy of the speech attribute detectors when using Multi Task Learning (MTL), dropout regularization (Dout), both MTL and Dout algorithms
(MTL + Dout) and deep neural network without any regularization method (DNN) for (a) the test set and (b) the training set.

37
M. Shahin and B. Ahmed
Fig. 12. 2D scatter plot of the t-SNE projection of the 26 attribute features of subset of the phonemes with and without dropout and MTL.
The attribute features used in training the OCSVM models were ex-
tracted from four different attribute detectors, DNN-Dout, DNN-Dout-BN,
DNN-MTL and DNN-Dout-BN, where BN refers to extracting the features
from the bottleneck layer rather than the output layer. Fig. 13(a) and
(b) show the frame-level performance of each phoneme-specific model
when using each of the aforementioned attribute features for the conso-
nants and vowels respectively.
The results show that using features extracted from the attribute de-
tectors trained with MTL criteria improved the performance of almost
all the OCSVM phoneme specific models as compared to when features
extracted from attribute detectors trained on a single task were used.
Overall, the consonants performed better than vowels with an average
F1 score of 0.88±0.05 compared to 0.86±0.04 for the vowels. The con-
sonants /sh/ and /y/ had the highest performance with a F1 score of
around 0.95, while the vowels /ah/ and /ih/ had the lowest perfor-
mance with 0.71 F1 score.
We then evaluated the OCSVM models on a phoneme level by testing
their performance in classifying the whole speech segment. The whole
phoneme was considered in-class if the majority of its frames were clas-
sified as in-class and out-of-class otherwise. In this experiment each
phoneme model was tested against samples from the same phoneme
and samples from all other phonemes in the test set and each model’s
FR and FA rates were computed respectively. For each phoneme we used
the model that achieved the best frame level F1 score with the valida-
38
Speech Communication 111 (2019) 29–43
Fig. 11. 2D scatter plot of the t-SNE projection of the
26 attribute features of subset of the phonemes.
tion set. The results are summarized in Table 4 along with the number
of samples from each phoneme in the test set.
4.3. Results on PV task
In these experiments, we evaluated the performance of the OCSVM
based classifiers in detecting pronunciation errors in native speech with
artificial errors and foreign accented and disordered speech with natural
pronunciation errors. In all the experiments we used a system trained
only on native speech with the parameters that achieved the best per-
formance on the validation set as explained in previous experiments.
In the first experiment, we generated artificial errors by manipu-
lating the labels of the native speakers test set (WSJ0 + TIMIT). This
was done to overcome the lack of accurate annotated mispronounced
data and provide a larger amount of data to better evaluate the sys-
tem (Zhao et al., 2012; Yoon et al., 2009; Witt and Young, 1997).
Kanters et al. (2009) showed that the behavior of the GOP algorithm
is almost the same on both real and artificial error datasets.
In order to simulate a real pronunciation error, the phonemes were
changed based on common mispronunciation mistakes made by speak-
ers of Scandinavian languages who learn English as a second language
according to (Smith, 2001). Table 5 summarizes these common errors.
The alterations are equally distributed over all possible mispronuncia-
tions of any specific phoneme. If phoneme i is the expected error of Ni
M. Shahin and B. Ahmed Speech Communication 111 (2019) 29–43

Fig. 13. The frame-level F1 score of the OCSVM models of the (a) consonants and (b) vowels when trained using features extracted from different architectures for
speech attribute detectors.

Table 4
The phoneme-level false-acceptance (FA) and false-rejection (FR) rates
of the OCSVM mode.

Ph N# FR (%) FA (%) Ph N# FR (%) FA (%)

aa 940 3.19 4.82 g 243 3.29 3.17

ae 623 7.04 6.95 hh 522 6.30 5.32
ah 3695 7.46 12.37 Jh 267 4.87 2.04
ao 306 3.94 3.17 k 1832 2.02 3.48
aw 20 4.17 2.94 l 1552 3.51 1.27
ay 576 2.11 2.74 m 1199 2.59 2.25
eh 1274 7.40 9.42 n 3431 4.65 5.59
er 1355 4.06 3.92 ng 332 5.42 4.45
ey 811 1.34 5.62 p 1479 5.92 4.33
ih 2613 12.60 12.71 r 1961 3.62 2.98
iy 1978 4.64 4.65 s 2403 2.75 2.51
ow 557 3.17 2.53 sh 451 1.55 4.40
oy 152 3.23 2.40 t 3181 8.62 9.75
uh 108 7.27 8.63 th 343 7.58 10.24
uw 508 5.47 4.45 v 803 5.73 3.76
b 693 2.16 5.62 w 602 2.99 2.30
ch 176 5.68 1.71 y 380 3.42 2.34
d 2108 5.68 1.71 z 1337 3.07 6.51
dh 759 5.67 8.39 zh 30 6.67 2.54
f 976 5.68 1.71

Table 5
Common pronunciation errors of Scandinavian speakers learn-
ing English.
Fig. 14. Phoneme-level comparison between the OCSVM and GOP based PV
Phone b ch d dh g jh th w z systems in terms of the false-acceptance (FA) and false-rejection (FR) rates when
Error p t t d k d s v s applied on the native English dataset with artificial errors.
Phone zh ae ah aw ey ih ow uw
Error sh eh uh ow ae iy uw aw

To demonstrate the effectiveness of our system in pronunciation ver-

phonemes, the occurrences of phoneme i in the test set were divided into ification, we compared our OCSVM algorithm with the DNN-GOP algo-
equal 𝑁𝑖 + 1 folds where Ni folds were replaced with the Ni phonemes, rithm. Fig. 14 shows the FA and FR rates of each phoneme using both
to simulate the pronunciation errors, and one fold was kept intact, to the OCSVM and DNN-GOP models. Overall, the OCSVM method outper-
represent the correct pronunciation of the phoneme i. forms the DNN-GOP algorithm in most of the phonemes.

39
M. Shahin and B. Ahmed Speech Communication 111 (2019) 29–43

Fig. 15. Comparison between the OCSVM and

GOP based PV when applied on native English
(WSJ0+TIMIT), the disordered speech (CAS) and
foreign-accented speech (GMU) datasets in terms
of the F1 score and false-acceptance (FA) and
false-rejection (FR) rates.

Fig. 16. A phoneme-level F1 score of (a) CAS and (b) GMU speech using both GOP and OCSVM methods.

The vowel /uw/ achieved the best performance with FA and FR rates
of 1.8% and 1% using the OCSVM method as opposed to 11.1% and
13.6% obtained with the GOP algorithm respectively. However, the GOP
discriminated between /zh/ and /sh/ better, where /sh/ is the common
mistake of /zh/ as in Table 5, with FA of 9.2% compared to 16% using
OCSVM algorithm. The vowels /ae/ and /ih/ and the consonant /z/ are
the most problematic phonemes with FA and FR between 25% and 30%
respectively for both the OCSVM and GOP models, where the actual
pronounced phonemes of the FA samples of these three phonemes were
/eh/, /iy/ and /s/ respectively.
In addition to the artificial error dataset, we evaluated the system
with two natural-error datasets, the CAS disordered speech and GMU
foreign-accented speech. Fig. 15, shows the FA and FR rates and the
F1 scores of the 3 data sets using our OCSVM method and the GOP Fig. 17. The breakdown of OCSVM performance of the GMU speech datasets
method. Our method improved the FA and FR rates obtained with the over different accents.
artificial error dataset, decreasing from around 26% and 29% respec-
tively with the GOP method to 19% and 17%, while with the CAS data
the FR reduced significantly from 40% using the GOP method to around GMU test sets, we see that both /b/ and /t/ maintained almost the same
26% when using OCSVM method. Both methods achieved similar FA F1 score, while /th/ degraded significantly from 0.89 to 0.73 with CAS
rates. Moreover, the OCSVM method achieved F1 score and FA and FR and GMU respectively.
rates of 0.80, 25% and 24% respectively when tested against the GMU The mispronounced phonemes most difficult to detect were the
foreign-accented data as opposed to 0.70, 38% and 30% obtained by the voiced fricatives /z/ and /v/ in the GMU speech test set. The common
GOP. mistakes in the pronunciation of these phonemes were replacements
Fig. 16(a) and (b) show a phoneme-level breakdown of the perfor- with their unvoiced versions of /s/ and /f/ respectively. A possible rea-
mance of the CAS and GMU speech using both GOP and OCSVM meth- son as to why the system failed to detect these mispronunciations could
ods. The mispronunciation detection of most of the phonemes was better be the noise level in the speech files recorded by volunteers with their
with our OCSVM method compared to the GOP method with some minor own personal recording equipment in the GMU archive.
exceptions such as /w/ and /b/ in the CAS test set and /p/ in the GMU Fig. 17 shows the average performance of our OCSVM system for
test set. The vowel /eh/ and the consonants /n/, /w/, /p/, /th/ and /t/ each accent of the GMU foreign-accented speech dataset. The Dutch and
achieved F1 score above or close to 0.9 in the CAS speech test set. On Arabic achieved higher average F1 scores of 0.83 and 0.79 respectively,
the other hand, the consonants /f/, /s/ and /t/ had F1 score greater than while the worst performance was obtained with the Farsi accent with
or almost 0.9. By looking at the common phonemes between CAS and an average F1 score of 0.67.

40
M. Shahin and B. Ahmed
5. Discussion and conclusions
In this paper we proposed a novel pronunciation verification ap-
proach that overcomes the need for annotated mispronounced data
to model pronunciation errors. Our approach is based upon anomaly
detection, where only correctly pronounced speech is used to train a
phoneme-specific acoustic model that can detect any deviation from the
correct pronunciation. We adopted the OCSVM classifier as our anomaly
detector which was fed by a set of speech attribute features derived from
a bank of DNN-based speech attribute detectors modeling the manners
and places of articulation. These attribute features perfectly describe the
pronunciation characteristics of each phoneme and hence are sensitive
to any pronunciation error.
As our system consists of two basic modules, speech attribute detec-
tion and phoneme-specific OCSVM modeling, we first optimized each
module separately to obtain the structure that achieves best perfor-
mance and then evaluated the whole system in pronunciation verifi-
cation. Two standard correctly pronounced speech corpora, namely the
TIMIT and WSJ, were utilized for training, validating and testing the
two modules, while pronunciation verification was evaluated using (1)
part of the correctly pronouncing speech corpora with artificial errors,
(2) the GMU foreign-accented speech corpus collected from non-native
English speakers and (3) the CAS children disordered speech corpus.
The DNN-based speech attribute detectors achieved an average ac-
curacy of 90% ± 2.7% when 26 different manners and places of artic-
ulation were utilized. These results showed that the DNN models over-
fit the training data. We therefore employed two different techniques
to overcome this problem, dropout and the Multi-Task Learning (MTL)
with phoneme classification as a secondary task. The combination of
these two algorithms improved the accuracy of the attributes to an av-
erage accuracy of 91.5% ± 2.5%. Our experiments demonstrated that
using MTL with phoneme classification as a secondary task increased
the ability of the speech attribute DNN classifiers to further discrimi-
nate between phonemes that shared the same attribute(s).
OCSVM models were trained and tuned for each specific phoneme.
Each speech frame was first converted to its corresponding speech at-
tribute feature vector of size 26 representing the existence probabil-
ity of each of the 26 adopted speech attributes. The results demon-
strated that using the OCSVM with speech attribute features is effective
in modeling the correct pronunciation of each phoneme and discrimi-
nates between frames belonging to the underlying phoneme (in-class),
and frames belonging to other phonemes (out-of-class) with average F1
scores of 0.88 ± 0.05 and 0.86 ± 0.04 for the consonants and vowels
respectively. The results also showed that the features extracted from
the speech attribute detectors trained with MTL achieved the best per-
formance across the majority of the phonemes.
Our results with the integrated PV system showed that our anomaly
detection approach outperforms the commonly used DNN-GOP algo-
rithm in all testing sets. Our approach achieved F1 scores of 0.84, 0.82
and 0.80 compared to 0.76, 0.71 and 0.70 obtained using the DNN-GOP
algorithm when applied on the native speech with artificial errors, the
GMU foreign-accented speech and the CAS disordered speech respec-
tively. The system was more effective with real errors than the artifi-
cially produced ones. This could be explained by the nature of the real
pronunciation error which in most cases is a distorted version of the tar-
get phoneme and not a complete replacement with another phoneme.
Real pronunciation errors are more challenging for confidence-score
based methods such as the DNN-GOP because it is very hard to deter-
mine a pre-defined threshold value that is able to discriminate between
the correct and distorted pronunciation.
The results showed that the speech attribute features can efficiently
model the phoneme articulatory characteristics. The anomaly detection
model trained using these features was sensitive to any deviation in the
modeled characteristics. More interestingly, the system is robust against
adult-child acoustic variations when the model was trained on adult
speech and tested on disordered children speech. Moreover, the train-
41
Speech Communication 111 (2019) 29–43
ing and testing data were recorded from different domains and environ-
ments demonstrating that the system is domain-independent and robust
against recording setups.
Dropout is a powerful regularization tool applied successfully on dif-
ferent applications, and speech attribute detection is no exception. Our
experiments showed clearly how dropout controlled the model overfit-
ting over the training set and improved the model generalization. On the
other hand, even though MTL had a minor impact on the performance
of the speech attribute detectors, it significantly improved the ability
of the attribute features to discriminate between phonemes by using
phoneme classification as a secondary task and therefore improved the
performance of the anomaly detection model. This demonstrated an ad-
ditional powerful benefit of using MTL, namely that it can be used to
improve the discriminability of the main task in the direction of the
secondary task.
Moreover, instead of representing each speech attribute with one
probability value from the softmax output layer of the DNN classifier,
an extended representation was extracted from a bottleneck layer lo-
cated before the last hidden layer. This increases the degrees of freedom
of the extracted features allowing variations among different phonemes
sharing same speech attribute model. However, the results showed that
only four consonants, namely /sh/, /y/, /zh/ and /dh/, and two vowels,
namely /ao/ and /uw/, benefitted from the bottleneck features, while
the rest achieved better performance when features were extracted from
the output of the softmax layer. A deeper analysis of the extracted fea-
tures and applying some sort of feature selection techniques may help
in taking advantage of the bottleneck features.
However, some phonemes still suffer from high FA and FR rates
reaching 30% for vowels such as /ih/ and /ae/. These results could
be improved by working on phoneme-specific feature selection of the
speech attribute features. Furthermore, employing a more sophisticated
anomaly detection approach can improve the sensitivity of the phoneme
model to pronunciation errors. Broader testing of the system on a wider
range of different languages and pronunciation verification domains is
also needed, such as in the second language learning domain.
In the future, we intend to focus on 1) improving the performance
of the speech attribute detectors by utilizing more speech corpora and
trying different DNN architectures, 2) carefully studying the speech at-
tribute features and selecting the most discriminative features for each
phoneme, 3) exploring other anomaly detection methods such as the
auto-encoder and LSTM. Moreover, to further validate the effectiveness
of our approach over other PV methods, we intend to conduct a com-
parison with a binary classification method which has proved to be the
most accurate if enough correct and incorrect data is available.
Declaration of Competing Interest
We wish to confirm that there are no known conflicts of interest as-
sociated with this publication and there has been no significant financial
support for this work that could have influenced its outcome.
Acknowledgments
This work was made possible by NPRP grant #[8-293-2-124] from
the Qatar National Research Fund (a member of Qatar Foundation). The
statements made herein are solely the responsibility of the authors.
References
Abdou, S.M., et al., 2006. Computer aided pronunciation learning system using speech
recognition techniques. Ninth International Conference on Spoken Language Process-
ing.
Al Hindi, A., Alsulaiman, M., Muhammad, G., Al-Kahtani, S., 2014. Automatic pronunci-
ation error detection of nonnative Arabic Speech. In: Computer Systems and Applica-
tions (AICCSA), 2014 IEEE/ACS 11th International Conference on. IEEE, pp. 190–197.
Al-Barhamtoshy, H., Jambi, K., Al-Jedaibi, W., Motaweh, D., Abdou, S., Rashwan, M.,
2014. Speak Correct: phonetic Editor Approach. Life Sci. J. 11 (8).
Baxter, J., 1997. A Bayesian/information theoretic model of learning to learn via multiple
task sampling. Mach. Learn. 28 (1), 7–39.
M. Shahin and B. Ahmed
Behravan, H., Hautamauki, V., Siniscalchi, S.M., Kinnunen, T., Lee, C.-H., 2014. Introduc-
ing attribute features to foreign accent recognition. In: Acoustics, Speech and Signal
Processing (ICASSP), 2014 IEEE International Conference on. IEEE, pp. 5332–5336.
Bonaventura, P., Howarth, P., Menzel, W., 2000. Phonetic annotation of a non-native
speech corpus. In: Proceedings International Workshop on Integrating Speech Tech-
nology in the (Language) Learning and Assistive Interface. InStil, pp. 10–17.
Bounsiar, A., Madden, M.G., 2014. Kernels for one-class support vector machines. In: In-
formation Science and Applications (ICISA), 2014 International Conference on. IEEE,
pp. 1–4.
C. M. University. (2014). CMUdict. Available: http://www.speech.cs.cmu.edu/cgi-
bin/cmudict.
Chandola, V., Banerjee, A., Kumar, V., 2009. Anomaly detection: a survey. ACM Comput.
Surveys (CSUR) 41 (3), 15.
Collobert, R., Weston, J., 2008. A unified architecture for natural language processing:
deep neural networks with multitask learning. In: Proceedings of the 25th interna-
tional conference on Machine learning. ACM, pp. 160–167.
van Doremalen, J., Cucchiarini, C., Strik, H., 2009. Automatic detection of vowel pronun-
ciation errors using multiple information sources. In: Automatic Speech Recognition
& Understanding, 2009. ASRU 2009. IEEE Workshop on. IEEE, pp. 580–585.
Duan, R., Kawahara, T., Dantsujii, M., Zhang, J., 2016. Pronunciation error detection using
DNN articulatory model based on multi-lingual and multi-task learning. In: Chinese
Spoken Language Processing (ISCSLP), 2016 10th International Symposium on. IEEE,
pp. 1–5.
Elaraby, M.S., Abdallah, M., Abdou, S., Rashwan, M., 2016. A deep neural networks (DNN)
based models for a computer aided pronunciation learning system. In: International
Conference on Speech and Computer. Springer, pp. 51–58.
Ferber, J., 1999. Multi-agent Systems: An Introduction to Distributed Artificial Intelli-
gence. Addison-Wesley Reading.
Franco, H., Ferrer, L., Bratt, H., 2014. Adaptive and discriminative modeling for improved
mispronunciation detection. In: Acoustics, Speech and Signal Processing (ICASSP),
2014 IEEE International Conference on. IEEE, pp. 7709–7713.
Franco, H., Neumeyer, L., Ramos, M., Bratt, H., 1999. Automatic detection of phone-level
mispronunciation for language learning. Sixth European Conference on Speech Com-
munication and Technology.
Garofolo, J.S., Lamel, L.F., Fisher, W.M., Fiscus, J.G., Pallett, D.S., 1993. NASA STI/Recon
Technical Report n. NASA STI/Recon Technical Report n, 93.
Glorot, X., Bengio, Y., 2010. Understanding the difficulty of training deep feedforward
neural networks. In: Proceedings of the thirteenth international conference on artifi-
cial intelligence and statistics, pp. 249–256.
Harrison, A.M., Lo, W.-K., Qian, X.-J., Meng, H., 2009. Implementation of an extended
recognition network for mispronunciation detection and diagnosis in computer-as-
sisted pronunciation training. International Workshop on Speech and Language Tech-
nology in Education.
Hu, W., Qian, Y., Soong, F.K., 2013. A new DNN-based high quality pronunciation evalu-
ation for computer-aided language learning (CALL). In: Interspeech, pp. 1886–1890.
Hu, W., Qian, Y., Soong, F.K., 2014. A new neural network based logistic regression clas-
sifier for improving mispronunciation detection of L2 language learners. In: Chinese
Spoken Language Processing (ISCSLP), 2014 9th International Symposium on. IEEE,
pp. 245–249.
Huang, J.-T., Li, J., Yu, D., Deng, L., Gong, Y., 2013. Cross-language knowledge trans-
fer using multilingual deep neural network with shared hidden layers. In: Acoustics,
Speech and Signal Processing (ICASSP), 2013 IEEE International Conference on. IEEE,
pp. 7304–7308.
Jo, C.-H., Kawahara, T., Doshita, S., Dantsuji, M., 1998. Automatic pronunciation error
detection and guidance for foreign language learning. Fifth International Conference
on Spoken Language Processing.
Kanters, S., Cucchiarini, C., Strik, H., 2009. The goodness of pronunciation algorithm:
a detailed performance study. presented at the Speech and Language Technology in
Education (SLaTE2009).
Khan, S.S., Madden, M.G., 2014. One-class classification: taxonomy of study and review
of techniques. Knowl. Eng. Rev. 29 (3), 345–374.
Kim, Y., Franco, H., Neumeyer, L., 1997. Automatic pronunciation scoring of specific
phone segments for language instruction. Fifth European Conference on Speech Com-
munication and Technology.
Lee, C.-H., Siniscalchi, S.M., 2013. An information-extraction approach to speech process-
ing: analysis, detection, verification, and recognition. Proc. IEEE 101 (5), 1089–1115.
Li, J., Zhang, T., Luo, W., Yang, J., Yuan, X.-T., Zhang, J., 2017a. Sparseness analysis in
the pretraining of deep neural networks. IEEE Tran. Neural Netw. Learn. Syst. 28 (6),
1425–1438.
Li, W., Chen, N.F., Siniscalchi, S.M., Lee, C.-H., 2017b. Improving mispronunciation de-
tection for non-native learners with multisource information and LSTM-based deep
models. In: Proceeding. Interspeech 2017, pp. 2759–2763.
Li, K., Qian, X., Meng, H., 2017c. Mispronunciation detection and diagnosis in L2 English
speech using multidistribution deep neural networks. IEEE/ACM Trans. Audio Speech
Lang. Process. 25 (1), 193–207. doi:10.1109/TASLP.2016.2621675.
Lo, W.-K., Zhang, S., Meng, H., 2010. Automatic derivation of phonological rules for
mispronunciation detection in a computer-assisted pronunciation training system.
Eleventh Annual Conference of the International Speech Communication Association.
Luo, D., Minematsu, N., Yamauchi, Y., Hirose, K., 2009. Analysis and comparison of au-
tomatic language proficiency assessment between shadowed sentences and read sen-
tences. International Workshop on Speech and Language Technology in Education.
Maaten, L.V.d., Hinton, G., 2008. Visualizing data using t-SNE. J.Mach. Learn. Res. 9
(Nov), 2579–2605.
Maier, A., et al., 2009. Automatic detection of articulation disorders in children with cleft
lip and palate. J. Acoust. Soc. Am. 126 (5), 2589–2602.
42
Speech Communication 111 (2019) 29–43
Mak, B., et al., 2003. PLASER: pronunciation learning via automatic speech recognition.
In: Proceedings of the HLT-NAACL 03 workshop on Building educational applica-
tions using natural language processing, 2. Association for Computational Linguistics,
pp. 23–29.
Mohamed, A., Hinton, G., Penn, G., 2012a. Understanding how deep belief networks per-
form acoustic modelling. In: Acoustics, Speech and Signal Processing (ICASSP), 2012
IEEE International Conference on. IEEE, pp. 4273–4276.
Mohamed, A.-R., Dahl, G.E., Hinton, G., 2012b. Acoustic modeling using deep belief net-
works. IEEE Trans. Audio Speech, Language Process. 20 (1), 14–22.
Neri, A., Cucchiarini, C., Strik, H., 2006. ASR-based corrective feedback on pronunciation:
does it really work? Ninth International Conference on Spoken Language Processing.
Neri, A., Mich, O., Gerosa, M., Giuliani, D., 2008. The effectiveness of computer assisted
pronunciation training for foreign language learning by children. Comput. Assist.
Lang. Learn. 21 (5), 393–408.
Paul, D.B., Baker, J.M., 1992. The design for the Wall Street Journal-based CSR corpus.
In: Proceedings of the workshop on Speech and Natural Language. Association for
Computational Linguistics, pp. 357–362.
Pellegrini, T., Fontan, L., Mauclair, J., Farinas, J., Robert, M., 2014. The goodness of
pronunciation algorithm applied to disordered speech. Fifteenth Annual Conference
of the International Speech Communication Association.
Ruder, S., An overview of multi-task learning in deep neural networks, arXiv:1706.05098,
2017.
Ryu, H., Chung, M., 2017. Mispronunciation Diagnosis of L2 English at Articulatory Level
Using Articulatory Goodness-Of-Pronunciation Features. In: Proc. 7th ISCA Workshop
on Speech and Language Technology in Education, pp. 65–70.
Saz, O., Yin, S.-C., Lleida, E., Rose, R., Vaquero, C., Rodríguez, W.R., 2009. Tools and
technologies for computer-aided speech and language therapy. Speech Commun. 51
(10), 948–967.
Schölkopf, B., Platt, J.C., Shawe-Taylor, J., Smola, A.J., Williamson, R.C., 2001. Estimating
the support of a high-dimensional distribution. Neural Comput. 13 (7), 1443–1471.
Shahin, M., et al., 2015. Tabby talks: an automated tool for the assessment of childhood
apraxia of speech. Speech Commun. 70, 49–64.
Shahin, M., Ahmed, B., McKechnie, J., Ballard, K., Gutierrez-Osuna, R., 2014. A compar-
ison of gmm-hmm and dnn-hmm based pronunciation verification techniques for use
in the assessment of childhood apraxia of speech. Fifteenth Annual Conference of the
International Speech Communication Association.
Sim, K.C., 2009. A phone verification approach to pronunciation quality assessment for
spoken language learning. In: Proceedings: APSIPA ASC 2009: Asia-Pacific Signal and
Information Processing Association, 2009 Annual Summit and Conference. Interna-
tional Organizing Committee, pp. 619–622. Asia-Pacific Signal and Information Pro-
cessing Association, 2009 Annual Summit and Conference.
Smith, B., 2001. Learner English: A Teacher’s Guide to Interference and Other Problems.
Ernst Klett Sprachen.
Soong, F.K., Lo, W.-K., Nakamura, S., 2004. Generalized word posterior probability
(GWPP) for measuring reliability of recognized words. In: Proceeding SWIM2004,
pp. 13–16.
Srivastava, N., Hinton, G., Krizhevsky, A., Sutskever, I., Salakhutdinov, R., 2014. Dropout:
a simple way to prevent neural networks from overfitting. J. Mach. Learn. Res. 15 (1),
1929–1958.
Stouten, F., Martens, J.-P., 2006. On the use of phonological features for pronunciation
scoring. In: Acoustics, Speech and Signal Processing, 2006. ICASSP 2006 Proceedings.
2006 IEEE International Conference on, 1. IEEE pp. I-I.
Strik, H., Truong, K.P., d. Wet, F., Cucchiarini, C., 2007. Comparing classifiers for pronun-
ciation error detection. Eighth Annual Conference of the International Speech Com-
munication Association.
Truong, K., Neri, A., Cucchiarini, C., Strik, H., 2004. Automatic pronunciation error de-
tection: an acoustic-phonetic approach. InSTIL/ICALL Symposium 2004.
Wang, H., Zhao, Y., Xu, Y., Xu, X., Suo, X., Ji, Q., 2014. Cross-language speech at-
tribute detection and phone recognition for Tibetan using deep learning. In: Chinese
Spoken Language Processing (ISCSLP), 2014 9th International Symposium on. IEEE,
pp. 474–477.
Wang, Y.-B., Lee, L.-S., 2012. Improved approaches of modeling and detecting error pat-
terns with empirical analysis for computer-aided pronunciation training. In: Acoustics,
Speech and Signal Processing (ICASSP), 2012 IEEE International Conference on. IEEE,
pp. 5049–5052.
Wei, S., Hu, G., Hu, Y., Wang, R.-H., 2009. A new method for mispronunciation detection
using support vector machine based on pronunciation space models. Speech Commun.
51 (10), 896–905.
Weinberger, S., 2015. Speech Accent Archive. George Mason University Online:
http://accent.gmu.edu.
de Wet, F., Van der Walt, C., Niesler, T., 2009. Automatic assessment of oral language
proficiency and listening comprehension. Speech Commun. 51 (10), 864–874.
Witt, S.M., Young, S.J., 2000. Phone-level pronunciation scoring and assessment for in-
teractive language learning. Speech Commun. 30 (2–3), 95–108.
Witt, S., Young, S.J., 1997. Language learning based on non-native speech recognition.
Fifth European Conference on Speech Communication and Technology.
Xu, Y., Du, J., Dai, L.-R., Lee, C.-H., 2015. A regression approach to speech enhance-
ment based on deep neural networks. IEEE/ACM Trans. Audio, Speech Lang. Process.
(TASLP) 23 (1), 7–19.
Yan, K., Gong, S., 2011. Pronunciation proficiency evaluation based on discriminatively
refined acoustic models. Int. J. Info. Technol. Comput. Sci. 3 (2), 17–23.
Yoon, S.-Y., Hasegawa-Johnson, M., Sproat, R., 2009. Automated pronunciation scoring
using confidence scoring and landmark-based SVM. Tenth Annual Conference of the
International Speech Communication Association.
M. Shahin and B. Ahmed
Yu, D., Siniscalchi, S.M., Deng, L., Lee, C.-H., 2012. Boosting attribute and phone estima-
tion accuracies with deep neural networks for detection-based speech recognition. In:
Acoustics, Speech and Signal Processing (ICASSP), 2012 IEEE International Confer-
ence on. IEEE, pp. 4169–4172.
Zhang, F., Huang, C., Soong, F.K., Chu, M., Wang, R., 2008. Automatic mispronunciation
detection for Mandarin. In: Acoustics, Speech and Signal Processing, 2008. ICASSP
2008. IEEE International Conference on. IEEE, pp. 5077–5080.
Zhang, S., Bao, Y., Zhou, P., Jiang, H., Dai, L., 2014a. Improving deep neural networks
for LVCSR using dropout and shrinking structure. In: Acoustics, Speech and Signal
Processing (ICASSP), 2014 IEEE International Conference on. IEEE, pp. 6849–6853.
43
Speech Communication 111 (2019) 29–43
Zhang, Z., Luo, P., Loy, C.C., Tang, X., 2014b. Facial landmark detection by deep multi-task
learning. In: European Conference on Computer Vision. Springer, pp. 94–108.
Zhao, T., Hoshino, A., Suzuki, M., Minematsu, N., Hirose, K., 2012. Automatic Chinese
pronunciation error detection using SVM trained with structural features. In: Spoken
Language Technology Workshop (SLT), 2012 IEEE. IEEE, pp. 473–478.
Zheng, J., Huang, C., Chu, M., Soong, F.K., Ye, W.-P., 2007. Generalized segment posterior
probability for automatic Mandarin pronunciation evaluation. Acoustics, Speech and
Signal Processing, 2007. ICASSP 2007. IEEE International Conference on, 4. IEEE pp.
IV-201–IV-204.
