Fullset Logging System

www.RenheSun.com
www.geovista.cn
 Contents

Combo Logging System-Memory (ComboLog-M)

Slim Combo Logging System-Memory (ComboLog-SM)
Combo Logging System (ComboLog)
Slim Hostile Logging System (HostileLog)
Thru-Pipe Logging System (ThruLog) (CBL-M)

www.RenheSun.com
www.geovista.cn
 Combo Logging System-Memory (ComboLog-M)
Applications
Reservoir delineation
Hydrocarbon saturation
determination and imaging
Movable hydrocarbon
determination
Location of porous and permeable
zones
Gas detection
Lithology determination
Well-to-well correlation
Thin-bed analysis
Benefits
Less rathole needed for the shorter
length, lowering drilling time and
cost
More reliable performance for
reduced downtime, which saves rig
time
Better quality logs, more data and
higher resolution, revealing
hard-to-find pay zones
Fifty percent reduction in time
spent on location, significantly
lowering operating costs
Short-radius wells readily logged
Features
Overall length greatly reduced
through the use of integrated
sensors and reengineering
Speed correction
Integrated Rxo measurement
Depth matching and borehole
correction
Introduction
ComboLog is more cost effective to run because it requires significantly less rig
time. The ComboLog system is less than half as long as conventional tools and
weighs about half as much, yet it gives you better, quicker and more accurate
answers—both in memory and real time.
When ComboLog works in memory mode, it can provide wireline-quality
openhole logs without wireline. The tool string is powered by a battery sub, and
data are stored in nonvolatile memory chips housed in a memory sub. Log values
are recorded in time-base and converted to depth logs when the string is
recovered at the surface. Using drill pipe conveyance methods, ComboLog
enables fast and efficient logging in highly deviated wells and in horizontal wells
with challenging hole conditions.
General Specifications
Max Temperature 350°F (175°C)
Max Pressure 20000 psi (137.9 MPa)
Tension 68000 lb
OD 3.62 in. (92 mm)
Maximum logging speed 18 m/min
Continuous working time ＞50 h (One Battery Packs)
Data storage capacity 8 G bytes
DOWNHOLE TOOLS
Pipe Adapter (for 3-1/2’ and 5’ drillpipe)
Battery Power Sub (BPS)
Casing Collar Locator (CCL)
Memory/ Spectralog /Orientation Tool (MSO)
Four Arms Centralizer Sub (FCS)
Acoustic Tool-Memory (ACT-M)
Hexapod Arms Caliper- Memory (HAC-M)
Compensated Neutron Tool-Memory (CNT-M)
Litho-Density Logging Tool-Memory (ZDT-M)
Array Laterolog Tool (ALT)
Array Induction Tool-Memory (AIT-M)
SURFACE SYSTEM
Memory Control Box (MCB)
Laptop with PIDAS Software (with softdog)
Data Acquisition Panel-Memory (DAP-M)
www.RenheSun.com
www.geovista.cn
 Combo Logging System-Memory (ComboLog-M)

For 5’
drillpipe

For 3-1/2’
drillpipe
CCL

Pipe Adapter

TTR

SWS

BPS MSO FCS ACT-M HAC-M CNT-M ZDT-M ALT AIT-M

www.RenheSun.com
www.geovista.cn
 Slim Combo Logging System-Memory
(ComboLog-SM)

Applications Introduction
In-situ formation resistivity (Rt) with
No needed E-line coiled tubing, the ComboLog-SM delivers the same,
array induction high-quality data you would expect to get from conventional tools, but with a
Formation evaluation and lithology
much smaller 2.875-in. diameter in hostile envirement. Every Slim Combo
identification logging tool is fully characterized, which means that you never have to choose
Borehole geometry
between data fidelity and tool size. These tools provide the accuracy of traditional
High wellbore pressures and wireline logging. The Slim combo Logging system offers multiple conveyance
temperatures
options. Data can be acquired in real time when run on wireline, or it can be
deployed by coiled tubing or drillpipe in memory mode. When it conveyed by
drillpipe, it can be released by mechanical ball method or mud-pulse control
method.
With Slim Combo logging services, you can easily achieve reliable logging in
challenging applications with data quality you expect from conventional tools.Our
Slim Combo logging tools are available for holes with diameters up to 16 in. They
are environmentally corrected and fully characterized for:

 Weight
 T 


General Specifications
Max Temperature 350°F (175°C)
Max Pressure 20000 psi (137.9 MPa)
Tool Diameter 2.875 in. (73 mm)
Minimum Hole Diameter 4 in. (101.6 mm)
Maximum Hole Diameter 16 in. (406 mm)
Power Requirements:
Battery Lithium battery 10 cells
36 Vdc (Nominal)
Wireline 36 Vdc

DOWNHOLE TOOLS
Slim Temperature/Tension/Mud Resistivity Tool-Slim (TTR-S)
Casing Collar Locator-Slim (CCL-S)
Slim Data transfer/SpectralogTool (TSO-SM)
Slim Compensated Neutron Tool-Slim Memory (CNT-SM)
Slim Litho-Density Logging Tool-Slim Memory (ZDT-SM)
Slim Acoustic Tool-Slim Memory (ACT-SM)
Slim Dual Lateral log Tool-Slim Memory (DLT-SM)
Slim Micro Spherical Focused Laterolog Tool-Slim Memory (MSF-SM)
Slim Array Induction Tool-Slim Memory (AIT-SM)

www.RenheSun.com
www.geovista.cn
 Slim Combo Logging System-Memory
(ComboLog-SM)

Digital Control Releaser Mechanical Releaser

Mechanical Releaser
Upper Hanger

Adjuster Sub-1

ISS-S

Protective Casing SWS-S

MSO
ZDT-S
Adjuster Sub-2
DLT-S

CCL-S

AIT-S

Lower Hanger

TTR-S CNT-S FCS-S ACT-S

MSF-S
www.RenheSun.com
www.geovista.cn
 Combo Logging System (ComboLog)
Applications
Reservoir delineation
Hydrocarbon saturation
determination and imaging
Movable hydrocarbon
determination
Location of porous and permeable
zones
Gas detection
Lithology determination
Well-to-well correlation
Thin-bed analysis
Benefits
Less rathole needed for the shorter
length, lowering drilling time and
cost
More reliable performance for
reduced downtime, which saves rig
time
Better quality logs, more data and
higher resolution, revealing
hard-to-find pay zones
Fifty percent reduction in time
spent on location, significantly
lowering operating costs
Short-radius wells readily logged
Features
Overall length greatly reduced
through the use of integrated
sensors and reengineering
Extremely robust electronic
packaging and mechanical design
All components built to rigorous
LWD shock standards
Speed correction
Integrated Rxo measurement
Depth matching and borehole
correction
Introduction
Combo technology is a revolutionary reengineering of conventional logging. The
ComboLog Compared with the predecessor, Combo logging is about twice as
fast, gives you better answers and it is more cost effective to run because it
requires significantly less rig time. Reduced set-up and calibration time, and
faster turnaround on wellsite processing all contribute to increased efficiency.
The Combo system is less than half as long as predecessor and weighs about
half as much, yet it gives you better, quicker and more accurate answers—in
real time. ComboLog designed more shorter (17 m) and more slim (3.625 in.),
can used in 4.5 in. hole size and it can fullest logging with coiled tubing in one
run.
General Specifications
Max Temperature 350°F (175°C)
Max Pressure 20000 psi (137.9 MPa)
Tension 68000 lb
OD 3.62 in. (92 mm)
Maximum logging speed 18 m/min
General Specifications
Casing Collar Locator (CCL)
Digital Data Transfer/Spectralog/Orientation Tool (TSO)
Litho-Density Logging Tool-Combo (ZDT-C)
Litho-Density Logging Tool-Integrated (ZDT-I)
Insulation Sub-Combo (ISS-C)
Four Arms CentralizerSub (FCS)
Acoustic Tool-Combo (ACT-C)
Dual Laterolog Tool-Combo (DLT-C)
Dual Laterolog Tool-Power (DLT-P)
Micro Spherical Focused Laterolog
Tool-Integrated (MSF-I)
Array Induction Tool-Combo (AIT-C)
www.RenheSun.com
www.geovista.cn
 Slim Hostile Logging System (HostileLog)

Applications Introduction
HostileLog has internal sensors that provide quality control data on critical
In-situ formation resistivity (Rt) with
operational characteristics even in prolonged high temperature and high pressure
array induction well conditions where temperature and pressure could approach the 435oF
Formation evaluation and lithology (220oC)/30000 psi (207 MPa) limit of a tool string. And the diameter is 79 mm.
identification
Borehole geometry
High wellbore pressures and
temperatures

General Specifications
Maximum Temperature 430oF (220oC)
Maximum Pressure 30,000 psi (207 MPa)
Diameter 3.125 in. (79.4 mm)
Maximum Hole Diameter 16 in. (406.4 mm)
Minimum Hole Diameter 4 in.(101.6 mm)
Maximum Logging Speed 18 m/min

DOWNHOLE TOOLS
Cablehead-Slim (CHS)
Temperature/Tension/Mud Resistivity Tool-Slim (TTR-S)
Casing Collar Locator-Slim (CCL-S)
Digital Data Transfer/Spectralog/Orientation Tool-Slim (TSO-S)
Four Arms Caliper-Slim (FAC-S)
Acoustic Tool-Slim (ACT-S)
Dual Lateral Log Tool-Slim (DLT-S)
Micro Spherical Focused Laterolog Tool-Slim (MSF-S)
Compensated Neutron Tool-Slim (CNT-S)
Litho-Density Logging Tool-Slim (ZDT-S)
Mass Isolator Sub-Slim (MIS-S)
Array Induction Tool-Slim (AIT-S)
Eight Laterolog Tool-Slim (ELT-S)

www.RenheSun.com
www.geovista.cn
 Thru-Pipe Logging System (ThruLog) (CBL-M)
Applications
Evaluation of cement quality
Determination of zone isolation
Location of cement top
Introduction
The CBL-M is a six sectors acoustic logging tool with 45 mm OD, it evaluates
cement bond integrity. In addition to measures of the amplitude of sonic signal
passing along the casing, the CBL-M radial receiver generates a map of the
cement.
The CBL-M is equipped with one transmitter and two sensors constructed of
piezoelectric crystals.
The Near receiver, located 3’ from the transmitter, is constructed of a
6-sector radial receiver. Each sector provides bond data covering a 60o section
of casing. The primary amplitude is constructed from radial signals at the near
receiver. The far receiver, located 5’ from the transmitter, generates a Variable
Density Log (VDL).
The CBL-M deploys in deviated/horizontal holes, is Memory capable. It can be
conveyed by ThruPipe. It uses mud pump pressure to be delivered. It slotted
sleeve technology imparts sound isolation, rigidity and tool strength. The tool is
comprised of corrosion resistant materials throughout.
Specifications
Maximum Temperature 350°F (175°C)
Maximum Pressure 20,000 psi
Minimum Hole Diameter 3.5 in.
Maximum Hole Diameter 7.5 in.
Tool Diameter 45 mm
Make-up Length 9.93 ft (3.03 m)
Shipping Length 10.27 ft (3.13 m)
Weight 18.1 kg (40 lbs)
Supply Voltage 36 Vdc
Power/Current 50 mA
Transmitters/Receivers Piezoelectric crystal
Signal Output 3 ft amplitude, 5 ft VDL and a
cement quality map
generated by the calibrated
6-segment receiver array
Maximum Logging Speed 21 m/min
Borehole Environment Fluid Media (i.e., brine, oil, fresh
water, drilling mud)
