Gasket

Selection
Materials / galvanic corrosion
To avoid galvanic corrosion it is important that the potential difference between the joined materials is not too high.
The difference in voltage between any two materials is an indication of their compatibility and the following criteria
are commonly used:
- Harsh environment (exposure to salt spray/weathering) no more than 0.3 volts
- Benign environment (indoors, salt-free condensation only) no more than 0.5

Material Volts Amucor Ultra Soft Tinned

shield shield/Monel copper
Zinc die-casting alloy -
1.10
Zinc plating on steel, chromate passivated -
1.05
Cadmium plating on steel -
0.80
Aluminium, wrought, cast A1 -
0.75
Iron and steel: not corrosion resisting -
0.70
Aluminium alloy/Amucor -
0.65
Duralumin -
0.60
Tin plate (T.C.S.) -
0.50
Tin plating on steel -
0.45
Chromium plating on nickel plated steel -
0.45
Iron and steel: corrosion resisting, 12% Cr -
0.45
Iron and steel: corrosion resisting, high Cr -
0.35
Copper and its alloys, conductive fabric -
0.25
Nickel-copper alloys, incl. Monel -
0.25
Silver 0
Carbon (colloidal graphite in acetone) + 0.10
Gold + 0.15
Platinum + 0.15

indicative gasket selection graphic Type of gasket /

dimension
weak

for customer-specific gaskets,

contact our product specialists
flat sheets

Warranty
All Holland Shielding Systems products are
continuously checked during the manufacturing
rigidity of the construction

process. Therefore all our products can be

V-shape gaskets
considered quality products, free of
Ultra Soft Shield 7400 manufacturing errors.
single flanged

Amucor shield 6800 PU

fo The technical data of our products are based
edges

O-profiles am on research and should only be regarded as a

co 9x
re 9m guideline for the different applications. Due to
m
the wide range of products and the large
9x variety of applications the technical data are
PV

6m
moulded and double flanged

m never to be interpreted as a guarantee.

neop
edges

fo
am

It is the buyer’s responsibility to test whether

solid O-profile

rene

co

9x the product meets the desired requirements.

3m
re

m
foam
machined parts

In the event that, unexpectedly, defects should

core

10 6

9x 9x 9x be found in our products, Holland Shielding

6x1

8x

3
8x

8x

6m
x1 m

mm 8m
3m

m m Systems will investigate and replace these

rigid

mm

mm

m
m
m
m
m

products as soon as possible. Holland

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 Shielding Systems cannot be held responsible
2 distance between fixings (m) for any delays that might ensue.
Index
page

3
 Amucor Shield
68OO

For panels
and screwed
applications.
With and without
self adhesive strip

Amucor Shield 6800 is an economical HF gasket

which can be supplied in a wide range of dimensions.
It is very effective in combination with zinc-plated
steel and aluminium constructions.

All gaskets can be provided with a (conductive)

self-adhesive strip.
Amucor Shield 6800 consists of a neoprene or
PVC foam core covered with reinforced foil, based on
an Amucor alloy. This guarantees excellent shielding
performance and very great strength.
For special applications, different foam cores
and conductive foils and fabrics are available.
Options
• cut into accurate lengths
• can be made die cut or frame
• combination with water seal
• UL94V-0 flame retardant foam core
• chemical resistant rubbers like EPDM
• silicone sponge for high temperatures up to 220 o C
• different conductive foils and fabrics

Benefits
• self-adhesive EMC gasket
• easy to fit, to cut with a pair of scissors
• good water resistance
• gasket can be die-cut (screw holes)
• roll length up to 50, 100, 250 or 1000 m
• high shielding performance
• low closure force
• EXTREMELY STRONG
4 • deflection 50%
Amucor Shield
68OO
Tape Specification
01 : standard self-adhesive placed in the middle Amucor Shield 6800 on a honeycomb
02 : without self-adhesive (page 18 & 19)
03 : with conductive self-adhesive
06 : standard self-adhesive, asymmetrical
07 : standard self-adhesive placed on the side

Foam Specification
N : standard neoprene foam
E : EPDM foam core
P : low closure force PVC foam, slow recovery
F : flame retardant UL94V-0 foam

Ordering Information
Please specify the dimension code from the
table below, followed by the code for the tapes
and the code for the foam core.

Example
Amucor Shield 6800, 8 x 2 mm, standard
self-adhesive non-conductive placed in
the middle, standard neoprene foam core:
6882- 01- N

width X

foam core height Y

self-adhesive
Dimensions
Width X (mm)
Height 2 3 4 5 6 7 8 10 12 15 18 20 25 32 50
Y (mm) 1 6821 6831 6841 6851 6861 6871 6881 68101 68121 68151 68181 68201 68251 68321 68501
2 6822 6832 6842 6852 6862 6872 6882 68102 68122 68152 68182 68202 68252 68322 68502
3 6833 6843 6853 6863 6873 6883 68103 68123 68153 68183 68203 68253 68323 68503
4 6844 6854 6864 6874 6884 68104 68124 68154 68184 68204 68254 68324 68504
5 6855 6865 6875 6885 68105 68125 68155 68185 68205 68255 68325 68505
6 6866 6876 6886 68106 68126 68156 68186 68206 68256 68326 68506
8 6878 6888 68108 68128 68158 68188 68208 68258 68328 68508
10 681010 681210 681510 681810 682010 682510 683210 685010
12 681212 681512 681812 682012 682512 683212 685012

Item numbers in bold are 98% stock items. Other dimensions on request.

Shielding Performance Mechanical proporties

12 0.5
Frequency Mode Screening neoprene
10 0.4
Hz dB
el. resistance (Ohm)

8
pressure (N/cm 2)

1M E 121 Shielding 0.3

effectiveness 6 PVC
10M E 110 depends on 0.2
100M E 103 surface, 4
shape of gaskets 0.1
400M E 98 and material 2
used. 0 0
1G P 92
0 10 20 30 40 50 60 70
See Guarantee compression (%) 5
 Ultra Soft
Shield 74OO

Very low closure force to prevent bending

of doors, lids and panels

Ultra Soft Shield 7400 is an HF shielding gasket

with high shielding performance and extremely low
closure force. This prevents deflection of doors/parts,
which improves shielding effectiveness.

The core consists of a high-grade polyurethane

foam core with a maximum compression of 80%,
which distinguishes Ultra Soft Shield 7400 from other
commonly used shielding materials.

Ultra Soft Shield 7400 is covered with a highly

conductive and wear & tear resistant metallized fabric.

Different foam cores and conductive foils and

fabrics are available for special application.

Shielding Performance Mechanical proporties

Frequency Mode Screening 60 0.5
PVC
Hz dB 50 0.4
el. resistance (Ohm)

40
pressure (N/cm 2)

1M E 115 Shielding
0.3
effectiveness
10M E 108 depends on
30
0.2
100M E 102 surface, 20
shape of gaskets PU
400M E 92 10 0.1
and material
used.
1G P 90 0 0
0 10 20 30 40 50 60 70 80
6 See Guarantee compression (%)
Ultra Soft
Shield 74OO
Benefits
• deflection up to 80% Round, half-round, D-section and
• very low closure force reactangular shapes
• very high electrical conductivity
• high shielding performance
• roll length: 50, 100, 250 or 1000 m
• easy to fit, self-adhesive
• high abrasion resistance
• tools required: a pair of scissors

Options
• cut into accurate lengths
• combination with water seal
• UL94V-0 flame retardant foam core
• chemical resistant rubbers like EPDM
• silicone sponge for high
temperatures up to 220 o C
• different conductive foils and fabrics
width X

height Y
Dimensions self-adhesive

Width X (mm)
Height 4 5 6 9 10 12 15 18 20 25
Y 3 7443 7453 7463 7493 74103 74123 74153 74183 74203 74253
(mm) 4 7444 7454 7464 7494 74104 74124 74154 74184 74204 74254
6 7466 7496 74106 74126 74156 74186 74206 74256
8 7488 74108 74128 74158 74188 74208 74258
9 7499 74109 74129 74159 74189 74209 74259
10 741010 741210 741510 741810 742010 742510
12 741212 741512 741812 742012 742512
15 741515 741815 742015 742515
18 741818 742018 742518
20 742020 742520
25 742525
Item numbers in bold are 98% stock items. Other dimensions on request.

EPDM rubber 740072 740068 740058 740064 740076 740051

Y
X
Y x X mm 2 x 4 mm 3 x 6 mm 4 x 8 mm 8 x 12 mm 10 x 12 mm 16 x 20 mm
Y x X inch .079" x .157" .118" x .236" .157" x .315" .315" x .472" .394" x .472" .630" x .787"

Tape Specification Ordering Information

01 : standard self-adhesive placed in the middle Please specify the dimension code from the table
02 : without self-adhesive above, followed by the code for the tape and the
03 : with conductive self-adhesive code for the foam core
06 : standard self-adhesive, asymmetrical
Example
Ultra Soft Shield 7400, 9 x 6 mm, standard
Foam Specification non-conductive self-adhesive, placed in the middle,
P : standard polyurethane foam standard polyurethane foam core:
F : flame retardant UL94V-0 foam 7496-01- P 7
 Standard Shield
7OOO
Benefits
• self-adhesive EMC gasket
• easy to fit, to cut with 1 pair of scissors
• good water resistance
• gasket can be die-cut (screw holes)
• roll length up to 50, 100, 250 or 1000 m
• high shielding performance
• low closure force
• EXTREMELY STRONG
• deflection 50%
Standard Shield
7000, with Options
self adhesive strip • cut into accurate lengths
• can be made die cut or frame
• combination with water seal
Standard Shield 7000 is an economical HF • UL94V-0 flame retardant foam core
• chemical resistant rubbers like EPDM
gasket which can be supplied in a wide range of
• silicone sponge for high temperatures up to 220o C
dimensions. It is very effective in combination with
• different conductive foils and fabrics
stainless steel, copper and chromated constructions.

All gaskets can be provided with a (conductive)

Tape Specification
self-adhesive strip. 01 : standard self-adhesive placed in the middle
02 : without self-adhesive
Standard Shield 7000 consists of a neoprene or 03 : with conductive self-adhesive
PVC foam core covered with textile. This guarantees 06 : standard self-adhesive, asymmetrical
07 : standard self-adhesive placed on the side
excellent shielding performance and very great
strength.
Foam Specification
For special applications, different foam cores N : standard neoprene foam
and conductive foils and fabrics are available. E : EPDM foam core
P : low closure force PVC foam, slow recovery
F : flame retardant UL94V-0 foam
Dimensions
Width X (mm)
Height 2 3 4 5 6 7 8 10 12 15 18 20 25 32 50
Y (mm) 1 7021 7031 7041 7051 7061 7071 7081 70101 70121 70151 70181 70201 70251 70321 70501
2 7022 7032 7042 7052 7062 7072 7082 70102 70122 70152 70182 70202 70252 70322 70502
3 7033 7043 7053 7063 7073 7083 70103 70123 70153 70183 70203 70253 70323 70503
4 7044 7054 7064 7074 7084 70104 70124 70154 70184 70204 70254 70324 70504
5 7055 7065 7075 7085 70105 70125 70155 70185 70205 70255 70325 70505
6 7066 7076 7086 70106 70126 70156 70186 70206 70256 70326 70506
8 7088 70108 70128 70158 70188 70208 70258 70328 70508
10 701010 701210 701810 701810 702010 702510 703210 705010
12 701212 701812 701812 702012 702512 703212 705012

Item numbers in bold are 98% stock items. Other dimensions on request.

Shielding Performance Ordering Information

Frequency Mode Screening Please specify the dimension code from the table
Hz dB above, followed by the code for the tapes and the code
1M E 115 Shielding for the foam core.
effectiveness
10M E 108 depends on
100M E 102 surface,
shape of gaskets
Example
400M E 92 and material Standard Shield 7000, 8 x 2 mm, standard
1G P 90 used.
self-adhesive non-conductive placed in the middle,
8 See Guarantee standard neoprene foam core: 7082-01-N
Frame Gasket 81OO &
Endless Gasket 8OOO
Frame Gasket 81OO Pre Fabricated
die cut-strips
For panels and screwed applications like displays,
windows and honeycomb vents.

The 8100 series frame gaskets are ready-made

gaskets according to customer specifications. They have
reinforced corner pieces to guarantee optimum shielding
performance and easy mounting characteristics.
The standard base material is Amucor-shield 6800 or
EMC/IP gasket 7300.
Disc or washer-type compression stops can be
included to prevent over compression. 8100 series
endless gaskets can also be supplied with an additional
water seal. Endless Gasket 8OOO
Combined EMI / Water seal for grooves

The 8000 series endless gaskets are suitable for

many applications in which both an EMI shielding gasket
and a water seal are required. The 8000 series endless
gaskets consists of a rectangular EMI gasket
(Amucor-shield 6800 or Ultra Soft Shield 7400), combined
Self adhesive with a closed-cell water seal. All gaskets can be provided
Frame Gasket with a self-adhesive strip for easy mounting.

Gasket materials for the 8000 series endless gaskets

are watertight at 30% compression, depending on the
construction

Shielding Performance 1 2
The shielding performance depends on the outer
Drawing
material chosen. Amucor-shield 6800 has reinforced Standards
Amucor foil and Ultra Soft Shield 7400 has conductive
fabric covering. 3 groove with
EMI / water seal
Compression R
stops A

Z X
WASHER TYPE DISK TYPE
used at bold holes used beside bolt holes
Y
Benefits S B

• easy mounting water seal EMI gasket

• high shielding performance self-adhesive
• no tools required S
• dimensions up to 2 x 2 m Section S-S Note: widths X and Z must
be smaller than height Y.

Ordering Information Ordering Information

When ordering 8100 series frame gaskets, please When ordering 8000 series endless gaskets, specifications
send your technical drawing. This drawing must contain should include: gasket material, water seal material,
the following items: dimensions, with or without self-adhesive and quantity
• thickness of gasket
• width of EMI gasket Options
• width of water seal gasket • UL94V-0 flame retardant foam core
• EMI gasket inside or outside • chemical resistant rubbers like EPDM
• position of holes • silicone sponge for high temperatures up to 220o C
• optional: type of compression stops • available in textile, Amucor or mesh 9
 EMC/IP Gaskets
73OO
Benefits
• bends easily around sharp corners without
interrupting the water seal.
• excellent water sealing up to IP65 (depending on
construction).
Water sealing
EMI gaskets for Construction
screwed applications R=3/4 X
like panels, displays continuous (!) water seal
and windows 7300 A EMI seal

The 7300 series EMC / IP gaskets are cost-

effective combinations of an EMI shielding gasket and
a water seal. This type comes with a self-adhesive
strip.
Width X conductive
foil Type I
The gasket consists of two neoprene foam Height Y
cores, one of which is covered with reinforced foil, self-adhesive
based on the high performance Amucor alloy.
Amucor is good compatible with aluminium and zinc Width X conductive
plated steel. For aluminium with alochrome or foil Type II
stainless steel it is better to use highly conductive Height Y
self-adhesive
textile. The two parts can deflect independently to
guarantee optimal shielding and sealing performance.
Sharp inside corners can be made easily, without Shielding Performance
interrupting the water seal. For special applications, Frequency Mode Screening dB
different foam cores and conductive foils and fabrics Hz Amucor (A) Conductive textile (T)
are available. 1M E 121 115 Shielding
effectiveness
10M E 110 108 depends on
Dimensions 100M E 103 102 surface,
shape of gaskets
Width X (mm) 400M E 98 92 and material
Height 4 6 8 9 10 12 15 18 20 25 1G P 92 90 used.
Y 1 7341 7361 7381 7391 73101 73121 73151 73181 73201 73251
(mm) 2 7342 7362 7382 7392 73102 73122 73152 73182 73202 73252
See Guarantee
3 7343 7363 7383 7393 73103 73123 73153 73183 73203 73253
4
5
7344
7345
7364
7365
7384
7385
7394
7395
73104 73124
73105 73125
73154
73155
73184
73185
73204
73205
73254
73255
Ordering Information
6 7346 7366 7386 7396 73106 73126 73156 73186 73206 73256 Please indicate if you want T (textile) or A (Amucorfoil).
8 7348 7368 7388 7398 73108 73128 73158 73188 73208 73258
Please specify if you want the product in one piece
10 73610 73810 73910 731010 731210 731510 731810 732010 732510
12 73612 73812 73912 731012 731212 731512 731812 732012 732512 (Type II) or two separate parts (Type I)
15 73815 73915 731015 731215 731515 731815 732015 732515
18 73918 731018 731218 731518 731818 732018 732518
20 731020 731220 731520 731820 732020 732520
Example
25 731225 731525 731825 732025 732525 Height Y 5mm, Width X 10mm with Amucorfoil,
10 Item numbers in bold are 98% stock items. Other dimensions on request. partly wrapped: 73105 A II.
Ultra Soft Twin
Shield 78OO

For doors:
low closure force
to prevent bending

Ultra Soft Shield Twin 7800 is a combined

HF gasket / water seal with very low closure force.
All gaskets are provided with a self-adhesive strip, on
the water seal side.

Ultra Soft Twin Shield 7800 consists of an HF width Z width X

gasket (compare Ultra Soft Shield 7400) combined
with an environmental seal of closed-cell foam rubber. Water Seal height Y
The standard material for the water seal is neoprene
foam and as option a slowly recovering PVC foam, Self-Adhesive EMI Gasket
which is fully watertight at 30% compression.
Dimensions
Tape Specification Z X Y Part
01 : standard self-adhesive, asymmetrical number
02 : without self-adhesive 2 mm 4 mm 4 mm 7864
3 mm 6 mm 6 mm 7896
Foam Specification water seal 3 mm 9 mm 6 mm 78126
P : low closure force PVC foam 3 mm 9 mm 9 mm 78129
N : neoprene foam 4 mm 12 mm 12 mm 781612
E : EPDM foam Other dimensions on request
F : flame retardant UL94V-0 foam

Shielding Performance Ordering information

Please specify the dimension code from the table
Frequency Mode Screening above, followed by the code for the tape and the
Hz dB
code for the material of the water seal.
1M E 115 Shielding
effectiveness
10M E 108 depends on
100M E 102 surface, Example
shape of gaskets
400M E 92 and material Ultra Soft Twin shield 7800, 2,4,4mm, standard
1G P 90 used. self-adhesive, with Neoprene foam water seal:
See Guarantee 7864-01-N 11
 Clip-on Gaskets
65OO
The gasket can make angles in two planes
Clip on EMI gaskets with water seal where a small radius is sufficient. Temperature
range from - 40o tot +110o C. A flame retardant
version (UL94 V0) is
WATER SEAL EMI SEAL
also available
(see on the right C
of the picture).

A
CONDUCTIVE
TEXTILE

D
Dimensions
Profile A B C D
6585 9 16 9 0.5 - 2.0
6590 10 21 11 1-3
6595 9,5 9 8,7 0.5 - 2.0
Flame
8,7
Retardent
6590 6585 Version Clip-On
6595
9,5
This range of easily mounted clip-on gaskets is 9

composed of a separate sponge rubber water seal

and an EMI-shielding side of highly conductive,
wear-resistant metallized fabric.
The construction is very flexible thanks to the hollow
rubber, so a low closure force is guaranteed.

The gasket is assembled without tools, simply

by pressing the section by hand onto the metal
flange of you enclosure.
Different sizes are available on request.

Shielding Performance
Frequency Mode Screening
Hz dB
1M E 121 Shielding
effectiveness
10M E 110 depends on
100M E 103 surface,
shape of gaskets
400M E 98 and material
1G P 93 used. 6595
12 See Guarantee
O-Profiles
79OO
Benefits
• easy to fit into grooves
• deflection up to 50%
• low closure force

Options
• cut into accurate lengths or endless O-rings
• drop out prevention fixtures
• UL94V-0 flame retardant core
• silicone core for high temperatures up to 220o C

For application in grooves

Material Specification
Extrusion Type X Base Material Y Covering Z
1YZ : hollow X1Z : neoprene XY1 : reinforced Amucor
2YZ : solid X2Z : silicone XY2 : conductive fabric
Several types of O-profiles have been developed 3YZ : cell rubber X3Z : PVC XY3 : silver filled rubber
4YZ : rectangular X4Z : EPDM XY4 : nickel filled rubber
for different applications, each with their own
X5Z : conductive rubber XY5 : graphite filled rubber
benefits.

Four kinds of cores are available: solid, hollow Ordering Information

extrusion, cell rubber and small rectangular shapes. Taken from the table above - dimensions in mm.
These can be covered with metallized fabric foils or For tolerances and dimensions of your groove,
conductive rubber. For optimal shielding performance please ask our engineers.
a compression of 10-15% is recommended for solid
extrusions and 10-50% for hollow extrusions and cell Example
rubbers. Hollow silicone O-profile covered with conductive
fabric, diameter 1.5 x 2.6 mm: 79122-1,5 x 2.6
Dimensions in mm
Hollow Solid Cell Rubber Rectangular
0.3 x 0.9 2.1 2.1 0.5 x 1
0.5 x 1.2 3.0 3.0 1x1
0.5 x 1.6 3.5 3.5 1 x 1.5
0.7 x 1.9 4.0 4.0 1x2
1.5 x 2.6 5.0 5.0 1 x 2.5
1.5 x 3.1 5.4 6.0 1x3
1.5 x 3.6 6.0 7.0 Only available
2.0 x 4.1 7.0 8.0 in XY3 and
3x5 8.0 9.0 XY4
4x6 9.0 10.0
6x8 10.0 12.0
7 x 10 11.0 15.0
8 x 12 12.0 18.0
12 x 15 15.0 20.0
12 x 16 18.0 22.0
16 x 20 20.0 25.0

Solid and hollow conductive Shielding Performance

o-rings and profiles Frequency Mode Screening
Hz dB
1M E 115 Shielding
effectiveness
10M E 108 depends on
100M E 102 surface,
shape of gaskets
400M E 82 and material
1G P 90 used.

See Guarantee 13
 Flatshield
57OO Series
Material Part no.
Sheet material to die cut solid silicone with monel wire 5711
complicated shapes solid silicone with aluminium wire 5712
solid fluorsilicone with monel wire 5713
sponge silicone with monel wire 5721
sponge silicone with aluminium wire 5722

Available thicknesses:
0.81, 1.13, 1.38, 1.57, 2.40, 3.18, 3.96, 4.78,
6.35 mm. Other thicknesses on request.
Shielding performance
120
E-field
100

attenuation (dB)
80
H-field
60
40
20
0
10 K 100 K 1M 10 M 100 M 1G
frequency (Hz)

Oriented Wire Shield Conductive Vilt 573O

Non woven texture polyester with nickel coating.
5711-5722 Thickness 1,5 mm. Maximum width 500 mm.
Oriented Wire Shield 5711-5722 is a composite Specifications
gasket material consisting of a large number of small grammature 150 g/m2
wires embedded and bonded in solid or sponge tensile strength ( length of roll) >=230 N/5cm
silicone. For oil-resistance applications (as well as tensile strength ( cross) >=340 N/5cm
hydraulic oil) we produce also fluor silicone. max. elongation >=55%
flame resistance UL 94 HB
The Material is used in military, industrial and
commercial products requiring EMI suppression, Shieldin performance
grounding, or static discharge. It is very suitable for Frequency Hz Attenuation dB
applications where an environmental or pressure seal 1M 100
is required. 5M 75
The sponge version is used in cases of severe 15M 62
joint unevenness, or if lower closure forces or 30M 56
greater compressibility are required. 100M 52
150M 50
700M 70
Ordering information
See Guarantee
Standard sheet of 90 x 900 mm but for bigger items
they will be welded. We also can joint them together
to prevent waste of material.

Benefits
• temperatures up to 220o C
• high shielding performance
• water sealing, up to 10m. of water
• pressure resistant
• salt spray / chemical resistant
• fluor-silicone rubber for fuel/oil-resistance
14 • supplied as sheets, strips or die-cuts
Flatshield
57OO Series
Conductive Rubber 575O
This heat-proof silicone rubber can make an
emi-proof and a pressure watertight seal in narrow
constructions. Also for EMP protection and against
static electricity. Also available in fluor silicone rubber
for resistance against (hydraulic) oil and fuels.
The rubber can be filled with silver, nickel, silvered
glass, silvered aluminum or graphite (only for ESD).
Also for wave-guide applications.

As it absorbes high frequencies, conductiver

rubber shows a shielding effect of 60 dB at 30MHz ~
10GHz. Owing to its excellent conductivity, grounding
and shielding effect, it is well suited for military Structure with
communication equipment. It can be manufactured in foam as its intermediate
various shapes such as sheets, moulded parts, layer, offering a suitable material for
die-cut, strips and o-rings ( see page 13). EMI shielding and absorbing Gasket

Specification
standard sheet 300 x 210 mm Conductive Foam 577O
thickness (mm) 0.2/0.5/1.0/1.5/2.0/3.0/5.0
The foam is characterized by:
hardness 55 shore A ± 5
elongation at break 120 % • Availability in thickness - Max 6 mm, 5mm, 4mm,
resistivity vertical 0.05 Ohm /sq 3mm, 2mm, 1mm,
resistivity horizontal 0.1 Ohm/sq • Other thickness available on request
Shielding effectiveness 70 - 100 dB (10-1000 Mhz) • Excellent electric conductivity all over the surface
across the thickness
Flammability UL94 V-2
• Excellent electromagnetic shielding effect
Halogen Content 0%
• Strong and good conductive adhesion
• Easy die cutting, kiss cutting and slitting
Characteristics • Size - Sheet Type: Max 450 x 450 mm
• Excellent electric conductivity all over the surface
across the thickness Options
• Excellent electromagnetic shielding effect
• With or without self-adhesive
• High workability for adhesion Supplied as sheets, strips or die-cuts
•
• Easy die-cutting, kiss-cutting and slitting With water seal
•
• High temperature resistant with cooling holes
Conductive Rubber 5700 • Reinforcement with non woven on 1 or 2 sides
• PSA Attachment Method Option
• Nickel/Copper Metallization
• X-Y-Z Axis Conductivity
• Tolerance of ± 0.5mm
• I/O Static Applications/Gasket Replacement

Specifications
Product Material Thickness Surface Volume
Number (base/material) (mm) resistance resistance
(Ω/sq) (Ω/sq)
57715 PET+PU / Cu+NI 1,5 0,2 0,2
57722 PET+PU / Cu+NI 2,2 0,2 0,2
57734 PET+PU / Cu+NI 3,4 0,2 0,2
57750 PET+PU / Cu+NI 5,0 0,2 0,5
57760 PET+PU / Cu+NI 6,0 0,2 0,5 15
 V-Shape Gasket
87OO

For doors: gaskets

with low closure
force, to prevent
bending of doors,
lids and panels

The 8700 series V-shape gaskets are 1 2

characterised by a very large compression range and
a low closure force. They come with a self-adhesive
strip for easy mounting.The most popular version is
with conductive Nickel over Copper textile (T).
The version with high conductive amucor foil (A) is
special designed for a combination with aluminum and hinge
zinc plated steel. To prevent loss of material and easy
shipping we can cut them in exact lengths. Maximum 3
2.5 meter. Also available with a resilient foam rubber cabinet door
insert (i) for more compression just at the moment of
closing.
No permanent closure force
The 8700 series is a flame retardant version,
which can be supplied in a UL94V-0 compliant version.
If applied as shown in figure 3, excellent shielding Ordering
can be achieved without any permanent closure force. information
This construction prevents bending of doors, so the Part number 87107 with
enclosure can be less rigid. Also for hinges and locks.
conductive textile and
Shielding Performance resilet insert and lenght
Frequency Mode Screening
of 1940 mm:
Hz dB 87107 -T -i -1940
1M E 115 Shielding
effectiveness
10M E 108 depends on Benefits
100M E 102 surface,
400M E 92
shape of gaskets • self-adhesive EMC gasket,
and material
1G P 90 used. easy to fit
See Guarantee • allows big tolerances
• high shielding performance
• very high deflection
• low closure force

Dimensions Y resilient Y
insert
Part no. 8733 8744 8755 8766 8777 8788 87107 871212 871818 872020
width X (mm) 3 4 5 6 7 8 10 12 18 20 self- self-
16 range Y (mm) 0.3-1.5 0.3-2 0.3-2.5 0.6-3 0.6-4 0.6-4 0.6-5 0.6-6 1-9 1-10 X adhesive X adhesive
Customized 88OO
Miniature Shield 14OO
A new CNC extrusion system has been developed to
manufacture EMI shielding gaskets in a wide range of
shapes and dimensions. With this system there are no
tooling costs, so it is also interesting for smaller quantities
or special constructions. The metal cladded flame retardant
gasket can be manufactured in several rigidities and is very
compatible with aluminum, zinc-plated steel, Aluzinc,
stainless steel, copper, etc.
Enclosures can be constructed more cost-effectively
and compactly and the (electrically conductive) self-adhesive
strips will reduce production time. The material is non-toxic
and is an excellent replacement for the environmentally
polluting beryllium gaskets.
Available in dimensions from 1.7 - 30 mm, with or
without separate water seal. The gaskets can be supplied Any size you want !
in lengths according to customer specifications.
Standard shapes are available for 19" racks, watertight Customised gasket production
enclosures and PCB shielding. in any size and shape
A C B
A
Benefits Options
C
B A A • no tooling costs • cut into accurate lengths
C • a wide range of shapes • combination with water seal
B • self-adhesive EMC • UL94V-0 compliant flame
B
gasket retardant
• easy to fit • chemical resistant versions
• small dimensions • high temperature resistant
• very high deflection versions
• low closure force • different conductive foils
and fabrics
Type A Type B Type C Type D
Part no. A B Part no. A B C Part no. A B C Part no. A B C
8801 10 7 8820 15 15 12 8840 15 12 15 8860 15 2,5 15
8802 10 7 8821 10 10 7 8841 10 8 10 8861 12 2 10
8803 6 3 8822 8 8 5 8842 8 6 8 8862 8 1,5 8
8804 4 2 8843 6 4 6 8863 6 1 6
Other dimensions on request

Miniature Shield 14OO Dimensions

Width X (mm)
Small width EMI-shield Height 1,0 1,5 2,0 2,5 3,0 3,5 4,0
Y 1,0 141015 141515 142015 142515 143015 143515 144015
(mm) 2,2 141022 141522 142022 142522 143022 143522 144022
This gasket can be produced so small in width is that 3,4 141034 141534 142034 142534 143034 143534 144034
its height exceeds its width. Application: on PCB and other 5,0 141050 141550 142050 142550 143050 143550 144040
6,0 141060 141560 142060 142560 143060 143560 144060
products where there is very little space available, and low
compression force is required.
Ordering Information
Please specify the dimension code from the table.
The material is a highly conductive foam with or without
a conductive self-adhesive strip at the bottom. The foam Example
can be compressed by even more than 50 % of it's original Miniature Shield 5700, 2,0 x 3,4 mm with self-adhesive: 572034 - ZK
height. The smallest width is 1 mm and the maximum Miniature Shield 5700, 3,5 x 2,2 mm without self-adhesive: 573522
height is 6 mm. Roll lengths up to 100 meter.

width X
Options
• with water seal
• high temperature resistant width Y Small width
• with cooling holes EMI-shield
Foam Core
• with or without self- (miniature shield)
adhesive Self-Adhesive 17
 Honeycomb Vents
95OO Series
Shielded Vent panels for
ventilation and heating

Honeycomb vents are used to shield

openings for heating and ventilation against
undesirable electro-magnetic waves.

The aluminium honeycomb vent panels are Airflow characteristics

supplied in rigid aluminium frames, pre-drilled or with
0.100
pressure drop (mm H 20)

captive fasteners to your specifications.

0.075
If a very high shielding level is required, the use
of cross-cell honeycombs is recommended. 0.050
These are made from two pieces of 6.35 mm thick
honeycomb within a single frame. The shielding 0.025

performance will improve at the expense of slightly

0
increased air flow resistance. 0 15 30 45 60 75
air flow (m/min)
Approximately 95% of the honeycomb vents are
made to customer specifications, and are all made Benefits
to order. • light weight
• high shielding performance
• very low air flow resistance
Shielding performance (cross cell, 30 mm) • reduction of turbulence
120
100
E-field Options
attenuation (dB)

80 • cross-cell honeycomb for extra high shielding

H-field performance
60
• slant honeycomb 30o , 45o , 60o for outdoor
40 rainproof applications (high volume only)
20 • polyurethane filter for dust protection
0 • mechanical protection against damage
10 K 100 K 1M 10 M 100 M 1G • stainless steel version
18 frequency (Hz) • brass
Honeycomb Vents
95OO Series
Standard
Mildsteel Vents for EMP

Cross Cell

Frame Construction

30
26
26 11
11 10
30
11 11
10

Frame A Frame B Frame C Frame D

A
Standard Dimensions C 0.5 C

Hole diameter P is standard 3.5mm but it can be

delivered in any other size. Also available with screw
apertures or inserts.
B G

Outer Mounting holes Mounting holes F

dimension horizontal vertical C

A B No. D E No. F G D E 0.5 C

P dia.
150 75 2 40 70 1 37.5 -
100 100 1 50 - 1 50 -
200 100 3 20 80 1 50 -
125 125 2 20 85 1 62.5 - Ordering Information
250 125 3 30 95 1 62.5 - All honeycomb vents are made according to
150 150 2 25 100 2 25 100
customers specifications, so there are no standard
300 150 4 30 80 2 25 100
175 175 2 40 95 2 40 95
part numbers. When ordering honeycomb vents, the
350 175 4 40 90 2 40 95 following information should be provided: frame style,
200 200 3 20 80 3 20 80 dimensions, quantity and gasket material.
400 200 5 30 85 3 20 80
250 250 3 30 95 3 30 95 The standard material for gaskets is an Endless
300 300 4 30 80 4 30 80 gasket 8100 series, thickness 2-4 mm, depending
600 300 7 30 90 4 30 80 on outer dimensions. 19
 Mesh Foil
9OOO Series

Roll of mesh foil with

flying mesh and ready
made displays with a
step and silver bushbar

The stainless steel mesh, fully integrated in the Application

foil, is protected by a scratch resistant layer. Also shielded windows
available with transparent self adhesive so easy to •
apply onto glass, acrylic and polycarbonate, by hand • touch screens
or with a laminator. • monitor and LCD shielding
• tempest shielding
Depending on the mesh quality it covers anything
between 10 kHz and 30 GHz. The finer the mesh, the Ordering Information
more effective it is for high frequencies. Please indicate size and part number
The foil can be delivered with a strip of the mesh Please indicate with or without (B) Bush Bar (± 3/4 mm)
longitudinally (flying mesh) Alternatively a conductive
or non-conductive adhesive can be provided along the Example
edges or there can be a silver bush bar around the Standard mesh foil, with scratch resistant layer,
circumference. A termination with a water/EMI gasket size 20 mm, length 5 m: 92020
is another option.
Shielding performance of mesh windows
Moreover, they can be processed in various forms
available meshes: stainless steel, blackened copper, Material Stainless steel Phosphor
Bronze
Copper

phosphor bronze. Type (wires/inch) 70 80 100 250 100 250 70 100

Wire diameter (mm) 0.076 0.050 0.050 0.035 0.097 0.035 0.076 0.050
Size Length Part number Nominal aperture (mm) 0.287 0.267 0.204 0.067 0.157 0.067 0.287 0.204
(mm) (m) standard standard + standard + standard + Light Transmission % 62.6 71 64.5 43.5 38.2 43.5 62.6 64.5
mesh foil self scratch scratch
Field Type Frequency dB dB dB dB dB dB dB dB
adhesive resistant resistant
layer layer and self H 10 kHz 20 21 22 22 22 20 24 22
adhesive H 100 kHz 21 23 23 22 42 24 39 35
10 5 90010 91010 92010 93010 H 1000 kHz 30 33 29 37 61 40 58 54
20 5 90020 91020 92020 93020
30 5 90030 91030 92030 93030 E 1 MHz 90 104 101 114 120 120 105 111
40 5 90040 91040 92040 93040 E 10 MHz 89 86 75 91 110 97 100 99
50 5 90050 91050 92050 93050 E 100 MHz 69 75 68 78 96 91 86 95
100 2 90100 91100 92100 93100
200 2 90200 91200 92200 93200 P 1 GHz 66 60 64 75 79 87 66 72
20 1000 roll 901000 911000 921000 931000 P 10 GHz 33 32 35 46 60 34 39
Displays & Windows
97OO Series
Conductive Window with step,
transparent f o i l silver bush bar and
protection foils
For smaller areas a transparent polyester foil
with ITO coating is commonly used. Applications:
LCD displays, membrane switches, etc.
The foil has a resistance of 5 Ohm/sq.

Windows with shielding mesh

A woven microstructure mesh is bonded between two
layers of glass or plastic. This can be done by lami-
nating or edge-bonding. The windows can be provi-
ded with a gasket or be supplied with a frame for 10 design tips for windows / displays
easy mounting.
and transparent foil
1 Do not be afraid of low light transmission
coefficients. An average pair of sunglasses has less
than 9 % light transmission and you can still see very
well through them.
2 In general, a mesh provides higher shielding
performance than an ITO coating.
3 Keep the window as small as possible;
rectangular windows are better than square windows
because the distance from the centre of the window
Shielding performance of ITO coating to the edge is smaller.
120 4 Please inform us of the size in mm that you need
100 and specify the free viewing area.
attenuation (dB)

80
5 It is cheaper to produce small windows so please
60 specify quantities and sizes rather than square
5 Ohm
40 meters.
20 Ohm
20
6 For small windows or little displays you can use
0 foils. It is best to integrate a foil in a display or to
1M 10 M 100 M 1G
frequency (Hz)
mount it onto the edges with copper tape 3201.
7 We can provide windows with a water seal.
Windows with sputtered ITO coating Please indicate if you want the seal to be on the
Light transmission is 65-95%, depending on electrical inside or outside of the window. It is also possible to
conductivity. (20-5 Ohm/sq) The coating can be have a separate water seal on the other side.
applied on foil, glass and polycarbonate. 8 If an anti-glare or optical coating is needed,
These windows can come equipped with frame and please indicate on the drawing from which direction
required EMC gaskets. the user will look at it.
9 Only use an anti-glare layer when the object is
ITO layer
close to the window, like a monitor. For viewing
Si02 layer
windows it is better to use an optical coating.
10 To prevent moiré-effects with mesh windows you
Glass Substrete can indicate the angle of the mesh. When you order
a window you can ask us for a sample window and
then measure the best angle yourself. 21
 Cable Shielding
47OO & 48OO
Cable Wrapping 47OO
The cable wrapping should be grounded. On one
or at both ends of the cables can be find in practice.
Cable wrappings are supplied in continuous lengths,
on a reel, or cut in lengths.

1. Flat cables:
Reinforced Amucor foil 4701- 4702
This material gives a high shielding performance for
cable wrapping. It is used for cables with large dia-
meters and flat cables. It comes provided with self- Cable Wrapping
adhesive backing but is also available without self-
adhesive.

2.Highly flexible cables:

Conductive fabric 4711- 4721
For applications where very high flexibility is required,
like cables with small diameters. The highly
conductive fabric guarantees superb shielding per
formance. Also available in conductive non-woven and
with self-adhesive.
• Conductive Fabric 4711
• Conductive fabric with self adhesive 4712
• Conductive fabric with conductive self adhesive 4713
• Conductive non-woven 4721
Widths: 8, 10, 12, 14, 16, 26, 32, 50 or 100 mm

Flat Shield with Shielding Performance

grounding strip
Frequency Mode Screening
Hz dB
1M E 115 Shielding
effectiveness
10M E 108 depends on
• Reinforced Amucor foil 4701 100M E 102 surface,
• Reinforced Amucor foil + self adhesive 4702 400M E 92
shape of gaskets
and material
1G P 90 used.
Standard widths: 8, 10, 12, 14, 16, 26, 32, 50 or See Guarantee
100mm

Shielding Performance
Frequency Mode Screening
Hz dB
1M E 121 Shielding
effectiveness
10M E 110 depends on
100M E 103 surface,
shape of gaskets
400M E 98 and material Highly Flexible Cable Shield
1G P 92 used.

22 See Guarantee
Cable Shielding
47OO & 48OO
3. Heavy duty, low frequency:
Wrapshield 4730 - 4760

Cable wrapping is used to shield cables or to harness

even bundles of cables. Wrapshield is made as a
tube so: two layers of knitted wire mesh.
With an overlap of 50% this results in even 4 layers
of metal.

It can be supplied in four wire materials:

• Wrapshield Monel 4730

• Wrapshield tinned copper/steel (T.C.S.) 4740
• Wrapshield stainless steel 4750
• Wrapshield aluminium 4760
Wrapshield
Standard Widths: 12, 25, 50, 100 or 150mm

Benefits Options Shielding Performance

• high flexibility • flame retardant Frequency Mode Screening
• high shielding performance version Hz dB
• wide range of • with self-adhesive 1M E 72 Shielding
applications backing 10M E 65 effectiveness
depends on
• easy to cut into the right • customer-specific 100M E 62 surface,
shape of gaskets
shape widths 1G E 58 and material
10G E 42 used.

See Guarantee

Flexible Shielding Tube 48OO

This material is a ready-to-use mu-copper or tinned mu-copper tube through Diameter Part no.
which a cable or bundle of cables can be pulled. If the tube is compressed 3 - 6 mm 4806
lengthwise, the diameter expands to simplify the assembly. Therefore a wide 5 - 15 mm 4815
range of cable diameters can be shielded with a single tube. 12 - 24 mm 4824

Please note that the tube has to be expanded for

larger diameters and that a larger nominal length will Flexible Shielding
then be required (up to twice the length of the cable). Tube

Electrical
Frequency Hz Mode Screening dB
1M E 121
10M E 110
100M E 103
400M E 98
1G P 93
Magnetical
10K H 10
100K H 14
1M H 21
See Guarantee 23
 Shielding Foil
58OO

For shielding plastics

enclosures and PCB

Many shielding problems can be solved easily by Shielding performance

the use of conductive foils. Not only can they be The shielding performance depends on the selected
used even for shielding large rooms but also for material. In the table you will find the characteristics
small plastic enclosures. of mu-copper foil. For characteristics of other
Some of the most commonly used materials are materials, please contact our technical specialists.
reinforced Amucor foil and mu-copper foil, with or
without (conductive) self-adhesive and insulation. PCB/compartment shield
Laminates of metal foils with flame retardant Nomex® An other application is a highly conductive foil
or Valox® are also available. Our engineers can help laminated with a high deflection, low closure force
you with the right design to make overlaps, holes for foam layer. The rigidity of the housing is used to
connectors, cables and spuds. shield the separations on the PCB. Combinations with
conductive fabrics or non-woven are also available.
Field Frequency Mu-Copper
H 1 kHz 22 dB
H 10 kHz 35 dB
H 200 kHz 68 dB
E 10 kHz 99 dB
E 200 kHz 127 dB
E 1 MHz 125 dB
E 18 MHz 101 dB
P 400 MHz 120 dB
P 1 GHz 110 dB
P 10 GHz 120 dB
Shielding performance of mu-Copper foil 0,12mm thick

Possible applications
PCB shielding, small folded boxes for sensitive Foam Type PU Foam Neoprene Foam
max. 80 % compression max. 50 % compression
components, with a flame retardant insulation on the
Conductive Amucor Conductive Amucor Conductive
inside. Folded insulated envelopes around PCBs, Layer Foil Fabric Foil Fabric
shielded displays (transparent conductive foils), and 3 mm 5813 5823 5833 5843
many more. 4 mm 5814 5824 5834 5844
5 mm 5815 5825 5835 5845
Options 6 mm 5816 5826 5836 5846
8 mm 5818 5828 5838 5848
• flame retardant version 10 mm 5810 58210 58310 58410
• with (conductive) self-adhesive backing 15 mm 5815 58215 58315 58415
24 • with insulation layer Other thicknesses and materials on request
Connector Gasket
82OO
EMI flange seals for electrical connectors
The 8200 series connector gaskets are die-cut
gaskets for EMI shielding and grounding of a wide
range of connectors. These new connector gaskets
are more effective in closing gaps caused by fabrication
tolerances and misaligned or irregular surfaces than
would be possible with a solid flange design.
The 8200 series consist of die-cut Amucor-shield
6800, 1 or 2 mm thick, provided with self-adhesive.
Sub-D connector gaskets
Dimensions in mm Front Mounting Rear Mounting
Shell Size E F G H L K L K
9 33.35 25.00 19.05 3.56 19.86 11.43 16.89 9.40
15 41.68 33.33 19.05 3.56 28.20 11.43 25.22 9.40
25 55.58 47.04 19.05 3.56 41.91 11.43 38.94 9.40
37 71.86 63.50 19.05 3.56 58.37 11.43 55.40 9.40
50 69.60 61.11 21.85 3.56 55.88 16.82 53.01 12.19
Connector
Please order size with (F) Front or (R) Rear Mounting.
E
Gasket 8200
F

JT, PT, PC, MIL-C-26482, MS-3110, MS-3112,

MS-3119, MS-3120 connector gaskets
K
G
H

Part Number/ Dimensions in mm

Shell Size A B C D
R 4.6 (4x) 8206 17.48 11.91 9.53 3.30
L
8208 20.62 15.09 12.70 3.30
8210 23.83 18.26 15.88 3.30
AN, HT, QWL, MIL-C-5015, MS3100, MS3102 8212 26.19 20.65 19.05 3.30
connector gaskets A Series 8214 28.56 23.01 22.23 3.30
8216 30.86 24.61 25.40 3.30
Part Number/ Dimensions in mm
8218 33.32 27.00 28.56 3.30
Shell Size A B C D
8220 36.53 29.36 31.75 3.30
8208A 22.23 15.09 12.70 4.37
8222 39.70 31.75 34.93 3.30
8210A 25.40 18.28 15.88 4.37
8224 42.88 34.93 38.10 3.96
8212A 29.79 20.65 19.05 4.37
8214A 30.16 23.01 22.23 4.37 A

8216A 32.54 24.61 25.40 4.37 B

8218A 34.3 27.00 28.56 5.15

8220A 38.10 29.36 31.75 5.15
8222A 41.28 31.75 34.93 5.15
8224A 44.45 34.93 38.10 5.15 C
B
A

8228A 50.80 39.70 44.45 5.15

8232A 57.15 44.45 50.80 5.56
8236A 63.50 49.23 55.58 5.56
8240A 69.85 55.58 61.93 5.56 D
8244A 76.20 60.33 70.64 5.56
Bendix-SP Connector Gasket B Series
8248A 82.55 66.68 76.99 5.56
Part Number/ Dimensions in mm
RF Connector Gasket Shell Size A B C D
Connector Dimensions in mm 8206B 24.21 16.28 9.53 4.06
Type A B C D 8208B 26.59 18.64 12.70 4.06
BN 17.45 12.70 11.10 2.77 8210B 28.56 20.62 15.88 4.06
BNC 17.45 12.70 11.10 2.77 8212B 31.75 23.83 19.05 4.06
C 25.40 18.26 15.88 4.37 8214B 34.93 26.19 22.23 4.06
HN 30.18 23.01 19.05 3.56 8216B 36.50 28.56 25.40 4.06
LC 50.80 36.50 31.75 6.53 8218B 38.51 30.56 28.56 4.06
N 25.40 18.26 15.88 4.37 8220B 42.47 32.94 31.75 4.06
UHF 32.54 24.61 25.40 4.37 8222B 44.45 34.93 34.93 4.06 25
 Conductive Coating &
Metallisation 38OO Series

Conductive Nickel Coating

For Plastics Conductive
A fast and easy way to shield plastic enclosures Nickel Coating
is by using a conductive paint containing nickel, 3801
copper or silver. The paint comes in aerosols for easy
use, but can also be supplied in tins of 5 or 20 litres
for larger quantities

Frequency Coating Shielding

(Hz) (dB) Performance
30M 36
100M 38
Shielding effectiveness
200M 44 depends on surface,
500M 54 shape of gaskets
and material used.
700M 54 Ordering Information
900M 50 Part numbers of conductive nickel coating:
See Guarantee • 3801 Aerosol 365 ml
• 3805 Tin 5 Litre
Conductive • 3820 Tin 20 Litre
• 3850 Silver Coating 50 gram
Metallisation 3838
Conductive Silver
Coating 385O
Silver Pigmented Conductive Coating
Silver Coating 3850 is the latest in a series of
coatings which provide Electromagnetic Compatibility
(EMC) and it has been specifically designed to give
increased coverage while maintaining a very high
conductivity. Thus it is a very economic means of
achieving excellent shielding against radiated
electromagnetic interference (EMI).
It maintains its low resistance even after
For higher demands and larger quantities we exposure to heat, cold, humidity and salt spray. It is
can sputter a full metal coating on 90% of commonly an air drying system that requires no primer or top
used plastics, even on PTFE! Normally this is done with coat. It is easily applied by spray or brush and is
a sandwich of three thin layers of metal. First a thin compatible with plastics commonly used for
layer of stainless steel, to prevent the softeners in the electronic equipment enclosures.
plastic affecting the shielding. Then a thin layer of
copper for superb shielding performance and finally a
second layer of stainless steel to avoid corrosion.

Frequency Metallisation
(Hz) (dB)
30M 50
100M 68
200M 70
Shielding
500M 74 Performance
700M 72 Shielding effectiveness
900M 70 depends on surface,
shape of gaskets Conductive Silver Coating 3850
26 See Guarantee and material used.
Conductive Glue
E.M. Absorber
Conductive adhesive 398O
Shieldokit
Shieldokit 3980 creates an electrically and
3980
thermally conductive connection between components.
One of the applications is EMI shielding. The glue can
cure at room temperature and has excellent filling
properties. The thickness is like peanut butter,
therefore uneven surfaces can be filled

The product consists of a 80% silver-filled

two-component epoxy-based glue. It is pasty and can
glue metals (copper, aluminium, stainless steel, brass,
etc.), ceramics and most plastics.

Curing Specifications
Ordering
information Temperature Time Silver Content ± 80%
21°C 30 hours Surface Resistance 0.5 Ohm/sq.cm
Shieldokit Specific Resistance 0.0025 Ohm/cm
50°C 3 hours
Conductive Glue.
80°C 2 hours Shelf Life 6 months (cool and dry)
50 grams package.
100°C 1 hour Shear Strength 10-13 N/sq.mm
Part number: 3980 200°C 10 min Temprature (cont.) 150oC
Temprature (brief) 200oC

E.M. Absorber 35OO

This Ferrite based Absorber is both light and Application
flexible and absorbs electronic waves, reduces noise • Wireless Communication
and also absorbs shocks. Depending on the absorber • SAR (Specific Absorption Rate) Reduction
thickness, it covers a range of 30 MHz to 5GHz. • LCD Cable
The thicker type is more effective for lower • FR-Block
frequencies. Conductive and non-conductive adhesive
can be applied on either the top or bottom, or both.
Ordering information
This material can be processed in various forms; Please Specify Dimensions and Thickness.
please ask our engineers to advise you.

Specification
Property Test Value
Hardness 75 + 5 Shore A
Density 3.5 + 0.5 g/cm3
Heat Conductivity 0.5 cal.sec.cm.oC
Thickness (mm) 0.5
Material Ferrite Loaded Rubber
Elongation / 8%
Frequency Range 30Mhz ~ 5Ghz
Reflectivity - 4dB ~ 10dB
Temperature Tolerance - 40oC ~ + 130oC
Conductive AC Permeability μ / 15
absorber based Insulation Resistance 2.5 x 106 V
on Ferrite Electric Strenght 7.9 kv
Tensile Strenght /1.1 x 106 N/m2 27
 Conductive
Tapes 32OO
3. Mounting tape 3205
A double-sided self-adhesive transfer tape for mounting
purposes. This system can be applied much faster than a
conductive glue and can be applied very accurately.
No time required for curing (pressure sensitive version)
For lower resistance and or to fill gaps with a rough
surface we advise you the shieldokit electrical conductive
2 components adhesive (See page 27).

conductive adhesive
siliconised paper

4. Die-cut mounting tape 3206

A soft metal foil, laminated on 2 sides with a conductive
self-adhesive. This is only available in sheets.
conductive adhesive
Conductive metal foil
conductive adhesive
Tapes 3200 siliconised paper

part nr. 3201 3202 3203 3204 3205 3206

1. Metal Tape with conductive self-adhesive
construction
3201, 3202 & 3203
foil material soft copper soft copper aluminium soft copper - soft copper
These tapes can be cut in all widths from 3 mm wide and surface bright tinned bright bright - -
can be delivered from stock. Standard are the 16.5 meter foil thickness 0.035 mm 0.035 mm 0.040 mm 0.035 mm - 0.035 mm
rolls. A width of 25 mm is the most common used size. When total thickness 0.060 mm 0.060 mm 0.065 mm 0.060 mm 0.050 mm 0.085 mm
synthetic synthetic synthetic synthetic synthetic synthetic
you need to cover bigger surfaces contact our engineers for
adhesive conductive conductive conductive conductive conductive conductive
than you can possible better use this tape together with
resin resin resin resin resin resin
copper foil with a non-conductive adhesive for this is cheaper. adhesive
4.5 N/cm 4.5 N/cm 4.5 N/cm 4.5 N/cm 4.5 N/cm 4.5 N/cm
performance
Applications: electrical connection between surfaces
tensile
(sheets / foils), die-cuts, mounting transparent foils, shielding strength
55 N/cm 40 N/cm 25 N/cm 55 N/cm - 55 N/cm
in housings, shielding cables, temporary shielding during tests temperature
(see also shielding foils). 155oC 155oC 155oC 155oC 155oC 155oC
resistance
el. resistance
There are three types of metal tape with conductive through 0.003 Ohm 0.003 Ohm 0.003 Ohm 0.003 Ohm 0.003 Ohm 0.003 Ohm
adhesive available: adhesive
standard roll 10, 25, 50, 10, 25, 50, 10, 25, 50, 10, 25, 50, 10, 25, 50, 10, 25, 50,
Copper tape with conductive adhesive part 3201 widths (mm) 100 100 100 100 100 100
A soft metal foil with a highly conductive self-adhesive on 16.5/33/ 16.5/33/ 16.5/33/ 16.5/33/ 16.5/33/ 16.5/33/
roll lengths
one side, with a release liner. 50 m 50 m 50 m 50 m 50 m 50 m

Tinned copper tape part 3202

As tape 3201 but than with a tin layer for corrosion
protection and better solder ability. Contact Surface Tape
with masking 3204
Aluminium tape part 3203
Special developed for metal foil
aluminium housings and frames conductive adhesive
to prevent galvanic corrosion. siliconised paper

2. Contact Surface Tape 3204

A metal tape with a highly conductive self-adhesive on one
side and a masking tape on the other side.
This contact surface tape is used to improve the
corrosion resistance of construction metals (like un treated
steel plates), or to improve the galvanic compatibility
when 2 metal parts are connected
with a gasket.
After the parts have been coated, masking tape
metal foil
the paint overlaps the metal tape conductive adhesive
28 to increase the bonding. siliconised paper
Knitted Mesh
12OO
The 1200 series EMC gaskets consist of a core
covered with knitted mesh. In most cases the
gaskets are made of sponge or hollow tubes or
extruded elastomers. For special applications like
EMP or high temperatures a full metal version
is available.

The temperature resistance depends on the core

material, but ranges from -60o C to 180o C.
These gaskets are insensitive to external influences
and can withstand harsh conditions very well.
Also available with separate neoprene of silicone
water seal.

The maximum deflection with a sponge

elastomer core is approximately 30%, with hollow
extrusion 50%. This is why the hollow type is used
more often. Knitted Mesh Gasket

Dimensions b

round rectangular round with fin double round

d(mm) b+h(mm) d x b(mm) dxb(mm) d h d d
1.6 3.2 x 1.6 3.2 x 12.7 3.2 x 9.5
3.2 x 1.6 3.2 x 3.2 3.2 x 15.9 3.2 x 12.7
b b
4.8 x 3.2 3.2 x 4.0 3.2 x 19.1 3.2 x 15.9
6.4 x 3.2 3.2 x 4.8 4.8 x 12.7 4.8 x 15.9
d d d
8.0 x 4.8 3.2 x 6.4 4.8 x 19.1 4.8 x 19.1
9.5 x 6.4 4.8 x 4.8 6.4 x 25.4 4.8 x 25.4
11.1 x 8.0 6.4 x 1.6 6.4 x 15.9 b b
12.7 x 9.5 6.4 x 3.2 6.4 x 19.1
14.9 x 11.1 6.4 x 6.4 6.4 x 25.4 Advantages:
6.4 x 9.5
6.4 x 12.7
• high attenuation level for lower frequencies
9.5 x 12.7 • suitable for use under extreme conditions
9.5 x 15.9 (military applications)
12.7 x 12.7 • wear resistant
12.7 x 19.1 • insensitive for corrosion

Magnetic field Electronic field

Material frequency attenuation frequency attenuation Application
MHz dB MHz dB
Monel 0.01 54 1 132 The most common used material.
Per QQ-N-281 0.1 63 10 114 Insensitive to corrosion and neutral
contact points of mesh BS 3075 N A 13 1.0 75 100 112 on the galvanic scale.
Class A 1.000 97
diameter 0.11mm 10.000 89
Aluminium 0.01 54 1 132 Is used in some cases for aluminium
AMS 4187 0.1 62 10 119 enclosures.
BS 1475 5056A 1.0 77 100 124 Aluminium can be chromated with an
Alloy 5056 1.000 97 Alchrome 1200 layer, if necessary.
contact surface of Amucor Shield diameter 0.13mm 10.000 90
T.C.S. 0.01 58 1 132 This material has excellent magnetic
For high frequency Steel Core(57%) 0.1 78 10 119 as well as electrical properties,
Copper cladding(40%) 1.0 82 100 124 because a Ferro alloy is covered with
shielding, foil-based and textile Tin Plating (3%) 1.000 97 copper. The outside is tinned to
bases gaskets like Amucor Shield diameter 0.11mm 10.000 90 prevent corrosion.
6800 will perform better, becau- Stainless Steel 0.01 54 1 132 The strongest material with a
AISI 304 0.1 64 10 115 shielding performance that can be
se of their much larger contact
diameter 0.13mm 1.0 72 100 100 compared with aluminium.
surface hence a better coupling also available with 1.000 89 High resistance against wear.
at higher frequencies. AISI 316 10.000 72 29
 Board Level
Shields
Benefit: thanks to the big clamping range, much less
accurate positioning is needed.
Board Level Recommended distance: depends on frequency and
Shields size - please consult our engineers.
mucopper cover any size

0,12
height
4 - 20 mm.
1,6
clip-on pin
1500
4 3,2

drill hole in
pcb Ø 0,8 mm.
0,14
0,55
Options:
3,0
• flush surface mount
• ventilation holes
• inside insulation sheets
• removable lid / peel shield
• multi compartment shielding
• pre assembled

EMV screening covers for pcb were developed to
shield only a part or parts of electronic equipment
from electromagnetic radiation, rather than the entire
housing. Battery packs, for instance, do not always
need shielding. EMV screening covers are available in
a wide range, both flexible and rigid.
Clip-on System 15OO
This system combines small clip-on pins with a
removable lid and results in high shielding protection.
Fixed 16OO Series
A small framework or fence can be manufactured
by our CNC production system, including pins in any
desired size. Tooling costs are relatively low, and so
this system is well suitable for series of 100 -100,000
pieces so please send your drawing.
Options: Several thicknesses, with or without electrical
insulation and/or (conductive) self-adhesive.
Also available in a flame retardant version.

Benefits: less space on the board, flexible pin
positions making the clip-on system 1500 an
excellent solution for series of 1 - 5,000 pieces.
For heavy duty applications the lid can also be fixed by
extra soldering between the lid and some of the pins.
a. standard through-hole clips with a tinned pin, can be
soldered into the pcb at any available place around the
cover (pin size 0.6 mm, so drill to 0.8 mm).
The minimum height on top of the board is 3 mm.
Drawn Board Level
Shields 17OO
Especially designed for seamless corners for ultra
high frequency shielding.
Available in heights of 0.5 - 8 mm and sizes of
6 - 80 mm.
Available in copper and silver-nickel.
Elastomers can be combined with the drawn board
shield as well as ventilation holes for solder out gassing.

b. mu-copper housing, will fit in the clips even with a

good tolerance of 0.6 mm.
The minimum height of the cover is 3 mm,
the maximum 20 mm.

We advise fixing clip-on pins at least every 20 mm.

We can produce any size with and without ventilation
30 holes in 2 working days.
Fingerstrips
2OOO
For high performance applications, Beryllium Copper finger
stripsoffer the best EMI shielding effectiveness, used in the
right construction. The mechanical spring characteristics far
surpass all other gaskets in the industry, but due the toxicity of
beryllium these strips are not always allowed. Therefore many
shapes are also available in stainless steel.The contact of the
Beryllium copper finger strip tolerates a wiping or sliding
action, so it is ideal for applications where frequent opening
and closing operations are likely. The product comes in a wide
range of profiles (see www.fingerstrips.com) and is also Fingerstrips
available in various plated versions. Standard lengths of 2000
406 mm, some shapes also in 610 mm or even on rolls.

G G H
Clip On B H
Stick On A
D C
2100 series C
2300 series
A
B F
E
F A B C F G H
2301- 01 7,1 2,8 4,6 610 4,8 4,3
A B C D E F G H
2301- 02 7,9 3,0 4,3 457 4,8 4,3
2101- 01 9,7 5,1 7,6 1,8 1,0 406 6,4 5,4
2301- 03 8,1 2,8 5,3 406 4,8 4,3
2101- 02 9,7 9,7 7,6 1,8 1,0 406 6,4 5,4
2101- 03 9,7 7,1 7,6 1,8 1,0 406 6,4 5,4 G
H
A
C
E G
H
B
A F
C
B
A B C F G H
2302- 01 7,1 2,8 5,8 406 4,8 4,3
D F
2302- 04 15,2 5,8 12,7 610 9,5 8,7
A B C D E F G H 2302- 05 19,3 6,4 11,9 610 9,5 8,5
2102- 01 11,4 2,5 6,9 1,0 3,6 406 4,8 3,6 G
H
2102- 02 11,4 2,5 6,4 1,5 4,1 406 4,8 3,6 A
2102- 06 11,9 3,0 5,1 2,0 2,7 457 4,8 3,8

G B
E H F

A B F G H
A 2303- 01 6,4 2,3 406 4,8 4,3
2303- 02 9,7 3,0 406 4,8 4,3
B C
D 2303- 03 13,0 3,8 406 6,4 5,8
F

A B C D E F G H
B G
2103- 01 27,8 5,5 6,0 3,4 8,1 406 9,5 8,7 H

2103- 02 27,9 6,4 7,4 1,5 8,0 406 9,5 8,5

Twisted Finger
2103- 06 27,9 6,4 6,9 2,0 8,5 406 9,5 8,5 2300 series A

G F

A B C F G H
A C H
2401- 01 12,5 1,6 4,8 610 4,2 3,7
B
2401- 02 12,7 1,8 4,8 610 4,2 3,8
D B G
F H

A B C D F G H
C
2105- 01 6,9 0,8 7,1 2,3 406 6,4 5,6 A

2105- 08 7,8 1,5 4,8 4,5 406 4,8 3,6

2105-19 15,6 1,0 4,8 5,3 406 4,8 3,6 F

A B F G H
2402- 01 5,8 0,8 610 2,4 2,0
G
2402- 02 8,6 1,6 610 4,2 3,7
Snap On B Rivets To
Suit Holes
H
2402- 03 12,7 3,1 610 6,0 5,4

2200 series A

C
Mounting by
holes on your
construction
F
Door Finger F

A B F G H 2800 series A A2

2202- 01 9,1 3,0 381 4,8 4,3

2202- 04 13,0 3,6 381,0 4,8 4,3 H
G
B
2202- 05 19,3 5,6 381,0 9,6 8,8
A B C D E F G H
C G 2801- 01 27,2 32,5 6,4 0,1 ø 3,8 503 9,5 8,5
H
B 2801- 02 39,5 48,3 10,3 0,2 ø 3,6 503 12,7 11,7
A C
F
B

F A A2

A B C F G H
2203- 01 7,6 1,9 3,3 406 4,8 4,3 B H
G

2203- 07 11,2 4,0 3,6 381 6,4 5,8 A B C D E F G H

2203-10 20,3 - 8,1 400 9,5 8,7 2802- 01 25,7 30,5 6,4 2,9 3,6 503 9,5 8,5
31
 Faraday cage
Mu-Copper wallcovering system

We produce Faraday cages, shielded chambers,

shielded tents and other shielding materials like power
& signal filters (page 35), waveguides, shielded doors
(page 34) and windows (page 21), and honeycomb
ventilation panels (page 18 & 19). In addition, tempest
equipment for crypto communication and even welded
EMP bunkers are our business.

From our big standard range in stock we deliver

to the cage building industry. We also design items
according to the customer's wishes, with very short
delivery times.
Wall Paper System Mu-Copper
Wallcovering System
Mu-Copper Shielding Performance Mu-copper cage
dB
Mu-Copper foil has high damping properties in
the electrical field (up to 120 dB) as well as in the 140
magnetic field (see table). It is easy to apply, like 120
wallpaper, thanks to its special adhesive for walls, 100
ceilings and floors. The finishing can be plasterboard,
80
foam tiles or plywood.
60

This product enables creating a Faraday cage 40

with high shielding performance yourself in an 20
economic way, using local labour. Both in existing 0
buildings and in new ones, without loss of space. 0 1 200 1 10 100 1000 1500 2000 2500 3000
KHz KHz KHz MHz MHz MHz MHz MHz MHz MHz MHz
Depending on the quality of the doors, vent panels,
filters and windows covered, damping of up to 60-80
dB in the E-field can be realised in an existing room
Shielding Performance
Basic Values for the Material
in just a few days, without loss of space.
When double layers are applied, it is possible to Field Frequency Mu-Copper
achieve over 120 dB. H 1 kHz 22 dB
H 10 kHz 35 dB
The standard width is 1000 mm or 40”. About 10-15% more than H 200 kHz 68 dB
the net surface is needed for overlap and lost. E 10 kHz 99 dB
E 200 kHz 127 dB
E 1 MHz 125 dB
50 mm overlap soldered seaming tape
E 18 MHz 101 dB
P 400 MHz 120 dB
P 1 GHz 110 dB
mounting frame P 10 GHz 120 dB
conductive wall with metal covering Shielding performance of mu-Copper foil 0,12mm thick
covering
EMI shielding
gaskets Ceilings
Detachable ceiling to separate existing ducts and
cables from the shielded room.
detachable ceiling panels
top side provided with mounting
conductive layer strips
Applications: EMC test rooms, computer rooms,
medical examination rooms (MRI, EEG, EMG & EVP),
rooms for physiotherapy, radar protection, tempest
plasterboard For more information please sites, military EMC protection or even complete
take alook at our website buildings for intelligence agencies.
32 www.faradaycages.com
 Faraday cage
for high & low freqencies

Prefab Faraday Cages

Single Layer (Modular)
Tent
Our prefab shielding system is designed to meet or
exceed the vast majority of shielding requirements.
This system is available both in standard modular
enclosures and custom-designed modular enclosures
to meet exacting specifications in government,
industry, r&d, university or hospital use. Modular
cages are provided with single or double knife edge
finger strip doors (page 34).The standard module is
1.09 meters.
Outside dimensions
Length x Width
in meters
Faraday Tents 1090 x 1170
1090 x 2260
Mounting on wall or ceiling, or in a stand-alone-frame. 2180 x 2260
Made of strong and highly conductive fabric to save 3270 x 2260
space. For experiments, measurements, mobile 3270 x 3350
military/forensic activities in the field. We can produce 4360 x 2260
4360 x 4440 Prefab Faraday Cage
them in any shape or dimension: pyramid (with
5450 x 5530
a single point mounting rope), cubic, or cylindrical.
Sizes range from 0.5 to 15 meters. Doors are fitted Dimensions
with magnetic strips or Velcro strips.
Standard Height: 2315 mm. Other dimensions on request.

Shielding Performance Tents Shielding Performance Prefab Cage

dB dB

140 140

120 120

100 100

80 80

60 60
double
layer
40 40

20 20
single
layer
0 0
0 1 200 1 10 100 200 500 1000 1500 2000 0 1 200 1 10 100 1000 1500 2000 2500 3000
KHz KHz KHz MHz MHz MHz MHz MHz MHz MHz MHz KHz KHz KHz MHz MHz MHz MHz MHz MHz MHz MHz

Anechoic Chambers
Our Anechoic Chambers are constructed as
shielded rooms. All over the walls and the ceiling, Anechoic Chamber
absorbing materials and/or ferrite tiles are attached.
The Anechoic Chambers show superb shielding perfor-
mance and are mainly applied in EM emission testing
according to commercial and military standards.
The Anechoic Chambers are used to perform
compliant radiated immunity tests in accordance to
EMC-standards such as IEC / EN 61000-4-3.
They provide a full compliance immunity test site for
the frequency range of 30 to 1000 MHz. Also suitable
for future free space emission test, pr EN 50147-3.
We also build open area test sites. 33
 Doors for
Faraday cages
We specialize in designing and manufacturing
standard and custom doors: high performance single Locking Mechanism
& double knife edge fingerstrip doors, sliding doors
and double shielded doors. Our engineers will assist
to find the best solution possible.
We also produce sets to shield doors with gaskets
on top and sides, while the bottom is provided with a
conductive copper brush and doorstep.
See the drawing at the bottom of this page.

Sliding Doors
The opening procedure of the sliding door is
performed in two steps:
• Unlatching of the contact spring system and outward
movement;
• Sideway movement of the door leaf.
Door for
The movements of the door and ramp are fully
Faraday
automatic; they are operated electrically and
Cages
pneumatically. Each opening and closing of the door
has a self-cleaning effect on the contact surfaces.
Sizes range from 1 x 2.1 meters to a 'jumbo' door
Fingerstrip Doors of 8 x 12 meters.
The fingerstrip doors are well known for their high
shielding performance and are used in prefab cages Options for Doors:
as well as together with our Mu-Copper systems. • Automatic locking
We manufacture single fingerstrip doors for medium system with 2 doors
shielding performance and double fingerstrip doors for • Lowered doorstep
high shielding performance (damping up to 140 dB). • Automatic closing systems
Delivery from stock in various dimensions. • Sound reduction
Options: fire proof, automatic closing, gas tight, • Clean room specifications
locking system.
Standard Sizes
Standard shielded leaf
doors in steel/wood or Fully
steel frames Automatic
Width : single 800 / 1200 mm,
Sliding
double 1500 / 2000 mm
Door
Height : 2000 / 2100 /
2500 mm

Double 75 mm

Fingerstrip Fingerstrip
frame
Door Door metal plate
58 mm

gasket Ultra Soft Shield door

Mu-copper
To achieve the attenuation levels required, our flap
metal sheet

doors are equipped with at least two rows of beryllium

40 mm plywood
48 mm

adjustment bolts
copper "fingers" around the periphery of the door. In
the closed position, the fingers contact the edge of copper brush

34 the door to assure an RFI/EMI leak-proof seal. hinge door

copper doorstep
RFI/EMI/EMP/NEMP
shielding filters for power and signal lines

We offer a selection of RFI signal, power and data

transmission filters and EMI filters. Apart from the
standards we stock, we also design custom EMI/RFI
filters for your specific application. For the entire
range and extra high performances up to 120 dB,
EMP filters and NEMP filters, please refer to
www.faradaycages.com
To allow for cable entry in Faraday cages we
produce filter plates or shielded racks, equipped with Power Filter
high performance power filters, also including the & Telephone Filter
cable passage of digital signals like ISDN and UTP
(internet/network connections), etc. We manufacture A21
signal filters for even higher performance as in the 27,5 B 8,5
8,5
case of tempest applications, and we can also provide
a system which uses optical technology and
waveguide passage.

Power Filters 3 - 200 Amp (A) Specifications M4 Serrage - Tighten: 3 max M4

Part Current C L Ohmic Leakage Weight A B Curve
7 s/plats - on flats M16 x 1.5
Number max (A) (μF) (μH) resitance current max. (mm) (mm)
max under (gr)
(m) Ω 250v -
50Hz
max. (mA)
HSS-3AW 3 0.1 270 85 17.3 140 105 60 1
HSS-5AW 5 0.22 80 22 38 175 105 60 1
HSS-5AV 5 0.1 80 22 17.3 175 105 60 2 24 s/plats - on flats Ø 45
HSS-10AW 10 0.47 110 11 81.2 300 131 86 1
HSS-10AV 10 0.22 110 15 38 280 105 60 2
HSS-25AW 25 0.47 65 5 81.2 420 146 101 1 Attenuation: 50 Ω
dB MIL - STD 220 A
HSS-32AW 32 0.47 30 3 81.2 420 146 101 1
HSS-32AV 32 0.22 30 3 38 420 146 101 2 100
HSS-50AW 50 1 40 <1.5 <173 860 192 115 1
HSS-50AV 50 0.47 40 <1.5 <81.2 860 192 115 2 80
HSS-100AW 100 1 7 <0.7 <173 880 199 122 1 70
HSS-100AV 100 0.47 7 <0.7 <81.2 880 199 122 2 60
HSS-200AW 200 1 2 <0.4 <173 940 217 140 1 1
HSS-200AV 200 0.47 2 <0.4 <81.2 940 217 140 2 2
40

6 6 20
68 14
MHz
10 25
0
Tighten max 11 0.01 0.1 1 10 100 1000
Snap 2.8 Pick Ø 0.8
1.5

Protected side
Telephone Filters with NEMP Lighting Protection,
Ø 30 32 on flat 32 on flat 2 Leads
M27 x 1.5
Part Under used Impendence Pass band Resistance Curve
Attenuation: GAMT21 TCM 50 Ω Number Ω t 3 dB Ω
dB
1 2 3 4 5 1400 Telephone 600 50 kHz < 1.5 1
70
CN DT 19200
60
bauds
50
1500 56 kbits/s 600 500 kHz < 1.2 4
40
1600 64 kbits/s 100/120 500 kHz < 1.2 1
30
1700 144 kbits/s 100/120 1 MHz <1 2
20 1800 256 kbits/s 100/120 2 MHz < 0.5 3
10 1900 512 kbits/s 100/120 5 MHz < 0.5 4
0
0,01 2 5 0,1 1 10 100 1000 MHz
2000 2.048 kbits/s 100/120 10 MHz < 0.5 5 35
