BENCHMARK, NEXES, DISCOVERY, SLS, VENTANA, and the VENTANA logo are trademarks of Roche.
The Ventana System Software (VSS) 12.1 is protected by contract law, copyright laws, and international treaties.
The Ventana System Software (VSS) 12.1 is licensed for use between Ventana Medical Systems, Inc.and a licensee, and only users authorized
there under are permitted to access and use the software. Unauthorized use and distribution may result in civil and criminal penalties.
Warranty
Ventana warrants and represents that when used per instructions, the Products will perform in accordance with the relevant Product specification
for a period of 12 months from the date of delivery or installation of system or instrument. Reagents are warranted until their respective expiry
dates. Ventana reserves the right to change the design or specifications of the Products at any time. Ventana will provide Customer prior notice
of any change in design or specification that materially affects Product performance. Ventana further warrants that the Products do not infringe
the patent rights of third parties. In the event of a court order of patent infringement results in an interruption in the Customer's continued use of
the Products, Ventana shall, at its option, either (a) ) provide for the Customer at Ventana's expense the right to continue using the affected
products; or (b) ) modify or replace the affected products so that the products become non-infringing, but only if the modification or replacement
does not negatively affect the performance of the products or their use by the Customer. THE FOREGOING WARRANTY IS IN LIEU OF ALL
OTHER WARRANTIES. VENTANA DISCLAIMS ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ALL WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE., Ventana will have no liability for any claim of infringement to
the extent that it is based on materials or modifications made by Customer or a third party at the request of Customer. This Section 4 states the
entire liability of Ventana and the exclusive remedy of Customer with respect to any alleged infringement. Ventana's warranty obligations are
contingent upon Customer: (i) ) notifying Ventana of a warranty claim within ten (10) days after having knowledge of same; (ii) ) providing
sufficient detail of the facts associated with a warranty claim in writing so as to allow Ventana to reasonably reproduce any alleged defects in the
Products, or demonstrate to Ventana such defect.
Revision History
Manual Version Revision date Changes
12.1 November 2012 Updated instructions for cleaning waste tub and drain.
Chapter 7, clarified that after a staining run completes, slide specific information is listed
on the Run Report or Case Report.
Contact
www.ventana.com
24814EN Rev E v
Contents BenchMark ULTRA Advanced Staining System Operator Guide
24814EN Rev E ix
Contents BenchMark ULTRA Advanced Staining System Operator Guide
24814EN Rev E xi
Contents BenchMark ULTRA Advanced Staining System Operator Guide
24814EN Rev E xv
Contents BenchMark ULTRA Advanced Staining System Operator Guide
Figure 118. Instrument View displaying the Reagent Grid with Zoom control,
Reagent Wheel, and Print icon ...................................................................101
Figure 119. Reagent Histogram View with Reagent Grid View Enabled .....................101
Figure 120. Reagent Grid and Multiple Column Sorting ..............................................102
Figure 121. Selected Reagent Access Point at Shortcut Icon with Reagent Pick List ...102
Figure 122. Report for Last Staining Run ......................................................................103
Figure 123. View Last Reagents ....................................................................................103
Figure 124. Register Ventana Products .........................................................................104
Figure 125. Product Registration Probe .........................................................................104
Figure 126. New Product in the Inventory List .............................................................104
Figure 127. Titration Information ..................................................................................105
Figure 128. Create a Titration Protocol .........................................................................106
Figure 129. Add a Titration Step to a Protocol ..............................................................106
Figure 130. Save Protocol ..............................................................................................106
Figure 131. Manual Applications Icon ..........................................................................108
Figure 132. Manual Applications List. ..........................................................................108
Figure 133. Titration Message in Communicator ..........................................................109
Figure 134. Select a Titer Run .......................................................................................109
Figure 135. Bulk Bottle Connectors ..............................................................................111
Figure 136. Waste Level Monitor ..................................................................................113
Figure 137. Set Maximum Waste Level ........................................................................114
Figure 138. Waste Container Lock ................................................................................115
Figure 139. Carboy, Spigot, and Threaded Connector ..................................................115
Figure 140. Spigot and Locknut .....................................................................................116
Figure 141. Spigot Handle Positions .............................................................................116
Figure 142. Control Block Information .........................................................................118
Figure 143. Log Control Slides ......................................................................................119
Figure 144. View Control Block Information ................................................................120
Figure 145. View a Series of Control Slides ..................................................................120
Figure 146. Enter a Case Request ..................................................................................121
Figure 147. List of Cases ...............................................................................................122
Figure 148. Cases Ordered .............................................................................................122
Figure 149. Select a Staining Run ..................................................................................123
Figure 150. Enter Quality Control Results ....................................................................123
Figure 151. Print Quality Control Results .....................................................................124
Figure 152. Quality Control Report ...............................................................................125
Figure 153. Case Report ................................................................................................127
Figure 154. Contact List ................................................................................................128
Figure 155. Contact Form ..............................................................................................128
Figure 156. Daily Maintenance Log ..............................................................................128
Figure 157. Inventory Report .........................................................................................129
Figure 158. Inventory Product Usage ............................................................................129
Figure 159. Detail Usage Report for Dispensers ...........................................................130
Issued by CSA.
Intended Use
The BenchMark ULTRA Advanced Staining System is intended to automatically stain histological or
cytological specimens on microscope slides with specific immunohistochemistry or in situ hybridization
reagents for in vitro diagnostic use. Evolved from the BenchMark series of instruments, the BenchMark
ULTRA instrument fully automates the processes of baking, deparaffinization, and staining.
Intended Purpose
The system is intended to be run by trained laboratory personnel, such as histotechnologists and laboratory
technicians, who are expert in histology processes and have basic computer operation skills. The system is
intended to be installed in an anatomical laboratory environment and must be used in a manner consistent with
industry practices for safety, security, regulatory, environmental, ergonomic, workflow, and information
technology.
FCC Information
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide
reasonable protection against interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy; if not installed and used in accordance with
the instruction manual, it may cause interference to radio communications. Operation of this equipment in a
residential area is likely to cause interference, in which case users will be required to correct the interference at
their own expense. There is no guarantee that interference will not occur in a particular installation. If this
equipment does cause interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a different circuit from the one the receiver is connected to.
• Consult the dealer or an experienced radio/TV technician for help.
Specifications
Physical Characteristics Stainer Assembly (05342716001 / 750-600)
Size (W x D x H w/rear cover 44.00” x 28.30” x 62.40” (111.76 x 71.88 x 158.50 cm)
removed)
Electrical
Characteristics U.S. and Canada Japan Europe
Power Connection Cord suited to country. For U.S., standard 3-prong grounded.
Environmental Requirements
Temperature Control
General Characteristics
Welcome
The BenchMark ULTRA Advanced Staining System takes the automated staining process to a new level.
• Continuous and random access increase efficiency and boost throughput.
• Dual and triple staining expand medical utility.
• New software gives the operator instant and easy access to staining information.
• Reducing manual laboratory touch points improves safety.
The BenchMark ULTRA instrument’s expanded features advance the staining process while maintaining the
BenchMark instrument standard of excellence and ensuring compatibility with current Ventana Medical
Systems, Inc. (Ventana) systems and products.
Description
The BenchMark ULTRA system includes a hardware staining instrument, reagents, host computer with system
software, connectivity software, and system peripherals. The staining instrument performs all operations
required to automatically process slides for immunohistochemistry (IHC) and in situ hybridization (ISH)
staining.
The system’s two main components are a computer with software and a staining instrument. The software can
be linked to as many as eight instruments so the operator can monitor and manage all instruments from a single
workstation. The software and instruments communicate with each other continuously. Instrument sensors read
slide and reagent bar codes, monitor fluids, and track slide processing and feed the information to the
computer. The computer plans the staining run, tells the operator which reagents to load, and starts the run at
the push of a button. During the run the instrument continues to detect conditions and feed information to the
computer.
The computer provides a graphic view of each instrument. It tells the operator where each slide is in its
processing, which reagent containers to remove or load, and when waste containers need to be emptied. It
announces problems, needs, or errors in a message display panel, and by simply resting the cursor on a slide
image, the operator can view slide information such as patient and doctor identification, protocol, and dates.
Similarly, resting the cursor on a reagent image brings up information such as reagent name and number,
dispenses left, and expiration date.
The BenchMark ULTRA system also expands and enhances functions that support slide processing, including
automating protocol handling, label printing, orders, inventory, case management, reagent registration,
reporting, and system maintenance.
24814EN Rev E 1
1 Welcome BenchMark ULTRA Advanced Staining System Operator Guide
System Capabilities
Staining Capabilities
The BenchMark ULTRA system automates IHC and ISH BTS on microscope slides in anatomical pathology,
including formalin-fixed paraffin-embedded sections, cytology preps, and frozen sections.
Operating Capabilities
• Random processing: Stain any slide with any process, independent of other slide states or processes.
• Single piece flow: Add new slides for processing and remove completed slides while the processing of
other slides continues. If you need to add or remove reagents, you can schedule a system-calculated
pause—called a reagent access point. Reagent access points are intervals when you can access to the
reagent carousel to add or remove a reagent without harming or delaying the runtimes of slides in process.
• Modularity: Add staining systems as capacity or lab needs increase.
• Flexibility: Optimize protocols, reagents, and timing to facilitate best lab practices and tissue fixation.
Staining Management
The BenchMark ULTRA system can be integrated with current VENTANA Advanced Staining Systems or
BenchMark Special Stains systems for the purposes of performing staining operations for clinical and research
diagnostics.
• Accession, run, and report the staining process and manage reagents, staining protocols, users, and slide
cases.
• Quick visual presentation of system, slide, and case status.
IHC
The ability to define and store protocols for IHC staining ensures reliable, high-quality results. Protocols are
defined step by step and saved on the computer. When IHC staining is required, you can recall the protocol and
print it on a slide bar code label. The staining instrument reads the protocol from the bar code and applies the
defined detection procedure and staining process.
ISH
• Faster turnaround of routine and complex staining.
• Reduced processing time—SISH 6 hours and IHC 2 ½ hours.
Dual Stains
• Simultaneous phenotyping and genotyping—IHC and ISH.
• Multiple markers recognized on a single slide—IHC and IHC, ISH and ISH.
• The Laboratory Information System (LIS) interface connects the laboratory system to an institutional LIS
to send and receive data or enhance workflow in the laboratory.
• Central Management synchronizes multiple Ventana host computers and associated staining systems to
easily deploy and integrate the system into the laboratory workflow.
• The VENTANA Image Analysis System (VIAS) interface connects to the VIAS system to provide data
needed to maintain or enhance imaging workflow.
Vantage Compatibility
The VENTANA Vantage workflow solution can reduce errors by improving the ability to track slides. It
eliminates or reduces multiple labeling of specimen slides, unnecessary specimen batching, and lack of
information about specimen locations.
• Recognizes both barcode symbology and 2D symbology.
• Reduces slide handling errors.
24814EN Rev E 3
1 Welcome BenchMark ULTRA Advanced Staining System Operator Guide
Safety Compliance
All safety related regulations, local codes, and instructions that appear in the manual or on equipment must be
observed to ensure personal safety and to prevent damage to the instrument or equipment connected to it. If
equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment
may be impaired.
Avoiding Injury
Biological and Chemical Hazards
Some of the reagents used in immunohistochemistry are hazardous. Be aware of local regulations and correct
procedures for handling and disposing of hazardous material. When working with any reagent or reagent
container, take appropriate precautions.
Reagent may collect around the container lid during transit and storage and be released when the reagent lid is
opened. Open containers carefully.
During system operation, reagent may collect around the slide staining assemblies and could contaminate slide
trays. Though risk to people and surroundings is minimal, routine precautions should be observed while
handling slide trays.
CAUTION: When working with any reagent or reagent container, take appropriate precautions.
CAUTION: Always wear approved eye protection, gloves, and protective clothing when you handle
reagents, reagent containers, slide trays, or preparation trays.
Spills
Clean spills with a disinfectant solution such as Lysol IC or equivalent. Do not allow xylene, chloroform,
acetone, strong acids (like 20% HCl), strong alkalis (like 20% NaOH), or other similar solvents near the stainer
subassembly. Clean up any spills immediately.
24814EN Rev E 5
2 Warnings and Precautions BenchMark ULTRA Advanced Staining System Operator Guide
WARNING: Place mats around the instrument to avoid risk of slipping in the event of reagent
spills or leaks.
CAUTION: Place caps on waste carboys before removing them from the instrument.
CAUTION: Wheel waste carboys to the disposal area instead of lifting them.
Instrument Location
The instrument is very heavy and is not designed to be moved by the user. Please contact an approved service
representative if you need to re-locate your instrument. This instrument is for indoor use only.
Safety Training
All operators must be trained in the safe use of the BenchMark ULTRA instrument. After training, operators
must demonstrate understanding of the following:
• The instrument must be connected to a grounded outlet.
• The instrument must be connected to a voltage source that complies with the rating label.
• Using instruments in a manner not specified by Ventana Medical Systems, Inc. (VMSI) may impair
protection provided by the equipment.
• Filters and tubing may be replaced only by VMSI service technicians.
• Operators must use caution when interacting with the reagent carousel, dispensers, and dispenser actuator,
when changing reagents during a reagent access point.
• Operators must keep their hands clear of potential pinch points, including slide trays and the reagent
carousel.
• Operators must consult the Material Safety Data Sheets for instructions for safe handling and disposal of
reagents used with the instrument.
Electrical Hazards
Dangerous voltages are present inside the instrument. Only VMSI approved service technicians should remove
any of the instrument covers or access the internal components of the instrument.
The instrument’s operating voltage is set during installation and may be changed only by VMSI approved
service technicians.
The instrument must be connected to a grounded power outlet that is easily accessible to VMSI service
technicians.
Use only power strips provided or approved by VMSI.
In the unusual circumstance that the instrument supply voltage is to change, contact VMSI to have the setting
changed. Severe damage may occur if the instrument is connected to an incorrect power supply voltage.
WARNING: Place mats around the instrument to avoid risk of electrical shock in the event of
reagent spills or leaks.
WARNING: Only service technicians authorized by VMSI should take apart any component of the
instrument.
WARNING: Only open the instrument hood during a scheduled reagent access point.
24814EN Rev E 7
2 Warnings and Precautions BenchMark ULTRA Advanced Staining System Operator Guide
Symbols
The following symbols are used in the BenchMark ULTRA Advanced Staining System.
PROTECTIVE EARTH
24814EN Rev E 9
2 Warnings and Precautions BenchMark ULTRA Advanced Staining System Operator Guide
System Components
Staining Instrument
The staining instrument houses slide drawers, a reagent dispensing system, bulk reagents, and waste
containers. It is controlled by the Ventana System Software (VSS).
Computer
The computer comes with all system software installed and runs Windows-based programs. From one to eight
BenchMark ULTRA instruments can be connected to it using communications cabling. The computer includes
a hardware key used by the software for quality control, data management, and security.
24814EN Rev E 11
3 The BenchMark ULTRA System BenchMark ULTRA Advanced Staining System Operator Guide
Products
All dispensers and most bulk reagents are compatible with the BenchMark XT instrument. However, ULTRA
CC1, ULTRA CC2, and ULTRA LCS have been specifically optimized for use with the BenchMark ULTRA
instrument. Reagents may be purchased from Ventana or from other suppliers. Products from other suppliers
must be registered in the VENTANA system. They should be validated by the customer and the validation
records retained, in accordance with CAP/CLIA and other applicable regulatory guidelines.
The instrument is designed and validated to use the following slides:
• 1 x 3 inch, 25 x 75 mm, and 26 x 76 mm original Superfrost Plus charged slides for tissue sections.
• Tripath slides for the Tripath HPV application.
• Cytyc slides for the Cytyc LBP application.
If slides other than those listed above are used, the customer should refer to the glass manufacturer’s
instructions for use, validate the slides, and keep the validation records, in accordance with CAP/CLIA and
other applicable regulatory guidelines.
Monitoring a Run
In the Ventana System Software you can monitor all connected instruments in a single glance. Color-coded
indicators show the status of reagents, slides, bulk reagents, and waste level for each instrument. Information
and warning messages tell you what the system is doing and alert you to any problems or required actions.
The software also provides a detailed view of each instrument, with instrument, reagent dispensers, slides, and
waste represented as images. You can mouse over or click images to see detailed information. Details can
include time to run completion, countdown to the next required action, type of action required, and status of
bulk bottles and waste containers. Histogram views of slides and reagents present real-time details for current
processing.
24814EN Rev E 13
3 The BenchMark ULTRA System BenchMark ULTRA Advanced Staining System Operator Guide
Staining Slides
As the staining run progresses, the reagent carousel and instrument nozzle plate swing back and forth on an arc,
dispensing and removing reagents. Vortex mixers ensure the reagents are mixed and applied evenly to the
slides. A chemical-based liquid coverslip is applied to each slide to prevent evaporation of reagents,
dehydration of tissue, and drying artifacts. Between reagent applications, a dual rinse washes slides clean and
leaves a controlled amount of buffer solution on them. A pressurized-hose system dispenses bulk reagents and
moves fluid to the waste containers. When a staining run is complete, green lights flash on the instrument slide
drawers.
Reagent Hood
A large semi-circular transparent hood covers the reagent carousel. To protect slides, operator, and equipment,
the lid locks automatically when the stainer is running.
Reagent Carousel
The reagent carousel (1) holds 35 reagent dispensers in five
trays of seven dispensers each. Dispenser trays (2) are
removable. When not in use, they are stored on magnetic
tray holders that help protect dispenser tips. When installed
on the reagent carousel, the trays are secured by mounting
holes that fit over mounting studs on the carousel.
Slide Drawers
Independent slide drawers are numbered 1 to 30. Slides can be
loaded in any drawer in any order. Every drawer runs
independently and has its own open and close button and
individual status lights. You can use the software to locate all of
the slides in an order. Located slides are indicated by a blue light
at the bottom of the slide drawer.
Each slide rests on a slide heating pad in the bed of the slide drawer. The temperature of each pad is controlled
independently by software and staining protocols.
A Slide Control Panel, located between drawers 15 and 16, provides a separate set of buttons to operate
multiple drawers simultaneously. You can open all available drawers, open all drawers with completed slides,
or close all open drawers. The same operations can be done using a similar Slide Control Panel in the Ventana
System Software. You can also operate slide drawers using the Selected Slide Actions in the software. The
actions are Abort, Open, or Close. Any action can be applied to one or more selected slides.
Bulk Reagents
Up to seven bottles of bulk
reagent are loaded at the front
of the instrument. Bottles are
translucent so you can see
their fluid levels.
Each bottle is secured to the instrument with a quick-disconnect latch and backed up by a reservoir that holds
fluid for an additional 30 slides. Fluid from the bottle runs into the reservoir, and the reservoir pushes the fluid
onto the slides. A float in the reservoir tells the system when the fluid level is too low. If fluids are not
sufficient for the planned run, the system alerts the operator and waits for the problem to be corrected.
Waste Containers
Two 20-liter waste containers sit behind the two front
doors at the bottom of the instrument. Tubing carries
waste liquid through the cap opening into the
container. While a container is in use, the instrument
locks it in place. Sensors above the containers detect
the fluid levels. When one container is full the
Figure 8. Waste Containers instrument switches to the other one and prompts you
to empty the full one. The waste container icon on the
Instrument Status Panel indicates whether a container
is removed or in use. Waste levels are also displayed
on the computer.
24814EN Rev E 15
3 The BenchMark ULTRA System BenchMark ULTRA Advanced Staining System Operator Guide
Global Navigation
The Global Navigation bar is at the top of the screen. From anywhere in the system, the Global Navigation
icons go directly to: 1) Home View, 2) the Login window, 3) the Order List, where you can view and manage
orders and labels, and 4) the Inventory List, where you can view and manage products.
Instrument Bar
The Instrument Bar is below the Global Navigation. It shows status information for each instrument connected
to the computer. Status is indicated by colored lights. When an instrument is connected and idle, its indicators
are green. During slide processing, indicators are yellow.
(1) Instrument status indicators.
(2) Next operator action.
(3) Time until next action.
Figure 11. Instrument Bar
Communicator
The Communicator shows information and error messages for connected instruments. Each message is
associated with a timestamp and an icon representing the message type. For error messages, a Sign Off button
appears at the right of the panel. You can click the resize arrow to expand or shrink the message area. You can
also enter notes about a message.
Home View
When the software starts up, the Home View appears in the lower part of the screen. It shows the same data as
the Instrument Bar, but in a graphic format. It also provides System buttons to go to other software functions
and an Instrument Setup button for configuring instruments. You can click the Home icon in the Global
Navigation to return to this view from anywhere in the system.
Instrument View
The Instrument View shows processing information and has buttons that operate the instrument. To go to an
Instrument View, you click the instrument name in the Instrument Bar or the instrument image in the Home
View.
24814EN Rev E 17
3 The BenchMark ULTRA System BenchMark ULTRA Advanced Staining System Operator Guide
Feature Description
1 Instrument Home From other views accessed from Instrument View, returns you to the Instrument
icon View.
2 Reagent Access Displays a list of available reagent access points that you can select from
Shortcut icon without having to navigate to the slide or reagent histogram.
3 Reagent icon Opens the reagent histogram where you can see details for each dispenser on
the reagent carousel.
4 Slide icon Opens the slide histogram where you can see details for each slide drawer and
real-time slide processing information for loaded slides.
5 Instrument Opens Instrument Maintenance where you can print maintenance logs and
Maintenance icon check lists, record maintenance done, and run functions to decontaminate the
instrument or clean the slide drawers.
6 Clean icon Starts an instrument cleaning cycle with one mouse click. The instrument must
be in sleep mode.
7 Slide images Displays which slide drawers are available and in use and the status of the
slides on the instrument.
8 Reagent wheel Displays which reagent slots are available and in use and the status of the
reagent dispensers on the instrument.
9 Reagent Grid icon Opens the reagent grid that displays recently scanned reagent information.
10 Instrument name Displays the instrument name and the next operator action.
11 Bulk bottles Monitor the status of bulk reagent bottles and internal reservoirs.
Feature Description
13 Maximum Waste Specifies the maximum fluid levels for the maximum waste containers.
Level slider
15 Sleep button Places the instrument into sleep mode to reduce wear when not in use.
24814EN Rev E 19
3 The BenchMark ULTRA System BenchMark ULTRA Advanced Staining System Operator Guide
Step Reference
1 Start the system Chapter 5, Start and Stop the System, page 27
2 Refill bulk bottles Chapter 13, Remove or Replace a Bulk Bottle, page 111
3 Empty waste containers Chapter 13, Empty and Replace a Waste Container, page 115
Start Up
1. Start the Ventana System Software. If the instrument is off, turn the power switch On (I=On).
2. Click the instrument name in the Instrument Bar. The
Instrument View opens, showing reagent and slide
status, bulk and waste fluid levels, and instrument
mode.
3. Click the Ready button to activate the instrument so you
can load slides. When the drawers are ready to use, their
lights turn green.
24814EN Rev E 21
4 Perform a Staining Run BenchMark ULTRA Advanced Staining System Operator Guide
CAUTION: Handle waste containers carefully.To avoid injury, wheel the carboy to the disposal area.
To prevent spillage, put the cap on the carboy before removing it.
Create Labels
1. At the Home View, click the Create Label button. SLS opens.
2. Click the Protocols button. The Select Slide Labels options appear.
Option What To Do
2 The default label template is displayed. You can use the default template or click the
arrow to select a different template.
3 For each label you want to print, click a protocol, and then click the Add button. The
protocols appear in the Label(s) to Print list.
4. Click the Close/Print button. The label template appears. The first label in the list is highlighted.
Option What To Do
6. Click the Print button to print the label. Repeat the same steps for each label in the list.
NOTE: If you click the Cancel or Close buttons and leave SLS, the labels will still be selected when
you return to SLS.
24814EN Rev E 23
4 Perform a Staining Run BenchMark ULTRA Advanced Staining System Operator Guide
2. In the Order List, select the slide orders that you want a list of reagents for. To select more than one order,
CTRL click each order. To select a group of orders, SHIFT click the first and last orders in the group.
3. Under Actions, click the Printer button, and then select Pick
List.
4. At the confirmation message, click Yes to print the pick list.
5. The pick list opens in Print Preview. Click the Printer button
to print the pick list. Click the Close button when you are
finished. Figure 25. Print Pick List
Load Slides
1. At the Instrument View, make sure the instrument is in Ready mode. If necessary, click the Ready button.
When the instrument is ready to use, the slide drawer lights will turn green.
2. Press the Open All Available Drawers button on the instrument Slide Control Panel.
24814EN Rev E 25
4 Perform a Staining Run BenchMark ULTRA Advanced Staining System Operator Guide
NOTE: You can print a Run Report to keep as a record of the staining run and the protocols and
reagents used. (See Print Run Reports, page 87.)
NOTE: If you use AEC detection procedure, do not dehydrate and clear the slides. Mount with
aqueous mounting medium.
24814EN Rev E 27
5 Start and Stop the System BenchMark ULTRA Advanced Staining System Operator Guide
Start an Instrument
1. Turn on the instrument. The switch is inside the
left door below the bulk bottles. I = On. O = Off.
When the power is on, the power icon in the
Instrument Status Panel lights up.
The software starts communication with the
instrument. The instrument’s name appears in the
Instrument Bar, and its image appears in the
Home View. Its status indicators in the Instrument
Bar are green.
Startup Modes
A summary of startup modes is provided below. For more details, see About Startup Modes, page 34.
Sleep The instrument is on, but the compressor • Open the reagent hood and install or
is not running, and slide drawers are remove reagent dispensers.
inactive and unlit. • Remove and install bulk reagents.
The instrument name shows in the • Remove and install waste
software Instrument Bar. containers.
Instruments start up in Sleep mode when • Go to the software Instrument View.
they are turned on. To save wear, an
• Change the startup mode to Ready.
instrument can be put to sleep by clicking
the Sleep button.
Ready The instrument is pressurized and • Remove and install bulk reagents.
accessible. • Remove and install reagent trays.
Status indicators in the Instrument Bar • Remove and replace waste
and slide drawer lights on the instrument containers.
are green.
• Load slides.
• Go to the software Instrument View.
• Change the startup mode to Sleep
or Running.
Running The system plans the run, locks the • Install or remove bulk reagents and
reagent hood and loaded slide drawers, unlocked waste containers.
and processes the slides.
• Go to the software Instrument View.
While the run is being compiled (before • Load slides into empty drawers.
processing begins), the reagent hood
can be opened to install or remove • Remove completed slides.
reagents. During processing the reagent • Cancel selected slides.
hood can only be opened during a • Schedule a reagent access point.
reagent access point.
Stop an Instrument
You can either turn off the instrument completely or put it to sleep. In Sleep mode, the instrument doesn’t
maintain pressure, but it starts up faster than if it is turned off completely. It also retains information about the
last reagents used and displays it in the reagent wheel in the software Instrument View and Reagent Histogram.
To put an instrument to sleep:
1. Click the instrument name in the Instrument Bar.
2. At the Instrument View, click the Sleep button.
To shut down completely, turn off the instrument On-Off switch (I=On. O=Off.)
24814EN Rev E 29
5 Start and Stop the System BenchMark ULTRA Advanced Staining System Operator Guide
WARNING: To avoid damaging important VENTANA system files, always exit the software
before turning off the computer.
Instrument Parts
(1) Reagent hood
(2) Reagent carousel
(3) Independent slide drawers
(4) Slide Control Panel
(5) VENTANA button
(6) Instrument Status Panel
(7) Bulk reagents (backed up by reservoirs)
(8) Waste containers (behind doors)
24814EN Rev E 31
6 Operate the Staining Instrument BenchMark ULTRA Advanced Staining System Operator Guide
1 Click the button to connect the instrument to or disconnect it from the host computer.
2 Enter or change the instrument name. The name entered here will appear on the
Instrument Bar and in the Instrument View.
4 Click the color bar and select a color. The color selected here will appear on the
Instrument Bar and in the Instrument View.
3. To exit Instrument Seup, click the Home icon. You will be prompted to Save your changes. You can click
Yes to save the changes, No to exit without saving the changes, or Cancel to remain in Instrument Setup
without saving the current changes. The settings you save will appear in the Instrument Bar, Home View,
and Instrument View.
Feature Description
2 Bulk reagents Turns red when a bulk bottle is missing or internal reservoir space
is insufficient.
3 System error Turns red to indicate an error or problem with the instrument.
24814EN Rev E 33
6 Operate the Staining Instrument BenchMark ULTRA Advanced Staining System Operator Guide
Sleep Mode
In Sleep mode, the power is on and the instrument is communicating with the software, but the compressor is
off. The lights on the slide drawers are unlit, and the drawers can’t be opened. The reagent hood is unlocked,
and dispensers, bulk fluids, and waste containers can be added or removed.
There are two ways to get to Sleep mode:
1. The instrument starts up in Sleep mode when you turn on the power switch.
2. Click the Sleep button in the Instrument View. Putting the instrument to sleep when it isn’t in use reduces
wear. Typically, this is done only once a day when you are through using the instrument.
CAUTION: Before putting the instrument to sleep, make sure no slides are left in the drawers.
Ready Mode
In Ready mode, the reagent hood is unlocked, and dispensers, bulk fluids, and waste containers can be added or
removed. The slide drawers can be opened and closed to load slides. All of the slides loaded in Ready mode
will run as a batch. In batch mode, a problem with any single slide will prevent the whole batch from running
until the problem is corrected. (After the batch run begins, the instrument is in Running mode, and any slides
added will run individually.)
There are two ways to get to Ready mode:
1. Click the Ready button in the Instrument View.
2. When the instrument has completed a staining run (all slides in all drawers are completed), it waits for a
brief period, then automatically returns to Ready mode.
Running Mode
In Running mode, the system processes slides. To start Running mode, you click the Running button in the
Instrument View. Typically, this needs to be done only for the first run of the day. After the first run, the system
may return to Ready mode, but if you load more slides, it will start automatically after a short pause.
Processing Slides
When you start a run from Ready mode, the system compiles the run for the initial batch of slides. The reagent
hood and all drawers must be closed before the run will begin.
During compiling, the reagent hood and slide drawers remain unlocked. The yellow lights on the slide drawers
flash. The system checks each drawer to see if a slide is loaded. If a drawer is empty, its light turns green.
Drawers where slides are detected continue to flash yellow. If everything needed for every slide in the batch is
present, the system locks the hood and the drawers that contain slides. The yellow lights on the slide drawers
stop flashing. In a few minutes, the run starts.
If something is wrong or missing, the drawer lights flash red and the status indicators in the software
Instrument bar turn red. The hood and drawers remain unlocked. The run will not start until everything is ready
for all of the loaded slides.
24814EN Rev E 35
6 Operate the Staining Instrument BenchMark ULTRA Advanced Staining System Operator Guide
Stop an Instrument
You can either turn off the instrument completely or put it to sleep. In Sleep mode, the instrument may not
maintain pressurization, but it starts up faster than if you turn it off with the switch.
To shut an instrument down completely, turn its On-Off switch to Off (O).
To put an instrument to sleep, make sure all the slides have been removed, then go to Instrument View and
click the Sleep button.
IMPORTANT: For efficiency and to reduce wear on the instrument, it is best to make sure all reagents
and slides are loaded before you start Running mode.
While the instrument is staining slides (the yellow lights on the drawers stop flashing), the hood automatically
locks. When all slides are completed, the slide drawers flash green and the hood is unlocked.
WARNING: Never try to force the hood open or bypass the locking system.
Groups of Drawers
Press a button on the Slide Control Panel located between drawers 15 and 16.
On the Computer
Selected Drawers
1. Click the instrument name in the Instrument Bar.
2. At the Instrument View, click the slide image for
the drawer you want to operate. To select more
than one drawer, CTRL click each image.
Selected drawers are outlined.
3. Right-click any selected slide image, and then
click Open Selected or Close Selected.
24814EN Rev E 37
6 Operate the Staining Instrument BenchMark ULTRA Advanced Staining System Operator Guide
Groups of Drawers
1. Click the instrument name in the Instrument Bar.
2. At the Instrument View, click a button on the software Slide Control Panel.
WARNING: To be detected a slide must be loaded into the drawer correctly. It should be seated
between the two posts with the label facing up and inward.
IMPORTANT: You can open and close each drawer individually, but processing starts sooner if you
close all the drawers at once.
Cancel Slides
1. Click the instrument name in the Instrument Bar.
2. At the Instrument View, click the image of the slide
you want to cancel. To select more than one slide,
CTRL click each image. Selected drawers are
outlined.
3. Right-click any selected drawer, and then click Abort
Selected.
24814EN Rev E 39
6 Operate the Staining Instrument BenchMark ULTRA Advanced Staining System Operator Guide
Solid Blue Three minutes to add or remove reagents on the reagent carousel.
IMPORTANT: If you do not close the hood, the system will continue to operate. However, if there is a
dispense step required for a slide while the hood is open, that slide will be aborted. Follow the power
fail sequence to recover the slide (refer to Remote Software, page 172).
Close hood A red icon that means it is time to close the hood.
You have one minute to close the hood before the reagent
carousel sweeps back to position 1.
6. When you are done, close the instrument hood. The instrument
hood locks and the reagents are scanned. The drawer lights begin
to turn off and the instrument alarm stops.
24814EN Rev E 41
6 Operate the Staining Instrument BenchMark ULTRA Advanced Staining System Operator Guide
View the Selected Reagent Access Time and the Reagent Pick List
1. In the Instrument View, click the Reagent Access Shortcut icon.
The selected time and a reagent pick list displays to help you
manage the reagents that need to be added and can be removed.
2. To deactivate the reagent access point, click on the button with
the red hood icon and time.
Figure 52. Selected Reagent Access Shortcut Icon with Reagent Pick List
Schedule Reagent Access Points From Slide and Reagent Histogram Views
You can view and set reagent access points from both the Slide and Reagent Histogram views. The histogram
views provide reagent access information in multiple ways and in the context of processing slides or reagent
usage.
Figure 53. Setting Reagent Access Points from the Slide Histogram View
Figure 54. Selected Reagent Access Point from Reagent Histogram View with Reagent Pick List
NOTE: Notice that the medium blue and light blue bands are not always the same size. This is because
in certain instances you will have only one reagent access point at a time, or you will have multiple
contiguous reagent access points. The size, number, and color of the sections that display depend on
the type and number of protocols being run at any given time.
3 The square button indicates when multiple contiguous access points are available for selection.
4 The round button indicates when only one reagent access point is available.
5 Once a reagent access point has been selected, a dark blue band will appear and the unselected
reagent access points will be disabled (grayed out) and a reagent pick list will be available for viewing
and printing.
24814EN Rev E 43
6 Operate the Staining Instrument BenchMark ULTRA Advanced Staining System Operator Guide
The square button depicted displays both the reagent icon and the first reagent
access point available from a menu of reagent access times.
IMPORTANT: You have one minute to open the reagent hood when the reagent access point begins.
6. Open the reagent hood and add or remove reagents on the reagent carousel.
CAUTION: Only open the instrument hood during a scheduled reagent access point. Keep hands clear
of hot surfaces and moving parts.
7. When you are done, close the instrument hood. The instrument hood locks and the reagents are scanned.
The drawer lights begin to turn off and the instrument alarm stops.
Maintenance
Maintenance Check List
Task Daily Monthly Quarterly Reference
*Cleaning slide drawers as needed is generally done once per day, before the first run or after
the last run.
Daily Maintenance
Wipe External Surfaces
Wipe external surfaces with a soft, damp cloth.
CAUTION: Handle filled waste containers carefully. To prevent spillage, place the cap on the carboy
before removing it from the instrument. Wheel the carboy to the disposal area instead of lifting it.
24814EN Rev E 45
6 Operate the Staining Instrument BenchMark ULTRA Advanced Staining System Operator Guide
Order List
To open the Order List, click the Orders icon in the Global Navigation.
*The Order List may be missing slide specific information after the staining run has completed. All
information can be obtained from the Run Report or Case Report for these slides.
Feature Description
1 View Use Layout and Group by options to view and organize orders.
24814EN Rev E 47
7 Manage Slide Orders BenchMark ULTRA Advanced Staining System Operator Guide
Feature Description
6 State Key Colors used to indicate the status of slides in the State column.
9 Records Displayed Shows the number of order records displayed in the list.
Column Description
Show Displays a blue button when the slide location feature is activated.
Label Appears black when a label has been printed and gray when a label has
not been printed.
State Displays a color-coded status for each slide. Corresponds to the State
Key located above the list.
Protocol Number Lists the protocol number for the order and the slide label.
Protocol Name Lists the protocol name for the order and the slide label.
Column Description
Patient Name Shows the name of the patient whose tissue is being tested.
Block ID Lists an identifier used to track a tissue block through the system.
Anatomic Site Lists the site where a tissue sample was taken from the patient.
Surgical Procedure Lists any surgical procedure associated with the patient’s care.
Custom 1 and 2 Fields defined by the laboratory manager and unique to each facility.
Date Entered Shows when the order was entered into the system.
Column Options
Use the Column Options List to sort the data in a column.
1. Right-click a column heading. The Column Options list box opens.
2. Select Sort Ascending or Sort Descending. All of the records in the list are sorted by the values in the
heading.
3. To go back to the original order, right-click the column heading again, and then select Clear Sorting.
24814EN Rev E 49
7 Manage Slide Orders BenchMark ULTRA Advanced Staining System Operator Guide
Custom Filters
You can create filters to make it easier to locate a specific order or to sort an order set.
The Order List will remember the last custom filter you applied using the Filter Builder. You can then reapply
the filter directly from the Layout menu.
1. To open the Filter Builder, click the Filter button (1), and then click the Customize button (2).
2. In the Filter Builder, you can either set up a new filter or open a filter you created and saved earlier. After
you select or create the filter, click the Apply button. Only the records defined in the filter remain in the
Order List.
3. If you create a new filter click Save As, enter a name for the filter, and click Save.
4. Click the OK button to close the filter.
5. In the Layout menu, select another option, such as Printed Case Slide Orders. The grid changes to display
the new set of records.
6. To re-use the last filter applied, open the Layout menu again and select Custom.
Order Maintenance
The Order List provides maintenance options so you can delete out of date or incomplete records from the list.
Because each order is a separate record, you need to delete the record and then save the changes. To restore a
record, you can cancel the changes.
Find Orders
Because the Order List shows all orders currently in the system, you will want to sort the list to view specific
orders or use the quick find feature to look up orders.
• Use the Layout and Group by options to sort orders.
• Use the Find feature to quickly search for orders.
• Right-click a column heading and select a Group by option to group order records by that column.
24814EN Rev E 51
7 Manage Slide Orders BenchMark ULTRA Advanced Staining System Operator Guide
Feature Description
1 The banner shows the column heading used to group the records. Drag and drop a
column heading onto the banner. Drag it off to remove it.
2 The header separates the first group of Label records (the non-generated group).
3 The header Separates the second group of Label records (the generated group).
Print Orders
From the Order List you can print reports, labels, or pick lists. Click the Print button, and then do any of the
following:
• Select Grid to print an order report.
• Select Label to print slide labels.
• Select Pick List to print a pick list of reagents.
• Select Screen to print a screen shot of the Order List.
Option What To Do
Staining Instrument After a staining run begins, this field shows the instrument name.
Slide Position After a staining run begins, this field shows the slide position number.
State Shows the status of the slide order: pending, processing, completed,
error. For new orders, pending is the default.
Protocol Number Click the look up button and choose a protocol from the Select Protocol
options. (Required)
Protocol Name If blank, choose a protocol number. The protocol name appears in this
field.
24814EN Rev E 53
7 Manage Slide Orders BenchMark ULTRA Advanced Staining System Operator Guide
Option What To Do
Accession ID, Block Type an identification number for each item. The ID number tracks the
ID, Case ID, Slide item through the system.
ID, Patient ID
Anatomic Site Type the site where the tissue sample was taken from the patient.
Surgical Procedure Enter the surgical procedure associated with the patient’s care.
NOTE: Slide data can’t be changed while a slide is on the staining instrument.
3. Click the Save button to confirm the changes, or click the Cancel button to exit without saving the changes.
4. Click the Close button to return to the Order List.
Feature Description
1 Protocol Number—If a single protocol is selected, the protocol number is displayed.
If multiple protocols are selected, “Multiple Protocols” is displayed.
2 Protocol Name—If a single protocol is selected, the protocol name is displayed. If
more than one protocol is selected, “Multiple Protocols” is displayed.
3 Pop-up Box—Pausing the mouse on the words “Multiple Protocols” opens the pop-
up box. It shows the first 10 protocols selected and the summary information from
the Select Protocol view.
4 • Save button—Records the orders in the Order List and closes the Order Details
view.
• Save and Print button—Records the orders in the Order List, closes the Order
Details view, and prints the slide labels.
• Cancel button—Closes the Order Details view without saving.
24814EN Rev E 55
7 Manage Slide Orders BenchMark ULTRA Advanced Staining System Operator Guide
Feature Description
1 Quick Find By Value—Type a number to find all protocols whose names or numbers
include that number. To clear the field, press the BACKSPACE key, or select the
number and press the DELETE key.
2 Filter Options—After selecting protocols, click Display Selected to view the selected
protocols only. To return to the complete list, click Display All.
3 Protocol Number and Protocol Name—You can click the headings to sort protocols
by number or name.
4 Order Count—Click in the Order Count field to specify the number of orders to
create for each protocol. You can specify any number from 0 to 100. You can type
the number, click the up or down arrow in the count field to increase or decrease a
number, or double-click the protocol name to increase the number by 1.
5 Summary Protocols—Protocols Selected displays the number of protocols selected.
Order Count shows the total number of orders that will be created from the
selections.
Feature Description
6 • Re-create Orders button—Activated when an order count is entered for a
selected protocol. Records new orders in the Order List and closes the Select
Protocol view.
• Re-create and Print Orders button—Activated when an order count is entered for
a selected protocol. Records new orders in the Order List, closes the Select
Protocol view, and prints the slide labels.
• Clear Order Counts button—Activated when an order count is entered for a
selected protocol. Clears all order counts, clears the Quick Find By Value field,
and sets the filter to Display All.
• Selection Complete button—Activated when protocols are selected for a new
order or changed for an existing order. Transfers the protocol information to the
Order Details view and closes the Select Protocol panel.
• Cancel button—Closes the Select Protocol view without saving selections.
IMPORTANT: Once the orders are saved, they are no longer a batch. Each order becomes a separate
record in the Order List. For the best use of the batch functions, make sure all order details are
complete before you click the Save button.
24814EN Rev E 57
7 Manage Slide Orders BenchMark ULTRA Advanced Staining System Operator Guide
Re-create an Order
If you have created an order and need to run additional protocols for the same patient, you can quickly re-create
the order for each additional protocol. The original order will not be changed.
1. In the Order list, select the order you want to copy (1).
2. In the Actions buttons, click the Maintenance button and select Re-create (2). The Select Protocol panel
opens.
3. For each protocol you want to add, click in the Order Count field and specify the number of orders to create
for this protocol. The number of protocols selected and the total number of orders that will be created
appear in the Summary at the bottom of the panel.
IMPORTANT: Before continuing, check the summary and make sure the order count is correct.
4. When your selections are complete, you can do any of the following:
• Click the Re-create Orders button to save the new records and return to the Order List.
• Click the Re-create and Print Orders button to save the new records, print the slide labels, and return to
the Order List.
• Click the Clear Order Counts button to remove all order counts, clear the Quick Find By Option, and
set the Filter to Display All.
• Click the Cancel button to close the Select Protocol view without saving the records.
Edit an Order
To edit an existing order, double-click the record in the Order List. The new Order Details view opens without
the Order Count column. You can change patient information or select a different protocol. Click the Save
button to save your changes. Click the Cancel button to exit Order Details without saving.
Delete an Order
1. Open the Order List, and then select the order you want to delete. To select more than one order, use CTRL
click.
2. Click the Maintenance button, and then select Delete. The order record is removed from the list.
3. To save the changes, click the Save button. To cancel the deletion, click the Cancel button.
24814EN Rev E 59
7 Manage Slide Orders BenchMark ULTRA Advanced Staining System Operator Guide
To use the buttons go to the protocol selection view, click the appropriate button and proceed as usual.
24814EN Rev E 61
8 Create Staining Protocols BenchMark ULTRA Advanced Staining System Operator Guide
3 Zoom dial Increase or decrease font size of the Protocol Editor View.
5 Select Protocol Options Display selectable protocol options in a pop-up or sidebar view.
1 Green check box The protocol step is complete and the protocol can be saved.
2 Red X The protocol step has selectable options that are not complete.
3 Blue underlined text A selectable option that you can click and fill in with a specific value.
Protocol Views
The Create/Edit Protocols View provides a pop-up window or a sidebar view to display protocol options
(incubation time, temperature, reagents type, etc.) for the protocol step. One mouse click on a protocol option
activates a pop-up window that lists the available entries for the option. The pop-up window is the default
view.
24814EN Rev E 63
8 Create Staining Protocols BenchMark ULTRA Advanced Staining System Operator Guide
3. If the pop-up window has multiple options that are not visible at one time, the Find feature will allow you
to search the box by keyword.
• In the Find box, type the first few characters of a word, and then press Enter. The cursor highlights the
next instance of the word.
4. When you are finished with your selection, click OK to go back to the Protocol Editor View.
24814EN Rev E 65
8 Create Staining Protocols BenchMark ULTRA Advanced Staining System Operator Guide
NOTE: The Protocol Full Procedure report shows all details for a protocol including steps,
reagents, and the actions the instrument performs. This report can include many pages.
24814EN Rev E 67
8 Create Staining Protocols BenchMark ULTRA Advanced Staining System Operator Guide
NOTE: In the Protocol Number box, you can also type digits to go to a range of numbers. For example,
if you type in 300, the list will begin at 300. The list number is incremented by each digit you enter. For
example, entering 2 will take you to the second number in the list. Entering another 2 will take you to
number 22, and so on. You can still use the scroll bar to move up and down from any point in the list.
Use the BACKSPACE key to erase the last number typed.
5. Click the Save button. To quit without saving the protocol, click the Cancel button.
6. After you save a protocol, click the Print button to print a protocol report. The Print Protocol Report
options appear.
7. Click either the Full Procedure tab to print a detailed report, or the Protocol Summary tab to print a short
report.
8. Under Select Procedure, select a detection procedure from the list box.
9. Under Select a Protocol, click a protocol to select it. To select more than one, CTRL click each protocol.
Click and drag the scroll button to move up and down in the list.
10. Click the Print Report button to open the report in Print Preview. Click the Printer button to print the report
on the default printer.
Modify a Protocol
IMPORTANT: If you modify a protocol, you must also update the label that you print in the SLS. Before
you apply a label to a slide, check that the label includes the correct protocol.
1. At the Home View, click the Protocols button, and then click Create/Edit Protocols. The Protocol Editor
appears.
2. In the Procedure list box, click the list box arrow to select a detection procedure.
3. Under Protocol, click either Name or Number to indicate whether to look up the protocol by name or
number, and then select a protocol from the list box. The protocol’s definitions appear.
4. Edit the protocol by adding or removing options. Click the check box next to a step to add it to or remove
it from the protocol. Click the list box arrow to select additional options.
5. When your changes are complete, do one of the following:
• Click the Save button to keep the protocol under its current name and number.
• Click the Save As button to save the protocol under a new name and number.
• Click the Clear button to remove your changes.
NOTE: You can also print a protocol report as described in the Create and Print a Protocol section.
However, only users who are assigned the Print Protocol Reports privilege have access to the Print
button in the Protocol Editor.
24814EN Rev E 69
8 Create Staining Protocols BenchMark ULTRA Advanced Staining System Operator Guide
Delete a Protocol
1. At the Home View, click the Protocols button, and then click Manage Protocols.
2. Under Protocol(s), click a protocol to select it. To select more than one, CTRL click each protocol.
3. Click the Delete button. The system prompts you to confirm your deletions.
3. Under Select Procedure, choose a detection procedure from the list box.
4. Under Select a Protocol, click a protocol to select it. To select more than one, CTRL click each protocol.
5. Click the Print Report button. The report opens in Print Preview. Click the Printer button to print the report.
When you are finished, click the Close button.
2. Under Select Protocol, click a protocol to select it. To select more than one, CTRL click each protocol.
3. Under Date Range, click Available Dates to print all dates that the protocol was used. To specify a
different date range, click another item in the list or click Custom, and then type the Start Date and End
Dates (or click the calendar icon to select a start or end date).
4. Click the Print Report button. The report opens in Print Preview. Click the Printer button to print the
report. When you are finished, click the Close button.
24814EN Rev E 71
8 Create Staining Protocols BenchMark ULTRA Advanced Staining System Operator Guide
CAUTION: Handle slides carefully to avoid injury. Use universal precautions to avoid potential blood
borne pathogen exposure.
Slide labels are printed using the SLS. All labels must include a bar code and a protocol name. You can add
information to the rest of the label for your own purposes.
Two font sizes are provided: small and large. The large font cannot print on the line shown above the bar code
in the figure. Maximum characters in each font are listed below.
Small Large
Dates displayed in split (half) fields will be formatted without separators, e.g., “Feb 8, 2000” becomes
“020800” on the label, even if the template specifies otherwise.
24814EN Rev E 73
9 Generate Slide Labels BenchMark ULTRA Advanced Staining System Operator Guide
Label Handling
• Store labels at 22-32°C.
• Labels may be applied before deparaffinizing with solvents.
• Labels must be applied after baking or microwave treatment.
• Make sure the label does not extend past any edge of the slide.
• You can handwrite information on a label using a fine-point, permanent marking pen. Do not write on the
transparent flap.
• Do not trim the lot number section of the label. Make sure the lot number section is secured tightly to the
slide.
• Limit Xylene exposure to the minimum necessary for optimal tissue processing (15 minutes maximum).
• Do not let a coverslip overlap the label. The coverslip will not seal and will eventually fall off. Most
automated coverslip lengths are adjustable. See your user’s manual or contact the manufacturer for more
information.
Option What To Do
Select Template The default label template is displayed. If you want to use a different
template, click the list box arrow and select another label template.
Option What To Do
Protocol List For each label you want to print, click a protocol. To select multiple
protocols, use CTRL click.
Copies Enter the number of copies to print for the selected protocol.
4. Click the Add button. The selected protocols appear in the Label(s) to Print list. To remove a protocol from
the list, select it, and then click the Remove button.
5. Click the Close/Print button. The Ventana Slide Labeling System view opens.
6. Type the accession number and other text you want to appear on the label, and then click the Print button.
The next label moves to the top of the list. Continue entering text and printing each label until the list is
empty.
IMPORTANT: If you modify a protocol, you must also update the label that you print in the SLS. Before
you apply a label to a slide, check that the label includes the correct protocol.
24814EN Rev E 75
9 Generate Slide Labels BenchMark ULTRA Advanced Staining System Operator Guide
Option What To Do
Select Template The default label template is displayed. If you want to use a different
template, click the list box arrow and select another template.
Protocol List Select the protocol you want to use for the batch.
Copies Enter the number of copies to print for the selected protocol.
4. Click the Save as Panel button. The Enter Name for this Panel dialog box appears. Type a name for the
batch, and then click the Save button.
5. To print the labels, click the Close/Print button. To exit the Select Slide Labels options without printing,
click the Clear button, and then click Close/Print.
NOTE: If you selected slide labels to print and then exited SLS without printing them, the labels will
remain selected until you print, remove, or clear them, or exit the VSS. If you click the Cancel or Close
button and leave SLS, the labels will still be selected when you return to SLS.
Option What To Do
Delete Label button Click it to delete the highlighted label from the list. The system prompts
you to verify that you want to delete the label.
Clear button Click it to remove all labels from the list and cancel printing. The system
prompts you to verify that you want to clear all labels from the list.
Print button Click it to return to the SLS and continue printing slide labels.
24814EN Rev E 77
9 Generate Slide Labels BenchMark ULTRA Advanced Staining System Operator Guide
1. At the Home View, click the Create Label button. The SLS opens.
2. Click the Protocols button. The Select Slide Labels view appears.
3. Click the History tab.
4. Select the labels you want to reprint, and then click the Add button.
5. To print the labels, click the Close/Print button. The Select Slide Labels options appear.
6. Type the accession number and other text you want to appear on the label, and then click the Print button.
The next label moves to the top of the list. Continue entering text and printing each label until the list is
empty.
NOTE: Before printing a label, make sure the label printer is connected to the computer, is turned on,
and has enough label stock loaded to print the labels.
NOTE: If a slide is loaded on the instrument, the text in the Slide Data record appears gray and you
cannot modify it.
4. Click the Save button to confirm the changes. Click the Close button to return to the Order List.
24814EN Rev E 79
9 Generate Slide Labels BenchMark ULTRA Advanced Staining System Operator Guide
CAUTION: Handle slides carefully to avoid injury. Use universal precautions to avoid potential blood
borne pathogen exposure.
About Slides
The BenchMark ULTRA instrument has 30 independent slide drawers, numbered from right to left. Slides can
be loaded in any order. Every drawer runs independently and has its own open and close button, status lights,
and independently controlled slide heater.
If there are any problems during a run, slide status indicators in the Instrument Bar turn red, and error messages
appear in the Communicator. After the problems are corrected and the messages are signed off, the run will
start again.
24814EN Rev E 81
10 Work with Slides BenchMark ULTRA Advanced Staining System Operator Guide
Cancel a Slide
1. Click the instrument name in the Instrument Bar.
2. At the Instrument View, click the slide you want to
cancel. The slide is outlined. To select more than
one slide, CTRL click each slide. To unselect a
slide, click it again.
3. Right-click any selected slide and select Abort
Selected. A confirmation message is displayed.
Click the Yes button to confirm the action.
Monitor Slides
Instrument Bar Status
From any software view, you can see a slide status indicator in the Instrument Bar.
Computer does not Slide drawers are Slides are being Slide error or action
detect slide drawers. idle and ready to use. processed. required.
Slide Details
1. Click the instrument name in the Instrument Bar.
2. At the Instrument View, stop the mouse cursor on a slide image. A pop-up box displays the slide
information.
3. Double-click the slide to display its order details. The Order Details Slide Data view opens.
4. In Order Details, click the Protocols button. While a slide is processing, protocol details show the steps in
the slide protocol, including the time each step occurs and how long it takes. Each step is represented by a
bar that fills with blue to indicate progress. Use the scroll bar on the right to scroll through the list of steps.
24814EN Rev E 83
10 Work with Slides BenchMark ULTRA Advanced Staining System Operator Guide
24814EN Rev E 85
10 Work with Slides BenchMark ULTRA Advanced Staining System Operator Guide
5. In the Slide Data Type to Print list box, select the slide data to appear on the report.
6. In the list of runs, click a run, and then click the Print Report button. To select more than one run, use
CTRL click or SHIFT click.
24814EN Rev E 87
10 Work with Slides BenchMark ULTRA Advanced Staining System Operator Guide
7. A Print Preview window appears so you can review the report before you print it. Click the Printer button
to print the report. When you are finished, click the Close button.
4. In the Edit Slide Data form, click any cell, type in new data, and then click the Save button.
3. Click the New Report button. The system prompts you to enter a new report name. Enter a unique name,
and then click the Save button.
4. In the Print Case Report options, design the report.
24814EN Rev E 89
10 Work with Slides BenchMark ULTRA Advanced Staining System Operator Guide
Option What To Do
Date Range Select a date range for the runs to include on the report.
Selection
To enter a Custom Date Range, type a Start Date and End Date or click
the down arrow and select a date.
Primary Data Click an option to define the first category used to sort slide data.
Grouping
Secondary Data Click an option to define the second category used to sort slide data.
Grouping
Slide Data Sort Click an option used to sort the slides in a staining run.
Options
Slide Data to View Check marks indicate the options already selected. Click a check box to
select additional options.
Select which Report Select whether you want report headers, reagent, bulk, or error
Bands to Show information to print on the report.
5. The records that meet the report criteria are displayed. Do either of the following:
• Click the Print button to print the case report. A Print Preview window appears so you can review the
report before you print it. When you are finished, click the Close button.
• Click the Save Definitions button to save the report settings in the computer. The system prompts you
to verify that you want to save the report.
24814EN Rev E 91
10 Work with Slides BenchMark ULTRA Advanced Staining System Operator Guide
3. In the Options box, select the check box to include the slides that were started at the same time, which is
usually the first run of the day. The software will automatically select the other slides that were batched
together.
4. In the Include sections box, select one or more check boxes to include Reagent Usage, Bulk Usage, or
System Messages on the report.
• To deselect a report option, uncheck the box to clear it.
• In the Slide Data Type to Print list box, select the slide data to appear on the report.
5. In the Successful Runs list, select the runs that you want to consolidate into one report. To select more than
one order, use CTRL click or SHIFT click.
6. Click the Print Report button. If enabled, the Print Preview window displays so you can review the report
before you print it.
7. Click the Printer icon to print the report.
8. When you are finished, click the Close button.
Manage Reagents
About Reagents
The BenchMark ULTRA instrument holds 35 reagent dispensers in five reagent trays. Each dispenser is
labeled with a bar code. Dispensers and their contents are logged and registered in inventory, so the system
knows what is in each dispenser and how many applications are left. When a run starts, the instrument reads
the bar codes to determine which reagents are loaded. The software calculates how much of each reagent is
needed to complete the run. After the run, the system updates inventory records by subtracting the reagent used
from the starting level for each dispenser.
Status Indicators
If there are any problems during a run, the reagent status indicators in the Instrument Bar turn red and error
messages appear in the Communicator. The affected run will not start until all the required reagents are loaded
and the message is signed off.
Dispensers
Reagents may be purchased from Ventana or from other suppliers. VENTANA reagents come in plastic
dispensers. Reagents purchased from other suppliers are put into VENTANA dispensers. Each VENTANA
dispenser has a bar code label and a dispenser chamber. For use, the dispenser is snapped into a dispenser tray,
and the tray is mounted on the instrument’s reagent carousel.
Duplicate Products
More than one kit or reagent of the same type can be on the reagent carousel at the same time. The system
automatically selects which dispensers to use on each slide. Selections are based on the following rules.
• Dispensers from different kits of the same type may not be used on the same slide.
• The product that will expire soonest is used first if possible.
• If any dispenser in a kit is too low to process the next slide for that kit, the kit with the next oldest
expiration date is used. If two products have the same expiration date, the one with the fewest tests
remaining is used first.
Pick Lists
Best practice is to make sure all reagents needed for a run are loaded before you start the run. Occasionally you
might need to schedule a reagent access point to add or change reagents.
24814EN Rev E 93
11 Manage Reagents BenchMark ULTRA Advanced Staining System Operator Guide
CAUTION: Only open the instrument hood during a scheduled reagent access point. Keep hands
clear of hot surfaces and moving parts.
NOTE: When Login Passwords are not enabled, all users have privileges to manage reagent
access points as the default.
Reagent Access
Sequence Instrument Indicators Description
Reagent access Blue lights flash on each Over the span of one minute, the blue lights will begin to
sequence begins. slide drawer. turn off starting from slide position one and 30, moving
Instrument will alarm inward to slide positions 15 and 16. This blue light
when the hood and sequence visually alerts you to the passing of the ability
reagent carousel are to open the reagent hood over the one minute time
unlocked. period.
The instrument will alarm during the one minute time
period when the reagent hood and reagent carousel are
unlocked.
Once all the blue lights turn off, the reagent hood will
automatically lock and the reagent carousel will be
scanned.
24814EN Rev E 95
11 Manage Reagents BenchMark ULTRA Advanced Staining System Operator Guide
Reagent Access
Sequence Instrument Indicators Description
Reagent access Red lights flash on each After three minutes have passed and the reagent hood is
sequence ends. slide drawer. still open, one minute will remain to finish the reagent
Instrument will alarm access action and close the reagent hood.
when the hood is open. The red lights on each slide drawer will begin flashing
and will turn off starting from slide position one and 30,
moving inward to slide positions 15 and 16.
The instrument will alarm and increase in urgency during
the one minute time period when the reagent hood is
open.
When the hood is closed, the reagent hood will
automatically lock and the reagent carousel will be
scanned.
If the reagent hood is not closed prior to the end of the
close reagent hood alarm before all the red lights turn off,
the reagent carousel will sweep back to position one and
the red lights will continue to flash and the instrument will
alarm.
IMPORTANT: If you do not close the reagent hood before the one minute time period elapses, any
slides that require an immediate reagent dispense will be aborted.
If one or more reagent dispensers were added, the reagents will not be qualified until the reagent hood
is closed and the reagents are rescanned.
Install a Tray
1. Lift the tray from the magnetic tray holder.
2. Make sure the dispensers are snapped into the tray.
3. If the dispensers are capped, remove the caps and place them on the dispenser cap holders.
4. Check each dispenser to see if each dispenser chamber contains a drop of reagent. If necessary, prime the
dispensers.
5. Slip the tray mounting holes onto the carousel mounting studs. Make sure the tray is settled firmly on the
carousel.
Remove a Tray
1. Lift the tray off the reagent carousel.
2. Put it in a tray holder.
3. If the tray is to be stored, replace the caps
on the dispensers and put the tray in the
refrigerator.
24814EN Rev E 97
11 Manage Reagents BenchMark ULTRA Advanced Staining System Operator Guide
Monitor Reagents
Check Reagent Status
From anywhere in the Ventana System software, you can see a reagent status indicator in the Instrument Bar.
3. For more details, double-click a dispenser slot. Product details are displayed. To return to Instrument
View, click Close.
• The vertical lines indicate time. The red vertical line marks the present time. The shaded area on the
left represents the past. The unshaded area to the right represents the future.
24814EN Rev E 99
11 Manage Reagents BenchMark ULTRA Advanced Staining System Operator Guide
• Each horizontal bar represents a reagent dispenser on the reagent carousel. The length of the bar
represents the amount of time the reagent is needed to finish the current run. The color of the bar
indicates the dispenser status.
• The slider above the histogram zooms the timeline from 1 hour up to 48 hours.
3. Pause the mouse cursor on a bar to open an information pop-up box.
4. For more details, double-click a bar. To return to the histogram, close the display.
5. To move the slider, click and drag it with the mouse.
6. To return to Instrument View, click the Instrument button at the left of the slider.
Figure 118. Instrument View displaying the Reagent Grid with Zoom control, Reagent Wheel, and Print icon
• To close the reagent grid and return to the previous view—click the Close icon.
Figure 119. Reagent Histogram View with Reagent Grid View Enabled
Figure 121. Selected Reagent Access Point at Shortcut Icon with Reagent Pick List
2. Click the Print Run Report option at upper left of the screen.
3. Select the latest run, and then click the Print Report button.
Figure 124. Register Ventana Products Figure 125. Product Registration Probe
3. Press the product registration probe (2) against the memory button (1) on the product package. The
information from the button is copied to the Inventory List.
NOTE: If One Touch Product Registration is disabled in the Setup Host options, the Finalize button is
activated after you apply the probe. This gives you a chance to double check the information in the
product button before recording it. To complete the registration, click Finalize. To back out, click Close.
Otherwise, the process is the same as for one-touch registration.
Titrating
About Titration
Because all slide drawers work independently, manual application protocols can run at the same time as
automatic processing protocols.
When you need to do a manual application, you can use the Protocol Editor to create a titration protocol. A
titration protocol pauses the staining run at the appropriate time so you can apply antibodies to the titration
slides.
Option What To Do
Protocol options Click a check box to add it to or remove it from the protocol. If a listbox
arrow appears, click it to select additional options, such as an incubation
time or temperature.
Titration options Click this check box so you can pipette antibodies onto a slide. Click the
listbox arrow to select additional options, such as incubation time.
4. Click the Save As button. The Save Protocol dialog box appears.
5. Type a protocol name, and then type or select a number from the Protocol Number box. If the protocol
number you enter is already in use, an asterisk appears next to it. You can do one of the following:
• Keep the protocol number and overwrite the protocol currently associated with it.
NOTE: In the Protocol Number box, you can also type digits to go to a range of numbers. For example,
if you type in 300, the list will begin at 300. The list number is incremented by each digit you enter. For
example, entering 2 will take you to the second number in the list. Entering another 2 will take you to
number 22, and so on. You can still use the scroll bar to move up and down from any point in the list.
Use the BACKSPACE key to erase the last number typed.
6. Make sure the name and number are correct, and then click the Save button.
2. At the Instrument View, click the Slide Histogram button. The Histogram view appears with the Manual
Application button activated.
3. Click the button to display the Manual Applications List. You can view or print the list like any other
custom report.
1. On the instrument, press the Open button on each slide drawer that requires titration.
2. To dispense the reagent:
• Hold the pipette at a 45° angle.
• Insert the tip so it penetrates the liquid puddle on the slide.
• Dispense gently so as not to spill reagents over the slide edges. Take care not to draw liquid from the
slide back into the pipette.
3. After all slides are completed, press the Close All Open drawers button on the instrument Slide Control
Panel and hold it for two seconds. The system will resume processing automatically shortly after the
drawer closes.
4. A Print Preview window appears so you can view the report before you print it. Click the Printer button to
print the report. Click the Close button when you are finished.
3. Pour the contents of a 2-liter 10x EZ Prep bottle into the carboy and swirl to mix.
4. Add DI water to fill the carboy to the 20-liter mark. Swirl to mix. If air bubbles form, wait for them to settle
before you continue.
5. Loosely screw the cap onto the carboy. If the cap is too tight, the solution will not dispense freely from the
spigot.
Position 3: SSC
SSC is used for ISH applications only.
VENTANA 10xSSC comes in a 2-liter bottle, and is five times the working concentration. The concentrate is
diluted with DI water to make ten liters of 2xSSC solution. A 20-liter graduated carboy is supplied for diluting
and storing the solution. Refill the SSC bottle before each run.
To dilute the 10xSSC concentrate:
1. Make sure the spigot handle on the carboy is in the off position.
2. Fill the carboy approximately half full with DI water.
3. Pour two of the 2-liter containers of 10xSSC concentrate into the carboy and swirl to mix.
4. Add DI water to fill the carboy to the 20-liter mark. Swirl to mix. If air bubbles form, wait for them to settle
before you continue.
5. Loosely screw the cap on the carboy. If the cap is too tight, the solution will not dispense freely from the
spigot.
Position 7: Optional
The optional feature is not available at this time. This bottle must be filled with diluted reaction buffer to make
the bulk fluid system operate properly.
Icon Meaning
2 Waste bottle is present and not locked or waste bottle is present and confirmed for use.
3 Waste bottle is locked, contains fluid, and is reserved for use by the instrument.
4 Waste bottle is locked, contains fluid, and is receiving fluid from the instrument
IMPORTANT: A Change Maximum Waste Level privilege can be found in the Host Maintenance Setup
view. The waste level slider is visible only to users who are assigned this privilege. The slider is not
displayed when the instrument is in Testing, Service, or Decontamination mode.
1. Go to the Instrument view. A blue slider is displayed between the waste container images.
2. Click the slider with the mouse and drag it up or down.
IMPORTANT: The slider can be moved down only when the instrument is not in Running mode. To
reduce maximum levels, adjust the slider before you start processing slides.
CAUTION: Handle filled waste containers carefully. To prevent spillage, place the cap on the carboy
before removing it from the instrument. Wheel the waste carboy to the disposal area instead of lifting it.
3. Place the empty carboy on its back with the threaded connector facing up. (The following steps may be
easier if the carboy is placed on the floor.)
4. Place the spigot on the threaded connector (D). Make sure it is straight and turns easily.
5. Screw the spigot’s locknut until it is firm (E).
6. Push the spigot down on the connector to seat the O-ring. When the spigot is seated properly, the locknut
will turn easily again.
7. Point the spout towards the bottom of the container and tighten the locknut again.
8. Make sure the spigot handle (F) is in the off position (G) (the word “off” on the handle should be facing the
front). The carboy is now ready to use.
Quality Control
You can use Quality Control to record information about tissue control blocks and control slides. The
information can be stored in the computer, viewed, and printed on quality control reports.
3. Enter information about the control block and any control slides that were cut.
Option What To Do
Control Block Type the number or text printed on the control block.
Number
Block Accession Type the accession number associated with the control block.
Number
Block Tissue Type Enter the type of tissue embedded in the block.
Cut Slides Start at Enter the number that the control slides start at.
Number of Slides Record the total number of control slides that were cut.
Cut
Cut Date Select the date the control slides were cut.
4. When your entries are complete, click the Receive button to save the control block information in the
computer. A message prompts you to enter quality control results.
Option What To Do
Number of Slides Cut Enter the total number of control slides that were cut.
Cut Date Click the listbox arrow and select the date.
5. When your entries are complete, click the Receive button to save the control slide information. A message
prompts you to enter quality control results.
3. In the Log New Requester field, type the name of the person requesting control slides.
4. At the bottom of the screen, type the accession number of the case and enter the date you received the
request.
5. Click the Receive button to save the case request in the computer.
3. In the list, select a requester, and then click the View Cases button. A list of cases logged for the requester
appears.
2. Select the staining run, and then click the Select Run button.
Option What To Do
QC Result tabs Click the tab for the type of results you are entering.
Selected Run list Shows the staining run you are recording results for.
Select Antibody (or Record quality control results for the selection.
other product)
Enter Control Slide Select the control block and control slide number and record staining
Data information and comments.
Cases Quality Prints a list of slides grouped by requester, and within requester by
Control Report accession number, ordering physician, or category.
Antibodies Quality Lists the receive date, antibody lot number, manufacturer, catalog
Control Report number, concentration, serial number, and expiration date.
Probes Quality Shows when probes were entered into Inventory and if quality control
Control Report results were entered.
Dispensed Reagent Lists the receive date, lot number, serial number, and expiration date of
Quality Control Log reagents from Inventory.
Kits Quality Control Prints the receive date, lot number, serial number, and expiration date
Report of kits logged into Inventory.
Bulk Quality Control Shows when bulks were entered into Inventory and if quality control
Report results were entered.
Block Quality Control Shows the status of each block sorted by antibody and validation of
Report control blocks.
Slide Quality Control Titled “Antigen Activity Failure of Control Slide Series,” this report lists
Report each slide that was rejected during case quality control, with the slide
number (from a cut series) and information about the slide. You can
also sort this report by ordering physician and accession number.
4. Under Select Range, do any of the following to choose the date range for the report:
• Click Available Dates to print all dates for that item.
• Click any other option and notice the entries in the Start and End Date fields are updated.
• Click Custom and enter the start and end dates you want for the report.
5. Under Dates Used, select the dates to use for the report: the date when the item was received or the date
when quality control results were entered.
6. Click the Print Report button. A Print Preview window appears so you can review the report before you
print it. Click the Printer button to print the report, or click the Closed button to exit Print Preview.
Reports
This chapter shows examples of the reports available in the Ventana System Software and explains how to use
Print Preview. You can find instructions for specific reports in the chapters where they apply.
NOTE: Before printing a report, make sure the report printer is connected to the computer, is turned
on, and has enough paper to print the report.
Case Report
For instructions on how to generate this report, see Create Slide Reports, page 87.
Contact Reports
For instructions on how to generate these reports, see Manage Contacts, page 237.
Contact List
Contact Form
Inventory Reports
For instructions on how to generate inventory reports, see Print Inventory Reports, page 208.
Inventory Report
Order Grid
Protocol Reports
For instructions on how to generate these reports, see Create Staining Protocols, page 61.
Protocol Report
Antibody QC Report
Probe QC Report
Kit QC Report
Bulk QC Report
Print Preview
In Print Preview, you can view reports before printing them.
Feature Description
1 Printer Set Up Click to specify another printer on the network or the number of
copies to print.
3 Page Size Click to change the page size or magnification of a page on the
Print Preview screen.The selections are from left to right: fit the
report to the computer screen, increase the page width, or view at
100% magnification.
5 Page number Click the arrows to page through a report or type a page number to
go to.
Label Printer
6. Press and hold the feed button (8) while you turn on the power switch. The LED (9) will turn orange and
then red.
7. When the LED turns red, release the feed button. The printer will feed labels and calibrate the sensor. The
LED will turn from orange to red.
1. Pull the levers (9) on each side toward the front of the printer and lift the top cover slowly until it passes the
first stop position (see the diagram where the cover hinge meets the printer case).
2. Remove the label spindle (4) from the spindle mounts.
3. Slide a roll of VMSI labels onto the label spindle. Make sure the label orientation and roll unwind direction
are correct.
4. Slide the label spindle tabs (3) onto the label spindle. Use the scale marks on the label spindle to center the
label roll and the tabs.
5. Place the label spindle and label roll into the label spindle mounts so that the labels roll from the top of the
roll, not the bottom.
6. Thread the roll of labels, label side up, under the plastic roller (6), between the paper guides (7), and over
the rubber roller (8) and the metal bar (9).
7. Adjust the paper guides so that they touch the edges of the label roll.
8. Close the printer top cover by lifting the cover all the way up, then closing it slowly. Do not let the top
cover free fall or force it closed.
Load a Ribbon
1. Push down on the ribbon access window (2) to unlock, open, and raise it.
2. Slide a ribbon onto the ribbon supply
spindle (11) so that the ribbon will roll from
the bottom. Center the ribbon on the metal
roll part of the ribbon supply spindle.
3. Slide a ribbon rewind paper core onto the
ribbon spindle.
4. Fit the ribbon supply spindle on the rear
mounts (12). Figure 184. Printer Ribbon and Spindle
5. Pull the top-cover release levers (10) to open the printer top cover (1). Lift the top cover slowly until it
passes the first stop position (see the diagram in the printer case next to the cover hinge). The ribbon
should hang freely from the ribbon supply spindle toward the label roll (5).
6. Guide the ribbon over the plastic roller (7), rubber
roller (8), and metal bar (9).
7. Close the printer top cover by lifting the cover all
the way up, then closing it slowly. Do not let the top
cover free fall nor force it closed.
8. Place the ribbon rewind paper core on the front
hubs (10), then attach the ribbon to the ribbon
rewind paper core with tape.
9. Rotate the ribbon rewind paper core by hand until it
is thoroughly and firmly encompassed by the black
section of the ribbon, then close the ribbon access
window.
Figure 185. Printer Ribbon Installed
Messages in the Communicator use different symbols and require different actions.
Manage Messages
Sign off on a Critical Error
When a critical error message is displayed, a Sign Off button appears next to the message. A critical error
requires immediate action. The message stays on the screen until you click the Sign Off button. If the message
is not signed off within 5 minutes, the staining run is aborted.
1. In the Communicator, read the text of the error message to determine which instrument encountered a
problem and take any corrective action.
2. Click the Sign Off check box. The message is removed from the Communicator.
2. Type your comments, and then click the Sign Off button.
3. Click the Ok button to close the form.
Message Classes
Messages are identified by a class number and a message number within the class. The class number identifies
the type of message.
8 Database Access
HASP Key
Class No. Message Description What To Do
1 2 The Date/Time was out of The Time and Date in the Contact Ventana.
range and could not be HASP key are not within
stored, Reenter. 24 hours of each other
when the software starts
up.
Product Registration
Class No. Message Description What To Do
2 3 Seal has already been The touch memory button Contact Ventana.
burned by another NexES has been registered by
Host %d. (%d being a Host another Host system.
ID value)
2 4 Seal was burned by this The touch memory button Contact Ventana.
NexES system too long has been registered for
ago. more than 10 days and
user is attempting to re-
register it.
2 5 The touch memory has The touch memory button Contact Ventana.
been changed after has been changed after
reading its contents. the contents have been
read, but not burned.
3 1 Communication failure The remote code form was Try the download
attempting to upgrade closed before the again. If it still fails,
software, Retry. download was completed. contact Ventana.
3 6 Bulk Fluid System not The host is unable to Make sure the
communicating. Check communicate with the instrument is turned
power and cable. Automatic Fluidics System on and connected to
before starting a run. the computer.
3 7 Invalid or Missing Serial The User Maintenance Log Make sure the
Number! Please, turn on is opened and no serial instrument is turned
the staining module to numbers have been on and connected to
acquire its Serial Number. obtained from the the computer.
connected instrument.
If the problem persists
contact Ventana.
3 16 Failed to Set RTS. Error Unable to set the Request Contact Ventana.
number %d (%d to Send signal.
represents error)
3 17 Failed to Set DTR. Error Unable to set the Data Contact Ventana.
number %d (%d Terminal Ready signal.
represents error)
3 19 Unknown Tagged Value. Tag values sent from Host Contact Ventana.
Identifier: %0:d [ %1:d ] PC not defined on
Instrument Remote Code.
Serial Numbers
Class No. Message Description What To Do
4 2 %0:s is not a valid Staining An invalid serial number for Contact Ventana.
Instrument serial number. the staining instrument is
(%0:s represents version detected.
number) Call Ventana
technical support before
starting another run on this
Staining Instrument
Software Application
Class No. Message Description What To Do
5 2 Slide number is invalid, Slide count entered did not Verify slide count.
Please Re-enter. reflect number of slides Clean off bar codes if
read on the instrument. needed. Retry.
5 3 One or more of the You have not checked off Complete the actions
checklist questions have the required boxes on the in the list, then check
not been checked. pre-run checklist. the boxes.
5 7 The Ending Date is invalid! An invalid ending date is Enter a valid ending
entered for the Product date.
Usage Report.
5 8 The Ending Date precedes The ending date entered Reenter dates.
Starting Date! for the Product Usage
Report is earlier than the
start date.
5 26 Bulk: %s has already been The bulk product you are Enter a unique bulk
registered (%s represents logging has already been name.
Bulk Name) registered.
5 41 Block: %s has already The control tissue you are Enter a unique control
been registered (%s logging has already been block.
represents Block Number) registered.
5 58 Enter a valid Antibody The antibody name is left Enter the antibody
Name blank when logging fillable name.
antibodies.
5 64 The following AFM bottles The listed bulk fluid bottles Fill the bottles or if you
are not full: [list]. Proceed on the instrument are not are sure you have
Anyway? full when you start a run. enough for the run,
click Yes to proceed.
5 65 Waste level is too high. The waste space available Empty the container.
Please empty it. is insufficient for the run.
5 67 Please close the staining Staining Module door is Close door and retry.
module door and try again. open.
5 81 The following Automated The bulk fluid bottles are Fill the listed bottles or
Fluidics Instrument bottles not full when starting a test click 'Yes' to proceed.
are not full: [list]. Proceed function.
Anyway?
5 82 Case: %s has already The case you are logging Enter a unique case.
been registered for %s (%s has already been
represents Case Number) registered.
5 86 Invalid Date Range! Dates Date range is invalid. Enter a valid date
must be between January range.
1, 1997 and the current
date. The start date must
not be after the end date.
5 88 Waste level is too high. The waste bottle is full Empty the waste
Please empty it. when a test function is container.
started.
5 101 Dispenser Usage is not Cleaning Kits for SS do not Cleaning Kits are not
available for Special Stains have a saved history. available showing kit
Cleaning Kits. components.
5 102 The Archive Procedure Archive process failed to Make sure no staining
has failed. Existing system complete. runs are in progress
data is still intact. then repeat the
archive process.
If the problem
persists, Contact
Ventana.
5 111 The Archive Procedure The archive process was Perform archive
canceled. Existing system canceled by the User. process again.
data is still intact.
5 117 The Starting Date is An invalid start date is Enter a valid start
invalid! entered for the Bulk Usage date.
Report.
5 118 The Ending Date is invalid! An invalid ending date is Enter a valid ending
entered for the Bulk Usage date.
Report.
5 119 The Ending Date precedes The ending date specified Enter valid dates.
Starting Date! for the Bulk Usage Report
is earlier than starting date.
Run Compilation
Class No. Message Description What To Do
6 1 Rule operand: XXXXXX This should not normally This could indicate
only valid in a recipe step. occur. database corruption
or an internal software
error. Contact
Ventana.
6 2 Rule operand argument: This should not normally This could indicate
XXXXX missing from occur. database corruption
Argument database. or an internal software
error. Contact
Ventana.
6 3 Rule operand: XXXX This should not normally This could indicate
missing from Argument occur. database corruption
database. or an internal software
error. Contact
Ventana.
6 4 Rule operator: %s missing This should not normally This could indicate
from Argument database. occur. database corruption
or an internal software
error. Contact
Ventana.
6 5 Rule action: XXXX missing This should not normally This could indicate
from Argument database. occur. database corruption
or an internal software
error. Contact
Ventana.
6 6 Rule action argument: %s This should not normally This could indicate
missing from Argument occur. database corruption
database. or an internal software
error. Contact
Ventana.
6 7 Rule block: %s has no This should not normally This could indicate
rules. occur. database corruption
or an internal software
error. Contact
Ventana.
6 8 Rule block name cannot be This should not normally This could indicate
blank. occur. database corruption
or an internal software
error.Contact
Ventana.
6 11 Macro step: %s not in The required macro step is This could indicate
macro function database. not included in the database corruption
(%s represents the macro MacroFunc database or an internal software
function name) table. error. Contact
Ventana.
6 12 Error processing sub An invalid sub macro step This could indicate
macro: %s (%s represents is detected during the run database corruption
the sub macro name) compilation process. or an internal software
error. Contact
Ventana.
6 17 Could not locate macro An argument record does This could indicate
step argument: %s in the not exist for the required database corruption
ARGUMENT database. macro step. or an internal software
(%s represents the macro error. Contact
step argument) Ventana.
6 18 Could not locate macro A macro function record This could indicate
step: %s in the does not exist for the database corruption
MACRFUNC database. required macro step. or an internal software
(%s represents the macro error. Contact
step name) Ventana.
6 19 Sub macro: %s is missing A macro step record does This could indicate
from macro step database. not exist for the required database corruption
(%s represents the sub sub macro step. or an internal software
macro step name) error. Contact
Ventana.
6 20 Sub macro name cannot This should not normally This could indicate
be blank.. occur. database corruption
or an internal software
error. Contact
Ventana.
6 22 Maximum staining run The number of macro This error should not
macros exceeded steps for the staining run normally occur.
exceed the limit of macro Contact Ventana.
steps that can be executed
by the remote software.
6 25 Protocol for slide position # The slide barcode record Make sure a protocol
%d unassigned. (%d does not have a protocol is defined for the bar
represents the barcode associated to the barcode. code on that slide.
position)
6 27 Invalid slide position # %d. The slide barcode position This should not
(%d represents the identified in the barcode normally occur. This
barcode position) record is outside the could indicate
minimum (1) and database corruption
maximum (30) number of or an internal software
slide positions. error.
6 28 Error allocating memory for Not enough memory to This should normally
Protocol item. create protocol item. not happen. Contact
Ventana.
6 29 Too many Protocol items. Number of Protocol Items This should normally
is greater than the not happen. Contact
maximum allowable recipe Ventana.
steps.
6 32 %0:s dispenser # %1:d The reagent data needed Ensure that the
missing from Dispenser for a reagent dispenser dispenser has been
database. (%0:s loaded on the reagent registered into the
represents the reagent carousel is not in the NexES software.
name and %1:d represents Dispense database.
the reagent serial number)
6 35 Recipe step destructor not Error constructing Recipe This should normally
assigned. Step destructor not happen. Contact
Ventana
6 36 Recipe rule constructor not Error constructing Recipe This should normally
assigned. Step Rule Constructor not happen. Contact
Ventana
6 38 Error allocating memory for Not enough memory to This should normally
Recipe step. create recipe step. not happen. Contact
Ventana.
6 39 Too many Recipe steps. There are too many steps Contact Ventana.
in one of the Recipes
(Procedures) you are
attempting to run.
6 40 Recipe %s has non- The recipe steps are not in This could indicate
consecutive steps in it. (%s sequential order when database corruption
represents the recipe loading recipe steps during or an internal software
name) the run compilation error. Contact
process. Ventana.
6 41 Recipe %0:s has an invalid The recipe step is This could indicate
recipe step # %1:d. (%0:s determined to be invalid database corruption
represents the recipe during the run compilation or an internal software
name and %1:d represents process. error. Contact
the step number) Ventana.
6 42 Recipe %s has no steps. The recipe used during the This could indicate
(%s represents the recipe run compilation process database corruption
name) has no recipe steps or an internal software
associated with it. error. Contact
Ventana.
6 51 Macro step %0:s has an The macro step function is This could indicate
invalid macro function outside a valid range (0 to database corruption
number: %1:d (%0:s 162). or an internal software
represents the macro step error. Contact
name and %1:d represents Ventana.
the macro step function
number)
6 56 Macro %s is missing in the Compiling sub macros for This could indicate
Macros file. (%s a staining run and the sub database corruption
represents the sub macro macro is not included in or an internal software
name) the Macros database table. error. Contact
Ventana.
6 58 Maximum staining run size The run contains too many A limited number of
exceeded. steps for the staining steps can be
module to perform. downloaded to an
instrument in a run.
Report the message
to Ventana, including
the protocols in the
run.
6 62 Could not locate argument: When computing the This could indicate
%0:s of type: %1:s in the constructor steps, an database corruption
argument database. (%0:s argument is missing from or an internal software
represents the macro step the database. error.
argument and %1:s
represents the argument
type)
6 63 Could not locate macro When computing the This could indicate
function: %s in the macro constructor steps, a macro database corruption
function database. (%s function is missing from the or an internal software
represents the macro step MacrFunc database table. error.
name)
6 65 Recipe step: %0:s contains Computing macro steps for This could indicate
function # %1:d which is an active case slide and an database corruption
invalid in a recipe step. invalid macro function is or an internal software
(%0:s represents the identified in a staining error.
recipe step name and procedure step
%1:d represents the macro
step function number)
6 68 Reagent %s missing from A reagent needed for the Put the missing
tray. (%s represents the staining run is not on the reagent on the
reagent) reagent carousel. carousel and restart
the run.
6 70 Errors in recipe constructor Error creating rule block. This could indicate
rule block : %s. database corruption
or an internal software
error. Contact
Ventana.
6 71 Errors in recipe sync rule Error creating recipe This could indicate
block : %s synchronization rules. database corruption
or an internal software
error. Contact
Ventana.
6 72 Macro 0 generating object Compiling the macro 0 and This could indicate
not ready to start now. the staining instrument is database corruption
not a valid type. or an internal software
error. Contact
Ventana.
6 73 Invalid instrument id (%s). Compiling the macro 0 and This should not
(%s represents the the staining instrument is normally occur.
instrument ID) not a valid type. Restart the instrument
and the host
computer.
6 78 %0:s, Serial # %1:d has Loading reagent data to Load a reagent that is
expired and can not be compile a staining run and registered on the
used in this run. (%0:s the reagent has expired. current host.
represents the reagent
name and %1:d represents
the reagent serial number)
6 78 %0:s, Serial # %1:d has Loading reagent data to Load a valid reagent.
been Deactivated and can compile a staining run and
not be used in this run. the reagent has been
(%0:s represents the deactivated.
reagent name and %1:d
represents the reagent
serial number)
6 78 %0:s, Serial # %1:d has no Loading reagent data to Load a valid reagent.
reagent in it and can not be compile a staining run and
used in this run. (%0:s the reagent has no tests
represents the reagent remaining.
name and %1:d represents
the reagent serial number)
6 78 %0:s, Serial # %1:d is not Loading reagent data to Load a valid reagent.
enabled for this instrument compile a staining run and
type and can not be used the reagent has no
in this run. (%0:s argument record in the
represents the reagent argument database.
name and %1:d represents
the reagent serial number)
6 86 Recipe %0:s has an invalid The recipe function is not Contact Ventana.
recipe step #%1:d. valid for this instrument.
6 90 Expected but did not find a Invalid procedure steps. Contact Ventana.
Pre-Wet Slide sync step.
6 91 Found more than one Pre- Invalid procedure steps. Contact Ventana.
Wet Slide sync step.
Database
Class No. Message Description What To Do
7 4 This dispenser is owned by Preparing to refill a Wait for the other Host
another host and cannot dispenser and the system to relinquish
be filled at this time. dispenser is owned by ownership.
another Host system.
Force ownership via
access code from
Ventana.
Contact Ventana if the
problem persists.
7 21 Backup was cancelled User cancels the backup Do the backup again.
prior to completion before it is completed.
7 60 There are no runs to print Attempting to print a run Change the date
at this time report and no data is range or cancel the
available for the selected report.
date range.
7 64 There were no runs which Attempting to print a bulk Change the date
used bulk in the date range usage report and the bulk range.
selected product has not been used
in a staining run.
Database Access
Class No. Message Description What To Do
8 15 Could not locate Kit Unable to locate the kit Contact Ventana.
Dispensers in table dispensers when
attempting to add or
change reagent
comments.
Reagent Database
9 6 Can not proceed with A staining run is started Register the product,
staining run at this time. and no bulk reagents are associate it with the
You must register the registered and associated instrument, and start
following product(s) before with the instrument. the staining run.
proceeding
Printing
Class No. Message Description What To Do
10 2 There are no contacts You try to print a Contact Set up the contacts.
recorded report and there are no
contacts set up in the
Ventana software.
Communication Port
Class No. Message Description What To Do
Remote Software
Class No. Message Description What To Do
12 3 Reagent cover lid was The reagent cover lid lock This should not
opened during the run has been overridden and happen. If it does,
the lid opened while slides close the lid within 5
are in process. If the minutes and sign off
problem is corrected within the error message.
5 minutes, the run will Otherwise, slides in
continue. After that, any process will be
slides started before the aborted.
error occurred will be
aborted. Run reports for
affected slides will include
the error information.
12 5 Low pressure too low The low pressure falls Contact Ventana.
below the low pressure low
limit.
12 6 Low pressure too high The low pressure exceeds Contact Ventana.
the low pressure high limit.
12 16 Nozzle plate failed to find The home sensor fails to Contact Ventana.
home position detect during the homing
of the nozzle plate.
12 17 Reagent tray failed to find The home sensor fails to Contact Ventana.
home position detect during the homing
of the reagent tray
carousel.
12 23 User aborted run before The User ends a staining Contact Ventana.
normal completion run prior to its natural
completion.
12 35 SS Wash reservoir failed to High float did not hit when Check sensors, check
prime. trying to prime the bulk for clogs in tubing.
fluid.
12 37 Depar reservoir failed to High float did not hit when Check sensors, check
prime. trying to prime the bulk for clogs in tubing
fluid.
12 39 Probe Wash reservoir High float did not hit when Check sensors, check
failed to prime. trying to prime the bulk for clogs in tubing
fluid
12 43 SS Wash reservoir failed to High float did not hit in Check sensors, check
recharge itself in time. allotted time limit when for clogs in tubing.
trying to prime the bulk
fluid.
12 45 Depar reservoir failed to High float did not hit in Check sensors, check
recharge itself in time. allotted time limit when for clogs in tubing.
trying to prime the bulk
fluid.
12 47 Probe Wash reservoir High float did not hit in Check sensors, check
failed to recharge itself in allotted time limit when for clogs in tubing.
time. trying to prime the bulk
fluid.
12 53 Nozzle plate check at end The nozzle plate is slightly Contact Ventana.
of run indicated minor out of alignment.
misalignment
12 55 Reagent tray check at end The reagent tray is slightly Contact Ventana.
of run indicated minor out of alignment.
misalignment.
12 57 Syringe pump error. Check Syringe pump did not Check pump integrity.
the audit trail for details. respond as expected. Check connections.
12 76 Slide #10 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 77 Slide #11 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 78 Slide #12 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 79 Slide #13 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 80 Slide #14 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 81 Slide #15 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 82 Slide #16 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 83 Slide #17 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 84 Slide #18 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 85 Slide #19 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 86 Slide #20 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 87 Slide #21 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 88 Slide #22 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 89 Slide #23 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 90 Slide #24 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 91 Slide #25 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 92 Slide #26 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 93 Slide #27 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 94 Slide #28 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 95 Slide #29 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 96 Slide #30 offline The slide position for the Contact Ventana.
requested operation is
offline.
12 99 AFM left offline The AFM left board is not Contact Ventana.
responding to commands.
12 99 AFM control board is not The AFM control board is Contact Ventana.
responding normally to not responding to
commands. If this situation commands.
persists, call for service.
12 100 AFM right offline The AFM right board is not Contact Ventana.
responding to commands.
12 101 Reagent cover lid open too The instrument cover was Delays can affect
long during Landing Zone left open too long after a slide processing.
landing zone. The system Check the Run
waits until the lid is closed, Report, evaluate the
and then resumes the run. impact of the delay,
The error is listed in the and take appropriate
Run Report. action.
12 102 Exhaust fan failure The exhaust fan is not Contact Ventana.
operating properly.
12 104 Locked bottle now A previously locked waste Make sure waste
undetected container is now missing. containers are in
place.
12 106 High pressure too low The high pressure falls Contact Ventana.
below the high pressure
low limit.
12 107 High pressure too high The high pressure exceeds Contact Ventana.
the high pressure high limit
12 108 Tank pressure exceeded The tank pressure exceeds Contact Ventana.
the maximum allowable
limit for a specified amount
of time
12 109 Slide failed to be detected The system fails to confirm Contact Ventana.
that a slide is still present.
12 111 Barcode reader comm fail There is a slide barcode Contact Ventana.
SLIDE reader comm failure.
12 112 Barcode reader comm fail There is a reagent barcode Contact Ventana.
REAGENT reader comm failure.
12 119 Total allotted Landing The pause time for the Do what is needed,
Zone time exceeded for specified slide has been close the reagent
this slide. too long. When the hood, and sign off the
problem is corrected, error message.
processing will resume. Evaluate the impact of
Error information will the error on slide
appear in run reports for processing.
affected slides.
12 122 Slide barcode is The instrument can’t read Make sure the slide
unreadable, check slide the barcode on the barcode is readable
and retry. indicated slide. and re-start the slide.
12 130 Slide #21 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 131 Slide #22 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 132 Slide #23 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 133 Slide #24 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 134 Slide #25 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 135 Slide #26 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 136 Slide #27 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 137 Slide #28 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 138 Slide #29 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 139 Slide #30 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 169 Slide #10 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 170 Slide #11 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 171 Slide #12 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 172 Slide #13 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 173 Slide #14 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 174 Slide #15 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 175 Slide #16 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 176 Slide #17 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 177 Slide #18 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 178 Slide #19 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 179 Slide #20 temperature The slide position is unable Contact Ventana.
control error (too low) to achieve the setpoint
temperature in the timeout
duration.
12 247 Press button on staining A function test has come to Press the button to
instrument to run test a stop and needs to be resume the test.
function continued.
12 251 Open slide tray, perform The system has paused for Complete the
titration/manual a manual application. application and
application, close slide tray resume the staining
& press button when run.
complete).
13 25 Not enough available slide Too many blacked out Contact Ventana.
positions for "%s". slides to complete cleaning
run
Staining Run
Class No. Message Description What To Do
14 1 Hardware key missing The HASP key is not Reattach and start
from back of host computer attached to the computer NexES.
during the staining run
process.
14 7 Run download Timed Out, The run download Restart staining run
Restart Run information is formatted
incorrectly during the run
process.
14 11 Run Download Aborted, Test Function timed out Restart the staining
Restart Run while attempting to run. run.
14 12 Test Function Aborted, During a function test the Restart the staining
Restart Run run download information run.
is formatted incorrectly.
15 88 Dispense conflicts with the Newly added slides cannot Select a new Reagent
selected Reagent Access fit within the selected Access point.
Point, slide run will be Reagent Access point
reattempted in 4 minutes
99 7 The Zip file already exists. Attempting to create a zip Rename the old file if
Overwrite? archive file and the zip file you wish to keep it.
already exists. Otherwise, click Yes
to automatically
overwrite the file.
99 8 Error reading data from Unable to read the HASP Contact Ventana.
hardware key key when creating a zip
archive
Reagent Positioning
Error Message Instrument View What to do
If a complete reagent kit The reagent carousel If the incorrect positioning error occurs before
set is loaded but the positions on the the nozzle plate reaches the close hood
components that are Instrument View will turn alarming position, you can open the hood and
required to be side-by-side red for the incorrectly correct the error.
are positioned incorrectly, positioned reagents. If the error occurs during the last minute of the
the software displays an close hood alarm, the hood will remain locked
error message in the and you need to schedule a new reagent
Global Communication access point in order to open the hood and
Bar indicating that the address the error.
reagents that are required
If the reagents in error are required to start
to be side-by-side are
newly added slides, those slides are not
incorrectly positioned.
processed and will remain in a compile failed
state.
Manage Inventory
How It Works
Every product you use with the BenchMark ULTRA system must be recorded in inventory. A bar code label on
each product dispenser links the dispenser to an inventory record. The record tells the system what is in the
dispenser, and the system updates the record each time the product is used. Inventory records include key
information such as reagent name, lot number, expiration date, and amount of fluid in a dispenser.
Reagents
When the system compiles a staining run, it checks the inventory records to make sure the dispensers on the
instrument contain enough fluid to complete the run. It also uses the inventory records to determine which
dispensers to use first, make sure reagents have not expired, and monitor other key information. Whenever a
reagent dispenser is used in a run, the system subtracts the amount of product used and updates the inventory
record.
Example: The dispenser with serial number 49 contains DAKO WT-1, 50 of its 250 drops have been used, and
200 drops are still available to dispense.
Reagents and other products may be purchased from Ventana or from other suppliers. Fillable dispensers used
with non-Ventana products are always provided by Ventana.
Bulk Fluids
Bulk fluids are recorded the same as reagents. Because bulk bottles are not identified by bar code, the amount
remaining is not calculated in the inventory system. Instead, the bulk lot number is associated with the serial
number of the instrument(s) the lot will be used on. This tells the software that you will be filling the
instrument’s bulk bottles with that lot. The system records the number of milliliters in the lot and keeps track of
how many slides have been stained with it. The Run Report shows which lot was used in each slide run. The
Bulk Usage Report shows the original fluid amount and the number of slides stained with it to date. The lot is
used continuously until it is used up, and then a new lot is associated with the instrument. Levels of bulk fluids
on the instrument are monitored by sensors and are not associated with lot numbers.
IMPORTANT: Best practice is to avoid mixing bulk reagents from different lots. Ventana recommends
purging the bulk reservoir and lines before introducing a new reagent lot.
Reagent Dispensers
All reagent dispensers are supplied by Ventana and come labeled with bar codes that identify them to the
system. Dispensers may be pre-filled with VENTANA reagents or may be user-fillable with products from
other suppliers. Reagents and antibodies not purchased from Ventana must be transferred to VENTANA
dispensers and manually recorded in inventory.
Every dispenser has a lifetime, defined by how many drops of fluid can be dispensed from it before it must be
retired. A user-fillable dispenser might initially be filled partway and topped off with more of the same reagent
later. You can add more fluid whenever you want, up to the dispenser’s lifetime limit. When you add product,
it’s important to report the added amount to the inventory system. (See Top Off a Partly Filled Dispenser,
page 222.)
Products purchased from suppliers other than Ventana are transferred to VENTANA dispensers for use on the
BenchMark ULTRA instrument. When you fill a VENTANA dispenser with a non-Ventana product, you need
to complete three steps to record the product in the inventory system.
1. Log the product manually to identify it to the system.
2. Register the dispenser using the Product Registration Probe.
3. Fill the dispenser—that is, tell the system that a dispenser registered using step 2 contains a product logged
using step 1. For details, see Register Non-Ventana Products, page 214.
3. To see the columns at the right of the screen, click and drag the horizontal scroll bar.
4. Type comments about the product in the Comments space. The Close button changes to Cancel, and the
Save button is activated. Click the Save button to keep your comments or click the Cancel button to erase
them. The Close button returns.
5. To return to the Inventory List, click the Close button.
3. In the Kit tab, click the View Kit Components button to see the contents of a selected kit. To see all kit
components for all kits, click the View Kit Components check box at the bottom of the window.
2. When the position is right, release the mouse button. The column moves to the new location and other
columns shift to make room for it.
3. If the move disrupts the column widths, right-click a column heading, and then select Best Fit.
Group Products
1. Right-click a column heading, and then select Group By This Field. All records that have the same value in
the column are grouped together. The column heading appears in the Group by list box.
2. To eliminate all but one of the groups, right-click the column heading and select Group By Box from the
column options. The box is displayed in a banner above the grid. Click it and select the value of the group
to keep.
3. To remove the Group By Box, click it and drag it off the banner.
4. To remove the banner, right-click any column heading, and then select Group by Box.
You can also:
• Group and filter records using the View Layout and Group by features.
• Click a column heading list box and select a value to display only records with that value.
• Right-click a column heading, and then select Group by Box to open the Group by banner and list box.
5. To see the flagged records, click the Inventory button. The records are highlighted in the Inventory List. If
you want a printed list, you can select the records, and then click the Print button and select Inventory
Report.
2. In the Layout menu, choose a different filter such as Bulks Only. The list of records changes and the
warnings are gone.
3. Open the Layout menu and select Warnings. The records with warnings reappear.
4. To permanently erase the Quick Find Near entry, you can either click the Reset button (4) or select
Default—All data, no groups in the Layout menu.
Custom Filter
You can create filters to sort data in the Inventory List..
1. To open the Filter Builder, click the Filter button (1), and then click the Customize button (2).
2. In the Filter Builder, you can either set up a new filter or open a filter you created and saved earlier. After
you select or create the filter, click the Apply button. Only the records defined in the filter remain in the
Inventory List.
3. If you create a new filter, click Save As. Enter a name for the filter and click Save.
4. Click the OK button to close the filter.
5. In the Layout menu, select another option. The grid changes to display the new set of records.
6. To re-use the last filter applied, open the Layout menu again and select Custom.
4. At the confirmation message, click Yes. A print preview of the report is displayed.
5. Click the Printer button in the Print Preview tool bar to print the report. You can also use Print Preview to
save the report.
NOTE: When login passwords are enabled, the Print Product Usage Report privilege is required to
generate this report.
2. Click the Print button and then select the Detail Usage menu option.
Figure 211. Access the Detail Usage Report from the Inventory View
3. At the confirmation message, click Yes. A print preview of the report is displayed.
4. Click the Printer button in the Print Preview tool bar to print the report. You can also use Print Preview to
save the report.
3. Select the products to include in the report. For each type of product, click the product tab, and then select
the products. To select individual products, CTRL click each product. To select all products under a tab,
click the Select All button.
NOTE: Select All and Clear All Selections apply only to the currently selected tab.
4. Specify a date range. You can select a range in the Select panel, or select Custom in the Select Panel, and
then select Start and End Dates in the Select By Date panel.
5. Click the Print Report button. The Print Preview window opens with the report displayed. Click the Printer
button to print the report on the default printer.
4. Specify a date range. You can click a range in the Select panel, or click Custom in the Select Panel, and
then select Start and End Dates in the Select By Date panel.
5. Click the Print Report button. The report is displayed in Print Preview. Click the Printer button to print the
report on the default printer.
3. Click a product tab. A list of lot numbers is displayed in the left panel and a list of instruments is displayed
in the right panel.
4. Click a lot number, and then click an instrument to associate it with. (To associate the product with all
connected instruments, click the Select All button.) When the instrument is selected, the Associate button
is activated.
5. Click the Associate button. The status changes from unassociated to associated.
NOTE: If One Touch Product Registration is disabled in the Host Setup options, the Finalize button will
be activated when you apply the probe. This allows you to check the product information before
recording it. To complete the registration, click Finalize. To cancel the registration, click Close.
IMPORTANT: Every product must have a unique name. If you receive the same product from different
suppliers, give the product a different name for each supplier. For example, if you receive XYZ from
both Antibodies-R-Us and Apex, call one product XYZ-A and the other XYZ-B.
Log Products
1. Click the Inventory button in the Global Navigation.
2. Click the Associate and Log button, and then select Log Fillable Antibodies, Log Fillable Probes, or Log
Fillable Reagents. The corresponding log product view opens.
3. At the log product view, do one of the following:
• To log a new lot of a product that has been logged before, click the Log Antibody (Probe, Reagent) tab.
A list of logged products is displayed. Click the product you want to log, and then enter the required
information.
• To log a product that has never been logged into the system before, click the Log New Antibody
(Probe, Reagent) tab, and then enter the required information.
4. When you start to enter information, the Receive button is activated. The system automatically enters the
current date as the Receive Date and a year later as the Expiration Date. If the actual expiration date is
different, you can select it in the Expiration Date list box.
5. When your entries are complete, click the Receive button. A message tells you whether or not quality
control information has been entered for the lot number. Click OK to clear the message. (For information
about quality control procedures, see Quality Control, page 117.)
6. You can now do any of the following:
• Repeat the steps to enter more products of the same type.
• Click another tab to enter a different type of product.
• Click the Close button to return to the Inventory List.
• Fill a VENTANA dispenser with the product.
The following sections tell you what to enter for each type of product.
Field Description
Lot Number Type in the lot number on the product package. (Required)
Concentration Click the Concentration Unknown check box, or click a unit in the Units
panel, and then type the concentration in the box beside the unit
identifier.
Field Description
Catalog Number Type the catalog number. (Used for quality control reports.)
Species Select Mouse, Rabbit, Guinea Pig, Rat, Goat, Sheep, Horse, or Donkey.
If you select nothing, the system will use the value shown in the box.
Lot Number Type in the lot number on the product package. (Required)
Concentration Click the Concentration Unknown check box, or click a unit in the Units
panel, and then type the concentration in the box beside the unit
identifier.
Field Description
Lot Number Type in the lot number on the product package. (Required)
Concentration Click the Concentration Unknown check box, or click a unit in the Units
panel, and type the concentration in the box beside the unit identifier.
Field Description
Catalog Number Type the catalog number. (Used for quality control reports.)
Label Select Fluorescein, Digoxigen, or Biotin from the list box. If you select
nothing, the system will use the value shown in the box.
Type of Probe Select Nick Translated, Oligo, Peptide Nucleic Acid, or Branched Chain.
If you select nothing, the system will use the value shown in the box.
Target Select Human, Mouse, Guinea Pig, or Rat. If you select nothing, the
system will use the value shown in the box.
Concentration Click the Concentration Unknown check box, or click a unit in the Units
panel, and type the concentration in the box beside the unit identifier.
Field Description
Lot Number Type in the lot number on the product package. (Required)
Field Description
Catalog Number Type the catalog number. (Used for quality control reports.)
Lot Number Type in the lot number on the product package. (Required)
4. Click a dispenser to select it, and then click the Fill button. A list of products appears below the dispenser.
The Milliliters field at the bottom of the screen shows how much the dispenser can hold. You can use the
amount shown or type in a smaller number.
5. Click a reagent to select it, and then click the Fill button. The system combines the dispenser and reagent
and saves the information. The Product Name now includes both the dispenser name and the reagent name,
Tests Remaining has changed to the maximum number, and the reagent’s Lot Number is in the product
record.
NOTE: The Fill (or Partial) button completes the process. When you click it, the record is saved, so it is
good practice to check before you click.
CAUTION: Due to the risk of cross-contamination, Ventana strongly discourages re-using any
dispenser for a product other than the one it originally contained.
A dispenser can be used for a limited number of dispenses, no matter what you put into it. After that, it must be
discarded.
1. Dispose of any product left in the dispenser.
2. Click the Inventory button in the Global Navigation.
3. Click the Associate and Log button, and then select Fill Ventana Dispenser.
4. Click the tab for the type of product you want to refill.
5. Select the dispenser, note the lot number, and then click the Fill button. The Fill button changes to Refill,
and reagent names are displayed below the product record.
6. Select the product to refill the dispenser with. It should have the same lot number as the previous product.
7. Specify how much product to put in the dispenser. The maximum amount is shown in the Milliliters box.
To add less, type a smaller number in the box. (Even though the container is empty, you can fill it only to
the number of tests remaining in its lifetime.)
8. Click the Refill button. You are prompted to confirm that the old volume in the dispenser has been
emptied. When you click Yes, the product record is updated. You can then add the actual product to the
dispenser.
CAUTION: Due to the risk of cross-contamination, Ventana strongly discourages re-using any
dispenser for a product other than the one it originally contained.
A dispenser can initially be partly filled. Later you can add more of the same reagent, up to the dispenser’s
lifetime limit.
1. Click the Inventory button in the Global Navigation.
2. Click the Associate and Log button, and then select Fill Ventana Dispenser.
3. Click the tab for the type of product, and then select the dispenser and click the Fill button. A list of
reagents is displayed. Because the dispenser is not empty, the Partial button is activated.
4. Specify how much product to put in the dispenser. The maximum amount is shown in the Milliliters box.
To add less, type a smaller number in the box. If you enter a larger number, the maximum amount is
displayed again. You can either:
• Click No to cancel, and then choose another dispenser that has more tests left.
• Click Partial to fill the dispenser to the amount shown. The information is saved, and the product
record is updated.
Deactivate Products
1. Click the Inventory button in the Global Navigation.
2. At the Inventory List, select the record, and then click the Deactivate button at the bottom of the screen.
3. At the confirmation message, click Yes. The product’s status is changed from A to D.
Reactivate Products
1. Click the Inventory button in the Global Navigation.
2. At the Inventory List, open the Layout list box and select Deactivated Status Only.
3. Find and select the product, and then click the Reactivate button.
4. At the confirmation message, click Yes. The product status changes from (D) deactivated to (A) activated.
About Setup
Slide Data Fields
Slide data includes information such as patient ID and name, institution and requester, accession ID, case ID,
block ID, and slide ID. Each category of data is defined by a slide data field. Slide data fields can be used when
you design label templates and will appear in SLS. During a staining run, the system gathers the specified data
and records it in the computer. You can update or edit the data for any slide and print it on a Run Report.
Standard slide data fields are defined in the Ventana System Software. You can use the standard fields, define
your own fields, or change the names of existing fields.
Keycodes
Keycodes track slides through the staining process and activate the slide data fields you use in label templates.
You can set up the system to scan label bar codes for keycodes only or for both keycodes and protocols. When
a slide label is scanned, the protocol information is included with the keycode information.
To use keycodes with slide labels, you define a keycode range from zero to 99,999 in the Ventana System
Software. When a slide label is generated, the software assigns it a keycode number from the specified range,
and includes the number in the bar code. During the staining run, the system stores the keycode and associated
data and keeps them until the run is completed. After the run, the information appears on the Run Report, and
the keycode is deleted (later it will be re-used for another slide). If a slide has not been run or the slide label has
been damaged, misprinted, or lost, the keycode assigned to it can be deleted to make it available for another
slide.
NOTE: When Login Passwords are not enabled, all users have privileges to manage reagent
access points as the default.
Option Description
Context Hints Enabled Context hints provide information about screen features when
the mouse hovers over a feature.
Print Preview Enabled If Print Preview is enabled, reports are displayed in a preview
window before they are printed. If it is not enabled, reports are
printed with no preview.
Fill Dispenser after This feature determines how a user-fillable dispenser will be
Registration Enabled recorded after you register it using the product registration
probe. If the feature is enabled, the Fill Ventana Dispenser
form will be displayed so you can specify a product to fill the
dispenser with. If the feature is not enabled, the dispenser will
be recorded in the inventory database as an empty dispenser;
you can specify a product to fill it with later.
Associate Bulk after This feature determines how a bulk product will be recorded
Registration Enabled after you register it using the product registration probe. If the
feature is enabled, the Associate Bulk Products form will be
displayed so you can associate the product with an instrument
immediately. If the feature is not enabled, the product will be
recorded in the inventory database, and you can associate it
with an instrument later.
Run Failure Alarm Enabled If this feature is enabled, an alarm will sound when an error
occurs during a staining run. If it is disabled, no alarm will
sound.
Backup Confirmation at Run This feature specifies whether a backup will be initiated
Start Enabled automatically at the start of a run. If it is enabled, a
confirmation message will be displayed before the backup is
initiated.
Option Description
Edit Protocol by Registered This feature specifies whether or not only registered products
Products Enabled will be available for selection in the Protocol Editor. If it is
enabled, the List Only Registered Products box in the Protocol
Editor is automatically checked.
Safe Printing Enabled Enabling this feature adjusts printing quality if you encounter
printing problems.
Run Start Alarm via Sound Enabling this feature activates an audible alarm that you can
Card Enabled adjust using the computer Control Panel setting.
3. When you have finished setting the host options, click the Save button.
NOTE: When Login Passwords are enabled, the Ultimate Reagent Access feature requires that any
laboratory personnel who will set reagent access points need an update to their user privileges to add
the “Manage Reagent Access Points” option. When Login Passwords are not enabled, all users have
privileges to manage reagent access points as the default.
Option Description
Login Passwords Enabled If this feature is enabled, each user must enter a user name
and password to access the system. If it is not enabled, only a
user name is required.
Login Timeout This feature specifies the time after which a user will be
automatically logged out when the system is inactive. Double-
click in the field and enter any number between 1 and 999
(minutes). The default is five minutes.
2. Click the Slide Data tab, and then do any of the following:
• To change a field name, double-click in the field and type a different name.
• To allow slide data to be edited in SLS, set Edit Slide Data Enabled to Yes.
3. When your entries are complete, click the Save button.
Option What To Do
Lab Manager Name Type a name that identifies VLM to other vendor systems.
Exchange Protocols Click to share protocols created on another host system. You
will then need to specify the Rules for Protocol Add Offers and
Protocol Modify Offers. You can specify Ask or Select.
• Select Ask to display the protocols that have been added or
modified by another host system and view their details to
determine whether to accept or reject them. This is the
default entry.
• Select Accept to automatically accept protocols that have
been added or modified by another host system without
reviewing them.
Exchange Cases Click to share cases created on another host computer. Click
the Designated Label Printer check box to designate the host
system for printing queued labels generated via VIP. You can
select one of the following Label Printing Modes.
• Queued: Labels generated by VIP will remain in the queue
until selected and printed from SLS.
• Pass Through: The labels generated by VIP will go directly
to a printer.
Exchange Dispensers and Click to share dispensers or vials created on another host
Vials system.
Option What To Do
Exchange User and User Share user names and systems privileges created on another
Group Privileges host system. You will then need to specify the rules for User
Add Offers and User Modify Offers. You can select Ask or
Accept.
• Select Ask to display the users and user groups that have
been added or modified by another host system and view
their details to determine whether to accept or reject them.
This is the default entry.
• Select Accept to automatically accept users and user
groups that have been added or modified by another host
system, without displaying a notification message.
Note: If a user or a user group is renamed, the old name will be
deleted, and the new name will be added.
Option What To Do
Only Keycodes Click this box if you want the BenchMark ULTRA instrument to
read only keycodes from slide labels.
Both Protocol Bar Codes and Click this box if you want the BenchMark ULTRA instrument to
Keycodes read both protocols and keycodes from slide labels.
2. Under Keycode Range, select the range of numbers for the host computer to use to assign to slide labels,
and then click Commit. A red key appears with the number range. A gold key symbol displays keycode
ranges for other host computers.
3. When your entries are complete, click the Save button.
3. Under Label Printers, you can see the name of the printer connected to the host computer. Click Add
Printer to select a printer.
4. Under Alignment, use the arrows to set the vertical and horizontal alignment of the text on the label.
5. To add label stock to the printer, click the appropriate button for your printer type.
6. Set the following options for your label printer.
Option What To Do
Print Density Enter a number from 6 to 14 to adjust the print quality. If print is
fading, enter a higher number to increase the density.
Orientation Click normal to print labels right-side up. Click 180 degrees to
print labels upside down.
History Select the number of days you want the computer to store
labels so you can reprint them if needed.
Include Stainer Type Prefix If your lab uses more than one type of instrument, select this
with Protocol Number check box to have the stainer type specified on slide labels.
Translate Barcode Reader Select this check box to automatically advance to the next
Delimiter to Entry Field template field when using a bar code scanner for entering data
Advance into fields.
Passwords
Log-in passwords control access to the system software and specify the tasks an operator is allowed to do—for
example, add or modify protocols, print labels and reports, or approve quality control results.
A sign-off password allows operators to sign off on error messages that appear in the Communicator. The sign-
off password appears on the Run Report and the Case Report.
You activate log-in password checking or sign-off password checking in the Security tab in Setup Host. Define
user names and passwords first and then activate the password feature.
Log-in and sign-off passwords are optional. Either, both, or neither may be required. For each operator, the two
passwords may be the same or different. When passwords are required, the functions available to each operator
will be determined by the authorizations associated with that operator’s user name and password. Menu items
for which an operator does not have privileges will not be displayed. Ventana recommends that if any operator
is required to enter a password, all operators be required to enter passwords.
When a password is typed in, an asterisk (*) appears for each keystroke, instead of the actual letters entered, to
prevent someone from ascertaining the password. Passwords are associated with time limits; operators may be
automatically logged out when the system is inactive and will need to re-enter their user names and passwords
to log back in.
System Privileges
When you set up system privileges, assign the Setup Users and Setup Host options only to trusted operators.
The Setup Users privilege activates user names and passwords, and the Setup Host privilege enables Log-in
Password checking and Sign-off Password checking. Anyone authorized to change these options can easily
give anyone access to any function or change user names and passwords. Only the Administrator or operators
with Setup Host privileges can turn off password checking. Other functions that you might want to assign only
to trusted operators include Protocol Editing, access to Inventory functions, and designing slide label
templates.
User Groups
To give the same system privileges to a group of users, you can define a user group. When you set up user
names for operators, you can assign them both individual system privileges and user group privileges. When a
group to which a user currently belongs is deleted, the user no longer has the group privileges (unless the
privileges were also assigned to the individual).
2. To enter a new user name, click the Add button. The Enter a Unique User Name dialog box appears. Type
the user name the operator will use to log in to the system, and then click the Save button. (If the name you
enter is already in the system, the Save button remains inactive. Enter a different name that is not already
in use.)
3. The name you saved appears under User Name. You can set the following options.
Option What To Do
User Group Click the listbox arrow to select a user group to associate with the user
name. Privileges assigned to the user group appear with check marks.
Login Password Type the password the operator uses to enter the system and then re-
type it to verify it.
Sign-Off Password Type the password the operator uses to sign off on errors in the
Communicator and then re-type it to verify it.
Left-Handed Mouse Click the check box to specify mouse actions for a left-handed user.
Privileges Click check boxes to indicate the tasks the user can perform. Ventana
recommends that Setup Host and Setup Users privileges be assigned
only to trusted operators.
• Click the Set All button to permit access to all system functions.
• Click the Clear All button to remove access to all system functions.
NOTE: For users that have been trained to use the Ultimate
Reagent Access feature and to whom you would like to assign
reagent management privileges, scroll down to the bottom of the
list of privileges and select the Manage Reagent Access Points
check box
4. Click the Save button to save the user name, password, and privileges.
3. Click the Add button to enter a new user group. The Enter a Unique User Group Name dialog box appears.
Type the name and click the Save button. The name you entered appears under User Group Name.
4. Under Privileges, do any of the following:
• Click a check box to select a system privilege.
• Click the Set All button to select all system functions for this user group.
• Click the Clear All button to remove all system functions for this user group.
5. When you are finished, click the Save button. The system prompts you to save the changes.
Manage Contacts
You can enter contact information for service engineers and other people you need to be in contact with. You
can also print a list of contacts to refer to if you need to call a service engineer.
Option What To Do
1 Click the first arrow button to see the first record. Click the last arrow button to see
the last record.
2 Click the left arrow to see the previous record. Click the right arrow to advance to the
next record.
3 Click a heading with the mouse and drag it to a new position to reorganize the table.
4. To change contact information, double-click the record. The Contact Edit form opens.
Add a Contact
1. At the Home View, click the Setup button, and then click Contact Management.
2. If this is the first entry for contact information, the Contact Edit form appears and you can begin entering
contact information. If the Edit form does not appear, click the Contact Edit tab, and then click the Add
button.
3. Type in the name, phone number, email address, and other information you want to include.
4. Click the Save button. Your entries are saved and appear in the Contact Select list.
Delete a Contact
1. At the Home View, click the Setup button, and then click Contact Management.
2. In the Contact Select list, click the contact you want to delete, and then click the Delete button. You are
prompted to verify the deletion.
Go to Instrument Maintenance
The Instrument Maintenance View provides tools to maintain your BenchMark ULTRA instruments and
generate maintenance logs and reports. This section tells you how to go to the Instrument Maintenance View.
Detailed steps for maintenance tasks are provided in later sections.
1. Click the instrument name in the Instrument Bar to open the Instrument View.
2. At the Instrument View, click the Instrument Maintenance icon to open the Instrument Maintenance View.
Go to Maintenance
The Maintenance View provides tools to manage the data on your host computer. This section tells you how to
go to the Maintenance View. Detailed steps for maintenance tasks are provided in later sections.
1. At the Home View, click the Maintenance button.
2. At the Maintenance View, you can click buttons and tabs to manage maintenance on your host computer.
Decontaminate EZ Prep X
Decontaminate SSC X
Decontaminate Optional X
*Cleaning slide drawers as needed is generally done once per day, before the first run or after
the last run.
3. In the list boxes, select the instrument and year, then select a report month.
4. Click Print Report. Print Preview opens. To print the report, click the Printer icon in the toolbar.
1. In Instrument Maintenance, click User Maintenance, and then click the tab for the appropriate maintenance
period.
Daily Maintenance
Wipe External Surfaces
Wipe external surfaces of the instrument with a soft, damp cloth.
5. When cleaning is finished, the drawer lights turn off and a test completed message appears in the
Communicator. Click the Sign-off button to clear the message. The instrument is ready for use.
Available The system is in SLEEP mode, and you can run a cleaning
cycle.
3. Click the Clean icon to perform a cleaning cycle. Once the instrument begins a cleaning cycle, the Clean
icon and slides turn amber in the Instrument View. The cleaning cycle will take approximately 12 minutes
to complete.
Weekly Maintenance
Back Up the Database
IMPORTANT: Ventana recommends backing up the database every week to maintain data integrity
and optimal performance.
1. Go to Maintenance, and then click the Backup Database button. The system displays the following
message.
2. Wait for the backup to finish or click the Cancel button to end without finishing.
Monthly Maintenance
Rinse Bulk Fluid Containers
1. Empty the residual fluids out of the EZ Prep,
SSC, ULTRA CC1, ULTRA CC2, Optional,
and Reaction Buffer bottles.
2. Rinse the bottles with deionized (DI) water.
3. Refill the bottles with their original fluids.
CAUTION: Handle filled waste containers carefully. Wheel the carboy to the disposal area instead of
lifting it. To prevent spillage, place the cap on the carboy before removing it from the instrument.
3. Prepare a soapy water solution, using warm tap water and mild liquid dishwashing detergent (or
equivalent).
4. Brush the pads lightly using the soapy water and the instrument cleaning brush supplied with the system.
5. Proceed to the Clean Waste Tub and Drain section.
Quarterly Maintenance
Run Slide Heater Temperature Verifiers
For this test, you use temperature verification slides to check the slide heater temperatures.
1. Load all temperature verification slides onto the instrument and close all slide drawers.
2. Go to Instrument Maintenance, and then click Function Tests.
3. Select TEST–TEMP VERIFY ULTRA and click the Run button. When the test runs, all slide drawers are heated to
95 degrees C for 10 minutes and then cooled. On each slide, the bar that represents 93 degrees C should
have turned black, and the bar that represents 99 degrees C should be unchanged.
Decontamination Alert
When any reservoir is due for decontamination, the Instrument Maintenance icon in the Instrument View turns
red. It will stay red until all scheduled reservoirs are decontaminated. It doesn’t have to be red for
decontamination to run.
During decontamination, a decontamination icon is displayed in the Instrument Bar and Home View. After the
icon disappears, you can resume slide processing.
• If you click Abort after decontamination fluid is pumped into the system, the process pauses, but is not
terminated. You must finish decontaminating before you can process slides. To continue, correct the
condition that caused you to click Abort, then click the Continue button. Depending on where it was in the
process, the system will resume where it left off or start over. It will update the reservoir status markers and
display information in the message window to let you know what it is doing and what you need to do.
CAUTION: To prevent spillage, place caps on waste carboys before removing them from the
instrument. Wheel the carboys to the disposal area to avoid lifting them.
IMPORTANT: The decontamination process will generate from 1 to 40 liters of waste or more,
depending on how full the bulk reservoirs are when you start and how many reservoirs are
decontaminated. If the waste containers are full, the process will stop until they are emptied and
replaced.
Decontamination Record
Decontamination is automatically recorded in the Quarterly Maintenance Log. After decontamination, the
report appears on the screen, showing a check mark for each reservoir that was cleaned.
When the tubing harness method is used, all bulk reagents are checked off on the log. When the individual
bottles method is used, only the bulk reagents selected for decontamination are checked. You can view or print
the report like any other maintenance report.
8. At the computer, go to the Instrument View and click the Instrument Maintenance icon.
9. At Instrument Maintenance, click the Decontamination button to open the Decontamination View.
10. Under Fluid Connection Method, click Tubing Manifold. All of the Select Bulks to Decontaminate boxes
are checked automatically (except LCS, which is not included in the process). The Start button is activated.
11. Set the Incubation Time by clicking the up or down arrow. The correct time depends on the
decontamination fluids you use and your laboratory practices.
12. Click the Start button.
The system initializes the AFS and nozzle plate, evaluates the volume of fluids to be drained, and checks
the capacity of waste containers. (If there is not enough room for the waste, the system pauses, alerts the
operator, and displays a message. Empty and replace the waste containers. The system will automatically
resume processing.) When initialization is complete, the top status marker turns green. The second marker
turns yellow as fluids start to drain.
NOTE: Reservoirs drain two at a time, except ULTRA CC1 and CC2. They drain along with the others,
but through a different opening, so their progress might appear slower.
After the selected reservoirs are drained, the third status marker turns yellow. The person icon indicates
that operator action is required. The system alerts the operator and displays a message. The Start button
becomes the Continue button.
13. Make sure the tubing manifold is attached to the bulk connectors, and the free end is inserted in the large
carboy of decontamination fluid. Click the Continue button.
Decontamination fluid is pumped through the tubing into the reservoirs, and the incubation time begins.
The percentage of incubation completed is shown on the Incubation Progress bar.
14. While the reservoirs are soaking:
• Empty the decontamination fluid from the large carboy. Rinse the carboy at least twice with DI water,
and then refill it with at least 20 liters of DI water.
• Remove the tubing harness from the instrument. Rinse it inside and out with DI water to prevent cross
contamination.
15. When the incubation time has passed, the system drains the decontamination fluid and signals the operator
to provide DI water. Reconnect the tubing harness to the bulk connectors, set the large carboy filled with
DI water in front of the instrument, and insert the long tube into the carboy. Click the Continue button.
16. Empty the bulk fluid bottles and dispose of the sterilizing solution appropriately. Rinse each bottle with DI
water at least twice (until the sterilizing fluid odor is gone). Make sure the bottle’s whole interior is rinsed.
Refill the bottles with fresh bulk fluids and replace the caps.
17. When the system starts draining the DI water from the reservoirs, remove the tubing manifold from the
bulk connectors and empty any remaining DI water out of the large carboy.
18. When the DI water has drained, the system signals the operator and displays a message. Replace the freshly
filled bulk reagent bottles on the instrument. Make sure the connectors snap into place. Click the Continue
button.
The system fills the reservoir with the VENTANA fluids, then primes the lines. The Start button is
reactivated, and the instrument is ready to use. The system automatically records the date for each reservoir
that was decontaminated and displays the Quarterly User Maintenance Log (see Decontamination Record,
page 253).
6. Replace the cap on each bottle. Wearing gloves, cover the air vent in the cap with your finger and swish the
fluid around in the bottle to wet the whole interior.
7. At the computer, go to the Instrument View and click the Instrument Maintenance icon.
8. At Instrument Maintenance, click the Decontamination button to open the Decontamination View. The
status indicators for the removed bulk bottles appear red with lines above and below them.
11. Set the Incubation Time by clicking the up or down arrow. The correct time depends on the
decontamination fluids you use and your laboratory practices.
12. Click the Start button.
The system initializes the AFS and nozzle plate, evaluates the volume of fluids to be drained, and checks
the capacity of waste containers. (If there is not enough room for the waste, the system pauses, alerts the
operator, and displays a message. Empty and replace the waste containers. The system will automatically
resume processing.) When initialization is complete, the top status marker turns green. The second marker
turns yellow as fluids start to drain.
NOTE: Reservoirs drain two at a time, except ULTRA CC1 and CC2. They drain along with the others,
but through a different opening, so their progress might appear slower.
After the selected reservoirs are drained, the third status marker turns yellow. The person icon indicates
that operator action is required. The system alerts the operator and displays a message. The Start button
becomes the Continue button.
13. Re-install the bulk bottles on the instrument. Make sure the connectors snap into place. (Do not reconnect
the Reaction Buffer bottles.) Click the Continue button.
Decontamination fluid is pumped from the bottles into the reservoirs, and the incubation time begins. The
percentage of incubation completed is shown on the Incubation Progress bar.
14. Remove the bottles from the instrument and empty any remaining decontamination fluid. Rinse each bottle
with DI water at least twice.
15. Using the funnel, pour DI water into the bottles. Replace the caps on the bottles.
16. When the incubation time has passed, the system drains the decontamination fluid and signals the operator
to provide DI water. Return the bulk bottles to their places on the instrument. Make sure the connections
snap into place. (Do not reconnect the Reaction Buffer bottles.) Click the Continue button.
17. When the system starts draining DI water from the reservoirs, remove the bulk bottles from the instrument.
Pour out any remaining DI water and fill the bottles with fresh VENTANA fluids.
18. When the DI water has drained, the system signals the operator and displays a message. Replace the freshly
filled bulk reagent bottles on the instrument. Make sure the connectors snap into place. Reconnect the
Reaction Buffer bottles. Click the Continue button.
The systems fills the reservoir with the VENTANA fluids, then primes the lines. The Start button is
reactivated, and the instrument is ready to use. The system automatically records the date for each reservoir
that was decontaminated and displays the Quarterly User Maintenance Log (see Decontamination Record,
page 253).
Database Management
Use the Maintenance options to archive system data, back up the database, and analyze the database for errors.
NOTE: Databases that have not been archived in a very long time may take several hours or longer to
complete the archive process.
NOTE: Systems connected via Central Management must be archived in succession and before a run
is started. Failure to archive all systems connected via Central Management will result in data being
auto-populated and a potential loss of archive data.
The archive includes system data for cases, blocks, run data, and dispensers.
Run Data Run information, including used dispensers, will be archived starting
at the Archive Date, and only if the dispensers used within those runs
are also targeted to be archived and purged.
Option What To Do
Archive Date Click the arrow and select a date. All system data up to this date will be
archived onto the network or external USB flash drive.
Blocks Click the check box to include deactivated blocks in the archive data and
purge them from the system. Click the check box again to clear it and
remove blocks from the archive data.
Cases Click the check box to include deactivated cases in the archive data and
purge them from the system. Click the check box again to clear it and
remove cases from the archive data.
Create Disk Select the check box to create an archive disk that is used to view the
archive data. The archive disk includes all data up to the archive date
and then purges the old data from the computer. Ventana recommends
that you select this option and create an archive disk.
If this option is not selected, no archive disk is created and the old data is
purged from the computer.
3. In the Archive Folder field, type the drive letter and folder name of where you want to save the data or
click the Archive Folder arrow to open the Select Folder panel.
4. In the Select Folder panel, you can do any or all of the following:
• Navigate to the drive and folder where you want to save the archive.
• If needed, click the Create New Folder button (1), and then type a new folder name (2).
• Click OK to close the Select Folder panel.
• Open the Select Folder panel again and change your selection.
• Click in the Archive Folder field, erase the current name, and type a new one.
5. Click the Archive button to start the back up. After the file is saved, you can see it in Windows Explorer.
NOTE: If you want to view the archive file on a computer that is running the VSS software, you must
close the software prior to opening the archive. The system will not allow VSS and an archive data file
to run simultaneously.
2. Navigate to the drive and folder where the Archive disk is saved.
3. Double-click on the Archive disk.
4. A message appears that lists the archive date, software version, and Host ID. Click OK to continue.
5. A software program opens that is similar to the VSS so you can view the archived system data. To generate
reports from the archived data, go to the Home View and click the Reports button.
4. If defragmentation is needed, click the Defragment button and wait for the process to complete. It could
take a few minutes or a few hours. A completion message will be displayed when the process is finished.
Preventive Maintenance
About Preventive Maintenance
Regular preventive maintenance is done by a Ventana technician or a Ventana-certified technician at your
facility. It includes instrument calibration and other tests and tuning that are more technical than routine user
maintenance. Preventive maintenance is scheduled based on time or number of slides processed. The interval
for each facility is determined by its service contract. The time interval may be 2 weeks, 6 months, 12 months,
or 18 months. The slides processed interval may be 2000, 3000, 6000, or 9000 slides. The most common
intervals are 12 months and 12000 slides.
The customer monitors the preventive maintenance schedule and calls the Ventana Customer Service Center
(CSC) when maintenance is due. After the maintenance is done, the technician reports it to the CSC and resets
the schedule for the next maintenance.
2. (Customer) If maintenance is due, call the Ventana CSC and schedule a visit.
3. (Technician) After the maintenance is done, go to Schedule Preventive Maintenance and click the Yes
button. A challenge code is displayed.
4. (Technician) Call the CSC and tell them the code. Type the response code into the Response Code box, and
then click the Apply button. The time for the next service is calculated according to the service contract,
and the schedule numbers and dates are reset.
Customization
Label Templates
A template is a set of instructions that define how a label looks when it is printed. You can design up to 25
templates. The Ventana System Software includes a set of predefined templates that you can customize for
your facility. You can also specify which template is used during label printing. For more information about
printing slide labels, see Generate Slide Labels, page 73.
VENTANA instruments only require a bar code and protocol name on templates. When you design a template,
you can specify the font size and field names that appear during label printing.
Feature Description
1 Font Size Style Set the font size used on the label.
Option What To Do
No Fields Click this if you want to remove a field from the label.
One/Two Fields Select one or two fields per line for the user prompt.
Insert New Line Click this to insert a line at the bottom of the label.
Move Line Up/ Click this to move the current line up or down.
Down
2. In the Prompt box, type the text that replaces the User Prompt entry on the template.
Require Text Click the check box to require text entry during label printing. The text
box will be yellow. Remove the check mark if text entry is not required.
Clear previous text Click the check box if you want previous text to be cleared during label
when pausing for printing. Remove the check mark to create a tool tip that appears during
entry label printing. Type the tool tip in the Default text field box.
Pause for input Click Each Label to pause printing for text entry on each label.
Click Each Panel to pause printing for text entry on each panel.
Click Each Job to pause for text entry on each job during label printing.
2. In the Prompt box, type the text that replaces the User Prompt entry on the template.
3. Set the options.
Option What To Do
New List button Click to create a new list. The system prompts you to name the new list.
Option What To Do
Delete button Click the down arrow to select a list and then click Delete.
Add a Date
1. In the Field Properties view, click Date. The Date options appear.
2. In the Prompt box, type the text that replaces the User Prompt entry on the template.
3. Set the options.
Option What To Do
Pause for input Click Each Label to pause printing for text entry on each label.
Click Each Panel to pause printing for text entry on each panel.
Click Each Job to pause for text entry on each job during label printing.
Option What To Do
Start at Choose the increment to begin with. For example, enter 2 if you want to
increment the number by 2 each time it is printed.
Option What To Do
3. When you are finished, click the Add button. The system displays your selections.
Increment Alphabetically
You can apply a letter to each label and automatically increment it.
1. In the Field Properties view, click Mask.
Option What To Do
Start at Type the increment you want to begin with. For example, enter A if you
want to start with that letter.
3. When you are finished, click the Add button. The system displays your selections.
Option What To Do
Year Click yyyy for a four-digit year. Click yy for a two-digit year.
Month Click mm for a two-digit month. Click mmm for a three-digit month.
Connectivity
This section provides an overview of available connectivity options and benefits.
LIS Connectivity
The interface between the laboratory information system (LIS) and the VENTANA staining instruments
supports automatic test ordering and automatic test status updates.
Central Management
The Ventana Lab Manager (VLM) links the VENTANA system and other vendor systems in the Anatomic
Pathology lab. The VLM facilitates communication between staining host computers and the staining and
imaging platforms. In addition, the VLM, in combination with the Ventana Interface Point (VIP), connects the
VENTANA system and the LIS.
Ventana customers with multiple staining instruments can manage reagents, protocols, and inventory and share
the information between computer hosts.
Reagents on one host may be used on another, simplifying reagent inventory management and expense. In
addition, protocols may be automatically shared across hosts to save staff time and reduce the potential for
errors.
Troubleshooting
Home Nozzle Plate ULTRA Send nozzle plate to home Diagnose problems in homing
position. sensor and nozzle plate
assembly.
Jog Nozzle Plate CW ULTRA Advance nozzle plate one After homing, check nozzle
position at a time. plate alignment; detect worn
parts.
1. To home the nozzle plate, select TEST - HOME NOZZLE PLATE ULTRA, and then click the Run button.
2. To jog the nozzle plate, select TEST - JOG NOZZLE PLATE CW ULTRA, and then click the Run button. The
nozzle plate advances one position each time you click the Run button. You can jog it repeatedly to go
through all 30 nozzle plate positions. If a mechanical part is worn, the plate may not advance correctly each
time it is jogged.
Home Reagent Tray ULTRA Sends the reagent carousel Diagnose problems in the
to the home position. homing sensor and the
carousel drive assembly.
Jog Reagent Tray CW Advances the reagent After homing, check to see if
ULTRA carousel one position at a the carousel is positioning the
time. reagent dispensers correctly.
1. To home the reagent carousel, select TEST - HOME REAGENT TRAY ULTRA and click the Run button. To repeat
the test, press the Run button again.
2. To jog the reagent carousel, select TEST - JOG REAGENT TRAY CW ULTRA and click the Run button. To repeat
the test, press the Run button again. The carousel advances one position each time you click the button.
You can jog repeatedly to go through all 30 dispense positions. If a mechanical part is worn, the plate may
not advance correctly each time it is jogged.
Set Up VLM
1. Double-click the VLM shortcut icon. The VLM view opens.
.
Option What To Do
Operational Role Select Master if this is the computer that communicates with other host
buttons computers on the network. Select Simulcaster if this is the computer that
receives data from the host computers on the network.
Unique Lab On the VLM tab, type the Lab Manager Name set in the Setup Host
Manager Name options.
Enable VIP Client Select this option to allow communication with the VIP software so that
Connections the host computer can receive data from an LIS.
Enable VISTA Select this option to allow communication with the VISTA software so
Client Connections that the host computer can receive data from VIAS.
Automatically Select this option to automatically start the VLM application when the
Launch computer starts up.
Enable Sub- Select this option to exchange data with other computers.
network
Simulcasting
Services
Computer Names Type the name of the computer you want to exchange data with.
Computer Name Enter the computer’s IP address to exchange data with that computer.
3. When your entries are complete, click the Apply button to save them.
Monitor Connections
Open VLM and click the Connections tab. A list appears showing the computers connected, connection type,
and data packets received and sent.
Option What To Do
Capture Click the check box to capture current events and display them. Clear
the check box if you do not want to capture current events.
Auto Scroll Click the check box to turn automatic scrolling to the current event on or
off.
Clear Display Click this button to clear all the events from the display.
button
Apply Filter button Click this button to apply the current selections of event types and event
sources to the current display.
Load Log button Click this button to load a log file stored on a disk into the event grid.
Clear Log button Click this button to clear the on-disk event log of all events.
Event Types Filter Use with the Apply Filter button to set up the filter criteria to display
specific event types (exchange between the computer and any
connected computer).
Event Sources Use with the Apply Filter button to set up the filter criteria to display
Filter specific event sources (computers that generated data exchange).
Option What To Do
Facility Name Type the name of the laboratory or facility using VIP.
Receiving Facility Type the name of the laboratory receiving information from an LIS.
(MSH.6)
Validate OBR.4 Check this box to validate the value received in OBR.4 of each order
value with current against the list of protocols replicating in the VLM. If the Universal
Protocols Service Identifier specified in OBR.4 does not match a defined protocol,
the LIS order is rejected.
Abbreviated ORR & Check this box to receive a simple acknowledgment of an order rather
ORL than a complete echo of the original order.
Acknowledgments
OBX segment Date Check this box to display observation dates in plain text.
values as text
Load Connections Check this box to load previously established connections when the VIP
on Startup is started up.
Automatically Check this box to launch the VIP automatically when Windows is started.
Launch
Lab Manager Name Type the name found in the Lab Manager Name field of the VLM Options
tab in Setup Host.
4. In the Keycode Range list box, click the arrow and select the keycode range used for orders placed via the
LIS connection, and then click the Commit button.
5. When you are finished, click the Apply button.
Map Fields
You can use the Field Mapper to create an HL7 script. The script maps codes in the HL7 Message tab to any
field in the right pane, such as Template, Patient ID, Patient Name, and so on. The Field Mapper transforms
data from HL7 messages into a format that the VLM can understand.
Button Description
1 Execute the field mapping script and translate the currently loaded HL7 message to
a case result test.
Option What To Do
Select Data Type Choose Variable to store the value to a temporary variable to be further
processed by another command line.
Choose Ventana Data to store the mapped field’s value to one of the
slide data types.
Select Ventana Click the list box arrow and select a slide data field.
Data Field
Option What To Do
Select Function Choose Concat to combine up to four values from an HL7 field variable
or literal.
Choose Copy to copy a value from one HL7 field or variable to another.
Choose Extract to extract a sub-string from an HL7 field or variable by a
literal delimiter.
Choose Left to extract the left sub-string from a field or variable.
Choose Mid to extract the middle sub-string from a field or variable.
Choose Right to extract the right sub-string from a field or variable.
Option What To Do
Select Data Type Choose HL7 Field as the source for the data.
Select HL7 Field Click the list box arrow and select an HL7 field.
NOTE: If you select Variable from the Select Data Type list box, the Select HL7 menu will change to
Select Variable, and the Enter New HL7 Field Name field will change to Enter New Variable.
View Protocols
You can see all the protocols currently defined and used on the staining instrument.
1. Click Protocols to see the defined protocols.
2. Protocol information appears, including the number, name, and the date it was modified.
3. Click the Refresh button to update the protocol list.
Option What To Do
1 Click Client. This means the VIP will be acting as a TCP/IP socket client, while the
LIS will be acting as the TCP/IP socket server.
3. Click the Connect button. When the VIP and the LIS are connected, the button will change from Connect
to Disconnect. Click Disconnect to break the connection between the VIP and the LIS.
The prompts below the Connect button allow you to monitor communication between the HL7 and LIS.
• Messages Received—the total count of HL7 messages received by this connection.
• Messages Sent—the total number of HL7 messages sent by this connection.
• Queued Messages—in the event of communication latency issues, out-bound messages are queued to
disk, this shows the total number of LIS bound messages that are currently queued to disk.
• Average Response—the average number of milliseconds it took VIP to receive and acknowledge an
in-bound HL7 message.
• Acknowledgement—the average number of milliseconds it took the LIS to receive and acknowledge
an out-bound HL7 message.
Option What To Do
3. Click the Connect button to open an HL7 connection that will be available for a client connection. The
Listening button displays until the connection is established. Once the connection is available, the button
will change from Connect to Disconnect. Click Disconnect to break the connection.
The prompts below the Connect button allow you to monitor communication between the VIP and LIS.
• Messages Received—the total count of HL7 messages received by this connection.
• Messages Sent—the total number of HL7 messages sent by this connection.
• Queued Messages—in the event of communication latency issues, out-bound messages are queued to
disk, this shows the total number of LIS bound messages that are currently queued to disk.
• Average Response—the average number of milliseconds it took VIP to receive and acknowledge an
in-bound HL7 message.
• Acknowledgement—the average number of milliseconds it took the LIS to receive and acknowledge
an out-bound HL7 message.
2. The data being processed by the host appears, including the data type (configurations, protocols, case
slides), the state (if the host is idle or transmitting data), total number of data type, and version.
Option What To Do
Date/Time See the date and time that the event took place.
Fast Time (ms) View a very accurate millisecond timer used for communications packets
versions.
Source View the source of the event, for example VLM, a host PC, or internal
source.
Connection View the staining instrument to which the source was connected.
Auto Scroll check Click to turn on or off automatic scrolling to the current event.
box
