Computer Networks

CS F303

IP Addressing

Ashutosh Bhatia
Department of Computer Science and Information Systems
BITS Pilani Birla Institute of Technology and Science
Pilani|Dubai|Goa|Hyderabad
Pilani Campus, Pilani
 BITS Pilani
Pilani|Dubai|Goa|Hyderabad

Outline
• IP addresses
• Subnetting
 Problem Statement

• Flat Addressing: N hosts needs N entries

in the table (MAC addresses)

• Millions of hosts, address lookup in

forwarding becomes a bottleneck

• Need a method of reducing entries in the

forwarding table for scalability purposes
3
BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956
 Solution: Hierarchical Addressing
• Structure to addresses: Address captures location in the
network topology
• IP address (32 bits) consists of two parts: network and
host
– Network part identifies the network to which host is
connected
– Host part uniquely identifies each host in the network

netid hostid
• How does this help?
– An entire network (in some specific direction) could be
represented by a single entry at a router
BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956
 IP addresses

• IP addresses are logical entities

• IP addresses usually refer to interfaces, not
machines
• Several interfaces: several IP addresses
• Same interface: multiple addresses possible
• It is also possible to have several interfaces,
but only one IP address
• 32 bit addresses in IPv4

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 IP addresses
• Netid: allocated to organizations
• Hostid: allocated by the organization

• How many bits for netid and hostid?

– Large corporations: many hosts, so many hostid
bits required
– Small organizations: few hosts, few hostid bits

• Single partitioning scheme will not work

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 IP addresses
• Possible scheme: find out the netid-hostid
partition by looking at the IP address

• Requires
– Breaking up the IP address space into disjoint sets
– Each set has a pre-defined number of bits
allocated to netid

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 IP addresses
Fixed Partitioning

0-3 4-7 8-11 12-15

Variable Partitioning

0-1 2-3 4-7 8-15

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 IP address classes

IP address space

Beginning with 0 : Class A 10 : Class B 110 : 1110 :

Class C Class
D

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 IP address classes

A: 0 7 bits 24 bits

netid

B: 10 14 bits 16 bits
netid

C: 110 21 bits 24 bits

netid

D: 1110 Multicast group id

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 IP Address

• Private IP addresses:
– A: 10.0.0.0 through 10.255.255.255
– B: 172.16.0.0 through 172.31.0.0
– C: 192.168.0.0 through 192.168.255.0.
– 127.0.0.1 is loopback address.

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Interconnected networks

Net A Net B Net C

Interconnected networks (“Internet”)

• Each n/w: a physical network, uses a certain technology

• Hosts can talk to one another using technology-specific
mechanisms
• Abstraction: Each network corresponds to a netid
• Routers maintain tables with “netid” and “next hop” mapping

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

Example: Class C

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Forwarding at Host
• If (NetNum of Dest = my NetNum) then
– deliver packet to destination directly
– use ARP to get MAC address corresponding to dest IP
address

• Else deliver packet to default router

– use ARP to get MAC address corresponding to router
IP address

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Forwarding at Router
• If (NetNum of Dest = NetNum of one of my
interfaces) then
– deliver packet to destination over that interface
Else if (NetNum of Dest is in my forwarding
table) then
– deliver packet to NextHop router

Else deliver packet to default router

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Summary
• Top concern: Scalability

• Handled via hierarchical addressing

– IP address has a network and a host part
– Significantly reduces entries in forwarding table

• Looked at how forwarding is done at host and

router based on the addressing scheme

• Ahead: Address assignment inefficiency

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Problem Statement

• Network part uniquely identifies a physical

network

• Network with just 2 hosts needs Class C address

– Efficiency: 2/2^8 = 0.7%

• Network with 256 hosts needs a Class B address

– Efficiency: 256/2^16 = 0.4 %

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Problem Statement

• Class B addresses in high demand (keeping

future needs in mind)
– Host addresses ~ 4 billion (232)
– Class B networks: 214 (~16000)
– Out of class B addresses, out of addresses to
hand out

• Need to solve “Address assignment

inefficiency”
– Challenge: Within IP framework (using 32-bits)

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Specific Scenario –1
• An organization has 30 different physical
networks, each network has about 2000 hosts

• Current Allocation: Allocate 30 class B

addresses
– Efficiency = 2000/2^16 = 3%

• Will one class B address suffice?

– Can support 216 = 65536 hosts > 30*2000

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Solution: Subnetting
• The bits in the hostid part are further divided:

netid hostid

subnetid hostid

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Subnet masks
• To extract the netid and subnetid parts from
the IP address
• String of 1-s with trailing 0-s in the hosted part

144 16 68 117

255 255 224 0

Bit-wise AND

144 16 64 0

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Subnet masks
• In the example, subnet mask is 19 bits wide
• Also written as
– 144.16.68.117 / 19
• Each interface having an IP address must have a subnet mask
also
• Used to determine the network to which the subnet
“belongs”, or , to which it is “directly connected”
• Putting 0’s in the hostid part yields:
– Netid-subnetid
• Putting 1’s in the hostid part provides:
– Subnet-directed broadcast address

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Subnetting: benefits
• “Internal”: The internal network structure of
an organization can be changed without
affecting the routing tables of external routers
– Hide unnecessary details from external routers

• “External”: Can lead to decrease in core

routers’ routing table sizes

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Example
.52.0 .53.0 .54.0 .55.0

R11 R12 R13 R14

.51.7
.51.1 .51.0

140.252.104.1 .2.0 next hop .1.9

.3.0 next hop .1.10
Gateway
To the .52.0 next hop .51.7
Internet .1.4 .1.0
.1.9

R1 R2 R3 R4

.2.0 .3.0 .4.0 .5.0

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956
 Without Subnetting

Core Router Core Router

C1 C1
C2 C2
C3 Nw 2 C2
------- -------
C50 C50

Nw 1 Nw 2 Nw 50

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 With Subnetting

Core Router Core Router

B
B
Nw 2

B1
Edge Router B2
B3
-------
B50

Nw 1 Nw 2 Nw 50

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Example

• All routers outside organization have one entry

(190.23.0.0/16)

• Routers within organization have more detailed entries

corresponding to different subnets
BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956
 Forwarding at a Router
D = Destination IP Address
For each forwarding table entry
T = D & SubnetMask
If T == SubnetNum
If Nexthop is an interface
deliver datagram directly to destination
Else
deliver datagram to NextHop (router)

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

Example

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Specific Scenario -- 2

• An organization has a physical network with

4000 hosts
• Current Solution: Give a class B address
– Efficiency: 4000/216 = 6%
• How about assigning multiple class C
addresses?
• Problem: 16 entries for same organization in
the routing table

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Solution
• Assign multiple contiguous class C addresses
& aggregate
• 222.7.16.* through 222.7.31.*, top 20 bits in
this range are the same (0001 bits, 20-bit
network number)
• Advertise 222.7.16.0/20 as the organization’s
network address
• Goes by the name supernetting

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Conclusions
• Subnetting: One class address shared among
many physical networks

• Supernetting: Multiple class addresses shared

among one physical network (Autonomous
system -- AS)

• Network portion can take on any length

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Classless Interdomain Routing (CIDR)

• Use a new notation to represent network

numbers (also called IP prefixes)
• Address block represented as A/X, where A is
the address prefix and X is the prefix length
– X can range from 2 till 32
– X is represented as a network mask as well
• E.g. 222.7.16/20 (Mask 255.255.240.0)
represents addresses in the range 222.7.16.0
to 222.7.31.255

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Example
• As an example, RFC 1466 recommends that new class C addresses
in Europe be in the range 194.0.0.0 through 195.255.255.255.

• This represents 65536 different class C network IDs, but they all
share the same high-order 7 bits.

• In countries other than Europe a single routing table entry with an

IP address of 194.0.0.0 and a 32-bit mask of 254.0.0.0 could be
used to route all of these 65536 class C network IDs to a single
point.

• Subsequent bits of the class C address can also be allocated

hierarchically, European routers using additional bits beyond the 7
high-order bits of the 32-bit mask.

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Longest Prefix Match

• Routers do a prefix match.

– Does destination address fall in the range of
addresses captured by prefix?
• Prefix match works if Internet topology is a
tree
– Shortest path between networks is unique
• Internet is a graph
– Many networks multi-home
– Many matching prefixes

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Example
• perhaps one service provider in Europe needs to use a different
entry point router than the rest of Europe.

• If that provider has been allocated the block of addresses

194.0.16.0 through 194.0.31.255 (16 class C network IDs), routing
table entries for just those networks would have an IP address of
194.0.16.0 and a mask of 255.255.240.0

• A datagram being routed to the address 194.0.22.1 would match

both this routing table entry and the one for the rest of the
European class C networks.

• But since the mask 255.255.240 is "longer" than the mask

254.0.0.0, the routing table entry with the longer mask is selected.

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956

 Summary
• Class based addressing was found not to be
scalable

• Subnetting: Share a single class address among

multiple networks

• Supernetting: Share multiple class addresses on a

single network

• Lead to CIDR (classless addressing) and Longest

prefix match --- widely used now

BITS Pilani, Deemed to be University under Section 3 of UGC Act, 1956
